Sapido Technology Inc. www.sapido.com.tw
CS105x
User Manual
V2.2.X Android System
Smart Home Kit
Security Alarm + Wireless Switch
Product Introduction:
CS105x is easy to install to your home network. Download Sapido APP, you can enjoy the remote control
the security system, receive the instant push notification from your handheld devices if it detects any
abnormal movement and view the 30 seconds video gram recording. With IP Cam's built-in microphone &
speaker and Sapido APP, you can take real-time action to set up alarm or broadcast your voice to intruders.
Keep your home safe and secured.
With Smart Switch, you can do the power ON/OFF via Sapido APP Schedule Management Function. It provides
electricity usage consumption and history record function to calculate electricity usage as the reference. Even
you are in a frenzy of work, you can turn the electric appliances On/Off via your smartphone for saving energy
and money, giving the experience of smart life with more convenience.
1
Sapido Technology Inc. www.sapido.com.tw
Catalogue
1. Hardware Instruction and Introduction ............................................................................................ 4
1.1 LED guide-light indicator ................................................................................................... 4
1.2 Hardware Instruction........................................................................................................ 8
1.3 Hardware Installation ..................................................................................................... 12
2. APP Download and Network Setup (Android system) ..................................................................... 16
3. Internet Settings ........................................................................................................................... 23
4. Security System Application .......................................................................................................... 26
4.1 Door & Window Sensor (DDLA0z) ..................................................................................... 27
4.2 Cloud Motion Sensor (MDKA0z) ....................................................................................... 33
5. Instruction of Security Alarm Router (WDG71n) ............................................................................... 39
5.1 Sound Sensor ................................................................................................................. 40
5.2 Temperature Sensor ....................................................................................................... 45
5.3 Light Sensor .................................................................................................................... 50
6. Application of IP Camera ............................................................................................................... 56
6.1. Surveillance Recording and Browse ................................................................................ 56
6.1.1. Real-Time Recording .................................................................................................. 56
6.1.2. Personalized Recording Schedule ............................................................................... 59
6.2. Real-Time Screenshot and Browse .................................................................................. 63
6.3. Music Play ...................................................................................................................... 65
6.3.1 Add the music to USB drive of IP Camera ................................................................... 65
6.3.2 Play music in USB drive .............................................................................................. 67
6.3.3 Schedule Setup of Music Play .................................................................................... 69
6.4. Setup for Alarm Siren ..................................................................................................... 72
6.4.1 Add the siren alarm to IP Camera’s USB ..................................................................... 72
6.4.2 Schedule Setup for Alarm Siren .................................................................................. 74
7. Smart Switch Application Instruction ............................................................................................... 77
7.1 Cloud Switch APP On/Off and Schedule Set-up .................................................................. 78
7.1.1 Set up Schedule of Power On/Off ................................................................................ 78
7.1.2 Schedule Setting ......................................................................................................... 81
7.1.3 Electricity Statistics ..................................................................................................... 86
7.1.4 History ....................................................................................................................... 87
8. How to add Family Users to the CS105x ......................................................................................... 88
8.1 Advice: When the family user’s handheld device is around the same place as CS105x ..... 88
8.2 When the family user’s handheld device is not around the same place as CS105x ........... 90
9. Advanced Settings of CS105x ......................................................................................................... 91
9.1 How to mute the alarm and the message notification ........................................................ 91
9.1.1 ZigBee Cloud Motion Sensor (MDKA0z) ........................................................................ 91
2
Sapido Technology Inc. www.sapido.com.tw
9.1.2 ZigBee Door & Window Sensor (DDLA0z) ..................................................................... 92
9.2 How to change the security alarm sound ........................................................................... 93
9.2.1 ZigBee Cloud Motion Sensor (MDKA0z) ........................................................................ 93
9.2.2 ZigBee Door & Window Sensor (DDLA0z) ..................................................................... 96
10. Application for Media Storage ....................................................................................................... 99
10.1 Upload the files in mobile device to IP Camera USB drive ................................................ 99
10.2 File download from USB drive of IP Camera .................................................................. 102
10.3 Directly stream the files of USB drive in mobile device .................................................. 105
11. Network Security ........................................................................................................................ 107
11.1 Network Security – Network security setup and internet device control ........................ 107
11.1.1 Client List ................................................................................................................ 107
11.1.2 Wireless Schedule ................................................................................................... 111
11.1.3 Keyword Blocked ..................................................................................................... 113
11.1.4 Website History ....................................................................................................... 115
11.1.5 Distributed Denial of Service (DDoS) .......................................................................... 118
11.1.6 Login History ........................................................................................................... 118
11.2 Download List – How to manage the files of mobile device (Smartphone / Tablet) ........ 119
11.2.1 Document Browse ................................................................................................... 120
11.2.2 Rename ................................................................................................................... 123
11.2.3 File Edit ................................................................................................................... 124
11.2.4 Offline Browse ........................................................................................................ 127
11.3 IOT Network – To review IP Camera and USB device status ............................................ 128
11.4 IOT Settings- How to manage security device in system .................................................... 132
11.4.1 How to auto update the firmware version .................................................................. 133
11.4.2 The Function of GUI .................................................................................................. 134
12. “How to set up other sensor device or IP Cam” instruction .............................................................. 135
12.1 Set up a new Door & Window Sensor（DDLA0z） .......................................................... 135
12.2 Add a New IP Camera (IPJC2n) ........................................................................................ 137
13. How to connect security system to the existing Sapido devices at your home? .................................. 140
13.1 Wired network connecting- Transfer to wireless network mode ........................................ 140
13.2 Wireless network connecting- Transfer to Wireless network mode.................................... 149
14. Q & A .......................................................................................................................................... 159
3
Sapido Technology Inc. www.sapido.com.tw
Guide-light
Light Color
Statue Instruction
WAN/LAN
Orange
Power on is being applied on the device. After 30 seconds,
the LED light will be green.
Green
Wireless network is connected properly
ZigBee
LED
Green
Steady：Security system working properly
Flashing: Alarm, Door & Window sensors and motion
detector are mapping the connection.
Wireless Status
Green
Wi-Fi signal normal
WPS Status
Orange
Wi-Fi signal extending
Green
Wi-Fi signal extended successfully
1. Hardware Instruction and Introduction
1.1 LED guide-light indicator
(1) Security Alarm（WDG71n）
4
Sapido Technology Inc. www.sapido.com.tw
Product
Guide-light
Light Color
Statue Instruction
DDLA0z
ZigBee
Red
Connecting with WDG71n
Green
Connected with WDG71n successfully
Orange
Low Battery
MDKA0z
ZigBee
Red
Connecting with WDG71n
Green
Connected with WDG71n successfully
Orange
Low Battery
(2) Cloud Door & Window Sensor（DDLA0z）and Cloud Motion Sensor
（MDKA0z）
5
Sapido Technology Inc. www.sapido.com.tw
Guide-light
Light Color
Statue Instruction
Power
Green
IR Recording properly
WAN
Green
Wireless network is connected properly
LAN
Green
Wireless network is connected properly
Wireless Status
Green
Wi-Fi signal normal
WPS Status
Orange
Wi-Fi signal extending
Green
Wi-Fi signal extended successfully
(3) Smart Cloud Night Vision Camera with Audio Wireless Router（IPJC2n）
6
Sapido Technology Inc. www.sapido.com.tw
Guide-light
Light Color
Statue Instruction
WAN/LAN
Orange
Power on is being applied on the device. After 30
seconds, the LED light will be green.
