Samsung SyncMaster SM710NT, SyncMaster SM711XT, SyncMaster SM720XT, SyncMaster SM920XT, SyncMaster SM220TN Brochure & Specs

imagine an all-in-one monitor

Samsung SyncMaster™ Thin Client Monitors

www.samsung.com/uk/business

The new wave of office computing

Server-based computing is an increasingly popular alternative to having a PC on every desk. Samsung thin

client monitors take server-based computing to a new level of convenience and affordability. By combining

a premium quality LCD monitor with a built-in thin client in one space-efficient unit, they offer an even lower

total cost of ownership and simpler maintenance and support.

www.samsung.com/uk/business

Thin Client

Each thin client provides basic computing functions: connecting
to a server via the network, transmitting input signals to the
server, and showing output of performance.

SBC (Server-Based Computing)

In SBC environments, multiple thin clients are connected to a
central server via the network. In big installations there may be
more than one server - it may be a cluster of terminal servers
with failover. This IT solution enhances efficiency of installation,
maintenance, security, and virus protection compared to the
conventional computing environment that consists of multiple PCs.

Server-Based Computing with Client Monitor

Client Monitor Client Monitor

Client Monitor Client Monitor

Server

Thin Clients offer:

• High reliability

• Low power consumption, heat and noise generation

• High data security

• Ease of management

• Ease of updates

• Vastly reduced desktop maintenance costs

• Quick to swap out and replace

• Central processing, so ease of maintenance, backup,
server consolidation

• Less desktop space needed

• Ease of ability to change network configuration

• Ease of assigning user privileges

• Low cost of maintenance – no need for IT people
to be deskside

Combined PC
& Monitor Solutions

imagine a cost effective, stylish

& easy to use monitor solution

Education

Benefits: Tamper proof; low cost; easy to look after; easy to
boot; easy to troubleshoot; resilient; low cost of ownership; do
not go obsolescent easily; no viruses.

• Easy to configure and use

• Not possible to change settings so great for multiple users in
classroom environment

• Easy to manage remotely

• Very low cost of ownership and easy to maintain

• Resilient and tamperproof

Finance

Benefits: Fast; multiple screen possibility; low down time;
virus free; highly secure; easy to manage multiple units across
organisations.

• Security and compliance

• Easy maintenance

• Reliable and quick to swap out

• Ideal for home working

• Easy to add new features

• Low heat, power consumption and noise levels

Healthcare

Benefits: Highly secure; flexible; no data; reliable; easy to
manage; easy to deploy and manage remotely.

• Personnel can log in on any thin client and have access to their own
desktop and applications

• Cost effective

• Complete confidentiality of data

• Ideal for remote working

• Easy to manage both on site and remote devices

• Easy to upgrade features via management software

• Easy to deploy

Retail

Benefits: Quick to boot up; virus free; easy to deploy remotely
and manage remote units; easy to add peripherals (bar code
scanners, printers, registers etc), plus space to store local
copies of the bar code and pricing database.

• Easy to install and manage in remote locations

• Easy to attach POS peripherals

• Ability to store barcode and pricing database locally, in case of network outage

• No local data – all transactions recorded centrally

• Updates to all remote terminals easy with remote management software

Government

Benefits: Highly secure; easy to manage large numbers of
these; virus free; easy to deploy.

• Highly cost effective

• Highly secure

• Easy to deploy both on site and remotely

• Low cost to purchase and to maintain

• Easy to manage vast quantities of devices centrally

Samsung Thin Client and your work environment

Thin Client monitor solutions are set to revolutionize the modern work environment. Their time saving, cost

saving and space saving benefits offer unparalleled access and security. Below we have highlighted some

key sectors and the opportunities thin client solutions offer.

www.samsung.com/uk/business

Unrivalled performance and reliability as standard

Samsung’s thin client monitors are everything you would expect from the world’s number one manufacturer

of LCD screens. Combining the latest technology with outstanding design, they deliver vibrant images and

crystal clear audio, while taking up no more room than a standard monitor. For the ultimate in clutter-free

working they can even be wall-mounted.

