TW-14N5R

SAMSUNG TW-14N5R Service Manual Part List

Electrical Parts List
Samsung Electronics 7-1
7-1 TW14N34X/BWT
ASSY CHASSIS
1 AA91-05889A ASSY CHASSIS;TW14N34X/BWT,C17A,RUSS,PHIL
2 AA94-12219A ASSY PCB POWER;C17A,14,RUSSIA,PHILIPS,5 3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb 3 0204-001095 THINNER;#4520,-,-,­3 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,­3 Q401 0502-001115 TR-POWER;KSC5386,NPN,50W,TO-3PF,ST,8­3 PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST 3 NT801S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T 3 PT801S 1404-001264 THERMISTOR-PTC;4.5OHM,+30/-20%,220V,290V 3 CY801S 2201-000446 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x 3 CR410S 2303-001015 C-FILM,PPF;5.5nF,5%,1.6kV,TP,29x9.5x17,2 3 CR402S 2306-000195 C-FILM,MPPF;360nF,5%,400V,TP,26x19x11.5, 3 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm 3 C805 2401-003030 C-AL;220uF,20%,450V,GP,BK,30x35,10 3 RL801S 3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS, 3 CN502A 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH 3 CN801B AA39-20055B LEAD CONNECTOR-ASSY;,6P,YBNH025-06,67096 3 CN802B AA39-00180C LEAD CONNECTOR-ASSY;TF20P1,UL1007#26,UL/ 3 PCB+SC AA60-10008A SCREW-TAPPING;-,SWRCH18A,M3,L10,TH,+,-,­3 T801S AA26-00163A TRANS SWITCHING;35B125-DM,V17A,SMV-20A5S 3 T444S AA26-00192A TRANS FBT;FTK-21H001,CTV,3.7MH,FERRITE,E 3 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,-,-,7.1mH,-,-,102uH, 3 LR401S AA27-00122A COIL LINEARITY;90UH,90UH,L81 DR10x10,7.5 3 L402 AA27-40001M COIL HORIZ. WIDTH;-,180/480uH,SB-5S6202. 3 LX801S AA29-30001D FILTER LINE NOISE;SQ1913,-,6.0MH,0.8A,­3 GT101A AA39-20010D LEAD CONNECTOR-ASSY;,1P,YFH800-01,S,400, 3 AA61-01045A SUPPORT-PCB;DASS-T 9N,NYLON ,9.4,NTR 3 AA63-00609A SHIELD-CASE;DP,20P1,AA63-00518A 3 AA65-30014A CLAMPER CORE-WIRE;-,NYLON-66,V0,-,NTR,DA 3 AA65-30111A CLAMPER CORE-WIRE;ALL MODEL,NYLON,V0,-,W 3 D810 AA96-00243D ASSY H/S;-,BRIDGE,AA62-00045A,D06U20S,D 4 0205-000129 GREASE-SILICON;SC102,JAPAN 4 0402-001374 DIODE-RECTIFIER;FFPF06U20S,200V,6A,TO-22 4 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR 4 AA62-00065A HEAT SINK-PS;DP,-,-,-,AA62-00045A,-,-,-, 3 Q803 AA96-00243G ASSY H/S;-,POWER,AA62-00045A,C2073-H2,V 4 0205-000129 GREASE-SILICON;SC102,JAPAN 4 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6 4 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR 4 AA62-00065A HEAT SINK-PS;DP,-,-,-,AA62-00045A,-,-,-, 3 IC301 AA96-00244A ASSY H/S;-,-,AA62-00046A,LA7840,­4 0205-000129 GREASE-SILICON;SC102,JAPAN 4 1204-001483 IC-VERTICAL PROCESSO;LA7840,SIP,7P,708MI 4 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR 4 AA62-00064A HEAT SINK-PS;DP,-,-,-,AA62-00046A,-,-,-, 3 IC801S AA96-00662B ASSY H/S;-,POWER,AA62-30171J,KA5Q0765R, 4 0205-000129 GREASE-SILICON;SC102,JAPAN 4 1203-001932 IC-PWM CONTROLLER;5Q0765,TO-220F,5P,185M 4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 4 AA62-30171J HEAT SINK-ES;-,-,-,SILVER,-,DREAM1,-,-,­3 Q813 AA96-50305D ASSY H/S;-,POWER,AA62-30012E,KSD73Y,STY 4 0502-000298 TR-POWER;KSD73,NPN,30000mW,TO-220,TP,12 4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 4 AA62-30012E HEAT SINK-ES;-,A6063 EXTR,-,-,TO-220 H55 3 AA97-13455A ASSY AUTO-POWER;C17A,14,RUSSIA,PHILIPS, 4 D822 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D823 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D825 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D827 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D811 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D812 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D816 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D820 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D806 0401-000006 DIODE-SWITCHING;BAV21,250V,250mA,DO-35,T
4 D828 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D815 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D301 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D405 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D809 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D814 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L 4 D404 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T 4 D808 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 4 D403 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 4 D402 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 4 D804S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 4 D803S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 4 D802S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 4 D801S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 4 D807 0402-001443 DIODE-RECTIFIER;EGP20K,800V,2A,DO-15,TP 4 DZ401 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 4 DZ807 0403-000699 DIODE-ZENER;TZP27B,27V,27-30.8V,1W,DO-41 4 DZ810 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T 4 DZ303 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T 4 DZ805 0403-000714 DIODE-ZENER;MTZJ3.3B,3.3V,3.32-3.53V,500 4 DZ811 0403-000714 DIODE-ZENER;MTZJ3.3B,3.3V,3.32-3.53V,500 4 DZ804 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 4 DZ803 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 4 DZ808 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 4 DZ302 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D 4 DZ806 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500mW,DO 4 DZ802 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D 4 DZ301 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D 4 DZ304 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D 4 DZ813 0403-001373 DIODE-ZENER;MTZJ5.1A,4.81V-5.07V,500mW,D 4 DZ812 0403-001373 DIODE-ZENER;MTZJ5.1A,4.81V-5.07V,500mW,D 4 Q812 0501-000362 TR-SMALL SIGNAL;KSA2328A-Y,NPN,1W,TO-92L 4 Q811 0501-000362 TR-SMALL SIGNAL;KSA2328A-Y,NPN,1W,TO-92L 4 Q810 0501-000362 TR-SMALL SIGNAL;KSA2328A-Y,NPN,1W,TO-92L 4 Q402 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO­4 Q805 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 4 Q807 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 4 Q806 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 4 Q804 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T 4 Q808 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T 4 Q801 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL 4 VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP 4 R301 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM 4 R408 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M 4 R829 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 4 R825 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 4 R823 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4 4 R808 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4 4 R828 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M 4 R405 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M 4 R814 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R824 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R809 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R840 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R835 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R816 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R821 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R822 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R843 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R842 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R841 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R831 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R811 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R827 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R817 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R407 2001-001037 R-CARBON(S);0.39OHM,5%,1/2W,AA,TP,2.4X6. 4 R813 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4 4 R812 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4 4 R410 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
7. Electrical Parts List
!
!
!
