Halogen
Halogen
PAR16/PAR20/PAR30
PAR16/PAR20/PAR30
Whiter light, brighter colors, precise beam control.
Not Shown Actual Size
P AR16 P AR20 P AR30
SATCO PAR HALOGEN LAMPS
QUALITY • VALUE • PERFORMANCE
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours CBCP Lumens Filament M.O.L. Type Ctn.
halogen lamps
120
45 P AR16 Med. S2200
45 P AR16 Med. S2300
60 P AR16 Med. S2201 60PAR16/HAL/NFL NFL 30º 120V 2500 1400 600 CC–8 3 3/16”Box15
60 P AR16 Med. S2301 60PAR16/HAL/NFL NFL 30º 130V 2500 1400 600 CC–8 3 3/16”Box15
60 P AR16 Med. S2202 60PAR16/HAL/NSP NSP 10º 120V 2500 4700 550 CC–8 3 3/16”Box15
60 P AR16 Med. S2302 60PAR16/HAL/NSP NSP 10º 130V 2500 4700 550 CC–8 3 3/16”Box15
75 P AR16 Med. S2203 75PAR16/HAL/NFL NFL 30º 120V 2500 1800 850 CC–8 3 3/16”Box15
75 P AR16 Med. S2303 75PAR16/HAL/NFL NFL 30º 130V 2500 1800 850 CC–8 3 3/16”Box15
75 P AR16 Med. S2204 75PAR16/HAL/NSP NSP10º 120V 2500 7000 850 CC–8 3 3/16”Box15
75 P AR16 Med. S2304 75PAR16/HAL/NSP NSP10º 130V 2500 7000 850 CC–8 3 3/16”Box15
50 P AR20 Med. S2205 50PAR20/HAL/NFL NFL 34º 120V 2500 1300 495 CC–8 3 1/4”Box15
50 P AR20 Med. S2305 50PAR20/HAL/NFL NFL 34º 130V 2500 1300 495 CC–8 3 1/4”Box15
50 P AR20 Med. S2206 50PAR20/HAL/NSP NSP 10º 120V 2500 4700 495 CC–8 3 1/4”Box15
50 P AR20 Med. S2306 50PAR20/HAL/NSP NSP 10º 130V 2500 4700 495 CC–8 3 1/4”Box15
50 P AR30 Med. S2207 50PAR30/HAL/NFL NFL 34º 120V 2500 1750 560 CC–8 3 5/8”Box15
50 P AR30 Med. S2307 50PAR30/HAL/NFL NFL 34º 130V 2500 1750 560 CC–8 3 5/8”Box15
50 P AR30 Med. S2208 50PAR30/HAL/WFL WFL 50º 120V 2500 460 560 CC–8 3 5/8”Box15
50 P AR30 Med. S2308 50PAR30/HAL/WFL WFL 50º 130V 2500 460 560 CC–8 3 5/8”Box15
50 P AR30 Med. S2209 50PAR30/HAL/NSP NSP 9º 120V 2500 7600 560 CC–8 3 5/8”Box15
50 P AR30 Med. S2309 50PAR30/HAL/NSP NSP 9º 130V 2500 7600 56+0 CC–8 3 5/8”Box15
75 P AR30 Med. S2210 75PAR30/HAL/NFL NFL 34º 120V 2500 3100 945 CC–8 3 5/8”Box15
75 P AR30 Med. S2310 75PAR30/HAL/NFL NFL 34º 130V 2500 3100 945 CC–8 3 5/8”Box15
75 P AR30 Med. S2211 75PAR30/HAL/WFL WFL 50º 120V 2500 770 945 CC–8 3 5/8”Box15
75 P AR30 Med. S2311 75PAR30/HAL/WFL WFL 50º 130V 2500 770 945 CC–8 3 5/8”Box15
75 P AR30 Med. S2212 75PAR30/HAL/NSP NSP 9º 120V 2500 13000 945 CC–8 3 5/8”Box15
75 P AR30 Med. S2312 75PAR30/HAL/NSP NSP 9º 130V 2500 13000 945 CC–8 3
Satco Avg.Rated Pack. Mst.
45PAR16/HAL/NFL
45PAR16/HAL/NFL
NFL 30º 120V 2500 1200 420 CC–8 3 3/16”Box15
NFL 30º 130V 2500 1200 420 CC–8 3 3/16”Box15
5
/8”Box15
Halogen
Halogen s
PAR14/PAR16/PAR20
PAR14/PAR16/PAR20
Not Shown Actual Size
P AR14
P AR16
Whiter light,brighter colors ,
precise beam control.
halogen lamps
122
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours CBCP Lumens Filament M.O.L. Type Ctn.
35 P AR14 Med. S4658 35PAR14/CAP/WFL WFL 50º 120V 2000 85 300 CC–8 2 7/16”Box 6
60 P AR16 Med. S4900 60PAR16/CAP/NFL NFL 30º 120V 2000 1300 650 CC–8 2 7/8”Box15
60 P AR16 Med. S4901 60PAR16/CAP/NFL NFL 30º 130V 2000 1300 650 CC–8 2 7/8”Box15
60 P AR16 Med. S4902 60PAR16/CAP/NSP NSP 10º 120V 2000 5000 650 CC–8 2 7/8”Box15
60 P AR16 Med. S4903 60PAR16/CAP/NSP NSP 10º 130V 2000 5000 650 CC–8 2 7/8”Box15
75 P AR16 Med. S4904 75PAR16/CAP/NFL NFL 30º 120V 2000 1900 900 CC–8 2 7/8”Box15
75 P AR16 Med. S4905 75PAR16/CAP/NFL NFL 30º 130V 2000 1900 900 CC–8 2 7/8”Box15
75 P AR16 Med. S4906 75PAR16/CAP/NSP NSP 10º 120V 2000 7500 900 CC–8 2 7/8”Box15
75 P AR16 Med. S4907 75PAR16/CAP/NSP NSP 10º 130V 2000 7500 900 CC–8 2 7/8”Box15
35 P AR20 Med. S4908 35PAR20/CAP/NFL NFL 30º 120V 2500 800 360 CC–8 3 1/4”Box15
35 P AR20 Med. S4663 35PAR20/CAP/NFL NFL 30º 130V 2500 800 360 CC–8 3 1/4”Box15
35 P AR20 Med. S4909 35PAR20/CAP/NSP NSP 10º 120V 2500 3000 360 CC–8 3 1/4”Box15
35 P AR20 Med. S4661 35PAR20/CAP/NSP NSP 10º 130V 2500 3000 360 CC–8 3 1/4”Box15
35 P AR20 Med. S4910 35PAR20/CAP/WFL WFL 40º 120V 2500 500 360 CC–8 3 1/8”Box15
35 P AR20 Med. S4665 35PAR20/CAP/WFL WFL 40º 130V 2500 500 360 CC–8 3 1/8”Box15
50 P AR20 Med. S4911 50PAR20/CAP/NFL NFL 30º 120V 2500 1400 550 CC–8 3 1/
50 P AR20 Med. S4912 50PAR20/CAP/NFL NFL 30º 130V 2500 1400 550 CC–8 3 1/
50 P AR20 Med. S4913 50PAR20/CAP/NSP NSP 10º 120V 2500 6200 550 CC–8 3 1/4”Box15
50 P AR20 Med. S4914 50PAR20/CAP/NSP NSP 10º 130V 2500 6200 550 CC–8 3 1/4”Box15
50 P AR20 Med. S4666 50PAR20/CAP/WFL WFL 40º 120V 2500 900 550 CC–8 3
Satco Avg.Rated Pack. Mst.
P AR20
4
”Box15
4
”Box15
1
8
”Box15
/
PAR
PAR
Reflectors
Reflectors
Not Shown Actual Size
Not Shown Actual Size
PAR30LN/PAR38
PAR30LN/PAR38
halogen lamps
P AR38 P AR30LN
SATCO PAR HALOGEN LAMPS
QUALITY • VALUE • PERFORMANCE
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours CBCP* Lumens Filament M.O.L. Type Ctn.
