Scag MAG User Manual

OPERATOR'S MANUAL

MAGNUM III
MODEL MAG

FROM SERIAL NUMBER 70001 TO 79999

PART 03034

WARNING

FAILURE TO FOLLOW SAFE OPERATING PRACTICES

MAY RESULT IN SERIOUS INJURY.

* Keep all shields in place, especially the grass discharge chute.
* Before performing any maintenance or service, stop the machine and
remove the spark plug wire and ignition key.
* If a mechanism becomes clogged, stop the engine before cleaning.
* Keep hands, feet and clothing away from power-driven parts.
* Read this manual completely as well as other manuals that came

with your mower.

* Keep others off the tractor (only one person at a time).

REMEMBER - YOUR MOWER IS ONLY AS SAFE AS THE OPERATOR!

Hazard control and accident prevention are dependent upon the awareness,
concern, prudence, and proper training of the personnel involved in the
operation, transport, maintenance, and storage of the equipment.

This manual covers the operating instructions

and illustrated parts list for:

All MAG Machines

with a serial number of 27870001- 27879999

Always use the entire serial number listed on the serial number
tag when referring to this product.

Section 1

GENERAL INFORMATION

1.1 INTRODUCTION

Your mower was built to highest standards in the industry.
However, the prolonged life and maximum efficiency of
your mower depend on you following the operating,
maintenance and adjustment instructions in this manual.

If additional information or service is needed, contact your
Scag Power Equipment Dealer.

We encourage you to contact your dealer for repairs. All
Scag dealers are informed of the latest methods to service
this equipment and provide prompt and efficient service in
the field or at their service shop. They carry a full line of
Scag service parts.

USE OF OTHER THAN ORIGINAL SCAG
REPLACEMENT PARTS WILL VOID THE
WARRANTY.

When ordering parts, always give the model and serial
number of your tractor and cutting deck. The serial plates
are located where shown in Figure 1-1.

For pictorial clarity, some illustrations and Figures in this
manual may show shields, guards or plates open or removed.
Under no circumstances should your mower be operated
without these devices in place.

All information is based upon product information available
at time of approval for printing. Scag Power Equipment
reserves the right to make changes at any time
without notice and without incurring any obligation.

1.2 DIRECTION REFERENCE

The Right and Left, Front and Rear of the machine
are referenced from the operators right and left when seated
in the normal operating position and facing the
forward travel direction.

1.3 SERVICING THE ENGINE AND DRIVE
TRAIN COMPONENTS

The detail servicing and repair of the engine, hydraulic pump
and motors and gear boxes are not covered in this manual;
only routine maintenance and general service instructions
are provided. For service of these components during the
limited warranty period, it is important to contact your Scag
dealer or find a local authorized servicing agent of the
component manufacturer. Any unauthorized work done on
these components during the warranty period may void your
warranty.

Tractor Serial Number
Plate Location

Figure 1-1 Serial Plate Locations

Cutter Deck
Serial Number
Plate Location

1

SAFETY INFORMATION

2.1 INTRODUCTION

Your mower is only as safe as the operator. Carelessness or
operator error may result in serious bodily injury or death.
Hazard control and accident prevention are dependent upon
the awareness, concern, prudence, and proper training of
the personnel involved in the operation, transport,
maintenance and storage of the equipment. Make sure every
operator is properly trained and thoroughly familiar with
all the controls before operating the mower.

Section 2

The signal word DANGER denotes that an extremely
hazardous situation exists on or near the machine that could
result in high probability of death or irreparable injury if
proper precautions are not taken.

WARNING:

READ THIS OPERATORS MANUAL BEFORE
ATTEMPTING TO START YOUR MOWER.

A replacement manual is available from your authorized
Scag Service Dealer or by Contacting Scag Power
Equipment, Service Department at P.O. Box 152, Mayville,
WI 53050. There is nominal charge of $2.00 for each
manual. Please indicate the complete model and serial
number of your Scag product.

2.2 SIGNAL WORDS

This symbol means Attention! Become Alert! Your
Safety is Involved!" The symbol is used with the

following signal words to attract your attention to safety
messages found on the decals and throughout this manual.
The message that follows the symbol contains important
information about safety. To avoid injury and possible
death, carefully read the message! Be sure to fully
understand the causes of possible injury or death.

Signal Word:

It is a distinctive word on safety decals and throughout
this manual that alerts the viewer to the existence and
relative degree of the hazard.

The signal word WARNING denotes a hazard exists on
or near the machine that can result in injury or death if
proper precautions are not taken.

CAUTION:

The signal word CAUTION is a reminder of safety
practices on or near the machine that could result in personal
injury if proper precautions are not taken.

Your safety and the safety of others depend significantly
upon your knowledge and understanding of all correct
operating practices and procedures of this machine.

2.3 BEFORE OPERA TION
CONSIDERATIONS

1. NEVER allow children to operate this riding
mower. Do not allow adults to operate this machine
without proper instructions.

2. DO NOT mow when children and/or others are
present.

3. Clear the area to be mowed of objects that could be
picked up and thrown by the cutter blades.

4. DO NOT carry passengers.

5. DO NOT wear loose fitting clothing that could get
caught in moving parts. Do not operate the machine
wearing shorts; always wear adequate protective
clothing including long pants. Wearing safety glasses,
safety shoes and a helmet is advisable and is required
by some local ordinances and insurance regulations.

2

Section 2

6. Prolonged exposure to loud noise can cause hearing
impairment or loss. Operator hearing protection is
recommended, particularly for continuous operation of
the mower. Wear suitable hearing protection.

7. Keep the machine and attachments in good operating
condition. Keep all shields and safety devices in place.
If a shield, safety device or decal is defective or
damaged, repair or replace it before operating the

machine.

WARNING:

This machine is equipped with an interlock
system intended to protect the operator and
others from injury. This is accomplished by
preventing the engine from starting unless the
parking brake is applied and the blades are
disengaged. The system also shuts off the
engine if the operator removes his foot from
the interlock pedal with the mower running and
the parking brake not engaged. Never operate
equipment with the interlock system discon­nected or malfunctioning.

2.4 OPERATION CONSIDERATIONS

1. Know the function of all controls and how to stop
quickly.

2. Reduce speed and exercise extreme caution on slopes
and in sharp turns to prevent tipping or loss of control.
Be especially cautious when changing directions on
slopes.

WARNING:

DO NOT operate on steep slopes. To check a slope,
attempt to drive up it (with cutter deck down). If
machine can drive up the slope without the wheels
slipping, reduce speed and use extreme caution.
ALWAYS FOLLOW OSHA APPROVED OPERATION.

3. Do not stop or start suddenly. WHEN GOING
UPHILL OR DOWN HILL, MOW UP AND
DOWN THE FACE OF SLOPES, NEVER
ACROSS THE FACE.

8. Be sure interlock switches are functioning correctly
.

9. Fuel is flammable; handle with care.

10.Equipment must comply with the latest requirements
per ANSI J137 and/or ANSI S279 when driven on
public roads.

11.DO NOT operate without a chute deflector installed;
keep the deflector in lowest possible position.

12.Check the blade mounting bolts at frequent intervals
for proper tightness.

13.Make sure all hydraulic fluid connections are tight and
all hydraulic hoses and lines are in good condition
before starting the machine.

4. When using any attachment, never direct the discharge
of material toward bystanders nor allow anyone near
the machine while in operation.

5. Before attempting to start the engine, disengage power
to all attachments and engage the parking brake. DO
NOT depress the right foot pedal.

6. If the mower discharge ever plugs, shut off the engine,
remove the ignition key, and wait for all movement to
stop before removing the obstruction.

7. Be alert for holes, rocks, and roots in the terrain and
other hidden hazards. Keep away from any drop off.
Beware of overhead obstructions (low limbs, etc.),
underground obstacles (sprinklers, pipes, tree roots,
etc.). Cautiously enter a new area. Be alert for hidden
hazards.

8. Disengage power to mower before backing up. Do not
mow in reverse unless absolutely necessary and then
only after observation of the entire area behind the
mower.

3

Section 2

9. DO NOT turn sharply. Use care when backing up.

10.Use counterweights or wheel weights when suggested
in this manual.

11.Watch for traffic when crossing roads or operating
near roadways

.

12.Mow only in daylight or good artificial light.

13.Take all possible precautions when leaving the ma­chine unattended, such as disengaging the mower,
lowering the attachments, setting the parking brake,
stopping the engine, and removing the key.

14.Disengage power to the attachments when transport­ing or when not in use.

15.The machine and attachments should be stopped and
inspected for damage after striking a foreign object,
and damage should be repaired before restarting and
operating the machine.

16.DO NOT touch the engine or the muffler while the
engine is running or immediately after stopping. These
areas may be hot enough to cause a burn.

2.5 MAINTENANCE CONSIDERATIONS

1. Never make adjustments to the machine with the
engine running unless specifically instructed to do so.
If the engine is running, keep hands, feet, and clothing
away from moving parts.

2. Remove the key from the ignition switch to prevent
accidental starting of the engine when servicing or
adjusting the machine.

3. Keep all nuts, bolts and screws tight to ensure the
machine is in safe working condition. Check blade
mounting bolts frequently to be sure they are tight.

4. Do not change the engine governor settings or
overspeed the engine.

5. To reduce fire hazard, keep the engine free of grass,
leaves, excessive grease and dirt.

6. Hydraulic fluid is under high pressure. Keep body
and hands away from pin holes or nozzles that eject
hydraulic fluid under high pressure. Use only card­board or paper to search for leaks.

7. Hydraulic fluid under high pressure may have suffi­cient force to penetrate skin and cause serious injury.
If hydraulic fluid is injected into the skin it must be
surgically removed within a few hours by a doctor or
gangrene may result.

4

Section 2

2.6 SAFETY AND INSTRUCTIONAL DECALS

DANGER

SPINNING BLADE

KEEP CLEAR

CONTACT CAN INJURE

48071

WARNING

ROTATING BLADES AND BELTS

KEEP HANDS, FEET & CLOTHING CLEAR
KEEP ALL GUARDS IN PLACE
SHUT OFF ENGINE & DISENGAGE BLADE
CLUTCH BEFORE SERVICING
CLEAR AREA OF DEBRIS BEFORE MOWING
USE CAUTION IN DIRECTING DISCHARGE
KEEP BYSTANDERS, CHILDREN & PETS AWAY
READ INSTRUCTION MANUAL BEFORE OPERATING

DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING

KIT, OR ENTIRE GRASS CATCHER INSTALLED

481040

WARNING

INSTALL BELT COVER BEFORE

OPERATING MACHINE

READ OPERATOR'S MANUAL

481039

5

Section 3

3.1 ENGINE

SPECIFICATIONS

General Type ............................................................................. Heavy Duty Industrial/Commercial Diesel

Brand ......................................................................................... Kubota 28 HP Super 5 Series, Electric Start

Model ......................................................................................... D1105-B

Horsepower ................................................................................ SAE Gross Intermittent, 28 HP @ 3000 RPM

Type ........................................................................................... Horizontal Shaft, Water Cooled, 4-Cycle Diesel

Displacement ............................................................................. 1123 cc.

Low Idle..................................................................................... 850 - 950 RPM

Cylinders ................................................................................... 3

Order of Firing .......................................................................... 1-2-3

Direction of Rotation ................................................................. Counter-clockwise (Viewed From Flywheel End)

Fuel Injection Pump .................................................................. Bosch MD Type, Mini Pump

Injection Pressure ...................................................................... 1,991 psi

Injection Timing (Before T.D.C.) ............................................. 19°

Compression Ratio .................................................................... 23:1

Starting System ......................................................................... Electric Starting with Cell Starter, Glow Plug In Combustion

Chamber

Fuel ............................................................................................ Diesel Fuel No. 2 -D (ASTM D975)

Oil Type ..................................................................................... API Sandard, CD Grade or Better

Oil Filter .................................................................................... Full Flow Oil Filter Cartridge

Oil Capacity ............................................................................... 4 Quarts With Filter

Cooling Pressurized, Sealed Cooling System, 170° F Thermostat, Blade

Fan, Cooling Capacity 8 Quarts
Belts:

Alternator .............................................................................. See Engine Manual for Part Number

Fan......................................................................................... Scag Part Number - 481114

Electric Clutch ...................................................................... Scag Part Number - 481104

Hydraulic Pump .................................................................... Scag Part Number - 481103

3.2 ELECTRICAL

Battery ....................................................................................... 12 Volt

Charging System ....................................................................... Alternator

Charging Output ....................................................................... 12 Volt, 30 Amp

System Polarity .......................................................................... Negative Ground

Starter ........................................................................................ 12 Volt Electric Ring Gear Type, Key and Solenoid Operated

Interlock Switches ..................................................................... Left Foot Pedal, Blade Brake, and Parking Brake

Fuses .......................................................................................... Two (2) 30 Amp

3.3 TRACTOR

Drive Motors ............................................................................. 12 Cu. In. Cast Iron High Torque Motors

Steering ...................................................................................... Chain and Sprocket

Forward and Reverse Control ................................................... Pedal Operated Linkage Connected To The Hydraulic Pump

Parking Brake ............................................................................ Lever Actuated Linkage to Drum Brakes on Both Drive Wheel

Assemblies
Wheels:

(2) Front Caster .................................................................... 12 x 3.5

(2) Drive ............................................................................... 2 x 10.5 -12, 4-ply Pneumatic Tubeless, Radius Edge

(1) Rear ................................................................................ 18 x 8.50 -8 NHS

Fuel Tank ................................................................................... Seamless Polyethylene Tank; 8 Gallon Capacity

Tire Pressure:

Front Caster .......................................................................... 25 PSI

Drive..................................................................................... 15 PSI

Rear ...................................................................................... 15 PSI

6

Section 3

3.3 TRACTOR (CONT'D)

Seat ............................................................................................ Milsco Seat With Adjustment Lever For Forward and Back

Movement
Travel Speed:

Forward ................................................................................ 0 - 8 MPH Infinitely Variable

Reverse ................................................................................. 0 - 4.3 MPH Infinitely Variable

3.4 CUTTER DECK

No. of Blades ............................................................................. 3

Width of Cut:

Mag-61 ................................................................................. 61 in.

