Savin 9040b,9040,9050b,9050v,9050 Specification

Digital Imaging System
COPY
>
PRINT
>
SCAN
>
FAX
>
PRODUCE
>
The everyday black & white powerhouse.
with color scanning capabilities.
All the Resources You Need in One System.
Wouldn’t it be nice if you could expand your digital imaging resources without expending your budget? The Savin 9040b/9040 & 9050b/9050 Digital Imaging Systems let you do exactly that. Now you’ll have the flexibility to maximize production with output speeds of up to 50 pages per minute, conserve IT resources with advanced network printing and monitoring capabilities, and save time and money with Super G3 and Internet faxing.
Confidentiality is ensured with unsurpassed security, and documents are finished easily and professionally. These systems also streamline document distribution with the color/black & white scanning capabilities of the Savin 9040 & 9050, and the black & white scanning capabilities of the 9040b & 9050b.
The large, panel lets you choose from normal or simplified display for maximum visibility and easier opera
www.savin.com
8.5-inch color touch
tion.
9040b/9040 & 9050b/9050
Digital Imaging System
COPY
>
PRINT
The Resources You Need to Drive Productivity.
The fastest way to get more done is to have the right resources at your fingertips. The Savin 9040b/9040 & 9050b/9050 systems easily put functionality and flexibility within your reach:
• Boost production with up to 50 black & white copies/prints per minute.
• Take advantage of cost-free document distribution, storage and versatile scanning capabilities with the Savin 9040b/9040 & 9050b/9050.
• Save time with up to three Super G3 fax lines and eliminate long-distance phone charges with Internet fax capabilities.
• Impress internal and external customers with crisp 600 dpi resolution and 256 gray scale levels.
• Increase your processing and storage capabilities with up to 768 MB RAM and 40 GB Hard Disk Drive.
• Put the final touch on your documents with three different finishing options, any one of which will add a professional touch to your documents.
>
SCAN
>
Scanning: The New Standard of Convenience.
A variety of sophisticated yet user-friendly scan functions makes document distribution cost-free and convenient.
• Eliminate postage and overnight delivery costs via Scan-to-Email, with the color/black & white scanning capabilities of the 9040/ 9050 and the black & white scanning capabilities of the 9040b/9050b. Plus, access your company’s LDAP Directory to maximize the use of existing company information and ensure accuracy.
• Maintain the image quality of PDFs while reducing their file size using the High Compression PDF function.
• Save physical space and time when you convert paper copies to electronic files and store them in a network folder with Scan-to-Folder—you no longer have to detach documents and save them electronically. Not only will you be able to easily find and retrieve files, but designated users on your LAN or WAN can access, review and update the files as well.
• Ensure that you’ve captured documents accurately using the Thumbnail View.
FAX
>
• Reduce the burden to network traffic and transmit more efficiently with Scan-to-URL, which stores the document on the Hard Disk Drive of the device. Recipients can then view and download the files from any Web browser.
PRODUCE
Intuitive Tools to Maximize Efficiency.
The Savin suite of easy-to-use software utilities simplify system management, monitoring and troubleshooting—everything needed to ensure smooth daily operation.
• Web Image Monitor enables Web access to system settings, address book and much more.
• To efficiently manage multiple, connected Savin devices, Web SmartDeviceMonitor allows centralized configuration, monitoring and management.
• Regardless of location, On-demand Status E-mail Notification enables IT to query the device for important system reports.
• To maximize uptime, Auto E-mail Notification sends a report to a designated e-mail address when the machine is not operating at optimum performance levels. For instance, when the toner is lo
w.
>
Full-Color Scanning
Full-color scanning achieves maximum impact and captures your customers’ attention in ways that black & white cannot. (Not available on 9040b/9050b models.)
Scan-to-URL
Scan-to-URL improves informa
tion sharing in your organiza
tion while minimizing network traffic.
More Productive Printing.
The Savin 9040b/9040 & 9050b/9050 Series works seamlessly with today’s most popular operating systems and print drivers.
• Accept data from Windows®, AS/400, Linux, Macintosh®and Novell®for seamless integration with a variety of network operating systems.
• Finish documents quickly via an icon-based Graphical User Interface using the Refined Print Command Stream (RPCS) print driver.
