SV-DVD40B

SAMSUNG SV-DVD40B, SV-DVD55 Service Manual Part List

Download
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
Samsung Electronics
4-1
601 ASSY-VCR;-,COMBO4,PV14
AC18 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 AC19 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 AC20 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 AC21 2203-000315 C-CERAMIC,CHIP;0.12NF,5%,50V,C0G,TP,1608 AC22 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 AC23 2203-000125 C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,1608 AC24 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 AC25 2203-000315 C-CERAMIC,CHIP;0.12NF,5%,50V,C0G,TP,1608 AC26 2203-000125 C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,1608 AC27 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 AE10 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 AE11 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5 AE12 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 AE13 2401-000913 C-AL;22uF,20%,16V,GP,TP,5x11,5 AE14 2401-001370 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 AE8 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 AE9 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 AIC2 1002-001294 IC-D/A CONVERTER;PCM1742KE,24BIT,TSSOP,1 AIC4 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m AL1 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m AL2 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m AR15 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 AR29 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 AR41 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 AR42 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 AR43 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 AR44 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 AR45 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 AR46 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 AR47 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 AR48 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 AR49 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 AR50 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 BD601 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400, BD602 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400, BD603 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400, BD801 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m BD802 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m BD803 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m BD810 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m BD811 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m BD812 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m BD813 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m BD814 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m BD815 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m C315 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C317 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C318 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C319 2203-000843 C-CERAMIC,CHIP;39nF,10%,25V,X7R,TP,1608, C320 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C321 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608 C322 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C324 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C325 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C326 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C327 2203-001211 C-CERAMIC,CHIP;8.2nF,10%,50V,X7R,TP,1608 C328 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C329 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C330 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C331 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C332 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C333 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C334 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C335 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, C336 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C337 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, C338 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608 C339 2401-000407 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5 C340 2401-001226 C-AL;4.7uF,20%,16V,BP,TP,4x7,5mm C341 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C342 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C343 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C344 2203-000315 C-CERAMIC,CHIP;0.12NF,5%,50V,C0G,TP,1608 C345 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 C347 2203-005065 C-CERAMIC,CHIP;1000nF,+80-20%,10V,Y5V,TP C348 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C349 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C350 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C351 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C352 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C353 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C354 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C355 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C372 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C380 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608 C384 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C385 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C393 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C395 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C396 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 C3A01 2401-003122 C-AL;4.7uF,20%,50V,LL,TP,4X7,1.5 C3A02 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 C3A08 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C3A09 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608 C3A10 2203-001211 C-CERAMIC,CHIP;8.2nF,10%,50V,X7R,TP,1608 C3A11 2301-000174 C-FILM,PEF;15nF,5%,100V,TP,7.2x4.0x7.5mm C3A12 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C3A14 2203-001656 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,1608 C3A15 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C3A16 2401-003122 C-AL;4.7uF,20%,50V,LL,TP,4X7,1.5 C3A17 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C3A18 2203-001126 C-CERAMIC,CHIP;0.68nF,10%,50V,X7R,TP,160 C3A21 2203-001554 C-CERAMIC,CHIP;1.8nF,10%,50V,X7R,TP,1608 C3A23 2401-002069 C-AL;33uF,20%,16V,GP,TP,6.3x5,5 C3A24 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C3A29 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C3A30 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C3A40 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C3A41 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C3Q1 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C3Q2 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 C3Q3 2203-001086 C-CERAMIC,CHIP;0.005nF,0.25pF,50V,NP0,TP C3Q4 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C3S01 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C3S02 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C3S03 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C3S04 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C3S05 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C3S06 2401-001775 C-AL;470nF,20%,50V,GP,TP,4x7,5 C3S08 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C3S09 2401-001775 C-AL;470nF,20%,50V,GP,TP,4x7,5
4. Electrical Parts List
Loc.No Part No Description ; Specification RemarkLoc.No Part No Description ; Specification Remark
4-2
Samsung Electronics
Electrical Parts List
C3S10 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C3S11 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C3S12 2301-000008 C-FILM,PEF;2.2nF,5%,50V,TP,5.5X7X3,5mm C3S13 2301-000008 C-FILM,PEF;2.2nF,5%,50V,TP,5.5X7X3,5mm C3S14 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5 C3S15 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,­C401 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­C402 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608 C403 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­C404 2401-001085 C-AL;330nF,20%,50V,GP,-,5x9,2mm C405 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5 C406 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C407 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C408 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C409 2401-003122 C-AL;4.7uF,20%,50V,LL,TP,4X7,1.5 C410 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C4N01 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 C4N02 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C4N03 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 C4N04 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5 C4N05 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C4N06 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C4N07 2203-001656 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,1608 C4N08 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 C4N09 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C4N10 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C4N11 2401-001020 C-AL;3.3UF,20%,50V,GP,TP,4X7,5 C4N12 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C4N13 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C4N14 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C4N15 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C4N16 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C4N17 2203-001656 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,1608 C4N18 2203-001656 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,1608 