Mag-72 ................................................................................. 72 in.

Blade Size:

Mag-61 ................................................................................. 1/4 thick x 21" long, milled edge, 5150 alloy steel

Mag-72 ................................................................................. 1/4 thick x 24-1/2" long, milled edge, 5150 alloy steel

Blade Spindles ........................................................................... Cast Iron with Easy Removable Taper Hubs

Deck Drive................................................................................. Belt Driven Electric Clutch Connected to Drive Shaft to

Gearbox on Deck

Electric Clutch Type ................................................................. Warner Mag Stop Electric Clutch

Blade Brake ............................................................................... Lever Controlled Linkage to Band Type Brake. Brake Hub

Connected to Drive Shaft

Cutting Height ........................................................................... Switch on Instrument Panel Controls Electric Actuator;

Cutting Heights - 1-1/2" to 5-1/2"

Deck Tilt .................................................................................... Switch on Instrument Panel Controls Electric Actuator

Cutter Deck Belts:

Blade and Gearbox Drive (Mag-61) .................................... Scag Part Number - 48204

Blade and Gearbox Drive (Mag-72) .................................... Scag Part Number - 48089

Blade Drive (Mag-61) .......................................................... Scag Part Number - 48265

Blade Drive (Mag-72) .......................................................... Scag Part Number - 481295

Gearbox Type ............................................................................. Sealed Housing, Bevel Gear and Pinion Type

Drive Shaft ................................................................................ Quick-Disconnect Shaft With Two High Speed U-Joints

3.5 HYDRAULIC SYSTEM

Hydraulic Pump ......................................................................... Sunstrand Series 15

Hydraulic Cooler ....................................................................... Part of Radiator

Hydraulic Oil Filter ................................................................... 10 Micron Spin-on Element Type

Hydraulic Reservoir................................................................... High Density Polyethylene; 13 Quart Capacity

3.6 WEIGHTS AND DIMENSIONS

Length:

Mag-61 ................................................................................. 120.0"

Mag-72 ................................................................................. 120.0"

Tracking Width:

Mag-61 ................................................................................. 54.0"

Mag-72 ................................................................................. 54.0"

Overall Width:

Mag-61 ................................................................................. 73.0"

Mag-72 ................................................................................. 84.0"

Overall Width (with Discharge Chute Up):

Mag-61 ................................................................................. 62.0"

Mag-72 ................................................................................. 73.0"

Overall Height ........................................................................... 51.0"

Operating Weight:

Mag-61 ................................................................................. 1,750 lb.

Mag-72 ................................................................................. 1,800 lb.

7

OPERATING INSTRUCTIONS

CAUTION:

Do not attempt to drive this mower unless you
have read this manual. Learn the location and
purpose of all controls and instruments before
you operate this mower.

4.1 CONTROLS AND INSTRUMENT
IDENTIFICATION

Before operating the mower, familiarize yourself with all
mower and engine controls. Knowing the location, function
and operation of these controls is important for safe and
efficient operation of the mower.

A. Instrument Panel (See Figure 4-1)

1. Ignition Switch: The ignition switch is used to start
and stop the engine and has four positions; PREHEAT,
OFF, ON, and START. Rotate the key to the PRE­HEAT position to energize the glow plug. Hold the
key at the PREHEAT position until the yellow indica­tor light for the glow plug turns off, then release and
rotate the key to the START position.

Section 4

Do not hold the key in the START position longer than
15 seconds. If the engine does not start, return the key
to the OFF position for at least 60 seconds before a
restart attempt is made. Prolonged cranking can
damage the starter motor and shorten battery life.
Release the key when the engine starts and it will
automatically return to the run position. To stop the
engine, rotate the key counter-clockwise to the OFF
position.

2. Glow Plug Indicator Light: Yellow indicator turns
off when glow plugs have been properly energized
after the ignition switch is turned and held in the
PREHEAT position.

3. Hourmeter: Indicates the number of hours the engine
has been operated. It operates whenever the ignition
key is in the ON position. Can be used to keep track
of maintenance intervals and the amount of time
required to perform various tasks.

4. Voltmeter: Indicates the battery condition and charge
level.

7

Engine

Oil Pressure

Switch

Blade
Brake

Control

Lever

6

Hourmeter

Temperature Gauge

Mower

Deck Lift

Switch

Figure 4-1 Instrument Panel

5

Mower

Deck Height

Switch

8

6

Fuel Gauge

Voltmeter

9

4

Ignition

Switch

1

Throttle

Lever

Fuse

Holders

Glow Plug

Indicator

Light

10

2

8

Section 4

INTERLOCK

PEDAL

5. Temperature Gauge: Indicates engine coolant
temperatures. Green zone indicates proper working
temperature. Red zone indicates engine over heating
and the engine should be shut off immediately.

6. Fuel Gauge: Indicates the amount of fuel in the fuel
tank.

7. Engine Oil Pressure Indicator Light: Indicator will
light if oil pressure drops below a safe operating
pressure. Stop the engine immediately; determine the
cause and correct the problem before continuing
operation.

8. Mower Deck Lift Switch: This switch raises and
lowers the deck for road travel, etc. Pushing the
switch forward tilts the mower deck back. Pulling the
switch back tilts the deck forward.

Parking Brake

Lever

Forward/Reverse

Foot Pedal

Figure 4-2

C. Foot Pedals

9. Mower Deck Height Switch: This switch raises and
lowers the cutting height of the mower deck. An
indicator is located above the deck that gives the
cutting height setting. Pushing the switch forward
raises the deck cutting height. Pulling the switch back
lowers the deck cutting height.

10.Fuse Holders: Two 30 amp fuses protect the
mowers electrical system. To replace fuses, pull fuse
out of socket and install new fuse.

B. Levers

1. Blade Brake Control Lever (Figure 4-1): Used to
engage and disengage the mower blade brake. Pulling
the lever down and to the right engages the brake and
stops the blades from rotating. Pushing the lever up
and to the left disengages the brake, allowing blades to
rotate.

2. Throttle Lever (Figure 4-1): Regulates engine speed.
Push the lever forward to increase or pull the lever
backwards to decrease the engine speed.

3. Parking Brake Lever (Figure 4-2): Used to engage
and disengage the parking brakes. Pull the lever
backwards to engage the parking brake. Push the
lever forward to disengage the parking brake.

1. Forward/Reverse Foot Pedal (Figure 4-2): Used to
select the travel direction of the mower. Pressing the
pedal forward moves the mower in the forward
direction. Pressing the pedal backwards moves the
mower in the backward (reverse) direction.

2. Interlock Switch Pedal (Figure 4-3): Stops the
mower when operator's left foot in raised off the pedal.

Figure 4-3 Interlock Pedal

9

Section 4

4.2 SAFETY INTERLOCK SYSTEM

This mower is equipped with a safety system that prevents
the engine from starting unless the mower blade brake is
disengaged and parking brake is engaged. The system also
shuts the engine off if the operator's left foot is raised from
the interlock pedal with the mower and parking brakes
disengaged.

WARNING:

Never operate the mower with the interlock
system disconnected or malfunctioning. Do not
disconnect or bypass any switch; injury to
yourself and others or property damage could
result.

If the safety interlock system is malfunctioning or if you
want to ensure that it is working properly, perform the tests
in Table 4-1. Stop the test and have the system inspected
and repaired if:

4.3 INITIAL RUN-IN PROCEDURES (First
Day of Use or Approximately 10 Hours)

1. Check all belts for proper tension at 2, 4 and 8 hours;
adjust as needed.

2. Check the neutral adjustment. If necessary, adjust the
linkage so that the mower does not move when forward
and reverse pedal is in neutral (See Adjustments in
Section 6).

3. Check the tires for proper inflation (See Section 7-2).

4. Check for loose hardware. Tighten as needed.

5. Perform Interlock Tests in Table 4-1.

6. Apply lubricant to all machine grease fittings. See
Lubrication Chart in Section 7.2.

 the engine does not start in test 1, or

 the engine does start during tests 2 and 3, or

 the engine continues to run during tests 4 and 5.

Table 4-1 Interlock System Tests

Left Foot Parking Mower Engine
Lifted From Brake Blade Operates
Interlock Brake
Pedal

Test Yes No On Off On Off Yes No

1 - X X X X
2 X X X X
3 - X X X X
4 X X X X
5 X X X X

10

Section 4

4.4 DIESEL ENGINE BREAK-IN

The proper break-in of a new diesel engine can make a
difference in the performance and life of the engine. Perform
the following break-in procedure during the first 50 hours
of operation:

1. A new engine should be operated with as near full load
as possible. However, the engine must be allowed to
reach an operating temperature before operating at full
load conditions.

2. The engine oil should be checked twice daily. Higher
than normal oil consumption is not uncommon during
the initial break-in period.

3. Change the oil and filter element after the first 40
hours of operation.

4. Check all engine belts for proper tension after the first
10 hours of operation and adjust, if necessary. Refer
to Adjustments in Section 6.

4. Turn the ignition key switch to the PREHEAT position
until the indicator light for the glow plug glows bright
red. The colder the temperature, the longer it will take
to energize the glow plug. This step is not necessary
when starting a warm engine.

5. Turn the ignition key switch to START position and
release the key as soon as the engine starts. Do not
hold the key in the START position for more than 15
seconds at a time. Allow at least 60 seconds between
each cranking attempt to inhibit overheating the starter
motor. Prolonged cranking can damage the starter
motor and shorten battery life.

6. Allow engine to warm to operating temperature.

4.6 OPERATOR COMFORT ADJUSTMENTS

Two adjustments can be made to make your mowing job
comfortable. The steering handle can be adjusted up or
down and the seat can be adjusted forward or back.

5. During the break-in period, check and tighten all
engine hardware.

4.5 STARTING THE DIESEL ENGINE

CAUTION:

DO NOT USE STARTING FLUIDS. Use of starting
fluids in the air intake system may be potentially
explosive or cause “Runaway” engine condition
that could result in engine damage and/or
personal injury.

1. Be sure the fuel shut-off valve is completely open.
The valve is located in the fuel line between the fuel
tank and electric fuel pump (See Section 7).

2. Sit in the operators seat and depress the interlock foot
pedal with your left foot. Make sure the parking brake
and mower blade brake are engaged.

A. Adjusting Steering Handle Height

1. Remove the hardware securing the handle to the
steering shaft. Two sets of holes are available to
adjust the handle height.

Hardware

Second Bolt Hole

Figure 4-4 Steering Handle Adjustment

2. Move the handle to align with the other holes in the
steering shaft. Install the hardware and tighten.

3. Set throttle lever to 3/4 throttle.

11

Section 4

B. Seat Adjustment

1. Pull the handle on the left side of seat (Figure 4-5) and
move the seat either forward or back.

2. Release the handle to lock the position.

Figure 4-5 Seat Adjustment

4.7 ADJUSTING GROUND SPEED AND

DIRECTION

-NOTE-

If you are not familiar with the operation of
the hydrostatic drive, practice turning and ma­neuvering with the foot controls before engag­ing the blades. Learn the operation in an open
area away from buildings, fences, or obstruc­tions. Learn the operation on a flat ground
before operating on slopes. Start maneuver­ing with SLOW engine speed until you are fa­miliar with all operating characteristics. Prac­tice maneuvering the mower until you can
make it go exactly where you intend.

1. To travel forward, depress the right foot pedal at the
toe. (See Figure 4-6). The further the pedal is de­pressed the faster the mower will travel forward.

Figure 4-6 Forward - Depress Toe End of Pedal

-NOTE-

Before shifting from forward to reverse, or re­verse to forward, come to complete stop then
shift the foot pedal to the desired direction.

2. To travel backwards (reverse), depress the right foot
pedal at the heel (See Figure 4-7). The further the
pedal is depressed the faster the mower will travel
backwards. Use slower traveling speed when traveling
backwards and observe the area behind you before
moving.

-NOTE-

If the mower is driven on public roads, it must
comply with state and local ordinances as well
as SAE J137 and/or ASME S279 requirements.
Contact your local authorities for regulations
and equipment requirements.

-NOTE-

The left operator foot pedal must be depressed
before operation.

Figure 4-7 Backward (Reverse) Operation- Depress

Heel End of Pedal

12

Section 4

3. Check that all systems function correctly.

4. When traveling, the throttle control can be adjusted to
increase or decrease travel speed.

5. Reduce speed when turning around trees, shrubs, etc.

IMPORTANT:

Avoid high-speed turns on all surfaces. Tires
can slip on grass and can wear rapidly on
concrete and asphalt.

6. When going over curbs, first activate the mower deck
lift switch to fully raise the deck to clear the curb. Go
FORWARD over the curb.

4.8 ENGAGING THE MOWER

1. Set engine throttle about 1/2 speed. Do not attempt
to engage the blade at high engine speed as this

shortens the electric clutch life  use only moderate
engine speed when engaging the blades.

3. Always operate the engine at full throttle to
properly maintain cutting speeds. If the engine
starts to lug down, reduce the forward speed to
allow the engine to operate at maximum RPM.

