Sanyo HT28745, HT27745 User Manual

AS

Model Nos:
No. de Modelo:
N

o

de modèle :

HT27745
HT28745

ENERGY STAR

“As an ENERGY STAR®Partner, Sanyo
Manufacturing Corporation has determined
that this product meets the ENERGY STAR

®

guidelines for energy efficiency.”

As Real

As It Gets!

“Read this manual before assembling (or using) this product.”

Need assistance?

Visit our website at www.sanyoctv.com
or Call toll free 1.800.877.5032

We can Help!

Owner’s Manual
ENGLISH

Table of Contents . . . . 3

Manual de Instrucciónes
ESPAÑOL

Contenido . . . . . . . . . . 25

Manuel d’instructions
FRANÇAIS

Table des matières . . 49

Printed in U.S.A. SMC, March 2005
Impreso en U.S.A. SMC, Marzo 2005
Imprimé aux é.-U. SMC, mars 2005
Part No. / No. de Parte /
N

o

de pièce : 1AA6P1P4785––

Service Code / Código de Servicio /
Code de service : 610 319 9245

I
N

T

E

G

R

A

T

E

D

D

I
G

I
T

A

L

D

I
GI

T

A

L

DO

L
B
Y

D
OL

B
Y

C

H

CH

V
O

L

VO

L

P
O
W

E
R

P
O

W
ER

INT

E

GR

A

T

E

D

I
NT

E

G

RAT

E

D

D
I
G

I
T
A

L
T

U
N

ER

D
I
GI

T

A
L

T
U

N

E
R

D

I
G

I
T

A
L

D

I
G

I
T

A
L

D
O

L
B
Y

DO

L
BY

C

H

V

O

L

PO

W

E

R

HT28745

HT27745

Importado Por : Comercializadora México
Americana, S. DE R.L. DE C.V.
Nextengo No78
Col. Santa Cruz Acayucan
Del. Azcapotzalco, México D.F. C.P. 02770
RFC CMA 9109119L0
Telefono: 55-5328-3500

MediaStack-ATSC
the DTV software embedded in
this product copyright (c) 2004

by Zentek Technology, Inc.

All rights reserved.

R

Positioning the Appliance

1. Do not place your appliance on an unstable cart, stand, shelf or table. Serious
injury to an individual, and damage to the appliance, may result if it should
fall. Your salesperson can recommend approved carts and
stands or shelf and wall mounting instructions. An appliance and
cart combination should be moved with care. Quick stops, exces­sive force, and uneven surfaces may cause the appliance and
cart combination to overturn.

2. Slots and openings in the cabinet and in the back or bottom are provided for
ventilation. To ensure reliable operation of the appliance and to protect it
from overheating, these openings must not be blocked or covered. The open­ings should never be covered with a cloth or other material, and the bottom
openings should not be blocked by placing the unit on a bed, sofa, rug, or
other similar surface. This appliance should never be placed near or over a
radiator or heat register. This appliance should not be placed in a built-in
installation such as a bookcase unless proper ventilation is provided.

3. Do not expose the appliance to rain or use near water . . . for example, near
a bathtub, swimming pool, kitchen sink, in a wet basement, etc.

Hooking Up Outdoor Antenna

LIGHTNING PROTECTION FOR YOUR ANTENNA AND SET AS PER NATIONAL
ELECTRICAL CODE INSTRUCTIONS.

4. If an outside antenna is connected to the receiver, be sure the antenna system
is grounded so as to provide some protection against voltage surges and built
up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with respect to proper grounding of the mast and support­ing structure, grounding of the lead in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.

An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside antenna system
extreme care should be taken to keep from touching such power lines or cir­cuits as contact with them might be fatal.

Plug in the power cord

5. This product should be operated only from the type of power source indi­cated on the marking label. If you are not sure of the type of power supply to
your home, consult your product dealer or local power company. This
product is equipped with a three-wire grounding-type plug, a plug having a
third (grounding) pin. This plug will only fit into a grounding-type power outlet.
This is a safety feature. If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the grounding-type plug.