C4N19 2203-000998 C-CERAMIC,CHIP;0.047NF,5%,50V,C0G,TP,160 C4N21 2203-000160 C-CERAMIC,CHIP;0.0015NF,0.25PF,50V,C0G,T C4N22 2203-000160 C-CERAMIC,CHIP;0.0015NF,0.25PF,50V,C0G,T C4N23 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C4N24 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C4N25 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C4N30 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C501 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C502 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C503 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 C504 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C505 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C506 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C507 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 C508 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 C510 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C511 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C513 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C517 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 C518 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 C519 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C520 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C521 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C522 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C523 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C524 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C525 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C526 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C527 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C529 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C530 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C535 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C536 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C537 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5 C538 2401-000665 C-AL;2.2uF,20%,50V,GP,TP,3.5x5,5 C539 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C540 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C541 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C542 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C601 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608 C602 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5 C605 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C606 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C607 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5 C608 2401-002259 C-AL;0.1F,+80-20%,5.5V,-,TP,12.5x11 C610 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C618 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5 C619 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C620 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5 C621 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C623 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C624 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 C625 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 C625B 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 C626 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 C627 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 C633 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C634 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C635 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 C636 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 C637 2203-001656 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,1608 C638 2401-002196 C-AL;4.7UF,20,25V,GP,TP,4X5,5MM,­C639 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 C640 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C641 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C642 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5 C645 2203-000357 C-CERAMIC,CHIP;0.15NF,5%,50V,C0G,TP,1608 C646 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C659 2203-001140 C-CERAMIC,CHIP;68nF,10%,16V,X7R,TP,1608, C661 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C688 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C691 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C695 2203-000357 C-CERAMIC,CHIP;0.15NF,5%,50V,C0G,TP,1608 C696 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 C6P01 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C6P02 2203-000315 C-CERAMIC,CHIP;0.12NF,5%,50V,C0G,TP,1608 C6P04 2203-000646 C-CERAMIC,CHIP;0.024NF,5%,50V,C0G,TP,160 C6P05 2203-000646 C-CERAMIC,CHIP;0.024NF,5%,50V,C0G,TP,160 C6P06 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,­C6P07 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5 C6P08 2203-001071 C-CERAMIC,CHIP;0.056NF,5%,50V,C0G,TP,160 C6P10 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C6P11 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C6P12 2401-001370 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 C6P13 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C6P15 2203-001140 C-CERAMIC,CHIP;68nF,10%,16V,X7R,TP,1608, C701 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,­C702 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C703 2401-000255 C-AL;100uF,20%,10V,WT,TP,5x11,2mm C704 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5 C705 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C706 2401-000118 C-AL;1000uF,20%,10V,GP,TP,10x12.5,5 C707 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 C708 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,­C709 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,­C816 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C817 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C818 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
Electrical Parts List
Samsung Electronics
4-3
C819 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 C820 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 C821 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 C822 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 C822A 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 C823 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 C824 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 C824A 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 C825 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 C826 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 C829 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 C830 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 C833 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 C835 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C836 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C851 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C852 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C880 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C881 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C882 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­C883 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­C884 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­C8A20 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 C8A21 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C8A22 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 C8A88 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 C904A 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 CA8001 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 CA8002 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 CA801 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 CA802 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 CA803 2401-001250 C-AL;4.7uF,20%,35V,GP,TP,4x5,5 CA805 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 CAA801 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 CAA802 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 CAA888 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 CN1 3708-001696 CONNECTOR-FPC/FFC/PIC;24P,1MM,STRAIGHT,S CN101 3711-005314 CONNECTOR-HEADER;NOWALL,16P,1R,2.5MM,STR CN2 3708-001695 CONNECTOR-FPC/FFC/PIC;13P,1MM,STRAIGHT,S CN3 3711-001018 CONNECTOR-HEADER;BOX,5P,1R,2mm,STRAIGHT, CN301 3708-000391 CONNECTOR-FPC/FFC/PIC;10P,1.25mm,STRAIGH CN3A01 3708-001165 CONNECTOR-FPC/FFC/PIC;6P,1.25mm,STRAIGHT CN3A02 3710-001881 CONNECTOR-SOCKET;2P,1R,2.5MM,STRAIGHT,SN CN3A1S 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm CN601 3711-005312 CONNECTOR-HEADER;3WALL,6P,1R,2MM,STRAIGH CN604 3711-004833 CONNECTOR-HEADER;BOX,12P,2R,2MM,STRAIGHT CNR1 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 CNR2 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 CNR3 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 CNR4 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 CNR5 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 CNR6 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 CVV801 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 CVV802 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 CVV803 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 D301 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D302 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP D401 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP D4N01 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D4N02 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D501 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D601 0401-000008 DIODE-SWITCHING;DAN217,80V,100mA,SOT-23, D603 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D620 