Series PM172 Powermeters
GE EGD
Communications Protocol
Reference Guide
BG0417 Rev. A1
2
Every effort has been made to ensure that the material herein is complete and accurate.
However, the manufacturer is not responsible for any mistakes in printing or faulty instructions
contained in this book. Notification of any errors or misprints will be received with
appreciation.
For further information regarding a particular installation, operation or maintenance of
equipment, contact the manufacturer or your local representative or distributor.
3
Table of Contents
1 GENERAL ..........................................................................................................5
2 EGD MESSAGING PROTOCOL........................................................................6
2.1 EGD PRODUCTION EXCHANGES...............................................................................................6
2.2 DATA TYPES............................................................................................................................6
2.3 POINT ADDRESS RANGES.........................................................................................................6
2.4 EGD PRODUCTION PERIODS....................................................................................................7
3 DEVICE POINT MAP..........................................................................................8
Special Inputs ......................................................................................................................................8
Event Flags (bitmap) EH........................................................................................................................8
Digital Inputs DI1-DI2 (bitmap).............................................................................................................8
Relay Outputs RO1-RO2 (bitmap) .......................................................................................................8
Counters ..............................................................................................................................................8
1-Cycle Phase Values..........................................................................................................................8
1-Cycle Total Values............................................................................................................................9
1-Cycle Auxiliary Values.......................................................................................................................9
Phasor..................................................................................................................................................9
1-Second Phase Values.......................................................................................................................10
1-Second Total Values......................................................................................................................... 10
1-Second Auxiliary Values ...................................................................................................................11
Present Harmonic Demands................................................................................................................ 11
Present Volt, Ampere and Power Demands.........................................................................................11
Total Energies E...................................................................................................................................12
Summary Energy Registers E...............................................................................................................12
Phase Energies E.................................................................................................................................12
V1/V12 Harmonic Distortions EH...........................................................................................................13
V2/V23 Harmonic Distortions EH...........................................................................................................13
V3/V31 Harmonic Distortions EH...........................................................................................................13
I1 Harmonic Distortions EH...................................................................................................................13
I2 Harmonic Distortions EH...................................................................................................................13
I3 Harmonic Distortions EH...................................................................................................................13
Fundamental (H01) Phase Values.......................................................................................................13
Harmonic Total Values......................................................................................................................... 14
Minimum 1-Cycle Phase Values ..........................................................................................................14
Minimum 1-Cycle Total Values.............................................................................................................15
Minimum 1-Cycle Auxiliary Values....................................................................................................... 15
Maximum 1-Cycle Phase Values .........................................................................................................15
Maximum 1-Cycle Total Values............................................................................................................15
Maximum 1-Cycle Auxiliary Values...................................................................................................... 15
Maximum Demands............................................................................................................................. 16
Maximum Harmonic Demands.............................................................................................................16
Scaled Analog Inputs...........................................................................................................................16
Raw Analog Inputs...............................................................................................................................16
TOU Parameters E...............................................................................................................................16
Scaled Analog Outputs ........................................................................................................................17
TOU Energy Register #1 E...................................................................................................................17
TOU Energy Register #2 E...................................................................................................................17
TOU Energy Register #3 E...................................................................................................................17
TOU Energy Register #4 E...................................................................................................................17
TOU Energy Register #5 E...................................................................................................................17
TOU Energy Register #6 E...................................................................................................................17
TOU Energy Register #7 E...................................................................................................................17
TOU Energy Register #8 E...................................................................................................................18
Summary Energy Accumulated Demands E.........................................................................................18
Summary Energy Block Demands E.....................................................................................................18
Summary Energy Sliding Window DemandsE......................................................................................18
4
Summary Energy Maximum Demands E..............................................................................................18
TOU Maximum Demand Register #1 E.................................................................................................18
TOU Maximum Demand Register #2 E.................................................................................................18
TOU Maximum Demand Register #3 E.................................................................................................18
TOU Maximum Demand Register #4 E.................................................................................................19
TOU Maximum Demand Register #5 E.................................................................................................19
TOU Maximum Demand Register #6 E.................................................................................................19
TOU Maximum Demand Register #7 E.................................................................................................19
TOU Maximum Demand Register #8 E.................................................................................................19
V1/V12 Harmonic Angles EH.................................................................................................................19
V2/V23 Harmonic Angles EH.................................................................................................................19
V1/V31 Harmonic Angles EH.................................................................................................................19
I1 Harmonic Angles EH.........................................................................................................................20
I2 Harmonic Angles EH.........................................................................................................................20
I3 Harmonic Angles EH.........................................................................................................................20
Setpoint Status SP1-SP16 (bitmap).....................................................................................................20
4 DATA SCALES AND UNITS............................................................................21
Data Scales..........................................................................................................................................21
Data Units............................................................................................................................................21
5 EGD IMPLEMENTATION PROFILE.................................................................22
5
1 General
This document specifies the GE EGD (Ethernet Global Data) messaging protocol used to transfer
data between the PM172 EGD producer and EGD consumer nodes. The document provides the
complete information necessary to develop third-party communications software capable of
communication with the Series PM172 devices. Additional information concerning communications
operation, configuring the communications parameters, and communications connections is found in
"Series PM172 Powermeters, Installation and Operation Manual".
IMPORTANT
In 3-wire connection schemes, the unbalanced current and phase readings for power factor, active power,
and reactive power will be zeros, because they have no meaning. Only the total three-phase power values will
be shown.
