Samsung U32D970 User Manual

UHD Monitor

User Manual

U32D970

The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.

BN46-00430A-01

Table of contents

Before Using the Product

Securing the Installation Space 6

Precautions for storage 6

Safety Precautions 6

Symbols 6 Cleaning 7 Electricity and Safety 7 Installation 8 Operation 10

Correct posture to use the product 12

Preparations

Checking the Components 13

Components 13

Parts 14

Front Buttons 14 Reverse Side 16

Installation 17

Installing a Wall-mount Kit or Desktop Stand 18 Adjusting the Product Tilt and Height 20 Rotating the Monitor Screen 20 Anti-theft Lock 21

MagicRotation Auto 22

Software Installation 22 Caution 22

Rotating the monitor 23

Caution 23

Using NCE(Natural Color Expert)

What is Monitor Calibration? 24

Supported calibrators 24

What is NCE (Natural Color Expert)? 25

NCE Program Installation/Uninstallation 25

Starting NCE (Natural Color Expert) 26

Connecting the Calibrator 26

Features of the NCE Program 27

Layout and Menu Items on the NCE Home Screen 27

Layout and Menu Items on the Uniformity Screen 28

Overview and Functions of the Verification Screen 28

Starting Calibration 29

Connecting and Using a Source Device

Before Connecting 34

Pre-connection Checkpoints 34

Connecting and Using a PC 34

Connection using a Dual-link DVI cable 34

Connection Using the HDMI Cable 35 Connection Using the DP Cable 35 Connecting to Headphones or Speakers 36 Connecting the Power 36 Tidying Up the Connected Cables 37

Connecting the Product to a PC as a USB HUB 38

Connecting a PC to the Product 38 Utilizing the Product as a USB HUB 39

Driver Installation 40

Setting Optimum Resolution 40

Screen Setup

Color Mode 41

Configuring Color Mode (with a PC connected) 41 Configuring Color Mode (with AV connected) 42

Brightness 43

Configuring Brightness 43

Contrast 44

Configuring Contrast 44

Sharpness 45

Configuring Sharpness 45

Color 46

Configuring Color 46

Dual Color Mode 47

Configuring Dual Color Mode 47

Table of contents

Response Time 48

Configuring the Response Time 48

View Calibration Values 49

Viewing calibration settings 49

HDMI Black Level 50

Configuring the HDMI Black Level Settings 50

Reset Color Mode 51

Configuring Reset Color Mode 51

Screen Adjustment

Image Size 52

Changing the Image Size 52

H-Position & V-Position 54

Configuring H-Position & V-Position 54

PIP/PBP 55

Configuring PIP/PBP Mode 56 Configuring Size 57 Configuring Position 58 Configuring Sound Source 59 Configuring Source 61 Configuring Image Size 64 Configuring Contrast&Color 66

Coordinating OSD

Language 68

Configuring Language 68

Display Time 69

Configuring Display Time 69

Setup and Reset

Eco Saving 70

Configuring Eco Saving 70

USB Super Charging 71

Configuring USB Super Charging 71

PC/AV Mode 72

Configuring PC/AV Mode 72

DisplayPort Ver. 73

Configuring DisplayPort Ver. 73

Source Detection 74

Configuring Source Detection 74

Key Repeat Time 75

Configuring Key Repeat Time 75

Off Timer 76

Configuring Off Timer 76 Configuring Turn Off After 77

Information Menu and Others

Information 79

Displaying Information 79

Configuring Brightness and Contrast in the Initial Screen 80

Configuring Volume in the Initial Screen 80

Installing the Software

Easy Setting Box 81

Installing the Software 81 Removing the Software 81

Troubleshooting Guide

Requirements Before Contacting Samsung Customer Service Center 82

Testing the Product 82 Checking the Resolution and Frequency 82 Check the following. 83

Q & A 86

Reset All 78

Initializing Settings (Reset All) 78

Table of contents

Specifications

General 88

PowerSaver 90

Standard Signal Mode Table 91

Appendix

Contact SAMSUNG WORLD WIDE 93

Responsibility for the Pay Service(Cost to Customers) 102

Not a product defect 102 A Product damage caused by customer's fault 102 Others 102

Correct Disposal 103

Correct Disposal of This Product (Waste Electrical & Electronic Equipment) 103

Terminology 104

Chapter 01

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

•

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product (i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product (i.e. where you have failed to read this user manual).