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP D688 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D692 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D6P01 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D701 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D702 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D703 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D704 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D705 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP D706 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D805 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, DAA801 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT­DAA802 0401-000008 DIODE-SWITCHING;DAN217,80V,100mA,SOT-23, DAA803 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT­DAA804 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT­DAA805 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT­DC1 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 DC2 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 DD1 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOT­DOC1 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 DOC2 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 DOC3 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 DOC4 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 DOE1 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 DOIC1 AH14-10004R IC;M74HCU04,SOP,TAPE 14P DOIC2 3707-001060 CONNECTOR-OPTICAL;PLUG,GP1FA550TZ,6DB,2. DOL1 2901-001125 FILTER-EMI ON BOARD;50V,0.5A,-,220pF,7x2 DOL2 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m DOL3 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm DOR1 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 DOR2 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 DOR3 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 DOZ1 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 DOZ2 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 DQ1 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­DQ2 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­DQ3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­DR1 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 DR2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 DR3 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 DR4 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 DR5 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 DR6 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 DR7 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608 DR8 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608 DT701 AK07-00004A LED DISPLAY;BCD-9027A,(BRIGHT),DVD-V3000 FC1 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC10 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC11 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC12 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC13 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC15 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC2 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC3 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC4 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC5 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608 FC6 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 FC7 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 FE1 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 FE2 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 FE3 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 FE4 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 FE5 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 FE6 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 FL3A01 2702-000166 INDUCTOR-RADIAL;47uH,5%,6x6.4mm FR1 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 FR10 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 FR11 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 FR12 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
FR13 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 FR14 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 FR15 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608 FR16 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 FR17 2007-000088 R-CHIP;7.5Kohm,5%,1/10W,TP,1608 FR18 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 FR2 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 FR3 2007-000034 R-CHIP;1OHM,5%,1/4W,DA,TP,3216 FR4 2007-000034 R-CHIP;1OHM,5%,1/4W,DA,TP,3216 FR5 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 FR6 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 FR7 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 FR8 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 FR9 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 IC301 1204-001922 IC-VIDEO PROCESS;LA71750M,QFP,100P,-,PLA IC3S01 1204-001921 IC-CHROMA;LA70100M,SOP,30P,375MIL,PLASTI IC4N01 1204-001765 IC-AUDIO PROCESSOR;MSP3417D(PQFP),PQFP,4 IC501 1204-001920 IC-AUDIO PROCESSOR;LA72646M,QFP,80P,14X1 IC601 AK09-00023A IC MICOM;N128-B08-3BA,SV-DVD50-02,100PI IC604 AC14-12009W IC-RESET;PST572K,TO-92,R59-1766 2.5V IC605 1103-001150 IC-EEPROM;524C80D81,8KBit,DIP,8P,300MIL, IC608 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL IC6P01 1204-001794 IC-AUDIO PROCESSOR;LC74775NM-9808,MPF,30 IC6P01 1204-001796 IC-OSD PROCESSOR;LC74759JM-9820,MFP,24P, Russia Only IC701 1003-001443 IC-LED DRIVER;PT6959,SOIC,28P,300MIL,-,­IC802 0801-002741 IC-CMOS LOGIC;BU4053BCFV,MUX,SSOP,16P,17 ICA810 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m ICA811 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m J601 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 JC801 3722-001573 JACK-SCART;42P/2R,-,SN,BLK/BLU,#20-28 JC802 AC37-22002N JACK-PIN;3.2mm,DPAE-9836,3P(1),HI-FI,SV JK701 3722-001943 JACK-PIN;3P,8.3PI,NI,BLK,­JP1 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 JP13 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 JP14 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 JP15 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 JP16 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 JP5 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 JP6 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 L302 2702-000108 INDUCTOR-RADIAL;100uH,5%,6x6.4mm L370 2702-000108 INDUCTOR-RADIAL;100uH,5%,6x6.4mm L3A01 2702-000120 INDUCTOR-RADIAL;15mH,5%,6.2x7.4mm L3A02 2702-000108 INDUCTOR-RADIAL;100uH,5%,6x6.4mm L3A03 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm L3Q1 2701-000206 INDUCTOR-AXIAL;56uH,5%,2.4x3.4mm L3Q2 2701-000131 INDUCTOR-AXIAL;15uH,5%,2.5x3.4mm L402 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm L4N01 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6x6.4mm L4N02 2702-000108 INDUCTOR-RADIAL;100uH,5%,6x6.4mm L4N03 2702-000160 INDUCTOR-RADIAL;4.7uH,10%,6x6.4mm L4N04 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­L603 2702-000108 INDUCTOR-RADIAL;100uH,5%,6x6.4mm L605 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm L6P03 2702-000142 INDUCTOR-RADIAL;22uH,5%,6x6.4mm L6P05 2702-000144 INDUCTOR-RADIAL;27uH,5%,6x6.4mm L701 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm L702 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm L802 2702-000108 INDUCTOR-RADIAL;100uH,5%,6x6.4mm L803 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L804 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L805 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L806 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L807 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L808 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L809 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L810 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm
L811 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L812 2701-000181 INDUCTOR-AXIAL;33uH,5%,2.4x3.4mm L814 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­LD601 0601-000517 LED-IR;RECTANGULA,4x6.0mm,75mW,6V,950 PC1 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC10 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC11 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC12 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC13 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC2 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC20 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC3 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC4 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 PC5 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC6 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC7 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC8 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PC9 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 PE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE10 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE11 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE12 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE13 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 PE2 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE20 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE3 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE4 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE5 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE6 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­PE8 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PE9 