Sanyo 32K30TD Schematic

Model No. LCD-32K30TD

Service Ref.No. LCD-32K30TD-00

SERVICE MANUAL LCD Television

Safety Notice...............................................2

Specications..............................................3

Chassis Block Diagrams.............................4

CPU Block Diagrams ....................

.............

5

On-screen Service Menu System..........6-13

Service Adjustments.................................14

Mechanical Disassembly......

...............

15-16

Chassis Electrical Parts List.................17-33

PCB Assemble.....................................34-35

Printed Wiring Board............................36-39

Schematic Diagram..............................40-41

Product Code: 1-130-178-11

Original Version

Chassis Series:UE5-A

Contents

FILE NO.

Give complete "SERVICE REF. NO." for
parts order or servicing.It is shown on the
rating lable at the cabinet back of the unit.

This T.V. receiver will not work properly
in foreign countries where the television
transmission system and power source

differ from the design specications. Refer
to the specication table.

N6WM REFERENCE No. SM3010412

2

Safety Notice

Safety Precautions

The following precautions must be observed.

1:Comply with all caution and safety-related notes provided on the cabinet back, cabinet bottom, inside the
cabinet or on the chassis.

2:When replacing a chassis in the cabinet, always be certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers or shields, barriers, etc..

DO NOT OPERATE THIS TELEVISION WITHOUT THE PROTECTIVE SHIELD IN POSITION AND
PROPERLY SECURED

3:Before replacing the cabinet cover, thoroughly inspect the inside of the cabinet to see that no stray parts or
tools have been left inside.

Before returning any televison to the customer, the service personnel must be sure that it is completely safe
to operate without danger of electrical shock.

Product Safety Notice

Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by mark

in the parts list and the schematic diagram designate components in

which safety can be of special signicance.

It is particularly recommended that only parts designated on the parts list in this manual be used for
component replacement designated by mark

.
No deviations from resistance wattage or voltage ratings may be made for replacement items designated
by mark

.

3

Specications

Model LCD-32K30TD

Maximum Visible Range

80cm

Picture Resolution 1366(H) x 768(V)

Viewable Angle(L。/3) L/R:+/-89D, U/D:+/-89D

Brightness 500cd/m²

Degree of Colour Coverage ≥30%

Mobile Trailer Time 8ms

Voltage AC110-242V 50/60Hz

Power Consumption 106W

Power Management VESA DPMS

Digital TV System DVB-T(2K/8K COFDM), Band Wide: 7MHZ

Video decoder:MPEG2 MP@HL

Audio decoder:MPEG1,MPEG2(Layer I/II),and DOLBY Digital(AC3)

Analog TV System Colour System:PAL,SECAM,NTSC/NTSC4.43(only AV)

Sound System:D/K,I,B/G,

Stereo System:NICAM,A2/IGR(German Stereo)

Channel Coverage - VHF: 0-12

- UHF: 27-69,

- MATV: UHF 20-27, UHF 70-75, S2-S44

Aerial input impedance 75Ω

Speaker Size Mains: 6cm x 12cm x 2pcs

Sound speciality Maximum Output Power is 10W+10W

Total Harmonic Distortion(THD)≤10%

Input terminals PC input terminal : RGB X 1 HDMI terminal: x3

Audio: Mini stereo jack x 1 (Audio input of PC)

Video: Composite video terminals x1 (1Vp-p, 75Ω)

S-VIDEO input: x 1 (DIN 4-pin, Y/C separate signal input)

DVD input: Component video input Y, C

B/PB

, CR/PR input x 1

Audio input: (R/L) x 4 (400mVrms)

Output terminals

Video Monitor Output:

x1 (1Vp-p, 75Ω)

Audio Monitor Output: R/L x 2 (400mVrms, ≤1KΩ)

S/P DIF (Coaxial) Output x 1

Headphone Jack : Mini stereo jack x1

Dimensions
(Width x Height x Depth) 789mm X 550mm X 271.6mm (Including Stand)

Net Weight
(Including Stand ) 11.5 KG

Operating Environment
Operating Temperature 0ºC~40ºC（32ºF~104ºF

）

Operating Humidity 20~80%

Storage Temperature -10ºC~50ºC（14ºF~122ºF

）

Storage Humidity 20~80%

4

Chassis Block Diagrams

for HDCP

DRAFT VERSION

DESIGN BY HST

2008-9-4

REVISED:2008-10-27

5V VA

5V STB

SPI FLASH

(option for air

update)

