Samsung Strive SGH-A687, Strive User Manual

Download

Page 1

SGH-A687 Series

PORTABLE Quad-BAND

MOBILE PHONE

User Manual

Please read this manual before operating your

phone, and keep it for future reference.

a687 Crunch.book Page i Tuesday, February 23, 2010 6:20 PM

Page 2

a687_UCJB4_WC_022310_F8

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

Samsung Telecommunications America (STA), LLC

Headquarters: Customer Care Center: 1301 E. Lookout Drive 1000 Klein Rd. Richardson, TX 75082 Plano, TX 75074 Toll Free Tel: 1.888.987.HELP (4357)

Internet Address: www.samsungusa.com

2010 Samsung Telecommunications America, LLC is a registered trademark of Samsung Electronics America, Inc. and its related

entities. Do you have questions about your Samsung Mobile Phone?

For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:

www.samsungtelecom.com/support

a687 Crunch.book Page ii Tuesday, February 23, 2010 6:20 PM

Page 3

T9 Text Input is licensed by Tegic Communications and is covered by U.S. Pat. 5,818,437; U.S. Pat. 5,953,541; U.S. Pat. 6,011,554 and other patents pending.

ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other countries. The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are registered

trademarks and are wholly owned by the Bluetooth SIG. microSD™ and the microSD logo are Trademarks of the SD Card Association. Devices purchased for use on AT&T's system are designed for use exclusively on AT&T's system. You agree that you won't make any

modifications to the Equipment or programming to enable the Equipment to operate on any other system. A voice plan is required on all voice-capable devices, unless specifically noted otherwise in the terms governing your agreement. Some devices or plans may require you to subscribe to a data plan.

Your phone is designed to make it easy for you to access a wide variety of content. For your protection, AT&T wants you to be aware that some applications that you enable may involve the location of your phone being shared. For applications available through AT&T, AT&T offers privacy controls that let you decide how an application may use the location of your phone and other phones on your account. However, AT&T's privacy tools do not apply to applications available outside of AT&T. Please review the terms and conditions and the associated privacy policy for each location-based service to learn how location information will be used and protected.

Your phone may be used to access the Internet and to download, and/or purchase goods, applications, and services from AT&T or elsewhere from third parties. AT&T provides tools for you to control access to the Internet and certain Internet content. These controls may not be available for certain devices which bypass AT&T controls.

A&T may collect certain types of information from your device when you use AT&T services to provide customer support and to improve its services. For more information on AT&T's Privacy Policy, visit

http://www.att.com/privacy

Open Source Software

Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered under the open source licenses, please visit:

http://www.samsungnetwork.com/Home/opensource

a687 Crunch.book Page iii Tuesday, February 23, 2010 6:20 PM

Page 4

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

a687 Crunch.book Page iv Tuesday, February 23, 2010 6:20 PM

Page 5

Table of Contents

Section 1: Getting Started .............................................. 5

Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Switching the Phone On or Off . . . . . . . . . . . . . . . . . . . . . . . . . 8

Locking and Unlocking the Screen . . . . . . . . . . . . . . . . . . . . . . 9

Setting Up Your Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Section 2: Understanding Your Phone ......................... 10

Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Front Open View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . 10

Side Views of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Rear View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Section 3: Menu Navigation ......................................... 16

Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Section 4: Entering Text ............................................... 18

Using the QWERTY Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Changing the Text Input Mode . . . . . . . . . . . . . . . . . . . . . . . . 19

Using Fn (numeric) Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Using SYM (symbol) Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Section 5: Call Functions .............................................20

Displaying Your Phone Number . . . . . . . . . . . . . . . . . . . . . . . 20

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Making a Call Using Speed Dial . . . . . . . . . . . . . . . . . . . . . . . 21

Making a Call from the Address Book . . . . . . . . . . . . . . . . . . 21

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Options During a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Video Share . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Call Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Data Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Section 6: Changing Your Settings .............................. 29

Quick Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Sound Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Normal Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Silent Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Driving Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Outdoor Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Time & Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Configuring Your Phone’s USB Settings . . . . . . . . . . . . . . . . . 46

Network Profile Configuration . . . . . . . . . . . . . . . . . . . . . . . . 47

Applications Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Memory Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Software Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

a687 Crunch.book Page 1 Tuesday, February 23, 2010 6:20 PM

Page 6

Phone Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Section 7: Understanding Your Address Book ............ 52

AT&T Address Book Activation . . . . . . . . . . . . . . . . . . . . . . . . 52

Address Book Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Adding a New Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Using Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Address Book Entry Options . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Sync Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Finding My Own Phone Number . . . . . . . . . . . . . . . . . . . . . . . 57

