Sanyo MVP85 User Manual

INSTRUCTION MANUAL

MVP-85

Quad Compressor

Compresseur quadruplex

Compresor cuádruple

English GB

Français F

Español E

About this manual

• Before installing and using this unit, please read this manual

carefully. Be sure to keep it handy for later reference.

À propos de ce manuel

• Avant d’installer et d’utiliser cet appareil, veuillez lire ce

manuel attentivement. Assurez-vous de le garder à portée
de la main pour référence ultérieure.

Acerca de este manual

• Antes de instalar y usar este aparato, lea detenidamente

este manual. Asegúrese de guardarlo a mano para futuras
referencias.

PRECAUTION

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: To reduce the risk of fire or electric
shock, do not expose this appliance to rain or
moisture.

CAUTION: Changes or modifications not expressly
approved by the manufacturer may void the user’s
authority to operate this equipment.

The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.

The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.

This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generated, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by
one or more of the following measures:

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different

•

from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

•

For the customers in Canada

This class B digital apparatus complies with Canadian
ICES-003.

CAUTION

Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Discard used batteries according to the manufacture’s
instructions.

Declaration of Conformity

Model Number : MVP-85
Trade Name : SANYO
Responsible party : SANYO FISHER COMPANY
Address : 21605 Plummer Street,

Chatsworth, California 91311

Telephone No. : [phone]

• This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,

and

(2) this device must accept any interference

received, including interference that may
cause undesired operation.

Location

For safe operation and satisfactory performance of your
unit, keep the following in mind when selecting a place for
its installation:

Shield it from direct sunlight and keep it away from

•

sources of intense heat.
Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper heat

•

dissipation. Do not block the ventilation holes at the top
and bottom of the unit. Do not place the unit on a
carpet because this will block the ventilation holes.

Install the unit in a horizontal position only.

•

Avoid locations subject to strong vibrations.

•

Avoid moving the unit between cold and hot locations.

•

Do not place the unit directly on top of a monitor TV, as

•

this may cause playback or recording problems.

Avoiding Electrical Shock and Fire

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting it

•

from an AC wall outlet. Grasp it by the plug.
If any liquid is spilled on the unit, unplug the power

•

cord immediately and have the unit inspected at a
factory-authorised service centre.

Do not place anything directly on top of this unit.

•

SERVICE

This unit is a precision instruments and if treated with
care, will provide years of satisfactory performance.
However, in the event of a problem, the owner is advised
not to attempt to make repairs or open the cabinet.
Servicing should always be referred to your dealer or
Sanyo Authorized Service Centre.

English 1

CONTENTS

FEATURES

PARTS NAMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

REAR PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

RECORDING LIVE PICTURES IN QUAD
SCREEN DISPLAY MODE ONLY

CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

REMOTE CONTROLLER CIRCUIT

CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

INSTALLING THE RACK MOUNTING

BRACKETS (SOLD SEPARATELY) . . . . . . . . . . . 6

BASIC OPERATIONS . . . . . . . . . . . . . . . . . . . . . . . 7

MODE SWITCHING . . . . . . . . . . . . . . . . . . . . . . . . . .7

SECURITY LOCK FUNCTION . . . . . . . . . . . . . . . . .8

SETTINGS BACKUP FUNCTION . . . . . . . . . . . . . . .8

RESET FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . .8

LIVE PICTURE MODE . . . . . . . . . . . . . . . . . . . . . . 9

LIVE PICTURE MODE OPERATIONS STEPS . . . . .9

QUAD SCREEN OPERATIONS . . . . . . . . . . . . . . .10

FULL SCREEN OPERATIONS . . . . . . . . . . . . . . . .13

VCR PLAYBACK MODE . . . . . . . . . . . . . . . . . . . . 14

QUAD SCREEN OPERATIONS . . . . . . . . . . . . . . .14

FULL SCREEN OPERATIONS . . . . . . . . . . . . . . . .14

MENU SETTING MODE . . . . . . . . . . . . . . . . . . . . 15

LANGUAGE SETTING . . . . . . . . . . . . . . . . . . . . . .16

CLOCK AND DAYLIGHT SAVING SETTING . . . . .17

CAMERA TITLE SETTING . . . . . . . . . . . . . . . . . . .18

ALARM SETTING . . . . . . . . . . . . . . . . . . . . . . . . . .19

VIDEO SENSOR SETTING . . . . . . . . . . . . . . . . . . .20

VIDEO SENSOR ALARMS . . . . . . . . . . . . . . . . . . .20

TIMER SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . .21

CLOCK, TITLE DISPLAY AND MONITOR

SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

VCR SIGNAL SETTING AND COMPUTER

CONTROL SETTING . . . . . . . . . . . . . . . . . . . . . . . .25

ALARM DATA DISPLAY . . . . . . . . . . . . . . . . . . . . .26

SETTING UP THE VCR SIGNAL OUTPUT

(SW IN) AUTOMATIC SWITCHING SPEED . . . . 26

ALARMS OPERATIONS . . . . . . . . . . . . . . . . . . . . 27

EXTERNAL ALARMS . . . . . . . . . . . . . . . . . . . . . . .27

VIDEO LOSS ALARM . . . . . . . . . . . . . . . . . . . . . . .27

VIDEO SENSOR ALARMS . . . . . . . . . . . . . . . . . . .27

RS232C CONTROL . . . . . . . . . . . . . . . . . . . . . . . . 28

CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

INTERFACE SPECIFICATIONS . . . . . . . . . . . . . . .28

COMMANDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 32

Date/Time function
Up to 10 characters title function

Title and time display can be turned on/off

•

Title and time display position can be selected

•

Up to 100 alarm recordings log on-screen display
Timer function allowing to record only when necessary (night

and/or day) for each camera

Sequential speed for each camera can be adjusted

•

Important cameras to be displayed in quad screen can be

•

selected

Video loss warning function that can switch the display to
colour bars or to a frozen image

3 alarm functions
External alarm, video loss alarm, video sensor alarm

Security lock function
Computer control function using an RS232C connection

ACCESSORIES

Power cord x1

Fixer
Power cord tie x1

Rack mounting brackets
bolts x4

2 English

PARTS NAMES

FRONT PANEL

1

POWER

1 2 65 8743

STILL ZOOM

EXIT NEXT

SEQUENCE QUAD LIVE VCR MENU

F2 3456789

ALL RESET

MENU RESET

G

This unit is not equipped with a power switch. The power is turned on/off when the supplied power cord is connected/disconnected at
the power source.

1 POWER indicator
2 Camera select buttons and camera indicators

Use these buttons to select the picture from the
corresponding camera. When a camera is selected, the
corresponding indicator will light.

3 STILL button and indicator

In live picture quad screen display mode, press this button
to set the freeze mode.

4 ZOOM button and indicator

In live picture quad screen display mode, press this button
to set the 2x zoom in mode.

7 LIVE button and indicator

Press this button to select the live input mode.

8 VCR button and indicator

Press this button to select the VCR playback input mode.

9 MENU button (see page 7)

Press this button to display the menus. Press repeatedly to
select the different menus in order. Buttons 3 to 8 are
used for menu control.

F ALL RESET button (see page 8)
G MENU RESET button (see page 8)

5 SEQUENCE button and indicator

Press this button for an automatic sequential quad screen
or full screen display of the pictures.

6 QUAD button and indicator

In live picture mode, press this button repeatedly to switch
between quad screens A and B.

English 3

PARTS NAMES

REAR PANEL

156

15263748

CAMERA

23 4

VIDEO OUT

VCR

QUAD

IN

FULL

1 CAMERA input terminals (1 – 8)
2 VCR IN (Video cassette recorder input) terminal
3 VCR OUT QUAD FULL (Video signal output) terminal

Output in quad screen and full screen display modes.

4 VCR OUT QUAD ONLY (Video signal output) terminal

Output only in quad screen display mode.
However, the output display mode at this terminal can be

switched from quad screen mode only to quad screen and
full screen display modes (see (MONITOR SET) on page
22, and Tables 1 and 2 on pages 23 and 24).

5 RS232C (RS-232C) terminal

To control this unit using a personal computer, connect the
computer serial terminal to this terminal using a 9-pin
D-SUB cable (sold separately).

6 CONTROL terminal
7 Battery compartment
8 Power cord holder

Using the supplied tie, attach the power cord to the holder
as illustrated.

9 AC Power socket

Insert the power cord female plug firmly into this socket.
When the other plug of the power cord is connect to a live
power source, the POWER indicator on the front panel will
light.

QUAD
ONLY

(RS232C terminal)

Pin No. Signal Function Signal direction

1 –– –
2 RXD Data reception Computer →This unit
3 TXD Data transmission This unit → Computer
4 DTR Normally “H”
5 GND Common –
6 –– –
7 –– –
8 CTS No reception This unit → Computer
9 –– –

(CONTROL terminal)

Pin Signal
RC Remote input

C Common

SW Switching input (DC 5V)

C Common

AL Alarm input (DC 5V)

C Common

1 Alarm input 1
2 Alarm input 2
3 Alarm input 3
4 Alarm input 4
5 Alarm input 5
5 Alarm input 6
7 Alarm input 7
8 Alarm input 8

CONTROL

RS232C

RCCSWCAL

C12345678

7

9876

89

54321

4 English

CONNECTION

07

03

04

01

02

07

03

01

Before making any connection, make sure all the devices are turned off.
Before making the connections, please refer to the instruction manual accompanying each device.

If the devices are not connected properly, that may cause a fire and/or damages.

RECORDING LIVE PICTURES IN QUAD SCREEN DISPLAY MODE ONLY CONNECTIONS

01 05 02 0601 05 02 06

06

0601 05 02 0601 05 02 06

010101

01

01 02

03 04

02

04

050505

050505 060606

07 08080803

07

Monitor (sold separately)

12

34

External alarm sensors

(door bell, interphone, etc.)