TUNER

TDTC-G501D

DVB-T

DEMODULATOR

CE6353

IF-PLL

TDA9886

VGA

HDMI_2

HDMI_3

1/3

SWITCH

PS321

HDMI

PORTS

CVBS0P

SIF

TS

DDR

UART

DDR SDRAM

256Mb x2

UART

I/F

SPI

DUAL

LVDS

LG PANEL

32” -LC320WXN-SBA1

42” -LC420WUN-SBA1

MUX

LINE

AUDIO

OUT

OP AMP

4558R

POWER

AMPLIFIER

TDA3124D2

IR

KEY BOARD

IR

USB

HEADER

EEPROM

24C32

DDCR

R/G/B 1

Y/Pb/Pr

R/G/B 0

24C02CT

AV1

HDMI_1

AV OUT

H.PHONE

EEPROM

24C512

SPDIF

SPDIFO

CVBS1P

CVBSO

LINE OUT1

10W

10W

HEAD PHONE

OUTPUT

CVBS/L/R

HP-L

R/G/B

JACK

LINE IN2

L

/

R

L/R

LINE IN1

L/R

Y/Pb/Pr

L/R

LINE IN3

L/R

CVBS

MSD1

09CL- H

DVB LCD/PDP DTV

PROCESSOR

MCU

VIDEO DEC

MPEG2 MP@HL DEC

MPEGI&II,AC3 DEC

NICAM/A2

SCALER

HDMI

LVDS

Q24C02CT/ SN-P

QNJM4558M---P

SPI FLASH

32Mb

QRCLAMP0524PP

1LB4J

11B0580M

TS

IF-

IF+

IIC1

IF_AGC

IF_TV

TV-VID

SIF P/M

I2C

RF-AGC

RST

20.48M

12MHz

I2C

UAR

FOR SOFT DEBUG

L

R

RESET

Q

PS321TQFP80M

USB

ESD

ESD

ESD

4MH

IIC1

IIC2

IIC3

HPD3

HPD1

HPD2

DDCDA

I2C-DDC

HOTPLUG

MUTE1

AU AMP

TPA6110

MUTE2

QTPA6110A2--P

KEY

IIC2

SPDIF

HP-R

HP-L

HP-R

RS232_I

UART1

RXD/TXD

QTDA9886TSV4P

S_VIDEO

MAX232

C

Y

CVBS4P

CVBS6P

UAR

for external

u

p

date

BUFFER

5

CPU

Block Diagrams

MSD109CL-H

6

256Mb TSOP-II Package Pinout

V

DD

1

66Pin TSOP

II

(400mil x 875mil)

DQ

0

2

V

DDQ

3

NC

4

DQ

1

5

V

SSQ

6

NC

7

DQ

2

8

V

DDQ

9

NC

10

DQ

3

11

V

SSQ

12

BA

0

20

CS

19

RAS

18

CAS

17

WE

16

NC

15

V

DDQ

14

NC

13

V

DD

27

A

3

26

A

2

25

A

1

24

A

0

23

AP/A

10

22

BA

1

21

V

SS

54

DQ

7

53

V

SSQ

52

NC

51

DQ

6

50

V

DDQ

49

NC

48

DQ

5

47

V

SSQ

46

NC

45

DQ

4

44

V

DDQ

43

A

11

35

36

CKE

37

CK

38

DM

39

V

REF

40

V

SSQ

41

NC

42

V

SS

55

A

4

56

A

5

57

A

6

58

A

7

59

A

8

60

A

9

34

(0.65mm Pin Pitch)

