Samsung SyncMaster 42TS, SyncMaster P50F, SyncMaster 42PS, SyncMasterP50Hn, SyncMaster 320MX Control Protocol

SEC-VD-DSW Multiple Display Control - 0008

Ver. 2.1

2008-06-26

Multiple Display Control Protocol

for SyncMaster 42TS/42PS P50Hn

P50F(n) P63F(n)
320MX(n) 400CX(n)
400MX(n) 460CX(n)

Copyright © 2003 2008 Samsung Electronics Co., Ltd

1

SEC-VD-DSW Multiple Display Control - 0008

Ver. 1.0

2008-06-26

Copyright notice

This document is Copyright © Samsung Electronics, Co. - all rights reserved.

「

This document is a technical asset of Samsung Electronics, Co. and using or copying

this material without the authorization from the technical data management group is strictly

prohibited..

」

Contact Information

Display S/W Group, VD Business Division

Samsung Electronics Co., Ltd

Address : 416, Maetan-3Dong, Paldal-Gu,

Suwon City, Kyungki-Do, Korea

442-742

Telephone : [phone]

E-mail : [email protected]

Prepared by :

Display S/W, Video Display Division.

Status :

Prepared

Subject :

Technical Writer, Programmer, Developer

Outline :

Protocol type document of Multiple Display Control 1.0

History :

Version Date Content Prepared by Compared by

1.0 2005. 01. 05. Protocol for Multiple Display Control S. Jang

1.1 2005. 01. 07 Add Safety Lock S. Jang

1.2 2005. 01. 18 Add Video Wall J. Lee

1.3 2005. 01. 26 modify Maintenance Control S. Jang

1.4 2005. 03. 11 modify Baudrate, PIP Control J. Lee

1.5 2005. 07. 04 Add Commands S. Jang

1.6 2005. 11. 11 Add Command ( Screen Scroll On) S. Jang

1.7 2006. 02. 01 Add Commands H. Park

1.8 2006. 10. 02 Add Commands H. Park

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

2

1.9 2006. 12. 18 Add Commands ( New Video Wall ) H. Park

Version Date Content Prepared by Compared by

2.0 2007. 04. 17. Add Commands H. Park

2.1 2008. 06. 26. Add Commands J. Choi

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

3

1. INTERFACE

1.1. Connecting Method

1) Connecting method

- As of Figure 1-1, connect RS232-In(9Pin) to Personal Computer, connect thenext
TV of Display to be connected from RS232-Out (9Pin).

- In doing so, each TV or Monitor ID can be given from 0 to 99.

- ID cannot be given duplicated.

- When granting ID, it does not need to be given out in the connecting order.

Figure1-1 PC,TV or Monitor connecting method

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

LCD 1

OUTIN

UART

LCD 2

OUTIN

UART

LCD 3

OUTIN

UART

LCD 4

OUTIN

UART

Personal

Computer

RS232

LCD 1

OUTIN

UART

LCD 2

OUTIN

UART

LCD 3

OUTIN

UART

LCD 4

OUTIN

UART

Personal

Computer

RS232

4

1.2. Connection Spec.

1) Connection Spec.

- Interactive communications using RS232.

- Of RS232 standards, three signals TxD(No.2), RxD(No.3) and GND(No.5) are used →

Refer to Figure 1

- Limit the distance between devices to less than 4m.

- Currently, out of 9 PIN RS232 terminal, PINS in use are numbers 2, 3 and 5.

- ID should show hexadecimal value of assigned ID, but ID 0 should be 0xFF.

- Every communication will be made in hexadecimals and Checksum is the sum of all

remainings. If it exceeds two digits, for example, it is 11+FF+01+01=112, discard the
number in the first digit like below.
example) Power On & ID=0

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x11 1 Power

→

Header Command

0xFF

Data Length

Data 1

12

0xAA 0x11 1 1

- If you want to control every mechanism connected with Serial Cable regardless of its

ID,setIDpartto"0xFE"andsendcommands.Atthetime,eachSETwillfollow
commands but it will not respond with ACK.

Table 2-1 RS232 Network spec

Bits Rate 9600 bps
Data Bits 8 bits
Parity None
Stop Bits 1 bit
Flow Control None