FDN Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Group Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Adding Speed Dial Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Using the Service Dialing Numbers . . . . . . . . . . . . . . . . . . . . . 59

Managing Address Book Entries . . . . . . . . . . . . . . . . . . . . . . . 59

Yellow Pages Mobile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Section 8: My Stuff ....................................................... 63

My Stuff Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Memory Card Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Online Locker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Other Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Used Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Section 9: Camera ........................................................ 70

Using the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Camera Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Using the Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Camcorder Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Section 10: Mobile Video ............................................. 76

Viewing a Video Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Using the Video Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Customizing Mobile Video . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Section 11: Messaging ................................................. 78

Types of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Creating and Sending Messages . . . . . . . . . . . . . . . . . . . . . . 78

Viewing New Received Messages . . . . . . . . . . . . . . . . . . . . . . 79

Using Message Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Deleting Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Messaging Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Using Instant Messaging (IM) . . . . . . . . . . . . . . . . . . . . . . . . . 83

Using Mobile Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Section 12: Games & Applications .............................. 84

Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Section 13: AppCenter ................................................. 87

Ringtones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Cool Tools/Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

a687 Crunch.book Page 2 Tuesday, February 23, 2010 6:20 PM

Page 7

Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Color Graphics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Themes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Answer Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

MEdia Net Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

AppCenter Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Section 14: AT&T Music ...............................................89

Accessing AT&T Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Using the Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Using Playlists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Shop Music/Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

MusicID 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Using XM Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Accessing Music Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Make-UR-Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Music Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Section 15: AT&T GPS ..................................................99

Shopping for GPS Applications . . . . . . . . . . . . . . . . . . . . . . . . 99

AllSport GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Loopt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Launching AT&T Navigator . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Using Navigator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Obtaining Driving Directions . . . . . . . . . . . . . . . . . . . . . . . . . 101

Where . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Section 16: Mobile Web ............................................. 103

Accessing the Mobile Web . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Homepage - att.net . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Navigating with the Mobile Web . . . . . . . . . . . . . . . . . . . . . . 104

Enter a URL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Search the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

My Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

My Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Using Bookmarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Emptying the Cookies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Using your History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Changing the WAP Profiles . . . . . . . . . . . . . . . . . . . . . . . . . 107

Section 17: Tools ........................................................ 109

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Voice Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Record Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Tip Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

World Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

a687 Crunch.book Page 3 Tuesday, February 23, 2010 6:20 PM

Page 8

Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Section 18: Accessibility ............................................ 118

Section 19: Health and Safety Information ...............119

Health and Safety Information . . . . . . . . . . . . . . . . . . . . . . . . 119

Please Note the Following Information When Using

Your Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Samsung Mobile Products and Recycling . . . . . . . . . . . . . . . 121

UL Certified Travel Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Consumer Information on Wireless Phones . . . . . . . . . . . . . . 121

Road Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Responsible Listening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Using Your Phone Near Other Electronic Devices . . . . . . . . . 131

FCC Hearing-Aid Compatibility (HAC) Regulations for

Wireless Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Potentially Explosive Environments . . . . . . . . . . . . . . . . . . . . 133

Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

FCC Notice and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Other Important Safety Information . . . . . . . . . . . . . . . . . . . . 135

Product Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Availability of Various Features/Ring Tones . . . . . . . . . . . . . . 136

Battery Standby and Talk Time . . . . . . . . . . . . . . . . . . . . . . . 136

Battery Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Section 20: Warranty Information .............................139

Standard Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 139

End User License Agreement for Software . . . . . . . . . . . . . . 142

Index ............................................................................ 147

a687 Crunch.book Page 4 Tuesday, February 23, 2010 6:20 PM

Page 9

Getting Started 5

Section 1: Getting Started

This section explains how to start using your phone by first configuring your hardware, activating your service, and then setting up your voice mail.

Setting Up Your Phone

Prior to use it is necessary to install both the battery and SIM into their corresponding internal compartments. The microSD™ card slot is also located in this same internal area.

1. Remove the battery cover by pressing down on the back

cover and sliding the cover in the direction shown (1).

2. Lift the cover away from the phone (2).

Installing the SIM Card

When you subscribe to a cellular network, you are provided with a plug-in SIM card loaded with your subscription details, such as your PIN, available optional services, and many others features.

Important!:

The plug-in SIM card information and its contacts can be easily damaged by scratching or bending, so be careful when handling, inserting, or removing the card. Keep all SIM cards out of reach of small children.

