About this Guide

About this Guide
This guide is intended for business intelligence users who need to establish LiveCycle Data Services connections while working with Dashboard Design in corporate environments.
For more information about features and capabilities, see the
Design User Guide
.
Dashboard Design and Presentation
2010-10-015
About this Guide
2010-10-016

Planning Installations

Planning Installations
2.1 Getting started
2.1.1 Overview of the Dashboard Design LiveCycle Data Services Gateway
Dashboard Design is a data visualization tool that allows you to create dynamic, interactive dashboards. These dashboards access live data, and you can add them to web-based dashboards.
Adobe LiveCycle Data Services is a development framework that allows you to create rich Internet applications (RIA), establish communication interfaces, and share data sources between applications in real time.
You must install the Dashboard Design LiveCycle Data Services Gateway (XLCDS) on an Adobe LiveCycle Data Services (LCDS) server to establish LCDS connections within Dashboard Design.
2.2 Naming conventions
2.2.1 Variables
This guide uses the following variables.
2010-10-017
Planning Installations
DescriptionVariable
<MEDIADIR>
<LCDSDIR>
The directory where required files are located on the Dashboard Design media.
D:\AddOns\LiveCycle Data Services\Adobe
The directory where configuration files are located on your Adobe LiveCycle Data Services (LCDS) server by default.
C:\lcds\WEB-INF\
If you use LCDS with integrated JRun, the configuration files are located in the following directory:
C:\lcds\jrun4\servers\default\flex\WEB-INF
2010-10-018

Performing Installations

Performing Installations
3.1 To install the Dashboard Design LiveCycle Data Services Gateway
Before you install the Dashboard Design LiveCycle Data Services Gateway, ensure that your Adobe LiveCycle Data Services (LCDS) server is installed and configured. For more information, see the documentation in <MEDIADIR> on your installation media.
1.
Copy XLCDSServlet.class from <MEDIADIR>/classes/xcelsius/servlet to <LCDS DIR>/classes/xcelsius/servlet
2.
Copy Xcelsius-config.xml (the destination list) and Xcelsius-config.xsd (the destination list schema) from <MEDIADIR> to <LCDSDIR>
3.
Add <servlet> and <servlet-mapping> entries to <LCDSDIR>/web.xml
Note:
A sample web.xml file is included in <MEDIADIR>
Your LCDS Gateway is installed. Before you begin using the gateway, you must configure it.
Example: Adding an entry to web.xml
<servlet>
<servlet-name>XcelsiusServlet</servlet-name> <servlet-class>xcelsius.servlet.XLCDSServlet</servlet-class> <init-param>
<param-name>configuration.file</param-name> <param-value>/WEB-INF/Xcelsius-config.xml</param-value>
</init-param>
</servlet>
<servlet-mapping>
<servlet-name>XcelsiusServlet</servlet-name> <url-pattern>/xcelsius/*</url-pattern>
</servlet-mapping>
<destination>
<id>RandomNumbers</id> <description>Sample LCDS Feed</description> <metadata>
<field datatype="String" shape="Singleton">time</field> <field datatype="Short[]" shape="1D">column/row</field> <field datatype="Short[]" shape="2D">table</field>
</metadata>
</destination>
Related Topics
Variables
2010-10-019
Performing Installations
3.2 To configure the Dashboard Design LiveCycle Data Services Gateway
Before you begin to use the Dashboard Design LiveCycle Data Services Gateway, you must configure it by creating data destinations in your Adobe LiveCycle Data Services (LCDS) server. For more information, see the documentation in <MEDIADIR> on your installation media.
1.
Open Xcelsius-config.xml in a text editor.
2.
Add a <destination> entry for each LCDS destination that you want to expose to the Dashboard Design LCDS connection. Include the following elements for each entry:
<id> Corresponds to a valid LCDS destination defined in messaging-config.xml (the LCDS
Message Service configuration file).
<description> Provides details about the available data fields for the LCDS destination.
<metadata> Describes the type of field and how the field should be mapped when bound to a
Dashboard Design range.
Note:
Xcelsius-config.xsd (the XLCDS destination list schema) defines the exact structure of the XML in the file.
3.
Save your changes to Xcelsius-config.xml
Your LCDS Gateway is now configured.
Example: Adding an entry to Xcelsius-config.xml
<destination>
<id>RandomNumbers</id> <description>Sample LCDS Feed</description> <metadata>
<field datatype="String" shape="Singleton">time</field> <field datatype="Short[]" shape="1D">column/row</field> <field datatype="Short[]" shape="2D">table</field>
</metadata>
</destination>
You can now start your destinations and connect to them from Dashboard Design.
Related Topics
Variables
2010-10-0110

Post Installation

Post Installation
4.1 To test the Dashboard Design LiveCycle Data Services Gateway installation
You can use a random number generator to test your Dashboard Design LiveCycle Data Services Gateway installation. A sample generator is located in<MEDIADIR> on your installation media.
1.
Open Xcelsius-config.xml in a text editor.
2.
Add the following entry to the file:
<destination>
<id>RandomNumbers</id> <description>Sample LCDS Feed</description> <metadata>
<field datatype="String" shape="Singleton">time</field> <field datatype="Short[]" shape="1D">column/row</field> <field datatype="Short[]" shape="2D">table</field>
</metadata>
</destination>
3.
Save your changes to Xcelsius-config.xml
4.
Copy RandomNumberDataService.class and RandomNumberFeed.class from <MEDI ADIR>/classes/com/bobj/samples/lcds to <LCDSDIR>/classes/com/bobj/sam
ples/lcds
5.
Open <LCDSDIR>/flex/services-config.xml in a text editor.
6.
Add the following string into the <services> entry:
<service class="com.bobj.samples.lcds.RandomNumberDataService"
7.
Save your changes to services-config.xml
id="random-number-ds" />
You can now use the random number generator on your LCDS server.
To test the random number generator service, start your LCDS server (For example, if you use LCDS with integrated JRun, you can run C:\lcds\jrun4\bin\startJRun.bat)
When the LCDS server finishes initializing the server command prompt, it will begin to output strings similar to the following:
{table=[[I@18b9a72, column/row=[I@48bc64, time=07:07:35} {table=[[I@18b9a72, column/row=[I@48bc64, time=07:07:37}
Related Topics
Variables
2010-10-0111
Post Installation
4.2 To uninstall the Dashboard Design LiveCycle Data Services Gateway
To uninstall the Dashboard Design LiveCycle Data Services Gateway, you must delete the files that you have copied to Adobe LiveCycle Data Services (LCDS) server.
1.
Stop your LCDS server.
2.
Delete XLCDSServlet.class from <LCDSDIR>/classes/xcelsius/servlet
3.
Delete Xcelsius-config.xml (the destination list) and Xcelsius-config.xsd (the destination list schema) from <LCDSDIR>
4.
Delete the <servlet> and <servlet-mapping> entries from <LCDSDIR>/web.xml
Your LCDS Gateway is uninstalled.
You can now start your LCDS server.
Related Topics
Variables
To install the Dashboard Design LiveCycle Data Services Gateway