Green
Wireless network is connected properly
Manual Button
Green
Power ON
No Light
Power OFF
Wireless Status
Green
Wi-Fi signal normal
WPS Status
Orange
Wi-Fi signal extending
Green
Wi-Fi signal extended successfully
(4) Smart Cloud Control Insight Switch Wireless Router（WSG70n）
7
Sapido Technology Inc. www.sapido.com.tw
Guide-light
Statue Instruction
WAN/LAN
Connect to xDSL/Fiber, Static IP, Dynamic IP, PPTP, L2TP, Wi-Fi ISP AP,
WiFi-AP
Power Outlet
Power supply 100V-240V
ZigBee/ Alarm
power Off Button
For ZigBee signal extend, it is also a button for turn on/off alarm manually
Network Mode
Switch
Please switch to the R mode while the RJ45 cable is connecting to the
xDSL modem and WDG71n
Please switch to A mode while RJ45 cable is connecting to Sapido router
and WDG71n.
Please switch to the W mode while connecting to Wi-Fi network by
Sapido router.
Please switch to the R mode while connecting to the network by other
brand routers.
Reset Button
Press over 10 seconds to factory default settings(like your Wi-Fi
password)
Press about 3 seconds, the device will be rebooted
1.2 Hardware Instruction
(1) Security Alarm（WDG71n）
8
Sapido Technology Inc. www.sapido.com.tw
Product
Button
Statue Instruction
DDLA0z
Power Button
ON：Power On
OFF：Power Off
ZigBee
LED
ZigBee signal connecting
MDKA0z
Power Button
ON：Power On
OFF：Power Off
ZigBee
LED
ZigBee signal connecting
(2) Cloud Motion Sensor（MDKA0z）and Cloud Door & Window Sensor
（DDLA0z）
9
Sapido Technology Inc. www.sapido.com.tw
Button and Port
Function Description
WAN
Connect to xDSL/Fiber, Static IP, Dynamic IP, PPTP, L2TP, Wi-Fi ISP AP, WiFiAP
LAN
* Connecting to on-line equipment, such as personal PC, web-cam, printer
server, etc.
* If more LAN ports are needed, please apply Switch/Hub for extension
USB
Connectable
Micro USD Power
Port
Please connect with Sapido adapter.
Volume (- +)
Adjust the volume of speaker
R/A/W Mode
* Switch to R mode: connects between xDSL modem and IPJC2n.
* Switch to A mode: Connects between Sapido router and IPJC2n.
* Switch to W mode: Build WiFi bridge connection to Sapido router.
* Connecting with other brand router via Ethernet cord, please switch to R
mode.
RESET
REBOOT
* Press over 10 seconds to factory default settings(like your Wi-Fi
password)
* Press about 3 seconds, the device will be rebooted
(3) Smart Cloud Night Vision Camera with Audio Wireless Router（IPJC2n）
10
Sapido Technology Inc. www.sapido.com.tw
Guide-light
Statue Instruction
WAN/LAN
Connect to xDSL/Fiber, Static IP, Dynamic IP, PPTP, L2TP, Wi-Fi ISP AP,
WiFi-AP
Power Outlet
Power supply 100V-240V
Manual Button
Switch power ON/OFF
Network Mode
Switch
Please switch to the R mode while the RJ45 cable is connecting to the
xDSL modem and WSG70n
Please switch to A mode while RJ45 cable is connecting to Sapido router
and WSG70n.
Please switch to the W mode while connecting to Wi-Fi network by
Sapido router.
Please switch to the R mode while connecting to the network by
other brand routers.
RESET
REBOOT
* Press over 10 seconds to factory default settings(like your Wi-Fi
password)
* Press about 3 seconds, the device will be rebooted
(4) Smart Cloud Control Insight Switch Wireless Router（WSG70n）
11
Sapido Technology Inc. www.sapido.com.tw
Step 1. Please switch to R mode on the lateral side of Alarm (WDG71n), then plug on the power
outlet. WDG71n is starting up when the WAN/LAN indicator turning red. The system is
completely turn on when ZigBee light and all LED lights turn green after 30 seconds. The alarm
(WDG71n) can not only deter the intruders by alert sound, but also warn the owner about any
unusual circumstances are happening. For example, the door and window to which are attached
Cloud Door & Window Sensors were opened by intruders, or the Cloud Motion Sensor detected
intruders.
Step 2. Please open the lid of the Cloud Door & Window Sensor (DDLA0z), and insert 2 x AAA
batteries.
1.3 Hardware Installation
12
Sapido Technology Inc. www.sapido.com.tw
Step 3. Please tear the double-sided tape and
paste on the back of Cloud Door & Window
Sensor (DDLA0z). Then paste the DDLA0z one
part on the frame of Window, and the other
part on the Window. The interval of both parts
is no longer than 1 cm. (You can also fasten the
DDLA0z by the attached fasteners.)
Step 4. Please turn on the power. When the
ZigBee light is blinking, which means the
DDLA0z is mapping with alarm (WDG71n).
Once the Window is opened, the alarm will
start to have the alert sound.
Step 5. Please open the lid of the Cloud Motion Sensor (MDKA0z) and insert 2 x AAA batteries.
Before close the lid, switch the power to ON.
13
Sapido Technology Inc. www.sapido.com.tw
Step 6. When the left light
(ZigBee) of MDKA0z is
blinking, means the MDKA0z
is connecting properly with
WDG71n.
Step 7. After fastening the MKDA0z on the hallway or gate, it will
trigger the alarm (WDG71n) if someone approaches the MDKA0z.
Step 8. Put your IP Cam (IPJC2n) at your
entrance or window to monitor anytime. Power
on, turns red and blink to boot.
Step 9. Wait for 30 sec., when and
turns green, the boot is succeed. IP Cam will
make alarm while both Window & Door Sensor
and Motion Sensor been detected.
14
Sapido Technology Inc. www.sapido.com.tw
Step 10. Switch your smart Switch to “W” network mode and Plug-in. Wait for 30 seconds to start
up. When Wireless/WPS light turns to green, which means the start-up was successful.
Plug in with the non-electronic control type of household appliances like below: One Switch for
one electric appliance only. No extension cord recommend in order to avoid heavy electric
tension.
Step 11. There are two ways to make WiFi connection with Smart Switch (WSG70n) based on
distance:
(1) Get started to make the WPS wireless (Wi-Fi) connection of Security Alarm (WDG71n) and
Smart Switch (WSG70n): Please press the WPS button on both Security Alarm Router
(WDG71n) and WSG70n separately. When both of the lights stop blinking, it means the
connection is completed.
(2) Get started to make the WPS wireless (Wi-Fi) connection of IP Cam (IPJC2n) and Smart
Switch (WSG70n): Please press the WPS button on both Smart Switch (WSG70n) and
IPJC2n separately. When both of the lights stop blinking, it means the connection and
encryption are completed.
15
Sapido Technology Inc. www.sapido.com.tw
Step 1. Apply 3G smartphone
and go to Play Store to search
and download Sapido APP.