Live pictures in
quad screen/full
screen display

CAMERA

152 3 74 8

3

6

Monitor (sold separately)

12

34

For playback in

quad screen only

01 02

01

02

04

03 04

Video input
terminal

050505 060606

07 08080803

07

Video output

terminal

VCRINVIDEO OUT

QUAD
FULL

QUAD
ONLY

Timelapse VCR (sold separately)

Video input
terminal

CONTROL

RS232C

SW AL

RC

CC

C 12345678

Alarm input
terminal

Common

Common
Switching output
terminal

English 5

CONNECTION

C

REMOTE CONTROLLER CIRCUIT CONNECTIONS

Use the layout below to make a remote controller and make the connections to the remote input pins (RC, C) of the
CONTROL terminal as indicated. This will permit remote controlled operation of this unit. (make contact LOW input)

1.8kΩ

SW 9

: Still image

2.2kΩ

SW 10

: Zoom

3.3kΩ

SW 11

: Camera sequential
display

4.7kΩ

SW 12

: Quad screen

7.5kΩ

SW 13

: VCR playback

13kΩ

SW 14

: Live picture

27kΩ

SW 15

: Menu selection

ONTROL

RS232C

RCCSWCAL

C12345678

SW: switch

220Ω

SW 1: Camera 1

220Ω

SW 2: Camera 2

300Ω

SW 3: Camera 3

360Ω

SW 4: Camera 4

470Ω

SW 5: Camera 5

680Ω

SW 6: Camera 6

820Ω

SW 7: Camera 7

1.2kΩ

SW 8: Camera 8

INSTALLING THE RACK MOUNTING BRACKETS (SOLD SEPARATELY)

To mount this unit onto a rack, please use the rack mount hardware (model VA-RACMK 1) sold separately.

1 Insert the head of two of the supplied bolts into the

keyhole opening on the side of the unit.

Insert the head of the bolt in the larger side, then slide it to
the smaller side of the opening.

1

2 Align the slot on the mounting bracket with the two

bolts.

Make sure the bolts have not moved from their position,
then place a flat washer, a locking washer, and fix with a
nut.

NOTE:

Make sure to use the bolts provided with this unit, as the
bolts provided with the rack mount hardware are too short.

3 Install the second mounting bracket on the opposite

side, then attach the unit onto the rack using the rack
mount bolts.

2

3

6 English

BASIC OPERATIONS

MODE SWITCHING

When the unit is connected to a power source, the default display mode will be: live picture from the four cameras 1 – 4 in a
quad screen. You can use the VCR, LIVE and MENU buttons to switch to the desired mode (see below for further information).

LIVE picture mode VCR playback mode LIVE picture mode Menu mode

(LANGUAGE/LANG./IDIO.)

ENGLISH

FRANCAIS

ESPANOL

Power on

VCR

Live Picture Mode (see page 9)

When the LIVE button is pressed, the live (direct) picture from
cameras 1 – 4 connected to the camera input terminals on the
unit rear panel, will be displayed. While in live picture mode you
can use the still and zoom functions.

NOTE:

The unit will automatically start in the live picture or VCR

•

playback display mode (quad screen or full screen display)
last selected. Therefore, when a mode is selected, the
display mode will remain the same.

In quad screen mode, if a camera is not connected at one of

•

the input terminals, “NO VIDEO” will be displayed on the
monitor screen.

NO VIDEO

NO VIDEO

NO VIDEO

NO VIDEO

VCR Playback Mode (see page 14)

Start playback on the VCR. If the video signal is correctly
recorded, the VCR playback image will be displayed when the

VCR button is pressed.

MENULIVE

Menu Setting Mode (see page 15)

Press the MENU button to display the menu. The buttons used
for menu control are indicated below.

Menu control buttons

STILL ZOOM

EXIT NEXT

SEQUENCE QUAD LIVE VCR MENU

ALL RESET

MENU RESET

1 23 4

1 EXIT (STILL) button

To exit the menu mode.

2 NEXT (ZOOM) button

To select a sub-menu in order to set the title position, etc. Press
the NEXT button to switch between the menu and the sub-menu.

3 +, – (QUAD, SEQUENCE) buttons … Press repeatedly

Use these buttons to select numbers, letters, symbols.

+ button: for forward selection

•

– button: for backward selection

•

4 c, l (VCR, LIVE) button … Press repeatedly

Use these buttons to move the cursor to the right or down.

c button: will move the cursor towards the right.

•

l button: will move the cursor down.

•

English 7

BASIC OPERATIONS

SECURITY LOCK FUNCTION

This function lets you lock the camera live picture mode or VCR
playback mode, so that it cannot be switched to another mode.

Security lock

Press the LIVE or the VCR button for about 3 seconds.

The buzzer will be heard and all the buttons will be locked. If a
button is pressed by mistake, the buzzer is heard and the
corresponding function will not operate.

LIVE

VCR

or

Canceling the Security Lock

To cancel the security lock, press the same (LIVE or VCR)
button again for about 3 seconds. A buzzer will be heard and the
mode will be unlocked.

SETTINGS BACKUP FUNCTION

This unit is equipped with a backup battery (lithium battery) to
maintain the clock settings. When the unit is used under normal
conditions, the backup battery is recharged. The battery is fully
recharged after a minimum of about 30 hours, and will maintain
the clock settings for up to 30 days.

NOTE: The settings may not be maintained properly if the

backup battery has been recharged for less than 30
hours when the power goes off.

Battery Life

If the power is turned off for about one hour or more, when the
power is restored, the (CLOCK SET) menu is displayed so the
clock settings can be checked.

If the clock settings are reset to: 01-01-2000 SAT 00:00:00, that
may indicate that the battery is dead and must be replaced.

RESET FUNCTION

The menus can be reset or cleared.

LIVE VCR MENU

Using the MENU RESET Button

A: While a menu is displayed, press the MENU RESET button

to reset all the values of the displayed menu to the default
values.

B: If no menu is displayed, press the MENU RESET button to

reset the time to the nearest hour.

NOTE: For example, between 10:30:00 and 11:29:59 the

clock will be reset to 11:00:00.

Using the ALL RESET button

Press this button to reset the following:

Reset the time and date in the (CLOCK SET) menu to the

•

default setting.
The display will return to the default quad screen display

•

mode.

NOTE: If the unit does not function properly, press the

ALL RESET button.

Please note that all the settings mentioned above
will be reset.

ALL RESET

MENU RESET

Replacing the Battery

To replace the battery, please consult your dealer. After the
battery has been replaced, press the ALL RESET button, then
in the (CLOCK SET) menu set the date and time (see page 17).

Depending on the battery usage it may become necessary to
change it. For replacement and disposal of the old battery,
please contact your dealer.

8 English

LIVE PICTURE MODE

07

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

Z4

01

02

03

01

02

SZ4

07

(VIDEO OUT QUADFULL)
Operations with the monitor connected
to the VIDEO OUT QUADFULL
terminal.

LIVE

12

34

VIDEO OUT

QUAD

QUAD

FULL

ONLY

Press the LIVE button.

The live pictures from the cameras connected to the CAMERA terminals (1 – 4) on the unit
back panel will be displayed.

Refer to the diagrams below for the buttons to press in order to select the desired operation
mode.

LIVE PICTURE MODE OPERATIONS STEPS

b Automatic switching between quad screen A and B

SEQUENCE

(Quad screen A)

01 02

01

03

03 04

02

050505 060606

04

07 080808

07

LIVE

01 02

01

03

03 04

QUAD

02

04

(Quad screen B)

050505 060606

07

07 080808

STILL

ZOOM

ZOOM

4

01 02

01

03

03 04

4

01 02

01

4

4

03

03 04

01

01 02

03

03 Z4

040404

02

04

02

04

02

Z4

SEQUENCE

STILL

S4S4S4

Z4Z4Z4

4

01

01 02

03

03

010101

02

SZ4

SZ4

b Selecting the quad screens A and B displayed cameras (☞ 21)

Settings entered in the (TIMER SET) menu.

b Automatic sequential switching speed (delay) set for each camera (☞ 21, 22)

Settings entered in the (TIMER SET) and the (MONITOR SET) menus.

English 9

04

02

07

03

04

03

04

01

02

07

03

04

01

02

05

07

07

05

07

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

QUAD SCREEN OPERATIONS (Live picture)

Press the QUAD button once.

01 02

01 02

03 04

03 04

QUAD QUAD

01

01 02

03

03 04

02

04

070707 080808

03

03 04

070707 080808

SEQUENCE

04

(TIMER SET)
TIME 00:00 00:00
SEQ. QUAD SEQ. QUAD
CAM1 T1 OFF T1 ON
CAM2 T1 OFF T1 ON
CAM3 T1 OFF T1 ON
CAM4 T1 OFF T1 ON
CAM5 T1 ON T1 OFF
CAM6 T1 ON T1 OFF
CAM7 T1 ON T1 OFF
CAM8 T1 ON T1 OFF

Camera number

Example 3:
Set the cameras to
be ON/OFF during

Example 2:

the night.

Set the cameras to be ON/OFF
during the day.

050505 060606

07

07 080808

The camera select indicators (1 – 4) light and quad screen A is displayed.
Press the QUAD button one more time to switch to quad screen B.

NOTE: The quad screen (A or B) last selected is memorised and will be selected first

when switching to quad screen mode again.

Sequential display of quad screen A and quad screen B at
1 second interval

Press the SEQUENCE button.

Quad screen A and quad screen B are displayed sequentially at 1 second interval.
The camera select indicators (1 – 4, 5 – 8) light sequentially according to the
displayed quad screen.

NOTE:

The sequential display speed (screen interval) is set to 1 second in the (MONITOR
SET) menu. The sequence speed setting can be set as desired, refer to “QUAD SEQ.

