Commissioning
Instruction leaflet
product is correctly oriented as shown in the diagram on
the right.
is now ready for use.
Fitting/replacing bulbs
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could damage the finish.
Tribeca Wall
EL-40074
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
Safety information
For your safety, always switch off the power supply before changing lightbulbs, or cleaning.
www.saxbylighting.com
www.saxbylighting.com
V1 10/01/2020
Saxby Lighting Ltd. LS9 0SE
Saxby Lighting Ltd. BH17 7BY
operation of this product. Please retain these instructions for future reference.
Warning
Installation
Existing fittings must be completely removed before installation of a new product. Before removing the existing fitting,
carefully note the position of each set of wires.
This light fitting is Class 1 and must be connected to
an Earth circuit
Please read these instructions carefully before
commencing any work.
electrician.
Install in accordance with IEE Wiring regulations and
before installing or maintaining this fitting. Ensure other
persons cannot restore the electrical supply without
your knowledge. If you are in any doubt, please consult a
Specification
Voltage: 240V 50Hz a.c.
8W LED module (SMD), 6000K
IP rating: 54
Layout
If replacing an existing fitting, make a careful note of the
connections.
serviced. If damage occurs the part should be scrapped.
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling
advice.
marine or sea environment.
supplied Ensure the wall is capable of holding the
be used for brick or cavity walls.
Wiring
Having correctly identified the wiring from your existing light fitting, connect to the connection block inside the product in the
following way:
SUPPLY LIGHT FITTING
NEUTRAL
BLUE (N)
the cables will reach the distance between the junction
box and the light fitting
cause a hazard. Position cables and junction boxes (not
from being cut, trapped or damaged
conduit or plastic trunking.
sectional area of 1.0mm²
of moisture and is IP54 rated.
EARTH (GREEN/YELLOW)
SWITCHED LIVE
Check that...
No loose strands have been left out of the connection block.
GREEN/YELLOW
BROWN (L)