4.9 HILLSIDE OPERATION

WARNING:

To minimize the possibility of overturning, the
least dangerous method of operating on hills
and terraces is to travel vertically up and down
the slope, not horizontally along the slope.
Avoid any unnecessary turns and travel at
reduced speed.

1. The mower has been designed for good traction and
stability under normal mowing conditions. However,
caution must be used when traveling on slopes,
especially when the grass is wet. Wet grass limits
traction and steering control.

2. Engage the mower blades by moving the blade brake
lever down and to the right.

WARNING:

A safety interlock switch (left foot pedal) will
cause the engine to stop if the blade brake
is disengaged, and the left foot pedal is not
depressed. The function of the switch
should be checked by the operator raising
his left foot and disengaging the blade
brake; the engine should stop. If the switch
is not working, it should be repaired or
replaced before operating the mower. Do
not disconnect the interlock safety switches
because they are for the operator’s protec­tion.

-IMPORTANT-

Do not engage the mower blades when
transporting the mower across drives, loose
materials, etc.

2. To inhibit tipping or loss of control, do not start or
stop suddenly, avoid unnecessary turns and travel at a
reduced speed.

3. Keep tires properly inflated.

4. Always travel up or down the slope, whenever pos­sible; NEVER across the slope.

5. If the mower cannot climb the slope, the grade is too
steep for safe operation. Do not make another attempt
to climb the slope. Engage the blade brake to stop the
blades and back down slowly.

13

Figure 4-8 Proper Operation on Slope

Section 4

-IMPORTANT-

If at all possible, do not engage the mower
brake with engine running at high speed, since
premature wear of the electric clutch will oc­cur. Lower speed to near idle then engage the
brake.

CAUTION:

The blade brake stops the blades from rotating.
If the blades do not stop, contact your Scag
Dealer.

CAUTION:

Remove the key from the ignition switch when
leaving the mower unattended to inhibit children
and inexperienced operators from starting the
engine.

Figure 4-9 Improper Operation on Slope

4.10 STOPPING

1. Slow engine speed to idle.

2. Place the right foot pedal in the center (neutral)
position.

3. Engage the blade brake.

4. Engage the parking brake and turn ignition key to OFF.

4.1 1 AFTER OPERA TION

1. Park the mower on a flat and level surface and fully
lower the cutting deck to the ground. Stop the engine
and engage the parking and blade brakes. Remove the
key from the ignition switch.

-IMPORTANT-

If the radiator dirt screen is not removed and
cleaned after every use, the screen will be­come clogged with grass clippings, etc., block­ing the air flow through the radiator. This
will cause a high engine operating tempera­ture that may cause damage to the engine.

2. Clean the radiator dirt screen. See Section 7 for
radiator dirt screen removal and cleaning instructions..

3. Wash the entire mower after each use. Do not use high
pressure spray or direct the spray onto electrical
components.

14

Section 4

-IMPORTANT-

Do not wash a hot or running engine. Use
compressed air to clean the engine and the
radiator fins. Cold water will damage the
engine and/or radiator.

4. Keep the entire mower clean to inhibit serious heat
damage to the engine or hydraulic oil circuit.

5. Recheck the cutter drive belts for proper tension,
alignment and any signs of rubbing. Correct and adjust
as necessary.

6. Fill the fuel tank with fresh, clean fuel at the end of
every day of operation.

7. Check the tire pressure. Inflate tires if necessary.

4.12 MOVING MOWER WITH THE ENGINE

STOPPED

To free-wheel or move the mower around without the
engine running, rotate the dump valve handle (screw and
nut) located on the side of the hydraulic pump to full open
position. See Figure 4-10. Disengage the parking brake
and move the mower by hand. The lever must be returned
to the original position to operate the mower.

4.13 RECOMMENDATIONS FOR MOWING

1. Keep the mower deck and discharge chute clean.

2. Mow with sharp blades. A dull blade will tear grass,
resulting in poor lawn appearance and takes extra
power (slow mowing speed).

3. The discharge deflector must not be removed and must
be kept in the lowest position to deflect grass clippings
and thrown objects downward. Orient the side dis­charge away from sidewalks or street to minimize
cleanup of clippings. When mowing close to obstacles,
orient the discharge away from obstacles to reduce the
chance of property damage by thrown objects.

4. Cut grass when it is dry and not too tall. Mow
frequently and do not cut grass too short (cut off 1/3
or less of existing grass for best appearance).

5. Operate the engine at or near full throttle for best
cutting. Mowing with a lower RPM causes the mower
to not cut clean and tear the grass. The engine is
designed to be operated at full speed.

6. Use slow travel speed for trimming purposes.

7. When mowing tall or wet grass, mow the grass twice.
Raise the mower to the highest setting for the first pass
and then make a second cutting pass to the desired
height.

Dump Valve

Handle

Close

Figure 4-10 Dump Valve Handle

8. Be sure the mower is leveled properly for a smooth
cut. See Section 7, Adjustments.

Open

9. Use alternate stripe mowing pattern for best appear­ance and vary the direction of the stripe each time the
grass is mowed to avoid wear patterns in the grass.

4.14 ADJUSTING CUTTING HEIGHT

The mower deck height switch on the instrument panel is
used to adjust the cutting height of the deck. Do not adjust
the cutting height while the mower is moving. Stop the
mower, then activate the deck height switch to position the
deck at the desired height. A gauge is located on the right
front of the mower (See Figure 4-11) for use in selecting
the proper cutting height.

15

1

2

3

4

Figure 4-11 Mower Cutting Height Gauge

Section 4

4.15 TILTING THE MOWER DECK

CAUTION:

Do not tilt the deck with the mower blades
rotating. Engage the blade brake before tilting
the deck. Bodily injury or damage to the mower
or property could result.

1. Stop the traveling movement of the mower and engage
the blade brake.

2. Use the deck tilt control switch on the instrument panel
to raise the deck.

3. Before lowering the deck, observe that there are no
objects under the deck. Remove any objects then,
activate the deck tilt switch to lower the deck.

16

Section 5

TROUBLESHOOTING CUTTING CONDITIONS

CONDITION

CAUSE

CURE

Stringers - Occasional Low engine RPM Run engine at full 3600 RPM
Blades of Uncut
Grass Ground speed too fast Slow speed to adjust for conditions

Wet grass Cut grass after it has dried out
Dull blades, incorrect sharpening Sharpen blades
Deck plugged, grass accumulation Clean underside of deck

Width of Deck

SGB020

Belts slipping Adjust belt tensions

Streaking - Strips of Dull, worn blades Sharpen blades
Uncut Grass in Cutting
Path Incorrect blade sharpening Sharpen blades

Low engine RPM Run engine at full 3600 RPM
Belt slipping Adjust belt tension
Deck plugged, grass accumulation Clean underside of deck
Ground speed too fast Slow speed to adjust for conditions
Wet grass Cut grass after it has dried out

Width of Deck

SGB018

Bent blades Replace blades

Streaking - Strips of Not enough overlapping Increase the overlap of each
Uncut Grass Between between rows pass
Cutting Paths

Width

of

Deck

SGB019

Width

of

Deck

17

TROUBLESHOOTING

Section 5

CONDITION

CAUSE

CURE

Uneven Cut on Flat Lift worn off of blade Replace blade
Ground - Wavy
High-Low Blade upside down Mount with cutting edge toward
Appearance, ground
Scalloped Cut, or
Rough Contour Deck plugged, grass accumulation Clean underside of deck

Too much blade angle (deck pitch) Adjust pitch and level
Deck mounted improperly See your authorized SCAG dealer
Bent spindle area See your authorized SCAG dealer
Dull blade Sharpen blade

Width of Deck

SGB020

Uneven Cut on Uneven ground May need to reduce ground speed,
Uneven Ground - raise cutting height, and/or change
Wavy Appearance, direction of cut
High-Low Scalloped
Cut, or Rough Contour

Width of Deck

SGB021

Sloping Ridge Across Tire pressures not equal Check and adjust tire pressure
Width of Cutting Path

Wheels uneven Check and adjust tire pressure
Deck mounted incorrectly See your authorized SCAG dealer

Width of Deck

SGB023

18

Section 5

TROUBLESHOOTING

CONDITION

CAUSE

CURE

Scalping - Blades Low tire pressures Check and adjust pressures
Hitting Dirt or
Cutting Very Close to Ground speed too fast Slow speed to adjust for conditions
the Ground

Cutting too low May need to reduce ground speed,

raise cutting height, change direction
of cut, and/or change pitch and level

Rough terrain May need to reduce ground speed,

raise cutting height, and/or change
direction of cut

Ground speed too fast Slow speed to adjust for conditions

Width of Deck

SGB022

Wet grass Cut grass after it has dried out

Step Cut Blades not mounted evenly Adjust pitch and level
Ridge in Center of
Cutting Path Bent blade Replace blade

Internal spindle failure See your authorized SCAG dealer
Mounting of spindle incorrect See your authorized SCAG dealer

Width of Deck

SGB024

Slope Cut - Sloping Bent spindle mounting area See your authorized SCAG dealer
Ridges Across Width
of Cutting Path Internal spindle failure See your authorized SCAG dealer

Bent deck housing See your authorized SCAG dealer

Width of Deck

SGB025

19

ADJUSTMENTS

Section 6

6.1 P ARKING BRAKE ADJUSTMENT

WARNING:

Do not operate the mower if the parking brake is
not operable. Possible severe injury could
result.

The parking brake linkage should be adjusted whenever the
parking brake lever is placed in the Engage position and
the parking brake will not hold the mower from moving. A
minor adjustment can be made at the control lever by
loosening the jam nut shown in Figure 6-1 and turning the
rod in a clockwise direction to tighten the linkage. Tighten
the jam nut.

If this adjustment does not hold the mower from moving or
no more thread is available on the rod, contact your Scag
dealer before operating the mower.

6.2 FORW ARD/REVERSE NEUTRAL

ADJUSTMENT

The forward/reverse linkage should be adjusted whenever
the mower will not stay stationary when the forward/reverse
(right) foot pedal is placed in the neutral position.

1. Set the engine deck on jack stands so the wheels are
free to rotate.

2. Block the caster wheels to prevent an accident should
the unit fall off the jacks.

3. Start the engine and observe for drive wheel
rotation.

If the wheels consistently rotate when the foot control
is in neutral, go to step 4.

If the drive wheels intermittently rotate, i.e. the drive
wheels sometimes rotate and sometimes do not when
the foot pedal is not depressed, then check the neutral
adjustment bolt for zero free play in the neutral control
spring.

Adjustment
Dimension

1/4"

Right Foot Pedal
Adjustment Nuts

Pump Drive
Adjustment Nut

Forward/Reverse
Neutral Adjustment
Nut

Parking Brake
Adjustment Nuts

Figure 6-1 Adjustments

20

Section 6

-NOTE-

If you turn the nut too much, you will com­press the spring, making too much end play.
Go to step 4.

4. If the drive wheels rotate in rearward travel direction,
turn the adjustment bolt (Figure 6-1) clockwise until
rotation stops. If the drive wheels rotate in the for­ward travel direction, turn the adjusting bolt counter­clockwise until rotation stops.

5. Check the adjustment of the right foot pedal for full
forward speed. The bottom of the foot pedal should be
1/4 inch from the top of the foot plate (See Figure 6-1)
when the pump is stroked in the full forward position.

To make an adjustment, loosen the jam nut at the
pump control bellcrank (Figure 6-1). Depress the foot
pedal and turn the control rod until 1/4 inch is obtained
between the bottom of the foot pedal and the top of the
foot plate. Tighten the jam nut.

6. Start the engine. The drive wheels should rotate only
when the forward/reverse foot pedal is depressed.

6.3 THROTTLE CONTROL LINKAGE

ADJUSTMENT

Should the throttle control lever not stay in
position after moving it to increase or decrease the
engine speed, the throttle linkage must be
tightened. Hold the lock nut (Figure 6-2) with a wrench
while turning the bolt clockwise to tighten the throttle lever
against the friction plate. Do not overtighten as the control
lever will be hard to move.

Locknut

Bolt

Figure 6-2 Throttle Control Adjustment

6.4 CUTTER BRAKE LINKAGE

The cutter brake linkage is self-adjusting. If the brake will
not hold the cutter blades from turning, consult your Scag
dealer. Do not operate the mower if the cutter brake is not
functioning properly.

6.5 FAN BELT ADJUSTMENT

1. Remove the pump belt guard to gain access to the fan
drive idler bracket.

2. Loosen the two bolts (A and B, Figure 6-3). Using a
3/8 inch ratchet wrench installed in hole C, rotate the
bracket until 1/2 inch deflection in the belt is observed
using 10 pounds of pressure on the belt. See Engine
Drive Belts, section 7.9 for checking method.

If the engine speed must be increased or decreased, consult
your Scag dealer.

21

A

B

C

Figure 6-3 Fan Belt Adjustment

Section 6

3. After proper tension is obtained, tighten the two bolts
and install the pump belt guard.

6.6 PUMP DRIVE BELT ADJUSTMENT

To adjust belt tension, turn the adjusting nut (Figure 6-1)
until 1/2 inch deflection in belt is obtained with 10 pounds
of pressure. See Engine Drive Belts, section 7.9 for checking
method.

6.7 ELECTRIC CLUTCH DRIVE BELT

ADJUSTMENT

To adjust the belt tension, turn the adjusting nut (Figure 6-

4) to obtain 1/2 inch belt deflection with 10 pounds of

pressure. See Engine Drive Belts, section 7.9 for checking
method.