• Output documents generated from the most common business applications with PCL5e/6 print drivers or genuine Adobe PostScript®3™.
• Reorder print and copy jobs according to the most pressing priorities with the Job Function List.
• Use PDF Direct Print to print PDFs quickly without opening an application and slowing down your network.
• Improve security by password protecting your print files until you release them right at the system. You can even print and delete multiple documents in a single operation.
®
Time- and Money-Saving Fax Features.
ax more conveniently and economically
F with these innovative fax capabilities:
• Send hard copies at a quick 2 seconds per page on up to three analog lines via the Super G3 Modem and standard JBIG compression.
• Save time and paper with LAN Fax and send faxes right from your desktop.
• Capitalize on the cost-saving benefits of IP faxing (T.38) for fast, high quality communication: send and receive faxes directly over your LAN or WAN, bypassing your PSTN (Public Switched Telephone Network).
• Deliver inbound faxes quickly by auto­matically forwarding them to e-mail addresses or network folders. Recipients receive an automatic e-mail notification of fax deliveries.
Security Every Step of the Way.
Sophisticated security features protect not only you, but also your customers, business partners and emplo 9040b/9040 & 9050b/9050.
yees with the Savin
Prevent unauthorized access to system
• functions with Windows/LDAP/Kerberos Authentication, which requires a valid user name and password.
• Ensure unauthorized documents are never duplicated with the optional Copy Data Security unit, which grays-out text when copied.
• Protect temporary data stored on the Hard Drive with DataOverwriteSecurity, which overwrites latent copy, print, scan, fax and Document Server data.
• Protect address book data with Encrypted Address Book, which protects data even if the built-in hard drive is removed, disposed of, or stolen.
• Secure Internet Protocol (IP) communication by authenticating and/or encrypting each IP packet in a data stream with IPsec Communication and transmit PDFs securely with Encrypted PDF Transmission.
• Encrypt Hard Disk Drive and non-volatile RAM data immediately upon storage with the HDD Data Encryption.
Unauthorized Copy Control Features
Print
(Output)
with
masking
pattern
Using the RPCS driver, you can print an embedded message and masking pattern on your documents. If the confidential document is copied, scanned or faxed on a Savin 9040b/9040 & 9050b/9050 with the Copy Da the copy will gray out.
ta Security Unit installed,
the output of
Copy
(Input)
Copy
(Input)
(Output)
Copy Data Security Unit installed
(Output)
Copy Data Security Unit not installed – embedded message appears
9040b/9040 & 9050b/9050
Digital Imaging System
COPY
Process jobs quickly and easily when you save special settings with the Refined Print Command Stream icon­based print driver.
>
PRINT
>
SCAN
The Hold/Locked/Stored Print functions let you hold your documents securely in the device until you’re ready to print them.
>
Technology to Empower Your Business.
At Savin, we’re committed to helping you achieve your goals for reducing overall Total Cost of Ownership, optimizing fleet management and ultimately increasing employee productivity.The @Remote Intelligent Management System is a powerful tool that offers Device Management solutions for…
• Automating service call procedures, eliminating the need for end-users to initiate service calls. If a service call is required, the @Remote network appliance automatically places a request for service—including detailed and accurate diagnostic information.
FAX
>
PRODUCE
Your Environmental Partner
Savin continues its long-standing commitment to developing office solutions with environmentally friendly and superior energy- and supply-saving features, including:
• Quick Start-Up (QSU) Technology
>
• Upgrading and adjusting your devices via remote firmware applications, which means that your devices will always be functioning within the most current and productive operational parameters.
o ensure that your devices are constantly up and running, alerts can be sent, such as
T
• a low toner warning.
User-Friendly Accessibility.
The Savin 9040b/9040 & 9050b/9050 systems not only give you more functionality, but also make their powerful features more accessible to all users.
• Open and close paper trays effortlessly with overhand/underhand grips.
• Increase readability with the Simplified Display.
• Scan more comfortably with the optional detachable scanner, which can be placed at table height.
Open Architecture.
The Savin Embedded Software Architecture—an innovative Java (J2ME-compatible) software development pla run on the Savin 9040b/9040 & 9050b/9050.
