Samsung UE40F8000ST, UE55F7000ST, UE55F8000ST, UE46F8000ST User Manual

E-MANUAL

Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at

www.samsung.com/register

Model______________ Serial No.______________

Contents

e-Manual Guide

Viewing the e-Manual

1 Scrolling a Page

1 Using the Top Icons

1 Returning to the Home Page

1 Searching the Index

2 Searching Pages

2 Closing the e-Manual

2 Jumping to a Menu Item

2 Updating the e-Manual

Connections

Aerial Connection

Video Device Connections

HDMI Connection

Programming

15 Auto Tuning

15 Antenna Connection Type

Channel Settings

16 Country (Area)

16 Manual Tuning

17 When Aerial Source is set to Air or Cable

17 Transfer Channel List

17 Delete CAM Operator Profile

18 Satellite System

20 Scanning for Satellite Channels

Channel Management

23 Remove Channels

23 Number Change

23 Channel Lock

23 Channel Unlock

23 Rename Analogue Channels

Component Connection

5 For the LED 7000 series models

5 For the LED, PDP 8000 series models

AV Connection

6 For the LED 7000 series models

6 For the LED, PDP 8000 series models

SCART Connection

Audio Device Connections

Digital Audio (Optical) Connection

ARC (Audio Return Channel)

Headphone Connection

Computer Connection

11 HDMI Connection

12 HDMI-to-DVI Connection

Smartphone Connection

Common Interface

Audio Options

Favourites Channels

26 Add Channels

27 Remove Channels

27 Rearrange the Favourites Channels List

27 Rename a Favourites Channel List

27 Copy a Favourites Channels List

Network Settings

Network Configuration

28 Wired Network

29 Wireless Network

29 Wireless Network Precautions

29 Network Security Protocols

Wired Network Setup

30 Automatic Wired Network Setup

Getting Started

Switching Between Video Sources

31 Manual Wired Network Setup

33 Failed Wired Connection

Wireless Network Setup

34 Automatic Wireless Network Setup

Using the Virtual Remote Control

51 Changing the Virtual Remote Control Panel

35 Manual Wireless Network Setup

36 WPS Button

37 Failed Wireless Connection

Checking the Network Status

Mobile Device Connection

39 Wi-Fi Direct

40 AllShare Settings

40 Set Remote Access

40 Rename the TV

Controlling TV

Smart Touch Control

41 Inserting the Batteries (AAA X 2)

41 Connecting to the TV

42 Reconnecting the Smart Touch Control

42 Battery Low Alarm

43 Buttons and Descriptions

45 Special Functions

Touchpad

46 Dragging

46 Press

47 Flicking

47 Pressing and Holding

48 Pressing and Dragging

48 Scrolling Up/Down

49 Scrolling Left/Right

49 Changing Channels by Entering Numbers

49 Numerical Input Guide

50 Adjusting the Touchpad

50 Show Status and Notification Banner

50 Recommendations

50 History

50 Deleting History Data

50 Searching

51 Change a position of the Virtual Remote Panel

52 Using the Number Panel

52 Using the Playback Control Panel

52 Using the Quick Access Panel

52 Adjusting the virtual remote control

Universal Remote Setup

53 Connecting the IR Extender

54 Add the External Device

54 Using the Universal Remote Control

54 Registered External Device Management

Entering Text using the Onscreen Keypad

55 Entering Text using the QWERTY Keypad

55 Additional Features

SMART Interaction

SMART Interaction

56 Precautions

56 Face Recognition

56 TV Camera Use

57 Motion Control

57 Voice Recognition

Voice Recognition

59 Operating Environment

59 Voice Recognition Environment Test

59 Voice Recognition Tutorial

59 Enabling Voice Recognition

60 Basic Voice Recognition Use

61 Voice Recognition Settings

61 Interactive Voice Recognition Commands

61 Deactivating Voice Recognition

Motion Control

62 Operating Environment

63 Motion Control Environment Test

63 Motion Control Tutorial

64 Motion Control Activation

64 Using the Basic Motion Controls

64 Motion Control Options

65 Motion Control Screen

65 The Screen Composition while Viewing TV

66 The Smart Hub Screen Composition

Face Recognition

68 Operating Environment

Recorded Programme Playback

82 Changing the Viewing Mode

69 Face Registration

69 Face Registration from the Smart Hub account information

screen

70 Face Registration for the Smart Hub account using face

recognition

70 Face Recognition Login

Using Peripheral Devices

71 Keyboard Connection

71 Keyboard Use

72 Mouse Connection

72 Mouse Use

TV Viewing

TV Viewing

73 Programme Info

73 Change the Broadcast Signal

73 Guide

74 Change Channels

74 Recording the Current Programme

74 Change Category

74 Quick Navigation

74 Schedule Viewing

74 Schedule Recording

74 Checking the Programme Info

75 Channel List

75 Change Channels

75 Sorting

75 Genre

75 Change the Broadcast Signal

75 Change the Channel List

82 Filtered View

82 Playlist Creation

82 Recording Lock / Unlock

83 Deleting Saved Programmes

83 Rename

83 Manage Devices

83 Playing a Different Programme

83 Programme Scan

84 Additional Recorded Programme Playback Settings

Timeshift

85 Precautions

86 Activating the Timeshift function

3D TV

87 Precautions

87 Tips

88 Activating 3D Mode

89 Setting 3D Effects

PIP

Analogue Screen Calibration

91 Fine Tune

Subtitles

92 Show Subtitles

92 Subtitle Options

92 Changing the Teletext Language

Schedule Viewing

76 Digital Channel Schedule Viewing

76 Guide

76 Programme Info

77 Analogue Channel Schedule Viewing

77 Cancel a Schedule Viewing

77 Edit Schedule List

Schedule Recording

78 Precautions

79 Dedicated Recording Device Setup

79 Plug & Play

80 Dedicated Recording Device Management

80 Programme Recording

80 Instant Recording

81 Guide

81 Programme Info

81 Specified Time and Date

81 Cancel the Schedule Recording function

81 Edit Timer List

TV Settings

Basic Picture Settings

93 Changing the Picture Mode

94 Picture Quality

94 Applying the Current Picture Quality Setting to Another

Input

95 Picture Size

96 Screen Position

96 4:3 Screen Size

96 Picture Off

96 Picture Reset

Advanced Settings

Picture Options

Basic Sound Settings

101 Changing the Sound Mode

Additional Features

113 Changing the Menu Language

102 Adjusting the Sound Settings

102 Auto Volume

102 TV Installation Type

102 3D Audio

102 Sound Reset

Sound Customiser

103 Creating Custom sound

103 Editing Custom Sound

103 Managing Custom Sounds

Speaker Settings

104 Speaker Select

104 Additional Settings

104 DTV Audio Level

105 Digital Audio Out

105 Dolby Digital Comp

105 Samsung Audio Device Connection

Clock and Timer

106 Setting the Time

106 Auto

106 Time Offset

107 Manual

107 Sleep Timer

107 On Timer

108 Off Timer

Screen Protection and Maintenance

109 Eco Solution

110 Screen Burn Protection

110 Pixel Shift

110 Auto Protection Time

111 Scrolling

111 Side Grey

111 Auto Protection Time

Password

112 Password Change

112 Programme Rating Lock

113 Game Mode

113 Precautions and Restrictions

114 BD Wise

114 Menu Transparency

114 Sound Feedback

114 Panel Locking

115 Booting Logo

115 Light Effect

115 Anti Flicker

115 DivX® Video On Demand

SMART TV Features

Smart Hub

116 Agreements Required to Use Smart Hub

117 Samsung Account

117 Creating a Samsung Account

117 Terms & Conditions, Privacy policy

118 Logging In

118 Linking a Samsung Account to Other Accounts

119 Managing Accounts

119 Resetting Smart Hub

120 Searching

120 Keyword Search

120 Setting Search Scope

120 Sports Mode

121 Status and Notification

121 Voice Recognition & Motion Control Configuration

121 Samsung Account Configuration

121 Network Configuration

121 Notification

Social

122 Social Settings

122 Checking the Application

122 Connecting a Service to a Samsung Account

123 Watching Videos

123 Friend Profile

123 Select a friend to call

123 Filters

Apps

125 Precautions

Photos, Videos & Music

138 Restrictions

126 Installing Standard Applications

126 Launching an Application

126 Samsung Apps

126 Searching for Apps

126 Installing Applications

127 Apps Management

127 Edit My Apps

128 Deleting Applications

128 Managing Application Folders

128 Application Lock/Unlock

128 Application Update

129 Fitness

129 Creating a Profile

129 Kids

130 Web Browser

130 Social Networks

130 Linking Service Accounts

131 Apps Settings

131 Auto Ticker

131 Push Notification Settings

131 Channel-Bound Apps

131 Properties

On TV

133 On TV Settings

133 On TV Setup

133 Recommendation Notice

133 Recommendation Method

133 Adult Content Block

134 Auto Start

134 Watching an On-Aerial Recommended Programme

134 Scheduled Recommended Programme Info

134 Activating the Guide

134 Programme Recommendations by Time

134 Watching Recorded Programmes

139 Supported File Formats

139 USB Device Connection

139 USB Device Removal

140 Watching Recorded Programmes

140 Playing all the Content on a Storage Device

140 Clearing the Photos, Videos & Music Screen

140 Using Networked External Storage Devices

141 Allowing DLNA Device Connections

141 AllShare

141 Exporting Contents

Video Playback

142 Changing the view mode

142 Playlist Creation

142 Opening a Different File

142 Video Scanning

143 Show Subtitles

143 Additional Video Playback Settings

Music Playback

144 Changing the view mode

144 Playlist Creation

144 Music Scanning

144 Opening a Different File

145 Additional Music Playback Settings

Photo Playback

146 Changing the view mode

146 Slideshow

146 Slideshow Settings

146 Playlist Creation

146 Opening a Different File

Movies & TV Shows

135 Sub Menus on the Bottom of the Main Screen

136 Custom Recommendations List

136 Watching Content

136 VOD Rating Lock

136 Miscellaneous

147 Background Music

147 Mini Player

147 Additional Photo Playback Settings

Anynet+ (HDMI-CEC)

148 Precautions

149 Anynet+ (HDMI-CEC) Setup

149 Anynet+ (HDMI-CEC) Use

149 Switching between Anynet+ Devices

150 Anynet+ (HDMI-CEC) Device Menu

150 ARC

Sharing Mobile Device Screens on the TV

151 MHL

151 MHL USE

151 Restrictions

152 Screen Mirroring

152 Mobile Device Connection

Teletext Feature

Anti-theft Kensington Lock

Display Resolution

167 IBM

167 MAC

168 VESA DMT

Other Information

Support

153 Remote Management

153 What is Remote Support?

154 How Does it Work?

155 e-Manual

155 Self Diagnosis

155 Picture Test

156 Sound Test

156 Voice & Motion Control Environment Check

156 Signal Information

156 Reset

157 Updating the Software

157 Update now

157 Manual Update

158 Auto update

158 Manage Satellite Channels

158 Usage Mode

158 Support Info

Data Service

159 Auto Run Data Service

159 Using Data Service

160 Main Data Service buttons and their functions

169 Picture Size and Input Signal

169 Supported 3D Resolutions

169 HDMI

170 Component

170 Digital Channel

170 Videos / Photos

170 Computer via HDMI

Subtitle and Media Contents file formats, and Codec

171 Subtitle

171 External

171 Internal

172 Supported image resolutions

172 Supported music file formats

173 Video Codec

174 Other Restrictions

174 Video Decoders

174 Audio Decoders

Restrictions

175 Requirements for Aerial Connection

176 Restrictions to PIP (Picture-in-Picture) and Dual View

176 Flexible CI

177 3D Precautions

177 CAUTION

178 SAFETY PRECAUTIONS

HbbTV

Connecting to a TV Viewing Card slot

162 To connect the CI CARD, follow these steps:

162 Using the “CI or CI+ CARD”

163 To connect the CI CARD Adapter, follow these steps:

164 Using the “CI or CI+ CARD”

WARRANTY

179 PROCEDURE FOR MAKING A WARRANTY CLAIM

179 WARRANTY CONDITIONS

Licence

Troubleshooting

Screen

Sound

3D TV

Connection

186 Aerial (Air / Cable / Satellite) Connection

186 Computer Connection

Networking

Miscellaneous

Data Service

Schedule Recording / Timeshift

Anynet+ (HDMI-CEC)

Photos, Videos & Music

Apps

Reset the Personal Info and TV settings

Web Browser

Viewing the e-Manual

The embedded e-Manual contains information about your TV's key features.