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 PIC1 1203-002178 IC-VOLTAGE REGULATOR;1563,SOP,7P,173MIL, PIC2 1203-002779 IC-VOLTAGE REGULATOR;G952T63U,SOT-223,3P PIC3 1203-002185 IC-VOLTAGE REGULATOR;3RD13,TO-220,4P,402 PL1 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm PL2 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm PL3 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm PL5 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm PL6 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm PL7 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm PR3 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 PT601 0604-001206 PHOTO-INTERRUPTER;TR,-,150mW,CY5894102,B PT602 0604-001206 PHOTO-INTERRUPTER;TR,-,150mW,CY5894102,B Q302 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q351 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, Q3A01 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3A02 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, Q3A03 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 Q3A04 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 Q3A05 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 Q3A06 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, Q3Q1 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q2 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q3 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q4 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q3Q5 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S Q3Q6 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT Q3Q7 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q601 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT Q6P01 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, Q6P02 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, Q6P04 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q802 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT Q803 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT Q804 0504-000152 TR-DIGITAL;KSR2101,PNP,200mW,4.7K/4.7K,S Q808 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT
Loc.No Part No Description ; Specification Remark
4-4
Samsung Electronics
Electrical Parts List
Loc.No Part No Description ; Specification Remark
Q809 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q810 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q811 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­Q812 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT Q813 0504-000129 TR-DIGITAL;KSR1104,NPN,200mW,47K/47K,SOT Q882 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, QA801 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­QA802 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­QAA801 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP QAA802 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT QAA803 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, QAA804 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT QAA805 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP QAA806 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­QAA807 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT QAA808 0501-000341 TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT­QAA809 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP R315 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 R316 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 R320 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608 R321 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R322 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608 R323 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608 R324 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 R325 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R326 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R327 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 R328 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 R329 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608 R330 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 R331 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 R333 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608 R334 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 R335 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R350 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 R360 2001-000773 R-CARBON;470KOHM,5%,1/8W,AA,TP,1.8X3.2M R371 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 R372 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R373 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 R380 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 R3A01 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R3A04 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 R3A05 2007-000616 R-CHIP;24Kohm,5%,1/10W,TP,1608 R3A06 2007-000450 R-CHIP;180ohm,5%,1/10W,TP,1608 R3A07 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608 R3A08 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 R3A09 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R3A11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 R3A12 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R3A13 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 R3A14 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 R3A16 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R3A17 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 R3A18 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 R3A23 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 R3A24 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 R3A25 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 R3A26 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R3A28 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 R3A50 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608 R3A51 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R3A60 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608 R3Q1 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 R3Q12 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 R3Q2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R3Q3 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608
R3Q4 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608 R3Q5 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 R3Q6 2007-000259 R-CHIP;1.6Kohm,5%,1/10W,TP,1608 R3Q7 2007-000083 R-CHIP;3Kohm,5%,1/10W,TP,1608 R3Q8 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 R3Q9 2007-001157 R-CHIP;750ohm,5%,1/10W,TP,1608 R3S01 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R3S02 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 R401 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 R402 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R403 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R404 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R406 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608 R407 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R408 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 R4N01 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R4N02 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R4N03 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R4N04 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608 R4N05 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R4N06 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R501 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R502 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608 R503 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 R505 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R506 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608 R507 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R508 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608 R509 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 R510 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R511 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R512 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608 R517 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 R518 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R519 2007-001056 R-CHIP;6.2Kohm,5%,1/10W,TP,1608 R520 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R521 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 R522 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 R523 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 R533 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R540 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R545 2007-000512 R-CHIP;2.4Kohm,5%,1/10W,TP,1608 R546 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R547 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R550 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R551 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 R552 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R553 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 R570 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R571 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608 R608 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608 R609 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608 R610 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R611 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R612 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R613 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R614 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R615 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R617 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608 R630 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R631 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R640 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R641 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 R642 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 R644 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R647 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
