SAMSUNG SV-DVD641, SV-DVD440, SV-DVD546, SV-DVD340 Service Manual Part List

This Document can not be used without Samsung’s authorization

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

Samsung Electronics

4-1

601 ASSY PCB-MAIN; DVD-V540 Only

S.M.P.S PARTS

BD1S01 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1S02 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1SS3 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­C1SD12 2305-001029 C-FILM,LEAD-PEF;10nF,10%,630V,TP,12x9x12
C1SD13 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
C1SD16 2201-000129 C-CERAMIC,DISC;0.1NF,10%,1KV,Y5P,TP,7X4M
C1SF02 2401-002608 C-AL;33uF,20%,35V,GP,TP,5x11,5
C1SS01 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS02 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS03 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS05 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS06 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS10 2401-003303 C-AL;82uF,20%,400V,GP,BK,22X30,10
C1SS11 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1SS12 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1SS15 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS16 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1SS17 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS18 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS19 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
C1SS21 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS22 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS26 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS27 2301-000129 C-FILM,LEAD-PEF;100nF,5%,50V,TP,10X9X4.3
CN01 3711-005565 CONNECTOR-HEADER;NOWALL,24P,1R,2mm,STRAI
CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
D1SF01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1SF02 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
D1SS12 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS13 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS14 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS15 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS16 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,-,TP
D1SS19 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
F1SS01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI
FZ01 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
FZ02 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
IC1S02 0604-001028 PHOTO-COUPLER;TR,50-600%,250mW,DIP-4,ST
IC1S03 AC14-12006D IC;KA431Z,TO-92,TAPING
IC1SS2 1203-002805 IC-PWM CONTROLLER;ICE2BS01,PDIP,8P,9.52X
L1SS01 AC29-00002A FILTER LINE NOISE;-,30mH,-,-,BLF-2116
L1SS02 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,­L1SS03 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS04 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS05 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­PT1S01 AC26-00012J TRANS SWITCHING;EER-3126,SLV-D950E,-,-,­R1SD11 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD13 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD14 2001-000598 R-CARBON;3.3OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF05 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF06 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
R1SF07 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm
R1SQ11 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM

R1SR01 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR02 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR03 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SS01 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
R1SS08 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS31 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS34 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R1SS35 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
ZD1SS1 0403-000713 DIODE-ZENER;MTZJ20B,18.63-17.7V,500MW,DO
ZD1SS2 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO

POWER DRIVER PARTS

C1P101 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1P102 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P103 2401-002026 C-AL;10UF,20%,35V,GP,TP,5X5,2.5
C1P104 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C1P105 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C1P106 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P107 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P109 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P110 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P111 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P112 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P113 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1P114 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P115 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P116 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
D1P104 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P105 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P106 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P107 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P108 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P130 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L1P102 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q1P101 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P102 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P103 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P104 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P105 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P106 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P107 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P108 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P109 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P110 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P111 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P103 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
R1P104 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P105 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P109 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P110 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P111 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P112 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P122 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
R1P3A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P4A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD1P02 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD1P04 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO-

4. Electrical Parts List

This Document can not be used without Samsung’s authorization

Loc.No Part No Description ; Specification RemarkLoc.No Part No Description ; Specification Remark

4-2

Samsung Electronics

Electrical Parts List

ZD1P05 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P06 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO-

SYSTEM CONTROL/SERVO PARTS

C601 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C602 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C603 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C604 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C605 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C607 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5
C607A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C608 2401-002259 C-AL;0.1F,+80-20%,5.5V,-,TP,12.5x11
C609 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C610 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C611 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C612 2203-000726 C-CER,CHIP;3.9nF,10%,50V,X7R,TP,1608,­C613 2203-000206 C-CER,CHIP;100nF,10%,50V,X7R,TP,2012
C614 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C615 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
C616 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C617 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C618 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C618A 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C619 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C619A 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C620 2401-001543 C-AL;47uF,20%,25V,GP,TP,6.3x5mm,2.5
C621 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C621A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C623 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C624 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C625 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C626 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C627 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C628 2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,TP,1608
C628A 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C629 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C630 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C633 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C637 2203-001662 C-CER,CHIP;5.6NF,10%,50V,X7R,TP,1608
C645 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C659A 2203-001140 C-CER,CHIP;68nF,10%,16V,X7R,TP,1608
C660 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C661 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C661A 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V
C662 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C663 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C664 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C691 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C695 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C699A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C699B 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
CN604 AC37-00027A CONNECTOR-HEADER;20045WS,X-11,T8.5,W17.4
D603 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D604 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D620 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D688 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC601 AC09-00515A IC MICOM;M3776AMFA-103GP,DVD-V540,100P,
IC604 AC14-12006C IC;KA7533,DIP,­IC605 1103-001150 IC-EEPROM;24C081,1Kx8,DIP,8P,9.2x6.4mm,2
IC608 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
L601 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
L602 2701-000238 INDUCTOR-AXIAL;1.8UH,10%,2534
L603 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L605 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298

LD601 0601-001817 LED-IR;SIDE-VIEW,2.5mm,75mW,6V,940,TR
PT601 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
PT602 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
Q601 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
R601 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608
R602 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R603 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R604 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R608 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R612 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R613 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R614 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R615 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R617 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R621A 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R622 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R630 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R631 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R632 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R633 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R634 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R635 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R636 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R640 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R641 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R642 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R643 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R651 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R652 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM
R657 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608
R660 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R661 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R666 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R667 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R668 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R669 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R670 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R671 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R672 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R673 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R674 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R675 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6.4MM
R676 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R678 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R679 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R682 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R685 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R688 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R691 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R693 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R694 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R698 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
S602 0603-001134 PHOTO TR;-,30V,4V,50mA,75mW,TRAY
SW601 AC34-00005A SWITCH MODE;-,-,-,-,-,-,-,-,-,-,-,-,-,-,
SW602 AC34-00006A SWITCH-REC;-,-,-,-,-,-,-,-,-,-,-,-,-,-,­W668 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
XT601 2801-003318 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAP,12.5
XT602 2801-001381 CRYSTAL-UNIT;12MHz,30ppm,28-AAA,30pF,50o

AUDIO/VIDEO PARTS

C301F 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608

This Document can not be used without Samsung’s authorization

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

Electrical Parts List

Samsung Electronics

4-3

C315 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C317 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C318 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C319 2203-000843 C-CER,CHIP;39nF,10%,25V,X7R,TP,1608,­C320 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C321 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C322 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C324 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C325 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C326 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C327 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C328 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C329 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C330 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C331 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C332 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C333 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C334 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C334A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C335 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C336 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C337 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C338 2203-000609 C-CER,CHIP;22nF,10%,50V,X7R,TP,2012
C339 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C340 2401-001226 C-AL;4.7uF,20%,16V,BP,TP,4x7,5mm
C341 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C342 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C343 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C344 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C345 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C347 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C348 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C349 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C350 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C351 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C352 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C353 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C354 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C355 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C355A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C393 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C395 2203-000260 C-CER,CHIP;10nF,10%,50V,X7R,TP,2012
C3A01 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A02 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C3A08 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A09 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,­C3A10 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C3A11 2301-000174 C-FILM,LEAD-PEF;15nF,5%,100V,TP,7.2x4.0x Australia Only

2301-001680 C-FILM,PEF;15nF,5%,50V,TP,6. Other Only
C3A12 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C3A14 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
C3A15 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A16 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A17 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A18 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A21A 2203-001554 C-CER,CHIP;1.8nF,10%,50V,X7R,TP,1608
C3A23 2401-002069 C-AL;33uF,20%,16V,GP,TP,6.3x5,5
C3A24 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A29 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A30 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C3A40 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A41 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C3A70 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A71 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
C3Q1 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3Q2 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3.

C3Q3 2203-001086 C-CER,CHIP;0.005nF,0.25pF,50V,NP0,TP,160
C3Q4 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
CN301 3708-000391 CONNECTOR-FPC/FFC/PIC;10P,1.25MM,STRAIGH
CN3A01 3708-001165 CONNECTOR-FPC/FFC/PIC;6P,1.25MM,STRAIGHT
CN3A02 AC37-00028A CONNECTOR-SOCKET;-,X-11,T9.0,W8.5,PBT NT
CN3A1S 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm
D301 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D302 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
FL3A01 2702-000166 INDUCTOR-RADIAL;47uH,5%,6.0x6.4mm
IC301 1204-002141 IC-VIDEO PROCESS;LA71730EM-MP NT4.43 Only

1204-002140 IC-VIDEO PROCESS;LA71750EM-MPB-E,QFP,100 Other Only
J330 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L301 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L301A 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L302 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L303 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L304 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
L370 2701-000113 INDUCTOR-AXIAL;100UH,5%,2534
L3A01 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3A02 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A03 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A70 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3Q1 2701-000206 INDUCTOR-AXIAL;56uH,5%,2434
L3Q2 2701-000131 INDUCTOR-AXIAL;15uH,5%,2534
Q301F 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q3A01 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q3A02 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T
Q3A03 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A04 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A05 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A06 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q3Q1 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q2 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q4 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q5 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q3Q6 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
Q3Q7 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­R301F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R302F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R315 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R316 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R320 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R321 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R322 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R323 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608
R325 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R326 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R327 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R328 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R329 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608
R330 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R331 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R333 2007-001039 R-CHIP;56Kohm,5%,1/8W,TP,2012
R334 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R335 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R360 2007-001196 R-CHIP;820Kohm,5%,1/10W,TP,1608
R372 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R373 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R380 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A01 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A04 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A05 2007-000616 R-CHIP;24Kohm,5%,1/10W,TP,1608
R3A06 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608
R3A07 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608
R3A08 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608

R3A09 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R3A11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A12 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R3A13 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R3A14 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A16 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A17 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A18 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A23 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608
R3A24 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A25 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A26 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A28 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A50 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A51 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A60 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608
R3A70 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R3Q1 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R3Q12 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3Q2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3Q3 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q4 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R3Q5 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q6 2001-000252 R-CARBON;1.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3Q7 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3Q8 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q9 2001-000958 R-CARBON;750OHM,5%,1/8W,AA,TP,1.8X3.2MM
W177 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W178 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W221 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W222 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W311 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
XT301 2801-001397 CRYSTAL-UNIT;4.433619MHz,20ppm,28-AAA,S,
XT302 2801-003399 CRYSTAL-UNIT;3.579545MHz,15pp Not used NT4.43

TM-BLOCK PARTS

C401 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C401A 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C401B 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C402 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C403 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C404 2401-001077 C-AL;330nF,20%,50V,GP,TP,4x7mm,5mm
C405 2401-002438 C-AL;47uF,20%,50V,WT,TP,6.3x11,5
C406 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C407 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C409 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C410 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D401 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L401 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q401 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
R401 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R402 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R403 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R404 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R406 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608
R408 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R440 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R441 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608
TM401 AC40-00029A TM BLOCK;TCMK0601PD20A,PAL B/G + I + D/
W404 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD401 0403-000390 DIODE-ZENER;UZP33B,31.4-34.6V,1000MW,DO-

HI-FI PARTS

C501 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C502 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C503 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5

C504 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C505 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C506 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C507 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C508 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C510 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C511 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C513 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C517 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C518 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C519 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C520 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C521 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C522 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C523 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C524 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C525 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C526 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C527 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C529 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5
C530 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C535 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C536 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C537 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C538 2401-002569 C-AL;2.2uF,20%,50V,GP,TP,4x5,2.5
C541 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
D501 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
IC501 1204-001920 IC-AUDIO PROCESSOR;LA72646M,QFP,80P,14X1
J602 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R501 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R502 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R503 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R505 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R506 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R507 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R508 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R509 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R510 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R511 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R512 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R517 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R518 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R519 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R520 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R521 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R522 2007-001071 R-CHIP;6.8Kohm,5%,1/8W,TP,2012
R533 2007-000003 R-CHIP;43Kohm,5%,1/8W,TP,2012
R540 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R545 2007-000512 R-CHIP;2.4Kohm,5%,1/10W,TP,1608
R546 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R547 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R550 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R551 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R552 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R553 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R570 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R571 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608

A2/NICAM PARTS

C4N01 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1608,­C4N02 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N03 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C4N04 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C4N05 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C4N06 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C4N07 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608

Loc.No Part No Description ; Specification Remark

4-4

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C4N08 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1608,­C4N09 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N10 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N11 2401-002186 C-AL;3.3UF,20%,50V,GP,BK,4X5,2.5
C4N12 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N13 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N14 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N15 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N16 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C4N17 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N18 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N19 2203-000998 C-CER,CHIP;0.047NF,5%,50V,C0G,TP,1608
C4N21 2201-002069 C-CERAMIC,DISC;0.0015NF,0.25PF,50V,C0G,T
C4N22 2201-002069 C-CERAMIC,DISC;0.0015NF,0.25PF,50V,C0G,T
C4N23 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C4N24 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C4N25 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N30 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D4N01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D4N02 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC4N01 1204-001766 IC-AUDIO PROCESSOR;MSP3407D(PQFP),PQFP,4 Australia Only

