Samsung x460 Service Manual Part List

- This Document can not be used without Samsung's authorization -

Part List : NP-X460-AS04RU

Ver. Location Part Number

0001 A0004 BA46-08827A S/W MICOM;SANTORINI,-,SYSTEM,ALL,00LY,-,

0001 A0010 3903-000055 CBF-POWER CORD;DT,EU,CP2/NO,E(IEC320 C7)

0001 A1001 BA46-08031A S/W CD;RCD,NP/DT,VISTAHP SP1,1.0,RUS,DVD

0001 B0015 BA81-04970A DOOR-DOCKING;OXFORD,PC,W56.2*L6*H4,T1mm, 2 SA

0001 B0302 BA81-05061A LINK-BATTERY_L;SAMOA,POM,W31*L9.8*T4.6mm 1 SA

0001 B0402 BA81-05059A KNOB-BATTERY_L;SAMOA,PC/ABS,W20.1*L4.6*T

0001 B0403 BA81-05060A KNOB-BATTERY_R;SAMOA,PC/ABS,W20.1*L4.6*T

0001 B0501 BA61-00780A SPRING ETC-BATT;AQUILA-P,STS304,CD0.3,ID

0001 B0504 BA61-00039A SPRING ETC-DOCKING;BAUHAUS,STS304-WPA,CD 1 SA

0001 D1002 BA59-02313A DVD-SUPERMULTI;DU-8A2S,8X,170ms,SATA,2MB

0001 ETC01 BA68-40010Y LABEL-ETC;S3935,-,POLYESTER,T0.025,-,-,-

0001 G0003 BA59-02321A MODULE-WLAN;N/P,512AGXMMWG,-,802.11AG,mi

0001 G0011 BA59-01691A MODULE-BLUETOOTH;Bluetooth V2.0,T60H928.

0001 G0011 BA59-01916A MODULE-BLUETOOTH;Bluetooth Version 2.0,B

0001 I0001 0902-002356 IC-MICROPROCESSOR;AW80577SH0413M,2.0GHz, 1 SA NP-X460-AS04RU

0001 I0002 1105-001921 IC-DRAM MODULE;M471B5673DZ1-CF8,DDR3 SDR 1 SA NP-X460-AS04RU

0001 I0002 1105-001923 IC-DRAM MODULE;M471B2874DZ1-CF8,DDR3 SDR 1 SA NP-X460-AS04RU

0001 I0005 BA59-02190A HDD;250G,HM250JI,S63,H16,D16385,H9.5mm,2

0001 I0005 BA59-02205A HDD;250G,HTS542525K9A300,S63,H16,D16385,

0001 I0005 BA59-02211A HDD;250G,MHY2250BH,S63,H16,D16385,9.5mm,

0001 I0005 BA59-02288A HDD;250G,MK2546GSX,S63,H16,D16385,H9.5mm

0001 I0005 BA59-02346A HDD;250G,MHZ2250BH-G2,S63,H16,D16385,9.5

0001 I0005 BA59-02348A HDD;250G,HTS543225L9A300,S63,H16,D16385,

0001 I0005 BA59-02354A HDD;250G,HM251JI,S63,H16,D16385,9.5mm,2.

0001 I0005 BA59-02376A HDD;250G,MK2552GSX,S63,H16,D16385,H9.5mm

0001 I0007 BA44-00238A ADAPTOR;0335C1960,AD-6019,-,90to264Vac,4

0001 I0007 BA44-00243A ADAPTOR;ADP-60ZH A,AD-6019,-,90to264Vac,

0001 I0009 BA43-00149A BATTERY;P32R07-02-H01,SEDONA,Li-ion,2P3S

0001 I0009 BA43-00150A BATTERY;3UR18650F-2-SDN-12,Sedona,Li-ion

0001 I0013 BA59-02305A MODULE-CAMERA;SCB-1400D,GD-5932AA,1.3M C

0001 K0101 BA81-03448A RUBBER-FRONT_LOWER;HAINAN2,DOMESTIC,SR,W 4 SA

0001 L1004 BA68-20039A LABEL-PPID_E;BLADE,-,PET,-,W50.8,L12.7mm

0001 L1005 BA68-20323A LABEL CAUTION;NOTE PC,-,PET,T0.06,W30.0,

0001 LABE1 BA68-40012N LABEL-LOCATION;NOTE PC,-,ART PAPER,-,W6.

0001 M0006 BA39-00431A WIRE HARNESS;RTC battery assy.,-,UL 1061

0001 M1002 3301-001272 BEAD-SMD;120ohm,2x1.25x1mm,-,TR,-,-,-

0001 M1002 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90

0001 M1002 3301-001594 BEAD-SMD;90ohm,2.0*1.2*1.3mm,-,TP,-,-,-

0001 M1004 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005

0001 M1004 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,1005

0001 M1004 2203-000425 C-CER,CHIP;0.018nF,5%,50V,C0G,1005

0001 M1004 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005