50 P AR30/LN Med. S2213 50PAR30/HAL/NFL NFL 34º 120V 2500 1750 560 CC–8 4 1/2”Box15
50 P AR30/LN Med. S2313 50PAR30/HAL/NFL NFL 34º 130V 2500 1750 560 CC–8 4 1/2”Box15
50 P AR30/LN Med. S2214 50PAR30/HAL/WFL WFL 50º 120V 2500 460 560 CC–8 4 1/2”Box15
50 P AR30/LN Med. S2314 50PAR30/HAL/WFL WFL 50º 130V 2500 460 560 CC–8 4 1/2”Box15
50 P AR30/LN Med. S2215 50PAR30/HAL/NSP NSP 9º 120V 2500 7600 550 CC–8 4 1/2”Box15
50 P AR30/LN Med. S2315 50PAR30/HAL/NSP NSP 9º 130V 2500 7600 550 CC–8 4 1/2”Box15
75 P AR30/LN Med. S2216 75PAR30/HAL/NFL NFL 34º 120V 2500 3100 945 CC–8 4 1/2”Box15
75 P AR30/LN Med. S2316 75PAR30/HAL/NFL NFL 34º 130V 2500 3100 945 CC–8 4 1/2”Box15
75 P AR30/LN Med. S2217 75PAR30/HAL/WFL WFL 50º 120V 2500 770 945 CC–8 4 1/2”Box15
75 P AR30/LN Med. S2317 75PAR30/HAL/WFL WFL 50º 130V 2500 770 945 CC–8 4 1/2”Box15
75 P AR30/LN Med. S2218 75PAR30/HAL/NSP NSP 9º 120V 2500 13000 945 CC–8 4 1/
75 P AR30/LN Med. S2318 75PAR30/HAL/NSP NSP 9º 130V 2500 13000 945 CC–8 4 1/2”Box15
45 P AR38 Med. S2219 45PAR38/HAL/FL FL 30º 120V 2500 1380 465 CC–8 5 5/16”Box15
45 P AR38 Med. S2319 45PAR38/HAL/FL FL 30º 130V 2500 1380 465 CC–8 5 5/16”Box15
45 P AR38 Med. S2220 45P AR38/HAL/NSP NSP 9º 120V 2500 5000 465 CC–8 5 5/16”Box15
45 P AR38 Med. S2320 45P AR38/HAL/NSP NSP 9º 130V 2500 5000 465 CC–8 5 5/16”Box15
75 P AR38 Med. S2221 75PAR38/HAL/FL FL 30º 120V 2500 3200 960 CC–8 5 5/16”Box15
75 P AR38 Med. S2321 75PAR38/HAL/FL FL 30º 130V 2500 3200 960 CC–8 5 5/16”Box15
75 P AR38 Med. S2222 75P AR38/HAL/NSP NSP 9º 120V 2500 16000 960 CC–8 5 5/16”Box15
75 P AR38 Med. S2322 75P AR38/HAL/NSP NSP 9º 130V 2500 16000 960 CC–8 5 5/16”Box15
90 P AR38 Med. S2223 90P AR38/HAL/FL FL 30º 120V 2500 3800 1260 CC–8 5 5/
90 P AR38 Med. S2323 90P AR38/HAL/FL FL 30º 130V 2500 3800 1260 CC–8 5 5/16”Box15
90 P AR38 Med. S2224 90PAR38/HAL/NSP NSP 9º 120V 2500 14000 1260 CC–8 5 5/16”Box15
90 P AR38 Med. S2324 90PAR38/HAL/NSP NSP 9º 130V 2500 14000 1260 CC–8 5 5/16”Box15
120 PAR38 Med. S2225 120PAR38/HAL/FL FL 30º 120V 2500 4700 1600 CC–8 5 5/16”Box15
120 PAR38 Med. S2325 120PAR38/HAL/FL FL 30º 130V 2500 4700 1600 CC–8 5 5/
120 PAR38 Med. S2226 120PAR38/HAL/NSP NSP 9º 120V 2500 22000 1600 CC–8 5 5/16”Box15
120 PAR38 Med. S2326 120PAR38/HAL/NSP NSP 9º 130V 2500 22000 1600 CC–8 5
Satco Avg.Rated Pack Mst.
2
”Box15
16
”Box15
16
”Box15
5
/16”Box15
121
Halogen
Halogen
Short & Long Neck
Short & Long Neck
PAR30
P AR30
Not Shown Actual Size
halogen lamps
P AR30
Long Neck
P AR30
Short Neck
Whiter light,brighter colors , precise beam control.
/NFL
/NFL
/NSP
/NSP
SHORT NECK
NFL 25º 120V 2500 4000 1130 CC–8 3 5/8”Box15
NFL 25º 130V 2500 4000 1130 CC–8 3 5/8”Box15
NSP 9º 120V 2500 15400 1130 CC–8 3 5/8”Box15
NSP 9º 130V 2500 15400 1130 CC–8 3 5/8”Box15
LONG NECK
5
/8”Box15
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours CBCP* Lumens Filament M.O.L. Type Ctn.
50 P AR30 Med. S4915 50PAR30/CAP/FL FL 40º 120V 2500 1300 600 CC–8 3 5/8”Box15
50 P AR30 Med. S4916 50PAR30/CAP/FL FL 40º 130V 2500 1300 600 CC–8 3 5/8”Box15
50 P AR30 Med. S4917 50P AR30/CAP/NFL NFL 25º 120V 2500 2300 660 CC–8 3 5/8”Box15
50 P AR30 Med. S4918 50P AR30/CAP/NFL NFL 25º 130V 2500 2300 660 CC–8 3 5/8”Box15
50 P AR30 Med. S4919 50P AR30/CAP/NSP NSP 9º 120V 2500 8800 660 CC–8 3 5/8”Box15
50 P AR30 Med. S4920 50P AR30/CAP/NSP NSP 9º 130V 2500 8800 660 CC–8 3 5/8”Box15
75 P AR30 Med. S4921 75PAR30/CAP/FL FL 40º 120V 2500 2000 1130 CC–8 3 5/8”Box15
75 P AR30 Med. S4922 75PAR30/CAP/FL FL 40º 130V 2500 2000 1130 CC–8 3 5/8”Box15
75 P AR30 Med. S4923
75 P AR30 Med. S4924
75 P AR30 Med. S4925
75 P AR30 Med. S4926
35 P AR30/LN Med. S2654 35PAR30LN/CAP/WFL WFL 50º 120V 2500 450 450 CC–8 4 5/8”Box15
35 P AR30/LN Med. S2655 35PAR30LN/CAP/NSP NSP 9º 120V 2500 5700 450 CC–8 4 5/8”Box15
50 P AR30/LN Med. S4927 50PAR30LN/CAP/WFL WFL 50º 120V 2500 660 660 CC–8 4 5/8”Box15
50 P AR30/LN Med. S4928 50PAR30LN/CAP/WFL WFL 50º 130V 2500 660 660 CC–8 4 5/8”Box15
50 P AR30/LN Med. S4929 50PAR30LN/CAP/NFL NFL 25º 120V 2500 2300 660 CC–8 4 5/8”Box15
50 P AR30/LN Med. S4930 50PAR30LN/CAP/NFL NFL 25º 130V 2500 2300 660 CC–8 4 5/8”Box15
50 P AR30/LN Med. S4931 50PAR30LN/CAP/NSP NSP 9º 120V 2500 8800 660 CC–8 4 5/8”Box15
50 P AR30/LN Med. S4932 50PAR30LN/CAP/NSP NSP 9º 130V 2500 8800 660 CC–8 4 5/8”Box15
75 P AR30/LN Med. S4933 75PAR30LN/CAP/WFL WFL 50º 120V 2500 1100 1130 CC–8 4 5/8”Box15
75 P AR30/LN Med. S4934 75PAR30LN/CAP/WFL WFL 50º 130V 2500 1100 1130 CC–8 4 5/8”Box15
75 P AR30/LN Med. S4935 75PAR30LN/CAP/NFL NFL 25º 120V 2500 4000 1130 CC–8 4 5/8”Box15
75 P AR30/LN Med. S4936 75PAR30LN/CAP/NFL NFL 25º 130V 2500 4000 1130 CC–8 4 5/8”Box15
75 P AR30/LN Med. S4937 75PAR30LN/CAP/NSP NSP 9º 120V 2500 15400 1130 CC–8 4 5/8”Box15
75 P AR30/LN Med. S4938 75PAR30LN/CAP/NSP NSP 9º 130V 2500 15400 1130 CC–8 4
Satco Avg.Rated Pack Mst.
75PAR30/
CAP
75PAR30/
CAP
75PAR30/
CAP
75PAR30/
CAP
123
Halogen
Halogen
PAR38
PAR38
Whiter light,
brighter colors ,
precise beam
control.
Not Shown Actual Size
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours CBCP* Lumens Filament M.O.L. Type Ctn.
45 PAR38 Med.Skt. S4939 45PAR/CAP/FL FL 30º 120V 2500 1500 560 CC–8 5 5/16”Box15
45 PAR38 Med.Skt. S4940 45PAR/CAP/FL FL 30º 130V 2500 1500 560 CC–8 5 5/16”Box15
45 PAR38 Med.Skt. S4941 45PAR/CAP/NSP NSP 9º 120V 2500 10000 560 CC–8 5 5/16”Box15
45 PAR38 Med.Skt. S4942 45PAR/CAP/NSP NSP 9º 130V 2500 10000 560 CC–8 5 5/16”Box15
halogen lamps
124
45 PAR38 Med.Skt. S4630
60 PAR38 Med.Skt. S4943 60PAR/CAP/FL FL 30º 120V 3000 2500 850 CC–8 5 5/16”Box15
60 PAR38 Med.Skt. S4944 60PAR/CAP/FL FL 30º 130V 3000 2500 850 CC–8 5 5/16”Box15
60 PAR38 Med.Skt. S4945 60PAR/CAP/NSP NSP 9º 120V 3000 16000 850 CC–8 5 5/16”Box15
60 PAR38 Med.Skt. S4946 60PAR/CAP/NSP NSP 9º 130V 3000 16000 850 CC–8 5 5/16”Box15
75 PAR38 Med.Skt. S4964 75PAR/CAP/FL FL 30º 120V 2500 3150 1060 CC–8 5 5/
75 PAR38 Med.Skt. S4965 75PAR/CAP/FL FL 30º 130V 2500 3150 1060 CC–8 5 5/16”Box15
75 PAR38 Med.Skt. S4966 75PAR/CAP/NSP NSP 9º 120V 2500 19200 1060 CC–8 5 5/16”Box15
75 PAR38 Med.Skt. S4967 75PAR/CAP/NSP NSP 9º 130V 2500 19200 1060 CC–8 5 5/
75 PAR38 Med.Skt. S4631
90 PAR38 Med.Skt. S4968 90PAR/CAP/FL FL 30º 120V 2500 3500 1310 CC–8 5 5/16”Box15
90 PAR38 Med.Skt. S4969 90PAR/CAP/FL FL 30º 130V 2500 3500 1310 CC–8 5 5/16”Box15
90 PAR38 Med.Skt. S4970 90PAR/CAP/NSP NSP 9º 120V 2500 19000 1310 CC–8 5 5/16”Box15
90 PAR38 Med.Skt. S4971 90PAR/CAP/NSP NSP 9º 130V 2500 19000 1310 CC–8 5 5/16”Box15
90 PAR38 Med.Skt. S4950 90PAR/CAP/WSP
90 PAR38 Med.Skt. S4951 90PAR/CAP/WSP
90 PAR38 Med.Skt. S4632 90PAR/CAP/NFL
90 PAR38 Med.Skt. S4633 90PAR/CAP/WFL
120 PAR38 Med.Skt. S4972 120PAR/CAP/FL FL 30º 120V 3000 4600 1800 CC–8 5 5/16”Box15
120 PAR38 Med.Skt. S4973 120PAR/CAP/FL FL 30º 130V 3000 4600 1800 CC–8 5 5/16”Box15
120 PAR38 Med.Skt. S4974 120PAR/CAP/SP SP 10º 120V 3000 22500 1800 CC–8 5 5/
120 PAR38 Med.Skt. S4975 120PAR/CAP/SP SP 10º 130V 3000 22500 1800 CC–8 5 5/16”Box15
120 PAR38 Med.Skt. S4634 120P AR/CAP/WFL
250 PAR38 Med.Skt. S4947 250PAR/CAP/FL FL 30º 120V 4500 4500 3600 CC–8 5 5/16”Box6
250 PAR38 Med.Skt. S4948 250PAR/CAP/SP SP 10º 120V 4500 46500 3600 CC–8 5
Satco Avg.Rated Pack. Mst.