Step 2. Click and type into
key word “Sapido” for search.
Step 3. Click “Install” to
download APP.
Step 4. After completing the
installation, you can find Sapido
APP icon in your smartphone
desktop.
Step 5. Go to “Settings”
Step 6. Switch the Wi-Fi signal
to ON and search for Security
Alarm (WDG71n) WiFi signal.
2. APP Download and Network Setup (Android system)
16
Sapido Technology Inc. www.sapido.com.tw
Step 7. Select WDG71n WiFi
signal to connect.
Step 8. Activate Sapido APP.
Step 9. Click “New IOT”.
Step 10. Sapido APP will show the network device name and user name. All you have to do is to give
a name for the network domain in blank and enter the default password “admin” in blank.
In order to protect your network domain security, please click <Change Password> and enter the new
password. Then, click <New IOT> to finish the process. Now you have to enter your new password to
access the domain security
IOT name
You can give your IOT Name in the blank.
Device
Name
The Device name will show up
automatically, doesn't need to change.
User
name of
Domain
The account will show up automatically,
doesn't need to change
Password
of Domain
Need to enter the default password
“admin”
The
Options of
Changing
Password
You can change the password for your
domain
17
Sapido Technology Inc. www.sapido.com.tw
Step 11. Connecting…
Step 12. Click <IOT Settings>
Step 13. Entered the IOT
Settings, you can see the
security system is built-up (as
below).
: Security Alarm
: Door & Window Sensor
: Motion Sensor
: IP Cam and Smart Switch
: Battery Status
18
Sapido Technology Inc. www.sapido.com.tw
Step 14. In IOT Setting page,
you can rename the device.
Select IP Camera (IPJC2n) and
click “Rename”
Step 15. After typing in the new
name, click “Apply” to confirm.
Step 16. IP Camera has been
shown with new device name.
Step 17. You can rename the
name of device in IOT Setting.
Please select the Security Alarm
router (WDG71n) first, then
click <Rename>
Step 18. After entering the new
name, please click <Apply>,
then it will show the new name.
Step 19. The alarm (WDG71n)
had been changed to the new
name.
19
Sapido Technology Inc. www.sapido.com.tw
Step 20. To rename the Cloud
Door & Window Sensor: Choose
the Cloud Door & Window
Sensor (DDLA0z_xxx) in IOT
Setting first, then click
<Rename>.
Step 21. After entering the new
name, please click <Apply>,
then it will show the new name.
Step 22. The Cloud Door &
Window Sensor (DDLA0z_xxx)
had been changed to the new
name.
Step 23. To rename the Cloud
Motion Sensor: Choose the
Cloud Motion Sensor
(MDKA0z_xxx) in IOT Setting
first, then click <Rename>
Step 24. After entering the new
name, please click <Apply>,
then it will show the new name
Step 25. The Cloud Motion
Sensor (MDKA0z_xxx) had been
changed to the new name.
20
Sapido Technology Inc. www.sapido.com.tw
Step 26. You can rename the
name of device in IOT Settings.
Please click the Switch
(WSG70n) first, then click
<Rename>
Step 27. After entering the new
name, please click <Apply>,
then it will show the new name.
Step 28. The Switch (WSG70n)
had been changed to the new
name.
Step 29. After renaming, click to control the remote PC and click to access GUI.
21
Sapido Technology Inc. www.sapido.com.tw
Step 30. Please turn on WiFi to connect the alarm (WDG71n) to control the security system.
Security
System
Arm
Once you are sleeping or go out, please set
the shield as green, which represents the
security system is working.
Alarm
Triggered
When the security system was triggered,
the shield will turn red. Click the shield
from red to green to turn off the alert
sound and stay security mode.
Security
System
Disarm
To click the shield to turn gray represents
turn off the security system.
22
Sapido Technology Inc. www.sapido.com.tw
Step 1. Connect the Ethernet cable to WDG71n's WAN/LAN port, and switch to R mode while
Ethernet cable is connecting to the xDSL modem and WDG71n (modem mode).
3. Internet Settings
Make sure the network environment stable for any of your smartphone and handheld devices using
first, this step will let you receive emergency messages successfully while you go out. Follow the
security system set-up steps as below:
23
Sapido Technology Inc. www.sapido.com.tw
Step 2. Log in APP and click
“Internet Settings”, and then
your internet network will be
automatically detected
Step 3. Please enter your ISP
account and password, and select
WPA2 as the encryption mode (at
lease 8 (included) digital
characters), and finally click
“Apply”.
(Please memorize your Wi-Fi
security password)
Step 4. Please wait for the
setup operation. Do not turn
off or return.
Step 5. After the update, the
screen will subsequently goes
back to Log-In page, you might
directly connect to the network
if you have 3G in your
smartphone, to make sure it is
available for remote use as
well.
Step 6. If your smart phone didn't
have 3G network services, please
turn on Wi-Fi of your smartphone
and choose the network from
WDG71n. Enter the password that
setup by step 3, then your smart
phone has been connected to the
alarm (WDG71n).
Step 7. Back to the Sapido APP
again, you will see the new
name of domain that you just
setup.
24
Sapido Technology Inc. www.sapido.com.tw
Step 8. The instruction of the symbols from the main page:
Guide-light
Light
Statue Instruction
1. The lights of
device of the
domain
Green- Domain and network is
connected.
Gray- Domain and network is
disconnected
Red- Event alert
2. The light
symbols of the
Cloud Security
Green- Security System Arm.
Gray- Security System Disarm.
Red- Alarm is triggered.
(Empty)-No Installed or Security
System offline.
3. Change the
password Key
To change the password of domain.
4. Trash Can
Symbol
To delete the domain.
Congratulations!!! The Internet Setting of Cloud Security Alarm (WDG71n) is completed. Please enter
the Security System to utilize the functions.
25
Sapido Technology Inc. www.sapido.com.tw
4. Security System Application
Once someone opened the door and windows when you're not home, or the Cloud Motion Sensor
detects any unusual situation, your smartphone will receive an alert message, the alarm at home will
make sound at the same time as well. In addition, you can control the situation by self via Sapido APP.
Click the push notification to enter the APP main page, you will see the shield is red , and the event
alert will show up in front of the network name. Meanwhile, you can enter the Message to obtain
the detail of event (Ex: 2nd Floor Window is opened), and turn off the alert . Moreover, with 30
seconds real-time recording and monitor the environment via Cloud Camera function. Press “Arm ”
and “Voice Sender ” to deter the intruder. When everything settle down, turn off the alarm and the
security system is still working. The shield on the main page will stay green .
※ Press ZigBee button to directly turn off the alarm if you are at home.
26
Sapido Technology Inc. www.sapido.com.tw
Default of Door & Window Sensor
Step 1. Click <Security>
Step 2. Click <Door & Window
Sensor>.
Step 3. Select your specific Door
& Window Sensor.
Step 4. You can see the “message”, “alert”, “Speaker”, and “Recording” are selected already, means that
WDG71n will send you an alert message and make alert at the same time.
4.1 Door & Window Sensor (DDLA0z)
Door & Window Sensor has preinstalled the setting of “push notification” and “alert” already. Once it
detects abnormal situation, the alarm system will be activated.
