SAP BusinessObjects Enterprise XI 4.0 Diagnostic Tool User's Guide

SAP BusinessObjects Enterprise Repository Diagnostic Tool User's Guide
SAP BusinessObjects Enterprise XI 4.0
2011-01-12
Copyright
© 2011 SAP AG. All rights reserved.SAP, R/3, SAP NetWeaver, Duet, PartnerEdge, ByDesign, SAP Business ByDesign, and other SAP products and services mentioned herein as well as their respective logos are trademarks or registered trademarks of SAP AG in Germany and other countries. Business Objects and the Business Objects logo, BusinessObjects, Crystal Reports, Crystal Decisions, Web Intelligence, Xcelsius, and other Business Objects products and services mentioned herein as well as their respective logos are trademarks or registered trademarks of Business Objects S.A. in the United States and in other countries. Business Objects is an SAP company.All other product and service names mentioned are the trademarks of their respective companies. Data contained in this document serves informational purposes only. National product specifications may vary.These materials are subject to change without notice. These materials are provided by SAP AG and its affiliated companies ("SAP Group") for informational purposes only, without representation or warranty of any kind, and SAP Group shall not be liable for errors or omissions with respect to the materials. The only warranties for SAP Group products and services are those that are set forth in the express warranty statements accompanying such products and services, if any. Nothing herein should be construed as constituting an additional warranty.
2011-01-12

Contents

Repository Diagnostic Tool.....................................................................................................5Chapter 1
Using the Repository Diagnostic Tool.....................................................................................7Chapter 2
2.1
2.2
Index 21
To use the Repository Diagnostic Tool.....................................................................................7
Repository Diagnostic Tool Parameters...................................................................................8
Inconsistencies between the CMS and the FRS...................................................................13Chapter 3
Inconsistences in the CMS metadata...................................................................................15Chapter 4
More Information...................................................................................................................19Appendix A
2011-01-123
Contents
2011-01-124

Repository Diagnostic Tool

Repository Diagnostic Tool
The Repository Diagnostic Tool (RDT) is a command-line tool that scans, diagnoses, and repairs inconsistencies that may occur between your Central Management Server (CMS) system database and the File Repository Servers (FRS) filestore, or inconsistencies that can occur in the metadata of InfoObjects stored in the CMS database.
During normal operations, it is unusual for the CMS system database to have inconsistencies. However, inconsistencies may occur during unexpected events such as disaster recovery, back-up restoration, or network outages. During these events, the CMS system database may be interrupted while performing a task. This can cause inconsistencies with objects in the CMS system database.
The RDT scans the CMS system database and identifies inconsistencies in such objects as reports, users, user groups, folders, servers, universes, universe connections, and other objects.
The RDT scans for two types of inconsistencies.
Object to file inconsistencies.
These are inconsistencies that can occur between InfoObjects in the CMS database and the corresponding files in the File Repositories. For example, a file that is stored in the FRS may be missing a corresponding object in the CMS system database.
InfoObject metadata inconsistencies.
These are inconsistencies that may exist in an InfoObject's object definition (metadata) in the CMS database. For example, an InfoObject may reference another InfoObject that does not exist in the CMS database.
The RDT peforms two functions, depending on the parameters that you provide when you run the tool:
It scans the CMS system database and FRS filestore, reports inconsistencies, and outputs a log file
in XML format with suggested actions to repair the inconsistencies.
It scans and repairs the inconsistencies identified in the CMS system database and FRS, and outputs
the actions taken to a log file in XML format.
2011-01-125
Repository Diagnostic Tool
2011-01-126