Designations used in the guide:
E - available in the meters with the E and EH suffixes
EH - available in the meters with the EH suffix
6
2 EGD Messaging Protocol
The PM172 implements an EGD data producer that supports up to 4 data exchanges. Each data
exchange is individually configurable through the supplemental PAS software and can produce and
send data to the same or to different consuming nodes. The implementation is based on the Ethernet
Global Data Protocol Specification V2.01. See the EGD implementation profile in Section 5 for EGD
implementation and configuration details.
The PM172 does not provide a command port and cannot receive command PDU’s.
2.1 EGD Production Exchanges
The PM172 production exchanges use exchange IDs in the range of 1 to 4. For the configuration
signature, refer to the EGD implementation profile in Section 5. Each exchange sends data messages
to the EGD UDP data port 18246 on the consuming node at a fixed periodic rate.
For each production exchange, the following parameters are configurable:
1. Destination IP address of the consuming node.
2. Production period.
3. Point address ranges of the production data to be sent via an exchange.
4. Data element type for each address range.
Up to 30 point ranges can be defined for each exchange that may specify a single point or a range of
contiguous points. An exchange can send a total of 480 bytes of production data. This provides up to
120 data points per exchange using floating-point or double word data format, or 240 points per
exchange using word format.
A configured exchange can be temporarily put into the pending state (disabled), and then resumed
(enabled) whenever needed.
2.2 Data Types
Data transferred through the EGD exchanges is represented in little endian format: the bytes are
ordered from least significant at the highest address to most significant at the lowest address. Data can
be transferred in word (16-bit) or double word (32-bit) integer format, or in IEEE single precision
floating-point format. Negative integer numbers are represented in 2-complement code.
Though data can be requested in floating-point format, it is actually stored in the device memory in
integer format. The device point map in Section 3 shows an actual device storage type for each data
point, a data range and available precision. If you use word or double word integer format and the data
measurement units are indicated for the point with decimal places, multiply received data by the units
to get readings in real engineering units.
If you use 16-bit word format for transferring 32-bit data, beware of the possible over-range. The value
range allowed for 16-bit word data is 0 to 65535 for unsigned numbers and –32768 to 32767 for signed
numbers. If the requested data exceeds a 16-bit word range, it is truncated to the maximum allowable
negative or positive number. When over-range occurs, an unsigned value is reported as 65535, a
positive signed value as 32767 and a negative signed value as -32768.
2.3 Point Address Ranges
Device data points are addressed using 16-bit point identifiers (ID). Available device data points are
listed in Section 3. The point IDs are given in both decimal notation and in four-digit hexadecimal
notation.
7
2.4 EGD Production Periods
The PM172 exchanges can provide production periods from 70 ms to 10 minutes in 10 ms increments.
Though lower settings are allowed, the actual production period in most cases will not be less than 70
ms.
In the event that other active device TCP ports transfer data, like Modbus or DNP TCP/IP ports that
can run along with the EGD producer, the production periods may increase. At least 60 ms timeout is
highly recommended.
8
3 Device Point Map
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
0 0x0000 None 0 UINT16 R
Special Inputs
257 0x0101 Phase rotation order 0=error, 1=positive (ABC),
2=negative (CBA)
UINT16 R
768 0x0300 Event Flags (bitmap) EH 0x0000-0x00FF UINT16 R
1536 0x0600 Digital Inputs DI1-DI2 (bitmap) 0x0000-0x0003 UINT16 R
2048 0x0800 Relay Outputs RO1-RO2 (bitmap) 0x0000-0x0003 UINT16 R
Counters
2560 0x0A00 Counter #1 0-999,999 UINT32 R
2561 0x0A01 Counter #2 0-999,999 UINT32 R
2562 0x0A02 Counter #3 0-999,999 UINT32 R
2563 0x0A03 Counter #4 0-999,999 UINT32 R
1-Cycle Phase Values
3072 0x0C00 V1/V12 Voltage 0-Vmax U1 UINT32 R 1
3073 0x0C01 V2/V23 Voltage 0-Vmax U1 UINT32 R 1
