Samsung UE46B7000, UE46B7020, UE40B7020, UE40B7000 User Manual

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.

Country

EIRE 0818 717 100 www.samsung.com/ie
U.K 0845 SAMSUNG (7267864) www.samsung.com/uk

Customer Care Centre

Web Site

LED TV

user manual

BN68-01985L-00

imagine the possibilities

Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at

www.samsung.com/register

Model Serial No.

Information on Use

2

English

Precautions When Displaying a Still Image

A still image may cause permanent damage to the TV screen.

Do not display a still image and partially still image on the LED panel for more than 2 hours as it can cause screen



image retention. This image retention is also known as screen burn. To avoid such image retention, reduce the degree of
brightness and contrast of the screen when displaying a still image.



Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.



To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.

WARNINGS:

■

Image retention, commonly known as screen burn-in, can occur on most types of television if the same image is displayed continuously.
The most common causes of image retention are logos that remain stationary on the TV screen. These logos are common on many
programmes received via a Set-top Box.

To reduce this risk, avoid displaying still images for long durations and lower the brightness or contrast settings to decrease the
intensity of the picture. Extended viewing of movies and programs in aspect ratios that are different from the aspect ratio of the TV may
cause image retention. Always endeavour to avoid black borders top or bottom by using the zoom function. This will help eliminate the
black borders and fit the picture to the entire area of the screen. Using a video game console may cause image retention and is not
recommended. When using a PC input, avoid displaying still images for long durations and reduce the brightness or contrast settings to
decrease the intensity of the picture.

IMPORTANT:

■

Image retention issues are not covered by your Samsung® warranty.

Watching the LED TV in 4:3 format for a long period of time may leave traces of borders displayed on the
left, right and centre of the screen caused by the difference of light emission on the screen.
Playing a DVD or a game console may cause a similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.

Digital TV (DVB-T) Notice

Functionalities related to Digital TV(DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC)

■

digital terrestrial signals are broadcasted or where you are able to access to a compatible DVB-C(MPEG2 and MPEG4
AAC) cable- TV service. Please check with your local dealer the possibility to receive DVB-T or DVB-C signal.

DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and

■

DVBC is that for the broadcast transmission of digital TV over cable. However, some differentiated features like EPG
(Electric Programme Guide), VOD (Video on Demand) and so on, are not included in this specification. So, they cannot be
workable at this moment.

Although this TV set meets the latest DVB-T and DVB-C standards, as of [August, 2008], the compatibility with future

■

DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed.

Depending on the countries/areas where this TV set is used some cable-TV providers may charge an additional fee for

■

such a service and you may be required to agree to terms and conditions of their business.

Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with

■

some cable service providers.

For more information, please contact your local Samsung customer care centre.

■

3

English

Trademark & Label License Notice

TruSurround HD, SRS and symbol are trademarks of SRS Labs, Inc. TruSurround HD technology is

incorporated under license from SRS Labs, Inc.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of
Dolby Laboratories.

DivX® Certified to play DivX® video, including premium content.

Symbol

Note

One-Touch Button

TOOL Button

Press

© 2009 Samsung Electronics Co., Ltd. All rights reserved.

Contents

4

English

6 Installing the Stand

6

Disconnecting the Stand

7

Installing the Wall Mount Kit

7

Assembling the Cables

8

Anti-Theft Kensington Lock

8

Preparing before installing Wall-Mount

8

Securing the Installation Space

9

Securing the TV to the Wall

10

Accessories

11

Viewing the Control Panel

12

Viewing the Connection Panel

14

Connections

15

Mini Remote Control

15

Installing Batteries in the Remote Control

16

Viewing the Remote Control

17 Placing Your Television in Standby Mode

17

Plug & Play Feature

18

Viewing the Display

19 Viewing the Menus

19

Channel Menu

24 Picture Menu

Getting Started

Basic Operation

Using the Menus

19 Country
Auto Store
20 Manual Stor
Cable Search Option (depending on the

country)
21 Full Guide / Mini Guide / Default Guid
22 Channel Lis
23 Channel Mode
Fine Tune

24 Mode
Backlight / Contrast / Brightness / Sharpness /

Colour / Tint(G/R)
Advanced Settings
25 Picture Option
27 Picture Rese
Auto Adjustment
Screen

e

e

t

s

t

28 Sound Menu

28 Mode
Equalizer
SRS TruSurround HD
Audio Language
Audio Format
Audio Description
Auto Volume
Speaker Select
29 Sound Selec
Sound Reset

t

30 Setup Menu

30 Language
Time
31 Broadcas
32 Securit
Network
General

t

y

35 Network Connection

37

Setting the Network

37 Network Type
Network Setup

40 Input Menu

40 Source List
Edit Name

41 Support menu

41 Legal Notice
Product Guide
Self Diagnosis
42 Software Upgrade
HD Connection Guid
Contact Samsung

e

Media Play - USB Device

43 Connecting a USB Device

44

Media Play Function

45

Sorting the Photo List

47

Viewing a Photo or Slide Show

49

Sorting the Music List

50

Playing a Music

52

Sorting the Movie List

53

Playing a Movie File

56

Using the Setup Menu

5

English

Media Play-DLNA

Other Information

57 Setting the DLNA Network

58

Installing the DLNA Application

59

Using the DLNA Application

61

Using the DLNA Function

Anynet

62 Connecting Anynet+ Devices

63

Setting Up Anynet

Switching between Anynet+ Devices

63

65

Recording

65

Listening through a Receiver (Home Theatre)

66

Troubleshooting for Anynet

+

+

+

Content Library

67 Using the Content Library

68

Using the Contents

69

Using the Content Management

Internet@TV

70 Getting Started with Internet@TV

73

Using the Prole Widget

74

Using the Yahoo!® Widget Gallery

75

Using the Yahoo!® Weather Widget

75

Using the Yahoo!® News Widget

76

Using the Yahoo!® Flickr Widget

77

Using the Yahoo!® Finance Widget

77

Troubleshooting for Internet@TV

78

Help Website

83 Teletext Feature

84

Using Your TV as a Computer (PC) Display

85

Troubleshooting: Before Contacting

Service Personne

86

Specications

Warning! Important Safety Instructions

Wiring the Mains Power Supply Plug (UK Only)

Warranty Card

l

Home Network Centre

79 About the Home Network Centre

79

Connecting to the Home Network Centre

80

Setting Up the Home Network Centre

81

Using the Message Function

82

Using the Media Function

6

English

Getting Started

Installing the Stand

Getting Started

Attach your LED TV to the stand.

Two or more people should carry the TV.

■

1

2

Make sure to distinguish between the front and back of the stand when assembling

■

them.
To make sure the TV is installed on the stand at a proper level, do not apply excess

■

downward pressure to the upper left of right sides of the TV.

Fasten screws at position 1 and then fasten screws at position 2.

Stand the product up and fasten the screws. If you fasten the screws with the LED

■

TV placed down, it may lean to one side.
The stand is installed for models with the screen size of 37 inch and above.

■

Disconnecting the Stand

Remove four screws from the back of the TV.

1

Separate the stand from the TV.

Two or more people should carry the TV.

■

2

Cover the bottom hole with the cover.

3

2

1

1 2 3

7

English

Getting Started

Installing the Wall Mount Kit

Wall mount items (sold separately) allow you to mount the TV on the wall.
For detailed information on installing the wall mount, see the instructions provided with the Wall
Mount items. Contact a technician for assistance when installing the wall mounted bracket.
Samsung Electronics is not responsible for any damage to the product or injury to yourself or
others if you elect to install the TV on your own.

Do not install your Wall Mount Kit while your TV is turned on. It may result in personal

■

injury due to electric shock.
Remove the stand and cover the bottom hole with a cap and fasten with two screws.

■

Assembling the Cables

Stand Type

Enclose the cables in the Holder-Wire Cable so that the cables are not visible through the transparent stand.

■

1

1

2

3

1

2

3

Wall-Mount Type

1

Anti-Theft Kensington Lock

8

English

The Kensington Lock is a device used to physically fix the system when using it in a public
place. The appearance and locking method may differ from the illustration depending on the
manufacturer. Refer to the manual provided with the Kensington Lock for proper use.

The locking device has to be purchased separately.

■

The location of the Kensington Lock may be different depending on its model.

■

Getting Started

Insert the locking device into the Kensington slot on the LED TV (1) and turn it in

1

the locking direction (2).

Connect the Kensington Lock cable (3).

3

2

1

2

Fix the Kensington Lock to a desk or a heavy stationary object.

3

Preparing before installing Wall-Mount

To install a wall-mount, use the Holder-Ring 1.

Case A. Installing the SAMSUNG Wall-Mount Case B. Installing another company’s Wall-Mount

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation.
Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product.
Install the product so the required distances shown in the figure are kept.

When using a stand or wall-mount, use parts provided by Samsung Electronics only.

■

If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.
If you use parts provided by another manufacturer, it may result in a problem with the product or fire due to an increase in the internal
temperature of the product due to poor ventilation.

The appearance may differ depending on the product.

■

When installing the product with a stand When installing the product with a wall-mount

10 cm

10 cm

10 cm

10 cm

10 cm

10 cm

10 cm

9

English

Getting Started

Securing the TV to the Wall

Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall.
In particular, ensure your children do not hang over or destabilize the TV;
doing so may cause the TV to tip over, causing serious injuries or death.
Follow all safety precautions provided on the included Safety Flyer. For
added stability, install the anti-fall device for safety purposes, as follows.

To avoid the TV from falling:

Put the screws into the clamps and firmly fasten them onto the wall. Confirm that the

1

screws have been firmly installed onto the wall.

You may need additional material such as an anchor depending on the type of

■

wall.
Since the necessary clamps, screws, and string are not supplied, please

■

purchase these additionally.

Remove the screws from the centre back of the TV, put the screws into the clamps,

2

and then fasten the screws onto the TV again.

Screws may not be supplied with the product. In this case, please purchase the

■

screws of the following specifications.
Screw Specifications:

■

For a 32 ~ 40 Inch LED TV: M6 X L15



For a 40 ~ 55 inch LED TV : M8 X L30



Wall

Connect the clamps fixed onto the TV and the clamps fixed onto the wall with a strong

3

string and then tie the string tightly.

Install the TV near to the wall so that it does not fall backwards.

■

It is safe to connect the string so that the clamps fixed on the wall are equal to or

■

lower than the clamps fixed on the TV.
Untie the string before moving the TV.

■

Verify all connections are properly secured. Periodically check connections for any

4

sign of fatigue for failure. If you have any doubt about the security of your connections,
contact a professional installer.

Wall

10

English

Getting Started

Accessories

Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer.

■

Remote Control & Batteries

(AAA x 2)

Mini Remote Control &

Batteries (3V)

(M4 X L10)

Cover-Bottom Cleaning Cloth

User Manual Stand Screw X 5 Programme CD

Component Cable SCART Cable Holder-Ring (4ea) Holder-Wire Stand

Holder-Wire (3ea) AV Cable

The items colour and shape may vary depending on the model.

■

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.

■

Product design and specifications may be changed without notice in order to enhance product performance.

Holder-Wire Cable

(Depending on the model)

11

English

Getting Started

Viewing the Control Panel

The product colour and shape may vary depending on the model.

■

The front panel buttons can be activated by touching it with your finger.

■

Speakers

Aim the remote control towards
this spot on the TV.

Press to turn the TV on and off.

Toggles between all the available input
sources.
In the on-screen menu, use this button as
you would use the ENTERE button on
the remote control.

Press to increase or decrease the
volume. In the on-screen menu, use
the

Y

the ◄ and ► buttons on the remote

control.

Press to change channels. In the
on-screen menu, use the z
buttons as you would use the

▼ and ▲ buttons on the remote

control.

Press to see an on-screen
menu of your TV’s features.

buttons as you would use

12

213 4 65

9

0

!

0

@

#

7

8

English

Getting Started

Viewing the Connection Panel

The product colour and shape may vary depending on the model.

■

Power Input

[TV Rear Panel]

1 KENSINGTON LOCK (depending on the model)
The Kensington Lock (optional) is a device used to physically fix the system when used in a public place. If you want to use a

locking device, contact the dealer where you purchased the TV.

The location of the Kensington Lock may be different depending on its model.

■

When connecting, use the appropriate connector.

■

2 LAN
Connect a LAN cable to this port to connect to the Network.

3 ANT IN
Connects to an antenna or cable TV system.

4 EXT (RGB)
Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players.

When connecting, use the appropriate connector.

■

In EXT Mode, DTV Out supports MPEG SD Video and Audio only.

■

Input/Output Specification

■

Connector

EXT O O O Only TV or DTV output is available.

Video Audio (L / R) RGB Video + Audio (L / R)

Input Output

13

English

Getting Started

5 AV IN [VIDEO] / [R-AUDIO-L]
Video and audio inputs for external devices, such as a camcorder or VCR.

When connecting, use the appropriate connector.

■

6 COMPONENT IN
Connects Component video / audio.

When connecting, use the appropriate connector.

■

7 PC IN
Connects to the video output jacks on your PC.

If your PC supports an HDMI connection, you can connect this to the HDMI IN 1(DVI), 2, 3 or 4 terminal.

■

If your PC supports a DVI connection, you can connect this to the HDMI IN 1(DVI) / PC/DVI AUDIO IN terminal.

■

8 PC/DVI AUDIO IN
Connect to the audio output jack on your PC.

DVI audio outputs for external devices.
9 HDMI IN 1(DVI), 2, 3, 4

Connects to the HDMI jack of a device with an HDMI output.

No sound connection is needed for an HDMI to HDMI connection.

■

Use an HDMI cable which is smaller than 14mm.

■

What is HDMI?

■

HDMI(High-Definition Multimedia Interface), is an interface that enables the transmission of digital audio and video



signals using a single cable.

The difference between HDMI and DVI is that the HDMI device is smaller than DVI’s one.



The TV may not output sound and pictures may be displayed with abnormal colour when DVD / Blu-ray player / Cable Box

■

/ Satellite receiver (Set-Top Box) supporting HDMI versions older than 1.3 are connected. When connecting an older HDMI
cable and there is no sound, connect the HDMI cable to the HDMI IN 1(DVI) jack and the audio cables to the PC/ DVI AUDIO
IN jacks on the back of the TV. If this happens, contact the company that provided the DVD / Blu-ray player / Cable Box /
Satellite receiver (Set-Top Box) to confirm the HDMI version, then request an upgrade.

Use the HDMI IN 1(DVI) jack for DVI connection to an external device. Use a DVI to HDMI cable or DVI-HDMI adapter (DVI to

■

HDMI) for video connection and the PC/DVI AUDIO IN jacks for audio. When using an HDMI / DVI cable connection, you must
use the HDMI IN 1(DVI) jack.

HDMI cables that are not 1.3 may cause annoying flicker or no screen display.

■

0 USB1(HDD) / USB2
Connector for software upgrades and Media Play, etc.
You can connect to Samsung’s network wirelessly using the ‘Samsung Wireless LAN Adapter’ (Sold separately).

For USB HDD, use the USB1 (HDD) port.

■

! DIGITAL AUDIO OUT (OPTICAL)
Connects to a Digital Audio component such as a Home theatre receiver.

When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL) jack: Decrease the volume of the TV and

■

adjust the volume level with the system’s volume control.

5.1CH audio is possible when the TV is connected to an external device supporting 5.1CH.

■

When the receiver (home theatre) is set to On, you can hear sound output from the TV’s Optical jack. When the TV is displaying a

■

DTV(air) signal, the TV will send out 5.1 channel sound to the Home theatre receiver. When the source is a digital component such
as a DVD / Blu-ray player / Cable Box / Satellite receiver (Set-Top Box) and is connected to the TV via HDMI, only 2 channel sound
will be heard from the Home Theatre receiver. If you want to hear 5.1 channel audio, connect the digital audio out jack on DVD /
Blu-ray player / Cable Box / Satellite receiver (Set-Top Box) directly to an Amplifier or Home Theatre, not the TV.

@ COMMON INTERFACE Slot

Insert CI (Common Interface) card into the slot.

■

When not inserting ‘CI CARD’ in some channels, ‘Scrambled Signal’ is displayed on the screen.

■

The pairing information containing a telephone number, CI CARD ID, Host ID and other information will be displayed in about

■

2~3 minutes. If an error message is displayed, please contact your service provider.
When the channel information configuration has finished, the message ‘Updating Completed’ is displayed, indicating that the

■

channel list is now updated.

You must obtain a CI CARD from a local cable service provider. Remove the CI CARD by carefully pulling it out with



your hands since dropping the CI CARD may cause damage to it.
Insert the CI-Card in the direction marked on it.



The place of the COMMON INTERFACE Slot may be different depending on its model.



CAM is not supported in some countries and regions, check with your authorized dealer.



The CI+ function is only applicable to LE********P.



If you have some problems, please contact to service provider.

# EX-LINK
Connector for service only.

14

English

Connections

Best

Getting Started

OPTICAL (Digital)

AUDIO (Analog)

Normal

Digital Audio connection

Using an Optical Cable

Digital Audio System

OPTICAL

HD connection

Using an HDMI Cable

HDMI OUT

HD connection

Using an HDMI/DVI Cable

DVI OUTAUDIO OUT

Using a D-Sub Cable

PC OUTAUDIO OUT

15

English

Getting Started

Mini Remote Control

1

4

2
3

2

3

OPEN

CLOSE

The Mini Remote Control is a simplified remote control that consists of the power,

■

channel and volume buttons only.

Television Standby button.

This button only works when you press it for longer than 1.5 seconds.

■

1

< : Next channel / > : Previous channel

2

+ : Volume up / – : Volume down

3

IrDA transmitter

Use the Mini Remote Control so that this part faces the TV.

■

4

Installing Batteries in the Remote Control

Normal Remote Control

Lift the cover at the back of the remote control upward as shown in the figure.

1

Install two AAA size batteries.

Make sure to match the ‘+’ and ‘–’ ends of the batteries with the diagram inside

■

2

3

the compartment.

Replace the cover.

Remove the batteries and store them in a cool, dry place if you won’t be using

■

the remote control for a long time. (Assuming typical TV usage, the batteries
should last for about one year.)

OPERATION

Mini Remote Control

Turn the battery cover counterclockwise to unlock it and then separate the battery

1

cover.

Insert the corresponding 3V Lithium battery.

2

Place the battery cover into the remote control aligning it with the grooves and then

3

turn the battery cover clockwise to lock the cover.

If the remote control doesn’t work, check the following:

■

Is the TV power on?



Are the plus and minus ends of the batteries reversed?



Are the batteries drained?



Is there a power outage or is the power cord unplugged?



Is there a special fluorescent light or neon sign nearby?



OPERATION

16

English

Getting Started

Viewing the Remote Control

You can use the remote control up to a distance of about 23 feet from the TV.

■

The performance of the remote control may be affected by bright light.

■

The product colour and shape may vary depending on the model.

■

Turns the TV on and off.

Press to change the channel.

Press to switch to your
favourites channels. (p. 22)

Press to display information
on the TV screen. (p. 18)

Displays the main on-screen
menu.

Use to quickly select frequently
used functions.

Press to use various internet
services to view useful formation
and entertaining content. (p. 70)

Use these buttons in the

Channel list, Internet@TV,
Media Play menu, etc.

Press to increase or decrease
the volume.

Alternately select Teletext,
Double, or Mix. (p. 83)

Displays the Channel List on
screen. (p. 22)

Use these buttons in the Media
Play and Anynet+ modes. (∏:
This remote can be used to control
recording on Samsung recorders
with the Anynet+ feature)

Selects the TV mode directly.
(p. 83)

Pressing the ON/OFF @ light
button toggles between on and
off. When the remote control is
on, and a button is pressed on
the remote control, the remote
control buttons will be lit for a
moment. (Using the remote
control with the ON/OFF @
light button set to On will reduce
the battery usage time.)

Enables you to return to the
previous channel you were
watching.

Displays the Electronic
Programme Guide (EPG).
(p. 21)

Returns to the previous menu.

Use to select on-screen menu
items and change menu values.

Press to exit the menu.

Press to change channels.

Press to display and select the
available video sources. (p. 40)

Press to temporarily cut off the
sound. (p. 41)

Allows you to play music files,
pictures, and movies. (p. 44)
This function enables you to
view the Content Library. (p. 61)

Displays the Digital subtitle.
(p. 31)

Audio Description selection.
(p. 28)

0

8
4

Colour buttons Fastext

Teletext mode selection
(LIST / FLOF)

Teletext store

Teletext

size selection

topic selection

Teletext Functions (p. 83)

Teletext

5

:
1
2

reveal

Exit from the Teletext display

Teletext

sub page

Teletext

next page

Teletext previous page

3

Teletext

Teletext

Teletext

index

hold

cancel

6
9
7

Basic Operation

Placing Your Television in Standby Mode

17

English

Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when
you wish to interrupt viewing temporarily (during a meal, for example).

Press the POWERP button on the remote control.

The screen is turned off and a red standby indicator appears on your set.

■

1

To switch your set back on, simply press the POWERP button again.

Do not leave your set in standby mode for long periods of time (when you are away on holiday, for example). It is best to

■

2

unplug the set from the mains and aerial.

Plug & Play Feature

When the TV is initially powered on, basic settings proceed automatically and
subsequently.

Press the POWERP button.

You can also use the POWERP button on the TV.

■

1

2
3

4
5

6

7

8
9

The message Select the OSD Language. is displayed.

■

Press the ENTERE button. Select the appropriate language by pressing the

▲ or ▼ button. Press the ENTERE button to confirm your choice.

Press the ◄ or ► button to select Store Demo or Home Use, then the

ENTERE button.

We recommend setting the TV to Home Use mode for the best picture in your

■

home environment.
Store Demo mode is only intended for use in retail environments.

■

If the unit is accidentally set to Store Demo mode and you want to return to

■

Home Use (Standard): Press the volume button on the TV. When the volume
OSD is displayed, press and hold the MENU button on the TV for 5 seconds.

Press the ENTERE button. Select the appropriate country by pressing the

▲ or ▼ button. Press the ENTERE button to confirm your choice.

Press the ▲ or ▼ button to select Air or Cable, then press the ENTERE button.

Air: Air antenna signal.

■

Cable: Cable antenna signal.

■

Press the ▲ or ▼ button to select the channel source to memorize.

Press the ENTERE button to select Start.

When setting the antenna source to Cable, a step appears allowing you to

■

set a value for the digital channel search. For more information, refer to pages
19~20..

Digital & Analogue: Digital and Analogue channels.

■

Digital: Digital channels.

■

Analogue: Analogue channels.

■

The channel search will start and end automatically.

■

Press the ENTERE button. Press the ▲ or ▼ button to select Auto, then press

the ENTERE button.

If you select Manual, Set current date and time is displayed.

■

If you have received a digital signal, the time will be set automatically. If not,

■

select Manual to set the clock.

The description for the connection method providing the best HD screen quality is

displayed. Check the description and press the ENTERE button.

Press the ◄ or ► button to select See Product Guide or Watch TV. Press the
ENTERE button.

See Product Guide: You are moved to the Product Guide where you can

■

view the introduction to the main functions of your new HDTV.
Watch TV: You can watch the set broadcasting channel.

■

Plug & Play

Select the OSD Language.

Menu Language : English ▶

E

Enter

Press the ENTERE button

■

at any time to interrupt the
memorization process.

Basic Operation

18

English

Basic Operation

If you want to reset this feature...

Press the MENU button.

1

Press the ▲ or ▼ button to select Setup, then press the ENTERE button.

Press the ENTERE button again to select Plug & Play.

2

Enter your 4 digit PIN number.

The default PIN number of a new TV set is ‘0-0-0-0’.

■

3

If you want to change PIN number, use the Change PIN function.

■

Viewing the Display

The display identifies the current channel and the status of certain audio-video
settings.

Press the INFO button on the remote control.

1

The TV will display the channel, the type of sound, and the status of certain picture
and sound settings.

Press the INFO button once more or wait approximately 10 seconds and the

■

display disappears automatically.

Setup

Plug & Play ▶

Language : English
Time
Broadcast
Security
Network
General

The Plug & Play feature is only

■

available in the TV mode.

Press the INFO button to viewing

■

the information.

abc1

DTV Air

15

18:11 Thu 6 Jan

Life On Venus Ave nue

Unclassif ied

No Detai ld Informa tion

18:00 ~ 6:00

E Watch
' Informat ion

Using the Menus

Viewing the Menus

19

English

Menu provides one button access for controlling your TV. It enables you to perform a variety of tasks intuitively with a control
panel on the screen rather than a variety of remote control button presses.

Display the main on-screen menu.

ENTERE / Direction button

Move the cursor and select an item.

Select the currently selected item.

MENU button

Confirm the setting.

RETURN button
Return to the previous menu.

EXIT button
Exit the on-screen menu.

Operation the Menu

The access step may differ depending on the selected menu.

Press the MENU button.

The menu is displayed on the screen.

■

1

Press the ▲ or ▼ button to select one of the icons.

2

Press the ENTERE button to access the icon’s sub-menu.

Press the ▲ or ▼ button to move to items in the menu.

3

Press the ENTERE button to enter items in the menu.

Using the Menus

Press the ▲/▼/◄/► button to change the selected items.

4

Press the RETURNR button to return to the previous menu.

Press the EXITe button to exit from the menu.

5

Channel Menu

Channel

Option Description

Country Analogue Channel

Auto Store

❑

You can change the country for analogue channels.

Digital Channel

❑

You can change the country for digital channels.
The PIN number input screen appears. Enter your 4 digit

PIN number.
You can scan for the frequency ranges available to you

(and availability depends on your country). Automatically
allocated programme numbers may not correspond to
actual or desired programme numbers.

Scans for all channels with active broadcast stations and
stores them in the TV’s memory.

Channel

Country ▶

Auto Store
Manual Store
Cable Search Option
Full Guide
Mini Guide
Default Guide : Full Guide
Channel List

If a channel is locked using the

■

Child Lock function, the PIN
input window appears.

20

English

Using the Menus

Channel

Option Description

Auto Store Air / Cable

Manual Store

❑

Antenna source to memorize

Digital & Analogue: Digital and Analogue

■

channels.
Digital: Digital channels.

■

Analogue: Analogue channels.

■

When selecting Cable → Digital & Analogue
or Cable → Digital:

Provide a value to scan for cable channels.

Search Mode → Full / Network /Quick

■

Quick

■

Network ID: Displays the network



identification code.
Frequency: Displays the frequency



for the channel. (Differs in each
country)

Modulation: Displays available



modulation values.
Symbol Rate: Displays available



symbol rates.

Scans for a channel manually and stores it in the TV’s
memory.

Digital Channel

❑

Manual store for digital channels.

Channel: Set the Channel number using the ▲, ▼ or

■

number (0~9) buttons.
Frequency: Set the frequency using the number buttons.

■
Bandwidth: Set the bandwidth using the ▲, ▼ or

■

number (0~9) buttons.

When it has finished, channels are updated in the channel
list.

If you want to stop Auto Store,

■

press the ENTERE button.
The Stop Auto Store? message
will be displayed. Select Yes by

pressing the ◄ or ► button, then

press the ENTERE button.

If a channel is locked using the

■

Child Lock function, the PIN
input window appears.

Digital Channel is only available

■

in DTV mode.

Cable Search Option
(depending on the
country)

Analogue Channel

❑

Manual store for analogue channel.

Programme (Programme number to be assigned to a

■
channel): Sets the programme number using the ▲, ▼

or number (0~9) buttons.

Colour System → Auto / PAL / SECAM / NTSC4.43:

■
Sets the colour system value using the ▲ or ▼ button.

Sound System → BG / DK / I / L: Sets the sound

■
system value using the ▲ or ▼ button.

Channel (When you know the number of the channel

■
to be stored): Press the ▲ or ▼ button to select C (Air
channel) or S (Cable channel). Press the ► button, then
press the ▲, ▼ or number (0~9) buttons to select the

required number.

You can also select the channel number directly by



pressing the number (0~9) buttons.
If there is abnormal sound or no sound, reselect



the sound standard required.

Search (When you do not know the channel numbers):

■
Press the ▲ or ▼ button to start the search. The tuner

scans the frequency range until the first channel or the
channel that you selected is received on the screen.

Store (When you store the channel and associated

■

programme number): Set to OK by pressing the
ENTERE button.

Sets additional search options such as the frequency and
symbol rate for cable network searches.

Freq.Start (Frequency Start): Set the start frequency

■

(Differs in each country)
Freq.Stop (Frequency Stop): Set the stop frequency

■

(Differs in each country)
Modulation: Displays available modulation values.

■

Symbol Rate: Displays available symbol rates.

■

Analogue Channel is only

■

available in analogue TV mode.

Channel mode

■

P (Programme mode):



When completing tuning, the
broadcasting stations in your
area have been assigned
to position numbers from
P00 to P99. You can select
a channel by entering the
position number in this
mode.