1204-001765 IC-AUDIO PROCESSOR;MSP3417D( Other Only
L4N01 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6.0x6.4mm
L4N02 2702-000106 INDUCTOR-RADIAL;100uH,10%,6.2x7.4mm
L4N03 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6.0x6.4mm
L4N04 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
R4N01 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R4N02 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N03 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N04 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N05 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R4N06 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
XT4N01 2801-004096 CRYSTAL-UNIT;18.432MHZ,20PPM,28-AAA,16PF

INPUT-OUTPUT PARTS

C818 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C819 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C820 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C821 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C822A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C835 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­C853 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C854 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
J880 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J905 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J910 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J911 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J913 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
JC801 3722-001577 JACK-PIN;6P,3.5mm,NI,BLK,­L807 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L808 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L809 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L810 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
Q806 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q810 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q891A 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q891B 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
R807 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608
R813 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R814 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R815 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R816 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R822B 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
R842 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608
R851 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608

R852 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R891A 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R891B 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R892A 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R892B 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R893A 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R893B 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R894A 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R894B 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
ZD806 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD807 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD851 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD852 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD853 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD854 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

DISPLAY/FUNCTION MATRIX PARTS

BD701 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD702 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD703 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
C701 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C702 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C703 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C706 2203-000239 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,2012
C707 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C708A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C712 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­C714 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­CN701 3710-001918 CONNECTOR-SOCKET;6P,1R,2MM,ANGLE,SN
CN701A 3711-005312 CONNECTOR-HEADER;3WALL,6P,1R,2MM,STRAIGH
D701 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D702 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D703 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D704 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D705 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
DT701 AC07-00069A LED DISPLAY;BCD-9027E,SV-DVD440,5-DIGIT,
IC701 1003-001561 IC-LED DRIVER;PT6961,SOP,32P,300MIL,-,40
JK701 3722-001943 JACK-PIN;3P,8.3PI,NI,BLK,­L701 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L702 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
R701 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R702 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R703 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R704 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R711 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R712 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
RM701 AC32-00006A MODULE REMOCON;TSOP2238WE1,38KHZ,-,5.08m
SW701 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW702 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW703 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW704 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW705 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW707 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW708 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW709 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW710 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW713 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW714 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW715 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW716 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
W735 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
W737 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
ZD701 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

Electrical Parts List

Samsung Electronics

4-5

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

601 ASSY PCB-MAIN; DVD-V440 Only

S.M.P.S PARTS

BD1S01 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1S02 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1SS3 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­C1SD12 2305-001029 C-FILM,LEAD-PEF;10nF,10%,630V,TP,12x9x12
C1SD13 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
C1SD16 2201-000129 C-CERAMIC,DISC;0.1NF,10%,1KV,Y5P,TP,7X4M
C1SF02 2401-002608 C-AL;33uF,20%,35V,GP,TP,5x11,5
C1SS01 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS02 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS03 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS05 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS06 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS10 2401-003303 C-AL;82uF,20%,400V,GP,BK,22X30,10
C1SS11 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1SS12 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1SS15 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS16 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1SS17 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS18 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS19 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
C1SS21 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS22 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS26 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS27 2301-000129 C-FILM,LEAD-PEF;100nF,5%,50V,TP,10X9X4.3
CN01 3711-005565 CONNECTOR-HEADER;NOWALL,24P,1R,2mm,STRAI
CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
D1SF01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1SF02 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
D1SS12 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS13 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS14 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS15 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS16 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,-,TP
D1SS19 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
F1SS01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI
FZ01 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
FZ02 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
IC1S02 0604-001028 PHOTO-COUPLER;TR,50-600%,250mW,DIP-4,ST
IC1S03 AC14-12006D IC;KA431Z,TO-92,TAPING
IC1SS2 1203-002805 IC-PWM CONTROLLER;ICE2BS01,PDIP,8P,9.52X
L1SS01 AC29-00002A FILTER LINE NOISE;-,30mH,-,-,BLF-2116
L1SS02 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,­L1SS03 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS04 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS05 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­PT1S01 AC26-00012J TRANS SWITCHING;EER-3126,SLV-D950E,-,-,­R1SD11 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD13 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD14 2001-000598 R-CARBON;3.3OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF05 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF06 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
R1SF07 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm
R1SQ11 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SR01 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR02 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR03 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SS01 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
R1SS08 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM

R1SS31 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS34 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R1SS35 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
ZD1SS1 0403-000713 DIODE-ZENER;MTZJ20B,18.63-17.7V,500MW,DO
ZD1SS2 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO

POWER DRIVER PARTS

C1P101 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1P102 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P103 2401-002026 C-AL;10UF,20%,35V,GP,TP,5X5,2.5
C1P104 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C1P105 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C1P106 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P107 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P109 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P110 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P111 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P112 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P113 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1P114 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P115 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P116 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
D1P104 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P105 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P106 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P107 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P108 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P130 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L1P102 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q1P101 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P102 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P103 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P104 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P105 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P106 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P107 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P108 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P109 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P110 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P111 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P103 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
R1P104 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P105 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P109 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P110 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P111 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P112 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P122 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
R1P3A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P4A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD1P02 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD1P04 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO­ZD1P05 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P06 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO-

SYSTEM CONTROL/SERVO PARTS

C601 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C602 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C603 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C604 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C605 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608

Loc.No Part No Description ; Specification Remark

4-6

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C606A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C607 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5
C607A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C608 2401-002259 C-AL;0.1F,+80-20%,5.5V,-,TP,12.5x11
C609 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C610 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C611 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C612 2203-000726 C-CER,CHIP;3.9nF,10%,50V,X7R,TP,1608,­C613 2203-000206 C-CER,CHIP;100nF,10%,50V,X7R,TP,2012
C614 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C615 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
C616 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C617 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C618 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C618A 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C619 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C619A 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C620 2401-001543 C-AL;47uF,20%,25V,GP,TP,6.3x5mm,2.5
C621 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C621A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C623 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C624 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C625 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C626 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C627 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C628 2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,TP,1608
C628A 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C629 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C630 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C633 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C637 2203-001662 C-CER,CHIP;5.6NF,10%,50V,X7R,TP,1608
C645 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C659A 2203-001140 C-CER,CHIP;68nF,10%,16V,X7R,TP,1608
C660 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C661 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C661A 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V
C662 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C663 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C664 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C691 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C695 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C699A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C699B 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
CN604 AC37-00027A CONNECTOR-HEADER;20045WS,X-11,T8.5,W17.4
D603 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D604 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D620 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D688 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC601 AC09-00515A IC MICOM;M3776AMFA-103GP,DVD-V540,100P,
IC604 AC14-12006C IC;KA7533,DIP,­IC605 1103-001150 IC-EEPROM;24C081,1Kx8,DIP,8P,9.2x6.4mm,2
IC608 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
J602 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L601 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
L602 2701-000238 INDUCTOR-AXIAL;1.8UH,10%,2534
L603 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L605 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
LD601 0601-001817 LED-IR;SIDE-VIEW,2.5mm,75mW,6V,940,TR
PT601 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
PT602 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
Q601 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
R601 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608
R602 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R603 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R604 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608

R608 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R612 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R613 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R614 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R615 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R617 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R621A 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R622 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R630 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R631 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R632 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R633 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R634 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R635 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R636 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R640 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R641 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R642 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R643 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R651 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R652 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM
R657 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608
R660 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R661 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R666 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R667 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R668 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R669 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R670 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R671 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R672 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R673 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R674 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R675 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6.4MM
R676 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R678 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R679 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R682 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R685 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R688 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R691 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R693 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R694 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R698 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
S602 0603-001134 PHOTO TR;-,30V,4V,50mA,75mW,TRAY
SW601 AC34-00005A SWITCH MODE;-,-,-,-,-,-,-,-,-,-,-,-,-,-,
SW602 AC34-00006A SWITCH-REC;-,-,-,-,-,-,-,-,-,-,-,-,-,-,­W668 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
XT601 2801-003318 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAP,12.5
XT602 2801-001381 CRYSTAL-UNIT;12MHz,30ppm,28-AAA,30pF,50o

AUDIO/VIDEO PARTS

C301F 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C315 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C317 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C318 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C319 2203-000843 C-CER,CHIP;39nF,10%,25V,X7R,TP,1608,­C320 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C321 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C322 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C324 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C325 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5

Electrical Parts List

Samsung Electronics

4-7

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C326 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C327 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C328 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C329 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C330 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C331 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C332 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C333 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C334 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C334A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C335 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C336 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C337 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C338 2203-000609 C-CER,CHIP;22nF,10%,50V,X7R,TP,2012
C339 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C340 2401-001226 C-AL;4.7uF,20%,16V,BP,TP,4x7,5mm
C341 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C342 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C343 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C344 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C345 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C347 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C348 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C349 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C350 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C351 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C352 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C353 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C354 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C355 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C355A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C393 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C395 2203-000260 C-CER,CHIP;10nF,10%,50V,X7R,TP,2012
C3A01 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A02 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C3A08 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A09 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,­C3A10 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C3A11 2301-000174 C-FILM,LEAD-PEF;15nF,5%,100V,TP,7.2x4.0x Australia Only
C3A11 2301-001680 C-FILM,PEF;15nF,5%,50V,TP,6. Other Only
C3A12 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C3A14 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
C3A15 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A16 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A17 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A18 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A21A 2203-001554 C-CER,CHIP;1.8nF,10%,50V,X7R,TP,1608
C3A23 2401-002069 C-AL;33uF,20%,16V,GP,TP,6.3x5,5
C3A24 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A29 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A30 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C3A40 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A41 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C3A70 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A71 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
C3Q1 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3Q2 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3.
C3Q3 2203-001086 C-CER,CHIP;0.005nF,0.25pF,50V,NP0,TP,160
C3Q4 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
CN301 3708-000391 CONNECTOR-FPC/FFC/PIC;10P,1.25MM,STRAIGH
CN3A01 3708-001165 CONNECTOR-FPC/FFC/PIC;6P,1.25MM,STRAIGHT
CN3A02 AC37-00028A CONNECTOR-SOCKET;-,X-11,T9.0,W8.5,PBT NT
CN3A1S 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm
D301 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D302 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
FL3A01 2702-000166 INDUCTOR-RADIAL;47uH,5%,6.0x6.4mm

IC301 1204-002141 IC-VIDEO PROCESS;LA71730EM-MP NT4.43 Only
IC301 1204-002140 IC-VIDEO PROCESS;LA71750EM-MPB-E,QFP,100 Other Only
J330 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L301 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L301A 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L302 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L303 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L304 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
L370 2701-000113 INDUCTOR-AXIAL;100UH,5%,2534
L3A01 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3A02 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A03 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A70 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3Q1 2701-000206 INDUCTOR-AXIAL;56uH,5%,2434
L3Q2 2701-000131 INDUCTOR-AXIAL;15uH,5%,2534
Q301F 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q3A01 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q3A02 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T
Q3A03 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A04 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A05 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A06 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q3Q1 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q2 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q4 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q5 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q3Q6 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
Q3Q7 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­R301F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R302F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R315 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R316 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R320 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R321 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R322 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R323 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608
R325 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R326 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R327 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R328 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R329 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608
R330 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R331 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R333 2007-001039 R-CHIP;56Kohm,5%,1/8W,TP,2012
R334 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R335 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R360 2007-001196 R-CHIP;820Kohm,5%,1/10W,TP,1608
R372 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R373 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R380 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A01 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A04 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A05 2007-000616 R-CHIP;24Kohm,5%,1/10W,TP,1608
R3A06 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608
R3A07 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608
R3A08 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608
R3A09 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R3A11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A12 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R3A13 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R3A14 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A16 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A17 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A18 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A23 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608

Loc.No Part No Description ; Specification Remark

4-8

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R3A24 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A25 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A26 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A28 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A50 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A51 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A60 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608
R3A70 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R3Q1 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R3Q12 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3Q2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3Q3 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q4 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R3Q5 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q6 2001-000252 R-CARBON;1.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3Q7 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3Q8 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q9 2001-000958 R-CARBON;750OHM,5%,1/8W,AA,TP,1.8X3.2MM
W177 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W178 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W221 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W222 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W311 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
XT301 2801-001397 CRYSTAL-UNIT;4.433619MHz,20ppm,28-AAA,S,
XT302 2801-003399 CRYSTAL-UNIT;3.579545MHz,15pp Not used NT4.43

TM-BLOCK PARTS

C401 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C401A 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C401B 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C402 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C403 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C404 2401-001077 C-AL;330nF,20%,50V,GP,TP,4x7mm,5mm
C405 2401-002438 C-AL;47uF,20%,50V,WT,TP,6.3x11,5
C406 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C407 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C409 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C410 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D401 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L401 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q401 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
R401 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R402 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R403 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R404 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R406 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608
R408 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R440 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R441 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608
TM401 AC40-00029A TM BLOCK;TCMK0601PD20A,PAL B/G + I + D/
W404 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD401 0403-000390 DIODE-ZENER;UZP33B,31.4-34.6V,1000MW,DO-