45P AR/
CAP
/WFL WFL 50º
75P AR/
CAP
/WFL
WFL 50º
WSP
WSP
NFL 25º
WFL 50º
WFL 50º
130V 2500 700 560 CC–8 5 5/16”Box15
16
”Box15
16
”Box15
130V 2500 1300 1060 CC–8 5 5/16”Box15
12º 120V 2500 14300 1310 CC–8 5 5/16”Box15
12º 130V 2500 14300 1310 CC–8 5 5/16”Box15
130V 2500 4700 1310 CC–8 5 5/16”Box15
130V 2500 1600 1310 CC–8 5
130V 3000 2000 1800 CC–8 5 5/16”Box15
5
16
”Box15
/
16
”Box15
5
/16”Box6
PAR
PAR
Reflectors
Reflectors
Not Shown Actual Size
PAR16/PAR20/PAR30/PAR38
PAR16/PAR20/PAR30/PAR38
Frosted Halogen Lamps
SOFT–RAY
Introducing – Soft Ray , a new concept in halogen
lighting. Our new line of frosted MR16 and PAR lamps
offer a simple, cost effective solution to problems
normally associated with standard halogen reflectors.
It is known that many users of traditional MR16 & PAR
lamps object to the
rance of these lamps. Soft Ray lamps solve these
problems and more!
• Glare Free
• Does not create hot spots
• Eliminates shadows & striations
• Produces a smoothand even
beam pattern
“headlamp look”
or glary appea-
PAR16
halogen lamps
PAR20
PAR30 Short Neck
PAR30 Long Neck
PAR38
Not Shown Actual Size
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours Lumens Filament M.O.L. Type Ctn.
60 PAR16 Med. S4108 60PAR16/FL/FROST Flood 38º 120V 2500 525 CC–8 3 3/16”Box15
75 PAR16 Med. S4109 75PAR16/FL/FROST Flood 38º 120V 2500 725 CC–8 3 3/
50 PAR20 Med. S4100 50PAR20/NFL/FROST Flood 38º 120V 2500 450 CC–8 3 3/8”Box15
50 PAR20 Med. S4200 50PAR20/NFL/FROST Flood 38º 130V 2500 450 CC–8 3 3/8”Box15
50 PAR30 Med. S4101 50PAR30/FL/FROST Flood 38º 120V 2500 520 CC–8 3 5/8”Box15
50 PAR30 Med. S4201 50PAR30/FL/FROST Flood 38º 130V 2500 520 CC–8 3 5/8”Box15
75 PAR30 Med. S4102 75PAR30/FL/FROST Flood 38º 120V 2500 900 CC–8 3 5/8”Box15
75 PAR30 Med. S4202 75PAR30/FL/FROST Flood 38º 130V 2500 900 CC–8 3 5/8”Box15
50 PAR30/LN Med. S4103 50P AR30/LN/FL/FROST Flood 38º 120V 2500 520 CC–8 4 1/2”Box15
50 PAR30/LN Med. S4203 50P AR30/LN/FL/FROST Flood 38º 130V 2500 520 CC–8 4 1/2”Box15
75 PAR30/LN Med. S4104 75P AR30/LN/FL/FROST Flood 38º 120V 2500 900 CC–8 4 1/2”Box15
75 PAR30/LN Med. S4204 75P AR30/LN/FL/FROST Flood 38º 130V 2500 900 CC–8 4 1/2”Box15
45 PAR38 Med. Skt. S4105 45PAR38/FL/FROST Flood 38º 120V 2500 450 CC–8 5 5/16”Box15
45 PAR38 Med. Skt. S4205 45PAR38/FL/FROST Flood 38º 130V 2500 450 CC–8 5 5/16”Box15
60 PAR38 Med. Skt. S4106 60PAR38/FL/FROST Flood 38º 120V 2500 600 CC–8 5 5/16”Box15
60 PAR38 Med. Skt. S4206 60PAR38/FL/FROST Flood 38º 130V 2500 600 CC–8 5 5/16”Box15
90 PAR38 Med. Skt. S4107 90PAR38/FL/FROST Flood 38º 120V 2500 1150 CC–8 5 5/16”Box15
90 PAR38 Med. Skt. S4207 90PAR38/FL/FROST Flood 38º 130V 2500 1150 CC–8 5
Satco Avg.Rated Pack. Mst.
16
Box 15
5
/16”Box15
125
Halogen Ref lectors
Halogen Ref lectors
R20/BR30 & BR40
R20/BR30 & BR40
Nickel Plated Brass Base
•
High Lumen Output
•
Brilliant White Light
•
Better Color Rendering than
•
Standard Floods
20% Brighter & Longer Lasting
•
2500 Hours
halogen lamps
R20
126
Medium Base
120 Volt
S4500 50 Watt
Packing: Individually Sleeved
48/Master,6/Inner
Not Shown Actual Size
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours Lumens Kelvin M.O.L. Type Inner Pack
50 R20 Med. S4500 50R20/FL/HAL 70° 120V 2500 480 3000K 4” Sleeve 6/48
60 BR30 Med. S4501 60BR30/FL/HAL 80° 120V 2500 730 3000K 5 3/8” Sleeve 6/48
60 BR30 Med. S4401 60BR30/FL/HAL 80° 130V 2500 730 3000K 5 3/8” Sleeve 6/48
75 BR30 Med. S4502 75BR30/FL/HAL 80° 120V 2500 900 3000K 5 3/8” Sleeve 6/48
75 BR30 Med. S4402 75BR30/FL/HAL 80° 130V 2500 900 3000K 5 3/8” Sleeve 6/48
75 BR40 Med. S4504 75BR40/FL/HAL 90° 120V 2500 900 3000K 6 1/2” Sleeve 6/24
100 BR40 Med. S4503 100BR40/FL/HAL 90° 120V 2500 1400 3000K 6 1/2” Sleeve 6/24
All lamps rated at design voltage.
Satco Avg.Rated Pack. Mst.Ctn./
Medium Base
120 Volt/130Volt
S4501 60 Watt
S4401 60 Watt/130 Volt
S4502 75 Watt
S4402 75 Watt/130 Volt
Packing: Individually Sleeved
48/Master,6/Inner
BR30
BR40
Medium Base
120 Volt
S4504 75 Watt
S4503 100 Watt
Packing: Individually Sleeved
24/Master,6/Inner
Halogen
Halogen
2000 Hours / 12 & 24 V olt
Not Shown
Actual Size
Packing: Individually Boxed,
MR11
Bayonet / Lensed
12 Volt
S1954 20W SP FST/C
S1952 20W NFL FSV/C
S1955 35W SP GDY/C
S1953 35W NFL GDZ/C
Packing: Individually Boxed
12/Carton
MR11
GZ4 / Lensed
Packing: Individually Boxed
Frosted
12 Volt
S4124 20W FL
S4125 35W FL
12/Carton
MR8 & MR11
MR8 & MR11
MR8
Lensed
12 Volt
S4646 10W NSP
S4645 10W NFL
12/Carton
Lamps
Lamps
MR11
12 Volt
S3194 5W NSP
S3195 10W SP
S3150 20W NSP FTB
S3152 20W SP FTC
S3154 20W NFL FTD
S3151 35W NSP FTE
S3153 35W SP FTF
S3155 35W NFL FTH
Packing: Individually Boxed,
12/Carton
MR11
Lensed
12 Volt
S1950 20W NFL FTD/C
S1951 35W NFL FTH/C
24 Volt
S1990 20W NSP FTD/C
S1988 20W NFL FTD/C
S1991 35W NSP FTH/C
S1989 35W NFL FTH/C
Packing: Individually Boxed,
12/Carton
halogen lamps
Watts Bulb Type Base Order No. Code Lamp Code Beam Volts Hours Power Filament M.O.L. Type Mst.Ctn.