•

The amount of such administration charge will be advised to you before any work or home visit is carried out.

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire and damage the product. Be sure to allow the amount of space as shown below or greater when installing the product.

―

The exterior may differ depending on the product.

10 cm

Safety Precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

10 cm

Precautions for storage

High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used nearby.

―

Contact your nearest Samsung Customer Service Center if you want to clean the inside of the product

(Service fee will be charged.)

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been included with this product.

Symbols

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Cleaning

Electricity and Safety

―

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―

Take the following steps when cleaning.

―

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Power off the product and computer.

Disconnect the power cord from the product.

―

Hold the power cable by the plug and do not touch the cable with

wet hands. Otherwise, an electric shock may result.

Wipe the monitor with a clean, soft and dry cloth.

•

Do not apply a cleaning agent that contains alcohol, solvent, or surfactant to the monitor.

•

Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the product.

Connect the power cord to the product when cleaning is finished.

―

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

•

An electric shock or fire may result.

Do not use multiple products with a single power socket.

•

Overheated power sockets may cause a fire.

Do not touch the power plug with wet hands. Otherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

•

An unsecure connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated devices only).

•

An electric shock or injury may result.

Power on the product and computer.

Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy object.

•

Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

•

A fire or electric shock may result.

Installation

Hold the plug when disconnecting the power cord from the power socket.

•

An electric shock or fire may result.

Warning

Clean any dust around the pins of the power plug or the power socket with a dry cloth.

•

A fire may result.

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

•

A fire may result.

Caution

Do not disconnect the power cord while the product is being used.

•

The product may become damaged by an electric shock.

Only use the power cord provided with your product by Samsung. Do not use the power cord with other products.

•

A fire or electric shock may result.

Keep the power socket where the power cord is connected unobstructed.

•

The power cord must be disconnected to cut off power to the product when an issue occurs.

Do not install the product in poorly ventilated spaces such as a bookcase or closet.

•

An increased internal temperature may cause a fire.

Install the product at least 10cm away from the wall to allow ventilation.

•

An increased internal temperature may cause a fire.

Keep the plastic packaging out of the reach of children.

•

Children may suffocate.

Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.)

•

The product may fall and become damaged and/or cause an injury.

•

Using the product in an area with excess vibration may damage the product or cause a fire.

Caution

Do not drop the product while moving.

•

Product failure or personal injury may result.

Do not install the product in a vehicle or a place exposed to dust, moisture

(water drips, etc.), oil, or smoke.

•

A fire or electric shock may result.

Do not set down the product on its front.

•

The screen may become damaged.

Do not expose the product to direct sunlight, heat, or a hot object such as a stove.

•

The product lifespan may be reduced or a fire may result.

Do not install the product within the reach of young children.

•

The product may fall and injure children.

Edible oil, such as soybean oil, can damage or deform the product. Do not

When installing the product on a cabinet or shelf, make sure that the bottom edge of the front of the product is not protruding.

•

The product may fall and become damaged and/or cause an injury.

•

Install the product only on cabinets or shelves of the right size.

Set down the product gently.

•

Product failure or personal injury may result.

install the product in a kitchen or near a kitchen counter.

Installing the product in an unusual place (a place exposed to a lot of fine dust, chemical substances, extreme temperatures or a significant presence of moisture, or a place where the product will operate continuously for an

SAMSUNG

extended period of time) may seriously affect its performance.

•

Be sure to consult Samsung Customer Service Center if you want to install the product at such a place.

Operation

Warning

Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the product.