Adjusting Bolt

Adjusting Bolt
Location

Figure 6-5 Alternator Belt Adjustment

6.9 CUTTER DRIVE BELT ADJUSTMENTS

1. Remove the top cutter deck cover.

Figure 6-4 Electric Clutch Drive Belt Adjustment

6.8 ALTERNATOR BELT ADJUSTMENT

To adjust the alternator belt tension, loosen the two bolts
holding the alternator (Figure 6-5). Move the alternator
until proper tension of 0.28 to 0.35 inch deflection with 22
pounds of pressure is obtained, then tighten the two bolts.
See Engine Drive Belts, section 7.9 for checking method.

2. Each belt has an adjustment rod attached to its belt
idler arm. To adjust the belt tension, turn the adjusting
nut (Figure 6-6) until 1/2 inch deflection in the belt is
obtained with 10 pounds of pressure. See Cutter Deck
Belts, section 7-10 for checking method.

Tension Adjusting Nuts

Figure 6-6 Blade Belt Tension Adjustments

(Mag-72 Deck Shown)

3. Replace the top cutter deck cover.

22

Section 6

6.10 BELT ALIGNMENT

Belt alignment is important for proper performance of your
Scag mower. If you experience frequent belt wear or
breakage, see your authorized Scag service dealer for belt
adjustment.

6.11 CUTTER DECK ADJUSTMENTS

Due to many conditions that exist, it is difficult to suggest a
setting that will work for every lawn. However, two
adjustments should be made on the cutter deck to ensure
proper grass cutting: DECK LEVEL AND PITCH.

-NOTE-

Before checking for proper cutter deck adjust­ments, check that all tires are inflated to the
correct pressure.

DECK LEVEL is the adjustment to level the deck side-to­side. For proper blade cutting, the deck should be level.
To check for level, place the mower on a flat, level surface.
On the right side of the deck, measure from the ground to
the bottom of the cutter deck (Figure 6-7). Then, take a
measurement on the left side of the deck. Both measurements
should be equal. If different, adjust the deck to level.

To level the deck, loosen the adjusting nut (Figure 6-8) and
lift or lower the deck until the left side measurement equals
the right side measurement. Tighten the adjusting nut.

Adjusting Nut

Figure 6-8 Leveling the Cutter Deck

PITCH is the adjustment to angle the blades from rear to
front. For proper grass cutting, the blades should be angled
forward. To check proper blade pitch, place the mower on
a flat, level surface. Measure the distance from the ground
to the rear of the mower deck ("X", Figure 6-9). Then,
measure on both sides of the mower deck the distance from
the ground to the front of the deck ("Y"). The front should
be 1/4 inch lower than the rear. If not correct, adjust the
pitch.

Figure 6-7 Measuring Height of Deck

= " Y "

Figure 6-9 Pitch Measurement

1. To adjust the pitch, loosen the jam nut on both
adjusting rods (See Figure 6-10).

23

23

" X " =

2. Turn the adjusting rods counter-clockwise to lower the
front of the deck and clockwise to raise the front of the
deck. When a difference of 1/4 inch from front to rear
is obtained on left and right, tighten both jam nuts.

Adjusting Nut

Jam Nut

Section 6

1

2

3

4

Adjusting Rod

Figure 6-10 Adjusting Deck Pitch

6.12 BLADE CUTTING HEIGHT

ADJUSTMENT

The blade cutting height is adjusted by actuating the deck
height switch on the instrument panel. However, if the
cutting height compared to what is shown on the cutting
height gauge (See Figure 6-12) is in question, the cutting
height should be checked. To check the cutting height, lift
the discharge chute and measure from the ground to the
cutting edge of the blade (See Figure 6-11). If the
measurement is different from what is registered on the
gauge, adjust the gauge rod to the proper setting.

Blade

Tape Measure

Figure 6-11 Measuring Cutting Edge Height

Loosen the two jam nuts on the gauge rod (See Figure
6-12). Slide the gauge rod to the proper setting on the height
gauge. Tighten the jam nuts.

Adjusting
Nuts

Height
Indicator Rod

Figure 6-12 Adjusting Nuts

24

24

MAG-61, MAG-72 CUTTER DECK

58

68

2

55

56

41

54

69

70

32

68

71

53

32

12

67

74

29
24

16

57

63

38

10

25

12

23
25

24

7

22

3

2

26

20

13

21

61

39

72

18

27

60

10

19

1
3

4

8
9

9

24

65

16

37

64

59

53
41

58

2

54

55

56

11

12

14
13

15
16

17

41

1

3
2
4

5

73

53

24

2

55

56

41

35

54

34

33
35

6

36

40

46

74

31

32

42

43

44

45
47

48
49

44

50
51

52

1
2

4
5

12

28

16

24
64

16

62

58

40

390S0111

MAG-61, MAG-72 CUTTER DECK

Ref. Part. Mag Mag
No. Number Description 61 72

1 04020-09 Nut, Hex, 5/8-11 X X
2 43278 Spacer, Cutter Blade X X
3 04001-01 Bolt, Hex Head, 1/4-20 x 3/4 Gr .5 X X
4 48926 Taper Hub , 1.125 Bore X X
5 48924 Pulley , 5.75 Dia. X X
6 48753 Pulley , 6.35 Dia. X

48924 Pulley , 5.75 Dia. X
7 48923 Pulley , 5.75 Double Groove X X
8 04050-05 Retaining Ring, .75 Ext "E" X X
9 48100-02 Bushing, Oilite - 1.125 ID X X
10 48114-04 Grease Fitting X X
1 1 46866 Arm, Idler (Includes 9 & 10) X X
12 04021-09 Locknut, Elastic Stop, 3/8-16 X X
13 04041-12 Flat Washer, 3/8 (.375 x 1.50 x .060) X X
14 43277 Spacer, J-Hook X X
15 48269 Pulley , Idler X X
16 04041-07 Flatwasher, 3/8 (.391 x .938 x .105) X X
17 04001-54 Bolt, Hex Head, 3/8-16 x 3 X X
18 45720 Pivot, Idler Arm X X
19 44107 J-Hook X X
20 43077 Spacer, J-Hook X X
21 04001-46 Bolt, Hex Head, 3/8-16 x 2-1/4 X X
22 45037 Idler Pivot X X
23 04041-08 Flatwasher, 3/4 (.776 x 1.25 x .059) X X

04041-08S Flatwasher, 3/4 (.776 x 1.25 x .035) X X
24 04019-03 Serr. Fl. He x Nut, 5/16-18 X X
25 48100-05 Bushing, Oilite - 3/4 ID X X
26 46081 Idler Arm (Includes 10 & 25) X X
27 04001-19 Bolt, Hex Head, 3/8-16 x 1 X X
28 04050-02 Retaining Ring, .75 Ext "E" X X
29 43028 Pull Rod, Idler X

44078 Pull Rod, Idler X
30 45816 Belt Cover, RH X

45818 Belt Cover, RH X
31 45815 Belt Cover , LH X

45817 Belt Cover , LH X
32 04029-03 Wingnut, Plastic, 3/8-16 X X
33 481214 Gearbox, Deck Drive X X
34 481213 Drive Shaft X X
35 04063-01 Key, 1/4 x 1/4 x 1-1/4 X X
36 04001-109 Bolt, Hex Head, 1/4-20 x 1-3/8

(Full Thread) X X
37 48141 Tapered Hub , 1.00 Bore X X
38 48265 Belt, Cutter Deck X

481295 Belt, Cutter Deck X

39 48204 Belt, Cutter Deck X

48089 Belt, Cutter Deck X

Ref. Part Mag Mag
No. Number Descripton 61 72

40 46867 Cutter Deck with Decals X

46868 Cutter Deck with Decals X
41 46631 Spindle Assembly X X
42 43298 Shaft, Cutter Spindle X X
43 481024 Seal, 2.00 OD x 1.50 Bore X X
44 481022 Bearing Assembly X X
45 48114-04 Grease Fitting X X
46 48677 Relief Fitting, Cutter Spindle X X
47 43294 Spindle Housing X X
48 43312 Spacer, Outside X X
49 43296 Spacer, Inside X X
50 481025 Seal, 2.00 OD x 1.625 OD X X
51 43297 Spindle Bushing, Bottom X X
52 481035 Nut, 1-1/16-18 UNEF-2B X X
53 04063-08 Key, 1/4 x 1/4 x 2 X X
54 481159 Blade, 21" X

481160 Blade, 24-1/2" X
55 04040-10 Washer, 5/8 (.688 x 1.75 x .134) X X
56 04001-41 Bolt, Hex Head, 5/8-11x 9-1/2 Gr.5 X X
57 48038 Roller X X
58 04001-10 Bolt, Hex Head, 5/16-18 x 1-1/4 X X
59 04001-08 Bolt, Hex Head, 5/16-18 x 3/4 X X
60 04030-03 Lockwasher, 5/16 X X
61 04040-15 Flatwasher, 5/16 (.375 x .875 x .083) X X
62 45046 Shaft, Roller X X
63 421820 Cover, Belt - Front X X
64 04017-16 Serr. Fl Hex Head Capscre w,

5/16-18 x 3/4 X X
65 04030-04 Lockwasher, 3/8 X X
66 04001-19 Bolt, Hex Head, 3/8-16 x 1 Gr.5 X X
67 04001-09 Bolt, Hex Head, 5/16-18 x 1.0 X X
68 04021-10 Hex Locknut, Elastic Stop, 5/16-18 X X
69 481050 Spring, Discharge Chute X X
70 46726 Discharge Chute X X
71 04001-108 Bolt, Hex Head, 5/16-18 x 4-1/4 X X
72 48181 Pulley , Idler X X
73 04012-06 Set Screw, Hex Socket, 3/8-16 x 1/2 X X
74 48098 Spindle Shield X X

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.

41

MAG-61, MAG-72 DECK SUPPORT

46
45

49

43

44

74

47

62

13

61

48

2

4

5

6

5

44

63

1

67

52
67

52

2

3

23

39

42

41

49

65

39

54

58

69

39

57

70

47

68

48

33

67

66

47

51

50

36

67

65
64

59

8

41

42

23

39

57

60

43

35

27

48

72

47

29

49
43

71

37

42

41

45

23

38

44

46

36

38
26
25

23

40

23

34

12

22

13

26

11

10

23

12

56

53

5

8
24

12

15

11
23

8
55
56

5

16

3

17
18

21

22

61

12

19
20

21

14

73

13

12

17

11

7

9
10
11

12

75

28

32

31

30

29 27

390S0112

42

MAG-61, MAG-72 CUTTER DECK SUPPORT

Ref. Part Mag Mag
No. Number Description 61 72

1 45733 Cover, Belt X X
2 04029-03 Wingnut, Plastic, 3/8-16 X X
3 04001-52 Bolt, Hex Head, 1/2-13 x 2-1/2 X X
4 481195 Actuator, Deck Lift X X
5 04019-06 Serr. Fl. Hex Nut, 1/2-13 X X
6 04050-05 Retaining Ring, 1.125 Ext X X
7 43356 Pin, Deck support Mounting X X
8 04050-08 Retaining Ring, 1.00 Ext "E" X X
9 45728 Lift Bellcrank, LH Rear X X
10 421878 Link, Deck Support X X
1 1 04001-117 Bolt, Hex Head, 7/16-14 x 1-3/4 X X
12 04019-05 Serr. Fl. Hex Nut, 7/16-14 X X
13 04063-19 Key, 1/4 x 1/4 x 3/4 X X
14 481215 Spring, Deck Lift X X
15 421838 Anchor, Deck Spring X X
16 04001-119 Bolt, Hex Head, 5/8-11 x 5-1/2 X X
17 04017-16 Serr. Fl. Hex Head CPSCR,

5/16-18 x 3/4 X X
18 422027 Retainer, Spring X X
19 04020-21 Hex Nut, 3/4-16 X X
20 46865 Push Rod Assy (Includes 19, 21, 23,

53) X X
21 48100-06 Bushing, Olite - 3/4 ID X X
22 04019-03 Serr. Fl. Hex Nut, 5/16-18 X X
23 48114-04 Grease Fitting X X
24 45727 Lift Bellcrank, Front X X
25 45722 Tube, LH Caster (Shown) X

45724 Tube, LH Caster (Shown) X
45723 Tube, RH Caster (Not Shown) X

45725 Tube, RH Caster (Not Shown) X
26 48100-08 Bushing, Olite - 1.00 ID X X
27 43041 Spacer X X
28 48537 Wheel Assembly, Caster (includes

29, 30, 31, 32) X X
29 48006-07 Retainer X X
30 48006-06 Bearing, Roller X X
31 48537-03 Rim X X
32 48537-02 Tire X X
33 04012-04 Setscrew, Hex Socket, 5/16-18 x .75X X
34 43022 Sleeve, Caster Wheel X X
35 04001-80 Bolt, Hex Head, 1/2-13 x 6-1/2 X X
36 04021-07 Hex Locknut, Elastic Stop, 1/2-13 X X
37 46869 Frame, Deck Support (Includes 23,

38,39, 74) X X

Ref. Part Mag Mag
No. Number Description 61 72

38 48100-02 Bushing, Olite - 1-1/8 ID X X
39 48100-08 Bushing, Olite - 1.00 ID X X
40 04021-13 Hex Locknut, Elastic Stop, 5/8-11 X X
41 04042-05 Flatwasher, 1" (1.062 x 1.75 x .10) X X

04041-14 Flatwasher, 1" (1.062 x 1.50 x .048) X X
42 43353 Spacer X X
43 04001-45 Bolt, Hex Head, 3/8-16 x 2 X X
44 04021-09 Hex Locknut, Elastic Stop, 3/8-16 X X
45 04020-09 Hex Nut, 5/8-11 X X
46 43270 Swivel Joint, RH X X
47 04040-09 Flatwasher, 5/8 (.656 x 1.312 x .095) X X
48 04050-01 Retaining Ring, 5/8 Ext "E" X X
49 45731 Lever, Deck Lift X X
50 43271 Swivel Joint, LH X X
51 04064-11 Pin, Clevis, 1/2 x 2.25 X X
52 04044-01 Flatwasher, Nylon, 1" (.54 x 1.125

x 25) X X
53 481217 Rod End, Male, 3/4-16 RH X X
54 04001-120 Bolt, Hex Head, 3/4-16 x 3 X X
55 04021-14 Hex Locknut, Elastic Stop, 3/4-16 X X
56 43352 Spacer X X
57 04020-04 Hex Nut, 3/8-16 X X
58 43357 Swivel Joint, LH X X
59 44113 Rod, Height Indicator X X
60 04004-15 Stud, Mower Lift X X
61 04063-01 Key, 1/4 x 1/4 x 1-1/4 X X
62 45729 Lift, Bellcrank, RH Rear X X
63 04062-01 Cotter Pin, Hair - 0.94 x 1.62 X X
64 481216 Actuator, Cutting Height X X
65 421834 Link, Deck Travel Limit X X
66 04001-118 Bolt, Hex Head, 1/2-13 x 4-3/4 X X
67 04040-07 Flatwasher, 1/2 (.531 x 1.06 x .095) X X
68 45730 Lever, Bellcrank Actuation X X
69 04001-72 Bolt, Hex Head, 1/2-13 x 2 X X
70 04020-07 Hex Nut, 1/2-13 X X
71 45325 Y oke, Caster Wheel X X
72 04066-01 Quick Pin X X
73 45332 Shaft, Push Rod X X
74 481331 Decal, Cutting Height X X
75 481379 Cover, Spring X X

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.

