Sartorius MCA3.6P-2S00-M, MCA6.6SM-S00, MCA6.6S-2S00-M, MCA2.7SM-S00, MCA2.7S-2S00-M Sartorius Cubis II (MCA) Micro Balances Operating Instructions
...
Operating Instructions
Original Operating Instructions
Cubis®
MCA Models
Micro B
alances
1000047994
Contents
Contents
1 About these Instructions............................ 5
1.1 Scope......................................... 5
1.2 Symbols Used .................................. 5
1.2.1 Warnings in Operating Instructions ......... 5
1.2.2 Other Symbols........................... 5
1.3 Target Groups.................................. 6
2 Safety Instructions ................................. 7
2.1 Intended Use...................................7
2.2 Personnel Qualification.......................... 7
2.3 Proper Working Order of the Device ............... 8
2.4 Symbols on the Device ..........................8
2.5 Electrical Equipment ............................8
2.5.1 Damage to the Device’s Electrical
Equipment.............................. 8
2.5.2 Working on the Device’s Electrical
Equipment.............................. 8
2.5.3 AC Adapter and Power Supply Cable ........8
2.6 Conduct in an Emergency........................ 8
2.7 Accessories, Consumables, and Spare Parts..........9
2.8 Personal Protective Equipment ...................9
2.9 Glass Breakage ................................. 9
3 Device Description ................................10
3.1 Device Overview............................... 10
3.2 Draft Shield ..................................11
3.3 Weighing Pan and Associated Components ........12
3.4 Connections and Components on the Backside
of the Weighing Module........................ 12
3.5 Connections on the Control Unit.................13
3.6 Connections and Components on the Electronics
Module ......................................13
3.7 Displays on the Weighing Module ................14
3.8 Motorized Draft Shield .........................14
3.8.1 Sensor Area ............................14
3.8.2 Operating Elements for the Draft Shield ....14
3.9 Conformity-assessed Devices ....................14
3.10 Symbols on the Device .........................15
4 Operating Concept................................16
4.1 Operating Elements in the Main Menu ............16
4.2 Operating Elements in Task Management.......... 17
4.3 Operating Elements in the Weighing Display .......18
4.4 Advanced Operator Guidance....................19
4.5 Messages..................................... 20
4.6 Status Center .................................21
4.7 Keypad.......................................22
4.8 Status Display of the Buttons....................22
4.9 Buttons in the Operating Display................. 23
4.9.1 Buttons for Navigation or Organization
in Displays .............................23
4.9.2 Buttons for Editing or Managing Entries....24
4.9.3 Weighing and Print Function Buttons ......25
4.10 Displays in the Operating Display.................26
4.11 User Management .............................27
4.11.1 User Profiles ...........................27
4.11.2 User Login .............................27
4.12 Profile Management ...........................27
4.13 Applications and Tasks..........................27
4.14 Menu Structure ...............................28
4.14.1 Main Menu ............................28
4.14.2 “Settings” Menu . . . . . . . . . . . . . . . . . . . . . . . . 28
4.15 Navigating the Menus.......................... 32
5 Installation....................................... 34
5.1 Scope of Delivery.............................. 34
5.2 Selecting an Installation Site ....................34
5.3 Unpacking the Device ..........................35
5.4 Connecting the Ethernet Cable ..................35
5.5 Preparing Below-balance Weighing ..............35
5.6 Procedure ....................................36
5.7 Installing a Microbalance with Glass Draft Shield ...36
5.7.1 Positioning the Weighing Pan and
Associated Components..................36
5.8 Installing a Filter Balance with a Metal Ring
Draft Shield ..................................37
5.8.1 Positioning the Weighing Pan and
Associated Components..................37
5.8.2 Optimizing a Filter Weighing Pan
with a Metal Ring Draft Shield for
Left-handed Users ......................38
5.9 Connecting the Electronics Module............... 38
5.10 Installing Palm-operable Keys (Only for Devices
with Motorized Draft Shield) ....................39
5.11 Acclimatizing .................................39
6 Getting Started................................... 40
6.1 Installing the AC Adapter .......................40
6.2 Connecting the Power Supply ...................40
7 System Settings................................... 41
7.1 Performing System Settings..................... 41
7.2 Switching Off the isoCAL Function ...............41
7.3 Assigning a Password ..........................41
7.4 Parameter List ................................42
7.4.1 Parameters in the “User Configuration”
Menu .................................42
7.4.2 Parameters in the “Profile Management”
Menu .................................42
7.4.3 Parameters in the “Device Settings” Menu ..45
7.4.4 Parameters in the “Connections” Menu.....49
7.4.5 Parameters in the “Device Maintenance”
Menu .................................53
Cubis® MCA Operating Instructions 3
Contents
8 Operation ........................................ 54
8.1 Switching the Device On and Off.................54
8.2 Logging Users In and Out .......................54
8.3 Leveling the Device ............................55
8.3.1 Leveling the Device .....................55
8.4 Opening and Closing the Motorized Draft Shield
(Only for Devices with a Motorized Draft Shield) ...55
8.4.1 Defining the Opening Width.............. 56
8.5 Activating Applications and Adding a Task.........56
8.5.1 Activating Applications . . . . . . . . . . . . . . . . . . 56
8.5.2 Adding an Application to a Task........... 57
8.6 Adding Print and Weighing Profiles to a Task ......57
8.7 Preparing Weighings ...........................57
8.8 Weighing.....................................58
8.9 Overview of Calibration, Adjustment,
and Linearization .............................. 58
8.10 Adjusting with the isoCAL Function ..............59
8.11 Internally Calibrating and Adjusting the Device ....60
8.12 Weighing and Printing with ID Marking ...........60
8.12.1 Saving Values for Printouts............... 60
8.12.2 Marking Saved Values as Invalid........... 61
8.12.3 Marking Saved Values as Valid ............61
8.12.4 Printing Saved Values ...................61
8.12.5 Exiting the Task.........................61
8.13 Viewing the Alibi Memory ......................62
8.14 Running Applications (Examples)................. 62
8.14.1 Executing the “Toggle Between Weight
Units” Function.........................62
8.14.2 Running the “Statistics” Application .......63
9 Cleaning and Maintenance.........................64
9.1 Preparing the Device........................... 64
9.2 Cleaning the Device............................ 64
9.3 Assembling and Connecting the Device ...........65
9.4 Maintenance Schedule .........................65
9.5 Performing a Software Update ..................65
9.6 Performing a QAPP Center Update ...............66
10 Malfunctions ..................................... 67
10.1 Status Messages...............................67
10.2 Warning Messages .............................67
10.3 Troubleshooting ...............................67
11 Decommissioning .................................68
11.1 Decommissioning the Device ....................68
14 Disposal..........................................70
14.1 Information on Decontamination ................70
14.2 Disposing of Device and Parts ...................70
14.2.1 Information on Disposal .................70
14.2.2 Disposing ..............................70
15 Technical Data.................................... 71
15.1 Dimensions and Weight ........................71
15.1.1 Microbalance ..........................71
15.2 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
15.2.1 Device ................................71
15.2.2 AC Adapter ............................71
15.2.3 Safety of Electrical Equipment ............72
15.2.4 Electromagnetic Compatibility ............72
15.3 Materials..................................... 72
15.4 Integrated Clock............................... 72
15.5 Backup Battery................................72
15.6 Ambient Conditions............................ 73
15.6.1 Installation Site.........................73
15.6.2 Ambient Temperature for the
isoCAL Function ........................73
15.6.3 Protection Class ........................73
15.7 Metrological Data .............................74
15.7.1 Models MCA2.7S | MCA10.6S | MCA6.6S |
MCA3.6P ..............................74
15.8 Recommended Calibration Weight ...............74
15.9 isoCAL Function ...............................75
15.10 Alibi Memory ................................. 75
15.11 Interfaces.................................... 75
15.11.1 Specifications of the COM-RS232
Interface ..............................75
15.11.2 Specifications for the USB-A Interface .....75
15.11.3 Specifications for the USB-B Interface .....75
16 Accessories.......................................76
16.1 Accessories ...................................76
16.1.1 Printers and Communication .............76
16.1.2 Displays and Input / Output Elements.......76
16.1.3 Hardware and Software for Pipette
Calibration............................. 77
16.1.4 Filter Balance and Antistatic Accessories.... 77
16.1.5 Weighing Tables ........................77
16.1.6 Weighing Accessories....................77
17 Sartorius Service..................................78
12 Transport ........................................68
12.1 Transporting the Device ........................68
13 Storage and Shipping .............................69
13.1 Storage ......................................69
13.2 Returning Device and Parts .....................69
4 Cubis® MCA Operating Instructions
18 Conformity and Certificates........................78
18.1 EU Declaration of Conformity ...................78
18.2 Certificate of Compliance .......................80
18.3 FCC Supplier’s Declaration of Conformity.......... 82
About these Instructions
1 About these Instructions
1.1 Scope
These instructions are part of the device. These instructions apply to the device in the
following versions:
Device Model
Ultramicrobalance and microbalance
with motorized draft shield
Filter Ultramicrobalances and
Microbalances
1.2 Symbols Used
MCA10.6S...-M | MCA2.7S...-M |
MCA3.6P...-M | MCA6.6S...-M
MCA10.6S...-F | MCA2.7S...-F |
MCA6.6S...-F
1.2.1 Warnings in Operating Instructions
WARNING
Denotes a danger with the risk that death or severe injury may result if it is not
avoided.
CAUTION
Denotes a hazard that may result in moderate or minor injury if it is not avoided.
NOTICE
Denotes a danger with the risk that property damage may result if it is not avoided.
1.2.2 Other Symbols
t
y Result: Describes the result of the actions carried out.
[ ] Text inside brackets refers to control and display items.
[ ] Text inside brackets indicates status, warning, and error messages.
Required action: Describes actions which must be carried out.
Indicates information for legal metrology for conformity-assessed
(verified) devices. Conformity-assessed devices are also referred to as
“verified” in these instructions.
Figures on the Operating Display
The figures on the operating display of the device may deviate from those in these
instructions.
Cubis® MCA Operating Instructions 5
About these Instructions
1.3 Target Groups
These instructions are addressed to the following target groups. The target groups
must possess the specified knowledge.
Target group Knowledge and responsibilities
User The user is familiar with the operation of the device and the
associated work processes. They understand the hazards which may
arise when working with the device and know how to prevent them.
They have been trained in the operation of the device.
The training is carried out by the operating engineer / laboratory
manager or the operator of the device.
Operator The operator of the device is responsible for compliance with safety
requirements and workplace safety regulations.
The operator must ensure that all persons who work with the device
have access to the relevant information and are trained in working
with the device.
6 Cubis® MCA Operating Instructions
Safety Instructions
2 Safety Instructions
2.1 Intended Use
The device is a high-resolution balance, which can be used in laboratories. The device
was developed for the accurate determination of the mass of materials in liquid,
paste, powder, or solid form.
Appropriate containers must be used for loading each type of material. The device
can be used in stand-alone operation or can be operated on a PC.
The device is exclusively designed for use according to these instructions. Any further
use beyond this is considered improper.
If the device is not used properly: The protective systems of the device may be
impaired. This can lead to unforeseeable personal injury or property damage.
Operating Conditions for the Device
Do not use the device in potentially explosive environments. The device may only be
used indoors.
The device may only be used with the equipment and under the operating conditions
described in the Technical Data section of these instructions.
Modifications to the Device
You may not modify or repair the device or make any technical changes.
Any retrofitting or technical changes to the device are only permitted with prior
written permission from Sartorius.
2.2 Personnel Qualification
All persons working on the device must possess the necessary knowledge and
responsibilities (see Chapter “1.3 Target Groups”, page 6).
If no qualifications are indicated for the actions described in these instructions:
The actions described are addressed to the “User” target group.
If individual actions must be carried out by other target groups or by
Sartorius Service personnel: The qualification required will be indicated in the
description of the action.
Significance of these Instructions
Failure to follow the instructions in this manual can have serious consequences,
e.g., exposure of individuals to electrical, mechanical, or chemical hazards.
t Before working with the device, read the instructions carefully and in full.
t If these instructions are lost, request a replacement or download the latest
version from the Sartorius website (www.sartorius.com).
t Ensure that the information contained in these instructions is available to all
individuals working on the device.
Cubis® MCA Operating Instructions 7
Safety Instructions
2.3 Proper Working Order of the Device
A damaged device or worn parts may lead to malfunctions or cause hazards which
are difficult to recognize.
t Only operate the device when it is safe and in perfect working order.
t Have any malfunctions or damage repaired immediately by Sartorius Service.
2.4 Symbols on the Device
All symbols appearing on the device, such as warnings and safety labels, must be
legible.
t Do not conceal, remove, or modify the symbols.
t Replace the symbols if they become illegible.
2.5 Electrical Equipment
2.5.1 Damage to the Device’s Electrical Equipment
Damage to the electrical equipment of the device, e.g. damage to the insulation,
can be life-threatening. Contact with parts under voltage represents a direct danger
to life.
t If the device’s electrical equipment is defective, disconnect the device from the
power supply and contact Sartorius Service.
t Keep live parts away from moisture. Moisture can cause short-circuits.
2.5.2 Working on the Device’s Electrical Equipment
Only Sartorius Service personnel may work on or modify the electrical equipment of
the device. The device may only be opened by Sartorius Service personnel.
2.5.3 AC Adapter and Power Supply Cable
Serious injury can result, e.g. from electric shocks, if an unsuitable and inadequately
dimensioned power supply cable or unsuitable AC adapter is used.
t Only use the original power supply cable and AC adapter.
t If the AC adapter or power supply cable must be replaced: Contact Sartorius
Service. Do not repair or modify the AC adapter or power supply cable.