10 MR8 GZ4 S4646 n/a 10MR8/NSP SP9° 12V 2000 tbd C–6 1 1/4”Box12
10 MR8 GZ4 S4645 n/a 10MR8/NFL NFL23° 12V 2000 tbd C–6 1 1/4”Box12
5 MR11 GZ4 S3194 n/a 5MR11/NSP NSP9° 12V 2000 tbd C–6 1 1/
10 MR11 GZ4 S3195 n/a 10MR11/SP SP12° 12V 2000 tbd C–6 1 1/4”Box12
20 MR11 GZ4 S3150 FTB 20MR11/NSP NSP9° 12V 2000 4100 C–6 1 1/4”Box12
20 MR11 GZ4 S1990
20 MR11 GZ4 S3152 FTC 20MR11/SP SP12° 12V 2000 1750 C–6 1 1/4”Box12
20 MR11 DC.Bay S1954 FST/C
20 MR11 GZ4 S3154 FTD 20MR11/NFL NFL24° 12V 2000 700 C–6 1 1/
20 MR11 GZ4 S1950 FTD/C 20MR11/NFL/C NFL24° 12V 2000 700 C–6 1 1/4”Box12
20 MR11 GZ4 S1988
20 MR11 DC.Bay S1952 FSV/C
20 MR11 GZ4 S4124 n/a 20MR11/FL/FR FL36° 12V 2000 288 C–6 1 1/4”Box12
35 MR11 GZ4 S3151 FTE 35MR11/NSP NSP9° 12V 2000 7000 C–6 1 1/4”Box12
35 MR11 GZ4 S1991
35 MR11 GZ4 S3153 FTF 35MR11/SP SP12° 12V 2000 1500 C–6 1 1/4”Box12
35 MR11 DC.Bay S1955 GDY/C
35 MR11 GZ4 S3155 FTH 35MR11/NFL NFL24° 12V 2000 700 C–6 1 1/
35 MR11 GZ4 S1951 FTH/C 35MR11/NFL/C NFL24° 12V 2000 700 C–6 1 1/4”Box12
35 MR11 GZ4 S1989
35 MR11 DC.Bay S1953 GDZ/C
35 MR11 GZ4 S4125 n/a 35MR11/FL/FR FL36° 12V 2000 520 C–6 1
Satco ANSI Avg.Rated Candle Pack.
4
”Box12
20MR11/NSP/C NSP9° 24V 2000 4100 C–6 1
FTB/C/24
20MR11/DC/SP/C
FTD/C/24
20MR11/NFL/C NFL24° 24V 2000 700 C–6 1 1/4”Box12
20MR11/DC/NFL/C
35MR11/NSP/C NSP9° 24V 2000 tbd C–6 1
FTE/C/24
35MR11/DC/SP/C
FTH/C/24
35MR11/C NFL24° 24V 2000 1500 C–6 1 1/4”Box12
35MR11/DC/NFL/C
SP12° 12V 2000 1750 C–6 1 5/8”Box12
NFL24° 12V 2000 700 C–6 1
SP12° 12V 2000 1500 C–6 1 5/8”Box12
NFL24° 12V 2000 700 C–6 1
1
4
”Box12
/
4
”Box12
5
8
”Box12
/
1
4
”Box12
/
4
”Box12
5
8
”Box12
/
1
/4”Box12
127
Halogen
Halogen
MR16
MR16
Lamps 120V
Lamps 120V
JDR
Lensed
120 Volt/Medium
S3139 50W Flood
S3113 75W Flood
S3114 100W Flood
120 Volt/Intermediate
S3115 75W Flood
S3116 100W Flood
Packing: Individually Boxed
12/Carton
MR16
Standard Pin
120 V olt/GX5.3 Base
S1976 20W FL BAB/C
S1977 35W FL FMW/C
S1978 50W FL EXN/C
Packing: Individually Boxed
12/Carton
Lensed
2000 Hours
MR1 6
120 Volt/Med.Base
S4623 20W FL BAB/C
S4624 35W FL FMW/C
S4625 50W FL EXN/C
Packing: Individually Boxed
12/Carton
MR1 6
Wide Pin
120 Volt/G8 Base
S4626 20W FL BAB/C
S4627 35W FL FMW/C
S4618 50W FL EXN/C
Packing: Individually Boxed
12/Carton
Lensed/Short
Lensed
MR1 6
Lensed
Twist Lock
120Volt/GU10 Base
halogen lamps
Satco Avg.Rated Candle Pack. Mst.Ctn./
128
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours Power Filament M.O.L. Type Inner Pack
20 MR16 GX5.3 S1976 20MR16/FL/C FL 36° 120V 2000 700 CC–8 1 7/8”Box 12
20 MR16 G8 S4618 20MR16/G8/FL/C FL 36° 120V 2000 700 CC–8 1 7/8”Box 12
20 MR16 GU10 S3515 20MR16/GU10/FL FL 36° 120V 2000 700 CC–8 1 7/8”Box 12
20 MR16 GU10 S4127 20MR16/GU10/Frost FL 36° 120V 2000 650 CC–8 1 7/8”Box 12
20 MR16 Med. S4623 20MR16/S/FL/C FL 36° 120V 2000 700 CC–8 1 3/4”Box 12
35 MR16 GX5.3 S1977 35MR16/FL/C FL 36° 120V 2000 1250 CC–8 1 7/8”Box 12
35 MR16 G8 S4626 35MR16/G8/FL/C FL 36° 120V 2000 1250 CC–8 1 7/8”Box 12
35 MR16 GU10 S3516 35MR16/GU10/FL FL 36° 120V 2000 1250 CC–8 1 7/8”Box 12
35 MR16 GU10 S4128 35MR16/GU10/Frost FL 36° 120V 2000 1200 CC–8 1 7/
35 MR16 Med. S4624 35MR16/S/FL/C FL 36° 120V 2000 1250 CC–8 1 3/
50 MR16 GX5.3 S1978 50MR16/FL/C FL 36° 120V 2000 1700 CC–8 1 7/
50 MR16 G8 S4627 50MR16G8/FL/C FL 36° 120V 2000 1700 CC–8 1 7/
50 MR16 GU10 S3517 50MR16/GU10/FL FL 36° 120V 2000 1700 CC–8 1 7/
50 MR16 GU10 S4129 50MR16/GU10/Frost FL 36° 120V 2000 1650 CC–8 1 7/
50 MR16 Med. S4625 50MR16/S/FL/C FL 36° 120V 2000 1700 CC–8 1 3/
50 JDR Med. S3139 50JDR16/FL FL 36° 120V 2000 1500 CC–8 2 7/
75 JDR Int. S3115 75JDR16/N/FL FL 36° 120V 2000 1650 CC–8 2 7/
75 JDR Med. S3113 75JDR16/FL FL 36° 120V 2000 1650 CC–8 2 7/
100 JDR Int. S3116 100JDR16/N/FL FL 36° 120V 2000 1950 CC–8 2 7/
100 JDR Med. S3114 100JDR16/FL FL 36° 120V 2000 1950 CC–8 2 7/
S3515 20W Flood
S3516 35W Flood
S3517 50W Flood
Packing: 12 Cards/Inner
120 Cards/Master
MR16
Lensed
Twist Lock / Fr osted
120 V olt/GU10 Base
S4127 20W Flood
S4128 35W Flood
S4129 50W Flood
Packing: Individually Boxed
12/Carton
8
”Box 12
4
”Box 12
8
”Box 12
8
”Box 12
8
”Box 12
8
”Box 12
4
”Box 12
8
”Box 12
8
”Box 12
8
”Box 12
8
”Box 12
8
”Box 12
Halogen
Halogen
2000 Hours / 12 Volt
MR16
MR16
Lamps
Lamps
halogen lamps
MR16
S1956 20W FL BAB
S1957 20W NSP ESX
S1958 35W NSP FRB
S1959 35W FL FMW
S1960 50W FL EXN
S1961 50W NSP EXT
Watts Bulb Type Base Order No. ANSI Lamp Code Beam Volts Hours Power Filament M.O.L. Type Ctn
20 MR16 GX5.3 S1957 ESX 20MR16/NSP NSP 9°12V 2000 4100 C–8 1 7/8”Box12
20 MR16 GX5.3 S1956 BAB 20MR16/FL FL 36
35 MR16 GX5.3 S1958 FRB 35MR16/NSP NSP 9°12V 2000 7000 C–6 1 7/8”Box12
35 MR16 GX5.3 S1959 FMW 35MR16/FL FL 36
50 MR16 GX5.3 S1961 EXT 50MR16/NSP NSP 9°12V 2000 10000 C–6 1 7/8”Box12
50 MR16 GX5.3 S1962 EXZ 50MR16/NFL NFL 18°12V 2000 4400 C–6 1 7/8”Box12
50 MR16 GX5.3 S1960 EXN 50MR16/FL FL 36
50 MR16 GX5.3 S1963 FNV 50MR16/WFL VWFL 60°12V 2000 2200 C–6 1 7/8”Box12
65 MR16 GX5.3 S1965 FPA 65MR16/NSP NSP 9°12V 2000 9530 C–6 1 7/8”Box12
65 MR16 GX5.3 S1964 FPB 65MR16 FPB FL 36
Satco Avg.Rated Candle Pack. Mst..