6. Power-supply cords should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them, paying particular atten­tion to cords at plugs, convenience receptacles, and the point where they
exit from the product.

Cleaning

7. Before cleaning, unplug the unit from the wall outlet. Do not apply liquid
cleaners or aerosol cleaners directly to the unit. Use a dry cloth for cleaning.

Service & Repair

8. Unplug the appliance from the wall outlet and refer servicing to qualified
service personnel under the following conditions:

A. If the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the appliance.
C. If the appliance has been exposed to rain or water.
D. If the appliance has been dropped or the cabinet has been damaged.
E. If the appliance exhibits a distinct change in performance.
F. If the appliance does not operate normally by following the operating

instructions, adjust only those controls that are covered in the operating
instructions. Improper adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the
appliance to normal operation.

9. Upon completion of any service or repair, request the service technician’s
assurance that only Factory Authorized Replacement Parts that have the
same characteristics as the original parts were used, and that routine safety
checks have been performed to determine that the appliance is in safe oper­ating condition. Unauthorized substitutions may result in fire, electrical
shock, or other hazards.

10. Never add accessories that have not been specifically designed for use with
this appliance as they may cause hazards.

11. For added protection during a lightning storm, or when the set is left unat­tended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna. This will prevent damage to the set due to lightning
or power line surges.

12. Never push objects of any kind into this product through openings as they
may touch dangerous voltage points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any kind on the product.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTI­TUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING
AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPA­NYING THIS UNIT.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

IMPORTANT SAFETY INSTRUCTIONS

CAUTION: PLEASE ADHERE TO ALL WARNINGS ON THE PRODUCT AND IN THE OPERATING INSTRUCTIONS. BEFORE OPERATING THE PRODUCT,
PLEASE READ ALL OF THE SAFETY AND OPERATING INSTRUCTIONS. RETAIN THIS LITERATURE FOR REFERENCE. Follow all instructions...

EXAMPLE OF ANTENNA GROUNDING
ACCORDING TO NATIONAL
ELECTRICAL CODE,
ANSI/NFPA 70

2

Need help?

Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032

NEC

- NATIONAL ELECTRICAL CODE

ANTENNA
LEAD IN
WIRE

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUND
CLAMP

ELECTRIC
SERVICE
EQUIPMENT

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

“Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the
NEC that provides guidelines for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building, as close to the point of
cable entry as practical.”

CHILD SAFETY

Sanyo is committed to making home entertainment safe and enjoyable.
Always use an appropriate table or stand when positioning your DTV.
Use appropriate brackets, braces, or straps to anchor your furniture in
place. But never screw anything directly to the television.

Do not place televisions on dressers, shelves, desks, carts, etc. where
curious or excited children could pull, push, or otherwise cause the unit
to fall and cause personal injury.

Never place toys or other items on top of
the DTV that could pique children’s
curiosity causing them to climb about the
furniture.

Always use stands that are designed to
support the size and combined weight of
your television and other electronic
devices.

A

S

VIDEO

IN L-AUDIO-R

Welcome to the World of Sanyo

Thank you for purchasing this Sanyo High-Definition Digital
Television. You made an excellent choice for Performance,
Reliability, Features, Value, and Styling.

Important Information

Before installing and operating this DTV, read this manual
thoroughly. This DTV provides many convenient features and
functions. Operating the DTV properly enables you to manage

those features and maintain it in good condition for many years
to come.

If your DTV seems to operate improperly, read this manual
again, check operations and cable connections and try the
solutions in the “Helpful Hints” section, page 22 of this
manual. If the problem still persists, visit our website at

www.sanyoctv.com or call 1.800.877.5032. We can help!

