DECLARATION OF PERFORMANCE (DOP)
NO. . 90066600 CPR-20140821
1. Product Type: Freestanding stove Scan 66
2. Type, batch or serial number: Scan 66-2, Scan 66-3, Scan 66-4, Scan 66-5
3. Intended use of the product: Heat distribution/room heating
Without hot water supply
Fuel type: Wood
4. Name and Address of the manufacturer: Scan A/S
Glassvænget 3-9
5492 Vissenbjerg
5. Contact address: No relevance
6. AVC P
System(s) of assessment and verification of constancy
op performance (AVCP) of the construction product as
set out in CPR, Annex V
7. Notified body:
Test report no:
8. Declared performance
Harmonized technical specification EN 13240
Essential characteristics Performance
Fire safety Reaction to fire
Distance to combustible materials
Risk of burning fuel falling out
Emission of combustion products CO [0,029 %]
Surface temperature Pass
Electrical safety -
Cleanability Pass
Maximum water operating pressure -
Flue gas temperature at nominal heat output [EN] T [302°C]
Mechanical resistance (to carry a chimney/flue) NPD
Thermal output Normal heat output
Room heating output
Water heating output
Energy efficiency ŋ [78 %]
System 3
DTI
NB-No 1235
300-ELAB-2081-EN Rev. 1
A1
Minimum distances in mm:
Rear: 150
Sides: 300
Front: 850
NPD
NOx [85 mg/Nm
OGC [27 mg/Nm
Dust [27 mg/Nm
5 kW
3
]
3
]
3
]
DECLARATION:
The performance of the product identified in points 1 and 2 in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Signed on behalf of the manufacturer:
Ole Hansen (R&D LAB)
Vissenbjerg, Juni 29, 2016
(Place and date of issue) (Signatute)
DECLARATION OF PERFORMANCE (DOP)
NO. . 90066601 CPR-20140821
1. Product Type: Wall mounted stove SCAN 66
2. Type, batch or serial number: Scan 66-1
3. Intended use of the product: Heat distribution/room heating
Without hot water supply
Fuel type: Wood
4. Name and Address of the manufacturer: Scan A/S
Glassvænget 3-9
5492 Vissenbjerg
5. Contact address: No relevance
6. AVC P
System(s) of assessment and verification of constancy
op performance (AVCP) of the construction product as
set out in CPR, Annex V
7. Notified body:
Test report no:
8. Declared performance
Harmonized technical specification EN 13240
Essential characteristics Performance
Fire safety Reaction to fire
Distance to combustible materials
Risk of burning fuel falling out
Emission of combustion products CO [0,029 %]
Surface temperature Pass
Electrical safety -
Cleanability Pass
Maximum water operating pressure -
Flue gas temperature at nominal heat output [EN] T [302°C]
Mechanical resistance (to carry a chimney/flue) NPD
Thermal output Normal heat output
Room heating output
Water heating output
Energy efficiency ŋ [78 %]
System 3
DTI
NB-No 1235
300-ELAB-2081-EN Rev 1
A1
Minimum distances in mm:
Sides: 300
Front: 850
Floor: 310
NPD
NOx [85 mg/Nm
OGC [27 mg/Nm
Dust [27 mg/Nm
5 kW
3
]
3
]
3
]
DECLARATION:
The performance of the product identified in points 1 and 2 in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Signed on behalf of the manufacturer:
Ole Hansen (R&D LAB)
Vissenbjerg, Juni 29, 2016
(Place and date of issue) (Signatute)
