Sanyo HEC-DR5700 Instruction Manual

CONTENTS

PAGE

Be sure to read this manual thoroughly in order to ensure
proper use. In particular, make certain to read the section

“IMPORTANT SAFETY INSTRUCTIONS.”

Keep this manual in a safe place so that it can be found easily.

INSTRUCTION MANUAL

Chair Type Massager

IMPORTANT SAFETY INSTRUCTIONS

……… 1〜4

NAME/FUNCTION OF EACH PART ……… 5〜7

HOW TO PLACE THE MASSAGER …………… 8

HOW TO INSTALL THE STAND ………………… 9

HOW TO USE ……………………………………… 10

PRIOR TO USE …………………………………… 11

ADJUSTMENT OF CHAIR ………………… 12〜14

MASSAGING ……………………………… 15〜24

WHOLE BODY SENSOR AUTOMATIC COURSES

…… 15〜17

AUTOMATIC COURSES ………………… 18〜19

MANUAL COURSES ……………………… 20〜24

ADJUSTING MASSAGE INTENSITY ………… 25

AFTER USE ………………………………………… 26

MAINTENANCE PROCEDURES ………………… 26

CONTENTS OF MASSAGING …………… 27〜28

TROUBLE-SHOOTING …………………………… 29

SPECIFICATIONS ………………………………… 30

HEC-DR5700

1

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:
Read all instructions before using this appliance.

Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in doubt as to whether the product is
properly grounded. Do not modify the plug provided with the product – if it will not fit outlet, have a
proper outlet installed by a qualified electrician.

DANGER To reduce the risk of electric shock:

An appliance should never be left unattended when plugged in. Unplug from outlet when not in use,
and before putting on or taking off parts.

WARNING To reduce the risk of burns, fire, electric shock, or injury to persons:

Close supervision is necessary when this appliance is used by, on, or near children, invalids, or
disabled persons.

Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Return the appliance to a service center for examination
and repair.

Use this appliance only for its intended use as described in this manual. Do not use attachments not
recommended by the manufacturer.

Do not carry this appliance by supply cord or use cord as a handle.

Keep the cord away from heated surfaces.

Never operate the appliance with the air openings blocked. Keep the air openings free or lint, hair, and
the like.

Never drop or insert any object into any opening.

Do not use outdoors.

Do not operate where aerosol (spray) products are being used or where oxygen is being administered.

To disconnect, turn all controls to the off position, then remove the plug from the outlet.

If the supply cord or plug is damaged, it must be replaced by the manufacture, its service agent or
similarly qualified persons in order to avoid a hazard.

Massager is intended for Household Use Only.

Do not use the massager if you have been forbidden to use it by a doctor.

If you are currently receiving medical treatment of any type or if any of the following apply to you, be
sure to consult a doctor prior to using this appliance.

Example: If you are suffering from blood clots (embolisms), severe aneurysms, acute varicose veins,

skin inflammation or skin infections (including epidermal infections)

If you are using an internal electronic medical device such as a pacemaker which may be affected by electromagnetic interference
If you have any malignant tumors
If you suffer from heart trouble
If you have lost temperature sensitivity
If you are having your menstrual period, or if you are pregnant or have just given birth
If you have any sensory problems due to severe peripheral circulation problems caused by illnesses such as diabetes
If you have any injuries to your skin
If you require complete rest
If your body temperature is 38°C or higher (if you are feverish)

●

●

●

●

●

●

●

●

●

●

●

●

If you use the massager while any of the above apply to you, accidents or feeling of sickness may occur.

Example：If you have symptoms of acute inflammation [such as fatigue, chills or fluctuating blood pressure] or if you are suffering
     from general debility

If you suffer from osteoporosis, or if you suffer from acute pain from causes such as spinal injuries, sprains or torn muscles
If your spine is abnormal or bent
If you are planning to use the massager on a part of the body which is currently receiving medical treatment or which is diseased

2

All of the following information is important.
Be sure to follow the instructions carefully.

●

●

Do not allow persons in the following categories to use massager.

If this is not done, they may be burned.

Those who have a diminished sense of temperature or pain
 Those who cannot move their legs by themselves

Wipe off any dust that has collected on the prongs or the base of the power plug.

If this is not done, fire may occur.

Do not use the massager at any current other than the designated voltage.

If this is not done, fire or electric shock may occur.

Do not wind the power cord, remote control cord or sensor controller cord around the main unit,
remote control, sensor controller, or remote control stand.

Do not scratch, damage, process, excessively bend, pull, twist or bundle the power cord or place
heavy objects on it or clamp it.

If this is not done, unreasonable force may be applied to the cord, possibly resulting in fire or electric shock.

Moreover, be careful not to operate the back rest with the cord hooked on an obstruction.

If this is not observed, the power cord may become damaged and fire or electric shock may result.

Do not use the product if the power cord or power plug is damaged or if it does not fit securely into
the wall outlet.

Be sure to disconnect the power plug from the wall outlet before cleaning. Do not pull out the power
plug with wet hands.

If this is not observed, electric shock, short-circuits or fire may result.

Do not place anything other than the remote control and the sensor controller respectively on the
remote control stand.

If this is not observed, electric shock or injury may result.

Be sure to check that there is no-one (children in particular), or any pets under the foot rest and that
there are no other obstructions in the way before tilting back the back rest or lowering the foot rest.
In addition, do not leave the foot rest in the raised position.

If this is not done, the stand may break, resulting in injury.

Do not allow people to use the massager if they are unable to clearly indicate their intentions or if
they do not know how to operate the massager.

If this is not observed, injury may occur.

Do not let children use the massager. Do not let them play on or around the massager or allow them
to come near the massager while it is being used.

Be careful not to put your hand or foot into the spaces between any moving parts, including into the
space between the back rest and arm rest or into the space at the underside of the back rest or
between the foot rest and the seat or into the space under the foot rest. Furthermore, do not place
your hands, feet or head inside the upholstery of the massager.

Be sure to check that the upholstery is not torn before using the massager. If a tear is found, stop
using the massager immediately, disconnect the power plug from the wall outlet and consult the
place of purchase.

If this is not observed, injury may occur.

Do not use the massager on the head, the chest, the abdomen or on joints such as the elbows or
knees. In addition, do not place your hands, feet or arms between the massaging rollers.

Do not use the massager if the upholstery is torn, otherwise injury or electric shock may occur.

Do not stand or sit on the arm rests, foot rest or back rest.

If this is not observed, you may fall down and injury may occur.

If this is not observed, there is the danger that you may start to feet sick or an injury may occur. (When
massaging the nape of the neck, place a soft towel on the neck in order to avoid strong stimulation.)

3

IMPORTANT SAFETY INSTRUCTIONS (continued)

WARNING To reduce the risk of burns, fire, electric shock, or injury to persons:

Do not suddenly release your hand while raising the foot rest manually. To ensure safety, release
your hand gently from the foot rest.

Do not raise or lower the foot rest while your feet are enclosed in it for an air massage.

If this is not observed, injury may occur.

Never attempt to dismantle the massager. Do not allow any person other than a qualified repair
technician to dismantle or repair the massager.

If discomfort or pain is felt during use, stop using the massager and consult a doctor immediately. In
addition, if the massage force feels too strong, stop using the massager earlier than planned.

Otherwise, if you continue using the massager under such conditions, an unexpected accident may occur.

If this is not observed, fire, electric shocks or injury may occur. Ask the place of purchase of your nearest
Customer Service Center (separate sheet) if repairs are required.

If the massager has not been used for a long time, check that it operates correctly and safely before
using it. In addition, check that there are no problems with the cords and other parts.