HI-FI PARTS

C501 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C502 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C503 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C504 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C505 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C506 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C507 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C508 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C510 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C511 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C513 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C517 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608

C518 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C519 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C520 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C521 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C522 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C523 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C524 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C525 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C526 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C527 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C529 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5
C530 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C535 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C536 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C537 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C538 2401-002569 C-AL;2.2uF,20%,50V,GP,TP,4x5,2.5
C541 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
D501 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
IC501 1204-001920 IC-AUDIO PROCESSOR;LA72646M,QFP,80P,14X1
R501 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R502 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R503 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R505 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R506 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R507 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R508 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R509 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R510 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R511 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R512 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R517 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R518 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R519 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R520 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R521 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R522 2007-001071 R-CHIP;6.8Kohm,5%,1/8W,TP,2012
R533 2007-000003 R-CHIP;43Kohm,5%,1/8W,TP,2012
R540 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R545 2007-000512 R-CHIP;2.4Kohm,5%,1/10W,TP,1608
R546 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R547 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R550 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R551 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R552 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R553 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R570 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R571 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608

A2/NICAM PARTS

C4N01 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1608,­C4N02 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N03 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C4N04 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C4N05 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C4N06 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C4N07 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N08 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1608,­C4N09 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N10 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N11 2401-002186 C-AL;3.3UF,20%,50V,GP,BK,4X5,2.5
C4N12 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N13 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N14 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N15 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N16 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C4N17 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608

Electrical Parts List

Samsung Electronics

4-9

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C4N18 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N19 2203-000998 C-CER,CHIP;0.047NF,5%,50V,C0G,TP,1608
C4N21 2201-002069 C-CERAMIC,DISC;0.0015NF,0.25PF,50V,C0G,T
C4N22 2201-002069 C-CERAMIC,DISC;0.0015NF,0.25PF,50V,C0G,T
C4N23 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C4N24 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C4N25 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N30 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D4N01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D4N02 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC4N01 1204-001766 IC-AUDIO PROCESSOR;MSP3407D(PQFP),PQFP,4 Australia Only
IC4N01 1204-001765 IC-AUDIO PROCESSOR;MSP3417D( Other Only
L4N01 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6.0x6.4mm
L4N02 2702-000106 INDUCTOR-RADIAL;100uH,10%,6.2x7.4mm
L4N03 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6.0x6.4mm
L4N04 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
R4N01 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R4N02 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N03 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N04 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N05 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R4N06 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
XT4N01 2801-004096 CRYSTAL-UNIT;18.432MHZ,20PPM,28-AAA,16PF

INPUT-OUTPUT PARTS

C818 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C819 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C820 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C821 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C822A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C835 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­C853 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C854 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
J880 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J905 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J910 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J911 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J913 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
JC801 3722-001577 JACK-PIN;6P,3.5mm,NI,BLK,­L807 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L808 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L809 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L810 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
Q806 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q810 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q891A 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q891B 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
R807 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608
R813 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R814 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R815 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R816 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R822B 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
R842 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608
R851 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R852 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R891A 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R891B 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R892A 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R892B 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R893A 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R893B 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R894A 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R894B 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
ZD806 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

ZD807 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD851 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD852 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD853 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD854 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

DISPLAY/FUNCTION MATRIX PARTS

BD701 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD702 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD703 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
C701 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C702 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C703 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C706 2203-000239 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,2012
C707 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C708A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C712 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­C714 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­CN701 3710-001918 CONNECTOR-SOCKET;6P,1R,2MM,ANGLE,SN
CN701A 3711-005312 CONNECTOR-HEADER;3WALL,6P,1R,2MM,STRAIGH
D701 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D702 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D703 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D704 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D705 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
DT701 AC07-00069A LED DISPLAY;BCD-9027E,SV-DVD440,5-DIGIT,
IC701 1003-001561 IC-LED DRIVER;PT6961,SOP,32P,300MIL,-,40
JK701 3722-001943 JACK-PIN;3P,8.3PI,NI,BLK,­L701 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L702 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
R701 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R702 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R703 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R704 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R711 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R712 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
RM701 AC32-00006A MODULE REMOCON;TSOP2238WE1,38KHZ,-,5.08m
SW701 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW702 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW703 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW704 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW705 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW707A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW708A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW709A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW710A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW711A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW712A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW714A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW715A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
W735 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
W737 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
ZD701 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

Loc.No Part No Description ; Specification Remark

4-10

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

601 ASSY PCB-MAIN; DVD-V340 Only

S.M.P.S PARTS

BD1S01 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1S02 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1SS3 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­C1SD12 2305-001029 C-FILM,LEAD-PEF;10nF,10%,630V,TP,12x9x12
C1SD13 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
C1SD16 2201-000129 C-CERAMIC,DISC;0.1NF,10%,1KV,Y5P,TP,7X4M
C1SF02 2401-002608 C-AL;33uF,20%,35V,GP,TP,5x11,5
C1SS01 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS02 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS03 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS05 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS06 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS10 2401-003303 C-AL;82uF,20%,400V,GP,BK,22X30,10
C1SS11 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1SS12 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1SS15 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS16 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1SS17 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS18 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS19 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
C1SS21 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS22 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS26 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS27 2301-000129 C-FILM,LEAD-PEF;100nF,5%,50V,TP,10X9X4.3
CN01 3711-005565 CONNECTOR-HEADER;NOWALL,24P,1R,2mm,STRAI
CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
D1SF01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1SF02 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
D1SS12 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS13 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS14 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS15 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS16 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,-,TP
D1SS19 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
F1SS01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI
FZ01 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
FZ02 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
IC1S02 0604-001028 PHOTO-COUPLER;TR,50-600%,250mW,DIP-4,ST
IC1S03 AC14-12006D IC;KA431Z,TO-92,TAPING
IC1SS2 1203-002805 IC-PWM CONTROLLER;ICE2BS01,PDIP,8P,9.52X
L1SS01 AC29-00002A FILTER LINE NOISE;-,30mH,-,-,BLF-2116
L1SS02 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,­L1SS03 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS04 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS05 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­PT1S01 AC26-00012J TRANS SWITCHING;EER-3126,SLV-D950E,-,-,­R1SD11 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD13 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD14 2001-000598 R-CARBON;3.3OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF05 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF06 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
R1SF07 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm
R1SQ11 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SR01 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR02 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR03 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SS01 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
R1SS08 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM

R1SS31 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS34 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R1SS35 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
ZD1SS1 0403-000713 DIODE-ZENER;MTZJ20B,18.63-17.7V,500MW,DO
ZD1SS2 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO

POWER DRIVER PARTS

C1P101 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1P102 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P103 2401-002026 C-AL;10UF,20%,35V,GP,TP,5X5,2.5
C1P104 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C1P105 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C1P106 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P107 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P109 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P110 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P111 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P112 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P113 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1P114 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P115 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P116 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
D1P104 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P105 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P106 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P107 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P108 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P130 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L1P102 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q1P101 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P102 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P103 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P104 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P105 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P106 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P107 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P108 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P109 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P110 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P111 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P103 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
R1P104 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P105 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P109 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P110 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P111 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P112 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P122 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
R1P1A 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P1B 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R1P2A 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P2B 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R1P3A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P4A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD1P02 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD1P04 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO­ZD1P05 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P06 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO-

SYSTEM CONTROL/SERVO PARTS

C601 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C602 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5

Electrical Parts List

Samsung Electronics

4-11

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C603 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C604 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C605 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C607 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5
C607A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C608 2401-002259 C-AL;0.1F,+80-20%,5.5V,-,TP,12.5x11
C609 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C610 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C611 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C612 2203-000726 C-CER,CHIP;3.9nF,10%,50V,X7R,TP,1608,­C613 2203-000206 C-CER,CHIP;100nF,10%,50V,X7R,TP,2012
C614 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C615 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
C616 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C617 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C618 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C618A 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C619 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C619A 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C620 2401-001543 C-AL;47uF,20%,25V,GP,TP,6.3x5mm,2.5
C621 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C621A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C623 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C624 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C625 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C626 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C627 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C628 2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,TP,1608
C628A 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C629 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C630 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C633 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C637 2203-001662 C-CER,CHIP;5.6NF,10%,50V,X7R,TP,1608
C645 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C659A 2203-001140 C-CER,CHIP;68nF,10%,16V,X7R,TP,1608
C660 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C661 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C661A 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V
C662 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C663 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C664 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C691 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C695 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C699A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C699B 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
CN604 AC37-00027A CONNECTOR-HEADER;20045WS,X-11,T8.5,W17.4
D603 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D604 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D620 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D688 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC601 AC09-00515A IC MICOM;M3776AMFA-103GP,DVD-V540,100P,
IC604 AC14-12006C IC;KA7533,DIP,­IC605 1103-001150 IC-EEPROM;24C081,1Kx8,DIP,8P,9.2x6.4mm,2
IC608 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
J602 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L601 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
L602 2701-000238 INDUCTOR-AXIAL;1.8UH,10%,2534
L603 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L605 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
LD601 0601-001817 LED-IR;SIDE-VIEW,2.5mm,75mW,6V,940,TR
PT601 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
PT602 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
Q601 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
R601 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608

R602 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R603 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R604 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R608 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R612 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R613 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R614 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R615 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R617 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R621A 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R622 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R630 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R631 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R632 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R633 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R634 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R635 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R636 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R640 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R641 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R642 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R643 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R651 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R652 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM
R657 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608
R660 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R661 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R666 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R667 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R668 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R669 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R670 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R671 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R672 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R673 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R674 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R675 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6.4MM
R676 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R678 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R679 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R682 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R685 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R688 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R691 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R693 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R694 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R698 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
S602 0603-001134 PHOTO TR;-,30V,4V,50mA,75mW,TRAY
SW601 AC34-00005A SWITCH MODE;-,-,-,-,-,-,-,-,-,-,-,-,-,-,
SW602 AC34-00006A SWITCH-REC;-,-,-,-,-,-,-,-,-,-,-,-,-,-,­W668 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
XT601 2801-003318 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAP,12.5
XT602 2801-001381 CRYSTAL-UNIT;12MHz,30ppm,28-AAA,30pF,50o

AUDIO/VIDEO PARTS

C301F 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C315 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C317 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C318 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C319 2203-000843 C-CER,CHIP;39nF,10%,25V,X7R,TP,1608,­C320 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,-

Loc.No Part No Description ; Specification Remark

4-12

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C321 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C322 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C324 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C325 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C326 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C327 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C328 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C329 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C330 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C331 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C332 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C333 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C334 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C334A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C335 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C336 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C337 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C338 2203-000609 C-CER,CHIP;22nF,10%,50V,X7R,TP,2012
C339 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C340 2401-001226 C-AL;4.7uF,20%,16V,BP,TP,4x7,5mm
C341 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C342 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C343 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C344 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C345 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C347 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C348 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C349 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C350 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C351 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C352 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C353 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C354 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C355 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C355A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C393 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C395 2203-000260 C-CER,CHIP;10nF,10%,50V,X7R,TP,2012
C3A01 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A02 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C3A08 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A09 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,­C3A10 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C3A11 2301-001680 C-FILM,PEF;15nF,5%,50V,TP,6.3x3x7mm,­C3A12 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C3A14 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
C3A15 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A16 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A17 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A18 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A21A 2203-001554 C-CER,CHIP;1.8nF,10%,50V,X7R,TP,1608
C3A22 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A23 2401-002069 C-AL;33uF,20%,16V,GP,TP,6.3x5,5
C3A24 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A29 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A30 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C3A40 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A41 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C3A51 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A52 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A53 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A54 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A70 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A71 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3Q1 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3Q2 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3.
C3Q3 2203-001086 C-CER,CHIP;0.005nF,0.25pF,50V,NP0,TP,160

C3Q4 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
CN301 3708-000394 CONNECTOR-FPC/FFC/PIC;6P,1.25MM,STRAIGHT
CN3A01 3708-001165 CONNECTOR-FPC/FFC/PIC;6P,1.25MM,STRAIGHT
CN3A02 AC37-00028A CONNECTOR-SOCKET;-,X-11,T9.0,W8.5,PBT NT
CN3A1S 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm
D301 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D302 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
FL3A01 2702-000166 INDUCTOR-RADIAL;47uH,5%,6.0x6.4mm
IC301 1204-002140 IC-VIDEO PROCESS;LA71750EM-MPB-E,QFP,100 NT4.43 Only
IC301 1204-002141 IC-VIDEO PROCESS;LA71730EM-MP Other Only
IC302 1204-001748 IC-SELECTOR;MM1503XN,SOP,6P,63MIL,PLASTI
J330 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L301 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L301A 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L302 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L303 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L304 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
L370 2701-000113 INDUCTOR-AXIAL;100UH,5%,2534
L3A01 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3A02 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A03 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A70 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3Q1 2701-000206 INDUCTOR-AXIAL;56uH,5%,2434
L3Q2 2701-000131 INDUCTOR-AXIAL;15uH,5%,2534
Q301F 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q3A01 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q3A02 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T
Q3A03 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A04 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A05 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A06 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q3Q1 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q2 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q4 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q5 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q3Q6 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
Q3Q7 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­R301F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R302F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R315 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R316 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R320 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R321 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R322 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R323 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608
R325 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R326 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R327 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R328 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R329 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608
R330 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R331 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R333 2007-001039 R-CHIP;56Kohm,5%,1/8W,TP,2012
R334 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R335 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R360 2007-001196 R-CHIP;820Kohm,5%,1/10W,TP,1608
R372 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R373 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R380 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A01 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A04 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A05 2007-000616 R-CHIP;24Kohm,5%,1/10W,TP,1608
R3A06 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608
R3A07 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608
R3A08 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608