䊳

Carefully slide the SIM card into the SIM card socket until the card locks into place.

•

Make sure that the card’s gold contacts face into the phone and that the upper-left angled corner of the card is positioned as shown.

a687 Crunch.book Page 5 Tuesday, February 23, 2010 6:20 PM

Page 10

Note:

If the card is not inserted correctly, the phone does not detect the SIM card. Re-orient the card back into the slot.

Installing the Memory Card

Your phone also supports the use of a memory card (microSD) for data storage of such things as data, music, pictures, and video files. This type of memory card is designed for use with this mobile phone and other devices.

1. Push the microSD card into the slot until it clicks (as

shown).

•

Make sure the microSD’s gold contact pins face upward and the card is securely inserted.

Note:

The Samsung a687 has been tested to support up to a 16GB memory card.

Installing the Batter y

1. Insert the battery into the opening on the back of the

phone, making sure the connectors align (1).

2. Gently press down to secure the battery (2).

3. Replace the battery cover onto the back of the phone (1).

Correct

Incorrect

a687 Crunch.book Page 6 Tuesday, February 23, 2010 6:20 PM

Page 11

Getting Started 7

Slide the cover in the direction shown while pressing down until you hear a light click (2).

Note:

Make sure the battery is properly installed before switching on the phone.

Charging a Battery

Your phone is powered by a rechargeable Li-ion battery. The Travel Adapter that is used to charge the battery, is included with your phone. Use only Samsung-approved batteries and chargers.

Note:

Long backlight settings, searching for service, vibrate mode, browser use, and other variables may reduce the battery’s talk and standby times.

Although you can use the phone while the battery is charging, doing so will require additional charging time.

Note:

You must fully charge the battery before using your phone for the first time. A discharged battery recharges fully in approximately 4 hours.

Using the Travel Adapter

1. With the battery installed, temporarily remove the plastic

cover (lower right side of phone) and plug in the wall

charger’s connector into the jack.

Important!:

Verify that the handset battery is installed prior to connection. If the battery is not properly installed and the wall charger is connected, the handset may power off and on continuously, preventing proper operation.

Note:

The wall charger’s connector attaches to the phone at a slight angle.

a687 Crunch.book Page 7 Tuesday, February 23, 2010 6:20 PM

Page 12

Plug the flat end of the Travel Adapter into the Power/

Accessory Interface connector and the other end into a

standard AC wall outlet.

3. When charging is finished, remove the flat end from the

interface connector jack on the phone.

Warning!:

If your device has a touch screen display, please note that a touchscreen responds best to a light touch from the pad of your finger or a non-metallic stylus. Using excessive force or a metallic object when pressing on the touch screen may damage the tempered glass surface and void the warranty. For more information, refer to “Standard Limited Warranty” on page 139.

Note:

Failure to unplug the wall charger before you remove the battery, can cause damage to the phone.

Low Battery Indicator

When the battery is weak and only a few minutes of talk time remain, the battery icon ( ) blinks and the device sounds a warning tone at regular intervals. In this condition, your phone conserves its remaining battery power by reducing the backlight’s brightness and entering a dimming mode. For a quick check of your battery level, glance at the battery charge indicator located in the upper-right corner of your device’s display. Five bars ( ) indicate a full charge.

When the battery level becomes too low, the phone automatically turns off.

Switching the Phone On or Off

1. Press and hold or until the phone switches on.

The phone launches the activation splash screen and then

proceeds to search for the network. Once the network has

been found, you can make or receive calls.

Note:

The display language is preset to English at the factory. To change the language, use the Language menu. For more information, refer to “Changing Your Settings” on page 29.

Incorrect

Correct

a687 Crunch.book Page 8 Tuesday, February 23, 2010 6:20 PM

Page 13

Getting Started 9

Press and hold until the phone switches off.

Locking and Unlocking the Screen

䊳

To lock the phone screen, slide the phone closed.

– or –

To unlock the phone screen when closed, press the

Unlock

soft key and then press the OK soft key.

You can set your phone to either stop operation or continue operation whenever you slide your phone closed.

For more information, refer to “Slide Down Setting” on page 39.

Setting Up Your Voice Mail

1. In Idle mode, press and hold .

You may be prompted to enter a password.

2. Follow the tutorial to create a password, record a greeting,

and record your name.

Note:

These steps may be different depending on your network.

Accessing Your Voice Mail

1. In Idle mode, press and hold .

2. When connected, follow the voice prompts from the voice

mail center.