43

RIDER FRAME

60

55

50

47

46
43

42

49

48

6

46

33

8

7

38

9

51

10

11

58

10

12

36

32

34

13

14

35

16

59

15

17

20

1

2

54

5

4

4

3

48

45

44

56

3

57

41

46

41

40

53
52

37

38

61

18

18

19

39

44

30

16

29

28

27

22

26

31

25

24

21

23

390S0113

RIDER FRAME

Ref. Part
No. Number Description

1 46029 Handle, Steering (Includes 2)
2 48159 Handle Grip
3 04021-10 Hex Locknut, Elastic Stop, 5/16-18
4 04040-15 Flatwasher, 5/16 (.375 x .875 x .083)
5 04001-12 Bolt, Hex Head, 5/16-18 x 1.75
6 481156 Seat (with Adjuster Rails)
7 421976 Plate, Seat Mount
8 04003-11 Carriage Bolt, 3/8-16 x 1-1/4
9 04050-05 Retaining Ring - 1.125 Ext
10 48100-02 Bushing, Oilite - 1-1/8 ID
1 1 46870 Frame, Steering
12 04001-83 Bolt, Hex Head, 7/16-14 x 3-1/2
13 45606 Pedal, Foot Interlock
14 481056 Spring, Foot Interlock Switch
15 45698 Pivot, Rear Yoke
16 481154 Connector Link, #50 Chain
17 43329 Anchor Bolt, Chain
18 04020-12 Nut, Jam, 3/8-16
19 45794 Yoke, Rear
20 04021-13 Hex Locknut, Elastic Stop, 5/8-11
21 43020-05 Spacer, Rear Wheel
22 481345 Rear Wheel Assembly (Includes 23-29)
23 48005-06 Seal, Grease
24 48005-05 Bearing Cone
25 48005-04 Bearing Cup
26 48114-06 Grease Fitting
27 48005-03 Rim (Includes 23, 24, 25 & 26)
28 481345-02 Tire
29 43398 Sleeve, Rear Tire
30 43020-06 Spacer, Rear Wheel
31 04001-91 Bolt, Hex Head, 7/16-14 x 2-1/2
32 04001-115 Bolt, Hex Head, 5/8-11 x 11-1/4
33 481476 Switch, Foot Interlock

Ref. Part
No. Number Description

34 04021-08 Hex Locknut, Elastic Stop, 1/4-20
35 04017-17 Serr. Fl. Hex Head Capscrew, 5/16-18 x 1.00
36 04010-17 Screw, Flat Hed, #10-32 x 3/4
37 45699 Footplate, LH
38 04019-03 Serr. Fl. He x Nut, 5/16-18
39 481152 Chain, Steering - #50
40 45696 Shaft, Steering
41 48100-01 Bushing, Bronze - .877 ID
42 04003-18 Carriage Bolt, 1/2-13 x 1-3/4
43 421784 Pad, Reinforcement
44 04019-06 Serr. Fl. Hex Nut, 1/2-13
45 45502 Foot Pedal
46 48114-04 Grease Fitting
47 46880 Footplate, RH
48 48100-06 Bushing, Oilite - 3/4 ID
49 45506 Foot Pedal Arm
50 04065-01 Pin, Drive Lock, 3/16 x 1-1/4
51 04019-04 Serr. Fl. Hex Nut, 3/8-16
52 42366 Reinforcement, Spring
53 42026 Spring, Seat Support
54 04021-11 Hex Locknut, Elastic Stop, 7/16-14
55 04003-12 Carriage Bolt, 5/16-18 x 3/4
56 421988 Retainer, Bolt
57 04050-03 Retaining Ring, 7/8 Ext
58 421755 Guide, T op Chain
59 421757 Divider, Chain Spacer
60 481480 Armrest Assembly
61 481158 T rack Set, Seat

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

45

ENGINE DECK

43
51

42

18

41

44

17

52

53

16

37

54

17

15

39

50

45

37

14

17 56

29

40

17

37

47

36

46

1

756

57

51

48

11

49

12

13

63

A

19

34

33

30

38 10

68

71

15

32

31

35

8

9

59

64

B

65

14

67

65

16

390S0114

61

64

37

17

6

66
58

27

2

3

4

5

58

61

60

A

B

63

70

14

62

17

18

14

19

20

69

21

24

25

28

26

55

22

23

46

ENGINE DECK

Ref. Part
No. Number Description

1 422002 Catch, Hood Latch
2 04010-01 Screw, Round Head W asher, #10-32 x 1/2
3 481309 Latch, Hood
4 04020-01 Hex Nut, #10-32
5 421801 Stiffener, Hood
6 * Engine, Kubota, 28 HP Diesel
7 422236 Hood
8 421802 Mounting Plate, Engine
9 04030-05 Lockwasher, 7/16
10 04002-10 Bolt, Hex Head, M10 - 1.25 x 25
1 1 04021-11 Hex Locknut, Elastic Stop, 7/16-14
12 04020-07 Hex Nut, 1/2-13
13 04030-06 Lockwasher, 1/2
14 04019-06 Serr. Fl. Hex Nut, 1/2-13
15 04017-38 Serr. Fl. Hex Head Capscrew, 1/2-13 x 1-1/2
16 421782 Stop, Cutter Deck
17 04019-03 Serr. Fl. Hex Nut, 5/16-18
18 421806 Anchor, Deck Spring
19 04001-52 Bolt, Hex Head, 1/2-13 x 2-1/2
20 04017-16 Serr. Fl. Hex Head Capscrew, 5/16-18 x 3/4
21 422027 Retainer, Spring
22 48680 Castle Nut, 1.0-20 UNEF
23 04028-01 Nut, Wheel
24 481205 Wheel Assembly (Includes 25, 26)
25 481205-02 Tire, 23 x 1050 -12, 4-ply
26 481205-03 Rim
27 46825 Hub, Wheel (includes 28)
28 04008-01 Bolt, Hub
29 04040-15 Flat Washer, 5/16 (.375 x .875 x .083)
30 48461 Parking Brake Assembly (Includes 31, 32,

33, 34)
31 48461-02 Brake Pads - Pair
32 48461-03 Springs - Pair
33 48461-05 Clip
34 48461-04 Actuating Arm
35 48769 Motor, Hydraulic - White (Includes 22)

Ref. Part
No. Number Description

36 04001-28 Bolt, Hex Head, 7/16-14 x 1-1/4
37 04003-12 Carriage Bolt, 5/16-18 x 3/4
38 43394 Stud, Metric
39 48205 Pad, Rubber
40 04021-10 Nex Locknut, Elastic Stop, 5/16-18
41 421798 Battery Box
42 481177 Battery
43 421799 Hold Down, Battery
44 04003-20 Carriage Bolt, 5/16-18 x 10
45 421781 Support Bracket, Hydraulic T ank
46 48711 Hydraulic Tank
47 481164 Cap, Hydraulic T ank
48 421288 Strap, Hydraulic Tank
49 04017-05 Serr. Fl. Hex Head Capscrew, 1/4-20 x 3/4
50 04021-08 Hex Locknut, Elastic Stop, 1/4-20
51 04003-14 Carriage Bolt, 5/16-18- 1/2
52 481165 Hinge
53 421783 Plate, Hinge
54 45862 Engine Deck
55 04061-04 Pin, Cotter, 5/32 x 1-1/2
56 481284 Bumper, Rubber
57 04019-03 Nut, 5/16-18 Serrated Flange
58 481440 Adapter, Remote Oil Filter
59 481441 Gasket, Oil Filter Adapter
60 481442 MTG Bolt, Filter Adapter
61 48603-04 O- Ring
62 481443 Reducer, Remote Filter
63 481444 Hose Assy ., Remote Filter
64 481445 Hose Assy ., Remote Filter
65 481446-01 Connector, 1/2 Pipe x 3/4 JIC
66 481447 Nut, 7/8 - 14
67 481457 Spring Filter Adapter
68 48572-08 Tube Union, 7/8-14 JIC x O-Ring
69 422239 Guard Oil Filter
70 * Oil Filter, Engine
71 04001-01 Bolt, 1/4-20 X .75 Hex Head

*Available through the engine manu facturer only .

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

47

RADIATOR/OIL COOLER

1

2

31

3

7

2

30

4

29

27

6

528

8

9

11

24

20

23

10

26

25

2

19

16
18

13

14

15
16

17

23

24

11

12

22

21

390S0115

48

RADIATOR/OILCOOLER

Ref. Part
No. Number Description

1 481207 Hose, Upper Radiator
2 48136-06 Clamp, Hose
3 45783 Shroud, Fan
4 04019-03 Serr. Fl. He x Nut, 5/16-18
5 * Tank, Coolant Ov erflow
6 422192 Mounting Bracket, Coolant Tank
7 04003-12 Carrage Bolt, 5/16-18 x .75
8 481286 Radiator with Oil Cooler
9 45784 Frame, Debris Screen
10 45785 Screen. Debris
1 1 04001-06 Bolt, Hex Head, 1/4-20 X 5/8
12 422010 Side Rail, Debris Screen
13 421992 Bracket, Radiator Mounting
14 04003-11 Carriage Bolt, 3/8-16 x 1-1/4
15 * Cushion, Radiator Mounting
16 * W asher, Radiator Mounting
17 04021-05 Locknut, 3/8-16
18 * Cushion, Radiator Mounting
19 481302 Drain Cock
20 481206 Hose, Lower Radiator
21 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
22 04021-09 Hex Locknut, Elastic Stop, 3/8-16
23 04040-14 Flatwasher, 1/4 (.312 X .75 X .065)
24 04030-02 Lockwasher, 1/4
25 48576-03 Coupling, 1/4 NPT
26 481383-01 Nipple, 1/4 NPT x 2.0
27 422194 Strap, Coolant Bottle
28 04001-44 Bolt, Hex Head, 1/4-20 x .50
29 04001-59 Bolt, Hex Head, 1/4-20 x 1.25
30 04019-02 Serr. Fl. Hex Nut, 1/4-20
31 04021-08 Hex Locknut, Elastic Stop, 1/4-20

* Availab le only through the engine manufacturer .

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

49

MUFFLER AND AIR CLEANER

4

3

19

20

10

11

1

9

2 1

5

6

7
8

16

15

14

15

15

14

13

1512

18

17

390S0116

50

MUFFLER AND AIR CLEANER

Ref. Part
No. Number Description

1 48136-08 Hose Clamp
2 481191 Hose, Air Intake
3 481333 Cap. Precleaner
4 04100-03 U-Bolt
5 481192 Air Cleaner
6 421981 Mounting Bracket, Air Cleaner
7 04030-03 Lockwasher, 5/16
8 04020-03 Nut, Hex, 5/16-18
9 * Gasket, Manifold
10 481340 Adapter, Manifold
1 1 04015-07 Capscrew, Socket Head, M8-1.125 x 20
12 422029 Brace, Muffler Suport
13 04001-09 Bolt, Hex Head, 5/16-18 x 1
14 04003-12 Carriage Bolt, 5/16-18 x 3/4
15 04019-03 Serr. Fl. Hex Nut, 5/16-18
16 421983 Bracket, Muffler Support
17 481439 Muffler
18 48633 Clamp, Exhaust Pipe
19 422254 Muffler Guard
20 04011-08 Screw, 10-32 x .50 Type F HH

*Available only through the engine manu facturer .