C (Air channel mode):



You can select a channel
by entering the assigned
number to each air
broadcasting station in this
mode.

S (Cable channel mode):



You can select a channel
by entering the assigned
number for each cable
channel in this mode.

21

English

Using the Menus

Full Guide /

3

6

9

P

Mini Guide /
Default Guide

Full Guide

Full Guide

900

Today

900 f tn
901 ITV Play
902 Kerrang!
903 Kiss
904 oneword

905 Hits

▼

Channel

Option Description

The EPG (Electronic Programme Guide) information is
provided by the broadcasters. Programme entries may
appear blank or out of date as a result of the information
broadcast on a given channel. The display will dynamically
update as soon as new information becomes available.

Full Guide

❑

Displays the programme information as time ordered One
hour segments. Two hours of programme information is
displayed which may be scrolled forwards or backwards in
time.

Mini Guide

❑

The information of each programme is displayed by each
line on the current channel Mini Guide screen from the
current programme onwards according to the programme
starting time order.

Default Guide → Mini Guide / Full Guide

❑

You can decide whether to display either the Mini Guide
or the Full Guide when the GUIDE button on the remote
control is pressed.

DTV Cable 900 f tn 2:10 Tue 1 Jun
Freshmen On Campus
2:00 - 2:30
No Detailed Information

2:00 - 3:00 3:00 - 4:00

Freshmen O..

Mint Extra
Loaded
40 with Dynamite MC
The Distillery
Smash Hits! Sunday

E

Watch Information Mini Guide +24 Hours Exit

Street Hypn..

No Information

No Information
Kisstory
No Information

You can also display the guide

■

menu simply by pressing the
GUIDE button. (To configure
the Default Guide, refer to the
descriptions.)

Mini Guide

Mini Guide DTV Cable 900 f tn

2:00
2:30
5:00

▼

Freshmen On Campus
Street Hypnosis
Booze Britain

E

Watch Information Full Guide Next Page Exit

(Red)

Using the Full / Mini Guide

To... Then...

Watch a programme in the EPG list Select a programme by pressing the ▲, ▼, ◄, ► button.

Exit the guide Press the Blue button

If the next programme is selected, it is scheduled with the clock icon displayed. If the ENTERE button is pressed again, press the
◄, ► button to select Cancel Schedules, the scheduling is cancelled with the clock icon gone.

View programme information

Please click on INFO button for the detailed information. Channel Number, Running Time, Status Bar, Parental Level, Video Quality
Information (HD / SD), Sound Modes, Subtitle or Teletext, languages of Subtitle or Teletext and brief summary of the highlighted
programme are included on the detailed information. “...” will be appeared if the summary is long.

Toggle between the Mini Guide and Full Guide Press the Red button repeatedly.

In Full Guide
Scrolls backwards quickly (24 hours).
Scrolls forwards quickly (24 hours).

In Mini Guide
Display previous page quickly.
Display next page quickly.

Select a programme of your choice by pressing the ▲, ▼, ◄, ► button.

Then press the INFO button when the programme of your choice is highlighted.
The programme title is on the upper part of the screen centre.

Press the Green button repeatedly.
Press the Yellow button repeatedly.

Press the Green button.
Press the Yellow button.

22

English

Using the Menus

Option Description

Channel List

Channel

Using this menu, you can add / delete or set favourites
channels and use the programme guide for digital
broadcasts.

All Channels

❑

Shows all currently available channels.

Added Channels

❑

Shows all added channels.

Favourites

❑

Shows all favourite channels.

Programmed

❑

Shows all current reserved programmes.

Select a channel in the All Channels, Added Channels
or Favourites screen by pressing the ▲ / ▼ buttons, and
pressing the ENTERE button. Then you can watch the
selected channel.

Using the Colour buttons with the Channel List

Red (Channel Type): Toggle between your TV, Radio,

■

Data / Other and All.
Green (Zoom): Enlarges or shrinks a channel number.

■

Yellow (Select): Selects multiple channel lists.

■

You can perform the add/delete or add to favourites/
delete from favourites function for multiple channels at
the same time. Select the required channels and press
the Yellow button to set all the selected channels at
the same time. The c mark appears to the left of the
selected channels.

Channel List Option Menu (in All Channels /
Added Channels / Favourites)

Press the TOOLS button to use the option menu.

■

Option menu items may differ depending on the channel

■

status.

Add / Delete

❑

You can delete or add a channel to display the channels you
want.

All deleted channels will be shown on All Channels

■

menu.
You can also delete a channel to the Added Channels or

■

Favourites menu in the same manner.

Add to Favourite / Delete from Favourite

❑

You can set channels you watch frequently as favourites.

Press the TOOLS button to display the Tools menu.

T

You can also set the add to (or delete from) Favourite by
selecting Tools → Add to Favourite (or Delete from
Favourite).

The “*” symbol will be displayed and the channel will

■

be set as a favourite.
All favourite channels will be shown on Favourites

■

menu.

Lock / Unlock

❑

You can lock a channel so that the channel cannot be
selected and viewed.

This function is available only when the Child Lock is set

■

to On.
The PIN number input screen appears. Enter your 4 digit

■

PIN number.
The default PIN number of a new TV set is “0-0-0-0”. You

■

can change the PIN, by selecting Change PIN from the
menu.
The “\” symbol will be displayed and the channel will be

■

locked.

All Channel Type Zoom Select T Tools

You can select these options by

■

simply pressing the CH LIST
button on the remote control.

To select the favourites channels

■

you have set up, press the FAV.
CH button on the remote control.

TOOLS (Tools): Displays

■

the Delete (or Add), Add to
Favourite (or Delete from
Favourite), Lock (or Unlock),
Timer Viewing, Edit Channel
Name, Edit Channel Number,
Sort, Select All (or Deselect
All), Auto Store menu. (The

Options menus may differ
depending on the situation.)

Channel Status Display Icons

■

A: An Analogue channel.



c: A channel selected by



pressing the Yellow button.
*: A channel set as a



Favourite.
(: A programme currently



being broadcast.
\: A locked channel.



): A reserved programme



All Channels

824 UKTV Gold
825 UKTV style

A

1 C --

A

2 C --

A

3 C --

A

4 C --

A

5 C --

A

6 C --

A

7 C --

A

8 C --

A gray-coloured channel

■

Delete
Add to Favourite
Lock
Timer Viewing
Edit Channel Name
Sort



indicates the channel has been
deleted.

The Add menu only appears for

■

deleted channels.

23

English

Using the Menus

Channel

Option Description

Channel List Timer Viewing

❑

If you reserve a programme you want to watch, the channel
is automatically switched to the reserved channel in the
Channel List; even when you are watching another channel.
To reserve a programme, set the current time first.

You can set the channel, day, month, year, hour and

■

minute directly by pressing the number buttons on the
remote control.
Reserving a programme will be shown in the

■

Programmed menu.
Digital Programme Guide and Viewing Reservation:

■

When a digital channel is selected, and you press

the ► button, the Programme Guide for the channel

appears. You can reserve a programme according to the
procedures described above.

Edit Channel Name (analogue channels only)

❑

Channels can be labelled so that their call letters appear
whenever the channel is selected.

Edit Channel Number (digital channels only)

❑

You can also edit the channel number by pressing the
number buttons on the remote control.

Sort (analogue channels only)

❑

This operation allows you to change the programme
numbers of the stored channels. This operation may be
necessary after using the auto store.

Select All / Deselect All

❑

Select All: You can select all the channels in the

■

channel list.
Deselect All: You can deselect all the selected

■

channels.

Auto Store

❑

For detailed procedures on setting up options, refer to
pages 19~20.

Channel List Option Menu (in Programmed)

You can view, modify or delete a reservation.
Press the TOOLS button to use the option menu.

Change Info

❑

Select to change a viewing reservation.

Cancel Schedules

❑

Select to cancel a viewing reservation.

Information

❑

Select to view a viewing reservation.
(You can also change the reservation information.)

Select All

❑

Select all reserved programmes.

Channel Mode

Fine Tune

When press the P >/< button, Channels will be switched
within the selected channel list.

Added Ch.

❑

Channels will be switched within the memorized channel list.

Favourite Ch.

❑

Channels will be switched within the favourite channel list.

If the reception is clear, you do not have to fine tune the
channel, as this is done automatically during the search and
store operation. If the signal is weak or distorted, you may
have to fine tune the channel manually.

Fine tuned channels that have been saved are marked

■

with an asterisk ‘*’ on the right-hand side of the channel
number in the channel banner.

To reset the fine-tuning, select Reset by pressing the

■
▲ or ▼ button and then press the ENTERE button.

Only memorized channels can

■

be reserved.

The names of digital

■

broadcasting channels are
automatically assigned and
cannot be renamed.

You can only select Deselect

■

All when there is a selected
channel.

If a channel is locked using the

■

Child Lock function, the PIN
input window appears.

Programmed

1 / 1 / 2009

13:59 5 TV1

18:59 2 TV3 ) The Equalizer
20:59 2 TV3 ) McMillan & Wife
21:59 2 TV3 ) M.Spillane’s mike

All Zoom Select T Tools E Information

Only Analogue TV channels can

■

)

Change Info
Cancel Schedules
Information
Select All

be fine tuned.

24

English

Using the Menus

Picture Menu

Option Description

Mode

Backlight /
Contrast /
Brightness /
Sharpness /
Colour /
Tint(G/R)

Advanced Settings

Selects the type of picture settings that best correspond to
your viewing preferences or requirements. Presets a higher
brightness, contrast, and sharpness to the picture.

Dynamic

■

Recommended for use in bright room conditions.

Standard

■

Recommended for use in a normal viewing condition.

Natural

■

Adds more punch and contrast to the image than the
Standard mode.

Movie

■

Corresponding to the conditions used in movie,
recommended for use in darker viewing conditions.

Your television has several setting options that allow you to
control the picture quality.

Backlight

■

Adjusts the brightness of LED back light.

Contrast

■

Increases or decreases the brightness in white areas of the
picture. Too little contrast and the picture may seem dark;
too much contrast and the picture will lose details in white
images.

Brightness

■

Increases or decreases the overall brightness of the
picture, but best used to adjust the black level of the image.
Too little brightness and shadow detail will be lost; too much
brightness and blacks will be gray and washed out.

Sharpness

■

Increases or decreases the apparent detail in the picture.
Too little sharpness and the image might look soft. Too
much sharpness can add false edges to objects or can
make noise more noticeable.

Colour

■

Increases or decreases colour saturation levels in the
picture. Too little colour and the image will be black and
white (undersaturated); too much colour and the image will
look oversaturated and cartoonish.

Tint(G/R)

■

Changes the picture hue from reddish to a greenish
appearance.

Samsung’s new TVs allow you to make even more precise
picture settings than previous models.

Black Tone → Off / Dark / Darker / Darkest

■

Increases the picture’s shadow detail by lightening the
black level (ie changing the gamma) at low levels. This is
most commonly used for watching movies with dark scenes
to keep the picture from appearing washed out in bright
rooms.

Dynamic Contrast → Off / Low / Medium / High

■

Increases or decreases the difference between the
brightest and darkest portions of the image with changing
scenes. Shadows are more visible with dark scenes, while
contrast is enhanced with bright scenes.



Mode : Standard ▶

Backlight : 7
Contrast : 95
Brightness : 45
Sharpness : 50
Colour : 50

Tint (G/R) : G50/R50

Advanced Settings

Press the TOOLS button to

■

display the Tools menu. You
can also set the picture mode
by selecting Tools → Picture

Mode.

Natural is not available in PC

■

mode.

▲

Backlight

▼

U

Move L Adjust E Enter R Return

Only analogue TV, Ext., AV

■

modes of the PAL system,
you cannot use the Tint(G/R)
Function.

When you make changes to

■

Backlight, Contrast, Brightness,
Sharpness, Colour or Tint(G/
R), the OSD will be adjusted

accordingly.
In PC mode, you can only make

■

changes to Backlight, Contrast
and Brightness.

Settings can be adjusted and

■

stored for each external device
you have connected to an input
of the TV.

The energy consumed during use

■

can be significantly reduced if the
brightness level of the picture is
lowered, which will reduce the
overall running cost.

Advanced Settings

Black Tone : Off ▶

Dynamic Contrast : Medium

Gamma : 0

Colour Space : Native

White Balance

Flesh Tone : 0

Edge Enhancement : On

U

Move E Enter R Return

7

25

English

Using the Menus

Option Description

Advanced Settings

Picture Options


Gamma

■

Changes the rate at which images ramp or fade from light
to dark. Recommended for advanced users only.

Colour Space

■

Increases or decreases the visible colour range for red,
green and blue. Recommended for advanced users only.

Auto: The TV will choose the colour range that



is closest to the range used during TV and movie
production.

Native: Displays the most enhanced, vibrant



colours possible.
Custom: Provides precise saturation and colour



point adjustment of Red, Green, Blue, Yellow,
Cyan, and Magenta. Recommended for advanced
users only.

White Balance

■

You can adjust the colour temperature for more natural
picture colours.

R, G, B-Offset: Fine tunes the white balance, or



colour ‘temperature’ in dark areas by changing the
individual values of R, G, B. Recommended for
advanced users only.

R, G, B-Gain: Fine tunes the white balance, or



colour ‘temperature’ in the light areas by changing
the individual values of R, G, B. Recommended for
advanced users only.

Reset: Resets the colour space to the default



values.

Flesh Tone

■

Adjusts the colour of flesh tones. Increasing the value
creates a more reddish picture. Decreasing the value
creates a more greenish picture.

Edge Enhancement

■

Increases or decreases the emphasis at object edges.

xvYCC

■

Setting the xvYCC mode to on increases detail and colour
space when watching movies from an external device (ie.
DVD player) connected to the HDMI or Component IN
jacks.

Colour Tone

■

Selects a preset white balance, or ‘colour temperature’
setting, to provide either a reddish or bluish hue, dependant
upon your personal preference.

Cool: Selects a white balance, or colour



‘temperature’ with a bluish hue. Skin tones may
have less warmth but whites will seem brighter.
Recommended when watching normal TV
broadcasting in a bright room.

Normal: Selects the white balance, or colour



“temperature” with a less bluish, more reddish hue.
Suitable for most viewing environments and programs.

Warm1, Warm2, Warm3: Selects a redder, warmer



hue that more closely matches the setting on monitors
used in the production of TV and movie content.
Recommended when watching movie and dramatic
TV content. The lowest setting is best used for black &
white content.

Advanced Settings is available in

■

Standard or Movie mode.
In PC mode, you can only make

■

changes to Dynamic Contrast,
Gamma and White Balance from

among the Advanced Settings
items.

Colour is available when Colour

■

Space is set to Custom.
In Colour, you can adjust the RGB

■

values for the selected colour.
To reset the adjusted RGB value,

■

select Reset.

xvYCC is available when the

■

picture mode is set to Movie, and
the external input is set to HDMI or
Component mode.

This function may not be

■

supported depending on your
external device.

Picture Options

Colour Tone : Normal ▶

Size : Auto Wide

Screen Mode : 16:9

Digital NR : Auto

HDMI Black Level : Normal

Film Mode : Off

100Hz Motion Plus : Standard

▼

In PC mode, you can only make

■

U

Move E Enter R Return

changes to the Colour Tone and
Size from among the items in
Picture Options.

Warm1, Warm2 or Warm3 is

■

only activated when the picture
mode is Movie.

26

English

Using the Menus

Option Description

Picture Options


Size

■

Changes the screen shape in terms of height and width.
Also known as Aspect Ratio.

Auto Wide: Enables the correct picture size to



match the original video signal.
16:9: Sets the picture aspect ratio to fill the screen.



Wide Zoom: Enlarges the middle part of the



picture.
Zoom: Magnifies the picture contents horizontally



and vertically.
4:3: Sets the picture aspect ratio to 4:3 with black



or gray side bars.
Screen Fit: Matches every pixel of the original



image to a pixel on the TV screen (aka 1:1 pixel
mapping) to show the entire image.

Wide Zoom: Press the ► button to select

●

Position, then press the ENTERE button.

Press the ▲ or ▼ button to move the picture up /

down. Then press the ENTERE button.
Zoom: Press the ► button to Select Position,

●

then press the ENTERE button. Press the ▲ or

▼ button to move the picture up and down. Then

press the ENTERE button. Press the ► button
to Select Size, then press the ENTERE button.

Press the ▲ or ▼ button to magnify or reduce the

picture size in the vertical direction. Then press the

ENTERE button.
After selecting Screen Fit in HDMI (1080i / 1080p)

●

or Component (1080i / 1080p) mode: Select
Position by pressing the ◄ or ► button. Use the

▲, ▼, ◄ or ► button to move the picture.

Reset: Press the ◄ or ► button to select Reset,
then press the ENTERE button. You can initialize
the setting.

If you use the Screen Fit function with HDMI 720p

●

input, 1 line will be cut at the top, bottom, left and
right as in the Overscan function.

When Double (À, Œ) mode has been set in PIP,

●

the Picture Size cannot be set.

Screen Mode

■

When setting the picture size to Auto Wide in a 16:9 wide
TV, you can determine the picture size you want to see the
4:3 WSS (Wide Screen Service) image or nothing. Each
individual European country requires different picture size
so this function is intended for users to select it.

16:9: Sets the picture to 16:9 wide mode.



Wide Zoom: Magnify the size of the picture more



than 4:3.
Zoom: Magnify the size of the picture vertically on



screen.
4:3: Sets the picture to 4:3 normal mode.



Digital NR → Off / Low / Medium / High / Auto

■

Can reduce the grain effect or level of video snow seen in
images coming from poor quality sources.

HDMI Black Level → Normal / Low

■

Adjusts the black level in the picture according to the type
of signal being transmitted through HDMI.

Film Mode

■

Applies the appropriate video processing needed to
achieve the best picture quality for watching movies.

Off: Turn the Film Mode function off.



Auto1: Improves the picture quality for fast motion



scenes.
Auto2: Allows a smoother text motion on fast



motion scenes.

Press the TOOLS button to

■

display the Tools menu. You can
also set the size by selecting
Tools → Picture Size.

Depending on the input source,

■

the picture size options may vary.
The items available may differ

■

depending on the selected mode.
In PC Mode, only 16:9 and 4:3

■

mode can be adjusted.
Settings can be adjusted and

■

stored for each external device
you have connected to an input
of the TV.

Temporary image retention may

■

occur when viewing a static image
on the set for more than two
hours.

This function is available in Auto

■

Wide mode.
This function is not available in

■

PC, Component or HDMI mode.

This function is active only when

■

an external device is connected to
the TV via HDMI (RGB signals).

Film Mode is supported in TV,

■

AV, COMPONENT(480i / 1080i)
and HDMI(480i / 1080i).

27

English

Using the Menus

Option Description

Picture Options

Picture Reset


100Hz Motion Plus → Off / Clear / Standard / Smooth

■

/ Custom / Demo

Removes drag from fast scenes with a lot of movement to
provide a clearer picture.

If you enable 200 Hz Motion Plus, noise may appear on
the screen. If this occurs, set 100Hz Motion Plus to Off.

Off: Switches 100Hz Motion Plus off.



Clear: Sets 100Hz Motion Plus to minimum.



Standard: Sets 100Hz Motion Plus to medium.



Smooth: Sets 100Hz Motion Plus to maximum.



Custom: Adjusts the blur and judder reduction



level to suit your preference.

Blur Reduction: Adjusts the blur reduction level

●

from video sources.
Judder Reduction: Adjusts the judder reduction

●

level from video sources when playing films.
Reset: Reset the custom settings.

●

Demo: Displays the difference between 100Hz



Motion Plus on and off modes.

Blue Only Mode

■

Helps to adjust the colour and tint controls when used with
colour bar test patterns. Recommended for qualified picture
alignment specialists only. Available only when the Picture
Mode is set to Movie or Standard.

Resets all picture settings to the default values.

Reset Picture Mode: Current picture values return to

■

default settings.

Blue Only Mode is available

■

when the picture mode is set to

Movie or Standard.

Option Description

Auto Adjustment

Screen

Picture (In the PC mode)

Use the Auto Adjust function to have the TV set
automatically adjust the video signals it receives.

The function also automatically fine-tunes the settings and
adjusts the frequency values and positions.

Coarse / Fine

■

The purpose of picture quality adjustment is to remove or
reduce picture noise. If the noise is not removed by Fine­tuning alone, then adjust the frequency as best as possible
(Coarse) and Fine-tune again. After the noise has been
reduced, readjust the picture so that it is aligned on the
centre of screen.

PC Position

■

Adjust the PC’s screen positioning if it does not fit the TV
screen.

Press the ▲ or ▼ button to adjusting the Vertical-Position.
Press the ◄ or ► button to adjust the Horizontal-Position.

Image Reset

■

You can replace all image settings with the factory default
values.

Preset: Press the SOURCE button

■

to select PC mode.
This function does not work in

■

DVI-HDMI mode.

Press the TOOLS button to

■

display the Tools menu. You can
also set the Auto Adjustment
by selecting Tools → Auto

Adjustment.

28

English

Using the Menus

Sound Menu

Option Description

Standard: Selects the normal sound mode.

Mode

Equalizer

SRS TruSurround HD

Audio Language

Audio Format

Audio Description

Auto Volume

Speaker Select

■

Music: Emphasizes music over voices.

■

Movie: Provides the best sound for movies.

■

Clear Voice: Emphasizes voice over other sounds.

■

Custom: Recalls your customized sound settings.

■

The sound settings can be adjusted to suit your personal
preferences.

Mode: Selects the sound mode among the predefined

■

settings.
Balance L/R: Adjusts the balance between the right and

■

left speaker.
100Hz / 300Hz / 1KHz / 3KHz / 10KHz (Bandwidth

■

Adjustment): To adjust the level of different bandwidth
frequencies.

Reset: Resets the equalizer settings to the default values.

■

SRS TruSurround HD is a patented SRS technology that
solves the problem of playing 5.1 multichannel content
over two speakers. TruSurround delivers a compelling,
virtual surround sound experience through any two-speaker
playback system, including internal television speakers.
It is fully compatible with all multichannel formats.

You can change the default value for audio languages.
Displays the language information for the incoming stream.

While viewing a digital channel, this function can be

■

selected.
You can only select the language among the actual

■

languages being broadcast.

When sound is emitted from both the main speaker and
the audio receiver, a sound echo may occur due to the
decoding speed difference between the main speaker
and the audio receiver. In this case, use the TV Speaker
function.

While viewing a digital channel, this function can be

■

selected.
The Audio Format appears according to the broadcasting

■

signal.

This is an auxiliary audio function that provides an
additional audio track for visually challenged persons.
This function handles the Audio Stream for the AD (Audio
Description), when it is sent along with the Main audio from
the broadcaster. Users can turn the Audio Description On or
Off and control the volume.

Audio Description

■

Turn the audio description function on or off.

Volume

■

You can adjust the audio description volume.





Each broadcasting station has its own signal conditions,
and so it is not easy to adjust the volume every time the
channel is changed. This feature lets you automatically
adjust the volume of the desired channel by lowering the
sound output when the modulation signal is high or by
raising the sound output when the modulation signal is low.

When you watch TV with it connecting to a Home theatre,
turn the TV speakers off so you can listen to sound from the
Home theatre’s (external) speakers.

External Speaker: Used to listen to the sound of the

■

External (Home Theatre) Speakers.
TV Speaker: Used to listen to the sound of the TV

■

Speakers.

Sound

Volume is active when Audio Description is set

to On.
While viewing a Digital channel, this function can

be selected.

Sound

Mode : Custom ▶

Equalizer
SRS TruSurround HD : Off

Audio Language : ---­Audio Format : ---­Audio Description

Auto Volume : Off
Speaker Select : TV Speaker

Press the TOOLS button to

■

display the Tools menu. You can
also configure the sound mode
by selecting Tools → Sound
Mode.

Press the TOOLS button to

■

display the Tools menu. You can
also set the SRS TruSurround
HD by selecting Tools → SRS
TS HD.

Press the AD button on the

■

remote control to select Off or
On.

The volume buttons and MUTE

■

buttons do not operate when the

Speaker Select is set to External
Speaker.

If you select External Speaker

■

in the Speaker Select menu, the
sound settings will be limited.

29

English

Using the Menus

Selecting the Speaker

TV’s Internal Speakers

RF / AV / Component / PC / HDMI RF / AV / Component / PC / HDMI

TV Speaker Sound Output Sound Output

External
Speaker

Video No Signal Mute Mute

Mute Sound Output

Audio Out (Optical) to Sound

System

Sound

Option Description

Sound Select

When the PIP feature is activated, you can listen to the
sound of the sub (PIP) picture.

You can select this option when PIP is set to On.

■

Sound Reset

Cancel sound reset.

Sound Reset

You can restore the Sound settings to the factory defaults.
Reset Sound Mode: Current sound values return to default

settings.

Selecting the Sound Mode

You can set the sound mode in the Tools menu. When you set to Dual l ll, the current sound
mode is displayed on the screen.

Audio Type Dual 1 / 2 Default

A2

Stereo

NICAM

Stereo

If the stereo signal is weak and an automatic switching occurs, then switch to the mono.

■

This function is only activated in stereo sound signal. It is deactivated in mono sound

■

signal.
This function is only available in TV mode.

■

Mono MONO

Stereo STEREO ↔ MONO

Dual DUAL 1 ↔ DUAL 2 DUAL 1

Mono MONO

Stereo MONO ↔ STEREO

Dual

MONO ↔ DUAL 1

DUAL 2

Automatic change

Automatic change

DUAL 1

Reset All Reset Sound Mode Cancel

L Move E Enter R Return

Press the TOOLS button to

■

display the Tools menu. You can
also set the sound of the sub
picture by selecting Tools → PIP

→ Sound Select.

30

English

Using the Menus

Setup Menu

Option Description

Language
Time Clock

You can set the menu language.

❑

Setting the clock is necessary in order to use the various timer
features of the TV. If you disconnect the power cord, you have
to set the clock again.

Clock Mode

■

You can set up the current time manually or automatically.

Auto: Set the current time automatically using the time



from the digital broadcast.
Manual: Set the current time to a manually specified time.



Clock Set

■

You can set the current time manually.

This function is only available when Clock Mode is set



to Manual.
You can set the day, month, year, hour and minute



directly by pressing the number buttons on the remote
control.

Sleep Timer

❑

The sleep timer automatically shuts off the TV after a preset
time (30, 60, 90, 120, 150 and 180 minutes).

To cancel the Sleep Timer function, select Off.

■

Timer 1 / Timer 2 / Timer 3

❑

Three different on / off timer settings can be made.
You must set the clock first.

On Time

■

Set the hour, minute, and activate / inactivate.
(To activate timer with the setting you’ve chosen, set to

Activate.)

Off Time

■

Set the hour, minute, and activate / inactivate.
(To activate timer with the setting you’ve chosen, set to

Activate.)

Volume

■

Set the desired volume level.

Source → TV / USB

■

You can select the TV or USB device content to be played
when the TV turns on automatically. Select TV or USB. (Make
sure that an USB device is connected to your TV.)

Antenna (when Source is set to TV)

■

Select ATV or DTV.

Channel (when Source is set to TV)

■

Select the desired channel.

Contents (when Source is set to USB)

■

You can select a folder on the USB Device with music or photo
files to be played when the TV turns on automatically.

If the folder name is too long, the folder cannot be



selected.
If you are using two of the same type USB device, be



sure the folder names are different so the correct USB
is read.

Repeat

■

Select Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun or
Manual.

When Manual is selected, press the ► button to select



the desired day of the week. Press the ENTERE button
over the desired day and the c mark will appear.

You can set the hour, minute and channel by pressing the



number buttons on the remote control.

Setup

Plug & Play

Setup

Language : English ▶

Time
Broadcast
Security
Network
General

The current time will appear

■

every time you press the INFO
button.

Depending on the broadcast

■

station and signal, the auto time
may not be set correctly. If this
occurs, set the time manually.

The Antenna or cable must be

■

connected in order to set the time
automatically.

Press the TOOLS button to

■

display the Tools menu. You
can also set the sleep timer by
selecting Tools → Sleep Timer.

On Time

00 00 Inactivate

Off Time

00 00 Inactivate

Volume

10

Repeat

Once

When there is only one photo file

■

Timer 1

Source Antenna Channel

TV ATV 0

Sun Mon Tue Wed Thu Fri Sat

L

Move U Adjust E Enter R Return

in the USB the Slide Show will
not play.

Auto Power Off

■

When you set the timer on, the
television will eventually turn off,
if no controls are operated for 3
hours after the TV was turned on
by the timer. This function is only
available in timer on mode and
prevents overheating, which may
occur if a TV is on for too long
time.