3074 0x0C02 V3/V31 Voltage 0-Vmax U1 UINT32 R 1
3075 0x0C03 I1 Current 0-Imax U2 UINT32 R
3076 0x0C04 I2 Current 0-Imax U2 UINT32 R
3077 0x0C05 I3 Current 0-Imax U2 UINT32 R
3078 0x0C06 kW L1 -Pmax-Pmax U3 INT32 R
3079 0x0C07 kW L2 -Pmax-Pmax U3 INT32 R
3080 0x0C08 kW L3 -Pmax-Pmax U3 INT32 R
3081 0x0C09 kvar L1 -Pmax-Pmax U3 INT32 R
3082 0x0C0A kvar L2 -Pmax-Pmax U3 INT32 R
3083 0x0C0B kvar L3 -Pmax-Pmax U3 INT32 R
3084 0x0C0C kVA L1 0-Pmax U3 UINT32 R
3085 0x0C0D kVA L2 0-Pmax U3 UINT32 R
3086 0x0C0E kVA L3 0-Pmax U3 UINT32 R
3087 0x0C0F Power factor L1 -1000-1000
×0.001
INT16 R
3088 0x0C10 Power factor L2 -1000-1000
×0.001
INT16 R
3089 0x0C11 Power factor L3 -1000-1000
×0.001
INT16 R
3090 0x0C12 V1/V12 Voltage THD 0-9999
×0.1%
UINT16 R 1 4-cycle value
3091 0x0C13 V2/V23 Voltage THD 0-9999
×0.1%
UINT16 R 1 4-cycle value
3092 0x0C14 V3/V31 Voltage THD 0-9999
×0.1%
UINT16 R 1 4-cycle value
3093 0x0C15 I1 Current THD 0-9999
×0.1%
UINT16 R 4-cycle value
3094 0x0C16 I2 Current THD 0-9999
×0.1%
UINT16 R 4-cycle value
3095 0x0C17 I3 Current THD 0-9999
×0.1%
UINT16 R 4-cycle value
3096 0x0C18 I1 K-Factor 10-9999
×0.1
UINT16 R 4-cycle value
3097 0x0C19 I2 K-Factor 10-9999
×0.1
UINT16 R 4-cycle value
9
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
3098 0x0C1A I3 K-Factor 10-9999
×0.1
UINT16 R 4-cycle value
3099 0x0C1B I1 Current TDD 0-1000
×0.1%
UINT16 R 4-cycle value
3100 0x0C1C I2 Current TDD 0-1000
×0.1%
UINT16 R 4-cycle value
3101 0x0C1D I3 Current TDD 0-1000
×0.1%
UINT16 R 4-cycle value
3102 0x0C1E V12 Voltage 0-Vmax U1 UINT16 R
3103 0x0C1F V23 Voltage 0-Vmax U1 UINT16 R
3104 0x0C20 V31 Voltage 0-Vmax U1 UINT16 R
1-Cycle Total Values
3840 0x0F00 Total kW -Pmax-Pmax U3 INT32 R
3841 0x0F01 Total kvar -Pmax-Pmax U3 INT32 R
3842 0x0F02 Total kVA 0-Pmax U3 UINT32 R
3843 0x0F03 Total PF -1000-1000
×0.001
INT16 R
3844 0x0F04 Total PF lag 0-1000
×0.001
UINT16 R
3845 0x0F05 Total PF lead 0-1000
×0.001
UINT16 R
3846 0x0F06 Total kW import 0-Pmax U3 UINT32 R
3847 0x0F07 Total kW export 0-Pmax U3 UINT32 R
3848 0x0F08 Total kvar import 0-Pmax U3 UINT32 R
3849 0x0F09 Total kvar export 0-Pmax U3 UINT32 R
3850 0x0F0A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R 1
3851 0x0F0B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
3852 0x0F0C 3-phase average current 0-Imax U2 UINT32 R
1-Cycle Auxiliary Values
4096 0x1000 Not used UINT32 R
4097 0x1001 In (neutral) Current 0-Imax U2 UINT32 R
4098 0x1002 Frequency 0-Fmax
×0.01Hz
UINT16 R
4099 0x1003 Voltage unbalance 0-3000
×0.1%
UINT16 R
4100 0x1004 Current unbalance 0-3000
×0.1%
UINT16 R
Phasor
4224 0x1080 V1/V12 Voltage magnitude 0-Vmax U1 UINT32 R 1
4225 0x1081 V2/V23 Voltage magnitude 0-Vmax U1 UINT32 R 1
4226 0x1082 V3/V31 Voltage magnitude 0-Vmax U1 UINT32 R 1
4227 0x1083 Not used UINT32 R
4228 0x1084 I1 Current magnitude 0-Imax U2 UINT32 R
4229 0x1085 I2 Current magnitude 0-Imax U2 UINT32 R
4230 0x1086 I3 Current magnitude 0-Imax U2 UINT32 R
4231 0x1087 Not used UINT32 R
4232 0x1088 V1/V12 Voltage angle -1800-1800
×0.1º
INT16 R 1
4233 0x1089 V2/V23 Voltage angle -1800-1800
×0.1º
INT16 R 1
4234 0x108A V3/V31 Voltage angle -1800-1800
×0.1º
INT16 R 1
4235 0x108B Not used INT16 R
4236 0x108C I1 Current angle -1800-1800
×0.1º
INT16 R
4237 0x108D I2 Current angle -1800-1800
×0.1º
INT16 R
10
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
4238 0x108E I3 Current angle -1800-1800
×0.1º
INT16 R
4239 0x108F Not used INT16 R
1-Second Phase Values
4352 0x1100 V1/V12 Voltage 0-Vmax U1 UINT32 R 1
4353 0x1101 V2/V23 Voltage 0-Vmax U1 UINT32 R 1
4354 0x1102 V3/V31 Voltage 0-Vmax U1 UINT32 R 1
4355 0x1103 I1 Current 0-Imax U2 UINT32 R
4356 0x1104 I2 Current 0-Imax U2 UINT32 R
4357 0x1105 I3 Current 0-Imax U2 UINT32 R
4358 0x1106 kW L1 -Pmax-Pmax U3 INT32 R
4359 0x1107 kW L2 -Pmax-Pmax U3 INT32 R
4360 0x1108 kW L3 -Pmax-Pmax U3 INT32 R
4361 0x1109 kvar L1 -Pmax-Pmax U3 INT32 R
4362 0x110A kvar L2 -Pmax-Pmax U3 INT32 R
4363 0x110B kvar L3 -Pmax-Pmax U3 INT32 R
4364 0x110C kVA L1 0-Pmax U3 UINT32 R
4365 0x110D kVA L2 0-Pmax U3 UINT32 R
4366 0x110E kVA L3 0-Pmax U3 UINT32 R
4367 0x110F Power factor L1 -1000-1000
×0.001
INT16 R
4368 0x1110 Power factor L2 -1000-1000
×0.001
INT16 R
4369 0x1111 Power factor L3 -1000-1000
×0.001
INT16 R
4370 0x1112 V1/V12 Voltage THD 0-9999
×0.1%
UINT16 R 1 3-sec value
4371 0x1113 V2/V23 Voltage THD 0-9999
×0.1%
UINT16 R 1 3-sec value