12 Volt
S1962 50W MFL EXZ
S1963 50W VWFL FNV
S1964 65W FL FPB
S1965 65W NSP FPA
Packing: Individually Boxed
12/Carton
Not Shown Actual Size
12V 2000 700 C–6 1 7/8”Box12
°
12V 2000 1250 C–6 1 7/8”Box12
°
12V 2000 1700 C–8 1 7/8”Box12
°
12V 2000 3600 C–6 1 7/8”Box12
°
129
Halogen
Halogen
MR16
MR16
Lamps
Lamps
MR16
Bayonet / Lensed
12 Volt
S1970 20W FL GES/C
S1971 20W NSP GEV/C
S1972 50W FL GBW/C
S1973 50W NSP GBT/C
S1974 65W FL FPB/C
S1975 65W NSP FPA/C
Packing: Individually Boxed
12/Carton
MR16
S1966 20W FL BAB/C
S1967 20W NSP ESX/C
S4365 35W FL FMW/C
S4364 35W NSP FRB/C
S3169 50W FL EXN/C
S3170 50W NSP EXT/C
S1968 65W FL FPB/C
S1969 65W NSP FPA/C
Packing: Individually Boxed
halogen lamps
130
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours Power Filament M.O.L. Type Inner Pack
20 MR16 GX5.3 S1966 20MR16/FL/C FL 36
20 MR16 GX5.3 S4120 20MR16/FL/FROST/C FL 36° 12V 2000 288 C-6 1 7/8”Box 12
20 MR16 D.C.Bay. S1970
20 MR16 GX5.3 S1992 20MR16/FL/C FL 36
20 MR16 GX5.3 S1967 20MR16/NSP/C NSP 9°12V 2000 4100 C–8 1 7/8”Box 12
20 MR16 D.C.Bay. S1971
20 MR16 GX5.3 S1995 20MR16/NSP/C NSP 9°24V 2000 4100 C–8 1 7/8”Box 12
35 MR16 GX5.3 S4365 35MR16/FL/C FL 36
35 MR16 GX5.3 S1993 35MR16/FL/C FL 36
35 MR16 GX5.3 S4121 35MR16/FL/FROST FL 36° 12V 2000 520 C-6 1 7/8”Box 12
35 MR16 GX5.3 S4364 35MR16/NSP/C NSP 9°12V 2000 7000 C–8 1 7/8”Box 12
35 MR16 GX5.3 S1996 35MR16/NSP/C NSP 9°24V 2000 7000 C–6 1 7/8”Box 12
50 MR16 GX5.3 S3169 50MR16/FL/C FL 36° 12V 2000 1700 C-8 1 7/8”Box 12
50 MR16 GX5.3 S4122 50MR16/FL/FROST FL 36° 12V 2000 820 C-6 1 7/8”Box 12
50 MR16 D.C.Bay. S1972
50 MR16 GX5.3 S1994 50MR16/FL FL 36
50 MR16 GX5.3 S3170 50MR16/NSP/C NSP 9° 12V 2000 10000 C-8 1 7/8”Box 12
50 MR16 D.C.Bay. S1973
50 MR16 GX5.3 S1997 50MR16/NSP/C NSP 9°24V 2000 10000 C–8 1 7/8”Box 12
65 MR16 GX5.3 S1968 65MR16/FL/C FL 36° 12V 2000 3600 C-8 1 7/8”Box 12
65 MR16 GX5.3 S4123 65MR16/FL/FROST/C FL 36° 12V 2000 880 C-6 1 7/8”Box 12
65 MR16 D.C.Bay. S1974
65 MR16 GX5.3 S1969 65MR16/NSP/C NSP 9° 12V 2000 9500 C-8 1 7/8”Box 12
65 MR16 D.C.Bay. S1975
Lensed
12 Volt
20/Carton
Not Shown Actual Size
Satco Avg.Rated Candle Pack.
20MR16/FL/DC/C
20MR16/NSP/DC/C
50MR16/FL/DC/C
50MR16/NSP/DC/C
65MR16/FL/DC/C
65MR16/NSP/DC/C
FL 36° 12V 2000 700 C–6 1 7/8”Box 12
NSP 9° 12V 2000 4100 C–8 1 7/8”Box 12
FL 36° 12V 2000 1700 C–8 1 7/8”Box 12
NSP 9° 12V 2000 10000 C–8 1 7/8”Box 12
FL 36° 12V 2000 tbd C–6 1 7/8”Box 12
NSP 9° 12V 2000 9500 C–8 1 7/8”Box 12
2000 Hours / 12 & 24 Volt
MR16
24 Volt
S1992 20W FL
S1993 35W FL
S1994 50W FL
S1995 20W SP
S1996 35W SP
S1997 50W SP
Packing: Individually Boxed
12/Carton
MR16
Frosted Lensed
12 Volt
S4120 20W FL BAB/C
S4121 35W FL FMW/C
S4122 50W FL EXN/C
S4123 65W FL FPB/C
Packing: Individually Boxed,
12/Carton
12V 2000 700 C–8 1 7/8”Box 12
°
24V 2000 700 C–8 1 7/8”Box 12
°
12V 2000 1250 C–8 1 7/8”Box 12
°
24V 2000 700 C–8 1 7/8”Box 12
°
24V 2000 1700 C–8 1 7/8”Box 12
°
Lensed
Mst.Ctn./Inner
Halogen
Halogen
4000 Hours
MR16
MR16
Specialty Lamps
Specialty Lamps
Not Shown Actual Size
Hard Coated
Alluminized Reflector
•Projects Heat & Light out the
front of the lamp
•Minimizes the “Backlight Ef fect”
•Constant Color Technology
Watts Bulb Type Base Order No. ANSI Lamp Code Volts Hours Power Filament M.O.L. Type Ctn
20 MR16 GU5.3 S2601 BAB 20MR16/B/FL35 12V 4000 625 AX 1
20 MR16 GU5.3 S2602 BAB/C 20MR16/B/FL35/C 12V 4000 600 AX 1
20 MR16 GU5.3 S2603 ESX 20MR16/B/NSP8 12V 4000 4650 AX 1
20 MR16 GU5.3 S2604 ESX/C 20MR16/B/NSP8/C 12V 4000 4400 AX 1
35 MR16 GU5.3 S2605 FMW 35MR16/B/FL35 12V 4000 1300 AX 1
35 MR16 GU5.3 S2606 FRB 35MR16/B/NSP10 12V 4000 8700 AX 1
50 MR16 GU5.3 S2607 EXN 50MR16/B/FL35 12V 4000 1900 AX 1
50 MR16 GU5.3 S2608 EXN/C 50MR16/B/FL35/C 12V 4000 1800 AX 1
50 MR16 GU5.3 S2609 EXZ 50MR16/B/NFL25 12V 4000 3000 AX 1
50 MR16 GU5.3 S2610 EXT 50MR16/B/NSP11 12V 4000 10500 AX 1
50 MR16 GU5.3 S2611 EXT/C 50MR16/B/NSP11/C 12V 4000 10000 AX 1
65 MR16 GU5.3 S2612 FPB 65MR16/B/FL40 12V 4000 2100 AX 1
65 MR16 GU5.3 S2613 FPC 65MR16/B/NFL25 12V 4000 3600 AX 1
65 MR16 GU5.3 S2614 FPA 65MR16/B/NSP10 12V 4000 12500 AX 1
20 MR16 GU5.3 S2615 BAB 20MR16/T/FL40 12V 4000 700 AX 1
20 MR16 GU5.3 S2616 ESX 20MR16/T/NSP10 12V 4000 5000 AX 1
20 MR16 GU5.3 S2617 n/a 20MR16/T/WFL60 12V 4000 350 AX 1
35 MR16 GU5.3 S2618 FMW 35MR16/T/FL40 12V 4000 1250 AX 1
35 MR16 GU5.3 S2619 n/a 35MR16/T/NFL25 12V 4000 3100 AX 1
35 MR16 GU5.3 S2620 FRB 35MR16/T/NSP10 12V 4000 8300 AX 1
35 MR16 GU5.3 S2621 n/a 35MR16/T/WFL60 12V 4000 650 AX 1
50 MR16 GU5.3 S2622 EXN 50MR16/T/FL40 12V 4000 2000 AX 1
50 MR16 GU5.3 S2623 EXZ 50MR16/T/NFL25 12V 4000 3200 AX 1
50 MR16 GU5.3 S2624 EXT 50MR16/T/NSP10 12V 4000 11500 AX 1
50 MR16 GU5.3 S2625 FNV 50MR16/T/WFL60 12V 4000 1000 AX 1
65 MR16 GU5.3 S2626 FPB 65MR16/T/FL40 12V 4000 2100 AX 1
65 MR16 GU5.3 S2627 FPC 65MR16/T/NFL25 12V 4000 4000 AX 1
65 MR16 GU5.3 S2628 FPA 65MR16/T/NSP10 12V 4000 14000 AX 1
65 MR16 GU5.3 S2629 n/a 65MR16/T/WFL60 12V 4000 1050 AX 1
20 MR16 GU5.3 S2630 n/a 20MR16/IR/FL40/C 12V 4000 1000 AX 1
20 MR16 GU5.3 S2631 n/a
20 MR16 GU5.3 S2632 n/a
20 MR16 GU5.3 S2633 n/a
37 MR16 GU5.3 S2634 n/a 37MR16/IR/FL40/C 12V 4000 2200 AX 1
37 MR16 GU5.3 S2635 n/a
37 MR16 GU5.3 S2636 n/a
37 MR16 GU5.3 S2637 n/a
50 MR16 GU5.3 S2638 n/a 50MR16/IR/FL40/C 12V 4000 2850 AX 1
50 MR16 GU5.3 S2639 n/a
50 MR16 GU5.3 S2640 n/a
50 MR16 GU5.3 S2641 n/a
Satco Avg.Rated Candle Pack. Mst..