31

English

Using the Menus

Option Description

Broadcast Subtitle

❑

You can activate and deactivate the subtitles. Use this
menu to set the Subtitle Mode. Normal under the menu is
the basic subtitle and Hard of hearing is the subtitle for a
hearing-impaired person.

Subtitle

■

Switches subtitles on or off.

Mode

■

Sets the subtitle mode.

Subtitle Language

■

Set the subtitle language.

If the programme you are watching does not support



the Hard of hearing function, Normal automatically
activates even though Hard of hearing mode is
selected.

English is the default in cases where the selected



language is unavailable in the broadcast.

Digital Text

❑

If the programme is broadcast with digital text, this feature
is enabled.

MHEG (Multimedia and Hypermedia Information Coding

■

Experts Group)
An International standard for data encoding systems
used in multimedia and hypermedia. This is at a higher
level than the MPEG system which includes data-linking
hypermedia such as still images, character service,
animation, graphic and video files as well as multimedia
data. MHEG is user runtime interaction technology
and is being applied to various fields including VOD
(Video-On-Demand), ITV (Interactive TV), EC (Electronic
Commerce), tele-education, tele-conferencing, digital
libraries and network games.

Setup

You can select these options

■

simply by pressing the SUBT.
button on the remote control.

Teletext Language

❑

You can set the Teletext language by selecting the language
type.

English is the default in cases where the selected

■

language is unavailable in the broadcast.

Preference

❑

Primary Audio Language / Secondary Audio

■

Language / Primary Subtitle Language / Secondary
Subtitle Language / Primary Teletext Language /
Secondary Teletext Language

Using this feature, users can select one of the languages.
The language selected here is the default when the user
selects a channel
If you change the language setting, the Subtitle
Language, Audio Language, and the Teletext Language
of the Language menu are automatically changed to the
selected language.
The Subtitle Language, Audio Language, and the Teletext
Language of the Language menu show a list of languages
supported by the current channel and the selection is
highlighted. If you change this language setting, the
new selection is only valid for the current channel. The
changed setting does not change the setting of the
Primary Subtitle Language, Primary Audio Language, or
the Primary Teletext Language of the Preference menu.

32

English

Using the Menus

Setup

Option Description

Broadcast Common Interface

Security Child Lock

❑

CI Menu

■

This enables the user to select from the CAM-provided
menu.

Select the CI Menu based on the menu PC Card.

Application Info.

■

This contains information on CAM inserted in the CI slot
and displays it. The Application Info inserting is about the
CI CARD. You can install the CAM anytime whether the TV
is ON or OFF.

1. Purchase the CI CAM module by visiting your nearest
dealer or by phone.

2. Insert the CI CARD into the CAM in the direction of the
arrow until it fits.

3. Insert the CAM with the CI CARD installed into the
common interface slot.
(Insert the CAM in the direction of the arrow, right up to
the end so that it is parallel with the slot.)

4. Check if you can see a picture on a scrambled signal
channel.

❑

This feature allows you to prevent unauthorized users, such
as children, from watching unsuitable programme by muting
out video and audio.

Before the setup screen appears, the PIN number input

■

screen appears. Enter your 4 digit PIN number.
You can change the PIN by selecting Change PIN from

■

the menu.
You can lock some channels in Channel List.

■

Child Lock is available only in

■

TV mode.
The default PIN number of a new

■

TV set is 0-0-0-0.

Parental Lock > Parental Rating

❑

This feature allows you to prevent unauthorized users,
such as children, from watching unsuitable programme by
a 4-digit PIN (Personal Identification Number) code that is
defined by the user.

The Parental Rating item differs depending on the

■

country.
Before the setup screen appears, the PIN number input

■

screen appears. Enter your 4 digit PIN number.
You can change the PIN by selecting Change PIN from

■

the menu.
When the parental ratings are set, the “\” symbol is

■

displayed.
Allow All: Press to unlock all TV ratings.

■

Block All: Press to lock all TV ratings.

■

Change PIN

❑

You can change your personal ID number that is required to
set up the TV.

Before the setup screen appears, the PIN number input

■

screen appears. Enter your 4 digit PIN number.

Network Network Type / Network Setup

❑

For detailed procedures on setting up options, refer to
pages 37~39.

If you forget the PIN code, press

■

the remote control buttons in the
following sequence, which resets
the PIN to 0-0-0-0: POWER

(Off) → MUTE → 8 → 2 → 4 →
POWER (On).

33

English

Using the Menus

General

Setup

Option Description

Game Mode

❑

When connecting to a game console such as PlayStation™
or Xbox™, you can enjoy a more realistic gaming
experience by selecting game menu.

If Game Mode is On:

■

Picture mode is automatically changed to Standard



and cannot be changed.
Sound mode is automatically changed to Custom



and cannot be changed. Adjust the sound using the
equalizer.

The Reset Sound function is activated. Selecting



the Reset function after setting the equalizer resets
the equalizer settings to the factory defaults.

BD Wise

❑

Provides the optimal picture quality for SAMSUNG DVD,
Blu-ray and Home Theatre products which support BD
Wise. You can enjoy a richer picture when using them
connected to this Samsung TV.

Connect SAMSUNG products that have BD Wise using

■

an HDMI cable.
When the BD Wise set to On, the picture mode is

■

automatically changed to the optimal resolution.
BD Wise is available in HDMI mode.

■

Energy Saving

❑

This feature adjusts the brightness of the TV in order to
reduce power consumption. When watching TV at night,
set the Energy Saving mode option to High to reduce eye
fatigue as well as power consumption.

Menu Transparency

❑

You can set the Transparency of the menu.

Restrictions on game mode

■

(Caution)

To disconnect the game



console and connect another
external device, set Game
Mode to Off in the setup
menu.

Game Mode is not available



in regular TV, PC and Ext
mode.

While PIP is in operation, the



Game Mode function cannot
be used.

If the picture is poor when

■

external device is connected
to TV, check if Game Mode is
On. Set Game Mode to Off and
connect external devices.

Press the TOOLS button to

■

display the Tools menu. You
can also set the Energy Saving
option by selecting Tools →

Energy Saving.

Melody

❑

A melody sound can be set to come on when the TV is
powered On or Off.

The Melody does not play

■

When no sound is output from the TV because the



MUTE button has been pressed.
When no sound is output from the TV because the



volume has been reduced to minimum with the
volume (-) button.

When the TV is turned off by Sleep Timer function.



Light Effect

❑

You can turn the LED on/off on the front of TV. Turn it off to
save power or if the LED bothers you.

Set the Light Effect to Off to reduce the power
consumption.

Off: LED is always Off.

■

In Standby: LED is On when TV is turned off.

■

Watching TV: LED is On when watching TV.

■

Always: LED is always On, regardless of TV settings.

■

LED

The colour of light may very

■

depending on the model.

34

English

Using the Menus

Option Description

PIP

General

❑

You can use the PIP feature to simultaneously watch the
TV tuner and one external video source. This product has
one built-in tuner, which does not allow PIP to function in
the same mode. Please see ‘PIP Settings’ below for details.

If you select the PIP picture sound, refer to page 29.

■

PIP

■

You can activate or deactivate the PIP function.

Size → Õ / Ã / À /

■

You can select a size of the sub-picture.

Position → Ã / – / — /

■

You can select a position of the sub-picture.

In Double (Œ, À) mode, Position cannot be

■

selected.

Channel

■

You can select the channel for the sub-screen.

PIP Settings

Main picture Sub picture
Component
HDMI1/DVI, HDMI2, HDMI3, HDMI4
PC

Setup

TV

Œ

œ

PIP

PIP : On ▶

Size :

Position :

Channel : ATV 4

Press the TOOLS button to

■

Õ
Ã

U

Move E Enter R Return

display the Tools menu. You
can also configure PIP related
settings by selecting Tools →
PIP.

If you turn the TV off while watching

■

in PIP mode and turn it on again, the
PIP window will disappear.

You may notice that the picture in

■

the PIP window becomes slightly
unnatural when you use the main
screen to view a game or karaoke.

While Internet@TV is in operation,

■

the PIP function cannot be used.

35

English

Using the Menus

Network Connection

You can set up the Internet Protocol so that you can communicate with various connected networks.

Network Connection - Cable

❑

LAN Connection for a DHCP Environment

■

The procedures to set up the network using Dynamic Host Configuration Protocol (DHCP) are described below. Since an IP address,
subnet mask, gateway, and DNS are automatically allocated when DHCP is selected, you do not have to enter them manually.

Connect the LAN port on the rear panel of the TV and the external modem with a LAN Cable.

1

Connect the Modem port on the wall and the external modem with a Modem Cable.

2

The Modem Port on the Wall External Modem

(ADSL / VDSL / Cable TV)

1 LAN Cable2 Modem Cable

You can connect the LAN via a Sharer (Router).

The Modem Port on the Wall

External Modem

(ADSL / VDSL / Cable TV)

IP Sharer

LAN CableModem CableLAN Cable

You can connect the LAN port and the TV directly depending on your network status.

The LAN Port on the Wall

LAN Cable

TV Rear Panel

TV Rear Panel

TV Rear Panel

The terminals (the position of the port and the type) of the external device may differ depending on the manufacturer.

■

If the IP address allocation by the DHCP server has failed, turn the external modem off, turn it on again after at least 10 seconds and

■

then try again.
For the connections between the external modem and the Sharer (Router), refer to the owner’s manual of the corresponding

■

product.
You can connect the TV to the LAN directly without connecting it through a Sharer (Router)

■

You cannot use a manual-connection-type ADSL modem because it does not support DHCP. You have to use an

■

automaticconnection-type ADSL modem.

36

English

Using the Menus

LAN Connection for Static IP Environment

■

The procedures to set up the network using a static IP address are described below. You have to manually enter the IP address, subnet
mask, gateway, and DNS that are provided by your Internet Service Provider (ISP).

Connect the LAN port on the rear panel of the TV and the LAN port on the wall using the LAN cable.

The LAN Port on the Wall

1 LAN Cable

TV Rear Panel

You can connect the LAN via a Sharer (Router).

IP Sharer

LAN CableLAN Cable

The terminals (the position of the port and the type) of the external device may differ depending on the manufacturer.

■

If you are using a static IP address, your ISP will inform you of the IP address, subnet mask, gateway, and DNS. You must enter

■

TV Rear PanelThe LAN Port on the Wall

these values to complete the network settings. If you do not know the values, ask your network administrator.
For the information on how to configure and connect a Sharer (Router), refer to the owner’s manual for the corresponding product.

■

You can connect the TV to the LAN directly without connecting it through a Sharer (Router).

■

If you use an IP Sharer (IP Router) that supports DHCP, you can set up the device as either DHCP or static IP.

■

For the procedures to use a static IP address, ask your Internet Service Provider.

■

Network Connection - Wireless

❑

You can connect to the network wirelessly through a wireless IP sharer.

Connect the ‘Samsung Wireless LAN Adapter’ into the USB1(HDD) or USB2 terminal of the TV.

TV Rear Panel

Wireless IP sharer

or

LAN Cable

Samsung Wireless

LAN Adapter

The LAN Port on the Wall

You must use the ‘Samsung Wireless LAN Adapter’(WIS09ABGN) to use a wireless network.

■

Samsung’s Wireless LAN adapter is sold separately. The WIS09ABGN Wireless LAN adapter is offered by select retailers,

■

Ecommerce sites and Samsungparts.com.
To use a wireless network, your TV must be connected to a wireless IP sharer. If the wireless IP sharer supports DHCP, your TV can

■

use a DHCP or static IP address to connect to the wireless network.
Samsung’s Wireless LAN adapter supports IEEE 802.11A, IEEE 802.11B, IEEE 802.11G, IEEE 802.11N. When you play DLNA

■

video over IEEE 802.11B/G connection, the video may not be played smoothly.
If the wireless IP sharer allows you to turn the Ping connection function on/off, turn it on.

■

Select a channel for the wireless IP sharer that is not currently being used. If the channel set for the wireless IP sharer is currently

■

being used by another device nearby, this will result in interference and communications may fail.
If you apply a security system other than the systems listed blow, it will not work with the TV.

■

When applying the security key for the AP (wireless IP sharer), only the following is supported.



1) Authentication Mode : OPEN, SHARED, WPAPSK, WPA2PSK

2) Encryption Type : WEP, TKIP, AES
When applying the security key for the Ad-hoc mode, only the following is supported.



1) Authentication Mode : SHARED, WPANONE

2) Encryption Type : WEP, TKIP, AES

If your AP supports WPS(Wi-Fi Protected Setup), you can connect to the network via PBC (Push Button Configuration) or PIN

■

(Personal Identification Number). WPS will automatically configure the SSID and WPA key in either mode.
If the device isn’t certified, it may not connect to the TV via the ‘Samsung Wireless LAN Adapter’.

■

37

English

Using the Menus

Setting the Network

Setup

Option Description

Network Type

Network Setup Cable Network Setup

Select Cable or Wireless as the method to connect to the
network.

Cable

■

Connect to the network using a cable.

Wireless

■

Connect to the network wirelessly.

❑

(when Network Type is set to Cable)

Please check if the LAN cable is connected.

■

Internet Protocol Setup → Auto / Manual



Network Test: You can test or confirm the network



connection status after setting up the network.

Cable Network Setup-Auto

If you connect the LAN cable and it supports DHCP, the
Internet Protocol (IP) Settings are automatically configured.

1. Set Network Type to Cable.

2. Select Cable Network Setup.

3. Set Internet Protocol Setup to Auto.

The Internet Protocol is set automatically.

■

4. Select Network Test to check the network connectivity.

Broadcast
Security

Setup

Network ▶

General

The menu is activated only if the

■

‘Samsung Wireless LAN Adapter’
is connected.

Cable Network Setup

Internet Protocol Setup : Auto ▶

Network Test

IP Address :

Subnet Mask :

Gateway :
DNS Server :

U

Move E Enter R Return

When unable to connect to a wired network

If your Internet service provider has registered the MAC address of the device used to
connect to the Internet for the first time and authenticates the MAC address each time you
connect to the Internet, your TV may not be able to connect to the Internet as the MAC
address differs from that of the device (PC).

In this case, ask your Internet service provider about the procedures to connect devices
other than your PC (such as your TV) to the Internet. If your Internet service provider
requires an ID or password to connect to the Internet (network), your TV may not be
able to connect to the Internet. In this case, you have to enter your ID or password when
connecting to the Internet using an Internet Sharer (Router).

The internet connection may fail due to a firewall problem. In this case, contact your
Internet service provider. If you cannot connect to the Internet even if you have followed
the procedures of your Internet service provider, please contact Samsung Electronics.

38

English

Using the Menus

Setup

Option Description

Network Setup Cable Network Setup-Manual

To connect the TV to the LAN using a static IP address, you
must set up the Internet Protocol (IP).

1. Set Network Type to Cable.

2.

Select Cable Network Setup.

3. Set Internet Protocol Setup to Manual.

4. Set up IP Address, Subnet Mask, Gateway and DNS
Server.

Press the number buttons on the remote control

■

when you set the Network manually.

5. Select Network Test to check the network connectivity.

Wireless Network Setup

■

Internet Protocol Setup → Auto / Manual



Network Test: You can test or confirm the network



connection status after setting up the network.
Select a network: Access Point: You can select



the IP sharer to use when using a wireless network.

If a wireless Access Point is not in the Access Point

●

list, press the Red button.
When the connection is made, you will be returned

●

to the screen automatically.
If you have selected an Access Point with a security

●

authentication: The Security Key input screen
appears. Enter the security key and press the Blue
button on the remote control.

If security encryption type is WEP, 0~9, A~F will be

●

available when you input security key.

The menu is activated only if the

■

‘Samsung Wireless LAN Adapter’
is connected.

Wireless Network Setup

Security Key

A B C D E F

n Move

`~9

Number

Delete

Done

Number E Enter R Return

Connecting WPS (Wi-Fi Protected Setup)

If Security Key is already set: In access point list, select
WPS.

You can select PBC, PIN, Security Key.

■

Connecting by using PBC: Select a PBC (Push



Button Configuration). Press the PBC
the AP (access point) within 2minutes, and wait for
connection.

Connecting by using PIN: Select a PIN (Personal



Identification Number).

The message showing the PIN Code is displayed.

●

Input the PIN Code at AP device within 2minutes.
Select OK and wait for connection.
Try again if connecting operation doesn’t work.

●

When the connection is not established although

●

tried again, reset the access point. Please refer to a
manual of each access point.

Connecting by using Security Key: When selecting



Security Key, the input window is
the security key and press ENTERE button.

Try again if connecting operation doesn’t work.

●

If Security Key is not set: When security setting



of AP that supports WPS is NONE, you
PBC, PIN, None Security. None Security is capable
of connecting to AP directly without using WPC
function.

Process of PBC, PIN is same as above.

●

Refer to if Security Key is already set.
Try again if connecting operation doesn’t work.

●

button on

displayed. Input

can select

Wireless Network Setup

Select a network 3/9

sson

Press the PBC button on the access point.
Access Point Name : AP_1

Press OK After input TV’s Pin code in the access
point’s setup.
Access Point Name : AP_1
PIN Code : 12345678

Security Key

A

H

O

V

Select a network 3/9

jee

Search

AP_1

Ad-hoc

Ap_2

Wireless Network Setup

B

C

D

I

J

K

P

Q

R

W

X

Y

n Move

Wireless Network Setup

sson
jee

Search

AP_1

Ad-hoc

Ap_2

PBC
PIN
Security Key

U Move E Enter R Return

Cancel

CancelOK

E

L

M

S

T

Z

`~9

U Move E Enter R Return

Number

F

G

Lowercase

N

Delete

Done

U

Number E Enter R Return

PBC
PIN
None Security

39

English

Using the Menus

Option Description

Network Setup

Setup

Ad-hoc: You can connect to a mobile device



without an access point through the ‘Samsung
Wireless LAN Adapter’ by
network.

How to connect to new Ad-hoc

1. Choose Select a network, then a device list is
displayed.

2. While in the device list, press the Blue button on the
remote or select Ad-hoc.

The message that means the existing network

■

is disconnected is displayed.

3. Input the generated Network Name(SSID) and

Security Key into the device you want to connect.

How to connect an existing Ad-hoc device

1. Choose Select a network, the device list is

displayed.

2. Select the device you want in the Device list.

3. If security key was applied, input the security key again.

If network doesn’t operate normally, please

■

check the Network Name(SSID) and
Security Key again. If the Security Key

is incorrect, it may be the reason for the
malfunction.

using a peer to peer

The existing network system may have limited
functionality. Do you want to change the network
connection?

Yes No

Wireless Network Setup-Auto

If you want to connect AP, AP should support DHCP.
Only devices which support Ad-hoc mode can be
connected without DHCP.

1. Set Network Type to Wireless.

2. Select Wireless Network Setup.

3. Set Internet Protocol Setup to Auto.
The Internet Protocol is set automatically.

■

4. Select a network through

Select a network.

5. Select Network Test to check the network connectivity.

Wireless Network Setup-Manual

1. Set Network Type to Wireless.

2. Select Wireless Network Setup.

3. Set Internet Protocol Setup to Manual.

4. Set up IP Address, Subnet Mask, Gateway and DNS

Server.

Press the number buttons on the remote control

■

when you set the Network manually.

5. Select

When unable to connect to an AP(Access Point)

Your TV may fail to locate an AP(Access Point) that is configured as a private SSID type. In
this case, please change the AP settings and try again. If your Internet service provider has
registered the MAC address of the device used to connect to the Internet for the first time and
authenticates the MAC address each time you connect to the Internet, your TV may not be able
to connect to the Internet as the MAC address differs from that of the device (PC).

In this case, ask your Internet service provider about the procedures to connect devices other
than your PC (such as your TV) to the Internet. If you cannot connect to the Internet even if
you have followed the procedures of your Internet service provider, please contact a Samsung
Electronics.

Network Test to check the network connectivity.

Wireless Network Setup

Internet Protocol Setup : Auto ▶

Network Test

Select a network : AP1

IP Address :

Subnet Mask :

Gateway :
DNS Server :

Internet Protocol Setup : Manual ▶

Network Test

Select a network : AP1

IP Address : 0 0 0

Subnet Mask : 0 0 0

Gateway : 0 0 0 0
DNS Server :

U

Move E Enter R Return

Wireless Network Setup

0

0 0

U

Move E Enter R Return

0

0

0

40

English

Using the Menus

Input Menu

Option Description

Source List

Edit Name

Input

Use to select TV or other external input sources such as
DVD / Blu-ray players / Cable Box / Satellite receivers
(Set-Top Box) connected to the TV. Use to select the input
source of your choice.

TV / Ext. / AV / Component / PC / HDMI1/DVI / HDMI2 /

■

HDMI3 / HDMI4 / USB1 / USB2

You can choose only those external devices that



are connected to the TV. In the Source List,
connected inputs will be highlighted and sorted to
the top. Inputs that are not connected will be sorted
to the bottom.

If USB devices are connected to the USB1(HDD)



and USB2 jacks, they are displayed as USB1 and
USB2 in order.

Using the Colour buttons on the remote with the



Source list.

Red (Refresh): Refreshes the connected external

●

devices. Press this if your Source is on and
connected, but does not appear in the list.

TOOLS (Tools): Displays the Edit Name and

●

Information menus.

Name the device connected to the input jacks to make your
input source selection easier.

VCR / DVD / Cable STB / Satellite STB / PVR STB / AV

■

Receiver / game / Camcorder / PC / DVI / DVI PC / TV
/ IPTV / Blu-ray / HD DVD / DMA

When a PC with a resolution of 1920 x 1080@60Hz



is connected to the HDMI IN 1 port, you should set
the HDMI IN 1(DVI) mode to DVI PC in the Edit
Name of the Input mode.

When connecting an HDMI/DVI cable to the HDMI



IN 1(DVI) port, you should set the HDMI1/DVI
mode to DVI or DVI PC in the Edit Name of
the Input mode. In this case, a separate sound
connection is required.

Input

Source List

Edit Name

Press the SOURCE button on

■

the remote control to view an
external signal source. TV mode
can be selected by pressing the
TV button.

PC always stays activated.

■

Source List

TV

Ext. : - - - ­PC : - - - -

AV : - - - ­Component : - - - ­HDMI1/DVI : - - - -

Refresh T Tools

41

English

Using the Menus

Support menu

Support

Option Description

Legal Notice

Product Guide

Using the Remote Control Buttons in the Product Guide Menu

Button Operations

Yellow Button

◄/► Move the cursor and select an item.

ENTER

E

RETURN Return to the previous menu.

EXIT

Option Description

Self Diagnosis

View the Legal Notice and General Disclaimer regarding
Third Party Contents and Service.

The General Disclaimer may differ depending on the

■

country.

The Product Guide gives you information on the most
important features of this TV.

The descriptions provided by this function are in English
only.

Picture Quality Full HD 1080p

100Hz Motion Plus

Picture Mode

Medi@2.0 Internet@TV

Content Library Flash

USB2.0 Movie

DLNA Wireless

Eco-Friendly Energy Saving Mode

Eco Material

Shows the contents of the Product Guide sequentially.
(Auto Play)

Select the currently selected item.

Stop the current function and return to the Product Guide
main menu.

Support

Picture Test

■

If you think you have a picture problem, perform the picture
test. Check the colour pattern on the screen to see if the
problem still exists.

Yes: If the test pattern does not appear or there



is noise in the test pattern, select Yes. Therefore,
contact Samsung’s call centre for assistance.

No: If the test pattern is properly displayed, select



No. There may be a problem with your external
equipment. Please check your connections. If the
problem still persists, refer to the external device’s
user manual.

Sound Test

■

If you think you have a sound problem, please perform the
sound test. You can check the sound by playing a built-in
melody sound through the TV.

‘Does the problem still exist with this sound test?’ appears
on the screen.

Yes: If during the sound test you can hear sound only



from one speaker or not at all, select Yes. Therefore,
contact Samsung’s call centre for assistance.

No: If you can hear sound from the speakers, select



No. There may be a problem with your external
equipment. Please check your connections. If the
problem still persists, refer to the external device’s
user manual.

Support

Legal Notice ▶

Product Guide
Self Diagnosis
Software Upgrade
HD Connection Guide
Contact Samsung

If you hear no sound from the

■

TV’s speakers, before performing
the sound test, make sure
Speaker Select is set to TV
speaker in the Sound menu.

The melody will be heard during

■

the test even if Speaker Select
is set to External Speaker or the
sound is muted by pressing the
MUTE button.

42

English

Using the Menus

Option Description

Self Diagnosis

Software Upgrade

HD Connection Guide

Contact Samsung

Support

Signal Information (digital channels only)

■

Unlike analogue channels, which can vary in reception
quality from ‘snowy’ to clear, digital (HDTV) channels have
either perfect reception quality or you will not receive them
at all. So, unlike analogue channels, you cannot fine tune
a digital channel. You can, however, adjust your antenna to
improve the reception of available digital channels.

Samsung may offer upgrades for the TV’s firmware in the
future. These upgrades can be performed via the TV when
it is connected to the Internet, or by downloading the new
firmware from samsung.com to a USB memory device.

Current Version is the software already installed in



the TV.
Alternative Software (Backup) shows the previous



version that will be replaced.
Software is represented as ‘Year/Month/Day_Version’.



The more recent the date, the newer the software
version. Installing the latest version is recommended.

By USB

■

Insert a USB drive containing the firmware upgrade

downloaded from samsung.com into the TV. Please be
careful to not disconnect the power or remove the USB
drive while upgrades are being applied. The TV will turn
off and turn on automatically after completing the firmware
upgrade. Please check the firmware version after the
upgrades are complete (the new version will have a
higher number than the older version). When software is
upgraded, video and audio settings you have made will
return to their default (factory) settings. We recommend you
write down your settings so that you can easily reset

them after the upgrade.

By Channel

■

Upgrades the software using the broadcasting signal.

If the function is selected during the software



transmission period, this function searches for
available software and downloads the software.

The time required to download the software is



determined by the signal status.

Standby Mode Upgrade

■

To continue software upgrade with master power on,

Select On by pressing the ▲ or ▼ button. 45 minutes after

entering standby mode, a manual upgrade is automatically
conducted. Since the power of the unit is turned on
internally, the screen may be on slightly for the LED
product. This phenomenon may continue for more than 1
hour until the software upgrade is completed.

Alternative Software (Backup)

■

If there is an issue with the new firmware and it is affecting
operation, you can change the software to the previous
version.

If software was changed, existing software is



displayed.
You can change current software to alternative



software by Alternative Software.

This menu presents the connection method that provides
the optimal quality for the HD TV. Refer to this information
when connecting external devices to the TV.

View this information when your TV does not work properly
or when you want to upgrade the software. You can view
the information regarding the call centre, product and
software file download method.

If the signal strength meter

■

indicates that the signal is weak,
physically adjust your antenna
to increase the signal strength.
Continue to adjust the antenna
until you find the best position
with the strongest signal.

TV Rear Panel

or

USB Drive

Current Version 2009/01/17_000001

By USB ▶

By Channel

Standby Mode Upgrade : 45 Min

Alternative Software 2009/01/16_000000

Software Upgrade

U

Move E Enter R Return

Media Play - USB Device

43

English

Connecting a USB Device

Press the POWER button to turn the TV on.

1

Connect a USB device containing photo, music and/or movie files to the

2

USB1(HDD) or USB2 jack on the side of the TV.

When the Application selection screen is displayed, press the ENTERE

3

button to select Media Play (USB & DLNA).

Using the Remote Control Button in Media Play Menu

Button Operations

▲/▼/◄/► Move the cursor and select an item.

Select the currently selected item. While playing a slide show,

ENTER

E

∂/∑

RETURN Return to the previous menu.

TOOLS Run various functions from the Photo, Music and Movie menus.

∫

π/μ

INFO Show file information.

MEDIA.P Exit Media Play mode.

< P >

, EXIT, TV

movie, or music file:

- Pressing the ENTERE button during play pauses the play.

- Pressing the ENTERE button during pause resumes the play.
Play or pause the Slide Show, music or movie.

Stop the current slide show, Music or Movie file.
Jump to previous group/Jump to next group.

Stop Media Play mode and Returns to TV mode.

TV Rear Panel


Device

SUM

or

USB Drive

851.86MB/993.02MB Free

SUM


Music Movie Setup

Media Play - USB Device

e

Exit

MTP (Media Transfer Protocol) is not supported.

■

The file system supports FAT16, FAT32 and NTFS.

■

Certain types of USB Digital camera and audio devices may not be compatible with this TV.

■

Media Play only supports USB Mass Storage Class devices (MSC). MSC is a Mass Storage Class Bulk-Only Transport device.

