Sangoma DC201 Datasheet

Created on: Tuesday 27 April, 2021

Sangoma DC201 DECT Base + Handset System (10 Pack)

Product Name: Sangoma DC201 DECT Base + Handset System (10 Pack)
Manufacturer: ­Model Number: PHON-DC201E10

Please Note: This product has been discontinued. Please see the Sangoma DC201 DECT Base +
Handset System.

Sangoma DC201 DECT Base + Handset System (10 Pack)
The Sangoma DC201 DECT Base + Handset (10 Pack) gives your staff and colleagues the
freedom and efficiency that is required in environments such as busy offices and campuses. Each
DC201 package supports up to 20 users and also features automatic provisioning with Sangoma's
FreePBX and PBXact phone system for easy deployment and mass provisioning.Sangoma
DC201 Package Key Features

� Each DECT Phone System Includes: 1 x DB20 DECT Base & 1 x D10 Handset
� Supports Up to 20 DECT Cordless Handsets (Additional Handsets Sold Separately)
� Up to 5 Simultaneous Calls
� Up to 8-hours Talk Time & 75-Hour Standby Time
� Autoprovision with FreePBX & PBXact Phone Systems
� TLS & SRTP Secure Encryption
� Range: Up to 50m Indoors

SecurityWith TLS and SRTP encryption, you are guaranteed privacy and security in your wireless
communications.Auto-ProvisioningCut down installation time thanks to the automatic configuration
with Sangoma's FreePBX and PBXact range. The Sangoma DC201 uses a built-in EndPoint
Manager auto-provisioning tool.Long RangeIncreased flexibility with up to 50 meters of indoor
range between handset(s) and base station.Supports Additional HandsetsSupports up to 20
DECT cordless handsets (additional handsets sold separately).Talk/Standby TimeEnjoy
long-lasting handset power with up to 8-hours talk time and 75-hour standby time.Complete DECT
SolutionThe DB20 DECT Base Station connects to local LAN network with the PBX, as the
handsets communicate over a wireless DECT connection.
Sangoma DC201 Package - Technical Specifications
D10 Handset

� 1.44’’ TFT display (128 x 128 x 64k) with graphical user interface
� Up to 2 simultaneous calls per handset
� Standby time: 75 hours
� Talk time: Up to 8 hours
� Range: Up to 50m indoors
� Headset connector (3.5mm)
� Handset selection for receiving call
� Handset and number selection for placing call
� Paging, intercom, auto answer, call hold, call transfer, 5-way conference, call waiting, mute,
silence, DND, caller ID with name and number, anonymous call, anonymous call rejection, call
forward, speed dial, voicemail, redial, message waiting
� indication and call history
� Wideband audio (G.722) support
� Graphical interface with selectable wallpaper
� Selectable polyphonic ringtones
� Local & remote phonebook support
� 1m drop protection
� IP-20 Ingress rated
� Wideband two-way speaker phone

www.voipon.co.uk | [e-mail] | Page 1/4

Created on: Tuesday 27 April, 2021

Sangoma DC201 DECT Base + Handset System (10 Pack)

� Handset automatically supports both North America and EU standards
� Firmware update

DB20 Base Station

� Network

� Up to 5 simultaneous calls

� 1x RJ45 10 / 100M Ethernet port

� IP assignment: static / DHCP

� SIP v1 (RFC2543), v2 (RFC3261)

� SNTP / NTP

� VLAN (802.1Q and 802.1P)

� 802.1x, LLDP, PPPoE

� STUN client (NAT traversal)

� UDP / TCP / TLS

� Audio

� 5 Audio channels using G.726 /G.711Codec

� 4 audio channels using G.729

� 5 CAT-iq wideband audio channelsusing G.722

� RFC3711 SRTP

DECT (Between Base & Handset)

� Frequency band: 1880MHz–1930MHz (DECT)

� 1880 – 1900 MHz (10 carriers) Europe
� 1920 – 1930 MHz (5 carriers) US