This TV has a built-in user guide. To read it, use one of the following methods:

Open the Support menu and choose e-Manual (Troubleshooting).

●

Press the E-MANUAL button on the regular remote control.

●

Press the MORE button on the Smart Touch Control to display control buttons on the screen.

●

Flick the Touchpad until e-Manual appears and select it.

"

Words in blue refer to screen menu options and words in light blue refer to remote control buttons.

"

A printable version of this guide is also available at www.samsung.com/support.

Scrolling a Page

To scroll a page, use of one of the following methods:

Press the or button on the scroll bar at the right edge of the screen.

●

Drag or flick up or down the line on either the left or right edge of the touchpad.

●

Place the focus on the or button at the right edge of the screen, drag or flick up or down

●

on the touchpad.

Using the Top Icons

Use the Back, Forward, and Opened page icons on the top left of the screen to navigate through
pages. These icons are available when two or more pages are passed.

Returning to the Home Page

To return to the home page, press the a button or select on the top right of the screen.

Searching the Index

Press the b button or select on the top right of the screen to display the index. Select a term to
display the page containing the term.

Searching Pages

Press the { button or select on the top of the screen to access the search screen. Enter a search
phrase and select Done. Select an item from the search results list to navigate to the relevant page.

Closing the e-Manual

To close the e-Manual, press and hold the RETURN button or select at the upper-right corner of
the screen or press EXIT button.

Jumping to a Menu Item

To directly jump to the menu item that is described in the current section, select
to jump from a menu item directly to the related section in the e-Manual. If you want to read an

e-Manual entry on a specific screen menu feature, press the virtual remote panel's or the regular

remote's E-MANUAL button to load the corresponding e-Manual page.

"

This feature may not be available, depending on the menu.

Try Now

. It is possible

Updating the e-Manual

Press the button to launch Smart Hub and select Apps, and then select More Apps. The e-Manual
can be updated in the same way with an application update.

On the More Apps screen, select Apps to update. Select e-Manual from the list. The e-Manual starts
updating to the latest version. However, Apps to update appears on the screen only when the update
is required.

Aerial Connection

Refer to the diagram and connect the aerial cable to the aerial input connector. Make sure that you do
not bend the cable. The number of connectors and their names and locations may vary depending on
the model.

Connect the correct aerial cable for your viewing environment (over-the-air or cable broadcasting).
However, an aerial connection is not necessary if you are using a cable box or satellite receiver.

Refer to the "Requirements for Aerial Connection" for more information.

Video Device Connections

This TV has a wide range of connectors for video input from video devices such as Blu-ray players,
DVD players, camcorders and gaming consoles. Below is a list of featured connectors shown in
descending order of picture quality.

HDMI

●

Component

●

AV

●

Connect the video device to the TV via an HDMI connector for the best picture quality. If the device
does not have an HDMI connector, try a component connector to get the next best possible picture
quality.

The number of connectors and their names and locations may vary depending on the model.

When connecting an external device, refer to the device's operating manual. The number of external
device connectors and their names and locations may vary depending on the manufacturer.

HDMI Connection

Refer to the diagram and connect the HDMI cable to the video device's HDMI output connector and the
TV's HDMI input connector. One of the following HDMI cable types is recommended:

High-Speed HDMI Cable

●

High-Speed HDMI Cable with Ethernet

●

Use an HDMI cable with a thickness of 14 mm or less. Using a non-certified HDMI cable may result in
a blank screen or a connection error.

"

Some HDMI cables and devices may not be compatible with the TV due to different HDMI specifications.

"

This TV does not support HDMI Ethernet Channel. Ethernet is a LAN (Local Area Network) built on coaxial
cables standardized by the IEEE.

"

The number of connectors and their names and locations may vary depending on the model.

Component Connection

For the LED 7000 series models

Refer to the diagram and connect the TV’s component video and audio input connectors to the
external device’s component video and audio output connectors using a component cable, so that the
connectors of the same colour connect to each other, as shown in the figure.

For the LED, PDP 8000 series models

Refer to the diagram and connect a component cable to the provided two jack-to-RCA extension
cables, so that the connectors of the same colour connect to each other. Plug the two jacks into the
TV’s component video and audio input connectors, and plug the five connectors on the other end into
the external device’s component video and audio output connectors, as shown in the figure.

AV Connection

Refer to the diagram and connect the AV cable to the TV's external input connectors and the device's
AV output connectors.

If you are using the TV's external input connectors, connect the video cable to the Y connector. Some
models feature a video connector as well. In this case, connect the cable to the video connector.

For the LED 7000 series models

For the LED, PDP 8000 series models

SCART Connection

Refer to the diagram and connect the TV’s SCART input connector to the device’s SCART output
connector using a SCART cable. An extra audio connection is not needed because SCART also carries
audio.

"

SCART can only carry standard-definition video.

"

The location of connectors may vary depending on the model.

Audio Device Connections

This TV has a wide range of connectors for audio input from devices such as amplifiers, Blu-ray
players and DVD players. For better audio quality, it is a good idea to use an AV receiver.

Digital Audio (Optical)

●

ARC (Audio Return Channel)

●

The number of connectors and their names and locations may vary depending on the model.

When connecting an external device, refer to the device's operating manual. The number of external
device connectors and their names and locations may vary depending on the manufacturer.

Digital Audio (Optical) Connection

Refer to the diagram and connect the optical cable to the TV's digital audio output connector and the
device's digital audio input connector.

Connecting the device using an optical cable does not automatically turn off the TV speakers. To turn
off the TV speakers, open the Speaker Select (Sound > Speaker Settings > Speaker Select) menu,
then set External Speaker.

Adjust the audio device's volume using its remote control.

An unusual noise coming from the audio device while it is being used may indicate a problem with the
audio device itself. If this is the case, ask for assistance from the audio device manufacturer.

5.1-channel audio for digital channels is only available with broadcasts that support 5.1-channel audio.

ARC (Audio Return Channel)

This TV supports 3D and ARC (Audio Return Channel) functions via an HDMI cable. ARC enables
digital sound to be output using just an HDMI cable. However, ARC is only available through the HDMI
(ARC) port and only when the TV is connected to an ARC-enabled AV receiver. Connect the HDMI
cable to the TV's HDMI (ARC) connector and the device's HDMI output connector.

"

Certain functions such as the Smart Hub may not be available if 3D Auto View is set to On while Source is
in HDMI mode. In this case, set 3D Auto View or 3D Mode to Off.

"

The number of connectors and their names and locations may vary depending on the model.

Headphone Connection

Refer to the diagram and connect the headphones to the headphone output connector. Only use
headphones with a 3-conductor TRS type jack. The headphone volume and the TV volume are
adjusted independently of each other. While the headphones are connected, the TV speakers are muted
and certain Sound options are deactivated.

"

The connectors names and locations may vary depending on the model.

"

The connectors may not be supported depending on the model.

Computer Connection

This SMART TV has the following computer connection ports:

HDMI

●

HDMI-to-DVI

●

For the highest picture quality, connect the computer to the HDMI/DVI port. Not all computers are
HDMI-enabled. In this case, use an HDMI-to-DVI cable to connect the computer to the TV. Refer to the
"Display Resolution" for information on the resolution settings supported by the TV.

HDMI Connection

Refer to the diagram and connect the HDMI cable to the TV's HDMI input port and the computer's
HDMI output port.

HDMI-to-DVI Connection

Refer to the diagram and connect the HDMI-to-DVI cable to the TV's HDMI (DVI) port and the
computer's DVI output port. The HDMI-to-DVI connection is available through the HDMI (DVI) port
only.

DVI cannot carry audio. To listen to the computer sound, connect the external speaker to the
computer’s audio output connector.

"

The connectors names and locations may vary depending on the model.

Smartphone Connection

This SMART TV supports MHL (Mobile High-definition Link) via an MHL cable. MHL makes it possible
to enjoy video, image, and audio files from mobile devices on your TV. However, MHL is only available
through the TV's HDMI (MHL) port and only when used in conjunction with an MHL-enabled mobile
device. Connect the MHL-to-HDMI cable to the TV's HDMI (MHL) port and the mobile device's USB
port.

"

Connecting the MHL-to-HDMI cable automatically switches Picture Size to Screen Fit. This setting will not
change automatically if you are using an HDMI adapter. In this case, change the setting manually in the
menu.

"

If you are using an HDMI adapter, the TV recognises the signal as an HDMI signal and may respond
differently than it would to an MHL-to-HDMI cable connection.

"

To use MHL function, make sure that your mobile device supports MHL and obtain a MHL cable to connect
it to the TV.

Switching Between Video Sources

Press SOURCE button to switch between devices connected to the TV.

For example, to switch to a game console connected to the second HDMI connector, press SOURCE
button. From the Source list, select HDMI2. The connector names may vary depending on the product.

Select Tools at the upper-right corner of the Source screen to access the following functions.

Refresh

●

Select this if a connected device does not appear in the list. If the list does not show the device
after selecting Refresh, check the status of the TV-to-device connection.

Edit Name

●

You can edit name of devices connected to the TV to more easily identify external sources.

With a computer connected to the TV's HDMI (DVI) port via an HDMI cable, for example, you can
change Edit Name to PC.

With a computer connected to the TV's HDMI (DVI) port via an HDMI-to-DVI cable, for example,
you can change Edit Name to DVI PC.

With an AV device connected to the TV's HDMI (DVI) port via an HDMI-to-DVI cable, for
example, you can change Edit Name to DVI Devices.

Information

●

View detailed information about the connected devices.

Disconnect USB Device

●

Remove the USB device from the list safely. This function is only available when the USB device
selected.

To add a new external device to control it with the Smart Touch Control, press the SOURCE button
and select Universal remote setup on the top right of the screen. Using the universal remote control,
users can control external devices connected to the TV, such as a settop box, Blu-ray player, and AV
receiver.

Programming

Scan and index available channels.

You can also remove channels from the index and designate favourites channels for a more convenient
TV viewing experience. Programming is not necessary if you are connected to a cable or satellite
receiver.

Auto Tuning

Screen Menu > Broadcasting > Auto Tuning

Try Now

Broadcasting

Auto Tuning

Aerial Air

Channel List

Guide

Schedule Manager

Edit Channel

Edit Favourites

"

The displayed image may differ depending on the model.

"

Some channel may not be transmitted to this television. It depends on broadcasting signal gain or
specification.

Automatically scans and indexes all channels received through the TV's aerial input connector.

To start, navigate to Broadcasting and select Auto Tuning.

1.

Select Start when prompted with a message. This initiates the Auto Tuning function. The process

2.

can take up to 30 minutes to complete. If starting the Auto Tuning function when there is an
existing index of channels overwrites the previous index.

Auto Tuning

●

Scans for channels automatically and stores them in the TV’s memory.

Cable Search Option (when the aerial was set to Cable)

●

Try Now

(Depending on the country)

Sets additional search options such as the frequency and symbol rate for a cable network search.

Try Now

Antenna Connection Type

Screen Menu > Broadcasting > Antenna Connection Type

Choose your antenna connection type Dual or Single.

"

This function is available when Aerial is set to Satellite.

Try Now

Channel Settings

Screen Menu > Broadcasting > Channel Settings

Try Now

Broadcasting

Channel Settings

Subtitle Off

Audio Options

Programme Rating Lock Allow All

Teletext Language ----

Common Interface

Channel Lock On

"

The displayed image may differ depending on the model.

Country (Area)

Screen Menu > Broadcasting > Channel Settings > Country (Area)

Try Now

Select your country so that the TV can correctly auto-tune the broadcasting channels.

"

The PIN input screen appears. Enter your 4 digit PIN number.

Digital Channel

●

Change the country for digital channels.

Analogue Channel

●

Change the country for analogue channels.

Manual Tuning

Screen Menu > Broadcasting > Channel Settings > Manual Tuning

Scans for a channel manually and stores in the TV.

"

If a channel is locked using the Channel Lock function, the PIN input window appears.

"

This function may not be supported depending on the country.

Try Now

When Aerial Source is set to Air or Cable

Digital Channel Tuning

●

Scans for a digital channel.

Select the New.

1.

"

When selecting Aerial → Air: Channel, Frequency, Bandwidth

"

When selecting Aerial → Cable: Frequency, Modulation, Symbol Rate

Select the Search. When scanning has finished, a channel is updated in the channel list.

2.

Analogue Channel Tuning

●

Scans for an analogue channel.

Select the New.

1.

Set the Programme, Colour System, Sound System, Channel and Search.