•

The product or heavy objects may fall as children try to reach for the toys or sweets resulting in a serious injury.

There is a high voltage inside the product. Never disassemble, repair or modify the product yourself.

•

A fire or electric shock may result.

•

Contact Samsung Customer Service Center for repairs.

Before moving the product, turn off the power switch and disconnect the power cable and all other connected cables.

•

Damage to the cord may result in a fire or electric shock.

If the product generates abnormal sounds, a burning smell or smoke, disconnect the power cord immediately and contact Samsung Customer Service Center.

•

An electric shock or fire may result.

Do not let children hang from the product or climb on top of it.

•

Children may become injured or seriously harmed.

If the product is dropped or the outer case is damaged, turn off the power switch and disconnect the power cord. Then contact Samsung Customer Service Center.

•

Continued use can result in a fire or electric shock.

GAS

During a lightning or thunderstorm, power off the product and remove the power cable.

•

A fire or electric shock may result.

Do not drop objects on the product or apply impact.

•

A fire or electric shock may result.

Do not move the product by pulling the power cord or any cable.

•

Product failure, an electric shock or fire may result from a damaged cable.

If a gas leakage is found, do not touch the product or power plug. Also, ventilate the area immediately.

•

Sparks can cause an explosion or fire.

Do not lift or move the product by pulling the power cord or any cable.

•

Product failure, an electric shock or fire may result from a damaged cable.

Do not use or keep combustible spray or an inflammable substance near the product.

•

An explosion or fire may result.

Ensure the vents are not blocked by tablecloths or curtains.

•

An increased internal temperature may cause a fire.

100

Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn easily (paper, matches, etc) into the product (via the vent or input/ output ports, etc).

•

Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product. Then contact Samsung Customer Service Center.

•

Product failure, an electric shock or fire may result.

Caution

-_-

Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels.

•

Activate power-saving mode or a moving-picture screen saver if you will not be using the product for an extended period of time.

Disconnect the power cord from the power socket if you do not plan on using the product for an extended period of time (vacation, etc).

•

Dust accumulation combined with heat can cause a fire, electric shock or electric leakage.

Use the product at the recommended resolution and frequency.

•

Your eyesight may deteriorate.

Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the product.

•

Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product. Then contact Samsung Customer Service Center.

•

Product failure, an electric shock or fire may result.

Do not hold the product upside-down or move it by holding the stand.

•

The product may fall and become damaged or cause an injury.

Looking at the screen too close for an extended period of time can deteriorate your eyesight.

Do not use humidifiers or stoves around the product.

•

A fire or electric shock may result.

Rest your eyes for more than 5 minutes for every 1 hour of product use.

•

Eye fatigue will be relieved.

Do not touch the screen when the product has been turned on for an extended period of time as it will become hot.

Store small accessories out of the reach of children.

Correct posture to use the product

Exercise caution when adjusting the product angle or stand height.

•

Your hand or finger may get stuck and injured.

•

Tilting the product at an excessive angle may cause the product to fall

and an injury may result.

Do not place heavy objects on the product.

•

Product failure or personal injury may result.

When using headphones or earphones, do not turn the volume too high.

•

Having the sound too loud may damage your hearing.

Use the product in the correct posture as follows:

•

Straighten your back.

•

Allow a distance of 45 to 50cm between your eye and the screen, and look slightly downward at the screen. Keep your eyes directly in front of the screen.

•

Adjust the angle so light does not reflect on the screen.

•

Keep your forearms perpendicular to your upper arms and level with the back of your hands.

•

Keep your elbows at about a right angle.

•

Adjust the height of the product so you can keep your knees bent at 90 degrees or more, your heels attached to the floor, and your arms lower than your heart.

Chapter 02

Preparations

Contact the vendor where you purchased the product if any components are missing.

The appearance of the components and items sold separately may differ from the image shown.

Recommend to use the HDMI cable and DP cable which is provided by the supplier.

The optimal resolution may not be available when using a non-high speed HDMI or HDMI-DVI cable.