TIMER” on page 22.

Selecting the quad screens A and B displayed cameras

TIMER SETTING: see page 21

Example 1:

CAMERA 1: ON CAMERA 5: ON
CAMERA 2: ON CAMERA 6: ON
CAMERA 3: ON CAMERA 7: ON
CAMERA 4: ON CAMERA 8: ON

Example 2:

CAMERA 1: OFF CAMERA 5: ON
CAMERA 2: OFF CAMERA 6: ON
CAMERA 3: OFF CAMERA 7: ON
CAMERA 4: OFF CAMERA 8: ON

Example 3:

CAMERA 1: ON CAMERA 5: OFF
CAMERA 2: ON CAMERA 6: OFF
CAMERA 3: ON CAMERA 7: OFF
CAMERA 4: ON CAMERA 8: OFF

Example 4:

CAMERA 1: OFF CAMERA 5: OFF
CAMERA 2: OFF CAMERA 6: OFF
CAMERA 3: OFF CAMERA 7: OFF
CAMERA 4: OFF CAMERA 8: OFF

NOTE:

When the timer is set, the quad screen will be selected according to the day/night

•

settings.
When the timer is not set, the day setting quad screen will be selected.

•

(Quad screen A) (Quad screen B)

01

01 02 05

03 04

05

05 060606

07 080808

07

01

01

01

01 02

01 02

01 02

03 04

03

03 04

03

03 04

03

01

01

01

01 02

01 02

01 02

03 04

03

03 04

03

03 04

03

02

04

02

02

02

04

04

04

02

02

02

04

04

04

050505 060606

05 060606

07

07

07 08080803

07 080808

050505 060606

07 080808

07

01

01

01

01 02

01 02

01 02

03

03 04

03

03 04

03

03 04

01

01

01

01 02

01 02

01 02

03

03 04

03

03 04

03

03 04

02

02

02

04

04

04

02

02

02

04

04

04

10 English

QUAD SCREEN OPERATIONS (Live picture)

Example: To freeze the image from camera 4

1 Press the STILL button.

The STILL indicator flashes and the still image display mode is selected.

2 Press the camera select 4 button.

The camera 4 indicator flashes, the image from camera 4 is frozen, and “S”

STILL

4

flashes on-screen.

☞ To cancel the still image display mode

Press the camera select 4 button one more time, then press the STILL button.

Example: To zoom in the image from camera 4

1 Press the ZOOM button.

The ZOOM indicator flashes and the zoomed in image display mode is selected.

2 Press the camera select 4 button.

The camera 4 indicator flashes, the image from camera 4 is zoomed in, and “Z”

ZOOM

4

flashes on-screen.

☞ To cancel the zoomed in image display mode

Press the camera select 4 button one more time, then press the ZOOM button.

ZOOM

STILL

Example: To freeze the zoomed in image from camera 4

1 Press the ZOOM button.

The ZOOM indicator flashes and the zoomed in image display mode is selected.

2 Press the camera select 4 button.

4

The camera 4 indicator flashes, the image from camera 4 is zoomed in, and “Z”
flashes on-screen.

3 Press the STILL button.

The STILL indicator flashes and the ZOOM indicator lights.

4 Press the camera select 4 button.

The camera 4 indicator flashes, the zoomed in image from camera 4 is frozen,
and “SZ” flashes on-screen.

4

NOTE: To use the zoom function again, first cancel the still image display mode.

☞ To cancel the still and zoomed in image display mode.

Press the camera select 4 button, then press the STILL button.
Press the camera select 4 button, then press the ZOOM button.

☞ To cancel all the still image displays and zoomed in image displays

Press the STILL button, then press the ZOOM button.

English 11

QUAD SCREEN OPERATIONS (Live picture)

(The zoomed in area is set

by the frame position.)

1
2

ZOOM

4

3

Z

c button:

•

will move the frame to the right

l button:

•

will move the frame down

4

4

Example: To zoom in the image from camera 4 and set the

zoom range

You can select the portion of the image to zoom in. The default zoomed in area is the
centre of the image, but if a different zoom range is selected it will be memorized until
changed or cancelled.

1 Press the ZOOM button.

The ZOOM indicator flashes and the zoomed in image display mode is selected.

VCRLIVE

2 Press the camera select 4 button for about 3 seconds.

In full screen mode, “Z” (flashing) and the zoom range frame are displayed.
NOTE: If during the zoom range setting, the displayed frame is not moved for

about 10 seconds, the display mode will automatically return to quad
screen display mode. To return to the setting mode, press the camera
select 4 button again for about 3 seconds.

3 Press the c (or l) button to move the zoom range frame to the desired

area of the image.

4 Press the camera select 4 button.

The area selected by the zoom range frame is now zoomed in.
If necessary, follow the same procedure to set the zoom range for the other
cameras.

NOTE: You can switch from zoomed in mode to normal (no zoom) mode by

pressing the camera select 4 button repeatedly.

☞ To cancel the zoomed in image display mode.

Press the ZOOM button.

12 English

FULL SCREEN OPERATIONS (Live picture)

Press a camera select (1 – 8) button.

The camera select indicator lights and the live picture from the corresponding camera
is displayed full screen.

040404

1 2 43 6 75 8

NOTE: In full screen mode, still and zoomed in image display modes are not possible.

Sequential display of each camera pictures at 1 second
interval

SEQUENCE

010101

Camera number

(TIMER SET)
TIME 07:30 19:30
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 OFF
CAM2 T2 OFF T1 ON
CAM3 T1 ON T1 OFF
CAM4 T2 OFF T1 ON
CAM5 T1 ON T2 OFF
CAM6 T2 OFF T2 ON
CAM7 T1 ON T2 OFF
CAM8 T2 OFF T2 ON

Example 2Example 1

080808

Press the SEQUENCE button.

The pictures from each camera are displayed sequentially at 1 second interval. The
camera select indicators (1 – 8) light sequentially according to the displayed camera.

NOTE:

The sequential display speed (image interval) is set to T1 or T2 in the (MONITOR

•

SET) menu. The default setting for T1 and T2 is 1 second (see page 22).
The sequential display speed (image interval) T1 or T2 can be set for each camera

•

in the (TIMER SET) menu.

Setting the sequential display speed for each camera

1 In the (TIMER SET) menu, set the item “SEQ.” to “T1” or “T2”.
2 In the (MONITOR SET) menu, set the desired speed for items “FULL SEQ.

TIMER T1” and “FULL SEQ. TIMER T2”.

Example 1: Sequential display speed for daytime (7:30 AM ~ 7:30 PM)

Camera 1: T1 (2 sec.)
Camera 2: T2 (5 sec.)
Camera 3: T1 (2 sec.)
Camera 4: T2 (5 sec.)
Camera 5: T1 (2 sec.)
Camera 6: T2 (5 sec.)
Camera 7: T1 (2 sec.)
Camera 8: T2 (5 sec.)

010101

(DISPLAY SET)
LIVE CLOCK OFF
TITLE ON

POSITION SET†RESS NEXT
(MONITOR SET)
FULL SEQ.TIMER
T1 02 S
T2 05 S
QUAD SEQ.TIMER 01 S
QUADONLY QUADFULL N

Set the sequential display speed
(see page 22)

English 13

Example 2: Sequential display speed for nighttime (7:30 PM ~ 7:30 AM)

Camera 1: T1 (2 sec.)
Camera 2: T1 (2 sec.)
Camera 3: T1 (2 sec.)
Camera 4: T1 (2 sec.)
Camera 5: T2 (5 sec.)
Camera 6: T2 (5 sec.)
Camera 7: T2 (5 sec.)
Camera 8: T2 (5 sec.)

010101

VCR PLAYBACK MODE

03

04

01

02

(VIDEO OUT QUADFULL)
Operations with the monitor connected to
the VIDEO OUT QUADFULL terminal.

VCR

12

34

VIDEO OUT

QUAD

QUAD

FULL

ONLY

Press the VCR button.

The VCR playback mode is selected. When a tape is played back, the recording of
the live pictures will be displayed on the monitor.

Refer to the diagrams below for the buttons to press in order to select the desired
operation mode.

If live pictures are recorded in full screen mode, playback will only be available in full
screen mode. Quad screen playback of such a recording is not possible.

QUAD SCREEN OPERATIONS

Press the QUAD button.

01

01 02

03

03 04

02

04

QUAD

The camera select indicators (1 – 4) light and quad screen A is displayed.

NOTE: It is not possible to switch to quad screen B of the recorded pictures.

FULL SCREEN OPERATIONS

Press a camera select (1 – 4) button.

The recorded pictures from the selected camera will be displayed full screen.

040404

1 2 43 6 75 8

SEQUENCE

010101

020202

030303

0404

NOTE:

In full screen and quad screen modes, still and zoomed in image display modes

•

are not possible.
If the recording has been made using the quad screens (A and B) auto switching,

•

and if, for example, camera select button 1 is pressed, the display will switch
between the images from camera 1 and camera 5.

Full screen sequential display at 1 second interval

Press the SEQUENCE button.

The pictures are displayed sequentially at 1 second interval. The camera select
indicators (1 – 4) light sequentially according to the displayed camera.

NOTE:

The sequential display speed (image interval) is set in the (MONITOR SET) menu.

•

To change the sequence speed setting, refer to “FULL SEQ. TIMER” on page 22.
The sequential display speed (image interval) “FULL SEQ. TIMER T1” or “T2” can

•

be set for each camera in the (TIMER SET) menu.

14 English

MENU SETTING MODE

MENUS DISPLAYS

To display the menus, press the MENU button.

Menu 1 Menu 2

(LANGUAGE/LANG./IDIO.)