Dichroic Ref lector
•Projects Heat out the back
of the lamp
•Constant Color Technology
Aluminized Relector
Hard Coated Dichroic Reflector
Infra-Red Reflecting Energy Saver
20MR16/IR/NFL25/C
20MR16/IR/NSP10/C
20MR16/IR/WFL60/C
37MR16/IR/NFL25/C
37MR16/IR/NSP10/C
37MR16/IR/WFL60/C
50MR16/IR/NFL25/C
50MR16/IR/NSP10/C
50MR16/IR/WFL60/C
12V 4000 2300 AX 1
12V 4000 6000 AX 1
12V 4000 450 AX 1
12V 4000 4400 AX 1
12V 4000 12500 AX 1
12V 4000 1100 AX 1
12V 4000 5700 AX 1
12V 4000 15000 AX 1
12V 4000 1430 AX 1
•Hard Coated Dichroic Reflector
•Infra-Red Reflective Coating
•Constant Color Technology
•Lensed
Energy Saving
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
3/4
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box10
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
”Box20
halogen lamps
131
Closed Aluminum
Closed Aluminum
Reflector (ALR)
Reflector (ALR)
37mm ALR
D.C.Bayonet
12 Volt
S2642 20W Narrow Spot GBD
Packing: Individually Boxed
Master/50,Inner/5
Lamps
Lamps
37mm ALR
D.C.Bayonet
12 Volt
S2643 20W Spot GBE
S2644 20W Flood GBF
Packing: Individually Boxed
Master/50,Inner/5
2000 Hours/12 Volt
halogen lamps
56mm ALR
D.C.Bayonet
12 Volt
S2645 50W Flood GBK
Packing: Individually Boxed
Master/50,Inner/5
Not Shown Actual Size
Satco Avg.Rated Candle Pack. Mst.Ctn./
S2642 20ALR12/NSP6-GBD 6° 12V 2000 6400 3000K 13⁄8” Box 50/5
S2643 20ALR12/SP18-GBE 18° 12V 2000 1000 3000K 13⁄8” Box 50/5
S2644 20ALR12/FL34-GBF 34° 12V 2000 350 3000K 13⁄8” Box 50/5
S2646 50ALR18/SP10-GBJ 10° 12V 2000 12,000 3000K 21⁄5” Box 50/5
S2645 50ALR18/NFL22-GBK 22° 12V 2000 2000 3000K 21⁄5” Box 50/5
132
Watts Bulb Type Base Order No. Lamp Code Beam Volts Hours Power Kelvin M.O.L. Type Inner Pack
20 37mm ALR
20 37mm ALR
20 37mm ALR
50 56mm ALR
50 56mm ALR
D.C.Bay
D.C.Bay
D.C.Bay
D.C.Bay
D.C.Bay
56mm ALR
D.C.Bayonet
12 Volt
S2646 50W Spot GBJ
Packing: Individually Boxed
Master/50,Inner/5
Halogen
Halogen
Aluminum Ref lectors
Aluminum Ref lectors
3000 Hours
filament in precisely engineered
AR111
Screw Terminal Base
S4685
S4686 35 Watt Spot
S4687 35 Watt Flood
S4688 50 Watt Super Spot
S4689 50 Watt Spot
S4690 50 Watt Flood
S4691 75 Watt Spot
35 Watt Super Spot
S4692 75 Watt Flood
S4693 75 Watt Wide Flood
S4694 100 Watt Spot
S4695 100 Watt Flood
S4696 100 Watt Wide Flood
Packing: Individually Boxed
6/Master
AR70 & AR111
AR70 & AR111
UV stop capsule with axial
aluminum reflector.
AR70
D.C. Bayonet
Base
S4680 20 Watt Spot
S4681 20 Watt Flood
S4682 50 Watt Spot
S4683 50 Watt Flood
Packing: Individually Boxed
10/Master
halogen lamps
Not Shown Actual Size
Bulb Satco Avg.Rated Pack. Mst.
Watts Type Base Order No. Lamp Code Beam Volts Hours CBCP* Filament M.O.L. Type Ctn.
20 AR70 DC Bayonet S4680 20AR70/SP8 Spot 8º 12V 3000 7700 C-8 1 15⁄16”Box10
20 AR70 DC Bayonet S4681 20AR70/FL25 Flood 25º 12V 3000 900 C-8 1 15⁄16”Box10
50 AR70 DC Bayonet S4682 50AR70/SP8 Spot 8º 12V 3000 12500 C-8 1 15⁄16”Box10
50 AR70 DC Bayonet S4683 50AR70/FL25 Flood 25º 12V 3000 2600 C-8 1 15⁄16”Box10
35 AR111 G53 S4684 35AR111/SSP4 Super Spot 4º 12V 3000 40000 C-8 2 3⁄8”Box6
35 AR111 G53 S4686 35AR111/SP8 Spot 8º 12V 3000 14000 C-8 2 5⁄16”Box6
35 AR111 G53 S4687 35AR111/FL25 Flood 25º 12V 3000 2500 C-8 2 5⁄16”Box6
50 AR111 G53 S4688 50AR111/SSP4 Super Spot 4º 12V 3000 45000 C-8 2 3⁄8”Box6
50 AR111 G53 S4689 50AR111/SP8 Spot 8º 12V 3000 20000 C-8 2 1⁄4”Box6
50 AR111 G53 S4690 50AR111/FL25 Flood 25º 12V 3000 4000 C-8 2 5⁄16”Box6
75 AR111 G53 S4691 75AR111/SP8 Spot 8º 12V 3000 30000 C-8 2 1⁄4”Box6
75 AR111 G53 S4692 75AR111/FL25 Flood 25º 12V 3000 5300 C-8 2 5⁄16”Box6
75 AR111 G53 S4693 75AR111/WFL45
100 AR111 G53 S4694 100AR111/SP8 Spot 8º 12V 3000 48000 C-8 2 1⁄4”Box6
100 AR111 G53 S4695 100AR111/FL25 Flood 25º 12V 3000 8500 C-8 2 5⁄16”Box6
100 AR111 G53 S4696 100AR111/WFL45
Wide Flood 45º
Wide Flood 45º
12V 3000 2000 C-8 2 3⁄16”Box6
12V 3000 2800 C-8 2 3⁄16”Box6
133
Halogen
Halogen
Sealed Beam Ref lectors
Sealed Beam Ref lectors
PAR36/PAR56/PAR64
PAR36/PAR56/PAR64
PAR36
halogen lamps
Screw Terminal
2 Piece Construction
12 V olt
S4807 36 Watt VeryNarrowSpot
S4808 36 Watt Narrow Spot
S4809 36 Watt Wide Flood
S4806 50 Watt Narrow Spot
Packing: Individually Boxed
12/Master
Bulb Satco Avg.Rated Pack. Mst.
Watts Type Base Order No. Lamp Code Beam Volts Hours CBCP* Lumens Filament M.O.L. Type Ctn.
36 P AR36 Screw Term. S4807 36P AR36/CAP/VNSP Spot 5º 12V 4000 17000 500 C–8 2 3/4”Box12
36 P AR36 Screw Term. S4808 36P AR36/CAP/NSP Spot 13º 12V 4000 3500 500 C–8 2 3/4”Box12
36 P AR36 Screw Term. S4809 36P AR36/CAP/WFL Flood 32º 12V 4000 1000 500 C–8 2 3/4”Box12
50 P AR36 Screw Term. S4806 50P AR36/CAP/NSP6 Spot 6º 12V 4000 25000 700 C–8 2 3/4”Box12
500 PAR56 Mogul End Prong S4668 500PAR56Q/NSP Narrow Spot 15º 120V 4000 78500 8800 CC–6 5 ” Box 12
500 PAR56 Mogul End Prong S4669 500PAR56Q/MFL Med.Flood 30º 120V 4000 40000 8800 CC–6 5” Box 12
500 PAR56 Mogul End Prong S4670 500PAR56Q/WFL Wide Flood 45º 120V 4000 19500 8800 CC–6 5 ” Box 12
1000 P AR64 Mogul End Prong S4671 1000PAR64Q/NSP Narrow Spot 20º 120V 4000 135000 19400 CC–6 6 ” Box 6
134
1000 P AR64 Mogul End Prong S4672 1000PAR64Q/MFL Med.Flood 30º 120V 4000 82000 19400 CC–6 6 ” Box 6
1000 P AR64 Mogul End Prong S4673 1000PAR64Q/WFL Wide Flood 60º 120V 4000 23000 19400 CC–6 6 ” Box 6
Mogul End Prong
2 Piece Construction
S4669 500 Watt Med. Flood
S4668 500 Watt Narrow Spot
S4670 500 Watt Wide Flood
Packing: Individually Boxed
Not Shown Actual Size
PAR56
120 V olt
12/Master
PAR64
Mogul End Prong
2 Piece Construction
120 V olt
S4672 1000 Watt Med.Flood
S4671 1000 Watt Narrow Spot
S4673 1000 Watt Wide Flood
Packing: Individually Boxed
6/Master
Halogen
Halogen
BRILLIANT
WHITE LIGHT
4000 Hours
EXTRA
LONG LIFE!
Dual
halogen
capsules
create
3 light levels
3 W ay
Reading Light
Soft White
Medium Base/120 Volt
S4505 30/70/100 Watt
S4506 50/100/150 Watt
Packing: 1/Sleeve
12/Inner
36/Master
General Service
General Service
A–Type
Double–Envelope
Medium Base/120 Volt
S4600 60 Watt White
S4601 75 Watt White
S4602 100 Watt White
S4603 60 Watt Clear
S4604 150 Watt White
Packing: 6/Inner
6/Inner - Tray Pack
60/Master
Not Shown Actual Size
Medium Base/120 Volt
S3472 75 Watt Clear
S3476 75 Watt Frosted
S3473 100 Watt Clear
S3477 100 Watt Frosted
S3474 150 Watt Clear
S3478 150 Watt Frosted
S3475 250 Watt Clear
S3479 250 Watt Frosted
Packing: 1 Bulb/Card
Lamps
Lamps
JDD Type
12 Cards/Master
halogen lamps
Watts Bulb Type Base Order No. Lamp Code Finish Volts Hours Lumens Filament M.O.L. Type Inner Pack
60 BT15 Med. S4603 60BT15/CL Clear 120V 5000 700 CC-8 4” Card/1 60/6
60 BT15 Med. S4600 60BT15/W White 120V 5000 600 CC-8 4” Card/1 60/6
75 BT15 Med. S4601 75BT15/W White 120V 5000 800 CC-8 4” Card/1 60/6
75 T10 Med. S3472 75T10Q/CL Clear 120V 2000 1050 CC-8 4” Card/1 12
75 T10 Med. S3476 75T10Q/F Frosted 120V 2000 1000 CC-8 4” Card/1 12
100 BT15 Med. S4602 100BT15/W White 120V 5000 1200 CC-8 4” Card/1 60/6
100 T10 Med. S3473 100T10Q/CL Clear 120V 2000 1500 CC-8 4” Card/1 12
100 T10 Med. S3477 100T10Q/F Frosted 120V 2000 1420 CC-8 4” Card/1 12
150 BT15 Med. S4604 150BT15/W White 120V 5000 1600 CC-8 4” Card/1 60/6
150 T10 Med. S3474 150T10Q/CL Clear 120V 2000 2500 CC-8 4” Card/1 12
150 T10 Med. S3478 150T10Q/F Frosted 120V 2000 2300 CC-8 4” Card/1 12
250 T10 Med. S3475 250T10Q/CL Clear 120V 2000 4200 CC-8 4” Card/1 12
250 T10 Med. S3479 250T10Q/F Frosted 120V 2000 3900 CC-8 4” Card/1 12
30 295 CC–8
70 A21 E26/Med. S4505
100 1080
50 585 CC–8
100 A21 E26/Med. S4506
150 1985
Satco Avg.Rated Pack. Mst.Ctn./
3–Way Reading Light
30/70/100A21/W
50/100/150A21/W
White 120V 4000 785 CC–8 5 1/16” Sleeve 36/12
White 120V 4000 1400 CC–8 5 1/16” Sleeve 36/12
135
Halogen
Halogen
JD Bayonet
JD Bayonet
JD
Bayonet
120 Volt
S1979 35 Watt
S1981 50 Watt
S3159 75 Watt
S3147 100 Watt
S3122 150 Watt
S3123 250 Watt
S1983 500 Watt
Packing:
Individually Boxed
12/Carton
Lamps
Lamps
2000 Hours
JD
Frosted
Bayonet
120 Volt
S1980 35 Watt
S1982 50 Watt
S1919 75 Watt
S1920 100 Watt
S1921 150 Watt
S1922 250 Watt
S1984 500 Watt
Packing:
Individually Boxed
12/Carton
halogen lamps
Not Shown Actual Size
Watts Bulb Type Base Order No. Lamp Code Finish Volts Hours Lumens Filament M.O.L. Type Mst.Ctn.
