Sanus PFPLB INS User Manual

PLATINUM FURNITURE

MODEL PFPLb-01 - Digital TV Stand

Assembly Instructions

Congratulations and thank you for purchasing your new Sanus Platinum Furniture Product. If you have any questions regarding this or any other Sanus product, please contact our customer service department at [phone], or www.sanus.com. It is not necessary to contact the retailer with any questions or problems, as parts can be sent directly to you

Please follow these assembly instructions. This will save you time, make assembly easier and prevent possible damage to your new Digital TV Stand. Assistance may be required for some assembly procedures. Correct assembly is your responsibility.

BUS5305

We recommend that the unit is assembled on a soft surface such as carpet. Please record your serial number in the space provided below and retain this manual for future reference.

Serial No

This unit was manufactured using ISO 9000 certified systems.

For improvement purposes, design and specifications are subject to change without notice.

BUS5305

CAUTION

There are many small components used in the construction of this unit. These loose items should be kept away from young children while assembling your unit.

Shelf Pin	P860121 x 1	P860035 x 6	Barrel nut
P840048 x 8			P840050 x 8

P860015 x 8	Connector rod	Cam	Wooden dowel
	P820016T x 8	P820015T x 8	P800201 x 8

P816145 x 4	Cable Ducts
	P840170 x 2

Insert wooden dowels into sides as shown.

x 8

1. Fasten 8 Connector Rods into small holes in Top as shown.

Intersecting

hole

Important:

*When fitting the rails onto the top, ensure that the grooved part of the rails are closest to the side edges of the top.

* The larger holes (cam holes) in the rails must always be closest to the Top.

1.Insert black Barrel Nuts into smaller holes in Rails, ensuring slot in cap is aligned to intersecting hole.

2.Insert silver Cams into larger holes in Rails, ensuring that arrow on Cam points towards intersecting hole.

3. Press fit Rails to Top as shown.
