BEFORE USING THE WASHING MACHINE

PRECAUTIONS 1

CONTROL PANEL 1

DESCRIPTION AND CLEANING OF PART 2 WASHING PROCEDURE 3

To Wash 3 To Spin Dry 3 To Rinsing 3 Overflow rinse 3 Additional rinse 4

INSTALLATION 4

Location 4 Connecting the drain hose

Mounting the legs

LAUNDRY GUIDE 5 MAINTENANCE 5 TROUBLE SHOOTING 5

WASHING MACHINE

Owner’s Instructions

SWT50A1(P) / SWT50A2(P) / SWT50B1(P) / SWT55B1

Before operating the washing machine, please read this manual

thoroughly, and retain it for future reference.

• Remove the cap-hose from the drain hose.

• In the case of pump drained washer, remove the cap-hose from the drain hole.

• Don't use excessively hot water. (50˚C or more)

Plastic parts may be deformed or damaged. Also, clothing may be deformed or decolored.

• Before washing,check all pockets.

If nails or pins remain in pockets,they may damage the washer or clothes.

• Close the water tap a little if the water pressure is too high.

• Never splash water on the control panel.

• Be sure to cover with the inner

cover on laundry before spinning.

This prevents laundry from being tossed out and damaged.

• To avoid water splashes, close the wash tub lid.

• Be sure laythe drain hose down.

(in case no drain pump)

• Be sure that the washer is grounded.

To avoid electrical shock,use a metal pipe for the ground connection. But, don't ground the washer with gas pipes or telephone lines to avoid to dangers of explosion or lightning strike.

• Do not put your hands into the

spin dryer basket when it is spinning.

Your fingers can be caught by spinning laundry and damaged.

• Never allow children to operate

or play with the washer.

Children playing with the washer may accidentally fall into the washing tub.

• Disconnect the power cord from the

power supply when not in use.

• Ventilation opening must not be obstructed by carpeting when the washing machine is installed on a carpeted floor.

• If the supply cord of this appliance is damaged, it must only be replaced by a repair shopappointed by the manufacturer, because special purpose tools are required.

• Warning to avoid overfilling and damages this appliance must be filled with the operator present using a moderate water supply pressure only.

•

Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any other appliance.

•

To avoid overfilling and damages this appliance

must be filled with the operator present using a moderate water supply pressure only.

WASH TIMMER

This is used to set the wash time, 1-15 minutes.

2.CYCLE SELECTOR

This is used to set the Washing/Rinsing or Draining.

SPIN DRY TIMER

This is used to set the spin time, 1-5 minutes.

4.WATER

SELECTOR(FOR SW-50B1)

During washing, WATER SELECTOR KNOB should be selected. During spin rinsing, WATER SELECTOR KNOB should be selected.

CONTROL PANEL

Wash/Rinse

Drain Rinse

CYCLE SELECTOR

Wash

Drain

CYCLE SELECTOR

SPIN DRY TIMER

WASH TIMER

WATER SELECTOR

Wash

Spin

BEFORE USING THE W ASHING MACHINE

CAUTIONS

PRECAUTIONS WHEN OPERA TING

HOW TO CLEAN THE FILTER

(In case drain pump)

1. Place a rag under the washer filter not to wet the floor.

2. Rotate the filter counterclockwise and pull out the filter.

3. Remove dirts and rotate the filter clockwise until it locks in position.

When you open this lid while the spin basket is spinning,the spinning will be stopped by the brake system.

POWER CORD

EARTH WIRE

WATER DRAIN HOSE

(without pump)

SPIN DRYER BASKET

PULSATOR

The plug’s shape may not be similar to that shown in this drawing.

SPIN DRYER LID

(with pump)

WASH TUB LID

Be sure to keep

the lid closed

during washing

and spinning.

WASH TUB

DRAIN FILTER

DRAIN HOSE

OVERFLOW

FILTER

LINT FILTER

INNER LID

DESCRIPTION AND / CLEANING OF PARTS

This is used for

gathering the

dregs made

during washing.

OVERFLOW FILTER

• Pull the upper side of the overflow filter with your fingers into the holes in the direction of arrow as shown

in the figure.

CLEANING THE LINT FILTER

• If the dregs are piled up in the lint filter after finishing the wash, push down and pull it out as shown in the figure.

• Wash the filter net in water.

OVERFLOW FILTER

Pull the upper side of the overflow filter with two

fingers inserted into

hole ‘A’ in the direction of arrow as shown in the figure.

CLEANING THE FILTER

• Pull the overflow filter out and take up the filter by removing 3 screws as shown in figure. Wash the filter and washing tub.

• Push the strainer(filter) out and take up the filter as shown in figure.

Wash the filter and washing tub.

DRAIN FILTER

In case of incomplete drain, disassemble the drain filter with screw driver(+), and remove lints from the filter as shown in the filter as shown in the figure.

CLEANING THE WASH TUB

First, fill water in the wash tub to ‘L’ level(

, then drain water from the wash tub simultaneously with

operating wash cycle for 1~2 minutes. •Close the wash tub lid.