After use, be sure to set the POWER switch to the “OFF” position.

If this is not done, accidents or injury due to a child’s mischief may occur.

If this is not done, accidents or injury may occur.

Do not use the massager for any other purpose than as a massager or chair.

If this is not done, accidents or injury may occur.

Do not use the massager together with other medical instruments.

If this is not observed, the user may feel sick or it may cause other health problems.

If a power failure occurs, set the POWER switch to the “OFF” position immediately and disconnect
the power plug from the wall outlet.

Insert the power plug securely into the wall outlet.

If this is not observed, electric shock, short-circuits or fire may result.

If this is not done, an accident or injury may occur when the power is restored.

Clean the massager after use so that it will be ready for the next use, and store it in a place which is
low in humidity.

Do not attempt to disconnect the power plug by pulling the cord, but always by holding the power
plug and pulling it out. Also, clean the dust off the power plug periodically.

If dust or moisture collect in the massager, fire, electric shock or problems with operation may occur.

If the massager stops working or any other problem occurs with it, stop using it immediately to
prevent accidents, disconnect the power plug and ask the place of purchase to carry out inspection
and repair work.

If this is not observed, electric shock, short-circuits or fire may result.

Do not use the massager on top of a heated carpet or other heater, or near a stove or other heat sources.

If this is not observed, fire may occur.

If this is not done, fire due to electric shock, current leaks or short-circuits may occur.

Do not use the massager in bathrooms or in places with high humidity.

If this is not observed, electric shock may occur.

Before using the massager, check all switches and other parts while referring to this instruction
manual to make sure they all operate correctly.

Always be sure to disconnect the power plug from the wall outlet when not using the massager.

If this is not done, the insulation may deteriorate and electric shock, current leaks or fire may occur.

For safety, check the position of the massaging rollers before leaning slowly back on the massager.
Do not twist the body, but lean straight back on the massager, so that the massaging rollers are
in position on either side of the spine.

Do not use the massager for more than 20 minutes at a time. In addition, limit the use of the
massager on one point to 5 minutes or less.

Leaning back abruptly on the massager may injure the spine or result in some other injury.

Using the massager continuously for long periods of time will apply more stimulation than is necessary and
may result in adverse effects or injury.

4

Do not hang anything from the back pad or head rest, or pull the back pad or head rest forcibly.

If this is not observed, the head rest may come off and injury may occur.

Be careful not to spill water over the remote control, sensor controller, seat, or foot rest.

If this is not observed, electric shock, short circuit or fire may occur.

Do not use the massager on bare skin.

If this is not observed, injury may occur.

At first, do not attempt to recline the seat deeply or lean on the back rest forcibly (until you have
become accustomed to massaging).

If the massaging force is too strong at first, it may result in adverse effects or injury.

Do not move the massager while a person is sitting in it.

If this is not observed, the massager may fall over and injury may occur.

Do not sit down or get up from the chair while the foot rest is raised or back rest reclined.

If this is not observed, injury may occur.

The maximum permissible weight of the user is 120 kg.

Otherwise, an accident may happen or damage to the machine may result.

Place the massager main unit on a level floor surface.

If it is placed on an unstable surface, it may fall over and injury may occur.

Be careful not to fall asleep during massaging.

If this is not observed, injury may occur.

5

Stand

NAME/FUNCTION OF EACH PART

Seat

Cord

Power plug

Installation screws

(3 screws)

Check for the accessories
first.

Stand

Used when moving
the chair.

Back rest

Back pad

Arm rest

Head rest

Remote control

Sensor controller

Massaging rollers

Foot rest

Casters

Used to turn on the power
source.

Remote power switch

＊

The remote power switch

 isdesigned to "halt standby

power consumption"
while the POWER switch
on the main unit is left on.

POWER switch

Used to turn on/off
the power source.

ON

POWER

6

SPEED ADJUST buttons

WIDTH ADJUST buttons

FOOT REST buttons

POSITION ADJUST buttons

RECLINING buttons

UPPER BODY STRENGTH ADJUST buttons

LOWER BODY STRENGTH ADJUST buttons

SOLE WARMER button

HOME POSITION button

BEST POSITION button

INSTANT STOP button

AUTOMATIC COURSE buttons

COVER

＊

All display icons are shown here
for explanation.

Remote control

OPERATION ON/OFF button

MANUAL (LOWER BODY)
MASSAGE buttons

MANUAL (UPPER BODY)
MASSAGE buttons

MANUAL SELECT button

WHOLE BODY SENSOR AUTOMATIC COURSE buttons

Used to return the back rest, foot rest and seat to
their home positions.

Used to adjust the back rest, foot rest and seat to
the two preset best positions.

Used if you have felt abnormal physical sensation
or want to stop the massager immediately.

Adjusts the strength of upper body massaging
(drum roll) in five stages.

Adjusts the strength of lower body and
air course massaging in three stages.
During the Whole Body Sensor Automatic
Courses, the lower body massaging can
be turned off.

Used for switching the sole heater
operation ON/OFF. (When the heater
switch is “ON”, the lamp is illuminated.)

Open the cover when using
manual massage and when
turning sole massage on and
off.

Used to select the desired type
of lower body air massaging.

Used to select the desired type
of upper body massaging.

Used for manual massaging.

Adjusts the width of the
massaging rollers in five stages.

Adjusts the speed of the massaging rollers in five stages.

Used to select the desired type of Automatic Course.

Used to select the desired type of Whole Body Sensor Automatic Course.

Used for switching the massaging operation ON/OFF.

Used to adjust the UP/DOWN position of massaging rollers.

Adjusts the angle of the foot rest.

Adjusts the angles between the back rest, seat and the foot rest.
The back rest, seat and foot rest are moved in conjunction with each other.

7

NAME/FUNCTION OF EACH PART (continued)

＊The remote power switch cuts the
 power supply after approximately
 3 hours since you turned on the
 switch.

REPEAT! display

MASSAGE ADJUST display

STIFFNESS display

The right side of the lamp indicates the degree of
stiffness, and the left side of the lamp indicates
the degree of relaxation.
The more the right side of the lamp is illuminated,
the higher the degree of detected stiffness.

Body areas that can be massaged.
Areas where stiffness has been detected.

SOLE WARMER display

Shoulder position measurement /
Original position display

MASSAGE OPERATION
display

WHOLE BODY SENSOR
AUTOMATIC COURSE display

Turns on during a Whole
Body Sensor Automatic
Course. ( flickers)
does not light up if
the fingers (hand) are not
placed on the sensor.

Illuminates if the fingers (hand) are not
placed on the sensor during a measurement
of stiffness in the Whole Body Sensor
Automatic Courses.

(Remote control display)

Sensor controller Remote power switch

Repeat button

RECLINING buttons

Sensors

The ”SHOULDER” icon flickers when the figure
(the shoulder position) is being measured, and
”ADJUST” lights up when the measurement is over.

Displays the operation of the
current massage technique.

Turns on when the sole heater
is on.

TWIST AIRBAG DISPLAY

Blinks during twist airbag
operation.

The degree of perspiration is
measured if the fingers are placed
on the sensors during a Whole
Body Sensor Automatic Course.

Displays the adjusted level of the strength
and speed of massaging and the width
of massaging rollers.
When these displays turn on, you can
adjust them with each adjust button.

If this button is pressed during
Whole Body Sensor Automatic
Courses or Automatic Courses,
the current massage will be repeated
once.

Adjusts the angle between the
back rest, seat and the foot rest.
The back rest and foot rest are
moved in conjunction with each
other.

Remote control can be used to turn
on this remote power switch after
turning on the POWER switch on
the main unit.