27
Sapido Technology Inc. www.sapido.com.tw
Step 5. If you want your lights
on while window is opened, just
select the Switch. (shown in red
frame)
Step 6. Select “Switch Mode”
Step 7. To face your needed, you
can choose ON, OFF, or Repeat
mode of your Switch.
Step 8. After click “Switch”, you will receive push notification and alarm will be triggered when
window is opened. Also, 30 seconds recording and Switch will turn on at the same time.
28
Sapido Technology Inc. www.sapido.com.tw
There are three ways to turn off the alarm when it the Door & Windows Sensor (DDLA0z) is
triggered. Follow the steps as below.
The 1st method to turn off the alarm
If the alarm is triggered and you are at home, you can press the ZigBee button of the alarm
(WDG71n) to mute the alarm.
The 2nd method to turn off the alarm
Step 1. You will receive the push
notification as the photo below.
Please click the push
notification and enter to the
security system in APP.
Step 2. You will see the event
alert , and the shield will turn
red . To mute the alarm, just
click the shield to return to
green.
Step 3. Click <Message> to
understand the situation
immediately. It will show the
event list included the event date
and time. To understand more
about event's detail, please
select the “event”.
29
Sapido Technology Inc. www.sapido.com.tw
Step 4. Click “Camera” to view
the situation of event right
away.
Step 5. Click “ Arm” once you find the intruder in the
smartphone screen. : Volume adjustor.
Step 6. Also, you can click “ Voice Sender” once you find the intruder.
30
Sapido Technology Inc. www.sapido.com.tw
The 3
rd
method to turn off the alarm
Step 1. The event list is sorted by
date and time. If you enter the
“event” to view the details while
the shield is red . Please select
the “event” again to view the
page with more detail.
Step 2. The event list is sorted by
date and time. You can turn off
the alert when you reenter the
“event” again to view the page
with more detail.
Step 3. Click the silence sign
to mute the alarm and click
Record Video to view the 30
seconds recording. Then back to
the main list and enter “Camera”
to view the real-time monitor.
Step 4. Click “Camera” to view
the situation of event right
away.
Step 5. Click “ Arm” once you find the intruder in the
smartphone screen. : Volume adjustor.
31
Sapido Technology Inc. www.sapido.com.tw
Step 6. Also, you can click “ Voice Sender” once you find the intruder.
Step 7. After disarming, the shield will turn back to green . Also, the event alert will turn to the
green dote , which means that the alert is turn off but the security keep working.
32
Sapido Technology Inc. www.sapido.com.tw
Default of Cloud Motion Sensor (MDKA0z)
Step 1. Click <Security>
Step 2. Click <Motion Sensor>
Step 3. Select your specific Cloud
Motion Sensor
Step 4. You can see the “message”, “alert”, “Speaker”, and “Recording” are selected already, means that
WDG71n will send you an alarm notification and make alert at the same time.
4.2 Cloud Motion Sensor (MDKA0z)
Cloud Motion Sensor (MDKA0z) has preinstalled the setting of “push notification” and “alert” already.
Once it detects abnormal situation, the alarm system will be activated.
33
Sapido Technology Inc. www.sapido.com.tw
Step 5. If you want your lights
on while window is opened, just
select the Switch. (shown in red
frame)
Step 6. Select “Switch Mode”
Step 7. To face your needed, you
can choose ON, OFF, or Repeat
mode of your Switch.
Step 8. After click “Switch”, you will receive push notification and alarm will triggered when window is
opened. Also, 30 seconds recording and Switch will turn on at the same time.
34
Sapido Technology Inc. www.sapido.com.tw
There are three ways to mute the alarm when the Cloud Motion Sensor (MDKA0z) is triggered.
Follow the steps as below.
The 1st method to turn off the alarm
If the alarm is triggered and you are at home, you can press the ZigBee button of the alarm (WDG71n)
to mute the alarm.
The 2nd method to turn off the alarm
Step 1. You will receive the push
notification as the photo below.
Please click the push
notification and enter to the
security system in APP.
Step 2. You will see the event alert
, and the shield will turn red
. To mute the alarm, just click
the shield to return to green.
Step 3. Click <Message> to
understand the situation
immediately. It will show the
event list included the event date
and time. To understand more
about event's detail, please select
the “event”.
35
Sapido Technology Inc. www.sapido.com.tw
Step 4. Click “Camera” to view
the situation of event right
away.
Step 5. Click “ Arm” once you find the intruder in the
smartphone screen. : Volume adjustor.
Step 6. Also, you can click “ Voice Sender” once you find the intruder.
36
Sapido Technology Inc. www.sapido.com.tw
The 3
rd
method to turn off the alarm
Step 1. The event list is sorted by
date and time. If you enter the
“event” to view the details while
the shield is red . Please select
the “event” again to view the
page with more detail.
Step 2. The event list is sorted by
date and time. You can turn off
the alert when you reenter the
“event” again to view the page
with more detail.
Step 3. Click the silence sign
to mute the alarm and click
Record Video to view the 30
seconds recording. Then back to
the main list and enter
“Camera” to view the real-time
monitor.
Step 4. Click “Camera” to view
the situation of event right
away.
Step 5. Click “ Arm” once you find the intruder in the
smartphone screen. : Volume adjustor.
37
Sapido Technology Inc. www.sapido.com.tw
Step 6. Also, you can click “ Voice Sender” once you find the intruder.
Step 7. After disarming, the shield will turn back to green . Also, the event alert will turn to the green
dote , which means that the alert is turn off but the security keep working.
38
Sapido Technology Inc. www.sapido.com.tw
5. Instruction of Security Alarm Router (WDG71n)
WDG71n is not only an alarm but also a sensor that can detects intensity of the environmental factors
such as sound, temperature, and light. It is suggested to place the alarm sensor in an area with an open
space. For example, kitchen and living room.
The sensor will alarm if it detects an abnormal movement in the level of sound, temperature, and light
at home. At the same time, the Security Alarm Router WDG71n will send you an alert message to tell
you the emergency immediately. In addition, you can control the situation by self via Sapido APP. Click
the push notification to enter the APP main page, you will see the shield is red , and the event alert
will show up in front of the network name. Meanwhile, you can enter the Cloud Message to obtain
the detail of event (Ex: Unusual temperature in kitchen), and turn off the alert at the same time.
※ If you are at home, you can press the ZigBee button on the alarm (WDG71n) to turn off the alarm.
39
Sapido Technology Inc. www.sapido.com.tw
Step 1. You can adjust the
alarm sound level based on
the level of Decibels (dB) in
<Sensor> section.
Step 2. Click <Sound Sensor>
Step 3. Current alarm
detected volume (dB) level
will show on the right of the
Sound Sensor page.
Step 4. Please click <Warning
Device>
Step 5. When it detects the
abnormal sound in the space,
you will receive an alert message
on your phone. Meanwhile,
the alarm system will activate.
Please choose <Notification
Message> and <Sensor Alarm>
Step 6. For setting up the
condition of the alarm trigger,
please click Sensor Alarm
Device (shown below in red
frame).