Accessing Your Voice Mail From Another Phone

1. Dial your wireless phone number.

2. When you hear your voicemail greeting, press the asterisk

key (*).

3. Enter your passcode using the QWERTY keypad.

a687 Crunch.book Page 9 Tuesday, February 23, 2010 6:20 PM

Page 14

Section 2: Understanding Your Phone

This section outlines some key features of your phone. It also

displays the screen and the icons that display when the phone is in use.

Features of Your Phone

Your phone is lightweight, easy-to-use and offers many useful features. The following list outlines a few of the features included in your phone.

•

User friendly, menu driven access to features and options

•

Ready access to the Internet

•

Built-in Bluetooth technology

•

Improved conversational messaging format

•

Instant Messaging capability

•

AT&T GPS Navigation functionality provides real-time navigation

•

microSD card compatibility for use in data storage and access

•

My Stuff feature provides Applications, Audio, Games, Picture, Online

Locker, Tools, Video, Other Files, and Used Space.

Front Open View of Your Phone

8 9

a687 Crunch.book Page 10 Tuesday, February 23, 2010 6:20 PM

Page 15

Understanding Your Phone 11

External speaker: allows you to hear the caller.

2. Display: shows the information needed to operate your

phone, such as the received signal strength, phone battery

level, time, etc.

Left Soft key

: allows you to select soft key actions or menu

items corresponding to the bottom left line on the display screen.

4. Multitasking key: opens the application switch window

which allows you to select from a group of different

applications without having to exit from the currently active application. These options include Call, Messaging,

Mobile Web, Music Player, Games, and End all.

5. Talk/Send key: allows you to power on the phone, make

or answer a call, access your Call History, Call Manager, and Call Block features. Press and hold to redial the last

phone number.

Voicemail key

: allows you to press and hold to

automatically dial your voicemail.

Built in QWERTY Keypad

: allows you to enter numbers, letters, and characters using a full QWERTY keypad

interface.

Microphone

: allows the other callers to hear you when you

are speaking to them.

Silent mode/Space key

: press and hold to place your device

in silent mode. In text entry mode, press to add a space.

10.

Messaging

: press the Messaging key to compose a text or

multimedia message.

11. Power/End key: ends a call. Press and hold for three

seconds to turn the phone on or off. While in a menu, pressing this key once cancels the current input and twice

returns the phone to Idle mode.

12. Back key: allows you to return to the previous menu. This

key also allows you to return to the previous page within

the Web browser. In Idle mode, press this key to display the Calendar in Month view.

13. Menu access/Confirm key: when navigating through a

menu accepts the highlighted choice in the menu. If you

press once in Idle mode, Mobile Web launches.

a687 Crunch.book Page 11 Tuesday, February 23, 2010 6:20 PM

Page 16

14.

Right Soft key

: allows you to select soft key actions or menu items corresponding to the bottom right line on the

display screen.

15. Navigation keys: this key allows you to scroll through

phone menu options and provides a shortcut to phone functions from standby mode.

Side Views of Your Phone

Volume keys

: allows you to adjust the ringer volume while in standby mode or adjust the voice volume during a call.

When receiving an incoming call, briefly press down either

volume key ( ) to mute the ring tone. Press and hold either volume key to reject the call and send it directly

to voicemail. Adjusts text size when reading a message or

using the browser located in the Applications folder.

Headset/Power adapter jack/USB or data cable

: allows you to plug in the travel adapter (power), PC connection cable

(data transfer), and optional headset for safe, convenient,

hands-free conversations.

Camera key

: allows you to both access the Picture camera menu and take pictures when you are in camera mode. In

Idle mode, press to launch the camera.

Rear View of Your Phone

Camera lens

: is used to take pictures and shoot videos.

Speaker

: allows you to hear music.

a687 Crunch.book Page 12 Tuesday, February 23, 2010 6:20 PM

Page 17

Understanding Your Phone 13

Display Layout

Your display screen provides a wealth of information about the phone’s status and options.The display has 3 main areas:

Icons

This list identifies the symbols you’ll see on your phone’s display and Indicator area:

Displays your current signal strength. The greater the number of bars, the stronger the signal.

Indicators

Main Display

Soft Key Indicators

Time and Date

Indicates that the Airplane Mode is active. You cannot send or receive any calls or access online information.

Displays when you are out of your service area.

Displays when a call is in progress.

Displays within the lock screen when a call has been missed.

Displays your battery’s charge level. The more bars you see, the more power you have remaining.

Displays when your connection to an EDGE network is active.