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

5

Figure 2-1 RS-232 pin out DB-9 pin used for Asynchronous Data

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

6

2. Commanding words

No Command Type Command Value Range

1 Status Control 0x00 -

2 Time Control 0x01 -

3 On Time Control 0x02 -

4 Off Time Control 0x03 -

5VideoControl 0x04 -

6AudioControl 0x05 -

7RGBControl 0x06 -

8 PIP Status Control 0x07 -

9 Maintenance Control 0x08 -

10 Serial Number Control 0x0B -

11 Display Status Control 0x0D -

12 Software Version Control 0x0E -

13 Model Number Control 0x10 -

14 Power Control 0x11 0~1

15 Volume Control 0x12 0 ~ 100

16 Mute Control 0x13 0 ~ 1

17 Input Source Control 0x14 -

18 ImageSizeControl 0x15 -

19 Direct Channel Control 0x16 -

20 Screen Mode Control 0x18 -

21 Screen Size Control 0x19 0 ~ 255

22 Red Offset Control 0x1A 0 ~ 100

23 Green Offset Control 0x1B 0 ~ 100

24 Blue Offset Control 0x1C 0 ~ 100

25 Contrast Control 0x24 0 ~ 100

26 Brightness Control 0x25 0 ~ 100

27 Sharpness Control 0x26 0 ~ 100

28 Color Control 0x27 0 ~ 100

29 Tint Control 0x28 0 ~ 100

30 Red Gain Control 0x29 0 ~ 100

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

7

31 Green Gain Control 0x2A 0 ~ 100

32 Blue Gain Control 0x2B 0 ~ 100

33 Treble Control 0x2C 0 ~ 100

34 Bass Control 0x2D 0 ~ 100

35 Coarse Control 0x2F 0 ~ 1

36 Fine Control 0x30 0 ~ 1

37 H-Position Control 0x31 0 ~ 1

38 V-Position Control 0x32 0 ~ 1

39 Clear Menu Control 0x34 0

40 Remote Control 0x36 0 ~ 1

41 RGB Contrast Control 0x37 0 ~ 100

42 RGB Brightness Control 0x38 0 ~ 100

43 PIP On/Off Control 0x3C 0 ~ 1

44 Auto Adjustment Control 0x3D 0

45 Color Tone Control 0x3E 0 ~ 4

46 Color Temperature Control 0x3F 0 ~ 10

47 PIP Source Control 0x40 -

48 Main-PIP Swap Control 0x41 0 ~ 1

49 PIP Size Control 0x42 -

50 PIP Locate Control 0x43 0 ~ 4

51 Sound Select Control 0x47 0 ~ 1

52 Pixel Shift Control 0x4C -

53 Video Wall Control 0x4F -

54 Auto Lamp Control 0x57 -

55 Manual Lamp Control 0x58 0 ~ 100

56 Safety Screen Run Control 0x59 0 ~ 6

57 Safety Screen Control 0x5B -

58 Video Wall Mode Control 0x5C 0 ~ 1

59 Safety Lock 0x5D 0 ~ 1

60 Panel Lock 0x5F 0 ~ 1

61 OSD On/OFF 0x70 0 ~ 1

62 P. Mode Control 0x71 -

63 S. Mode Control 0x72 0 ~ 4

64 NR Mode Set 0x73 0 ~ 1

65 PC Color Tone Control 0x75 0 ~ 3

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

8

66 Auto AutoAdjustment 0x76 0 ~ 1

67 All Keys Lock 0x77 0 ~ 1

68 SRS TSXT Control 0x78 0 ~ 1

69 Film Mode 0x79 0 ~ 1

70 Signal Balance 0x7A 0 ~ 1

71 SB Gain 0x7E 0 ~ 100

72 SB Sharpness 0x7F 0 ~ 100

73 Panel On Time 0x83 -

74 Video Wall On 0x84 0 ~ 1

75 Temperature Control 0x85 0 ~ 125

76 Brightness Sensor 0x86 0 ~ 1

77 Dynamic Contrast 0x88 0 ~ 1

78 Safety Screen On 0x88 1 ~ 5

79 Video Wall User Control 0x89 -

80 Model Name 0x8A -

"-" indicates multiple setting items-refer to "2.1. Command Detailed Explanation" for more
details.

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

9

2.1. Command Detailed Explanation

* Status Control

●

Function

Personal Computer shows current setting condition of TV / Monitor.

●

Get Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x00 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 9 'A' 0x00 Power Volume

Val 3 Val 4 Val 5 Val 6 Val 7

Check

Sum

Mute Input Aspect

NTimeNF FTimeNF

Power : Power code to be set on TV / Monitor
Volume : Volume value code ( 0 ~ 100 ) to be set on TV / Monitor
Mute : Mute code to be set on TV / Monitor
Input :InputSourcecodetobesetonTV/Monitor
Aspect : Image Size code to be set on TV/Monitor
NTimeNF: OnTime ON/OFF value of time to set TV/Monitor
FTimeNF : OffTime ON/OFF value of time to set TV/Monitor

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x00 ERR

ERR : Error code that shows what occurred error is

0 Check Sum Error
1etc.

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

10

* Time Control

●

Function

Personal Computer controls current time of TV / Monitor.

●

Get Time Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x01 0

●

Set Time

Header Command

ID

Data Length

Data 1 Data 2 Data 3 Data 4

0xAA 0x01 5 AP Time H Time M Time 0

Data 5

Check

Sum

0

AP Time :AM/PMvaluetobesetonTV/Monitor

1AM
0PM

HTime: Hour value ( 1 ~ 12 ) to be set on TV/Monitor
MTime: Minute value ( 0 ~ 59 ) to be set on TV/Monitor

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 7 'A' 0x01 AP Time H Time

Val 3 Val 4 Val 5

Check

Sum

MTime 0

0

AP Time, H Time, M Time :Sameasabove

H Time, M Time if current time was not set on Monitor, 0xFF

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x01 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

11

*OnTimeControl

●

Function:

Personal Computer controls the time that TV / Monitor turns on.

●

Get On Time Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x02 0

●

Set On Time

Header Command

ID

Data Length

Data 1 Data 2 Data 3 Data 4

0xAA 0x02 6

NAPTime NH Time NMTime NTimeVR

Data 5 Data 6

Check

Sum

NTimeNF NTimeSC

NAPTime: On Time AM/PM value to be set on TV/Monitor

1AM
0PM

NHTime: On Time Hour value ( 1 ~ 12 ) to be set on TV/Monitor
NMTime: On Time Minute value ( 0 ~ 59 ) to be set on TV/Monitor
NTimeVR:OnTimeVolumevalue(0~100)tobesetonTV/Monitor
NTimeNF: On Time ON/OFF value to be set on TV/Monitor

1OnTimeON
0OnTimeOFF

NTimeSC:

On Time ON/OFF Control Source value (refer to

Input Source Control )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 8 'A' 0x02

NAPTime NH Time

Val 3 Val 4 Val 5 Val 6

Check

Sum

NMTime NTimeVR NTimeNF NTimeSC

NAPTime,NHTime,NMTime,NTimeVR,NTimeNF,NTimeSC:Sameas

above
N H Time, N M Time if On Time was not set on Monitor, 0xFF

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x02 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

12

*OffTimeControl

●

Function

Personal Computer controls the time that TV / Monitor turns off.

●

Get Off Time Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x03 0

●

Set Off Time

Header Command

ID

Data Length

Data 1 Data 2 Data 3 Data 4

0xAA 0x03 6

FAPTime F H Time FMTime 0

Data 5 Data 6

Check

Sum

FTimeNF 0

FAPTime : Off Time AM/PM value to be set on TV/Monitor

1AM
0PM

FHTime : Off Time Hour value ( 1 ~ 12 ) to be set on TV/Monitor
FMTime : Off Time Minute value ( 0 ~ 59 ) to be set on TV/Monitor
FTimeNF : Off Time ON/OFF value to be set on TV/Monitor

1OffTimeON
0 Off Time OFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 8 'A' 0x03

FAPTime F H Time

Val 3 Val 4 Val 5 Val 6

Check

Sum

FMTime 0 FTimeNF 0

FAPTime,FHTime,FMTime,FTimeNF:Sameasabove

F H Time, F M Time if Off Time was not set on, 0xFF

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x03 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

13

*VideoControl(ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer shows the screen condition of TV / Monitor.

●

Get Video Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x04 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x0A 'A' 0x04 Contrast Brightness

Val 3 Val 4 Val 5 Val 6 Val 7 Val 8

Check

Sum

Sharpness Color Tint ColorTone ColorTemp 0

Contrast, Brightness, Sharpness, Color, Tint, ColorTone, ColorTemp :

Same as above

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x04 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

14

*AudioControl

●

Function

Personal Computer shows the sounds condition of TV / Monitor.

●

Get Audio Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x05 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x05 'A' 0x05 Treble Bass

Val 3

Check

Sum

Balance

Treble, Bass, Balance :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x05 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

15

*RGBControl(PC,BNC,DVIOnly)

●

Function

Personal Computer shows screen condition of TV / Monitor.

●

Get Video Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x06 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x0A 'A' 0x06 Contrast Brightness

Val 3 Val 4 Val 5 Val 6 Val 7 Val 8

Check

Sum

ColorTone ColorTemp 0 Red Gain Green Gain Blue Gain

Contrast, Brightness, ColorTone, ColorTemp, Red, Green, Blue :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x06 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

16

* PIP Status Control

●

Function

Personal Computer shows PIP setting state of TV / Monitor.