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

51

35

36

37

DECK DRIVE SYSTEM

31

25

51

22

27

28

23

23

18

19

20

21

24

38

39

24

41

43

40

34

48

42

15

16

14

47

8

13

12

10

30

33

46

50

9

5

46

4

11

9

32

50
17

27

28

44

49

29

26

45

3

2

1

52

8

7

6

390S0117

DECK DRIVE SYSTEM

Ref. Part
No. Number Description

1 04001-101 Bolt, Hex Head, 7/16-20 x 2-1/2
2 04030-05 Lockwasher, 7/16
3 481204 Clutch, Electric
4 481104 Belt, Deck Drive
5 46827 Spindle, Deck Drive (Includes 6 thru 16)
6 43321 Shaft, Deck Drive
7 481024 Seal, 2.00 O.D. 1-1/2 Bore
8 481022 Roller Bearing (Replace as a set only)
9 48114-04 Grease Fitting
10 43294 Housing, Spindle
1 1 48677 Relief Fitting
12 43296 Spacer, Outside
13 43312 Spacer, Inside
14 481025 Seal, 2.00 O.D. x 1-5/8 Bore
15 43297 Spindle Bushing, Bottom
16 481112 Nut, 1-1/16-18
17 04063-21 Key, #807 Woodruff, 1/4 x 7/8
18 04002-13 Bolt, Hex Head, M8-1.25 x 40
19 43428 Base, Anti-Rotation-Clutch
20 481469 Isolator, Rubber
21 04020-03 Nut, Hex, 5/16-18
22 04040-15 Flatwasher, 5/16 (.375 x .875 x .083)
23 04030-03 Lockwasher, 5/16
24 04019-03 Serr. Fl. Hex Nut, 5/16 - 18
25 45873 Anchor Bracket, J-Bolt
26 04001-46 Bolt, Hex Head, 3/8-16 x 2-1/4

Ref. Part
No. Number Description

27 04021-09 Hex Locknut, Elastic Stop, 3/8-16
28 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
29 48181 Pulley , Idler
30 43028 Rod, J-Hook
31 43336 Spacer
32 46871 Idler Arm, Clutch
33 45212 Bracket, Idler Pivot
34 04017-16 Serr. Fl. Hex Head Capscrew, 5/16-18 x 3/4
35 43330 Hub, Brake
36 04001-10 Bolt, Hex Head, 5/16-18 x 1-1/4
37 04017-19 Serr. Fl. Hex Head Capscrew, 5/16-18 x 1-1/2
38 45792 Belt Guard, Electric Clutch
39 422018 Brace, Fan Support - LH
40 45712 Upright, Fan Support - LH
41 04017-27 Serr. Fl. He x Head Capscrew, 3/8-16 x 1
42 04003-12 Carriage Bolt, 5/16-18 x 3/4
43 04019-06 Serr. Fl. Hex Nut, 1/2-13
44 43282 Spacer, J Pull Rod
45 04050-02 Retaining Ring, .75 Ext
46 04019-03 Serr. Fl. He x Nut, 5/16-18
47 04003-19 Carriage Bolt, 1/2-13 x 1-1/4
48 04021-07 Lock Nut, Elastic Stop, 1/2-13
49 04041-11 Flat Washer, 3/8 ( .406 x 1.50 x .179)
50 48100-05 Bushing, Oilite - .753 I.D.
51 04019-05 Nut, 7/16-14 Serr. Flg.

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

53

PUMP AND FAN DRIVE SYSTEMS

12

14

7

8

7

8

49

11
10

7

9

7

3

4

47

PART OF
ENGINE

5

48

46

45

1

2

3

34

8

6

8

35

18

8

7

17

29

20

24

15

16

17

11

22

23

49

50

30

13

44

36

4

37

38

39

33

40

21

42

31

7

8

7

8

32

7

43

10

41

21

27

25

28

19

26

390S0118

54

PUMP AND FAN DRIVE SYSTEMS

Ref. Part
No. Number Description

1 04021-16 Hex Locknut, 1/2-20
2 43335 Spacer, Fan
3 48442 Bearing
4 04003-19 Carriage Bolt, 1/2-13 x 1-1/4
5 46872 Bracket, Fan Mounting (Includes 3, 48)
6 422017 Idler Bracket, Fan Drive
7 04021-09 Hex Locknut, Elastic Stop, 3/8-16
8 04041-07 Flat Washer, 3/8 (.391 x .938 x .105)
9 04003-06 Carriage Bolt, 1/4-20 x 1
10 04001-32 Bolt, Hex Head, 3/8-16 x 1-1/4
1 1 04003-11 Carriage Bolt, 3/8-16x 1-1/4
12 422019 Brace, Fan Support
13 04019-02 Serr. Fl. Hex Nut, 1/4-20
14 421808 Guard, Pump Belt
15 04021-08 Hex Locknut, Elastic Stop, 1/4-20
16 04003-12 Carriage Bolt, 5/16-18 x 3/4
17 04019-06 Serr. Fl. Hex Nut, 1/2-13
18 43334 Hub, Fan
19 04030-02 Lockwasher,1/4
20 * Pulley, Fan
21 04001-21 Bolt, Hex Head, 3/8-18x 1-3/4
22 481315 Pulley, Belt T ensioning Idler
23 * Fan
24 43390 Hub, Fan
25 04001-114 Bolt, Hex Head, 1/2-20 x 4.75 LH Thread
26 04001-116 Bolt, Hex Head, 1/4-28 x 1
27 481330 Pulley, 4.25 O.D. x 1.4375 I.D.

Ref. Part
No. Number Description

28 481114 Belt, Fan Drive
29 45713 Upright, Fan Support - RH
30 45307 Base, Idler Pivot - Pump
31 44107 Rod, J-Hook
32 43282 Spacer, J Pull Rod
33 48114-04 Grease Fitting
34 48761 T aper Hub, .75 Bore
35 48790 Pulley, Pump, 5.94 O. D.
36 04001-109 Bolt, Hex Head, 1/4-20 x 3/8
37 481103 Belt, Pump Drive
38 481168 T aper Hub, 1-7/16 Bore
39 04015-09 CPSCR, Socket Head, 1/4-20 x 1-1/4
40 04050-02 Retaining Ring, .75 Ext
41 48181 Pulley , Idler, 5.95 O.D.
42 48100-05 Bushing, Olite - .75 I.D.
43 46878 Arm, Idler (Includes 33, 42)
44 04019-03 Serr. Fl. He x Nut, 5/16-18
45 481329 Pulley , Double Groov e
46 04063-22 Key, 3/8 x 1-1/4
47 * Stubshaft, Crankshaft
48 43139 Spacer
49 04003-12 Carriage Bolt, 5/16 - 18 x .75
50 04040-14 Flatwasher, 1/4

* Available only from the engine man ufacturer.

-NOTE-

Some of the hardware is common hardware and you may purchase it locally, Be sure that all bolts
purchased are a grade 5.

55

INSTRUMENT PANEL

29

27

4

3

2

1

6

7

21

20

19

20

15

19

32

29

21

20

26

20

12

30

21

11

25

18

12

11

24

12

11

31

28

18

17

9

11

12

5

9

13

15

16

16

33

11

12

9

25

9

8

9

10

14

56

19

20

21

22

23

390S0119

INSTRUMENT PANEL

Ref. Page
No. Number Description

1 48023 Hourmeter
2 481183 Gauge, W ater T emperature
3 481306 Gauge, Fuel Level
4 481184 Voltmeter
5 46873 Instrument Panel with Decal
6 42413 Bracket, Fuse Holder
7 04021-01 Hex Locknut, Elastic Stop, #10-32
8 04010-11 Screw, Round Head, #10-32 x 1-1/2
9 04010-01 Screw, Round Head, #10-32 x 1/2
10 * Timer, Glow Plug
1 1 04031-01 Lockwasher, External Tooth, #10
12 04020-01 Hex Nut, #10-32
13 481182 Indicator Light, Glow Plug, Yellow Lens
14 * Keyswitch
15 04003-12 Carriage Bolt, 5/16-18 x 3/4
16 481087 Switch, Deck Lift
17 46874 Mounting Bracket, Instrument Panel (Includes 18, 23)
18 48100-06 Bushing, Oilite - .75 I.D.
19 04040-04 Flatwasher, 5/16 (.281 x .625 x .065)
20 04030-03 Lockwasher, 5/16
21 04020-03 Hex Nut, 5/16-18
22 04019-03 Serr. Fl. Hex Nut, 5/16-18
23 48114-04 Grease Fitting
24 421788 Guide, Clutch Lever
25 48788 Relay, Synchronize Start and Cutter Blade
26 481311 Rubber Isolator
27 422193 Brace, Instrument Panel
28 04001-59 Serr. Flg. Hex Head Capscrew, 5/6-18 x 3/4
29 04001-08 Bolt, Hex Head, 5/16-18 x 3/4
30 481181 Indicator Light, Oil Pressure, Red Lens
31 481316 Timer, Delay Circuit
32 422004 Bracket, Support Brace
33 04019-02 Serr. Fl. Hex Nut, 5/16-18
34 04021-19 Hex Nut, Elastic Stop, 3/8-16
35 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
36 04001-32 Bolt, Hex Head, 3/8-16 x 1-1/4

*Available only from the engine manuf acturer.

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

57

18

31

29

WIRING HARNESS AND ELECTRICAL COMPONENTS

1

28

2

6

5

30

27

26

25

4

3

11

8

7

9

10

11

33

34

22

24

15

21

32

23

20

19

17

12

13

2

15

16

18

58

14

390S0120

WIRING HARNESS AND ELECTRICAL COMPONENTS

Ref. Page
No. Number Description

1 481216 Actuator, Cutting Height
2 481185 Wire Harness
3 481182 Indicator Light, Oil Pressure
4 48023 Hourmeter
5 481183 Gauge, W ater T emperature
6 481306 Gauge, Fuel Level
7 481316 Timer, Delay Circuit
8 481322 Fuse, 30 Amp
9 * Timer, Glow Plug
10 481182 Indicator Light, Glow Plug
1 1 48788 Relay , Synchonize Start and Clutch Kill Circuit
12 * Switch, Ignition
13 481087 Switch, Deck Lift and Cutting Height

14 481476 Switch, Safety - Parking Brake
15 481474 Switch, Foot Pedal and Cutter Brake Interlocks
16 481304 Sender, Fuel (includes Gasket and Screws)
17 04021-10 Hex Locknut, Elastic Stop, 5/16-18
18 48030-10 Clamp
19 04003-12 Carriage Bolt, 5/16-18 x 3/4
20 481204 Electric Clutch
21 * Fuel Pump, Electric
22 481195 Actuator, Deck Lift
23 * Sender, Oil Pressure
24 04025-02 Hex Nut, M8- 1.25
25 481335 Cap, Alternator T erminal
26 481190 Sender, Water T emperature
27 481177 Battery
28 481336 Cap, Battery Terminal - Black
29 481176-02 Battery Cable, Black
30 481337 Cap, Battery Terminal - Red
31 481176-01 Battery Cable, Red
32 04025-01 Hex Nut, M6 - 1.00
33 04017-16 Serr. Fl.He x Head Capscrew, 5/16-18 x3/4
34 04019-03 Serr. Fl. Hex Nut, 5/16-18

* Available only from the engine man ufacturer.

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

59

CUTTER BRAKE LINKAGE

35

1

2

3

4

14

6

12

24

36

39

25

2

5

38

18

40

7

6

9

8

17

10

11

29

11

14

15

14

13

16

31

30

41

11

21

40

25

28

27

41

21

60

24

40

25

32

25

11
39

14

40

26

27

23

33

22

21

13

16

19

37

20

21

34

14

390S0121

CUTTER BRAKE LINKAGE

Ref. Part
No. Number Description

1 04041-08 Flatwasher, 3/4 (.766 x 1.250 x .060)

04041-08S Flatwasher, 3/4 (.766 x 1.250 x .035)
2 04050-02 Retaining Ring - .75 Ext
3 45702 Lever, Clutch Engage
4 04021-10 Hex Locknut, Elastic Stop, 5/16-18
5 481163 Spring, Clutch Lever
6 04019-03 Serr. Fl. He x Nut, 5/16-18
7 04017-17 Serr. Fl. He x Head Capscrew, 5/16-18 x 1
8 04020-04 Nut, Hex, 3/8-16
9 48092 Grip, Clutch Lever
10 481244 Spring, Friction Control
1 1 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
12 04001-51 Bolt, Hex Head, 3/8-16 x 3-3/4
13 04017-26 Serr. Fl. Hex Head Capscrew, 3/8-16 x 3/4
14 04021-09 Hex Locknut, Elastic Stop, 3/8-16
15 48464 Ball Joint, RH Thd, 3/8-16
16 04001-53 Bolt, Hex Head, 5/16-18x 2-1/2
17 45693 Lever, Clutch
18 04017-19 Serr. Fl. Hex Head Capscrew, 5/16-18 x 1-1/2
19 421805 Base, Brake Assembly
20 481474 Switch, Interlock
21 04019-04 Serr. Fl. Hex Nut, 3/8-16
22 04001-31 Bolt, Hex Head, 3/8-16 x 2-1/2
23 46875 Lever, Brake Engage (Includes 24, 25)
24 48114-05 Grease Fitting, Short
25 48100-04 Bushing, Oilite - .50 I.D.
26 44109 Rod, Clutch Engage
27 04062-02 Cotter Pin, Hair (.080 x1.19)
28 46876 Bellcrank, Clutch Engage (Includes 24, 25)
29 43212 Sleeve
30 04001-20 Bolt, Hex Head, 3/8-16 x 1-1/2
31 481034 Spring, Brake
32 04001-26 Bolt, Hex Head, 3/8-16 x 1-1/4
33 481170 Brake Band
34 43337 Anchor, Brake
35 43336 Spacer, Brake
36 44110 Rod, Clutch Engage
37 04017-20 Serr. Fl. Hex Head Capscrew, 5/16-18 x 1-3/4
38 04020-14 Hex Nut, 3/8-24
39 43110 Sleeve, Control Lever
40 04040-04 Flatwasher, 5/16 (.344 x .688 x .065)
41 04021-10 Hex Locknut, Elastic Stop, 5/16-18