2.

Select the Store. When scanning has finished, a channel is updated in the channel list.

3.

Channel mode

P (programme mode)

●

When tuning is complete, the broadcasting stations in your area have been assigned to position
numbers from P0 to P99. You can select a channel by entering the position number in this mode.

C (aerial channel mode) / S (cable channel mode)

●

These two modes allow you to select a channel by entering the assigned number for each aerial
broadcasting station or cable channel.

Transfer Channel List

Screen Menu > Broadcasting > Channel Settings > Transfer Channel List

Imports or exports the channel map.

"

You should connect USB storage to use this function.

"

The PIN input screen appears. Enter the PIN using your remote.

Import from USB: Import channel list from USB.

●

Export to USB: Export channel list to USB. This function is available when USB is connected.

●

Now

Try Now

Try Now

Try

Delete CAM Operator Profile

Screen Menu > Broadcasting > Channel Settings > Delete CAM Operator Profile

Select the CAM operator to delete.

Try Now

Satellite System

Screen Menu > Broadcasting > Channel Settings > Satellite System

Try Now

A set of satellite dish settings must be configured for each wanted satellite before performing a
channel scan.

Satellite System is available when Aerial is set to Satellite.

"

The PIN input screen appears. Enter your 4 digit PIN number.

Satellite Selection: You can choose the satellites for this TV.

●

LNB Power: Enables or disables the power supply for the LNB.

●

LNB Settings: Configures the outdoor equipment.

●

Try Now

Try Now

Try Now

Satellite: Selects the satellite for receiving digital broadcasts.

Transponder: Selects a transponder from the list or adds a new transponder.

DiSEqC Mode: Selects DiSEqC mode for the selected LNB.

Lower LNB Oscillators: Sets the LNB oscillators to a lower frequency.

Upper LNB Oscillators: Sets the LNB oscillators to a higher frequency.

Tone 22 kHz: Selects the Tone 22 kHz depending on the LNB type. For a universal LNB it should

be Auto.

SatCR/Unicable Settings: Configure single cable installation.

●

"

SatCR is short for satellite channel router.

"

This function may not support depending on the country.

Try Now

SatCR/Unicable: Enables or disable single cable installation support.

Slot Number (Tuner 1), Slot Number (Tuner 2): Select the SatCR user slot number for this

receiver.

Slot Frequency (Tuner 1), Slot Frequency (Tuner 2): Enter the appropriate frequency to receive

the signal from SatCR.

Detect Slot Frequency: Auto-detect the signal frequency for the selected slot number.

Verify Slot Frequency: Verify that the frequency entered corresponds to the selected slot.

Positioner Settings: Configures the aerial positioner.

●

Try Now

Positioner: Enables or disables the positioned control.

Positioner Type: Sets the positioned type between DiSEqC 1.2 and USALS (Universal Satellite

Automatic Location System).

My Longitude: Sets the longitude for my location.

–

My Latitude: Sets the latitude for my location.

–

Satellite Longitude Settings: Sets the longitude of user defined satellites.

–

User Mode: Sets the position of satellite aerial according to each satellite.

If you store the current position of satellite aerial according to a certain satellite, when the signal
of that satellite is needed, the satellite aerial can be moved to pre-populated position.

Satellite: Selects the satellite to set the position for.

–

Transponder: Selects a transponder from the list for signal reception.

–

Moving Mode: Selects the movement mode between discrete and continuous movement.

–

Step Size: Adjusts the step size degrees for the aerial rotation. Step Size is available when

–

Moving Mode is set to Step.

Go To Stored Position: Rotates the aerial to the stored satellite position.

–

Aerial Position: Adjusts and stores the aerial position for the selected satellite.

–

Store Current Position: Stores current position as the selected positioner limit.

–

Installer Mode: Sets limits to the scope of movement of satellite aerial or reset the position.

Generally, installation guide uses this function.

Limit Position: Selects the direction of the positioner Limit.

–

Aerial Position: Adjusts and stores the aerial position for the selected satellite.

–

Store Current Position: Stores the current position as the selected positioner Limit.

–

Go to zero: Moves the aerial to the reference position.

–

Reset positioner limit: Allows the aerial to rotate over the full arc.

–

Reset All Settings: All satellite settings will be reset to the initial values.

●

Try Now

Scanning for Satellite Channels

Screen Menu > Broadcasting > Channel Settings > Manual Tuning

Press Scan after setting the items below.

Transponder

●

Selects the transponder.

Scan Mode

●

Selects either free or all channels to store.

Network Search

●

Enable / Disable network search.

Signal Quality

●

Display the current status of broadcasting signal.

Network Name

●

This displays the name of the network that is found.

"

Information on a satellite and its transponder is subject to change depending on the broadcasting
conditions.

"

When setting is completed, move to Search. Channel scan is started.

Channel Management

Screen Menu > Broadcasting > Edit Channel

Try Now Try Now

Broadcasting

Auto Tuning

Aerial Air

Channel List

Guide

Schedule Manager

Edit Channel

Edit Favourites

"

The displayed image may differ depending on the model.

Remove channels from the index and rename analogue channels. The Edit Channel screen icons
indicate the following:

●

●

: An analogue channel

: A favourites channel

●

: A locked channel

In the Edit Channel screen, select the Virtual Remote panel's or the regular remote's TOOLS button to
access the following options:

Sorting

●

(Digital channels only)

Change the list ordered by Name or Number.

Aerial

●

Choose between Air, Cable or Satellite.

Category

●

The TV's channel index is divided into different categories such as All, TV, Radio, Data/Other,

Analogue, Recently Viewed and Most Viewed. Choose a category.

Edit Favourites

●

Organize favourites lists to find favourite channels and switch between channels more easily.

Channel Info

●

Check the information of the channel.

Information

●

Check the information of the broadcast.

Remove Channels

Screen Menu > Broadcasting > Edit Channel

Remove registered channels from the index. Removing channels appearing in the Recently Viewed or

Most Viewed list clears the channels from the list only and does not remove them from the index.

From the screen, select the channels you wish to remove. Unselect channels by choosing them

1.

again.

Press { button. The selected channel(s) will be deleted.

2.

Number Change

Change the number of the channels in edit channels List.

Press a button to bring up the edit channels list and select the channel you wish to change the

1.

number of the channels.

Select the number you wish change. Select Done E or press touchpad to finish.

2.

Channel Lock

Screen Menu > Broadcasting > Channel Lock

You can lock channels you don't want your children to view.

Lock is only available with Channel Lock set to On.

Navigate to the Edit Channel screen, select the channels you wish to lock, press
enter the password. This locks the selected channels.

Try Now

button, and then

b

Channel Unlock

Unlock locked channels. Navigate to the Edit Channel screen, select the locked channels you wish to
unlock, press b button and then enter the password. This unlocks the selected channels.

Rename Analogue Channels

From the screen, select an analogue channel, and then select the virtual remote panel's or the regular
remote's TOOLS button. The list screen appears. Select Rename channel from the list.

You can now rename the selected channel. The new name can be up to 5 characters long.

Common Interface

Screen Menu > Broadcasting > Common Interface

Refer to the "Flexible CI" for more information.

CI Menu

●

This enables the user to select from the CAM-provided menu. Select the CI Menu based on the
menu PC Card.

CAM video transcoding

●

You can configure the setting to transcode the video codec from the CAM automatically. Turn it

Off if you do not want to use it.

"

You must use a CAM that supports transcoding the video codec.

Application Info

●

View information on the CAM inserted into the CI slot and on the “CI or CI+ CARD” which is
inserted into the CAM. You can install the CAM anytime whether the TV is on or off.

Purchase a CI CAM module at your nearest dealer or by phone.

1.

Firmly insert the “CI or CI+ CARD” into the CAM in the direction of the arrow.

2.

Insert the CAM with the “CI or CI+ CARD” into the common interface slot, in the direction of the

3.

arrow so that it aligns parallel with the slot.

Try Now

Check if you can see a picture on a scrambled signal channel.

4.

CICAM PIN Manager

●

Manage of CICAM (Common Interface Common Access Module) PIN. You can save PIN or change
stored PIN, and set other options about PIN.

Audio Options

Screen Menu > Broadcasting > Audio Options

Audio Language

●

Try Now

Try Now

(Digital channels only)

Change the default value for audio languages.

Primary audio

–

Set the primary audio language.

Secondary audio

–

Set the secondary audio language.

"

The available language may differ depending on the broadcast.

Audio Format

●

Try Now

(Digital channels only)

Change a desired audio format. The supported audio format may vary depending on the
broadcast programme.

Audio Description

●

Try Now

(Not available in all locations) (Digital channels only)

This function handles the Audio Stream for the AD (Audio Description) which is sent along with
the Main audio from the broadcaster.

"

Audio Description: Turn the audio description function on or off.

"

Volume: Adjust the audio description volume.

Favourites Channels

Screen Menu > Broadcasting > Edit Favourites

Try Now

Broadcasting

Auto Tuning

Aerial Air

Channel List

Guide

Schedule Manager

Edit Channel

Edit Favourites

"

The displayed image may differ depending on the model.

You can designate frequently watched channels as favourites. The channels assigned as a favourite
are displayed with the

symbol on the Edit Channel and channel list screens. You can create up to 5

favourites channel lists. You can also rename and edit favourites channel lists.

From the Edit Favourites screen, select the Virtual Remote panel's or the regular remote's TOOLS
button to access the following options:

Sorting: Change the list ordered by Name or Number. This function is not available on analogue

●

channel.

Aerial: Choose between Air, Cable, and Satellite.

●

Edit Channel: You can manage the channels saved on the TV.

●

Information: View detailed information about the current programme.

●

Add Channels

Add a channel to a favourites channels list.

Press a button to bring up the channel list containing the channels you wish to add and then

1.

select the channels. However, the a button is available only when the Recently Viewed or Most

Viewed channel list has one or more channel entries.

Press b button to bring up a favourites channels list and then { button to add the selected

2.

channels.

Remove Channels

Remove channels from a favourites channels list.

Press b button to bring up a favourites channels list and then select the channels you wish to

1.

remove.

Press { button to remove the channels from the list.

2.

Rearrange the Favourites Channels List

Rearrange the order of the channels in a Favourites Channels List.

Press b button to bring up the favourites channels list and select the channel you wish to move.

1.

Press a button to rearrange the order of the selected channel. Select Done E or press the

2.

touchpad to finish.

Rename a Favourites Channel List

Rename an existing favourites channels list.

Select the Virtual Remote panel's or the regular remote's TOOLS button to display the list. Select

1.

Rename Favourites from the list.

Rename the list in the popup window. The new name can be up to 20 characters long.

2.

Copy a Favourites Channels List

Copy channels from one favourites channels list to another.

Press b button to bring up a favourites channels list and select the channels you wish to copy.

1.

Select the Virtual Remote panel's or the regular remote's TOOLS button to display the list. Select

2.

Copy to Favourites from the list, and then select the favourites channels list(s) you wish to copy

to. This copies over the channels to the selected favourites channels list(s).

Network Configuration

Connecting the TV to a network gives you access to online services such as the Smart Hub and
AllShare Play, as well as software updates.

Wired Network

There are three ways to connect the TV to a Local Area Network (LAN).

External Modem

●

① IP Router + ② External Modem

●

Wall-mounted LAN Outlet

●

Wireless Network

Connect the TV to the Internet using a standard router or modem.

Wireless Network Precautions

This TV supports the IEEE 802.11a/b/g/n communication protocols. Samsung recommends using

●

IEEE 802.11n. Otherwise when you play video over a network connection, the video may not play
smoothly.

To use a wireless network, the TV must be connected to a wireless router or modem. If the

●

wireless router supports DHCP, the TV can use a DHCP or static IP address to connect to the
wireless network.

Select a channel that is not currently in use for the wireless router. If the channel set for the

●

wireless router is currently being used by another device, the result is usually interference and/or
a communications failure.

Most wireless networks have an optional security system. To enable a wireless network's security

●

system, you need to create a security key using characters and numbers. This security key is then
needed to connect to the wireless network.

Network Security Protocols

The TV only supports the following wireless network security protocols and is unable to connect to
non-certified wireless routers:

Authentication Modes: WEP, WPAPSK, WPA2PSK

●

Encryption Types: WEP, TKIP, AES

●

If the wireless router has been set to Pure High-throughput (Greenfield) 802.11n mode and the
Encryption Type to WEP or TKIP, Samsung SMART TVs will not support the connection in compliance
with the new Wi-Fi certification specifications.