• Dramatically enhance your organiza
• Customize to meet your needs by controlling features such as the operation panel, printing, saving files and scanning.
tform—allows for the development of key applications that
tion’
s workflo
w.
• Power-Saving Sleep Mode
• Duplex and Combine Copy Modes
• Internal Toner Recycling Mechanism
• Low Noise Levels
• Minimal Ozone Emissions
• Restriction of Hazardous Substances (RoHS) Compliant
The speed, printing, scanning, faxing and finishing you want in one user-friendly system.
100-Sheet Automatic Reversing Document Feeder (ARDF) (Standard)
Efficiently handles multi-page and double-sided originals up to 11" x 17".
Intuitive Control Panel
Inner One-Bin Tray (Optional)
Provides a cost-effective option to separate copy output from prints or faxes.
Full-color VGA display with graphic icons and animated guidance for easy programming.
Automatic Stackless Duplexing (Standard)
Produces cost-saving two-sided booklets, brochures,
agendas, and more.
Easy-to-Replace Toner Cartridge
Toner is not only easy to replace but offers high image definition, yielding superior quality on every page.
Over/Underhand-Grip Tray Handles and Easy-Open Trays
Ensure effortless paper loading for all users.
Finishers (Optional)
Choose from a variety of professional finishing options that lets you keep more work in-house, boost productivity and cut your outsourcing costs:
1,000-Sheet Finisher
Holds up to 1,000 sheets of 8.5" x 11" or smaller, 20 lb.Bond (500 sheets of 8.5"x 14" or larger) and automatically staples in three different positions.
2,000-Sheet Booklet/Saddle Stitch Finisher (Shown)
tically staples and punches (optional) your work
Automa to produce professional-quality booklets with a variety of staple and hole positions (2 or 3 holes).
3,000-Sheet Multi-Tray Finisher
Multiplies your productivity, convenience and versatility with high capacity trays and optional 2- or 3-hole punching and stapling in a variety of positions on a wide selection of paper weights and sizes.
100-Sheet Stack Bypass
Holds a variety of paper types and weights up to 58 lb. Bond.
Large Capacity Tray (Optional)
Holds an additional 1,200 letter-sized sheets to optimize workflow and keep user intervention on large jobs at an absolute minimum.
rays (Standard)
Dual 550-Sheet P
Further boost your productivity and efficiency by keeping day-to-day maintenance to a minimum.
Two 550-Sheet Tray Paper Bank (Optional)
Up to five different sizes and orienta can be loaded a
2,000-Sheet (Letter-Sized) Large Capacity Tray also available.
Document Ser
Document Server is a secure, virtual filing cabinet
t stores up to 3,000 documents.
tha documents can be reprinted,
aper T
tions of pa
t all times for maximum versatility.
ver (Requires Hard Disk Drive)
requently used
F
refaxed and rescanned.
per
9040b/9040 & 9050b/9050
Digital Imaging System
COPY
Choose Your Finishing Options
>
PRINT
1,000-Sheet Finisher
>
SCAN
Booklet/Saddle Stitch Finisher
>
holds up to 2,000 sheets
FAX
>
PRODUCE
Multi-Tray Finisher
holds up to 3,000 sheets
>
Choose Your System Configuration
9040b/9050b For robust copying and a flexible upgrade path to black & white scanning, printing and faxing.
9040sp/9050sp For exceptional black & white printing and color and black & white scanning.
9040spf/9050spf For a complete document management system with printing, faxing, color and black & white scanning in
compact device.
a single,
Flexible Upgrade Path (9040b/9050b)
or an all-inc
F Printer/Scanner Kit is also available.
lusive solution,
a
Upgrade
Upgrade
For a low-cost network printer, where a specific printer language is not required, start with Savin’s RPCS printer unit.
For the next step up, add the Printer Enhance and get PCL printing and document storage capabilities.
