Ordering number:EN3093

PNP/NPN Epitaxial Planar Silicon Transistors

2SA1707/2SC4487

High-Current Switching Applications

Features

·Adoption of FBET, MBIT processes.

·Large current capacity, wide ASO.

·Low collector-to-emitter saturation voltage.

·Fast switching speed.

( ) : 2SA1707

Specifications

Absolute Maximum Ratings at Ta = 25˚C

Package Dimensions

unit:mm

2064

[2SA1707/2SC4487]

E : Emitter

C : Collector

B : Base

SANYO : NMP

Parameter

Symbol

Conditions

Ratings

Unit











Collector-to-Base Voltage

VCBO



(–)60

V

Collector-to-Emitter Voltage

VCEO



(–)50

V

Emitter-to-Base Voltage

VEBO



(–)6

V

Collector Current

IC



(–)3

A

Collector Current (Pulse)

ICP



(–)6

A

Collector Dissipation

PC



1

W

Junction Temperature

Tj



150

˚C











Storage Temperature

Tstg



–55 to +150

˚C











Electrical Characteristics at Ta = 25˚C

Parameter



Symbol





Conditions



Ratings



Unit



























min

typ

max

























Collector Cutoff Current



ICBO



VCB=(–)40V, IE=0





(–)1

µA

Emitter Cutoff Current



IEBO



VEB=(–)4V, IC=0





(–)1

µA

DC Current Gain



hFE1



VCE=(–)2V, IC=(–)100mA

100*



400*









hFE2



VCE=(–)2V, IC=(–)3A

35







Gain-Bandwidth Product



fT



VCE=(–)10V, IC=(–)50mA



150



MHz

* : 2SA1707/2SC4487 are classified by 100mA hFE as follows :





























100 R 200

140 S 280

200 T 400

































Any and all SANYO products described or contained herein do not have specifications that can handle applications that require extremely high levels of reliability, such as life-support systems, aircraft’s control systems, or other applications whose failure can be reasonably expected to result in serious physical and/or material damage. Consult with your SANYO representative nearest you before using any SANYO products described or contained herein in such applications.

SANYO assumes no responsibility for equipment failures that result from using products at values that exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges,or other parameters) listed in products specifications of any and all SANYO products described or contained herein.

SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquaters

TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN

83098HA (KT)/6299MO, TS No.3093-1/5

Sanyo 2SC4487 Specifications

2SA1707/2SC4487

Parameter

Symbol

Conditions



Ratings



Unit













min

typ

max

















Collector-to-Emitter Saturation Voltage

VCE(sat)

IC=(–)2A, IB=(–)100mA



(–0.35)

(–0.7)

V









0.2

0.5

V















Base-to-Emitter Saturation Voltage

VBE(sat)

IC=(–)2A, IB=(–)100mA



(–)0.95

(–)1.2

V

Output Capacitance

Cob

VCB=(–)10V, f=1MHz



(39)25



pF

Collector-to-Base Breakdown Voltage

V(BR)CBO

IC=(–)10µA, IE=0

(–)60





V

Collector-to-Emitter Breakdown Voltage

V(BR)CEO

IC=(–)1mA, RBE=

(–)50





V

Emitter-to-Base Breakdown Votage

V(BR)EBO

IE=(–)10µA, IC=0

(–)6





V

Turn-ON TIme

ton

See specified Test Circuit



70



ns

Storage Time

tstg

See specified Test Circuit



(450)



ns









650



ns















Fall Time

tf

See specified Test Circuit



35



ns

Switching Time Test Circuit

Unit (resistance : Ω, capacitance : F)

No.3093-2/5