4 R422S 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M 4 R409 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA,TP,2.4X6.4 4 R818 2001-001134 R-CARBON(S);360ohm,5%,1/2W,AA,TP,2.4x6.4 4 R838 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6. 4 R839 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6. 4 R830 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4 4 R806 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4 4 R810 2001-001192 R-CARBON(S);820OHM,5%,1/2W,AA,TP,2.4X6.4 4 RX801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x 4 RY801S 2002-001012 R-COMPOSITION;8.2Mohm,5%,1/2W,AA,TP,3.7x 4 R805 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12 4 R804 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12 4 R803 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12 4 R315 2003-001018 R-METAL OXIDE(S);220ohm,5%,2W,AF,TP,3.9x 4 R303 2003-002070 R-METAL OXIDE;1ohm,5%,2W,AF,TP,3.9x10mm 4 R402 2003-002178 R-METAL OXIDE(S);1Kohm,5%,2W,AG,TP,3.9x1 4 R413 2004-001137 R-METAL;6.8Kohm,1%,1/8W,AA,TP,1.8x3.2m 4 R306 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm 4 R302 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm 4 R833 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6. 4 R815 2004-004089 R-METAL(S);123Kohm,1%,1/2W,AA,TP,2.5x6.5 4 R412 2004-004089 R-METAL(S);123Kohm,1%,1/2W,AA,TP,2.5x6.5 4 R406 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m 4 R404 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m 4 R414 2008-000264 R-FUSIBLE(S);1ohm,5%,1W,AF,TP,3.9x10mm 4 R317 2008-001013 R-FUSIBLE(S);1.2ohm,5%,2W,AF,TP,3.9x10mm 4 R415 2008-001031 R-FUSIBLE(S);1.8ohm,5%,1W,AF,TP,3.9x10mm 4 R411 2008-001015 R-FUSIBLE(S);1.5ohm,5%,2W,AF,TP,3.9x10mm 4 C302 2201-000259 C-CERAMIC,DISC;0.18nF,10%,500V,Y5P,TP,5. 4 C801 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250V,Y5U,TP,9x4 4 C817 2201-000374 C-CERAMIC,DISC;0.22nF,5%,50V,NP0,TP,10.5 4 C818 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. 4 C305 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. 4 C303 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. 4 C814 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. 4 C408 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. 4 CR404S 2201-000639 C-CERAMIC,DISC;0.68nF,10%,2kV,Y5P,TP,9x5 4 C812 2201-000991 C-CERAMIC,DISC;0.56nF,10%,2kV,Y5P,TP,7.5 4 CR409S 2201-000991 C-CERAMIC,DISC;0.56nF,10%,2kV,Y5P,TP,7.5 4 C826 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP 4 C825 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP 4 C824 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 4 C809 2301-000016 C-FILM,PEF;22nF,5%,100V,TP,7.2x4.5x9.0mm 4 C816 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5 4 C807 2301-000235 C-FILM,PEF;3.9nF,5%,50V,TP,6.5x3.0x5.5mm 4 C310 2301-000254 C-FILM,PEF;39nF,5%,50V,TP,7.5x3.5x6.5mm, 4 C407 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 4 C411 2301-001065 C-FILM,MPPF;47nF,5%,630V,TP,19x15.5x7,7. 4 C806 2301-001435 C-FILM,PPF;1.5nF,5%,1.2kV,TP,15x8x12.5mm 4 C309 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5 4 C301 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15 4 CR405S 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm 4 C821 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 4 C810 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 4 C813 2401-000262 C-AL;100uF,20%,160V,HR,TP,16x25,7.5 4 C307 2401-000365 C-AL;100uF,20%,50V,WT,TP,10x12.5mm, 4 C815 2401-000703 C-AL;2200uF,20%,25V,GP,-,12.5x25mm, 4 C827 2401-000901 C-AL;22uF,20%,160V,GP,TP,10x20,5 4 C401 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5 4 C304 2401-001115 C-AL;330uF,20%,25V,GP,TP,10x12.5,5 4 C808 2401-001192 C-AL;33uF,20%,50V,GP,TP,6.3x11,5 4 C306 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5 4 C823 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 4 C820 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 4 C406 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5 4 C308 2401-003028 C-AL;100uF,20%,25V,WT,TP,6.3x11,5 4 C819 2401-003139 C-AL;1000uF,20%,25V,WT,TP,10*20,5mm 4 L401 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 4 L404 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 4 L302 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 4 L301 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 4 L405 2701-000159 INDUCTOR-AXIAL;22uH,10%,4.2x9.8mm 4 J804 2701-001030 INDUCTOR-AXIAL;43uH,10%,5x14mm 4 L804 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,­4 L403 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,­4 L803 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,­4 L802 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
4 FP801S 3601-000261 FUSE-CARTRIDGE;250V,3.15A,TIME-LAG,GLASS 4 FD801S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS 4 FD802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS 4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm 4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm 4 J818 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J817 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J815 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J814 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J813 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J824 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J822 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J821 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J820 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J819 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J812 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J806 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J805 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J803 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J802 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J801 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J811 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J810 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J809 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J808 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J807 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 PCB AA41-00548B PCB-POWER;TF21B5S,FR-1,1L,A,1.6T,245X245 4 EY811 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY812 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY813 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY814 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY815 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY802 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY803 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY804 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY805 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY806 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY816 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY822 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY825 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY827 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY828 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY829 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY817 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY818 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY819 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY820 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY821 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY801 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY406 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY407 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY408 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY409 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY410 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY401 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY402 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY403 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY404 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY405 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY411 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY419 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY420 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY421 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY422 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY423 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY412 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY414 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY415 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY416 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY417 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EL802 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL803 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL804 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL805 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL801 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL301 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL302 AA60-40011B K EYELET;ID2.2,OD3.2,BSP
Electrical Parts List
7-2 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
4 EL403 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL404 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 GT805 AA60-40014A PIN-GT,ASSY;AUTO 4 GT804 AA60-40014A PIN-GT,ASSY;AUTO 4 GT803 AA60-40014A PIN-GT,ASSY;AUTO 4 GT806 AA60-40014A PIN-GT,ASSY;AUTO 4 GT807 AA60-40014A PIN-GT,ASSY;AUTO 4 GT808 AA60-40014A PIN-GT,ASSY;AUTO 4 GT301 AA60-40014A PIN-GT,ASSY;AUTO 4 GT302 AA60-40014A PIN-GT,ASSY;AUTO 4 GT401 AA60-40014A PIN-GT,ASSY;AUTO 4 GT402 AA60-40014A PIN-GT,ASSY;AUTO 4 GT801 AA60-40014A PIN-GT,ASSY;AUTO 4 GT802 AA60-40014A PIN-GT,ASSY;AUTO 4 HA68-02176A LABEL;LABEL 2 AA94-11851A ASSY PCB MISC-M/DECK;TF20P1D4X/XEF,C17A 3 0201-000280 ADHESIVE-TS;EH-260D,RED,450°æ50PS,10CC 3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb 3 0204-001095 THINNER;#4520,-,-,­3 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,­3 PTM601 0604-001122 PHOTO-INTERRUPTER;TR,0.065%,150mW,DIP-4, 3 PTM602 0604-001122 PHOTO-INTERRUPTER;TR,0.065%,150mW,DIP-4, 3 ICM602 1003-001318 IC-MOTOR DRIVER;LB11880,DIP,30P,417MIL,­3 IC601 1201-001386 IC-POWER AMP;7267,DIP,16P,-,DUAL,32dB,PL 3 XTM301 2801-000277 CRYSTAL-UNIT;4.433619MHz,8ppm,28-AAM,S,1 3 CNM302 3708-000394 CONNECTOR-FPC/FFC/PIC;6P,1.25mm,STRAIGHT 3 CNM301 3708-000394 CONNECTOR-FPC/FFC/PIC;6P,1.25mm,STRAIGHT 3 CNM602 3708-001053 CONNECTOR-FPC/FFC/PIC;7P,1.25mm,STRAIGHT 3 CNM303 3710-001648 CONNECTOR-SOCKET;2P,1R,2.5mm,STRAIGHT,SN 3 CN701A 3711-000628 CONNECTOR-HEADER;BOX,11P,1R,2.5MM,STRAIG 3 CN601B 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH 3 CN601A 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH 3 CN501A 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH 3 TPCN01 3711-002648 CONNECTOR-HEADER;BOX,9P,1R,2.5mm,STRAIGH 3 CNM603 3711-003749 CONNECTOR-HEADER;BOX,8P,2R,2mm,STRAIGHT, 3 CNM302 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm 3 CNM602 3809-001312 CABLE-FLAT;30V,80C,110MM,7P,1.25MM,UL289 3 FLM301 AA26-10006C TRANS RF;-,7MF,BIAS,2.4MH,7MM,-,65.3KHZ 3 SWM610 AA34-20001A SWITCH-MODE;1,25x14.6x29.8mm,BK,DC5V 3 SWM611 AA34-40001A SWITCH-REC.;1EA,37.5x14.4mm,BK,DC5V 3 W01 AA39-00046C LEAD CONNECTOR-ASSY;,1P,JUMPER,BLK,100MM 3 CN802A 3711-003975 CONNECTOR-HEADER;BOX,14P,1R,2.5mm,STRAIG 3 CN801A 3711-002645 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,STRAIGH 3 CNM601 AA39-20603A LEAD CONNECTOR-ASSY;,2P,GIL-S-2S-S2C2-S, 3 REM601 AA59-60003V MODULE REMOCON;-,SRV-18,38KHZ,940NM,MESH 3 GPM01 AA63-00444B GROUND;TVCR,PBS,T0.3,-,-,-,SUS-DECK 3 LDM601 AA91-60318A ASSY-HOLDER,LED;-,ABS,HB,BLK,IR LED,TS-D 4 LED 0601-001303 LED-IR;SIDE-VIEW,2.5mm,75mW,6V,950nm, 4 HOLDER AA61-00003A HOLDER-LED;TVN-502V,ABS,-,-,-,BLK,HB 3 SM602 AA91-60319A ASSY-HOLDER,SENSOR;-,ABS,HB,BLK,TR LED,T 3 SM601 AA91-60319A ASSY-HOLDER,SENSOR;-,ABS,HB,BLK,TR LED,T 4 TR 0603-001011 PHOTO TR;NPN,35V,6V,50mA,75mW,BK 4 HOLDER AA61-00005A HOLDER-SENSOR;TVN-502V,ABS,-,-,-,BLK,HB 3 LDM602 AA96-00462A ASSY LED GUIDE;-,-,DL-11S2R1,RED 3 AA97-12952A ASSY ROBOT;,C17A 4 IC702 0801-000213 IC-CMOS LOGIC;4052,MULTIPLEXER,DIP,16P,3 4 IC701 0801-000961 IC-CMOS LOGIC;4053,MUTIPLEXER,DIP,16P,30 4 IC902 1103-001177 IC-EEPROM;24WC16,2048x8Bit,DIP,8P,-,-,2. 4 SF101S 2904-000267 FILTER-SAW AV;38.9MHz,SIP5P,ST,16.8dB,PA 4 JS701 3722-000183 JACK-SCART;21P,4mm,SN,BLK,NO 4 IC201S AA09-00285A IC MICOM;TDA9381PS/N2/3/0749,SPM-744WOT 4 TU01S HA83-00061A LA-TUNER;AA40-00076A 4 AA97-12967A ASSY AUTO;,C17A 5 DM609 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 DM603 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 DM301 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D601 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D205 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D202 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D602 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 5 D203 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 5 ZDM601 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ901 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
5 DZ101 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ206 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ510 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ701 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 ZDM602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ201 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ203 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ205 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ202 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO 5 QM312 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92, 5 Q201 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T 5 Q701 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T 5 QM315 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T 5 QM311 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T 5 QM305 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T 5 QM317 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 QM304 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 Q205 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 QM605 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM604 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM603 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM308 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM306 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM302 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM301 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM314 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 5 QM313 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 5 QM303 0504-000119 TR-DIGITAL;KSR1004,NPN,300MW,47K/47K,TO­5 Q601 0504-000123 TR-DIGITAL;KSR1010,NPN,300mW,10K,TO-92,T 5 ICM603 1203-000642 IC-RESET;572,TO-92,3P,-,PLASTIC,2.35/2. 5 RM638 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM633 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM632 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM319 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM318 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM655 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM654 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 R205 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM352 2001-000006 R-CARBON;2.4KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM370 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R212 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM612 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM610 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM644 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R203 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R711 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4 5 RM641 2001-000118 R-CARBON(S);180OHM,5%,1/2W,AA,TP,2.4X6.4 5 RM316 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM349 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM335 2001-000232 R-CARBON;1.3KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM307 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM323 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM358 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM339 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM623 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R915 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R916 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R917 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R911 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R910 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM668 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM667 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM666 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM665 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM664 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM663 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R503 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R502 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R501 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R216 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R209 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R208 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