2.6 Conduct in an Emergency
If there is immediate danger of personal injury or if there is a risk of damage to
the device, e.g., due to malfunctions or dangerous situations, the device must be
immediately taken out of operation.
t Disconnect the device from the power supply by disconnecting the power supply
cable.
t Malfunctions should be remedied by Sartorius Service.
8 Cubis® MCA Operating Instructions
Safety Instructions
2.7 Accessories, Consumables, and Spare Parts
The use of unsuitable accessories, consumables, and spare parts can affect the
functionality and safety of the device and have the following consequences:
− Risk of injury to persons
− Damage to the device
− Device malfunctions
− Device failure
t Only use approved accessories, consumables, and spare parts supplied by
Sartorius. Information on operational quality is available upon request from
Sartorius.
t Only use accessories, consumables, and spare parts that are in proper working
order.
2.8 Personal Protective Equipment
Personal protective equipment protects against risks arising from the samples used.
t If the workplace or the measurement process in which the device is being used
requires personal protective equipment: Wear personal protective equipment.
2.9 Glass Breakage
Glass components can break if they fall or are handled incorrectly. Glass fragments
can cause cuts.
t Only lift the device by its base, not by the draft shield.
t When lifting and transporting, ensure that no personnel or objects are in the
way.
Cubis® MCA Operating Instructions 9
Device Description
3 Device Description
3.1 Device Overview
8
1
2
3
4
7
Fig. 1: Microbalance with glass draft shield and electronics module (example)
Pos. Designation Description
1 Leveling foot Motorically adjustable
2 Manufacturer’s ID label Not depicted
3 Electronics module
4 Operating display Touchscreen
5 Palm-operated key Only for microbalance with motorized draft shield: Opens and closes draft shield.
6 Control unit
7 Weighing module
8 Weighing chamber
5
5
6
10 Cubis® MCA Operating Instructions
3.2 Draft Shield
3
Device Description
4
1
2
Fig. 2: Microbalance with motorized glass draft shield and filter microbalance with manual metal ring draft shield (example)
Pos. Designation Description
1 Metal ring draft shield cover Made from metal, with handle, can be removed.
2 Metal ring draft shield Consists of 2 metal rings that have been placed into each other with a side opening,
can be rotated manually.
3 Glass draft shield Made from glass, with side opening, can be rotated manually or via a motor.
Can be removed.
4 Sensor window For the motion sensor, controls opening and closing of the motorized glass draft shield
Cubis® MCA Operating Instructions 11
Device Description
3.3 Weighing Pan and Associated Components
6
1
5
2
2
3
4
Fig. 3: Microbalance with motorized glass draft shield and filter microbalance with manual metal ring draft shield (example)
3
4
Pos. Designation Description
1 Filter weighing pan
2 Shield plate
3 Connector For models MCA2.7S... only
4 Pan retainer
5 Internal draft shield For models MCA2.7S...M only
6 Weighing pan
3.4 Connections and Components on the Backside of the Weighing Module
4
Fig. 4: Connections on the weighing module of the microbalance (example)
Pos. Designation Description
1 Cooling fins For models MCA2.7S... only
2 Electronics module connection For connecting the electronics module to the weighing module
3 Slot For attaching a “Kensington” anti-theft device
4 Connection clamp For connection of a potential equalization
1
2
3
12 Cubis® MCA Operating Instructions
Device Description
3.5 Connections on the Control Unit
1 32
Fig. 5: Connections on the control unit (example)
Pos. Designation Description
1 USB-C connection For USB mass storage
2 USB-A connection For USB accessories, e.g. printers, USB mass storage devices, barcode scanners
3 Ethernet connection For connecting an Ethernet cable
3.6 Connections and Components on the Electronics Module
1 2 3 4 5
Fig. 6: Connections on the electronics module (example)
Pos. Designation Description
1 On key Switches the device on from standby mode.
2 USB-A connection For USB accessories, e.g. printers, USB mass storage devices, barcode scanners
3 USB-B connection For connection to a PC
4 COM-RS232 connection 9-pin, for connection to a PC or PLC
5 Access switch Protects the device from changes to the device settings. Is sealed for conformity-
assessed devices.
6 Peripheral connection For connecting Sartorius accessories
7 Weighing module connection For connecting the electronics module to the weighing module
8 Power supply For connection to the power supply
6
7
8
Cubis® MCA Operating Instructions 13
Device Description
3.7 Displays on the Weighing Module
1
Fig. 7: Displays on the weighing module (example)
Pos. Designation Description
1 LED strip Used for lighting of weighing chamber. The intensity of the
lighting can be adjusted in the menu. When the control unit
displays an error message: The LED strip is illuminated in
orange.
3.8 Motorized Draft Shield
3.8.1 Sensor Area
The device has a motion sensor that opens the draft shield automatically as soon as
a motion is detected within the sensor area. Following that the draft shield will be
automatically closed again. The operation is optimized for left- and right-handed
users due to the motion sensor.
The motion sensor has a right and a left sensor window.
The motion sensor has two modes:
− Proximity sensor (one-hand operation)
− Crossover method (two-hand operation)
The motion sensor sensitivity can be adjusted in steps (see Chapter “Parameters in
the “Draft Shield” Submenu (Only for Devices with a Motorized Draft Shield)”,
page 46).
3.8.2 Operating Elements for the Draft Shield
The draft shield can be opened and closed via the palm-operated key. Operation via
the palm-operated key enables the opening and closing of the draft shield as well as
the activation and deactivation of the motion sensor.
14 Cubis® MCA Operating Instructions
3.9 Conformity-assessed Devices
Some settings of conformity-assessed models are protected against user changes,
e.g. “external calibration” for devices in accuracy class II. This measure is intended
to ensure the suitability of the devices for use in legal metrology.
Device Description
3.10 Symbols on the Device
1
Fig. 8: ID label on the device (example)
Pos. Designation Description
1 Manufacturer’s ID label Displays the metrological data of the device.
Conformity-assessed models only
Symbol Meaning
During operation, parts in the device may be live. Only
electricians may have access to and work on these parts,
such as for maintenance and repairs.
Cubis® MCA Operating Instructions 15
Operating Concept
4 Operating Concept
4.1 Operating Elements in the Main Menu
4
1
2
3
Fig. 1: Operating elements in the main menu (example)
Pos. Designation Description
1 Navigation and function bar − Enables navigation, searching, filtering, and sorting in menus and lists.
− In the “Settings” Menu: Displays the name of the menu.
2 Available tasks Displays all tasks available for the active user.
3 Function bar Displays available submenus and operating functions for the current display
and current user.
4 Task Starts the described task.
16 Cubis® MCA Operating Instructions
4.2 Operating Elements in Task Management
Operating Concept
1
2
Fig. 2: Operating elements in Task Management (example)
Pos. Designation Description
1 Navigation and function bar − Enables navigation and searching in menus and lists.
− Enables the addition of tasks.
− Opens the QAPP center.
− Displays the name of the menu.
2 Available tasks − Displays all available tasks.
− Opens a summary of the properties for the displayed task.
Cubis® MCA Operating Instructions 17
Operating Concept
4.3 Operating Elements in the Weighing Display
21 3 4 5
6
7
8
9
10
Fig. 3: Weighing display (example)
Pos. Designation Description
1 Application symbol Displays the symbol for the active application.
2 Task name Displays the name of the active task.
3 Date display Displays the current date.
4 User name Displays the name of the active user profile.
5 Time display Displays the current time.
6 Navigation bar Enables navigation in menus.
7 Metrological data
8 Labeled points Labels the differentiated points.
9 Weight value display In the selected unit and resolution
10 Weighing unit Displays the selected unit, e.g. grams, [g].
11 Bar graph Displays the measured value as a percentage of weighing capacity utilization.
12 Function bar Displays available operating functions for the current display.
11
12
18 Cubis® MCA Operating Instructions
4.4 Advanced Operator Guidance
Advanced applications have advanced operator guidance.
1 2
Operating Concept
Fig. 4: Advanced operator guidance (example)
Pos. Designation Description
1 Weighing display with
operator guidance
2 Advanced operator guidance Guides the user through the active task. Includes 2 or 3 convertible displays
depending on the selected application:
− First display: Shows the step currently being carried out as a graphic display.
− Second display: Shows the current parameters for the task.
− Third display, only for applications with statistics function: Represents statistical
information as a curve.
Cubis® MCA Operating Instructions 19
Operating Concept
4.5 Messages
4
Fig. 5: Error message (example)
Pos. Designation Description
1 Description Specifies the cause.
2 Remedy Specifies the measures necessary to eliminate the cause of the message.
3 Confirm Confirms and closes the message.
4 Message type Indicates that the message is a status message, warning message, or an
error message.
1
2
3
20 Cubis® MCA Operating Instructions
4.6 Status Center
1 2 3 2 3 4
Operating Concept
Fig. 6: Status Center (example)
Pos. Designation Description
1 Messages Displays information, warning, and error messages.
2 Leveling status Displays the status of the level.
3 Status for the device Displays the general device information.
4 Calibration and adjustment report Displays the data for the last and next adjustment and calibration.
Cubis® MCA Operating Instructions 21
Operating Concept
4.7 Keypad
The keypad is used for entering values in entry fields. If an entry field is activated: The alphanumeric keypad or numerical keypad
appears.
1
4 3
Fig. 7: Alphanumeric keypad and numerical keypad (example)
2
Pos. Designation Description
1 Entry field
2 Input assistance Indicates which values can be entered in the entry field, e.g. only numbers.
3 Numeric keypad
4 Alphanumeric keypad
4.8 Status Display of the Buttons
Pos. Symbol Designation Description
1
2
3
Predominant button Indicates that the function must be executed.
The button is color-highlighted.
Secondary button Indicates that the function can be executed.
The button is highlighted gray.
Inactive button Indicates that the function currently cannot be
executed. The button is grayed out.
22 Cubis® MCA Operating Instructions
Operating Concept
4.9 Buttons in the Operating Display
4.9.1 Buttons for Navigation or Organization in Displays
Pos. Symbol Designation Description
1
[Menu] button Quits the active task and opens the main menu.
2
3
4
5
6
7
8
9
[Back] button − Returns to the previous display.
− In the main menu: Accesses the last-performed task.
[Search] button Displays options for browsing tasks and list elements.
[Filter] button Displays options for filtering tasks and list elements.
[Sort] button Displays options for sorting tasks and list elements.
[Standby] button Switches the operating display to standby mode.
[Task Management] button Opens Task Management.
[Status Center] button Opens the Status Center.
[Setup] button Opens the “Settings” menu.
10
11
12
13
14
15
16
17
Service info
Device info
List
Leveling
[User Logout] button Logs the currently active user out and accesses the login display.
[User Login] button Accesses the login display.
[Next] button Accesses the next display, e.g. the next processing step for a wizard.
[Service Info] button Opens the “Settings” / “Device Settings” / “Device Information” /
“Service” menu.
[Device Info] button Opens the “Settings” / “Device Settings” / “Device Information” /
“General Device Information” menu.
[Status List] button Opens an overview of all current status messages, warning
messages, and error messages.
[Leveling] button Opens the Leveling Wizard.
[Warning] button Opens the list of current warning messages.
Cubis® MCA Operating Instructions 23
Operating Concept
Pos. Symbol Designation Description
18
[Error] button Opens the list of current error messages.
19
[Info] button − Opens a display with additional information using the current
menu.
− In the Status Center: Opens the list of current status messages.
20
21
22
23
24
[QAPP Center] button Opens the QAPP center.
[Profile Management] button Opens Profile Management.
[Details] button Shows additional information about an element.
[Display Image] button Displays available images or videos.
[Close Menu] button Closes the menu.
4.9.2 Buttons for Editing or Managing Entries
Pos. Symbol Designation Description
1
[New] button − In Task Management: Starts the wizard for creating a new task.
− In Profile Management: Starts the wizard for creating a new
weighing or print profile.
2
[Activate QAPP] button Opens the display for activating an application.
3
4
5
6
7
8
9
10
Licensing
[OK] button Saves a selection or entry.
[More] button Shows the keypad for entering a user-defined value.
[Select All] button Selects all elements of a list.
[Deselect All] button Deselects the selection for all elements of a list.
[Cancel] button − Cancels the current process without saving the changed
settings or values.
− In the display for editing the print memory: Marks the selected
value as invalid.
[Edit] button Accesses the Adjustment Wizard for editing the displayed element,
e.g. for setting the parameters for a task.
[Delete] button Deletes the selected element.
[License] button Opens the entry field for the license key for activating a QAPP
package or application.
24 Cubis® MCA Operating Instructions
Operating Concept
Pos. Symbol Designation Description
11
[Keypad] button Shows the keypad.
12
[Lock] button Opens the entry field to change the password for the active user.
4.9.3 Weighing and Print Function Buttons
Pos. Symbol Designation Description
1
2
3
4
5
6
7
isoCAL
Prc
Tare 1 0.00 g
[Leveling] button Opens the Leveling Wizard.
[isoCAL] button Starts the isoCAL function.
[Result] button Toggles between the result and weight value display for the current
application, e.g. weighing in percent.
[Zero] button Starts zeroing.
[Tare] button Starts taring.
[Tare 1] button Stores the current weight value in the tare 1 memory.
[Tare 1 Entry] button Opens an entry field for manually entering the tare 1 value.
8
9
10
11
[Delete Tare 1] button Deletes the tare 1 memory.
[Start] button Starts the selected application.
[Quit] button Quits the active application and opens the main menu.
[Confirm] button Confirms the current display and initializes the next step.
12 [Save] button Saves the weight value and sends it to the print memory.
13
14
[Print memory] button Opens the Print Memory display.
[Print] button − If the Print Memory is displayed: Exports the saved print orders
via the integrated data interfaces.