To display the screen using a supported resolution, use the cables that came with the product. You can also use DP or HDMI cables that support UHD.

The Mini DP to DP gender changer may not be provided, depending on the model.

Checking the Components

Components

―

Components may vary depending on the country.

Quick Setup Guide Warranty card

(Not available in some locations)

User manual DP cable (P. 35) Mini DP to DP gender (Optional)

Regulatory guide Natural Color Expert Data Sheet

HDMI cable (P. 35)

USB 3.0 cable (P. 38)

Power cable (P.36) Wall-mount bracket Cleaning cloth (Optional)

Parts

Front Buttons

―

The color and shape of parts may differ from what is shown. Specifications are

subject to change without notice to improve quality.

Icons Description

Open or close the onscreen display (OSD) menu, or return to the parent menu.

When the initial screen is displayed, press any button on the front of the product to display the Function Key Guide. With the Guide displayed, press display menu.

When the Function Key Guide is displayed, press to set the Volume.

―

The Volume can be adjusted if the input source is DisplayPort1, DisplayPort2 or

HDMI.

Move to the upper or lower menu or adjust the value for an option on the OSD menu.

When the Function Key Guide is displayed, press to adjust the Brightness and

Contrast.

Confirm a menu selection.

Pressing the button when the OSD menu is not displayed will change the input source (DVI, HDMI, DisplayPort1, DisplayPort2).

When PIP/PBP is set to On and the Function Key Guide is displayed, press the Source for PIP/PBP.

―

If you power on the product or change the input source by pressing the

a message that shows the changed input source will appear at the top left corner of the screen.

to display the on-screen

to set

button,

Function Key Guide

When the Function Key Guide is displayed, press to configure Color Mode settings.

―

For details on how to configure Color Mode settings, refer to "Color Mode(P. 41)".

When the Function Key Guide is displayed, press to configure PIP/PBP settings.

―

For details on how to configure PIP/PBP settings, refer to "PIP/PBP( P.55) ".

Icons Description

Turn the screen on or off.

The power indicator will be lit when the product is operating normally.

―

For details on the power-saving function, refer to “PowerSaver(P. 90)” in the product

specifications.

―

To reduce power consumption, it is best to remove the power cable when not using

the product for an extended period of time.

When a control button on the product is pressed, the Function Key Guide will be displayed before the onscreen menu opens.

(The guide shows the function of the button pressed.)

Function Key Guide

To access the onscreen menu when the guide is displayed, press the corresponding button again.

The Function Key Guide may vary depending on the function or product model.

Refer to the actual product.

Reverse Side

Port Description

―

The color and shape of parts may differ from what is shown. Specifications are

subject to change without notice to improve quality.

―

To maximize the picture quality, a graphics card that supports the UHD

(3840x2160) resolution is recommended.

Connect the power cord for your monitor to the POWER IN port on the back of the product.

Connects to a source device via a DVI cable.

―

UHD resolution (3840x2160 @ 30Hz) is available if a dual-link DVI cable is connected.

Connects to a source device using an HDMI cable or HDMI-DVI cable.

―

When an HDMI cable is connected, the product can display UHD resolution

(3840x2160 @ 30Hz).

―

The product does not support UHD resolution when an HDMI-DVI cable is connected.

Connects to a PC using a DP cable.

―

When a DP cable is connected, the product can display UHD resolution

(3840x2160 @ 60Hz).

Connect to an audio output device such as headphones.

Connects to a PC using a USB cable.

―

This port can only connect to a PC.

Connect to a USB device. Compatible with a USB cable version 3.0 or lower.

―

Source devices can be charged using these USB ports.

―

To use the USB Super Charging feature, go to Settings USB Super Charging and

set the USB port that will be used for fast charging to On. The USB data transfer feature is not available when the USB Super Charging feature is

set to On.

―

High-speed charging is possible using the and ports only. These ports

charge devices faster than typical USB ports. The speed depends on the connected devices.

Installation

―

The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.