Samsung Electronics 7-3
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
5 R908 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R906 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R905 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R712 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R901 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R902 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM639 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM637 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM619 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM615 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM614 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM697 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM696 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM693 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM692 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM670 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM656 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R718 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R710 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R709 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R707 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R601 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R504 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM360 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R923 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R922 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R907 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R920 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R921 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM606 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM671 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM303 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R604 2001-000347 R-CARBON;13KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM305 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM356 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R218 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM657 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM674 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM678 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM679 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM653 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM651 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM650 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM649 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM648 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM682 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM694 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM690 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM689 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM688 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM687 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM686 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM685 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM684 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM683 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM647 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM605 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM362 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM361 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM341 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM333 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM317 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM312 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM310 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R903 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM609 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM643 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM629 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM628 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM626 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM625 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM613 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM621 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM622 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM624 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM340 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
5 R913 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R912 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM344 2001-000454 R-CARBON;2.2MOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM359 2001-000458 R-CARBON;2.2OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM346 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM334 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM313 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R210 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R211 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM372 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM326 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM315 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM660 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM642 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM602 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM363 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM354 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R706 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R722 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R227 2001-000531 R-CARBON;240KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM669 2001-000539 R-CARBON;24KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM661 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM601 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM320 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R605 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R204 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R206 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM675 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R214 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM640 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R719 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM304 2001-000645 R-CARBON;330KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM616 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM604 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM306 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R704 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R201 2001-000689 R-CARBON;390KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM331 2001-000723 R-CARBON;4.3KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM636 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM635 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM634 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM365 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM345 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R221 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R914 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R919 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM324 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R220 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R219 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM379 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM328 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM357 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM327 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM618 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM377 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM375 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R226 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R223 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R106 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R207 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM369 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM373 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM351 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM302 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R703 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R702 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM611 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM348 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM347 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM627 2001-000850 R-CARBON;560KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R202 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM607 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM353 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM314 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R225 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R107 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM380 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
Electrical Parts List
7-4 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
5 RM350 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM329 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R105 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R215 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R721 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R714 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R715 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R716 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R717 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R720 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R222 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R705 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R708 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R713 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM338 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM378 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM371 2001-001000 R-CARBON;82KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R224 2001-001026 R-CARBON;910OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R213 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm 5 RM630 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m 5 CM319 2201-000345 C-CERAMIC,DISC;0.2nF,5%,50V,SL,TP,7x3,5 5 C226 2201-000472 C-CERAMIC,DISC;0.33nF,5%,50V,SL,TP,8.5x3 5 CM316 2201-000499 C-CERAMIC,DISC;0.39nF,5%,50V,SL,TP,8.5x3 5 C906 2201-000573 C-CERAMIC,DISC;0.047nF,5%,50V,NP0,TP,5x3 5 C905 2201-000573 C-CERAMIC,DISC;0.047nF,5%,50V,NP0,TP,5x3 5 CM359 2201-000611 C-CERAMIC,DISC;0.056nF,5%,50V,NP0,TP,7x3 5 CM360 2201-000611 C-CERAMIC,DISC;0.056nF,5%,50V,NP0,TP,7x3 5 CM315 2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP, 5 CM640 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP 5 CM613 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM612 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM397 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM396 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM379 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM378 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM615 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CT19 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM656 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM635 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM634 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM624 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM621 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM330 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM321 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM313 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 C602 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 C106 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 C102 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM334 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM349 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM341 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM338 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM337 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM336 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM335 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM318 2202-000162 C-CERAMIC,MLC-AXIAL;0.015NF,5%,50V,SL,TP 5 CM636 2202-000183 C-CERAMIC,MLC-AXIAL;2.2NF,20%,16V,Y5R,TP 5 CM637 2202-000183 C-CERAMIC,MLC-AXIAL;2.2NF,20%,16V,Y5R,TP 5 CM610 2202-000205 C-CERAMIC,MLC-AXIAL;22pF,5%,50V,SL,TP,1. 5 CM609 2202-000205 C-CERAMIC,MLC-AXIAL;22pF,5%,50V,SL,TP,1. 5 CM314 2202-000216 C-CERAMIC,MLC-AXIAL;0.027NF,5%,50V,SL,TP 5 C716 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP 5 C715 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP 5 C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP 5 C731 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3. 5 CM638 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP 5 CM395 2202-000279 C-CERAMIC,MLC-AXIAL;47pF,5%,50V,SL,TP,3. 5 CM606 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM394 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM393 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM367 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM358 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM659 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM652 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM651 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM631 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
5 CM607 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM327 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM301 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 C231 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 C205 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 C204 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM354 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM352 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM342 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM339 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM329 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM617 2202-000718 C-CERAMIC,MLC-AXIAL;3.9nF,20%,16V,Y5R,TP 5 CM616 2202-000718 C-CERAMIC,MLC-AXIAL;3.9nF,20%,16V,Y5R,TP 5 C704 2202-000719 C-CERAMIC,MLC-AXIAL;6.8nF,20%,16V,Y5R,TP 5 CM325 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 CM650 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 CM657 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 C904 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 C224 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 C223 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 CM601 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP 5 CM630 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM629 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM628 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM622 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM604 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM351 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM347 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM320 2202-000849 C-CERAMIC,MLC-AXIAL;18pF,5%,50V,CH,TP,3. 5 C211 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V 5 C911 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V 5 CL08 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V 5 CM350 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V 5 CM345 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V 5 CM309 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V 5 C227 2301-000104 C-FILM,PEF;1.2NF,5%,50V,TP,6.5X3.0X5.5MM 5 CM372 2301-000160 C-FILM,PEF;12nF,5%,50V,TP,11.0x6.0x9.0mm 5 CM368 2301-000175 C-FILM,PEF;15nF,5%,50V,TP,7.1x3.5x13mm,5 5 CM306 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm 5 C201 2301-000204 C-FILM,PEF;2.7nF,5%,50V,TP,7.4x3.9x13mm, 5 C604 2301-000204 C-FILM,PEF;2.7nF,5%,50V,TP,7.4x3.9x13mm, 5 C108 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5 5 CM370 2301-000254 C-FILM,PEF;39nF,5%,50V,TP,7.5x3.5x6.5mm, 5 CM362 2301-000301 C-FILM,PEF;6.8nF,5%,50V,TP,6.5X5.5X3.0X5 5 CM363 2301-000301 C-FILM,PEF;6.8nF,5%,50V,TP,6.5X5.5X3.0X5 5 CM371 2301-000301 C-FILM,PEF;6.8nF,5%,50V,TP,6.5X5.5X3.0X5 5 CM603 2301-000310 C-FILM,PEF;68nF,5%,50V,TP,8.0X8.5X4.0X5, 5 CM364 2301-000314 C-FILM,PEF;8.2nF,5%,50V,TP,6.5x3.0x5.5mm 5 C217 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, 5 CM305 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, 5 CM303 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 5 C903 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 5 C232 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm 5 CM660 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 5 C712 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 5 C216 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 5 C215 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 5 C901 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm 5 C207 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm 5 CM311 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C909 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C230 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C218 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C210 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C208 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C225 2309-000138 C-FILM,PE-PPF;100nF,5%,50V,TP,20x16x8.5, 5 C233 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5 5 C104 2401-000939 C-AL;22uF,20%,25V,GP,TP,5x11,5 5 CM332 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 5 CM323 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 5 CM304 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 5 CM361 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM348 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM333 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM331 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM317 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM310 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5