●

Get PIP Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x07 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 6 'A' 0x07 P.Size P.Source

Val 3 Val 4

Check

Sum

00

P.Size : PIP Size value code set at TV / Monitor

0x00 PIP Off
0x06 Large
0x08 Small
0x04 Double 1
0x05 Double 2
0x09 Double 3

P.Source : PIP Source value code set at TV / Monitor

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x07 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

17

* Maintenance Control

●

Function

Personal Computer shows maintenance state of TV / Monitor.

●

Get Maintenance Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x08 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x15 'A' 0x08 Power P.Size

Val 3 Val 4 Val 5 Val 6 Val 7 Val 8 Val 9 Val 10

P.Source LMax_H LMax_M LMax_AP LMaxValue LMin_H LMin_M LMin_AP

Val 11 Val 12 Val 13 Val 14 Val 15 Val 16

LMinValue LampValue ScreenInterval ScreenTime ScreenType V.Wall

Val17 Val 18 Val19

Check

Sum

V.WallFormat V.WallDivid V.WallSet

Power : Power code set on TV / Monitor
P.Size : PIP Size value code set on TV / Monitor
P.Source : PIP Source value code set on TV / Monitor
LMax_H : Auto Lamp Max Time Hour (1 ~ 12) set on TV / Monitor
LMax_M : Auto Lamp Max Time Minute (0 ~ 59) set on TV / Monitor
LMax_AP : Auto Lamp Max Time AM/PM set on TV / Monitor
LMaxValue : Auto Lamp Max value (0 ~ 100) set on TV / Monitor
LMin_H : Auto Lamp Min Time Hour (1 ~ 12) set on TV / Monitor
LMin_M : Auto Lamp Min Time Minute (0 ~ 59) set on TV / Monitor
LMin_AP : Auto Lamp Min Time AM/PM set on TV / Monitor
LMinValue : Auto Lamp Min value (0 ~ 100, 0xFF) set on TV / Monitor
LampValue : Manual Lamp Control value (0 ~ 100, 0xFF) set on TV / Monitor
ScreenInterval : Safety Screen Interval (Per Hour, 0(0ff)~10) set on TV / Monitor
ScreenTime : Safety Screen Time (Per Second, 0(off) ~5) set on TV / Monitor
ScreenType : Safety Screen Type (3 ~ 6) set on TV / Monitor
V.Wall : Video Wall Mode code set on TV / Monitor
V.WallFormat : Video Wall Format code set on TV / Monitor
V.WallDivid : Video Wall Divider code set on TV / Monitor
V.WallSet : Video Wall Set Number code set on TV / Monitor

Caution :IfLMinValueisReturned to 0xFF then Auto Lamp Control is OFF.

If LampValue is Returned to 0xFF then Manual Lamp Control is OFF.

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x08 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

18

* Serial Number Control

●

Function

Personal Computer controls serial number of TV / Monitor.

●

Get SerialNum Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x0B 0

●

Ack SerialNum

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x10 'A' 0x0B Data1 Data2

Val 3 Val 4 Val 5 Val 6 Val 7 Val 8 Val 9 Val 10

Data3 Data4 Data5 Data6 Data7 Data8 Data9 Data10

Val 11 Val 12 Val 13 Val 14

Data11 Data12 Data13 Data14

Check

Sum

Data1 ~ Data14 : Serial Number set on TV / Monitor.

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x0B ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

19

* Display Status Control

●

Function

Personal Computer shows display condition of TV / Monitor.

●

Get Maintenance Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x0D 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x08 'A' 0x0D Lamp Temperature

Val 3 Val 4 Val 5 Val 6

Bright_Sensor No_Sync Cur_Temp FAN

Check

Sum

Lamp : Lamp Error code (0 : Normal, 1 : Error) to be set on TV / Monitor
Temperature : Temperature Error code (0: Normal, 1: Error) to be set on TV /

Monitor

Bright_Sensor : Brighte Sensor Error code (0: Normal, 1: Error) to be set on

TV/Monitor

No_Sync: Sync Error code(0: Normal, 1: Error, No Sync) to be set on TV / Monitor
Cur_Temp : Current temperature of TV / Monitor
FAN : Fan Error code (0 : Normal, 1 : Error) to be set on TV / Monitor

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x0D ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

20

*SWVersionControl

●

Function

Personal Computer shows version information of TV / Monitor.

●

Get Version Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x0E 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x11 'A' 0x0E Version1 Version2

Val 3 Val 4 Val 5 Val 6 Val 7 Val 8 Val 9 Val 10

Version3 Version4 Version5 Version6 Version7 Version8 Version9 Version10

Val 11 Val 12 Val 13 Val 14 Val 15

Version11 Version12 Version13 Version14 Version15

Check

Sum

Version1 ~ Version11 : Project Info. of TV/Monitor
Version12 ~ Version15 : Software version of TV/Monitor

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x06 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

21

* Model Number Control

●

Function

Personal Computer grasps and shows model number of TV / Monitor.

●

Get Model Number Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x10 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2 Val 3 Check Sum

0xAA 0xFF 0x05 'A' 0x10 Species Model TV 0

Species : Types of panel used in TV / Monitor

0x01 PDP
0x02 LCD
0x03 DLP

Model : TV / Monitor Model Name

0x01 PPM50H2
0x02 PPM42S2
0x03 PS-42P2ST
0x04 PS-50P2HT
0x05 SyncMaster 400T
0x06 SyncMaster 403T
0x07 PPM42S3, SPD-42P3SM
0x08 PPM50H3, SPD-50P3HM
0x09 PPM63H3, SPD-63P3HM

0x0A PS-42P3ST

0x0B SyncMaster 323T

0x0C

SyncMaster 403T -

CT40CS(N)

0x0D PPMxxM5x

0x0E

SyncMaster 460P(n)
SyncMaster 400P(n)
SyncMaster 320P(n)

0x10

SyncMaster 320Px
SyncMaster 400Px/400Pxn
SyncMaster 460Px/460Pxn

TV : TV support of TV / Monitor

0x00 does not support TV
0x01 does support TV

SEC-VD-DSW External Control

0x13 SyncMaster 400TX(n)
0x14 SyncMaster 570DX

0x15

SyncMaster 320DX

SyncMaster 820DX
SyncMaster 400DX(n)
SyncMaster 460DX(n)
SyncMaster 700DX(n)
SyncMaster 820DX(n)

0x16 SyncMaster 460TX(n)

0x17

SyncMaster 400UX(n)
SyncMaster 460UX(n)

0x18 SyncMaster 42TS/42PS

0x19 SyncMaster P50Hn
0x1A SyncMaster P50F/P50Fn
0x1B SyncMaster P63F/P63Fn
0x1C SyncMaster 320MX/320MXn
0x1D SyncMaster 400CX/400CXn

0x1E SyncMaster 400MX/400MXn

0x20 SyncMaster 460CX/460CXn

22

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x10 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

23

*PowerControl

●

Function

Personal Computer turns TV / Monitor power ON/OFF.