Using the Repository Diagnostic Tool

Using the Repository Diagnostic Tool
The Repository Diagnostic Tool (RDT) is available on any machine with a Central Configuration Manager (CCM) installed on it. This command-line tool scans, diagnoses, and repairs inconsistencies that may occur between the Central Management Server (CMS) system database and the File Repository Servers (FRS) filestore, or inconsistencies that may occur in an InfoObject's metadata.
Do not run the RDT against a live CMS database and FRS. Changes that your users make to the CMS or FRS while the RDT is running can create new inconsistencies in your deployment. Repair actions that the RDT takes while users are accessing your deployment can create further inconsistencies.
Instead, it is recommended that you back up your CMS database and FRS filestore, and run the RDT against the backed-up version while your SAP BusinessObjects Enterprise services are down.
The RDT does not require the CMS service to be running. The RDT runs directly against the CMS database.
2.1 To use the Repository Diagnostic Tool
1.
If you are running the tool on a Windows computer, open a command window and run the following command.
<INSTALLDIR>\SAP BusinessObjects Enterprise XI 4.0\win64_x64\reposcan.exe <arguments>, where <arguments> is the list of parameters that you want to specify.
2.
If you are running the tool on a UNIX computer, open a /usr/bin/sh compatible shell, and run the following command.
.<INSTALLDIR>/sap_bobj/enterprise_xi40/<platform>/boe_reposcan.sh <argu ments> where <platform> is either “linux_x64”, “solaris_sparcv9”, “hpux_ia64”, or “aix_rs6000_64”,
and <arguments> is the list of parameters that you want to specify.
The Repository Diagnostic Tool scans your repository for inconsistencies. Depending on the parameters that you specify, it either diagnoses and logs inconsistencies, or it repairs inconsistences and logs the action that it takes.
Repo_Scan_yyyy_mm_dd_hh_mm_ss.xml lists the inconsistencies that the tool finds. If you had the tool repair the discrepancies that it finds, it also creates the file Repo_Re pair_yyyy_mm_dd_hh_mm_ss.xml.
2011-01-127
Using the Repository Diagnostic Tool
The path to the log files can be specified by the outputdir parameter. If this parameter is not specified, the default directory for the log files is <INSTALLDIR>\SAP BusinessObjects Enterprise XI
4.0\reposcan on Windows, and ./sap_bobj/enterprise_xi40/reposcan on UNIX.
Note:
The application also provides a default XSL file that is used with the XML file to produce an HTML page. The XSL file is stored in <INSTALLDIR>\SAP BusinessObjects Enterprise XI 4.0\reposcan on Windows, and ./sap_bobj/enterprisexi_40/reposcan on UNIX
For a list of the warning messages and recommended actions that the RDT takes when it finds inconsistencies, see .
Related Topics
Inconsistences in the CMS metadata
Inconsistencies between the CMS and the FRS
Inconsistences in CMS metadata
and
Inconsistencies between the CMS and FRS
2.2 Repository Diagnostic Tool Parameters
The RDT accepts the parameters in the following table:
Note:
Command-line arguments override any parameter file entries while executing.
Table 2-1: General Parameters
Parameter
Optional or Mandatory
Mandatorydbdriver
Description
The type of driver used to connect to the CMS database. Accepted values are:
db2databasesubsystem
maxdbdatabasesubsystem
mysqldatabasesubsystem
oracledatabasesubsystem
sqlserverdatabasesubsystem
sybasedatabasesubsystem
2011-01-128
Using the Repository Diagnostic Tool
Parameter
Optional or Mandatory
Mandatoryconnect
Mandatoryinputfrsdir
Mandatoryoutputfrsdir
Description
The connection details that are used to connect to the CMS database.
For example: -connect
"UID=root;PWD=<pass word>;DSN=<dsn>;HOSTNAME=<host name>;PORT=<portnumber>"
The file path of the Input File Repository Server.
Note:
The user account you are logged on with is used to execute the command-line tool. It must have full control to the file location.
The file path of the Output File Repository Server.
Note:
The user account you are logged on with is used to execute the command-line tool. It must have full control to the file location.
The file path where the RDT writes the log files.
The default value is <INSTALLDIR>\SAP
Optionaloutputdir
BusinessObjects Enterprise XI
4.0\reposcan on Windows, and ./sap_bobj/enterprise_xi40/reposcan on
UNIX.
The number of approximate errors to scan. This helps ensure optimum performance. The upper
Optionalcount
count is 2e31 - 1. A value of 0 is interpreted as the entire repository.
The default value is 0.
Tells the RDT to repair all inconsistencies it may find. The default behavior is to only report inconsis-
Optionalrepair
tencies but not to perform any repairs. If the -repair paramater exists on the command line, the RDT reports and repairs all inconsistencies.
2011-01-129
Using the Repository Diagnostic Tool
Parameter
Optional or Mandatory
Optionalscanfrs
Optionalscancms
Optionalsubmitterid
Description
Specifies whether the RDT scans the CMS and FRS for inconsistencies. Acceptable values are True and False.
The default value is True.
Specifies whether the RDT scans the CMS for incon­sistencies between InfoObjects. Acceptable values are True and False.
The default value is True.
Specifies the User ID to replace missing or invalid IDs for scheduled objects. If no value is provided, the RDT does not replace the invalid IDs. If the provided User ID doesn't exist in the CMS, the RDT prompts for a valid ID.
This parameter is only used when the RDT operates in repair mode.
Specifies the object in the CMS database to start the scan for. For example, if you've already scanned
Optionalstartid
the first 500 objects in your repository, you can set
-startid=501 to start a new scan at the 501st object.
The default value is 1.
Specifies the file path to a parameter file. The pa­rameter file is a text file that lists each command­line option and its values. The file should have one parameter per line.
Optionaloptionsfile
Note:
With this option, you can set all parameters in a Text file as described above. Use this option to point to the parameter file without entering the parameters on the command-line.
The following parameters are used if the Repository Diagnostic Tool is running on an active clustered CMS.
2011-01-1210
Using the Repository Diagnostic Tool
Table 2-2: Using the RDT against a clustered CMS
Parameter
Optional or Mandatory
Optionalrequestport
Optionalnumericip
Optionalipv6
Description
The port number that the RDT uses to commu­nicate to the CMS. Accepts whole, positive numbers. By default, the tool uses the value from the operating system of the machine that the RDT is running on.
Whether the RDT uses the numeric IP address instead of the hostname for communication between the CMS and the machine that the RDT is running on. Acceptable values are True and False.
The default value is False.
The ipv6 name of the machine that the RDT is running on. Accepts a string.
The default value is the hostname of the ma­chine that the RDT is running on.
The ipv4 name of the machine that the RDT is running on. Accepts a string.
Optionalport
The default value is the hostname of the ma­chine that the RDT is running on.
The number of threads to use. Accepts whole,
Optionalthreads
positive numbers.
The default value is 12.
The following parameters are used when the RDT uses SSL to communicate with the CMS database that it scans.
2011-01-1211
Using the Repository Diagnostic Tool
Table 2-3: Using the RDT with SSL
Parameter
Optional or Mandatory
Optionalprotocol
Optionalssl_certdir
Optionalssl_trustedcertificate
Optionalssl_mycertificate
Optionalssl_mykey
Optionalssl_mykey_passphrase
Description
Specifies whether the tool should run in SSL mode.
The only accepted value is ssl.
The directory that contains the SSL certificates.
The file name of the certificate.
The file name of the signed certificate.
The file name of the file that contains the pri­vate SSL key.
The file name of the file that contains SSL passphrase.
Example:
The following example scans the CMS and FRS for both kinds of inconsistencies, and repairs the inconsistencies that it finds.
reposcan.exe
-dbdriver mysqldatabasesubsystem
-connect “UID=root;PWD=Password1;DSN=myDsn;HOSTNAME=myHostname;PORT=3306
-repair
-inputfrsdir“C:\Program Files (x86)\SAP BusinessObjects\SAP BusinessObjects Enterprise XI 4.0\FileStore\Input”
-outputfrsdir “C:\Program Files (x86)\SAP BusinessObjects\SAP BusinessObjects Enterprise XI
4.0\FileStore\Output”
2011-01-1212