Electrical Parts List

Samsung Electronics

4-13

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R3A09 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R3A11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A12 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R3A13 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R3A14 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A16 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A17 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A18 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A23 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608
R3A24 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A25 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A26 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A27 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R3A28 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R3A29 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R3A31 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3A32 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R3A33 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3A50 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A51 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A60 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608
R3A70 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R3Q1 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R3Q12 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3Q2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3Q3 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q4 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R3Q5 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q6 2001-000252 R-CARBON;1.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3Q7 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3Q8 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q9 2001-000958 R-CARBON;750OHM,5%,1/8W,AA,TP,1.8X3.2MM
W177 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W178 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W221 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W222 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W311 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
XT301 2801-001397 CRYSTAL-UNIT;4.433619MHz,20ppm,28-AAA,S,
XT302 2801-003399 CRYSTAL-UNIT;3.579545MHz,15pp Not used NT4.43

TM-BLOCK PARTS

C401 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C401A 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C401B 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C402 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C403 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C404 2401-001077 C-AL;330nF,20%,50V,GP,TP,4x7mm,5mm
C405 2401-002438 C-AL;47uF,20%,50V,WT,TP,6.3x11,5
C406 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C407 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C409 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C410 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D401 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L401 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q401 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
R401 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R402 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R403 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R404 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R406 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608
R408 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R440 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R441 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608
TM401 AC40-00029A TM BLOCK;TCMK0601PD20A,PAL B/G + I + D/
W404 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD401 0403-000390 DIODE-ZENER;UZP33B,31.4-34.6V,1000MW,DO-

INPUT-OUTPUT PARTS

C818 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C819 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C820 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C821 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C822A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C835 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­C840 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R, Not used NT4.43
C853 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C854 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C857 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R, Not used NT4.43
D805 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
J880 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J910 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J911 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
JC801 3722-001575 JACK-PIN;4P/6P,3.5mm,NI,BLK,­L803 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434 Not used NT4.43
L804 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434 Not used NT4.43
L807 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L808 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L809 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L810 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
Q802 0504-000119 TR-DIGITAL;KSR1004,NPN,300MW, Not used NT4.43
Q803 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW, Not used NT4.43
Q804 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW, Not used NT4.43
Q806 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q810 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q811 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN Not used NT4.43
R801A 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,160 Not used NT4.43
R802 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,16 Not used NT4.43
R803 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,16 Not used NT4.43
R805 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,160 Not used NT4.43
R806 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,160 Not used NT4.43
R807 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608
R813 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R814 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R815 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R816 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R822B 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
R842 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608
R843 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,160 Not used NT4.43
R844 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 Not used NT4.43
R851 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R852 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R894A 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R894B 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
ZD801 0403-000297 DIODE-ZENER;MTZ6.2B,5.96-6.27 Not used NT4.43
ZD805 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3 Not used NT4.43
ZD806 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD807 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD811 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.0 Not used NT4.43
ZD851 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD852 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD853 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD854 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD863 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23 Not used NT4.43

DISPLAY/FUNCTION MATRIX PARTS

BD701 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD703 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
C701 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C702 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C703 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C706 2203-000239 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,2012

Loc.No Part No Description ; Specification Remark

4-14

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C707 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C708A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C714 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­CN701 3710-001918 CONNECTOR-SOCKET;6P,1R,2MM,ANGLE,SN
CN701A 3711-005312 CONNECTOR-HEADER;3WALL,6P,1R,2MM,STRAIGH
D701 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D702 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D703 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D704 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D705 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
DT701 AC07-00069A LED DISPLAY;BCD-9027E,SV-DVD440,5-DIGIT,
IC701 1003-001561 IC-LED DRIVER;PT6961,SOP,32P,300MIL,-,40
J01C 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J02C 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J10C 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J701A 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
JK701 3722-002170 JACK-PIN;2P,Ni,WHT/YEL,ANGLE
L701 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L702 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
R701 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R702 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R703 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R704 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R711 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R712 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
RM701 AC32-00006A MODULE REMOCON;TSOP2238WE1,38KHZ,-,5.08m
SW701 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW702 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW703 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW704 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW705 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW707 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW708 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW710 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW711 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW712 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW713 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW714 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW715 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
ZD701 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

601 ASSY PCB-MAIN, Iran Only

S.M.P.S PARTS

BD1S01 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1S02 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1SS3 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­C1SD12 2305-001029 C-FILM,LEAD-PEF;10nF,10%,630V,TP,12x9x12
C1SD13 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
C1SD16 2201-000129 C-CERAMIC,DISC;0.1NF,10%,1KV,Y5P,TP,7X4M
C1SF02 2401-002608 C-AL;33uF,20%,35V,GP,TP,5x11,5
C1SS01 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS02 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS03 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS05 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS06 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS10 2401-003303 C-AL;82uF,20%,400V,GP,BK,22X30,10
C1SS11 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1SS12 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1SS15 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS16 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1SS17 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS18 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS19 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
C1SS21 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS22 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS26 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS27 2301-000129 C-FILM,LEAD-PEF;100nF,5%,50V,TP,10X9X4.3
CN01 3711-005565 CONNECTOR-HEADER;NOWALL,24P,1R,2mm,STRAI
CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
D1SF01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1SF02 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
D1SS12 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS13 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS14 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS15 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS16 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,-,TP
D1SS19 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
F1SS01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI
FZ01 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
FZ02 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
IC1S02 0604-001028 PHOTO-COUPLER;TR,50-600%,250mW,DIP-4,ST
IC1S03 AC14-12006D IC;KA431Z,TO-92,TAPING
IC1SS2 1203-002805 IC-PWM CONTROLLER;ICE2BS01,PDIP,8P,9.52X
L1SS01 AC29-00002A FILTER LINE NOISE;-,30mH,-,-,BLF-2116
L1SS02 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,­L1SS03 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS04 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS05 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­PT1S01 AC26-00012J TRANS SWITCHING;EER-3126,SLV-D950E,-,-,­R1SD11 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD13 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD14 2001-000598 R-CARBON;3.3OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF05 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF06 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
R1SF07 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm
R1SQ11 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SR01 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR02 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR03 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SS01 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
R1SS08 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM

Electrical Parts List

Samsung Electronics

4-15

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R1SS31 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS34 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R1SS35 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
ZD1SS1 0403-000713 DIODE-ZENER;MTZJ20B,18.63-17.7V,500MW,DO
ZD1SS2 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO

POWER DRIVER PARTS

C1P101 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1P102 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P103 2401-002026 C-AL;10UF,20%,35V,GP,TP,5X5,2.5
C1P104 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C1P105 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C1P106 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P107 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P109 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P110 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P111 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P112 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P113 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1P114 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P115 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P116 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
D1P104 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P105 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P106 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P107 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P108 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P130 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L1P102 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q1P101 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P102 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P103 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P104 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P105 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P106 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P107 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P108 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P109 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P110 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P111 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P103 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
R1P104 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P105 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P109 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P110 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P111 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P112 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P122 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
R1P3A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P4A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD1P02 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD1P04 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO­ZD1P05 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P06 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO-

SYSTEM CONTROL/SERVO PARTS

C601 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C602 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C603 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C604 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C605 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608

C606A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C607 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5
C607A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C608 2401-002259 C-AL;0.1F,+80-20%,5.5V,-,TP,12.5x11
C609 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C610 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C611 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C612 2203-000726 C-CER,CHIP;3.9nF,10%,50V,X7R,TP,1608,­C613 2203-000206 C-CER,CHIP;100nF,10%,50V,X7R,TP,2012
C614 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C615 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
C616 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C617 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C618 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C618A 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C619 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C619A 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C620 2401-001543 C-AL;47uF,20%,25V,GP,TP,6.3x5mm,2.5
C621 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C621A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C623 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C624 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C625 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C626 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C627 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C628 2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,TP,1608
C628A 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C629 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C630 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C633 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C637 2203-001662 C-CER,CHIP;5.6NF,10%,50V,X7R,TP,1608
C645 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C659A 2203-001140 C-CER,CHIP;68nF,10%,16V,X7R,TP,1608
C660 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C661 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C661A 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V
C662 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C663 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C664 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C691 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C695 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C698 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C699A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C699B 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
CN604 AC37-00027A CONNECTOR-HEADER;20045WS,X-11,T8.5,W17.4
D603 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D604 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D620 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D688 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC601 AC09-00515A IC MICOM;M3776AMFA-103GP,DVD-V540,100P,
IC604 AC14-12006C IC;KA7533,DIP,­IC605 1103-001150 IC-EEPROM;24C081,1Kx8,DIP,8P,9.2x6.4mm,2
IC608 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
J602 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L601 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
L602 2701-000238 INDUCTOR-AXIAL;1.8UH,10%,2534
L603 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L605 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
LD601 0601-001817 LED-IR;SIDE-VIEW,2.5mm,75mW,6V,940,TR
PT601 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
PT602 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
Q601 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
Q603 0504-000126 TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7K,S
R601 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608
R602 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R603 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608

Loc.No Part No Description ; Specification Remark

4-16

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R604 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R608 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R612 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R613 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R614 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R615 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R617 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R621A 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R622 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R630 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R631 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R632 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R633 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R634 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R635 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R636 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R640 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R641 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R642 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R643 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R651 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R652 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM
R657 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608
R660 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R661 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R666 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R667 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R668 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R669 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R670 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R671 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R672 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R673 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R674 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R675 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6.4MM
R676 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R678 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R679 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R682 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R685 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R688 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R691 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R693 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R694 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R698 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
S602 0603-001134 PHOTO TR;-,30V,4V,50mA,75mW,TRAY
SW601 AC34-00005A SWITCH MODE;-,-,-,-,-,-,-,-,-,-,-,-,-,-,
SW602 AC34-00006A SWITCH-REC;-,-,-,-,-,-,-,-,-,-,-,-,-,-,­W668 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
XT601 2801-003318 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAP,12.5
XT602 2801-001381 CRYSTAL-UNIT;12MHz,30ppm,28-AAA,30pF,50o

AUDIO/VIDEO PARTS

C301F 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C315 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C317 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C318 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C319 2203-000843 C-CER,CHIP;39nF,10%,25V,X7R,TP,1608,­C320 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C321 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C322 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5

C324 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C325 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C326 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C327 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C328 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C329 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C330 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C331 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C332 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C333 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C334 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C334A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C335 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C336 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C337 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C338 2203-000609 C-CER,CHIP;22nF,10%,50V,X7R,TP,2012
C339 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C340 2401-001226 C-AL;4.7uF,20%,16V,BP,TP,4x7,5mm
C341 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C342 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C343 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C344 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C345 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C347 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C348 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C349 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C350 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C351 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C352 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C353 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C354 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C355 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C355A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C393 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C395 2203-000260 C-CER,CHIP;10nF,10%,50V,X7R,TP,2012
C3A01 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A02 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C3A08 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A09 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,­C3A10 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C3A11 2301-001681 C-FILM,PEF;18nF,5%,50V,TP,6.7x3.2x7.2mm,
C3A12 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C3A14 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
C3A15 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A16 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A17 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A18 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A21A 2203-001554 C-CER,CHIP;1.8nF,10%,50V,X7R,TP,1608
C3A23 2401-002069 C-AL;33uF,20%,16V,GP,TP,6.3x5,5
C3A24 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A29 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A30 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C3A40 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A41 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C3A70 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A71 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
C3D01 2301-000224 C-FILM,LEAD-PEF;22nF,5%,50V,TP,7.4x3.9x1
C3D02 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C3D03 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C3D04 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C3Q1 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3Q2 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3.
C3Q3 2203-001086 C-CER,CHIP;0.005nF,0.25pF,50V,NP0,TP,160
C3Q4 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
CN301 3708-000391 CONNECTOR-FPC/FFC/PIC;10P,1.25MM,STRAIGH
CN3A01 3708-001165 CONNECTOR-FPC/FFC/PIC;6P,1.25MM,STRAIGHT