Displays when your phone is communicating with the EDGE network.

Displays when your connection to a 3G network is active.

Displays when the phone is accessing services in a 3G+ (HSDPA) network. When data is being transferred, this icon animates.

a687 Crunch.book Page 13 Tuesday, February 23, 2010 6:20 PM

Page 18

Displays when your phone is communicating with the 3G network.

Displays when an internal microSD memory card is detected.

Displays when the phone is connected to a computer via a supported USB cable connection.

Displays within the Indicators area when a new text message is received.

Displays within the Indicators area when a new Multimedia message is received.

Displays within the Indicators area when a new voice mail is received.

Displays within the Indicators area when a new WAP message is received.

Displays when Inbox is full - Text Message.

Displays when you set an alarm to ring at a specified time. For more information, refer to “Alarms” on page 111.

Displays when Call forwarding is set to Forward always. For more information, refer to “Call Settings” on page 43.

Displays when the Sound profile is set to Normal.

Displays when the Sound profile is set to silent or the volume has been manually lowered below level 1.

Displays when the Sound profile is set to Driving.

Displays when the Sound profile is set to Outdoor.

Displays when Bluetooth is activated.

Displays when a Bluetooth stereo headset has been paired with the phone.

Displays when TTY device has been inserted.

Displays when browsing the web.

a687 Crunch.book Page 14 Tuesday, February 23, 2010 6:20 PM

Page 19

Understanding Your Phone 15

For more details on configuring your phone’s settings, see “Changing Your Settings” on page 29.

Displays when your Address Book is synchronizing with the AT&T Address Book, the network backup service. For more information, refer to “Sync Settings” on page 56.

Displays when signed on to IM service.

Displays when T-Coil is enabled. For more information, refer to “T-Coil Mode” on page 42.

a687 Crunch.book Page 15 Tuesday, February 23, 2010 6:20 PM

Page 20

Section 3: Menu Navigation

This section explains the menu navigation for your phone. It also includes an outline of all the available menus associated with your phone. Some menu options are controlled by the SIM provided by your service provider.

Menu Navigation

Menus and sub-menus can be accessed by scrolling through them using the Navigation keys or by using the shortcut keys.

Accessing a Menu Function by Scrolling

1. In Idle mode, press the Menu soft key and scroll using the

Navigation keys to reach a main menu item, Settings for example. Press the Select soft key or the key to enter

the menu.

2. If the menu contains sub-menus, Phone for example, you

can access them by first highlighting the option and then by pressing the Select soft key or the key. If the menu you selected contains further options, repeat this

step.

3. To scroll through these menus, press either the Up or

Down Navigation key or the Volume key (located on the

left side of your phone). Press the Select soft key or the

key to make your selection.

4. To return to the previous menu level, press the Back soft

key, the key.

5. To exit the menu without changing the settings, press the

key.

a687 Crunch.book Page 16 Tuesday, February 23, 2010 6:20 PM

Page 21

Menu Navigation 17

Using Shortcut Numbers

Numbered menu items, such as menus, sub-menus, and options can be quickly accessed by using their shortcut numbers. In Menu mode, Main Menus can be accessed by pressing the number keys (1 to 0, * and #) corresponding to their location on the screen.

Example:

Accessing the Music Player.

1. In Idle mode, press the Menu soft key.

2. Press the key for AT&T Music.

3. Press the key for Music Player.

The Music Player is displayed.

Shortcuts

The Shortcuts option is another way to access applications from the idle mode without navigating through the main menu icons and sub menus. There are twelve available shortcuts, seven preassigned (Bluetooth, Alarms, Recent Calls, Games, Applications, My Account, and Tools, and five empty shortcuts (8, 9, 0, *, #) you can assign.

To navigate to the shortcuts:

1. In Idle mode, press the Shortcuts soft key, and highlight a

short cut application.

2. Press the key to access the selected option.

– or –

Press the

Options

soft key and select one of the following:

•Open

: open the selected shortcut and displays the submenus,

launches the selected application, or displays a screen.

• Change

: changes the currently selected shortcut and assigns

another shortcut to this field.

•Remove

: removes the selected shortcut from this field.

• Remove All

: removes all the shortcuts from the fields in this menu.

a687 Crunch.book Page 17 Tuesday, February 23, 2010 6:20 PM

Page 22

Section 4: Entering Text

This section outlines how to select the desired text entry mode when entering characters using the QWERTY keyboard-style keypad.

This section also describes how to use the T9 predictive text entry system to reduce the number of key strokes needed to enter text.