0001 M1004 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608

0001 M1004 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005

0001 M1004 2203-000575 C-CER,CHIP;220nF,10%,25V,X7R,TP,2012

0001 M1004 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,1005

0001 M1004 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,1005

0001 M1004 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,1608

0001 M1004 2203-001405 C-CER,CHIP;22nF,+80-20%,25V,Y5V,1005

Part Name & Specification

Q'ty SA/SNA Parent Part

1 SNA BA92-04982D

1 SC NP-X460-AS04RU

1 SA

2 SA

1 SA

1 SNA NP-X460-AS04RU

1 SA NP-X460-AS04RU

1 SC NP-X460-AS04RU

1 SA NP-X460-AS04RU

1 SC NP-X460-AS04RU

1 SA

2 SA

1 SNA BA81-05613A

1 SNA BA92-04982D

1 SA

2 SNA BA92-04982C

1 SA

4 SNA BA92-04982C

2 SNA BA92-04984D

1 SNA BA92-04985D

1 SNA BA92-04982C

4 SNA BA92-04982C

2 SNA BA92-04982C

6 SNA BA92-04982C

1 SNA BA92-04982C

3 SNA BA92-04982C

BA99-13312A

BA75-02121A

BA96-03774A

BA96-03819A

BA81-05613A

BA96-03819A

BA92-05320A

BA92-04982C

- This Document can not be used without Samsung's authorization -

Part List : NP-X460-AS04RU

Ver. Location Part Number

0001 M1004 2203-001683 C-CER,CHIP;0.068nF,5%,50V,NP0,1608

0001 M1004 2203-002050 C-CER,CHIP;47nF,10%,50V,X7R,1608

0001 M1004 2203-002443 C-CER,CHIP;0.33nF,10%,50V,X7R,1005

0001 M1004 2203-002720 C-CER,CHIP;10nF,10%,25V,X7R,1005

0001 M1004 2203-005221 C-CER,CHIP;15nF,10%,50V,X7R,1608

0001 M1004 2203-005482 C-CER,CHIP;100nF,10%,10V,X5R,1005

0001 M1004 2203-005918 C-CER,CHIP;1000nF,10%,6.3V,X7R,1608

0001 M1004 2203-006000 C-CER,CHIP;1nF,10%,3000V,X7R,TP,4520

0001 M1004 2203-006170 C-CER,CHIP;220nF,10%,16V,X7R,1608

0001 M1004 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,1608

0001 M1004 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216

0001 M1004 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608

0001 M1008 3708-001824 CONNECTOR-FPC/FFC/PIC;8P,0.5mm,SMD-A,AU,

0001 M1009 3711-000456 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S

0001 M1009 3711-000922 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S

0001 M1009 3711-005753 HEADER-BOARD TO BOARD;BOX,10P,1R,1mm,SMD 1 SNA BA92-04984A

0001 M1012 2402-001125 C-ORGANIC;15uF,20%,25V,-,TP,7.3x4.3x1.9m

0001 M1013 2801-003856 CRYSTAL-SMD;0.032768MHz,20ppm,28-ACP,7pF

0001 M1014 0402-001024 DIODE-RECTIFIER;MBR0540,40V,0.5A,SOD-123

0001 M1016 0401-000132 DIODE-SWITCHING;BAV99,70V,50mA,SOT-23,TP

0001 M1018 0505-001883 FET-SILICON;RHU002N06,N,60V,200MA,3.3OHM

0001 M1021 1201-001991 IC-AUDIO AMP;TPA6017A2PWPR,TSSOP,20P,6.5

0001 M1023 2703-002073 INDUCTOR-SMD;1uH,10%,2012

0001 M1024 0801-002478 IC-CMOS LOGIC;7SZ14,SCHMITT TRIGGER,SOT-

0001 M1024 0904-002073 IC-I/O SUPPORT CHIP;SLB9635TT1.2,4Bit,TS

0001 M1025 1203-003344 IC-POSI.FIXED REG.;MIC5252,SOT-23,5P,2.9

0001 M1026 2703-001839 INDUCTOR-SMD;82nH,5%,1608

0001 M1026 2703-003135 INDUCTOR-SMD;4.7uH,20%,6965