5.1 Sound Sensor
40
Sapido Technology Inc. www.sapido.com.tw
Step 7. There are two different scenarios are provided from the function of "dB" section. You
can adjust the sound level between 0dB ~ 110dB. (Increments 5dB a time)
Step 8. The preinstall alarm setting is “continuity alarm”, means that the alarm will touch off when
the intensity reaches the level of indoor maximum limit. Sirens will continue beeping until you turn
off the alarm manually. If you want to change the setting to Define Alarm Sounds, then you can
adjust alarm sounding time under any abnormal movement, such as: 1 second, 2 seconds, 5
minutes ... etc.
41
Sapido Technology Inc. www.sapido.com.tw
Step 9. There are 5 types of different selectable beep length of "Siren”. When settle down alarm
sounds and siren, please press "Done" at the top right of the page to return to the sensing feature
page.
Step 10. If you want your
lights on while window is
opened, just select the
Switch. (shown in red frame)
Step 11. Face your needed to
setup dB, for example, higher
than 60dB to make the Switch
triggered.
Step 12. To face your needed,
you can choose ON, OFF, or
Repeat mode of your Switch.
42
Sapido Technology Inc. www.sapido.com.tw
There are two ways to mute the alarm when the alarm (WDG71n) triggers alarm.
The 1st method to turn off the alarm
If the alarm is triggered and you are at home, you can press the ZigBee button of the alarm
(WDG71n) to mute the alarm.
43
Sapido Technology Inc. www.sapido.com.tw
The 2nd method to turn off the alarm
Step 1. Open the Sapido APP,
you can enter <Message> to
view the situation immediately.
Step 2. The event list is sorted by
date and time. If you enter the
“event” to view the details while
the shield is red. Please select the
“event” again to view the page
with more detail.
Step 3. Click the silence sign
to mute the alarm and click
Record Video to view the 30
seconds recording. Then back
to the main list and enter
“Camera” to view the real-time
monitor.
Step 4. Click “Camera” to view
the situation of event right
away.
Step 5. Also, you can click “ Voice Sender” to talk to your
child once you find out your child is crying. : Volume
adjustor.
44
Sapido Technology Inc. www.sapido.com.tw
Step1. Click <Sensor>, you can
set up your predetermined
temperature level to activate
the alarm system.
Step2. Click <Temperature
Sensor>
Step3. The page of
Temperature Sensor will show
the current in room
temperature. The preinstall
measurement setting is
“Celsius”.
Step 4. Click the <Sensor
Device>
Step5. Select the “Notification
Message” and “Sensor Alarm”
options, you will receive a push
notification on your phone and
the alarm will make beeping
sound when the temperature is
in an abnormal situation.
Step 6. For setting up the
condition of the alarm trigger
by the limit of trigger
temperature, please click
Sirens Device (shown below in
red frame).
5.2 Temperature Sensor
45
Sapido Technology Inc. www.sapido.com.tw
Step 7. There are two different scenarios are provided from the function of "Celsius" section. You
can adjust the temperature level between 0 ° C ~ 50 ° C. (increments 1° C a time)
Step 8. The preinstall setting of "Sensor Alarm" is “continuity alarm”, means that the alarm will
touch off when the intensity reaches the level of indoor maximum limit. Sirens will continue
beeping until you turn off the alarm manually. If you want to change the setting to Define Alarm
Sounds, then you can adjust alarm sounding time under any abnormal movement, such as: 1
second, 2 seconds, 5 minutes ... etc.
46
Sapido Technology Inc. www.sapido.com.tw
Step 9. There are 5 types of different selectable beep length of "Siren”. When settle down alarm
sounds and siren, please press "Done" at the top right of the page to return to the sensing feature
page.
Step 10. If you want your
lights on while window is
opened, just select the
Switch. (shown in red frame)
Step 11. Face your needed to
setup Celsius, for example,
higher than 60C to make the
Switch triggered.
Step 12. To face your needed,
you can choose ON, OFF, or
Repeat mode of your Switch.
47
Sapido Technology Inc. www.sapido.com.tw
There are two ways to mute the alarm when the Security Alarm Router (WDG71n) triggers
alarm.
The 1st method to turn off the alarm
If the alarm is triggered and you are at home, you can press the ZigBee button of the alarm
(WDG71n) to mute the alarm.
48
Sapido Technology Inc. www.sapido.com.tw
The 2nd method to turn off the alarm
Step 1. Open the Sapido APP,
you can enter <Message> to
view the situation immediately.
Step 2. The event list is sorted
by date and time. You can turn
off the alert when you reenter
the “Event” again to view the
page with more detail.
Step 3. Click the silence sign
to mute the alarm and click
Record Video to view the 30
seconds recording. Then back
to the main list and enter
“Camera” to view the real-time
monitor.
Step 4. Click “Camera” to view
the situation of event right
away.
Step 5. Also, you can click “ Voice Sender” to talk to your
family members once you find out your home is on fire.
: Volume adjustor.
49
Sapido Technology Inc. www.sapido.com.tw
Step1. Click <Sensor>
Step2. Click <Light Sensor>
Step3. The page of Light
Sensor will show the current
in room brightness.
Step4. Click the <Siren
Device>
Step5. Select the “Notification
Message” and “Sensor Alarm”
options, you will receive a push
notification on your phone and
the alarm will make beeping
sound when the temperature is
in an abnormal situation.
Step 6. For setting up the
condition of the alarm trigger,
please click Sirens Device
(shown below in red frame).
5.3 Light Sensor
50
Sapido Technology Inc. www.sapido.com.tw
Step 7. There are two different scenarios are provided from high to low for the brightness. You can
adjust the brightness level between 0Lm ~ 2000Lm.
Step 8. The preinstall setting of "Sensor Alarm" is continuity sounds, means that the alarm will
touch off when the intensity reaches the level of indoor maximum limit. Sirens will continue
beeping until you turn off the alarm manually. If you want to change the setting to Define Alarm
Sounds, then you can adjust alarm sounding time under any abnormal movement, such as: 1
second, 2 seconds, 5 minutes ... etc.
51
Sapido Technology Inc. www.sapido.com.tw
Step 9. There are 5 types of different selectable beep length of "Siren”. When settle down alarm
sounds and siren, please press "Done" at the top right of the page to return to the sensing feature
page.
Step 10. If you want your
lights on while window is
opened, just select the
Switch. (shown in red frame)
Step 11. Face your needed to
setup brightness, for example,
higher than 400 Lm to make
the Switch triggered.
Step 12. To face your needed,
you can choose ON, OFF, or
Repeat mode of your Switch.
52
Sapido Technology Inc. www.sapido.com.tw
There are two ways to mute the alarm when the Security Alarm Router (WDG71n) triggers
alarm.
The 1st method to turn off the alarm
If the alarm is triggered and you are at home, you can press the ZigBee button of the alarm
(WDG71n) to mute the alarm.
53
Sapido Technology Inc. www.sapido.com.tw
The 2nd method to turn off the alarm
Step 1. Open the Sapido APP,
you can enter <Message> to
view the situation immediately.
Step 2. The event list is sorted by
date and time. If you enter the
“event” to view the details while
the shield is red. Please select the
“event” again to view the page
with more detail.
Step 3. Click the silence sign
to mute the alarm and click
Record Video to view the 30
seconds recording. Then back
to the main list and enter
“Camera” to view the real-time
monitor.
Step 4. Click “Camera” to view
the situation of event right
away.
Step 5. Click “ Arm” once you find the intruder in the
smartphone screen. : Volume adjustor.