Electrical Parts List
Samsung Electronics
4-5
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
R651 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 R652 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM R657 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R657 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 R660 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 R661 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608 R666 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R667 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R668 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 R669 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 R670 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 R671 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 R672 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 R673 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R674 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R675 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6.4MM R676 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 R677 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 R678 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 R679 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 R682 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 R685 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 R688 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608 R690 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R691 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 R693 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 R694 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 R698 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R6C2 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R6P01 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R6P02 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R6P03 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608 R6P04 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R6P05 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R6P06 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 R6P07 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 R6P08 2007-000118 R-CHIP;390ohm,5%,1/10W,TP,1608 R6P09 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R6P09 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 Russia Only R6P10 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 R6P12 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 R6P13 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 R6P14 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 R710 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 R711 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R712 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM R765 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m R766 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m R767 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m R770 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 R771 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 R772 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 R802 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 R803 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 R805 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608 R806 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608 R807 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 R808 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 R809 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 R810 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R811 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R812 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 R813 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608 R814 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608 R815 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R816 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R819 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R820 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R821 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608 R822 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 R825 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 R839 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 R841 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 R842 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 R843 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 R844 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 R861 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R862 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 R875 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 R876 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 R8A00 2007-000107 R-CHIP;470Kohm,5%,1/10W,TP,1608 R8A01 2007-000107 R-CHIP;470Kohm,5%,1/10W,TP,1608 RA801 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RA802 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RA895 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608 RA896 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608 RAA802 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 RAA803 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 RAA804 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RAA805 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RAA806 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RAA810 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 RAA811 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 RAA814 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 RAA815 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 RAA816 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 RAA817 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 RC1 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC11 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC12 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC13 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, RC14 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 RC15 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, RC16 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 RC17 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP, RC18 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 RC19 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP, RC2 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 RC21 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC22 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC23 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC24 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC25 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC27 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC28 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC29 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 RC3 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 RC31 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC32 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP, RC33 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608 RC34 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 RC35 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 RC4 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 RC5 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 RC6 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC60 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 RC7 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC8 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RC9 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 RD801 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, RD802 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, RDS811 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
Loc.No Part No Description ; Specification Remark
4-6
Samsung Electronics
Electrical Parts List
Loc.No Part No Description ; Specification Remark