ENGLISH

FRANCAIS

ESPANOL

MENU

MENU

STILL

EXIT

STILL

EXIT

STILL

EXIT

STILL

EXIT

(CLOCK SET)
01-01-2000 SAT 00:00:00

(DAYLIGHT SET)
MODE NO USE
WEEK MON TIME
ON 1ST-SUN 04 02:00
OFF LST-SUN 10 02:00

Menu 3

(TITLE SET)

TITLE
1 ---------1
2 ---------2
3 ---------3
4 ---------4
5 ---------5
6 ---------6
7 ---------7
8 ---------8

Menu 4

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER OFF
DATA ON
VIDEO OUT FULL

DOUBLE ALARM SWITCH

MENU

MENU

MENU

(Monitor)

STILL

EXIT

STILL

EXIT

STILL

EXIT

STILL

EXIT

Menu 5

CAM1 OFF

Menu 6

(TIMER SET)
TIME 00:00 00:00
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

Menu 7

(DISPLAY SET)
LIVE CLOCK OFF
TITLE ON

POSITION SET†PRESS NEXT
(MONITOR SET)
FULL SEQ.TIMER
T1 01 S
T2 01 S
QUAD SEQ.TIMER 01 S
QUADONLYíQUADFULL N

Menu 8

(VCR SET)
COLOR KILLER OFF
(VIDEO LOSS SET)
VIDEO LOSS ON
DATA ON
DISPLAY FREEZE
(RS232C SET)
DATA SPEED 19200

MENU

MENU

MENU

MENU

ZOOM

NEXT

return

CAM1 CAM1

CAM3 CAM4

ZOOM

NEXT

Menu 9

(ALARM DATA) 1/13
CAM DATE TIME ITEM
1 -- ----- --:-- ­ 2 -- ----- --:-- -

STILL

3 -- ----- --:-- ­ 4 -- ----- --:-- ­ 5 -- ----- --:-- ­ 6 -- ----- --:-- ­ 7 -- ----- --:-- ­ 8 -- ----- --:-- -

EXIT

Normal live picture display

English 15

MENU

LANGUAGE SETTING Menu 1

(LANGUAGE/LANG./IDIO.)

The default menu language is English. The available language
settings are English, French and Spanish.

Setting the language

1 Press the MENU button once to display the

(LANGUAGE/LANG./IDIO.) menu.

2 Press the l button to highlight the desired language.
3

Press the MENU button to go to the next menu, or

☞

Press the EXIT button to exit the menu display, the

☞

selected language is set.

All the on-screen menus and settings will be displayed in
the selected language.

(LANGUAGE/LANG./IDIO.)

ENGLISH

FRANCAIS

ESPANOL

MENU

LIVE

(HORLOGE)
01-01-2000 SAM 00:00:00

(HEURE ETE)
MODE NON
SEM. MOIS HEURE
MAR 1ER-DIM 04 02:00
ARR DER-DIM 10 02:00

(AJUSTE DE RELOJ)
01-01-2000 SAB 00:00:00

(AJUSTE DE INTERVALO)
MODO SIN USO
SEMANA MES HORA
ON PRI-DON 04 02:00
OFF ULT-DON 10 02:00

16 English

CLOCK AND DAYLIGHT SAVING SETTING

Menu 2

(CLOCK SET)

The default setting is as indicated below. The clock will start
after the actual time and date are set and the operations under
(DAYLIGHT SET) are completed.

Default clock settings: 01:01:2000 SAT 00:00:00

(January 1, 2000 at 00:00)

1 Press the MENU button 2 times to display the (CLOCK

SET) menu.

2 Example: Setting the clock to October 15, 1999 at 3:20 PM

1 Press the + (or –) button to set the month (10), then

press the c button.

2 Press the + (or –) button to set the day (15), then press

the c button.

3 Press the + (or –) button to set the year (1999), then

press the c button.

4 Press the + (or –) button to set the hours (15), then

press the c button.

5 Press the + (or –) button to set the minutes (20), then

press the c button.

NOTE: The day of the week (SAT) will be automatically set

according to the date entered.

3

Press the l button to go to the (DAYLIGHT SET).

☞

Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

TO MAKE CHANGES TO THE SETTINGS

1 Press the l button to highlight the NO USE setting,

then press the + (or –) button to select “USE”, and
press the l button one more time.

2 Example: Setting the daylight saving time from the

second Tuesday of May at 3:00 AM, to the
fourth Tuesday of September at 3:00 AM.

1 Press the + (or –) button to set the WEEK (2ND), then

press the c button.
Menu: 1ST, 2ND, 3RD, 4TH or LST (first, second, third,

fourth or last)

2 Press the + (or –) button to set the WEEK (TUE), then

press the c button.
Menu: SUN, MON, TUE, WED, THU, FRI, SAT or SUN

3 Press the + (or –) button to set the MON (05), then press

the c button.

Menu: 1, 2, 3, 4 ..... 11, 12

(for January, February, March ..... December)

4 Press the + (or –) button to set the TIME (03), then press

the c button.
Following the same procedure as above, set when the

•

time is changed back from daylight saving time to
standard time (the OFF settings).

3

Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

2-

1

(CLOCK SET)
10-01-2000 SAT 00:00:00

VCR LIVEQUAD

2-

2~5

(CLOCK SET)
10-15-1999 FRI 15:20:00

QUAD

NOTE: To set the display mode for the clock, refer to

“DISPLAY SET (CLOCK, TITLE)” on page 22.

(DAYLIGHT SET)

The default daylight saving time function setting is “NO USE”, so
the daylight adjustment will not be made.

If the unit will be used in an area where there is a daylight saving
time change, set it to “USE”, then if necessary, set when the

daylight saving time is changed.

The default settings are:

Daylight saving time from the first Sunday of April, at 2:00 AM
(1ST-SUN 04 02:00) to last Sunday of October, at 2:00 AM
(LST-SUN 10 02:00).

12-1

(DAYLIGHT SET)
MODE USE
WEEK MON TIME
ON 1ST-SUN 04 02:00
OFF LST-SUN 10 02:00

QUAD

(DAYLIGHT SET)
MODE USE
WEEK MON TIME
ON 2ND-SUN 04 02:00
OFF LST-SUN 10 02:00

2-2 2-3

(DAYLIGHT SET)
MODE USE
WEEK MON TIME
ON 2ND-TUE 04 02:00
OFF LST-SUN 10 02:00

QUAD VCR QUAD VCR

(DAYLIGHT SET)
MODE USE
WEEK MON TIME
ON 2ND-TUE 05 02:00
OFF LST-SUN 10 02:00

2-4

(DAYLIGHT SET)
MODE USE
WEEK MON TIME
ON 2ND-TUE 05 03:00
OFF LST-SUN 10 02:00

QUAD LIVE

LIVE QUAD VCR

English 17

CAMERA TITLE SETTING Menu 3

When a picture from a camera is displayed on-screen the camera number (1 to 8) is displayed at the bottom of the image. You can
enter a camera title, such as the camera location (up to 10 characters), that will be displayed instead of the camera number.

(TITLE SET)

1 Press the MENU button 3 times to display the (TITLE

SET) menu.

2 Example: To set the title “GATE-1F” for the camera 1

and “HALL-2F” for camera 2.

1 Press the + (or –) button to set the first character “G”,

then press the c button.
By pressing the + (or –) button repeatedly, the

characters are selected as follows:

Letters: A, B, C,....X, Y, Z

•

Numbers: 0, 1,....8, 9

•

Symbols: – : . / * _

•

2 Following the same procedure, enter the rest of the title

“ATE-1F”.

3 Press the l button to set the cursor at the first character

location for camera 2.
Press the + (or –) button to set first character “H”, then

press the c button.

4 Following the same procedure, enter the rest of the title

“ALL-2F”.

3

Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

2-1 2-2

(TITLE SET)

TITLE
1 G
2
3
4
5
6
7
8

--------

---------

---------

---------

---------

---------

---------

---------

1
2
3
4
5
6
7
8

VCRQUAD

(TITLE SET)

TITLE
1 GATE-1F--1
2
3
4
5
6
7
8

2-3 2-4

(TITLE SET)

TITLE
1 GATE-1F--1
2 H
3
4
5
6
7
8

LIVE

--------

---------

---------

---------

---------

---------

---------

QUAD

2
3
4
5
6
7
8

VCR

(TITLE SET)

TITLE
1 GATE-1F--1
2 HALL-2F--2
3
4
5
6
7
8

---------

---------

---------

---------

---------

---------

---------

---------

---------

---------

---------

---------

---------

2
3
4
5
6
7
8

VCRQUAD

3
4
5
6
7
8

VCRQUAD

NOTE: To set the display mode for the title, refer to

“DISPLAY SET (CLOCK, TITLE)” on page 22.

18 English

ALARM SETTING Menu 4

When an alarm trigger is received from sensors such as a door bell, movement sensor, etc. you can set the display mode and the
recording mode for the pictures from the concerned camera.

(ALARM SET)

Changing the Settings

1 Press the MENU button 4 times to display the (ALARM

SET) menu.

2 Press the l button to highlight the setting to modify.
3 Using the + (or –) button, select the desired setting,

then press the l button.

Repeat step 3, until all the settings are as desired.

•

4

Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

1, 2 3

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER OFF
DATA ON
VIDEO OUT FULL

DOUBLE ALARM SWITCH

LIVE

ALARM SET menu

BUZZER

ON: A buzzer will be heard when an alarm trigger is received.

(Default setting)

OFF: The buzzer will not be heard.

DURATION

The alarm duration can be set to: 1, 2, 3, 4, 5, 10 (Default

setting), 30 seconds, CC, NC

CC: The alarm will go on for as long as the alarm signal is

received (minimum 1 second).

NC: The alarm will continue until canceled.

RETRIGGER

To set if an alarm is received while the unit is already in alarm
mode.