Built-in Speakers

Integrated speakers for a sleek,
uncluttered design

Best Quality LCD Screen

Premium display technology from the
world’s Number 1 LCD manufacturer

MagicSpeed

Fast image processing delivers high
quality moving images

Adjustable Height

Height adjustable for viewing
comfort and ergonomic working

Diverse Connectivity

Multiple USB 2.0 connectivity makes
it easy to add peripherals

Standard Features

Innovation & Design

Magic Rotation

Rotating display lets you switch
between landscape and portrait
viewing for total convenience

Embedded Browser

Lets you use simple internet
functions without connecting to
the server

SM710NT, SM711XT, SM720XT, SM920XT

Thin Client Monitor Range

Single Unit Thin Client LCD Monitors

Samsung’s SyncMaster™ thin client monitors provide an ideal
solution for server-based computing. With complete thin client
functionality built-in, they help businesses save costs and
reduce energy consumption. A single all-in-one design reduces
maintenance and installation costs and offers outstanding
space efficiency .

SM710NT
SM711XT
SM720XT
SM920XT

SM710NT

Specifications

• 17” LCD with Built-in Thin Client Module

• Resolution 1280 x 1024

• Win CE Platform

• 333MHz CPU

• MS RDP, Citrix ICA

• 128MB DDR, 32MB FDM

•

Fast Ethernet LAN (100Mbps)

• Built-in Speaker (1Wx2, Headphone Out/Line in)

• Client Management Program

Features

An Ideal Thin Client

Microsoft Windows CE is embedded on the SyncMaster™ 710NT and Windows
XP is embedded on 711XT/720XT/920XT. This guarantees full compatibility
with Microsoft Windows Server by supporting RDP (Remote Desktop Protocol),
making the monitors perfect streamlined thin client solutions. Each Samsung
thin client also supports the ICA protocol and enables connection to Citrix
environments.

Single Unit, Compact Design

Everything is in a single package - thin client CPU and network module, as well
as monitor speakers and adaptor - for maximum space efficiency.

Flexible Functionality

Four USB ports (2 on the side, 2 in the rear) are provided for connection with
various peripherals. An embedded browser enables you to use simple Internet
functions even without connecting to the server and to open files saved on
storage devices connected via the USB ports. In addition, the monitors can be
connected to other monitors via the signal output function, offering a dual monitor
capability.

Best Quality LCD Monitor

The name says it all. The SyncMaster™ 710NT/711XT/720XT/920XT boast
everything Samsung’s SyncMaster monitors are famous for - clear, vivid images
and a variety of additional functions for market-leading LCD quality.

SM711XT
Specifications

• 17” LCD with Built-in Thin Client Module

• Resolution 1280 x 1024

• Win XPe Platform

• 500MHz CPU

• MS RDP, Citrix ICA

• 256MB DDR, 1GB FDM

• Fast Ethernet LAN (100Mbps)

• Built-in Speaker (1Wx2, Headphone Out/Line in)

• Client Management Program

SM720XT
Specifications

• 17” LCD with Built-in Thin Client Module

• Resolution 1280 x 1024

• Win XPe Platform

• 1GHz CPU

• MS RDP, Citrix ICA

• 256MB DDR, 1GB FDM

• Gigabit Ethernet LAN (1Gbps)

• Built-in Speaker (1Wx2, Headphone Out/Line in)

• Client Management Program

SM920XT
Specifications

• 19” LCD with Built-in Thin Client Module

• Resolution 1280 x 1024

• Win XPe Platform

• 1GHz CPU

• MS RDP, Citrix ICA

• 256MB DDR, 1GB FDM

• Gigabit Ethernet LAN (1Gbps)

• Built-in Speaker (1Wx2, Headphone Out/Line in)

• Client Management Program

SM710NT, SM711XT, SM720XT, SM920XT

Thin Client Monitor Range

“Vibrant SyncMaster™ LCD displays with
built-in thin client functionality. The ultimate
small footprint network computers.”

Samsung’s Premium Thin Client Monitor

With a built-in webcam, stereo speaker and microphone,
the SM220TN provides everything you need for unified
communications including VoIP, instant messaging, audio and
video conferencing. The 22-inch screen size is ideal for
Microsoft Vista™ and other widescreen applications, making
this the perfect thin client monitor for forward-looking businesses.

