Page 1
S13127
100W/LED/HP360/850
GENERAL SPECIFICATIONS
Shape: UFO
Wattage: 100W
Lumen Output: 15000L
Color Temperature: 5000K
Base: Mogul Extended
TECHNICAL SPECIFICATIONS
Wattage: 100W
Volts: 100V-277V
HID Equivalent: 350
Shape: UFO
Filament: LED
Base: Mogul Extended
ANSI Base: EX39
Finish: White
Housing Color: White
Hours Rated: 50000H
DIMENSIONS
MOL: 12.35"
MOD: 4.6"
Weight: 3.19
Min. Compartment Size:
Length: 9.85 in. Width: 9.85 in.
Depth: 11.93 in.
Color Temperature: 5000K
CRI: 80CRI
Lumen Output: 15000L
Dimmable: Dimmable with optional control modules
Beam Spread: 360D
Power Factor: 0.9
Operating Temp: -30C (-22F) to a maximum of 45C ( 113F)
Safety Listing: cULus
Technology: LED
Material: Aluminum & PC
LISTINGS
Safety Listing: cULus
Location Rating: Damp
DLC Approved: Yes
DLC Classification: Standard
DLC ID: PLWAS1LC2WAX;PLDRT7BU9AXX
DLC Primary Use:
CEC Terse: Lawful for sale in California
IP Rating: IP64
RoHS Compliant: Yes
FCC Compliant: Yes
Replacement Lamps for Outdoor
Pole/Arm-mounted Area and
Roadway Luminaires (Type B)
PACKAGING
Each UPC: 045923131271
Each Quantity: 1
Each Dimensions: 14.23 x 8.73 x 6.48"
110 Heartland Blvd. Distribution Centers National Toll-Free Copyright 2020
Brentwood, NY 11717 New York, Florida, 800-43-SATCO Satco Products, Inc.
PH 631-243-2022 Texas, Washington, (800-437-2826) All Rights Reserved
FX 631-243-2027 California, Puerto Rico www.satco.com December 30, 2020
Inner UPC: 20045923131275
Inner Quantity:
Inner Dimensions: 0.00 x 0.00 x 0.00"
Page 1
Case UPC: 10045923131278
Case Quantity: 4
0
Case Dimensions: 14.86 x 18.08 x 13.60"