Turns on during Whole Body Sensor
Automatic Courses and Automatic Courses.
The ring lights up by pressing the REPEAT!
button when you want to repeat your
desired massage during the course of
massaging.
While the degree of stiffness is being
measured in a Whole Body Sensor
Automatic Course, the result
is displayed with the color
of the ring.

Green: Relax
Orange: Slight degree of stiffness
No display: High degree of stiffness

8

Press the BEST POSITION
button to fold down the
back rest.

NOTE

21

Carpet

50cm or
more

60cm or
more

Foot rest

Back rest

Back rest

Casters

Foot rest

Decide where to place it

How to move the massager

HOW TO PLACE THE MASSAGER

When carried by two people.

Lay a carpet, etc. on the set-up
area.

Ensure there is sufficient space
to allow the massager to recline.

When moving using the casters.

NOTE

CAUTION

●

●

●

●

●

●

●

●

●

●

●

●

Hold by the back rest and foot rest when moving. Lift up the front and move using the casters.

Do not suddenly release your hand while
raising the foot rest manually.

Before moving the massager, be sure to remove the
power plug from the outlet.

Be careful not to step on the power cord, remote
control or sensor during movement.

Be sure to move the massager with the assistance of
another person on an easily damaged floor surface
or concrete surface.

Place the massager on a level floor surface.
Keep the massager at least 1m away from AV products like a TV or radio.
Otherwise, the program may be disturbed by noise.
Do not keep the massager in a place with high humidity like a bathroom.
Do not keep the massager in a place where it will be exposed to direct sunshine for an extended period, or in
a place near a heater where the temperature may reach high levels.

To prevent damaging the floor and muffle the
noise while massaging.

In order not to touch the wall or other things
when reclined, allow a clearance of 50cm or
more to the front and 60cm or more to the
back.

ON

POWER

9

HOW TO INSTALL THE STAND

Installation
screws

hand screw

2

1

Tools needed: Phillips (crosshead) screwdriver (＊screwdrivers are not included)

If the remote
control stand
moves too
loosely,
tighten the
hand screw.

Secure the stand on the right-hand
side of the arm rest, using the
installation screws (3 screws).

Put the remote control on the
remote control stand (

upper part

).
Put the sensor controller on the
sensor controller stand (

lower part

).

5

4

Place the remote control cable into
the hook on the right side of the
sensor stand.

Using the hook-and-loop fasteners
attached to the case, fasten it
around the sensor controller stand,
as shown in the figure.

3

Place the sensor cable into the
hook on the left side of the sensor
stand.

Put the remote control on the remote control
stand in a tilted position as arrow

① shows,

and then push it in the direction of arrow

②.

①

②

Remote control
stand

Remote control

Sensor
controller

Sensor controller
stand

Hook

Sensor controller
cord

Stopper

Attach so that the
stopper is set into
the top of the hook.

Remote control cord

Hook

Form a ring with the hook-and-loop fasteners
and fasten it around the sensor controller stand.

Sensor
controller
stand

Hook

-and­loop
fasteners

Hook

-and­loop
fasteners

Hook

-and­loop
fasteners

POWER

10

HOW TO USE

①

③

Press the OPERATION ON/OFF button.

Select a massaging course.

②

Adjust the angle of back rest, seat and foot rest with the BEST POSITION button,
RECLINING button and FOOT REST UP and DOWN button.

1

Turn on the power switch.

Turn on the remote power switch.

The procedure for use of the massager is explained here. See the indicated pages for details.

Prior to use, make certain to read the “IMPORTANT SAFETY INSTRUCTIONS”. (Page 1 - 4)

4

Turn off the power and finish the massage.

REFRESH

RECOVERY

RELAX
FINE

Massages concentrating on tapping,
kneading and drum roll which is
designed to promote blood circulation.

Tapping massage to ease muscle fatigue

Kneading massage to relax the whole body

Massages the whole body gently
(reduced time course)

NECK & SHOULDER

LOWER BACK

LOWER BODY

Massages mainly the neck and
shoulders

Massages mainly the waist and
lower back

Air massage mainly on the legs and
soles of the feet

COMFORT AIR COURSE

Air massage mainly on the waist and
legs

27 massages for upper body, and air massaging for waist,
buttocks, legs, and soles.

WHOLE BODY SENSOR
AUTOMATIC COURSES

Custom whole
body massage
focused on areas
of detected stiffness

AUTOMATIC COURSES

MANUAL COURSES

Type of course

Features of course Sub-courses Features of program

Easy 1 or 2-button
operation

Full programmable
upper and lower
body massage

(See page 20 - 24)

(See page 18 - 19)

(See page 15 - 17)

3

2

Massaging.

(See page 11)

(See page 11)

(See page 12 - 14)

(See page 15 - 24)

(See page 26)

＊

Massaging of each course is possible

without placing fingers (hand) on
the sensor. In this case the degree
of stiffness is not detected.

Massages automatically by
effective combination of
kneading, tapping, stroking
shiatsu, spine stretching,
and lower body (air) mas­sage.

Measures the degree of stiffness in
each part of the body when the
fingers (hand) are placed on the
sensor, and massages automatically
according to biofeedback.

Massages with your own
adjustment of massage
types such as kneading,
tapping, drum roll, stroking
shiatsu, spine stretching, and
lower body (air) massage.

When the button is pressed, the lamps of the sole warmer and remote control will illuminate,and the
sole warmer will turn on.
When the foot rest is fully lowered, the foot rest will rise a little.
When the massaging rollers are not located in the upper section, the massaging rollers will move to the
upper section and stop.

(During the movement, the icon of “ORIGIN” on the remote control flickers.)

●

●

●

ON

POWER

11

CAUTION when massaging

PRIOR TO USE

1

2

3

WARNING

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

CAUTION

At first, do not attempt to select a strong method of
massaging (until you are accustomed to massaging).

Do not attempt to recline the back rest deeply, lean on
the back rest forcibly or massage without the back pad.
Do not attempt to continuously use the massager
on one place for an extended period.
Do not attempt to speed up the movement of the
massaging rollers or increase the strength of massage.

Otherwise, strong massaging at first may result in
injury.
Particularly, aged persons and those who have weak
bones need to use the massager with great care.

Check the upholstery of the chair.

Prior to use, be sure to raise the back pad in order
to check that the upholstery is not torn.
Also check that the upholstery covering other parts
is not torn either. If a tear is found, however small,
stop using the massager immediately, unplug the
power source, and obtain service. Do not use the
massager if the upholstery is torn, otherwise
injury or electric shocks may occur.

Check the power cord, remote
control cord and sensor controller
cord.

Check that there is neither breakage nor damage
to the cords.
Check that the cords are not caught between the
back rest and the arm rest, and that they are not
placed beneath the massager.

How to connect the power source.

①Connect the power plug to an outlet.
②Set the POWER switch to the “ON” position.
③Turn on the remote power switch (LED goes on.).

●

The remote power switch
cuts the power supply
after approximately 3
hours since you turned
on the switch.

The following persons are requested to consult a doctor
prior to use. Otherwise, the user may feel sick or an
injury may occur.

Those who are using self-contained medical electronic
equipment that is likely to be affected by electromagnetic
interference (e.g. a pacemaker)
Those who have malignant tumors
Those who suffer from heart trouble
Those who have lost temperature sensitivity
Those who are in the early-pregnancy period or in the
post-delivery period
Those who suffer from sensory disturbance caused by an
advanced peripheral circulatory disturbance such as diabetes
Those who have skin lesions
Those who require complete rest
Those who have a body temperature of 38°C or more
(at the fever stage)
Example: those who are suffering from strong acute

inflammation symptoms (fatigue, chill, blood
     pressure change, etc.), and from weakness

Those who suffer from osteoporosis, and from acute painful
conditions such as fracture of spine, sprain, pulled muscle, etc.
Those whose spine is abnormal or bent
Those who desire to use the massager on a part of the body
that is diseased or receiving medical treatment

If discomfort or pain is felt during use, stop using the
massager and consult a doctor immediately. In addition,
when the massage force is felt strongly, stop using it
earlier than planned. Otherwise, if the user continues
using in such a way, an unexpected accident may occur.