Electrical Parts List
Samsung Electronics 7-5
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
5 C605 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM611 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 5 CM346 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 5 CM344 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 5 C219 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 5 CM392 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 5 C212 2401-000647 C-AL;2.2uF,20%,50V,BP,TP,5x11,5 5 C221 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 5 CM308 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5 5 CM355 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 5 CM324 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 5 C606 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 5 C101 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5 5 CT18 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5 5 C601 2401-001115 C-AL;330uF,20%,25V,GP,TP,10x12.5,5 5 CM307 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 5 CM365 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 5 CM639 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 5 CM326 2401-001325 C-AL;470nF,20%,50V,GP,TP,3x5,5 5 CM605 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM602 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM399 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM373 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM312 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM340 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM343 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM632 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C907 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C902 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C229 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C209 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C213 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C214 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C228 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 5 CM623 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm 5 CM641 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 5 CM357 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 5 CM353 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 5 C603 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 5 C711 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C713 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C714 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C717 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 CL06 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 CM328 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C710 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C103 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C206 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C220 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C234 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C701 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C702 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 CM356 2401-002462 C-AL;33uF,20%,16V,GP,TP,5x11,5 5 C203 2401-002462 C-AL;33uF,20%,16V,GP,TP,5x11,5 5 C202 2401-002462 C-AL;33uF,20%,16V,GP,TP,5x11,5 5 CM618 2401-002463 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 5 C705 2401-002463 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 5 LM603 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 5 LM602 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 5 LM306 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 5 LM301 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 5 LM307 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM305 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM304 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM309 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM601 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM604 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM605 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L201 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L202 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L203 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L701 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L902 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L704 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L702 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM303 2701-000118 INDUCTOR-AXIAL;120uH,10%,2.5x3.4mm 5 L206 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm
5 L205 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 5 L102 2701-000159 INDUCTOR-AXIAL;22uH,10%,4.2x9.8mm 5 L204 2701-000169 INDUCTOR-AXIAL;3.9uH,10%,2.5x3.4mm 5 L101 2701-000171 INDUCTOR-AXIAL;330nH,10%,2.5x3.4mm 5 L903 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 L901 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 LM310 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 LM302 2701-000207 INDUCTOR-AXIAL;56uH,5%,2.5x3.4mm 5 LM308 2702-000120 INDUCTOR-RADIAL;15mH,5%,6.2x7.4mm 5 XTM601 2801-003750 CRYSTAL-UNIT;8MHZ,30PPM,28-AAA,22PF,80OH 5 X901 2801-003937 CRYSTAL-UNIT;12MHz,25ppm,28-AAM,30pF,30o 5 L104 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5, 5 L103 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5, 5 Z202 2903-000181 FILTER-CERAMIC;BR,5.5MHz,-,-,-,TP,TPS5.5 5 Z201 2903-001040 FILTER-CERAMIC;TR,5.5/6.0/6.5MHz,-,1dB,­5 SWM706 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM707 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM708 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM709 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM705 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM701 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM702 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM703 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM704 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 JB902 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB903 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB905 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB906 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB907 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB901 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB802 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB803 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB804 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB805 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB806 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB908 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG006 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG007 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG008 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG009 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG010 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG005 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB909 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG001 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG002 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG003 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG004 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V12 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V05 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V09 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V10 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V12 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V13 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V01 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J272 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J273 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J275 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J276 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA33 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB1201 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V04 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V07 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V08 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V09 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V11 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V03 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB1203 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB3301 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB3302 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V01 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V02 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG042 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG043 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG046 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JJ02 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP01 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG041 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
Electrical Parts List
7-6 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
5 JG036 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG037 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG038 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG039 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG040 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP03 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JPM303 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JPM306 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JTV500 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JTV501 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 L703 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JPM302 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP04 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP05 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP06 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP10 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JPM301 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG035 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG017 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG018 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG019 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG020 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG022 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG016 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG011 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG012 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG013 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG014 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG015 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG023 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG030 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG031 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG032 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG033 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG034 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG029 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG024 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG025 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG026 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG027 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG028 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J150 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J151 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J152 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J153 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J158 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J148 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J142 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J143 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J144 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J146 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J147 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J159 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J169 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J170 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J171 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J172 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J173 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J168 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J160 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J161 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J162 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J166 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J167 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J141 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J109 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J110 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J111 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J113 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J117 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J108 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 D101 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 DM601 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J103 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J106 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J107 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J120 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
5 J136 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J137 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J138 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J139 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J140 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J135 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J121 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J122 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J123 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J124 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J125 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J225 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J226 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J227 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J228 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J229 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J224 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J217 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J218 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J219 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J222 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J223 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J231 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J260 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J261 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J262 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J264 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J265 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J259 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J234 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J235 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J256 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J257 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J258 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J216 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J185 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J186 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J187 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J189 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J194 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J179 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J174 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J175 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J176 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J177 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J178 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J195 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J203 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J205 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J209 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J210 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J211 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J202 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J196 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J197 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J198 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J200 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J201 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 HIC01 AA13-20004WIC HYBRID;-,PAP103T,SIP,6P,PRE-AMP,TP 5 GT01 AA60-40014A PIN-GT,ASSY;AUTO 5 GT02 AA60-40014A PIN-GT,ASSY;AUTO 5 AA97-12501A ASSY SMD;CMC13410X/KMT 6 ICM301 1204-001649 IC-VIDEO PROCESS;LA71598M,QFP,100P,-,PLA 6 PCB AA41-00549C PCB-MAIN;TF20P1D4X,FR-1,1L,C,1.6T,330X24 6 AA97-06858A ASSY MICOM;,C17A,UPD784928,SNM-740MD,011 7 ICM601 AA09-00261A IC MICOM;UPD784927GF-230-3BA,TF20P1DF,1 6 HA68-02176A LABEL;LABEL 3 C612 2401-000703 C-AL;2200uF,20%,25V,GP,-,12.5x25mm, 3 C607 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm 2 AA94-11859A ASSY PCB CRT;14,C17A 3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb 3 0204-001095 THINNER;#4520,-,-,­3 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,­3 V999S 3704-001112 SOCKET-CRT;8P,12PI,22.5PI,NI,­3 CN502B AA39-20052A LEAD CONNECTOR-ASSY;,4P,YBNH025-04,YSH02 3 CN501B AA39-20069C LEAD CONNECTOR-ASSY;,5P,YBNH025-05,67096
