Ordering number:EN5032A
NPN Epitaxial Planar Silicon Transistor
2SC5226
VHF to UHF Wide-Band Low-Noise
Amplifier Applications
Features
·Low noise : NF=1.0dB typ (f=1GHz).
·High gain : S21e 2=12dB typ (f=1GHz).
·High cutoff frequency :Tf=7GHz typ.
Specifications
Absolute Maximum Ratings at Ta = 25˚C
Package Dimensions
unit:mm
2059B
|
|
[2SC5226] |
|
|
0.425 |
0.3 |
|
|
0.15 |
0.2 |
|
|
|
||
|
|
3 |
|
|
|
|
0 to 0.1 |
2.1 |
1.250 |
|
|
0.425 |
1 |
2 |
0.3 |
0.6 |
|
0.65 |
0.65 |
||||
|
0.9 |
||||
|
|
|
|||
|
2.0 |
|
|
|
1 : Base
2 : Emitter
3 : Collector
SANYO : MCP
Parameter |
Symbol |
Conditions |
Ratings |
Unit |
|
|
|
|
|
Collector-to-Base Voltage |
VCBO |
|
20 |
V |
Collector-to-Emitter Voltage |
VCEO |
|
10 |
V |
Emitter-to-Base Voltage |
VEBO |
|
2 |
V |
Collector Current |
IC |
|
70 |
mA |
Collector Dissipation |
PC |
|
150 |
mW |
Junction Temperature |
Tj |
|
150 |
˚C |
|
|
|
|
|
Storage Temperature |
Tstg |
|
–55 to +150 |
˚C |
|
|
|
|
|
Electrical Characteristics at Ta = 25˚C
Parameter |
Symbol |
|
Conditions |
|
|
Ratings |
|
Unit |
||
|
|
|
|
|
||||||
|
|
|
|
|
|
|
min |
typ |
max |
|
|
|
|
|
|
|
|
|
|
|
|
Collector Cutoff Current |
ICBO |
VCB=10V, IE=0 |
|
|
|
1.0 |
µA |
|||
Emitter Cutoff Current |
IEBO |
VEB=1V, IC=0 |
|
|
|
10 |
µA |
|||
DC Current Gain |
hFE |
VCE=5V, IC=20mA |
|
60* |
|
270* |
|
|||
Gain-Bandwidth Product |
fT |
VCE=5V, IC=20mA |
|
5 |
7 |
|
GHz |
|||
Output Capacitance |
Cob |
VCB=10V, f=1MHz |
|
|
0.75 |
1.2 |
pF |
|||
Reverse Transfer Capacitance |
Cre |
VCB=10V, f=1MHz |
|
|
0.5 |
|
pF |
|||
Forward Transfer Gain |
| S21e |2(1) |
VCE=5V, IC=20mA, f=1GHz |
|
9 |
12 |
|
dB |
|||
|
| S21e |2(2) |
VCE=2V, IC=3mA, f=1GHz |
|
|
8 |
|
dB |
|||
Noise Figure |
NF |
VCE=5V, IC=7mA, f=1GHz |
|
|
1.0 |
1.8 |
dB |
|||
* : The 2SC5226 is classified by 20mA hFE as follows : |
|
|
|
|
Marking : LN |
|
|
|
||
60 |
3 120 |
90 4 180 |
135 5 270 |
|
|
|
||||
|
|
|
|
|
|
hFE rank : 3, 4, 5 |
|
|
||
|
|
|
|
|
|
|
|