− If the weighing display is displayed and the prompt for the
sample ID is activated: Opens the entry field for the prompt for
the sample ID.
15
[Ionizer] button Starts an ionization process.
16
g
[Toggle between weight units]
button
− Toggles between the weight units and the resolution.
− Accesses the “Toggle between weight units” function menu.
Cubis® MCA Operating Instructions 25
Operating Concept
Pos. Symbol Designation Description
17
[Restart] button If an application is active: Deletes the saved values and restarts
the application.
18
19
[Report] button If an application is active, e.g. density determination: Displays a
report about the progress of the application.
[Result report] button If an application is active, e.g. density determination: Displays a
report about the result of the application.
4.10 Displays in the Operating Display
Pos. Symbol Designation Description
1
2
3
4
5
6
g
Gross
[Leveling] display Indicates that the device is not leveled.
[Print memory] display Indicates that the elements are located in the print memory.
[Unit symbol] display Indicates the set weight unit, e.g. [g] for “grams”.
[Result] display Indicates whether the weight value being displayed is a gross value
or the result of an application.
[Invalid weight value] display − Indicates that the display does not contain a weight value,
but is instead the calculated result of an application, e.g. for
the “Totalizing” application.
− For conformity-assessed devices: Indicates a fault. The cause
of this fault is displayed in the Status Center.
[Sign] display Indicates whether the value being displayed is positive or negative.
7
8
9
10
11
12
[Current page] display − Indicates that the current display is a multi-page display.
− Indicates which page of a multi-page display is being displayed
currently.
[Copy] button Indicates that data are being copied.
[Selection] display Indicates that an entry is selected in a list.
[Target value] display Displays the target value in the bar graph display.
[Factory mode] display Indicates that the device is being operated in the factory default
mode.
[Service mode] display Indicates that the device is being operated in the service mode.
26 Cubis® MCA Operating Instructions
Operating Concept
4.11 User Management
4.11.1 User Profiles
In the factory, 4 user profiles are created for the device. One role is assigned to each
user profile. Each role has rights to operate the device. The rights assigned to each
role depend on which device functions the user has to use.
User profiles can be adapted.
4.11.2 User Login
The user must log in to the login display with a user profile. Various setting options
and tasks are displayed in the operating display depending on the user profile and
role.
4.12 Profile Management
Weighing and print profiles can be created. These profiles can be assigned to a task.
4.13 Applications and Tasks
Device functions such as weighing or calibration and adjustment are carried out
using tasks. Applications must be assigned to a task.
A task is visible to all users who are approved for this task.
The device is supplied with some freely accessible applications that can be used to
carry out the most important functions.
Additional applications may be activated for a fee.
Cubis® MCA Operating Instructions 27
Operating Concept
4.14 Menu Structure
4.14.1 Main Menu
t Navigating in menus (see Chapter 4.15, page 32).
Level 1 Level 2 Level 3 Description
Task management (task menu)
QAPP center Display the available QAPP packages.
Status Center Display information on the device status,
Settings General device
information
User Management
Profile Management
Device Settings
Connections
Device Maintenance
Displays all available tasks.
Opens a summary of the properties for the
displayed task.
e.g. level status.
4.14.2 “Settings” Menu
Depending on the approved applications, the device may display additional menus.
t Navigating in menus (see Chapter 4.15, page 32).
Level 1 Level 2 Level 3 Description
Device
information
General device
information
Service Service contact Display the responsible contact at Sartorius
Manufacturer Display information about the device’s
manufacturer.
Model Display the device’s model ID.
Serial number Display the device’s serial number.
Version of device firmware
with check number
QAPP center version Display the version of the QAPP center.
IP address Display the IP address of the device.
MAC address Display the MAC address of the device.
Telephone number Display the telephone number for Sartorius
E-mail address Display the e-mail address for Sartorius Service.
Technical hotline Display the technical hotline for Sartorius Service.
Maintenance contact Display the responsible contact for maintenance
Next scheduled maintenance Display the date for the next scheduled
Maintenance cycle Display the maintenance cycle.
Display the version of the device firmware
with check number.
Service.
Service.
measures.
maintenance.
28 Cubis® MCA Operating Instructions
Operating Concept
Level 1 Level 2 Level 3 Description
Website Display the website for Sartorius Service.
Alibi memory Display, filter, or browse the contents of the
Alibi memory.
Weigh range Ranges 1–4 Display the values for maximum load, minimum
load, scale interval, and calibration step interval
for weigh ranges 1–4.
Diagnostics information Version of device firmware with
check number
Display the version of the device firmware with
check number.
QAPP center version Display the version of the QAPP center.
Restore mode version Display the restore mode version.
BAC balance processor version Display the version of the BAC processor.
APC application processor
Display the version of the APC processor.
version
MCU control processor version Display the version of the MCU processor.
WPC draft shield processor
Display the version of the WPC processor.
version
Software licenses The list of all open source software modules used.
User
4 standard user profiles Display or edit the standard user profiles.
Management
Profile
Management
Weighing List of available weighing
profiles
Report on
List of available print profiles Display all available print profiles. Edit, create or
USB Printer YDP30
Display all available weighing profiles. Edit,
create or delete the weighing profiles.
delete the print profiles.
Device Settings Date and time Date format Define the date display format.
New date Enter a date.
Time format Define the time display format.
New time Enter a new time.
NTP, Network Time Server Activate or deactivate time synchronization via
NTP.
IP address of the NTP server Enter the NTP server IP address.
Time zone Determine the time zone.
Leveling Automatic leveling (before
calibration / adjustment
Activate or deactivate automatic leveling before
each calibration / adjustment process.
function)
Leveling alert levels Set the alert level for the message indicating that
the device has not been leveled.
isoCAL isoCAL function Set the isoCAL function.
isoCAL alert levels Set the alert level for the message indicating that
the isoCAL function must be executed.
Device identifier ID1 – 2 Determine the device identifier.
Cubis® MCA Operating Instructions 29
Operating Concept
Level 1 Level 2 Level 3 Description
Draft shield Left/right key Set the function of the left and right palm-
operated keys. Only for devices with a motorized
draft shield
Sensor mode Set the operating mode for the sensor windows.
Only for devices with a motorized draft shield
Sensitivity range left sensor Define the sensitivity for the left sensor window
of the motion sensor. Only for devices with a
motorized draft shield
Sensitivity range right sensor Define the sensitivity for the right sensor window
of the motion sensor. Only for devices with a
motorized draft shield
Lighting brightness Activate or deactivate the LED strip. Only for
devices with a motorized draft shield
Opening angle, right key Configure how far the draft shield is opened by
pressing the right palm-operated key. Only for
devices with a motorized draft shield
Opening angle, left key Configure how far the draft shield is opened by
pressing the left palm-operated key. Only for
devices with a motorized draft shield
Self-diagnosis Software integrity Display the software status, e.g. the available
memory.
Internal sensors Settings for monitoring the device components,
e.g. the clock module battery.
Internal actuators Configure settings for device components, e.g.
the motor current for the calibration weight.
Environment Configure settings for monitoring the
environment, e.g. environmental movements.
Switch-on behavior Zero / tare at switch-on Activate or deactivate automatic zeroing and
taring when starting the device.
Automatic login, last user Activate or deactivate automatic log-in of the
last user when starting the device.
Automatic start, last task Activate or deactivate automatic start of the last
task when starting the device.
Properties display Display brightness Define the brightness of the operating display.
Switching the system on/off Activate or deactivate the “energy saving”
function.
Sound (loudspeaker) Sound for touch and keypad
operation
Sound for the end of execution
of an action
Activate or deactivate the acoustic signal when
operating a button.
Activate or deactivate the acoustic signal for the
end of an action.
Sound for messages Activate or deactivate the acoustic signal for
messages.
30 Cubis® MCA Operating Instructions
Operating Concept
Level 1 Level 2 Level 3 Description
Connections Website for the balance Website Determines the settings for the display of the
website for the device.
Remote control display Define the settings for controlling the device
remotely.
Interfaces Serial transmission via Ethernet Display the profiles for the Ethernet connection.
Edit, create or delete the profiles.
USB-B connection Display the profiles for the USB-B connection.
Edit, create or delete the profiles.
RS232 connection Display the profiles for the RS232 connection.
Edit, create or delete the profiles.
SBI protocol Format Configure the settings for the data output and
data output format.
Output Define whether the output takes place with or
without stability.
Automatic data output Activate or deactivate the output rate for
automatic data output.
PC direct protocol Output Define the output format for the data exchange
between the balance and the PC.
Decimal marker of readout Define the decimal separator character.
Connected devices Motion sensor Define the number and function of the gestures
and the sensitivity.
Only available if a motion sensor is connected to
the device.
External USB switch For keys 1–3 on the USB switch, determine which
functions are executed when the keys are pressed
and released.
Only available if an external USB switch is
connected to the device.
Device
maintenance
Update firmware Update the firmware. The menu is not available
for conformity-assessed devices.
Update QAPP center Update the QAPP center.
Export options Determine the settings for exporting data from
the device.
Import options Determine the settings for importing data to the
device.
Restore factory default
Reset the device to factory settings.
settings
Cubis® MCA Operating Instructions 31
Operating Concept
4.15 Navigating the Menus
Procedure
t To open a menu from the main menu: Tap on the desired menu button in the
function bar.
y The menu opens and the name of the open menu is displayed in the navigation
bar.
t To return to the main menu from other displays: Press the [Menu] button or
press the [Back] button (multiple times) until the main menu is displayed.
t To exit a display: Press the [Back] or [Cancel] button.
t To scroll through the tasks available in the main menu: Swipe the task list to the
left or right.
t To scroll through the list of options in an administration menu (settings, tasks,
applications, etc.): Swipe the list downwards or upwards.
t To display the next page in a display containing several pages, e.g. in the Status
Center: Swipe the display to the left.
t To display the previous page in a display with several pages: Swipe the display to
the right.
t If a value needs to be selected from a list:
t Scroll to the desired value in the display. In order to do so, swipe the display
upwards or downwards.
t Press the desired value.
t To confirm the selection: Press the [OK] button.
y The selected value is saved and the list closes.
32 Cubis® MCA Operating Instructions
Operating Concept
t If elements from a display need to be filtered or a display needs to be browsed:
t Press the [Search] or [Filter] button.
y The keypad is displayed.
1
t Type the searched value or value to be filtered into the entry field (1) using
the keypad.
t Press the [OK] button.
t To close the entry field for searching and filtering without starting a search or
filter operation: Enter no value in the entry field or delete the entered value.
t Press the [OK] button.
t If language-specific characters need to be entered using the keypad:
t Press and hold a letter on the keypad.
y If language-specific characters are available for the letter being pressed:
A display opens containing all the language-specific characters available for
the letter being pressed.
t To select a language-specific character and return to the keypad display:
Tap on the desired language-specific character.
Cubis® MCA Operating Instructions 33
Installation
5 Installation
5.1 Scope of Delivery
Item Quantity
Device 1
Weighing pan 1
Filter Ultramicrobalances and Microbalances: Filter weighing pan 1
For models MCA2.7S...: Internal draft shield 1
Shield plate 1
For models MCA2.7S...: Connector 1
AC adapter 1
For models with a motorized draft shield: Palm-operated key 2
Country-specific power supply cable with test seal 1
USB connection cable 1
In-use dust cover for display and control unit 1
In-use dust cover cover for the weighing module 1
Electronics module with power supply cable 1
Connection cable for electronics module 1
5.2 Selecting an Installation Site
Procedure
t Make sure that the following conditions are met at the installation site:
Condition Features
Ambient conditions Suitability tested (see Chapter “15.6 Ambient
Conditions”, page 73)
Setup surface Stable, even surface that is not exposed to
vibrations
Not directly against a wall
Sufficiently dimensioned for the device and the
peripheral devices (device space requirements see
Chapter “15.1 Dimensions and Weight”, page 71;
peripheral device space requirements see instructions for the peripheral devices, e.g. printer)
Sufficient load-bearing capacity for the device and
the peripheral devices even when full (device
weight see Chapter “15.1 Dimensions and Weight”,
page 71; weight of the peripheral devices see
instructions for the peripheral devices, e.g. printer)
Access Barrier-free
34 Cubis® MCA Operating Instructions
Installation
5.3 Unpacking the Device
Procedure
t Lift the device with the styrofoam padding out of the packaging.
t Place the device in the styrofoam padding on its side.
t Lift the styrofoam padding off the device.
t NOTICE Glass breakage due to incorrect handling of the device! Only lift the
device by its base.
t Place the device on its base.
t Keep all parts of the original packaging, e.g. to return the device.
5.4 Connecting the Ethernet Cable
Material: 1 Ethernet cable
1 soft support base
Tool: 1 Torx Allen key, T8
3 2 1
Procedure
t Turn over the electronics module with control unit and place on a soft surface.
t Remove the cover (3) of the Ethernet connection socket on the underside of the
display and control unit.
t Plug the Ethernet cable into the Ethernet connection socket.
t Place the Ethernet cable into the cable channel (1) and turn the cable lock (2)
using the network cable.
t Place the electronics module with control unit back on the device base on a level
surface.
5.5 Preparing Below-balance Weighing
The device can be configured for below-balance weighing. Samples can be
suspended for weighing using below-balance weighing, e.g. samples, which do not
fit on the weighing pan.
For below-balance weighing, the cover plate must be removed and the device set up
on a weighing table with recess.
In legal metrology:
− The below-balance weighing equipment may not be used.
− The cover of the below-balance weighing equipment may not be opened.
Material: 1 soft support base
1 draft protection shield
1 weighing table with recess
Tool: 1 Torx Allen key, T20
Cubis® MCA Operating Instructions 35
Installation
2
5.6 Procedure
t Turn the device on its side and place it on the soft support base.
t Unscrew both screws (2) from beneath the weighing module with the
Torx Allen key.