Electrical Parts List
Samsung Electronics 7-7
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
3 IC501 AA96-00842A ASSY H/S;,VIDEO,AA62-30175D,TDA6107Q 4 IC501 1201-001541 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA 4 SCR501 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR 4 H/S501 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 3 AA97-13016A ASSY AUTO-MAIN;CS21A5 4 D504 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D503 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D502 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D501 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP 4 DZ501 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 4 R509 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R508 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R507 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R506 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 4 R503 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 4 R502M 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 4 R501M 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 4 C503 2201-000723 C-CERAMIC,DISC;4.7nF,20%,3KV,Y5U,TP,16x5 4 C501 2202-000825 C-CERAMIC,MLC-AXIAL;680pF,10%,50V,Y5P,TP 4 C502 2301-000213 C-FILM,PEF;220nF,5%,250V,TP,21.5x11,7.5 4 C506 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m 4 C504 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5 4 JC501 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 JC500 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 PCB AA41-00550A PCB-CRT;TF21B5S,FR-1,1L,A,1.6T,330X245,C 4 GT502 AA60-40014A PIN-GT,ASSY;AUTO 2 AA94-11761A ASSY PCB MISC-A/V;TB20A54X/XSA,C17A 3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb 3 0204-001095 THINNER;#4520,-,-,­3 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,­3 JA03 3722-000145 JACK-PHONE;1P,3.6PI,MBAG,BLK,­3 JA02 3722-001342 JACK-PIN;1P,3.4MM,NI,YEL,­3 JA01 3722-001343 JACK-PIN;1P,3.4MM,NI,WHT,­3 CN701B AA39-20461C LEAD CONNECTOR-ASSY;,11P,YBNH250-11,6709 3 AA97-12473A ASSY AUTO-A/V;TB20A54X/XSA,C17A 4 RY701 2001-000958 R-CARBON;750OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 RY702 2001-000958 R-CARBON;750OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 CY702 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP 4 LY702 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 4 LY701 2701-000116 INDUCTOR-AXIAL;10uH,10%,4.2x9.8mm 4 AA41-00546A PCB-A/V MONO;TF21B5S,FR-1,1L,A,1.6T,330X 2 AA95-01822B ASSY SUB-PCB,MASTER;20P1,C17A,AA95-01615 3 SW811S 3403-001107 SWITCH-PUSH;250V,5A,DPST,-,KDC-A04 3 6001-000057 SCREW-MACHINE;RH,+,M3,L6,ZPC(BLK),SWRCH1 3 CN801 AA39-00206B LEAD CONNECTOR-ASSY;,2P,YFH800-02,S,400M 3 AA61-10320A BRACKET-MASTER;T3350,SECC,T1.0,-,-,-,­3 AA97-05602A ASSY AUTO-SUB;20P1,C17A 4 PCB AA41-00587A PCB-MASTER;20P1,FR-1,1L,A,1.6T,245X245,C 4 EY801 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY802 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY803 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY804 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY805 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY806 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 GTM801 AA60-40014A PIN-GT,ASSY;AUTO 4 GTM802 AA60-40014A PIN-GT,ASSY;AUTO 2 AA61-00050A SPRING ETC-DOOR;TVCR TVI,SUS304,-,-,-,-, 2 AA90-00947A ASSY-FULL DECK;2HD,SVTS-M2P/XEC 3 AA91-00741A ASSY-DECK;,SCORPIO TOSHIBA 3 AA91-00744A ASSY-DRUM;,2HD,NON-DLC,SCORPIO 3 AA91-00782A ASSY-S-IMP ROLLER;,PAL 2HD SESA,TF14N53, 3 6006-001092 SCREW-ASS’Y MACH;WS,PH,+,M3.0,L6.0,ZPC(Y 2 AA96-01127B ASSY POWER CORD;DP,AA39-10001M,CP2,H/C40 3 AA39-10001MCBF POWER CORD;-,KJP-140,KLCE-2F,2.4m,HO 3 AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 2 AA64-03102D DOOR-HOUSING;14N3(SEH),ABS HB,BLK,GD-905 2 AA90-02598A ASSY COVER MISC-FRAME;SEH TVCR,STYX C17A 3 DE+FD 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 3 PW+FD 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 3 FD+BF 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW 3 AA61-00862A FRAME-DECK;S-PJT,HIPS V0,BLK,ONE-BOARD 3 AA61-01214A BRACKET-FRAME;,SECC,T1.0 3 AA63-00520A SHIELD-BOTTOM;20A5S,SPTE,T0.3 3 AA91-03961A ASSY-SHIELD DRUM;,AA63-00521A+TAPE,20A5 4 AA63-00521A SHIELD-DRUM;20A5S,SECC,T0.5 2 AA65-30009A CLAMPER CORE-FBT;-,ABS,V0,-,BLK,-
ASSY CPT
1 AA91-05780A ASSY CPT;C17A,14,PHILIPS,A34EAC01X06
2 LC801S AA27-00241A COIL DEGAUSSING;-,CPT TV 14INCH,-,10%,55 2 AA03-10023X CRT COLOR;A34EAC01X06,+380mG,2.5mH,27.5m 2 AA98-70032A ASSY TBC WIRE(P);DP,14,AA98-70014A,1P,TV 2 AA39-20518A LEAD CONNECTOR-ASSY;,6(4)P,YFH806-06,350
ASSY COVER FRONT
1 AA90-04403A ASSY COVER FRONT;TW14N34X/BWT,C17A
2 CB+CF 6002-000515 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(WHT),SWR 2 CRT+CF AA60-10050Q SCREW-ASSY;-,SWRCH18A,M5,L26.5,HH,+,WC,­2 AA65-30106A CLAMPER CORE-D,COIL;14 INCH,NYLON 66,V2, 2 AA96-01025A ASSY COVER P-FRONT;14N3,HB,GD-905P 3 HA83-00049A LP-ADHESIVE-HM;12MM,NTR 3 KF+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 3 IND+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 3 AA61-60003Q SPRING ETC-CS;-,SUS304,-,-,OD8,N5,OD8,-, 3 AA64-01066H KNOB-FAMILY;14N3 SEH,ABS ,HB,G3676,GD905 3 AA64-01067J KNOB-MASTER;14N3 SEH,ABS,HB,G3676,GD905P 3 AA64-01068B WINDOW REMOCON;14N5,PC,-,-,-,VIOLET,-,­3 AA64-01069B INDICATOR LED;14N5,ABS,-,-,LG-02431,-,­3 AA64-03101A CABINET FRONT;14N3 SEH,HIPS,HB,G7666,GD9 4 0201-001031 ADHESIVE-STR;AS-141-3B,-,0.85-1.05,­4 AA61-40010A BOSS-WING;-,HIPS,-,-,-,NTR,HB 5 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB 3 AA64-70127F BADGE-BRAND;NEW,AL,-,-,L40,R800,SILVER,S 2 AA96-40161A ASSY SPEAKER;-,8ohm,2W,77BR02N,-,200 3 3001-000281 SPEAKER;2.5W,8OHM,90DB,140HZ 3 AA39-20501A LEAD CONNECTOR-ASSY;,3(2),67096-003,REC, 2 AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, 2 HA68-02177B LABEL-PQS;ALL,30MM,65MM,WHITE,AA68-02177 2 AV+CF 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW 2 KP+CF 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW 2 HA68-02179A LABEL-RATING;58MM,53MM,WHITE 2 QMS HA83-00052A LP-TAPE-INK;,WIDTH 55 MM 2 RATING HA83-00052A LP-TAPE-INK;,WIDTH 55 MM
ASSY COVER REAR
1 AA90-04410A ASSY COVER REAR;TW14N34X/BWT
2 AA64-02220A CABINET-BACK;14N5S(NEW),HIPS,FV2,G4309 2 AA65-30008A CLAMPER CORE-CORD;-,PE,HB,-,BLK,-
ASSY P/MATERIAL
1 AA92-06759A ASSY P/MATERIAL;14N5
2 0203-001096 TAPE-CELLULOSE;#301,T0.06,W75,L400,WHT 2 AA81-00107A A/S-HOT-MELT;TERMOKOL 2305,CLR,TVCR PCAS 2 AA69-00744B BAG-SHEET;-,HDPE PE FOAM,T0.015,W900,H80 2 AA69-01378A CUSHION;14N5S(NEW),EPS C=0.02
ASSY ACCESSORY
1 AA92-07399A ASSY ACCESSORY;TW14N*4X/BWT
2 AA59-00221E REMOCON;,TM66,SAA5554PS,38,G6671B,S/S, 2 4301-000121 BATTERY-MN;1.5V,-,AAA,10.5x44.5m,HOLDER 2 HA69-00276A BAG VINYL;HDPE,T0.025,L400,W240,-,W/O LO 2 AA26-90001C TRANS MATCHING;-,300ohm/75ohm,PAL,40-890 2 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,­2 AA68-02264A MANUAL USERS;,RUS,W/P100(G),2,B5,C17A,56 2 HA68-00816B CARD WARRANTY;RUSSINA,2,W/P 120G,BOTH FA 2 AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/
Electrical Parts List
7-8 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
ASSY CHASSIS
1 AA91-05971A ASSY CHASSIS;TX14N34X/XEC,C17A,EU,PHILIP
2 AA94-12216A ASSY PCB POWER;C17A,14,EU,PHILIPS,548B 3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb 3 0204-001095 THINNER;#4520,-,-,­3 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,­3 Q401 0502-001115 TR-POWER;KSC5386,NPN,50W,TO-3PF,ST,8­3 PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST 3 NT801S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T 3 PT801S 1404-001264 THERMISTOR-PTC;4.5OHM,+30/-20%,220V,290V 3 CY801S 2201-000446 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x 3 CR410S 2303-001015 C-FILM,PPF;5.5nF,5%,1.6kV,TP,29x9.5x17,2 3 CR402S 2306-000195 C-FILM,MPPF;360nF,5%,400V,TP,26x19x11.5, 3 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm 3 C805 2401-000534 C-AL;150uF,20%,400V,GP,ST,25x30,10 3 RL801S 3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS, 3 CN502A 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH 3 CN801B AA39-20055B LEAD CONNECTOR-ASSY;,6P,YBNH025-06,67096 3 CN802B AA39-00180C LEAD CONNECTOR-ASSY;TF20P1,UL1007#26,UL/ 3 PCB+SC AA60-10008A SCREW-TAPPING;-,SWRCH18A,M3,L10,TH,+,-,­3 T801S AA26-00163A TRANS SWITCHING;35B125-DM,V17A,SMV-20A5S 3 T444S AA26-00192A TRANS FBT;FTK-21H001,CTV,3.7MH,FERRITE,E 3 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,-,-,7.1mH,-,-,102uH, 3 LR401S AA27-00122A COIL LINEARITY;90UH,90UH,L81 DR10x10,7.5 3 L402 AA27-40001M COIL HORIZ. WIDTH;-,180/480uH,SB-5S6202. 3 LX801S AA29-30001C FILTER LINE NOISE;-,39mH,1.0A,-,­3 GT101A AA39-20010D LEAD CONNECTOR-ASSY;,1P,YFH800-01,S,400, 3 AA61-01045A SUPPORT-PCB;DASS-T 9N,NYLON ,9.4,NTR 3 AA63-00609A SHIELD-CASE;DP,20P1,AA63-00518A 3 AA65-30014A CLAMPER CORE-WIRE;-,NYLON-66,V0,-,NTR,DA 3 AA65-30111A CLAMPER CORE-WIRE;ALL MODEL,NYLON,V0,-,W 3 D810 AA96-00243D ASSY H/S;-,BRIDGE,AA62-00045A,D06U20S,D 4 0205-000129 GREASE-SILICON;SC102,JAPAN 4 0402-001374 DIODE-RECTIFIER;FFPF06U20S,200V,6A,TO-22 4 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR 4 AA62-00065A HEAT SINK-PS;DP,-,-,-,AA62-00045A,-,-,-, 3 Q803 AA96-00243G ASSY H/S;-,POWER,AA62-00045A,C2073-H2,V 4 0205-000129 GREASE-SILICON;SC102,JAPAN 4 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6 4 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR 4 AA62-00065A HEAT SINK-PS;DP,-,-,-,AA62-00045A,-,-,-, 3 IC301 AA96-00244A ASSY H/S;-,-,AA62-00046A,LA7840,­4 0205-000129 GREASE-SILICON;SC102,JAPAN 4 1204-001483 IC-VERTICAL PROCESSO;LA7840,SIP,7P,708MI 4 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR 4 AA62-00064A HEAT SINK-PS;DP,-,-,-,AA62-00046A,-,-,-, 3 IC801S AA96-00662B ASSY H/S;-,POWER,AA62-30171J,KA5Q0765R, 4 0205-000129 GREASE-SILICON;SC102,JAPAN 4 1203-001932 IC-PWM CONTROLLER;5Q0765,TO-220F,5P,185M 4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 4 AA62-30171J HEAT SINK-ES;-,-,-,SILVER,-,DREAM1,-,-,­3 Q813 AA96-50305D ASSY H/S;-,POWER,AA62-30012E,KSD73Y,STY 4 0502-000298 TR-POWER;KSD73,NPN,30000mW,TO-220,TP,12 4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 4 AA62-30012E HEAT SINK-ES;-,A6063 EXTR,-,-,TO-220 H55 3 AA97-13452A ASSY AUTO-POWER;C17A,14,EU,PHILIPS,548B 4 D822 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D823 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D825 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D827 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D811 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D812 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D816 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D820 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 4 D806 0401-000006 DIODE-SWITCHING;BAV21,250V,250mA,DO-35,T 4 D828 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D815 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D301 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D405 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D809 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
4 D814 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L 4 D404 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T 4 D808 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 4 D403 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 4 D402 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 4 D804S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 4 D803S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 4 D802S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 4 D801S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 4 D807 0402-001443 DIODE-RECTIFIER;EGP20K,800V,2A,DO-15,TP 4 DZ401 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 4 DZ807 0403-000699 DIODE-ZENER;TZP27B,27V,27-30.8V,1W,DO-41 4 DZ810 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T 4 DZ303 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T 4 DZ805 0403-000714 DIODE-ZENER;MTZJ3.3B,3.3V,3.32-3.53V,500 4 DZ811 0403-000714 DIODE-ZENER;MTZJ3.3B,3.3V,3.32-3.53V,500 4 DZ804 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 4 DZ803 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 4 DZ808 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 4 DZ302 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D 4 DZ806 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500mW,DO 4 DZ802 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D 4 DZ301 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D 4 DZ304 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D 4 DZ813 0403-001373 DIODE-ZENER;MTZJ5.1A,4.81V-5.07V,500mW,D 4 DZ812 0403-001373 DIODE-ZENER;MTZJ5.1A,4.81V-5.07V,500mW,D 4 Q812 0501-000362 TR-SMALL SIGNAL;KSA2328A-Y,NPN,1W,TO-92L 4 Q811 0501-000362 TR-SMALL SIGNAL;KSA2328A-Y,NPN,1W,TO-92L 4 Q810 0501-000362 TR-SMALL SIGNAL;KSA2328A-Y,NPN,1W,TO-92L 4 Q402 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO­4 Q805 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 4 Q807 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 4 Q806 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 4 Q804 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T 4 Q808 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T 4 Q801 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL 4 VX801S 1405-000152 VARISTOR;560V,2500A,14x8.5mm,TP 4 R301 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM 4 R408 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M 4 R829 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 4 R825 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 4 R823 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4 4 R808 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4 4 R828 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M 4 R405 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M 4 R814 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R824 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R809 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R840 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R835 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R816 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R821 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R822 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R843 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R842 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R841 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R831 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R811 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R827 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R817 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R407 2001-001037 R-CARBON(S);0.39OHM,5%,1/2W,AA,TP,2.4X6. 4 R813 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4 4 R812 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4 4 R410 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4 4 R422S 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M 4 R409 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA,TP,2.4X6.4 4 R818 2001-001134 R-CARBON(S);360ohm,5%,1/2W,AA,TP,2.4x6.4 4 R838 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6. 4 R839 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6. 4 R830 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4 4 R806 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AA,TP,2.4X6.4 4 R810 2001-001192 R-CARBON(S);820OHM,5%,1/2W,AA,TP,2.4X6.4 4 RX801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x
Electrical Parts List
Samsung Electronics 7-9
7-2 TX14N34X/XEC
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
!