If the wireless router supports WPS (Wi-Fi Protected Setup), it is possible to connect to the network
using PBC (Push Button Configuration) or a PIN (Personal Identification Number). WPS automatically
configures the SSID and WPA key settings.

Wired Network Setup

Screen Menu > Network > Network Settings

Network

Network Status

Network Settings

Wi-Fi Direct

AllShare Settings

Set Remote Access

Device Name [TV]Samsung LE...

"

The displayed image may differ depending on the model.

Try Now

Automatic Wired Network Setup

The TV's wired network connection is automatically configured when it is connected to a network that
supports DHCP.

Set Network Type to Wired and then select Connect.

1.

The TV attempts to connect to the network. A confirmation message is then shown once a

2.

connection is established. Select OK to proceed. If the attempt fails, try again or connect
manually.

Manual Wired Network Setup

If the network requires a static IP address, enter the IP address, subnet mask, gateway and DNS values
to connect to the network manually. To get the IP address, subnet mask, gateway and DNS values,
contact your Internet Service Provider (ISP). Refer to the "Dynamic versus Static IP Addresses" for
more information.

Set Network Type to Wired and then select Connect.

1.

Network Settings

Select your network type.

Network Type Wired

Connect

Plug a network cable into

the back of your TV.

Select Stop when the TV attempts to connect to the network. Once the network connection has

2.

been interrupted, select IP Settings.

Network Settings

Connection verification cancelled.

Wired network connection test stopped.

Change Network IP Settings Retry Close

From the IP Settings screen, set IP setting to Enter manually, enter IP Address, Subnet Mask,

3.

Gateway, and the DNS Server values, and then select OK.

IP Settings

IP setting Enter manually

IP Address 0.0.0.0
Subnet Mask 0.0.0.0
Gateway 0.0.0.0

DNS setting Enter manually

DNS Server 0.0.0.0

OK Cancel

The TV attempts to connect to the network again using the specified settings. A confirmation

4.

message is then shown once a connection is established. Select OK to proceed.

Failed Wired Connection

No network cable found

Make sure the network cable is plugged in. If it is connected, make sure the router is turned on. If it is
on, try turning it off and on again.

IP auto setting failed

Perform the following or set the IP address manually from IP Settings.

Ensure that the DHCP server is enabled on the router and reset the router.

1.

If this does not work, contact your Internet Service Provider for more information.

2.

Unable to connect to the network

Check the following:

Check the IP Settings.

1.

Ensure that the DHCP server is enabled on the router and unplug and then plug the router back in.

2.

If this does not work, contact your Internet Service Provider for more information.

3.

Try Now Try Now

Try Now

Try Now

Connected to a local network, but not to the Internet

Make sure that the Internet LAN cable is connected to the router's external LAN port.

1.

Check the DNS settings under IP Settings.

2.

If the problem persists, contact your Internet Service Provider.

3.

Network setup complete, but unable to connect to the Internet

If the problem persists, contact your Internet Service Provider.

Try Now

Try Now

Wireless Network Setup

Screen Menu > Network > Network Settings

Network

Network Status

Network Settings

Wi-Fi Direct

AllShare Settings

Set Remote Access

Device Name [TV]Samsung LE...

"

The displayed image may differ depending on the model.

Try Now

Automatic Wireless Network Setup

Connect the TV to the Internet via a wireless router. Check the wireless router's SSID and security
key settings before attempting to connect. The security key can be found on the wireless router's
configuration screen.

Setting Network Type to Wireless automatically displays a list of available wireless networks.

1.

Select the network (SSID) you wish to connect to. If the desired wireless router doesn't appear in

2.

the list, select Add Network and enter the network's SSID manually.

Enter the security key and select Done. If the selected network is not security-enabled, the TV will

3.

attempt a connection right away.

The TV attempts to connect to the network. A confirmation message is then shown once a

4.

connection is established. Select OK to proceed. If the attempt fails, try again or connect
manually.

Manual Wireless Network Setup

If the network requires a static IP address, enter the IP address, subnet mask, gateway and DNS values
to connect to the network manually. To get the IP address, subnet mask, gateway and DNS values,
contact your Internet Service Provider (ISP). Refer to the "Dynamic versus Static IP Addresses" for
more information.

Setting Network Type to Wireless automatically displays a list of available wireless networks.

1.

Network Settings

Select your network type.

Network Type Wireless

Wireless network

AP0000

AP0001

Add Network

Refresh WPS(PBC)

You can connect your TV to the
internet. Please select which
wireless network to use.

Select the network (SSID) you wish to connect to. If the desired wireless router doesn't appear in

2.

the list, select Add Network and enter the network's SSID manually.

Enter the security key and select Done. If the selected network is not security-enabled, the TV will

3.

attempt a connection right away.

Select Stop when the TV attempts to connect to the network. Once the network connection has

4.

been interrupted, select IP Settings.

Network Settings

Connection verification cancelled.

AP00000

Wireless network connection test stopped.

Change Network IP Settings Retry Close

From the IP Settings screen, set IP setting to Enter manually, enter IP Address, Subnet Mask,

5.

Gateway, and the DNS Server values, and then select OK.

IP Settings

IP setting Enter manually

IP Address 0.0.0.0
Subnet Mask 0.0.0.0
Gateway 0.0.0.0

DNS setting Enter manually

DNS Server 0.0.0.0

OK Cancel

The TV attempts to connect to the network again using the specified settings. A confirmation

6.

message is then shown once a connection is established. Select OK to proceed.

WPS Button

If the router has a WPS push button, you can use it to connect the TV to the router automatically. WPS
automatically configures the SSID and WPA key settings.

Setting Network Type to Wireless automatically displays a list of available wireless networks.

1.

Select WPS(PBC) and then press the router's WPS button within two minutes.

2.

The TV automatically acquires the SSID and security key settings and connects to the network. A

3.

confirmation message is then shown once a connection is established. Select OK to proceed.

Failed Wireless Connection

Wireless network connection failed, or no wireless router selected.

Go to Network Settings and select the correct router.

Unable to connect to a wireless router

Check the following:

Check that the router is turned on, and if it is, turn it off and on again.

1.

Enter the correct security key if required.

2.

IP auto setting failed

Perform the following or set the IP address manually from IP Settings.

Make sure that the DHCP server is enabled on the router and unplug and plug the router back in.

1.

Enter the correct security key if required.

2.

If this does not work, contact your Internet Service Provider for more information.

3.

Try Now

Try Now Try Now

Try Now Try Now

Unable to connect to the network

Check the following:

Check the IP Settings.

1.

Enter the correct security key if required.

2.

If this does not work, contact your Internet Service Provider for more information.

3.

Connected to a local network, but not to the Internet

Make sure that the Internet LAN cable is connected to the router's external LAN port.

1.

Check the DNS settings under IP Settings.

2.

If the problem persists, contact your Internet Service Provider.

3.

Try Now

Try Now

Network setup complete, but unable to connect to the Internet

Try Now

If the problem persists, contact your Internet Service Provider.

Dynamic versus Static IP Addresses

If the network requires a dynamic IP address, use an ADSL modem or router that supports the
Dynamic Host Configuration Protocol (DHCP). Modems and routers that support DHCP automatically
provide the IP address, subnet mask, gateway and DNS values the TV needs to access the Internet, so
they do not have to be entered manually. Most home networks use a dynamic IP address.

If the network requires a static IP address, enter the IP address, subnet mask, gateway, and DNS values
manually when setting up the network connection. To get the IP address, subnet mask, gateway and
DNS values, contact your Internet Service Provider (ISP).

If the network requires a static IP address, use an ADSL modem that supports DHCP. ADSL modems
that support DHCP also allow static IP addresses.

Checking the Network Status

Screen Menu > Network > Network Status

Try Now

Network

Network Status

Network Settings

Wi-Fi Direct

AllShare Settings

Set Remote Access

Device Name [TV]Samsung LE...

"

The displayed image may differ depending on the model.

View the current network and Internet status.

Mobile Device Connection

Network

Network Status

Network Settings

Wi-Fi Direct

AllShare Settings

Set Remote Access

Device Name [TV]Samsung LE...

"

The displayed image may differ depending on the model.

You can either directly connect a mobile device to the TV with no need for a wireless router or connect
them on the same network to play media files from the mobile device on the TV.

Wi-Fi Direct

Screen Menu > Network > Wi-Fi Direct

Connect a mobile device that supports Wi-Fi Direct to the TV without using a wireless router.

Enable Wi-Fi Direct on the mobile device and then launch Wi-Fi Direct. The TV automatically

1.

scans for and displays a list of available devices. The TV's name also appears on the mobile
device.

Select the device from the list to initiate a connection. If a connection request is made by the

2.

TV, a permission message appears on the mobile device and vice versa. Accept the request to
connect the mobile device to the TV.

Try Now

AllShare Settings

Screen Menu > Network > AllShare Settings

This TV can play media files from computers or other DLNA-enabled devices connected to the TV via
a network. Refer to the "Using Networked External Storage Devices", for more information.

In addition, this TV can be used as a display for mobile devices, including smartphones and tablets.
Refer to the "Screen Mirroring", for more information.

Set Remote Access

Screen Menu > Network > Set Remote Access

Remote access allows you to access and control your TV from other devices. You need to log in to set
this service. When it is enabled on your TV, the TV will automatically go into stand-by when you turn
it off. Energy consumption may increase as a result.

Rename the TV

Screen Menu > Network > Device Name

Assign a unique name for your TV. The assigned name appears on the external devices connected to
the TV via the network.

Try Now

Smart Touch Control

The Smart Touch Control makes it easier and more convenient to use the TV. For example, you can
use the remote control's built-in touchpad to move the focus and make selections as you would on a
computer using a mouse. In addition, you can use the virtual remote panel displayed on the screen to
change channels, play media files, and access favourites.

Inserting the Batteries (AAA X 2)

Slightly lift the battery cover by pulling the strap or using a plastic card (e.g. a credit card). Next,

1.

pull on the cover’s notch with a fingernail to remove the cover completely.

Insert 2 AAA batteries, making sure to align the positive and negative ends correctly.

2.

Align the battery cover with the back of the remote control and press down along the edges until

3.

it is cleanly attached to the remote control.

Connecting to the TV

In order to operate the TV using a Smart Touch Control, you must first pair it to the TV via Bluetooth.
However, the Smart Touch Control is only available for the paired Sam.sung TV.

When the TV is off, point the Smart Touch Control at the remote control receiver of the TV and

1.

press the TV button for the first pairing. Only this buttons sends an IR signal. The remote control
receiver's location may vary depending on the model.

A Bluetooth icon will appear at the bottom left of the screen as shown below. The TV will then

2.

attempt to connect to the Smart Touch Control automatically.

<Attempting to connect and completion icons>

Reconnecting the Smart Touch Control

If you need to reestablish the connection between the TV and the Smart Touch Control, press the
pairing button at the back of the Smart Touch Control toward the Remote receiver of the TV.

<The Smart Touch Control pairing button>

The pairing button can be accessed by removing the Smart Touch Control's battery cover. Pressing the
pairing button automatically reestablishes the connection between the control and the TV.

Battery Low Alarm

If the battery becomes and blanks low while using the Smart Touch Control, the following alarm
window blinks and appears at the bottom left of the screen. If the alarm window pops up, replace the
batteries of the Smart Touch Control. Use alkaline batteries for longer usage.

<Low battery alarm window>

Buttons and Descriptions

"

The product colour and shape may vary depending on the country or region.

Buttons Descriptions

TV

SOURCE

STB

w = v

VOICE

MUTE / AD Turns the TV sound on/off.

P

<

>

MORE

Touchpad

a, b, {, }

Turns the TV on/off.

Changes the source.

Turns on and off the satellite or cable set-top box connected to the TV. For this,
the Smart Touch Control must be configured as a universal remote control.

Adjusts the volume.

Run Voice Recognition. To speak a voice command, press and hold the VOICE
button and say a voice command.

Changes the channel.

Displays the virtual remote panel on the screen. The the virtual remote panel
consists of a number panel, a colour and playback control panel, and a quick
access panel. Use the touchpad to select numbers and buttons.

Drag your finger on the touchpad as you would on the touchpad of a laptop to
move the focus displayed on the screen. To select item, press the touchpad.

The colour buttons work differently, depending on the function that the TV is
currently performing.

RETURN / EXIT Returns to the previous menu.

SMART HUB

GUIDE

Launch Smart Hub. While an application is running, pressing the
terminates the application.