Press

Power switch

Remote
power
switch

LED

Do not use the massager on the head, the chest, the
abdomen or on bones (elbow, knee, etc). In addition, do
not put your hand, foot or arm between the massaging
rollers. Otherwise, the user may feel sick or an injury
may occur. (When massaging the nape of the neck,
put a soft towel on the neck in order to avoid strong
stimulation.)

Those who are forbidden by a doctor to receive massage.

Example: Those who suffer from thrombosis (embolism),

severe aneurysm, acute varicose veins, various
     types of dermatitis, skin infections (including
     inflammation of subcutaneous tissue), etc.

The following people should not use the massager,
otherwise burns may occur.

People who are less sensitive to temperature and pain
People who cannot move their feet by themselves

Aim to use the massager for up to 20 minutes each
time. Limit the use of the massager on one point to
5 minutes or less. Also, the total time to massage in
one day should be not more than 30 minutes in total.
Otherwise, the continuous use of the massager on one
point for an extended period may result in adverse
effects or injury.

Do not use the massager on bare skin.
Otherwise, an injury may occur.

Be careful not to fall asleep during massaging.
Otherwise, an injury may occur.

①

②

③

12

ADJUSTMENT OF CHAIR

Before sitting on the massage chair

Head rest

Center of the chair

Foot rest

Back rest

Foot rest

NOTE

Bring all parts of the massage chair to
their home position by pressing the
HOME POSITION button.

1

Install the head rest.

2

Sit on the center of massage chair.

 Sit deeply in the massage chair so that the waist

touches the back rest.

3

Adjust the position of the head rest.

 During the massage, adjust the head rest so that it does

not touch the shoulders.

4

Press the OPERATION ON/OFF button.

 When the button is pressed, the lamps of the sole warmer and

remote control will illuminate, and the sole warmer will turn on.

When the foot rest is fully lowered, the foot rest will rise a little.
 When the massaging rollers are not located in the upper

section, the massaging rollers will move to the upper section
and stop. (During the movement, the icon of “ORIGIN” on the
remote control flickers.)

 Sitting on the massage chair while the foot rest is being raised is

dangerous. Be sure to lower the foot rest completely before sitting on
the massage chair.

 The chair will be automatically brought to its home position by

pressing the HOME POSITION button.

 Do not attempt to climb onto or off the seat by stepping

on the foot rest. Do not attempt to place anything upon or
sit on the foot rest. The user may fall over, resulting in an
accident or injury.

NOTE

 The head rest contains a weight, so do not shake it or

throw it around, otherwise it may cause injury.

 For safety, check the position of the

massaging rollers before leaning slowly back
on the massager. Do not twist the body, but
lean straight back on the massager, so that
the massaging rollers are in position on either
side of the spine.

Remove the Hook­and-loop fasteners
and pass the cord
through.

Align the Hook­and-loop fasteners.

Hook-and-loop
fasteners

Cord

Press

●

●

●

●

●

●

●

●

●

●

CAUTION

13

ADJUSTMENT OF CHAIR (continued)

 Reclining positions change automatically at each press of the button.

(Button illuminates while reclining and flickers when in position)

When switched from BEST POSITION 1 to 2, the foot rest is raised first, and moves to the set angle.
 Reclining can be stopped during the reclining motion by pressing either the BEST POSITION button,

HOME POSITION button, RECLINING button, FOOT REST button, OPERATION ON/OFF button, or STOP
button.
When the reclining motion is stopped by pressing the STOP button, press the OPERATION ON/OFF
button to resume the operation.
When the reclining motion is stopped by pressing buttons other than the STOP button, press the desired
button for motion.

 When the back rest and foot rest angles are adjusted from the BEST POSITION 2, roller massage can be

selected.

 Do not attempt to recline the back rest deeply at first (until the body is accustomed to massaging),

otherwise the massage force may be too strong.

 Be sure to check that there are no people (particularly children) or pets around the massager prior to

adjusting the back rest. It may result in an accident or injury.

 While massaging the legs, do not attempt to recline the back rest when the legs are squeezed by the air

bags. Do not pull the legs out forcibly, this may result in injury to the legs.

 When adjusted at BEST POSITION, the seat is lowered together with the above mentioned movement. (It

is not possible to adjust only the seat.)

 For the sake of safety, if the UP ( ) button is pressed with the seat raised, the foot rest may be raised

briefly before going down.

OR

(Remote control) (Sensor controller)

Raise the back rest, and
lower the foot rest by
continuously pressing
the UP ( ) button.

Recline the back rest, and
raise the foot rest by
continuously pressing
the DOWN ( ) button.

NOTE

Adjustment range

Approx. 50°

120°

Adjustment range Approx. 85°

Back rest

Foot rest

5

BEST POSITION 1

Posture suited for whole body massaging

BEST POSITION 2

Posture suited for lower body massaging

BEST POSITION 1

(Slow flickering)

BEST POSITION 2

(Rapid flickering)

＊

Automatically starts massaging in Air
Course (Roller massagecannot be
selected)

Press

Adjust the angle of back rest, foot rest, and the seat.

Press the BEST POSITION button.

Pre-set Angles

Keep the RECLINING button pressed until the desired angle is achieved.

Custom Angles

●

●

●

●

●

●

●

●

●

14

6

Adjust the angle of the foot rest.

Foot rest can be adjusted independently.

 Keep the FOOT REST button pressed until the desired angle is

achieved.

 When massaging the soles or calves, adjust the angle so that the

massaging part of the foot rest touches the soles or calves.

To return the massager to
the home position,
press the HOME POSITION button.

 The HOME POSITION button will illuminate and the

massager will return automatically to the home
position.

 The foot rest is raised first, and then goes down

completely.

Back rest

Foot rest

Adjustment range

Approx. 85°

Foot rest

Raise the foot rest by
continuously pressing the
UP ( ) button.

Lower the foot rest by
continuously pressing the
DOWN ( ) button.

 Do not suddenly release your hand while raising the

foot rest manually.
For safety, be sure to lower the foot rest slowly using
your hand.

(Remote control)

Press

●

●

●

●

●

WARNING

15

MASSAGING (WHOLE BODY SENSOR AUTOMATIC COURSES)

1

Press the OPERATION ON/OFF button.

 When the button is pressed, the lamps of the sole warmer and remote

control will illuminate, and the sole warmer will turn on.

When the foot rest is fully lowered, the foot rest will rise a little.
 When the massaging rollers are not located in the upper section, the

massaging rollers will move to the upper section and stop.
(During the movement, the icon of “ORIGIN” on the remote control
flickers.)

5

Grip the sensor while touching with
your fingers (hand) at two sensor
points.

Refer to the page 27 and 28 regarding the contents of Whole Body Sensor Automatic Courses.
 Change of course during massaging, or change to the Automatic Course or the Manual Courses, is possible.

 Be sure to place your fingers (hand) on the sensor. The degree of stiffness cannot be measured if your

fingers (hand) are not placed on the sensor. (If your fingers (hand) are not gripping the sensor, “Grip the
sensor” on the remote control will be illuminated.) If your fingers (hand) are not touching the sensor
points, massages will be carried out according to the standard operation of the selected course.