54
Sapido Technology Inc. www.sapido.com.tw
Step 6. Also, you can click “ Voice Sender” to yield to intruder. : Volume adjustor.
55
Sapido Technology Inc. www.sapido.com.tw
Step 1. Select “Camera”.
Step 2. Click the functional
key「 Record」
Step 3. Setting, please wait...
Step 4. When the recording
starts, you can find the
red pot on the top left corner.
Step 5. Video will be
automatically stored in the
USB drive of IP camera;
please go「 View
Videos」for video browse.
Step 6. Videos will be sorted
by date and time, please
directly choose the video you
want to view.
6. Application of IP Camera
6.1. Surveillance Recording and Browse
6.1.1. Real-Time Recording
56
Sapido Technology Inc. www.sapido.com.tw
Step 7. Select the video for
immediate play.
Step 8. Click “Exit” when
finished, and goes back to
the last page. (Rotating the
device to enlarge for
browse)
Step 9. Click “Download” if
you want to back up the files
to your smartphone or other
devices.
Step 10. Video Downloading…
Step 11. Once download
successfully and then you
can play it.
Step 12. Downloaded files will
be directly stored in “Camera”
of “Download List”.
57
Sapido Technology Inc. www.sapido.com.tw
Step 13. Please Click “
Stop” to stop recording.
Step 14. Click “Apply” and
await.
Step 15. Once the red pot is
disappeared, the recording
has been stopped.
58
Sapido Technology Inc. www.sapido.com.tw
Step 1. Select “ Camera”
Step 2. Click “ Schedule” in
below.
Step 3. Click “New” to add
new schedule
Step 4. Cross day recording schedule of every 10pm to 6am of the next day. Set up 1st
recording schedule: please first select “Record Schedule”, and set up the start time at 22:00
and end time at 23:59, choose “Everyday” for Day, and finally click “Done” for confirmation.
6.1.2. Personalized Recording Schedule
You can set up the recording schedule at different time based on your requirement, such as
personalize the recording time during day time or bedtime, the operating method are as below:
59
Sapido Technology Inc. www.sapido.com.tw
Step 5. Choose the USB
storage device.
Step 6. Please await.... do not
shut down the APP
Step 7. After completing the
schedule added, the screen
will automatically go back to
home page. Please click the
network to log in.
Step 8. Click “Camera”
Step 9. Click “ Schedule” in
below
Step 10. You can find the
schedule you just added.
Please again click “New” if
you want to add new
schedule.
60
Sapido Technology Inc. www.sapido.com.tw
Step 11. Set up the 2nd recording schedule: Recording from every 10pm to 6am of next
morning. Choose “Record Schedule”, and select start time at 00:00, end time at 06:00, and
“Everyday” for Day, and finally click “Done” for completion.
Step 12. Choose USB storage
device
Step 13. Please await...do not
shut down the APP.
Step 14. The APP screen will
automatically go back to login page after completing
schedule added, please click
the network to log in.
61
Sapido Technology Inc. www.sapido.com.tw
Step 15. Click “Camera”
Step 16. Click “ Schedule”
in below
Step 17. You can find the 2nd
schedule added.
To modify the schedule,
please click
To delete the schedule,
please click
62
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click “Camera”
Step 2. Click “Screenshot” in
below to immediate save the
image in your smartphone
Step 3. Click “View Picture”
to review the screenshot
image.
Step 4. The images will be
sorted by date; please direct
select the date you want to
view.
Step 5. Image checklist will
be listed in order by time
sequence. See left side to
directly preview the image,
and click the image for full
screen review.
Step 6. Click below Play icon
to review all images in turn
when browsing full screen
6.2. Real-Time Screenshot and Browse
63
Sapido Technology Inc. www.sapido.com.tw
Step 7. Rotating the device to full screen review, and click “Exit” to leave.
64
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click “Upload”
Step 2. Select “My Files”
Step 3. Select the music you
want to upload and click
“Change” to choose path.
Step 4. Click your IP Camera
device name (nickname).
Step 5. Click “New Folder”
Step 6. Rename the folder,
such as “Music Folder” and
click “Apply”.
6.3. Music Play
6.3.1 Add the music to USB drive of IP Camera
IP Camera can be your music player, you are able to store your favorite music in USB drive of IP
Camera via “Upload” and bring you more options.
65
Sapido Technology Inc. www.sapido.com.tw
Step 7. Select the new added
folder.
Step 8. Click “Upload”.
Step 9. Uploading…
Step 10. Upload succeeded. Click “Upload more files” to upload more music, or click “Home”
to leave.
66
Sapido Technology Inc. www.sapido.com.tw
Step 1. Select “Camera”
Step 2. Click “Play ”
Step 3. Click “Change”
Step 4. Select the “play
mode” per your needed
In order: Play in order
Repeat: Repeat all selected
music and play
Timer: Play in scheduled
hours/minutes and stop
Step 5. If you want to play
music for 2 hours and then
stop, please first select
Schedule Mode and set up
the time, click “Done” to
complete.
Step 6. First select the music
you want to play (or whole
folder), and click “Play” on
the top right corner.
6.3.2 Play music in USB drive
67
Sapido Technology Inc. www.sapido.com.tw
Step 7. In music play mode,
you can adjust the volume
via
Step 8. Click “Stop ” to
stop.
Step 9. Music play is stopped
68
Sapido Technology Inc. www.sapido.com.tw
Step 1. Select “Camera”
Step 2. Click “Schedule ”
Step 3. Click “New”
Step 4. For example, set up automatic music play at every 12:00 pm to 13:00 pm; please first
select “Music Schedule” mode, and set the start time at 12:00 pm and end time at 13:00 pm
and choose “Everyday” for Day.
6.3.3 Schedule Setup of Music Play
69
Sapido Technology Inc. www.sapido.com.tw
Step 5. Click “Song”
Step 6. First select the music
(or whole folder), and then
“Done”
Step 7. Click “Done” in top
right corner for completion.
Step 8. Please await for
setting...Do not turn off or
return
Step 9. Once the setup is
done, the screen will
automatically go back to login page. Please again log in.
Step 10. Click “Camera”
70
Sapido Technology Inc. www.sapido.com.tw
Step 11. Click “ Schedule”
in below.
Step 12. You can see the music schedule you just added in the
checklist.
To modify, please click
To delete, please click
71
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click “Upload”
Step 2. Select “My Files”
Step 3. Select the music you
want to upload and click
“Change” to choose path.
Step 4. Click your IP Camera
device name (nickname).
Step 5. Click “Alarm Siren”
Step 6. Click “Upload”
6.4. Setup for Alarm Siren
IP Cam can broadcast the siren. You can upload the favorite sirens to “Siren” folder of IP camera
USB drive via “Upload” for more options.
6.4.1 Add the siren alarm to IP Camera’s USB
72
Sapido Technology Inc. www.sapido.com.tw
Step 7. Uploading…
Step 8. Upload succeeded. Click “Upload more files” to
upload more music, or click “Home” to leave.
73
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click “Camera”
Step 2. Click “Schedule” in
below.
Step 3. Click “New”
Step 4. For example, to set up the morning alarm at every 6:00 am; please first select the
mode as “Siren Schedule” and set the start time at 6:00 am, end time at 6:05 am, and select
“Everyday” for Day.