View each digital channel's programming schedule, including showtimes. In
addition, sets a Schedule Viewing or Schedule Recording to press the touchpad
on the programme entry scheduled to air later.

button

Special Functions

Press and hold the following Smart Touch Control buttons to access various special functions.

Buttons Descriptions

MUTE / AD

Touchpad

RETURN / EXIT Press and hold this button to quit the current process or app.

MORE

button

{

Press and hold this button to select Audio Description and Subtitle. (Depending
on the country or region.)

Press and hold the touchpad while watching TV to display CH List on the screen.
In addition, you can press and hold the touchpad for 2 seconds or more while an
application is running to access the application's hidden features. (Not available
with all applications.)

Press and hold the touchpad to select a desired function (e.g. MENU (m), TOOLS
(T), INFO (`), etc.) easily.

Press and hold the
current programme.

button while watching TV to view information about the

{

Touchpad

Use the touchpad to perform various commands. Navigate to Tutorial (System > Device Manager

Smart Touch Control Settings > Tutorial) to view an on-screen guide to using the Smart Touch

>

Control.

Dragging

Drag on the touchpad in the desired direction. Move the focus or the pointer in the direction the finger
is dragging.

Try Now

Press

Press on the touchpad. This selects the focused item.

Flicking

Flick on the touchpad in the desired direction. This moves the focus or scrolls the screen based on the
direction and speed of the flick.

Pressing and Holding

Press and hold the touchpad while watching TV to display CH List on the screen. In addition, you
can tap and hold the touchpad for 2 seconds or more while an application is running to access the
application's hidden features. (Not available with all applications.)

Pressing and Dragging

Press the touchpad, drag and release. This moves the selected web item in a webpage or your current
location on a map.

Scrolling Up/Down

Scroll up/down the line on either the left or right edge of the touchpad. This scrolls a webpage or a
list up/down. This scrolling feature easily accommodates both right-handed and left-handed users.

Scrolling Left/Right

Move your finger horizontally on the projected line at the top of the touchpad. You can horizontally
scroll a horizontal list or the Smart Hub panel.

Changing Channels by Entering Numbers

While watching TV, tap on the protruding line on the left or right edge of the touchpad to bring up the
numerical input window on the screen. Use your finger to enter the number for the channel you want
to watch. The recognised number is displayed on the screen and the TV switches to the corresponding
channel. However, the number you have entered may not be recognised properly by the TV. Refer to
the guide below to ensure that your numerical entries are recognised accurately.

Numerical Input Guide

Refer to the diagrams below when entering numerical values. The TV may not recognise your entries if
you do not follow the sequences shown below.

Adjusting the Touchpad

Screen Menu > System > Device Manager > Smart Touch Control Settings > Touch Sensitivity

Now

Users can adjust the sensitivity of the Smart Touch Control’s touchpad. Set Touch Sensitivity to adjust
sensitivity and make it more convenient to use.

Try

Show Status and Notification Banner

Press the MORE button on the Smart Touch Control and then select STATUS on the virtual control
panel to display the status and notification banner at the top of the screen. Refer to the "Status and
Notification" banner for more information.

Recommendations

Press the RECOMM. / SEARCH button and then select Recommended from the list displayed at the
bottom of the screen.

This shows the current / scheduled programme and application recommendations.

Select a programme that is currently airing to jump to the corresponding channel or a programme
that is scheduled to air to set up a Schedule Viewing or Schedule Recording setting. Refer to the
"Scheduled Recommended Programme Info" for more information.

Select an application to launch. Samsung Apps will launch if the selected application is not installed
on the TV. For more information, see "Samsung Apps".

History

Press the RECOMM. / SEARCH button and then select History from the list displayed at the bottom
of the screen. This displays an interactive list of recently accessed channels, media content and
applications.

"

The RECOMM. / SEARCH button may function as a History recall feature, depending on your country or
region.

Deleting History Data

Screen Menu > Smart Features > Clear viewing history > History

You can delete the history information about recently viewed channels, content and applications.

Searching

Press the RECOMM. / SEARCH button on the Smart Touch Control. The list appears at the bottom of
the screen. Press the RECOMM. / SEARCH button again. The keypad will appear on the screen. Enter
search criteria to search not only many apps and their contents on the TV but also the Web. This
button toggles between Recommended and Search.

Using the Virtual Remote Control

Press MORE button to display the virtual remote panel on the screen. The virtual remote panel consists
of a number panel, a playback control panel, and a quick access panel. Use the touchpad to select
numbers and buttons. Press and hold the MORE button. A quick access panel of virtual remote panel
appears. You can select screen buttons easily.

Changing the Virtual Remote Control Panel

Choose the number panel, playback control panel, or quick access panel as the panel to be shown on
the screen.

Use the touchpad to keep moving the focus left or right. The panel changes when the focus is moved
beyond the leftmost or rightmost edge.

Use left/right scroll function on the touchpad to change the panel easily.

Change a position of the Virtual Remote Panel

Press the MORE button on the Smart Touch Control. The virtual remote panel appears on the screen.
Press and hold the touchpad for one second. Users can change a position of the virtual remote panel
of the screen.

Using the Number Panel

Use the number panel to enter numbers on a keypad screen or webpage or to change the channel
while watching TV. Changing the channel using the number pad leaves a record, allowing you to easily
return to previous channels.

Using the Playback Control Panel

Use the playback control panel to pause, rewind, fast forward, skip to the next file, and much more
while enjoying media content.

Using the Quick Access Panel

Quickly access the INFO, MENU and e-Manual buttons. However, the availability of buttons vary
depending on the operating mode of the Smart Touch Control (with the TV only, as a universal remote,
etc.).

Adjusting the virtual remote control

Screen Menu > System > Device Manager > Smart Touch Control Settings > Onscreen Remote Size

Try Now

You can resize the virtual remote control. If the virtual remote control buttons are too small, enlarge
the remote control window before using the virtual remote control.

Universal Remote Setup

Screen Menu > System > Device Manager > Universal Remote Setup

This TV has a universal remote control feature that lets you control cable boxes, Blu-ray players, home
theatres, and other third-party external devices connected to the TV using the TV's remote control.
You can also use the Anynet+ (HDMI-CEC) function to operate Samsung external devices with your
TV's remote control without any additional setup. Refer to the "Anynet+ (HDMI-CEC)" for more
information.

Try Now

Connecting the IR Extender

Plug the cable into the TV IR connector and then point the transmitter at the other end of the cable
towards the external device's remote panel receiver. However, there can' be any obstacles between
the IR extension cable and the external device. The presence of an obstacle will interfere with the
transmission of the remote control signal.

"

The colour and design of the IR extension cable may vary depending on the model.

Add the External Device

Turn on the external device you wish to set up universal remote function for and then press

1.

SOURCE to bring up the Source screen.

Select Universal remote setup from the top of the screen. This initiates the universal remote

2.

setup process.

Follow the on-screen instructions for the Universal remote setup. If it does not respond properly,

3.

set up the remote control by entering the model number manually.

Using the Universal Remote Control

By configuring the universal remote control feature for a connector to which an external device is
already connected, you can use the Smart Touch Control as a universal remote control simply by
sending the input signals to the corresponding connector.

Registered External Device Management

From the Universal remote setup screen, select a registered external device. The following options are
available:

Source Setup

●

Change the TV's input connector that the external device is connected to.

Synced Power Off

●

Configure the external device to turn off when the TV is turned off.

Rename

●

Rename the registered external device (up to 15 characters long).

Delete

●

Delete the registered external device.

Entering Text using the Onscreen Keypad

An onscreen keypad appears when you need to enter text (entering the network password, logging
into your Samsung account, etc.), allowing you to enter text using your remote control.

Entering Text using the QWERTY Keypad

Use the QWERTY keypad as you would a normal keyboard. Simply select the letters you want to enter
them.

Additional Features

Select the icon from the keypad to access the following features:

Language

●

Select a language from the list.

Recommend text

●

Enable/disable the Recommend Text feature. Enabling the Recommend Text feature displays word
recommendations based on the entered characters. To enter the word "Internet", for example, all
you have to do is enter "In" and select the word "Internet" from the list of recommend words.

Predict Next Letter

●

Enable/disable the Text Prediction feature. Enabling the Text Prediction feature eliminates the
need to find and select individual character keys. However, this feature is limited to words that
have previously been added to the dictionary. To enter the word "Internet", for example, select
"I". A predicted word will then appear next to the I key. Simply select the predicted word to enter
"Internet".

SMART Interaction

Using this function, you can access and control menu options and functions using motions.

When using the Motion Control feature for the first time, the TV must be connected to the Internet so
that it can download the software module related to Motion Control. Users can control the TV more
easily and quickly using this feature. It takes about 15 seconds after the TV turns on to get ready for
Motion Control.

Motion Control and Face Recognition may not be available in all regions and territories.

–

Certain Samsung Smart Hub features may not be available without express consent to the

–

collection and use of personal information.

Precautions

Face Recognition

This product saves thumbnail images of users' faces for use during the Face Login. Logging into the
Smart Hub via face recognition may be less secure than logging in using an ID and password.

TV Camera Use

Under some circumstances and under certain legal conditions, the use/misuse of the TV camera may
result in legal liability. There may be obligations under local privacy laws regarding the protection of
individuals concerning personal data and on the free movement of such data, and possibly other laws
including criminal laws, regulating camera surveillance both in the workplace and elsewhere.

By using the TV camera, users agree that it will not be used (i) in locations where cameras are
generally prohibited (such as bathrooms, locker rooms or changing rooms), (ii) in any manner that will
result in an invasion of a person’s privacy or (iii) in violation of any applicable laws, regulations or
statutes.

If you are using a camera, first check the back for a sticker.

Remove the sticker cover before adjusting the TV camera angle.

When you are no longer using the camera, rotate the lens downward and secure it in place. This
prevents any inadvertent or unintentional camera operation,

Motion Control

Motion Control works by using the camera, so the user must be within the camera's recognition range.
The camera's recognition range varies depending on the ambient light level and other factors. User
may experience physical fatigue when using Motion Control for extended periods.

Voice Recognition

For the best Voice Recognition experience, we recommend that you use a Smart Touch Control.

Voice Recognition is not available in all languages, dialects or regions. The performance varies

depending on the language chosen, voice volume and ambient noise levels in the surrounding area.

Perform a Voice Recognition Environment Test prior to using Voice Recognition to test the level and
clarity and the ambient sound of the surrounding area.

Voice Text Input requires the user's agreement with any third-party app’s voice privacy policy and to
provide Samsung with the user's MAC address and other private information.

Voice Text Input lets users enter text using voice commands instead of a mouse, keyboard or remote
control. This feature is particularly useful for searching, browsing the web, and using applications that
require text input.

Voice Recognition

Screen Menu > Smart Features > Voice Recognition

Try Now

Voice Recognition

Voice Recognition On

Language UK English

Trigger Word Hi TV

Use TV Voice

Voice Recognition Environment Test

Voice Recognition Tutorial

"

The displayed image may differ depending on the model.

Voice Recognition lets you access and control specific functions of the TV using voice commands.

For the accurate recognition of voice commands, pronounce words and phrases clearly in the language
selected in Language. The TV's clock has to be set before you use Voice Recognition. Set the Clock
(System > Time > Clock).

Voice Recognition can be used in the following ways:

Using the TV's built-in microphone (from a distance)

●

Using the VOICE button (up close)

●

Ambient noise can interfere with voice recognition. If this is the case, press VOICE and then say
the command word/phrase 10cm to 15cm away from the microphone on the Smart Touch Control.
Commands may not be recognised if you speak too softly or loudly. The optimal volume is
approximately 60dB (ex: 60 dB: general conversation, 70 dB: telephone ring).

Operating Environment

Voice Recognition and the Turn TV On voice command should be used within 4m of the TV.

Perform a Voice Recognition Environment Test prior to using Voice Recognition to test the level and
clarity and the ambient sound of the surrounding area. Ambient noise can cause Voice Recognition
to malfunction. (Suitable Ambient Noise Level: Less than 40 dB, *40 dB - the sound at library or
residential area in the daytime.) Visit the Samsung website for a list of standard voice commands.

The voice recognition rate varies depending on the volume/tone, pronunciation, and ambient
environment (TV sound and ambient noise).

Voice Recognition Environment Test

Screen Menu > Smart Features > Voice Recognition > Voice Recognition Environment Test

This test determines how well Voice Recognition will work in the TV’s current environment. This test
must be performed before using Voice Recognition to make sure it functions properly.

Run the Voice Recognition Environment Test and stand within 4m of the TV.

1.