4372 0x1114 V3/V31 Voltage THD 0-9999
×0.1%
UINT16 R 1 3-sec value
4373 0x1115 I1 Current THD 0-9999
×0.1%
UINT16 R 3-sec value
4374 0x1116 I2 Current THD 0-9999
×0.1%
UINT16 R 3-sec value
4375 0x1117 I3 Current THD 0-9999
×0.1%
UINT16 R 3-sec value
4376 0x1118 I1 K-Factor 10-9999
×0.1
UINT16 R 3-sec value
4377 0x1119 I2 K-Factor 10-9999
×0.1
UINT16 R 3-sec value
4378 0x111A I3 K-Factor 10-9999
×0.1
UINT16 R 3-sec value
4379 0x111B I1 Current TDD 0-1000
×0.1%
UINT16 R 3-sec value
4380 0x111C I2 Current TDD 0-1000
×0.1%
UINT16 R 3-sec value
4381 0x111D I3 Current TDD 0-1000
×0.1%
UINT16 R 3-sec value
4382 0x111E V12 Voltage 0-Vmax U1 UINT16 R
4383 0x111F V23 Voltage 0-Vmax U1 UINT16 R
4384 0x1120 V31 Voltage 0-Vmax U1 UINT16 R
1-Second Total Values
5120 0x1400 Total kW -Pmax-Pmax U3 INT32 R
5121 0x1401 Total kvar -Pmax-Pmax U3 INT32 R
5122 0x1402 Total kVA 0-Pmax U3 UINT32 R
5123 0x1403 Total PF -1000-1000
×0.001
INT16 R
5124 0x1404 Total PF lag 0-1000
×0.001
UINT16 R
11
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
5125 0x1405 Total PF lead 0-1000
×0.001
UINT16 R
5126 0x1406 Total kW import 0-Pmax U3 UINT32 R
5127 0x1407 Total kW export 0-Pmax U3 UINT32 R
5128 0x1408 Total kvar import 0-Pmax U3 UINT32 R
5129 0x1409 Total kvar export 0-Pmax U3 UINT32 R
5130 0x140A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R 1
5131 0x140B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
5132 0x140C 3-phase average current 0-Imax U2 UINT32 R
1-Second Auxiliary Values
5376 0x1500 Not used UINT32 R
5377 0x1501 In (neutral) Current 0-Imax U2 UINT32 R
5378 0x1502 Frequency 0-Fmax
×0.01Hz
UINT16 R
5379 0x1503 Voltage unbalance 0-3000
×0.1%
UINT16 R
5380 0x1504 Current unbalance 0-3000
×0.1%
UINT16 R
Present Harmonic Demands
5504 0x1580 V1/V12 THD demand 0-9999
×0.1%
UINT16 R 1
5505 0x1581 V2/V23 THD demand 0-9999
×0.1%
UINT16 R 1
5506 0x1582 V3/V31 THD demand 0-9999
×0.1%
UINT16 R 1
5507 0x1583 Not used UINT16 R
5508 0x1584 I1 THD demand 0-9999
×0.1%
UINT16 R
5509 0x1585 I2 THD demand 0-9999
×0.1%
UINT16 R
5510 0x1586 I3 THD demand 0-9999
×0.1%
UINT16 R
5511 0x1587 Not used 0-9999
×0.1%
UINT16 R
5512 0x1588 I1 TDD demand 0-1000
×0.1%
UINT16 R
5513 0x1589 I2 TDD demand 0-1000
×0.1%
UINT16 R
5514 0x158A I3 TDD demand 0-1000
×0.1%
UINT16 R
5515 0x158B Not used 0-1000
×0.1%
UINT16 R
Present Volt, Ampere and Power Demands
5632 0x1600 V1/V12 Volt demand 0-Vmax U1 UINT32 R 1
5633 0x1601 V2/V23 Volt demand 0-Vmax U1 UINT32 R 1
5634 0x1602 V3/V31 Volt demand 0-Vmax U1 UINT32 R 1
5635 0x1603 I1 Ampere demand 0-Imax U2 UINT32 R
5636 0x1604 I2 Ampere demand 0-Imax U2 UINT32 R
5637 0x1605 I3 Ampere demand 0-Imax U2 UINT32 R
5638 0x1606 kW import block demand 0-Pmax U3 UINT32 R
5639 0x1607 kvar import block demand 0-Pmax U3 UINT32 R
5640 0x1608 kVA block demand 0-Pmax U3 UINT32 R
5641 0x1609 kW import sliding window demand 0-Pmax U3 UINT32 R
5642 0x160A kvar import sliding window demand 0-Pmax U3 UINT32 R
5643 0x160B kVA sliding window demand 0-Pmax U3 UINT32 R
5644 0x160C Not used 0 UINT32 R
5645 0x160D Not used 0 UINT32 R
12
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
5646 0x160E Not used 0 UINT32 R
5647 0x160F kW import accumulated demand 0-Pmax U3 UINT32 R
5648 0x1610 kvar import accumulated demand 0-Pmax U3 UINT32 R
5649 0x1611 kVA accumulated demand 0-Pmax U3 UINT32 R
5650 0x1612 kW import predicted sliding window demand 0-Pmax U3 UINT32 R
5651 0x1613 kvar import predicted sliding window demand 0-Pmax U3 UINT32 R
5652 0x1614 kVA predicted sliding window demand 0-Pmax U3 UINT32 R
5653 0x1615 PF (import) at Max. kVA sliding window demand 0-1000
×0.001
UINT16 R
5654 0x1616 kW export block demand 0-Pmax U3 UINT32 R
5655 0x1617 kvar export block demand 0-Pmax U3 UINT32 R
5656 0x1618 kW export sliding window demand 0-Pmax U3 UINT32 R
5657 0x1619 kvar export sliding window demand 0-Pmax U3 UINT32 R
5658 0x161A kW export accumulated demand 0-Pmax U3 UINT32 R
5659 0x161B kvar export accumulated demand 0-Pmax U3 UINT32 R
5660 0x161C kW export predicted sliding window demand 0-Pmax U3 UINT32 R
5661 0x161D kvar export predicted sliding window demand 0-Pmax U3 UINT32 R
Total Energies E
5888 0x1700
kWh import 0-10
9
-1
1 kWh UINT32 R
5889 0x1701 kWh export
0-10
9
-1
1 kWh UINT32 R
5890 0x1702 Not used INT32 R
5891 0x1703 Not used UINT32 R
5892 0x1704 kvarh import
0-10
9
-1
1 kvarh UINT32 R
5893 0x1705 kvarh export
0-10
9
-1
