Introduction of DPI Sunroof Solution
PDIM Manual
PDIM KTB(KTA)
Manual
S&T Daewoo
1
Introduction of DPI Sunroof Solution
PDIM Manual
Contents
1. Features and Location
2. Connection
S&T Daewoo
3. Overview of operation
4. Caution
2
Introduction of DPI Sunroof Solution
PDIM Manual
1. Features and Location
S&T Daewoo
USB
connector
20pin
connector
3
Introduction of DPI Sunroof Solution
PDIM Manual
2. Cable connection
S&T Daewoo
Connect
USB cable
Connect
20pin cable
4
Introduction of DPI Sunroof Solution
PDIM Manual
3. Operational description
PDIM KTB(KTA) is Car Audio Interface Device that is controlled by Car
Audio Box and can transmit audio signal of external devices(such as USB
storage, Aux input, Bluetooth) to the Audio Box in a car.
MICOM controls DAC IC to transmit audio signal from input data of USB
storage (USB mode), controls Audio switch to transmit audio signal from
Aux input audio(Aux mode), controls Bluetooth module to transmit audio
signal from other bluetooth devices(Bluetooth mode Æ KTB only).
S&T Daewoo
- USB 2.0 support
- Bluetooth V2.0+EDR, Class2, using 2.4GHz ISM band
- Bluetooth Frequency Range : 2400GHz ~ 2483.5GHz(0CH ~ 78CH)
- Frequency Step : 1MHz
5
Introduction of DPI Sunroof Solution
PDIM Manual
4. Caution
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
S&T Daewoo
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20cm between the radiator & your
body.
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such
modifications could void the user’s authority to operate the equipment.