6.4.2 Schedule Setup for Alarm Siren
First complete the step to add siren (refer to 6.4.1) and enter into schedule setup to select the
siren.
74
Sapido Technology Inc. www.sapido.com.tw
Step 5. Select “Alarm”
Step 6. Click “Done”
Step 7. Settings, please
await....do not turn off or
return.
Step 8. After adding the
schedule, APP will
automatically return to home
page, and click to log in
again.
Step 9. Click “Camera”
75
Sapido Technology Inc. www.sapido.com.tw
Step 10. Select “ Schedule”
in below
Step 11. New added Alarm Schedules are showed in the
checklist.
To modify, please click
To delete, please click
76
Sapido Technology Inc. www.sapido.com.tw
7. Smart Switch Application Instruction
Sapido creates a new device “WSG70n”, Smart Cloud Switch, matches smartphone (iOS, Android) to control
your electric appliances anytime anywhere. In addition, Sapido APP offers numerous functions: power
consumption measurement, power switch set-up, schedule making, and start-up timing with the specific
electric appliance for historical electric information reference. Also, it provides the function of over-heating
protection. Giving you a lifestyle with smart protection, power saving, and energy conservation.
*You can turn on/off the power directly click the power button on the Smart Switch (WSG70n) if you are
home.
*Turn on/off power via Sapido APP when you are out:
77
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Switch>
Step 2. Click one specific
electric appliance's power
button at the right next to
device name, button is grey
means OFF.
Step 3. Power button turns to
red means ON
7.1 Cloud Switch APP On/Off and Schedule Set-up
If you are out or on the way to work, and forget to turn off the electric appliances, such as fan, and
light, etc. You can power ON/OFF the appliances via the Cloud Insight Switch APP power switch
mode. In addition, you can operate the appliances in your house along with the set schedules of
Smart Insight Switch through cycling time setting and schedule function, to surely accompany with
daily routine and fully saving the energy and cost.
7.1.1 Set up Schedule of Power On/Off
78
Sapido Technology Inc. www.sapido.com.tw
Step 4. Select one specific
electric appliance
Step 5. You can view different
functions such as: Power on
Reason, power consumption,
Uptime & Since time of
startup.
Step 6. If you want to change
the Switch Mode to “Repeat”,
click <Switch Mode>.
Step 7. Click <Repeat>
Step 8. Get Started to set up
Repeat Condition, for example,
let it power on for 3 minutes
and turn off for 1 minute in 10
minutes as a period. Click
<Done> to finish setting.
Step 9. Back to the front page
automatically, and your electric
appliance will follow the
schedule you have set-up
79
Sapido Technology Inc. www.sapido.com.tw
Step 10. Back to the front page,
you will see the repeat sign at
the right next to the device
name that means your setup
was successful. Now turn the
repeat sign to red represents
turn on the repeat mode.
Step 11. After ten minutes in a
period, the sign will turn to
grey.
Step 12. If you want to stop the
repeat mode, click the sign and
it will turn to grey.
80
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Switch>
Step 2. Select the specific
electric appliance
Step 3. Select <Schedule>
Step 4. Click <New> on the top
right corner to add your new
schedule
Step 5. There are three modes
for power On/Off:
OFF: power off
ON: power on
Repeat: power on/off
circulation
Step 6. If you want to select
power mode in ON, just select
it
7.1.2 Schedule Setting
Smart Cloud Switch can turn on/off your electric appliances based on the schedule that you
have set. You can decrease the trivial events, like turn on/off many electric appliances at home.
Smart Cloud Switch will give you an energy-saving life style.
7.1.2.1 Set Up Schedule of Power On/Off
81
Sapido Technology Inc. www.sapido.com.tw
Step 7. Select <Day>, you will
see the options from Monday
to Sunday, and Everyday. You
can select the days you like to
set up your schedule.
Step 8. Select <Start & End>,
for example, from 19:00 to
21:00. Click <Done> for saving,
and your Switch will follow the
schedule for powering on/off.
Step 9. Please wait for the setup operation. Do not turn off
or return
Step 10. After setting up, it will
pop up on the main page of
domain.
Step 11. Click <Switch>
Step 12. Select the specific
electric appliance.
82
Sapido Technology Inc. www.sapido.com.tw
Step 13. Select <Schedule>
Step 14. You can see your
schedule under the page. To
delete or edit the schedule,
click “delete ” or “edit ”
button to do so.
Step 15. To add a new
schedule, click <New> on the
top right corner.
Step 16. Select the “OFF” time,
then select the days to turn off
your electric appliance
Step 17. Select <Start & End>,
for example, from 19:00 to
21:00. Click <Done> for saving,
and your switch will follow the
schedule for power off.
Step 18. You can see your
schedule is under the page. To
delete or edit the schedule,
click “delete ” or “edit ”
button to do so.
83
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Switch>
Step 2. Select the specific
electric appliance
Step 3. Select <Schedule>
Step 4. To add a new schedule,
click <New> on the top right
corner.
Step 5. Select the “Repeat” of
“Switch Mode”
Step 6. Set up the schedule like this:
ON: 1 Hour and 10 minutes
OFF: 30 minutes
Day: Friday
Start: 10:00
End: 14:00
Then click <Done> to complete
setting
7.1.2.2 Switch Repeat Schedule Setting Examples
This function can let your electric appliances follow the schedule of repeating turn on/off in a
circle within a period. For example, if you want your electric fan, which plug-in Smart Cloud
Switch, working in such the rule: Turn on for 1.5 hours and turn off for 30 minutes within a 5hours circle schedule on every Friday. Please follow the steps below:
84
Sapido Technology Inc. www.sapido.com.tw
Step 7. Please wait for the
setup operation. Do not turn
off or return
Step 8. After setting up, it will
pop up on the main page of
domain.
Step 9. Click <Switch>
Step 10. You will see the repeat
sign at the right next to the
device name, and enter the
specific electric appliance
Step 11. Select <Schedule>
Step 12. You can see your
schedule is under the page. To
delete or edit the schedule,
click “delete ” or “edit ”
button to do so.
85
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Switch>
Step 2. Select the specific
electric appliance
Step 3. Click <Electricity
Statistics>
Step 4. You can view the data
of your specific electric
appliance's total “Day”,
“Week”, “Month”, and “Year”
power consumption, like the
picture below
Step 5. To delete all the data
before, click <Reset> on the top
right corner. After deleting, the
device will show up the time of
reset. If you turn on the power
button again, the data
measurement will restart from the
reset time.
Step 6. You will see the reset
data after deleting. Click power
ON/OFF to start measuring
your specific electric
appliance's total daily, weekly,
monthly, and annual power
consumption.
7.1.3 Electricity Statistics
You can view the data of your specific electric appliance's total daily, weekly, monthly, and
annual power consumption for known if your electric appliance saving power or not.
86
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Switch>
Step 2. Select the specific
electric appliance
Step 3. Click <History>
Step 4. History record of your electric
appliances power on/off
Cloud Switch Schedule: Use schedule
set-up to turn on/off power
Mobile APP Switch: Use mobile APP
to turn on/off power
Button: Press Button on the Smart
Switch to turn on/off power
Step 5. To delete all the data,
click <Reset>
Step 6. All history record were
deleted
7.1.4 History
You can view the history record of your electric appliances power on/off and working schedule like
below:
87
Sapido Technology Inc. www.sapido.com.tw
Step 1. Go to “Settings”
Step 2. Switch on Wi-Fi of new
device for searching.