Select Start to measure the ambient noise. If the ambient noise level is suitable, the test will

2.

proceed to the next step. If this part of the test fails, remain quiet and try again.

This part of the test measures the volume and clarity of the user's voice. A command will appear

3.

on the TV's screen. Say the command loud and clear within 30 seconds. If the TV successfully
recognises the user's voice, the test proceeds to the next step. If this part of the test fails, try
again.

To measure the level of echo in the surrounding area. If the echo level is suitable, the Voice

4.

Recognition Environment Test will end.

Try Now

Voice Recognition Tutorial

Screen Menu > Smart Features > Voice Recognition > Voice Recognition Tutorial

This lets you familiarize yourself with the basics of using Voice Recognition. Run Voice Recognition

Tutorial or activate Voice Recognition.

Try Now

Enabling Voice Recognition

Say the trigger word or press VOICE button to run Voice Recognition. Say a command. You can use
Voice Recognition to operate the TV.

If Voice Recognition is not working, check see if Voice Recognition (Smart Features > Voice

Recognition > Voice Recognition) has been enabled. To use Voice Recognition, Voice Recognition

must be set to On.

"

While Voice Recognition is activated, the TV can turn on automatically due to an environmental input.

Try Now

Basic Voice Recognition Use

You can use the following commands anytime while Voice Recognition is active:

All Voice Commands: Say "Show all commands" to display a complete list of voice commands

●

by category. Say the name of a category.

Available Voice Commands: A list of basic voice commands available in the current state is

●

shown.

TV Basics

●

Adjust Volume: Say "Volume up" / "Volume down".

–

Change Channels: Say "Channel up" / "Channel down".

–

Power off: Say "TV Power Off".

–

Moving the Focus: Say "Focus left", "Focus right", "Focus up", or "Focus down" to move

–

the focus. However, these commands can only be used in situations when the focus can be
moved.

Select Item: Say "Select".

–

Apps and Services

●

A list of the words associated with the Apps and Services available in the current state is shown
as "Explore 3D", "Web Browser", "Samsung Apps".

Only preset voice commands are recognised. Available voice commands may vary, depending on the
software version.

Voice Recognition Settings

Screen Menu > Smart Features > Voice Recognition

Language: Select a language for Voice Recognition.

●

Trigger Word: Designate certain commands as trigger words. Saying a trigger word activates

●

Try Now

Voice Recognition. To turn on the TV using a voice command, say "(a trigger word) + Power On".
(Example: “Hi TV Power On")

"

Spanish commands are not available on models for sale in Turkey.

Use TV Voice: Enable / disable the TV's voice responses to your Voice Recognition commands

●

Try Now

and choose between a male and female voice.

"

This function is not supported depending on the region.

Interactive Voice Recognition Commands

Interactive Voice Recognition allows you to set up a Schedule Recording / Schedule Viewing,
access VODs, search and launch applications, and execute various other commands without having
to remember specific commands or keywords. Saying "Turn off the TV in 30 minutes," for example,
instructs the TV to turn off after 30 minutes (Sleep Timer).

Activate Interactive Voice Recognition and say a command. See the examples below:

When you don't know which channel a specific programme is on:

●

"Play <programme title>."

When you need information about a specific genre:

●

"Which *** (genre name) shows are on today?"

When you want to watch a programme featuring a specific actor or directed by a specific director:

●

"Please look up programmes featuring *** (cast member)." / "Find me works directed by ***
(director name)."

When you want to find out more information about the programme you are watching:

●

"Who are the cast members in this programme?" / “What's the title of this programme?"

When you want programme recommendations:

●

"Please recommend something to watch this evening." / "Are there any shows worth watching
today?"

When you want to operate the TV:

●

"Adjust the volume to ten." / "Change to channel **."

Deactivating Voice Recognition

To deactivate Voice Recognition, say "Close Voice Recognition".

Motion Control

Screen Menu > Smart Features > Motion Control

Motion Control

Motion Control On

Animated Motion Guide Off

Pointer Speed Medium

Motion Control Environment Test

Motion Control Tutorial

"

The displayed image may differ depending on the model.

Use Motion Control to change the channel, adjust the volume, move the pointer, and control other TV
functions.

Some applications may not support Motion Control.

Try Now

Operating Environment

Make sure that the TV camera is extended before using motion controls.

Users should be located between 1.5m and 4m from the camera. The actual recognition range may
vary depending on the camera angle and other factors.

Motion Control relies on the TV camera and therefore will not function if the camera is pointed up or
down. Adjust the camera angle using the wheel on the back of the camera. Do not point the camera
directly at the sun or any other light source or obstruct its view.

In order for the camera to recognise movement, the user has to stand out from the background.

The appropriate ambient brightness is between 50 to 500 lux. (ex: 100 Lux: bathroom, 400 Lux: living
room)

Avoid direct sunlight when using Motion Control.

Run Motion Control Environment Test to assess the camera's recognition range before using Motion
Control.

Motion Control Environment Test

Screen Menu > Smart Features > Motion Control > Motion Control Environment Test

Run this test before using Motion Control to ensure proper functionality.

Run Motion Control Environment Test and select Start within 1.5m and 4m of the TV. If light

1.

reflects on the TV screen, user can be difficult to use Motion Control.

Adjust the camera angle so that you appear inside the square displayed on the screen. Once

2.

you have finished adjusting the camera angle, wave one hand slowly from left to right. Spread
your hand out with the palm facing the TV. An arrow cursor appears on the screen when the TV
recognises the action. If recognition fails, try again.

Motion Control Tutorial

Screen Menu > Smart Features > Motion Control > Motion Control Tutorial

A fun and easy way to learn about Motion Control. Launch Motion Control and follow the guide's
instructions.

Motion Control Activation

Screen Menu > Smart Features > Motion Control > Motion Control

Try Now

Raise your hand with the palm facing the TV. Hold it for a moment and slowly wave your hand from
side to side three or four times. When your hand is successfully recognised, the Motion Control is
activated and a pointer is displayed on the screen.

"

Dropping your hand out of the range of the TV camera deactivates Motion Control. Raise your hand within 3
seconds to reactivate it.

Using the Basic Motion Controls

Available motion commands may vary, depending on what the TV is currently doing.

The following basic Motion Control commands are available:

Pointing Navigation: This action moves the cursor to the desired position.

●

Run / Select: Make a fist to select an option or execute a command. Keeping your fist clenched is

●

like holding down a remote control button.

Return: Make a circle with your hand in the counterclockwise direction to return to the previous

●

menu.

Turning over screens: Hold one palm vertical, and swing to the left or right to change the Smart

●

Hub screens.

Zoom in / Zoom out: Clench two fists, and make the gap between them wider or narrower. Use

●

these actions with webpages, maps, or photos.

Rotate: Clench two fists, and rotate them clockwise or anticlockwise as if turning a steering

●

wheel. Use these actions with photos.

Like: Without activating the Motion Control, raise and hold your thumb for 2 seconds. This

●

automatically adds Facebook's "Like" option. However, This motion is available only on the
Facebook.

Pan: While zoomed into the photo, make a fist and then move it left / right / up / down to pan.

●

Scrolling a web page: While viewing a web page, make a fist on the scroll bar, and then move it

●

up / down to scroll the page up / down.

Motion Control Options

Screen Menu > Smart Features > Motion Control

Animated Motion Guide

●

Displays an Animated Motion Guide guide when user motion is detected.

Pointer Speed

●

Set the speed of the pointer used in Motion Control.

Motion Control Screen

The Screen Composition while Viewing TV

Launching Motion Control while watching TV displays the following icons on the screen.

Icon Description

/

/

Adjust the volume.

Turns the TV sound on / off.

Changes the channel.

Check the recommended programme information and aerial times. Select a
programme from the list to view detailed information about that programme.

Launch Smart Hub.

Enter a channel number using the number panel to jump to the channel. Use the
playback control panel with the on-screen colour buttons to control a media file
that is currently playing.

Change the source.

Turn off the TV.

The Smart Hub Screen Composition

Launching Motion Control while using Smart Hub displays the following icons on the screen.

Icon Description

/

/

Adjust the volume. However, this can only be used from On TV.

Turns the TV sound on / off. However, this can only be used from On TV.

Changes the channel. However, this can only be used from On TV.

Return to the previous menu.

Check the recommended programme information and aerial times. Select a
programme from the list to view detailed information about that programme.

Enter a channel number using the number panel to jump to the channel. Use the
playback control panel with the on-screen colour buttons to control a media file
that is currently playing.

Change the source.

Turn off the TV.

Retrieving Icons on the Screen

When using Motion Control with Smart Hub, the icons will disappear automatically after two seconds
of inactivity. To retrieve the icons, move the pointer to one of the three edges shown below (marked in
blue) and then hold it there for 1 second. The icons will reappear on the screen.

Icon Description

①

②

③

/ / / /

/ /

/

Face Recognition

Users can register their faces and log into their Smart Hub accounts through Face Recognition. One
face may be registered per account. Depending on the ambient brightness level and the user's skin
tone, the TV may have difficulty recognizing the user's face. Refer to the "Samsung Account" for more
information.

Operating Environment

The user should be located between 1.5m and 4m from the camera. The actual recognition range may
vary depending on the camera angle and other factors. The appropriate ambient brightness is 50 to
500 lux. (100 Lux: Bathroom, 400 Lux: Living Room)

Face Recognition can recognise up to 5 different users at a time.

The TV may have difficulty recognising twins and people with similar faces as two different
individuals.

Note the following when using Face Recognition.

Do not cover your face with a hat, a pair of sunglasses, or your hair.

●

The user's entire face must be visible to the camera. Avoid shadows over your face. Shadows

●

prevent the camera from recognising your face accurately.

Keep your expression as neutral as possible. In addition, keep your mouth closed but at the same

●

time as neutral as possible.

Your facial expression when logging into your Samsung account must be the same as the facial

●

expression during the registration process.

Face Registration

Users can register their faces to the Smart Hub accounts. Create a new account if you do not already
have one.

Face Registration from the Smart Hub account information screen

"

Log into Smart Hub first.

Open the Smart Features > Samsung Account > Edit profile menu, and select Register face.

1.

Read the instruction, select OK, and then enter the password for the Samsung account.

2.

Select Take picture, and the user’s face appears on the screen. Keep the face to be completely

3.

in the red dotted frame. The face is successfully registered when the frame turns green. If it fails,
select Retry.

"

The user's entire face must be visible to the camera. Avoid shadows over your face. Shadows prevent
the camera from recognising your face accurately.

"

Keep your expression as neutral as possible. In addition, keep your mouth closed but at the same time
as neutral as possible.

"

It is better to select the checkbox beside I want to enter a password as well for increased security for
higher security. With the checkbox selected, the user must enter the password when logging in using
face recognition.

Select Save to finish.

4.

Face Registration for the Smart Hub account using face recognition

From the Smart Hub login window, select Face Recognition, and then select Start. The TV

1.

automatically recognises the user's face.

Select a face to register from the list, and then select Register face in the popup window.

2.

Read the instruction from the popup window, select OK, and then select the account from the list.

3.

However, a user account appears in the list if the TV has a record of the user's account and the
user is logged in.

Enter the password for the Samsung account. To make face recognition more accurate, scan the

4.

user's face again.

Select Take picture. The user’s face appears on the screen. Keep the face completely within the

5.

red round. The face is successfully registered when the round turns green. Select OK to proceed.

"

The user's entire face must be visible to the camera. Avoid shadows over your face. Shadows prevent the
camera from recognizing your face accurately.

"

Keep your expression as neutral as possible. In addition, keep your mouth closed but at the same time as
neutral as possible.

"

It is better to select the checkbox beside I want to enter a password as well for increased security for
higher security. With the checkbox selected, the user must enter the password when logging in using face
recognition.

Face Recognition Login

Select Face Registration, and then select Start from the login window. The TV automatically recognises
a user's face. If recognition fails, try again. If the password entry option has been enabled under Edit

profile, you need to enter your password as well in order to log into the Smart Hub.

"

The user's entire face must be visible to the camera. Avoid shadows over your face. Shadows prevent the
camera from recognising your face accurately.

"

Keep your expression as neutral as possible. In addition, keep your mouth closed but at the same time as
neutral as possible.

"

Once recognition succeeds, the TV logs into the Smart Hub automatically. If the TV recognises two or more
registered faces, a list of corresponding accounts appears. Select the appropriate account. Recognition of an
unregistered face prompts a warning.

Using Peripheral Devices

Device Manager

Keyboard Settings

Mouse Settings

Smart Touch Control Settings

Universal Remote Setup

"

The displayed image may differ depending on the model.