 When the user’s skin is dry, the degree of stiffness may not be measured correctly. In such a case, slightly

moisten the fingers (hand) using hand cream and place the fingers (hand) on the sensor again.

2

Turn the sole warmer on or off.

 Sole warmer will be turned on or off each time the SOLE WARMER button is pressed. (The button is

illuminated while the sole warmer is on.)

 If you feel that the sole warmer is too hot, turn it off by pressing the SOLE WARMER button.

＊When the room temperature is low such as in winter, it takes some time to warm up or you may barely

feel heat.

4

Press the desired Whole Body Sensor Automatic Course button.

Sensors

Underside of sensor

Sensor controller

3

Adjust the positions of the back rest and the foot rest. (See page 12 - 14)

RECOVERY RELAX

Kneading massage
to relax the whole
body

REFRESH

Tapping massage to ease
muscle fatigue

FINE

NOTE

Massages concentrating on
tapping, kneading and drum
roll which is designed to
promote blood circulation.

Massages the whole
body gently (reduced
time course)

Press

●

●

●

●

●

●

●

●

●

16

 The massaging that corresponds to the

pressed button will stop. (The Massaging
rollers will stop at that point.)

 All the massaging will stop.

(The massaging rollers are moved to the
upper position and remain in that position.)

 All the massaging will stop and the lamp of the remote

control will turn off.

 When you want to restart massaging, press the

OPERATION ON/OFF button. (The massaging rollers
move to the upper position and remain in that
position.)
After the movement, repeat the operation to begin a
massage.

 Massage in relaxed condition as much as possible. The degree of stiffness may not be measured correctly

when the user is given stimulation other than sensor massage.
Examples of this are if the user massages immediately after taking a bath or while watching TV.

 The measurement result indicates the stiffness according to the body's biological reaction (the amount of

perspiration from fingers) to the sensor massage, so it may differ from the stiffness the user actually feels.

 Massaging rollers are moved to the upper position, and stop massaging automatically.

The beep sounds and the lamp on the remote control will turn off.

 The massaging time differs according to the detected stiffness, but the maximum is approx. 20 minutes.

 Check if the position of shoulder is correct. If not, adjust the position using the POSITION ADJUST buttons.

(The POSITION ADJUST buttons can also be used while massaging is in progress.) (See page17)

7

Adjust the strength of massage.

③ Massages according to detected stiffness.

Adjusts the operation and strength of standard massaging
according to the measured degree of stiffness.
→Massaging operation and the display of remote control.
(See page 17)

■

Finishes massaging automatically by timer operation.

6

Starts massaging automatically.

①

Measure the position of shoulder.

② Sensor massaging will start.

Measures the degree of stiffness in each part of body with the
sensor and informs of the degree of stiffness.
→Massaging operation and the display of remote control.
(See page 17)

NOTE

If you have felt abnormal physical sensation or want to stop the massager immediately

To stop the massage during operation.

Press the OPERATION ON/OFF button.

Press the INSTANT STOP button.

Press the button for the current operation.

(See page 17)

●

●

●

●

●

● ●

●

●

17

(Remote control display)

Massaging
rollers

MASSAGING

(WHOLE BODY SENSOR AUTOMATIC COURSES

)

(continued)

Displays the aim of massaging positions, the type of
massaging, the stiffness, body pressure and the
remaining massaging time on the remote control.

The explanation uses promoting blood
circulation as an example.

SENSOR MASSAGE

Massaging according to the degree of stiffness

Displays the position where the
stiffness has been detected.

Adjusting the strength of massage

NOTE

Massaging operation and display of remote control

Measurement of shoulder position

Massaging rollers move up and down
to measure the position of shoulder.

(Sit deeply on the massage chair and raise your
head slightly. The matching of the position of
shoulders may not be possible if the head is
leaning on the back rest.)

Massaging operation at recognized
position of shoulder.

Check that massaging rollers match
the position of your shoulder.
If not, when the lamp of is
flickering (a beep sounds),
adjust the position by pressing
the POSITION ADJUST buttons.

The massaging rollers are
moved up or down by 1cm
each time the POSITION
ADJUST button is pressed.

When it is difficult to
adjust with POSITION
ADJUST button, move
your body for adjustment.
The height that can be
adjusted is between
approx. 150 to 180cm.

Decides the position of shoulder.

Measurement of the degree of stiffness.

The sensor will display the positions of stiffness (those
where stiffness has been detected) by measuring the
amount of perspiration from your hand in reaction to
sensor massage.
When measuring the degree of stiffness, the result is
displayed by the ring around the REPEAT! (See page 7)
When the measurement is over, a beep sounds.

 Each time the UPPER (DRUM ROLL) button is pressed, the strength of

upper body (drum roll) massaging can be adjusted in five stages.
(The strength is displayed by the lamp on the remote control.)

 Each time the LOWER BODY STRENGTH ADJUST button is pressed, the

strength of lower body massaging (air) can be adjusted in three stages.
(The strength is displayed by the lamp on the remote control.)

＊If you continue to press the “ ” button until the illumination of the

lower body strength scale turns off, you can turn off the massaging of
the lower body. If you press the “ ” button, the massaging will
resume.

When it is felt that the massaging on the soles or calves is too strong even when reducing the
strength of lower body (air) massaging, put a towel etc. on those massaged parts.

Position too high

Position too low

Appropriate position

●

●

●

●

18

１

６

４

５

３

２

MASSAGING (AUTOMATIC COURSES)

① Measure the position of shoulder.

② Starts the massaging of selected course.

5

Massaging will start automatically.

6

Adjust the strength of massage. (See page 19)

4

Press the desired Automatic Course button.

Massages mainly
the neck and
shoulders.

NECK & SHOULDER

LOWER BACK

Massages mainly
the waist and lower
back.

LOWER BODY

Air massage mainly
on the legs and
soles of the feet.

COMFORT AIR COURSE

Air massage mainly
on the waist and
legs.

1

Press the OPERATION ON/OFF button.

3

Adjust the positions of the back rest and the foot rest. (See page 12 - 14)

2

Turn the sole warmer on or off.

 The massaging that corresponds to the

pressed button will stop. (The Massaging
rollers will stop at that point.)

 All the massaging will stop.

(The massaging rollers are moved to the
upper position and remain in that position.)

 All the massaging will stop and the lamp of the remote

control will turn off.

 When you want to restart massaging, press the

OPERATION ON/OFF button. (The massaging rollers
move to the upper position and remain in that
position.)
After the movement, repeat the operation to begin a
massage.

If you have felt abnormal physical sensation or want to stop the massager immediately

To stop the massage during operation.

Press the OPERATION ON/OFF button.

Press the INSTANT STOP button.

Press the button for the current operation.

 The massaging rollers are moved to the upper position and are stopped automatically approx. 15 minutes

after starting the operation. The beep sounds and the lamp on the remote control will turn off.

 Check if the position of shoulder is correct. If not, adjust the position using the POSITION ADJUST buttons.

(The POSITION ADJUST buttons can also be used while massaging is in progress.) (See page 19)

LOWER BODY can be operated simultaneously with NECK & SHOULDER or LOWER BACK.
 COMFORT AIR COURSE cannot be operated simultaneously with any other courses.
 Refer to the page 28 regarding the massaging contents of Automatic Courses.
 Change of course during massaging, or change to the Whole Body Sensor Automatic Courses or the

Manual Courses, is possible.

■

Finishes massaging automatically by timer operation.

 Sole warmer will be turned on or off each time

the SOLE WARMER button is pressed. (The button is
illuminated while the sole warmer is on.)

 If you feel that the sole warmer is too hot, turn it off

by pressing the SOLE WARMER button.