Caution

Take extra care to ensure your hand does not get stuck in the rotating area or the height adjustment area. This could injure your hand.

Do not put the hand below the stand body.

Do not hold the product upside down only by the stand.

Installing a Wall-mount Kit or Desktop Stand

―

The color and shape of parts may differ from what is shown. Specifications are subject to change

without notice to improve quality.

Before Installation

―

Power the product off and remove the power cable from the power socket.

Place a protective cloth or cushion on a flat surface. Next, place the product with the face down on top of the cloth or cushion.

Lift and detach the rear cover of the product in the arrow direction.

Detach the cover from the back of the product in the direction indicated by the arrows.

Unfasten the screw from the back of the product.

Lift and detach the stand.

Installing a Wall-mount Kit or Desktop Stand

Align the grooves and tightly fasten the screws on the bracket on the product with the corresponding parts on the wall-mount kit or desktop stand you want to attach.

―

Using a screw longer than the standard length can damage the internal components of the product.

―

The length of screws required for a wall mount that does not comply with the VESA standards may

vary depending on the specifications.

―

Do not use screws that do not comply with the VESA standards. Do not attach the wall-mount kit

or desktop stand using excessive force. The product may get damaged or fall and cause personal injury. Samsung shall not be held liable for any damage or injury caused by using improper screws or attaching the wall-mount kit or desktop stand using excessive force.

―

Samsung shall not be held liable for any product damage or personal injury caused by using a

wallmount kit other than the one specified or from an attempt to install the wall-mount kit on your own.

―

To mount the product on a wall, ensure you purchase a wall-mount kit that can be installed 10 cm or

farther away from the wall.

―

Be sure to use a wall-mount kit that complies with the standards.

―

To install the product on a wall using the wall-mount kit, remove the stand.

- Attach the wall-mount kit or desktop stand here

- Wall-mount bracket

Adjusting the Product Tilt and Height

―

The color and shape of parts may differ from what is shown. Specifications are subject to change

without notice to improve quality.

-1.5˚(-1.5˚,+1.5˚) ~ 91.5˚(-1.5˚,+1.5˚)

-30˚(+0,-2˚) ~ 30˚(+2˚,0)

-5˚(±2.0˚) ~ 20˚(±2.0˚)

130 mm ± 2.0 mm

Rotating the Monitor Screen

You can rotate your monitor as shown below.

1 2 3

4 5 6

―

Adjust the screen following the arrow direction.

―

Rotate the screen in clockwise direction till it becomes completely vertical to the desktop.

―

Rotating the screen counterclockwise can damage the product. Rotating the screen when the

product is upright or when the height is not at the maximum can also damage the product.

•

The monitor tilt and height can be adjusted.

•

To avoid damage to the product when adjusting the tilt, push or pull the top area of the product at the center while holding the top of the stand.

Anti-theft Lock

―

An anti-theft lock allows you to use the product securely even in public places.

―

The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details.

To lock an anti-theft locking device:

Fix the cable of your anti-theft locking device to a heavy object such as a desk.

Put one end of the cable through the loop on the other end.

Insert the locking device into the anti-theft lock slot at the back of the product.

Lock the locking device.

An anti-theft locking device can be purchased separately.

Refer to the user guide provided with your anti-theft locking device for details.

Anti-theft locking devices can be purchased at electronics retailers or online.

MagicRotation Auto

The MagicRotation Auto function detects the rotation of monitors that are fitted with a rotation sensor and rotates the Windows screen accordingly.

Software Installation

Insert the user manual CD provided with the product into the CD-ROM drive.

Follow the instructions given on the screen to proceed with installation.

―

After installation, the application menu language will be displayed in the language of the operating

system. (This complies with the basic policies of Windows.)

Caution

Compatible only with Windows 7 (32 bit or 64 bit) and Windows 8 (32 bit or 64 bit),

Windows 8.1 (32 bit or 64 bit).

Compatible with a graphics card that complies with the DDC/CI and MS API standards

Fourteen languages are available as installation languages.