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . 2

To the Owner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

First-Things-First (Required Initial Setup) . . . . . . . . . . . . . . . . 5

Digital (DTV) Antenna Connection . . . . . . . . . . . . . . . . . . . . . . . . 5

Analog (RF) Antenna Connection . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Channel Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Auto Clock Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Antenna Selection (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

DTV Back—Jacks Locations & Functions . . . . . . . . . . . . . . . . . 7

Glossary of Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Choose Your Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Digital A/V Connections

Using the Component Jacks to connect a DVD Player

or Other Digital Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting Digital Audio Out Jacks to a Multi-Channel Receiver . . 9

Analog A/V Connections

Using the Analog Video Jacks to connect a VCR

(or Other Analog Device) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting Analog Audio Out Jacks to a

Stereo Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Using the Remote Control . . . . . . . . . . . . . . . . . . . . . . . 11 ~ 12

DTV Adjustment and Setup

How to Operate the On-Screen Menu . . . . . . . . . . . . . . . . . . . . . 13

Menu Navigation Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Channel Setup Options:

Channel Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Digital Cable Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Digital Add-On Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Antenna Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Channel Scan Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Initial Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Closed-Captioning Options:

Changing the Look of Digital Captioning

On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

To View Captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

V-Guide (Parental Control) Options:

To Block Movies or TV Programs . . . . . . . . . . . . . . . . . . . . 18

To Temporarily Unblock Movies or TV Programs . . . . . . . . . . 18

To Unblock Movies or TV Programs . . . . . . . . . . . . . . . . . . 18

TV Ratings (Age and Content-Based)

Symbol Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

MPAA Movie Ratings (Age-Based)

Symbol Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setup Menu Options:

Auto Date /Time Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Manual Date / Time Setting . . . . . . . . . . . . . . . . . . . . . . . . . 19

Digital Audio Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

DTV Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Menu Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Picture/Sound Adjustment Options:

Preset Picture and Sound Options . . . . . . . . . . . . . . . . . . . . 20

Manual Picture and Sound Adjustment . . . . . . . . . . . . . . . . 21

Color Enhancer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Scan Velocity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Helpful Hints (Problems/Solutions) . . . . . . . . . . . . . . . . . . . . 22

Warranty (Mexico) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Warranty (U.S.A. and Canada) . . . . . . . . . . . . . . . . . . . . . . . 24

Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

CONTENTS

3

Need help?

Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032

TO THE OWNER

 27” / 28” High-Definition Digital True Flat-screens
 Trilingual Menu Options (English, French, or Spanish)
 Built-in Digital and Analog Tuners
 Automatic Channel Search
 Auto Shut Off (no signal received after 15 minutes)
 3-Line Digital Comb Filter (for better picture detail)
 Adjustable Scan Velocity Modulation
 V-Chip for Movies and TV guidelines rating limits (parental control)
 Closed-Captioning: Analog EIA-608B

Digital EIA-708B

 Audio Modes: DTV—Main and Sub

NTSC—Stereo, Mono, and SAP

 Front Surround Sound
 Bass / Treble Sound
 Front speakers 6 x 12 cm (two)
 Factory preset adjustments for picture/sound
 Picture Shape: Letter box (HT27745 only), Zoom, Normal, and

Full (HT28745 only)

 Initial Channel (automatic selection)

 Receivable Formats: Digital Tuner for ATSC terrestrial broadcasts

and nonscrambled (ClearQAM) cable programs.
NTSC analog tuner for VHF/UHF or CATV

 Audio Format: Dolby

®

Digital for DTV and Analog for NTSC

 Channel Scan Memory
 Color Enhancer
 Auto Flesh Tone

 Receives 181 Analog Channels [VHF 2~13 and

UHF 14~69; Cable DTV 1, 14~125]; and
99 Digital Channels

 RF Antenna Input Jacks: Digital and Analog
 Component Video Input (Two Sets)

 Rear AV Input (Two Sets)
 S-Video Input (Two Sets)
 Optical Digital Audio Out
 Audio Out fixed
 Clock (auto clock)

 XDS (Extended Data Services) displays station call letters,

Title of show, and ratings when broadcast

 Sleep Timer (3 hours)
 32-Key Remote Control

FEATURES

SPECIFICATIONS

Picture Tube Size (Measured Diagonally):

HT27745- 27” True-Flat Screen Integrated HDTV
HT28745- 28” True-Flat Wide Screen Integrated HDTV

Scanning Format: 1080i [All Signals are Converted to 1080i]
RF Antenna Input: Analog–UHF/VHF/CATV 75 ohm

Digital–75 ohm

No Signal Reception: When tuned to an Analog Channel, and no
signal is present for more than 15 minutes, the DTV automatically
switches OFF. In Video Modes, DTV will NOT switch off automatically.