OFF: The unit will not receive another alarm, while one is

already being received. (Default setting)

ON: During alarm mode, other alarm triggers will be received

and the alarm duration will be extended.

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER OFF
DATA ON
VIDEO OUT FULL

DOUBLE ALARM SWITCH

LIVEQUAD

VIDEO OUT (A)

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER ON
DATA ON
VIDEO OUT FULL

DOUBLE ALARM SWITCH

FULL: If an alarm trigger is received while in quad screen, the

picture from the camera corresponding to the alarm input
will be displayed full screen. (Default setting)

DOUBLE ALARM

This item is only displayed and can only be set if “VIDEO
OUT” above is set to “FULL”.

SWITCH: The picture from each concerned camera will be

displayed sequentially at 1 second interval.
(Default setting)

FIRST: The picture from the first alarm received only is displayed.
LAST: The picture from the last alarm received is displayed.

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER ON
DATA ON
VIDEO OUT NC

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER ON
DATA ON
VIDEO OUT QUAD
STILL OFF
ZOOM OFF

VIDEO OUT (B)

QUAD: If an alarm trigger is received while in full screen, the

display mode will switch to quad screen.

STILL

ON: The image from the camera corresponding to the

alarm trigger will be frozen.

OFF: The image will not be frozen. (Default setting)

ZOOM

ON: The image from the camera corresponding to the

alarm trigger will be zoomed in.

OFF: The image will not be zoomed in. (Default setting)

VIDEO OUT (C)

NC: The display mode will remain unchanged when an alarm

trigger is received.

DATA

The camera number, date, time, type of the alarm can be
recorded. (To view the recorded alarm data, refer to “ALARM

DATA DISPLAY” on page 26.)
ON: The alarm data is recorded. (Default setting)
OFF: The alarm data is not recorded.

English 19

VIDEO SENSOR SETTING Menu 5

02

02

You can set an area of the image on the screen to be used as a video sensor ( ). The video sensor detects movement in the
selected area of the image and sends an alarm trigger that will initiate priority recording of the images from the concerned camera.

(VIDEO SENSOR SET)

SETTING THE VIDEO SENSOR POSITION AND
SENSITIVITY LEVEL

1 Press the MENU button 5 times to display the video

sensor setting screen.

The video sensor frame is displayed on the live picture from
camera 1.

Press the NEXT button repeatedly to select the video
sensor setting screen for the other cameras.

2 Using the l (or c) button move the video sensor down

(or right) to the desired alarm sensor area position.

3 Press the + (or –) button to raise (or lower) the sensor

sensitivity level.
The available sensitivity levels are:

OFF (not used), 01, 02, 03, 04, 05, 06, 07, 08, 09, 10 (10
being the least sensitive)

4

Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

Video sensor

1 2

VIDEO SENSOR ALARMS

Example:

If an alarm trigger is received for camera 4
(in quad screen)

1 The buzzer is heard and the camera 4 indicator light.

The alarm output changes from HI (5V) to LOW (0V).

2 The image from camera 4 and the camera number (04)

will be displayed, SA (Video Sensor Alarm) will flash at
the left of the camera number.

SA 04

Video sensor alarm Camera number

Example of display when there is an alarm trigger.

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER ON
DATA ON
VIDEO OUT FULL

DOUBLE ALARM SWITCH

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER ON
DATA ON
VIDEO OUT QUAD
STILL OFF
ZOOM OFF

01 02

01 02

03 04

03 04

0101

SA 01SA 01

SA 01SA 01 02

02

03 04

03 04

3

QUAD

CAM1 03

CAM1 OFF

Sensitivity Level

LIVE

CAM1 OFF

(ALARM SET)
BUZZER ON
DURATION 10 S
RETRIGGER ON
DATA ON
VIDEO OUT QUAD
STILL ON
ZOOM ON

0101

01 02

01 02

03 04

03 04

SA B Z 01SA B Z 01 02

02

03 04

03 04

NOTE: The display mode (quad or full screen) selected for the

alarm operation is set by the item “VIDEO OUT” in the
(ALARM SET) menu (see page 19).

Resetting the Alarm

For an alarm in full screen display mode, press the

•

corresponding camera select button twice.
For an alarm in quad screen display mode, press the

•

corresponding camera select button to switch to full screen
display mode then press the corresponding camera select
button one more time.

NOTE:

During normal monitoring operations, the camera select

•

indicator lights according to the displayed camera. If there is
an alarm trigger for another camera, the indicator will flash.

When in quad screen A, even if a video sensor alarm is

•

triggered at a quad screen B camera, the display will not
switch to quad screen B.

20 English

TIMER SETTING Menu 6

The timer can be set to record during the daytime and/or nighttime. According to the timer settings, each camera picture full screen
display switching speed can be set, and the cameras to be displayed in the quad screens can be selected.

(TIMER SET)

1 Press the MENU button 6 times to display the (TIMER

SET) menu.

2 Set the daytime period start and end times.

Example: To set the daytime period from 7:30 AM to

7:30 PM (the nighttime will then be from 7:30
PM to 7:30 AM).

1 Using the + (or –) button, select the starting hour (7) (the

first part of the first setting of the TIME line).

2 Press the c button, then using the + (or –) button select

the starting minutes (30) (the second part of the first
setting of the TIME line).

3 Press the c button, then using the + (or –) button select

the end hour (19) (the first part of the second setting of
the TIME line).

4 Press the c button, then using the + (or –) button select

the end minutes (30) (the second part of the second
setting of the TIME line).

3 Set the timer operations for each (daytime/nighttime)

period.
(Daytime)

1 Press the l button, then using the + (or –) button select

the switching speed “T1” or “T2” in the first SEQ. column
for camera 1. (This sets the duration the image from
camera 1 is displayed, when in full screen mode, during
the daytime period.)

2 Press the c button, then using the + (or –) button select

“ON” or “OFF” in the first QUAD column for camera 1.
(This determines if the image from that camera is
displayed (ON) or not (OFF), when in quad screen mode,
during the daytime.)

(Nighttime)

3 Press the c button, then using the + (or –) button select

the switching speed “T1” or “T2” in the second SEQ.
column for camera 1. (This sets the duration the image
from camera 1 is displayed, when in full screen mode,
during the nighttime period.)

4 Press the c button, then using the + (or –) button select

“ON” or “OFF” in the second QUAD column for camera

1. (This determines if the image from that camera is
displayed (ON) or not (OFF), when in quad screen mode,
during the nighttime.)

NOTE: The settings for the sequential display speeds T1

and T2 are entered in the (MONITOR SET) menu.

4

Press the MENU button to go to the next menu

☞

screen or,
Press the EXIT button to exit the menu display.

☞

Daytime start time Daytime end time

(TIMER SET)
TIME 00:00 00:00
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

Daytime setting area

2-

1

(TIMER SET)
TIME 07:00 00:00
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

QUAD QUAD

2-

3

(TIMER SET)
TIME 07:30 19:00
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

QUAD

VCR

3-

1

(TIMER SET)
TIME 07:30 19:30
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

QUAD

VCR

3-

3

(TIMER SET)
TIME 07:30 19:30
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

QUAD

VCR

Nighttime setting area

2-

2

(TIMER SET)
TIME 07:30 00:00
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

VCR

2-

4

(TIMER SET)
TIME 07:30 19:30
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

QUAD

VCR

3-

2

(TIMER SET)
TIME 07:30 19:30
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

QUAD

VCR

3-

4

(TIMER SET)
TIME 07:30 19:30
SEQ. QUAD SEQ. QUAD
CAM1 T1 ON T1 ON
CAM2 T1 ON T1 ON
CAM3 T1 ON T1 ON
CAM4 T1 ON T1 ON
CAM5 T1 ON T1 ON
CAM6 T1 ON T1 ON
CAM7 T1 ON T1 ON
CAM8 T1 ON T1 ON

QUAD

VCR

English 21

CLOCK, TITLE DISPLAY AND MONITOR
SETTINGS Menu 7

(DISPLAY SET)

The clock and the camera title settings entered in the menus
(CLOCK SET) and (TITLE SET) can be displayed on-screen.

SETTING THE CAMERA TITLE AND THE
CLOCK DISPLAY POSITION (POSITION SET)

1 Press the MENU button 7 times to display the (DISPLAY

SET) menu.

2 Using the + (or –) button, select the desired setting,

then press the l button.

Following this procedure, select the settings for LIVE

•

CLOCK and TITLE.

3 From the (DISPLAY SET) menu, press the NEXT button.

The quad screen A display is selected.

4 Using the + (or –) button, set the camera title display

position. (Select among the 4 positions.)

5 Using the l button, set the clock display position.
6 Press the NEXT button. The display will return to the

(DISPLAY SET) menu.

Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

2

(DISPLAY SET)
LIVE CLOCK ON
TITLE ON

POSITION SET†RESS NEXT
(MONITOR SET)
FULL SEQ.TIMER
T1 01 S
T2 01 S
QUAD SEQ.TIMER 01 S
QUADONLY QUADFULL N

QUAD

45

CAM3 CAM4

CAM1 CAM2

CAM3 CAM4

DISPLAY SET menu

LIVE CLOCK

ON: The clock is displayed during live picture mode.
OFF: The clock is not displayed during live picture mode.

(Default setting)

LIVE

CAM2CAM1

CAM1 CAM2
CAM3 CAM4

CAM1 CAM2

CAM3 CAM4

(Quad screen A)

3

CAM1 CAM2

CAM3 CAM4

ZOOM

CAM1

CAM3 CAM4

NEXT

1999-10-20
15:40:00

CAM2

1999-10-20
15:40:00

LIVE TITLE

ON: The camera title is displayed during live picture mode.

(Default setting)

OFF: The camera title is not displayed during live picture mode.