＊When the room temperature is low such as in winter, it

takes some time to warm up or you may barely feel warm.

 When the button is pressed, the lamps of the sole warmer

and remote control will illuminate, and the sole warmer
will turn on.
When the foot rest is fully lowered, the foot rest will rise a little.

 When the massaging rollers are not located in the upper

section, the massaging rollers will move to the upper
section and stop. (During the movement, the icon of
“ORIGIN” on the remote control flickers.)

●

●

●

●

●

●

●

●

●

●

●

● ●

●

●

19

(Remote control display)

Massaging
rollers

MASSAGING (AUTOMATIC COURSES) (continued)

 Displays the aim of massaging positions, the

type of massaging and the remaining
massaging time on the remote control.

The explanation uses NECK & SHOULDER
as an example.

Adjusting the strength of massage

NOTE

Massaging operation and display of remote control

Measurement of shoulder position

Massaging rollers move up and down
to measure the position of shoulder.

(Sit deeply on the massage chair and raise your
head slightly. The matching of the position of
shoulders may not be possible if the head is
leaning on the back rest.)

Massaging operation at recognized
position of shoulder.

Check that massaging rollers match
the position of your shoulder.
If not, when the lamp of is
flickering (a beep sounds),
adjust the position by pressing
the POSITION ADJUST buttons.

The massaging rollers are
moved up or down by 1cm
each time the POSITION
ADJUST button is pressed.

When it is difficult to
adjust with POSITION
ADJUST button, move
your body for adjustment.
The height that can be
adjusted is between
approx. 150 to 180cm.

Decides the position of shoulder.

 Each time the UPPER (DRUM ROLL) button is pressed, the strength of

upper body (drum roll) massaging can be adjusted in five stages.
(The strength is displayed by the lamp on the remote control.)

 Each time the LOWER BODY STRENGTH ADJUST button is pressed, the

strength of lower body massaging (air) can be adjusted in three stages.
(The strength is displayed by the lamp on the remote control.)

When it is felt that the massaging on the soles or calves is too strong even when reducing the
strength of lower body (air) massaging, put a towel etc. on those massaged parts.

The position of current massage
flickers.

The timer will operate and then
stop. After the rollers have
retracted, the display will turn off.

Massaging concentrated on the
neck and shoulders will be carried
out.

Position too high

Position too low

Appropriate position

●

●

●

●

20

MASSAGING (MANUAL COURSES)

① ②Place the hook on the underside of

cover around the lower
post of the remote
control.

Slide the hook on the upper side of
cover around the post on the upper
side of the remote control until you
hear a clicking noise.

How to attach the cover

Massaging of upper body

Cover

3

Adjust the positions of the back rest and the foot rest.

(See page 12 - 14)

Post

Post

Hook

Hook

1

Press the OPERATION ON/OFF button.

When the button is pressed, the lamps of the sole warmer and remote control will illuminate, and the sole
warmer will turn on.

When the foot rest is fully lowered, the foot rest will rise a little.
 When the massaging rollers are not located in the upper section, the massaging rollers will move to the

upper section and stop. (During the movement, the icon of “ORIGIN” on the remote control flickers.)

4

Open the cover of the remote control.

＊If an excessive force is applied to the cover, it may be

detached. In such a case, re-attach the cover according to
the following procedure.

2

Turn the sole warmer on or off.

 Sole warmer will be turned on or off each time the SOLE WARMER button is pressed.

(The button is illuminated while the sole warmer is on.)

 If you feel that the sole warmer is too hot, turn it off by pressing the SOLE WARMER button.

＊

When the room temperature is low such as in winter, it takes some time to warm up or you may barely
feel warm.

●

●

●

●

●

21

MASSAGING (MANUAL COURSES) (continued)

 The speed of the massaging rollers will change

each time the button is pressed, and is indicated
by the lamp on the remote
control. (in five stages)

The approximate position of the massaging rollers
is indicated by the lamp on the remote control.

 The strength of the massage will change each

time the button is pressed, and is indicated by
the lamp on the remote
control. (in five stages)

 The width of the massaging rollers will

change each time the button is pressed and is
indicated by the lamp on the remote control.
(in five stages)

7

Adjust the height, width, speed, and strength of the massaging rollers.

Adjusting the height of massaging rollers.

Adjusting the width of the massaging rollers.

Press the button.Press the button.

Adjusting the movement speed of massaging rollers.

Press the button.

Adjusting the strength of drum roll massaging.

Press the button.

5

Press the MANUAL button.

 The massaging that corresponds to the

pressed button will stop. (The Massaging
rollers will stop at that point.)

 All the massaging will stop.

(The massaging rollers are moved to the
upper position and remain in that position.)

 All the massaging will stop and the lamp of the remote

control will turn off.

 When you want to restart massaging, press the

OPERATION ON/OFF button. (The massaging rollers
move to the upper position and remain in that
position.)
After the movement, repeat the operation to begin a
massage.

If you have felt abnormal physical sensation or want to stop the massager immediately

To stop the massage during operation.

Press the OPERATION ON/OFF button.

Press the INSTANT STOP button.

Press the button for the current operation.

The massaging rollers are moved to the upper position and are stopped automatically approx. 15 minutes
after starting the operation. The beep sounds and the lamp on the remote control will turn off.

 If a different course button (manual) is pressed during the course of operation, the massage will be

completed by operation of the timer approx. 30 minutes after starting the massage selected first.

 There are some adjustments which are not possible, depending on the type of massage chosen.

(See page 22-23)

■

Finishes massaging automatically by timer operation.

The massaging rollers will move up if the
UP( ) button is pressed continuously and
move down if the DOWN( ) button is
pressed continuously.

6

Press the desired MANUAL (UPPER BODY)
MASSAGING button.

Refer to pages 22 - 23 for details of the contents of massage.
 For spine stretching (full), the shoulder position is first measured.

When the position of shoulder is not correct, adjust the position of
massaging rollers. (See page 17)

 During massaging operation, the operation can be changed to

other manual massage, Whole Body Sensor Automatic Course or
Automatic Courses.

 It is possible to operate the upper body massage and lower body

massage simultaneously. However, upper body massage and
TWIST massage cannot be used simultaneously.

＊The massage will not start without pressing MANUAL button,

even if the MANUAL (UPPER BODY) MASSAGING buttons are
pressed. (In such a case, the MANUAL button flickers five times.)

MANUAL button

MANUAL (UPPER BODY)
MASSAGING buttons

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

22

27 types of desired massage can be selected.

Types of massage and adjustments of massaging rollers

It is possible to adjust the movement speed, height position and width of massaging rollers and the strength of
massage. (There are some adjustments that are not possible, depending on the type of massaging. Refer to the
tables below.)

Type of massage

Operation

Adjustment of massaging rollers

Kneading

Vertical position and speed are
adjustable.

Tapping

Vertical position, speed and
width are adjustable.

Combined tapping and kneading actions

Spinal stretch along the entire length of
back

Spinal stretch along an 200mm region of
back.

Spinal stretch along a 100mm region of
back.

Massaging by spine stretching (full), while
executing kneading operation

Massaging by spine stretching (partial),
while executing kneading operation

Massaging by spine stretching (focus), while
executing kneading operation

Massaging by spine stretching (full), while
executing tapping operation

Massaging by spine stretching (partial),
while executing tapping operation

Massaging by spine stretching (focus), while
executing tapping operation

Vertical position and speed are
adjustable.

Drum roll massaging

Vertical position, width and
strength are adjustable.

Shiatsu massaging

Vertical position and speed are
adjustable.

Vertical position and width are
adjustable.