If the orientation is set to a mode other than "Landscape" in the screen resolution menu on

Windows 7, the "MagicRotation Auto" function may not work properly.

The OSD menu will be displayed if the monitor is rotated. When the monitor is rotated, the screen

reconfiguration process may be displayed or screen burn-in may appear, depending on the

graphics card. This is performed by the Windows operating system and has nothing to do with the

product.

If you do not want the screen to rotate automatically when the monitor is rotated, press the

Windows and L keys at the same time to lock the Windows operating system. If the operating

system cannot be locked, it is due to the constraints of Windows API and has nothing to do with

the product.

With a graphics card that does not comply with the aforementioned standards, the MagicRotation Auto function may not be available.

To maximize the performance of the function, update the graphics card driver to the latest version.

Rotating the monitor

MENU SOURCE PIP/PBP

When rotating the monitor, the rotation angle is displayed on the monitor screen.

0° 90°

The on-screen display (OSD) menu items will automatically rotate when the screen rotates.

Caution

If the MagicRotation Auto software is not installed on the monitor, contents on the screen cannot

be rotated. The OSD can still rotate by 90° and display properly.

Once rotated, the OSD may appear in a different view mode from the mode before it was rotated.

MENU SOURCE PIP/PBP

Chapter 03

Using NCE(Natural Color Expert)

Configure the screen settings such as brightness and color tone.

What is Monitor Calibration?

Most of digital images are managed onscreen. That is why a monitor is very important for photographers and designers.

The process to calibrate a monitor in order to display proper colors is called monitor calibration.

This product went through a calibration process using color measurement equipment in the factory before shipment.

To obtain the optimum picture quality after calibration, select Custom or Calibration 1, Calibration 2, Calibration 3 mode on the monitor.

Supported calibrators

Manufacturer

Supported operating systems

(Windows)

Supported operating systems

(Mac)

I1 Pro i1Display Pro ColorMunki Design

CA-210 / CA-310 Spyder 4

ColorMunki Photo

xrite xrite xrite KONICA MINOLTA datacolor

Windows Vista 32 & 64

Windows 7 32 & 64

Windows 8 32 & 64

Windows 8.1 32 & 64

Mac OS X 10.6 Snow Leopard

Mac OS X 10.7 Lion

Mac OS X 10.8 Mountain Lion

Mac OS X 10.9 Mavericks

Windows Vista 32 & 64

Windows 7 32 & 64

Windows 8 32 & 64

Windows 8.1 32 & 64

Mac OS X 10.6 Snow Leopard

Mac OS X 10.7 Lion

Mac OS X 10.8 Mountain Lion

Mac OS X 10.9 Mavericks

Windows Vista 32 & 64

Windows 7 32 & 64

Windows 8 32 & 64

Windows 8.1 32 & 64

Mac OS X 10.6 Snow Leopard

Mac OS X 10.7 Lion

Mac OS X 10.8 Mountain Lion

Mac OS X 10.9 Mavericks

Windows Vista 32 & 64

Windows 7 32 & 64

Windows 8 32 & 64

Windows 8.1 32 & 64

Windows Vista 32 & 64

Windows 7 32 & 64

Windows 8 32 & 64

Windows 8.1 32 & 64

Mac OS X 10.6 Snow Leopard

Mac OS X 10.7 Lion

Mac OS X 10.8 Mountain Lion

Mac OS X 10.9 Mavericks

What is NCE (Natural Color Expert)?

NCE Program Installation/Uninstallation

The Natural Color Expert (hereinafter "NCE") program was developed by Samsung Electronics to display optimized colors customized by users.

―

This product supports the monitor calibration feature through the internal

NCE function and the provided NCE program. (a calibrator can be purchased separately).

―

The default calibration settings measured at the factory can be restored after

the product is calibrated using the NCE software.

―

Note that the default calibration settings measured at the factory may vary

depending on the panel characteristics. Panel characteristics can change according to operating time.