●

Get Power ON/OFF Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x11 0

●

Set Power ON/OFF

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x11 1 Power

Power : Power code to be set on TV / Monitor

1PowerON
0PowerOFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x11 Power

Power :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x11 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

24

* Volume Control

●

Function

Personal Computer changes volume of TV / Monitor.

●

Get Volume Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x12 0

●

Set Volume

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x12 1 Volume

Volume : Volume value code to be set on TV/Monitor (0 ~ 100 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x12 Volume

Volume :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x12 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

25

* Mute Control

●

Function

Personal Computer turns TV / Monitor mute ON/OFF.

●

Get Mute ON/OFF Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x13 0

●

Set Mute ON/OFF

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x13 1 Mute

Mute : Mute code to be set on TV / Monitor

1MuteON
0MuteOFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x13 Mute

Mute :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x13 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

26

* Input Source Control

●

Function

Personal Computer changes input source of TV / Monitor.

●

Get Input Source Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x14 0

●

Set Input Source

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x14 1 Input

Input :InputSourcecodetobesetonTV/Monitor

0x14 PC
0x1E BNC
0x18 DVI
0x0C AV
0x04 S-Video
0x08 Component
0x20 MagicNet
0x1F DVI_VIDEO
0x30 RF(TV)

0x40 DTV

0x21 HDMI
0x22 HDMI_PC

Caution : DVI_VIDEO, HDMI_PC →GetOnly

In the case of MagicNet, only possible with models include MagicNet.

In the case of TV, only possible with models include TV.

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x14 Input

Input :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x14 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

27

* Picture Size Control

●

Function

Personal Computer changes Picture Size of TV / Monitor.

Cannot control when Video Wall is on.

●

Get Picture Size Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x15 0

●

Set Picture Size

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x15 1 Aspect

Aspect : Picture Size ㅊode to be set on TV / Monitor

PC1, PC2, DVI, BNC
0x10 16 : 9
0x18 4 : 3

AV, S-VIdeo, Component
0x00 Auto Wide
0x01 16 : 9
0x04 Zoom
0x05 Zoom1
0x06 Zoom2

0x09 Just Scan

0x31 Wide Zoom
0x0B 4 : 3
0x0C Wide Fit

Caution :ForsomeImage,sizesarenotsupporteddependingonsomeinputsignals

(720p, 1080i).

For MFM model only possible for those include Europe TV if size is Auto Wide.

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x15 Aspect

Aspect :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x15 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

28

* Direct Channel Control (DTV)

Caution : Only works with models include TV.

●

Function

Personal Computer can control TV Channel.

●

Get Channel

Header Command

ID

Data Length

Check

Sum

0xAA 0x17 0

●

Set Channel

Header Command

ID

Data

Length

Data 1 Data 2 Data 3 Data 4

0xAA 0x17 0x09 Country ATV_DTV AirCable CH_NUM

Data 5 Data 6 Data 7 Data 8

Check

Sum

Sel_Minor Minor_CH Reserved Reserved

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x06 'A' 0x16 Country ATV_DTV

Val 3 Val 4 Val 5 Val 6 Val 7 Val 8

Check

Sum

AirCable CH_NUM Sel_Minor Minor_CH 0 0

Country :SelectthecountrytobesetonTV/Monitor(0:Korea,1:USA,....)

ATV_DTV : Select Analog TV and DTV to be set on TV / Monitor ( 0 : Analog TV,

1: Digital TV)

AirCalbe : Select if TV is cabled or general ( 0 : general, 1: cabled)
CH_NUM : TV channel number to be set on TV / Monitor ( Analog TV : 1 ~ 135 ,

Digital TV : 0 ~ 999)

Sel_Minor : Select minor channel when DTV is to be set on TV / Monitor( 0 : minor

channel not selected. 1: minor channel selected.)

Minor_CH : Select minor channel number when DTV is to be set on TV / Monitor

( 0 ~ 999.)

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x17 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

29

* Screen Mode Control

●

Function

Personal Computer changes screen mode of TV / Monitor.

Cannot control when Video Wall is on and only operates when Picture Size is Auto
Wide.

●

Get Screen Mode Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x18 0

●

Set Picture Size

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x18 1 ScrMode

ScrMode : Screen Mode Code to be set on TV / Monitor

0x01 16 : 9
0x04 Zoom
0x31 Wide Zoom
0x0B 4 : 3

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x18 ScrMode

ScrMode :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x18 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

30

* Screen Size Control

●

Function

Personal Computer recognizes the screen size of TV / Monitor.

●

Get Screen Size Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x19 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x19

Screen

Size

Screen Size : Screen size of TV / Monitor (Range: 0 ~ 255, Unit: Inch)

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x19 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

31

* Red Offset Control

●

Function

Personal Computer changes R Offset from Signal Control function of TV / Monitor.
※ Signal Control R Offset Control only operates when Signal Balance is on and

current input source is PC and BNC.

●

Get Signal Control R Offset Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x1A 0

●

Set Signal Control R Gain

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x1A 1 R Offset

R Offset : R Gain value to be set on TV/Monitor (0 ~ 100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x1A R Offset

R Offset :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x1A ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

32

* Green Offset Control

●

Function

Personal Computer changes G Offset from Signal Control function of TV / Monitor.
※SignalControlGOffsetControlonlyoperateswhenSignalBalanceisonand

current input source is PC and BNC.

●

Get Signal Control G Offset Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x1B 0

●

Set Signal Control G Gain

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x1B 1 G Offset

GOffset: G Offset value to be set on TV/Monitor (0 ~ 100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x1B G Offset

GOffset:Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x1B ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

33

* Blue Offset Control

●

Function

Personal Computer changes B Offset from Signal Control function of TV / Monitor.
※ Signal Control B Offset Control only operates when Signal Balance is on and
current input source is PC and BNC.

●

Get Signal Control B Offset Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x1C 0

●

Set Signal Control B Offset

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x1C 1 BOffset

B Offset :BOffsetvaluetobesetonTV/Monitor(0~100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x1C BOffset

B Offset :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x1C ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

34

* Contrast Control (ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer changes contrast of TV / Monitor.

●

Get Contrast Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x24 0

●

Set Contrast

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x24 1 Contrast

Contrast : Contrast value code to be set on TV/Monitor ( 0 ~ 100 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x24 Contrast

Contrast :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x24 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

35

* Brightness Control (ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer changes brightness of TV / Monitor.

●

Get Brightness Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x25 0

●

Set Brightness

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x25 1 Brightness

Brightness : Brightness value code to be set on TV/Monitor ( 0 ~ 100 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x25 Brightness

Brightness :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x25 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

36

* Sharpness Control (ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer changes sharpness of TV / Monitor의.

●

Get Sharpness Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x26 0

●

Set Sharpness

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x26 1 Sharpness

Sharpness :SharpnessvaluecodetobesetonTV/Monitor(0~100)

Caution : Sharpness could only be set in 50 Steps (0, 2, 4, 6... 100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x26 Sharpness

Sharpness :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x26 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

37

* Color Control (ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer changes the color of TV / Monitor.