1
t Lift out the cover plate (1).
t Install a draft protection shield.
t Set up the device on the weighing table with recess. The hook for below-balance
weighing (3) may not touch the weighing table.
t Install the draft protection shield.
3
5.7 Installing a Microbalance with Glass Draft Shield
5.7.1 Positioning the Weighing Pan and Associated Components
Procedure
t For a device with a connector: Place the connector (2) on the base of the
weighing chamber.
t Place the shield plate (1) on the base of the weighing chamber.
1
2
36 Cubis® MCA Operating Instructions
Installation
t Place the weighing pan (1) through the opening in the base of the weighing
chamber into the pan retainer.
t To mount the weighing pan: Turn the weighing pan slightly while pressing down
lightly.
1
t For devices with an internal draft shield: Place the internal draft shield on a
shield plate.
t Center and insert glass draft shield with recess (1) above the snap-in peg (2).
1
2
5.8 Installing a Filter Balance with a Metal Ring Draft Shield
5.8.1 Positioning the Weighing Pan and Associated Components
Procedure
t For a device with a connector: Place the connector on the base of the weighing
chamber.
t Place the shield plate (2) on the base of the weighing chamber.
t Place the metal ring draft shield (1) on the base of the weighing chamber. The
1
2
inner metal ring of the draft shield must be inserted into the outer metal ring.
t Turn the opening of the metal ring draft shield in the direction of the arrows.
t To mount the metal ring draft shield: Turn the screw (2).
1
2
t Place the filter pan (1) or the weighing pan through the opening in the shield
plate into the pan retainer.
t NOTICE The filter pan or weighing pan can be damaged due to improper
assembly. To mount the inserted filter pan or weighing pan: Screw in the filter
pan or weighing pan with slight pressure to correctly position it in the pan
retainer.
Cubis® MCA Operating Instructions 37
Installation
1
t Insert the bearing pin (1) into the recess of the draft shield.
t Place the draft shield cover on the draft shield.
5.8.2 Optimizing a Filter Weighing Pan with a Metal Ring Draft Shield for Left-handed Users
Requirements
The metal ring draft shield has been mounted.
Procedure
t Lift the draft shield cover from the metal ring draft shield and turn.
t Pull out the bearing pin (1) from the underside of the draft shield cover and
1
insert into the opening on the opposite side.
t Place the draft shield cover on the metal ring draft shield.
t Loosen the screw (1) on the metal ring draft shield and turn all parts of the draft
shield in the direction of the arrows by 90°.
t Retighten the screw.
1
5.9 Connecting the Electronics Module
Procedure
t Connect the connection cable to the electronics module’s weighing module
connection.
t Connect the other end of the connection cable to the weighing module’s
electronics module connection.
t To lock the connection cable: Lock the plugs of the connection cable onto both
connections with two clicks in each case.
t NOTICE Damage to the device due to incorrect connection!
t Check the correct fit of the plug contacts.
t There should be no tension on the connection cable, e.g. do not install
directly against a wall.
38 Cubis® MCA Operating Instructions
Installation
5.10 Installing Palm-operable Keys (Only for Devices with Motorized Draft Shield)
For models with a motorized draft shield, 2 palm-operable keys can be installed.
Procedure
t Affix both palm-operable keys (1) onto the side of the display and control unit.
1
5.11 Acclimatizing
When a cold device is brought into a warmer area: The temperature difference can
lead to condensation of humidity in the device (moisture formation). Moisture in the
device can lead to malfunctions.
t Allow the device to acclimatize for approx. 2 hours at the installation site.
Ensure that the device is disconnected from the power supply during that time.
Cubis® MCA Operating Instructions 39
Getting Started
6 Getting Started
Procedure
t NOTICE Improper connection may damage the device! If the device is connected
using electronic components, e.g. printer, PC: The device must be disconnected
from the power supply. Ensure that the device is disconnected from the power
supply.
t Connect the device using electronic components (see electronic components
instructions).
6.1 Installing the AC Adapter
Procedure
t Plug the DC supply cable of the power supply unit into the electronics module’s
“power supply” connection socket and tighten the threaded fitting.
t Connect the power supply cable to the power supply unit connection.
6.2 Connecting the Power Supply
Procedure
t
WARNING Severe injuries caused by using a defective power supply cable!
Check the power supply cable for damage, e.g., cracks in the insulation.
t If required: Contact Sartorius Service.
t Check whether the country-specific power plug matches the power connections
at the installation site.
t If required: Contact Sartorius Service.
t NOTICE Damage to the device due to excessive input voltage! Check whether the
voltage specifications on the AC adapter match those of the power supply at the
installation site.
t If the input voltage is too high: Do not connect the device to the power
supply.
t Contact Sartorius Service.
t Connect the mains plug of the power supply cable to the wall outlet at the
installation site.
y The [Booting device...] display appears in the operating display.
y The [Starting system...] display appears in the operating display.
y The [Starting application...] display appears in the operating display.
y The [Loading] display appears in the operating display.
y The device performs an initial tare function.
40 Cubis® MCA Operating Instructions
System Settings
7 System Settings
7.1 Performing System Settings
Default settings can be adjusted for the device and the applications in order to align
with the ambient conditions and individual operating requirements.
The following settings are necessary to operate the device together with connected
components:
− Set up the communication of the connected devices
− Set up additional components
The following settings are recommended to set up the device:
− Set the menu language
− Select date / time format
− Set date / time
− Assign a Password
− Set the behavior of the isoCAL function
− Set the behavior of the motorized draft shield (only for devices with a motorized
draft shield)
Procedure
t Open the main menu.
t Press the [Setup] button.
t To adjust settings: Open the desired submenu.
t Select the desired configuration value (see Chapter “7.4 Parameter List”,
page 42).
t Exit the menu.
7.2 Switching Off the isoCAL Function
If the isoCAL function is switched off for a conformity-assessed device: The device
can only be used for legal-for-trade applications in restricted temperature ranges
(see Chapter “15.6.2 Ambient Temperature for the isoCAL Function”, page 73).
The isoCAL function cannot be switched off for all model versions.
Procedure
t In the “Settings / Device Settings / isoCAL” menu, for the “isoCAL function”
parameter, select the “Off” configuration value.
7.3 Assigning a Password
Procedure
t Log into the device using the user profile; a password should be assigned.
t Open the “Settings / User Configuration” Menu.
t Press the [Lock] button.
y The user password input field is displayed.
t Enter the desired password in the entry field and confirm with the [OK] button.
Cubis® MCA Operating Instructions 41
System Settings
7.4 Parameter List
7.4.1 Parameters in the “User Configuration” Menu
Parameters Configuration values Explanation
Name User input Assign a name for the user.
Description User input Enter a description for the user.
User color Define a user color for the user.
Language Set a language for the user.
Log-on method Determine whether the user password is saved locally on the device or
provided by an IDAP network server.
* Factory setting
7.4.2 Parameters in the “Profile Management” Menu
Parameters in the “Weighing” Submenu
Parameters Configuration values Explanation
Ambient conditions Very stable Sets the ambient conditions to “very stable”: Activates a fast change in the
weight values in the event of a load change with a high output rate.
Recommended for the following work environment:
− Very stable table near the wall
− Closed and calm room
Stable Sets the ambient conditions to “stable”.
Recommended for the following work environment:
− Stable table
− Slight movement in the room
− Slight draft
Unstable* Sets the ambient conditions to “unstable”: Activates the delayed change in
weight values with a reduced output rate.
Recommended for the following work environment:
− Simple office desk
− Room with moving machinery or personnel
− Slight air movement
Very unstable Sets the ambient conditions to “very unstable”: Activates a significantly
delayed change in the weight values and long wait for stability with a
further reduction in the output rate.
Recommended for the following work environment:
− Noticeable and slow floor vibrations
− Noticeable building vibrations
− Weighed goods moved
− Very strong air movements
* Factory setting
42 Cubis® MCA Operating Instructions
System Settings
Parameters Configuration values Explanation
Application filter Weighing (final readout)* Activates a filter that enables a fast change in the display for very fast load
changes.
Display changes with minimal load changes (in the digit range) occur more
slowly.
Dosing (initial weighing) Activates a filter that enables a very fast change in the display with
minimal load changes (e.g. when filling containers).
Sensor mode (low filtering) Activates a weak but fast filter that always behaves in the same way for
load changes (e.g. when filling automated systems).
Dynamic mode
Deactivates the active application filter.
(without filtering)
Stability Very high degree of
Sets the stability to “very high degree of accuracy”.
accuracy
High degree of accuracy Sets the stability to “high degree of accuracy”.
Average degree of accuracy* Sets the stability to “average degree of accuracy”.
Fast Sets the stability to “fast”.
Very fast Sets the stability to “very fast”.
Very slow Sets the stability to “very slow”.
Stability delay Very short Sets the stability delay to “very short”: The stability symbol is displayed
after the stability criterion is reached.
Short* Sets the stability delay to “short”: The stability symbol only appears after
a short delay in order to provide a reliable result despite fluctuations.
Medium Sets the stability delay to “medium”: The stability symbol only appears
after a longer delay in order to provide a reliable result in case of higher
fluctuations.
Long Sets the stability delay to “long”: The stability symbol only appears after
a long delay in order to balance out major instability.
Zeroing/taring Without stability Without stability: The function of the [Zero] or [Tare] key is executed
immediately once the key is pressed.
With stability* With stability: The function of the [Zero] or [Tare] key is only executed
after stability is achieved.
At stability At stability: The function of the [Zero] or [Tare] key is executed if stability
exists when the key is pressed.
Automatic zeroing On* Activates automatic zeroing. The display is automatically set to zero in case
of a deviation of 0 less than (X).
Off Deactivates automatic zeroing. Zeroing must be triggered with the
[Zero] key.
Tare preset 1 On* Activates the initial taring / zeroing. The device is tared or zeroed after it is
switched on.
Off Deactivates the initial taring / zeroing. After it is switched on, the device
shows the value before it was last switched off.
* Factory setting
Cubis® MCA Operating Instructions 43
System Settings
Parameters Configuration values Explanation
Available units The availability of units may depend on national legislation and is
therefore country-specific. Multiple selection is possible.
mg – milligrams* The device displays the weight in milligrams.
g – grams* The device displays the weight in grams.
kg – kilograms* The device displays the weight in kilograms.
ct – carats* The device displays the weight in carats.
lb – pounds The device displays the weight in pounds.
oz – ounces The device displays the weight in ounces.
ozt – troy ounces The device displays the weight in troy ounces.
tlh – Hong Kong taels The device displays the weight in taels (Hong Kong).
tls = Singapore taels The device displays the weight in taels (Singapore).
tlt – Taiwanese taels The device displays the weight in taels (Taiwan).
tlc = Chinese taels The device displays the weight in taels (China).
GN – grain The device displays the weight in grains.
dwt = pennyweight The device displays the weight in pennyweights.
mom – mommes The device displays the weight in mommes.
tol – tolas The device displays the weight in tolas.
bat – baht The device displays the weight in baht.
MS – mesghals The device displays the weight in mesghals.
N – newtons The device displays the weight in newtons.
Available resolutions Show all decimal places* “Show all decimal places”: All decimal places are shown in the display.
Not available on conformity-assessed devices.
Last decimal place after
load change
Last decimal place of the
1st division
“Reduced by 1 decimal place for load change”: The last decimal place
on the display is switched off until stability is achieved.
“Last decimal place of the 1st division”: The last decimal place always
shows the 1st division.
Last decimal place off “Last decimal place off”: The last decimal place is switched off.
Name User input Assign a name for the weighing profile e.g. “weighing.
Description User input Enter a description for the Profile (optional).
* Factory setting
Parameters in the “Report on USB Printer YDP30” Submenu
Parameters Configuration values Explanation
GLP printing Off* Deactivates the GLP printout.
On The GLP printout is always switched on. All printouts contain a GLP header
and a GLP footer.
Date/time Off* Exports the measured value without the date and time.
On Exports the measured value with the date and time.
Block pressure
Off* Exports the measured value without the gross, net, and tare value.
(N,T,GC)
On Exports the measured value with the gross, net, and tare value.
* Factory setting
44 Cubis® MCA Operating Instructions
System Settings
Parameters Configuration values Explanation
Character memory Off* Deactivates the ID marking for the Alibi memory.
On Activates the ID marking for the Alibi memory.
Name User input Assign a name for the report e.g. “YDP30”.
Description User input Enter a description for the report (optional).
* Factory setting
7.4.3 Parameters in the “Device Settings” Menu
Parameters in the “Date and Time” Submenu
Parameters Configuration values Explanation
Date format DD/MM/YYYY Sets the date display format to DD/MM/YYYY
MM/DD/YYYY Sets the date display format to MM/DD/YYYY
DD.MM.YYYY Sets the date display format to DD.MM.YYYY
YYYY-MM-DD (ISO)* Sets the date display format to YYYY-MM-DD (ISO)
New date User input Saves the entered date.
Time format HH.MM.SS Sets the time display format to HH.MM.SS
HH:MM:SS (ISO)* Sets the time display format to HH:MM:SS (ISO)
HH:MM:SS am/pm Sets the time display format to HH:MM:SS am/pm
New time User input Saves the entered time.
NTP NTP active Activates the time synchronization with the NTP server.
NTP not active* Deactivates the time synchronization with the NTP server.
IP address of the
User input Saves the entered server ID for the NTP server.
NTP server
Time zone List of available time zones Saves the selected time zone.
* Factory setting
Parameters in the “Leveling” Submenu
Parameters Configuration values Explanation
Automatic leveling Off Deactivates the trigger for automatic leveling: The leveling process must
be started manually.