Inconsistencies between the CMS and the FRS

Inconsistencies between the CMS and the FRS
The following table describes the inconsistencies that may between a Central Management Server (CMS) data base and the File Repository Servers (FRS) that are recognized by the Repository Diagnostic Tool (RDT). The table has 4 columns:
Warning Message
The warning message that is written to the scan and repair log files.
Inconsistency
An explanation of the inconsistency that the RDT finds for the object.
Recommendation
The recommended action that the RDT should take when it finds an inconsistency. This is found in the scan log file.
Action
The action that the RDT takes to repair an inconsistency. This is found in the repair log file.
2011-01-1213
Inconsistencies between the CMS and the FRS
ActionRecommendationInconsistencyWarning Message
<Object Name> object <Object Type> (Object
ID: <ID>) is referencing some files that do not exist in the FRS (<File Name>)
<File Name> exists in the Input or Output FRS, but there is no corresponding InfoObject in the repository.
<Object Type> Object <Object Name> (Object ID <ID>) has a file size <Size>. The stored file size
is <Size> which does not match the actual file size
<Size>.
<Folder Path> contains
no files.
The object exists in the CMS database, but there is no corresponding file in the FRS.
The file exists in the FRS, but there is no correspond­ing file in the CMS database.
The size of the file does not match the InfoObject file size.
The FRS folder is empty.
“Allow the application to remove the missing files from the object's file list.”
“Please republish the file. The application will not publish this file for you.”
“Allow the application to update the object with the correct file size.”
“Allow the application to remove the directo­ry.”
The RDT removes the object from the CMS database.
When you republish the file, an object is created in the CMS database.
The RDT updates the file size in the CMS database.
The RDT removes the empty directory.
2011-01-1214