●

Get Color Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x27 0

●

Set Color

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x27 1 Color

Color : Color value code to be set on TV/Monitor( 0 ~ 100 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x27 Color

Color :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x27 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

38

* Tint Control (ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer changes tint of TV / Monitor when visual display is NTSC.

Does not operate with PAL signals.

●

Get Tint Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x28 0

●

Set Tint

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x28 1 Tint

Tint : Tint value code to be set on TV/Monitor (0 ~ 100 )

R Tint Value

G (100 - Tint)Value

Caution : Tint could only be set in 50 Steps (0, 2, 4, 6... 100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x28 Tint

Tint :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x28 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

39

*RedGainControl(PC, BNC Only)

●

Function

Personal Computer changes Red Gain of TV / Monitor.

●

Get Red Gain Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x29 0

●

Set Red Gain

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x29 1 Red

Red :RedGainvaluecodetobesetonTV/Monitor(0~100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x29 Red

Red :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x29 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

40

*GreenGainControl(PC, BNC Only)

●

Function

Personal Computer changes Green Gain of TV / Monitor.

●

Get Green Gain Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x2A 0

●

Set Green Gain

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x2A 1 Green

Green :GreenGainvaluecodetobesetonTV/Monitor(0~100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x2A Green

Green :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x2A ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

41

*BlueGainControl(PC, BNC Only)

●

Function

Personal Computer changes Blue Gain of TV / Monitor.

●

Get Blue Gain Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x2B 0

●

Set Blue Gain

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x2B 1 Blue

Blue : Blue Gain value code to be set on TV/Monitor ( 0 ~ 100 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x2B Blue

Blue :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x2B ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

42

* Treble Control

●

Function

Personal Computer changes Treble of TV / Monitor.

●

Get Treble Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x2C 0

●

Set Treble

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x2C 1 Treble

Treble : Treble value code to be set on TV/Monitor ( 0 ~ 100 )

Caution : Treble could only be set in 40 Steps (0, 2, 5, 7... 100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x2C Treble

Treble :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x2C ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

43

* Bass Control

●

Function

Personal Computer changes Bass of TV / Monitor.

●

Get Bass Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x2D 0

●

Set Bass

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x2D 1 Bass

Bass : Bass value code ( 0 ~ 100 )

Caution : Basscouldonlybesetin40Steps.(0,2,5,7...100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x2D Bass

Bass :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x2D ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

44

* Balance Control

●

Function

Personal Computer changes Balance of TV / Monitor.

●

Get Balance Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x2E 0

●

Set Balance

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x2E 1 Balance

Balance : Balance value code to be set on TV/Monitor ( 0 ~ 100 )

L (100 - Balance)Value
R Balance Value

Caution : Balance could only be set in 22 Steps. (0, 4, 9, 13... 100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x2E Balance

Balance :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x2E ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

45

* Coarse Control (PC, BNC Only)

●

Function

Personal Computer adjusts Coarse of TV / Monitor.

●

Get Coarse Status

None

●

Set Coarse

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x2F 1 Coarse

Coarse : Coarse Increase/Decrease code to be set on TV/Monitor

1Increase
0Decrease

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x2F Coarse

Coarse :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x2F ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

46

* Fine Control (PC, BNC Only)

●

Function

Personal Computer adjusts Fine of TV / Monitor.

●

Get Fine Status

None

●

Set Fine

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x30 1 Fine

Fine : Phase Increase/Decrease code

1Increase
0Decrease

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x30 Fine

Fine :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x30 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

47

* H-Position Control (PC, BNC Only)

●

Function

Personal Computer adjusts Horizontal Position of TV / Monitor.

●

Get H-Position Status

None

●

Set H-Position

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x31 1 H-Pos

H-Pos : H-Position Increase/Decrease code to be set on TV/Monitor

1MovetoRight
0MovetoLeft

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x31 H-Pos

H-Pos :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x31 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

48

* V-Position Control (PC, BNC Only)

●

Function

Personal Computer adjusts Vertical Position of TV/Monitor.

●

Get V-Position Status

None

●

Set V-Position

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x32 1 V-Pos

V-Pos : V-Position Increase/Decrease code to be set on TV/Monitor

1MoveDown
0MoveUp

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x32 V-Pos

V-Pos :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x32 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

49

* Clear Menu Control

●

Function

Personal Computer removes Menu OSD left in TV / Monitor.

●

Get Clear Menu Status

None

●

Set Clear Menu

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x34 1 Clear

Clear :0x00(Always)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x34 Clear

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x34 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

50

* Remote Control

●

Function
Personal Computer enables/disables IR receiving function of TV/Monitor/

Can operate regardless of whether power is ON/OFF

●

Get Remote Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x36 0

●

Set Remote Enable/Disable

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x36 1 RMC

RMC : Power code to be set on TV/Remocon

1RemoconEnable
0 Remocon Disable

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x36 RMC

RMC :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x36 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

51

* RGB Contrast Control (PC, BNC, DVI Only)

●

Function

Personal Computer changes contrast of TV / Monitor when Input Source is PC.

●

Get Contrast Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x37 0

●

Set Contrast

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x37 1 Contrast

Contrast :RGBContrastvaluecodetobesetonTV/Monitor(0~100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x37 Contrast

Contrast :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x37 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

52

* RGB Brightness Control (PC, BNC, DVI Only)

●

Function

Personal Computer changes Brightness when Input Source of TV / Monitor is PC.

●

Get Brightness Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x38 0

●

Set Brightness

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x38 1 Brightness

Brightness : RGB Brightness value code to be set on TV/Monitor ( 0 ~ 100 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x38 Brightness

Brightness :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x38 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

53

*PIPOn/OffControl

●

Function

Personal Computer turns PIP of TV / Monitor ON/OFF.

Does not operate in MagicNet.

●

Get PIP ON/OFF Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x3C 0

●

Set PIP ON/OFF

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x3C 1 PIP

PIP : PIP On/Off code to be set on TV/Monitor

1PIPON
0PIPOFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x3C PIP

PIP :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x3C ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

54

* Auto Adjustment Control (PC, BNC Only)

●

Function

Personal Computer controls PC system screen automatically.

●

Get Auto Adjustment Status

None

●

Set Auto Adjustment

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x3D 1 Auto

Auto :0x00(Always)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x3D Auto

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x3D ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

55

* Color Tone Control (ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer changes Color Tone of TV / Monitor.

●

Get Color Tone Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x3E 0

●

Set Color Tone

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x3E 1 Color Tone

Color Tone : Color Tone value code to be set on TV/Monitor ( 0 ~ 4 )

0x00 Cool 2
0x01 Cool 1
0x02 Normal
0x03 Warm 1
0x04 Warm 2

0x50 Off

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x3E Color Tone

Brightness :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x3E ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

56

* Color Temperature Control

●

Function

Personal Computer changes Color Temperature value of TV / Monitor.