■

Examples of MSC are Thumb drives, Flash Card Readers and USB HDD (USB HUB are not supported.).
Please connect directly to the USB port of your TV. If you are using a separate cable connection, there may be a USB compatibility

■

problem.
Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not

■

responsible for any data file damage or data loss.
Connect a USB HDD to the dedicated port, USB1 (HDD) port. However, if the connected device requires high power, the USB1 (HDD)

■

may fail to support the device.
Do not disconnect the USB device while it is loading.

■

MSC supports MP3 and JPEG files, while a PTP device supports JPEG files only.

■

The sequential JPEG format is supported.

■

The higher the resolution of the image, the longer it takes to display on the screen.

■

The maximum supported JPEG resolution is 15360X8640 pixels.

■

For unsupported or corrupted files, the ‘Not Supported File Format’ message is displayed.

■

If sort key is set to Basic View, up to 1000 files can be displayed in each folder. The other sort key can display up to 10000 files.

■

MP3 files with DRM that have been downloaded from a non-free site cannot be played. Digital Rights Management (DRM) is a

■

technology that supports the creation of content, the distribution and management of the content in an integrated and comprehensive
way, including the protection of the rights and interests of the content providers, the prevention of the illegal copying of contents, as well
as managing billings and settlements.
When moving to a photo, loading may take a few seconds. At this point, the loading icon will appear at the screen.

■

If more than 2 PTP devices are connected, you can only use one at a time.

■

If more than one MSC device is connected, some of them may not be recognized.

■

If a device requires high power (more than 500mA or 5V), the USB device may not be supported.
If an over-power (Fail add new device USB1/USB2 Power Overload) warning message is displayed while you are connecting or using a

■

USB device, the device may not be recognized or may malfunction.

44

English

Media Play Function

This function enables you to view and listen to photo, music and/or movie files saved on a
USB Mass Storage Class (MSC) device.

It might not work properly with unlicensed multimedia files.

■

Entering the Media Play (USB & DLNA) Menu

Media Play - USB Device

Press the MENU button. Press the ▲ or ▼ button to select Application, then

1

press the ENTERE button.

Press the ▲ or ▼ button to select Media Play (USB & DLNA), then press the

2

ENTERE button.

The Media Play (USB & DLNA) menu is displayed.

■

Press the Red button, then press the ▲ or ▼ button to select the USB Memory.

3

Press the ENTERE button.

This function differs depending on the USB Memory Device / DLNA device.

■

The selected USB device name appears at the bottom left of the screen.

■

Press the ◄ or ► button to select an icon (Photo, Music, Movie, Setup), then

4

press the ENTERE button.

To exit Media Play mode, press the MEDIA.P button on the remote control.

■

Removing a USB Memory Device Safely

You can remove the device safely from the TV.

Press the TOOLS button in the Media Play file list screen, or while a Slide Show,

1

music or movie is being played.

Press the ▲ or ▼ button to select Remove Safely, then press the ENTERE

2

button.

Remove the USB device from the TV.

3

851.86MB/993.02MB Free

SUM



Music Movie Setup

Device

SUM

Press the MEDIA.P button on the

■

remote control to display the Media
Play menu.

Press the SOURCE button on the

■

remote control to view the source

list. Then Press the ▲ or ▼ button

to select USB.

5/15

Timeline

Basic View

Slide Show
Play Current Group
Information
Remove Safely





SUM Device

Colour

Folder

Preference



Favourites Settings Select T Tools R Return

R

Return


Screen Display

Colour

Folder

Preference

1

Basic View

Timeline

2

5/15








3

4 5

SUM Device

Favourites Settings Select T Tools R Return

1File(s) Selected

Move to either ‘Sort key List Section’, ‘Group List Section’ or ‘File List Section’ using the Up

and Down buttons. After selecting a section, press the ◄ or ► buttons to select an item.

Sort key List Section

Group List Section

File List Section

6

45

English

Media Play - USB Device

1 Current Sort key: This field shows the current standard for sorting files.

Press the ◄ or ► button to change the standard for sorting files.

2 View Groups: Shows the detailed groups of the files sorted according the

selected Sort key. The sort group where the currently selected file is contained is
highlighted.

3 Currently selected file: The selected file is the file you can now control.

Photo and movie files are displayed as thumbnail images.

4 Current Device: Shows the currently selected device name.

Press the Red button to select a device.

Red (Device) button: Selects a connected device.

■

5 Help Items

Green (Favourites Settings) button: Changes the Favourites Settings

■

for the selected file. Press this button repeatedly until the desired value
appears.

Yellow (Select) button: Selects file from the file list.

■

Selected files are marked with a symbol c.
Press the Yellow button again to cancel a file selection.

TOOLS (Tools) button: Displays the option menus.

■

(The option menu changes according to the current status.)

6 Item Selection Information: Shows the number of files that are selected by

pressing the Yellow button.

Sorting the Photo List

You can sort photos in the Photo List by a particular standard.

Press the MEDIA.P button.

1

Press the ◄ or ► button to select Photo, then press the ENTERE button.

2

Press the ▲ button to move to the Sort key Section.

3

Press the ◄ or ► button to select a sorting standard. (Basic View, Timeline,

4

Colour, Folder, Preference)

The photos are sorted according to the newly selected sorting standard.

■

Press the ▼ button to move to the File List Section. Press the ∂ (Play)/

5

ENTERE button to start the Slide Show in the order you selected.

To move to the previous/next group, press the π (REW) or μ (FF)

■

button.
Photo information is automatically set. The colour information extracted from

■

a photo file may be different from your expectations. You can change the
colour and preference.

PTP does not support folder sort mode.

■



SUM Device

Colour

Folder

Preference



Favourites Settings Select T Tools R Return

Timeline

Basic View

5/15




Option Description

Basic View

Timeline

Colour

Folder

Preference

Shows the folders on the USB memory device.
If you select a folder and press the ENTERE button, only
the photo files contained in the selected folder are displayed.

When sorted according to the Basic View, you cannot

■

set Favourites files.

It sorts and shows photos by date.
It sorts by year and month from the earliest photo.

Sorts photos by colour. You can change the photo colour
information

You should set the Use Colour View to on in the Setup

■

menu before sorting photos by colour.

It Sorts photos by folder. If there are many folders in USB,
the photos files are shown in order in each folder.
The photo file in the Root folder is shown first and the others
are shown in alphabetical order by name.

It Sorts photos by preference (Favourites).
You can change the photo preferences.

Changing the Favourites Settings.

■

Select the desired photo in the Photo list, then press the
Green button repeatedly until the desired setting appears.

Up to 3 stars can be selected.

■

The stars are for grouping purposes only.

■

For example, the 3 star setting does not have any priority
over the one star setting.

46

English

Media Play - USB Device

Photo List Option Menu

Press the MEDIA.P button.

1

Press the ◄ or ► button to select Photo, then press the ENTERE button.

2

Press the ◄ or ► button to select the desired photo file.

Selecting Multiple Photos

■

3

Press the TOOLS button.

4

Slide Show

Play Current Group

Change Group Info

(When the Sort key is the
Colour)

Deselect All

(When at least one file is
selected)

Information

Remove Safely

Press the ◄ or ► button to select the desired photo file.



Then press the Yellow button.
Repeat the above operation to select multiple photo files.



The mark c appears to the selected photo file.



The option menu changes according to the current status.

■

Option Description

Using this menu, you can play a Slideshow using the
photo files on the USB memory device.

Using this menu, you can play a Slideshow using only the
photo files in the currently selected sorting group.

You can change a selected photo file’s (or group of files)
colour information in order to move it from one colour
group to another.

This does not change the actual colour of the photo.

■

The group information of the current file is updated and

■

the photos are moved to the new colour group.
To change the information of multiple files, select the

■

files you want by pressing the Yellow button.

You can deselect all files.

The c mark indicating the corresponding file is

■

selected is hidden.

The photo file information including the name, the
size, the resolution, the date modified and the path is
displayed.

You can view the information of photo files during a

■

Slideshow using the same procedures.

You can remove the device safely from the TV.

5/15

Preference

Folder

Slide Show
Play Current Group
Change Group Info
Information


Basic View

Timeline

Colour





SUM Device

Press the INFO button to viewing

■

Favourites Settings Select T Tools R Return

the information.


▼


47

English

Media Play - USB Device

Viewing a Photo or Slide Show

Viewing a Slide Show

 Pressthe▼buttontoselecttheFileListSection.   

1

Press the TOOLSbutton.     

2

 Pressthe▲or▼buttontoselectSlide Show, then press the ENTERE

3

button.

All files intheFileListSectionwillbeusedfortheSlideShow.

■
Duringtheslideshow,filesaredisplayedinorderfromthecurrentlyshown

■
file.

TheSlideShowprogressesintheordersortedintheFileListSection.

■
MusicfilescanbeautomaticallyplayedduringtheSlideShowifthe

■
Background MusicissettoOn.

Whileaphotolistisdisplayed,pressthe

■
theremotecontroltostartslideshow.

Slideshow Control Buttons

Button Operations

ENTER

∂
∑
∫

π/μ

TOOLS RunvariousfunctionsfromthePhotomenus.

Play/PausetheSlideShow.

E

PlaytheSlideShow.
PausetheSlideShow.
ExitSlideShowandreturntothephotolist.
ChangetheSlideshowplayingspeed.

Playing Current Group

 Pressthe▲buttontomovetotheSortkeySection.   

1

 Pressthe◄or►buttontoselectasortingstandard.   

2

 Pressthe▼buttontomovetotheGroupListSection.   

3

 Selectagroupusingthe◄and►buttons.    

4

Press the ∂(Play)button.Aslideshowbeginswiththefilesoftheselected

5

group.

∂

(Play)/ENTEREbuttonon



SUM Device

SUM



SUM Device

Colour


▶ Normal

Colour


Folder


E

Pause ◀▶ Previous / Next

Folder

Basic View

Preference

5/15

Slide Show
Play Current Group
Information
Remove Safely



Favourites Settings Select T Tools R Return

580x765 2009/12/02 5/15

T

Timeline

Basic View

Preference

5/15



Favourites Settings Select T Tools R Return

Timeline



Tools R Return



Alternatively

 SelectaSortkeyandthenintheFileListSection,selectthephotoscontainedin

1

thedesiredgroup.

Tomovetotheprevious/nextgroup,pressthe

■

Press the TOOLSbutton.     

π(REW)orμ(FF)button.

2

 Pressthe▲or▼buttontoselectPlay Current group, then press the

3

ENTEREbutton.

Onlythephotosinthesortinggroupincludingtheselectedfileswillbeused

■
fortheSlideShow.

To perform a Slide Show with only the selected Files

 Pressthe▼buttontoselecttheFileListSection.   

1

 Pressthe◄or►buttontoselectthedesiredphotointheFileListSectiont. 

2

 PresstheYellowbutton.     

3

 Repeattheaboveoperationtoselectmultiplephotos.

The

c

■

4

■

■

Press the ∂(Play)/ENTEREbutton.

■

5

markappearstotheleftoftheselectedphoto.
Ifyouselectonefile,theSlideShowwillnotbeperformed.
Todeselectallselectedfiles,pressthe

All.

TheselectedfileswillbeusedfortheSlideShow.

TOOLSbuttonandselectDeselect

48

English

Media Play - USB Device

Alternatively

In the File List Section, press the Yellow buttons to select the desired photos.

1

Press the TOOLS button.

2

Press the ▲ or ▼ button to select Slide Show, then press the ENTERE

3

button.

The selected files will be used for the Slide Show.

■

Slide Show Option Menu

During a slide show (or when viewing a photo), press the TOOLS button to set

1

the option.

Press the ▲ or ▼ button to select the desired option, then press the ENTERE

2

button.

Option Description

Stop Slide Show /
Start Slide Show

Slide Show Speed

Slide Show Effect

Rotate

Zoom

Background Music

Picture Setting /
Sound Setting

Information
Remove Safely

You can start or stop a Slideshow.

You can select the slide show speed.

This function is available only during a slide show.

■

You can also change the speed of the Slide Show by

■

pressing the π (REW) or μ (FF) button during the
Slide Show.

You can select the screen transition effect used in the
slideshow.

None / Fade1 / Fade2 / Blind / Spiral / Checker /

■

Linear / Stairs / Wipe / Random
This function is available only during a slide show.

You can rotate photos saved on a USB memory device.

Whenever you press the ◄ button, it rotates by 270˚,

■
180˚, 90˚, and 0˚.

Whenever you press the ► button, it rotates by 90˚,

■
180˚, 270˚, and 0˚.

The rotated file is not saved.

■

You can magnify photos saved on a USB memory device.

(x1 → x2 → x4)

To move the enlarged photo image, press the

■

ENTERE button, then press the ▲/▼/◄/► buttons.

Note that when the enlarged picture is smaller than
the original screen size, the location change function
doesn’t work.

The enlarged file is not saved.

■

You can select background music when watching a Slide
Show.

Background Music

■

Off: Background music is not played.



On: When the background music is available, if



you select On, the music is played back.

BGM Mode

■

You can select a mode to use for the background music.

BGM Mood

■

Music with the mood you selected is set as the
background music.

If you set BGM Mode to Mood, you can select a mood.

Select Music File (0 File(s) Selected)

■

Only the selected music file is set as the background
music.

If you set BGM Mode to Selected File, you can select a
music file.

You can select the picture and sound settings.

The photo file information is displayed.

You can remove the device safely from the TV.

Tools

Stop Slide Show

Slide Show Speed : Normal

Slide Show Effect : Fade1

Rotate

Zoom

Background Music

Picture Setting

Sound Setting

Information

▼

U

Move E Enter e Exit

To use this feature, there must be

■

music and photo files stored on
the USB device.

Loading music files is needed to

■

change BGM mode. Play music
files in music category to load.

49

English

Media Play - USB Device

Sorting the Music List

You can sort music files in the Music List by a particular standard.

Press the MEDIA.P button.

1

Press the ◄ or ► button to select Music, then press the ENTERE button.

2

Press the ▲ button to move to the Sort key Section.

3

Press the ◄ or ► button to select a sorting standard. (Basic View, Title, Artist,

4

Mood, Genre, Folder, Preference)

The Music files are sorted according to the newly selected sorting standard.

■

Press the ▼ button to move to the File List Section. Press the ENTERE button

5

to start playing music in the order selected by the user.

To move to the previous/next group, press the π (REW) or μ (FF)

■

button.
Music information is automatically set. The mood information extracted from

■

a music file may differ from the expectations of the user. You can change the
mood and preference.

Option Description

Basic View

Title

Artist

Mood

Genre
Folder

Preference

Shows the folders of the USB memory device.
If you select a folder and press the ENTERE button,
only the music files contained in the selected folder are
displayed.

When sorted according to the Basic View, you cannot

■

set Favourites files.

Sorts the music titles in symbol/number/alphabet/special
order, and shows the music file.

Sorts the music file by artist in symbol/number/alphabet/
special order.

Sorts music files by the mood. You can change the music
mood information.

Sorts music files by the genre.

Sorts music files by the folder. If there are many folders in
USB, the files are shown in order in each folder.
The music file in the Root folder is shown first and the
others are shown in alphabetical order by name.

Sorts music files by preference (Favourites).
You can change the music files preferences.

Changing the Favourites Setting

■

Select the desired music file in the Music list, then
press the Green button repeatedly until the desired
setting appears.

Up to 3 stars can be selected.

■

The stars are for grouping purposes only.

■

For example, the 3 star setting does not have any
priority over the one star setting.

Genre

Folder

Preference

Glen Hans
Once Ost
2007

Lies

Want Me

SUM Device

If there is no title information

■

Soundtrack

Way

I Love You

Favourites Settings Select T Tools R Return

Title

Basic View

3/37Energetic

Gold

HaHaHa

for a music file, the filename is
displayed.

If no information is available for the

■

Artist, Album, Year, or Genre the
corresponding item is displayed
as blank.

Shine

Music List Option Menu

Press the MEDIA.P button.

1

Press the ◄ or ► button to select Music, then press the ENTERE button.

2

Press the ◄ or ► button to select the desired Music file.

Selecting Multiple Music Files

■

3

Press the TOOLS button.

4

Press the ◄ or ► button to select the desired music file. Then press the



Yellow button.



Repeat the above operation to select multiple music files.



The mark c appears to the selected music file.

The option menu changes according to the current status.

■

Genre

Lies

Want Me

SUM Device

Folder

Way

Basic View

Preference

3/37Energetic

Glen Hans
Once Ost
2007
Soundtrack

I Love You

Favourites Settings Select T Tools R Return

Title

Play Current Group
Information
Remove Safely

Gold

HaHaHa

Shine

50

English

Media Play - USB Device

Option Description

Play Current Group

Change Group Info

(When the Sort key is
Mood)

Deselect All

(When at least one file is
selected)

Information

Remove Safely

Using this menu, you can only play music files in the
currently selected sorting group.

You can change the mood information of music files.
The group information of the current file is updated and

the file is moved to the new group.

To change the information of multiple files, select files

■

by pressing the Yellow button.

You can deselect all files.

The c mark indicating the corresponding file is

■

selected is hidden.

The music file information including the name, the size,
the date modified and the path is displayed.

You can view the music file information during a Play

■

Current Group using the same procedures.

You can remove the device safely from the TV.

Playing a Music

Playing a Music File

Press the ▼ button to select the File List Section.

1

Press the ◄ or ► button to select a music file to be played.

2

Press the ∂ (Play)/ENTERE button.

This menu only shows files with the MP3 file extension. Files with other

■

3

file extensions are not displayed, even if they are saved on the same USB
device.

The selected file is displayed at the top with its playing time.

■

To adjust the music volume, press the volume button on the remote control.

■

To mute the sound, press the MUTE button on the remote control.
If the sound is odd when playing MP3 files, adjust the Equalizer and SRS

■

TruSurround HD in the Sound menu. (An over-modulated MP3 file may
cause a sound problem.)

The playing duration of a music file may be displayed as ‘00:00:00’ if its

■

playing time information is not found at the start of the file.

π

(REW) or μ (FF) buttons do not function during play.

■

Press the INFO button to viewing

■

the information.

▶ 00:00:04 / 00:04:04 3/37

I Love You

E

SUM

Pause ◀▶ Previous / Next

T

HaHaHaWay

Tools R Return

Music Play Control Buttons

Button Operations

ENTER

E

∂
∑
∫

TOOLS Run various functions from the Music menus.

Play/Pause the music file.
Play the music file
Pause the music file
Exit play mode and return to the music list.

Music Function Information Icon

p

q

When all music files in the folder (or the selected file) are
repeated. Repeat Mode is On.
When all music files in the folder (or the selected file) are played
once. Repeat Mode is Off.

51

English

Media Play - USB Device

Playing the Music Group

Press the ▲ button to move to the Sort key Section.

1

Press the ◄ or ► button to select a sorting standard.

2

Press the ▼ or ENTERE button to move to the Group List Section.

3

Press the ∂ (Play) button. The files of the selected group will start playing.

4

Alternatively

Select a sort key and then in the File List Section, select the files contained in

1

the desired group.

To move to the previous/next group, press the π (REW) or μ (FF)

■

button.

Press the TOOLS button.

2

Press the ▲ or ▼ button to select Play Current Group, then press the

3

ENTERE button.

The music files in the sorting group including the selected file are played.

■

Playing the selected Music Files

Press the ▼ button to select the File List Section.

1

Press the ◄ or ► button to select the desired music file.

2

Press the Yellow button.

3

Repeat the above operation to select multiple music files.

The c appears to the left of the selected music file.

■

4

5

To deselect all selected files, press the TOOLS button and select Deselect

■

All.

Press the ∂ (Play)/ENTERE button.

The selected files will be played.

■

Option Description

Repeat Mode
Picture Setting /

Sound Setting
Information
Remove Safely

Music Play Option Menu

You can play music files repeatedly.

You can configure the picture and sound settings.

The music file information is displayed.

You can remove the device safely from the TV.

Tools

Repeat Mode ◀ On ▶

Picture Setting

Sound Setting

Information

Remove Safely

U

Move L Adjust e Exit

52

English

Media Play - USB Device

Sorting the Movie List

You can sort movies in the Movie List by a particular standard.

Press the MEDIA.P button.

1

Press the ◄ or ► button to select Movie, then press the ENTERE button.

2

Press the ▲ button to move to the Sort key Section.

3

Press the ◄ or ► button to select a sorting standard. (Basic View, Timeline,

4

Title, Folder, Preference)

The movie files are sorted according to the newly selected sorting standard.

■

Press the ∂ (Play)/ENTERE button to play the movie in the order selected.

Movie information is automatically set. You can change the preference.

■

5

Option Description

Basic View

Timeline

Title

Folder

Preference

Shows the folders of the USB memory device.
If you select a folder and press the ENTERE button,
only the movie files contained in the selected folder are
displayed.

When sorted according to the Basic View, you cannot

■

set Favourites files.

Sorts movies by date. It sorts by year and month from the
earliest movie.

Sorts and displays the movie titles in symbol/number/
alphabet/special order.

If there are many folders in USB, the movies files are
shown in order in each folder. The movie file in the
Root folder is shown first and the others are shown in
alphabetical order by name.

Sorts movies by preference. (Favourites)
You can change the movie preferences.

Changing the Favourites Setting

■

Select the desired movie file in the movie list, then
press the Green button repeatedly until the desired
setting appears.
Up to 3 stars can be selected.

■

The stars are for grouping purposes only.

■

For example, the 3 star setting does not have any
priority over the one star setting.

1231.avi

1232.avi

SUM Device

Title

Folder

Preference

1233.avi

ABCD.avi

Favourites Settings Select T Tools R Return

Timeline

Basic View

5/15

1237.avi

1236.avi

1235.avi

Movie List Option Menu

Press the MEDIA.P button.

1

Press the ◄ or ► button to select Movie, then press the ENTERE button.

2

Press the ◄ or ► button to select the desired Movie file.

Selecting Multiple Movie Files

■

3

Press the TOOLS button.

4

Press the ◄ or ► button to select the desired movie file.



Then press the Yellow button.



Repeat the above operation to select multiple movie files.
The mark c appears to the selected movie file.



The option menu changes according to the current status.

■

1231.avi

1232.avi

SUM Device

Title

Folder

Preference

1233.avi

ABCD.avi

Favourites Settings Select T Tools R Return

5/15

Timeline

Basic View

Play Current Group
Information
Remove Safely

1235.avi

1236.avi

1237.avi

53

English

Media Play - USB Device

Option Description

Play Current Group

Deselect All

(When at least one file is
selected)

Information

Remove Safely

Using this menu, you can only play movie files in the
currently selected sorting group.

You can deselect all files.

The c mark indicating the corresponding file is

■

selected is hidden.

The movie file information including the name, the size,
the date modified and the path is displayed.

You can remove the device safely from the TV.

Playing a Movie File

Playing a movie file

Press the ▼ button to select the File List Section.

1

Pressing the ◄ or ► button to select a movie file to be played.

2

Press the ∂ (Play)/ENTERE button.

The selected file is played.

■

3

The selected file is displayed at the top with its playing time.

■

The playing duration of a movie file may be displayed as ‘00:00:00’ if its

■

playing time information is not found at the start of the file.
You can watch exciting gaming multimedia files, but the gaming function is

■

not supported.
Movie doesn’t support subtitles. (for example, not support smi, srt and sub

■

files, etc and not support subtitles included in movie files)

Press the INFO button to viewing

■

the information.

▶ 00:00:01 / 00:05:30 3/37

ABC.avi

E

Pause ◀ ▶ Jump

SUM

T

Tools R Return

Supported Subtitle Formats

Name File extension Format

MPEG-4 time-based text .ttxt XML

SAMI .smi HTML

SubRip .srt string-based
SubViewer .sub string-based
Micro DVD .sub or .txt string-based

Supported Video Formats

File Extension Container Video Decoder Audio codec

*.avi AVI

*.mkv MKV

Divx 3.11
Divx 4.x
Divx 5.1
Divx 6.0

XviD
H.264 BP

H.264 MP
H.264 HP
MPEG-4 SP
MPEG-4 ASP
Motion JPEG

Divx 3.11

Divx 4.x
Divx 5.1
Divx 6.0

H.264 BP
H.264 MP
H.264 HP

MPEG-4 SP

MPEG-4 ASP

Motion JPEG

XviD

MP3, AC3, LPCM, ADPCM

(MULAW ALAW)

MP3, AC3, LPCM, ADPCM

(MULAW ALAW), AAC

54

English

Media Play - USB Device

File Extension Container Video Decoder Audio codec

*.asf

*.wmv (VC1) Window Media Video v9

*.mp4

*.3gp 3GPP

*.vro (ps)

*.mpg

*.mpeg (ps)

others (ts)

ASF

MP4

(SMP4)

VRO /

VOB

MPEG1 (Programme Stream)
MPEG2 (Programme Stream)

Divx 3.11

Divx 4.x
Divx 5.1
Divx 6.0

XviD
H.264 BP
H.264 MP
H.264 HP

MPEG-4 SP

MPEG-4 ASP

H.264 BP
H.264 MP
H.264 HP

MPEG-4 SP

MPEG-4 ASP

XVID
H.264 BP
H.264 MP
H.264 HP

MPEG-4 SP

MPEG-4 ASP

MPEG2
MPEG1

MPEG2 (Transport Stream)

H.264 (Transport Stream)

VC1 (Transport Stream)

WMA, MP3, AC3, LPCM,

ADPCM, (MULAW ALAW),

AAC

ADPCM, (HE)-AAC, mp3

ADPCM, (HE)-AAC

AC3, MPEG, LPCM

AC3, MPEG, LPCM

AAC, HE-AAC, MP3, DD+

Video Play Control Buttons

Button Operations

ENTER

∂
∑

TOOLS Run various functions from the Movie menus.

∫

◄ / ► Skip forwards or backwards through the movie file.
▲ / ▼ Move to the first/last of the file.

μ

Play/Pause the movie file

E

Play the movie file
Pause the movie file

Exit play mode and return to the movie list.

Play the file at double speed. This function may not be supported
depending on the codec.

Playing the movie group

Press the ▲ button to move to the Sort key Section.

1

Press the ◄ or ► button to select a sorting standard.

2

Press the ▼ or ENTERE button to move to the Group List Section.

3

Press the ∂ (Play) button. Only the files of the selected group will start playing.

4

55

English

Media Play - USB Device

Alternatively

Select a Sort key and then in the File List Section, select the files contained in

1

the desired group.

To move to the previous/next group, press the π (REW) or μ (FF)

■

button.

Press the TOOLS button.

2

Press the ▲ or ▼ button to select Play Current Group, then press the

3

ENTERE button.

The movie files in the sorting group including the selected file are played.

■

Playing the selected Movie Files

Press the ▼ button to select the File List Section.

1

Press the ◄ or ► button to select the desired music file.

2

Press the Yellow button.

The c mark appears to the left of the selected movie file.

■

3

To deselect all selected files, press the TOOLS button and select Deselect

■

All.

Repeat the above operation to select multiple movie files.

4

Press the ∂ (Play)/ENTERE button.

Only the selected file is played.

■

5

Playing Movie continuously (Resume Play)

If you exit the playing movie function, the movie can be played later from the point where it
was stopped.

Select the movie file you want to play continuously by pressing the ◄ or ►

1

button to select it from the File List Section.

Press the ∂ (Play)/ENTERE button.

2

Select Play Continuously (Resume Play) by pressing the Blue button.

The Movie will begin to play from where it was stopped.

■

3

If Cont. Movie Play Help function is set On in the Setup menu, a pop-up

■

message will appear when you resume play a movie file.

M

Option Description

Picture Setting /
Sound Setting

Picture Size

M

ovie Play Option Menu

You can configure the picture and sound settings.

Fit

■

Play video at the TV screen size.

Original

■

Play video at the original size.

Tools

Picture Setting

Sound Setting

Picture Size : Fit

Caption Setting

Information

Remove Safely

U

Move E Enter e Exit

56

English

Media Play - USB Device

Option Description

Caption Setting

Information
Remove Safely

You can set the captions for the movie.

Caption

■

You can turn the captions for the movie on or off.

Caption Language

■

You can set the caption language.

Caption Size

■

You can change the font size of the captions.

Caption Sync

■

You can adjust the caption sync.

Caption Sync Reset

■

You can reset the adjusted caption sync.
The movie file information is displayed.

You can remove the device safely from the TV.

Using the Setup Menu

Setup displays the user settings of the Media Play menu.

Press the MEDIA.P button.

1

Press the ◄ or ► button to select Setup, then press the ENTERE button.

2

Press the ▲ or ▼ button to select the desired option.

3

Press the ◄ or ► button to select the option, then press the ENTERE button.

To exit Media Play mode, press the MEDIA.P button on the remote control.

■

4


SUM Device

851.86MB/993.02MB Free

SUM

SETUP

Music Movie Setup

e

Exit

Option Description

Use Colour View

Music Repeat Mode
Cont. movie play help

Get the DivX® VOD
registration code

Get the DivX® VOD
deactivation code

Screen Saver Run Time

Information
Remove Safely

You can select sorting photos by colour. If this option is
set to On, the loading time may be increased to collect
colour information from the photos.