Vertical position and width are
adjustable.

Vertical position and width are
adjustable.

Vertical position and speed are
adjustable.

Vertical position and speed are
adjustable.

Vertical position and speed are
adjustable.

Vertical position, speed and
width are adjustable.

Vertical position, speed and
width are adjustable.

Vertical position, speed and
width are adjustable.

＋

＋

＋

＋

＋

＋

〈Individual massages〉

〈Combined massages〉

23

MASSAGING (MANUAL COURSES) (continued)

Massaging by spine stretching
(full) with tapping and
kneading operations.

Vertical position and speed are
adjustable.

Massaging by spine stretching
(partial) with tapping and
kneading operations.

Vertical position and speed are
adjustable.

Massaging by spine stretching
(focus) with tapping and
kneading operations.

Vertical position and speed are
adjustable.

Massaging by spine stretching
(full) with drum roll operation.

Vertical position, width and
strength are adjustable.

Massaging by spine stretching
(partial) with drum roll
operation.

Vertical position, width and
strength are adjustable.

Massaging by spine stretching
(focus) with drum roll
operation.

Vertical position, width and
strength are adjustable.

Massaging with drum roll and
kneading operations.

Vertical position, speed and
strength are adjustable.

Massaging by spine stretching
(full) with drum roll and
kneading operations.

Vertical position, speed and
strength are adjustable.

Massaging by spine stretching
(partial) with drum roll and
kneading operations.

Vertical position, speed and
strength are adjustable.

Massaging by spine stretching
(focus) with drum roll and
kneading operations.

Vertical position, speed and
strength are adjustable.

Massaging by spine stretching
(full) with stroking shiatsu
operation.

Vertical position and speed are
adjustable.

Massaging by spine stretching
(partial) with stroking shiatsu
operation.

Vertical position and speed are
adjustable.

Massaging by spine stretching
(focus) with stroking shiatsu
operation.

Vertical position and speed are
adjustable.

Type of massage Operation

Adjustment of massaging rollers

〈Combined massages〉

＋

＋

＋

＋

＋

＋

＋

＋

＋ ＋

＋ ＋

＋ ＋

＋

＋

24

Massaging of lower body

4

Open the cover of the
remote control.

5

Press the MANUAL button.

Press the desired MANUAL (LOWER BODY) MASSAGING button.

6

By pressing the LOWER BODY strength adjustment button, adjust the strength of massage.

7

1

Press the OPERATION ON/OFF button.

3

Adjust the
positions of the
back rest and
the foot rest.

2

Turn the sole
warmer on or
off.

(See page 20)

(See page 12 - 14)

 Simultaneous massaging of any part of “upper body” and “lower body (air)” is possible.

Independent massaging of “upper body” and “lower body (air)” is possible.

 1 to 5 are the same operation for massaging the upper body. When massaging the upper body, start from

operation 6.

 During massaging operation, you can change to a different manual massage, Whole Body Sensor

Automatic Courses, or Automatic Courses.

＊TWIST cannot be used together with other massaging.

 The massaging that corresponds to the

pressed button will stop.

 All the massaging will stop.

 All the massaging will stop and the lamp of the remote

control will turn off.

 When you want to restart massaging, press the

OPERATION ON/OFF button and repeat the operation
to begin a massage.

If you have felt abnormal physical sensation or want to stop the massager immediately

To stop the massage during operation.

Press the OPERATION ON/OFF button.

Press the INSTANT STOP button.

Press the button for the current operation.

 It will stop automatically approx. 15 minutes after starting the operation.

The beep sounds, and the display part of the remote control turns off.

 The strength of massage will change each time the button is pressed, and

is indicated by the lamp on the remote control. (in three stages)

■

Finishes massaging automatically by timer operation.

LOWER BODY

Air massage of the waist,
legs and soles of the feet.

CALF&FOOT

Air massage of the legs
and soles of the feet.

SEAT&BACK

Air massage of the seat
and low back.

AIR MASSAGE/TWIST

To carry out air massaging of the
hips at left and right alternately.

SOLE ON/OFF

To switch sole massaging
between on and off.

＊The SOLE ON/OFF button can also be used

for courses other than manual massaging.

●

●

●

●

●

●

●

●

●

25

ADJUSTING MASSAGE INTENSITY

Back rest

Head rest

Head rest

Back pad

Towel

Use the massager after placing
a towel, etc., on the back pad.

When the massage is too strong

When the massage is too weak

Flip the back pad to the rear.

①

②

③

Remove the head rest from
the back pad.

Flip the back pad to the rear.

Attach the head rest to the
back rest.

Back pad

26

POWER switch

AFTER USE

MAINTENANCE PROCEDURES

MAIN UNIT (Cloth,plastic parts and frame)

NOTE

CAUTION

①

②

Soak a cloth in clean water, and
squeeze it well. Wipe off the remaining
detergent with the damp cloth.

③

Wipe it with a dry cloth afterwards.

①

Soak a soft cloth in diluted
neutral kitchen detergent
and squeeze it well.
Wipe the main unit with
the damp cloth in
a tapping motion.

HEAD REST, BACK PAD, SEAT COVER, ARM REST (SYNTHETIC LEATHER PARTS)

 After use, be sure to set the POWER switch to the [OFF] position, and be sure to disconnect the power

plug from the outlet.

 Be sure to disconnect the power plug from the outlet prior to maintenance.

 Soak a soft cloth in diluted neutral kitchen

detergent, and squeeze it well. Wipe the main
unit with the damp cloth, and wipe it with a
dry cloth afterwards.

＊Do not force-dry with a drier.
＊Do not make contact with vinyl products for an

extended period. It may cause discoloration.

 Perform daily maintenance by wiping with a soft dry cloth.

When they are badly soiled, adopt the following maintenance procedure:

 Do not attempt to use benzene, thinner, alcohol, alkaline detergent or bleaching agent for

cleaning, as this may result in deformation, discoloration or cracking.

 Do not wash the head rest or the back pad. This may cause discoloration or deformation.

1

Bring all parts of the massage chair to their
home position by pressing the HOME
POSITION button.

 Be sure to check that there are no people (particularly children) or

pets, or any obstacles around the massager.

Close the cover of remote control.
 Put the remote control and the sensor controller back on the stand.

2

Turn off the POWER.

3

Disconnect the power plug.

When the display part of the
remote control does not turn off,
press the OPERATION ON/OFF button.

Set the POWER switch to the [OFF] position.

②

Press

Press

●

●

●

●

●

●

●

●

●

WARNING

27

CONTENTS OF MASSAGING

〈WHOLE BODY SENSOR AUTOMATIC COURSES〉

Standard massage in RECOVERY Course

Standard massage in REFRESH Course

Standard massage in RELAX Course

Sensor massage

Sensor massage

Sensor massage

Tapping/Kneading
and Spine stretching
(full)

Tapping/Kneading
and Kneading
(Shoulder, Back,
Waist)

Tapping,
Tapping/Kneading
and Kneading
(Shoulder, Back,
Waist)

Drum roll,
Kneading and
Tapping
(Shoulder, Back,
Waist)

Drum roll,
Tapping (Shoulder,
Back, Waist) and
Spine stretching

(focus)

Tapping/Kneading
and Spine stretching
(full)

Drum roll and
Spine stretching
(full)

Drum roll (Shoulder)
and Kneading

Drum roll and
Kneading
(Shoulder, Back,
Waist)

Drum roll and
Tapping/Kneading
(Shoulder, Back,
Waist)

Tapping/Kneading
and Spine stretching
(full)

Kneading
(Shoulder)

Kneading
(Shoulder)

Kneading
(Shoulder)

Kneading
(Waist)

Kneading
(Waist)

Kneading
(Back)

Kneading and
Spine stretching
(full)

Kneading and
Spine stretching
(full)

Spine stretching
(full)

Spine stretching
(full)

Tapping/Kneading
(Shoulder)

Tapping and
Spine stretching
(full)

＊The drawing of the massage for each course is omitted in part, in order to describe the operation in a

simplified manner. Also, the drawings of air massage operation for lower body are all omitted.