Using the QWERTY Keypad

Your phone has a QWERTY ( ) keypad to support easy and quick text input. You can enter text as you would when using a computer’s keyboard. To access the QWERTY keypad, slide your phone open to expose the keypad.

The keys are labelled with the alphabet on the lower half and numbers and symbols on the upper half. Press the key corresponding to the character you want to enter. To switch between using the upper case characters and lower case characters, press . You can move the cursor by moving the Navigation key.

Tip:

To delete a character, press the key.

In addition, you can use the following function keys:

Press to delete characters.

Press to start a new line.

Press twice to select CAP LOCK. Press once more to remove CAP LOCK.

Press twice to select Function lock.

Press once more to remove Function lock.

a687 Crunch.book Page 18 Tuesday, February 23, 2010 6:20 PM

Page 23

Entering Text 19

Changing the Text Input Mode

The available Text Input modes are:

Fn (123

numeric),

Abc,

and

Symbols (Sym)

. Refer to the Text Input mode in the upper right

corner of the screen to identify the mode.

•

Abc

: activates the default alphabet keys.

•

Fn (123)

: activates the number keys.

•

Sym

: displays the symbols table.

To change the Text Input mode, follow these steps:

1. Press once, twice, or three times to change the text

input mode to Abc, ABC, or abc.

2. Enter the desired text. For more information on sending

messages, see “Creating and Sending Messages” on

page 78.

Using Fn (numeric) Mode

1. Press the key once and press a number key.

Press the key twice ( displays in the upper right corner of the screen) and press as many number keys

as required.

Press the key a third time to display Abc mode.

2. Continue until you are finished composing your message.

For more information on sending messages, see “Creating and Sending Messages” on page 78.

Using SYM (symbol) Mode

Symbol mode enables you to insert symbols and punctuation marks into text.

1. Press the key to display a matrix of symbols. Use the

arrow keys to display more tables.

2. Select the number of the corresponding symbol and press

the OK soft key to insert the symbol into the text message.

3. Continue until you are finished composing your message.

For more information on sending messages, see “Creating and Sending Messages” on page 78.

Short press inserts a space.

Double press inserts a period and a space.

Press and hold in Idle mode to set phone to Silent mode.

Press to display the symbols grid.

a687 Crunch.book Page 19 Tuesday, February 23, 2010 6:20 PM

Page 24

Section 5: Call Functions

This section describes how to make or answer a call. It also includes the features and functionality associated with making or answering a call.

For more information, refer to “Call Settings” on page 43.

Displaying Your Phone Number

䊳

Press

➔

Settings ➔ Phone ➔ Own Number

Making a Call

䊳

From the Idle screen, with the phone open, use the keypad to

enter the number you wish to call and press .

Note:

When you activate the

Auto Redial

option in the Voice Call menu

(

➔

Settings

➔

Calls

➔

Voice Call

➔

Auto Redial

) the phone automatically redials up to 10 times when the person does not answer the call or is already on the phone.

Making an International Call

1. From the Idle screen, press . The + character displays.

2. Use the keypad to enter the country code, area code, and

phone number.

•

If you make a mistake, press until the desired numbers are deleted.

3. Press .

Manual Pause Dialing

To manually call a number with pause(s) without storing it in your Contacts list:

1. From the Idle screen, use the keypad to enter the phone

number.

2. Press to add a two-second pause, and use the keypad

to enter the additional numbers.

Tip:

You can create pauses longer than two seconds by entering multiple p pauses.

3. Press .

For more information, refer to “Adding Pauses to Contact Numbers” on page 55.

Correcting an Entered Number

Use the following steps to correct a mis-typed entry when dialing.

1. After entering a number using the keypad.

•

If you make a mistake, press to erase a single character.

a687 Crunch.book Page 20 Tuesday, February 23, 2010 6:20 PM

Page 25

Call Functions 21

•

Press and hold to erase the entire string of numbers.

2. Press to return to the Idle screen.

Ending a Call

䊳

Press the key.

– or –

You can end a call by sliding down your phone if the

Slide

Down

setting is set to

Stop Operation

. For more

information, refer to “Slide Down Setting” on page 39.

Dialing a Recent Number

All incoming, outgoing and missed calls are recorded in the Calls menu. If the number or caller is listed in your Address Book, the associated name also displayed.

1. From the Idle Screen, briefly press .

2. Press the

Down

Navigation key to highlight a recent call in

the

All Calls

list.