SM220TN

Specifications

• 22” wide LCD with Built-in Thin Client Module

• Resolution 1680 x 1050

•

Win XPe Platform

•

256MB DDR, 1GB FDM

•

MS RDP, Citrix ICA

•

Built-in Web Cam, MIC & Speaker (2x1.5W)

•

TCP/IP with DNS/DHCP (100Mbps)

•

Office/Media File Sharing

•

VGA In

•

SIP, H.263, G.711

“The SM220TN is the ultimate Thin
Client Monitor for the twenty-first century
business, combining stunning design
with the latest interactive communication
features.”

SM220TN

Thin Client Monitor Range

Features

An integrated webcam, speaker and microphone make the SM220TN the
ultimate solution for the next wave of business communications including video
conferencing, VoIP and Instant Messaging.

A convenient all-in-one solution that’s easy to install, maintain and support, with
no need for additional peripherals. An ideal solution for call centres, internet cafés
and school IT labs to name a few.

With Microsoft OCS and Live Messenger certification, the SM220TN enables
businesses to take advantage of the time and cost-saving benefits of Microsoft
unified communications, without the risk of system errors.

The 22-inch wide screen is the optimum size for Windows Vista™. It is also
designed to accommodate web content, DVD, games and other widescreen
applications in line with evolving wide aspect technologies.

A stunning design with touch-sensitive buttons, high gloss black finish and
invisible speakers.

Model shown SM710NT

“

”

The public sector spends £1bn a year on PCs
and has for some time questioned the security
implications of the technology. As a result the
government plans to move to thin client computers
to help tackle security issues. A move to a thin client
architecture will have major implications – Whitehall
alone uses more than 250,000 PCs and there are an
estimated five million across the whole public sector.

John Suffolk, Whitehall Chief Information Officer (CIO)

Introducing Avnet

Avnet is one of the largest specialist IT distributors in the World. They use their experience and expertise

to ensure their reseller partners have all the information they need to sell IT technology effectively to you,

the Corporate End Users. In the UK, Avnet is one of the largest and most experienced distributor of server

based computing solutions. Their years of experience in this marketplace allows them to work with both

reseller partners and their end user customers to provide help and advise on all topics. They sell thin

client hardware and application delivery software solutions, including remote access software; application

streaming and virtual desktop. They offer services such as pre-configuration; installation; asset tagging;

bespoke device re- imaging; help with WEEE recycling of old kit and disposal of packaging, amongst

many others.

Avnet - the Thin Client
Specialist

Why Thin Client?

The Personal Computer has ruled the roost for a considerable number of years and as a basic computing

tool has served its purpose well. However, over the years, the true costs of employing a computing device

which is open to abuse from both internal and external influences have become apparent. A thin client

at its simplest is a device which has no hard disk drive or fan, no huge operating system, no method of

storing data. It connects to a central computer via a network and allows key presses and mouse clicks to

be sent to the computer and allows screen updates to be transmitted back to the monitor. All computing

takes place in a server running Microsoft’s Terminal Server. As far as a user is concerned, they are using

a PC, they see the same response time, the same applications, the same flexibility. But, the application

is running on a remote server, no data is travelling between the client and the server. What this gives any

organisation is a computing system that is secure from virus attack, and hijacking of data; allows multiple

devices both on and off site to be managed from a remote location; does not need updating that often

(but if it does, can be done via the management tool); reduces network bandwidth costs; allows working

from home to be as secure as working on site; the low power consumption means a vast reduction in

consumed power and heart generation; if a unit goes wrong it is simply swapped out – no lengthy re-

imaging tasks required. The choice is simple.

www.samsung.com/uk/business

Samsung Electronics (UK) Ltd

Samsung House, 1000 Hillswood Drive, Chertsey, Surrey KT16 0PS, Tel: [phone]

www.samsung.com/uk/business

In line with Samsung’s commitment to continuous improvement this guide is subject to change without notice. E&OE.