Only operates when Color Tone is set to Off.

●

Get C_Temp Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x3F 0

●

Set Brightness

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x3F 1 C_Temp

C_Temp : Color Temperature value code to be set on TV/Monitor ( 0 ~ 10 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x3F C_Temp

C_Temp :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x3F ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

57

* PIP Source Control

●

Function

Personal Computer changes PIP source of TV / Monitor.

Does not operate in MaginNet.
Only works with TV/Monitor where PIP is on.

●

Get PIP Source Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x40 0

●

Set PIP Source

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x40 1 P.Source

P.Source :InputSourcecodetobesetonTV/Monitor

Caution : PIP Source convert may not operate depending on Main Source. Refer to table

below.
*ModelswithnoDTV

PC BNC DVI AV S-Video Comp. HDMI

PC X X X ○ ○ ○ X

BNC X X X ○ ○ ○ ○

DVI X X X ○ ○ ○ ○

AV ○ ○ ○ X X X X

S-Video ○ ○ ○ X X X X

Component ○ ○ ○ X X X X

HDMI ○ ○ ○ X X X X

*ModelswithDTV

PC DVI TV/DTV AV S-Video Comp. HDMI

PC X X X ○ ○ ○ X

DVI X X X ○ ○ ○ X

TV/DTV X X X X X X X

AV ○ ○ X X X X X

S-Video ○ ○ X X X X X

Component ○ ○ X X X X X

HDMI X X X X X X X

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x40 P.Source

P.Source :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x40 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

58

* Main-PIP Swap Control

●

Function

Personal Computer swaps Main screen and PIP screen.

Does not operate in MagicNet.

●

Get Main-PIP Swap Status

None

●

Set Main-PIP Swap

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x41 1 Swap

Swap :0x00(Always)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x41 Swap

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x41 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

59

*PIPSizeControl

●

Function

Personal Computer changes PIP Size of TV / Monitor.

Does not operate in MagicNet.

●

Get PIP Size Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x42 0

●

Set PIP Size

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x42 1 P.Size

P.Size :PIPSizevaluecodetobesetonTV/Monitor

0x00 PIP Off
0x06 Large
0x08 Small
0x04 Double 1
0x05 Double 2
0x09 Double 3

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x42 P.Size

P.Size :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x42 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

60

*PIPLocateControl

●

Function

Personal Computer controls PIP position of TV / Monitor.

Does not operate in MagicNet.

●

Get PIP Locate Status

None

●

Set PIP Locate

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x43 1 P.Locate

P.Locate : PIP Locate Increase/Decrease code to be set on TV/Monitor

0 PIP Off(Get Only)
1UpperLeft
2UpperRight
3 Lower Right
4LowerLeft

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x43 P.Locate

P.Locate :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x43 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

61

* Sound Select Control

●

Function

Personal Computer converts Sound when PIP of TV / Monitor is on.

●

Get Sound Select

Header Command

ID

Data Length

Check

Sum

0xAA 0x47 0

●

Set Sound Select

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x47 1 S.Selct

S.Select : Sound Select code to be set on TV/Monitor

1Main
0Sub

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x47 S.Select

S.Select :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x47 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

62

* Pixel Shift Control

●

Function

Personal Computer controls Pixel Shift function of TV / Monitor.

Cannot control when Video Wall is on or when Zoom(0x39) is set or when Input
Signal is VESA Mode in DVI.

●

Get Pixel Shift Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x4C 0

●

Set Pixel Shift

Header Command

ID

Data Length

Data 1 Data 2 Data 3 Data 4

0xAA 0x4C 0x04 Shift

H.Dot V.Line S.Time

Check

Sum

Shift : Pixel Shift On/Off Code to be set on TV/Monitor

Caution : If Shift valueisoff,H.Dot,V.Line,S.TimevaluesareignoredinTV/

Monitor.

1ON
0OFF

H.Dot : Horizontal Dot value code set on TV/Monitor (0 ~ 4)
V.Line : Vertical Line value code set on TV/Monitor (0 ~ 4)
S.Time : Shift Time value code set on TV/Monitor (1 ~ 4)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x06 'A' 0x4C Shift H.Dot

Val 3 Val 4

Check

Sum

V.Line S.Time

Shift, H.Dot, V.Line, S.Time :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x4C ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

63

* Video Wall Control

●

Function

Personal Computer turns Video Wall function of TV / Monitor ON/OFF.

Does not operate in MagicNet.

●

Get Video Wall Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x4F 0

●

Set Video Wall

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x4F 1 V.Wall

V.Wall : Video Wall code set on TV/Monitor

Set 2X2 3X3 4X4 1X5 5X1 1X2 2X1

OFF 0x00 0x00 0x00 0x00 0x00 0x00 0x00
No. 1 0x11 0x21 0x31 0x41 0x51 0x61 0x71
No. 2 0x12 0x22 0x32 0x42 0x52 0x62 0x72
No. 3 0x13 0x23 0x33 0x43 0x53
No. 4 0x14 0x24 0x34 0x44 0x54
No. 5 0x25 0x35 0x45 0x55

... ... ...

No. 9 0x29 0x39

... ...

No. 16 0x40

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x4F V.Wall

V.Wall :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x4F ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

64

* Auto Lamp Control

●

Function

Personal Computer sets Auto Lamp Function of TV / Monitor.

When Manual Lamp Control is on, Auto Lamp Control will automatically turn off.

●

Get Auto Lamp

Header Command

ID

Data Length

Check

Sum

0xAA 0x57 0

●

Set Auto Lamp

Header Command

ID

Data Length

Data 1 Data 2 Data 3 Data 4

0xAA 0x57 8 LMax_H LMax_M LMax_AP LMaxValue

Data 5 Data 6 Data 7 Data 8

Check

Sum

LMin_H LMin_M LMin_AP LMinValue

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x0A 'A' 0x57 LMax_H LMax_M

Val 3 Val 4 Val 5 Val 6 Val 7 Val 8

Check

Sum

LMax_AP LMaxValue LMin_H LMin_M LMin_AP LMinValue

LMax_H : Auto Lamp Max Time Hour set on TV/Monitor (1 ~ 12)
LMax_M : Auto Lamp Max Time Minute set on TV/Monitor (0 ~ 59)
LMax_AP : Auto Lamp Max Time set on TV/Monitor AM/PM
LMaxValue : Auto Lamp Max Value set on TV/Monitor (0 ~ 100)
LMin_H : Auto Lamp Min Time Hour set on TV/Monitor (1 ~ 12)
LMin_M : Auto Lamp Min Time Minute set on TV/Monitor (0 ~ 59)
LMin_AP : Auto Lamp Min Time set on TV/Monitor AM/PM
LMinValue : Auto Lamp Min Value set on TV/Monitor (0 ~ 100)

Caution: When LMinValue is Returned to 0xFF, Auto Lamp Control is off.