Select to repeatedly play music files.

Select to display the help pop-up message for continuous
movie playback.

Shows the registration code authorized for the TV. If you
connect to the DivX web site and register the registration
code with a personal account, you can download VOD

registration file.
If you play the VOD registration using Media Play, the

registration is completed.

For more information on DivX® VOD, visit www.DivX.

■

com.

When DivX® VOD is not registered, the registration
deactivation code is displayed.

If you execute this function when DivX® VOD is
registered, the current DivX® VOD registration is
deactivated.

Select to set the waiting time before the screen saver
appears.

Select to viewing the information of the connected device.

You can remove the device safely from the TV.

Use Colour View ◀ Off ▶

Music Repeat Mode On

Cont. movie play help On

Get the DivX® VOD registration code

Get the DivX® VOD deactivation code

Screen Saver Run Time 4 hours

Information

Remove Safely

If this is set to ON, the loading time increases for collecting the colour

information.

SUM Device

U

Move L Adjust R Return

Media Play-DLNA

Setting the DLNA Network

57

English

DLNA allows you to watch pictures, musics and videos saved on your PC or on your TV through a network connection in Media
Play mode. This removes the need to copy them to a USB storage device and then connect the device to your TV.

To use DLNA, the TV must be connected to the network and the DLNA application must be installed on your PC.

Network Connection Diagram

Network Connection Diagram-Cable

LAN

Network Connection Diagram-Wireless

TV Rear Panel

TV

External Modem

(ADSL/VDSL/Cable TV)

TV

PC

LAN

PC

Media Play-DLNA

LAN

Samsung Wireless

LAN Adapter

Wireless IP sharer

LAN Cable

For more information on how to configure your network, refer to page 37.

You are recommended to locate both TV and PC in same subnet. The first 3 parts of the subnet address of the TV and

■

1

2

the PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address:

123.456.789.**)

Connect the PC to which the Samsung PC Share Manager programme will be installed and the external modem using a

LAN cable.

You can connect the TV to the PC directly without connecting it through a Sharer (Router).

■

58

English

Installing the DLNA Application

To play content on the PC on the TV, you have to first install the application. To use the DLNA function smoothly, use the
programme in the CD-ROM supplied with the TV or use the Samsung PC Share Manager programme corresponding to the TV
model that can be downloaded from the Samsung web site.

Media Play-DLNA

Insert the Programme CD supplied with this TV into your PC.

System Requirements

1

30MB of free hard disk space is needed for the programme installation.

If you share files, up to 30MB of hard disk drive space is required for each 100 files.

■

2

Image: JPEG/ Audio: MP3/ Video: AVI, MKV, ASF, MP4, 3GPP, PS, TS container.
For detailed supported video formats, refer to page 53.

If you cancel file sharing, the hard disk drive space used for the thumbnail information is also freed.

■

Supported Formats

Install the Application

Run the Setup.exe file on the Programme CD supplied with the product.

Alternatively, you can download the file from www.samsung.com.

■

1

Install the SAMSUNG PC Share Manager as shown in the figures.

2

When the installation is complete, the PC Share Manager icon appears on your Desktop.

Double-click the icon to run the programme.

■

3

59

English

Media Play-DLNA

Using the DLNA Application

The Programme Screen Layout

1

3 4 5

2

Option Description

File

6 7

Property

■

Shows information on the selected file or folder.

Method 1: Select a file or folder and select the File menu and then select the Property



sub-menu.
Method 2: Select a file or folder, right-click over the selected file or folder and then select



Property from the pop-up menu.

<Method 1>

Menus: The following application menus

1

are provided : File, Share, Server, and
Help.

Click to share the selected PC server

2

folder.

Click to cancel sharing.

3

Click to refresh the PC folder and files.

4

Click to synchronize the share status.

5

The folders and files of the PC to be

6

shared are listed.

Folders shared by the user are listed.

7

<Method 2>

Exit

■

Exits the DLNA application.
If you select Exit without applying the changes after changing the shared status, a message will appear

asking if you want to apply the changed settings to the PC. Select Yes to apply the changes and exit the
application.

60

English

Media Play-DLNA

Option Description

Sharing a Folder

Share

■

You can share a folder from your PC to the TV. The maximum number of folders that can be shared is 32.
Your PC will operate as a server to the TV.

Method 1: Select a folder in My Computer, select the Share menu and then select the Share



Folder sub-menu.
Method 2: Select a folder in My Computer, right-click over the selected folder and then select



Share Folder from the popup menu.
Method 3: Locate the mouse pointer over a folder in the My Computer folder list in the left pane



and drag & drop the folder into the Shared Folders pane. If a message appears asking you to
confirm the shared folder, select Yes.

<Method 1> <Method 2> <Method 3>

Cancelling a Shared Folder

■

You can cancel a shared folder on your PC. Select a folder from the Shared Folder pane and select
Unshare Folder.

Method 1: Select a folder from the Shared Folder pane, select the Share menu and then select



Unshare Folder.
Method 2: Select a folder from the Shared Folder pane, right-click over the selected folder and



then select Unshare Folder from the pop-up menu.
Method 3: Locate the mouse pointer over a folder in the Shared Folder pane and drag&drop



the folder into the My Computer pane. If a message appears asking you to confirm the
cancelation, select Yes.

<Method 1> <Method 2> <Method 3>

Applying the Current Settings

■

Perform this when synchronization is necessary due to a new shared folder or cancelling a shared folder.
The Set Changed State menu applies changes to shared folders to the data saved with the PC share
programme.

Since applying changes to the internal data is a time-consuming process, this function enables users to
apply changes to the data only when required.

Until the Set Changed State menu is selected, the changed state of the shared folder is not applied to the
server.

Changes to the shared folders are not applied to your PC until you select the Set Changed State menu.

Method 1: Select the Share menu and select the Refresh DB sub-menu.



Method 2: Click the Set Changed State icon.



<Method 1> <Method 2>

61

English

Media Play-DLNA

Option Description

Setting the Access Permission

Share

Server

Help

■

To enable the TV to find your PC, the TV must be set to Set Device Policy in the Access Permission
Settings window. In addition, the PC server and the TV must be on the same subnet.

Method: Select the Share menu and select Set Device Policy. Rejected items are represented



in gray. You can change the access permissions by using the Allow Accept / Deny button.
To delete an item, select the item and select Delete Item.

Server

■

You can run or stop using your PC as a server.

Run DLNA Digital Media Server when Windows Starts

■

You can determine whether to start the PC server automatically when Windows starts.

Change server name

■

You can rename the PC server. Enter a new name and click OK. The new name will appear at the top right
of the window and will appear on the TV.

Version

■

The programme version information message box appears.

Using the DLNA Function

Using the DLNA Menu

DLNA (Digital Living Network Alliance) enables content saved on a DLNA server (usually your PC) connected to your TV or over a
network to be played. Media Play enables playing content saved on a USB memory device connected to the TV, while DLNA enables
playing content saved on a DLNA server (your PC) connected to your TV or over the network. The procedures to use the content are
the same as those for Media Play (USB & DLNA).

If you install the PC share manager programme supplied with the TV onto a PC, you can have the PC perform the role of a DLNA

■

server over the network.
For the detailed procedures on using the DLNA menu, refer to pages 43~56.

■

Press the MEDIA.P button on the remote control to display the DLNA menu.

1

Press the ◄ or ► button to select an icon (Photo, Music, Movie, Setup), then press the ENTERE button.

To exit DLNA mode, press the MEDIA.P button on the remote control.

■

2

DLNA does not support the following functions.

■

The Background Music and Background Music Setting functions.



Sorting files by preference in the Photo, Music, and Movie folders.



The Change Group Info function.



The Copy / Delete function.



The Remove Safely function.



The REW/FF (π/μ) key functions while a movie is playing.



Function to watch continuously when playing movie.



Playing Movie Continuously (Resume Play) function.



The Skip function may not work with some container such as asf and mkv.

■

The Divx DRM, Multi-audio, embedded caption does not supported.

■

Samsung PC Share manager should be permitted by the firewall programme on your PC.

■
The Skip (◄/► keys) or Pause function may not work while a movie is playing for the DLNA of other manufacturers,

■

depending on the corresponding content information.
The playing time may not be displayed while a movie is playing.

■

62

English

Anynet+

Anynet

+

Connecting Anynet+ Devices

What is Anynet+?

Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote.
The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this

feature, check if there is an Anynet+ logo on it.

To connect to a TV

TV

Anynet+ Device 1

Anynet+ Device 2 Anynet+ Device 3 Anynet+ Device 4

HDMI 1.3 Cable

Connect the HDMI IN (1(DVI), 2, 3 or 4) jack on the TV and the HDMI OUT jack of the corresponding Anynet+ device using an HDMI
cable.

HDMI 1.3 CableHDMI 1.3 Cable

HDMI 1.3 Cable

To connect to Home Theatre

TV

Optical Cable

HDMI 1.3 Cable

Connect the HDMI IN (1(DVI), 2, 3 or 4) jack on the TV and the HDMI OUT jack of the corresponding Anynet+ device using

1

an HDMI cable.

Connect the HDMI IN jack of the home theatre and the HDMI OUT jack of the corresponding Anynet+ device using an HDMI

2

cable.

Connect the Optical cable between the DIGITAL AUDIO OUT (OPTICAL) jack on your TV and the Digital Audio Input on

■

the Home Theatre.
When following the connection above, the Optical jack only outputs 2 channel audio. You will only hear sound from the

■

Home Theatre’s Front Left and Right speakers and the subwoofer. If you want to hear 5.1 channel audio, connect the
DIGITAL AUDIO OUT (OPTICAL) jack on the DVD player or Cable / Satellite Box (ie Anynet Device 1 or 2) directly to
the Amplifier or Home Theatre, not the TV.
Connect only one Home Theatre.

■

You can connect an Anynet+ device using the HDMI 1.3 cable. Some HDMI cables may not support Anynet+ functions.

■

Anynet+ works when the AV device supporting Anynet+ is in the Standby or On status.

■

Anynet+ supports up to 12 AV devices in total. Note that you can connect up to 3 devices of the same type.

■

Anynet+ Device 2 Anynet+ Device 3 Anynet+ Device 4

Home Theatre

HDMI 1.3 CableHDMI 1.3 Cable

HDMI 1.3 Cable

HDMI 1.3 Cable

Anynet+ Device 1

63

English

Anynet+

Setting Up Anynet

+

Option Description

Anynet+ (HDMI-CEC)

Setup

■

To use the Anynet+ Function, Anynet+ (HDMI-CEC) must
be set to On.

When the Anynet+ (HDMI-CEC) function is disabled, all
the Anynet+ related operations are deactivated.

Auto Turn Off

■

Setting an Anynet+ Device to turn Off automatically when
the TV is turned Off.

The active source on the TV remote must be set



to TV to use the Anynet+ function.
If you set Auto Turn Off to Yes, connected



external devices are also turned off when the
TV is turned off. If an external device is still
recording, it may or may not turn off.

Switching between Anynet+

Media Play (USB & DLNA)

Application

Anynet

Auto Turn Off : Yes

Anynet

Auto Turn Off : Yes ▶

Press the TOOLS button to

■

display the Tools menu. You
can also display Anynet+ menu
by selecting Tools → Anynet+
(HDMI-CEC).

+

(HDMI-CEC)

Anynet

Content Library
Internet@TV
Home Network Centre

Setup

+

(HDMI-CEC) : On ▶

U

Move E Enter R Return

Setup

+

(HDMI-CEC) : On

U

Move E Enter R Return

Devices

Press the TOOLS button. Press the ENTERE button to select Anynet+ (HDMI-

1

CEC).

Press the ▲ or ▼ button to select Device List, then press the ENTERE button.

Anynet+ devices connected to the TV are listed. If you cannot find a device

■

2
3

you want, press the red button to scan for devices.

Press the ▲ or ▼ button to select to a particular device and press the ENTERE

button. It is switched to the selected device.

Only when you set Anynet+ (HDMI-CEC) to On in the Application menu, the

■

Device List menu appears.
Switching to the selected devices may take up to 2 minutes. You cannot

■

cancel the operation during the switching operation.
The time required to scan for devices is determined by the number of

■

connected devices.
When the device scan is complete, the number of devices found are not

■

displayed.
Although the TV automatically searches the device list when the TV is turned

■

on via the power button, devices connected to the TV may not always be
automatically displayed in the device list. Press the Red button to search for
the connected device.
If you have selected external input mode by pressing the SOURCE button,

■

you cannot use the Anynet+ function. Make sure to switch to an Anynet+
device by using the Device List.

View TV

Device List

Recording: DVDR
DVDR MENU
DVDR INFO
Receiver: Off
Setup

U

Move E Enter R Return

64

English

Anynet+

Anynet+ Menu

The Anynet+ menu changes depending on the type and status of the Anynet+ devices
connected to the TV.

Option Description

View TV Anynet+ mode changes to TV broadcast mode.

Device List Shows the Anynet+ device list.

(device_name) MENU Shows the connected device menus.

E.g. If a DVD recorder is connected, the disc menu of the
DVD recorder will appear.

(device_name) INFO Shows the play menu of the connected device.

E.g. If a DVD recorder is connected, the play menu of the
DVD recorder will appear.

Recording: (*recorder) Starts recording immediately using the recorder.

(This is only available for devices that support the
recording function.)

Stop Recording: (*recorder) Stops recording.

Receiver Sound is played through the receiver.

TV Remote Control Buttons Available in Anynet+ Mode

Device Type Operating Status Available Buttons

If more than one recording

■

device is connected, they are
displayed as (*recorder) and
if only one recording device is
connected, it will be represented
as (*device_name).

After switching to the device,
when the menu of the
corresponding device is displayed
on the screen.

Anynet+ Device

After switching to the device,
while playing a file

Device with built-in
Tuner

Audio Device When Receiver is activated

The Anynet+ function only works when the active source on the TV remote control is set

■

to TV.
The ∏ button works only while in the recordable state.

■

You cannot control Anynet+ devices using the buttons on the TV.

■

You can control Anynet+ devices only using the TV remote control.
The TV remote control may not work under certain conditions.

■

If this occurs, reselect the Anynet+ device.
The Anynet+ functions do not operate with other manufacturers’ products.

■

The π, μ operations may differ depending on the device.

■

After switching to the device,
when you are watching a TV
programme

Numeric buttons

▲/▼/◄/►

ENTERE buttons

Colour buttons
EXIT button

π

(Backward search)

μ

(Forward search)

∫

(Stop) / ∂(Play)

∑

(Pause)

P > / P < button

Y

/ MUTE button

65

English

Anynet+

Recording

You can make a recording of a TV programme using a Samsung recorder.

Press the TOOLS button. Press the ENTERE button to select Anynet+ (HDMI-

1

CEC).

Press the ▲ or ▼ button to select Recording Immediately and press the

2

ENTERE button. Recording begins.

When there is more than one recording device.

■

When multiple recording devices are connected, the recording devices are

listed. Press the ▲ or ▼ button to select a recording device and press the

ENTERE button. Recording begins.
When the recording device is not displayed select Device List and press the

■

Red button to search devices

Press the EXIT button to exit.

You can record the source streams by selecting Recording: (device_name).

■

3

Pressing the ∏ button will record whatever you are currently watching. If you

■

are watching video from another device, the video from the device is recorded.
Before recording, check whether the antenna jack is properly connected to the

■

recording device. To properly connect an antenna to a recording device, refer
to the recording device’s users manual.

Listening through a Receiver
(Home Theatre)

You can listen to sound through a receiver instead of the TV speaker.

Press the TOOLS button. Press the ENTERE button to select Anynet+ (HDMI-

1

CEC).

Press the ▲ or ▼ button to select Receiver. Press the ◄ or ► button to select

2

On or Off.

Press the EXIT button to exit.

If your receiver supports audio only, it may not appear in the device list.

■

3

The receiver will work when you have properly connected the optical in jack of

■

the receiver to the DIGITAL AUDIO OUT (OPTICAL) jack of the TV.
When the receiver (home theatre) is set to On, you can hear sound output

■

from the TV’s Optical jack. When the TV is displaying a DTV(air) signal, the
TV will send out 5.1 channel sound to the Home theatre receiver. When the
source is a digital component such as a DVD and is connected to the TV via
HDMI, only 2 channel sound will be heard from the Home Theatre receiver.
If there is a power interruption to the TV when the Receiver is set to On (by

■

disconnecting the power cord or a power failure), the Speaker Select may be
set to External Speaker when you turn the TV on again.

View TV

Device List

Recording: DVDR

DVDR MENU
DVDR INFO
Receiver: Off
Setup

View TV

Device List

Recording: DVDR
DVDR MENU
DVDR INFO

Receiver: Off

Setup

U

Move E Enter R Return

U

Move E Enter R Return

66

English

Troubleshooting for Anynet

Problem Possible Solution

+

Anynet+ does not work. Check if the device is an Anynet+ device. The Anynet+ system supports Anynet+ devices

Anynet+

I want to start Anynet+. Check if the Anynet+ device is properly connected to the TV and check if the Anynet+

I want to exit Anynet+. Select View TV in the Anynet+ menu.

The message ‘Connecting to
Anynet+ device...’ appears on
the screen.

The Anynet+ device does not
play.

●

only.
Connect only one receiver (home theatre).

●

Check if the Anynet+ device power cord is properly connected.

●

Check the Anynet+ device’s Video/Audio/HDMI 1.3 cable connections.

●

Check whether Anynet+ (HDMI-CEC) is set to On in the Anynet+ setup menu.

●

Check whether the TV remote control is in TV mode.

●

Check whether it is Anynet+ exclusive remote control.

●

Anynet+ doesn’t work in certain situations. (Searching channels, Operating Media Play,

●

Plug & Play, etc.)
When connecting or removing the HDMI 1.3 cable, please make sure to search devices

●

again or turn your TV off and on again.
Check if the Anynet+ Function of Anynet+ device is set on.

●

●

(HDMI-CEC) is set to On in the Anynet+ Setup menu.
Press the TV button on the TV remote control to switch to TV. Then press the TOOLS button

●

to show the Anynet+ menu and select a menu you want.

●

Press the SOURCE button on the TV remote control and select a device other than Anynet+

●

devices.
Press P >/<, PRE-CH, and FAV.CH to change the TV mode. (Note that the channel

●

button operates only when a tuner-embedded Anynet+ device is not connected.)

You cannot use the remote control when you are configuring Anynet+ or switching to a view

●

mode.
Use the remote control when the Anynet+ setting or switching to view mode is complete.

●

You cannot use the play function when Plug & Play is in progress.

●

The connected device is not
displayed.

The TV programme cannot be
recorded.

The TV sound is not output
through the receiver.

Check whether or not the device supports Anynet+ functions.

●

Check whether or not the HDMI 1.3 cable is properly connected.

●

Check whether Anynet+ (HDMI-CEC) is set to On in the Anynet+ setup menu.

●

Search Anynet+ devices again.

●

You can connect an Anynet+ device using the HDMI 1.3 cable only. Some HDMI cables may

●

not support Anynet+ functions.
If it is terminated by an abnormal situation such as disconnecting the HDMI cable or power

●

cord or a power failure, please repeat the device scan.

Check whether the antenna jack on the recording device is properly connected.

●

Connect the optical cable between TV and the receiver.

●

Content Library

Using the Content Library

67

English

The Content Library allows you to enjoy various content on your TV.
You can use the default content stored in the TV memory or you can enjoy new content using a USB device.

Using the Content Library Menu

Press the MENU button. Press the ▲ or ▼ button to select Application, then

1

press the ENTERE button.

Press the ▲ or ▼ button to select Content Library, then press the ENTERE

2

button.

The Content Library main menu is displayed.

■

Press the ◄ or ► button to select an icon (Gallery, Cooking, Game, Children,

3

Wellness, Others, Content Management), then press the ENTERE button.

Using the Remote Control Button in Content Library Menu

Button Operations

▲/▼/◄/► Move the cursor and select an item.

ENTER

RETURN Return to the previous menu.

EXIT

< P >

FAV.CH / CH LIST

Select the currently selected item.

E

Stop the current function and return to the Content Library main
menu.

/

Stop Content Library mode and Returns to TV mode.

Media Play (USB & DLNA)
Anynet

Application

Content Library

Internet@TV
Home Network Centre

Gallery Cooking Game Children Wellness

+

(HDMI-CEC)

Gallery

R

Content Library

Return e Exit

Colour button Keys that provide functions are described on the corresponding page.

- VOL + / MUTE

CONTENTS LIBRARY CONTAINS TEXT, GRAPHICS, IMAGES, MULTIMEDIA, AND
OTHER MATERIALS FOR INFORMATIONAL AND PROMOTIONAL PURPOSES ONLY.
MATERIALS IN CONTENTS LIBRARY HAS BEEN MODIFIED AND KEEPS BEING
REVISED AND UPDATED. THE MATERIALS IN THE CONTENTS LIBRARY MAY NOT BE
SUITABLE FOR ALL AUDIENCES.
INFORMATION IN THE CONTENTS LIBRARY IS PROVIDED ‘AS IS.’ ALTHOUGH THE
INFORMATION PROVIDED TO YOU IN THE CONTENTS LIBRARY IS OBTAINED OR
COMPLIED FROM SOURCES WE BELIEVE TO BE RELIABLE, SAMSUNG CANNOT
AND DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS OR
COMPLETENESS
OF ANY INFORMATION OR DATA MADE AVAILABLE TO YOU FOR ANY PARTICULAR
PURPOSE. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL
SAMSUNG BE HELD LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY
FEES, EXPENSES, OR ANY OTHER DAMAGES WHATSOEVER ARISING OUT OF, OR
IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR THE USE OF, THE
CONTENTS LIBRARY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

You can control the volume of the played content.

68

English

Content Library

Using the Contents

You can use enjoy content stored in the TV memory.

To return to Content Library main menu, press the EXIT button.

■

Option Description

Gallery This function plays a Slideshow with high resolution

Cooking You can view various recipes and then easily follow them

Game This category provides entertainment games for the

Children This is educational and interactive content that children

Wellness This is beneficial health management content that

images and background music and produces various
atmospheres. Using the Gallery function of the TV, you
can change your home atmosphere.

The copyrights of the Gallery contents and all issues

■

related to them are reserved by TimeSpace, Inc.
Press the ENTERE button to pause the Slideshow,

■

and also press the ENTERE button to resume the
Slideshow.

Press the INFO button to display information on the

■

selected photo. (This is not displayed if the photo has
no information.)

step by step. Enjoy these contents which will give you
great ideas for meals.

The recipes introduced in the Cooking contents on

■

the Samsung TV are based on recipes published by
Anness Publishing.

The copyrights of the Cooking contents and all issues

■

related to them are reserved by Practical Pictures.

whole family.

For the buttons used in the games, refer to the

■

directions on the screen.
Colour Buttons for Games

■

Red:

Press to move to the game home screen.



Green:





can watch repeatedly.

The copyrights of the Children contents and issues

■

related to them reserved by UpToTen.

provides stretching and massage exercises that can be
enjoyed by the whole family.

The Basic Stretches contents are automatically

■

played so that you can easily follow the movements on
the screen. To move to the previous or next operation,

press the ◄ or ► button to view the required step. The

selected item is displayed on the screen.

Press to pause the game.

Yellow:

Option Key.

Blue:

Press to exit the game

Gallery

Gallery Cooking Game Children Wellness

R

Return e Exit

69

English

Content Library

Using the Content Management

You can select multiple content items by selecting content items repeatedly and pressing the Yellow button.

Option Description

Content Management You can select multiple content items by selecting

My Contents You can check the content saved in the TV memory for

USB You can check the content saved on the USB device for

Setup Screen Saver Run Time: Select to set the waiting

■

content items repeatedly and pressing the Yellow
button.

each subitem of the Content Library.

Select a content item and press the ENTERE button.

■

You can play or delete the selected content item.

each subitem of the Content Library.

Select a content item and press the ENTERE button.

■

You can play the selected content item.

Content Library only supports USB Mass



Storage Class devices (MSC). MSC is a Mass
Storage Class Bulk-Only Transport device.
Examples of MSC are Thumb drives and Flash
Card Readers.

Playing a game using an external USB memory



device will allow you to save your game
(depending on the game). Take care as removing
the USB memory device while saving data to the
USB memory device may cause the data to be
lost.

Downloading New Contents



New content other than the built-in content will be
provided via the Samsung.com website free of
charge. When you download the paid contents, you
need UDN number to download contents. Check
the UDN number before downloading a new content
item.

Downloading Content

■

1. Visit the www.samsung.com website.

2. Select a content item in the Contents Download

page.

3. Download the contents onto the USB memory
device.

4. Go to Content Library main menu by pressing
CONTENT button or choosing Content Library
(Menu → Application → Content Library).

5. Plug the USB memory into USB port on the side of

the TV.

6. You can see the content sub item which you
downloaded.

7. Select a content item and press the enter button.

8. You can play the selected content item.

■

time before the screen saver appears.
Save UDN: Saves the UDN number to a USB device.

■

Game Children Wellness Other Content

Content Management > My Contents

My Contents

USB

Setup

TV Memory

17.16GB/189.00MB Available

An NTFS format USB storage

■

device does not support saving
UDN.
We recommend using a FAT
format USB storage device.

Gallery

Cooking

Game

Children

Wellness

Others

Content

Management

Management

R

Return e Exit

R

Return e Exit

1/1

 

70

English

Internet@TV

Internet@TV

If you have some problems while using a widget service, please contact to content provider. In the widget, press the Green button and
get information of contact or refer to help website for widget provider information.

Getting Started with Internet@TV

Internet@TV provides an integrated Internet and television experience powered by the Yahoo!® Widget Engine.
You can monitor financial stocks, share photos with friends and family, and track news and weather all through the Internet@TV service
on your television.

If Network condition is unstable, this function may not work. Then, TV would be turned off automatically. Otherwise turn off the TV

■

using power button.
You may experience slow operation or hesitation when using this function due to network conditions.

■

When running Internet@TV for the rst time, the basic settings proceed automatically.

The first step is to set up your network. For more information on how to configure your network, refer to page 37.

■

After your network is operational, the Internet@TV software guides you through a step-by-step setup wizard.

■

What is a Widget?

A TV Widget is a small web application that allows you to easily access your favourite site using the remote control. You can enjoy
various types of information, such as the latest news, weather information, and stock information, etc. on your TV along with your
friends or family members.
Some widgets may not be supported depending on the regulations of the corresponding country.

Some widgets will only support limited services depending on the regulations of the corresponding country.

■

The colour buttons may work differently depending on the widget.

■

The operation may not be smooth depending on the network condition.

■

The Snippet is a symbol of Widget.

■

What is a Snippet?

A snippet shows a part of the Widget contents such as weather and stock information that the user wants to view.

The snippets are automatically updated in real time.

■

It may take a few seconds to load the snippet.

■

Press the MENU button. Press the ▲ or ▼ button to select Application, then

1

press the ENTERE button.

Press the INTERNET@ button

Press the ▲ or ▼ button to select Internet@TV, then press the ENTERE

2

button.

Internet@TV starts.

■

The General Disclaimer is displayed on the screen. Select I accept or I do not

3

accept.

For more information on the General Disclaimer, refer to page 41.

■

The ‘welcome screen’ is the starting point of the Internet@TV guided setup.

If you select Exit Setup, this step is resumed when you press the

■

4

5
6

7

8

INTERNET@ button.
Select Let’s get started!

■

Choosing your location allows TV Widgets to use localized content.

Select your country from the list provided.

■

Accepting the Yahoo!® TV Widget Engine Privacy Policy is required to use

Internet@TV.

Select OK, I Accept.

■

Accepting the Yahoo!® TV Widget System Terms of Service is required to use

Internet@TV.

Select OK, I Accept.

■

Enter your name to setup your profile. Each profile has its own list of widgets.

You can create a profile for each person who uses Internet@TV.

Enter your name and select Save this name.

■

For more information, refer to page 73.

■

■

on the remote control to display
the Internet@TV menu.

Welcome to Yahoo!® TV Widgets!

Yahoo! TV Widgets bring the best of the internet to
your TV! You can get updated weather conditions or
sports scores, get updated information on stocks, or
even view full-screen photos and video!

We just need to get a few things set up, and you’ll be
on your way!

Let’s get started! Exit setup

What’s your name?

Save this name5Skip this step Exit setup

Each person in the house who
uses the TV can have their own
personalized set of widgets.

We’ll keep track of these
individual widget profiles by the
name you enter, Enter the name
YOU want to use now.

1

71

English

Internet@TV

Internet@TV tests the network connection.