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

61

27

PARKING BRAKE LINKAGE

1

28

23

24

22

20

21

25

15

16

14

13

17

16

6

29

8

6

34

24

16

32

4

33

3

2

16

18

14

6

19

30

5

6

6

12

35

9

4

3

7

6

26

3

4

5

11

10

8

8

31

8

7

21

20

12

62

24

20

22

23

MAG008

PARKING BRAKE LINKAGE

Ref. Part
No. Number Description

1 48093 Grip, Handle
2 45716 Lever, Brake
3 48114-04 Grease Fitting
4 04050-01 Retaining Ring, .625 Ext
5 04020-05 Hex Locknut, Elastic Stop, 3/8-16
6 04041-07 Washer, Flat, 3/8 (.391 x .938 x .105)
7 48464 Ball Joint, 3/8-24 RH Thd
8 04021-09 Hex Locknut, Elastic Stop, 3/8-16
9 45782 Arm, Weldment
10 04020-14 Hex Nut, 3/8-24
1 1 04004-23 Rod, Parking Brake
12 04003-05 Carriage Bolt, 3/8-16 x 1-1/2
13 481474 Switch, Interlock
14 04001-19 Bolt, Hex Head, 3/8-16 x 1.00
15 04017-17 Serr. Fl. Hex Head Capscrew, 5/16-18 x 1.00
16 04019-04 Serr. Fl. Hex Nut, 3/8-16
17 45781 Mounting Base, Parking Brake
18 04001-21 Bolt, Hex head, 3/8-16 x 1-1/4
19 421338 Link, Cam
20 04019-02 Serr. Fl. Hex Nut, 1/4-20
21 04001-59 Bolt, Hex Head, 1/4-20 x 1-1/4
22 44108 Rod, Brake Actuator
23 43032 Swivel
24 0462-02 Hair Pin, Cotter , .08 x 1.19
25 45705 Actuator, Brake
26 04017-37 Serr. Fl He x Head Capscre w , 1/2-13 x 1-3/4
27 04019-03 Serr. Fl. Hex Nut, 5/16-18
28 04019-06 Serr. Fl. Hex Nut, 1/2-13
29 48544 Ball Joint, 3/8-24 LH Thread
30 43212 Sleeve
31 44124 Rod, Interlock
32 45834 Bracket, Neutral Lockout Mounting
33 04001-51 Bolt, Hex Head, 3/8-16 x 3.75
34 45835 Bracket, Neutral Lockout
35 04003-03 Carriage Bolt

-NOTE-

Some of the hardware is common hardware and you may purchase it locally, Be sure that all bolts
purchased are a grade 5.

63

32

15

26

28

27

THROTTLE LINKAGE

1

2

3

34

23

28

37

7

5
6

7

30

8

9

35

10

29

4

38

30

17

27

26

31

23

14

36

24

39

25

18

33

17

16

23
19

12

13

18

22

11

19

20

21

21

64

390S0123

THROTTLE LINKAGE

Ref. Part
No. Number Description

1 04003-02 Carriage Bolt, 1/4-20 x .75
2 421776 Mounting Base, Throttle
3 04019-02 Serr . Fl. Hex Nut, 1/4-20
4 04001-13 Bolt, Hex Head, 5/16-18 x 2-3/4
5 46877 Lever, Throttle (Includes 6, 7)
6 48114-05 Grease Fitting
7 48100-04 Bushing, Oilite - .50 I.D.
8 44115 Rod, Throttle Control
9 04002-11 Bolt, Hex Head, M10 - 1.25 x 30
10 45822 Mounting Bracket, Throttle
1 1 04021-13 Hex Locknut, Elastic Stop, 5/8-11
12 04041-10 Flatwasher, 5/8
13 481244 Spring, Friction Control
14 04004-26 Stud, 5/16-24 x 4.50
15 04020-03 Hex Nut, 5/16-18
16 481189 Rod End, 5/16-24 RH Thread
17 04040-04 Flatwasher, 5/16 (.344 x .688 x .065)
18 04001-10 Bolt, Hex Head, 5/16-18 x 1-1/4
19 04019-02 Serr. Fl. He x Nut, 1/4-20
20 481314 Spring, Throttle Control
21 04019-03 Serr. Fl. Hex Nut, 5/16-18
22 04001-39 Bolt, Hex Head, 5/16-18 x 2-1/4
23 04021-10 Hex Locknut, Elastic Stop, 5/16-18
24 04001-59 Bolt, Hex Head, 1/4-20 x 1-14
25 421997 Lever, Throttle
26 04021-09 Hex Locknut, Elastic Stop, 3/8-16
27 48464 Ball Joint, 3/8-24 RH Thread
28 04040-04 Flatwasher, 5/16
29 04001-20 Bolt, Hex Head, 3/8-16 x 1-1/2
30 04020-14 Hex Nut, 3/8-24
31 481188 Rod End, 5/16-24 LH Thread
32 481092 Knob, Shifter
33 481243 Disc, Friction
34 04001-51 Bolt, Hex Head, 3/8-16 x 3-3/4
35 04030-05 Lockwasher, 7/16
36 04001-125 Bolt, Hex Head, 5/8-11 X 3-1/2
37 43110 Sleeve
38 43212 Sleeve
39 04020-13 Hex Nut,5/16-24

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

65

16

FORWARD/REVERSE LINKAGE

1

2

3

4

5

10

15

10

1

2

22

12

12

13

21

18

17

3

4
6

8

9

7

11

4

24

20

19

14

12

390S0124

66

FORWARD/REVERSE LINKAGE

Ref. Part
No. Number Description

1 04021-09 Hex Locknut, Elastic Stop, 3/8-16
2 48544 Ball Joint, 3/8-24 LH Thread
3 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
4 04003-05 Carriage Bolt, 3/8-16 x 1-1/2
5 04004-22 Rod, Tr ansmission Control
6 45708 Bellcrank, Pump Control
7 04021-08 Hex Locknut, Elastic Stop, 1/4-20
8 04001-59 Bolt, Hex Head, 1/4-20 x 1-1/4
9 04003-04 Carriage Bolt, 5/16-18 x 1
10 04020-14 Hex Nut, 3/8-24
1 1 04019-03 Serr. Fl. Hex Nut, 5/16-18
12 43257 Bushing, Spring Keeper
13 48463 Spring, Neutral Return
14 48512 Bolt, Neutral Adjustment, 3/8-24 x 6-3/4
15 421148 Retainer, Neutral Spring
16 48464 Ball Joint, 3/8-24 RH Thread
17 481102 Hydraulic Pump
18 04001-71 Bolt, Hex Head, 1/2-13 x 1-1/2
19 04030-06 Lockwasher, 1/2
20 04020-07 Hex Nut, 1/2-13
21 04010-11 Screw, Round Head, #10-32
22 04021-01 Hex Nut, Elastic Stop, #10-32
23 04040-15 Flatwasher, 5/16 (.375 x .875 x .083

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

67

FUEL TANK AND LINES

27

8

3

28

23

29

31

56

23

16

24

15

16

2

1

4

26

14

20

16

15

30
25

9

16

17

16

15

16

18

13

7

9

10

15

16

11

16

15

14

68

22

16

16

19

21

390S0125

FUEL TANK AND LINES

Ref. Part
No. Number Description

1 46933 Fuel Tank (Includes 2, 3, 4)
2 481313 Fitting, Return Line
3 481304 Sender Unit, Fuel Level (Includes Gasket and Screws)
4 481312 Fitting, Hose
5 04017-16 Serr. Fl. He x Head Capscre w, 5/16-18 x 3/4
6 481298 Cap, Diesel Fuel
7 45864 Fill Neck Wlmt.
8 04020-01 Hex Nut, #10-32
9 48136-08 Clamp, Hose
10 481296 Hose, Fuel Fill
1 1 481307 Fuel Pre-Filter
12 48030-08 Clamp, Fuel Filter
13 04017-05 Serr. Fl. Hex Head Capscrew, 1/4-20 x 3/4
14 04019-02 Serr. Fl. Hex Nut, 1/4-20
15 481178 **Hose, Fuel Line
16 48136-05 Clamp Hose
17 481308 Valve, Fuel Shutoff
18 * Fuel Pump, Electric
19 * Fuel Filter (Kubota P/N 70000-43081)
20 04017-17 Serr. Fl. Hex Head Capscrew, 5/16-18 x 1
21 04019-03 Serr. Fl. Hex Nut, 5/16-18
22 04021-08 Hex Locknut, Elastic Stop, 1/4-20
23 48059-03 Fuel Hose Clamp, 3/16
24 481179 **Hose Fuel Line, 3/16 x 33"
25 04017-04 Serr. Fl. Hex Head Capscrew, 1/4-20 x1-1/2
26 422003 Strap, Fuel Tank
27 04030-01 Lockwasher, #10
28 481431 Elbow, 90 Deg.
29 481432 Bushing, Fuel Tank
30 48351-10 Hose, Fuel V ent, 1/2 x21.5"
31 48502-04 Clamp, Hose .75 OD Hose

* Available only from the engine manuf acturer.
** When ordering fuel line hose, specify the length required.

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.

69

HYDRAULIC CIRCUITS

1

2

16

17

13

2

4

29

11

5

2

6

7

25

13

6

17

16

30

28

2

13

6

6

6

6

27

22

9

23

24

26

31

2

12

14

15

18

3

8

10

21

19

20

390S0126

70

HYDRAULIC CIRCUITS

Ref. Part
No. Number Description

1 481292 Hose, Pump to Oil Cooler, 5/8 Hose Barb
2 48136-04 Clamp, Hose
3 481301-01 Elbow, 90°,
4 481202 Hose, Oil Cooler to Reservoir, 5/8 & 3/8 Hose Barb
5 48939 Elbow, 90°
6 48059-01 Clamp, Hose
7 48936-02 Coupling, Hose, 7/8-14 SAE x 5/8 Hose Barb
8 48350-13 Elbow, 90°, 1-1/16-12 JIC x 7/8-14 O-Ring
9 481203-01 Elbow, 90°, 3/4 JIC Swivel x 3/4 JIC
10 481197 Hose Assembly, Left Motor
1 1 481201 Hose Assembly, Pump Inlet
12 04017-05 Serr. Fl. Hex Head Capscrew, 1/4-20 x 3/4
13 48482 *Hose, Hydraulic, 1/4"
14 481174 Filter Head
15 48758 Filter, Hydraulic
16 48350-03 Elbow, 90°
17 48353-02 Coupling, Hose
18 04021-10 Hex Nut, Elastic Stop, 5/16-18
19 04040-04 Flatwasher, 5/16 (.344 x .688 x .065)
20 481196 Relief Valve, Dual Cross-Ov er
21 04001-39 Bolt, Hex Head, 5/16-18 x 2-1/4
22 481199 Hose Assembly, Pump to V alve
23 48571-03 Tube Cap , 1-1/16-12
24 48937-02 Tee, Run, 3/4 x 3/4
25 48350-05 Elbow, 90°, 7/8-14 JIC x 7/8-14 O-ring
26 48602 *Hose, Reservoir to Filter , 3/4
27 48935-01 Tee, Pushlock, 1/2
28 481198 Hose Assembly, Right Motor
29 48937-01 Tee, Run
30 48309 Bushing
31 48936-01 Hose BArb to JIC Swivel

* When ordering hydraulic hose, specify length required

-NOTE-

Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased are a grade 5.

71

RED

RED

RED

RED

RED

RED

*GLOW PLUG

TIMER

*SYNCHO-START

RELAY

GRN

WHT

*PARKING BRAKE

SWITCH

PINK/BLK

PINK/BLK

ORN/WHT

RED

GRN

FUSE

HOLDER

PURP

ORN

PINK

FUEL

SENDER

PURP

PINK

RED

BLK

LT. BLU

GRN

ORN

WHT

PURP

BLK

PINK

BLK

*SYNCHO-START

ENGINE

*DELAY MODULE TIMER

BLK

ORN

BLK

BLK

GRN

ORN

G

*VOLTMETER

I

ORN

RED

ORN

*IGNITION

SWITCH

RED

WHT

GLOW PLUG

*FUEL GAUGE

BLK

BLK

G

S

I

ORN

ORN

ORN/WHT

ORN

PINK

*GLOW PLUG

RED

ORN

LIGHT

B

D

E

*CUTTING

HEIGHT SWITCH

WHT

BLK

G

S

I

WHT

BLK

A

C

RED

STARTER

SOLENOID

WHT

GRN

*OIL

PRESSURE

SENDER

BLK

CONTROL PANEL

*WATER

TEMPERATURE GAUGE

ORN

BLK

RED/WHT

YEL/BLK

RED

RED

RED

*HOURMETER

BLK
BLU

WHT

BLK

BLK

ORN

BLK

BLK

B

E

BLKBLK

D

BLK

ORN

WHT

A

C

RED

ORN

BLK

BLU

BLK

BLK

*LOW OIL

PRESSURE

LIGHT

*CLUTCH

KILL CIRCUIT

RELAY

*DECK

LIFT

SWITCH

BLU

*ELECTRIC

CLUTCH

ORN
GRN

GRN

ORN

FUEL

PUMP

BLK

BLK

*FOOT

INTERLOCK

SWITCH

BLU

*CLUTCH

SWITCH

ORN

*CUTTING HEIGHT

ACTUATOR

WA TER TEMPERA TURE

SENDER

BATTERY

72

ALTERNA T OR

RED/WHT

YEL/BLK

*DECK LIFT

ACTUATOR

390S0127

48404

MANUFACTURED UNDER ONE OR MORE

OF THE FOLLOWING PATENTS:

PATENTS PENDING

4,487,006
4,885,903
4,920,733
4,967,543

4,991,382
4,998,948
4,118,617

48656

REPLACEMENT DECALS AND INFORMATION

DANGER

SPINNING BLADE

KEEP CLEAR

CONTACT CAN INJURE

1

7a, 7b

3

48071

10

1
2

3

WARNING

ROTATING BLADES AND BELTS

KEEP HANDS, FEET & CLOTHING CLEAR
KEEP ALL GUARDS IN PLACE
SHUT OFF ENGINE & DISENGAGE BLADE
CLUTCH BEFORE SERVICING
CLEAR AREA OF DEBRIS BEFORE MOWING
USE CAUTION IN DIRECTING DISCHARGE
KEEP BYSTANDERS, CHILDREN & PETS AWAY
READ INSTRUCTION MANUAL BEFORE OPERATING

DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING

KIT, OR ENTIRE GRASS CATCHER INSTALLED

2

6

481040

HEAVY DUTY

COMMERCIAL

INSTALL BELT COVER BEFORE

Ref. Part
No. Number Description

1 48071 Decal, Danger - Spinning Blades
2 481040 Decal, Warning - Rotating Blades
3 481326 Decal, Magnum III
4 48072 Decal, Heavy Duty Commercial
5 481039 Decal, Warning - Belt Cover
6 48404 Decal, Metalcraft - Made In USA
7A 481355 Decal, Scag Logo - 12" x 4.23 (Hood)
7B 48825 Decal, Scag Logo - 8.5" x 2" (Seat Back)
8 481331 Decal, Cutting Height
9 48656 Decal, Patent
10 481186 Decal, Instrument Panel
1 1 48320 Decal, 61
12 48327 Decal, 72

48072

4

WARNING

OPERATING MACHINE

READ OPERATOR'S MANUAL

5

4

9

5

8

481039

11 12

73

GREASE FITTING LUBRICATION CHART

LUBRICATION NO. OF
LOCATION INTERVAL LUBRICANT PLACES

1. Cutter Drive Spindle 40 Hours/Weekly +Lithium MP White Grease 2125 1

2. Cutter Deck Spindles 40 Hours/Weekly +Lithium MP White Grease 2125 3

3. Caster Wheel Bearing 100 Hours/Bi-Monthly Chassis Grease 2

4. Caster Wheel Pivot 100 Hours/Bi-Monthly Chassis Grease 2

5. Electric Clutch Belt Idler Arm 100 Hours/Bi-Monthly Chassis Grease 1

6. Cutter Drive Shaft 100 Hours/Bi-Monthly Chassis Grease 3

7. Cutter Belt Idler Arms 100 Hours/Bi-Monthly Chassis Grease 2

8. Deck Support Pivot 100 Hours/Bi-Monthly Chassis Grease 2

9. Deck Push Arms 100 Hours/ Bi-Monthly Chassis Grease 2

10. Deck Lift Bellcranks 100 Hours/Bi-Monthly Chassis Grease 4
11 . Pump Idler Arm 100 HoursBi-Monthly Chassis Grease 1

12. Rear Wheel Pivot 200 Hours/Monthly Chassis Grease 1

13. Rear Wheel Bearings 200 Hours/Monthly +Lithium MP White Grease 2125 1

14. Right Hand Foot Plate Pivot 200 Hours/Monthly Chassis Grease 1

15. Steering Handle 200 Hours/Monthly Chassis Grease 1

16. Throttle Lever 200 Hours/Monthly Chassis Grease 1

17. Parking Brake Lever 200 Hours/Monthly Chassis Grease 1

18. Blade Brake Linkage Lever 200 Hours/Monthly Chassis Grease 1

19. Blade Brake Linkage Bellcrank 200 Hours/Monthly Chassis Grease 1

20. Blade Brake Control Lever 200 Hours/Monthly Chassis Grease 1

* Lubrication may be required every 8 to 40 hours, depending on climate and environment. Apply two

pumps of hand gun when lubricating these locations. DO NOT over-grease; damage to seal may
occur.

+ Compatible Greases: Mobilix #2 found at Mobil Service Station

Ronex MP found at Exxon Service Stations

Super Lube MEP #2 & Super Stay-M #2 found at Conoco Stations

Lidok EP #2 found at industrial shops

74

75

SPECIFICATIONS

ENGINE

General Type ............................................................................. Heavy Duty Industrial/Commercial Diesel

Brand ......................................................................................... Kubota 28 HP Super 5 Series, Electric Start

Model......................................................................................... D1105-B

Horsepower................................................................................SAE Gross Intermittent, 28 HP @ 3000 RPM

Type ........................................................................................... Horizontal Shaft, Water Cooled, 4-Cycle Diesel

Displacement ............................................................................. 1123 cc.

Low Idle..................................................................................... 850 - 950 RPM

Cylinders ................................................................................... 3

Order of Firing ..........................................................................1-2-3

Direction of Rotation.................................................................Counter-clockwise (Viewed From Flywheel End)

Fuel Injection Pump .................................................................. Bosch MD Type, Mini Pump

Injection Pressure ...................................................................... 1,991 psi

Injection Timing (Before T.D.C.) ............................................. 19°

Compression Ratio ....................................................................23:1

Starting System ......................................................................... Electric Starting with Cell Starter, Glow Plug In Combustion

Chamber

Fuel ............................................................................................ Diesel Fuel No. 2 -D (ASTM D975)

Oil Type ..................................................................................... API Sandard, CD Grade or Better

Oil Filter .................................................................................... Full Flow Oil Filter Cartridge

Oil Capacity ............................................................................... 4 Quarts With Filter

Cooling ...................................................................................... Pressurized, Sealed Cooling System , 170° F Thermostat, Blade

Fan, Cooling Capacity 8 Quarts
Belts:

Alternator .............................................................................. See Engine Manual for Part Number

Fan......................................................................................... Scag Part Number - 481114

Electric Clutch ...................................................................... Scag Part Number - 481104

Hydraulic Pump .................................................................... Scag Part Number - 481103

ELECTRICAL

Battery ....................................................................................... 12 Volt

Charging System ....................................................................... Alternator

Charging Output ....................................................................... 12 Volt, 30 Amp

System Polarity.......................................................................... Negative Ground

Starter ........................................................................................ 12 Volt Electric Ring Gear Type, Key and Solenoid Operated

Interlock Switches ..................................................................... Left Foot Pedal, Blade Brake, and Parking Brake

Fuses .......................................................................................... Three (3) 30 Amp

TRACTOR

Drive Motors ............................................................................. 12 Cu. In. Cast Iron High Torque Motors

Steering ...................................................................................... Chain and Sprocket

Forward and Reverse Control ................................................... Pedal Operated Linkage Connected To The Hydraulic Pump

Parking Brake ............................................................................Lever Actuated Linkage to Drum Brakes on Both Drive Wheel

Assemblies
Wheels:

(2) Front Caster....................................................................12 x 3.5

(2) Drive ............................................................................... 2 x 10.5 -12, 4-ply Pneumatic Tubeless, Radius Edge

(1) Rear ................................................................................ 18 x 8.50 -8 NHS

Fuel Tank................................................................................... Seamless Polyethylene Tank; 8 Gallon Capacity

Tire Pressure:

Front Caster.......................................................................... 25 PSI

Drive..................................................................................... 15 PSI

Rear ......................................................................................15 PSI

76

TRACTOR (CONT'D)

Seat ............................................................................................ Milsco Seat With Adjustment Lever For Forward and Back

Movement
Travel Speed:

Forward ................................................................................ 0 - 8 MPH Infinitely Variable

Reverse .................................................................................0 - 4.3 MPH Infinitely Variable

CUTTER DECK

No. of Blades .............................................................................3

Width of Cut:

Mag-61 ................................................................................. 61 in.

Mag-72 ................................................................................. 72 in.

Blade Size:

Mag-61 ................................................................................. 1/4 thick x 21" long, milled edge, 5150 alloy steel

Mag-72 ................................................................................. 1/4 thick x 24-1/2" long, milled edge, 5150 alloy steel

Blade Spindles ........................................................................... Cast Iron with Easy Removable Taper Hubs

Deck Drive ................................................................................. Belt Driven Electric Clutch Connecte d to Drive Shaft to

Gearbox on Deck

Electric Clutch Type ................................................................. Warner “Mag Stop” Electric Clutch

Blade Brake ...............................................................................Lever Controlled Linkage to Band Type Brake. Brake Hub

Connected to Drive Shaft

Cutting Height ........................................................................... Switch on Instrument Panel Controls Electric Actuator;

Cutting Heights - 1-1/2" to 5-1/2"

Deck Tilt.................................................................................... Switch on Instrument Panel Control s Electric Actuator

Cutter Deck Belts:

Blade and Gearbox Drive (Mag-61) .................................... Scag Part Number - 48204

Blade and Gearbox Drive (Mag-72) .................................... Scag Part Number - 48089

Blade Drive (Mag-61) .......................................................... Scag Part Number - 48265

Blade Drive (Mag-72) .......................................................... Scag Part Number - 481295

Gearbox Type............................................................................. Sealed Housing, Bevel Gear and Pinion Type

Drive Shaft ................................................................................ Quick-Disconnect Shaft With Two High Speed U-Joints

HYDRAULIC SYSTEM

Hydraulic Pump ......................................................................... Sunstrand Series 15

Hydraulic Cooler ....................................................................... Part of Radiator

Hydraulic Oil Filter ................................................................... 10 Micron Spin-on Element Type

Hydraulic Reservoir................................................................... High Density Polyethylene; 13 Quart Capacity

WEIGHTS AND DIMENSIONS

Length:

Mag-61 ................................................................................. 120.0"

Mag-72 ................................................................................. 120.0"

Tracking Width:

Mag-61 ................................................................................. 54.0"

Mag-72 ................................................................................. 54.0"

Overall Width:

Mag-61 ................................................................................. 73.0"

Mag-72 ................................................................................. 84.0"

Overall Width (with Discharge Chute Up):

Mag-61 ................................................................................. 62.0"

Mag-72 ................................................................................. 73.0"

Overall Height ........................................................................... 51.0"

Operating Weight:

Mag-61 ................................................................................. 1,750 lb.

Mag-72 ................................................................................. 1,800 lb.

77

WARNING:

!

If incorrectly used, this machine can cause severe injury. Those who use and maintain the

machine should be trained in its proper use, warned of its dangers, and should read the entire

manual before attempting to set up, operate, adjust or service the machine.

LIMITED WARRANTY-COMMERCIAL EQUIPMENT

Any part of the Scag commercial mower manufactured by Scag Power Equipment and found, in the reasonable judgment
of Scag, to be defective in materials or workmanship, will be repaired or replaced by an Authorized Scag Service Dealer
without charge for parts and labor. This warranty is limited to the original purchaser and is not transferable. Proof of
purchase will be required by the dealer to substantiate any warranty claims. All warranty work must be performed by an
Authorized Scag Service Dealer.

This warranty is limited to the following specified periods from the date of the original retail purchase for defects in materials
or workmanship:

* Wear items including drive belts, blades, hoses and tires are warranted for 90 days.
* Batteries are covered for 90 days.
* Frame, deck, and structural components including oil reservoir, fittings, and oil cooler are

warranted for 1 year.
* Engines and electric starters are covered by the manufacturers warranty period.
* Drive system components are warranted for 1 year by the component manufacturer, in

conjunction with Scag Power Equipment. (Excluding fittings, hoses, cooling system, oil

reservoir, drive belts).
* Electric clutch components are warranted for 1 year.

Any Scag product used for rental purposes is covered by a 90 day warranty.

The Scag mower, including any defective part must be returned to an Authorized Scag Service Dealer within the warranty
period. The expense of delivering the mower to the dealer for warranty work and the expense of returning it to the owner
after repair will be paid for by the owner. Scags responsibility is limited to making the required repairs and no claim of
breach of warranty shall be cause for cancellation or rescission of the contract of sale of any Scag mower.

This warranty does not cover any mower that has been subject to misuse, neglect, negligence, or accident, or that has been
operated in any way contrary to the operating instructions as specified in the Operators Manual. The warranty does not
apply to any damage to the mower that is the result of improper maintenance, or to any mower or parts that have not been
assembled or installed as specified in the Operators Manual and Assembly Manual. The warranty does not cover any mower
that has been altered or modified, changing performance or durability. In addition, the warranty does not extend to repairs
made necessary by normal wear, or by the use of parts or accessories which, in the reasonable judgment of Scag, are either
incompatible with the Scag mower or adversely affect its operation, performance or durability.

Scag Power Equipment reserves the right to change or improve the design of any mower without assuming any obligation
to modify any mower previously manufactured.

All other implied warranties are limited in duration to the one (1) year warranty period or ninety (90) days for mowers used
for rental purpose. Accordingly, any such implied warranties including merchantability, fitness for a particular purpose,
or otherwise, are disclaimed in their entirety after the expiration of the appropriate one year or ninety day warranty period.
Scags obligation under this warranty is strictly and exclusively limited to the repair or replacement of defective parts and
Scag does not assume or authorize anyone to assume for them any other obligation. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you.

Scag assumes no responsibility for incidental, consequential or other damages including, but not limited to, expense for
gasoline, expense of delivering the mower to an Authorized Scag Service Dealer and expense of returning it to the owner,
mechanics travel time, telephone or telegram charges, rental of a like product during the time warranty repairs are being
performed, travel, loss or damage to personal property, loss of revenue, loss of use of the mower, loss of time or
inconvenience. Some states do not allow the exclusion or limitation of incidental or consequential damages,so the above
limitation or exclusion may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

© 1996
SCAG POWER EQUIPMENT
DIVISION OF METALCRAFT OF MAYVILLE, INC.

PART NO. 03034

PRINTED 10/96

PRINTED IN USA