– or –

Press the

Left

Right

Navigation key to display

All Calls

Missed Calls, Calls Made

, or

Calls Received

3. Press to dial the number.

Making a Call Using Speed Dial

You can assign a shortcut number to a phone number for speed dialing.

1. Press

➔

Address Book

➔

Speed Dial List

Note:

The

Speed Dial

screen displays showing the numbers 1 through 9. The

number 1 is reserved for Voice Mail.

2. Highlight an unused number and press

Options

➔

Assign

3. Select

Address Book

FDN Contacts

4. Highlight a contact to assign to the number and press the

key.

Making a Call from the Address Book

You can store phone numbers that you use regularly on the SIM card or in the phone’s memory. These entries are collectively called the Address Book.

For further details about the Address Book feature, see “Finding an Address Book Entry” on page 55.

a687 Crunch.book Page 21 Tuesday, February 23, 2010 6:20 PM

Page 26

Answering a Call

When a call is received the phone rings and displays the caller’s phone number, or name if stored in the Address Book.

1. From the Incoming call screen, press or

•

If the

Any Key

option is activated (

➔ Settings

➔ Calls

➔

General

➔ Call Answer

), you can press any key to answer a call

except .

– or –

Slide open the phone to accept the call.

2. Press to end the call.

Note:

You can answer a call while using the Address Book or other menu feature. After ending the call, the phone returns to the previously active function screen.

Options During a Call

During a call, if you want to adjust the earpiece volume, use the Volume keys on the left side of the phone to increase or decrease the volume level.

In Idle mode, you can also adjust the ringer volume using these same keys.

Tip:

Press one of the volume keys to immediately silence the tone of an incoming call or alarm.

Putting a Call on Hold

You can place the current call on hold whenever you want. You can also make another call while you have a call in progress if your network supports this service.

To put a call on hold:

1. While on a call, press

Options

➔ Hold

2. Press

Resume

to continue the conversation.

To end a call on hold:

䊳

Press

Options

➔ End Call

to disconnect.

To make a new call while you have a call in progress:

1. While on a call, press

Options

➔ Hold

2. Dial the new phone number or look it up in the Address

Book.

3. Press to dial the second number.

– or –

Press

Options

➔ New Call

to dial the second number.

a687 Crunch.book Page 22 Tuesday, February 23, 2010 6:20 PM

Page 27

Call Functions 23

When you have an active call and a call on hold, you may switch between the two calls, changing the one on hold to active and placing the other on hold.

To switch between two calls:

䊳

Press

Options

➔ Swap

To end a specific call:

䊳

Press to end the current call.

– or –

Press

Options

➔ End

and then select

Active Call, Held Call

All Calls

and press .

In-Call Options

1. During a call, press the

Mute

soft key to mute the

microphone.

Press the

Options

soft key to access the following:

•Video Share

: initiates a video sharing session. Video can be Live or

Recorded.

•Hold

: places the current call on hold.

• Address Book

: allows you to access your Address Book

information.

• Save to Address Book

: allows you to save the current number to your Address Book. This option only appears if the number is not currently in your address book.

• View Address Book Details

: allows you to view the number’s Address Book information. This option only appears if the number is in your address book.

• New Call

: places the current call on hold and then allows you to

enter and call another number.

• Send Message

: allows you to create and send a new Text or

Multimedia Message.

•More

–

Calendar

: Allows you to temporarily access your calendar while still

maintaining the active call.

–

Notes

: Allows you to access Notes.

–

Whisper Mode On/Off

: Increases the microphone sensitivity level so you do not have to speak loudly to be heard by the other party. Used in quiet environments such as theaters, and meetings.

–

Key tone off/on

: Silences/mutes the key tones when on the call.

–

Send DTMF

: Sends DTMF (Dual Tone Multi-Frequency) tones to the contacts you have selected. These DTMF tones are sent as a group. The DTMF tones are the tones used in phones for tone dialling, sounding when you press the number keys. This option is helpful for entering a password or an account number when you call an automated system, like a banking service.

• End Call

: Allows you to end the active call.

a687 Crunch.book Page 23 Tuesday, February 23, 2010 6:20 PM

Page 28

If you are engaged in a call, you can place the active call on hold by selecting the

New Call

option and either dialing another number or answering another incoming call. Once the second call is activated, the following options are available:

•

Swap

: Places the active call on hold and then re-activates the call on

hold.

•

Join

: Joins two calls (both active and on hold) into a multi-party call.

Using the Speakerphone During an Active Call

While in an active call, it is possible to enable the speakerphone feature.

