4 pcs
Legs
FIGURE
DESCRIPTION
QTY
Table Top
1 pce
1 pce
Hardware Bag
1 pce
Fixed Shelf
48” COFFEE TABLE WITH 2 DRAWERS
Thank you for purchasing this quality product.Be sure to check all packaging material
carefully for small parts that may have come loose inside the carton during shipment.
COMPONENT LIST: HARDWARE LIST:
This product will take 15-20
minutes to assemble.
Reminders
1.Use only the hardware supplied.
2.Once the product is assemble,level and tighten all the bolts.
3.Do not over-tighten bolts.
4.This item may require periodic tightening
PART NO
1
2
3
4
5
NOTE:
1.Two or two people are needed for assembly
2 please keep all hardware parts out of the reach of children.
FIGURE
DESCRIPTION
HexBolt
Pan Head Screw
Lock Washer
Flat Washer
Wrench
QTY
8 pcs
4 pcs
8 pcs
8 pcs
1 pce
Page 1 of 2
MADE IN MALAYSIA
48” COFFEE TABLE WITH 2 DRAWERS
ASSEMBLY :
STEP 1
1.1-Pull out the Drawer Box as shown and Turn the Table Top upside down on a protective surface such as carpet or other soft
materialas shown in Fig1.
1.2-Use Flat Washer(4), Lock Washer(3), Hex Bolt(1) and Wrench(5), to attach three legs randomly to the table top,
do not fully tighten yet.
Flat Washer
Lock Washer
Hex Bolt
Wrench
Fig.1
STEP 2
2.1-Insert the Fixed Shelf to three legs, insert the last leg to the corner of apron frame and Fixed Shelf.Then tighten with
Flat Washer(4), Lock Washer(3) and Hex Bolt(1) using the Wrench(5) provided.
2.2- Insert and tighten the Pan Head Screw(2) using a screw-driver (Not provided) into the Fixed Shelf to scure Shelf as shown
on Fig.2
Fig.2
STEP 3
3.1- Turn table to uprigtht position.
3.2- Once coffee table with 2 drawers is fully balance fully tighten all bolts.
Fig.3
Assembly is now Completed.
Page 2 of 2
CARE INSTRUCTION
~ Be sure to use the same type of polish consistenly.
Your furniture will appear cloudy or streaky if oil
based or wax based polishes are interchanged.
~ Spray your furniture surface evenly. Wipe in a
circular motion with a soft clean cloth.
MADE IN MALAYSIA
