Samsung WA80R3, WA70R3 User Manual
WASHING MACHINE
• Please read this manual before using and note how
to use in the proper manner.
Please be careful of keeping the manual.
Otherwise, it should be bought separately.
• The User’s Manual is for common use.
Make use of the User’s Manual depending upon
your washing machine model.
User’s Manual
WA70R3 / WA80R3
FEATURES........................................................................................... 2
SAFETY INSTRUCTIONS.................................................................... 3
DESCRIPTION OF PARTS................................................................... 4
CHECKING BEFORE WASHING AND CARING FOR GARMENTS...... 5
CONTROL PANEL ............................................................................... 6
HOW TO WASH AUTOMATICALLY DEPENDS ON THE LAUNDRY ...... 7
MANUAL FUNCTIONS......................................................................... 9
INSTALLATION & MAINTENANCE ..................................................... 9
Environment.......................................................................................... 9
Levelling................................................................................................ 9
Connecting the water supply hose...................................................... 10
Assembling the rat protection panel.................................................... 11
How to connect the drain hose ........................................................... 11
How to add the fabric softener ............................................................ 12
How to put the detergent in................................................................. 12
Water supply connector filter .............................................................. 12
Cleaning the filter. ............................................................................... 12
How to clean the pump filter ............................................................... 12
TROUBLESHOOTING........................................................................ 13
WASHING MACHINE WON’T WORK ................................................ 13
SPECIFICATIONS .............................................................................. 14
CODE NO.: DC68-01921F
(220V/50~60Hz)
FEATURES
■ CAS SYSTEM
• CHILD LOCK FUNCTION
• AUTO RESTART
The power is turned on automatically after power failure.
• SAVING ENERGY
The ECO+ COURSE, it is a wash course to saving the energy reduces
laundry time for frequent and soiled clothes.
■ DIGITAL CONTROL
Digital control operates with best washing course by sensing the washload
like artificial intelligence.
■ TRANSPARENT WINDOW
This Transparent Window is the new concept to solve the curiosity of users
to see inside of washing machine while operation.
While operation, the laundry progress inside of washing machine can be
checked by looking through the transparent window.
■ PULSATOR
The Pulsator helps water and detergent to go through fabrics efficiently
while providing both the powerful water action to clean lager and heavier
clothes and the gentle water action to clean all delicates with less wear and
tear on clothes.
■ WATERFALL FLOW
The Waterfall Flow injected from under the pulsator cascades with full force
back into the tub, pushing down any clothes that float right under the water
surface. It is this Waterfall Flow that enables this washing machine to effectively wash large and heavy items, such as bluejeans and blankets.
■ SUPER CLEAN
SUPER CLEAN adjust the level of water by 5 steps so as to enhance detergent efficiency by adjusting the density of detergent to normal density.
■ CHILD-LOCK FUNCTION
This is a device to protect children from being accidentally hurt while playing
with the washer.
How to start Child-Lock function:
• Press the “Power” button to go to an initial washing mode.
• By pressing “Start/Hold” button, you start washing and in case Child
Lock function is needed during the laundry
• Press both the “WATER LEVEL” and “WASH” buttons in simultaneously
and get the function started.
(Note: You cannot perform the function without the “Power” button on.)
To release the function of Child-Lock:
• In case the “Child-Lock” is programmed, press both the “WATER
LEVEL” and “WASH” buttons in simultaneously.
■ MAGIC FILTER
This unique magic Filter ensures that all the lint inside the tub is captured
for top quality filtering results to deliver consistently effective cleaning
results.
■ SOFTENER DISPENSER
The Softener Dispenser releases the fabric softener at the appropriate time
when the last rinsing proceeds.
- 2 -
SAFETY INSTRUCTIONS
Please note that the following precautions for safety intend to prevent
unpredictable danger and damage by helping the proper use in safety.
When using hot water in washing, please make sure that the water should not
exceed 50°C.
☞ Plastic parts may be deformed or damaged, and an electric shock or a fire
may take place.
WARNING
There might be serious injury or fatal accident when you violate this
instruction.
If the power supply cord or plug is damaged or loosened, do not use.
☞ An electric shock or a fire may take place.
Do not pull the cord off or touch it with moist hands.
☞ An electric shock or a fire may take place.
Do not bend the power supply cord by force or press it with heavy things.
☞ An electric shock or a fire may take place.
Do not install the washer nearby electric implement or don’t put a candle
light or cigarette light on the washer.
☞ A fire may take place.
Do not disassemble, repair or remodel it recklessly.
☞ When you need to repair it, please call service agent. An electric shock or a
fire may take place.
During operation, do not put your hands or metal materials under the
washer.
☞ You may be hurt by spinning board beneath the washer.
Stay away from the washer when the bottom of the washer sinks into the
water.
☞ There might be an electric shock. Please wait until the water drains out
completely.
Do not put laundry stained with gasoline, benzene, or alcohol in the
washer, and keep the materials away from the washer.
☞ An explosion or a fire may take place.
During spinning, don’t put your hand in the spinning tub.
☞ It may hurt your hands. If it does not stop within 15 seconds after you open
the lid, call service agent immediately.
CAUTIONS
There might be a slight injury or damage when you violate this
instruction.
Don’t install it in the area with moisture or outdoor where it has rain or
snow.
☞ An electric shock or a fire may take place.
Please unplug the power supply cord when you do not use it.
☞ An electric shock or a fire may take place.
If there is dust or water on the power supply plug and its connected part,
please remove it completely.
☞ An electric shock or a fire may take place.
Do not make your kids look into the inside of the washer.
☞ If your kid falls into the washer, his life could be in danger.
Ventilate immediately without touching the power plug if gas is leaking.