33

32

31

30

29

28

61

62

63

64

65

66

NC

NC

NC

NC

NC

V

DD

NC

DQS

NC

V

SS

CK

NC

A

12

V

SS

NC

V

SSQ

NC

DQ

3

V

DDQ

NC

NC

V

SSQ

NC

DQ

2

V

DDQ

A

11

CKE

CK

DM

V

REF

V

SSQ

NC

V

SS

A

4

A

5

A

6

A

7

A

8

A

9

NC

DQS

NC

V

SS

CK

NC

A

12

V

DD

NC

V

DDQ

NC

DQ

0

V

SSQ

NC

NC

V

DDQ

NC

DQ

1

V

SSQ

BA

0

CS

RAS

CAS

WE

NC

V

DDQ

NC

V

DD

A

3

A

2

A

1

A

0

AP/A

10

BA

1

NC

NC

NC

NC

NC

V

DD

Bank Address

BA0~BA1

Auto Precharge

A10

64Mb x 4

32Mb x 8

V

DD

DQ

0

V

DDQ

DQ

1

DQ

2

V

SSQ

DQ

3

DQ

4

V

DDQ

DQ

5

DQ

6

V

SSQ

BA

0

CS

RAS

CAS

WE

LDM

V

DDQ

DQ

7

V

DD

A

3

A

2

A

1

A

0

AP/A

10

BA

1

NC

LDQS

NC

NC

NC

V

DD

V

SS

DQ

15

V

SSQ

DQ

14

DQ

13

V

DDQ

DQ

12

DQ

11

V

SSQ

DQ

10

DQ

9

V

DDQ

A

11

CKE

CK

UDM

V

REF

V

SSQ

DQ

8

V

SS

A

4

A

5

A

6

A

7

A

8

A

9

NC

UDQS

NC

V

SS

CK

NC

A

12

16Mb x 16

IC Block Diagrams

K4H561638H

7

IC

Block Diagrams

CE6353(INTEL)

8

IC Block Diagrams

TPA3124D2PWPR

TDA9886

1
2
3

4
5
6
7
8
9

10
11
12

PVCCL

SD

PVCCL

MUTE

LIN

RIN

BYPASS

AGND
AGND

PVCCR

VCLAMP

PVCCR

24
23
22

21
20
19
18
17
16

15
14
13

PGNDL
PGNDL
LOUT
BSL
AVCC
AVCC
GAIN0
GAIN1
BSR
ROUT
PGNDR
PGNDR

PWP (TSSOP) PACKAGE

(TOP VIEW)

9

On-screen Service Menu System

General

This set has an On-screen Menu system included in the CPU that allows remote operation for most of the
service adjustments.

r How to select the service item and adjust data:

On-screen Service Menu System

Quick operation is needed to enter Service Mode.

r How to enter the Service Menu

1. Press and hold the MENU button on Side Controls.

2. Press “1” button on the remote control, and the Service Mode will be displayed.

With the menu, press

▲

, ▼,

7

or

8

button to navigate through the
options or adjust an option. Press OK button to confirm a selection or
enter a sub-menu.

r To exit service mode

Press MENU button to exit service mode. 　

OK

Open or close the On-Screen Menu.

MENU button

Side Controls

[ Service Mode Menu ]

Service Mode

ADC ADJUST

PICTURE MODE

W/B ADJUST

WHITE PATTERN : OFF

RFAGC ADJUST : 16

SSC ADJUST

BACKLIGHT ADJUST

UE5A_V1.825_LG32_090324

10

On-screen Service Menu System

1.ADC ADJUST
CONDITION ITEM NAME INITIAL DATA IC Remark
TOTAL ITEM
SOURCE <RGB/YPbPr(SD)/YPbPr(HD)> MSD109CL-H-LF

R-GAIN <0 - 255> MSD109CL-H-LF decide by factory
G-GAIN <0 - 255> MSD109CL-H-LF decide by factory
B-GAIN <0 - 255> MSD109CL-H-LF decide by factory

R-OFFSET <0 - 255> MSD109CL-H-LF decide by factory
G-OFFSET <0 - 255> MSD109CL-H-LF decide by factory
B-OFFSET <0 - 255> MSD109CL-H-LF decide by factory