When Dynamic contrast is on, Auto Lamp Control does not operate.

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x57 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

65

* Manual Lamp Control

●

Function

Personal Computer sets Manual Lamp Function of TV / Monitor.

When Auto Lamp Control is on, Manual Lamp Control will automatically turn off.

●

Get Manual Lamp Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x58 0

●

Set Manual Lamp

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x58 1 LampValue

LampValue : Manual Lamp value to be set on TV/Monitor (0 ~ 100)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x58 LampValue

LampValue :Sameasabove

Caution : When LampValue is Returned to 0xFF, Manual Lamp Control is off.

When Dynamic contrast is on, Manual Lamp Control does not operate.

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x58 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

66

* Safety Screen Run Control

●

Function

Personal Computer will make Safety Screen function to operate immediately, not by
Timer operation.

●

Get

Safety Screen Run

Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x59 0

●

Set

Safety Screen Run

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x59 1

Safety

Screen

Type

Safety Screen Type : Safety Screen Type to be set on TV/Monitor (1~6)

0Off
1 Signal Pattern
2AllWhite
3Scroll
4Bar
6Eraser

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x59

Safety

Screen

Type

Safety Screen Type :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x59 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

67

*SBPTimerControl(TV)

●

Function

Personal Computer sets Screen Burn Protection Timer of TV/Monitor.

●

Get SBP Timer Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x5B 0

●

Set SBP Timer

Header Command

ID

Data Length

Data 1 Data 2 Data 3

Check

Sum

0xAA 0x5B 3 Timer T.Period T.Time

Timer : SBP Timer code to be set on TV/Monitor

0OFF
1 Pattern
2AllWhite
3Inverse
4Bar
5Bar&Inverse

T.Period : SBP Timer Period value code to be set on TV/Monitor (1~24 Hr.)
T.Time : SBP Timer Time value code set on TV/Monitor (1~30 min.)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 5 'A' 0x5B Timer T.Period

Val 3

Check

Sum

T.Time

Timer, T.Period, T.Time :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x5B ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control

68

* Video Wall Mode Control

●

Function

Personal Computer converts Video Wall Mode of TV / Monitor when Video Wall is
ON.

Only works with TV/Monitor where Video Wall is on.
Does not operate in MagicNet.

●

Get Video Wall Mode

Header Command

ID

Data Length

Check

Sum

0xAA 0x5C 0

●

Set Video Wall Mode

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x5C 1 WallMode

WallMode : Video Wall Mode code to be set on TV/Monitor

1Full
0 Natural

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x5C WallMode

WallMode :sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x5C ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

69

*SafetyLock

●

Function
Personal Computer turns Safety Lock function of TV/Monitor On/Off.

전원 On/Off 여부와 상관없이 동작할 수 있다.

●

Get Safety Lock Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x5D 0

●

Set Safety Lock Enable/Disable

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x5D 1 Lock

Lock : LockcodetobesetonTV/Monitor

1On
0Off

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x5D Lock

Lock :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x5D Lock

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

70

*PanelLock

●

Function

Personal Computer turns Panel function Key Lock of TV/Monitor On/OFF.

Can operate regardless of whether power is on/off.

●

Get Panel Lock Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x5F 0

●

Set Panel Lock

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x5F 1 Panel Lock

Panel Lock : Panel Key Lock On/Off code to be set on TV/Monitor

1Lock
0Unlock

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x5F Panel Lock

Panel Lock :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x5F ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

71

*OSDOn/Off

●

Function

Personal Computer turns OSD of TV / Monitor On/Off.

When OSD is on, OSD will be shown on screen
When OSD is off, OSD will not shown on screen at all

●

Get OSD Enable Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x70 0

●

Set OSD Enable/Disable

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x70 1 OSD

OSD : OSD On/Off code to be set on TV/Monitor

1OSDOn
0OSDOff

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x70 OSD

OSD :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x70 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

72

* P.Mode Control

●

Function

Personal Computer changes Picture Mode of TV / Monitor.

●

Get PMode Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x71 0

●

Set PMode

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x71 1 PMode

PMode : Picture Mode code to be set on TV/Monitor

Source

Data Mode

AV

S-Video

Component

HDCP

(TV)

0x00 Dynamic
0x01 Standard
0x02 Movie
0x03 Custom
0x50 Off

PC

BNC

DVI

(MagicNet)

0x10 Entertain
0x11 Internet
0x12 Text
0x13 Custom
0x50 Off

Caution : Dynamic Contrast will not operate in any other mode except Off mode.

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x71 PMode

PMode :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x71 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

73

* S.Mode Control

●

Function

Personal Computer changes Sound Mode of TV / Monitor.

●

Get SMode Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x72 0

●

Set SMode

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x72 1 SMode

SMode : Sound Mode code to be set on TV/Monitor

Data Mode
0x00 Standard
0x01 Music
0x02 Movie
0x03 Speech
0x04 Custom

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x72 SMode

SMode :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x72 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

74

* NR Mode Set (ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer changes Digital NR mode.

●

Get NR Mode Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x73 0

●

Set NR Mode

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x73 1 NR Mode

NR Mode : NR Mode On/Off code to be set on TV/Monitor

1NRModeOn
0NRModeOff

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x73 NR Mode

NR Mode :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x73 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

75

* PC Color Tone Control (PC, BNC, DVI Only)

●

Function

Personal Computer can change color tone of Monitor.

●

Get Color Tone Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x75 0

●

Set Color Tone

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x75 1 Color Tone

Color Tone : Color Tone value code to set on TV/Monitor (0 ~ 3)

Source

Data Mode

PC

DVI

BNC

0x00 Custom
0x01 Cool
0x02 Normal
0x03 Warm

0x50 Off

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x75 Color Tone

Color Tone :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x75 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

76

* Auto AutoAdjustment

●

Function

Personal Computer can Enable/Disable Auto Adjustment function.

On 되었을 경우에만 Auto Auto Adjustment 기능이 동작된다.

●

Get A.Adjustment Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x76 0

●

Set A.Adjustment

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x76 1 A.Adjustment

A.Adjustment : Auto Auto Adjustment Value Code to be set on TV/Monitor

1Enable
0Disable

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x76 A.Adjustment

A.Adjustment :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x76 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

77

*AllKeysLock

●

Function

Personal Computer turns both REMOCON and Panel Key Lock function on/off.

Can operate regardless of whether power is on/off.

●

Get All Key Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x77 0

●

Set All Key Lock/Unlock

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x77 1 All Key

All Key : Lock On/Off code of every Key to be set on TV/Monitor

1Lock
0Unlock

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x77 All Key

All Key :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x77 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

78

*SRSTSXTControl

●

Function

Personal Computer turns SRS TS XT of TV / Monitor on/off.

Can only operate with TV/Monitor that has SRS TS XT function.