35 T4 DC.Bay S1979 35Q/CL Clear 120V 2000 400 CC–8 2 23/32”Box 12
35 T4 DC.Bay S1980 35Q/F Frost 120V 2000 360 CC–8 2 23/
50 T4 DC.Bay S1981 50Q/CL Clear 120V 2000 750 CC–8 2 23/32”Box 12
50 T4 DC.Bay S1982 50Q/F Frost 120V 2000 675 CC–8 2 23/32”Box 12
75 T4 DC.Bay S3159 75Q/CL Clear 120V 2000 1250 CC–8 2 13/32”Box 12
75 T4 DC.Bay S1919 75Q/F Frost 120V 2000 1125 CC–8 2 13/32”Box 12
100 T4 DC. Bay S3147 100Q/CL Clear 120V 2000 1600 CC–8 2 13/
100 T4 DC. Bay S1920 100Q/F Frost 120V 2000 1440 CC–8 2 13/32”Box 12
150 T4.5 DC. Bay S3122 150Q/CL Clear 120V 2000 2400 CC–8 2 13/32”Box 12
150 T4.5 DC. Bay S1921 150Q/F Frost 120V 2000 2160 CC–8 2 13/32”Box 12
250 T4.5 DC. Bay S3123 250Q/CL Clear 120V 2000 4350 CC–8 2 27/32”Box 12
250 T4.5 DC. Bay S1922 250Q/F Frost 120V 2000 3915 CC–8 2 27/
500 T4.5 DC. Bay S1983 500Q/CL Clear 120V 2000 8500 CC–8 3 3/4”Box12
500 T4.5 DC. Bay S1984 500Q/F Frost 120V 2000 7650 CC–8 3
136
Satco Avg.Rated Pack.
32
”Box 12
32
”Box 12
32
”Box 12
3
/4”Box12
Halogen
Halogen
2000 Hours
JD
JD
JD
JD
JD E–14
Lamps
Lamps
halogen lamps
Clear Mini Can
120 Volt
S3165 35 Watt
S3162 50 Watt
S3157 75 Watt
S3107 100 Watt
S3108 150 Watt
S3109 250 Watt
S3181 500 Watt
130 Volt
S3198 50 Watt
Packing: Individually Boxed
12/Carton
Satco Avg.Rated Pack.
Watts Bulb Type Base Order No. Lamp Code Finish Volts Hours Lumens Filament M.O.L. Type Mst.Ctn.
35 T4 E11 S3165 35Q/CL Clear 120V 2000 400 CC–8 2 5/16”Box 12
35 T4 E11 S1913 35Q/F Frost 120V 2000 360 CC–8 2 5/16”Box 12
50 T4 E11 S3162 50Q/CL Clear 120V 2000 750 CC–8 2 5/16”Box 12
50 T4 E11 S1914 50Q/F Frost 120V 2000 675 CC–8 2 5/16”Box 12
50 T4 E11 S3198 50Q/CL Clear 130V 2000 750 CC–8 2 5/16”Box 12
75 T4 E11 S3157 75Q/CL Clear 120V 2000 1250 CC–8 2 11/16”Box 12
75 T4 E11 S1915 75Q/F Frost 120V 2000 1125 CC–8 2 11/16”Box 12
100 T4 E11 S3107 100Q/CL Clear 120V 2000 1600 CC–8 2 11/16”Box 12
100 T4 E11 S1916 100Q/F Frost 120V 2000 1440 CC–8 2 11/16”Box 12
100 T4.5 E14 S3132 100Q/CL Clear 120V 2000 1600 CC–8 2 15/16”Box 12
150 T4.5 E11 S3108 150Q/CL Clear 120V 2000 2400 CC–8 2 23/32”Box 12
150 T4.5 E11 S1917 150Q/F Frost 120V 2000 2160 CC–8 2 23/32”Box 12
150 T4.5 E14 S3133 150Q/CL Clear 120V 2000 2400 CC–8 3 1/32”Box 12
250 T4.5 E11 S3109 250Q/CL Clear 120V 2000 4350 CC–8 3 5/32”Box 12
250 T4.5 E11 S1918 250Q/F Frost 120V 2000 3915 CC–8 3 5/32”Box 12
250 T4.5 E14 S3134 250Q/CL Clear 120V 2000 4350 CC–8 3 11/32”Box 12
500 T4.5 E11 S3181 500Q/CL Clear 120V 2000 8500 CC–8 3 15/32”Box 12
500 T4.5 E11 S3182 500Q/F Frost 120V 2000 7650 CC–8 3
Frosted Mini Can
120 Volt
S1913 35 Watt
S1914 50 Watt
S1915 75 Watt
S1916 100 Watt
S1917 150 Watt
S1918 250 Watt
S3182 500 Watt
Packing:
Individually Boxed
12/Carton
European
120 Volt
S3132 100 Watt
S3133 150 Watt
S3134 250 Watt
Packing:
Individually Boxed
12/Carton
Not Shown
Actual Size
15
/32”Box 12
137
Krypton/Xenon
Krypton/Xenon
High Performance Lamps
High Performance Lamps
Frosted
E–11
Mini Can Base
S4489 20 Watt
S4490 40 Watt
S4491 60 Watt
Clear
E–11
Mini Can Base
S4486 20 Watt
S4487 40 Watt
S4488 60 Watt
Frosted
D.C.
Bayonet Base
S4495 20 Watt
S4496 40 Watt
S4497 60 Watt
Frosted
E–12
Candelebra Base
S4483 20 Watt
S4484 40 Watt
S4485 60 Watt
3000 Hours
120 Volt
Clear
D.C.
Bayonet Base
S4492 20 Watt
S4493 40 Watt
S4494 60 Watt
Clear
E–12
Candelebra Base
S4480 20 Watt
S4481 40 Watt
S4482 60 Watt
halogen lamps
White light similar to halogen•Less heat •Lamps can be touched
Fully dimmable
•
Not Shown Actual Size
Satco Avg.Rated Pack. Mst.Ctn./
138
Watts Bulb Type Base Order No. Lamp Code Finish Volts Hours Lumens Filament M.O.L. Type Inner Pack
20 T3 E12 S4480 KX20CL/E12 Clear 120V 3000 200 CC–8 2 7/16” Box 100/10
20 T3 E12 S4483 KX20FR/E12 Frost. 120V 3000 200 CC–8 2 7/16” Box 100/10
20 T3 E11 S4486 KX20CL/E11 Clear 120V 3000 200 CC–8 2 5/16” Box 100/10
20 T3 E11 S4489 KX20FR/E11 Frost 120V 3000 200 CC–8 2 5/16” Box 100/10
20 T3 D.C. Bay S4492 KX20CL/DC Clear 120V 3000 200 CC–8 2 1/4” Box 100/10
20 T3 D.C. Bay S4495 KX20FR/DC Frost 120V 3000 200 CC–8 2 1/4” Box 100/10
40 T3 E12 S4481 KX40CL/E12 Clear 120V 3000 560 CC–8 2 7/16” Box 100/10
40 T3 E12 S4484 KX40FR/E12 Frost 120V 3000 560 CC–8 2 7/16” Box 100/10
40 T3 E11 S4487 KX40CL/E11 Clear 120V 3000 560 CC–8 2 5/16” Box 100/10
40 T3 E11 S4490 KX40FR/E11 Frost 120V 3000 560 CC–8 2 5/16” Box 100/10
40 T3 D.C. Bay S4493 KX40CL/DC Clear 120V 3000 560 CC–8 2 1/4” Box 100/10
40 T3 D.C. Bay S4496 KX40FR/DC Frost 120V 3000 560 CC–8 2 1/4” Box 100/10
60 T3 E12 S4482 KX60CL/E12 Clear 120V 3000 960 CC–8 2 7/16” Box 100/10
60 T3 E12 S4485 KX60FR/E12 Frost 120V 3000 960 CC–8 2 7/16” Box 100/10
60 T3 E11 S4488 KX60CL/E11 Clear 120V 3000 960 CC–8 2 5/16” Box 100/10
60 T3 E11 S4491 KX60FR/E11 Frost 120V 3000 960 CC–8 2 5/16” Box 100/10
60 T3 D.C. Bay S4494 KX60CL/DC Clear 120V 3000 960 CC–8 2 1/4” Box 100/10
60 T3 D.C. Bay S4497 KX60FR/DC Frost 120V 3000 960 CC–8 2
No Significant UV.