1 kvarh UINT32 R
5894 0x1706 Not used INT32 R
5895 0x1707 Not used UINT32 R
5896 0x1708 kVAh total
0-10
9
-1
1 kVAh UINT32 R
5897
-5900
0x1709
-0x170C
Not used UINT32 R
5901 0x170D
Harmonic kWh import
EH
0-109-1
1 kWh UINT32 R
5902 0x170E Harmonic kWh export EH
0-10
9
-1
1 kWh UINT32 R
5903
-5904
0x170F
-0x1710
Not used UINT32 R
5905 0x1711 Harmonic kVAh total
EH
0-10
9
-1
1 kVAh UINT32 R
Summary Energy Registers E
6016 0x1780
Summary energy register #1 0-10
9
-1
1 kWh UINT32 R
6017 0x1781
Summary energy register #2 0-10
9
-1
1 kWh UINT32 R
…
6023 0x1787
Summary energy register #8 0-10
9
-1
1 kWh UINT32 R
Phase Energies E
6144 0x1800
kWh import L1 0-10
9
-1
1 kWh UINT32 R
6145 0x1801
kWh import L2 0-10
9
-1
1 kWh UINT32 R
13
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
6146 0x1802
kWh import L3 0-10
9
-1
1 kWh UINT32 R
6147 0x1803 kvarh import L1
0-10
9
-1
1 kvarh UINT32 R
6148 0x1804 kvarh import L2
0-10
9
-1
1 kvarh UINT32 R
6149 0x1805 kvarh import L3
0-10
9
-1
1 kvarh UINT32 R
6150 0x1806 kVAh total L1
0-10
9
-1
1 kVAh UINT32 R
6151 0x1807 kVAh total L2
0-10
9
-1
1 kVAh UINT32 R
6152 0x1808 kVAh total L3
0-10
9
-1
1 kVAh UINT32 R
V1/V12 Harmonic Distortions EH
1
6400 0x1900
H01 Harmonic distortion
0-10000 0.01% UINT16 R
6401 0x1901
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
6439 0x1927
H40 Harmonic distortion
0-10000 0.01% UINT16 R
V2/V23 Harmonic Distortions EH
1
6656 0x1A00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
6657 0x1A01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
6695 0x1A27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
V3/V31 Harmonic Distortions EH
1
6912 0x1B00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
6913 0x1B01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
6951 0x1B27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
I1 Harmonic Distortions EH
7168 0x1C00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
7169 0x1C01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
7207 0x1C27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
I2 Harmonic Distortions EH
7424 0x1D00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
7425 0x1D01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
7464 0x1D27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
I3 Harmonic Distortions EH
7680 0x1E00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
7681 0x1E01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
7719 0x1E27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
Fundamental (H01) Phase Values 4-cycle values
10496 0x2900 V1/V12 Voltage 0-Vmax U1 UINT32 R 1
10497 0x2901 V2/V23 Voltage 0-Vmax U1 UINT32 R 1
14
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
10498 0x2902 V3/V31 Voltage 0-Vmax U1 UINT32 R 1
10499 0x2903 I1 Current 0-Imax U2 UINT32 R
10500 0x2904 I2 Current 0-Imax U2 UINT32 R
10501 0x2905 I3 Current 0-Imax U2 UINT32 R
10502 0x2906 kW L1 -Pmax-Pmax U3 INT32 R
10503 0x2907 kW L2 -Pmax-Pmax U3 INT32 R
10504 0x2908 kW L3 -Pmax-Pmax U3 INT32 R
10505 0x2909 kvar L1 -Pmax-Pmax U3 INT32 R
10506 0x290A kvar L2 -Pmax-Pmax U3 INT32 R
10507 0x290B kvar L3 -Pmax-Pmax U3 INT32 R
10508 0x290C kVA L1 0-Pmax U3 UINT32 R
10509 0x290D kVA L2 0-Pmax U3 UINT32 R
10510 0x290E kVA L3 0-Pmax U3 UINT32 R
10511 0x290F Power factor L1 -1000-1000
×0.001
INT16 R
10512 0x2910 Power factor L2 -1000-1000
×0.001
INT16 R
10513 0x2911 Power factor L3 -1000-1000
×0.001
INT16 R
Harmonic Total Values 4-cycle values
10752 0x2A00 Total fundamental kW -Pmax-Pmax U3 INT32 R
10753 0x2A01 Total fundamental kvar -Pmax-Pmax U3 INT32 R
10754 0x2A02 Total fundamental kVA 0-Pmax U3 UINT32 R
10755 0x2A03 Total fundamental PF -1000-1000
×0.001
INT16 R
10755 0x2A04 Total harmonic kW EH -Pmax-Pmax U3 INT32 R
10756 0x2A05 Not used INT32 R
10757 0x2A06 Total harmonic kVA EH 0-Pmax U3 UINT32 R
10758 0x2A07 Not used INT16 R
Minimum 1-Cycle Phase Values
11264 0x2C00 V1/V12 Voltage 0-Vmax U1 UINT32 R 1
11265 0x2C01 V2/V23 Voltage 0-Vmax U1 UINT32 R 1
11266 0x2C02 V3/V31 Voltage 0-Vmax U1 UINT32 R 1
11267 0x2C03 I1 Current 0-Imax U2 UINT32 R
11268 0x2C04 I2 Current 0-Imax U2 UINT32 R
11269 0x2C05 I3 Current 0-Imax U2 UINT32 R
0x2C06
-0x2C11
Not used 0 INT32 R
11276 0x2C12 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R 1 4-cycle value
11277 0x2C13 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R 1 4-cycle value