(MONITOR SET)

You can set the sequential display speed T1 and T2, and the
quad screen A and B switching speed. Switching the display
mode on the monitor connected to the VIDEO OUT (QUAD
ONLY) terminal from quad screen to full screen display is also
possible in this menu.

These FULL and QUAD SEQ.TIMER settings must only be
done when not using a SW IN signal.

When using a SW IN signal, please refer to “Setting up the
VCR signal output (SW IN) automatic switching speed” on
page 26.

MONITOR SET menu

Press the l button to select the desired item, then using the +
(or –) button, select the desired setting.

FULL SEQ. TIMER T1

Set the desired speed at which the full screen image will be
switched. The sequential display speed T1 (or T2) setting is
applied in the (TIMER SET) menu (see page 21).

The automatic switching speed is entered in seconds of
interval.

01 (default), 02, 03, 04, 05, 10, 20, 30

FULL SEQ. TIMER T2

Set the desired speed at which the full screen image will be
switched. The sequential display speed T2 (or T1) setting is
applied to each camera in the (TIMER SET) menu (see page

21).
The automatic switching speed is entered in seconds of

interval.

01 (default), 02, 03, 04, 05, 10, 20, 30, OFF

OFF: The camera this setting is applied to will be skipped.

QUAD SEQ. TIMER

Set the desired speed at which the display will switch between
quad screen A and B.

The automatic switching speed is entered in seconds of
interval.

01 (default), 02, 03, 04, 05, 10, 20, 30

QUADONLY ← QUADFULL

Y: A quad screen and full screen display will be output to the

monitor connected to the QUADONLY terminal.

N (Default): A quad screen only will be output to the monitor

connected to the QUADONLY terminal.

NOTE: For more information on the monitor displays, please

refer to Table 1 and 2 (see pages 23, 24).

22 English

CLOCK, TITLE DISPLAY AND MONITOR SETTINGS Menu 7

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

Display when no switching signal input is present (Table 1)

(MONITOR SET) menu QUADONLY ← QUADFULL setting N (normal setting) Y

Image output at the VIDEO OUT terminal

Quad screen A or
B display

QUAD ONLY

Either setting (Y or N)

•

Quad screen A or B (manual switching
possible)

QUAD FULL

Either setting (Y or N)

•

Quad screen A or B (manual switching
possible)

01 02

01 02

03 04

03 04

01 02

01 02

03 04

03 04

01 02

01 02

03 04

03 04

01 02

01 02

03 04

03 04

QUAD

1

(1 – 8)

Quad screen A or
B automatic
switching display

SEQUENCE

Full screen display

Automatic
switching display

QUAD ONLY

Either setting (Y or N)

•

Automatic switching of the display will
depend on the quad screen A/B settings
entered in the (TIMER SET) menu.

QUAD FULL

Either setting (Y or N)

•

Automatic switching of the display will
depend on the quad screen A/B settings
entered in the (TIMER SET) menu.

QUAD ONLY

N setting:

•

Quad screen A or B
Y setting:

•

Full screen display of a live picture
(manual switching possible)

QUAD FULL

Either setting (Y or N)

•

Full screen display of a live picture
(manual switching possible)

QUAD ONLY

N setting:

•

Quad screen A or B
Y setting:

•

Full screen display of a live picture
switched according to the setting entered
in the menu

01 02

01

03

03 04

01 02

01

03

03 04

02

04

070707 080808

02

04

070707 080808

01 02

01 02

03 04

03 04

01 02

01 02

03 04

03 04

01 02

060606

060606

01

03

03 04

01 02

01

03

03 04

02

04

070707 080808

02

04

070707 080808

010101

010101 010101

0101

060606

060606

SEQUENCE

QUAD FULL

Either setting (Y or N)

•

Full screen display of a live picture
switched automatically according to the
setting entered in the menu

English 23

0101 0101

CLOCK, TITLE DISPLAY AND MONITOR SETTINGS Menu 7

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

03

04

01

02

Display when a switching signal input is present (Table 2)

(MONITOR SET) menu QUADONLY ← QUADFULL setting N (normal setting) Y

Image output at the VIDEO OUT terminal

Quad screen A or B
display

QUAD ONLY

Either setting (Y or N)

•

Quad screen A or B (manual switching
possible)

QUAD FULL

Either setting (Y or N)

•

Quad screen A or B (manual switching
possible)

01 02

01 02

03 04

03 04

01 02

01 02

03 04

03 04

01 02

01 02

03 04

03 04

01 02

01 02

03 04

03 04

QUAD

Quad screen A or B
automatic switching
display

SEQUENCE

Full screen display

QUAD ONLY

Either setting (Y or N)

•

Automatic switching of quad screen A/B
according to the switching signal input at
the SW terminal.
The minimum switching speed delay will be
1 second.

QUAD FULL

Either setting (Y or N)

•

Automatic switching of quad screen A/B
according to the switching signal input at
the SW terminal.
The minimum switching speed delay will be
1 second.

QUAD ONLY

N setting:

•

Automatic switching of quad screen A/B
according to the switching signal input at
the SW terminal.
The minimum switching speed delay will be
1 second.
Y setting:

•

Full screen display of a live picture (manual
switching possible)

QUAD FULL

Either setting (Y or N)

•

Full screen display of a live picture (manual
switching possible)

01

01 02

03

03 04

01 02

01

03

03 04

01 02

01

03

03 04

02

04

070707 080808

02

04

070707 080808

02

04

070707 080808

060606

060606

060606

01

01 02

03

03 04

01 02

01

03

03 04

02

04

070707 080808

02

04

070707 080808

010101

010101 010101

060606

060606

1

(1 – 8)

Automatic
switching display

SEQUENCE

QUAD ONLY

N setting:

•

Automatic switching of quad screen A/B
according to the switching signal input at
the SW terminal.
The minimum switching speed delay will be
1 second.
Y setting:

•

Automatic switching of a full screen display
of a live picture according to the switching
signal input at the SW terminal

QUAD FULL

N setting:

•

Full screen display of a live picture
switched automatically according to the
setting entered in the menu
Y setting:

•

Automatic switching of a full screen display
of a live picture according to the switching
signal input at the SW terminal.
The minimum switching speed delay will be
1 second.

24 English

01 02

01

03

03 04

02

060606

04

070707 080808

0101 0101

0101

VCR SIGNAL SETTING AND COMPUTER
CONTROL SETTING Menu 8

(VCR SET)

1 Press the MENU button 8 times to display the (VCR

SET) menu.

2 Press the l button to highlight the setting to modify,

then using the + (or –) button select the desired setting.

3

Press the l button to go to the next menu (VIDEO

☞

LOSS SET), (RS232C SET),
Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

(VCR SET)
COLOR KILLER OFF
(VIDEO LOSS SET)
VIDEO LOSS ON
DATA ON
DISPLAY FREEZE
(RS232C SET)
DATA SPEED 19200

LIVEMENU

COLOR KILLER

Used to playback a tape recorded through a black and white
multiplexer, using a color multiplexer.

ON: When using a black and white tape, the color killer

function is active.

OFF: The color killer function is not active. (Default setting)

(VIDEO LOSS SET)

When the live picture signal feed is interrupted, you can set the
action taken, and if the video loss is recorded as alarm data.
This function will only operate in quad screen display, to select
it, set “VIDEO LOSS” to “ON”.

Setting the Video Loss Mode

1 Press the l button to highlight the setting to modify.
2 Using the + (or –) button, select the desired setting,

then press the l button.
Following this procedure, select the settings for DATA and

DISPLAY.

VIDEO LOSS SET menu

VIDEO LOSS

You can set the action to take when there is an interruption in
the video signal feed.

When there is video loss, the image just previous to the interruption

ON:

is frozen on-screen or colour bars are displayed (see “DISPLAY”
below) and “VIDEO LOSS” is displayed on-screen. (Default setting)

OFF: When there is video loss, “NO VIDEO” is displayed on-screen.
NOTE: If no camera is connected to one of the terminals, then “NO

VIDEO” will be displayed on a grey screen. This will not trigger

a video loss alarm.

DATA

You can set the data (date, time, etc) of the video losses to be
recorded as alarm data. (To view the recorded data, refer to

“ALARM DATA DISPLAY” on page 26.)
ON:

The video losses data is recorded as alarm data. (Default setting)

OFF: The video losses data is not recorded.

DISPLAY

You can set the display mode when there is an interruption in
the video signal feed.

FREEZE:

TEST: When there is video loss, colour bars are displayed on-screen.
NOTE: If the (VIDEO LOSS SET) menu, “DISPLAY” is set to

When there is video loss, the image just previous to the
interruption is frozen on-screen. (Default setting)

“FREEZE”, when there is a loss of the video signal, “VIDEO
LOSS” and the image just previous to the interruption will be

shown frozen on screen. To switch to a colour bars display,
press the camera select button or QUAD button.

(RS232C SET)

Connect this unit to a computer, using a 9-pin D-SUB cable (sold
separately), then set the maximum communication speed with
the computer.

For detailed information, refer to “RS232C CONTROL” on page

28.

Changing the Setting

3

Press the l button to go to the next menu, or

☞

Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

(VCR SET)

1, 2

COLOR KILLER OFF
(VIDEO LOSS SET)
VIDEO LOSS ON
DATA ON
DISPLAY FREEZE

LIVE QUAD

English 25

1 Press the l button to highlight the setting to modify.
2 Using the + (or –) button, select the desired setting.

The available speeds are:

2400, 4800, 9600, 19200 (Default setting) bps

3

Press the MENU button to go to the next menu

☞

screen, or
Press the EXIT button to exit the menu display.