!
!
4 RY801S 2002-001012 R-COMPOSITION;8.2Mohm,5%,1/2W,AA,TP,3.7x 4 R805 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12 4 R804 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12 4 R803 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12 4 R315 2003-001018 R-METAL OXIDE(S);220ohm,5%,2W,AF,TP,3.9x 4 R303 2003-002070 R-METAL OXIDE;1ohm,5%,2W,AF,TP,3.9x10mm 4 R402 2003-002178 R-METAL OXIDE(S);1Kohm,5%,2W,AG,TP,3.9x1 4 R413 2004-001137 R-METAL;6.8Kohm,1%,1/8W,AA,TP,1.8x3.2m 4 R306 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm 4 R302 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm 4 R833 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6. 4 R815 2004-004089 R-METAL(S);123Kohm,1%,1/2W,AA,TP,2.5x6.5 4 R412 2004-004089 R-METAL(S);123Kohm,1%,1/2W,AA,TP,2.5x6.5 4 R406 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m 4 R404 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m 4 R414 2008-000264 R-FUSIBLE(S);1ohm,5%,1W,AF,TP,3.9x10mm 4 R317 2008-001013 R-FUSIBLE(S);1.2ohm,5%,2W,AF,TP,3.9x10mm 4 R415 2008-001031 R-FUSIBLE(S);1.8ohm,5%,1W,AF,TP,3.9x10mm 4 R411 2008-001015 R-FUSIBLE(S);1.5ohm,5%,2W,AF,TP,3.9x10mm 4 C302 2201-000259 C-CERAMIC,DISC;0.18nF,10%,500V,Y5P,TP,5. 4 C801 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250V,Y5U,TP,9x4 4 C817 2201-000374 C-CERAMIC,DISC;0.22nF,5%,50V,NP0,TP,10.5 4 C818 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. 4 C305 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. 4 C303 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5. 4 C814 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. 4 C408 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. 4 CR404S 2201-000639 C-CERAMIC,DISC;0.68nF,10%,2kV,Y5P,TP,9x5 4 C812 2201-000991 C-CERAMIC,DISC;0.56nF,10%,2kV,Y5P,TP,7.5 4 CR409S 2201-000991 C-CERAMIC,DISC;0.56nF,10%,2kV,Y5P,TP,7.5 4 C826 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP 4 C825 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP 4 C824 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 4 C809 2301-000016 C-FILM,PEF;22nF,5%,100V,TP,7.2x4.5x9.0mm 4 C816 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5 4 C807 2301-000235 C-FILM,PEF;3.9nF,5%,50V,TP,6.5x3.0x5.5mm 4 C310 2301-000254 C-FILM,PEF;39nF,5%,50V,TP,7.5x3.5x6.5mm, 4 C407 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 4 C411 2301-001065 C-FILM,MPPF;47nF,5%,630V,TP,19x15.5x7,7. 4 C806 2301-001435 C-FILM,PPF;1.5nF,5%,1.2kV,TP,15x8x12.5mm 4 C309 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5 4 C301 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15 4 CR405S 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm 4 C821 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 4 C810 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 4 C813 2401-000262 C-AL;100uF,20%,160V,HR,TP,16x25,7.5 4 C307 2401-000365 C-AL;100uF,20%,50V,WT,TP,10x12.5mm, 4 C815 2401-000703 C-AL;2200uF,20%,25V,GP,-,12.5x25mm, 4 C827 2401-000901 C-AL;22uF,20%,160V,GP,TP,10x20,5 4 C401 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5 4 C304 2401-001115 C-AL;330uF,20%,25V,GP,TP,10x12.5,5 4 C808 2401-001192 C-AL;33uF,20%,50V,GP,TP,6.3x11,5 4 C306 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5 4 C823 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 4 C820 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 4 C406 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5 4 C308 2401-003028 C-AL;100uF,20%,25V,WT,TP,6.3x11,5 4 C819 2401-003139 C-AL;1000uF,20%,25V,WT,TP,10*20,5mm 4 L401 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 4 L404 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 4 L302 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 4 L301 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 4 L405 2701-000159 INDUCTOR-AXIAL;22uH,10%,4.2x9.8mm 4 J804 2701-001030 INDUCTOR-AXIAL;43uH,10%,5x14mm 4 L804 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,­4 L403 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,­4 L803 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,­4 L802 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,­4 FP801S 3601-000261 FUSE-CARTRIDGE;250V,3.15A,TIME-LAG,GLASS 4 FD801S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS 4 FD802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS 4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm 4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm 4 J818 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J817 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J815 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J814 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
4 J813 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J824 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J822 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J821 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J820 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J819 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J812 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J806 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J805 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J803 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J802 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J801 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J811 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J810 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J809 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J808 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J807 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 PCB AA41-00548B PCB-POWER;TF21B5S,FR-1,1L,A,1.6T,245X245 4 EY811 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY812 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY813 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY814 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY815 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY802 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY803 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY804 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY805 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY806 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY816 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY822 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY825 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY827 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY828 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY829 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY817 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY818 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY819 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY820 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY821 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY801 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY406 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY407 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY408 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY409 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY410 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY401 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY402 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY403 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY404 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY405 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY411 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY419 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY420 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY421 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY422 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY423 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY412 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY414 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY415 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY416 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EY417 AA60-40011A K EYELET;ID2.0,OD2.8,BST 4 EL802 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL803 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL804 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL805 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL801 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL301 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL302 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL403 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 EL404 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 4 GT805 AA60-40014A PIN-GT,ASSY;AUTO 4 GT804 AA60-40014A PIN-GT,ASSY;AUTO 4 GT803 AA60-40014A PIN-GT,ASSY;AUTO 4 GT806 AA60-40014A PIN-GT,ASSY;AUTO 4 GT807 AA60-40014A PIN-GT,ASSY;AUTO 4 GT808 AA60-40014A PIN-GT,ASSY;AUTO 4 GT301 AA60-40014A PIN-GT,ASSY;AUTO
Electrical Parts List
7-10 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
4 GT302 AA60-40014A PIN-GT,ASSY;AUTO 4 GT401 AA60-40014A PIN-GT,ASSY;AUTO 4 GT402 AA60-40014A PIN-GT,ASSY;AUTO 4 GT801 AA60-40014A PIN-GT,ASSY;AUTO 4 GT802 AA60-40014A PIN-GT,ASSY;AUTO 4 HA68-02176A LABEL;LABEL 2 AA94-11847A ASSY PCB MISC-M/DECK;TF20P1D4X/XEF,C17A 3 0201-000280 ADHESIVE-TS;EH-260D,RED,450°æ50PS,10CC 3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb 3 0204-001095 THINNER;#4520,-,-,­3 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,­3 PTM601 0604-001122 PHOTO-INTERRUPTER;TR,0.065%,150mW,DIP-4, 3 PTM602 0604-001122 PHOTO-INTERRUPTER;TR,0.065%,150mW,DIP-4, 3 ICM602 1003-001318 IC-MOTOR DRIVER;LB11880,DIP,30P,417MIL,­3 IC601 1201-001386 IC-POWER AMP;7267,DIP,16P,-,DUAL,32dB,PL 3 XTM301 2801-000277 CRYSTAL-UNIT;4.433619MHz,8ppm,28-AAM,S,1 3 CNM302 3708-000394 CONNECTOR-FPC/FFC/PIC;6P,1.25mm,STRAIGHT 3 CNM301 3708-000394 CONNECTOR-FPC/FFC/PIC;6P,1.25mm,STRAIGHT 3 CNM602 3708-001053 CONNECTOR-FPC/FFC/PIC;7P,1.25mm,STRAIGHT 3 CNM303 3710-001648 CONNECTOR-SOCKET;2P,1R,2.5mm,STRAIGHT,SN 3 CN701A 3711-000628 CONNECTOR-HEADER;BOX,11P,1R,2.5MM,STRAIG 3 CN601B 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH 3 CN601A 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH 3 CN501A 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH 3 TPCN01 3711-002648 CONNECTOR-HEADER;BOX,9P,1R,2.5mm,STRAIGH 3 CNM603 3711-003749 CONNECTOR-HEADER;BOX,8P,2R,2mm,STRAIGHT, 3 CNM302 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm 3 CNM602 3809-001312 CABLE-FLAT;30V,80C,110MM,7P,1.25MM,UL289 3 FLM301 AA26-10006C TRANS RF;-,7MF,BIAS,2.4MH,7MM,-,65.3KHZ 3 SWM610 AA34-20001A SWITCH-MODE;1,25x14.6x29.8mm,BK,DC5V 3 SWM611 AA34-40001A SWITCH-REC.;1EA,37.5x14.4mm,BK,DC5V 3 W01 AA39-00046C LEAD CONNECTOR-ASSY;,1P,JUMPER,BLK,100MM 3 CN802A 3711-003975 CONNECTOR-HEADER;BOX,14P,1R,2.5mm,STRAIG 3 CN801A 3711-002645 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,STRAIGH 3 CNM601 AA39-20603A LEAD CONNECTOR-ASSY;,2P,GIL-S-2S-S2C2-S, 3 REM601 AA59-60003V MODULE REMOCON;-,SRV-18,38KHZ,940NM,MESH 3 GPM01 AA63-00444B GROUND;TVCR,PBS,T0.3,-,-,-,SUS-DECK 3 LDM601 AA91-60318A ASSY-HOLDER,LED;-,ABS,HB,BLK,IR LED,TS-D 4 LED 0601-001303 LED-IR;SIDE-VIEW,2.5mm,75mW,6V,950nm, 4 HOLDER AA61-00003A HOLDER-LED;TVN-502V,ABS,-,-,-,BLK,HB 3 SM602 AA91-60319A ASSY-HOLDER,SENSOR;-,ABS,HB,BLK,TR LED,T 3 SM601 AA91-60319A ASSY-HOLDER,SENSOR;-,ABS,HB,BLK,TR LED,T 4 TR 0603-001011 PHOTO TR;NPN,35V,6V,50mA,75mW,BK 4 HOLDER AA61-00005A HOLDER-SENSOR;TVN-502V,ABS,-,-,-,BLK,HB 3 LDM602 AA96-00462A ASSY LED GUIDE;-,-,DL-11S2R1,RED 3 AA97-12954A ASSY ROBOT;,C17A 4 IC702 0801-000213 IC-CMOS LOGIC;4052,MULTIPLEXER,DIP,16P,3 4 IC701 0801-000961 IC-CMOS LOGIC;4053,MUTIPLEXER,DIP,16P,30 4 IC902 1103-001177 IC-EEPROM;24WC16,2048x8Bit,DIP,8P,-,-,2. 4 SF101S 2904-001070 FILTER-SAW AV;38.9MHz,SIP5K,TP,14.6dB,B/ 4 JS701 3722-000183 JACK-SCART;21P,4mm,SN,BLK,NO 4 IC201S AA09-00285A IC MICOM;TDA9381PS/N2/3/0749,SPM-744WOT 4 TU01S HA83-00061A LA-TUNER;AA40-00076A 4 AA97-12969A ASSY AUTO;,C17A 5 DM609 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 DM603 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 DM301 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D601 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D205 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D202 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, 5 D602 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 5 D203 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 5 ZDM601 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ901 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ101 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 5 DZ206 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ510 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ701 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 ZDM602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ201 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ203 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 5 DZ205 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
5 DZ202 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO 5 QM312 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92, 5 Q701 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T 5 Q201 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T 5 QM315 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T 5 QM311 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T 5 QM305 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T 5 QM317 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 QM304 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 Q205 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 5 QM605 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM604 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM603 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM308 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM306 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM302 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM301 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T 5 QM314 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 5 QM313 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 5 QM303 0504-000119 TR-DIGITAL;KSR1004,NPN,300MW,47K/47K,TO­5 Q601 0504-000123 TR-DIGITAL;KSR1010,NPN,300mW,10K,TO-92,T 5 ICM603 1203-000642 IC-RESET;572,TO-92,3P,-,PLASTIC,2.35/2. 5 RM638 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM633 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM632 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM319 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM318 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM655 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM654 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 R205 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm 5 RM352 2001-000006 R-CARBON;2.4KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM370 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R212 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM612 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM610 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM644 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R203 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R711 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4 5 RM641 2001-000118 R-CARBON(S);180OHM,5%,1/2W,AA,TP,2.4X6.4 5 RM316 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM349 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM335 2001-000232 R-CARBON;1.3KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM307 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM323 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM358 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM339 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM623 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R915 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R916 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R917 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R911 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R910 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM668 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM667 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM666 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM665 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM664 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM663 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R503 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R502 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R501 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R216 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R209 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R208 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R908 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R906 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R905 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R712 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R901 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R902 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM639 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM637 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
Samsung Electronics 7-11
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