AUTO ADC <FAIL/SUCCESS> MSD109CL-H-LF

SOURCE: RGB R-GAIN <97> MSD109CL-H-LF
MODEL:LCD-32K30TD G-GAIN <103> MSD109CL-H-LF
B-GAIN <101> MSD109CL-H-LF

R-OFFSET <137> MSD109CL-H-LF
G-OFFSET <143> MSD109CL-H-LF
B-OFFSET <145> MSD109CL-H-LF

SOURCE: RGB R-GAIN <101> MSD109CL-H-LF
MODEL:LCD-42K30TD G-GAIN <101> MSD109CL-H-LF
B-GAIN <105> MSD109CL-H-LF

R-OFFSET <147> MSD109CL-H-LF
G-OFFSET <141> MSD109CL-H-LF
B-OFFSET <125> MSD109CL-H-LF

SOURCE: YPbPr(SD) R-GAIN <65> MSD109CL-H-LF
MODEL:ALL G-GAIN <61> MSD109CL-H-LF
B-GAIN <66> MSD109CL-H-LF

R-OFFSET <128> MSD109CL-H-LF
G-OFFSET <128> MSD109CL-H-LF
B-OFFSET <128> MSD109CL-H-LF

SOURCE: YPbPr(HD) R-GAIN <63> MSD109CL-H-LF
MODEL:ALL G-GAIN <61> MSD109CL-H-LF
B-GAIN <66> MSD109CL-H-LF

R-OFFSET <128> MSD109CL-H-LF
G-OFFSET <128> MSD109CL-H-LF
B-OFFSET <128> MSD109CL-H-LF

2. PICTURE MODE
CONDITION ITEM NAME INITIAL DATA IC REMARK

Input Source <DTV/ATV/AV1/AV2/PC/HDMI1/HDMI2/HDMI3>
MSD109CL-H-LF
Picture Mode <Personal / Standard / Vivid / Dynamic / Soft >
MSD109CL-H-LF
Brightness <0 - 100> MSD109CL-H-LF
Contrast <0 - 100> MSD109CL-H-LF
Colour <0 - 100> MSD109CL-H-LF
Sharpness <0 - 100> MSD109CL-H-LF
Tint <0 - 100> MSD109CL-H-LF
Brightness Max <0 - 255> MSD109CL-H-LF Can not change
Brightness Mid <0 - 255> MSD109CL-H-LF Can not change
Brightness Min <0 - 255> MSD109CL-H-LF Can not change
Contrast Max <0 - 255> MSD109CL-H-LF Can not change

■ Service Adjustment Data Table

11

Contrast Mid <0 - 255> MSD109CL-H-LF Can not change
Contrast Min <0 - 255> MSD109CL-H-LF Can not change
Colour Max <0 - 255> MSD109CL-H-LF Can not change
Colour Mid <0 - 255> MSD109CL-H-LF Can not change
Colour Min <0 - 255> MSD109CL-H-LF Can not change
Sharpness Max <0 - 63> MSD109CL-H-LF Can not change
Sharpness Mid <0 - 63> MSD109CL-H-LF Can not change
Sharpness Min <0 - 63> MSD109CL-H-LF Can not change
Tint Max <0 - 100> MSD109CL-H-LF Can not change
Tint Max <0 - 100> MSD109CL-H-LF Can not change
Tint Max <0 - 100> MSD109CL-H-LF Can not change
COPY ALL MSD109CL-H-LF Can not change

Input Source: ALL Brightness <55> MSD109CL-H-LF
Picture Mode: Personal Contrast <100> MSD109CL-H-LF
Colour <60> MSD109CL-H-LF
Sharpness <60> MSD109CL-H-LF
Tint <50> MSD109CL-H-LF

Input Source: ALL Brightness <60> MSD109CL-H-LF
Picture Mode: Standard Contrast <80> MSD109CL-H-LF
Colour <50> MSD109CL-H-LF
Sharpness <50> MSD109CL-H-LF
Tint <50> MSD109CL-H-LF

Input Source: ALL Brightness <58> MSD109CL-H-LF
Picture Mode: Vivid Contrast <90> MSD109CL-H-LF
Colour <60> MSD109CL-H-LF
Sharpness <50> MSD109CL-H-LF
Tint <50> MSD109CL-H-LF

Input Source: ALL Brightness <55> MSD109CL-H-LF
Picture Mode: Dynamic Contrast <100> MSD109CL-H-LF
Colour <60> MSD109CL-H-LF
Sharpness <60> MSD109CL-H-LF
Tint <50> MSD109CL-H-LF

Input Source: ALL Brightness <50> MSD109CL-H-LF
Picture Mode: Soft Contrast <60> MSD109CL-H-LF
Colour <40> MSD109CL-H-LF
Sharpness <40> MSD109CL-H-LF
Tint <50> MSD109CL-H-LF