Inconsistences in the CMS metadata

Inconsistences in the CMS metadata
The following table describes the inconsistencies that can occur in the metadata of the objects that are in a Central Management Server (CMS) system data base that are recognized by the Repository Diagnostic Tool (RDT). The table has 4 columns:
Warning Message
The warning message that is written to the scan and repair log files.
Inconsistency
An explanation of the inconsistency that the RDT finds for the object.
Recommendation
The recommended action that the RDT should take when it finds an inconsistency. This is found in the scan log file.
Action
The action that the RDT takes to repair an inconsistency. This is found in the repair log file.
2011-01-1215
Inconsistences in the CMS metadata
ActionRecommendationInconsistencyWarning Message
<Object Type> Object <Object Name> (Object ID: <Object Name><ID>)'s parent ob-
ject is missing (Parent Object ID = <ID>).
<Object Type> Object <Object Name> (Object
ID: <ID>)'s owner object is missing (Owner Object ID = <ID>).
<Object Type> Object <Object Name> (Object
ID: <ID>)'s submitter ob­ject is missing (Submitter Object ID = <ID> ).
The object has a missing or invalid Parent Object ID.
The object has a missing or invalid Owner Object ID.
The object has a missing or invalid Submitter Object ID.
“Allow RDT to move the object to the BO Repair folder. ”
“Allow the RDT to assign the object to the Adminis­trator. ”
The recommendation that the RDT displays depends on whether you've provid­ed a value for the -submit­terid parameter.
If you provide this pa-
rameter, the recom­mendation is “Allow the application to up­date the object with the provided submitter ID”.
If you don't provide this
parameter, the recom­mendation is “ Reschedule the object or submit a user ID to use to replace the in­valid submitter ID”.
The RDT moves the ob­ject and any child objects to a repair folder. Only the administrator has access to this folder.
The RDT assigns the val­ue of the Administrator's ID to the objects Owner ID.
If you provide a value from the -submitterid parame­ter, the RDT applies the value for the object's sub­mitter ID.
If you don't provide a val­ue for this parameter, the RDT takes no action. When you reschedule the object, the CMS applies a new ID.
<Object Type> Object '<Object Name>' (Object ID: <ID>)'s last success­ful instance property refers to a missing object (Object ID = <ID>).
The object's last sucessful instance is missing or invalid.
“Allow the application to recalculate the property.”
When you reschedule the object, the CMS automati­cally recalculates the ID.
2011-01-1216
Inconsistences in the CMS metadata
ActionRecommendationInconsistencyWarning Message
<Object Type> Object '<Object Name>' (Ob­ject ID: <ID>)'s calendar object is missing (Calen­dar ID = <ID>).
<Object Type> Object '<Object Name>' (Object ID: <ID>) 's required scheduling server group is missing (Server Group Object ID = <ID>)..
<Object Type> Object '<Object Name>' (Object ID: <ID>)'s list of events to wait for contains miss­ing object(s) (Object ID(s) = <ID>).
<Object Type> Object '<Object Name>' (Object ID: <ID>)'s list of events to trigger contains missing object(s) (Object ID(s) = <ID>).
The object refer­ences a calendar that doesn't exist.
The preferred serv­er does not exist.
The event or events that this object is waiting on does not exist.
This object triggers an event that does not exist.
“Reschedule the object with an existing calendar. No action can be taken by this application.”
“ Reschedule the object and choose an existing server group. No action can be taken by this appli­cation.”
“Allow the application to remove the missing events from the object's list of events to wait for.”
“Allow the application to remove the missing events from the object's list of events to trigger.”
When you reschedule the object, the CMS applies a calendar to the object.
When you reschedule the object, the CMS applies a server group to the object.
The RDT removes the missing events.
The RDT removes the missing events.
2011-01-1217
Inconsistences in the CMS metadata
ActionRecommendationInconsistencyWarning Message
<Object Type> Object '<Object Name>' (Object ID: <ID>) Access Control List references a missing principal (Object ID =
<ID>).
<Object Type> Object
'<Object Name>' (Object ID: <ID>) has invalid Server Group entries
<Server Group Entries>.
<Object Type> Object <Object Name> (Object
ID: <ID>) has multiple Favorites folders.
Orphaned Access Control entry.
The preferred serv­er does not exist.
A specific user ac­count has multiple favorites folders.
“ Allow the application to remove the missing princi­pal(s) from the object's Access Control List.”
“Allow the tool to remove the object's invalid entries from its Server Group list.”
“Allow the application to consolidate multiple Fa­vorites folders into a sin­gle Favorites folder.”
The RDT removes the missing principal(s).
The RDT removes the ob­jects missing entries from the object's server group list.
The RDT consolidates the user's Favorites folders into a single folder.
2011-01-1218