On* Activates the trigger for automatic leveling: The device automatically
performs a leveling function using the integrated sensor before every
internal adjustment.
Leveling alert levels Low: For information only If the device must be leveled: The device displays a status message.
Medium: Warning message* If the device must be leveled: The device displays a warning message.
Some device functions are limited until the device is leveled: The displayed
weight value is marked as invalid; printed data are marked with [!].
High: Error message,
leveling mandatory
If the device must be leveled: The device displays an error message.
Some device functions are limited until the device is leveled: The displayed
weight value is marked as invalid; the starting of applications and saving
of values is disabled; data output is deactivated.
* Factory setting
Cubis® MCA Operating Instructions 45
System Settings
Parameters in the “isoCAL” Submenu
Parameters Configuration values Explanation
isoCAL function Off Deactivates the isoCAL function. This setting change is not available for all
models.
Info, manual execution If the device must be calibrated: The [isoCAL] button is displayed as the
predominant button in the operating display. The isoCAL function must be
manually triggered using the [isoCAL] button.
On, automatic execution* Activates the isoCAL function. The device is automatically adjusted as soon
as a trigger starts the isoCAL function.
On, automatic execution
with linearization
Activates the isoCAL and linearization function. The device is automatically
adjusted and then linearized as soon as a trigger starts the isoCAL function.
isoCAL alert levels Low: For information only If the isoCAL function must be carried out: The device displays a status
message.
Medium: Warning message* If the isoCAL function must be carried out: The device displays a warning
message. Some device functions are limited until the device is leveled:
The displayed weight value is marked as invalid; printed data are marked
with [!].
High: Error message,
adjustment mandatory
If the isoCAL function must be carried out: The device displays an error
message. Some device functions are limited until the device is leveled:
The displayed weight value is marked as invalid; the starting of functions
and saving of data in tasks is disabled; data output is deactivated.
* Factory setting
Parameters in the “Device ID” Submenu
Parameters Configuration values Explanation
ID 1 User input Saves the entered device ID.
ID 2 User input Saves the entered device ID.
* Factory setting
Parameters in the “Draft Shield” Submenu (Only for Devices with a Motorized Draft Shield)
Parameters Configuration values Explanation
Left/right key Off, no function Deactivates the function for both palm-operated keys.
Same function Assigns the same function to the palm-operated keys. The two palm-
operated keys cannot be assigned functions independently of each other.
Separate function* Assigns separate functions to the palm-operated keys. The two palm-
operated keys can be assigned functions independently of each other.
Sensor mode Proximity sensor
(one-hand operation)*
If a sensor window detects something approaching: Opens and closes
the draft shield automatically on the side on which the motion sensor
detected something approaching and locks the function of the second
sensor window.
Crossover method
(two-hand operation)
If a sensor window detects something approaching: Opens and closes the
draft shield automatically on the opposite side and locks the function of
the second sensor window.
* Factory setting
46 Cubis® MCA Operating Instructions
System Settings
Parameters Configuration values Explanation
Left sensor
sensitivity range
Off Deactivates the sensitivity settings for the motion sensor. The left sensor
field does not detect anything approaching.
Short Sets the motion sensor response threshold to a low value: The left sensor
field detects something approaching at a close distance.
Medium* Sets the motion sensor response threshold to a medium value: The left
sensor field detects something approaching at a medium distance.
Long Sets the motion sensor response threshold to a high value: The left sensor
field detects something approaching at a great distance.
Right sensor
sensitivity range
Off Deactivates the sensitivity settings for the motion sensor. The right sensor
field does not detect anything approaching.
Short Sets the motion sensor response threshold to a low value: The right sensor
field detects something approaching at a close distance.
Medium* Sets the motion sensor response threshold to a medium value: The right
sensor field detects something approaching at a medium distance.
Long Sets the motion sensor response threshold to a high value: The right sensor
field detects something approaching at a great distance.
Lighting brightness Off Deactivates the LED strip on the weighing module.
Dark Sets the lighting intensity of the LED strip to “dark”.
Medium* Sets the lighting intensity of the LED strip to “medium”.
Bright Sets the lighting intensity of the LED strip to “bright”.
Opening angle,
right key
Opening angle,
left key
User input, 0–360° Saves the entered value. Determines how far the draft shield is opened in
degrees when the right palm-operated key is pressed.
User input, 0–360° Saves the entered value. Determines how far the draft shield is opened in
degrees when the left palm-operated key is pressed.
* Factory setting
Parameters in the “Device Monitoring” Submenu
Parameters Configuration values Explanation
Clock module battery Off Deactivates the monitoring for the clock module battery.
On Activates the monitoring for the clock module battery.
Temperature
Off Deactivates the monitoring for the temperature compensation status.
compensation status
On Activates the monitoring for the temperature compensation status.
Leveling motor
Off Deactivates the monitoring of the motor current for the leveling process.
current
On Activates the monitoring of the motor current for the leveling process.
Calibration weight
motor current
Off Deactivates the monitoring of the motor current for positioning the
internal calibration weight.
On Activates the monitoring of the motor current for positioning the internal
calibration weight.
Draft shield motor
current
Off Deactivates the monitoring of the motor current for the motorized draft
shield. Only for devices with a motorized draft shield
On Activates the monitoring of the motor current for the motorized draft
shield. Only for devices with a motorized draft shield
* Factory setting
Cubis® MCA Operating Instructions 47
System Settings
Parameters Configuration values Explanation
Available memory,
warning limit
Available memory,
critical limit
User input Saves the entered value. If the available storage space is less than the
entered value: The device displays a warning message.
User input Saves the entered value. If the available storage space is less than the
entered value: The device displays an error message.
* Factory setting
Parameters in the “Startup Behavior” Submenu
Parameters Configuration values Explanation
Zero/tare at switch-on Off Deactivates automatic zeroing and taring when starting the device.
On* Activates automatic zeroing and taring when starting the device.
Automatic login,
Off* Deactivates automatic log-in of the last user when starting the device.
last user
On Activates automatic log-in of the last user when starting the device.
Automatic start,
Off* Deactivates automatic start of the last task when starting the device.
last task – zero / tare
at switch-on
On Activates automatic start of the last task when starting the device.
* Factory setting
Parameters in the “Display Settings” Submenu
Parameters Configuration values Explanation
Display brightness Bright Sets the lighting intensity on the operating display to “bright”.
Medium* Sets the lighting intensity on the operating display to “medium”.
Eco mode Activates eco mode. For longer periods of downtime, the operating display
darkens automatically.
Switching the system
on/off
Energy saving, short
switch-on time*
Maximum energy saving,
long switch-on time
Sets idle mode: The [Standby] button switches the device into idle mode.
The device can be reactivated by pressing the [Standby] button.
Sets standby mode: The [Standby] button switches the device into standby
mode. The device must be reactivated by pressing the ON key.
Color scheme Sartorius Standard* Selects the color scheme for the “Sartorius Standard” operating display.
* Factory setting
48 Cubis® MCA Operating Instructions
System Settings
Parameters in the “Sound (Loudspeaker)” Submenu
Parameters Configuration values Explanation
Sound for touch and
Off* Deactivates the acoustic signal for touch and keypad operation.
keypad operation
On Activates the acoustic signal for touch and keypad operation.
Sound for the end of
Off* Deactivates the acoustic signal for the completion of an action.
execution of an action
On Activates the acoustic signal for the completion of an action.
Sound for messages Off Deactivates the acoustic signal for messages.
On* Activates the acoustic signal for messages.
* Factory setting
7.4.4 Parameters in the “Connections” Menu
Parameters in the “Website for the Balance” Submenu
Parameters Configuration values Explanation
Website Off Deactivates the display of the Sartorius Service website.
On, without authentication* Sets the display options of the Sartorius Service website to “without
authentication”.
On, with authentication Sets the display options of the website for the device to “with
authentication”.
Remote control
Display only* Permits remote access in view mode via a browser.
and display
Display and remote
Permits remote access via a browser.
operation
* Factory setting
Parameters in the “Serial Transmission via Ethernet” Submenu
Parameters Configuration values Explanation
Protocol Off* Deactivates the serial transmission via Ethernet.
SBI Enables SBI communication. The data is output to a PC or control unit.
Enables the use of ESC commands from a PC to control the basic balance
functions with ASCII protocol.
xBPI Extended range of commands to control numerous balance functions
with binary protocol for direct communication with the weighing module.
Port number User input Saves the entered port number for the Ethernet interface.
Log data Off* Deactivates the automatic data recording for this interface.
On Activates the automatic data recording for this interface.
* Factory setting
Cubis® MCA Operating Instructions 49
System Settings
Parameters in the “USB-B connection” Submenu
Parameters Configuration values Explanation
Protocol Off* Deactivates the USB-B connection.
SBI Enables SBI communication. The data is output to a PC or control unit.
Enables the use of ESC commands from a PC to control the basic balance
functions with ASCII protocol.
PC direct Enables data output to a spreadsheet program via a direct PC connection.
xBPI Extended range of commands to control numerous balance functions with
binary protocol for direct communication with the weighing module.
Log data Off* Deactivates the automatic data recording for this interface.
On Activates the automatic data recording for this interface.
* Factory setting
Parameters in the “RS232 Connection” Submenu
Parameters Configuration values Explanation
Protocol Off* Deactivates the RS232 connection.
SBI Enables SBI communication. The data is output to a PC or control unit.
Enables the use of ESC commands from a PC to control the basic balance
functions with ASCII protocol.
xBPI Extended range of commands to control numerous balance functions with
binary protocol for direct communication with the weighing module.
Log data Off* Deactivates the automatic data recording for this interface.
On Activates the automatic data recording for this interface.
Baud rate 600 baud Sets the baud rate to 600 baud.
1200 baud Sets the baud rate to 1200 baud.
2400 baud Sets the baud rate to 2400 baud.
4800 baud Sets the baud rate to 4800 baud.
9600 baud* Sets the baud rate to 9600 baud.
19200 baud Sets the baud rate to 19200 baud.
38400 baud Sets the baud rate to 38400 baud.
57600 baud Sets the baud rate to 57600 baud.
115200 baud Sets the baud rate to 115200 baud.
Data bits 7 data bits Sets the number of data bits to 7.
8 data bits* Sets the number of data bits to 8.
Parity Odd* Applies an odd parity.
Even Applies an even parity.
None Does not apply a parity.
Stop bits 1 stop bit* Sets the number of stop bits to 1.
2 stop bit Sets the number of stop bits to 2.
Handshake Software Sets the handshake protocol to software handshake.
Hardware* Sets the handshake protocol to hardware handshake.
None Does not set a handshake protocol.
Log data Off* Deactivates the automatic data recording for this interface.
On Activates the automatic data recording for this interface.
* Factory setting
50 Cubis® MCA Operating Instructions
System Settings
Parameters in the “SBI Protocol” Submenu
Parameters Configuration values Explanation
Format Readout without identifier The data output only exports the measured value without ID.
Readout with identifier* The data output exports the measured value with ID codes.
Date/time and readout The data output exports the measured value, date, and time.
Readout with weighing
block (N, T, GC)
The data output exports the measured value with the net, tare, and
calculated gross value.
Output without stability* The data is output without the weight value being stable.
with stability The data is output only when the weight value is stable.
Automatic data
output
Off, triggered by means of
SBI commands (ESC P)*
Each weight value
Deactivates the automatic data output. The data output must be triggered
by means of an SBI command.
Starts the automatic data output with each value.
(according to display result)
1 second Starts the automatic data output after every second.
2 seconds Starts the automatic data output every 2 seconds.
5 seconds Starts the automatic data output every 5 seconds.
10 seconds Starts the automatic data output every 10 seconds.
30 seconds Starts the automatic data output every 30 seconds.
60 seconds Starts the automatic data output every 60 seconds.
* Factory setting
Parameters in the “PC Direct Protocol” Submenu
Parameters Configuration values Explanation
Output (TABseparated),
Text (identifier, value,
and unit)
The data output exports the measured value with identifier and unit
directly into a spreadsheet program.
multiple selection
Title (in regional language) The data output exports the title in the regional language directly into
a spreadsheet program.
Identifier* The data output exports the identification codes (IDs) directly into
a spreadsheet program.
Readout* The data output exports the readout directly into a spreadsheet program.
Unit* The data output exports the displayed unit directly into a spreadsheet
program
Decimal marker
Decimal point* Sets a point as a decimal separator for the data output.
of readout
Decimal comma Sets a comma as a decimal separator for the data output.
* Factory setting
Cubis® MCA Operating Instructions 51
System Settings
Parameters in the “Motion Sensor” Submenu (Only Where a Motion Sensor is Connected)
Parameters Configuration values Explanation
Number of gestures 2 gestures (left, right)* Activates the control of functions with 2 gestures. Gestures: left, right
4 gestures (left, right, up,
down)
Activates the control of functions with 4 gestures. Gestures: left, right, up,
down
Sensor sensitivity Weak Sets the gesture control response threshold to a low value: Gestures are
recognized at a close distance.
Normal* Sets the gesture control response threshold to a medium value: Gestures
are recognized at a medium distance.
High Sets the gesture control response threshold to a high value: Gestures are
recognized at a great distance.
Gesture to the left
Execute / cancel taring The gesture starts a taring process or cancels a taring process.
Gesture to the right
Execute / cancel zeroing The gesture starts the zeroing process or cancels the zeroing process.
Execute / cancel printing The gesture starts a printing process or cancels a printing process.
Press left draft shield key The gesture executes the left palm-operated key function.
Only for device with motorized draft shield
Press right draft shield key The gesture executes the right palm-operated key function.
Only for device with motorized draft shield
Close all doors The gesture closes the entire draft shield.