Specifications

SM710NT SM711XT SM720XT SM920XT SM220TN

Processor Speed 333MHz 500MHz 500MHz 500MHz 500MHz

Operating System Microsoft Windows CE Microsoft Windows XPe Microsoft Windows XPe Microsoft Windows XPe Microsoft Windows XPe

Memory 128MB DDR

32MB FDM

256MB DDR
1GB FDM

256MB DDR
1GB FDM

256MB DDR
1GB FDM

256MB DDR
1GB FDM

Network Speed 100Mbps 100Mbps 1Gbps 1Gbps 100Mbps

Panel

Viewable area

17” 17” 17” 19” 22”

Pixel Pitch(mm) 0.264 0.264 0.264 0.294 0.282

Brightness(cd/m2)(typ.) 300 cd/m

2

300 cd/m

2

300 cd/m

2

300 cd/m

2

300cd/m

2

Contrast Ratio(typ.) 600:1 600:1 600:1 1,000:1 700:1

Viewing Angle(H/V) 160˚/160˚ (CR>5) 160˚/160˚ (CR>5) 160˚/160˚ (CR>5) 160˚/160˚ (CR>5) 160˚/160˚ (CR>5)

Response Time(ms)(typ.) 8 8 8 5 8

Frequency

Horizontal Frequency(kHz)

30~81 30~81 30~81 30~81 170˚/160˚

Vertical Frequency(Hz) 56~75 56~75 56~75 56~75 56~75

Maximum Resolution 1280x1024 1280x1024 1280x1024 1280x1024 1680x1050

Color Supported 16.2 Mil. 16.2 Mil. 16.2 Mil. 16.7 Mil. 16.7 Mil.

Signal Input

Input Video Signal

Analog RGB Analog RGB Analog RGB Analog RGB Analog RGB

Sync. Type Separate H/V, Composite Separate H/V, Composite Separate H/V, Composite Separate H/V, Composite Separate H/V, Composite

Input Connectors 15pin D-sub 15pin D-sub 15pin D-sub 15pin D-sub 15pin D-sub

Plug & Play DDC 2B DDC 2B DDC 2B DDC 2B DDC 2B

USB powered hub option 0 0 0 0 0

Mac compatibility 0 0 0 0 0

Power

On Mode

40 Watts (typ.) 70 Watts (typ.) 70 Watts (typ.) 58Watts (typ.) 50Watts (typ.)

DPMS Mode < 2 Watt < 2 Watt < 2 Watt < 4 Watt < 2 Watt

Type Built-in Built-in Built-in Built-in Built-in

Multimedia Speakers 1W x 2 1W x 2 1W x 2 1W x 2 1W x 2

Wall-Mount VESA 100mm VESA 100mm VESA 100mm VESA 100mm VESA 100mm

TCO TCO’99 TCO’99 TCO’99 TCO’99 TCO’99

Cabinet Color Silver/Black Silver/Black Silver/Black, Black/Black Silver/Black, Black/Black Black/Black

Other include accessories - - - - -

Dimension

Set(W*H*D)(mm) (with stand)

370.0x404.0x200.0 370.0x404.0x200.0 370.0x404.0x200.0 416.6x420.9x200.0 520.0x452.0.x202.0

Set(W*H*D)(mm) (w/o stand) 370.0x342.3x60.3 370.0x342.3x69.0 370.0x342.3x69.0 416.6x375.2x74.7 520.0x399.0x68.5

Packing(W*H*D)(mm) 508x431x235 470x445x235 470x445 x235 490x485x236 612.0x525.0x246.0

Weight

Set(kg) 6.2 6.65 6.65 6.9 7.9

Packing(kg) 8.1 8.5 8.5 8.6 10.4

Stand

Function

Height Adjustable Stand Height Adjustable Stand Height Adjustable Stand Height Adjustable Stand Simple Stand

Type Swivel / Height Adjustable

/ Pivot

Swivel / Height Adjustable
/ Pivot

Swivel / Height Adjustable
/ Pivot

Swivel / Height Adjustable
/ Pivot

Tilt Only

Warranty 3 Years on site (NBD) 3 Years on site (NBD) 3 Years on site (NBD) 3 Years on site (NBD) 3 Years on site (NBD)