Electrical Parts List

Samsung Electronics

4-17

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

CN3A02 AC37-00028A CONNECTOR-SOCKET;-,X-11,T9.0,W8.5,PBT NT
CN3A1S 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm
D301 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D302 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
FL3A01 2702-000166 INDUCTOR-RADIAL;47uH,5%,6.0x6.4mm
FL3D01 2702-000166 INDUCTOR-RADIAL;47uH,5%,6.0x6.4mm
IC301 1204-002141 IC-VIDEO PROCESS;LA71730EM-MPB-E,QFP,100
J330 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L301 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L301A 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L302 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L303 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L304 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
L370 2701-000113 INDUCTOR-AXIAL;100UH,5%,2534
L3A01 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3A02 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A03 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A50 2702-000119 INDUCTOR-RADIAL;150uH,5%,6.0x6.4mm
L3A70 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3Q1 2701-000206 INDUCTOR-AXIAL;56uH,5%,2434
L3Q2 2701-000131 INDUCTOR-AXIAL;15uH,5%,2534
Q301F 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q3A01 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q3A02 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T
Q3A03 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A04 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A05 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A06 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q3D01 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3D02 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T
Q3D07 0504-000119 TR-DIGITAL;KSR1004,NPN,300MW,47K/47K,TO­Q3Q1 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q2 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q4 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q5 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q3Q6 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
Q3Q7 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­R301F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R302F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R315 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R316 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R320 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R321 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R322 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R323 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608
R325 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R326 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R327 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R328 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R329 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608
R330 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R331 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R333 2007-001039 R-CHIP;56Kohm,5%,1/8W,TP,2012
R334 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R335 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R360 2007-001196 R-CHIP;820Kohm,5%,1/10W,TP,1608
R372 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R373 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R380 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A01 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A04 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A05 2007-000616 R-CHIP;24Kohm,5%,1/10W,TP,1608
R3A06 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608
R3A07 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608
R3A08 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608

R3A09 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R3A11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A12 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R3A13 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A14 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A16 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A17 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A18 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A23 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608
R3A24 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A25 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A26 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A28 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A50 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A51 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A60 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608
R3A70 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R3D01 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R3D02 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R3D03 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3D04 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3Q1 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R3Q12 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3Q2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3Q3 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q4 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R3Q5 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q6 2001-000252 R-CARBON;1.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3Q7 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3Q8 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q9 2001-000958 R-CARBON;750OHM,5%,1/8W,AA,TP,1.8X3.2MM
W177 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W178 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W221 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W222 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W311 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
XT301 2801-001397 CRYSTAL-UNIT;4.433619MHz,20ppm,28-AAA,S,
XT302 2801-003399 CRYSTAL-UNIT;3.579545MHz,15ppm,28-AAA,S,

TM-BLOCK PARTS

C401 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C401A 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C401B 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C402 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C403 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C404 2401-001077 C-AL;330nF,20%,50V,GP,TP,4x7mm,5mm
C405 2401-002438 C-AL;47uF,20%,50V,WT,TP,6.3x11,5
C406 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C407 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C409 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C410 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D401 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L401 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q401 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
R401 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R402 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R403 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R404 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R406 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608
R408 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R440 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R441 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608
TM401 AC40-00029A TM BLOCK;TCMK0601PD20A,PAL B/G + I + D/
W404 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD401 0403-000390 DIODE-ZENER;UZP33B,31.4-34.6V,1000MW,DO-

Loc.No Part No Description ; Specification Remark

4-18

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

HI-FI PARTS

C501 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C502 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C503 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C504 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C505 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C506 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C507 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C508 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C510 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C511 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C513 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C517 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C518 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C519 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C520 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C521 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C522 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C523 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C524 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C525 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C526 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C527 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C529 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5
C530 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C535 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C536 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C537 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C538 2401-002569 C-AL;2.2uF,20%,50V,GP,TP,4x5,2.5
C541 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
D501 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
IC501 1204-001920 IC-AUDIO PROCESSOR;LA72646M,QFP,80P,14X1
R501 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R502 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R503 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R505 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R506 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R507 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R508 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R509 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R510 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R511 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R512 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R517 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R518 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R519 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R520 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R521 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R522 2007-001071 R-CHIP;6.8Kohm,5%,1/8W,TP,2012
R533 2007-000003 R-CHIP;43Kohm,5%,1/8W,TP,2012
R540 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R545 2007-000512 R-CHIP;2.4Kohm,5%,1/10W,TP,1608
R546 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R547 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R550 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R551 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R552 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R553 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R570 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R571 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608

A2/NICAM PARTS

C4N01 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1608,­C4N02 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N03 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C4N04 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5

C4N05 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C4N06 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C4N07 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N08 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1608,­C4N09 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N10 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N11 2401-002186 C-AL;3.3UF,20%,50V,GP,BK,4X5,2.5
C4N12 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N13 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N14 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N15 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N16 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C4N17 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N18 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N19 2203-000998 C-CER,CHIP;0.047NF,5%,50V,C0G,TP,1608
C4N21 2201-002069 C-CERAMIC,DISC;0.0015NF,0.25PF,50V,C0G,T
C4N22 2201-002069 C-CERAMIC,DISC;0.0015NF,0.25PF,50V,C0G,T
C4N23 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C4N24 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C4N25 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N30 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D4N01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D4N02 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC4N01 1204-001765 IC-AUDIO PROCESSOR;MSP3417D(PQFP),PQFP,4
L4N01 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6.0x6.4mm
L4N02 2702-000106 INDUCTOR-RADIAL;100uH,10%,6.2x7.4mm
L4N03 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6.0x6.4mm
L4N04 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
R4N01 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R4N02 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N03 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N04 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N05 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R4N06 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
XT4N01 2801-004096 CRYSTAL-UNIT;18.432MHZ,20PPM,28-AAA,16PF

INPUT-OUTPUT PARTS

C818 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C819 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C820 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C821 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C822A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C835 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­C853 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C854 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
J880 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J905 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J910 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J911 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J913 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
JC801 3722-001577 JACK-PIN;6P,3.5mm,NI,BLK,­L807 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L808 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L809 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L810 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
LD01 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
Q806 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q810 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q891A 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q891B 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
R807 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608
R813 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R814 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R815 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R816 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608

Electrical Parts List

Samsung Electronics

4-19

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R822B 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
R842 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608
R851 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R852 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R891A 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R891B 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R892A 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R892B 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R893A 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R893B 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R894A 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R894B 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
ZD806 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD807 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD851 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD852 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD853 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD854 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

DISPLAY/FUNCTION MATRIX PARTS

BD701 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD702 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD703 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
C701 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C702 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C703 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C706 2203-000239 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,2012
C707 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C708A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C712 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­C714 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­CN701 3710-001918 CONNECTOR-SOCKET;6P,1R,2MM,ANGLE,SN
CN701A 3711-005312 CONNECTOR-HEADER;3WALL,6P,1R,2MM,STRAIGH
D701 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D702 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D703 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D704 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D705 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
DT701 AC07-00069A LED DISPLAY;BCD-9027E,SV-DVD440,5-DIGIT,
IC701 1003-001561 IC-LED DRIVER;PT6961,SOP,32P,300MIL,-,40
JK701 3722-001943 JACK-PIN;3P,8.3PI,NI,BLK,­L701 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L702 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
R701 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R702 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R703 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R704 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R711 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R712 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
RM701 AC32-00006A MODULE REMOCON;TSOP2238WE1,38KHZ,-,5.08m
SW701 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW702 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW703 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW704 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW705 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW707 3404-001182 SWITCH-TACT;DC12V,50MA,100GF DVD-V28000 Only
SW707A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 DVD-V27000 Only
SW708 3404-001182 SWITCH-TACT;DC12V,50MA,100GF DVD-V28000 Only
SW708A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 DVD-V27000 Only
SW709 3404-001182 SWITCH-TACT;DC12V,50MA,100GF DVD-V28000 Only
SW709A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 DVD-V27000 Only
SW710 3404-001182 SWITCH-TACT;DC12V,50MA,100GF DVD-V28000 Only
SW710A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 DVD-V27000 Only
SW711A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 DVD-V27000 Only
SW712A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 DVD-V27000 Only
SW713 3404-001182 SWITCH-TACT;DC12V,50MA,100GF DVD-V28000 Only

SW714 3404-001182 SWITCH-TACT;DC12V,50MA,100GF DVD-V28000 Only
SW714A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 DVD-V27000 Only
SW715 3404-001182 SWITCH-TACT;DC12V,50MA,100GF DVD-V28000 Only
SW715A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 DVD-V27000 Only
SW716 3404-001182 SWITCH-TACT;DC12V,50MA,100GF DVD-V28000 Only
W735 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
W737 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
ZD701 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

Loc.No Part No Description ; Specification Remark

4-20

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

601 ASSY PCB-MAIN SV-DVD340 Only

S.M.P.S PARTS

BD1S01 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1S02 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1SS3 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­C1SD12 2305-001029 C-FILM,LEAD-PEF;10nF,10%,630V,TP,12x9x12
C1SD13 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
C1SD16 2201-000129 C-CERAMIC,DISC;0.1NF,10%,1KV,Y5P,TP,7X4M
C1SF02 2401-002608 C-AL;33uF,20%,35V,GP,TP,5x11,5
C1SS01 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS02 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS03 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS05 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS06 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS10 2401-003303 C-AL;82uF,20%,400V,GP,BK,22X30,10
C1SS11 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1SS12 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1SS15 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS16 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1SS17 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS18 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS19 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
C1SS21 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS22 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS26 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS27 2301-000129 C-FILM,LEAD-PEF;100nF,5%,50V,TP,10X9X4.3
CN01 3711-005565 CONNECTOR-HEADER;NOWALL,24P,1R,2mm,STRAI
CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
D1SF01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1SF02 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
D1SS12 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS13 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS14 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS15 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS16 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,-,TP
D1SS19 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
F1SS01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI
FZ01 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
FZ02 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
IC1S02 0604-001028 PHOTO-COUPLER;TR,50-600%,250mW,DIP-4,ST
IC1S03 AC14-12006D IC;KA431Z,TO-92,TAPING
IC1SS2 1203-002805 IC-PWM CONTROLLER;ICE2BS01,PDIP,8P,9.52X
L1SS01 AC29-00002A FILTER LINE NOISE;-,30mH,-,-,BLF-2116
L1SS02 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,­L1SS03 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS04 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS05 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­PT1S01 AC26-00012J TRANS SWITCHING;EER-3126,SLV-D950E,-,-,­R1SD11 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD13 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD14 2001-000598 R-CARBON;3.3OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF05 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF06 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
R1SF07 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm
R1SQ11 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SR01 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR02 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR03 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SS01 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
R1SS08 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM

R1SS31 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS34 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R1SS35 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
ZD1SS1 0403-000713 DIODE-ZENER;MTZJ20B,18.63-17.7V,500MW,DO
ZD1SS2 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO

POWER DRIVER PARTS

C1P101 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1P102 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P103 2401-002026 C-AL;10UF,20%,35V,GP,TP,5X5,2.5
C1P104 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C1P105 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C1P106 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P107 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P109 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P110 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P111 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P112 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P113 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1P114 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P115 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P116 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
D1P104 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P105 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P106 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P107 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P108 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P130 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L1P102 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q1P101 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P102 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P103 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P104 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P105 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P106 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P107 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P108 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P109 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P110 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P111 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P103 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
R1P104 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P105 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P109 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P110 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P111 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P112 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P122 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
R1P1A 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P1B 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R1P2A 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P2B 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R1P3A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P4A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD1P02 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD1P04 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO­ZD1P05 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P06 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO-

SYSTEM CONTROL/SERVO PARTS

C601 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C602 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5

Electrical Parts List

Samsung Electronics

4-21

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C603 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C604 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C605 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C607 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5
C607A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C608 2401-002259 C-AL;0.1F,+80-20%,5.5V,-,TP,12.5x11
C609 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C610 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C611 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C612 2203-000726 C-CER,CHIP;3.9nF,10%,50V,X7R,TP,1608,­C613 2203-000206 C-CER,CHIP;100nF,10%,50V,X7R,TP,2012
C614 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C615 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
C616 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C617 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C618 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C618A 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C619 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C619A 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C620 2401-001543 C-AL;47uF,20%,25V,GP,TP,6.3x5mm,2.5
C621 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C621A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C623 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C624 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C625 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C626 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C627 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C628 2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,TP,1608
C628A 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C629 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C630 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C633 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C637 2203-001662 C-CER,CHIP;5.6NF,10%,50V,X7R,TP,1608
C645 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C659A 2203-001140 C-CER,CHIP;68nF,10%,16V,X7R,TP,1608
C660 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C661 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C661A 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V
C662 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C663 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C664 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C691 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C695 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C699A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C699B 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
CN604 AC37-00027A CONNECTOR-HEADER;20045WS,X-11,T8.5,W17.4
D603 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D604 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D620 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D688 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC601 AC09-00515A IC MICOM;M3776AMFA-103GP,DVD-V540,100P,
IC604 AC14-12006C IC;KA7533,DIP,­IC605 1103-001150 IC-EEPROM;24C081,1Kx8,DIP,8P,9.2x6.4mm,2
IC608 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
J602 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L601 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
L602 2701-000238 INDUCTOR-AXIAL;1.8UH,10%,2534
L603 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L605 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
LD601 0601-001817 LED-IR;SIDE-VIEW,2.5mm,75mW,6V,940,TR
PT601 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
PT602 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
Q601 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
R601 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608