Only for device with motorized draft shield
Gesture upwards
Gesture downwards
Execute / cancel taring The gesture starts a taring process or cancels a taring process.
Only available if the number of gestures is set to 4 gestures.
Execute / cancel zeroing The gesture sets the device to zero or cancels the zeroing process.
Only available if the number of gestures is set to 4 gestures.
Execute / cancel printing The gesture starts a printing process or cancels a printing process.
Only available if the number of gestures is set to 4 gestures.
Press left draft shield key The gesture executes the left palm-operated key function.
Only for device with motorized draft shield; only available if the number
of gestures is set to 4 gestures.
Press right draft shield key The gesture executes the right palm-operated key function.
Only for device with motorized draft shield; only available if the number
of gestures is set to 4 gestures.
Close all doors The gesture closes the entire draft shield.
Only for device with motorized draft shield; only available if the number
of gestures is set to 4 gestures.
* Factory setting
52 Cubis® MCA Operating Instructions
System Settings
Parameters in the “External USB Switch” Submenu (Only Where an External USB Switch is Connected)
Parameters Configuration values Explanation
Key 1 pressed
Execute / cancel taring The key starts a taring process or cancels a taring process.
Key 1 released
Key 2 pressed
Key 2 released
Key 3 pressed
Key 3 released
Execute / cancel zeroing The key sets the device to zero or cancels the zeroing process.
Execute / cancel printing The key starts a printing process or cancels a printing process.
Press left draft shield key The key executes the left palm-operated key function.
Only for device with motorized draft shield
Press right draft shield key The key executes the right palm-operated key function.
Only for device with motorized draft shield
Close all doors The key closes the entire draft shield.
Only for device with motorized draft shield
* Factory setting
7.4.5 Parameters in the “Device Maintenance” Menu
Parameters Configuration values Explanation
Update firmware Starts a firmware update.
Not for conformity-assessed devices.
Update QAPP center Updates the QAPP center.
Export options,
User profiles Selects the user profiles for export and displays the export options.
multiple selection
Task profiles Selects the task profiles for export and displays the export options.
Audit Trail Selects the audit trail for export and displays the export options.
Alibi memory Selects the Alibi memory for export and displays the export options.
Log file(s) Selects the log files for export and displays the export options.
Import options,
User profiles Displays the import options for user profiles.
multiple selection
Task profiles Displays the import options for task profiles.
Restore factory
Resets the device to factory settings.
default settings
Cubis® MCA Operating Instructions 53
Operation
8 Operation
8.1 Switching the Device On and Off
The device only delivers accurate values if it has reached the necessary operating
temperature. The warm-up time after switching the device on must therefore be
complied with.
If the device is being switched on for the first time or if the device is switched on
after being reset to factory settings: The Setup Wizard opens. All steps in the Setup
Wizard must be completed.
Requirements
The device is connected to the power supply.
Procedure
t If the device does not switch on automatically after it is connected to the power
supply: Press the ON key on the electronics module.
t NOTICE Pointed or sharp-edged objects may damage the operating display!
Touching the operating display with objects, such as pens, may damage the
touchscreen surface of the operating display. Only touch the operating display
with your fingertips.
t If the Setup Wizard is shown: Follow the instructions in the Setup Wizard in the
operating display.
t If the login display is displayed: Log into the device using a user profile.
y If the device is switched on after the Setup Wizard is complete and no passwords
have been assigned for the user profiles: The user profile for the last user to be
logged in is loaded.
t To allow the device to reach the necessary operating temperature to accurately
determine the weight: Comply with the warm-up time of 30 minutes after
switching the device on.
y If this relates to a conformity-assessed device: The weight value is marked as
invalid during the warm-up period.
t NOTICE Damage to the device when disconnecting the device from the weighing
module or electronics module! The device must not be disconnected from the
weighing module or electronics module during operation.
t To switch the device off: Disconnect the device from the power supply.
1
54 Cubis® MCA Operating Instructions
8.2 Logging Users In and Out
Procedure
t If the name of the desired user profile is displayed in the entry field (1) of the
login display: Press the [Login] button.
t If the name of the desired user profile is not displayed in the entry field of the
login display:
t Tap on the entry field in the login display.
y The user selection opens.
t Press the name of the desired user profile.
t If a password has been assigned for the desired user: Enter the password in
the entry field and press the [OK] button.
y The user profile opens and the main menu or the last task being performed
by the active user is displayed.
t To log out the active user profile from the device: Press the [Log-out] button.
Operation
8.3 Leveling the Device
8.3.1 Leveling the Device
Leveling compensates any inclines at the device’s installation site. If leveling is
necessary: The [Leveling] button appears in the weighing display and a message
appears in the Status Center.
Procedure
t If the weighing display is displayed: Press the [Leveling] button.
t When the Status Center is displayed: Press the [Level] button.
y The Leveling Wizard opens.
t Follow the wizard’s instructions.
8.4 Opening and Closing the Motorized Draft Shield (Only for Devices with a Motorized Draft Shield)
Pressing the palm-operated key or using gestures enables the motorized draft shield
to be opened and closed.
Procedure
t Press a palm-operated key or move your hand to the side of the draft shield.
y The draft shield is opened or closed.
Cubis® MCA Operating Instructions 55
Operation
8.4.1 Defining the Opening Width
It can be determined how far the draft shield should open when pressing the
palm-operated key. The opening width of the draft shield can be determined
separately for each palm-operated key.
Procedure
Same function
(one opening angle)
Defining the
opening width
Pressing the
palm-operated
keys
y The next time a palm-operated key is pressed: The draft shield is opened or closed
until it reaches the required position.
Select the required
opening position manually
1) Open in line with
the opening position
set previously
2) Close
Separate Function
(2 opening angles)
–
1) Left palm-operated key:
Opens 260° clockwise
Right palm-operated key:
Opens 100° counterclockwise
2) Close
8.5 Activating Applications and Adding a Task
8.5.1 Activating Applications
All applications from the QAPP package “Essentials” are activated for the device at
the factory. Additional applications may be activated in the QAPP center.
Procedure
t Open Task Management.
t Press the [QAPP center] button.
y An overview of all available QAPP packages is displayed.
t Select the desired software application package e.g. pharmaceuticals.
t To scroll through the contents of a displayed QAPP package: Swipe the contents
of the QAPP package upwards or downwards.
56 Cubis® MCA Operating Instructions
t Select the desired QAPP package.
y A list of all the applications contained in the QAPP package is displayed.
t If the selected QAPP package is to be approved with all the applications it
contains or all QAPP packages are to be approved:
t Press the [License] button.
y The input field for the license key appears.
t If an additional cost is associated with the QAPP package: Enter the
license key in the entry field and press the [OK] button.
t If no additional cost is associated with the QAPP package: Press the
[OK] button.
Operation
t If an individual application from the displayed QAPP package is to be activated:
t Press the desired application.
y A display opens containing details about the selected application.
t Press the [License] button.
y The input field for the license key appears.
t If an additional cost is associated with the application: Enter the license key
in the entry field and press the [OK] button.
t If no additional cost is associated with the application: Press the [OK] button.
8.5.2 Adding an Application to a Task
Applications must be added to a task so that they can run.
Procedure
t Open Task Management.
t Press the [New] button.
y A list of all activated applications is displayed.
t To select an application: Press the desired application.
y The wizard for creating a new task starts.
t Follow the wizard’s instructions in the operating display.
8.6 Adding Print and Weighing Profiles to a Task
To be able to use a print or weighing profile: Add a print or weighing profile to
a task.
Procedure
t Open Task Management.
t Create or edit a task. In order to do so, start the wizard to create or edit a task
and follow the wizard’s instructions in the operating display.
8.7 Preparing Weighings
The device must be prepared before every weighing.
Procedure
t Level the device.
t Zero the device. In order to do so, press the [Zero] button.
t If the device cannot be zeroed: Remove the sample to be weighed and re-zero
the device.
t Calibrate the device.
Cubis® MCA Operating Instructions 57
Operation
8.8 Weighing
NOTICE
Chemicals may damage the device or accessories!
Chemicals can attack the device or the connected accessories internally and
externally. This may damage the device and accessories.
t Use appropriate containers when weighing chemicals.
Procedure
t Start a task with weighing function.
t Zero the device. In order to do so, press the [Zero] button.
t If below-balance weighing is being carried out: Suspend the sample on the hook
for below-balance weighing, e.g. with a wire.
t If a container is being used for the sample:
t Place the container on the weighing pan.
t Tare the device. In order to do so, press the [Tare] button.
t Place the sample in the container or fill the container.
t If no container is used for the sample and no below-balance weighing is being
carried out: Place the sample on the weighing pan.
t Once the weight value is displayed in black and the weighing unit is displayed:
Read off the measured value.
8.9 Overview of Calibration, Adjustment, and Linearization
During calibration, a calibration weight is used to determine how much the displayed
value deviates from the actual value. This deviation is compared with a preset target
value. The subsequent adjustment eliminates this deviation. During linearization, the
deviation of the values from the ideal characteristic curve is corrected.
Calibration and adjustment must be performed regularly:
− Daily, every time the device is switched on
− After every leveling
− After changing the ambient conditions (temperature, humidity, or air pressure)
− After setting the device up at a new installation site
Calibration and adjustment may be performed in different ways:
− Adjusting with the isoCAL Function
− Internal or external calibration or adjustment
Only internal adjustment/calibration is possible for all conformity-assessed devices in
legal metrology.
58 Cubis® MCA Operating Instructions
Operation
8.10 Adjusting with the isoCAL Function
The device can be automatically internally calibrated and adjusted using the isoCAL
function.
Requirements
− The device is not located in the menu.
− Alphanumeric inputs are not active.
− The load on the weighing pan remains unchanged for 2 minutes.
− The load on the weighing pan amounts to no more than 2 % of the maximum
load.
− The device does not register an input for 2 minutes.
If all requirements for starting the isoCAL function are met and one of the following
conditions occurs: The isoCAL function is automatically triggered.
Possible conditions are:
− The ambient temperature has changed since the last adjustment.
− The interval time was exceeded (interval time, see Chapter “15.9 isoCAL
Function”, page 75).
− The device has been leveled.
− The device has been disconnected from the power supply since the last
adjustment (only for conformity-assessed models).
Procedure
t If the isoCAL automatic start function is set and the [isoCAL] button is displayed
as the predominant button in the operating display:
t Wait until the isoCAL function starts automatically.
y In the operating display, a time display counts down to 0.
y If no load change or no operation takes place on the device before the
expiration of the time display: The isoCAL function starts.
t If the isoCAL manual start function is set and the [isoCAL] button is displayed as
the predominant button in the operating display:
t Press the [isoCAL] button.
t If information is displayed stating that the weighing pan is loaded: Unload
the weighing pan.
y The isoCAL function starts.
y If the isoCAL function is complete: The device confirms the completion of the
calibration/adjustment process with an acoustic signal, and the calibration report
is displayed.
t To close the calibration report and return to the previous display: Press the [OK]
button.
Cubis® MCA Operating Instructions 59
Operation
8.11 Internally Calibrating and Adjusting the Device
Requirements
The weighing pan is unloaded.
Procedure
t Open the main menu.
t Press the “Balance Adjustment” task.
y The internal calibration / adjustment function is executed.
y If automatic leveling is set for a model with motorized adjusting feet: The device
levels itself automatically.
y If the calibration / adjustment function is complete: The device confirms the
completion of the calibration / adjustment process with an acoustic signal, and
the calibration report is displayed.
t To close the calibration report and return to the main menu: Press the [OK]
button.
8.12 Weighing and Printing with ID Marking
8.12.1 Saving Values for Printouts
Every lot and every sample can be assigned an ID number. The ID numbers are saved
in the print memory and exported during the printing process.
Requirements
The prompt for the lot IDs and sample IDs is activated for the “Standard weighing”
task.
Procedure
t Open the main menu.
t Start the “standard weighing” task: In order to do so, tap on the task.
y The input field for the lot ID is displayed.
t If a barcode scanner is connected to the device: Enter the lot ID in the entry field
or scan using the barcode scanner.
t If no barcode scanner is connected to the device: Type the lot ID into the entry
field.
t Press the [OK] button.
y The weighing display is displayed.
t Zero the device. In order to do so, press the [Zero] button.
t Place the sample on the weighing pan.
t Press the [Print] button.
y The input field for the sample ID is displayed.
t Type the sample ID into the entry field.
t Press the [OK] button.
y The [Print memory] button appears in the operating display.
y The weight value and entered IDs are saved.
t If additional values are to be saved:
t Remove the sample being weighed.
t Place the next sample on the weighing pan and press the [Confirm] button.
t Type the sample ID into the entry field.
t Press the [OK] button.
60 Cubis® MCA Operating Instructions
Operation
8.12.2 Marking Saved Values as Invalid
Procedure
t Press the [Print Memory] button.
y The print memory opens and a list of all saved values is displayed.
t Press the [Edit] button.
t Press the desired items.
y An overview of all data to be printed is displayed for the selected items.
t Press the [Cancel] button.
t If a reason for the invalidity of the value needs to be displayed on the printout:
Enter a reason in the entry field and press the [OK] button.
t If no reason for the invalidity of the value needs to be displayed on the printout:
Press the [OK] button.
8.12.3 Marking Saved Values as Valid
Procedure
t Press the [Print Memory] button.
y The print memory opens and a list of all saved values is displayed.
t Press the [Edit] button.
t Press the items which are desired to be marked as invalid.
y An overview of all data to be printed is displayed for the selected items.
t Press the [Cancel] button.
8.12.4 Printing Saved Values
Procedure
t Press the [Print Memory] button.
y The print memory opens and a list of all saved values is displayed.
t To start the print process using the print profile embedded in the current task:
Press the [Print] button.
y A PDF file is produced and sent to the printer defined in the print profile.