9

For more information, refer to page 37

■

If the test fails, configure your network again.

■

The guided setup is complete. A tutorial on how to use Internet@TV is next.

10

Select Exit setup to start using Internet@TV now.

■
To run the tutorial again, select Profile Widget → System Setting → Repeat Tutorial.

■

P

ress the INTERNET@ button on the remote control to display the Internet@TV user interface.

Select Continue to view the tutorial.

■

11

Screen Display

Dock mode

1 A welcome banner is shown with your profile name in the top right corner.

This banner disappears after a short delay.

■

2 The banner highlights two remote control shortcuts.

If you press the blue button (Viewport) on your remote control, the

■

display is toggled between ‘Viewport mode’ and ‘Overlay mode’. In
Viewport mode, the TV or video plays in a scaled-down area with
graphics outside. In overlay mode, the graphics are displayed on top
of the TV or video.

If you press the yellow button (Edit Snippet) on your remote control,

■

a help window is displayed and the snippet with focus can be edited

3 Press the INTERNET@ button on the remote control to begin.

The horizontal list at the bottom of your TV screen is called ‘the dock’.

■

The items in the list are called ‘snippets’.

■

A snippet is a shortcut which launches a TV Widget.

■

A TV Widget is an Internet application designed to run on your TV.

■
Move between snippets by pressing the ◄ or ► buttons on the remote

■

control.
Focus is located in the left most region (highlighted in blue).

■

The dock slides snippets under that focal point.

■

Launch a TV Widget by pressing the ENTERE button on the remote

■

control when its snippet is in focus.
When you add snippets, they form a stack which you can navigate by

■
pressing the ▲ or ▼ buttons.

Two special TV Widgets appear in the dock: the Profile Widget and the

■

Gallery Widget. These cannot be deleted.
The dock will slide off screen after a timeout period.

■

3

3

Signed in as

John

display

1
2

WEATHER Widget Gallery FINANCE

Hello John!

5:15 AM Mon January 19th

Viewport Edit Snippet

Sidebar mode

1 Focus on a snippet and press the ENTERE button to launch the TV

Widget sidebar. The TV Widget logo and Home are at the top of the
sidebar.

2 Current menu is displayed under the TV Widget logo.

To return to a previous screen, select it and press the ENTERE

■

button.
You can also press the RETURN button on the remote control.

■

3 Current selection is always highlighted in blue. The highlighted button has

focus and is activated when you press the ENTERE button.

4 When there is a lot of data, a page control is used.

Current page and total pages are displayed.

■
Move between pages by pressing ◄ or ► buttons.

■

5 The bottom toolbar includes colour buttons that correspond to the red, green,

yellow and blue buttons on the remote control.

Red button: Close the widget.

■

Green button: Change the widget’s setting.

■

Yellow button: Manage your snippets.

■

Blue button: Size video to fit, or make it full screen.

■

To remove a stocks symbol, please
select it from the list below.

^DJI

^IXIC

YHOO
AAPL

INTC

AMZN

Add New Symbol...
Import Symbols From Yahoo!...
Display Format Value
About Yahoo! Finance...

FINANCE

My Stocks

 PAGE 1 OF 2 

1
2

3
4

5

72

English

Internet@TV

All content and services accessible through this device belong to third parties and are protected by copyright, patent, trademark
and/or other intellectual property laws. Such content and services are provided solely for your personal noncommercial use. You may
not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting
the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not modify, copy, republish,
upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services
displayed through this device.
YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF THE DEVICE IS AT YOUR SOLE RISK AND THAT THE ENTIRE
RISK AS TO SATISFACTORY QUALITY, PERFORMANCE AND ACCURACY IS WITH YOU. THE DEVICE AND ALL THIRD
PARTY CONTENT AND SERVICES ARE PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED. SAMSUNG EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE DEVICE AND
ANY CONTENT AND SERVICES, EITHER EXPRESS OR, IMPLIED, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF
MERCHANTABILITY, OF SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY, OF QUIET
ENJOYMENT, AND NON-INFRINGEMENT OF THIRD PARTY RIGHTS. SAMSUNG DOES NOT GUARANTEE THE ACCURACY,
VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH
THIS DEVICE AND DOES NOT WARRANT THAT THE DEVICE, CONTENT OR SERVICES WILL MEET YOUR REQUIREMENTS,
OR THAT OPERATION OF THE DEVICE OR SERVICES WILL BE UNINTERRUPTED OR ERROR-FREE. UNDER NO
CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY
DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER
DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF THE USE
OF THE DEVICE, OR ANY CONTENT OR SERVICE ACCESSED BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Third party services may be changed, suspended, removed, terminated or interrupted, or access may be disabled at any time,
without notice, and Samsung makes no representation or warranty that any content or service will remain available for any period
of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which Samsung
has no control. Without limiting the generality of this disclaimer, Samsung expressly disclaims any responsibility or liability for any
change, interruption, disabling, removal of or suspension of any content or service made available through this device. Samsung
may impose limits on the use of or access to certain services or content, in any case and without notice or liability.
Samsung is neither responsible nor liable for customer service related to the content and services. Any question or request for
service relating to the content or services should be made directly to the respective content and service providers.

Editing Snippets in the Dock

Edit a snippet by focusing on it in the dock and pressing the yellow button.

1

The snippet moves to the Second position and its tile slides up to show the following help text:

Delete (Red button): Remove this TV Widget.

■

2

Deleted widgets can be re-installed using the Widget Gallery.

Move (Blue button): Re-order the snippet. Press the ◄ or ► button to scroll. Press the yellow button to drop into the

■

new position.
Done (Yellow button): Exit the Edit Snippet menu.

■

73

English

Internet@TV

Using the Profile Widget

The Profile Widget configures your user profile.
You can set up multiple profiles, and each profile maintains its own list of widgets.
The Switch Profile menu allows you to switch to a different user profile.

At least two profiles must be registered. If you want to add a profile, refer to page 73.

■

The Prole Settings menu allows you to customize and protect your prole.

User profiles can be customized with a unique Name and an Avatar (a picture used to

■

represent your profile).

■

Your profile’s Name and Avatar are displayed in the profile snippet in the dock.

■

Profiles can be protected by Create Profile PIN.

■

When setting the PIN for the first time, you can set a Security Question.

■

The Prole Settings menu can limit access to widgets.

If you forget your Profile PIN you can answer a Security Question that is associated with

■

your profile.
A profile that has the Limit Profile indicator turned on will not allow new widgets to be installed.

■

The Owner PIN must be set to use this function. To set the Owner PIN, refer to page 73.

■

PROFILE

Signed in as

John

Switch Profile

Profile Settings

System Settings

Administrative Controls

Sign out of Yahoo!

PROFILE

Profile Settings

John

Name

Avatar

Create Profile PIN

Security Question

Security Answer

Limit Profile Off

The System Settings menu allows you to:

Change your Location and set your Zip Code (US only) to tailor the content to your region.

■

Repeat the Tutorial that was shown during guided setup.

■

Restore Factory Settings to delete all widget configurations and information.

■

In the Administrative Controls menu you can:

Set the Screen Saver timeout to avoid screen burn in.

■

Create Owner PIN and set a Security Question to control other profiles.

■

Create a new Profile which can be configured with a different set of widgets.

■

Delete an existing profile.

■

Done
Cancel

PROFILE

System Settings

Location
Repeat Tutorial
Restore Factory Settings

PROFILE

Administrative Controls

Screen Saver 240 Minutes
Create Owner PIN
Create Profile
Remove Profile

74

English

Internet@TV

From the Prole Widget you can Sign in to Yahoo!® using your Yahoo! ID.

If you have a Yahoo! ID, you can access your personalized content using the Yahoo!®! TV

■

Widgets.
All Yahoo!®! TV Widgets that are installed are automatically signed-in with your profile’s

■

Yahoo! ID.
If you have no Yahoo! account, visit www.yahoo.com and create an account.

■

You may fail to log in with an ID created on the Yahoo website in a country that does not

■

support Internet@TV.

About Prole widget

Press the Green button.

■

You can view a brief description of the Profile Widget, Copyright Policy, Terms of Service,

■

and Privacy Policy.

Using the Yahoo!® Widget
Gallery

PROFILE

Sign in to access your Yahoo! data for
the Yahoo! Widgets in this profile. Use
the Profile Widget to sign out.

Yahoo! ID

a b c def g h i

j k l m n o p q r

s

t u v w x y z 0

1 2 3 4 5 6 7 8 9

Switch Profile

Next

Profile Settings

Cancel

System Settings

Administrative Controls

Sign out of Yahoo!

Signed in as

John

space.@#

ãéì



Use the Yahoo!® Widget Gallery to add more widgets to your TV.
View available TV Widgets in the following categories:

Latest Widgets: Displays recently updated widgets.

■

Yahoo!® Widgets: Displays widgets provided by Yahoo!®.

■

Samsung Widgets: Displays widgets provided by Samsung.

■

Categories: Displays all widgets by category.

■

To install a widget, navigate to the detail screen and select Add Widget to My Profile and

■

press the ENTERE button. The widget is installed and becomes available in the dock.

Widget Gallery Settings

Press the Green button.

About Yahoo! Widget Gallery...

You can view brief information for the Widget Gallery, Copyright Policy, Terms of Service, and
Privacy Policy.

In the Developer Settings menu You can make your own widget.

For more information on creating your own widget, visit our developer site at http://connectedtv.
yahoo.com/

Widget Gallery

Yahoo! News

by Yahoo!

NEWS HEADLINES

 PAGE 1 OF 2 

Top Stories

Business
Potics

Sports
Technology
More Categories



Latest Widgets

Yahoo! Widgets

Samsung Widgets

Categories



WIDGET GALLERY

Settings

V 0.9.0

NEWS



About Yahoo! Widget Gallery...
Developer Settings

75

English

Internet@TV

Using the Yahoo!® Weather
Widget

The Yahoo!® Weather Widget provides updates on your local and favorite weather locations.
This content dynamically changes with weather conditions.

Press the green button on the remote control to display the Yahoo!® Weather Widget Settings

■

menu.
From the Settings menu you can add or remove a city for which you want to view weather

■

information.

From the Settings menu:

Add New City by entering the name of the city. Once the search results are displayed, select

■

the city you want and press the ENTERE button.
Delete City by selecting the city you want to delete from the city list. Press the ENTERE

■

button and confirm the deletion.
Changing the Temperature Indication Mode

■

You can change the temperature indication mode to Imperial or Metric. For example,
Imperial will show temperatures in Fahrenheit and Metric in Celsius.

Create a Snippet for a Favorite City

Select the city from the Yahoo!® Weather Widget’s home page and view the detailed weather

■

information.
Press the Yellow button.

■

Select the Add Snippet menu and press ENTERE to add the city as a snippet.

■

Delete a Snippet for a City

Launch the snippet.

■

Press the Yellow button.

■

Select the Delete Snippet menu and press ENTERE to remove the snippet.

■

WEATHER

51°

Sunnyvale, CA

San Francisco, CA

New York, NY

London, England

Paris, France

Sunnyvale

Cloudy

Using the Yahoo!® News Widget

The Yahoo!® News Widget provides the latest headline news for business, entertainment,
politics, sports, top stories, and many other categories.

Select a category, select a headline within the category, and view a dynamically updated news
summary.

World

NEWS







76

English

Internet@TV

Using the Yahoo!® Flickr
Widget

The Flickr Widget can provide you access to your favorite photos from friends and family
while

watching TV. Share your photos with your family on your big screen TV through a
slideshow.

Personalize the Flickr Widget by logging in with your Yahoo! ID.

■

For detailed procedures on log in, refer to page 73.

■

For more information on Flickr, visit http://www.flickr.com.

■

Your Photos shows photos you have registered with Flickr website.

■

To view Flickr photos in a slideshow:

Select a thumbnail of a photo and press the

■

details.
Select Start Slideshow and press the

■

To control the slideshow display:

Press the ENTERE button during a slideshow.

■

The thumbnails of photos are displayed on the bottom of the screen.

■

When the slideshow control is displayed, you can Pause, Play and Stop the



slideshow.
If you select the menu and press ENTERE, you can view information for the



selected photo.

The Your Sets menu allows you to view photos you have classified in Flickr.

■

The Explore menu allows you to explore photos featured by the Flickr website.

■

You can view the photos updated daily.
The Mark as Favorite or Remove From Favorite menu moves photos to your Favorite

■

Photos set or removes photos from it.
The Favorite Photos menu allows you to see the photos you have classified as

■

favorites.
The Your Contacts menu allows you to see updates from family and friends.

■

ENTERE

ENTERE

button to view the photo’s

button.

Your Photos

Your Sets

Explore

Favorite Photos

Your Contacts

Your Groups

The Your Groups menu allows you to select your favorite groups from the
Flickr website to share and enjoy photos with the Flickr community of users.

To configure the Yahoo!® Flickr Widget Settings press the Green button on the remote
control.

The Time Per Slide menu controls the speed of the slideshow.

■

The Repeat menu will restart the slideshow at the beginning after the last photo is

■

shown.

77

English

Internet@TV

Using the Yahoo!® Finance
Widget

View stock information and the latest stock news with the Yahoo!® Finance Widget.
Press the green button to set up your stocks.
Use the Add New Symbol menu to enter the name of a new stock.

Select the stock you want to add from the search results and select the Add Symbol menu and

■

press the ENTERE button.

The selected stock is added to the My Stocks list.



Use the Import Symbols From Yahoo!® menu to retrieve your Yahoo!® Finance portfolio.

■

The Merge Symbols menu merges the symbols in the Yahoo!® Finance Widget with



the symbols from your portfolio.
The Replace Symbols menu deletes the symbols in the Yahoo!® Finance Widget and



replaces them with the symbols from your portfolio.

Use the Display Format menu to change the stock-price fluctuation transition to Value or

■

Percentage.
Create a snippet for a favorite stock.

■

Select the stock symbol from the Yahoo!® Finance Widget’s home page and view the



detailed finance information.
Press the Yellow button.



Select the Add Snippet menu and press ENTERE to add the stock as a snippet.



Delete a snippet

■

Launch the snippet from the dock



Press the yellow button.



Select the Delete Snippet menu and press ENTERE to remove the snippet.



Troubleshooting for Internet@
TV

FINANCE

My Stocks

To remove a stocks symbol, plase
select it from the list below.

^DJI

^IXIC

YHOO

AAPL

INTC

AMZN

 PAGE 1 OF 2 

Add New Symbol...
Import Symbols From Yahoo!...
Display Format Value
About Yahoo! Finance...

Problem Possible Solution

Some widget services do not work. Check with that service provider.

Some widget contents only have
English. How can I change the
language?

After factory reset, Yahoo Widget
service doesn’t work and warning
message is displayed.

At the Flickr widget, I logged in my
account. But, I can’t view my picture.

At the Profile widget, I did change
location, but the previous setting still
remains.

In the widget, press the green button and get contact information or refer to help
website for widget service provider information.
Refer to Help website page.

Widget content language may be different from widget user interface language.
It depends on service provider.

After factory reset, turn off and on your TV. Then restart Internet@TV.

Visit Yahoo Web site, and activate your Flickr account at your Yahoo! ID.

Turn off and on your TV. Then restart Internet@TV.
Now, you can enjoy widget services supported in changed location.

78

English

Help Website

Country Website

Austria www.samsung.com → Produkte → Fernseher → medi@2.0 → Internet@TV

Internet@TV

Belgium

Czech www.samsung.com → Produkty → televizory → medi@2.0 → Internet@TV

Denmark www.samsung.com → Produkter → stue & soveværelse → medi@2.0 → Internet@TV

Finland www.samsung.com → Tuotteet → kodinelektroniikka → medi@2.0 → Internet@TV

France www.samsung.com → Produits → télévisions → medi@2.0 → Internet@TV

Germany www.samsung.com → Privatkunden → Fernseher → medi@2.0 → Internet@TV

Greece www.samsung.com → Προϊόντα → τηλεοράσεις → medi@2.0 → Internet@TV

Hungary www.samsung.com → Termékek → televíziók → medi@2.0 → Internet@TV

Ireland www.samsung.com → Products → Television → medi@2.0 → Internet@TV

Italy www.samsung.com → Prodotti → TV → medi@2.0 → Internet@TV

Netherlands www.samsung.com → Producten → televisies → medi@2.0 → Internet@TV

Norway www.samsung.com → Produkter → hverdagsrom & soverom → medi@2.0 → Internet@TV

Poland www.samsung.com → Produkty → telewizory → medi@2.0 → Internet@TV

Portugal www.samsung.com → Produtos para Consumidores → televisores → medi@2.0 → Internet@TV

Slovakia www.samsung.com → Produkty → televízory → medi@2.0 → Internet@TV

Spain www.samsung.com → Productos → televisores → medi@2.0 → Internet@TV

www.samsung.com → Producten → televisies → medi@2.0 → Internet@TV

www.samsung.com → Produits → téléviseurs → medi@2.0 → Internet@TV

Sweden www.samsung.com → Produkter → vardagsrum & sovrum → medi@2.0 → Internet@TV

Switzerland

United Kingdom www.samsung.com → Products → Television → medi@2.0 → Internet@TV

Turkey www.samsung.com → Tüketici Ürünleri → televizyon → medi@2.0 → Internet@TV

Estonia www.samsung.com → Klientidele → Televiisorid → medi@2.0 → Internet@TV

Latvia www.samsung.com → Klientiem → Televizori → medi@2.0 → Internet@TV

Lithuania www.samsung.com → Namams → Televizoriai → medi@2.0 → Internet@TV

Russia www.samsung.com → Продукты → Телевизоры → medi@2.0 → Internet@TV

Ukraine www.samsung.com → Потребительские продукты → телевизоры → medi@2.0 → Internet@TV

Approaching step may be changed later on.

■

It can be different links for special countries.

■

www.samsung.com → Produits → télévisions → medi@2.0 → Internet@TV

www.samsung.com → Produkte → Fernseher → medi@2.0 → Internet@TV

Home Network Centre

About the Home Network Centre

79

English

The Home Network Centre connects the TV and mobile phones through a network. You can view call arrivals, text message
contents, and schedules set on the mobile phone on the TV using the Home Network Centre. In addition, you can play the media
contents saved on the mobile phones such as videos, photos and music by controlling them onto the TV via the network.

If the device supports DLNA DMC (Digital Media Controller) function, Home Network Centre function is available.

■

The Samsung SCH-i900 mobile phone supports the Home Network Centre. Other models will be added in the future.

■

The mobile device may need additional software installation. For details, refer to each user’s guide.

Connecting to the Home Network Centre

For more information about the network settings, refer to page 37.

Connecting to a Wi-Fi Ad-hoc Network

TV Rear Panel

or

Samsung Wireless or

LAN Adapter

Connect the ‘Samsung Wireless LAN Adapter’ to the USB1(HDD) or USB2 port of the TV.

1

For more information on how to configure Ad-hoc network, refer to page 37.

For information on configuring the mobile phone’s network settings, refer to the mobile phone manual.

■

2

Set up the IP address, SSID and password for the mobile phone in the Ad-hoc Settings of the mobile phone using the Network

3

Name (SSID) and Security Key (password) displayed on the TV.

Mobile phone

Home Network

Connecting through a Wire / Wireless IP Sharer

Wire/Wireless IP sharer

Mobile phone

LAN Cable

TV Rear Panel

Wire/Wireless IP sharer

Mobile phone

LAN Cable

Connect the LAN port of the TV and the Wire/Wireless IP sharer using the LAN cable or connect the USB1(HDD) or USB2 port of the
TV and the ‘Samsung Wireless LAN Adapter’

For the procedures to set up the wire/wireless sharer and the mobile phone, refer to the manual of the corresponding device.

■

or

Samsung

Wireless LAN

Adapter

80

English

Setting Up the Home Network Centre

Option Description

Message Shows a list of mobile phones which have been set up

Home Network

with this TV to use the message function (the call arrivals,
text message contents and schedules set on the mobile
phone).

Allowed

■

Allows the mobile phone.

Denied

■

Blocks the mobile phone.

Delete

■

Deletes the mobile phone from the list.

This function just deletes the name from the list.



If the deleted mobile device turns on or tries to
connect to the TV, it may be shown on the list.

Media Shows a list of mobile phones which is available to

control media contents (videos, photos, music) from the
phone.

Besides mobile phone, other mobile devices that



support DLNA DMC are available

Allowed

■

Allows the mobile phone.

Denied

■

Blocks the mobile phone.

Delete

■

Deletes the mobile phone from the list.

This function just deletes the corresponding



name on the list. If the deleted mobile device
turns on or tries to connect to the TV, it may be
shown on the list.

Home Network Centre

Message

111-1234-5671 : Allowed

Media

111-1234-5672 : Allowed

Setup

111-1234-5673 : Denied

111-1234-5674 : Denied

Home Network Centre

Message

111-1234-5671 : Allowed

Media

111-1234-5672 : Allowed

Setup

111-1234-5673 : Denied

111-1234-5674 : Denied

R Return e Exit

R Return e Exit

Setup Message

■

You can determine whether to use the message function
(the call arrivals, text message contents, and schedules
set on the mobile phone).

Media

■

You can select whether to use the media function that
plays the contents (videos, photos, music) from the
mobile phone.

TV name

■

You can set the TV name so as to find it easily on the
mobile device.

If you selects User Input, you can type the TV



name by OSK(On Screen
set a name for your TV to be used in the Home
Network.

Keyboard). You can

Home Network Centre

Message

Message : On

Media

Media : On

Setup

TV name : TV

R Return e Exit

81

English

Home Network

Using the Message Function

Using this function, you can view the call arrivals, text message contents and schedules
set on the mobile phone through the alarm window while watching TV.

To disable this Message alarm window, set Message to Off in Setup of the Home Network

■

Centre.
The alarm window appears for 20 seconds. If no key is pressed or if Cancel is selected, it

■

appears up to three times at 5 minute intervals.
If OK is selected, or if OK is not selected while the message is displayed three times, the

■

message will be deleted. The message is not deleted from the mobile phone.
The simple alarm window can be displayed, while using some applications such as Media

■

Play, Content Library, etc. In this case, to view the contents of the message, switch to TV
viewing mode.

When the message of an unknown mobile phone is displayed, select the mobile phone in the

■

Message item of the Home Network Centre and select Denied to block the phone.


husband

SMS

New message received

Do you want to view

the details?

OK Cancel

851.86MB/993.02MB Free

SUM

Message View

If a new text message (SMS) arrives while you are watching TV, the alarm window
appears. If you click the OK button, the contents of the message are displayed.

If you select the OK button, the contents of the message are displayed.

■

If you select the Cancel button, the alarm window appears up to three times at 5 minute

■

intervals.

You can configure the viewing settings for the text message (SMS) contents on the



mobile phone. For the procedures, refer to the mobile phone manual.
Some special characters may be displayed as blank or broken characters.



Call Arrival Alarm

If a call arrives while you are watching TV, the alarm window appears.

If you select the OK button, the call arrival alarm is confirmed and the alarm window is closed.

■

If you select the Cancel button, the alarm window appears up to three times at 5 minute

■

intervals.

Schedule Alarm

While you are watching TV, the alarm window appears to display the registered
schedule.

If you select the OK button, you can view the contents of the schedule registered on the

■

mobile phone.
If you select the Cancel button, the alarm window appears up to three times at 5 minute

■

intervals.

You can configure the viewing settings for the schedule contents on the mobile phone.



For the procedures, refer to the mobile phone manual.
Some special characters may be displayed as blank or broken characters.



SUM


Music Movie Setup

Device

husband

R

Return

husband

SMS

New message received

Do you want to view

the details?

OK Cancel

husband

Call

You have a phone call

Mom

011-298-2030

OK Cancel

husband

Scheduled event

You have a schedule

Do you want to view

the details?

OK Cancel

82

English

Home Network

Using the Media Function

An alarm window appears informing the user that the media contents (videos, photos, music)
sent from the mobile phone will be displayed on the TV.

The contents are played automatically 3 seconds after the alarm window appears.
If you press the RETURN or EXIT button when the alarm window appears, the Media

Contents are not played.

To turn off the media contents transmission from the mobile phone, set Media to Off in

■

Setup of the Home Network Centre.
The contents may not be played on the TV depending on their resolution and format.

■

Media Play Control Buttons

Button Operations

Media will be played from “111-123 4-5671”

◄/►

ENTER

RETURN Return to the previous menu.

TOOLS Run various functions from the Photo, Music and Movie menus.

INFO Show file information.

EXIT Stop Media Play mode and Returns to TV mode.

The ENTERE and ◄/► buttons may not work depending on the type of media content.

■

Using the mobile device, you can control playing media. For details, refer to each user’s guide.

■

Move the cursor and select an item.
While playing a movie file: Skip forwards or backwards through the movie file.

Pressing the ENTERE button during play pauses the play.

E

Pressing the ENTERE button during pause resumes the play.

Other Information

3

1

2

4

7

5

6

8

9

0

!

#

@

Teletext Feature

83

English

Most television stations provide written information services via Teletext. The index page of the Teletext service gives you information
on how to use the service. In addition, you can select various options to suit your requirements by using the remote control buttons.

For Teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some

■

pages may not be displayed.

1 : (exit)
Exit from the Teletext display.
2 6 (index)
Used to display the index (contents) page at any time while you are viewing Teletext.
3 5 (reveal)
Used to display the hidden text (answers to quiz games, for example). To display normal

screen, press it again.

4 4 (size)
Press to display the double-size letters in the upper half of the screen. For lower half of the

screen, press it again. To display normal screen, press it once again.

5 Colour buttons (red/green/yellow/blue)
If the FASTEXT system is used by a broadcasting company, the different topics covered

on a Teletext page are colour-coded and can be selected by pressing the coloured
buttons. Press one of them corresponding to the required. The page is displayed
with other coloured information that can be selected in the same way. To display the
previous or next page, press the corresponding coloured button.

6

/

Press to activate Teletext mode after selecting the channel providing the Teletext service.

7 8 (store)
Used to store the Teletext pages.
8 1 (sub-page)
Used to display the available sub-page.
9 9 (hold)
Used to hold the display on a given page if the selected page is linked with several

0 7 (cancel)
Used to display the broadcast when searching for a page.
! 2 (page up)
Used to display the next Teletext page.
@ 3 (page down)
Used to display the previous Teletext page.
# 0 (mode)
Press to select the Teletext mode (LIST/ FLOF). If you press it in the LIST mode, it switches

The Teletext pages are organized according to six categories:

■

■

■

■

■

(Teletext on/mix)

Press it twice to overlap the Teletext with the current broadcasting screen.

secondary pages which follow on automatically. To resume, press it again.

into the List save mode. In the List save mode, you can save Teletext page into list using the

8

(store) button.

Part Contents

A Selected page number.
B Broadcasting channel identity.
C Current page number or search indications.
D Date and time.
E Text.
F Status information.

FASTEXT information.

Teletext information is often divided between several pages displayed in sequence, which can
be accessed by:





Teletext level supported by the TV is version 2.5 which is capable of displaying additional
graphics or text.
Depending upon the transmission, blank side panels can occur when displaying Teletext.
In these cases, additional graphics or text is not transmitted.
Older TV’s which do not support version 2.5 are not capable of displaying any additional
graphics or text, regardless of the Teletext transmission.

Entering the page number
Selecting a title in a list
Selecting a coloured heading (FASTEXT system)

You can change Teletext

■

pages by pressing the
numeric buttons on the
remote control.

Press the TV button to exit

■

from the Teletext display.

Other Information

84

English

Other Information

Using Your TV as a Computer (PC) Display

Setting Up Your PC Software (Based on Windows XP)

The Windows display-settings for a typical computer are shown below. The actual screens on your PC will probably be different, depending
upon your particular version of Windows and your particular video card. However, even if your actual screens look different, the same basic
set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.)

First, click on ‘Control Panel’ on the Windows start menu.

1

When the control panel window appears, click on ‘Appearance and Themes’ and a display

2

dialog-box will appear.

When the control panel window appears, click on ‘Display’ and a display dialogbox will

3

appear.

Navigate to the ‘Settings’ tab on the display dialog-box.

The correct size setting (resolution) - Optimum: 1920 X 1080 pixels.

■

4

If the signal from the system equals the standard signal mode, the screen is adjusted automatically. If the signal from the system doesn’t
equal the standard signal mode, adjust the mode by referring to your videocard user guide; otherwise there may be no video. For the display
modes listed on the next page, the screen image has been optimized during manufacturing.

D-Sub and HDMI/DVI Input

If a vertical-frequency option exists on your display settings dialog box, the correct value

■

is ‘60’ or ‘60 Hz’. Otherwise, just click ‘OK’ and exit the dialog box.

Display Modes

Mode Resolution

IBM

MAC

VESA CVT

VESA DMT

VESA GTF

VESA DMT /

DTV CEA

When using an HDMI / DVI cable connection, you must use the HDMI IN 1(DVI) jack.