11278 0x2C14 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R 1 4-cycle value
11279 0x2C15 I1 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
11280 0x2C16 I2 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
11281 0x2C17 I3 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
11282 0x2C18 I1 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
11283 0x2C19 I2 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
15
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
11284 0x2C1A I3 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
11285 0x2C1B I1 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
11286 0x2C1C I2 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
11287 0x2C1D I3 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
Minimum 1-Cycle Total Values
11520 0x2D00 Total kW -Pmax-Pmax U3 INT32 R
11521 0x2D01 Total kvar -Pmax-Pmax U3 INT32 R
11522 0x2D02 Total kVA 0-Pmax U3 UINT32 R
11523 0x2D03 Total PF 0-1000
×0.001
UINT32 R Absolute value
Minimum 1-Cycle Auxiliary Values
11776 0x2E00 Not used UINT32 R
11777 0x2E01 In Current 0-Imax U2 UINT32 R
11778 0x2E02 Frequency 0-Fmax
×0.01Hz
UINT32 R
Maximum 1-Cycle Phase Values
13312 0x3400 V1/V12 Voltage 0-Vmax U1 UINT32 R 1
13313 0x3401 V2/V23 Voltage 0-Vmax U1 UINT32 R 1
13314 0x3402 V3/V31 Voltage 0-Vmax U1 UINT32 R 1
13315 0x3403 I1 Current 0-Imax U2 UINT32 R
13316 0x3404 I2 Current 0-Imax U2 UINT32 R
13317 0x3405 I3 Current 0-Imax U2 UINT32 R
0x3406
-0x3411
Not used 0 INT32 R
13324 0x3412 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R 1 4-cycle value
13325 0x3413 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R 1 4-cycle value
13326 0x3414 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R 1 4-cycle value
13327 0x3415 I1 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
13328 0x3416 I2 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
13329 0x3417 I3 Current THD 0-9999
×0.1%
UINT32 R 4-cycle value
13330 0x3418 I1 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
13331 0x3419 I2 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
13332 0x341A I3 K-Factor 10-9999
×0.1
UINT32 R 4-cycle value
13333 0x341B I1 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
13334 0x341C I2 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
13335 0x341D I3 Current TDD 0-1000
×0.1%
UINT32 R 4-cycle value
Maximum 1-Cycle Total Values
13568 0x3500 Total kW -Pmax-Pmax U3 INT32 R
13569 0x3501 Total kvar -Pmax-Pmax U3 INT32 R
13570 0x3502 Total kVA 0-Pmax U3 UINT32 R
13571 0x3503 Total PF 0-1000
×0.001
UINT32 R Absolute value
Maximum 1-Cycle Auxiliary Values
13824 0x3600 Not used UINT32 R
13825 0x3601 In Current 0-Imax U2 UINT32 R
16
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
13826 0x3602 Frequency 0-Fmax
×0.01Hz
UINT32 R
Maximum Demands
14080 0x3700 V1/V12 Maximum volt demand 0-Vmax U1 UINT32 R 1
14081 0x3701 V2/V23 Maximum volt demand 0-Vmax U1 UINT32 R 1
14082 0x3702 V3/V31 Maximum volt demand 0-Vmax U1 UINT32 R 1
14083 0x3703 I1 Maximum ampere demand 0-Imax U2 UINT32 R
14084 0x3704 I2 Maximum ampere demand 0-Imax U2 UINT32 R
14085 0x3705 I3 Maximum ampere demand 0-Imax U2 UINT32 R
14086 0x3706 Not used UINT32 R
14087 0x3707 Not used UINT32 R
14088 0x3708 Not used UINT32 R
14089 0x3709 Maximum kW import sliding window demand 0-Pmax U3 UINT32 R
14090 0x370A Maximum kvar import sliding window demand 0-Pmax U3 UINT32 R
14091 0x370B Maximum kVA sliding window demand 0-Pmax U3 UINT32 R
14092 0x3737 Not used UINT32 R
14093 0x370D Not used UINT32 R
14094 0x370E Not used UINT32 R
14095 0x370F Maximum kW export sliding window demand 0-Pmax U3 UINT32 R
14096 0x3710 Maximum kvar export sliding window demand 0-Pmax U3 UINT32 R
Maximum Harmonic Demands
14336 0x3880 V1/V12 THD demand 0-9999
×0.1%
UINT32 R 1
14337 0x3881 V2/V23 THD demand 0-9999
×0.1%
UINT32 R 1
14338 0x3882 V3/V31 THD demand 0-9999
×0.1%
UINT32 R 1
14339 0x3883 Not used UINT32 R
14340 0x3884 I1 THD demand 0-9999
×0.1%
UINT32 R
14341 0x3885 I2 THD demand 0-9999
×0.1%
UINT32 R
14342 0x3886 I3 THD demand 0-9999
×0.1%
UINT32 R
14343 0x3887 Not used UINT32 R
14344 0x3888 I1 TDD demand 0-1000
×0.1%
UINT32 R
14345 0x3889 I2 TDD demand 0-1000
×0.1%
UINT32 R
14346 0x388A I3 TDD demand 0-1000
×0.1%
UINT32 R
14347 0x388B Not used UINT32 R
Scaled Analog Inputs
15104 0x3B00 Analog input AI1 AImin - AImax (programmable scale) UINT32 R
15105 0x3B01 Analog input AI2 AImin - AImax (programmable scale) UINT32 R