More Information

More Information
LocationInformation Resource
SAP BusinessObjects product infor­mation
SAP Help Portal
SAP Service Marketplace
http://www.sap.com
Navigate to http://help.sap.com/businessobjects and on the "SAP Busi­nessObjects Overview" side panel click All Products.
You can access the most up-to-date documentation covering all SAP BusinessObjects products and their deployment at the SAP Help Portal. You can download PDF versions or installable HTML libraries.
Certain guides are stored on the SAP Service Marketplace and are not available from the SAP Help Portal. These guides are listed on the Help Portal accompanied by a link to the SAP Service Marketplace. Customers with a maintenance agreement have an authorized user ID to access this site. To obtain an ID, contact your customer support representative.
http://service.sap.com/bosap-support > Documentation
Installation guides: https://service.sap.com/bosap-instguides
Release notes: http://service.sap.com/releasenotes
The SAP Service Marketplace stores certain installation guides, upgrade and migration guides, deployment guides, release notes and Supported Platforms documents. Customers with a maintenance agreement have an authorized user ID to access this site. Contact your customer support representative to obtain an ID. If you are redirected to the SAP Service Marketplace from the SAP Help Portal, use the menu in the navigation pane on the left to locate the category containing the documentation you want to access.
Docupedia
Developer resources
https://cw.sdn.sap.com/cw/community/docupedia
Docupedia provides additional documentation resources, a collaborative authoring environment, and an interactive feedback channel.
https://boc.sdn.sap.com/
https://www.sdn.sap.com/irj/sdn/businessobjects-sdklibrary
2011-01-1219
More Information
LocationInformation Resource
SAP BusinessObjects articles on the SAP Community Network
Notes
Forums on the SAP Community Network
Training
Online customer support
https://www.sdn.sap.com/irj/boc/businessobjects-articles
These articles were formerly known as technical papers.
https://service.sap.com/notes
These notes were formerly known as Knowledge Base articles.
https://www.sdn.sap.com/irj/scn/forums
http://www.sap.com/services/education
From traditional classroom learning to targeted e-learning seminars, we can offer a training package to suit your learning needs and preferred learning style.
http://service.sap.com/bosap-support
The SAP Support Portal contains information about Customer Support programs and services. It also has links to a wide range of technical in­formation and downloads. Customers with a maintenance agreement have an authorized user ID to access this site. To obtain an ID, contact your customer support representative.
Consulting
http://www.sap.com/services/bysubject/businessobjectsconsulting
Consultants can accompany you from the initial analysis stage to the delivery of your deployment project. Expertise is available in topics such as relational and multidimensional databases, connectivity, database design tools, and customized embedding technology.
2011-01-1220

Index

R
repository diagnostic tool
inconsistencies
diagnose and repair 5 object to file 5
repository diagnostic tool
inconsistencies
scenarios 5 overview 5 parameters 7
(continued)
(continued)
repository diagnostic tool
table of inconsistencies
recommendations 13, 15
using
Windows and Unix 7
(continued)
2011-01-1221
Index
2011-01-1222
Loading...