For a device that can send cost-free documents electronically an the world, Scanner Enhance for black & white scanning.
ywhere in
simply add the
9040b/9040 & 9050b/9050
SPECIFICATIONS
COPY
>
PRINT
>
ENGINE/COPIER SPECIFICATIONS
Configuration Console S
canning Element Flatbed with Moving CCD Array Image
Printing Process Twin Laser Beam Scanning &
Toner Dry, Dual Component S
ystem Memory 9040/9050: 768 MB RAM (std./max.) 9040b/9050b: 256/512 MB RAM
Hard Disk Drive 9040/9050: 40 GB Standard
Document Feeder 100-Sheet ARDF (Standard) C
opy Resolution 600 x 600 dpi Grayscale 256 levels Exposure Adjustment Manual & Automatic (Standard) Quantity Indicator Up to 999 Original Type Book/Sheet Maximum Original Size Up to 11" x 17" Copy Size 5.5" x 8.5" to 11" x 17" Copy Type Plain Paper, Transparencies, Recycled
Warm-Up Time 13 seconds First Copy Speed 9040b/9040: 4.1 seconds
C
ontinuous Copying 9040b/9040: 40 copies/minute (LTR)
Speed 9050b/9050: 50 copies/minute (LTR) Recovery Time 10 seconds (from Auto Off) Power Source 120V/60Hz Dimensions 26.4" (W) x 35.8" (H) x 26.6" (D) Weight 187.4 lbs. Standard Paper Capacity 550 sheets x 2 trays
aper Capacity 550 sheets x 2 trays OR
Optional P
Paper Size 5.5" x 8.5" to 11" x 17" Paper Weight Tray 1 & 2: 16 - 45 lb. Bond/60 - 169 g/m
Reduction Ratios 25%, 50%, 65%, 73%, 78%, 85%, 93% Enlargement Ratios 121%, 129%, 155%, 200%, 400% Zoom 25% to 400% in 1% increments Standard F
Requires Hard Disk Background Numbering, Booklet/
ea
Drive Magazine Copy, Document Server
Sensor
Electrophotographic Printing
9040b/9050b: 40 GB Optional
Paper, Card Stock, Letterhead
9050b/9050: 3.5 seconds
100-Sheet Bypass Tray
2,000 x 1; 1,200-Sheet Large Capacity Tray (LCT)
Bypass: 14 - 58 lb. Bond/52 - 220g/m Duplex: 16 - 45 lb. Bond/60 - 169g/m
tion,
gnifica
Auto Ma
tures
Auto Tray Switch, Center/Border Erase, Chapters, Combine Mode, Cover Insertion, Date Stamp, Directional Magnification, Double Copy, Electronic/Rotate Sorting, English Preset Stamps, Full-Color VGA Touch Screen, 10 Job Programs, Negative/ Positive, OHP Slip Sheet, Page Number Stamp, Paper Designate, Sample Copy, Simplified Display, 500 User Codes
(3,000 File Capacity), 8 Job Presets, Series Copy, User Stamps
Auto Paper Select,
2
2
PRINTER SPECIFICATIONS (STANDARD)*
Print Speed 9040b/9040: 40 ppm
CPU RM7035C-533 MHz Standard Interfaces 10BaseT/100BaseTX, USB 2.0 Optional Interfaces IEEE 802.11a/b/g Wireless LAN,
Memory Capacity Shared with Copier Memory Network Protocol Network Opera
Systems Netware 3.12, 3.2, 4.1, 4.11, 5.0, 5.1,
Utilities Web SmartDeviceMonitor
9050b/9050: 50 ppm
Gigabit Ethernet,
Bluetooth, IEEE 1284
A
IPX/SPX,
,
TCP/IP
Vista/2000/Me/XP/Ser
ws
Windo
ting
6, 6.5, UNIX; Sun Solaris, HP-UX, SCO OpenServer, RedHat Linux, IBM AIX, Mac OS 8.6 - 9.2x, OS X 10.1 or later,
NDPS Ga
SAP R/3, 400 using OS/400 Host Print Citrix Metaframe
SmartDeviceMonitor Monitor, DeskTopBinder V2 Lite
alk
ppleT
, IBM iSeries/AS/
teway
,
eb Ima
W
,
ver 2003,
Transform,
ge
www.savin.com
Savin Five Dedrick Place, West Caldwell, NJ 07006
®
SAVIN
is a registered trademark of Ricoh Americas Corporation. Windows®and Windows®95/98/Me/NT4.0/2000/XP are registered trademarks of Microsoft Corporation. Macintosh®, Mac®OS and AppleTalk®are registered trademarks of Apple Computer, Inc. Adobe the property of their respective owners.