Power Requirement: Source: AC 120V, 60Hz
Power Consumption: 140 Watts (Average)
Sound: Two Speakers, size: 6 x 12cm
Amplifier: Built-in with 5.0W/ch

Jacks / Connectors:

Video 1 Input: S-Video1, Video and Audio L/R
Video 2 Input: S-Video2, Video and Audio L/R

Compo 2 Input: Component (Y/Pb/Pr), with

shared Video 2 Audio L/R Input

Compo 3 Input: Component (Y/Pb/Pr), and

Audio 3 L/R Input
Digital Audio Output: Dolby Digital (Optical)
Analog Audio Output: Audio L/R
Service Input Terminal: For Technical use only (Phone jack)

Size and Weight (approximately):

HT27745—27”

Horizontal Dim. (Width): 30.3 in. (770mm)
Vertical Dim. (Height): 23.0 in. (585mm)
Depth Dim. (Thickness): 19.5 in. (496mm)
Weight: 103.5 (lbs.), 47.0 (Kg)

HT28745—28”

Horizontal Dim. (Width): 33.8 in. (858mm)
Vertical Dim. (Height): 21.4 in. (543mm)
Depth Dim. (Thickness): 21.2 in. (537mm)
Weight: 92.3 (lbs.), 41.9 (Kg)

Specifications are subject to change without notice.

CAUTION: FCC Regulations state that improper modifications or un-

authorized changes to this unit may void the user’s authority
to operate the unit.

Trademarks Information:

Manufactured under license from Dolby Laboratories. Dolby and
the double-D symbol are trademarks of Dolby Laboratories

.

4

Need help?

Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032

This symbol on the nameplate means the product is
Listed by Underwriters’ Laboratories Inc. It is
designed and manufactured to meet rigid U.L.
safety standards against risk of fire, casualty and
electrical hazards.

5

Need help?

Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032

FIRST-THINGS-FIRST

This new high-definition digital television is capable of reproducing a crystal clear picture and exceptional
sound.

The signal makes the difference!

1

INITIAL SIGNAL CONNECTIONS

Analog RF Antenna Connection

•

Connect a Cable signal (with or without a cable
box), Satellite Receiver, or RF antenna to the
Analog RF input.

The analog tuner in this DTV receives Analog
Antenna signals, Analog Cable signals, or the RF
output from a Satellite Receiver, VCR, or cable box.

UHF/VHF/CATV

FROM ANT.

OUT TO TV

IN

OUT

CATV FRANCHISE NOTE: Cable
companies, like public utilities,
are franchised by local govern­ment authorities. To receive
cable programs, even with
equipment which is capable of
receiving cable channels, the
consumer must subscribe to
the cable company’s service.



DTV will select the correct Antenna mode for the type of Analog RF
signal connected automatically.



Use “Antenna Selection” in the Setup menu to change the Antenna
Mode.



DTV will switch off automatically after 15 minutes if there is no
signal reception (cable out or station not broadcasting).

Exception—When the Video mode is selected, the DTV will not auto-

matically switch off when signal reception has stopped for 15 minutes.



If you move the DTV to a new location, press the RESET key twice
after connecting the signal and turning on the DTV.

Analog Cable

RF

Antenna

Analog Satellite

Receiver

TV Back

VCR Back

NOTES: If you do not have a VCR connect signal directly

to DTV 75 (UHF/VHF/CATV) ohm terminal.
The only resolution available with any of these

connections, regardless of the original content, is
standard analog (SDTV).