■

The interlace mode is not supported.

■

The set might operate abnormally if a non-standard video format is selected.

■

Separate and Composite modes are supported. SOG is not supported.

■

Too long or low quality VGA cable can cause picture noise at high resolution modes 1920x1080.

■

640 x 350 31.469 70.086 25.175 +/­ 720 x 400 31.469 70.087 28.322 -/+

640 x 480 35.000 66.667 30.240 -/-

832 x 624 49.726 74.551 57.284 -/-

1152 x 870 68.681 75.062 100.000 -/-

720 x 576 35.910 59.950 32.750 -/+

1152 x 864 53.783 59.959 81.750 -/+
1280 x 720 44.772 59.855 74.500 -/+
1280 x 720 56.456 74.777 95.750 -/+
1280 x 960 75.231 74.857 130.000 -/+

640 x 480 31.469 59.940 25.175 -/­640 x 480 37.861 72.809 31.500 -/­640 x 480 37.500 75.000 31.500 -/­800 x 600 37.879 60.317 40.000 +/+
800 x 600 48.077 72.188 50.000 +/+

800 x 600 46.875 75.000 49.500 +/+
1024 x 768 48.363 60.004 65.000 -/­1024 x 768 56.476 70.069 75.000 -/­1024 x 768 60.023 75.029 78.750 +/+

1152 x 864 67.500 75.000 108.000 +/+
1280 x 1024 63.981 60.020 108.000 +/+
1280 x 1024 79.976 75.025 135.000 +/+

1280 x 800 49.702 59.810 83.500 -/+
1280 x 800 62.795 74.934 106.500 -/+
1280 x 960 60.000 60.000 108.000 +/+
1360 x 768 47.712 60.015 85.500 +/+
1440 x 900 55.935 59.887 106.500 -/+
1440 x 900 70.635 74.984 136.750 -/+

1680 x 1050 65.290 59.954 146.250 -/+

1280 x 720 52.500 70.000 89.040 -/+

1280 x 1024 74.620 70.000 128.943 -/-

1920 x 1080p 67.500 60.000 148.500 +/+

Horizontal Frequency

(KHz)

Vertical Frequency

(Hz)

Pixel Clock Frequency

(MHz)

Sync Polarity

(H / V)

85

English

Other Information

Troubleshooting: Before Contacting Service
Personnel

No sound or picture Check that the mains lead has been connected to a wall socket.

Normal picture but no sound Check the volume.

Screen is black and power
indicator light blinks steadily

No picture or black and white

Sound and picture interference Try to identify the electrical appliance that is affecting the set and move it further away.

Blurred or snowy picture,
distorted sound

Remote control malfunctions Replace the remote control batteries.

‘Check signal cable.’ message is
displayed

On PC mode, ‘Not Supported
Mode.’ message is displayed

●

Check that you have pressed the button on your set.

●

Check the picture contrast and brightness settings.

●

Check the volume.

●

●

Check whether the MUTEM button has been pressed on the remote control.

●

Check the Speaker Select settings.

●

On your computer check; Power, Signal Cable.

●

The TV is using its power management system.

●

Move the computer’s mouse or press any key on the keyboard.

●

Adjust the colour settings.

●

Check that the broadcast system selected is correct.

●

●

Plug your set into a different mains socket.

●

Check the direction, location and connections of your aerial.

●

This interference is often due to the use of an indoor aerial.

●

●

Clean the upper edge of the remote control (transmission window).

●

Check the battery terminals.

●

Check that the signal cable is rmly connected to the PC or video sources.

●

Check that the PC or video sources are turned on.

●

Check the maximum resolution and the frequency of the video adaptor.

●

Compare these values with the data in the Display Modes.

●

The damaged picture appears in
the corner of the screen

The ‘Resets all settings to
the default values.’ message
appears.

You may see small particles if
you look closely at the edge of
the bezel surrounding the TV
screen.

This TFT LED panel uses a panel consisting of sub pixels (6 220 800) which require sophisticated technology to produce.

■

However, there may be few bright or dark pixels on the screen. These pixels will have no impact on the performance of the product.

If Screen Fit is selected in some external devices, the damaged picture may appear in

●

the corner of the screen. This symptom is caused by external devices, not TV.

This appears when you press and hold the EXIT button for a while. The product settings

●

are reset to the factory defaults.

This is part of the product’s design and is not a defect.

●

86

English

Other Information

Specifications

Model Name UE40B7000, UE40B7020 UE46B7000, UE46B7020

Screen Size

(Diagonal)

Power Consumption

Standby

PC Resolution

(Optimum)

Sound

(Output)

Dimensions (WxDxH)

Without Stand
With stand

Weight

With Stand

Environmental Considerations

Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity

Stand Swivel

(Left / Right)

Model Name UE55B7000, UE55B7020

Screen Size

(Diagonal)

Power Consumption

Standby

PC Resolution

(Optimum)

Sound

(Output)

Dimensions (WxDxH)

Without Stand
With stand

Weight

With Stand

Environmental Considerations

Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity

Stand Swivel

(Left / Right)

40 inches 46 inches

<1W <1W

1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz

10W X 2 10W X 2

996 X 30 X 630 mm

996 X 255 X 692 mm

19 kg 23 kg

10°C to 40°C (50°F to 104°F)
10% to 80%, non-condensing

-20°C to 45°C (-4°F to 113°F)
5% to 95%, non-condensing

-20˚ ~ 20˚

55 inches

<1W

1920 x 1080 @ 60 Hz

15W x 2

1321 X 30 X 815 mm

1321 X 305 X 877 mm

28 kg

10°C to 40°C (50°F to 104°F)
10% to 80%, non-condensing

-20°C to 45°C (-4°F to 113°F)
5% to 95%, non-condensing

-20˚ ~ 20˚

1129 X 30 X 705 mm

1129 X 275 X 767 mm

Design and specifications are subject to change without prior notice.

■

This device is a Class B digital apparatus.

■

For the power supply and Power Consumption, refer to the label attached to the product.

■

Warning! Important Safety Instructions

Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK). THERE ARE

NO USER SERVICEABLE PARTS INSIDE. REFER ALL

SERVICING TO QUALIFIED PERSONNEL.

The slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation.

●

To ensure reliable operation of this apparatus, and to protect it from overheating, these slots and openings must never be
blocked or covered.

- Do not cover the slots and openings with a cloth or other materials.

- Do not block the slots and openings by placing this apparatus on a bed, sofa, rug or other similar surface.

- Do not place this apparatus in a confined space, such as a bookcase, or built-in cabinet, unless proper ventilation is provided.
Give your product 10 cm (4 inch) clearance from the wall.

Do not place this apparatus near or over a radiator or heat resistor, or where it is exposed to direct sunlight.

●

Do not place heat generating items such as candles, ashtrays, incense, flammable gas or explosive materials near the product.

●

Do not place a water containing vessel on this apparatus, as this can result in a risk of fire or electric shock.

●

Do not expose this apparatus to rain or place it near water(near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet

●

basement, or near a swimming pool etc.). If this apparatus accidentally gets wet, unplug it and contact an authorized dealer
immediately. Make sure to pull out the power cord from the outlet before cleaning.

This apparatus use batteries. In your community there might be regulations that require you to dispose of these batteries properly

●

under environmental considerations. Please contact your local authorities for disposal or recycling information.

Do not overload wall outlets, extension cords or adaptors beyond their capacity, since this can result in fire or electric shock.

●

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them,

●

paying particular attention to cords at plug end, adaptors and the point where they exit from the appliance.

To protect this apparatus from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the

●

wall outlet and disconnect the antenna or cable system.
This will prevent damage to the set due to lightning and power line surges.

Before connecting the AC power cord to the DC adaptor outlet, make sure the voltage designation of the DC adaptor corresponds to

●

the local electrical supply.

Never insert anything metallic into the open parts of this apparatus. Doing so many create a danger of electric shock.

●

To avoid electric shock, never touch the inside of this apparatus. Only a qualified technician should open this apparatus.

●

Make sure to plug the power cord in until it is firmly inserted. When removing the power cord, make sure to hold the power plug

●

when pulling the plug from the outlet. Do not touch the power cord with wet hands.

If this apparatus does not operate normally - in particular, if there are any unusual sounds or smells coming from it

●

unplug it immediately and contact an authorized dealer or service centre.

Be sure to pull the power plug out of the outlet if the TV is to remain unused or if you are to leave the house for an extended period

●

of time (especially when children, elderly or disabled people will be left alone in the house).

Accumulated dust can cause an electric shock, an electric leakage or a fire by causing the power cord to generate sparks and heat
or the insulation to deteriorate.

Be sure to contact an authorized service centre, when installing your set in a location with heavy dust, high or low temperatures,high

●

humidity, chemical substances and where it operates for 24 hours such as the airport, the train station etc. Failure to do so may
cause serious damage to your set.

Use only a properly grounded plug and receptacle.

●

An improper ground may cause electric shock or equipment damage. (Class l Equipment only.)

To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug shall be

●

readily operable.

Do not allow children to hang onto the product.

●

Store the accessories (battery, etc.) in a location safely out of the reach of children.

●

Do not install the product in an unstable location such as a shaky self, a slanted floor or a location exposed to vibration.

●

Do not drop or impart any shock to the product. If the product is damaged, disconnect the power cord and contact a service centre.

●

This symbol indicates that high voltage is present
inside. It is dangerous to make any kind of contact
with any internal part of this product.

This symbol alerts you that important literature
concerning operation and maintenance has been
included with this product.

WARNING - TO PREVENT THE SPREAD OF FIRE,

KEEP CANDLES OR OTHER OPEN FLAMES
AWAY FROM THIS PRODUCT AT ALL TIMES.

Wiring the Mains Power Supply Plug (UK Only)

IMPORTANT NOTICE

The mains lead on this equipment is supplied with a moulded plug incorporating a fuse. The value of the fuse is indicated on the pin
face of the plug and, if it requires replacing, a fuse approved to BSI1362 of the same rating must be used.
Never use the plug with the fuse cover omitted if the cover is detachable. If a replacement fuse cover is required, it must be of the same
colour as the pin face of the plug. Replacement covers are available from your dealer.
If the fitted plug is not suitable for the power points in your house or the cable is not long enough to reach a power point, you should
obtain a suitabl y approved extension lead or consult your dealer for assistance. However, if there is no alternative but to cut off the
plug, remove the fuse and then safely dispose of the plug.
Do NOT connect the plug to a mains socket as there is a risk of shock hazard from the bared flexible cord.

IMPORTANT

The wires in the mains lead are coloured in accordance with the following code:
BLUE - NEUTRAL BROWN - LIVE
As these colours may not correspond to the coloured markings identifying the terminals in your plug, proceed as follows :
The wire coloured BLUE must be connected to the terminal marked with the letter N or coloured BLUE or BLACK. The wire coloured
BROWN must be connected to the terminal marked with the letter L or coloured BROWN or RED.

WARNING:

DO NOT CONNECT EITHER WIRE TO THE EARTH TERMINAL, WHICH IS MARKED WITH THE
LETTER E OR BY THE EARTH SYMBOL , OR COLOURED GREEN OR GREEN AND YELLOW.

Warranty Card

UNITED KINGDOM

This Samsung product is warranted for a period of twelve (12) months from the original date of purchase, against defective materials
and workmanship. In the event that warranty service is required, you should return the product to the retailer from whom it was
purchased. However, Samsung Authorised Dealers and Authorised Service Centres in other EC Countries will comply with the warranty
on the terms issued to purchasers in the country concerned. In case of difficulty, details of our Authorised Service Centres are available
from:

Samsung Electronics U.K. Ltd.

Customer Care Centre

PO Box 17243

Edinburgh, EH11 4YB

Tel: 0845 SAMSUNG (7267864) (UK & Northern Ireland)

WARRANTY CONDITIONS

1. The warranty is only valid if, when warranty service is required, the warranty card is fully and properly completed and is presented

with the original invoice or sales slip or confirmation, and the serial number on the product has not been defaced.

2. Samsung’s obligations are limited to the repair or, at its discretion, replacement of the product or the defective part.

3. Warranty repairs must be carried out by Authorised Samsung Dealers or Authorised Service Centres. No re-imbursement will be

made for repairs carried out by non Samsung Dealers and, any such repair work and damage to the products caused by such
repair work will not be covered by this warranty.

4. This product is not considered to be defective in materials nor workmanship by reason that it requires adaptation in order to
conform to national or local technical or safety standards in force in any Country other than the one for which the product was
originally designed and manufactured.

United Kingdom

Tel: [phone] (EIRE Only)

Fax: [phone]

Web : www.samsung.com

This product uses parts of the software from the Independent JPEG Group.

●

This product uses parts of the software owned by the Freetype Project (www.freetype.org).

●

This product uses some software programs which are distributed under the GPL/LGPL license. Accordingly, the following

●

GPL and LGPL software source codes that have been used in this product can be provided after asking to vdswmanager@
samsung.com.

GPL software: Linux Kernel, Busybox, Binutils
LGPL software: Glibc, ffmpeg, smpeg, libgphoto, libusb, SDL

GNU GENERAL PUBLIC LICENSE

Version 3, 29 June 2007

Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/>
Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.

Preamble

The GNU General Public License is a free, copyleft license for software and other kinds of works.

The licenses for most software and other practical works are designed to take away your freedom to share and change the works. By
contrast, the GNU General Public License is intended to guarantee your freedom to share and change all versions of a program--to
make sure it remains free software for all its users. We, the Free Software Foundation, use the GNU General Public License for most of
our software; it applies also to any other work released this way by its authors. You can apply it to your programs, too.

When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that
you have the freedom to distribute copies of free software (and charge for them if you wish), that you receive source code or can get it
if you want it, that you can change the software or use pieces of it in new free programs, and that you know you can do these things.

To protect your rights, we need to prevent others from denying you these rights or asking you to surrender the rights. Therefore, you
have certain responsibilities if you distribute copies of the software, or if you modify it: responsibilities to respect the freedom of others.

For example, if you distribute copies of such a program, whether gratis or for a fee, you must pass on to the recipients the same
freedoms that you received. You must make sure that they, too, receive or can get the source code. And you must show them these

terms so they know their rights.
Developers that use the GNU GPL protect your rights with two steps: (1) assert copyright on the software, and (2) offer you this License

giving you legal permission to copy, distribute and/or modify it.
For the developers’ and authors’ protection, the GPL clearly explains that there is no warranty for this free software. For both users’ and

authors’ sake, the GPL requires that modified versions be marked as changed, so that their problems will not be attributed erroneously
to authors of previous versions.

Some devices are designed to deny users access to install or run modified versions of the software inside them, although the
manufacturer can do so. This is fundamentally incompatible with the aim of protecting users’ freedom to change the software. The
systematic pattern of such abuse occurs in the area of products for individuals to use, which is precisely where it is most unacceptable.
Therefore, we have designed this version of the GPL to prohibit the practice for those products. If such problems arise substantially
in other domains, we stand ready to extend this provision to those domains in future versions of the GPL, as needed to protect the
freedom of users.

Finally, every program is threatened constantly by software patents. States should not allow patents to restrict development and use
of software on general-purpose computers, but in those that do, we wish to avoid the special danger that patents applied to a free
program could make it effectively proprietary. To prevent this, the GPL assures that patents cannot be used to render the program non­free.

The precise terms and conditions for copying, distribution and modification follow.

TERMS AND CONDITIONS

0. Definitions.

“This License” refers to version 3 of the GNU General Public License.
“Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks.
“The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”. “Licensees”

and “recipients” may be individuals or organizations.
To “modify” a work means to copy from or adapt all or part of the work in a fashion requiring copyright permission, other than

the making of an exact copy. The resulting work is called a “modified version” of the earlier work or a work “based on” the
earlier work.

A “covered work” means either the unmodified Program or a work based on the Program.
To “propagate” a work means to do anything with it that, without permission, would make you directly or secondarily liable

for infringement under applicable copyright law, except executing it on a computer or modifying a private copy. Propagation
includes copying, distribution (with or without modification), making available to the public, and in some countries other
activities as well.

To “convey” a work means any kind of propagation that enables other parties to make or receive copies. Mere interaction with
a user through a computer network, with no transfer of a copy, is not conveying.

An interactive user interface displays “Appropriate Legal Notices” to the extent that it includes a convenient and prominently
visible feature that (1) displays an appropriate copyright notice, and (2) tells the user that there is no warranty for the work
(except to the extent that warranties are provided), that licensees may convey the work under this License, and how to view a
copy of this License. If the interface presents a list of user commands or options, such as a menu, a prominent item in the list
meets this criterion.

1. Source Code.

The “source code” for a work means the preferred form of the work for making modifications to it. “Object code” means any
non-source

form of a work.
A “Standard Interface” means an interface that either is an official standard defined by a recognized standards body, or, in the

case of interfaces specified for a particular programming language, one that is widely used among developers working in that
language.

The “System Libraries” of an executable work include anything, other than the work as a whole, that (a) is included in the
normal form of packaging a Major Component, but which is not part of that Major Component, and (b) serves only to enable
use of the work with that Major Component, or to implement a Standard Interface for which an implementation is available to
the public in source code form. A “Major Component”, in this context, means a major essential component (kernel, window
system, and so on) of the specific operating system (if any) on which the executable work runs, or a compiler used to produce
the work, or an object code interpreter used to run it.

The “Corresponding Source” for a work in object code form means all the source code needed to generate, install, and (for an
executable work) run the object code and to modify the work, including scripts to control those activities. However, it does not
include the work’s System Libraries, or general-purpose tools or generally available free programs which are used unmodified
in performing those activities but which are not part of the work. For example, Corresponding Source includes interface
definition files associated with source files for the work, and the source code for shared libraries and dynamically linked
subprograms that the work is specifically designed to require, such as by intimate data communication or control flow between
those subprograms and other parts of the work.

The Corresponding Source need not include anything that users can regenerate automatically from other parts of the
Corresponding Source.

The Corresponding Source for a work in source code form is that same work.

2. Basic Permissions.

All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the
stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output
from running a covered work is covered by this License only if the output, given its content, constitutes a covered work.
This License acknowledges your rights of fair use or other equivalent, as provided by copyright law. You may make, run and
propagate covered works that you do not convey, without conditions so long as your license otherwise remains in force. You
may convey covered works to others for the sole purpose of having them make modifications exclusively for you, or provide
you with facilities for running those works, provided that you comply with the terms of this License in conveying all material
for which you do not control copyright. Those thus making or running the covered works for you must do so exclusively on
your behalf, under your direction and control, on terms that prohibit them from making any copies of your copyrighted material
outside their relationship with you.

Conveying under any other circumstances is permitted solely under the conditions stated below. Sublicensing is not allowed;
section 10 makes it unnecessary.

3. Protecting Users’ Legal Rights From Anti-Circumvention Law.

No covered work shall be deemed part of an effective technological measure under any applicable law fulfilling obligations
under article 11 of the WIPO copyright treaty adopted on 20 December 1996, or similar laws prohibiting or restricting
circumvention of such measures.

When you convey a covered work, you waive any legal power to forbid circumvention of technological measures to the extent
such circumvention is effected by exercising rights under this License with respect to the covered work, and you disclaim any
intention to limit operation or modification of the work as a means of enforcing, against the work’s users, your or third parties’
legal rights to forbid circumvention of technological measures.

4. Conveying Verbatim Copies.

You may convey verbatim copies of the Program’s source code as you receive it, in any medium, provided that you
conspicuously and appropriately publish on each copy an appropriate copyright notice; keep intact all notices stating that this
License and any non-permissive terms added in accord with section 7 apply to the code; keep intact all notices of the absence
of any warranty; and give all recipients a copy of this License along with the Program.

You may charge any price or no price for each copy that you convey, and you may offer support or warranty protection for a
fee.

5. Conveying Modified Source Versions.

You may convey a work based on the Program, or the modifications to produce it from the Program, in the form of source code
under the terms of section 4, provided that you also meet all of these conditions:

a) The work must carry prominent notices stating that you modified it, and giving a relevant date.



b) The work must carry prominent notices stating that it is released under this License and any conditions added under



section 7. This requirement modifies the requirement in section 4 to “keep intact all notices”.
c) You must license the entire work, as a whole, under this License to anyone who comes into possession of a copy. This



License will therefore apply, along with any applicable section 7 additional terms, to the whole of the work, and all its
parts, regardless of how they are packaged. This License gives no permission to license the work in any other way, but it
does not invalidate such permission if you have separately received it.

d) If the work has interactive user interfaces, each must display Appropriate Legal Notices; however, if the Program has



interactive interfaces that do not display Appropriate Legal Notices, your work need not make them do so.

A compilation of a covered work with other separate and independent works, which are not by their nature extensions of
the covered work, and which are not combined with it such as to form a larger program, in or on a volume of a storage or
distribution medium, is called an “aggregate” if the compilation and its resulting copyright are not used to limit the access or
legal rights of the compilation’s users beyond what the individual works permit. Inclusion of a covered work in an aggregate
does not cause this License to apply to the other parts of the aggregate.

6. Conveying Non-Source Forms.

You may convey a covered work in object code form under the terms of sections 4 and 5, provided that you also convey the
machine-readable Corresponding Source under the terms of this License, in one of these ways:

a) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied



by the Corresponding Source fixed on a durable physical medium customarily used for software interchange.
b) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied



by a written offer, valid for at least three years and valid for as long as you offer spare parts or customer support for that
product model, to give anyone who possesses the object code either (1) a copy of the Corresponding Source for all the
software in the product that is covered by this License, on a durable physical medium customarily used for software
interchange, for a price no more than your reasonable cost of physically performing this conveying of source, or (2)
access to copy the Corresponding Source from a network server at no charge.

c) Convey individual copies of the object code with a copy of the written offer to provide the Corresponding Source. This



alternative is allowed only occasionally and noncommercially, and only if you received the object code with such an offer,
in accord with subsection 6b.

d) Convey the object code by offering access from a designated place (gratis or for a charge), and offer equivalent



access to the Corresponding Source in the same way through the same place at no further charge. You need not require
recipients to copy the Corresponding Source along with the object code. If the place to copy the object code is a network
server, the Corresponding Source may be on a different server (operated by you or a third party) that supports equivalent
copying facilities, provided you maintain clear directions next to the object code saying where to find the Corresponding
Source. Regardless of what server hosts the Corresponding Source, you remain obligated to ensure that it is available for
as long as needed to satisfy these requirements.

e) Convey the object code using peer-to-peer transmission, provided you inform other peers where the object code and



Corresponding Source of the work are being offered to the general public at no charge under subsection 6d. A separable
portion of the object code, whose source code is excluded from the Corresponding Source as a System Library, need not
be included in conveying the object code work.

A “User Product” is either (1) a “consumer product”, which means any tangible personal property which is normally used for
personal, family, or household purposes, or (2) anything designed or sold for incorporation into a dwelling. In determining
whether a product is a consumer product, doubtful cases shall be resolved in favor of coverage. For a particular product
received by a particular user, “normally used” refers to a typical or common use of that class of product, regardless of the
status of the particular user or of the way in which the particular user actually uses, or expects or is expected to use, the
product. A product is a consumer product regardless of whether the product has substantial commercial, industrial or non­consumer uses, unless such uses represent the only significant mode of use of the product.

“Installation Information” for a User Product means any methods, procedures, authorization keys, or other information required
to install and execute modified versions of a covered work in that User Product from a modified version of its Corresponding
Source. The information must suffice to ensure that the continued functioning of the modified object code is in no case
prevented or interfered with solely because modification has been made.

If you convey an object code work under this section in, or with, or specifically for use in, a User Product, and the conveying
occurs as part of a transaction in which the right of possession and use of the User Product is transferred to the recipient in
perpetuity or for a fixed term (regardless of how the transaction is characterized), the Corresponding Source conveyed under
this section must be accompanied by the Installation Information. But this requirement does not apply if neither you nor any
third party retains the ability to install modified object code on the User Product (for example, the work has been installed in
ROM).

The requirement to provide Installation Information does not include a requirement to continue to provide support service,
warranty, or updates for a work that has been modified or installed by the recipient, or for the User Product in which it has
been modified or installed. Access to a network may be denied when the modification itself materially and adversely affects the
operation of the network or violates the rules and protocols for communication across the network.

Corresponding Source conveyed, and Installation Information provided, in accord with this section must be in a format that is
publicly documented (and with an implementation available to the public in source code form), and must require no special
password or key for unpacking, reading or copying.

7. Additional Terms.

“Additional permissions” are terms that supplement the terms of this License by making exceptions from one or more of its
conditions. Additional permissions that are applicable to the entire Program shall be treated as though they were included in
this License, to the extent that they are valid under applicable law. If additional permissions apply only to part of the Program,
that part may be used separately under those permissions, but the entire Program remains governed by this License without
regard to the additional permissions.

When you convey a copy of a covered work, you may at your option remove any additional permissions from that copy, or
from any part of it. (Additional permissions may be written to require their own removal in certain cases when you modify the
work.) You may place additional permissions on material, added by you to a covered work, for which you have or can give
appropriate copyright permission.

Notwithstanding any other provision of this License, for material you add to a covered work, you may (if authorized by the
copyright holders of that material) supplement the terms of this License with terms:

a) Disclaiming warranty or limiting liability differently from the terms of sections 15 and 16 of this License; or



b) Requiring preservation of specified reasonable legal notices or author attributions in that material or in the Appropriate



Legal Notices displayed by works containing it; or
c) Prohibiting misrepresentation of the origin of that material, or requiring that modified versions of such material be



marked in reasonable ways as different from the original version; or
d) Limiting the use for publicity purposes of names of licensors or authors of the material; or



e) Declining to grant rights under trademark law for use of some trade names, trademarks, or service marks; or



f) Requiring indemnification of licensors and authors of that material by anyone who conveys the material (or modified



versions of it) with contractual assumptions of liability to the recipient, for any liability that these contractual assumptions
directly impose on those licensors and authors.

All other non-permissive additional terms are considered “further restrictions” within the meaning of section 10. If the Program
as you received it, or any part of it, contains a notice stating that it is governed by this License along with a term that is a
further restriction, you may remove that term. If a license document contains a further restriction but permits relicensing or
conveying under this License, you may add to a covered work material governed by the terms of that license document,
provided that the further restriction does not survive such relicensing or conveying.

If you add terms to a covered work in accord with this section, you must place, in the relevant source files, a statement of the
additional terms that apply to those files, or a notice indicating where to find the applicable terms.

Additional terms, permissive or non-permissive, may be stated in the form of a separately written license, or stated as
exceptions; the above requirements apply either way.

8. Termination.

You may not propagate or modify a covered work except as expressly provided under this License. Any attempt otherwise to
propagate or modify it is void, and will automatically terminate your rights under this License (including any patent licenses
granted under the third paragraph of section 11).

However, if you cease all violation of this License, then your license from a particular copyright holder is reinstated (a)
provisionally, unless and until the copyright holder explicitly and finally terminates your license, and (b) permanently, if the
copyright holder fails to notify you of the violation by some reasonable means prior to 60 days after the cessation.

Moreover, your license from a particular copyright holder is reinstated permanently if the copyright holder notifies you of the
violation by some reasonable means, this is the first time you have received notice of violation of this License (for any work)
from that copyright holder, and you cure the violation prior to 30 days after your receipt of the notice.

Termination of your rights under this section does not terminate the licenses of parties who have received copies or rights from
you under this License. If your rights have been terminated and not permanently reinstated, you do not qualify to receive new
licenses for the same material under section 10.

9. Acceptance Not Required for Having Copies.

You are not required to accept this License in order to receive or run a copy of the Program. Ancillary propagation of a covered
work occurring solely as a consequence of using peer-to-peer transmission to receive a copy likewise does not require
acceptance. However, nothing other than this License grants you permission to propagate or modify any covered work. These
actions infringe copyright if you do not accept this License. Therefore, by modifying or propagating a covered work, you
indicate your acceptance of this License to do so.

10. Automatic Licensing of Downstream Recipients.

Each time you convey a covered work, the recipient automatically receives a license from the original licensors, to run, modify
and propagate that work, subject to this License. You are not responsible for enforcing compliance by third parties with this
License.

An “entity transaction” is a transaction transferring control of an organization, or substantially all assets of one, or subdividing
an organization, or merging organizations. If propagation of a covered work results from an entity transaction, each party
to that transaction who receives a copy of the work also receives whatever licenses to the work the party’s predecessor in
interest had or could give under the previous paragraph, plus a right to possession of the Corresponding Source of the work
from the predecessor in interest, if the predecessor has it or can get it with reasonable efforts.