RE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 RE10 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 RE2 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 RE3 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 RE4 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 RE5 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 RE6 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 RE7 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 RE8 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 RE9 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 RIC1 AH13-00009B IC ASIC;S5L1463A01,DVD-P293,80,+5V,-40 RL11 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm RL3 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m RM701 AC32-00006A MODULE REMOCON;TSOP2238WE1,38KHZ,-,5.08m RQ1 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT­RQ2 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT­RR11 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RR12 2007-000312 R-CHIP;10ohm,5%,1/4W,TP,3216 RR15 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 RR16 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 RR17 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 RR18 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RR19 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 RR2 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608 RR21 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 RR22 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608 RR23 2007-001235 R-CHIP;910Kohm,5%,1/10W,TP,1608 RR24 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608 RR25 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 RR26 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 RR28 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 RR29 2007-000381 R-CHIP;13Kohm,5%,1/10W,TP,1608 RR3 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 RR31 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 RR4 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 RR5 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 RR60 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RR65 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 RR6A 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 RR7A 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 RR8 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 RR9 2007-000312 R-CHIP;10ohm,5%,1/4W,TP,3216 RS438 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RS439 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RS440 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RS497 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RS604 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RS609 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RS648 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RS664 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RVV801 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 RVV802 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 RVV803 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 S602 0603-001011 PHOTO TR;NPN,35V,6V,50mA,75mW,BK SC1 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC11 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP, SC13 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608, SC14 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 SC15 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC16 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 SC17 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 SC18 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 SC2 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, SC23 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC24 2203-000681 C-CERAMIC,CHIP;0.027NF,5%,50V,C0G,TP,160 SC25 2203-000681 C-CERAMIC,CHIP;0.027NF,5%,50V,C0G,TP,160
SC26 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC28 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 SC29 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 SC3 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608 SC31 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 SC32 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 SC33 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC34 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 SC35 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC36 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 SC38 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC4 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, SC41 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC42 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC43 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608, SC44 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608 SC45 2203-001126 C-CERAMIC,CHIP;0.68nF,10%,50V,X7R,TP,160 SC46 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, SC47 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 SC48 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 SC5 2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608 SC50 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP, SC52 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC53 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC54 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC55 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC56 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC57 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC58 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC59 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608 SC6 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 SC60 2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 SC7 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 SC8 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 SC9 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 SE1 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 SE2 2401-003498 C-AL;220uF,20%,10V,GP,TP,6.3x7mm,2. SIC1 AH13-00006B IC ASIC;S5L1455X01,DVD-P293,160,+3.3V, SIC2 1105-001504 IC-DRAM;IC41LV16256,256Kx16Bit,SOJ,40P SIC3 1003-001489 IC-MOTOR DRIVER;FAN8728,HQFP,48P,14X14MM SJACK 3722-001998 JACK-DIN;4P+1P,-,Cu-Sn,BLK,­SL1 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m SL2 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m SL3 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m SL4 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m SR1 2007-001235 R-CHIP;910Kohm,5%,1/10W,TP,1608 SR11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 SR13 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 SR14 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 SR15 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 SR16 2007-000655 R-CHIP;27Kohm,5%,1/10W,TP,1608 SR17 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 SR18 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 SR19 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 SR2 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 SR21 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 SR22 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 SR23 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 SR24 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 SR26 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 SR27 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 SR28 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 SR29 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 SR3 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 SR31 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 SR32 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
Electrical Parts List
Samsung Electronics
4-7
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
SR33 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SR34 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 SR35 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SR36 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 SR39 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608 SR4 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SR41 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SR42 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 SR43 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SR44 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 SR45 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 SR46 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 SR49 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 SR5 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 SR50 2007-000305 R-CHIP;10Mohm,5%,1/10W,TP,1608 SR51 2007-000305 R-CHIP;10Mohm,5%,1/10W,TP,1608 SR52 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SR54 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 SR6 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SR7 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SR8 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 SR9 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 SVL1 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m SVL2 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m SW601 AC34-00003A SWITCH MODE;-,-,-,-,-,-,-,-,-,-,-,-,-,NT SW602 AC34-20100B SWITCH-REC;-,-,X-9,­SW704 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW705 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW706 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW708 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW709 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SY1 2801-000261 CRYSTAL-UNIT;33.8688MHz,50ppm,28-AAA,12p TM401 AC40-00001T TM BLOCK;TCPL0601PD23A,G/L-SPLITTER,-,- L-B/G TM401 AC40-00001R TM BLOCK;TCMI0610PD13A,UHF-I(MO/HI),-,- I TM401 AC40-00014A TM BLOCK;TCMK0601PD13A,G/I/K(MONO,HIFI) G/K VC10 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 VC11 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 VC13 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 VC17 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 VC18 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 VC6 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 VC7 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 VC8 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 VC9 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 VE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 VE2 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 VE4 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­VE5 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­VE6 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­VE7 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­VIC1 1204-001978 IC-VIDEO PROCESS;LA73054,-,36P,-,SSOP,7V VL1A 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m VL6 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 VR29 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 VR30 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 VR31 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 VR35 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 VZ1 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 VZ2 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 VZ3 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 VZ4 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 W111 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 W225 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 W238 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 W239 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 W655 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