R602 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R603 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R604 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R608 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R612 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R613 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R614 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R615 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R617 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R621A 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R622 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R630 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R631 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R632 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R633 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R634 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R635 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R636 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R640 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R641 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R642 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R643 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R651 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R652 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM
R657 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608
R660 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R661 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R666 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R667 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R668 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R669 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R670 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R671 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R672 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R673 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R674 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R675 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6.4MM
R676 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R678 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R679 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R682 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R685 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R688 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R691 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R693 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R694 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R698 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
S602 0603-001134 PHOTO TR;-,30V,4V,50mA,75mW,TRAY
SW601 AC34-00005A SWITCH MODE;-,-,-,-,-,-,-,-,-,-,-,-,-,-,
SW602 AC34-00006A SWITCH-REC;-,-,-,-,-,-,-,-,-,-,-,-,-,-,­XT601 2801-003318 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAP,12.5
XT602 2801-001381 CRYSTAL-UNIT;12MHz,30ppm,28-AAA,30pF,50o

AUDIO/VIDEO PARTS

C301F 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C315 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C317 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C318 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C319 2203-000843 C-CER,CHIP;39nF,10%,25V,X7R,TP,1608,­C320 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C321 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608

Loc.No Part No Description ; Specification Remark

4-22

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C322 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C324 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C325 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C326 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C327 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C328 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C329 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C330 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C331 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C332 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C333 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C334 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C334A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C335 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C336 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C337 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C338 2203-000609 C-CER,CHIP;22nF,10%,50V,X7R,TP,2012
C339 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C340 2401-001226 C-AL;4.7uF,20%,16V,BP,TP,4x7,5mm
C341 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C342 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C343 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C344 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C345 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C347 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C348 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C349 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C350 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C351 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C352 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C353 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C354 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C355 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C355A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C392 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A01 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A02 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C3A08 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A09 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,­C3A10 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C3A11 2301-001680 C-FILM,PEF;15nF,5%,50V,TP,6.3x3x7mm,­C3A12 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C3A14 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
C3A15 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A16 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A17 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A18 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A21A 2203-001554 C-CER,CHIP;1.8nF,10%,50V,X7R,TP,1608
C3A22 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A23 2401-002069 C-AL;33uF,20%,16V,GP,TP,6.3x5,5
C3A24 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A29 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A30 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C3A40 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A41 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C3A51 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A52 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A53 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A54 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A70 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A71 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CN301 3708-000394 CONNECTOR-FPC/FFC/PIC;6P,1.25MM,STRAIGHT
CN3A01 3708-001165 CONNECTOR-FPC/FFC/PIC;6P,1.25MM,STRAIGHT
CN3A02 AC37-00028A CONNECTOR-SOCKET;-,X-11,T9.0,W8.5,PBT NT
CN3A1S 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm
D301 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

D302 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
FL3A01 2702-000166 INDUCTOR-RADIAL;47uH,5%,6.0x6.4mm
IC301 1204-002140 IC-VIDEO PROCESS;LA71750EM-MPB-E,QFP,100
IC302 1204-001748 IC-SELECTOR;MM1503XN,SOP,6P,63MIL,PLASTI
J330 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L301 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L301A 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L302 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L303 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L304 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
L370 2701-000113 INDUCTOR-AXIAL;100UH,5%,2534
L3A01 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3A02 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A03 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A70 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
Q301F 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q302 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3A01 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q3A02 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T
Q3A03 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A04 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A05 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A06 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
R301F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R302F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R315 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R316 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R320 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R321 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R322 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R323 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608
R324 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R325 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R326 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R327 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R328 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R329 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608
R330 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R331 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R333 2007-001039 R-CHIP;56Kohm,5%,1/8W,TP,2012
R334 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R335 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R350 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R360 2007-001196 R-CHIP;820Kohm,5%,1/10W,TP,1608
R372 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R373 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R380 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A01 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A04 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A05 2007-000616 R-CHIP;24Kohm,5%,1/10W,TP,1608
R3A06 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608
R3A07 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608
R3A08 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608
R3A09 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R3A11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A12 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R3A13 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R3A14 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A16 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A17 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A18 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A23 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608
R3A24 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A25 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A26 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A27 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608

Electrical Parts List

Samsung Electronics

4-23

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R3A28 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R3A29 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R3A31 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3A32 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R3A33 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R3A50 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A51 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A60 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608
R3A70 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
W177 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W178 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W221 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W222 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
W311 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
XT301 2801-001397 CRYSTAL-UNIT;4.433619MHz,20ppm,28-AAA,S,

TM-BLOCK PARTS

C401 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C401A 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C401B 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C402 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C403 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C404 2401-001077 C-AL;330nF,20%,50V,GP,TP,4x7mm,5mm
C405 2401-002438 C-AL;47uF,20%,50V,WT,TP,6.3x11,5
C406 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C407 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C409 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C410 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D401 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L401 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q401 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
R401 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R402 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R403 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R404 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R406 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608
R408 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R440 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R441 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608
TM401 AC40-00029A TM BLOCK;TCMK0601PD20A,PAL B/G + I + D/
W404 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD401 0403-000390 DIODE-ZENER;UZP33B,31.4-34.6V,1000MW,DO-

SECAM PARTS

C3S01 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3S02 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C3S03 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3S04 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C3S05 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3S06 2401-001324 C-AL;0.47UF,20%,50V,GP,BK,3X5,2.5
C3S07 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
C3S08 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3S09 2401-001324 C-AL;0.47UF,20%,50V,GP,BK,3X5,2.5
C3S10 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C3S11 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3S12B 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C3S14 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C3S14B 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C3S15 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­IC3S01 1204-001921 IC-CHROMA;LA70100M,SOP,30P,375MIL,PLASTI
R3S01 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R3S02 2001-000435 R-CARBON;1MOHM,5%,1/8W,AA,TP,1.8X3.2MM

INPUT-OUTPUT PARTS

C818 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C819 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608

C820 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C821 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C822A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C835 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­C840 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C853 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C854 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C857 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
D805 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
J880 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J881A 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J882A 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J883A 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J910 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J911 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
JC801 3722-001574 JACK-SCART;21P,-,SN,BLK,#20-28
JC802 AC37-22002P JACK-PIN;3.2mm,DPAM-9837,2P(1),MONO,SV­L803 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L804 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L807 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L808 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L809 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L810 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
Q802 0504-000119 TR-DIGITAL;KSR1004,NPN,300MW,47K/47K,TO­Q803 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
Q804 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q806 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q810 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q811 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­R801A 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608
R802 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R803 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R805 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R806 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R807 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608
R813 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R814 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R815 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R816 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R822B 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
R842 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608
R843 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608
R844 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
R851 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R852 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R894A 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R894B 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
ZD801 0403-000297 DIODE-ZENER;MTZ6.2B,5.96-6.27V,500MW,DO­ZD805 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD806 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD807 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD811 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD851 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD852 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD853 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD854 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD863 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD

DISPLAY/FUNCTION MATRIX PARTS

BD701 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD703 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
C701 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C702 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C703 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C706 2203-000239 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,2012

Loc.No Part No Description ; Specification Remark

4-24

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

C707 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C708A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C714 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­CN701 3710-001918 CONNECTOR-SOCKET;6P,1R,2MM,ANGLE,SN
CN701A 3711-005312 CONNECTOR-HEADER;3WALL,6P,1R,2MM,STRAIGH
D701 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D702 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D703 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D704 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D705 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
DT701 AC07-00069A LED DISPLAY;BCD-9027E,SV-DVD440,5-DIGIT,
IC701 1003-001561 IC-LED DRIVER;PT6961,SOP,32P,300MIL,-,40
J01C 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J02C 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J10C 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J701A 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
JK701 3722-002170 JACK-PIN;2P,Ni,WHT/YEL,ANGLE
L701 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L702 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
R701 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R702 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R703 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R704 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R711 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R712 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
RM701 AC32-00006A MODULE REMOCON;TSOP2238WE1,38KHZ,-,5.08m
SW701 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW702 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW703 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW704 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW705 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW707A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW708A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW709A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW710A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW711A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW712A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW714A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW715A 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
ZD701 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

601 ASSY PCB-MAIN; CIS Only

S.M.P.S PARTS

BD1S01 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1S02 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1SS3 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­C1SD12 2305-001029 C-FILM,LEAD-PEF;10nF,10%,630V,TP,12x9x12
C1SD13 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
C1SD16 2201-000129 C-CERAMIC,DISC;0.1NF,10%,1KV,Y5P,TP,7X4M
C1SF02 2401-002608 C-AL;33uF,20%,35V,GP,TP,5x11,5
C1SS01 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS02 2301-001157 C-FILM,LEAD-PEF;47nF,10%,275V,BK,17.5x12
C1SS03 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS05 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS06 2201-002044 C-CERAMIC,DISC;0.1NF,10%,400V,Y5P,TP,8.5
C1SS10 2401-003303 C-AL;82uF,20%,400V,GP,BK,22X30,10
C1SS11 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1SS12 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1SS15 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS16 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1SS17 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS18 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C1SS19 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
C1SS21 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS22 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS26 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS27 2301-000129 C-FILM,LEAD-PEF;100nF,5%,50V,TP,10X9X4.3
CN01 3711-005565 CONNECTOR-HEADER;NOWALL,24P,1R,2mm,STRAI
CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
D1SF01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1SF02 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
D1SS12 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS13 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS14 0404-001225 DIODE-SCHOTTKY;SRAF560,60V,5000mA,ITO-22
D1SS15 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
D1SS16 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,-,TP
D1SS19 0402-001195 DIODE-RECTIFIER;F1T4,400V,1A,DO-204AC,TP
F1SS01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI
FZ01 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
FZ02 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m
IC1S02 0604-001028 PHOTO-COUPLER;TR,50-600%,250mW,DIP-4,ST
IC1S03 AC14-12006D IC;KA431Z,TO-92,TAPING
IC1SS2 1203-002805 IC-PWM CONTROLLER;ICE2BS01,PDIP,8P,9.52X
L1SS01 AC29-00002A FILTER LINE NOISE;-,30mH,-,-,BLF-2116
L1SS02 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,­L1SS03 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS04 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS05 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­PT1S01 AC26-00012J TRANS SWITCHING;EER-3126,SLV-D950E,-,-,­R1SD11 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD13 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M
R1SD14 2001-000598 R-CARBON;3.3OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF05 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF06 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
R1SF07 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm
R1SQ11 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SR01 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR02 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SR03 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SS01 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20.
R1SS08 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM

Electrical Parts List

Samsung Electronics

4-25

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R1SS31 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS34 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R1SS35 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
ZD1SS1 0403-000713 DIODE-ZENER;MTZJ20B,18.63-17.7V,500MW,DO
ZD1SS2 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO

POWER DRIVER PARTS

C1P101 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5
C1P102 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P103 2401-002026 C-AL;10UF,20%,35V,GP,TP,5X5,2.5
C1P104 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C1P105 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C1P106 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P107 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P109 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P110 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C1P111 2401-000463 C-AL;10UF,20%,35V,GP,-,5X5,5
C1P112 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C1P113 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1P114 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P115 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C1P116 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
D1P104 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P105 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P106 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P107 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P108 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D1P130 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L1P102 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q1P101 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P102 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P103 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P104 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P105 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P106 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P107 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P108 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P109 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q1P110 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
Q1P111 0501-000362 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1000MW,TO
R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P103 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
R1P104 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P105 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P109 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P110 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P111 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P112 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1P122 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
R1P3A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP Not used SV-DVD546/DVD645
R1P4A 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD1P02 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD1P04 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO­ZD1P05 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD1P06 0403-000717 DIODE-ZENER;MTZJ5.1B,4.94-5.2V,500MW,DO-

SYSTEM CONTROL/SERVO PARTS

C601 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C602 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C603 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C604 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C605 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C606 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608