You may not impose any further restrictions on the exercise of the rights granted or affirmed under this License. For example,
you may not impose a license fee, royalty, or other charge for exercise of rights granted under this License, and you may not
initiate litigation (including a cross-claim or counterclaim in a lawsuit) alleging that any patent claim is infringed by making,
using, selling, offering for sale, or importing the Program or any portion of it.

11. Patents.

A “contributor” is a copyright holder who authorizes use under this License of the Program or a work on which the Program is
based. The work thus licensed is called the contributor’s “contributor version”.

A contributor’s “essential patent claims” are all patent claims owned or controlled by the contributor, whether already acquired
or hereafter acquired, that would be infringed by some manner, permitted by this License, of making, using, or selling its
contributor version, but do not include claims that would be infringed only as a consequence of further modification of the
contributor version. For purposes of this definition, “control” includes the right to grant patent sublicenses in a manner
consistent with the requirements of this License.

Each contributor grants you a non-exclusive, worldwide, royalty-free patent license under the contributor’s essential patent
claims, to make, use, sell, offer for sale, import and otherwise run, modify and propagate the contents of its contributor version.

In the following three paragraphs, a “patent license” is any express agreement or commitment, however denominated, not
to enforce a patent (such as an express permission to practice a patent or covenant not to sue for patent infringement). To
“grant” such a patent license to a party means to make such an agreement or commitment not to enforce a patent against the
party.

If you convey a covered work, knowingly relying on a patent license, and the Corresponding Source of the work is not
available for anyone to copy, free of charge and under the terms of this License, through a publicly available network server or
other readily accessible means, then you must either (1) cause the Corresponding Source to be so available, or (2) arrange
to deprive yourself of the benefit of the patent license for this particular work, or (3) arrange, in a manner consistent with the
requirements of this License, to extend the patent license to downstream recipients. “Knowingly relying” means you have
actual knowledge that, but for the patent license, your conveying the covered work in a country, or your recipient’s use of the
covered work in a country, would infringe one or more identifiable patents in that country that you have reason to believe are
valid.

If, pursuant to or in connection with a single transaction or arrangement, you convey, or propagate by procuring conveyance
of, a covered work, and grant a patent license to some of the parties receiving the covered work authorizing them to use,
propagate, modify or convey a specific copy of the covered work, then the patent license you grant is automatically extended
to all recipients of the covered work and works based on it.

A patent license is “discriminatory” if it does not include within the scope of its coverage, prohibits the exercise of, or is
conditioned on the non-exercise of one or more of the rights that are specifically granted under this License. You may not
convey a covered work if you are a party to an arrangement with a third party that is in the business of distributing software,
under which you make payment to the third party based on the extent of your activity of conveying the work, and under which
the third party grants, to any of the parties who would receive the covered work from you, a discriminatory patent license (a)
in connection with copies of the covered work conveyed by you (or copies made from those copies), or (b) primarily for and in
connection with specific products or compilations that contain the covered work, unless you entered into that arrangement, or
that patent license was granted, prior to 28 March 2007.

Nothing in this License shall be construed as excluding or limiting any implied license or other defenses to infringement that
may otherwise be available to you under applicable patent law.

12. No Surrender of Others’ Freedom.

If conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this
License, they do not excuse you from the conditions of this License. If you cannot convey a covered work so as to satisfy
simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not
convey it at all. For example, if you agree to terms that obligate you to collect a royalty for further conveying from those to
whom you convey the Program, the only way you could satisfy both those terms and this License would be to refrain entirely
from conveying the Program.

13. Use with the GNU Affero General Public License.

Notwithstanding any other provision of this License, you have permission to link or combine any covered work with a work
licensed under version 3 of the GNU Affero General Public License into a single combined work, and to convey the resulting
work. The terms of this License will continue to apply to the part which is the covered work, but the special requirements of
the GNU Affero General Public License, section 13, concerning interaction through a network will apply to the combination as
such.

14. Revised Versions of this License.

The Free Software Foundation may publish revised and/or new versions of the GNU General Public License from time to time.
Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.

Each version is given a distinguishing version number. If the Program specifies that a certain numbered version of the GNU
General Public License “or any later version” applies to it, you have the option of following the terms and conditions either of
that numbered version or of any later version published by the Free Software Foundation. If the Program does not specify
a version number of the GNU General Public License, you may choose any version ever published by the Free Software
Foundation.

If the Program specifies that a proxy can decide which future versions of the GNU General Public License can be used, that
proxy’s public statement of acceptance of a version permanently authorizes you to choose that version for the Program.

Later license versions may give you additional or different permissions. However, no additional obligations are imposed on any
author or copyright holder as a result of your choosing to follow a later version.

15. Disclaimer of Warranty.

THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN
OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM
“AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE
RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE
DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

16. Limitation of Liability.

IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT
HOLDER, OR ANY OTHER PARTY WHO MODIFIES AND/OR CONVEYS THE PROGRAM AS PERMITTED ABOVE, BE
LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA
OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF
THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

17. Interpretation of Sections 15 and 16.

If the disclaimer of warranty and limitation of liability provided above cannot be given local legal effect according to their terms,
reviewing courts shall apply local law that most closely approximates an absolute waiver of all civil liability in connection with
the Program, unless a warranty or assumption of liability accompanies a copy of the Program in return for a fee.

END OF TERMS AND CONDITIONS

How to Apply These Terms to Your New Programs

If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it
free software which everyone can redistribute and change under these terms.

To do so, attach the following notices to the program. It is safest to attach them to the start of each source file to most effectively state
the exclusion of warranty; and each file should have at least the “copyright” line and a pointer to where the full notice is found.

<one line to give the program’s name and a brief idea of what it does.> Copyright (C) <year> <name of author>
This program is free software: you can redistribute it and/or modify it under the terms of the GNU General Public License as

published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.
This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied

warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for
more details.

You should have received a copy of the GNU General Public License along with this program. If not, see <http://www.gnu.

org/licenses/>.
Also add information on how to contact you by electronic and paper mail.
If the program does terminal interaction, make it output a short notice like this when it starts in an interactive mode:

<program> Copyright (C) <year> <name of author> This program comes with ABSOLUTELY NO WARRANTY; for details type

`show w’. This is free software, and you are welcome to redistribute it under certain conditions; type `show c’ for details.
The hypothetical commands `show w’ and `show c’ should show the appropriate parts of the General Public License. Of course, your

program’s commands might be different; for a GUI interface, you would use an “about box”.
You should also get your employer (if you work as a programmer) or school, if any, to sign a “copyright disclaimer” for the program, if

necessary.
For more information on this, and how to apply and follow the GNU GPL, see <http://www.gnu.org/licenses/>.
The GNU General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine

library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do, use the
GNU Lesser General Public License instead of this License. But first, please read <http://www.gnu.org/philosophy/why-not-lgpl.html>.

GNU Lesser General Public License (LGPL)

Version 3, 29 June 2007

Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/>
Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.

Preamble

The GNU General Public License is a free, copyleft license for software and other kinds of works.

The licenses for most software and other practical works are designed to take away your freedom to share and change the works. By
contrast, the GNU General Public License is intended to guarantee your freedom to share and change all versions of a program--to
make sure it remains free software for all its users. We, the Free Software Foundation, use the GNU General Public License for most of
our software; it applies also to any other work released this way by its authors. You can apply it to your programs, too.

When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that
you have the freedom to distribute copies of free software (and charge for them if you wish), that you receive source code or can get it
if you want it, that you can change the software or use pieces of it in new free programs, and that you know you can do these things.

To protect your rights, we need to prevent others from denying you these rights or asking you to surrender the rights. Therefore, you
have certain responsibilities if you distribute copies of the software, or if you modify it: responsibilities to respect the freedom of others.

For example, if you distribute copies of such a program, whether gratis or for a fee, you must pass on to the recipients the same
freedoms that you received. You must make sure that they, too, receive or can get the source code. And you must show them these

terms so they know their rights.
Developers that use the GNU GPL protect your rights with two steps: (1) assert copyright on the software, and (2) offer you this License

giving you legal permission to copy, distribute and/or modify it.
For the developers’ and authors’ protection, the GPL clearly explains that there is no warranty for this free software. For both users’ and

authors’ sake, the GPL requires that modified versions be marked as changed, so that their problems will not be attributed erroneously
to authors of previous versions.

Some devices are designed to deny users access to install or run modified versions of the software inside them, although the
manufacturer can do so. This is fundamentally incompatible with the aim of protecting users’ freedom to change the software. The
systematic pattern of such abuse occurs in the area of products for individuals to use, which is precisely where it is most unacceptable.
Therefore, we have designed this version of the GPL to prohibit the practice for those products. If such problems arise substantially
in other domains, we stand ready to extend this provision to those domains in future versions of the GPL, as needed to protect the
freedom of users.

Finally, every program is threatened constantly by software patents. States should not allow patents to restrict development and use
of software on general-purpose computers, but in those that do, we wish to avoid the special danger that patents applied to a free
program could make it effectively proprietary. To prevent this, the GPL assures that patents cannot be used to render the program non­free.

The precise terms and conditions for copying, distribution and modification follow.

TERMS AND CONDITIONS

0. Definitions.

“This License” refers to version 3 of the GNU General Public License.

“Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks.

“The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”. “Licensees”

and “recipients” may be individuals or organizations.

To “modify” a work means to copy from or adapt all or part of the work in a fashion requiring copyright permission, other than

the making of an exact copy. The resulting work is called a “modified version” of the earlier work or a work “based on” the

earlier work.

A “covered work” means either the unmodified Program or a work based on the Program.

To “propagate” a work means to do anything with it that, without permission, would make you directly or secondarily liable

for infringement under applicable copyright law, except executing it on a computer or modifying a private copy. Propagation

includes copying, distribution (with or without modification), making available to the public, and in some countries other

activities as well.

To “convey” a work means any kind of propagation that enables other parties to make or receive copies. Mere interaction with

a user through a computer network, with no transfer of a copy, is not conveying.

An interactive user interface displays “Appropriate Legal Notices” to the extent that it includes a convenient and prominently

visible feature that (1) displays an appropriate copyright notice, and (2) tells the user that there is no warranty for the work

(except to the extent that warranties are provided), that licensees may convey the work under this License, and how to view a

copy of this License. If the interface presents a list of user commands or options, such as a menu, a prominent item in the list

meets this criterion.

1. Source Code.
The “source code” for a work means the preferred form of the work for making modifications to it. “Object code” means any
non-source

form of a work.
A “Standard Interface” means an interface that either is an official standard defined by a recognized standards body, or, in the

case of interfaces specified for a particular programming language, one that is widely used among developers working in that
language.

The “System Libraries” of an executable work include anything, other than the work as a whole, that (a) is included in the
normal form of packaging a Major Component, but which is not part of that Major Component, and (b) serves only to enable
use of the work with that Major Component, or to implement a Standard Interface for which an implementation is available to
the public in source code form. A “Major Component”, in this context, means a major essential component (kernel, window
system, and so on) of the specific operating system (if any) on which the executable work runs, or a compiler used to produce
the work, or an object code interpreter used to run it.

The “Corresponding Source” for a work in object code form means all the source code needed to generate, install, and (for an
executable work) run the object code and to modify the work, including scripts to control those activities. However, it does not
include the work’s System Libraries, or general-purpose tools or generally available free programs which are used unmodified
in performing those activities but which are not part of the work. For example, Corresponding Source includes interface
definition files associated with source files for the work, and the source code for shared libraries and dynamically linked
subprograms that the work is specifically designed to require, such as by intimate data communication or control flow between
those subprograms and other parts of the work.

The Corresponding Source need not include anything that users can regenerate automatically from other parts of the
Corresponding Source.

The Corresponding Source for a work in source code form is that same work.

2. Basic Permissions.
All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the
stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output
from running a covered work is covered by this License only if the output, given its content, constitutes a covered work.
This License acknowledges your rights of fair use or other equivalent, as provided by copyright law. You may make, run and
propagate covered works that you do not convey, without conditions so long as your license otherwise remains in force. You
may convey covered works to others for the sole purpose of having them make modifications exclusively for you, or provide
you with facilities for running those works, provided that you comply with the terms of this License in conveying all material
for which you do not control copyright. Those thus making or running the covered works for you must do so exclusively on
your behalf, under your direction and control, on terms that prohibit them from making any copies of your copyrighted material
outside their relationship with you.

Conveying under any other circumstances is permitted solely under the conditions stated below. Sublicensing is not allowed;
section 10 makes it unnecessary.

3. Protecting Users’ Legal Rights From Anti-Circumvention Law.
No covered work shall be deemed part of an effective technological measure under any applicable law fulfilling obligations
under article 11 of the WIPO copyright treaty adopted on 20 December 1996, or similar laws prohibiting or restricting
circumvention of such measures.

When you convey a covered work, you waive any legal power to forbid circumvention of technological measures to the extent
such circumvention is effected by exercising rights under this License with respect to the covered work, and you disclaim any
intention to limit operation or modification of the work as a means of enforcing, against the work’s users, your or third parties’
legal rights to forbid circumvention of technological measures.

4. Conveying Verbatim Copies.
You may convey verbatim copies of the Program’s source code as you receive it, in any medium, provided that you
conspicuously and appropriately publish on each copy an appropriate copyright notice; keep intact all notices stating that this
License and any non-permissive terms added in accord with section 7 apply to the code; keep intact all notices of the absence
of any warranty; and give all recipients a copy of this License along with the Program.

You may charge any price or no price for each copy that you convey, and you may offer support or warranty protection for a
fee.

5. Conveying Modified Source Versions.
You may convey a work based on the Program, or the modifications to produce it from the Program, in the form of source code
under the terms of section 4, provided that you also meet all of these conditions:

a) The work must carry prominent notices stating that you modified it, and giving a relevant date.



b) The work must carry prominent notices stating that it is released under this License and any conditions added under



section 7. This requirement modifies the requirement in section 4 to “keep intact all notices”.
c) You must license the entire work, as a whole, under this License to anyone who comes into possession of a copy. This



License will therefore apply, along with any applicable section 7 additional terms, to the whole of the work, and all its
parts, regardless of how they are packaged. This License gives no permission to license the work in any other way, but it
does not invalidate such permission if you have separately received it.

d) If the work has interactive user interfaces, each must display Appropriate Legal Notices; however, if the Program has



interactive interfaces that do not display Appropriate Legal Notices, your work need not make them do so.

A compilation of a covered work with other separate and independent works, which are not by their nature extensions of
the covered work, and which are not combined with it such as to form a larger program, in or on a volume of a storage or
distribution medium, is called an “aggregate” if the compilation and its resulting copyright are not used to limit the access or
legal rights of the compilation’s users beyond what the individual works permit. Inclusion of a covered work in an aggregate
does not cause this License to apply to the other parts of the aggregate.

6. Conveying Non-Source Forms.
You may convey a covered work in object code form under the terms of sections 4 and 5, provided that you also convey the
machine-readable Corresponding Source under the terms of this License, in one of these ways:

a) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied



by the Corresponding Source fixed on a durable physical medium customarily used for software interchange.
b) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied



by a written offer, valid for at least three years and valid for as long as you offer spare parts or customer support for that
product model, to give anyone who possesses the object code either (1) a copy of the Corresponding Source for all the
software in the product that is covered by this License, on a durable physical medium customarily used for software
interchange, for a price no more than your reasonable cost of physically performing this conveying of source, or (2)
access to copy the Corresponding Source from a network server at no charge.

c) Convey individual copies of the object code with a copy of the written offer to provide the Corresponding Source. This



alternative is allowed only occasionally and noncommercially, and only if you received the object code with such an offer,
in accord with subsection 6b.

d) Convey the object code by offering access from a designated place (gratis or for a charge), and offer equivalent



access to the Corresponding Source in the same way through the same place at no further charge. You need not require
recipients to copy the Corresponding Source along with the object code. If the place to copy the object code is a network
server, the Corresponding Source may be on a different server (operated by you or a third party) that supports equivalent
copying facilities, provided you maintain clear directions next to the object code saying where to find the Corresponding
Source. Regardless of what server hosts the Corresponding Source, you remain obligated to ensure that it is available for
as long as needed to satisfy these requirements.

e) Convey the object code using peer-to-peer transmission, provided you inform other peers where the object code and



Corresponding Source of the work are being offered to the general public at no charge under subsection 6d. A separable
portion of the object code, whose source code is excluded from the Corresponding Source as a System Library, need not
be included in conveying the object code work.

A “User Product” is either (1) a “consumer product”, which means any tangible personal property which is normally used for
personal, family, or household purposes, or (2) anything designed or sold for incorporation into a dwelling. In determining
whether a product is a consumer product, doubtful cases shall be resolved in favor of coverage. For a particular product
received by a particular user, “normally used” refers to a typical or common use of that class of product, regardless of the
status of the particular user or of the way in which the particular user actually uses, or expects or is expected to use, the
product. A product is a consumer product regardless of whether the product has substantial commercial, industrial or non­consumer uses, unless such uses represent the only significant mode of use of the product.

“Installation Information” for a User Product means any methods, procedures, authorization keys, or other information required
to install and execute modified versions of a covered work in that User Product from a modified version of its Corresponding
Source. The information must suffice to ensure that the continued functioning of the modified object code is in no case
prevented or interfered with solely because modification has been made.

If you convey an object code work under this section in, or with, or specifically for use in, a User Product, and the conveying
occurs as part of a transaction in which the right of possession and use of the User Product is transferred to the recipient in
perpetuity or for a fixed term (regardless of how the transaction is characterized), the Corresponding Source conveyed under
this section must be accompanied by the Installation Information. But this requirement does not apply if neither you nor any
third party retains the ability to install modified object code on the User Product (for example, the work has been installed in
ROM).

The requirement to provide Installation Information does not include a requirement to continue to provide support service,
warranty, or updates for a work that has been modified or installed by the recipient, or for the User Product in which it has
been modified or installed. Access to a network may be denied when the modification itself materially and adversely affects the
operation of the network or violates the rules and protocols for communication across the network.

Corresponding Source conveyed, and Installation Information provided, in accord with this section must be in a format that is
publicly documented (and with an implementation available to the public in source code form), and must require no special
password or key for unpacking, reading or copying.

7. Additional Terms.
“Additional permissions” are terms that supplement the terms of this License by making exceptions from one or more of its
conditions. Additional permissions that are applicable to the entire Program shall be treated as though they were included in
this License, to the extent that they are valid under applicable law. If additional permissions apply only to part of the Program,
that part may be used separately under those permissions, but the entire Program remains governed by this License without
regard to the additional permissions.

When you convey a copy of a covered work, you may at your option remove any additional permissions from that copy, or
from any part of it. (Additional permissions may be written to require their own removal in certain cases when you modify the
work.) You may place additional permissions on material, added by you to a covered work, for which you have or can give
appropriate copyright permission.

Notwithstanding any other provision of this License, for material you add to a covered work, you may (if authorized by the
copyright holders of that material) supplement the terms of this License with terms:

a) Disclaiming warranty or limiting liability differently from the terms of sections 15 and 16 of this License; or



b) Requiring preservation of specified reasonable legal notices or author attributions in that material or in the Appropriate



Legal Notices displayed by works containing it; or
c) Prohibiting misrepresentation of the origin of that material, or requiring that modified versions of such material be



marked in reasonable ways as different from the original version; or
d) Limiting the use for publicity purposes of names of licensors or authors of the material; or



e) Declining to grant rights under trademark law for use of some trade names, trademarks, or service marks; or



f) Requiring indemnification of licensors and authors of that material by anyone who conveys the material (or modified



versions of it) with contractual assumptions of liability to the recipient, for any liability that these contractual assumptions
directly impose on those licensors and authors.

All other non-permissive additional terms are considered “further restrictions” within the meaning of section 10. If the Program
as you received it, or any part of it, contains a notice stating that it is governed by this License along with a term that is a
further restriction, you may remove that term. If a license document contains a further restriction but permits relicensing or
conveying under this License, you may add to a covered work material governed by the terms of that license document,
provided that the further restriction does not survive such relicensing or conveying.

If you add terms to a covered work in accord with this section, you must place, in the relevant source files, a statement of the
additional terms that apply to those files, or a notice indicating where to find the applicable terms.

Additional terms, permissive or non-permissive, may be stated in the form of a separately written license, or stated as
exceptions; the above requirements apply either way.

8. Termination.

You may not propagate or modify a covered work except as expressly provided under this License. Any attempt otherwise to
propagate or modify it is void, and will automatically terminate your rights under this License (including any patent licenses
granted under the third paragraph of section 11).

However, if you cease all violation of this License, then your license from a particular copyright holder is reinstated (a)
provisionally, unless and until the copyright holder explicitly and finally terminates your license, and (b) permanently, if the
copyright holder fails to notify you of the violation by some reasonable means prior to 60 days after the cessation.

Moreover, your license from a particular copyright holder is reinstated permanently if the copyright holder notifies you of the
violation by some reasonable means, this is the first time you have received notice of violation of this License (for any work)
from that copyright holder, and you cure the violation prior to 30 days after your receipt of the notice.

Termination of your rights under this section does not terminate the licenses of parties who have received copies or rights from
you under this License. If your rights have been terminated and not permanently reinstated, you do not qualify to receive new
licenses for the same material under section 10.

9. Acceptance Not Required for Having Copies.

You are not required to accept this License in order to receive or run a copy of the Program. Ancillary propagation of a covered
work occurring solely as a consequence of using peer-to-peer transmission to receive a copy likewise does not require
acceptance. However, nothing other than this License grants you permission to propagate or modify any covered work. These
actions infringe copyright if you do not accept this License. Therefore, by modifying or propagating a covered work, you
indicate your acceptance of this License to do so.

10. Automatic Licensing of Downstream Recipients.

Each time you convey a covered work, the recipient automatically receives a license from the original licensors, to run, modify
and propagate that work, subject to this License. You are not responsible for enforcing compliance by third parties with this
License.

An “entity transaction” is a transaction transferring control of an organization, or substantially all assets of one, or subdividing
an organization, or merging organizations. If propagation of a covered work results from an entity transaction, each party
to that transaction who receives a copy of the work also receives whatever licenses to the work the party’s predecessor in
interest had or could give under the previous paragraph, plus a right to possession of the Corresponding Source of the work
from the predecessor in interest, if the predecessor has it or can get it with reasonable efforts.

You may not impose any further restrictions on the exercise of the rights granted or affirmed under this License. For example,
you may not impose a license fee, royalty, or other charge for exercise of rights granted under this License, and you may not
initiate litigation (including a cross-claim or counterclaim in a lawsuit) alleging that any patent claim is infringed by making,
using, selling, offering for sale, or importing the Program or any portion of it.

11. Patents.

A “contributor” is a copyright holder who authorizes use under this License of the Program or a work on which the Program is
based. The work thus licensed is called the contributor’s “contributor version”.

A contributor’s “essential patent claims” are all patent claims owned or controlled by the contributor, whether already acquired
or hereafter acquired, that would be infringed by some manner, permitted by this License, of making, using, or selling its
contributor version, but do not include claims that would be infringed only as a consequence of further modification of the
contributor version. For purposes of this definition, “control” includes the right to grant patent sublicenses in a manner
consistent with the requirements of this License.

Each contributor grants you a non-exclusive, worldwide, royalty-free patent license under the contributor’s essential patent
claims, to make, use, sell, offer for sale, import and otherwise run, modify and propagate the contents of its contributor version.

In the following three paragraphs, a “patent license” is any express agreement or commitment, however denominated, not
to enforce a patent (such as an express permission to practice a patent or covenant not to sue for patent infringement). To
“grant” such a patent license to a party means to make such an agreement or commitment not to enforce a patent against the
party.

If you convey a covered work, knowingly relying on a patent license, and the Corresponding Source of the work is not
available for anyone to copy, free of charge and under the terms of this License, through a publicly available network server or
other readily accessible means, then you must either (1) cause the Corresponding Source to be so available, or (2) arrange
to deprive yourself of the benefit of the patent license for this particular work, or (3) arrange, in a manner consistent with the
requirements of this License, to extend the patent license to downstream recipients. “Knowingly relying” means you have
actual knowledge that, but for the patent license, your conveying the covered work in a country, or your recipient’s use of the
covered work in a country, would infringe one or more identifiable patents in that country that you have reason to believe are
valid.

If, pursuant to or in connection with a single transaction or arrangement, you convey, or propagate by procuring conveyance
of, a covered work, and grant a patent license to some of the parties receiving the covered work authorizing them to use,
propagate, modify or convey a specific copy of the covered work, then the patent license you grant is automatically extended
to all recipients of the covered work and works based on it.

A patent license is “discriminatory” if it does not include within the scope of its coverage, prohibits the exercise of, or is
conditioned on the non-exercise of one or more of the rights that are specifically granted under this License. You may not
convey a covered work if you are a party to an arrangement with a third party that is in the business of distributing software,
under which you make payment to the third party based on the extent of your activity of conveying the work, and under which
the third party grants, to any of the parties who would receive the covered work from you, a discriminatory patent license (a)
in connection with copies of the covered work conveyed by you (or copies made from those copies), or (b) primarily for and in
connection with specific products or compilations that contain the covered work, unless you entered into that arrangement, or
that patent license was granted, prior to 28 March 2007.

Nothing in this License shall be construed as excluding or limiting any implied license or other defenses to infringement that
may otherwise be available to you under applicable patent law.

12. No Surrender of Others’ Freedom.

If conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this
License, they do not excuse you from the conditions of this License. If you cannot convey a covered work so as to satisfy
simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not
convey it at all. For example, if you agree to terms that obligate you to collect a royalty for further conveying from those to
whom you convey the Program, the only way you could satisfy both those terms and this License would be to refrain entirely
from conveying the Program.

13. Use with the GNU Affero General Public License.

Notwithstanding any other provision of this License, you have permission to link or combine any covered work with a work
licensed under version 3 of the GNU Affero General Public License into a single combined work, and to convey the resulting
work. The terms of this License will continue to apply to the part which is the covered work, but the special requirements of
the GNU Affero General Public License, section 13, concerning interaction through a network will apply to the combination as
such.

14. Revised Versions of this License.

The Free Software Foundation may publish revised and/or new versions of the GNU General Public License from time to time.
Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.

Each version is given a distinguishing version number. If the Program specifies that a certain numbered version of the GNU
General Public License “or any later version” applies to it, you have the option of following the terms and conditions either of
that numbered version or of any later version published by the Free Software Foundation. If the Program does not specify
a version number of the GNU General Public License, you may choose any version ever published by the Free Software
Foundation.

If the Program specifies that a proxy can decide which future versions of the GNU General Public License can be used, that
proxy’s public statement of acceptance of a version permanently authorizes you to choose that version for the Program.

Later license versions may give you additional or different permissions. However, no additional obligations are imposed on any
author or copyright holder as a result of your choosing to follow a later version.

15. Disclaimer of Warranty.

THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN
OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM
“AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE
RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE
DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

16. Limitation of Liability.

IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT
HOLDER, OR ANY OTHER PARTY WHO MODIFIES AND/OR CONVEYS THE PROGRAM AS PERMITTED ABOVE, BE
LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA
OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF
THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

17. Interpretation of Sections 15 and 16.

If the disclaimer of warranty and limitation of liability provided above cannot be given local legal effect according to their terms,
reviewing courts shall apply local law that most closely approximates an absolute waiver of all civil liability in connection with
the Program, unless a warranty or assumption of liability accompanies a copy of the Program in return for a fee.

END OF TERMS AND CONDITIONS

How to Apply These Terms to Your New Programs

If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it
free software which everyone can redistribute and change under these terms.

To do so, attach the following notices to the program. It is safest to attach them to the start of each source file to most effectively state
the exclusion of warranty; and each file should have at least the “copyright” line and a pointer to where the full notice is found.

<one line to give the program’s name and a brief idea of what it does.> Copyright (C) <year> <name of author>
This program is free software: you can redistribute it and/or modify it under the terms of the GNU General Public License as

published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.
This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied

warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for
more details.

You should have received a copy of the GNU General Public License along with this program. If not, see <http://www.gnu.
org/licenses/>.

Also add information on how to contact you by electronic and paper mail.
If the program does terminal interaction, make it output a short notice like this when it starts in an interactive mode:

<program> Copyright (C) <year> <name of author> This program comes with ABSOLUTELY NO WARRANTY; for details type
`show w’. This is free software, and you are welcome to redistribute it under certain conditions; type `show c’ for details.

The hypothetical commands `show w’ and `show c’ should show the appropriate parts of the General Public License. Of course, your
program’s commands might be different; for a GUI interface, you would use an “about box”.

You should also get your employer (if you work as a programmer) or school, if any, to sign a “copyright disclaimer” for the program, if
necessary.

For more information on this, and how to apply and follow the GNU GPL, see <http://www.gnu.org/licenses/>.
The GNU General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine

library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do, use the
GNU Lesser General Public License instead of this License. But first, please read <http://www.gnu.org/philosophy/why-not-lgpl.html>.