Digital (DTV) Antenna Connection

•

Connect an RF antenna to the Digital Antenna In
terminal.

The digital tuner in this DTV receives HD signals
from an antenna. Digital signals from a STB are
received through a STB via the Component In jacks.

This DTV can receive and display ANY resolution
being broadcast (HDTV, EDTV, or SDTV).

DIGITAL

ANTENNA IN

RF

Antenna

DTV Back

UHF/VHF/CATV

FROM ANT.

OUT TO TV

IN

OUT

IN FROM

SAT.

CATV IN

OUT TO TV S-VIDEO

CH3
CH4

L-

-RAUDIOVIDEO

L- -RAUDIOVIDEO

UHF/VHF/CATV

FROM ANT.

OUT TO TV

IN

OUT

TV Back

VCR Back

TV Back

VCR Back

(Continued on next page.)

OR

OR

6

Need help?

Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032

3

CHANNEL SEARCH

When the television is powered on
for the first time, it automatically
checks for the presence of an RF
signal.

•

Press the POWER key to turn
on the DTV.

•

Then press the CHANNEL
UP key to automatically
search for available channels:
Digital (ATSC) and Analog (NTSC).

The Channel Search contains two processes that are
executed simultaneously for digital and analog
channels.

NOTES:

The on-screen message for digital search will appear with a
progress bar and percentile number displayed across the
bottom of the screen (to indicate activity) as the search process
continues. (Channel numbers will appear under the progress
bar only when a digital channel is found.)

Channel information found during the channel search is
stored in the Channel Scan Memory database. After the
channel search is completed, the DTV will tune to the lowest
Digital channel or lowest Analog channel if no digital channels
are found.

If the DTV does not detect any
digital or analog channels, a
message advising the viewer
to check the cables and
antenna connections will
appear. In this case, you must
press the CHANNEL UP key
again to repeat the channel
search process. If after two
searches the DTV still fails to detect any channels, the DTV
will tune to analog channel 3. These two channel searches

are necessary even if you plan to use the DTV only as a
monitor.

If no analog or digital channels are found after the

second search, Channel Search will default to off-air analog

channels 2 through 69 and digital channel D3-1. Select analog
channels using the remote control keypad. See page 11, item
number 3.

RECALL

MENU

CAPTION EXIT

VOL

ENTER

TUNER MUTE

RECALL

MENU

CAPTION
EXIT

VOL

ENTER

TUNER

MUTE

CH

4

AUTO CLOCK SETTING (Optional)

After channel search is complete, the DTV will begin
Auto Clock setting. This feature searches for a local
PBS station that is broadcasting an extended data
service signal. This signal is used to automatically
set the clock/day. (This
may take several
seconds.) To cancel auto
clock setting, press the
CHANNEL UP key. (To
set the clock manually,
see page 19.)

5

ANTENNA SELECTION (Optional)

To change the initial ANALOG tuning system setup
(from antenna to cable or cable to antenna), use
the on-screen menu. See “Antenna Selection” on
page 15.

2

INSTALL TWO “AAA” BATTERIES

IMPORTANT NOTE: Spent or discharged batteries must be recycled
or disposed properly in compliance with all applicable laws. For
detailed information, contact your local County Solid Waste
Authority.

•

Install two “AAA” Batteries
(not included) so that the
“+” and “–” marks on the
batteries match the “+”
and “–” marks inside
the Remote.

To review the Remote
functions, go to
Pages 11 ~ 12.



Remove the batteries if the remote control will not be used for a
month or more. Weak batteries may leak and cause damage.
(Normal battery life is roughly six months.)



If batteries have leaked in the Remote Control Unit, carefully wipe
the case clean and load new batteries.

7

Need help?

Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032

HDTV BACK—JACKS LOCATIONS AND FUNCTIONS

 Component Video Input (COMPO 2)—Connect

digital video equipment to the Y, Pb, Pr and Video 2
Audio L/R jacks. These jacks will automatically detect
the type of signal being received (HDTV, EDTV, or
SDTV). (See page 9.)