Installation

Insert the installation CD into the CD-ROM drive.

Click the Natural Color Expert V4 installation program.

―

If the software installation screen does not pop up on the main screen, go to CD-ROM

folder. Next, install using the Natural Color Expert v4 execution file.

If the Natural Color Expert V4 InstallShield Wizard screen appears, click Next and Install in sequence.

Installation progress will be displayed.

Click Finish in the displayed InstallShield Wizard Complete screen.

The Natural Color Expert V4 shortcut icon will be created on the desktop after installation.

―

The Natural Color Expert V4 execution icon may not be displayed depending on the PC system or product specifications.

―

Press the F5 key (Refresh) if the execution icon does not appear.

AutoPlay Manual NCE

Uninstallation

Go to Settings Control Panel on the Start menu and double-click Add or Remove Programs.

Select Natural Color Expert V4 from the list and click Change/Remove.

―

Natural Color Expert V4 installation can be affected by the graphics card, mother board and network conditions.

Starting NCE (Natural Color Expert)

Connecting the Calibrator

Connect the PC IN port on the product to a USB port on the PC using the USB cable.

Connect the calibrator to a USB port on the product.

―

Install the driver (which is usually provided with a calibration program) provided by the calibrator manufacturer first before connecting the calibrator.

The connected calibrator will automatically appear in the Select a Calibrator screen.

―

If more than one calibrator is connected, select the desired calibrator in the Select a Calibrator screen. Next, click Next.

Features of the NCE Program

Select a tab to perform the desired functions.

Layout and Menu Items on the NCE Home Screen

Select Profile List to view information on each profile. Select the Start button to perform calibration.

If the Profile List does not contain a profile, select Default and then start calibration.

If the Profile List contains profiles, select a profile to edit or calibrate the profile.

Select a profile to preview the screen. Ensure the Profile List contains profiles.

Select More to edit a profile as follows.

•

Rename: Change a profile name.

•

Delete: Delete the selected profile.

•

Delete All: Delete all profiles on the list of profiles.

•

Export: Save the selected profile to another path.

•

Import: Import a profile from another path.

Configure the system settings.

Layout and Menu Items on the Uniformity Screen

Overview and Functions of the Verication Screen

Perform calibration for Uniformity to optimize the display uniformity of the monitor.

Specify the number of blocks displayed per screen during Uniformity calibration.

A greater number of blocks will increase the precision of uniformity calibration.

Select Luminance only to perform calibration only for the brightness. Select Luminance and Color to perform calibration for both the brightness and colors.

If both Luminance and Color are enabled, the color temperature uniformity will also increase after calibration.

This screen allows you to verify the difference between the current monitor picture quality and the target value. (for calibration mode only)

Perform color verification for the currently displayed screen compared with profiles (for calibration mode only).

Perform Uniformity verification for the currently displayed screen (for calibration mode only).

Specify the color temperature when performing calibration. To obtain a more accurate color temperature, it is recommended to perform Uniformity calibration before color calibration.

Starting Calibration

If the Profile List does not contain a profile, select Default and then start calibration.

If the Profile List contains profiles, select a profile to edit or calibrate the profile.

Go to “Home screen – System settings – Profile Mode.”

Basic mode

Select Default or a profile from the Profile List. Next, select the Start button.

Specify the color gamut.

Configure the Brightness. The brightness level after calibration may depend on the color

temperature.

Configure the Black Level setting. If you do not adjust the black level setting by moving the slider

button, the minimum brightness will automatically be applied.

Configure the color temperature for White Point (range: 4000K – 10000K). To select a standard

brightness, click the Standard button.

Configure the R/G/B Gamma settings. If you configure LUT, the gamma curve of sRGB will be

applied.

•

If Linear Gray is selected, DeltaE (color difference) for the gray scale changes to less than 1 after calibration.

•

If Deep Black is selected, the black luminance becomes darker than Linear Gray after calibration. The minimum brightness varies depending on the “Black Level” settings.