8.12.5 Exiting the Task
Procedure
t Press the [Exit] or [Menu] button.
y If additional values are to be saved in the print memory:
y A dialog for prematurely ending the task appears.
t To return to the weighing display and print the saved values: Tap on the [Yes]
button and print the saved values.
t To exit the task and delete the saved values from the print memory: Press the
[No] button.
y The task ends and the main menu is displayed.
Cubis® MCA Operating Instructions 61
Operation
8.13 Viewing the Alibi Memory
The Alibi memory stores weight values with date, time, and process number.
The content of the Alibi memory can be searched and sorted using a filter.
The Alibi memory has a ring buffer. This means that the oldest data records can
be overwritten by new ones. The Alibi memory is designed for a specific number
of data records (for the number of data records see Chapter “15.10 Alibi Memory”,
page 75).
The user alone is responsible for making sure that there is sufficient storage capacity
and the saved weighed values are present.
The Alibi memory is verifiable. The proper functioning of the Alibi memory must be
ensured for verification by saving and checking some values.
Procedure
t Open the “Settings / Device Settings / Device Information” menu.
t Press the “View Alibi memory” menu option.
y A list of all the values saved in the Alibi memory is displayed.
t If only the values for a desired date need to be displayed:
t Press the [Filter] button.
t Type the desired date into the entry field.
t To filter the list with the date entered: Press the [OK] button.
t If the list needs to be searched for a particular ID:
t Press the [Search] button.
t Type the desired ID into the entry field.
t To start the search with the entered ID: Press the [OK] button.
8.14 Running Applications (Examples)
8.14.1 Executing the “Toggle Between Weight Units” Function
The “Toggle between weight units” function enables the user to switch between the
different units and resolutions defined in the weighing profile of the active task.
The units and resolutions can be set at the beginning of the weighing process.
Procedure
t Start the desired task.
t Press the [Toggle between weight units] button.
y All units defined in the weighing profile for the active task are displayed in a list.
y All resolutions for the weight value defined in the weighing profile for the active
task are displayed in a list.
t Press the desired unit.
t To set the resolution for the selected unit: Press the desired resolution.
t To confirm the selection and return to the weighing display: Press the [OK]
button.
y The current weight value is displayed in the selected unit and resolution.
62 Cubis® MCA Operating Instructions
Operation
8.14.2 Running the “Statistics” Application
The “Statistics” application saves up to 100 weight values and evaluates these
statistically.
The following values are saved and exported by the statistics application:
− Number of components
− Mean value
− Standard deviation
− Variation coefficient
− Sum of all values
− Lowest value (minimum)
− Highest value (maximum)
− Spread: Difference between maximum and minimum
The “Statistics” application can be combined with the following functions:
− Toggle between weight units, only available in the weighing display,
before saving the initial weight value
− ID marking
− Automatic taring
Procedure
t Open the main menu.
t Start the task for the “Statistics” application.
t Zero the device.
t Place the sample on the weighing pan.
t To start the recording of the statistics: Press the [Confirm] button on the keypad.
y The current weight value is saved and the device is automatically tared.
t To save the next value: Place a new sample on the weighing pan and press the
[Confirm] button.
t To display an overview of the saved data: Press the [Report] button.
t To print the current statistics: Press the [Print] button.
t To exit the current statistics, and to delete the saved values: Press the [Exit]
button.
Cubis® MCA Operating Instructions 63
Cleaning and Maintenance
9 Cleaning and Maintenance
9.1 Preparing the Device
Procedure
t Turn the device off.
t Disconnect the device from the power supply.
t Open the draft shield.
9.2 Cleaning the Device
NOTICE
Corrosion or damage to the device due to unsuitable cleaning agents!
t Do not use corrosive, chloride-containing, or aggressive cleaning agents.
t Do not use cleaning agents that contain abrasive ingredients, e.g. scouring
agents, steel wool.
t Do not use solvent-based cleaning agents.
t Check whether the cleaning agents used are compliant materials (see
Chapter “15.3 Materials”, page 72).
t Make sure that cleaning materials, such as cloths, are only slightly damp.
Procedure
t NOTICE Damage to the device due to an unsuitable tool! The weighing system
is hermetically separated from the area of the draft shield plate. This area must
not be cleaned. This prevents dirt from entering.
t NOTICE Malfunction or damage to the device due to the ingress of moisture or
dust!
t Remove dust and powdery sample residue with a brush or hand-held vacuum
cleaner.
t Use blotting paper to remove any liquid sample material.
t NOTICE Corrosion or damage to the weighing pan due to unsuitable cleaning
agents!
t Wipe down the weighing pan and shield plate frame with a cleaning agent
and a cloth. The cleaning agent must be suitable for stainless steel and
titanium.
64 Cubis® MCA Operating Instructions
Cleaning and Maintenance
t Wipe the associated components of the weighing pan with a brush or a damp
cleaning cloth, e.g. shield plate, internal draft shield.
t Wipe the device housing with a damp cloth. For more severe contamination,
use a mild soap solution.
Tip
We recommend cleaning the weighing pan on a regular basis, e.g. weekly. Do not
allow deposits to form on the weighing pan.
9.3 Assembling and Connecting the Device
Procedure
t Re-insert all components into the device (to insert components for microbalance
with glass draft shield, see Chapter 5.7.1, page 36. To insert components for
filter weighing pan with metal ring draft shield, see Chapter 5.8.1, page 37).
t Re-connect the device to the power supply (see Chapter 6.2, page 40).
9.4 Maintenance Schedule
Interval Component Action Chapter, page
Monthly to every 2 years,
depending on the operating conditions
Device Contact Sartorius Service 17, 78
9.5 Performing a Software Update
A software update can be installed from a USB mass storage device using the
device’s USB-A connection.
Requirements
− The device is switched on.
− The software update is saved on a USB mass storage device.
Procedure
t Download the software update from the Sartorius website onto the USB mass
storage device.
t If this relates to a zip file: Unzip the software update on the stick.
t Insert the USB mass storage device with the software update into one of the
device’s USB-A connection sockets.
t Select the “Update Firmware” menu entry in the “Settings / Device Maintenance”
menu.
y The software update takes approx. 3 minutes.
y Once the software update is complete: The software version number is updated in
the login display.
Cubis® MCA Operating Instructions 65
Cleaning and Maintenance
9.6 Performing a QAPP Center Update
The QAPP center update can be installed from a USB mass storage device using the
device’s USB-A connection.
Requirements
− The device is switched on.
− The QAPP center update is saved on a USB mass storage device.
Procedure
t Download the QAPP center update from the Sartorius website onto the USB mass
storage device.
t If this relates to a zip file: Unzip the QAPP center update on the stick.
t Insert the USB mass storage device with the QAPP center update into one of the
device’s USB-A connections.
t Select the “QAPP Center Update” menu entry in the “Settings” / “Device
Maintenance” menu.
t Tap on the desired update.
t Once the software update is complete: Confirm successful installation with the
[OK] button.
66 Cubis® MCA Operating Instructions
Malfunctions
10 Malfunctions
10.1 Status Messages
Status Message Fault Cause Remedy Chapter, page
The LED strip on
the weighing
module is
illuminated
in orange
10.2 Warning Messages
Warning message Fault Cause Remedy Chapter, page
Disp.Err. The value to be output
High The device is overloaded. The device’s maximum
Low The modulation of the
Com.Err. The device is not
The device displays an
error message.
cannot be shown in the
operating display.
weighing converter inside
the weighing module is
too low.
receiving any weight
values.
The device has detected a
fault.
The data to be displayed is
not compatible with the set
display format.
weighing capacity has been
exceeded.
No weighing pan has been
placed on the balance.
A previously forgotten
weight was removed after
starting the device.
No communication exists
between the display and
control unit and the
weighing module.
Rectify the error shown in the
operating display.
Adjust the display settings in
the menu, e.g. resolution, unit,
decimal places.
Reduce the applied weight to
below the device’s maximum
weighing capacity.
Insert the weighing pan into the
device and switch the device off
and on again.
Wait until the display and control
unit restores the communication
with the weighing module.
If the problem occurs again:
Contact Sartorius Service.
15.7, 74
17, 78
10.3 Troubleshooting
Fault Cause Remedy Chapter,
page
The operating display
is blank.
The displayed weight
value changes
constantly.
The weight readout
displayed by the device
is obviously wrong.
The device is disconnected. Check the connection to the
power supply.
The AC adapter is not connected. Connect the power supply cable
to the power supply.
The installation site is unstable. Adjust the parameters in the
“Environment Monitoring”
Submenu.
Change the installation site. 5.2, 34
A foreign object is positioned between the
weighing pan and the housing.
The device has not been calibrated. Calibrate the device. 8.8, 58
The device was not tared before weighing. Tare the device.
Cubis® MCA Operating Instructions 67
Remove the foreign object.
6.2, 40
6.2, 40
7.4.3, 45
Decommissioning
2
11 Decommissioning
11.1 Decommissioning the Device
Procedure
t Turn the device off.
t Disconnect the device from the power supply.
t Disconnect the device from all connected devices and all accessories, e.g. printer
or electronics module.
t Clean the device (see Chapter 9.2, page 64).
t If below-balance weighing has been set up:
t Turn the device on its side and place it on a soft support base.
t Insert cover plate (1) and screw on with both screws (2).
t Place the device back on the device base on a level surface.
1
12 Transport
12.1 Transporting the Device
Procedure
t
CAUTION Risk of injury from breaking glass Glass components can break if
they fall or are handled incorrectly. Glass fragments can cause cuts.
t Only lift the device by its base, not by the draft shield.
t When lifting and transporting, ensure that no personnel or objects are in the
way.
t Get help from additional persons when lifting and transporting the device.
t Use suitable conveyance devices, e.g. trolleys, for long transport routes.
68 Cubis® MCA Operating Instructions
Storage and Shipping
13 Storage and Shipping
13.1 Storage
Procedure
t Turn the device off.
t Disconnect the device from the power supply.
t Disconnect the device from all connected devices and all accessories, e.g. printer.
t Clean the device (see Chapter 9.2, page 64).
t Store the device according to the ambient conditions (see Chapter “15.6 Ambient
Conditions”, page 73).
13.2 Returning Device and Parts
Defective devices or device components can be returned to Sartorius. Returned
devices must be clean, decontaminated, and properly packed, e.g. in the original
packaging.
Transport damage as well as measures for subsequent cleaning and disinfection of
the device or device components by Sartorius shall be charged to the sender.
WARNING
Risk of injury due to contaminated devices!
Devices contaminated with hazardous materials (NBC contamination) will not be
accepted for repair or disposal.
t Observe the information on decontamination (see Chapter 14.1, page 70).
Procedure
t Disconnect the device from the power supply.
t Disconnect the device from all connected devices and all accessories, e.g. printer.
t Clean the device.
t Contact Sartorius Service for instructions on how to return devices or device
components (please refer to www.sartorius.com for return instructions).
t Pack the device and the device components properly for return, e.g. in the
original packaging.
Cubis® MCA Operating Instructions 69
Disposal
14 Disposal
14.1 Information on Decontamination
The device does not contain any hazardous materials that would necessitate special
disposal actions.
Contaminated samples used during the process are potentially hazardous materials
that could cause biological or chemical hazards.
If the device has come into contact with hazardous substances: Steps must be taken
to ensure proper decontamination and declaration. The operator is responsible for
adhering to local government regulations on the proper declaration of transport and
disposal and the proper disposal of the device.
WARNING
Risk of injury due to contaminated devices!
Devices contaminated with hazardous materials (NBC contamination) will not be
accepted by Sartorius for repair or disposal.
14.2 Disposing of Device and Parts
14.2.1 Information on Disposal
The device and the device accessories must be disposed of properly by disposal
facilities.
A lithium cell battery, type CR2032, is installed inside the device. Batteries must be
disposed of properly by disposal facilities.
14.2.2 Disposing
Requirements
The device has been decontaminated.
Procedure
t Dispose of the device. Follow the disposal instructions on our website
(www.sartorius.com).
t Inform the disposal facility that there is a lithium cell battery, type CR2032,
installed inside the device.
t Dispose of the packaging in accordance with local government regulations.
70 Cubis® MCA Operating Instructions
Technical Data
15 Technical Data
15.1 Dimensions and Weight
15.1.1 Microbalance
With round glass ring draft shield With stainless steel draft shield
for the filter pan
Unit Value Value
Dimensions
Weighing module (L x W x H) mm 340 x 139 x 129 340 x 139 x 129
Electronics module with control
unit (L x W x H)
Weighing pan size
Weighing pan for models
MCA2.7S
Weighing pan for models
MCA10.6S, MCA6.6S, MCA3.6P
Filter weighing pan mm –
Weight, approx. kg 7.2 7.9
mm 355 x 240 x 61 355 x 240 x 61
mm
mm
d 20 d 20
d 30 d 30
d 50
15.2 Power Supply
15.2.1 Device
Only by Sartorius AC adapter YEPS03-15V0
15.2.2 AC Adapter
Unit Value
Item No. YEPS03-15V0
Primary
AC voltage V
Frequency Hz 50 – 60 (± 5 %)
Current consumption, maximum A 1.0
Secondary
DC voltage at 2 A output current V 14.25 – 15.75
Power, maximum W 30
Short circuit protection: Electronic
Protection class according to IEC 62368-1 I
Pollution level according to IEC 61010-1 2
Overvoltage category according to IEC 606641-1 II
Installation site according to IEC 62368-1, maximum altitude above sea level m 5000
Temperature
100 – 240 (±10 %)
Cubis® MCA Operating Instructions 71
Technical Data
Unit Value
In operation °C 0 – +40
During storage and transport °C -20 – +80
Connector for mains connection according to IEC 60320-1 / C14: 3-pin
Power supply cable
Power supply cable according to IEC 60320-1 / C14: Country-specific,
3-pin, two-sided plug
Other data: See label on AC adapter
15.2.3 Safety of Electrical Equipment
According to EN 61010-1 / IEC 61010-1 Safety requirements
for electrical equipment for measurement, control, and
laboratory use – Part 1: General Requirements
15.2.4 Electromagnetic Compatibility
Interference resistance
Suitable for use in industrial areas
Transient emissions
Class B
Suitable for use in residential areas and areas that are
connected to a low voltage network that also supplies
residential buildings.