3. W/B ADJUST
CONDITION ITEM NAME INITIAL DATA IC REMARK

BASE R-GAIN <0 - 155> MSD109CL-H-LF decide by factory
BASE G-GAIN <0 - 155> MSD109CL-H-LF decide by factory
BASE B-GAIN <0 - 155> MSD109CL-H-LF decide by factory
SOURCE <DTV/ATV/AV1/AV2/PC/HDMI1/HDMI2/HDMI3>
MSD109CL-H-LF
SOURCE R-GAIN <0 - 50> MSD109CL-H-LF Can not change
SOURCE G-GAIN <0 - 50> MSD109CL-H-LF Can not change
SOURCE B-GAIN <0 - 50> MSD109CL-H-LF Can not change
TEMPERATURE <Normal/Warm/Cold/Personal> MSD109CL-H-LF
USER R-GAIN <0 - 50> MSD109CL-H-LF Can not change
USER G-GAIN <0 - 50> MSD109CL-H-LF Can not change
USER B-GAIN <0 - 50> MSD109CL-H-LF Can not change
R-OFFSET <0 - 255> MSD109CL-H-LF
G-OFFSET <0 - 255> MSD109CL-H-LF
B-OFFSET <0 - 255> MSD109CL-H-LF
COPY ALL MSD109CL-H-LF Can not change

■ Service Adjustment Data Table

Source Item Name Initial Data IC Remark

On-screen Service Menu System

12

SOURCE: ALL BASE R-GAIN <78> MSD109CL-H-LF
TEMPERATURE: ALL BASE G-GAIN <78> MSD109CL-H-LF
BASE B-GAIN <78> MSD109CL-H-LF

SOURCE: ALL R-OFFSET <128> MSD109CL-H-LF
TEMPERATURE: ALL G-OFFSET <128> MSD109CL-H-LF
B-OFFSET <128> MSD109CL-H-LF

4. WHITE PATTERN: <Black/OFF/Whilte/Red/Green/Blue>

WHITE PATTERN: OFF MSD109CL-H-LF

5. RFAGC ADJUST <0-31> decide by factory

RFAGC ADJUST 16 MSD109CL-H-LF

6. SCC ADJUST

CONDITION ITEM NAME INITIAL DATA IC REMARK
SSC MIU <On/Off> MSD109CL-H-LF Can not change
MIU SPAN <0 - 500> MSD109CL-H-LF Can not change
MIU STEP <0 - 500> MSD109CL-H-LF Can not change

SSC LVDS <On/Off> MSD109CL-H-LF Can not change
LVDS SPAN <0 - 500> MSD109CL-H-LF Can not change
LVDS STEP <0 - 500> MSD109CL-H-LF Can not change

7.BACKLIGHT ADJUST

note: the sum of backlight value(ECO) and backlight value(Picture Mode) should be in <0% - 100%>

TOTAL ITEM
CONDITION ITEM NAME INITIAL DATA IC REMARK
ECO MODE <On/Off> MSD109CL-H-LF

Backlight value <0% - 100%> MSD109CL-H-LF

PICTURE MODE <Personal / Standard / Vivid / Dynamic / Soft >

MSD109CL-H-LF Backlight value <-100% - 0%> MSD109CL-H-LF

DCR <0% - 100%> MSD109CL-H-LF
DCR START <0% - 100%> MSD109CL-H-LF
DCR STOP <0% - 100%> MSD109CL-H-LF

ECO MODE: ON Backlight value 75% MSD109CL-H-LF

ECO MODE: OFF Backlight value 100% MSD109CL-H-LF

Picture Mode: Personal Backlight value 0% MSD109CL-H-LF

Picture Mode: Standard Backlight value -25% MSD109CL-H-LF

Picture Mode: Vivid Backlight value -10% MSD109CL-H-LF

Picture Mode: Dynamic Backlight value 0% MSD109CL-H-LF

Picture Mode: Soft Backlight value -30% MSD109CL-H-LF

DCR DCR 25% MSD109CL-H-LF
Picture Mode: ALL DCR START 6% MSD109CL-H-LF
DCR STOP 10% MSD109CL-H-LF

Source Item Name Initial Data IC Remark

On-screen Service Menu System

■ Service Adjustment Data Table

13

Service Adjustments

CAUTION !

