Sandstrom S08DPF10 Instruction Manual
Instruction Manual
8” Digital Photo Frame
S08DPF10
Contents
Unpacking the Photo Frame ...............................................................................4
Product Overview ................................................................................................5
Preparations.........................................................................................................6
Attaching the Stand ................................................................................................................6
Connecting to the Mains Power .......................................................................................... 7
Inserting a Memory Card / USB Flash Disk ...................................................................... 8
Basic Operation ...................................................................................................9
Display image ............................................................................................................................ 9
Setting ............................................................................................................... 10
Set Image Size ..........................................................................................................................10
Set Slideshow Eect ..............................................................................................................11
Set Slideshow Interval ..........................................................................................................11
Set Split Slideshow .................................................................................................................11
Rotate..........................................................................................................................................12
Zoom File ...................................................................................................................................12
Delete File..................................................................................................................................13
Reset Setting ............................................................................................................................13
Language ...................................................................................................................................14
Brightness / Contrast / Color / Tint ...................................................................................14
Time .............................................................................................................................................15
Troubleshooting ............................................................................................... 16
Specications .................................................................................................... 17
Safety Warnings ................................................................................................ 18
Settings
Basic Operation
PreparationsIntroduction and
Product Overview
Troubleshooting
and Specication
GB-4
Safety Warnings
2. Photo Frame Stand
(P.N. : 61-DPF-001)
3. Mains Adapter
(P.N. : 31-0512#UK)
4. Instruction Manual
(P.N. : 71-DPF980-002)
1. Digital Photo Frame
Unpacking the Photo Frame
Remove all packaging from the unit. Retain the packaging. If you dispose it please do
so according to local regulations.
If items are missing or damaged, please contact partmaster (UK only).
Tel: 0844 800 3456 for assistance.
Congratulations on the purchase of your new Sandstrøm Digital Photo Frame.
We recommend that you spend some time reading this instruction manual in order
that you fully understand all the operational features it oers. You will also nd
some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
Settings Basic Operation
Preparations Introduction and
Product Overview
Troubleshooting
and Specication
GB-5
Safety Warnings
MENU/EXIT
SD/MMC/MS
DC 5V
UNSCREW
LCD Display
Product Overview
Main Unit
Name Description
1
SD/MMC/MS slot
• To accommodate SD, MMC, MS cards
2
USB host
• To accommodate USB devices such as portable
USB ash drives or ash memory card readers
3
MENU / EXIT
• To display setting menu
• To exit the menu or return to last display
4
button
• To move left or up in the menu / thumbnail mode
/ option settings
• To display the previous photo
5
Enter / Play / Pause
button
• To conrm a setting or enter next display
• To slideshow the photos
• To pause the sildeshow
6
button
• To move right or down in the menu / thumbnail
mode / option settings
• To display the next photo
7
Power button
• Press to turn the photo frame on
• Press and hold to turn the photo frame o
8
Wall mounting hole
• For mounting the photo frame on the wall
9
DC-IN socket
• To connect to the mains supply
10
Stand receptacle
• To attach the supplied stand
3 4 5 6 7
1
9
8
2
10
GB-6
Settings
Basic Operation
PreparationsIntroduction and
Product Overview
Troubleshooting
and Specication
Safety Warnings
SD/MMC/MS
DC 5V
UNSCREW
2. Screw in the stand into the stand receptacle.
3. Now the stand is xed, you can choose to display your photo frame in a landscape
or portrait position.
To take o the stand, unscrew it from its receptacle.
Preparations
Attaching the Stand
1. Take out the stand attached in the package.
Stand
Stand Receptacle
Landscape Position
Portrait Position
SD/MMC/MS
DC 5V
UNSCREW
SD/MMC/MS
DC 5V
UNSCREW
SD/MMC/MS
DC 5V
UNSCREW
GB-7
Settings Basic Operation
Preparations Introduction and
Product Overview
Troubleshooting
and Specication
Safety Warnings
Connecting to the Mains Power
1. Connect the supplied mains adapter (5V DC, 1.2A) to the photo frame, and plug in
the mains adapter into the mains socket.
2. Press the
button on the photo
frame to turn it on.
SD/MMC/MS
DC 5V
UNSCREW
DC 5V
SD/MMC/MS
DC 5V
UNSCREW
MENU/EXIT
3. The opening screen will appear. The
display will automatically switch to
calendar in 3 seconds. To turn o press
and hold the button.
GB-8
Settings
Basic Operation
PreparationsIntroduction and
Product Overview
Troubleshooting
and Specication
Safety Warnings
Inserting a Memory Card / USB Flash Drive
Insert a SD memory card, MMC memory card, or Memory Stick into the slot with its
label side facing forward.
• This unit can play back only one memory card or a USB ash drive at a time.
• This unit does not support any external hard disk and MP3 player connection via the
USB 2.0 A-Type port.
• Some of the newer higher capacity cards may not be compatible with this frame.
• Do not insert a micro or mini memory card without an adapter.
MMC
SD
SD/MMC/MS
DC 5V
UNSCREW
• Insert your memory card into the
appropriate slot following the orientation
marked on the photo frame.
SD/MMC/MS
DC 5V
UNSCREW
• Insert a USB drive into the USB port.
Calendar Display
MENU/EXIT MENU/EXIT
MENU/EXIT
MENU/EXIT
Slideshow Image (default)
Index Thumbnails
(Hold / to scroll whole page)
Still Image
Loading...