15.3 Materials
Housing: Die-cast aluminum, plastic PBT, Optiwhite float glass and stainless steel 1.4401 | 1.4404, PA handles,
aluminum trim
Display and control unit: Plastic PBT, float glass and stainless steel 1.4301
15.4 Integrated Clock
Unit Value
Maximum deviation per month (RTC) s 30
15.5 Backup Battery
Unit Value
Lithium battery, type CR2032
Service life at room temperature, minimum Years 10
72 Cubis® MCA Operating Instructions
Technical Data
15.6 Ambient Conditions
15.6.1 Installation Site
Unit Value
Installation site
Standard laboratory rooms
Installation site according to IEC 60259-1, maximum altitude
above sea level
For indoor use only
Temperature
In operation °C +5 – +40
In operation for conformity-assessed devices:
See information on the device’s ID plate
During storage and transport °C -20 – +60
Relative humidity
At temperatures of up to 31 °C % 80
Then linear decrease from 80 % at 31 °C to 50 % at 40 °C
No heat from heating systems or direct sunlight
No drafts from open windows, AC systems, or doors
No vibrations
No “heavy traffic” areas (personnel)
No electromagnetic fields
No dry air
m 3000
15.6.2 Ambient Temperature for the isoCAL Function
Unit Value
Scope of application as per Directive 2014/31/EU
With isoCAL function °C +10 – +30
Without isoCAL function °C +17 – +27
15.6.3 Protection Class
IP Protection: Protected against dust and water
Cubis® MCA Operating Instructions 73
Technical Data
15.7 Metrological Data
15.7.1 Models MCA2.7S | MCA10.6S | MCA6.6S | MCA3.6P
MCA2.7S MCA10.6S MCA6.6S MCA3.6P
Unit Value Value Value Value
Scale interval (d) µg 0.1 1 1 1 | 2 | 5
Maximum capacity (Max)
Repeatability at 5 % load
Standard deviation of the load values,
tolerance
Standard deviation of the load values,
typical value
Repeatability at approx. maximum capacity
Standard deviation of the load values,
tolerance
Standard deviation of the load values,
typical value
Linearity deviation
Tolerance µg 0.9 4 4 4
Typical value µg 0.7 3 3 3
Deviation when load is off-center,
positions according to OIML R76
Test weight g 1 5 2 1
Tolerance µg 0.7 4 4 5
Typical value µg 0.5 3 3 3
Sensitivity drift between +10 °C and +30 °C ppm/K 1 1 1 1
Tare maximum capacity: Less than 100 % of
maximum capacity
Accuracy class according to Directive 2014/31/EU I I I I
Verification scale interval (e) according to
Directive 2014/31/EU
Minimum load (Min) according to Directive
2014/31/EU
Minimum initial weighing according to USP
(United States Pharmacopeia), Chap. 41
Optimum minimum initial weighing µg 82 820 820 820
Typical minimum initial weighing µg 300 1000 1000 1000
Typical stabilization time s 7 5 5 5
Typical measurement time s 10 8 8 8
g 2.1 10.1 6.1 1.1 | 2.1 | 3.1
µg 0.20 1 1 3
µg 0.15 0.5 0.5 0.5
µg 0.25 1 1 5
µg 0.18 0.6 0.6 0.6
mg 1 1 1 1
mg 0.01 0.1 0.1 0.1
15.8 Recommended Calibration Weight
MCA2.7S MCA10.6S MCA6.6S MCA3.6P
Unit Value Value Value Value
External test weight g 2 10 5 3
Recommended accuracy class E2 E2 E2 E2
74 Cubis® MCA Operating Instructions
Technical Data
15.9 isoCAL Function
Unit Value
isoCAL is triggered by the following criteria:
In the event of a temperature change K 1.5
After a time interval h 12
After successful leveling
15.10 Alibi Memory
Value
Maximum number of data records 150000
15.11 Interfaces
15.11.1 Specifications of the COM-RS232 Interface
Type of interface: Serial interface
Interface operation: Full duplex
Level: RS232
Connection: D-sub connector, 9-pin
Pin assignment
1
6
15.11.2 Specifications for the USB-A Interface
Communication: USB host (master)
Connectable devices: Sartorius printers, USB sticks with
software update
5
9
Pin 1: Not assigned
Pin 2: Data output (TxD)
Pin 3: Data input (RxD)
Pin 4: Not assigned
Pin 5: Internal ground
Pin 6: Not assigned
Pin 7: Clear to Send (CTS)
Pin 8: Request to Send (RTS)
Pin 9: Not assigned
15.11.3 Specifications for the USB-B Interface
Communication: USB device (slave)
Type of interface: Virtual serial interface (virtual COM-port,
VCP) and “PC direct” communication
Cubis® MCA Operating Instructions 75
Accessories
16 Accessories
16.1 Accessories
This table contains an excerpt of the accessories that can be ordered. For information
on other products, contact Sartorius.
16.1.1 Printers and Communication
Item Quantity Order number
Thermal transfer | thermal printer for GLP / GMP
printouts on continuous paper and labels
Standard paper and ink ribbon, set, 90 m, for YDP30 1 69Y03285
Self-adhesive paper and ink ribbon, 90 m, for YDP30 1 69Y03286
Standard thermal paper, 24 m roll, for YDP30 | YDP40 5 69Y03287
Self-adhesive thermal paper, 13 m roll, for YDP30 5 69Y03288
Self-adhesive labels for YDP30
58 mm × 100 mm 350 69Y03094
58 mm × 76 mm 500 69Y03093
58 mm × 30 mm 1000 69Y03092
Display cable, 3 m, for separate installation of display
and weighing units, installation by Sartorius Service
or at the factory (order code VF4016)
Installation of display cable, 3 m, for separate
installation of display and weighing units
Cable, 3 m, between the weighing module and
electronics module for semi-microbalance
RS232C connection cable, 9-pin, 3 m, for connection
to a PC with 9-pin COM interface
Sartorius Wedge, software for data communication
between the PC and balance
1 YDP30
1 On request
1 VF4016
1 YCC01-MSM3
1 On request
1 YSW02
76 Cubis® MCA Operating Instructions
16.1.2 Displays and Input / Output Elements
Item Quantity Order number
Display and control unit with color TFT display,
touch screen, and keys
Motion sensor for triggering a maximum of
4 functions via gesture control, selection via menu
1 YAC01MCE
1 YHS02MS
Accessories
16.1.3 Hardware and Software for Pipette Calibration
Item Quantity Order number
Pipette calibration kit (hardware) for microbalance
1 VF988
weighing modules 6.6S and 3.6P, consists of
moisture trap and all required adapters
16.1.4 Filter Balance and Antistatic Accessories
Item Quantity Order number
Filter weighing pan, diameter 75 mm, for ultramicro-
1 YWP05MS
balance or microbalance models (weighing modules
6.6S, 2.7S; only together with a metal ring draft
shield for filter)
Filter weighing pan, diameter 90 mm, for ultramicro-
1 YWP06MS
balance or microbalance models (weighing modules
6.6S, 2.7S; only together with a metal ring draft
shield for filter)
Ionization blower for electrostatically charged
1 YIB01-0DR
samples
Stat-Pen ionization pen for discharging electro-
1 YSTP01
statically charged samples
Ionizer with u-shaped electrode for 230 V 1 YIB02-230V
Ionizer with u-shaped electrode for 115 V 1 YIB02-115V
16.1.5 Weighing Tables
Item Quantity Order number
Weighing table
Made from synthetic stone, with vibration
1 YWT03
dampening
Made from wood and synthetic stone 1 YWT09
Wall console 1 YWT04
16.1.6 Weighing Accessories
Item Quantity Order number
Aluminum weighing scoop, 4.5 mg for
250 6565-250
ultramicrobalance and microbalance models
Aluminum weighing scoop, 52 mg for
50 6566-50
ultramicrobalance and microbalance models
Cubis® MCA Operating Instructions 77
Sartorius Service
17 Sartorius Service
Sartorius Service is available for queries regarding the device. For information
about the service addresses, services provided, or to contact a local representative,
please visit the Sartorius website (www.sartorius.com).
When contacting Sartorius Service with questions about the system or in the
event of malfunctions, be sure to have the device information, e.g. serial number,
hardware, firmware, and configuration, to hand. Consult the information on
the manufacturer’s ID label and in the “General Device Information” menu
(see Chapter “4.14 Menu Structure”, page <?>).
18 Conformity and Certificates
18.1 EU Declaration of Conformity
The attached Declaration of Conformity hereby confirms compliance of the device
with the directives cited.
The Declaration of Conformity supplied here is for conformity-assessed (verified)
balances for use in the EEA. Please keep it in a safe place.
78 Cubis® MCA Operating Instructions
Conformity and Certificates
Cubis® MCA Operating Instructions 79
Conformity and Certificates
DQD 507 Rev. 2016-02-18 Page 1
Certificate of Compliance
Certificate: 70185847 Master Contract: 167555 (056628)
Project: 70185847 Date Issued: 2018-09-24
Issued to: Sartorius Lab Instruments GmbH & Co. KG
Otto-Brenner-Strasse 20
Goettingen, Niedersachsen 37079
GERMANY
The products listed below are eligible to bear the CSA Mark shown
with adjacent indicators 'C' and 'US' for Canada and US or with adjacent
indicator 'US' for US only or without either indicator for Canada only.
Issued by:
Jean-Philippe Laplante
Jean-Philippe Laplante
PRODUCTS
CLASS - C872106 - ELECTRICAL LABORATORY EQUIPMENT
CLASS - C872186 - ELECTRICAL LABORATORY EQUIPMENT-Certified to US Standards
Digital scale, models: MCA Series & MCE Series; rated: 15Vdc, 12W max for external PS rated: 100-240Vac,
50-60Hz, 1.0A max
Notes:
1. The above model is Equipment Class I (powered by external class I power supply with detachable power
supply cord), Pollution Degree 2 and Overvoltage category II
2. Mode of operation: Continuous
3. Environmental Conditions: 5 to 40 °C, 3000 m max, 80% rH max
18.2 Certificate of Compliance
80 Cubis® MCA Operating Instructions
Conformity and Certificates
Certificate: 70185847
Project: 70185847
Master Contract: 167555
Date Issued: 2018-09-24
DQD 507 Rev. 2016-02-18 Page 2
APPLICABLE REQUIREMENTS
CSA Standards:
CAN/CSA-C22.2 No. 61010-1-12 - Safety Requirements for Electrical Equipment for Measurement,
Control, and Laboratory Use, Part 1: General Requirements
UL Standards:
UL Std. No. 61010-1 (3rdEdition) - Safety Requirements for Electrical Equipment for Measurement,
Control, and Laboratory Use - Part 1: General Requirements
CONDITIONS OF ACCEPTABILITY
(1) Equipment is intended to be used with power supply FSP Group Inc, Model FSP030-DGAN3 or Sinpro
Electronics Co Ltd, Model SPU31-106 or PSFD rated output 15Vdc, 2A. The equipment can also be used
with any other power supply approved for Canada and USA under the 60950-1 or 61010-1 or equivalent
standards and which provides Reinforced insulation between mains and secondary circuits. It must be
rated for 3000m and up to 40°C and must provide an output of 15Vdc LPS with a minimum of 1A
(2) Detachable cord set, to be delivered with the product, consisting of minimum NEMA 5-15 Plug, 3 x
18AWG cable and C13 Appliance coupler. For countries outside Canada and the USA the cable must be
equivalent and must fulfill the national requirements for detachable cord sets.
Cubis® MCA Operating Instructions 81
Conformity and Certificates
FCC
18.3 FCC Supplier’s Declaration of Conformity
upplier’s Declaration of Conformity
S
evice type Electronical Precision, Milligram, Analytical, Semi Micro, Micro-Small
D
and High-Capacity Balance
T
ype series MCAvw-2x-y, MCEvw-2x-y
v = 2.7, 3.6, 6.6, 10.6, 124, 125, 224, 225, 323, 324, 524, 623, 1202, 1203, 2202, 2203,
3203, 4202, 5201, 5202, 5203, 6202, 8201, 8202, 10202, 11201, 12201, 14202,
20201, 32202, 36200, 36201, 50201, 70200, 70201
w
x
y
P
arty issuing Supplier’s Declaration of Conformity /
R
esponsible Party – U.S. Contact Information
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
I
nformation to the user
Note: This equipment has been tested and found to comply with the limits for a c
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
= S, P
= S00, S01, CEU, CFR, CCN, OBR, OIN, ORU, OJP
= A, E, F, I, M, O, R, U
Sartorius Corporation
5 Orville Dr Suite 200
11716 Bohemia, NY
USA
Telephone: +1.631.254.4249
lass B
Connections between the device and peripherals must be made using shielded cables in order
to maintain compliance with FCC radio frequency emission limits.
Any modifications made to this device that are not approved by Sartorius may void the
authority granted to the user by the FCC to operate this equipment.
___________________________________________________________________________________________
Doc: 2384181-00 SLI18FCC001-00.en 1 / 1 PMF: 2369813 OP-113_fo1_2015.10.12