☞ An electric shock or a fire may take place if it catches flame.
If the washer makes strange noise, smell or smoke, unplug it promptly
and call service agent.
☞ An electric shock or a fire may take place.
When cleaning, don’t spray water to the parts of the washer directly.
☞ It may make it’s life span shorten.
Also an electric shock or fire may take place.
Don’t use several appliances together with an outlet.
☞ A fire may take place due to unusual heat.
Don’t press the button with an awl or pin.
☞ An electric shock or a fire may take place.
Use the new hose-sets and old hose-sets should not be reused.
If the damage is found on the current cord in use, it should be replaced
by manufacturer, service center or authorized person in order to advoid
the risk.
Connect the grounding wire to the shell plate, and bury it under at least
25cm of earth:elternatively, connect the ground wire to the appropriate
pin on a properly grounded power receptacle. Never connect the wire to a
telephone line, lightning rod, or gas pipe.
- 3 -
DESCRIPTION OF PARTS
The User’s Manual is for common use.
Make use of the User’s Manual depending upon your washing machine model.
FILTER
Lint will be collected in
the filter during washing.
BLEACH INLET
WATERDROP MARK
PULSATOR
FRONT CONTROL
PANEL
LID
Be sure to keep the lid
closed during washing
and spinning.
WATER SUPPLY HOSE(HOT)
WATER SUPPLY HOSE(COLD)
DRAIN-HOSE(PUMP)
DETERGENT BOX
SPIN BASKET
POWER CORD
GROUND LEAD
When the water pipe is
metal, make sure to cover
the end of the ground wire.
ADJUSTABLE LEGS
Adjust the length of the
legs when installing
the washer.
WATER DRAIN HOSE
SOUND ABSORPTION
PANEL
- 4 -
CHECKING BEFORE WASHING AND CARING FOR GARMENTS
Must follow the checkpoints in order to avoid machine problems or damages
on garments.
☞ If the below problems are caused by customer’s faults, separate service fee
will be charged.
Checkpoints Before Starting Washing
Check if the clothes are bleaching or not.
☞ Add liquid detergent to a white towel and the garment where you can’t
notice well. Then, rub together strongly. Check if the color transferred to the
towel.
☞ Be careful for scarves and imported clothes since they are easily
discoloring.
☞ Check for stains or partial dir t.
☞ If stains are found, use the towel wet with detergents to rub on in a single
direction.
☞ Before washing, the sleeves, collar, dress hem and pockets are pre-treated
by brushing with detergents.
The wrinkle-processed clothes made of wool are specially treated by fixing
them with threads before washing. The threads shall be removed after the
clothes are dried.
Not washable laundry
Clothes those are easily transformable even by soaking in water.
☞ Even by soaking in water, neckties, brassieres, jackets, suits and coats can
be easily transformed like shrinking and discoloring on the garment
surfaces because they are mostly made of rayon, polynosic, cuff and their
blend fabrics.
☞ The wrinkle-processed, embossed, or resin processed products are easy
to transform even by soaking in water.
☞ Easily discoloring products made of cotton and wool, wrinkled silk, leather
products, leather accessory, leather ornamented clothes and its accessory.
☞ Don’t wash those clothes without handling guideline or material indication
tag.
About Detergent
☞ When detergents are not dissolving well, use warm water (about 40°C) to
dissolve the detergent.
Caution
☞ Use an appropriate amount.
☞ Even if excess amount of detergent is used, there is not much difference in
washing result. It may cause damages to the garments because rinsing is
not enough.
☞ The bleaching agent may cause damages to garments since it is strong alkali.
☞ Do sufficient rinsing because the powder detergent is easily remained on
the garments causing bad odors.
☞ If too much detergent is used or cold water is used, it doesn't dissolve
completely and remain on the garments, hose or spin basket, causing
contamination on clothes.
☞ In case of reserved washing, detergents must be put in the detergent box.
If the powder detergents are spread on laundry directly, it may cause
discoloration.
CARING FOR CLO
☞ Must follow the checkpoints in order to avoid machine problems or
damages on garments.
☞ If the below problems are caused by customer's faults, separate service fee
will be charged.
THES BEFORE WASHING
Take out personal belongings from pockets.
☞ Caution, Check the pockets! Hairpins and
coins cause damages to clothes and washing
machine.
They make noise and problems to the
machine. Must check the pocket.
EIGHTY EIGHT
If pants zippers are open while washing, the spin basket may be damaged.
The zipper should be closed and fixed with a string before washing.
☞ If blue jeans and working uniform's zippers or hooks are
made of steel, they must be closed before washing.
☞ Wash winter jumpers, working uniforms, bed cover
sheets, and blue jeans separately.
☞ Fold clothes well into the spin basket. Must remove
the curtain hooks before washing.
☞ Turn inside out the button decorated and embroidered
clothes before washing.
☞ Be careful those metal decorations because they cause heavy damages
while washing.
☞ The long stringed clothes may tangle with other clothes. Must fix the
strings before washing.
☞ The metal from brassieres may stick out and damage other
clothes or the spin basket. Must use the commercial laundry
net for washing brassieres. (Use a laundry net of fine
mesh.)
Waterproof clothes (Ski Wear, Diaper Covers, Footboards)
are not allowed for washing.
☞ The waterproof sheet, clothes, and non water
permeable fabrics shouldn't be washed, rinsed, or
put in a spin basket. The laundry may pop out and
cause severe vibration so that a person may get
damaged and the machine, wall, and floor may break out in addition to
clothes. (Examples are diaper cover, waterproof wear, raincoat, umbrella
cover, ski wears, car cover sheet, and sleeping bags.)
- 5 -
Loading...