5 RM619 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM615 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM614 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM697 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM696 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM693 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM692 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM670 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM656 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R718 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R710 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R709 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R707 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R601 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R504 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM360 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R923 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R922 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R907 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R920 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R921 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM606 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM671 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM303 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R604 2001-000347 R-CARBON;13KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM305 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM356 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R218 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM657 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM674 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM678 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM679 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM653 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM651 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM650 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM649 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM648 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM682 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM694 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM690 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM689 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM688 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM687 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM686 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM685 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM684 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM683 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM647 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM605 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM362 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM361 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM341 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM333 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM317 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM312 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM310 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R903 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM609 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM643 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM629 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM628 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM626 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM625 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM613 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM621 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM622 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM624 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM340 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R913 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R912 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM344 2001-000454 R-CARBON;2.2MOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM359 2001-000458 R-CARBON;2.2OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM346 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM334 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM313 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R210 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R211 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
5 RM372 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM326 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM315 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM660 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM642 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM602 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM363 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM354 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R706 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R722 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R227 2001-000531 R-CARBON;240KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM669 2001-000539 R-CARBON;24KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM661 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM601 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM320 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R605 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R204 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R206 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM675 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R214 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM640 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R719 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM304 2001-000645 R-CARBON;330KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM616 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM604 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM306 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R704 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R201 2001-000689 R-CARBON;390KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM331 2001-000723 R-CARBON;4.3KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM636 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM635 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM634 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM365 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM345 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R221 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R914 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R919 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM324 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R220 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R219 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM379 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM328 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM357 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM327 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM618 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM377 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM375 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R226 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R223 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R106 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R207 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM369 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM373 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM351 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM302 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R703 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R702 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM611 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM348 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM347 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM627 2001-000850 R-CARBON;560KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R202 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM607 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM353 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM314 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R225 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R107 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM380 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM350 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM329 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R105 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R215 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R721 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 R714 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R715 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R716 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R717 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
7-12 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
5 R720 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R222 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R705 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R708 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R713 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM338 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M 5 RM378 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 RM371 2001-001000 R-CARBON;82KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R224 2001-001026 R-CARBON;910OHM,5%,1/8W,AA,TP,1.8X3.2MM 5 R213 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm 5 RM630 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m 5 CM319 2201-000345 C-CERAMIC,DISC;0.2nF,5%,50V,SL,TP,7x3,5 5 C226 2201-000472 C-CERAMIC,DISC;0.33nF,5%,50V,SL,TP,8.5x3 5 CM316 2201-000499 C-CERAMIC,DISC;0.39nF,5%,50V,SL,TP,8.5x3 5 C906 2201-000573 C-CERAMIC,DISC;0.047nF,5%,50V,NP0,TP,5x3 5 C905 2201-000573 C-CERAMIC,DISC;0.047nF,5%,50V,NP0,TP,5x3 5 CM359 2201-000611 C-CERAMIC,DISC;0.056nF,5%,50V,NP0,TP,7x3 5 CM360 2201-000611 C-CERAMIC,DISC;0.056nF,5%,50V,NP0,TP,7x3 5 CM315 2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP, 5 CM640 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP 5 CM613 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM612 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM397 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM396 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM379 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM378 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM615 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CT19 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM656 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM635 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM634 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM624 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM621 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM330 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM321 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM313 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 C602 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 C106 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 C102 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM334 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM349 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM341 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM338 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM337 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM336 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM335 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V 5 CM318 2202-000162 C-CERAMIC,MLC-AXIAL;0.015NF,5%,50V,SL,TP 5 CM636 2202-000183 C-CERAMIC,MLC-AXIAL;2.2NF,20%,16V,Y5R,TP 5 CM637 2202-000183 C-CERAMIC,MLC-AXIAL;2.2NF,20%,16V,Y5R,TP 5 CM610 2202-000205 C-CERAMIC,MLC-AXIAL;22pF,5%,50V,SL,TP,1. 5 CM609 2202-000205 C-CERAMIC,MLC-AXIAL;22pF,5%,50V,SL,TP,1. 5 CM314 2202-000216 C-CERAMIC,MLC-AXIAL;0.027NF,5%,50V,SL,TP 5 C716 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP 5 C715 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP 5 C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP 5 C731 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3. 5 CM638 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP 5 CM395 2202-000279 C-CERAMIC,MLC-AXIAL;47pF,5%,50V,SL,TP,3. 5 CM606 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM394 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM393 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM367 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM358 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM659 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM652 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM651 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM631 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM607 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM327 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM301 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 C231 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 C205 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 C204 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM354 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM352 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM342 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
5 CM339 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM329 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 5 CM617 2202-000718 C-CERAMIC,MLC-AXIAL;3.9nF,20%,16V,Y5R,TP 5 CM616 2202-000718 C-CERAMIC,MLC-AXIAL;3.9nF,20%,16V,Y5R,TP 5 C704 2202-000719 C-CERAMIC,MLC-AXIAL;6.8nF,20%,16V,Y5R,TP 5 CM325 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 CM650 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 CM657 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 C904 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 C224 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 C223 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 5 CM601 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP 5 CM630 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM629 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM628 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM622 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM604 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM351 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM347 2202-000807 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V 5 CM320 2202-000849 C-CERAMIC,MLC-AXIAL;18pF,5%,50V,CH,TP,3. 5 C211 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V 5 C911 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V 5 CL08 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V 5 CM350 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V 5 CM345 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V 5 CM309 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V 5 C227 2301-000104 C-FILM,PEF;1.2NF,5%,50V,TP,6.5X3.0X5.5MM 5 CM372 2301-000160 C-FILM,PEF;12nF,5%,50V,TP,11.0x6.0x9.0mm 5 CM368 2301-000175 C-FILM,PEF;15nF,5%,50V,TP,7.1x3.5x13mm,5 5 CM306 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm 5 C201 2301-000204 C-FILM,PEF;2.7nF,5%,50V,TP,7.4x3.9x13mm, 5 C604 2301-000204 C-FILM,PEF;2.7nF,5%,50V,TP,7.4x3.9x13mm, 5 C108 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5 5 CM370 2301-000254 C-FILM,PEF;39nF,5%,50V,TP,7.5x3.5x6.5mm, 5 CM362 2301-000301 C-FILM,PEF;6.8nF,5%,50V,TP,6.5X5.5X3.0X5 5 CM363 2301-000301 C-FILM,PEF;6.8nF,5%,50V,TP,6.5X5.5X3.0X5 5 CM371 2301-000301 C-FILM,PEF;6.8nF,5%,50V,TP,6.5X5.5X3.0X5 5 CM603 2301-000310 C-FILM,PEF;68nF,5%,50V,TP,8.0X8.5X4.0X5, 5 CM364 2301-000314 C-FILM,PEF;8.2nF,5%,50V,TP,6.5x3.0x5.5mm 5 C217 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, 5 CM305 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, 5 CM303 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 5 C903 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 5 C232 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm 5 CM660 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 5 C712 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 5 C216 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 5 C215 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 5 C901 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm 5 C207 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm 5 CM311 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C909 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C230 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C218 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C210 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C208 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 5 C225 2309-000138 C-FILM,PE-PPF;100nF,5%,50V,TP,20x16x8.5, 5 C233 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5 5 C104 2401-000939 C-AL;22uF,20%,25V,GP,TP,5x11,5 5 CM332 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 5 CM323 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 5 CM304 2401-000426 C-AL;10uF,20%,16V,GP,TP,3.5x5,5 5 CM361 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM348 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM333 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM331 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM317 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM310 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 C605 2401-000590 C-AL;1uF,20%,50V,GP,TP,3x5,5 5 CM611 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 5 CM346 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 5 CM344 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 5 C219 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 5 CM392 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 5 C212 2401-000647 C-AL;2.2uF,20%,50V,BP,TP,5x11,5 5 C221 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 5 CM308 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
Electrical Parts List
Samsung Electronics 7-13
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