 S-Video (Video 1 and 2) Input—To enhance video

detail, use the S-Video (Video 1/2) jacks instead of the
Video jacks, if available on your external equipment.
(S-Video connections will override connections to the
Video 1/2 input jacks.) (See page 10.)

 Digital Audio Output—Use an Optical Audio cable to

connect the Digital Audio Output to an advanced
stereo home theater system equipped with Dolby

®

Digital 5.1. (See page 9.)

 Analog Audio Out (L/R) Jacks—Connect external

audio equipment here. (See page 10.)

 Component Video Input (COMPO 3)—Connect

digital video equipment to the Y, Pb, Pr and Audio 3
(L/R) jacks. These jacks will automatically detect the
type of signal being received (HDTV, EDTV, or SDTV).
(See page 9.)

 Audio/Video Input (VIDEO1/VIDEO2)—Connect

standard video equipment here. (See page 10.)

NOTE:

S-Video1/2 connections override the AV1/2

video composite connections.

 Analog Antenna Input (UHF/VHF/CATV)—Connect

an RF antenna, cable, or satellite receiver to this ter­minal as shown on page 5.

 Digital Antenna Input—Connect an RF antenna to

this terminal as shown on page 5.

 Service Terminal—For technical use only.

Y

P

b

P

r

COMPONENT VIDEO INPUT VIDEO AUDIO INPUT

VIDEO 2 VIDEO 1

COMPO 3

(MONO)

COMPO 2 AUDIO 3

S-VIDEO

VIDEO

AUDIO (MONO)

ANALOG

AUDIO

OUTPUT

L

R

LL

R

UHF/VHF/CATV

SERVICE

DIGITAL

AUDIO

OUTPUT

DIGITAL

ANTENNA IN

 









Audio Cables—Provides analog left/right
audio for your external equipment connec­tions.

Component: Y, Pb, Pr—Use these cables
to connect your component equipment.
This connection provides the best picture,
but does not include sound. (Cable colors:
Y = green, Pb = blue, and Pr = red.)

Composite Audio/Video (RCA type)—
Use these cables for standard analog
audio/video connections. Normally cables
are color coded: Yellow for Video, White for
(L) Audio, and Red for (R) Audio.

Coaxial Cable—Used to connect a signal to
your digital or Analog RF Antenna In terminal.

Optical Digital Audio—Use this cable to
connect the DTV ‘s digital audio output to a

multi-channel audio receiver.

S-Video Cable—This cable provide separate
luminance and color signals for higher reso­lution and better picture quality. Use this
cable instead of the regular composite video
cable (RCA type), when available.

NOTE: None of these cables are supplied with this DTV.

GLOSSARY OF CABLES

8

Need help?

Visit our Web site at www.sanyoctv.com or Call 1-800-877-5032

CHOOSE YOUR CONNECTION

Digital Signal Compatible External Cables Needed Go to
Connections Equipment

(Not Supplied)

Page

9

This DTV is designed to handle several different connec­tions making it compatible with Digital and Analog
devices.

In order to receive the best performance from your DTV,
choose your connection using this chart; then go to the
specified page for detailed instructions.

COMPONENT
(Y, Pb, Pr) IN

Will accept HDTV,
EDTV, or SDTV Video
content.

(Requires separate
audio connections.)

Component
Video
Cable

COMPOSITE VIDEO
OR

S-VIDEO IN

10

DIGITAL AUDIO
OUT

(Only available when
received as part of a
Digital RF signal.)

Optical
Digital
Cable

9

ANALOG AUDIO
OUT JACKS

10

Audio Cable

S-Video
Cable

Analog Signal Compatible External Cables Needed Go to
Connections Equipment

(Not Supplied)

Page

Composite
Video Cable

Satellite Receiver

Multi-Channel
Receiver

Satellite
Receiver

DVD Player

VCR

Stereo Amplifier
System

LEFT / RIGHT
ANALOG AUDIO IN

Audio Cable

Digital Cable Box
or DVD Player