Printed in U.S.A. on recycled paper. S2683
®
and P
®
ostScript
are registered trademarks of
Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice. Products are shown with optional features.
SCAN
Page Description Standard RPCS and PCL 5e/6 and
L
anguages Optional Adobe PostScript3
Print Resolution Up to 600 dpi (2400 x 600 dpi with
Fonts for PCL 5e/6 35 Intellifonts, 10 Truetype Fonts,
F
onts for PS3 136 PostScript Fonts
Standard Features Sample/Locked/Hold/Stored Print
(Hard Disk Required)
Optional Features PDF Direct Print
smoothing)
1 Bitmap, 13 International Fonts
>
SCANNER SPECIFICATIONS (STANDARD)*
Scanning Speed BW: 50 ipm (@200 dpi);
Scanning Resolution Up to 600 dpi Grayscale 256 levels S
can Area Up to 11" x 17" Standard Interfaces 10BaseT/100BaseTX Ethernet Optional Interfaces Wireless LAN (802.11a/b/g),
Protocol TCP/IP, SMTP, SMB, FTP, POP3, NCP M
emory Capacity Shared with Copier Memory
Standard Features Embedded Scan-to-Email, HDD, Folder,
File Formats Single-Page and Multi-Page TIFF, PDF,
Note: Color Scanning, Color Dropout and High Compression PDF are not available on the 9040b/9050b models.
FAX SPECIFICATIONS (OPTION)
Circuit PSTN, PBX Compatibility ITU-T G3 Resolution 200 x 200/100 dpi (Standard)
Compression Method MH, MR, MMR,JBIG Scanning Speed 0.40 seconds (LEF) Modem Speed 33.6 Kbps with Auto Fallback
2
Transmission Speed G3: 3 seconds per page
Memory 4 MB standard (320 pages)
y Backup
Memor Auto Dials 2,000 (with HDD) Group Dials 100 (max. 500 numbers per group) ID Code Programming 4 digits User Function Key 3 keys Standard Features Dual Access, Image Rotation,
Optional Features Simultaneous operation of up to
Note: Faxing is standard on the 9040spf/9050spf models.
FC: 29 ipm (@200 dpi)
Gigabit Ethernet
URL
High Compression PDF
400 x 400 dpi (Optional)
(MMR Compression) G3: 2 seconds per page (JBIG Compression)
28 MB maximum (2,240 pages) 1 hour
ax Capability*, Internet Faxing
LAN-F (T.37)*, IP Faxing (T.38)*, Fax Forwarding to E-mail/HDD/Folder*
3 lines (G3 x 3)
, Single-Page JPEG
SECURITY FEATURES (STANDARD)*
S/MIME,
IPsec Communica Encryption, Encrypt Address Book, SSL Secure Socket Layer, Windows/LDAP/User Authentication, SNMP v3, Encryption of Password PDF, Encrypted PDF
tion, Locked Print Password
ONE-BIN TRAY BN3040 (OPTION)
Paper Size 5.5" x 8.5" - 11" x 17"/A3 - A5 Paper Weight 16 to 28 lb. Bond/60 - 196 g/m
pacity 125 sheets
per Ca
a
P
SR790 FINISHER (OPTION)
Paper Size 5.5" x 8.5" - 11" x 17"/A5 - A3 Paper Weight 14 to 68 lb. Bond/52 to 260g/m
Stack Capacity Proof Tray: 250 sheets (8.5" x 11"
Staple Capacity 50 sheets (8.5" x 11")
osition 1 staple /2 positions; 2 staples/1 position
ple P
Sta Dimensions 10.7" (W) x 20.5" (D) x 31.2"(H)
Adobe Systems,
(Proof Tray) 14 to 43 lb. Bond/52 to 163g/m
ray)
T
(Shift
or smaller) 50 sheets (8.5" x 14" or larger) Shift Tray: 1,000 sheets (8.5" x 11" or smaller) 500 sheets (8.5" x 14" or larger)
30 sheets (8.5" x 14" or larger)
®
PCL
Inc.