Raw Analog Inputs
15232 0x3B80 Analog input AI1 0-4095 UINT32 R
15233 0x3B81 Analog input AI2 0-4095 UINT32 R
TOU Parameters E
15360 0x3C00 Active tariff 0-7 UINT32 R
15361 0x3C01 Active profile 0-15:
0-3 = Season 1 Profile #1-4,
UINT32 R
17
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
4-7 = Season 2 Profile #1-4,
8-11 = Season 3 Profile #1-4,
12-15 = Season 4 Profile #1-4
Scaled Analog Outputs
15488 0x3C80 Analog output AO1 0-4095 UINT32 R
15489 0x3C81 Analog output AO2 0-4095 UINT32 R
TOU Energy Register #1 E
15616 0x3D00
Tariff #1 register 0-10
9
-1
1 kWh UINT32 R
15617 0x3D01
Tariff #2 register 0-10
9
-1
1 kWh UINT32 R
... … R
15623 0x3D07
Tariff #8 register 0-10
9
-1
1 kWh UINT32 R
TOU Energy Register #2 E
15872 0x3E00
Tariff #1 register 0-10
9
-1
1 kWh UINT32 R
15873 0x3E01
Tariff #2 register 0-10
9
-1
1 kWh UINT32 R
... … R
15879 0x3E07
Tariff #8 register 0-10
9
-1
1 kWh UINT32 R
TOU Energy Register #3 E
16128 0x3F00
Tariff #1 register 0-10
9
-1
1 kWh UINT32 R
16129 0x3F01
Tariff #2 register 0-10
9
-1
1 kWh UINT32 R
... … R
16135 0x3F07
Tariff #8 register 0-10
9
-1
1 kWh UINT32 R
TOU Energy Register #4 E
16384 0x4000
Tariff #1 register 0-10
9
-1
1 kWh UINT32 R
16385 0x4001
Tariff #2 register 0-10
9
-1
1 kWh UINT32 R
... … R
16391 0x4007
Tariff #8 register 0-10
9
-1
1 kWh UINT32 R
TOU Energy Register #5 E
16640 0x4100
Tariff #1 register 0-10
9
-1
1 kWh UINT32 R
16641 0x4101
Tariff #2 register 0-10
9
-1
1 kWh UINT32 R
... … R
16647 0x4107
Tariff #8 register 0-10
9
-1
1 kWh UINT32 R
TOU Energy Register #6 E
16896 0x4200
Tariff #1 register 0-10
9
-1
1 kWh UINT32 R
16897 0x4201
Tariff #2 register 0-10
9
-1
1 kWh UINT32 R
... … R
16903 0x4207
Tariff #8 register 0-10
9
-1
1 kWh UINT32 R
TOU Energy Register #7 E
17152 0x4300
Tariff #1 register 0-10
9
-1
1 kWh UINT32 R
17153 0x4301
Tariff #2 register 0-10
9
-1
1 kWh UINT32 R
... … R
18
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
17159 0x4307
Tariff #8 register 0-10
9
-1
1 kWh UINT32 R
TOU Energy Register #8 E
17408 0x4400
Tariff #1 register 0-10
9
-1
1 kWh UINT32 R
17409 0x4401
Tariff #2 register 0-10
9
-1
1 kWh UINT32 R
... … R
17415 0x4407
Tariff #8 register 0-10
9
-1
1 kWh UINT32 R
Summary Energy Accumulated Demands E
17664 0x4500
Summary register #1 demand
0-Pmax U3 UINT32 R
17665 0x4501
Summary register #2 demand
0-Pmax U3 UINT32 R
…
17671 0x4507
Summary register #8 demand
0-Pmax U3 UINT32 R
Summary Energy Block Demands E
17792 0x4580
Summary register #1 demand
0-Pmax U3 UINT32 R
17793 0x4581
Summary register #2 demand
0-Pmax U3 UINT32 R
…
17799 0x4587
Summary register #8 demand
0-Pmax U3 UINT32 R
Summary Energy Sliding Window DemandsE
17920 0x4600
Summary register #1 demand
0-Pmax U3 UINT32 R
17921 0x4601
Summary register #2 demand
0-Pmax U3 UINT32 R
…
17927 0x4607
Summary register #8 demand
0-Pmax U3 UINT32 R
Summary Energy Maximum Demands E
18304 0x4780
Summary register #1 maximum demand
0-Pmax U3 UINT32 R
18305 0x4781
Summary register #2 maximum demand
0-Pmax U3 UINT32 R
…
18311 0x4787
Summary register #8 maximum demand
0-Pmax U3 UINT32 R
TOU Maximum Demand Register #1 E
18432 0x4800
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
18433 0x4801
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
... … R
18439 0x4807
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
TOU Maximum Demand Register #2 E
18688 0x4900
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
18689 0x4901
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
... … R
18795 0x4907
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
TOU Maximum Demand Register #3 E
18944 0x4A00
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
18945 0x4A01
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
... … R
19
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
18951 0x4A07
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
TOU Maximum Demand Register #4 E
18560 0x4880
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
18561 0x4881
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
18567 0x4887
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
TOU Maximum Demand Register #5 E
18816 0x4980
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
18817 0x4981
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
18823 0x4987
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
TOU Maximum Demand Register #6 E
19072 0x4A80