0001 M1026 2703-003170 INDUCTOR-SMD;3.3uH,20%,6965

0001 M1026 2703-003191 INDUCTOR-SMD;2.2uH,20%,6965

0001 M1028 3722-002002 JACK-USB;4P/1C,AUF/TIN,BLK,ANGLE-OFFSET,

0001 M1029 2007-000057 R-CHIP;40.2Kohm,1%,1/10W,TP,1608

0001 M1029 2007-000066 R-CHIP;20Kohm,1%,1/10W,TP,1608

0001 M1029 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608

0001 M1029 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608

0001 M1029 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005

0001 M1029 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005

0001 M1029 2007-000147 R-CHIP;8.2Kohm,5%,1/16W,TP,1005

0001 M1029 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005

0001 M1029 2007-000168 R-CHIP;470Kohm,5%,1/16W,TP,1005

0001 M1029 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005

0001 M1029 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005

0001 M1029 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005

0001 M1029 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005

0001 M1029 2007-000608 R-CHIP;240ohm,5%,1/10W,TP,1608

0001 M1029 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608

0001 M1029 2007-000758 R-CHIP;330Kohm,5%,1/16W,TP,1005

0001 M1029 2007-000882 R-CHIP;4.7ohm,5%,1/10W,TP,1608

0001 M1029 2007-000969 R-CHIP;5.1ohm,1%,1/10W,TP,1608

Part Name & Specification

Q'ty SA/SNA Parent Part

1 SA

1 SNA BA92-04982C

2 SNA BA92-04982C

1 SNA BA92-04984C

1 SNA BA92-04982D

4 SNA BA92-04984D

1 SA

3 SA

1 SNA BA92-04982C

5 SNA BA92-04982C

14 SNA BA92-04982C

1 SNA BA92-04985D

1 SNA BA92-04982C

1 SA

3 SNA BA92-04982C

4 SNA BA92-04982D

1 SA

1 SNA BA92-04982C

2 SNA BA92-04982C

1 SNA BA92-04985D

1 SA

1 SNA BA92-04982D

1 SA

1 SNA BA92-04982C

3 SNA BA92-04982D

1 SNA BA92-04982C

4 SNA BA92-04982C

1 SA

2 SNA BA92-04982C

3 SNA BA92-04982C

1 SNA BA92-04982C

1 SNA BA92-04984C

11 SNA BA92-04982C

1 SNA BA92-04984C

1 SNA BA92-04982C

2 SNA BA92-04984D

4 SNA BA92-04982C

1 SNA BA92-04984A

6 SNA BA92-04982C

1 SNA BA92-04982C

2 SNA BA92-04982D

8 SNA BA92-04982C

3 SNA BA92-04982C

1 SNA BA92-04982C

2 SNA BA92-04982D

BA92-04982C

BA92-04984C

BA92-04982C

BA92-04982D

BA92-04982C

BA92-04982D

- This Document can not be used without Samsung's authorization -

Part List : NP-X460-AS04RU

Ver. Location Part Number

0001 M1029 2007-001139 R-CHIP;7.5Kohm,1%,1/10W,TP,1608

0001 M1029 2007-001313 R-CHIP;330ohm,5%,1/16W,TP,1005

0001 M1029 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005

0001 M1029 2007-002425 R-CHIP;1ohm,5%,1/10W,TP,1608

0001 M1029 2007-002899 R-CHIP;10ohm,1%,1/10W,TP,1608

0001 M1029 2007-002918 R-CHIP;51.1Kohm,1%,1/10W,TP,1608

0001 M1029 2007-002970 R-CHIP;56ohm,5%,1/16W,TP,1005

0001 M1029 2007-007046 R-CHIP;0.02ohm,1%,1W,TP,6432

0001 M1029 2007-007100 R-CHIP;10Mohm,5%,1/16W,TP,1005

0001 M1029 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007131 R-CHIP;13Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007226 R-CHIP;49.9ohm,1%,1/10W,TP,1608