W657 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 XT301 2801-001397 CRYSTAL-UNIT;4.433619MHz,20ppm,28-AAA,S, XT4N01 2801-003171 CRYSTAL-UNIT;18.432MHz,20PPM,28-AAM,4PF, XT601 2801-003318 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAP,12.5 XT602 2801-003139 CRYSTAL-UNIT;8MHz,50ppm,28-AAA,22pF,80oh ZC1 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC10 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC101 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC102 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC103 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC104 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC105 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC106 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC107 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC108 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC109 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC11 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC112 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC113 2203-000041 C-CERAMIC,CHIP;0.01NF,0.25PF,50V,C0G,TP, ZC12 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC13 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC14 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC15 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC16 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC17 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC18 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC19 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC195 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 ZC196 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC2 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC20 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC21 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC22 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC23 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC24 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC25 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC28 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC29 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 ZC3 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC30 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 ZC31 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 ZC32 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 ZC34 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC35 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC36 2203-000681 C-CERAMIC,CHIP;0.027NF,5%,50V,C0G,TP,160 ZC37 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC38 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC4 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC40 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC42 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160 ZC43 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC5 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC6 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZC7 2203-000681 C-CERAMIC,CHIP;0.027NF,5%,50V,C0G,TP,160 ZC78 2203-000998 C-CERAMIC,CHIP;0.047NF,5%,50V,C0G,TP,160 ZC79 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 ZC80 2203-000998 C-CERAMIC,CHIP;0.047NF,5%,50V,C0G,TP,160 ZC881 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZC9 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ZD401 0403-000390 DIODE-ZENER;UZP33B,33V,31.4-34.6V,1W,DO­ZD701 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZD801 0403-000297 DIODE-ZENER;MTZ6.2B,6.2V,5.96-6.27V,500m ZD882 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDA880 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDA881 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDA882 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m
Loc.No Part No Description ; Specification Remark
4-8
Samsung Electronics
Electrical Parts List
Loc.No Part No Description ; Specification Remark
ZDA883 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDA884 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDA885 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDA895 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ZDA896 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ZDA897 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ZDA898 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ZDS805 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDS806 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ZDS807 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDS808 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ZDS809 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ZDS810 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDS811 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZDS813 0403-001083 DIODE-ZENER;UDZ9.1B,9.1V,8.85-9.23V,200m ZE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 ZE100 2401-000922 C-AL;22uF,20%,16V,GP,TP,5x5,5 ZE2 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 ZE3 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 ZE4 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 ZIC1 1204-002092 IC-DECODER;ZR36742,QFP,208P,28X28MM,PLAS ZIC2 1105-001513 IC-DRAM;IS42S16400A-7T,1Mx16Bitx4Bit,T ZIC3 1107-001369 IC-FLASH MEMORY;MBM29LV800BA-90PFTN,512K ZIC7 1103-001204 IC-EEPROM;24C021,256x8Bit,SOP,8P,150MIL, ZIC8 0801-002701 IC-CMOS LOGIC;74VHCT125A,BUFFER,TSSOP,14 ZL10 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m ZL11 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m ZL195 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m ZL2 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 ZL3 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 ZL5 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m ZL6 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m ZL7 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m ZL78 3301-001309 CORE-FERRITE BEAD;AB,47ohm,1.6x0.8x0.8mm ZL8 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m ZL9 3301-001419 CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m ZR1 2007-000360 R-CHIP;12ohm,1%,1/10W,TP,1608 ZR10 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR101 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 ZR11 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR12 2011-000816 R-NETWORK;100OHM,5%,1/16W,L,CHIP,8P,TP ZR14 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR15 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR16 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR17 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR18 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR19 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR2 2007-000360 R-CHIP;12ohm,1%,1/10W,TP,1608 ZR20 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR21 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR22 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 ZR23 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 ZR24 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 ZR25 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 ZR26 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR27 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR28 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR29 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR3 2007-000118 R-CHIP;390ohm,5%,1/10W,TP,1608 ZR30 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR31 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR32 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR33 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 ZR34 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR35 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 ZR36 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