is a registered trademark of Hewlett-P
FAX
2
2
2
ackard Compan
>
PRODUCE
SR3020 BOOKLET FINISHER (OPTION)
P
aper Size 5.5" x 8.5" - 11" x 17"
Paper Weight 14 to 43 lb. Bond/52 to 163g/m
S
tack Capacity Proof Tray: 250 sheets (8.5"x 11" or
Staple Capacity 50 sheets (8.5" x 11")
Staple Position 1 staple/3 positions; 2 staples/2 positions Saddle Stitch 30 sets (2 - 5 sheets)
Dimensions 25.8" (W) x 24.2" (D) x 37.8" (H)
(Proof Tray) 14 to 68 lb. Bond/52 to 256g/m (Shift Tray)
smaller) 50 sheets (8.5" x 14" or larger) Shift Tray: 2,000 sheets (8.5" x 11") LEF 1,000 sheets (8.5" x 11" - 11" x 17") SEF 100 sheets (5.5" x 8.5")
30 sheets (8.5" x 14" or larger)
15 sets (6 -10 sheets) 10 sets (11 - 15 sheets)
2
2
SR3030 FINISHER (OPTION)
P
aper Size 5.5" x 8.5" - 11" x 17"
Paper Weight 14 to 43 lb. Bond/52 to 163g/m
S
tack Capacity Proof Tray: 250 sheets (8.5" x 11" or
Staple Capacity 50 sheets (8.5" x 11")
Staple Position 1 staple/3 positions; 2 staples/1 position Dimensions 25.8" (W) x 24.2" (D) x 37.8"(H)
Tray)
(Proof 14 to 68 lb. Bond/52 to 256g/m (Shift Tray)
smaller) 50 sheets (8.5" x 14" or larger) Shift Tray: 3,000 sheets (8.5" x 11") LEF 1,500 sheets (8.5" x 11" - 11"x 17") SEF
30 sheets (8.5" x 14" or larger)
2
2
RT3000 LARGE CAPACITY TRAY (OPTION)
Paper Size 8.5"x 11"/A4 Paper Weight 16 to 45 lb. Bond/60 - 169 g/m Paper Capacity 1,200 sheets x 1 Dimensions 13.7" (W) x 21.3" (D) x 11.4"(H)
2
PB3040 PAPER FEED UNIT (OPTION)
Paper Size 5.5" x 8.5" - 11"x 17"/A5 - A3 Paper Weight 16 to 45 lb. Bond/60 to 169g/m Paper Capacity 550 sheets x 2 Dimensions 22.8" (W) x 24.4" (D) x 10.2"(H)
2
PB3050 LARGE CAPACITY TRAY (OPTION)
Paper Size 8.5" x 11"/A4 Paper Weight 16 to 45 lb. Bond/60 to 169g/m Paper Capacity 2,000 sheets x 1 Dimensions 22.8" (W) x 24.4" (D) x 10.2"(H)
2
ADDITIONAL OPTIONS FOR 9040b/9040/ 9050b/9050
Bluetooth Interface Unit Type 3245, Bridge Unit Type BU3030, Copy Data Security Unit Type F, DOSS Type I, FAC33 Cabinet,
Type 5000, File Format Converter Type E, G3 Interface
ax
F Type 5000, Gigabit Ethernet Board Type A, Handset Type 1018, HDD Encryption Unit Type A, IEEE 1284 Interface Board Type A, IEEE 802.11a/b/g Interface Unit Key Counter Bracket Type H, Optional Counter Interface Type A, PostScript3 Type 5000, Punch Kit Type 3260 (for SR3020 & SR3030), Scanner Accessibility Option Type 4045, 32 MB Fax Memory
ype J,
T
VM Card Type F,
va
Ja
ADDITIONAL OPTIONS FOR 9040b/9050b MODELS ONLY
Hard Disk Drive Type 5000, Printer Enhance Type 5000, Printer/Scanner Unit Type 5000, RPCS Printer Unit Type 5000, Scanner Enhance
*Options for Savin 9040b/9050b
RPCS
.
y
ype 5000
T
is a trademark of Ricoh Compan
All other trademarks are
Ltd.
,
y
>
Loading...