0001 M1029 2007-007302 R-CHIP;24.9ohm,1%,1/10W,TP,1608

0001 M1029 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005

0001 M1029 2007-007307 R-CHIP;150ohm,1%,1/16W,TP,1005

0001 M1029 2007-007311 R-CHIP;22Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007334 R-CHIP;200Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007445 R-CHIP;9.09Kohm,1%,1/10W,TP,1608

0001 M1029 2007-007489 R-CHIP;150Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007521 R-CHIP;14.7Kohm,1%,1/10W,TP,1608

0001 M1029 2007-007528 R-CHIP;1.5Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007549 R-CHIP;4.99Kohm,1%,1/10W,TP,1608

0001 M1029 2007-007615 R-CHIP;11.8Kohm,1%,1/10W,TP,1608

0001 M1029 2007-007617 R-CHIP;2.49Kohm,1%,1/10W,TP,1608

0001 M1029 2007-007619 R-CHIP;60.4ohm,1%,1/10W,TP,1608

0001 M1029 2007-007642 R-CHIP;12.1ohm,1%,1/16W,TP,1005

0001 M1029 2007-007697 R-CHIP;2.4Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005

0001 M1029 2007-007778 R-CHIP;715Kohm,1%,1/10W,TP,1608

0001 M1029 2007-007792 R-CHIP;221ohm,1%,1/16W,TP,1005

0001 M1029 2007-007796 R-CHIP;2.21Kohm,1%,1/10W,TP,1608

0001 M1029 2007-007797 R-CHIP;44.2ohm,1%,1/10W,TP,1608

0001 M1029 2007-007839 R-CHIP;53.6Kohm,1%,1/10W,TP,1608

0001 M1029 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005

0001 M1029 2007-008007 R-CHIP;3.24Kohm,1%,1/10W,TP,1608

0001 M1029 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005

0001 M1029 2007-008293 R-CHIP;475ohm,1%,1/16W,TP,1005

0001 M1029 2007-008294 R-CHIP;33ohm,1%,1/16W,TP,1005

0001 M1029 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005

0001 M1029 2007-008302 R-CHIP;80.6ohm,1%,1/16W,TP,1005

0001 M1029 2007-008303 R-CHIP;27.4ohm,1%,1/16W,TP,1005

0001 M1029 2007-008304 R-CHIP;300Kohm,1%,1/16W,TP,1005

0001 M1029 2007-008314 R-CHIP;54.9ohm,1%,1/16W,TP,1005

0001 M1029 2007-008330 R-CHIP;22.6ohm,1%,1/16W,TP,1005

0001 M1029 2007-008400 R-CHIP;453ohm,1%,1/10W,TP,1608

0001 M1029 2007-008437 R-CHIP;121ohm,1%,1/16W,TP,1005

Part Name & Specification

Q'ty SA/SNA Parent Part

1 SNA BA92-04982C

1 SNA BA92-04984D

1 SNA BA92-04982C

2 SNA BA92-04982C

3 SNA BA92-04982C

2 SNA BA92-04982C

7 SNA BA92-04982C

1 SNA BA92-04982C

12 SNA BA92-04982C

1 SNA BA92-04982C

1 SNA BA92-04984C

6 SNA BA92-04984C

2 SNA BA92-04985D

8 SNA BA92-04982C

6 SNA BA92-04982D

1 SNA BA92-04982C

5 SNA BA92-04982C

1 SNA BA92-04985D

3 SNA BA92-04982C

1 SNA BA92-04982D

1 SNA BA92-04982C

2 SNA BA92-04982C

1 SNA BA92-04985D

1 SNA BA92-04982C

2 SNA BA92-04982C

1 SA

2 SNA BA92-04982D

2 SNA BA92-04982C

3 SNA BA92-04984D

1 SNA BA92-04984C

1 SNA BA92-04982C

2 SNA BA92-04982C

1 SNA BA92-04982D

1 SNA BA92-04982C

1 SNA BA92-04984D

1 SNA BA92-04982D

2 SNA BA92-04984D

1 SNA BA92-04985D

4 SNA BA92-04982C

1 SNA BA92-04985D

2 SNA BA92-04982D

2 SNA BA92-04982C

1 SNA BA92-04984D

6 SNA BA92-04982C

7 SNA BA92-04982C

1 SNA BA92-04982D

BA92-04982C

+ 7 hidden pages

Samsung x460 Service Manual Part List

Specifications and Main Features

Frequently Asked Questions

User Manual
