Ordering number : ENN*6298
N2599RM(OT) No. 6298-1/5
Features
• Very high resolution: 1616 × 1296 (H × V) pixels.
progressive scan
• 2/3 inch image area: 8.24mm × 6.61mm. Image diagonal
10.56mm
• Square pixel: 5.1µm × 5.1µm
• Color filter: R-G-B primary mosaic filter
• High sensitivity
• High dynamic range
• Low dark current
• Low noise
• Fast readout: 25 MHz horizontal drive frequency.
5 full-resolution images/s
• Electronic shuttering
• Supports monitoring modes
• Compact package: 20-pin leadless ceramic chip-carrier
(LCC)
Device Structure
• General
Frame-Transfer CCD with reduced storage section
Chip size: 9.49 mm (H) × 9.32 mm (V)
Package dimension
• Image Area
Unit cell size: 5.1 µm (H) × 5.1 µm (V)
Number of effective pixels: 1616 (H) × 1296 (V)
approx. 2094 k pixels.
Optical black: 12/Top + 12/Bottom 2/Left + 70/Right
Number of dummy lines: 4 /Bottom
Total number of pixels: 1688 (H) × 1324 (V)
approx. 2235k pix.
Effective Image size: 8.24 mm (H) × 6.61 mm (V)
Image diagonal: 10.56 mm (2/3 inch format)
Aspect ratio: 5:4 (or 4:3)
Color filter pattern: R-G-B; Bayer
Number of clock phase: 4
• Storage Area
Unit cell size: 5.1 µm (H) × 5.1 µm (V)
Number of cells: 1688 (H) × 298 (V)
Number of clock phase: 4
• Horizontal Register and Output Stage
Number of cells: 1696 (H) × 1 (V)
Number of dummy cells: 8/Front
Number of clock phase: 4
Output Stage: 3-stage source follower (open source)
Package Dimensions
unit: mm
3258
Preliminary
LC99452
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
2M pixel 2/3-inch Progressive Scan
CCD Image Sensor with Square Pixel
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft’s
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
1.49
1.05
0.44
0.635
1.075
2.0
Resin
Glass
Sensor
1.015
10.16
0.7
2.54
1.0
7.62
R0.3
R0.25
4.65
6.0
12.3
11.8
14.3
8.0
R1.0
8.6
0.15
1.0
(1.2)
(R0.6)
(R0.5)
1.2
Optical Center
[LC99452]
No. 6298-2/5
LC99452
Block Diagram and Pixel Arrangement
G B
R G
G B
R G
B
G
B
G
Vout
Phi-R
N-SUB VPW
Phi
1 to 4
Phi-S
1 to 4
Phi-H
1 to 4
Phi-R Vrd Vog
Vss
Vdd
A12757
Image area
Optical Black Area
Storage Area
Horizontal Shift Register
Output Amplifier
Pin Function
Symbol Description Symbol Description
N-sub N-Substrate Phi 1 to 4 Image area clock
Vpw P-Well Phi-S 1 to 4 Storage area clock
Vdd Power supply Phi-H 1 to 4 Horizontal register clock
Vss Power supply Source Phi-R Reset gate
Vog CCD output gate
Vrd Reset drain
Vout CCD output
No. 6298-3/5
LC99452
Modes of Operation
The LC99452 has been especially designed for high-resolution low cost digital photography in color full 1600 × 1280
resolution and real-time monitoring (preview) mode in color at reduced resolution. Two main modes of operation are
possible:
Still picture mode (mode-1)
In still picture mode, a 1600 (H) × 1280 (V) progressive scan image can be read out. A 'single shot' mechanical shutter is
required to obtain a 100% smear free image.
Preview mode (mode-2)
In preview mode, image with a reduced vertical resolution by on-chip data compression can be obtained. Progressive
scan images (mode-2), e.g. 120, 240 or 288 lines at up to 40 images/s, suitable for LCD displays can be selected by the
timing generator.
Clock Voltage Conditions
Parameter Symbol
Ratings
Unit Cap per phase
min typ max
Input resistanImage area pulses
Pulse amplitude V
PIF
11 12 13 V 5.5 nF
Phi 1 to 4
Low level V
LIF
0V
Storage area pulses
Pulse amplitude V
PSL
11 12 13 V 1.5 nF
Phi-S 1 to 4
Low level V
LSL
0V
Horizontal register pulses
Pulse amplitude V
PH
4.5 5.0 5.25 V 60 pF
Phi-H 1 to 4
Low level C1,C3 V
LH 13
0V
Low level C2,C4 V
LH 24
2.5 3 3.5 V
Reset gate pulses
Pulse amplitude V
PR
4.5 5 5.25 V 15 pF *
1
Phi-R
High level V
HR
21 22 23 V
Charge reset pulse on Nsub
V
PSUB
4.5 5 5.5 V
Note: *1. DC setting depends on RG clock-swing.
DC Electrical Characteristics
Parameter Symbol
Ratings
Unit I (mA)
min typ max
N-sub bias V
LSUB
20 24 28 V 2 *
1
P-well bias V
PW
67 9V2
Output circuit power supply
V
DD
19 20 21 V 5.5 *
2
V
SS
00 0V1 *
2
OG bias V
OG
3.5 4.0 4.5 V *
3
Reset drain bias V
RD
19 20 21 V
Notes: 1. V
LSUB
is set for optimal anti-blooming operation.
2. with RL = 3.3 kΩ, V
DD
should be adjusted at the same voltage as VRD.
3. OG setting depends on horizontal clock amplitude.
No. 6298-4/5
LC99452
AC Electrical Characteristics
Parameter Conditions
Ratings
Unit
min typ max
Transport frequency:
- horizontal 25 MHz
- vertical 1.56 *
1
3.125 MHz
Power consumption
mode 1 mW
mode 2 mW
Output impedance 400 Ω
Amplifier supply current (R
L
= 3.3 kΩ) 5.2 mA
Bandwidth (R
L
= 3.3 kΩ, CL= 2pF) 90 MHz
RMS readout noise @ 5 MHz BW (after CDS) 0.240 0.330 mV
Power supply rejection ratio at DC *
2
0.15 0.2 V/V
Notes: 1. Typical value for preview and movie mode.
2. V
DD
must be decoupled properly with a 100 nF decoupling capacitor close to the pin.
Performance Characteristics
Test conditions: Typical conditions
Image capture mode (mode-1) of operation
Integration time = 1/30 sec.( unless specified differently )
Test temperature 60°C; light source 3200 K; IR filter 1.7 mm BG40; F = 16
Parameter
Ratings
Unit
min typ max
green pixels 295 mV / lux
•s
Sensitivity red pixels 240 mV / lux
•s
blue pixels 175 mV / lux
•s
Saturation signal 840 1150 1320 mV / lux
•s
Qmax 40 50 60 k-electrons
Blooming suppression 100 x Qmax
Dark conditions:
Average number of dark signal electrons 25 electrons
per pixel after 1/30 sec integration
Dark signal shading 1mV
PS No. 6298-5/5
LC99452