Step 3. Select WiFi signal of
Security Alarm (WDG71n) or
IP Cam (IPJC2n) or Smart
Switch (WSG70n) to connect.
Step 4. Type in the Security
Password set by network
creator and click “Connect”
Step 5. Click “Play Store” and
search “Sapido APP” or
“Sapido”
Step 6. Click “Install”
8. How to add Family Users to the CS105x
8.1 Advice: When the family user’s handheld device is around the same place as
CS105x
88
Sapido Technology Inc. www.sapido.com.tw
Step 7. Click downloaded
Sapido APP
Step 8. Click “New IOT”
Step 9. APP will automatically
show device name and
user name, please type in
the password provided by
network family administrator in
column, and click “New
IOT” to log in.
Step 10. Connecting, please
await…
Step 11. Once log-in is success,
handheld device could access the
security system (see below
picture). The device can control
the security system and receive
push notification anytime and
everywhere once it is connected
to internet.
Step 12. Click “Back” and
return to home page, and
then you can see the
network nickname set by the
family administrator.
89
Sapido Technology Inc. www.sapido.com.tw
Step 1. Once the mobile
device and the Security Alarm
(WDG71n) are at the different
places, please connect the
internet and search, then
download Sapido APP. Open
the Sapido APP
Step 2. Click <New IOT>
Step 3.
Device Name: The Device
name will show up automatically,
doesn't need to change.
User name of Domain: The
account will show up
automatically, doesn't need to
change
Password of Domain: Need to
enter the default password
“admin”
Step 4. The network is under
connecting, please wait...
Step 5. Log in successfully,
you can see the security
system is built-up.
Step 6. Back to the APP
home page, you will see the
automatically setting
network nickname.
8.2 When the family user’s handheld device is not around the same place as CS105x
90
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Security>
Step 2. Click <Motion Sensor>
Step 3. Enter the alarm system
to the setting page.
Step 4. Cancel the <Notification
Message>: Once detected
someone's movement, you will
not receive the push notification
but alarm keeps working.
Step 5. Cancel the <Sensor Alarm>:
Once detected someone's
movement, alarm will not make the
beeping sound but you will receive
the push notification.
Step 6. Cancel both <Notification
Message> & <Sensor Alarm>: Once
detected someone's movement,
you will not receive any message
notification and the alarm will not
make the sound either.
9. Advanced Settings of CS105x
Sirens will continue beeping until you turn off the alarm manually. If you want to change the setting to
Define Alarm Sounds, then you can adjust alarm sounding time under any abnormal movement, such as: 1
second, 2 seconds, 5 minutes ... etc.
9.1 How to mute the alarm and the message notification
The security system has preinstalled setting with "Sensor Alarm" and “Notification Message”. Below
are the steps of how to cancel those functions.
9.1.1 ZigBee Cloud Motion Sensor (MDKA0z)
91
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Security>
Step 2. Click <Door & Window
Sensor>
Step 3. Enter the alarm system
to the setting page.
Step 4. Cancel the <Notification
Message>: Once detected the
door is opened, you will not
receive the push notification
but alarm keeps working.
Step 5. Cancel the <Sensor
Alarm>: Once detected the
door is opened, alarm will not
make the beeping sound but
you will receive the push
notification.
Step 6. Cancel all the function.
Once detected the door is
opened, you will not receive any
message notification and the
alarm will not make the sound
either.
9.1.2 ZigBee Door & Window Sensor (DDLA0z)
92
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Security>
Step 2. Click <Motion Sensor>
Step 3. Enter the alarm system
to the setting page
Step 4. Select the Sensor Alarm
to the setting page(shown
below in red frame)
Step 5. Enter “Alarm Setting” to
adjust the system.
Step 6. Choose one of the
options as you like to set up
the alarm type and time.
9.2 How to change the security alarm sound
9.2.1 ZigBee Cloud Motion Sensor (MDKA0z)
93
Sapido Technology Inc. www.sapido.com.tw
Step 7. There are 5 types of different selectable beep length of "Siren”. When settle down alarm
sounds and siren, please press "Done" at the top right of the page to return to the sensing feature
page.
Step 8. Select the Speaker to
the setting page(shown below
in red frame)
Step 9. Enter “Alarm Setting” to
adjust the system.
Step 10. Choose one of the
options as you like to set up
the alarm type and time.
94
Sapido Technology Inc. www.sapido.com.tw
Step 11. There are 5 types of different selectable beep length of "Siren”. When settle down alarm
sounds and siren, please press "Done" at the top right of the page to return to the sensing feature
page.
Step 12. Select the Video
Record to the setting
page(shown below in red
frame)
Step 13. Set up “Video Save” to “Auto” mode or other device
for saving the 30 seconds video recording while alarm trigger.
95
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click <Security>
Step 2. Click <Door & Window
Sensor>
Step 3. Enter the alarm system
to the setting page.
Step 4. Select the Sensor Alarm
to the setting page(shown
below in red frame)
Step 5. Enter the Sensor Alarm
to adjust the system.
Step 6. Choose one the options
as you like to set up the alarm
type and time.
9.2.2 ZigBee Door & Window Sensor (DDLA0z)
96
Sapido Technology Inc. www.sapido.com.tw
Step 7. There are 5 types of different selectable beep length of "Sirens”. When settle down alarm
sounds and siren, please press "Done" at the top right of the page to return to the sensing feature
page.
Step 8. Select the Speaker to
the setting page(shown below
in red frame)
Step 9. Enter “Alarm Setting” to
adjust the system.
Step 10. Choose one of the
options as you like to set up
the alarm type and time.
97
Sapido Technology Inc. www.sapido.com.tw
Step 11. There are 5 types of different selectable beep length of "Sirens”. When settle down alarm
sounds and siren, please press "Done" at the top right of the page to return to the sensing feature
page.
Step 12. Select the Video
Record to the setting page
(shown below in red frame).
Step 13. Set up “Video Save” to “Auto” mode or other device
for saving the 30 seconds video recording while alarm trigger.
98
Sapido Technology Inc. www.sapido.com.tw
Step 1. Click “Upload”
Step 2. Click “My Files”
Step 3. Tick the files you
want to upload (ex: photos),
and click “Change” to select
the path.
Step 4. Select your device
name (nickname)
Step 5. Click “New Folder”
Step 6. Rename the folder,
such as “Photo”, and click
“Apply”
10. Application for Media Storage
10.1 Upload the files in mobile device to IP Camera USB drive
Besides saving the recording image, USB drive of IP Camera is a media storage center, you can
upload photos, videos and files, etc. in your mobile device to USB drive for expanding your
storage spaces, and share to you family members at the same time.
99
Sapido Technology Inc. www.sapido.com.tw
Step 7. Select new added
folder.
Step 8. Click “Upload”
Step 9. Uploading the files…
Step 10. Please click “Upload
more files” after upload
succeeded.
Step 11. Click “Back” to select
other files. (ex: video)
Step 12. APP will memorize
the path of last upload, click
“Upload” without changing
path, or click “Change” to
choose other path.
100
Loading...