1
/4” Box 100/10
Halogen
Halogen
2000 Hours
Frosted Bi Pin
12 Volt
S1908 10 Watt
S1909 20 Watt
S1910 35 Watt
S1911 50 Watt
S1912 75 Watt
Packing:
Individually Boxed
48/Carton
Watts Bulb Type Base Order No. Lamp Code Finish Volts Hours Lumens Filament M.O.L. Type Inner Pack
5 T3 G4. S3179 5T3 Clear 12V 2000 50 C–6 32 MM Box 48
10 T3 G4. S3171 10T3 Clear 12V 2000 120 C–6 32 MM Box 48
10 T3 G4 S1908 10T3/F Frost 12V 2000 100 C–6 32 MM Box 48
20 T3 G4 S3120 20T3 Clear 12V 2000 320 C–6 32 MM Box 48
20 T3 G4 S1909 20T3/F Frost 12V 2000 300 C–6 32 MM Box 48
20 T3 G4 S1986 20T3 Clear 24V 2000 260 C–6 32 MM Box 48
20 T4 G8 S4610 20T4 Clear 120V 2000 180 C–6 46 MM Box 48
20 T4 G9 S4614 20T4 Clear 120V 2000 180 C–6 45 MM Box 48
25 T4 G8 S4611 25T4/F Clear 120V 2000 240 C–6 46 MM Box 48
25 T4 GY6.35 S3197 25T4 Clear 120V 2000 240 CC–8 50 MM Box 48
25 T4 G9 S4615 25T4/F Clear 120V 2000 240 C–6 45 MM Box 48
35 T4 GY6.35 S3160 35T4 Clear 12V 2000 600 C–6 41 MM Box 48
35 T4 GY6.35 S1910 35T4/F Frost 12V 2000 550 C–6 41 MM Box 48
35 T4 GY6.35 S3164 35T4 Clear 120V 2000 400 CC–8 50 MM Box 48
35 T4 G8 S4620 35T4 Clear 120V 2000 400 C–6 46 MM Box 48
35 T4 G9 S4621 35T4 Clear 120V 2000 400 C–6 45 MM Box 48
50 T4 G8 S4612 50T4 Clear 120V 2000 750 C–6 46 MM Box 48
50 T4 GY6.35 S3121 50T4 Clear 12V 2000 900 C–6 41 MM Box 48
50 T4 GY6.35 S1911 50T4/F Frost 12V 2000 850 C–6 41 MM Box 48
50 T4 GY6.35 S1987 50T4 Clear 24V 2000 850 C–6 41 MM Box 48
50 T4 GY6.35 S3167 50T4 Clear 120V 2000 750 CC–8 50 MM Box 48
50 T4 G9 S4616 50T4 Clear 120V 2000 750 C–6 45 MM Box 48
75 T4 GY6.35 S3156 75T4 Clear 12V 2000 1350 C–6 41 MM Box 48
75 T4 GY6.35 S1912 75T4/F Frost 12V 2000 1290 C–6 41 MM Box 48
75 T4 GY6.35 S3168 75T4 Clear 120V 2000 1250 CC–8 60 MM Box 48
75 T4 G8 S4613 75T4/F Clear 120V 2000 1250 C–6 58 MM Box 48
75 T4 G9 S4617 75T4/F Clear 120V 2000 1250 C–6 56 MM Box 48
100 T4 GY6.35 S1924 100T4 Clear 120V 2000 2000 CC–8 60 MM Box 48
100 T4 G8 S4622 100T4/F Clear 120V 2000 2000 CC–8 58 MM Box 48
Bi Pin
12 V olt
S3179 5 Watt
S3171 10 Watt
S3120 20 Watt
S3160 35 Watt
S3121 50 Watt
S3156 75 Watt
24 V olt
S1986 20 Watt
S1987 50 Watt
Packing: Individually
Boxed,48/Carton
Satco Avg.Rated Pack. Mst.Ctn./
Bi Pin
120 V olt
GY6.35 Base
S3197 25 Watt
S3164 35 Watt
S3167 50 Watt
S3168 75 Watt
S1924 100 Watt
Packing:
Individually Boxed
48/Carton
Bi–Pin
Bi–Pin
Bi Pin
120 V olt
G8 Base
S4610 20 Watt
S4611 25 Watt
S4620 35 Watt
S4612 50 Watt
S4613 75 Watt
S4622 100 Watt
Individually Boxed
Not Shown Actual Size
(Wide Pin)
Packing:
48/Carton
Lamps
Lamps
Double Loop
120 V olt
G9 Base
S4614 20 Watt
S4615 25 Watt
S4621 35 Watt
S4616 50 Watt
S4617 75 Watt
S4642 100 Watt
Packing:
Individually Boxed
48/Carton
halogen lamps
139
Halogen
Halogen
Double Ended
Double Ended
78MM J–Type
120 Volt
S3199 75 Watt
S3146 100 Watt
S3135 150 Watt
S3145 200 Watt
S3184 250 Watt
254MM J–Type
(Short)
130 Volt
S3183 75 Watt
Packing:
Individually Boxed,
12/Master
(Long)
240 Volt
S3106 1500 Watt
Packing: Individually Boxed,
Lamps
Lamps
118MM J–Type
120 Volt
S3166 100 Watt
S3142 150 Watt
S3136 200 Watt
S3104 300 Watt
S3105 500 Watt
12/Master
2000 Hours
(Long)
130 Volt
S1925 300 Watt
S1926 500 Watt
Packing:
Individually Boxed,
12/Master
Flat Blade
halogen lamps
Not Shown Actual Size
Satco Avg.Rated Pack. Mst.Ctn./
140
Watts Bulb Type Base Order No. Lamp Code Finish Volts Hours Lumens Filament M.O.L. Type Inner Pack
75 T3 R7S S3199 75T3Q/CL Clear 120V 2000 1200 C–8 3 1/8”Box12
75 T3 R7S S3183 75T3Q/CL Clear 130V 2000 1200 C–8 3 1/8”Box12
100 T3 R7S S3146 100T3Q/CL Clear 120V 2000 1650 C–8 3 1/8”Box12
100 T3 R7S S3166 100T3Q/CL Clear 120V 2000 1650 C–8 4 11/16”Box12
150 T3 R7S S3135 150T3Q/CL Clear 120V 2000 2600 C–8 3 1/8”Box12
150 T3 R7S S3142 150T3Q/CL Clear 120V 2000 2600 C–8 4 11/16”Box12
200 T3 R7S S3145 200T3Q/CL Clear 120V 2000 3200 C–8 3 1/8”Box12
200 T3 R7S S3136 200T3Q/CL Clear 120V 2000 3200 C–8 4 11/16”Box12
250 T3 R7S S3184 250T3Q/CL Clear 120V 2000 3950 C–8 3 1/8”Box12
300 T3 R7S S3104 300T3Q/CL Clear 120V 2000 5000 C–8 4 11/16”Box12
300 T3 R7S S1925 300T3Q/CL Clear 130V 2000 5000 C–8 4 11/16”Box12
300 T3 Blade S3180 300T3Q/CL Clear 120V 2000 5000 C–8 5 13/16”Box12
500 T3 R7S S3105 500T3Q/CL Clear 120V 2000 9500 C–8 4 11/16”Box12
500 T3 R7S S1926 500T3Q/CL Clear 130V 2000 9500 C–8 4 11/16”Box12
500 T3 Blade S1923 500T3Q/CL Clear 120V 2000 9500 C–8 5 13/16”Box12
1500 T3 R7S S3106 1500T3Q/CL Clear 240V 2000 33000 C–8 10
145MM J–Type
(Blade)
120 Volt
S3180 300 Watt
S1923 500 Watt
Packing: Individually Boxed,
12/Master
1
/16”Box 12
2000 Hours
Miniature Pendant
Fixtures
BBAALLLL
BBAALLLL
ite
L
ite
L
1.8”
2.22”
2.22”
1.6”
Ball
Ball
Lite
Lite
halogen lamps
0.32”
1.26”
Vanity Lighting
Cable Systems
Landscape Lighting
Application Suggestions
Decorative Fixtures
Application Suggestions
JCGV-14.4
12 Volt
1.8”Diameter
S3187 20W
S3188 35W
S3189 50W
Packing:
Individually Boxed
200/Master,25/Inner
1.8”
2.57”
0.32”
1.26”
0.32”
1.26”
JCGV-12.8
12 Volt
1.6”Diameter
S3193 20W
Packing:
Individually Boxed
200/Master,25/Inner
U.L.classified
for U.V. filtration
and particle
containment
JCGV-14.4
Long Neck
12 Volt
1.8”Diameter
S3190 20W
S3191 35W
S3192 50W
Packing:
Individually Boxed
200/Master,25/Inner
Watts Bulb Type Base Order No. Lamp Code Finish Volts Hours Lumens Filament M.O.L. Type Inner Pack
20 GV14.4 GX5.3 S3187 20JVGV2-614 White 12V 2000 320 C–6 2.22” Box 200/25
35 GV14.4 GX5.3 S3188 35JVGV2-614 White 12V 2000 620 C–6 2.22” Box 200/25
50 GV14.4 GX5.3 S3189 50JVGV2-614 White 12V 2000 940 C–6 2.22” Box 200/25
20 GV14.4 GX5.3 S3190 20JVGV2L-614 White 12V 2000 320 C–6 2.57” Box 200/25
35 GV14.4 GX5.3 S3191 35JVGV2L-614 White 12V 2000 620 C–6 2.57” Box 200/25
50 GV14.4 GX5.3 S3192 50JVGV2L-614 White 12V 2000 940 C–6 2.57” Box 200/25
20 GV12.8 G4 S3193 20JVGV2L-614 White 12V 2000 340 C–6 2.22” Box 200/25
Satco Avg.Rated Pack. Mst.Ctn./
141
Loading...