ZR37 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 ZR38 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZR39 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZR4 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR40 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 ZR41 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 ZR44 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR45 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR46 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR48 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR5 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 ZR56 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR57 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR6 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR62 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR63 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 ZR7 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 ZR78 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 ZR79 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 ZR80 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 ZR91 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZR92 2007-000303 R-CHIP;10Kohm,5%,1/4W,TP,3216 ZR93 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZR94 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZR95 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZR96 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZR97 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZR98 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 ZY1 2801-004279 CRYSTAL-UNIT;27.00MHz,10ppm,28-AAA,20pF,
602 AC92-01318A ASSY PCB-SMPS;COMBO4,SMPS PCB ASS’Y
BD1S01 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­BD1SS3 AC27-92001M COIL-INDUCTOR;RH3.5X6.5RS,BEAD(RADIAL),­C1P101 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5 C1P102 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5 C1P103 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5 C1P104 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C1P105 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5 C1P106 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C1P107 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C1P109 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C1P110 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C1P111 2401-000463 C-AL;10uF,20%,35V,GP,-,5x5,2mm C1P112 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5 C1P113 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 C1P114 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 C1P115 2401-003122 C-AL;4.7uF,20%,50V,LL,TP,4X7,1.5 C1P116 2401-003122 C-AL;4.7uF,20%,50V,LL,TP,4X7,1.5 C1SA04 2201-000987 C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,TP,12. C1SD02 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13. C1SD12 2305-001029 C-FILM,MPEF;10nF,10%,630V,TP,12x9x12.5,5 C1SD13 2305-001029 C-FILM,MPEF;10nF,10%,630V,TP,12x9x12.5,5 C1SD16 2201-000012 C-CERAMIC,DISC;0.22NF,10%,1KV,Y5P,TP,6.3 C1SF01 2201-000987 C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,TP,12. C1SF02 2401-002608 C-AL;33uF,20%,35V,GP,TP,5x11,5 C1SQ04 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 C1SS01 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13. C1SS03 2201-000916 C-CERAMIC,DISC;0.1NF,10%,400V,Y5U,TP,10X C1SS04 2201-000916 C-CERAMIC,DISC;0.1NF,10%,400V,Y5U,TP,10X C1SS06 2401-002299 C-AL;4.7uF,20%,50V,GP,TP,5x7,5 C1SS10 2401-003303 C-AL;82uF,20%,400V,GP,BK,22X30,10 C1SS15 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5 C1SS16 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,­C1SS17 2401-003480 C-AL;1000UF,20%,10V,LZ,TP,10X16MM,5 C1SS18 2401-001992 C-AL;2200UF,20%,10V,WT,TP,10X20MM,5 C1SS19 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
Electrical Parts List
Samsung Electronics
4-9
Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
C1SS20 2201-000812 C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,BK,12. C1SS21 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5 C1SS22 2401-003477 C-AL;330UF,20%,25V,LZ,TP,10X12.5MM, C1SS26 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5 C1SS27 2301-000129 C-FILM,PEF;100nF,5%,50V,TP,10X9X4.3X5,5m C901A 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V CN101 3710-001919 CONNECTOR-SOCKET;16P,1R,2.5MM,ANGLE-F,SN CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA D1P103 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D1P104 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D1P105 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D1P107 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D1P108 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D1SF01 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, D1SF02 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP D1SS11 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP D1SS12 0404-001180 DIODE-SCHOTTKY;SE55,45V,5000MA,TO-220A,B D1SS13 0404-001180 DIODE-SCHOTTKY;SE55,45V,5000MA,TO-220A,B D1SS14 0404-001180 DIODE-SCHOTTKY;SE55,45V,5000MA,TO-220A,B D1SS15 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP D1SS16 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,DO-204AC,TP D1SS19 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP F1SD01 3601-001123 FUSE-CARTRIDGE;250V,1.6A,TIME-LAG,CERAMI FZ01 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m FZ02 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m FZ03 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m FZ04 3601-001240 FUSE-RADIAL LEAD;50V,1A,-,-,5.0x4.0x5.0m IC1S02 0604-000186 PHOTO-COUPLER;TR,-,200mW,DIP-4,ST IC1S03 AC14-12006D IC;KA431Z,TO-92,TAPING IC1SS2 1203-002805 IC-PWM CONTROLLER;ICE2BS01,PDIP,8P,9.52X L1P101 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4mm,1/0.5 L1P102 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS01 AC29-00002A FILTER LINE NOISE;-,30mH,-,-,BLF-2116 L1SS02 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,­L1SS03 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS04 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­L1SS05 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,­PT1SD1 AC26-00012A TRANS SWITCHING;EER3530,DIVA(EUROPE),-,2 Q1P101 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L Q1P102 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T Q1P103 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T Q1P104 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L Q1P105 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L Q1P106 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L Q1P107 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L Q1P108 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T Q1P109 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T Q1P110 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L Q1P111 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM R1P103 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM R1P104 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M R1P105 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM R1P109 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM R1P110 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M R1P111 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM R1P112 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM R1P222 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM R1SD11 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M R1SD13 2006-000273 R-CEMENT;27KOHM,5%,2W,CA,BK,6.4X6.5X18M R1SD14 2001-000598 R-CARBON;3.3OHM,5%,1/8W,AA,TP,1.8X3.2MM R1SF05 2001-000527 R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SF06 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m R1SF07 2003-000105 R-METAL OXIDE;0.33ohm,5%,2W,AD,TP,6x16mm R1SQ11 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R1SR01 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M R1SR02 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M R1SR03 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP,1.8X3.2M R1SS01 2006-000262 R-CEMENT;2.7ohm,10%,2W,CB,TP,7.5x11x20. R1SS08 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM R1SS31 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM R1SS32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R1SS33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R1SS34 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm R1SS35 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m R1SS36 2008-001033 R-FUSIBLE(S);10ohm,5%,2W,AF,TP,3.9x10mm VA1SS1 1405-001026 VARISTOR;470V,600A,9x7mm,TP ZD1P02 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ZD1P04 0403-000717 DIODE-ZENER;MTZJ5.1B,5.1V,4.94-5.2V,500m ZD1P05 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D ZD1P06 0403-000717 DIODE-ZENER;MTZJ5.1B,5.1V,4.94-5.2V,500m ZD1SS1 0403-000713 DIODE-ZENER;MTZJ20B,20V,18.63-17.7V,500m ZD1SS2 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500mW,DO
701 ASSY SORT-FUNCTION;SV-DVD55,03-SECCOM430
CN701 3710-001918 CONNECTOR-SOCKET;6P,1R,2MM,ANGLE,SN SW710 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW711 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW712 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW713 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW714 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW715 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW716 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW720 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW721 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW722 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW723 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW724 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW725 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW726 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW727 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0 SW728 3404-001182 SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0
Loc.No Part No Description ; Specification Remark
4-10
Samsung Electronics
Electrical Parts List
Loc.No Part No Description ; Specification Remark