●

Get SRS TS XT Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x78 0

●

Set SRS TSXT

Header Command

ID

Data Length

Data 1

Check Sum

0xAA 0x78 1 SRS

SRS : SRS TS XT code to be set on TV/Monitor

1SRSON
0SRSOFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x78 SRS

SRS :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x78 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

79

* Film Mode Control

●

Function

Personal Computer turns Film Mode of TV / Monitor on/off.

●

Get Film Mode Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x79 0

●

Set Film Mode

Header Command

ID

Data Length

Data 1

Check Sum

0xAA 0x79 1 FMode

FMode :FilmModecodetobesetonTV/Monitor

1FilmModeON
0FilmModeOFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x79 FMode

FMode :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x79 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

80

* Signal Balance ( PC, BNC Only)

●

Function

Personal Computer turns Signal Balance of TV / Monitor ON/OFF.

●

Get Signal Balance Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x7A 0

●

Set Signal Balance

Header Command

ID

Data Length

Data 1

Check Sum

0xAA 0x7A 1 SBalance

SBalance : Signal Balance code to be set on TV/Monitor

1 Signal Balance ON
0 Signal Balance OFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x7A SBalance

SBalance :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x7A ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

81

*SBGain(PC, BNC Only)

●

Function

Personal Computer changes Gain value of Monitor Signal Balance.

●

Get SBGain Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x7E 0

●

Set SBGain

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x7E 1 SBGain

SBGain : Phase B value code of Signal Balance to be set on Monitor ( 0 ~ 100 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x7E SBGain

SBGain :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x7E ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

82

*SBSharpness(PC, BNC Only)

●

Function

Personal Computer changes Sharpness value of Monitor Signal Balance.

●

Get SBSharpness Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x7F 0

●

Set SBSharpness

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x7F 1 SBSharpness

SBSharpness : Signal Balance Sharpness value code to be set on Monitor ( 0 ~ 100 )

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x7F SBSharpness

SBSharpness :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x7F ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

83

*PanelOnTime

●

Function

Personal Computer shows Panel On Time of TV / Monitor.

●

Get Panel On Time Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x83 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x05 'A' 0x83 PTime_ H PTime_L

Check

Sum

PTime_H :PanelOnTimeHigh.
PTime_L :PanelOnTimeLow.

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x83 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

84

*VideoWallOn

●

Function

Personal Computer turns Video Wall of TV / Monitor ON/OFF.

Does not operate in MagicNet.

●

Get Video Wall On/Off Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x84 0

●

Set Video Wall On/Off

Header Command

ID

Data Length

Data 1

Check Sum

0xAA 0x84 1 V.Wall_On

V.Wall_On : Video Wall Code to set on TV / Monitor

1 Video Wall ON
0 Video Wall OFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x84 V.Wall_On

V.Wall_On :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x84 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

85

* Temperature Control

●

Function

Personal Computer sets the maximum value of TV / Monitor temperature.

Only supports models with Temperature notification function.

●

Get Temperature Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x85 0

●

Set Temperature Status

Header Command

ID

Data Length

Data 1

Check Sum

0xAA 0x85 1 Temperature

Temperature : Temperature code to be set on TV/Monitor

Data 45 ~ 125(℃)

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x85 Temperature

Temperature :Sameasabove

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x85 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

86

* Brightness Sensor

●

Function

Personal Computer turns Brightness Sensor of TV / Monitor on/off.

Only supports models with Brightness Sensor.

●

Get Brightness Sensor ON/OFF Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x86 0

●

Set Brightness Sensor ON/OFF

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x86 1 BR_Sensor

BR_Sensor : Power code to be set on TV/Monitor

1 Brightness Sensor ON

0BrightnessSensorOFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x86 BR_Sensor

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x86 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

87

*DynamicContrast

(ATV, DTV, AV, S-Video, Component, HDMI Only)

●

Function

Personal Computer turns Dynamic Contrast of TV / Monitor on/off.

Does not operate in PC, DVI and MagicNet.

●

Get Dynamic Contrast ON/OFF Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x87 0

●

Set Dynamic Contrast ON/OFF

Header Command

ID

Data Length

Data 1

Check

Sum

0xAA 0x87 1 DY_Cont

DY_Cont : Power code to be set on TV/Monitor

1DynamicContrastON

0 Dynamic Contrast OFF

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'A' 0x87 DY_Cont

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x87 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

88

* Video Wall User Control

●

Function

Personal Computer turns Video Wall function of TV / Monitor on/off.

Does not operate in MagicNet.
Does not operate when PIP is at operating status.

●

Get Video Wall Status

Header Command

ID

Data Length

Check

Sum

0xAA 0x89 0

●

Set Video Wall

Header Command

ID

Data Length

Data 1 Data 2

Check

Sum

0xAA 0x89 2 Wall_Div Wall_SNo

Wall_Div : Video Wall Divider code set on TV/Monitor

HV1 2 3 4 5

OFF 0x00 0x00 0x00 0x00 0x00

1

0x11 0x12 0x13 0x14 0x15

2

0x21 0x22 0x23 0x24 0x25

3

0x31 0x32 0x33 0x34 0x35

4

0x41 0x42 0x43 0x44 0x45

5

0x51 0x52 0x53 0x54 0x55

Wall_SNo : TV/Monitor Number code set on TV/Monitor

Set Number Data

1

0x01

2

0x02

... ...

24

0x18

25

0x19

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

Check

Sum

0xAA 0xFF 4 'A' 0x89 Wall_Div Wall_SNo

●

Nak

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1

Check

Sum

0xAA 0xFF 3 'N' 0x89 ERR

ERR : Error code that shows what occurred error is

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics

89

*ModelNameControl

●

Function

Personal Computer grasps TV / Monitor Model Name and display.

●

Get Model Number Status

Header Command

ID

Data Length

Check S

um

0xAA 0x8A 0

●

Ack

Header Command

ID

Data Length

Ack/Nak r-CMD Val 1 Val 2

0xAA 0xFF 0x12 'A' 0x8A M_Name1 M_Name2

Val 3 Val 4 Val 5 Val 6 Val 7 Val 8 Val 9 Val 10

M_Name3 M_Name4 M_Name5 M_Name6 M_Name7 M_Name8 M_Name9 M_Name10

Val 11 Val 12 Val 13 Val 14 Val 15 Val 16

M_Name11 M_Name12 M_Name13 M_Name14 M_Name15 M_Name16

Check

Sum

M_Name1 ~ M_Name16 : TV / Monitor의 Model Name

M_Name1 'S'

M_Name2 'y'

M_Name3 'n'

M_Name4 'c'

M_Name5 'M'

M_Name6 'a'

M_Name7 's'

M_Name8 't'

M_Name9 'e'

M_Name10 'r'

M_Name11 '4'

M_Name12 '0'

M_Name13 '0'

M_Name14 'D'

M_Name15 'X'

M_Name16 'n'

SEC-VD-DSW External Control - 0008

Display S/W, VD Business Team, Samsung Electronics