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
19073 0x4A81
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
19079 0x4A87
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
TOU Maximum Demand Register #7 E
21248 0x5300
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
21249 0x5301
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
21255 0x5307
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
TOU Maximum Demand Register #8 E
21376 0x5380
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
21377 0x5381
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
21383 0x5387
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
V1/V12 Harmonic Angles EH
1, 3
25600 0x6400
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
25601 0x6400
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
25639 0x6427
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
V2/V23 Harmonic Angles EH
1, 3
25856 0x6500
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
25857 0x6500
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
25895 0x6527
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
V1/V31 Harmonic Angles EH
1, 3
26112 0x6600
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
26113 0x6600
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
20
Point ID
(Dec)
Point ID
(Hex)
Description
Options/Range
2
Units2
Type R/W Notes
26151 0x6627
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
I1 Harmonic Angles EH
3
26368 0x6700
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
26369 0x6700
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
26407 0x6727
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
I2 Harmonic Angles EH
3
26624 0x6800
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
26625 0x6800
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
26663 0x6827
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
I3 Harmonic Angles EH
3
26880 0x6900
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
26881 0x6900
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
26919 0x6927
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
31744 0x7C00 Setpoint Status SP1-SP16 (bitmap) 0x0000-0xFFFF UINT16 R
NOTES:
Energy and power demand readings are only available in the meters with suffixes E and EH.
1
Voltage and voltage harmonics readings:
When the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.
When the 4LN3, 4LL3, 3LN3, 3LL3, 3BLN3 or 3BLL3 wiring mode is selected, the voltage harmonics will be line-to-neutral; for any other wiring mode, they will be line-to-line.
2
For volts, amps, power and frequency scales and units, refer to Section 4 ”Data Scales and Units”.
3
Harmonic angles are referenced to the fundamental voltage harmonic H01 on phase L1.
21
4 Data Scales and Units
Code Condition Value/Range Notes
Data Scales
Vmax
Voltage scale × PT Ratio, V
2
Imax
Current scale (2A/10A) × CT Ratio = CT Primary current × 2, A
1, 3
Wiring 4LN3, 3LN3, 3BLN3
Vmax × Imax × 3, W
Pmax
Wiring 4LL3, 3LL3, 3BLL3,
3OP2, 3OP3, 3DIR2
Vmax × Imax × 2, W
Nominal frequency 25, 50 or
60 Hz
100 Hz Fmax
Nominal frequency 400Hz 500 Hz
+/-1mA
AImin = -AI full scale × 2
AImax = AI full scale × 2
0-20mA AImin = AI zero scale
AImax = AI full scale
4-20mA AImin = AI zero scale
AImax = AI full scale
AImin
AImax
0-1mA AImin = AI zero scale
AImax = AI full scale
Data Units
PT Ratio = 1, Integer 0.1 V
PT Ratio > 1, Integer 1 V
PT Ratio = 1, Float 0.1 V
U1
PT Ratio > 1, Float 0.001 kV
U2 Integer and Float 0.01 A
PT Ratio = 1, Integer 1 W/Var/VA
PT Ratio > 1, Integer 1 kW/kvar/kVA
PT Ratio = 1, Float 0.001 kW/kvar/kVA
U3
PT Ratio > 1, Float 0.001 MW/Mvar/MVA
1
CT Ratio = CT primary current/CT secondary current
2
The default Voltage scale is 144V (120V + 20%). You can change it via the Device Options setup in PAS.
3
The default Current scale is 2 × CT secondary current (2 × 1A or 2 × 5A depending on the order).
22
5 EGD Implementation Profile
EGD Device: SATEC Model PM172
Maximum Exchanges: 4
Support Command Port: No
Support Masked Write: No
Data Coherency and Alignment:
Data Element Type Size in Bytes Alignment Requirements Coherent Transfer
Word 2 Even Yes
Double word 4 Divisible by 4 Yes
Float 4 Divisible by 4 Yes
Array up to 480 Same as elements Yes
Protocol Version Number (PVN): 1
Configuration Signature: 1.1
Production Data Size: up to 480 bytes
Production Rate: 70-600000 ms
Loading...