C606A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C607 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5
C607A 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C608 2401-002259 C-AL;0.1F,+80-20%,5.5V,-,TP,12.5x11
C609 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C610 2401-003336 C-AL;4.7UF,20%,50V,GP,TP,5X5,2
C611 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C612 2203-000726 C-CER,CHIP;3.9nF,10%,50V,X7R,TP,1608,­C613 2203-000206 C-CER,CHIP;100nF,10%,50V,X7R,TP,2012
C614 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C615 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
C616 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C617 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C618 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C618A 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C619 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C619A 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C620 2401-001543 C-AL;47uF,20%,25V,GP,TP,6.3x5mm,2.5
C621 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C621A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C623 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C624 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C625 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C626 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C627 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C628 2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,TP,1608
C628A 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C629 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C630 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C633 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C637 2203-001662 C-CER,CHIP;5.6NF,10%,50V,X7R,TP,1608
C645 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C659A 2203-001140 C-CER,CHIP;68nF,10%,16V,X7R,TP,1608
C660 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C661 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C661A 2202-002055 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V
C662 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C663 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C664 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C691 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C695 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C699A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C699B 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
CN604 AC37-00027A CONNECTOR-HEADER;20045WS,X-11,T8.5,W17.4
D603 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D604 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D620 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D688 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC601 AC09-00515A IC MICOM;M3776AMFA-103GP,DVD-V540,100P,
IC604 AC14-12006C IC;KA7533,DIP,­IC605 1103-001150 IC-EEPROM;24C081,1Kx8,DIP,8P,9.2x6.4mm,2
IC608 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
J602 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L601 2701-000114 INDUCTOR-AXIAL;10UH,10%,2534
L602 2701-000238 INDUCTOR-AXIAL;1.8UH,10%,2534
L603 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L605 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
LD601 0601-001817 LED-IR;SIDE-VIEW,2.5mm,75mW,6V,940,TR
PT601 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
PT602 0604-001275 PHOTO-INTERRUPTER;-,-,-,SNAP,TR
Q601 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
R601 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608
R602 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R603 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R604 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608

Loc.No Part No Description ; Specification Remark

4-26

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R608 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R612 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R613 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R614 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R615 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R617 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R621A 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R622 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R630 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R631 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R632 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R633 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R634 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R635 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R636 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R640 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R641 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R642 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R643 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R651 2001-000010 R-CARBON;68KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R652 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM
R657 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608
R660 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R661 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R666 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R667 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R668 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R669 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R670 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R671 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R672 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R673 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R674 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R675 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6.4MM
R676 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R678 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R679 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R682 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R685 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R688 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R691 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R693 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R694 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R698 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
S602 0603-001134 PHOTO TR;-,30V,4V,50mA,75mW,TRAY
SW601 AC34-00005A SWITCH MODE;-,-,-,-,-,-,-,-,-,-,-,-,-,-,
SW602 AC34-00006A SWITCH-REC;-,-,-,-,-,-,-,-,-,-,-,-,-,-,­XT601 2801-003318 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAP,12.5
XT602 2801-001381 CRYSTAL-UNIT;12MHz,30ppm,28-AAA,30pF,50o

AUDIO/VIDEO PARTS

C301F 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C315 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C317 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C318 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C319 2203-000843 C-CER,CHIP;39nF,10%,25V,X7R,TP,1608,­C320 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C321 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C322 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C324 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C325 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C326 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5

C327 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C328 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C329 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C330 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C331 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C332 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C333 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C334 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C334A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C335 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C336 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C337 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C338 2203-000609 C-CER,CHIP;22nF,10%,50V,X7R,TP,2012
C339 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C340 2401-001226 C-AL;4.7uF,20%,16V,BP,TP,4x7,5mm
C341 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C342 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C343 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C344 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
C345 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C347 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C348 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C349 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
C350 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C351 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C352 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C353 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C354 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C355 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­C355A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C392 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A01 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A02 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
C3A08 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A09 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,­C3A10 2203-001211 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1608
C3A11 2301-001680 C-FILM,PEF;15nF,5%,50V,TP,6.3x3x7mm,­C3A12 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C3A14 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
C3A15 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3A16 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C3A17 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A18 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A21A 2203-001554 C-CER,CHIP;1.8nF,10%,50V,X7R,TP,1608
C3A23 2401-002069 C-AL;33uF,20%,16V,GP,TP,6.3x5,5
C3A24 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A29 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3A30 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C3A40 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C3A41 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
C3A70 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C3A71 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
CN301 3708-000391 CONNECTOR-FPC/FFC/PIC;10P,1.25MM,STRAIGH
CN3A01 3708-001165 CONNECTOR-FPC/FFC/PIC;6P,1.25MM,STRAIGHT
CN3A02 AC37-00028A CONNECTOR-SOCKET;-,X-11,T9.0,W8.5,PBT NT
CN3A1S 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm
D301 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D302 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
FL3A01 2702-000166 INDUCTOR-RADIAL;47uH,5%,6.0x6.4mm
IC301 1204-002140 IC-VIDEO PROCESS;LA71750EM-MPB-E,QFP,100
J330 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
L301 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L301A 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L302 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L303 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L304 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,

Electrical Parts List

Samsung Electronics

4-27

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

L370 2701-000113 INDUCTOR-AXIAL;100UH,5%,2534
L3A01 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
L3A02 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A03 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L3A70 2702-000120 INDUCTOR-RADIAL;15000uH,5%,6.2x7.4mm
Q301F 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
Q302 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3A01 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q3A02 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T
Q3A03 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A04 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A05 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9
Q3A06 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
R301F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R302F 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R315 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R316 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R320 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R321 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R322 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608
R323 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608
R324 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R325 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R326 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R327 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R328 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R329 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608
R330 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R331 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R333 2007-001039 R-CHIP;56Kohm,5%,1/8W,TP,2012
R334 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R335 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R350 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R360 2007-001196 R-CHIP;820Kohm,5%,1/10W,TP,1608
R372 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R373 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R380 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A01 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A04 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A05 2007-000616 R-CHIP;24Kohm,5%,1/10W,TP,1608
R3A06 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608
R3A07 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608
R3A08 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608
R3A09 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R3A11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A12 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R3A13 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R3A14 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A16 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A17 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A18 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A23 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608
R3A24 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
R3A25 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A26 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A28 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R3A50 2001-000800 R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M
R3A51 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R3A60 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608
R3A70 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
W177 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
W178 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
XT301 2801-001397 CRYSTAL-UNIT;4.433619MHz,20ppm,28-AAA,S,

TM-BLOCK PARTS

C401 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5

C401A 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C401B 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C402 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608
C403 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C404 2401-001077 C-AL;330nF,20%,50V,GP,TP,4x7mm,5mm
C405 2401-002438 C-AL;47uF,20%,50V,WT,TP,6.3x11,5
C406 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C407 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C409 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5
C410 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D401 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
L401 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­Q401 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23,
R401 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R402 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R403 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R404 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R406 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608
R408 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R440 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R441 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608
TM401 AC40-00029A TM BLOCK;TCMK0601PD20A,PAL B/G + I + D/
W404 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD401 0403-000390 DIODE-ZENER;UZP33B,31.4-34.6V,1000MW,DO-

HI-FI PARTS

C501 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C502 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C503 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C504 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C505 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C506 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C507 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C508 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C510 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C511 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C513 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C517 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C518 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5
C519 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C520 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C521 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C522 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C523 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C524 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C525 2401-001249 C-AL;4.7uF,20%,35V,GP,TP,4x5,2.5
C526 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C527 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C529 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5
C530 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C535 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C536 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C537 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C538 2401-002569 C-AL;2.2uF,20%,50V,GP,TP,4x5,2.5
C541 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5
D501 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
IC501 1204-001920 IC-AUDIO PROCESSOR;LA72646M,QFP,80P,14X1
R501 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R502 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R503 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R505 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R506 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R507 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R508 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R509 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R510 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608

Loc.No Part No Description ; Specification Remark

4-28

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R511 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R512 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R517 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R518 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R519 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608
R520 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R521 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
R522 2007-001071 R-CHIP;6.8Kohm,5%,1/8W,TP,2012
R533 2007-000003 R-CHIP;43Kohm,5%,1/8W,TP,2012
R540 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R545 2007-000512 R-CHIP;2.4Kohm,5%,1/10W,TP,1608
R546 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R547 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R550 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R551 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R552 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608
R553 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R570 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R571 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608

SECAM PARTS

C3S01 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3S02 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C3S03 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C3S04 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C3S05 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3S06 2401-001324 C-AL;0.47UF,20%,50V,GP,BK,3X5,2.5
C3S07 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
C3S08 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3S09 2401-001324 C-AL;0.47UF,20%,50V,GP,BK,3X5,2.5
C3S10 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C3S11 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C3S12A 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,16 Not used SV-DVD546/DVD645
C3S12B 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C3S14 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C3S14A 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,16 Not used SV-DVD546/DVD645
C3S14B 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C3S15 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­IC3S01 1204-001921 IC-CHROMA;LA70100M,SOP,30P,375MIL,PLASTI
R3S01 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R3S02 2001-000435 R-CARBON;1MOHM,5%,1/8W,AA,TP,1.8X3.2MM

A2/NICAM PARTS

C4N01 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1608,­C4N02 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N03 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
C4N04 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5
C4N05 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C4N06 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C4N07 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N08 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1608,­C4N09 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N10 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N11 2401-002186 C-AL;3.3UF,20%,50V,GP,BK,4X5,2.5
C4N12 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N13 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N14 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5
C4N15 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N16 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5
C4N17 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N18 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C4N19 2203-000998 C-CER,CHIP;0.047NF,5%,50V,C0G,TP,1608
C4N21 2201-002069 C-CERAMIC,DISC;0.0015NF,0.25PF,50V,C0G,T
C4N22 2201-002069 C-CERAMIC,DISC;0.0015NF,0.25PF,50V,C0G,T
C4N23 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C4N24 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5

C4N25 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C4N30 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
D4N01 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D4N02 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
IC4N01 1204-001765 IC-AUDIO PROCESSOR;MSP3417D(PQFP),PQFP,4
L4N01 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6.0x6.4mm
L4N02 2702-000106 INDUCTOR-RADIAL;100uH,10%,6.2x7.4mm
L4N03 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6.0x6.4mm
L4N04 3301-000297 BEAD-AXIAL;25ohm,3.6x1.2x5.7mm,,TP,,,
R4N01 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R4N02 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N03 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N04 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R4N05 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R4N06 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
XT4N01 2801-004096 CRYSTAL-UNIT;18.432MHZ,20PPM,28-AAA,16PF

INPUT-OUTPUT PARTS

C818 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C819 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C820 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C821 2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,TP,1608
C822A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C835 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­C840 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C853 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C854 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
C857 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
D805 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
J881A 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J882A 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J883A 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J905 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J910 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J911 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
J913 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
JC801 3722-001574 JACK-SCART;21P,-,SN,BLK,#20-28
JC802 AC37-22002N JACK-PIN;3.2mm,DPAE-9836,3P(1),HI-FI,SV
L803 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L804 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L807 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L808 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L809 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
L810 2701-000181 INDUCTOR-AXIAL;33uH,5%,2434
Q802 0504-000119 TR-DIGITAL;KSR1004,NPN,300MW,47K/47K,TO­Q803 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
Q804 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q806 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S
Q810 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q811 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q891A 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Q891B 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
R801A 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608
R802 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R803 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608
R805 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R806 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R807 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608
R813 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R814 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R815 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R816 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608
R822B 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
R842 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608
R843 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608

Electrical Parts List

Samsung Electronics

4-29

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

R844 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
R851 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R852 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R891A 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R891B 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R892A 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R892B 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
R893A 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R893B 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R894A 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
R894B 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608
ZD801 0403-000297 DIODE-ZENER;MTZ6.2B,5.96-6.27V,500MW,DO­ZD805 0403-001211 DIODE-ZENER;MTZJ12B,11.8-12.3V,500MW,DO­ZD806 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD807 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD811 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD851 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD852 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD853 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD854 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
ZD863 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD

DISPLAY/FUNCTION MATRIX PARTS

BD701 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3 Not used SV-DVD546/DVD645
BD702 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3 Not used SV-DVD546/DVD645
BD703 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3 Not used SV-DVD546/DVD645
C701 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C702 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C703 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­C706 2203-000239 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,2012 Not used SV-DVD546/DVD645
C707 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5
C708A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C712 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,- Not used SV-DVD546/DVD645
C714 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,- Not used SV-DVD546/DVD645
CN701 3710-001918 CONNECTOR-SOCKET;6P,1R,2MM,ANGLE,SN
CN701A 3711-005312 CONNECTOR-HEADER;3WALL,6P,1R,2MM,STRAIGH
D701 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D702 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D703 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D704 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
D705 0401-000101 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
DT701 AC07-00069A LED DISPLAY;BCD-9027E,SV-DVD440,5-DIGIT,
IC701 1003-001561 IC-LED DRIVER;PT6961,SOP,32P,300MIL,-,40
JK701 3722-001943 JACK-PIN;3P,8.3PI,NI,BLK,- Not used SV-DVD546/DVD645
L701 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
L702 2701-000002 INDUCTOR-AXIAL;100UH,10%,4298
R701 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R702 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R703 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R704 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R711 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R712 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 Not used SV-DVD546/DVD645
RM701 AC32-00006A MODULE REMOCON;TSOP2238WE1,38KHZ,-,5.08m
SW701 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW702 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW703 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW704 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW705 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW707 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW708 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW709 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW710 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW711 3404-001182 SWITCH-TACT;DC12V,50MA,100GF SV-DVD546/DVD645 Only
SW712 3404-001182 SWITCH-TACT;DC12V,50MA,100GF SV-DVD546/DVD645 Only
SW713 3404-001182 SWITCH-TACT;DC12V,50MA,100GF, Not used SV-DVD546/DVD645
SW714 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0