Do not attempt to adjust service adjustments not listed below otherwise it may cause loss of performance

and for correct operation.

r Setting the Initial data

This adjustment is controlled by the CPU (IC5500) through the IIC Bus Data Line in the chassis, and those

adjustment data are memorized the memory IC (IC5750). Therefore, Main board or the memory IC (IC5750)

is replaced, these data will be disappeared. Readjust should be made. Initial data is provided in the CPU

ROM, when the memory IC (IC5750) is replaced with new one. CPU ROM data is loaded into the memory.

Initial data is provided to operating the monitor basically. For operating the monitor quality performance,

further adjustment is required following chassis electrical adjustment.

1. Receive good quality signal.

2. Enter the Service Mode.

3. ADC ADJUST and W/B ADJUST should be readjusted. And Confirm other data value to be the same

as the Service Adjustment Data Table. If it is different, change to correct data

4. Exit the Service Mode.

14

Service Adjustments

r ADC ADJUST

1. Enter the Service Mode.

2. Select "ADC ADJUST" by pressing ▲ or ▼ button, then press OK button to enter ADC ADJUST menu.

3. Press

▲

or ▼ button to select "SOURCE" item, press

7

or

8

button to select RGB, YPbPr(SD) or

YPbPr(HD).

(1).

Receive signal from PC input. And set ANSI pattern contrast in PC mode.Receive signal from PC input. And set ANSI pattern contrast in PC mode.

(2). Enter the ADC ADJUST menu. PressEnter the ADC ADJUST menu. PressPress ▲ or ▼ button to select "SOURCE" item

(3). Press 7 or

8

button to select RGB.

(4). Press

▲

or ▼ button to select AUTO ADC item, then press OK button.

(1).

Receive 100% Colour Bar from 480p and 576p singal in �PbPr input.Receive 100% Colour Bar from 480p and 576p singal in �PbPr input.

(2). Enter the ADC ADJUST menu. PressEnter the ADC ADJUST menu. PressPress ▲ or ▼ button to select "SOURCE" item.

(3). Press 7 or

8

button to select YPbPr (SD).

(4). Press

▲

or ▼ button to select AUTO ADC item, then press OK button.

(1).

Receive 100% Colour Bar from 1080p, 1080i and 720p singal in �PbPr input.Receive 100% Colour Bar from 1080p, 1080i and 720p singal in �PbPr input.

(2). Enter the ADC ADJUST menu. PressEnter the ADC ADJUST menu. PressPress ▲ or ▼ button to select "SOURCE" item.

(3). Press 7 or

8

button to select YPbPr (HD).

(4). Press

▲

or ▼ button to select AUTO ADC item, then press OK button.

4. Exit the Service Mode.

Wait for about several seconds until AUTO ADC adjust completed. Then press MENU button to exit.

Note:

●

If you want to adjust any item, please consult qualified service personnel.

ADC ADJUST

SOURCE : RGB

R-GAIN : 117

G-GAIN : 121

B-GAIN : 123

R-OFFSET : 131

G-OFFSET : 145

B-OFFSET : 123

AUTO ADC FAIL

RGB

YPbPr (SD)

YPbPr (SD)

15

r

W/B ADJUST

Pattern

White Pattern 100% (in AV mode).

Condition

Picture Mode: STANDARD

Color Temperature: NORMAL

Aging Time: More than 10 minutes

Adjustment

1. Enter the Service Mode.

2. Select "W/B ADJUST" by pressing ▲ or ▼ button, then press OK button to enter W/B ADJUST menu.

3. Exit the Service Mode.

After adjustment, confirm white balance again by normal picture.

Note:

●

Maybe BASE data for each TV set is different. And the items are for factory setting and

Service Centre.

●

SOURCE items are for all input source gain. Usually the items can not be adjusted.

●

USER items are just for user setting. Usually the items can not be adjusted.

●

If you want to adjust any item, please consult qualified service personnel.

W/B ADJUST

BASE R-GAIN : 78

BASE G-GAIN : 78

BASE B-GAIN : 78

SOURCE : DTV

SOURCE R-GAIN : 25

SOURCE G-GAIN : 25

SOURCE B-GAIN : 25

TEMPERATURE : Normal

USER R-GAIN : 25

USER G-GAIN : 25

USER B-GAIN : 25

R-OFFSET : 128

G-OFFSET : 128

B-OFFSET : 128

COPY ALL
