Santos 02 User Manual

250 mm

(10”)

www.santos.fr

Nom

du produit

N°06/06A

Pour …

www.santos.fr

Safety switch

:
machine stops when
opening drawer or hopper

Internationally patented models

Cheese Grater

#02

For restaurants, pizzerias,
supermarkets, food stores…

1 standard disc
for Gruyere or Emmenthal
with Ø 3mm holes

400 mm

(16”)

420 mm

(17”)

495 mm

(19”)

350 mm

(14”)

295 mm

(12”)

Appliance:

Shipping Bo

x:

TECHNICAL SPECIFICATIONS

• Motor: with thermal protection

Single Phase : 220-240 V - 50/60 Hz - 600 W

100-120 V - 50/60 Hz - 650W

Speed : 1500 RPM (50Hz)

1800 RPM (60 HZ)

• Weight: Net: 14 Kg (31 lbs)

Shipping: 15 Kg (33 lbs)

Stainless steel
and sanitary cast
aluminium

Special plastic drawer
(container)
Capacity 800 g (1.8lbs)

Average output :
50 kg/hour
(110 lbs/hour)

Articulated lever

Safety ON/OFF
switch

Special discs available on request :

• Ø 2,4,6,8 mm holes

• Parmesan or other discs for special cheese (fondue…)

• Grating discs : almonds, nuts, bread crumbs
All tools are Ø 110mm (4.3”) in stainless steel, removable
for cleaning

www.santos.fr

140 - 150 AV ROGER SALENGRO - 69120 - VAULX EN VELIN - LYON - FRANCE - TEL. [phone] - FAX [phone]

Website: www.santos.fr - Email: [e-mail]

Cheese Grater #02

FERREOL - 06/2007 - V2
