SanDisk Sansa™ c100

User Guide

Table of Contents

Safety Instructions .............................................................................. 4

Introduction .......................................................................................... 5

Playback Screen Description ......................................................

6Package Contents ..................................................................... 6

Getting Started ..................................................................................... 7

Overview ..................................................................................... 7

Install or replace Battery ............................................................. 8

Hold Switch ................................................................................. 8

Minimum System Requirements ................................................. 8

Connecting and Transferring ............................................................. 9

Connect to your computer ........................................................... 9

Sansa Media Converter .............................................................. 9

Supported IMPORT media types ................................................ 9

Transfer Photos ........................................................................... 9

Transfer Music ............................................................................. 10

Delete Files ................................................................................. 10

Synchronize Files ........................................................................ 10

Various software packages are available to synchronize songs on your device. Please refer to the speciﬁc software package

instructions. ................................................................................. 10

Safely Remove SanDisk Sansa™ c100 from Computer ............. 10

Basic Usage ......................................................................................... 11

Power On .................................................................................... 11

Main Menu .................................................................................. 11

Using Navigation Buttons ............................................................ 11

Power Off .................................................................................... 11

Music Mode ................................................................................. 11

 Music/Voice Playback ............................................................... 11

 Setting Repeat Mode ................................................................ 12

 Setting Shufﬂe Mode ................................................................ 12

 Setting Equalizer ...................................................................... 12

 Adding songs to GoList ............................................................. 13

 Remove songs from GoList ...................................................... 13

Photo Mode ................................................................................. 13

 Viewing Photos ......................................................................... 13

 Slideshow ................................................................................. 13

 Photo Options ........................................................................... 14

Recording Mode .......................................................................... 14

 Voice Recording ....................................................................... 14

Settings Mode ............................................................................. 14

 Setting Display Backlight .......................................................... 15

 Setting Display Contrast ........................................................... 15

 Setting Language ..................................................................... 15

 Resetting to original setting ...................................................... 15

 Device Information .................................................................... 16

 Setting Auto Power Off or Sleep ............................................... 16

 Setting USB Mode .................................................................... 16

Tips, FAQ, and Troubleshooting ........................................................ 17

Service and Warranty Information ..................................................... 19

Getting Technical Support ........................................................... 19

Learn More .................................................................................. 19

Your 1-Year SanDisk Limited Warranty ....................................... 19

End User License Agreement ............................................................. 22

Safety Instructions

1. Read the safety instructions carefully before using your Sansa.

2. Read this entire manual to ensure proper usage.

3. Keep this User Guide for future reference.

4. Do not use HeadPhones/Earphones while driving, cycling, or opera-

ting any motorized vehicle. This may create a trafﬁc hazard and may be illegal in some areas. It can also be dangerous to play your music with Headphones/Earphones at high volume while walking, or engaged in other activities. You should exercise extreme caution and discontinue use in potentially hazardous situations.

5. Avoid using Headphones/Earphones at high volume. Hearing experts

advise against continuous loud and extended music play. Keep the volume at a moderate level, so that you are better able to hear outside sound, and to be considerate of the people around you.

6. Keep your player away from sinks, drinks, bathtubs, showers, rain, and other sources of moisture. Moisture can cause electric shocks with any electronic device.

7. Follow these tips to keep your player working well for a long time:

 Clean your player with a soft lint-free cloth used on glass lenses.

 Do not allow young children to use your player unsupervised.

 Never force any connector into the ports of your player or your

computer. Make sure your connectors are the identical shape and size before you connect.

Introduction

Congratulations on your purchase of a SanDisk Sansa™ c100.

The SanDisk Sansa™ c100 is a high performance portable digital audio player with a photo browser and a voice recorder. The Sansa c100 enables users to play MP3, WMA, and secure WMA audio ﬁles. It also shows photo ﬁles that are transferred to the player through Sansa Media converter.

Features:

 Digital Audio Player – supports MP3, WMA and secure WMA ﬁles

playback.

 Color LCD

 Photo Browser – supports JPEG image ﬁles and provides slideshow

function.

 Voice Recorder – supports voice recording function with built-in

microphone.

 Digital Equalizer – supports 5 equalizer types: Normal, Rock, Jazz,

Classic, Pop, and one custom equalizer.

 Internal Memory – allows users to store data on the internal memory

as an USB drive.

Playback Screen Description

1. Track Number Display the current track number and the total num-

ber of sound tracks.

2. Artist Name Displays the artist name of the current playback ﬁle.

3. Song Name Displays the song name of the current playback

track.

4. Track Timer Displays the timer of the current playback track.

5. Repeat Indicates when Repeat function is enabled.

6. Shufﬂe Indicates when Shufﬂe function is enabled.

7. Play/Pause/Stop Displays the music or voice ﬁles playback status.

8. Battery Indicates the Battery Status.

Package Contents

Please unpack your Sansa c100 and check that the following were included.

 Sansa c100 digital audio player  Earphones  USB Cable  CD with User’s Manual and Software  Quick Start Guide  Lanyard  1 AAA Alkaline battery

Getting Started

Overview

1. Volume Up/Down Volume up/down

2. Strap Eyelet Lanyard connection.

3. Earphones Port Connect earphones here to listen to player..

4. MIC Internal Microphone

5. Hold Slide to lock(Orange Color) or unlock controls.

6. Display Window Read status and information here.

7. Select Button Press to select the item.

8. Play/Pause/Up Press to move up one item, pause, or resume.

9. Previous/Rewind Press for previous track or move left, press and

hold for rewind.

10. Down/Option menu Press to move down or to options menu.

11. Next/Forward Press for next track or move right, press and

hold for fast forward.

12. Power/Menu Press and hold to power on/off, press to enter

menu.

13. Dock Connector Port Plug the Dock Connector Cable here.

Install or replace Battery

The Sansa c100 is powered by an AAA alkaline battery. To install or replace battery, locate the battery compartment on the back of the player, press in on the tab of the battery compartment cover to remove it. Orient and insert the battery according to the battery icon with polarity signs inside the battery compartment for proper installation.

Hold Switch

The Sansa c100 Hold Switch is located on the side of the device, and is used to prevent any accidental operation. Once the Hold Switch is moved to the lock position, all function keys will be disabled. Buttons on the Sansa c100 will not operate when the Hold Switch is active (Orange Color visible).

Minimum System Requirements

 Windows XP SP1  Windows Media Player 10  Intel Pentium class PC or higher  CD-ROM drive  USB 2.0 port required for hi-speed transfer