SW715 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
SW716 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,0 Not used SV-DVD546/DVD645
W735 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
W737 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
ZD701 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V Not used SV-DVD546/DVD645

Loc.No Part No Description ; Specification Remark

4-30

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

602 ASSY PCB-DVD;

AC14 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
AC15 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
AC18 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
AC19 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
AC20 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
AC21 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
AC22 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
AC25 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
AC26 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,­AC27 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
AC4 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
AC5 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,­AC9 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
ACC1 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
ACC2 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
AD1 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT­AD2 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT­AD40 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOT­AE10 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
AE11 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
AE13 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
AE14 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
AE3 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
AE4 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
AE5 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
AE8 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
AE9 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
AEE1 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
AEE2 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
AEE50 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
AEE51 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
AIC2 1002-001294 IC-D/A CONVERTER;PCM1742KE,24BIT,TSSOP,1
AIC4 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
AIC5 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m
AL1 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
AL2 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
AL3 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
AL4 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
AQ1 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ2 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ20 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ21 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­AQ4 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
AQ40 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­AQ41 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­AQ5 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
AQ6 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­AR1 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
AR14 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
AR15 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
AR16 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
AR17 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
AR18 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
AR28 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
AR29 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
AR3 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
AR30 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
AR31 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
AR32 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
AR35 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
AR40 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
AR41 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
AR42 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608
AR43 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608

AR46 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
AR47 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608
AR48 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
AR49 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
AR50 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
ARR1 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608
ARR2 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608
ARR3 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608
ARR4 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608
ARR40 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
ARR41 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
ARR5 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
ARR50 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
ARR51 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
ARR6 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
AZ1 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
AZ2 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
AZ3 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
AZ4 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
BD01 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
BD02 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
C10 2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,TP,1608
C7 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C8 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C9 2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,TP,1608
CC1 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­CC10 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
CC12 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
CC13 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CC14 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CC15 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CC17 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,­CC2 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­CC20 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,-,1608
CC21 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­CC22 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CC23 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
CC24 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CC25 2203-000998 C-CER,CHIP;0.047NF,5%,50V,C0G,TP,1608
CC26 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CC27 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CC28 2203-005221 C-CER,CHIP;15nF,10%,50V,X7R,TP,1608,­CC3 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­CC30 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
CC31 2203-005221 C-CER,CHIP;15nF,10%,50V,X7R,TP,1608,­CC32 2203-005221 C-CER,CHIP;15nF,10%,50V,X7R,TP,1608,­CC33 2203-001052 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1608
CC34 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CC35 2203-000815 C-CER,CHIP;0.033NF,5%,50V,C0G,TP,1608
CC36 2203-000815 C-CER,CHIP;0.033NF,5%,50V,C0G,TP,1608
CC37 2203-000815 C-CER,CHIP;0.033NF,5%,50V,C0G,TP,1608
CC4 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­CC5 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,TP,1608
CC8 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5
CCC01 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC02 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC03 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC04 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC05 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC06 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC07 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC08 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­CCC09 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC10 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­CCC13 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
CCC15 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608

Electrical Parts List

Samsung Electronics

4-31

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

CCC16 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC17 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC18 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC19 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC20 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC21 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC22 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CCC23 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
CJ300 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216
CN41 3710-002050 CONNECTOR-SOCKET;12P,1R,2mm,STRAIGHT,SN,
CN42 3710-002050 CONNECTOR-SOCKET;12P,1R,2mm,STRAIGHT,SN,
CNL1 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
CNL2 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
CVL0 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3 Not used CIS
CVL1 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3 Not used CIS
CVL2 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3 Not used CIS
DABD1 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
DAC2 2203-005148 C-CER,CHIP;100nF,10%,16V,X Not used SV-DVD340/440/641/645
DAC4 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
DAE2 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 Not used SV-DVD340/440/641/645
DAL1 2703-000398 INDUCTOR-SMD;10uH,10%,3 Not used SV-DVD340/440/641/645
DAL3 2901-001273 FILTER-EMI SMD;50V,2A,-,220pF,3.2x1.6x0.
DAR1 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
DAR2 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
DAR24 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
DAR3 2007-000075 R-CHIP;220ohm,5%,1/10W,TP Not used SV-DVD340/440/641/645
DAZ1 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
DAZ2 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
DCON1 3708-001266 CONNECTOR-FPC/FFC/PIC;11P,1MM,STRAIGHT,S
DCON3 3708-001696 CONNECTOR-FPC/FFC/PIC;24P,1MM,STRAIGHT,S
DIC2 1107-001369 IC-FLASH MEMORY;29LV800,1Mx8/512Kx16,TSO
DIC3 1103-001204 IC-EEPROM;24C021,256x8,SOP,8P,5.13x3.95m
DIC4 0801-002701 IC-CMOS LOGIC;74VHCT125A,BUFFER,TSSOP,14
DIC5 1105-001513 IC-DRAM;IS42S16400A-7T,1Mx16Bitx4Bit,T
DJP10 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
DJP11 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
DJP2 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
DOIC2 3707-001065 CONNECTOR-OPTICAL;PLUG, Not used SV-DVD340/440/641/645
DY1 2801-004279 CRYSTAL-UNIT;27.00MHz,10ppm,28-AAA,20pF,
ECC1 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
ECC2 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
FB2 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
JACK1 3722-002059 JACK-PIN;6P(6P),-,RED/WHT/BLU/BLK/GRY,A

3722-002128 JACK-PIN;3P,SN/NI,RED/WHT/ CIS Only
JL1 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
JL2 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
LDD1 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOT­LDD2 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOT­LDQ1 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­LDQ2 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­LDQ3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­LDR1 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
LDR2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
LDR3 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608
LDR4 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
LDR5 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
LDR6 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
LPC2 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­LPC3 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­LPC4 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
LPE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
LPE2 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
LPR1 2007-000312 R-CHIP;10ohm,5%,1/4W,TP,3216
LPR2 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608
LPR3 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
LPR4 2007-000312 R-CHIP;10ohm,5%,1/4W,TP,3216

MC1 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
MC3 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
MC4 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
MC5 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
MCE1 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
MCE2 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
MCE3 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
MD1 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT­MIC1 1003-001661 IC-MOTOR DRIVER;FAN8004,HQFP,48P,13.2x13
MIC2 1201-001842 IC-OP AMP;TL3472CD,SO,TP,8P,-,DUAL,-,PAL
MPE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
MR1 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
MR10 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
MR11 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
MR12 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
MR13 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
MR14 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
MR15 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
MR16 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
MR17 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
MR18 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
MR2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
MR25 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608
MR26 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
MR3 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608
MR4 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
MR5 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
MR6 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608
MR7 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
MR8 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
MR9 2007-000127 R-CHIP;9.1Kohm,5%,1/10W,TP,1608
MTR4 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
MTR5 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
MTR6 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
opr10 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
OPR11 2007-000083 R-CHIP;3Kohm,5%,1/10W,TP,1608
OPR13 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
PAC10 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
PAE11 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PL2 2703-000398 INDUCTOR-SMD;10uH,10%,3225
PPBD1 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
PPC1 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
PPC118 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
PPC2 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
PPC3 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
PPC80 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
PPC81 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
PPC82 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
PPE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PPE110 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
PPE18 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­PPE2 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PPE25 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
PPE3 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
PPE4 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
PPIC2 1203-003132 IC-POSI.ADJUST REG.;AMC1117,SOT-223,3P,6
PPIC3 1203-003216 IC-POSI.FIXED REG.;G9133,TO-220F,4P,10.1
PPIC5 1203-000293 IC-POSI.FIXED REG.;7808,TO-220,3P,-,PLAS
PPL10 2703-000398 INDUCTOR-SMD;10uH,10%,3225
PPL12 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216
PPL2 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216
PPL80 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
PPR1 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216
PPR2 2007-000343 R-CHIP;120ohm,1%,1/10W,TP,1608
PPR3 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
QLP1 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT-

Loc.No Part No Description ; Specification Remark

4-32

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

QLP2 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT­R10 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R13 2007-000118 R-CHIP;390ohm,5%,1/10W,TP,1608
R36 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
R38 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
R39 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
R40 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
R41 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
R42 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R46 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
R47 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
R7 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R73 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R8 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R9 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
RAR11 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
RC1 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
RC12 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
RC14 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
RC19 2203-000315 C-CER,CHIP;0.12NF,5%,50V,C0G,TP,1608
RC20 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­RC21 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­RC22 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,­RC23 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­RC24 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
RC25 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,­RC28 2203-001222 C-CER,CHIP;0.82NF,10%,50V,X7R,TP,1608
RC29 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
RC30 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
RC31 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
RC32 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
RC33 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
RC34 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,­RC35 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
RC36 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
RC37 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608
RC6 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
RC7 2203-001634 C-CER,CHIP;33nF,10%,50V,X7R,TP,1608,1.6m
RC8 2203-000405 C-CER,CHIP;0.18NF,5%,50V,C0G,TP,1608
RC9 2203-000560 C-CER,CHIP;220nF,+80-20%,25V,Y5V,TP,1608
RCL23 3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,150mA,,,,
RE10 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­RIC1 1204-002223 IC-RF CIRCUIT;ES6603S,LQFP,64P,10x10mm,P
RL1 2703-000398 INDUCTOR-SMD;10uH,10%,3225
RL2 2703-000398 INDUCTOR-SMD;10uH,10%,3225
RN1 2011-000475 R-NET;33OHM,5%,1/16W,L,CHIP,8P,TP,32
RN2 2011-000475 R-NET;33OHM,5%,1/16W,L,CHIP,8P,TP,32
RN3 2011-000475 R-NET;33OHM,5%,1/16W,L,CHIP,8P,TP,32
ROC1 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
ROR2 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
RR11 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
RR15 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
RR16 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
RR17 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
RR18 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608
RR19 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
RR20 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
RR21 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
RR22 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
RR24 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
RR25 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
RR26 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608
RR27 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
RR28 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
RR29 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
RR3 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608

RR32 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
RR36 2007-001694 R-CHIP;12Kohm,0.5%,1/10W,TP,1608
RR37 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
RR39 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
RR4 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608
RR44 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
RR5 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608
RR50 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
RR51 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
RR6 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608
RR7 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
RR8 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608
RR87 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216
RR9 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608
SDC3 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
SDC4 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
SDC43 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
SDC49 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
SDC5 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
SDC6 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
SDC7 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
SDC8 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
SJACK 3722-001375 JACK-DIN;4P,-,NI,BLK,­U1 1204-002224 IC-PAL/NTSC DECODER;ES6698FD,P DIFFERENT from MODELS

1204-002260 IC-PAL/NTSC DECODER;ES6629F DIFFERENT from MODELS
VAR32 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,16 CIS Only
VAR33 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,16 CIS Only
VAR34 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,16 CIS Only
VBD1 3301-001461 BEAD-SMD;300ohm,1.6x0.8x0.8mm,300mA,TP,
VBD2 3301-001461 BEAD-SMD;300ohm,1.6x0.8x0.8mm,300mA,TP,
VC10 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
VC11 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
VC14 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608 Not used CIS
VC15 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608 Not used CIS
VC16 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608 Not used CIS
VC17 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
VC30 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
VC44 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608
VC50 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
VC6 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
VC7 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
VC8 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
VC9 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
VE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
VE2 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5
VE4 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­VE5 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­VE6 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­VE7 2401-001479 C-AL;470UF,20%,10V,GP,TP,6.3*11MM,­VIC1 1204-001978 IC-VIDEO PROCESS;LA73054,-,36P,-,SSOP,7V
VL1 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
VL2 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
VL3 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
VL4 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
VL5 3301-001419 BEAD-SMD;-,220,-,500,TP,-,0.3
VL6 2703-000398 INDUCTOR-SMD;10uH,10%,3225
VR10 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR11 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR17 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP CIS Only
VR18 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 Not used CIS
VR19 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
VR2 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR20 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
VR21 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
VR3 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR32 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608

Electrical Parts List

Samsung Electronics

4-33

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization

VR33 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
VR34 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608
VR4 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR5 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR6 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR7 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR8 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VR9 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608
VRC17 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 Not used CIS
VRC18 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,16 CIS Only
VRC31 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
VSC1 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
VZ10 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD Not used CIS
VZ20 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
VZ21 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
VZ22 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
VZ23 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD
VZ5 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD Not used CIS
VZ6 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD Not used CIS
VZ7 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD Not used CIS
VZ8 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD Not used CIS
VZ9 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD Not used CIS
ZC47 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
ZC49 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
ZR49 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
ZR50 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608

Loc.No Part No Description ; Specification Remark

4-34

Samsung Electronics

Electrical Parts List

Loc.No Part No Description ; Specification Remark

This Document can not be used without Samsung’s authorization