☞

(VCR SET)

1, 2

COLOR KILLER OFF
(VIDEO LOSS SET)
VIDEO LOSS ON
DATA ON
DISPLAY FREEZE
(RS232C SET)
DATA SPEED 19200

LIVE QUAD

ALARM DATA

SETTING UP THE VCR

DISPLAY Menu 9

According to the settings entered in the (ALARM SET), (VIDEO
SENSOR SET) and (VIDEO LOSS SET) menus, information
about the alarms (alarm data) can be recorded. Up to 100 alarm
data entries can be displayed on-screen (on up to 13 screens).

(ALARM DATA)

Displaying the Alarm Data

1 Press the MENU button 9 times to display the (ALARM

DATA) menu.

The first screen (1/13) of alarm data entries is displayed.

•

2 To display the next screen of alarm data entries, press

the NEXT button.

3

Press the EXIT button to exit the menu display, or

☞

Press the MENU button to return to the normal

☞

picture, then press the MENU button once more to
display the menu display.

1

(ALARM DATA) 1/13
CAM DATE TIME ITEM
1 4 08-22 08:48 E
2 2 08-21 08:51 S
3 4 05-04 16:22 E
4 3 05-04 07:45 V
5 1 04-30 14:37 E
6 1 04-21 18:26 V
7 2 04-12 05:31 E
8 4 04-12 12:51 S

2

(ALARM DATA) 2/13
CAM DATE TIME ITEM
9 4 03-29 17:40 E
10 2 03-26 08:49 V
11 4 03-13 09:25 E
12 3 03-05 08:15 S
13 1 02-11 15:18 E
14 1 02-29 12:30 V
15 2 02-21 08:21 S
16 4 01-15 11:34 E

SIGNAL OUTPUT (SW IN)
AUTOMATIC SWITCHING
SPEED

1 Connect the unit SW IN terminal to the VCR SW OUT

terminal (see page 5).

2 Set the VCR recording speed.

The settings entered for the SEQ. TIMER in menu 7 (MONITOR
SET) will be ignored, and the full screen image and quad screen
(A and B) switching speeds will be the speed set by the VCR.

NOTE:

Even if the screens switching speed is set to a very quick

•

timing, the minimum switching speed delay will be 1 second.
Even when the switching timing is set using the SW IN

•

terminal signal, the minimum switching speed delay will be 1
second (see page 24).

MENU

ZOOM

NEXT

The codes in the ITEM column indicate the type of alarm
data.

E: External alarm trigger (see page 27)

V: Video loss (see page 25, 27)
S: Video sensor alarms (see page 20, 27)

NOTE:

When the number of recorded alarm data entries reaches

•

100, the oldest ones are erased as new ones are recorded.

The alarm data screens are only displayed when alarm data

•

entries are recorded.

26 English

ALARMS OPERATIONS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSSVIDEO LOSS

VIDEO LOSSVIDEO LOSS VIDEO LOSSVIDEO LOSS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSSVIDEO LOSSVIDEO LOSS

VIDEO LOSS

There are three types of alarms; the alarms set by an external alarm trigger, the alarms set by a loss of the video signal and the
alarms set by the video sensor.

EXTERNAL ALARMS

When external inputs such as a door bell, an interphone, etc.,
are connected to the CONTROL terminal (pins 1 – 8), they will
send alarm triggers automatically. On the monitor screen, the
alarm display will identify the camera corresponding to the alarm
trigger.

Example: If an alarm trigger is received for camera 4

(in quad screen)

1 The buzzer is heard and the camera 4 indicator flashes.

The alarm output changes from HI (5V) to LOW (0V).

2 The image from camera 4 and the camera number (04)

will be displayed, EA (External Alarm) will flash at the
left of the camera number.

The action taken here will depend on the settings entered in
the (ALARM SET) menu (see page 19).

EA 04

External alarm Camera number

NOTE:

When the alarm operation is over, the display will return to

•

the mode preceding the alarm trigger.

An alarm trigger can also be received at a terminal for which

•

a camera is not connected to. In such a case, a grey screen
will be displayed.

The display mode (quad or full screen) selected for the alarm

•

operation is set by the item “VIDEO OUT” in the (ALARM
SET) menu.

Resetting the Alarm

For an alarm in full screen display mode, press the

•

corresponding camera select button twice.

For an alarm in quad screen display mode, press the

•

corresponding camera select button to switch to full screen
display mode then press the corresponding camera select
button one more time.

NOTE:

The alarm display mode is selected according to the settings

•

entered in the (DISPLAY SET) menu.

During normal monitoring operations the camera select

•

indicator lights according to the displayed camera. If there is
an alarm trigger for another camera, the indicator will flash.

VIDEO LOSS ALARM

If there is an interruption of the video signal, the buzzer is heard,
and the image just previous to the interruption is frozen
on-screen or colour bars are displayed and “VIDEO LOSS” will
flash on-screen.

The action taken will depend on the settings entered in the
(VIDEO LOSS SET) menu (see page 25).

VIDEO LOSS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSS

VIDEO LOSS

(Colour bars)

NOTE:

If a video signal is not present from the beginning, then “NO

•

VIDEO” will be displayed on a gray screen. This will not
trigger a video loss alarm.

The video loss alarm is recorded until the video signal is

•

restored.
In full screen display mode, video loss alarm is not possible.

•

Resetting the Alarm

For an alarm in full screen display mode, press the

•

corresponding camera select button.
For an alarm in quad screen display mode, press the

•

corresponding camera select button to switch to full screen
display mode. Then, press the corresponding camera select
button one more time.

NOTE:

The alarm display mode is selected according to the settings

•

entered in the (ALARM SET) menu.
During normal monitoring operations the camera select

•

indicator lights according to the displayed camera. If there is
an alarm trigger for another camera, the indicator will flash.

If the alarm is not reset, “VIDEO LOSS” will be displayed until

•

normal live picture signals are restored.

VIDEO SENSOR ALARMS

The video sensor area is set in the (VIDEO SENSOR SET)
menu. The brightness and contrast levels in the video sensor
frame are used to trigger the alarm, and the alarm display (type
of alarm and camera number) is shown on a live picture of the
alarm trigger channel (see page 20).

English 27

SA 04

Video sensor alarm Camera number

RS232C CONTROL

CONNECTION

Connect a 9-pin D-SUB cable (sold separately) from the
RS232C terminal on the rear panel to the computer serial
connector.

Computer

CONTROL

RCCSWCAL

C12345678

RS232C

9-pin D-SUB cable
(sold separately)

Setting the Data Transmission Speed

After the connection is made, set the data transmission speed in
the (RS232C SET) menu (see page 25).

INTERFACE SPECIFICATIONS

For the RS232C terminal specifications, refer to page 4.

DATA FORMAT

Mode Asynchronous
Character length 8 bits
Data transmission

speed
Parity check None
Stop bit One bit

TRANSMISSION PROTOCOL

The transmission is based on 1 byte units. After the computer
has transmitted 1 byte, it will wait for an answer from this unit,
then send the following byte of data.

The command ON (F6) is sent to start, and the command OFF
(F7) is sent to finish. This unit will receive the commands, and
will reply to each command by ACK (OA). (Refer to “COMMAND

TABLE 4” on page 31.)

2400, 4800, 9600, 19200 bps
(set in the (RS232C SET) menu)

COMMANDS

COMMANDS AVAILABLE FROM THE
COMPUTER

1-8 (90-97)

To select the picture from a camera to be displayed full screen.

QUAD (83)

To display a quad screen.

SEQUENCE (87)

In full screen mode, the display will be switched in order,
automatically.

In quad screen mode, the display will switch between quad
screen A and B automatically.

ZOOM (85)

To zoom a picture in quad screen.

STILL (86)

To freeze a picture in quad screen.

LIVE (80)

To select the live input mode.

VCR (81)

To select the VCR playback input mode.

MENU (74)

To display the menu or switch to the next menu.

+ (65), – (66)

To select settings for the menu items (ON/OFF, etc.)

« (63), 2 (64)

To change selection in the menus. (To move the cursor right,
down.)

NEXT (75)

To switch to the sub-menus.

EXIT (76)

To go to the next menu, or to exit the menu mode.

MENU RESET (E1)

To reset all the values of the displayed menu to the default
values.

CLOCK ADJUST (E0)

To reset the clock minutes and seconds setting to 00:00.

SECURITY LOCK ON (69)

To set the security lock.

SECURITY LOCK OFF (6A)

To cancel the security lock.

28 English

RS232C CONTROL

INFORMATION GATHERING COMMANDS

STATUS SENSE(D7)

When this command is sent from the computer, this unit will
send a 5-byte response (see Table 1).

ALARM STATUS SENSE(D5)

The external, video loss and video sensor alarm states are
indicated by a 6-byte response (see Table 2).

RXD
TXD

D7

d1 d2 d3 d4 d5

STATUS SENSE(D7) byte assignment (Table 1)

The third, fourth and fifth bytes are reserved.

