WWT-P-3200W Series
Wisenet WAVE Client Workstation
The WWT-P-3200W series client workstation is an easily
deployable solution that can be used on-site or remotely to
access your Wisenet WAVE video recorder running
Windows 10 Professional or Ubuntu Linux 18.04 LTS.
WWT-P-3200W / WWT-P-3200L
SYSTEM
Video Management Software
OS Drive Bays
Network Interface
Processor
Memory
Operating System
Video Outputs
USB Ports
Other Ports
Keyboard & Mouse Included
MECHANICAL / ELECTRICAL / ENVIRONMENTAL
Form Factor Small Form Factor Workstation
Mechanical
Electrical
Environmental
Certification
* The latest product information / specication can be found at www.hanwhasecurity.com
* Bandwidth performance gures based on performance testing by Hanwha Techwin using Wisenet WAVE
Color / Material
Dimensions (WxDxH) 3.7" x 11.5" x 11.4" (97mm x 292mm x 290mm)
Weight
Power Supply
Power Input 100 ~ 240V AC
Power Consumption
Operating Temperature
Storage Temperature
Operating Humidity
Wisenet WAVE
1 x 256GB SSD (internally mounted)
1 x 1GbE RJ45 Ports
1 x Intel® Core™ i3-9100 3.6Ghz to 4.2Ghz (4 Cores, 4 Threads, 6MB)
8GB DDR4
Windows 10 Professional / Ubuntu 18.04 LTS
Nvidia Quadro P400 GPU 3x Mini DisplayPort with 2x HDMI adapters
Rear: (2) USB 3.1 Gen 1, (2) USB 2.0; Front: (2) USB 3.1 Gen 1, (2) USB 2.0
3.5mm audio output
Black / Metal & Plastic
11.57 lbs (5.26 kg)
1x 200W 80 Plus Bronze
Maximum 200W
41°F ~ 95°F (5°C ~ 35°C)
-40°F ~ 149°F (-40°C ~ 65°C )
20% to 80% relative humidity (non-condensing)
UL, cUL, CB, FCC, 80 Plus Bronze
Key Features
• Preloaded and configured with Wisenet WAVE
video management system client & tools
• Includes USB mouse and keyboard
5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
•
Nvidia Quadro P400 GPU with 3 x Mini DisplayPort video outputs,
•
2 x Mini DisplayPort to HDMI adapters included
(System optimized for dual-monitor output configuration)
SECOND EDITION 03-2020 © 2020 Hanwha Techwin Co., Ltd. All rights reserved.