This TV can be controlled with a keyboard and a mouse instead of a remote control. These peripheral
devices make it easier and more convenient to use the TV.

Certain models do not support USB HID class keyboards and mice.

"

Some Keyboard may not support this function.

Keyboard Connection

Screen Menu > System > Device Manager > Keyboard Settings

Connect a keyboard to the TV for easier text entry. To use a USB keyboard, plug the keyboard cable
into the TV's USB port. With a Bluetooth keyboard, pair it using the TV's Bluetooth function.

Select Keyboard

●

Designate which keyboard to use. Only one keyboard can be used at a time.

Add Bluetooth Keyboard

●

View a list of Bluetooth keyboards within range. Select the keyboard you wish to use.

Keyboard Options

●

Configure the language, type and other basic keyboard settings.

Keyboard Use

Use the following keyboard keys to control the TV.

Arrows key (Moves the focus), Windows (m), Menu (TOOLS), Enter (Selects and activates), ESC

●

(RETURN), Numbers (Numbers)

Try Now

Try Now

Try Now

F1 (a), F2 (b), F3 ({), F4 (}), F5 ( ), F6 (SOURCE button), F7 (CH LIST button), F8 (MUTE button),

●

F9/F10 (w / v), F11/F12 (< / >)

Page Up / Page Down: Scroll a webpage up or down.

●

Mouse Connection

Screen Menu > System > Device Manager > Mouse Settings

Try Now

Connect a mouse to the TV and right-click on the mouse to bring up the go to screen. You can
then use the screen menu, Smart Hub, and other TV functions using the mouse as you would on a
computer.

To use a USB mouse, plug the mouse cord into the TV's USB port. To use a Bluetooth mouse, pair it
using the TV's Bluetooth function.

Select Mouse

●

Designate which mouse to use. Only one mouse may be used at a time.

Add Bluetooth Mouse

●

Try Now

View a list of Bluetooth Mouse within range. Select the mouse you wish to use.

Mouse Options

●

Configure button assignments, pointer speed and other basic mouse settings.

Try Now

Mouse Use

Left Button: Selects and activates.

●

Right Button: Brings up the go to screen, which includes options such as Power Off, Screen

●

Menu, Smart Hub, and Tools.

Mouse wheel: Scroll a webpage up or down.

●

TV Viewing

Broadcasting

Auto Tuning

Aerial Air

Channel List

Guide

Schedule Manager

Edit Channel

Edit Favourites

"

The displayed image may differ depending on the model.

Use this feature to view the programme guide and programme information more easily. However, these
features are not available when viewing TV using a cable box or satellite receiver.

Programme Info

Select the Virtual Remote panel's or press the regular remote's INFO button while watching TV to view
information about the current programme.

However, Programme Info is only available with digital channels. In order to use the Programme Info,
you must first set the TV's clock. To set the clock, navigate to Time (System > Time > Clock). The
Programme Info may vary depending on the type of incoming signal and may not be available at all
for certain programmes.

Tap on the touchpad while the programme information screen is shown to start recording the current
programme. In addition, drag left/right on the touchpad to check out other programmes or tap on the
touchpad to set up a Schedule Viewing or Schedule Recording setting for the selected programme.

"

Press and hold the { button while watching TV to view information about the current programme.

Change the Broadcast Signal

Screen Menu > Broadcasting > Aerial

Choose an aerial to receive digital broadcast signals from.

Try Now

Guide

Screen Menu > Broadcasting > Guide

View each digital channel's programming schedule, including showtimes. Check the programming
schedules and even setup a Schedule Viewing or Schedule Recording. Press GUIDE to launch the
guide.

Try Now

Change Channels

Select a channel from Guide to jump to that channel right away.

Recording the Current Programme

Highlight a programme currently being aired, and select the virtual remote panel's or the regular
remote's INFO button. The information screen appears. Select Record. Record is only available for the
programme currently being aired.

Change Category

Press b button to change the desired category.

Quick Navigation

Press a button. A popup window will open. Dragging left or right on the touchpad moves the focus
24 hours back or forward, enabling faster browsing of the programming schedule. However, the focus
cannot be on a time prior to the current time.

Schedule Viewing

Select a programme that you wish to view, and then select the Virtual Remote panel's or press the
regular remote's INFO button to display the detailed information screen. Select Schedule Viewing
from the detailed information screen to set up a Schedule Viewing. Schedule Viewing is only available
for programmes that haven't aired yet. Press { button and navigate to the Schedule Manager screen
to view a list of reserved programmes.

Schedule Recording

Select a programme that you wish to record, and then select the Virtual Remote panel's or press the
regular remote's INFO button to display the detailed information screen. Schedule Recording is only
available for programmes that haven't aired yet. Press { button and navigate to the Schedule Manager
screen to view a list of reserved programmes.

Checking the Programme Info

Highlight a programme and press INFO button. This displays detailed information about the highlighted
programme. The Programme Info may vary depending on the type of incoming signal and may not be
available at all for certain programmes.

Channel List

Screen Menu > Broadcasting > Channel List

Launch Channel List while watching TV to change channels or to check what's on other digital
channels. Press and hold the touchpad for 2 seconds. The Channel List screen appears.

The Channel List screen icons indicate the following:

●

●

●

●

●

: An analogue channel

: A favourites channel

: A Schedule Viewing reserved channel

: A Schedule Recording reserved channel

: A locked channel

Try Now

Change Channels

Select a channel to jump to it right away. To quickly scroll through the list, use the channel up/down
buttons. The focus moves up and down the list in one page.

Sorting

(Digital channels only)

Drag left on the touchpad or press the left arrow button on the remote control. Change the list ordered
by Name or Number.

Genre

Drag left on the touchpad or press the left arrow button on the remote control and then select Genre.
Select a desired TV channel genre.

Genre can only be used when the Channel List's Channel Mode is set to Added Channels. However, the
Added Channels must contain genre information.

Change the Broadcast Signal

Drag right on the touchpad or press the right arrow button on the remote control and then select a
broadcasting signal. This will change the signal source immediately.

Change the Channel List

Drag right on the touchpad or press the right arrow button on the remote control. The Favourites
list can only be selected if it contains at least one favourites channel. If no favourites channel was
previously added, select Edit Favourites and add channels from the Edit Favourites screen.

Schedule Viewing

Method 1: Screen Menu > Broadcasting > Schedule Manager

Try Now

Method 2: Select the Virtual Remote panel's or the regular remote's GUIDE button to activate Guide
screen, and then press the { button.

Broadcasting

Auto Tuning

Aerial Air

Channel List

Guide

Schedule Manager

Edit Channel

Edit Favourites

"

The displayed image may differ depending on the model.

Configure the TV to show a specific channel or programme at a specific time and date. Before
scheduling TV watching, make sure that the date and time is set properly under the System > Time >

Clock menu.

The

icon appears next to programmes that have been configured for a Schedule Viewing.

Digital Channel Schedule Viewing

Schedule Viewing for programmes on digital channels can be set up through the following two

options:

Guide

●

Programme Info

●

Guide

From Guide, select a programme you wish to view.

Programme Info

Select the Virtual Remote panel's or the regular remote's INFO button to display information about
the current programme. From the programme information screen, drag left / right on the touchpad or
press left / right button on the remote control to select a programme that has not yet aired and set up
a Schedule Viewing for it.

Analogue Channel Schedule Viewing

The Schedule Viewing function for programmes on analogue channels can be set up by specifying the
time and date.

Run Schedule Manager and then select Schedule. A popup menu will appear. Select Schedule

1.

Viewing to process.

Specify that programme's Aerial, Channel, Repeat, and Start Time and then select, OK to finish.

2.

Cancel a Schedule Viewing

To cancel a Schedule Viewing for a specific programme, select the programme from the Schedule

Manager screen. A popup menu will appear. Select Delete to cancel.

Edit Schedule List

Select an entry from the Schedule Manager screen and then select Edit from the popup menu. Edit the
settings of the selected entry.

Schedule Recording

Method 1: Screen Menu > Broadcasting > Schedule Manager

Method 2: Select the Virtual Remote panel's or the regular remote's GUIDE button to activate Guide

screen, and then press the
menu will appear. Select Schedule Recording to proceed.

Broadcasting

Auto Tuning

Aerial Air

Channel List

Guide

Schedule Manager

Edit Channel

Edit Favourites

"

The displayed image may differ depending on the model.

button to activate Schedule Manager screen. Select Schedule. A popup

{

This SMART TV is capable of recording current and future programmes onto a USB storage device for
later viewing without the use of an external recording device.

Schedule Recording is available for digital channels only. The

icon appears next to channels and

programmes that have been configured for a Schedule Recording.

You can view recordings by selecting Recorded TV of the On TV or Photos, Videos & Music.

Precautions

To set up a Schedule Recording, you must first set the TV's clock. Set the Clock from System >

●

Time > Clock.

Recordings are DRM-protected and therefore cannot be played back on a computer or on a

●

different TV. In addition, these files cannot be played back on your TV if its video circuit is
replaced.

A USB hard drive with a speed of 5,400rpm or above is recommended. However, RAID-type USB

●

hard drives are not supported.

The total recording capacity may vary depending on the amount of available hard drive space

●

and the recording quality level.

Schedule Recording requires at least 100MB of free space on the USB storage device. Recording

●

will stop if the available storage space falls below 50MB while recording is in progress.

If the available storage space falls below 500MB while the Schedule Recording and Timeshift

●

functions are in progress, only the recording will stop.

The maximum recording time is 360 minutes.

●

The TV's settings apply when playing back recordings and using the Timeshift function.

●

If the input signal is changed while recording is in progress, the screen will go blank until the

●

switch is made. Recording will resume, but will not be available.

Device Performance Test must be performed on the USB storage device connected to the TV

●

before a recording can be made. A Device Performance Test can be performed from the On TV
or Photos, Videos & Music > Recorded TV. If recording is selected from Guide or the Programme
Info and the USB storage device has failed the Device Performance Test, the TV will initiate

Format Device and conduct Device Performance Test again.

When using the recording function, the actual recording may start a second or two later than the

●

specified time.

If the Schedule Recording function is running at the same time as a recording is being made on

●

an HDMI-CEC-compliant external device, the priority is given to the Schedule Recording function.

Connecting a TV-recording USB device automatically deletes abnormally saved Timeshift and

●

recording files.

If Off Timer or Auto Power Off has been configured, the TV will override the setting if recording

●

is in progress at the specified time and turn off after the recording has ended.

Dedicated Recording Device Setup

After connecting an external storage device, it must be configured as a dedicated Recorded TV device
before the Schedule Recording and Timeshift features can be used.

Plug & Play

Press and launch Smart Hub. Select Recorded TV from the bottom of the On TV or Photos,

1.

Videos & Music screen to display a list of connected devices. Select the device you wish to use.

A popup window appears.

Select Yes . From the Format Device screen, you can format the device to a system compatible for

2.

video recording. Note that formatting the device erases all existing data.

Once formatting is complete, test the device to see if it supports the recording and Timeshift

3.

functions. Once testing is complete, the device is ready for use with the Schedule Recording
and Timeshift functions. A test failure indicates that the selected device cannot be used as a
dedicated recording device. Select a different device.

Dedicated Recording Device Management

Manage the external storage device that has been configured as the dedicated recording device.

Press and launch Smart Hub. Select Recorded TV from the bottom of the On TV or Photos,

1.

Videos & Music screen to display a list of connected devices. Select the dedicated recording

device to display the list of files stored on the device.

Select Options from the top of the screen and then Manage Devices.

2.

The following options are available from the Manage Devices screen:

Format Device: Format the external storage device to a system compatible for video recording.

●

Check Device: Check if the external storage device uses a system compatible for video recording.

●

Device Performance Test: Test the external storage device to see if it supports the recording and

●

Timeshift functions.

Default Recording Device: If there are multiple external storage devices connected to the TV, you

●

can designate a default device to use with the recording and Timeshift functions.

Programme Recording

The following options are available for programme recording:

Instant Recording

●

Guide

●

Programme Info

●

Specified Time and Date

●

Instant Recording

To record the programme currently being aired, select the virtual remote panel's or the regular remote's

button, and then set a desired recording duration.

Guide

From Guide, select a programme currently being aired, select the virtual remote panel's or the regular
remote's INFO button. You can record the selected programme. Alternatively, when you select a
programme scheduled to air later, you can reserve the recording. This function is only available with
digital channels.

Programme Info

Select the virtual remote panel's or the regular remote's INFO button. The information screen for the
program currently watching appears.

