Saplings Stephanie cot bed
Drop side
Assembly instructions – please keep for future reference
If you need help or have missing or damaged parts, call the customer helpline:
01952 550022
1
Big ends x2 small end x1 base x1
fr
Components – fittings please check all fittings are present
Components – parts
4 3 2
1
2
Fixed and drop Sides
5
Drop bars x2
Secure fixed side (part 4) to the
cot ends (part 1) using the bolts
(part A) and nuts (part D) as in
(fig. 1 & 2)
This is done by removal of one of the big
cot end and two sides replacing it with the
small end provided .ensure the base is
now changed to the lower position base
Assembly instructions
Stage 1 fixed side to ends
Cot bed conversions
3
CONFORMS TO BSEN 716-2008/BS8509-2008
Place the mattress base (part 3)
in position (slats up Fig. 3).
Using the bolts (part A) and
small barrel nuts, (part C),
secure to end. (See fig 7)
Fig 1
Fig 2
Fix the bottom rail supports
(part H) securely to the end
using the bolts (part B) as shown
on fig 4.
Holding the drop side rail, push
the rod(part 5) through the top
rail into bottom rail and into the
bottom bracket(part H) Fix the
top rail support (part G) and
gravity catches (part F)
Stage 2 bases to ends
Fig 3
Fig 4
Stage 3 drop side
Fig 5
Fig 6
Fig 7
SAFETY POINTS
The thickness of the mattress chosen shall be such that the internal height
(surface of the mattress to the upper edge of the bed frame) is at
500millimetres in the lowest position of the base and at least 200 millimetres
in the highest position of the bed base.
Warning: Do not use the cot if any part is broken, torn or missing and
use only spare parts approved by the manufacturer.
Warning: Do not leave anything in the cot or place the cot close to
another product, which could provide a foothold or present a danger
of suffocation or strangulation, e.g. strings, blind/curtain cords, etc.
Warning: Do not use more than one mattress in the cot.
WARNING To prevent injury from falls that when the child is able to
climb out of the cot, the cot shall no longer be used for that child
furniture. be aware of the risk of open fires and other sources of strong
heat, such as electric bar fires , gas fires , etc. In the near vicinity
WARNING: Do not use this child’s bed if any part is broken, torn or
missing.
APPROXIMATE AGE: 18 months to 4 years of age
CLEANING INSTRUCTIONS Clean by wiping with a damp cloth and drying with
a soft clean cloth. Do not use abrasives, bleach, alcohol or ammonia-based
household polishes
WARNING Children are likely to play, bounce, jump and climb on
beds, Therefore the child's bed should not be placed too close other
Furniture or windows, and should be placed either tight to any wall
Or have a gap of 300 mm between the wall and the side bed
RECOMMENDATION:
The recommended size of mattress for this cot is 55 x 27 inches or 140 x 69
centimetres. For correct and safe fitting, the length and width of the
mattress shall be such that the gap between the mattress and the sides and
ends does not exceed 30mm
Safety and care advice
FOR FURTHER ACCESORRIES FOR THIS PRODUCT PLEASE VISIT OUR WEBSITE AT WWW.SAPLINGS.COM.