28

〈WHOLE BODY SENSOR AUTOMATIC COURSES〉

〈AUTOMATIC COURSES〉

Standard massage in FINE Course

NECK & SHOULDER Course

LOWER BACK Course

Sensor massage Kneading

(Shoulder)

Kneading
(Shoulder)

Kneading
(Shoulder)

Kneading
(Waist)

Kneading
(Waist)

Kneading
(Shoulder)

Kneading
(Shoulder)

Tapping/Kneading
and Spine stretching
(full)

Tapping/Kneading
and Spine stretching
(full)

Kneading and
Spine stretching
(partial)

Tapping/Kneading
(Shoulder)

Tapping/Kneading
(Waist)

Tapping/Kneading
(Neck, Shoulder)

Kneading
(Shoulder, Back,
Waist)

Tapping/Kneading
(Shoulder, Back,
Waist) and
Spine stretching
(full)

Tapping (Shoulder,
Back, Waist) and
Spine stretching
(focus)

Tapping/Kneading,
Kneading (Shoulder,
Back, Waist) and
Spine stretching
(focus)

Tapping/Kneading,
Tapping (Shoulder)
and Spine stretching
(focus)

Tapping/Kneading
(Shoulder) and
Spine stretching
(focus)

Tapping/Kneading
(Waist) and
Spine stretching
(focus)

Kneading (Waist),
Tapping/Kneading
(Waist) and
Spine stretching
(focus)

Tapping (Neck,
Shoulder) and
Spine stretching
(focus)

Tapping (Neck,
Shoulder) and
Spine stretching
(focus)

Tapping (Waist) and
Spine stretching
(focus)

Tapping and
Spine stretching
(partial)

Kneading (Neck,
Shoulder) and
Spine stretching

(partial)

29

TROUBLE-SHOOTING

Type of Trouble

Movement of massaging rollers
in upward direction, causing
operation to stop.

Check points Countermeasure

The display of stiffness differs
from the degree of stiffness
actually felt.

Operation failure

The operation stops in the middle
of massaging.

Sounds and sensations during operation

Courses other than Air Course
cannot be selected.

 If the trouble still persists even after the following proper countermeasures have been taken, stop using the

massager to avoid possible accidents. Disconnect the power plug from the outlet and consult an authorized
service center. Do not attempt to repair the equipment at home by yourself, as it is very dangerous.

 If people who are heavier than the maximum weight (120 kg or more) use the massager, it may

stop operating suddenly.

The degree of stiffness cannot
be measured correctly.

NOTE

●

●

・Rattling sound during tapping
・The sound of massaging rollers moving up and

down and the sound of kneading operation 
 (Knocking, clinking, rubbing or whistling sounds)

・Creaking sound caused by massaging rollers

 and cloth during massaging operation

・Gear meshing sound

・Wobbling of the foot rest
・Creaking or sliding sounds when reclining

・Sound of air massaging

Whooshing sound (switching valve sound)
 Hissing or blowing sound (air exhaust sound)
 Sounds from the pump operating

Sound of the air bag filling up

・Small sounds and shocks coming from the massaging
 rollers when massaging near the waist
・Bouncing movement of the massaging rollers when
 they move from the back to the shoulder

Sounds and sensations such as the following may occur while the massager is operating,
but these occur as part of the normal mechanism of the massager and are not the signs of
a malfunction. (They have no effect on normal functioning.)

WARNING

Check that the power plug is securely
plugged into the outlet.

Push the power plug into the
outlet securely. (See page 11)

Check that the POWER switch is set to
the ON position.

Check if the remote power switch is
turned off. (LED is not illuminated.)

Press the POWER switch to the
[ON] position. (See page 11)

Press the OPERATION ON/OFF button
after turning on the remote power
switch. (See page 11)

Check if the remote power switch is
turned off. (LED is not illuminated.)

Press the OPERATION ON/OFF button
after turning on the remote power
switch. (See page 11)

Make sure that no more than one button
is being pressed at any one time.

Please press each button separately.

Check if the chair is set to the BEST
POSITION 2.

After adjusting the angle of back rest,
select the massaging button.

(See page 13)

This phenomenon is caused by the operation of the timer, but is not
a problem.

Reclining is not possible. The foot
rest cannot be raised or lowered.

Is it being obstructed by something? Remove the obstruction.

You feel discomfort during the
operation of reclining.

(

Move toward
the opposite direction temporarily,
or do not move smoothly.

)

This operation is conducted for safety, but is not a problem.

The position of massaging rollers
differ between right and left.

This phenomenon is caused by the adoption of the function of alternative
tapping on the right and left sides, but is not a problem.

Check if your fingers (hand) are placed
on the sensor.

Place your fingers (hand) on the
sensor. (See page 15)

The measurement result indicates the stiffness according to the body's
biological reaction to the sensor massage, so it may differ from the
stiffness the user actually feels.

Massage in relaxed condition as much as possible. The degree of stiffness may
not be measured correctly when the user massages immediately after taking
a bath or is given stimulation other than sensor massage, like watching TV.

Check your skin for dryness.

Slightly moisten your hand using hand cream
and place the fingers (

hand

) on the sensor again.

30

SPECIFICATIONS

Do not use the massager on other than the designated voltage.

230 WPower consumption

30 min.Rated time

WHOLE BODY SENSOR AUTOMATIC COURSES・・・Approx. 15 minutes
(Maximum of approx. 20 minutes due to stiffness detection)

AUTOMATIC COURSES・・・・・・・・・・・・・・Approx. 15 minutes
MANUAL COURSES・・・・・・・・・・・・・・・・Approx. 15 minutes

Timer

730 mm [width]×1,240 mm [depth]×1,220 mm [height]

＊When upright (with foot rest retracted)

730 mm [width]×1,940 mm [depth]×760 mm [height]

＊When reclined (with foot rest set horizontally)

Dimensions

Approx. 80 kgWeight

Cord length

Stand, Installation screws (Three)Accessories

Synthetic leatherUpholstery

One up/down pass in approx. 35 sec.

Vertical movement speed

(5 stages) Approx. 60〜130 mmTapping width

(5 stages) Approx. 60〜130 mm

Spine stretching width

Partial stretching (Partial): Repetition within Approx. 200 mm
Partial stretching (Focus): Repetition within Approx. 100 mm

Range of partial stretching

Approx. 710 mm

Maasger rollers up/down range

No gradation or 10 mm /one press of button

Height adjustment of massaging rollers

Approx. 120〜170°Reclining angle

Reclining method

Lower body massaging
(Air pressure)

33 W

Approx. 2,100 mm

Power dissipation of electric heating equipment

Back rest: Motor-driven type (Linked with foot rest)
Foot rest: Motor-driven type (Foot rest only)

(3 stages) Approx. 19〜38 kPa

＊There is a slight difference according to the part.

(5 stages) Approx. 10〜30 times/min.Kneading frequency

(5 stages) Approx. 300〜600 times/min.

Approx. 42〜98 times/min.

(5 stages) Approx. 7〜15 times/min.

Tapping frequency

Drum roll frequency

Shiatsu frequency

＊FINE Course is Approx. 8 minutes

SANYO Electric Co., Ltd.

9BF-6-P111-336DG-0 0210