From the information screen, press the touchpad, and then you can record the programme.
Alternatively, drag left or right on the touchpad and select a programme scheduled to air later, you can
reserve the recording. This function is only available with digital channels.

Specified Time and Date

Run Schedule Manager and then select Schedule. A popup menu will appear. Select Schedule

1.

Recording to proceed.

Specify the programme's Aerial, Channel, Repeat, Start Time, and End Time and then select OK

2.

to finish.

Cancel the Schedule Recording function

To cancel a Schedule Recording for a specific programme, select the programme from the Schedule

Manager screen. A popup menu will appear. Select Delete to cancel.

Edit Timer List

Select an entry from the Schedule Manager screen and then select Edit from the popup menu. Edit the
settings of the selected entry.

Recorded Programme Playback

Press and launch Smart Hub. Select Recorded TV from the bottom of the On TV or Photos, Videos

& Music screen. Select the external storage device containing the recorded programmes to display a

list of available recordings.

Select a programme from the list or press ∂ to play the selected programme. Use the remote control or
onscreen control buttons while playing the files. Press the touchpad or TOOLS to show the on-screen
control buttons. Press RETURN to hide them.

To exit, select the virtual remote panel's or the regular remote's ∫ button or press the RETURN button.

Changing the Viewing Mode

Select View at the top of the list and then select a viewing mode. The list will be sorted in the order
corresponding to the selected viewing mode.

Filtered View

Select Filter at the top of the list and then select a filter. Only the recorded programmes corresponding
to the selected filter will be listed.

Playlist Creation

From the Options list at the top of the screen, select Play Selected. Select the programmes you wish
to play and then select Play. You can create a playlist. However, if the list is in Folder view mode, you
can only select recordings from within the same folder. To add programmes from other folders to the
playlist, change the viewing mode.

Recording Lock / Unlock

From the Options list at the top of the screen, select Lock. Select the programmes you wish to lock
and then select Lock. This locks all the selected programmes.

To unlock a programme, go to the Options list at the top of the screen and select Unlock. Select the
programmes you wish to unlock and select Unlock. This unlocks all selected programmes.

Deleting Saved Programmes

From the Options list at the top of the screen, select Delete. Select all the programmes you wish to
delete and select Delete. This deletes all selected programmes.

Rename

From the Options list at the top of the screen, select Rename. Select the programme you wish to
rename. Enter the new name using the keypad and then select Done to finish renaming the programme.
The new name can be up to 29 characters long.

Manage Devices

Designate a device connected to the TV as a dedicated recording device.

Playing a Different Programme

Select the € / ‚ on-screen button.

●

Select the Search on-screen button and then Search Titles.

●

Programme Scan

Drag left/right on the touchpad. Scan 10 seconds backward or forward.

●

Press † / …. You can change the playback speed by a factor of up to 7. To restore normal

●

playback speed, press ∂. Alternatively, press … while paused to reduce the playback speed (1/8,
1/4, 1/2). Slow playback doesn't support audio and is available in the forward direction only.

Press ∑ to pause the screen and then ∑ to scan through the paused video in 1-frame increments.

●

Audio is not supported while the video is paused.

Select the Search on-screen button and then Search Scene. You can play the file from a

●

particular scene. However, this function is not available with the following.

Scene thumbnails are not created.

–

Only sound is recorded.

–

The recording time is under 60 seconds.

–

Select the Search on-screen button and then select Search Time Bar. This lets you skip to the

●

specified time frame.

Select the € on-screen button. This plays the video from the beginning.

●

Additional Recorded Programme Playback Settings

Repeat

●

Select the Repeat on-screen button. This changes the repeat mode. Repeat One repeats the
current programme only. Repeat All repeats all programmes contained in the folder.

Audio Language

●

Select a language from the list.

Picture Size

●

Select the Picture Size on-screen button and then select the picture size.

Receiver

●

Select the Receiver on-screen button and then power on the receiver.

Picture Mode

●

Select the Settings on-screen button and then select Picture Mode. Select the Picture Mode
setting.

Sound Mode

●

Select the Settings on-screen button and then select Sound Mode. Select the Sound Mode
setting.

Information

●

In the Screen Control button, select Settings and Information. You can view more detailed
information about the current programme.

Timeshift

Timeshift temporarily records the current programme. Using this feature, users can pause and resume
a live programme and even scan through it backward or forward. However, Timeshift is only available
for digital channels. In addition, activating the Timeshift function, only certain function disable in

Broadcasting Menu.

Precautions

Recordings are DRM-protected and therefore cannot be played back on a computer or on a

●

different TV. In addition, these files cannot be played back on your TV if its video circuit is
replaced.

The maximum amount of time available for the Timeshift function is 90 minutes.

●

The Timeshift function is not available for locked channels.

●

A USB hard drive with a speed of 5,400rpm or above is recommended. However, RAID-type USB

●

hard drives are not supported.

Device Performance Test must be performed on the USB storage device connected to the TV

●

before the Timeshift function can be used. Device Performance Test can be initiated from Smart

Hub > On TV or Photos, Videos & Music > Recorded TV.

The total recording capacity may vary depending on the amount of available hard drive space

●

and the recording quality level.

The TV's settings apply when playing back recordings and using the Timeshift function.

●

Connecting a TV-recording USB device automatically deletes abnormally saved Timeshift and

●

recording files.

The Timeshift function may terminate automatically once it reaches its maximum capacity.

●

The Timeshift function requires at least 1.5GB of free space available on the USB storage device.

●

Launching an application, switching to an analogue channel, and otherwise changing the TV

●

to a state that does not support the Timeshift function automatically terminates the Timeshift
function. The Timeshift operation will resume if the TV is changed back to a digital channel
again.

Activating the Timeshift function

Press ∂ while watching TV to activate the Timeshift function. The Timeshift Progress Bar appears on
the screen.

The Timeshift control buttons and functions are as follows:

/ …: You can change the playback speed by a factor of up to 7. To restore normal playback

●

†

speed, press ∂ button.

Drag left / right on the touchpad. Scan 10 seconds backward or forward.

●

: Press while viewing a Timeshift segment to return to real time. Press while in real-time viewing

●

∫

mode to deactivate the Timeshift function.

: Pause the screen. Press ∑ button while in the paused state to scan one paused frame at a time.

●

∑

Audio is not available when the TV is paused in Timeshift mode, and frame-by-frame scanning
is only available in the forward direction. Press † / … button while in the paused state to resume
playback at 1/4th the normal speed.

3D TV

Screen Menu > Picture > 3D

Try Now

3D

3D Mode

3D Perspective 0

Depth 5

L/R Change L/R Image

3D → 2D Off

3D Auto View On

3D Light Control Low

"

The displayed image may differ depending on the model.

This TV is 3D-enabled. For the best 3D viewing experience, users must wear Samsung's 3D Active
Glasses.

The ideal viewing distance is three times or more the height of the screen. We also recommend sitting
with your eyes level with the screen.

Precautions

Carefully read the health and safety information concerning 3D viewing before viewing the TV in 3D.

Refer to the "3D Precautions", for more information.

Tips

The left and right 3D images may initially overlap when the TV is turned on. It takes a moment

●

for the display to optimize and the overlapping to go away.

The 3D Active Glasses may not work properly if there is another 3D product or electronic device

●

turned on near the glasses or TV. If there is a problem, keep other electronic devices as far away
as possible from the 3D Active Glasses.

Whether or not 3D video is displayed in true HD is usually determined by the quality of the

●

content.

Activating 3D Mode

Screen Menu > Picture > 3D > 3D Mode

Try Now

Choose a 3D mode according to the input signal. Available 3D modes may vary depending on the
input signal. Some 3D contents may differ preferred 3D mode. In this case, change the desired 3D
mode for watching. Select a 3D mode from the available 3D modes depending on the input signal.

"

Available 3D modes may vary depending on the input signal.

●

●

●

●

●

●

●

●

Off: Deactivates 3D viewing.

Normal: Converts normal images to 3D images. Some formats do not support this mode.

L/R: Splits a single image into left and right overlapping images to create the 3D effect.

T/B: Splits a single image into top and bottom overlapping images to create the 3D effect.

Horizontal Line: Switches between left and right images one horizontal line at a time.

Vertical Line: Switches between left and right images one vertical line at a time.

Pixel: Switches between left and right images one pixel at a time.

Frame: Switches between left and right images one frame at a time.

"

(Horizontal Line), (Vertical Line), and (Pixel) can only be selected when the computer's resolution

is set to 1920x1080 or the computer is connected to the TV via an HDMI-DVI cable.

"

(Frame) can only be selected when the computer's resolution is set to 1920x1080 and the frequency to

60Hz.

Resolutions supported by the TV may vary, depending on the 3D mode. Refer to the "Supported 3D
Resolutions" for more information.

Setting 3D Effects

There are several adjustments that can be made to make 3D content more enjoyable.

3D Perspective

●

Adjusts the 3D perspective.

Depth

●

Adjusts the 3D depth. This option cannot be used if 3D mode is set to

Now

L/R Change

●

Swaps the left and right pictures.

3D → 2D

●

Try Now

(L/R) or (T/B).

Try Now

Converts 3D images to normal images. This function is not available if 3D mode is set to
(Normal) or (Off).

3D Auto View

●

Try Now

Setting 3D Auto View to On switches the TV to 3D automatically. Setting 3D Auto View
to Message Alert brings up a message screen when the TV receives a 3D signal. If some
applications are running, The TV can not switch 3D. In this case, close the application and then
watch the 3D. This mode is available for LED TVs only.

3D Light Control

●

Adjust the brightness of 3D images. If the screen is too dark, select High. This mode is available
for LED TVs only.

Try

PIP

Screen Menu > Picture > PIP

Try Now


3D

PIP Off

Advanced Settings

Picture Options

Picture Off

Apply Picture Mode All Source

Reset Picture

"

The displayed image may differ depending on the model.

When watching a 2D video from an external device connected to the TV, users can still watch TV in an
inset window. Open the Picture menu and choose PIP. Turn on PIP to activate it, and set any necessary
options. PIP is not available while the Smart Hub or 3D TV is active. Turning off the TV while PIP is
active automatically deactivates PIP. Refer to the "Restrictions to PIP (Picture-in-Picture) and Dual
View" for more information.

PIP: Activates/deactivates PIP.

●

Aerial: Selects the PIP sub-picture broadcast signal.

●

Channel: Selects the PIP sub-picture channel.

●

Size: Selects the PIP sub-picture size.

●

Position: Selects the PIP sub-picture position.

●

Sound Select: Selects the audio source.

●

"

Playing a game or using the karaoke feature on the main screen can result in a lower PIP picture quality.

"

To watch TV as a picture-in-picture, the main screen's source must be set to Component or HDMI. The
PIP window supports TV signals only.

Analogue Screen Calibration

Channel Settings

Country (Area)

Manual Tuning

Fine Tune

Transfer Channel List

Delete CAM Operator Profile

Satellite System

"

The displayed image may differ depending on the model.

Analogue pictures can become shaky and full of noise. If this happens, you can fine tune the signal
and/or reduce noise to clear up the picture.

Fine Tune

Screen Menu > Broadcasting > Channel Settings > Fine Tune

Clear up shaky pictures. Fine tune the pictures until they are clear and then select Save or Close.
Select Reset to reset the Fine Tune operation. This option is only available for analogue broadcasts.

Try Now

Subtitles

Screen Menu > Broadcasting > Subtitle

Broadcasting

Channel Settings

Subtitle Off

Audio Options

Programme Rating Lock Allow All

Teletext Language ----

Try Now

Common Interface

Channel Lock On

"

The displayed image may differ depending on the model.

View subtitles along with subtitle-enabled digital and analogue broadcasts.

Show Subtitles

Screen Menu > Broadcasting > Subtitle > Subtitle

Show subtitles. Subtitles will be displayed when you choose a broadcast that supports subtitles.

Switches subtitles On or Off.

Subtitle Mode

●

Sets the subtitle mode.

Subtitle Language

●

Sets the subtitle language.

"

DVD Subtitles are only available when connected to an external input connector.

Try Now

Try Now

Try Now

Subtitle Options

Screen Menu > Broadcasting > Subtitle

Select a subtitle mode. The list of modes may vary depending on the broadcast.

Primary Subtitle

●

Set the primary subtitle language.

Try Now

Secondary Subtitle

●

Set the secondary subtitle language.

Try Now

Changing the Teletext Language

Screen Menu > Broadcasting > Teletext Language

Use this to set the teletext language.

Try Now