First byte

Bit Bit state information

7 LIVE/VCR indication 0: LIVE picture mode

1: VCR playback mode

6 3-bit indication of the

display mode

5 001: Quad screen
4 010: Menu display
3 4-bit indication of the

channels and quad

2 0000: Channel 1

screen displayed

1 0001: Channel 2
0 0010: Channel 3

Second byte

Bit Bit state information

7 EXT/ALARM

indication

6 VIDEO LOSS

indication
5 SENSOR indication SENSOR is ON
4 Reserved 0
3 4-bit indication of the

display mode

2 0001: Sequential display mode
1 0010: Zoomed in mode
0 0011: Still image mode

000: Full screen

(Full screen mode)

0011: Channel 4
0100: Channel 5
0101: Channel 6
0110: Channel 7
0111: Channel 8

(Quad screen)

0000: Quad screen A (1, 2, 3, 4)
0001: Quad screen B (5, 6, 7, 8)

(Menu display)

0000: Menu 1 (LANGUAGE/LANG./IDIO.)
0001: Menu 2 (CLOCK SET)
0010: Menu 3 (TITLE SET)
0011: Menu 4 (ALARM SET)
0100: Menu 5 (VIDEO SENSOR SET)
0101: Menu 6 (TIMER SET)
0110: Menu 7 (DISPLAY SET)
0111: Menu 8 (VCR SET)
1111: Menu 9 (ALARM DATA)

EXTERNAL ALARM is ON

VIDEO LOSS is ON

0000: Normal display mode

0100: Frozen zoomed in image
0101: Zoomed in still image
0110: Zoom range setting mode
0111: Zoomed in still image range setting

mode

RXD
TXD

D5

d1 d2 d3 d4 d5 d6

ALARM STATUS SENSE(D5) byte assignment
(Table 2)

First byte Second byte

Bit Bit

7 ALARM ON 8 7 0
6 ALARM ON 7 6 0
5 ALARM ON 6 5 0
4 ALARM ON 5 4 0
3 ALARM ON 4 3 0
2 ALARM ON 3 2 0
1 ALARM ON 2 1 0
0 ALARM ON 1 0 0

Third byte Fourth byte

Bit Bit

7 SENSOR 8 7 0
6 SENSOR 7 6 0
5 SENSOR 6 5 0
4 SENSOR 5 4 0
3 SENSOR 4 3 0
2 SENSOR 3 2 0
1 SENSOR 2 1 0
0 SENSOR 1 0 0

Fifth byte Sixth byte

Bit Bit

7 VIDEO LOSS 8 7 0
6 VIDEO LOSS 7 6 0
5 VIDEO LOSS 6 5 0
4 VIDEO LOSS 5 4 0
3 VIDEO LOSS 4 3 0
2 VIDEO LOSS 3 2 0
1 VIDEO LOSS 2 1 0
0 VIDEO LOSS 1 0 0

English 29

RS232C CONTROL

COMMANDS AVAILABLE FROM THE QUAD
COMPRESSOR

ACK(0A)

Response when this unit receives a command.

NAK(0B)

Response if this unit did not receive the command.

ALARM(BF)

When there is an alarm, this command is sent as header. Then,
the alarm information is sent in a 1-byte transmission (see Table

3).

ALARM information (Table 3)

Bit Bit state information

7 2-bit indication of the

alarm type

6 10: Video loss alarms

5 Reserved 0
4 Reserved 0
3 4-bit indication of the

camera number

2 0110: CAMERA NO. 7
1 0101: CAMERA NO. 6
0 0100: CAMERA NO. 5

01: External alarms

11: Sensor alarms

0111: CAMERA NO. 8

0011: CAMERA NO. 4
0010: CAMERA NO. 3
0001: CAMERA NO. 2
0000: CAMERA NO. 1

OTHER COMMANDS

ENTER(40)

When numeric commands are all sent, this command is used to
enter the transmitted value.

CLEAR(56)

To erase multiple byte commands.

30 English

RS232C CONTROL

COMMAND TABLE (TABLE 4)

The commands available are indicated in the table.
If a function is not available on the unit, the command will not operate even if sent.

012345 6 7 89
0 0 ENTER LIVE FULL 1
11 VCR PB FULL 2
2 2 (VERSION) (MULTI) FULL 3
33(») « (SHIFT) QUAD FULL 4
44(1) O MENU (PLUS) FULL 5
55 + NEXT ZOOM FULL 6
6 6 CLEAR – EXIT STILL FULL 7
77 SEQ. FULL 8
88
9 9 SECURITY LOCK ON
A ACK SECURITY LOCK OFF
B NAK (POWER ON/OFF)
C (SET ON)
D (SET OFF)
E
F

ABC D EF
0 CLK. ADJ.
1 MENU RESET
2
3
4
5 ALARM STATUS SENSE
6
7 STATUS SENSE
8
9
A
B
C
D
E
F ALARM

English 31

SPECIFICATIONS

Signal format : Based on NTSC color signal standard
Camera signal input synchronization : Asynchronous
Camera input terminals (CAMERA) : VS/VBS, 1.0 Vp-p/75 Ω, BNC connector x 8
VCR input terminal (VCR IN) : Composite input, VS/VBS, 1.0 Vp-p/75 Ω, BNC connector x 1
VIDEO output terminal 1

(VIDEO OUT QUAD FULL)
VIDEO output terminal 2

(VIDEO OUT QUAD ONLY)
Control terminal (CONTROL) : Push-type terminal

Alarm input (1 – 8) : No voltage, make-contact switch input x 8 (Low input)

•

Remote input (RC) : 2-wire type with resistance-based identification system, can be used with a remote control

•

Alarm output (AL) : DC 5V, 5.7kΩ (Low output)

•

Switching input (SW) : 1 low input, for switching signal from SW OUT of a timelapse VCR (as per this

•

RS-232C terminal : 9-pin D-SUB
Monitor on-screen display : Title (up to 10 characters), date, time selectable
Menu settings : 9 menus screens
Video alarm sensor : Internal, 8 channel (each camera input, selectable)
Back-up function : Back-up for up to 30 days of the clock settings after connected for 30 hours continuously
Operations

Still : Available for camera live in quad screen, full screen and zoomed in picture

•

2x zoom : Available for camera live in quad screen

•

Display automatic switching speed : 8 settings (1, 2, 3, 4, 5, 10, 20 and 30 seconds interval) available in full screen mode and

Power : AC 120 V, 60Hz
Consumption : 12 W
Operating temperature range : 5 to 40˚C
Operating humidity range : 10 to 80%
Dimensions : 420 (W) x 44 (H) x 325 (D) mm
Weight : Approx. 3.4 kg

: Composite output: Quad screen/Full screen VS/VBS, 1.0 Vp-p/75 Ω, BNC connector x 1

: Composite output: Quad screen only VS/VBS, 1.0 Vp-p/75 Ω, BNC connector x 1

circuit

manufacturer specifications)

Can be set using a menu to operate automatically when there is an alarm trigger

quad screen A and B

Products are subject to change in design and specifications without notice and without incurring any obligation.

32 English

SANYO INDUSTRIAL

QUAD COMPRESSOR LIMITED WARRANTY

OBLIGATIONS

In order to obtain warranty service, the product must be delivered to and picked up from an Authorized Sanyo Service Center at the user’s
expense, unless specifically stated otherwise in this warranty. The names and addresses of Authorized Sanyo Service Centers may be
obtained by calling the toll-free number listed below.

For product operation, authorized service center referral, service assistance or problem resolution, call

CUSTOMER INFORMATION 1-800-421-5013

Weekdays 8:30 AM – 5:00 PM Pacific Time

For accessories and/or parts, call

PARTS ORDER INFORMATION 1-800-726-9662

Weekdays 8:30 AM – 5:00 PM Pacific Time

THIS WARRANTY IS VALID ONLY ON SANYO PRODUCTS PURCHASED OR RENTED IN THE UNITED STATES OF AMERICA,
EXCLUDING ALL U.S. TERRITORIES AND PROTECTORATES. THIS WARRANTY APPLIES ONLY TO THE ORIGINAL RETAIL
PURCHASER OR END-USER. THE ORIGINAL DATED BILL OF SALE, SALES SLIP OR RENTAL AGREEMENT MUST BE SUBMITTED
TO THE AUTHORIZED SANYO SERVICE CENTER AT THE TIME WARRANTY SERVICE IS REQUESTED.

Subject to the OBLIGATIONS above and EXCLUSIONS below, SANYO Fisher Company warrants this SANYO product against defects in
materials and workmanship for the periods specified below. SFC will repair or replace (at its option) the product and any of its parts which fail
to conform to this warranty. The warranty period commences on the date the product was first purchased or rented at retail.

LABOR PARTS

3 YEARS 3 YEARS

EXCLUSIONS

This warranty does not cover (A) the adjustment of customer-operated controls as explained in the appropriate model’s instruction manual, or
(B) the repair of any product whose serial number has been altered, defaced or removed.
This warranty shall not apply to the cabinet or cosmetic parts, batteries or routine maintenance.
This warranty does not apply to uncrating, setup, installation, removal of the product for repair or reinstallation of the product after repair.
This warranty does not apply to repairs or replacements necessitated by any cause beyond the control of SFC including, but not limited to, any
malfunction, defect or failure caused by or resulting from unauthorized service or parts, improper maintenance, operation contrary to furnished
instructions, shipping or transit accidents, modification or repair by the user, abuse, misuse, neglect, accident, incorrect power line voltage,
fire, flood or other Acts of God, or normal wear and tear.
The foregoing is in lieu of all other expressed warranties and SFC does not assume or authorize any party to assume for it any other
obligation or liability.
SFC DISCLAIMS ALL OTHER WARRANTIES EXPRESS OR IMPLIED, WITH REGARD TO THIS PRODUCT (INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS). IN NO EVENT SHALL SFC BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING FROM THE OWNERSHIP OR USE OF THIS PRODUCT OR FOR ANY DELAY IN THE
PERFORMANCE OF ITS OBLIGATIONS UNDER THIS WARRANTY DUE TO CAUSES BEYOND ITS CONTROL. SFC’S LIABILITY FOR
ANY AND ALL LOSSES AND DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER, ARISING OUT OF OR IN CONNECTION
WITH THE SALE, USE OR OWNERSHIP OF THIS PRODUCT INCLUDING WARRANTOR’S NEGLIGENCE, ALLEGED DAMAGED OR
DEFECTIIVE GOODS, WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT, SHALL IN NO EVENT EXCEED THE
PURCHASE PRICE OF THE PRODUCT.
ATTENTION
For your protection in the event of theft or loss of this product, please fill in the information below for you own personal records.

Model No. _____________________________________________ Serial No.______________________________________________

(Located on back or bottom side of unit.)

Date of Purchase _______________________________________ Purchase Price _________________________________________

Where Purchased _________________________________________________________________________________________________