5 CM355 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 5 CM324 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 5 C606 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 5 C101 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5 5 CT18 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5 5 C601 2401-001115 C-AL;330uF,20%,25V,GP,TP,10x12.5,5 5 CM307 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 5 CM365 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 5 CM639 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 5 CM326 2401-001325 C-AL;470nF,20%,50V,GP,TP,3x5,5 5 CM605 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM602 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM399 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM373 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM312 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM340 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM343 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7,5 5 CM632 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C907 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C902 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C229 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C209 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C213 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C214 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 5 C228 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 5 CM623 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm 5 CM641 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 5 CM357 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 5 CM353 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 5 C603 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 5 C711 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C713 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C714 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C717 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 CL06 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 CM328 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C710 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C103 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C206 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C220 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C234 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C701 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 C702 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm 5 CM356 2401-002462 C-AL;33uF,20%,16V,GP,TP,5x11,5 5 C203 2401-002462 C-AL;33uF,20%,16V,GP,TP,5x11,5 5 C202 2401-002462 C-AL;33uF,20%,16V,GP,TP,5x11,5 5 CM618 2401-002463 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 5 C705 2401-002463 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 5 LM603 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 5 LM602 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 5 LM306 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 5 LM301 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm 5 LM307 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM305 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM304 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM309 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM601 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM604 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM605 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L201 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L202 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L203 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L701 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L902 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L704 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 L702 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm 5 LM303 2701-000118 INDUCTOR-AXIAL;120uH,10%,2.5x3.4mm 5 L206 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 5 L205 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 5 L102 2701-000159 INDUCTOR-AXIAL;22uH,10%,4.2x9.8mm 5 L204 2701-000169 INDUCTOR-AXIAL;3.9uH,10%,2.5x3.4mm 5 L101 2701-000171 INDUCTOR-AXIAL;330nH,10%,2.5x3.4mm 5 L903 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 L901 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 LM310 2701-000180 INDUCTOR-AXIAL;33uH,5%,2.5x3.4mm 5 LM302 2701-000207 INDUCTOR-AXIAL;56uH,5%,2.5x3.4mm 5 LM308 2702-000120 INDUCTOR-RADIAL;15mH,5%,6.2x7.4mm
5 XTM601 2801-003750 CRYSTAL-UNIT;8MHZ,30PPM,28-AAA,22PF,80OH 5 X901 2801-003937 CRYSTAL-UNIT;12MHz,25ppm,28-AAM,30pF,30o 5 L104 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5, 5 L103 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5, 5 Z202 2903-000181 FILTER-CERAMIC;BR,5.5MHz,-,-,-,TP,TPS5.5 5 Z201 2903-001040 FILTER-CERAMIC;TR,5.5/6.0/6.5MHz,-,1dB,­5 SWM706 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM707 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM708 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM709 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM705 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM701 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM702 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM703 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 SWM704 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP 5 JB902 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB903 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB905 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB906 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB907 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB901 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB802 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB803 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB804 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB805 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB806 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB908 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG006 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG007 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG008 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG009 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG010 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG005 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB909 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG001 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG002 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG003 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG004 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V12 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V05 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V09 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V10 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V12 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V13 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA5V01 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J272 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J273 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J275 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J276 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JA33 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB1201 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V04 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V07 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V08 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V09 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V11 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V03 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB1203 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB3301 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB3302 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V01 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JB5V02 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG042 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG043 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG046 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JJ02 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP01 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG041 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG036 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG037 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG038 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG039 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG040 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP03 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JPM303 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JPM306 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JTV500 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
Electrical Parts List
7-14 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
5 JTV501 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 L703 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JPM302 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP04 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP05 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP06 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JP10 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JPM301 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG035 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG017 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG018 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG019 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG020 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG022 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG016 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG011 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG012 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG013 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG014 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG015 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG023 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG030 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG031 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG032 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG033 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG034 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG029 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG024 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG025 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG026 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG027 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 JG028 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J150 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J151 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J152 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J153 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J158 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J148 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J142 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J143 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J144 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J146 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J147 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J159 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J169 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J170 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J171 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J172 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J173 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J168 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J160 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J161 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J162 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J166 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J167 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J141 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J109 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J110 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J111 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J113 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J117 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J108 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 D101 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 DM601 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J103 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J106 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J107 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J120 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J136 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J137 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J138 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J139 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J140 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J135 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J121 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J122 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J123 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
5 J124 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J125 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J225 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J226 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J227 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J228 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J229 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J224 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J217 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J218 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J219 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J222 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J223 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J231 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J260 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J261 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J262 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J264 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J265 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J259 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J234 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J235 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J256 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J257 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J258 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J216 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J185 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J186 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J187 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J189 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J194 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J179 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J174 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J175 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J176 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J177 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J178 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J195 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J203 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J205 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J209 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J210 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J211 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J202 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J196 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J197 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J198 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J200 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 J201 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 5 HIC01 AA13-20004W IC HYBRID;-,PAP103T,SIP,6P,PRE-AMP,TP 5 GT01 AA60-40014A PIN-GT,ASSY;AUTO 5 GT02 AA60-40014A PIN-GT,ASSY;AUTO 5 A AA97-12501A ASSY SMD;CMC13410X/KMT 6 ICM301 1204-001649 IC-VIDEO PROCESS;LA71598M,QFP,100P,-,PLA 6 PCB AA41-00549C PCB-MAIN;TF20P1D4X,FR-1,1L,C,1.6T,330X24 6 AA97-06858A ASSY MICOM;,C17A,UPD784928,SNM-740MD,011 7 ICM601 AA09-00261A IC MICOM;UPD784927GF-230-3BA,TF20P1DF,1 6 HA68-02176A LABEL;LABEL 3 C612 2401-000703 C-AL;2200uF,20%,25V,GP,-,12.5x25mm, 3 C607 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm 2 AA94-11859A ASSY PCB CRT;14,C17A 3 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb 3 0204-001095 THINNER;#4520,-,-,­3 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,­3 V999S 3704-001112 SOCKET-CRT;8P,12PI,22.5PI,NI,­3 CN502B AA39-20052A LEAD CONNECTOR-ASSY;,4P,YBNH025-04,YSH02 3 CN501B AA39-20069C LEAD CONNECTOR-ASSY;,5P,YBNH025-05,67096 3 IC501 AA96-00842A ASSY H/S;,VIDEO,AA62-30175D,TDA6107Q 4 IC501 1201-001541 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA 4 SCR501 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR 4 H/S501 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 3 AA97-13016A ASSY AUTO-MAIN;CS21A5 4 D504 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D503 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D502 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 4 D501 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP
Electrical Parts List
Samsung Electronics 7-15
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