1. Dial the number and press .

2. Press to activate the speakerphone.

3. Press the

Volume

keys (located on the right side of your

phone) to adjust the volume.

Important!:

For more information, see “Responsible Listening” on page 129.

Switching off the Microphone (Mute)

You can temporarily switch your phone’s microphone off, so that the other person cannot hear you.

Example:

You wish to say something to person in the room, but do not want the person on the phone to hear you.

Note:

If you are already in Video Share or you have a call on hold, you need to select Mute/Unmute.

To switch the microphone off temporarily during a call:

1. Press Mute. The option is then replaced with Unmute.

2. Press Unmute to deactivate the Mute function and

reactivate the microphone.

Searching for a Number in Address Book

1. During the active call, press Options ➔ Address Book.

2. Highlight an Address Book entry.

For further details about the Address Book feature, see “Finding an Address Book Entry” on page 55.

Video Share

The Video Share features allows you to place a call and share live or recorded video while on the call. You can initiate or receive video by using the following steps.

Note:

In order to share video, both parties must be subscribed to Video Share, both must have phones that support Video Share, and both must be in a 3G coverage area.

a687 Crunch.book Page 24 Tuesday, February 23, 2010 6:20 PM

Page 29

Call Functions 25

Initiating and Receiving a Video Share Session

To initiate and receive a Video Share session:

1. From the Idle screen, use the key pad to enter the number

to dial and press .

2. Once the call is answered, if you're both capable of Video

Sharing, press Options ➔ Video Share to invite the other party to see video shot from your phone. “Inviting ###- ###-####” displays. A message is sent to the recipient “###-###-#### wants to Video Share with You.”

Important!:

When establishing a Video Share session, only the sender of the video clip can save the file.

3. The recipient receives a Video Share pop-up to either

Accept or Reject the Video Share call. They should press Accept to continue or Reject to reject the invitation.

4. If the

Auto Record

option is On,

REC

displays on the upper

right of the screen.

Note:

The

Auto Record

option (page 49) must be enabled for this popup to

display.

5. To end the video share call, press Stop.

6. A pop-up message displays

Video Share has stopped. Your recorded video “VSxxxxxxxx” is saved in the Video folder in My Stuff

Play a Video Share Recording

During a call (while not in a Live Video Share session) you can share a recorded video for the recipient.

1. Press

Options

➔

Video Share

➔

Recorded

and then select

from the available files in your Video folder.

2. To make the connection, the recipient should press Accept

and the Video begins to play on both phones.

Recent Calls

The phone stores the numbers of the calls you’ve dialed, received, or missed in the Calls menu. You can access this menu from the Idle screen by following these steps:

1. From the Idle Screen, briefly press .

2. Press the

Down

Navigation key to highlight a recent call in

the

All Calls

list.

– or –

Press the

Left

Right

Navigation key to display

All Calls

Missed Calls, Calls Made

, or

Calls Received

a687 Crunch.book Page 25 Tuesday, February 23, 2010 6:20 PM

Page 30

Press to dial the number.

If the number or caller is listed in your Address Book, the associated name displays.

Viewing All Calls

1. From the Idle Screen, briefly press . Listed are all

calls made, missed, or received.

2. Press the

Options

soft key to view the following options:

• Details

: allows you to view the caller’s name, phone number, time

and date called as well as the length of the call.

•Call

: allows you to automatically dial the selected number.

• Video Share Call

: allows you to call the number and share a video.

• Save to Address Book

: allows you to save the number to your

Address Book on either the phone or SIM card.

• Send Message

: allows you to sent a text or Multimedia message to

the caller.

• Delete

: allows you to delete the selected call.

• Add to Reject List

: allows you to add the selected number to the

Reject List.

• View Contact Details

: allows you to view the contact’s Address Book information. This option only appears if the contact is in your address book.

Viewing Missed Calls

The number of calls missed displays on the Idle screen.

1. From the Idle Screen, briefly press and use the

Right

navigation key to scroll to the

Missed Calls

folder. The most

recently missed calls display.

2. Scroll through the list of missed calls. As the call

highlights, the details display.

3. To move to another call type, press the

Left

Right

Navigation key to make your selection.

Saving a Missed Call to your Address Book

1. From the Idle Screen, briefly press and use the

Right

navigation key to scroll to the

Missed Calls

folder.

2. Highlight the desired missed call.

a687 Crunch.book Page 26 Tuesday, February 23, 2010 6:20 PM

Page 31

Call Functions 27

Press

Options ➔ Save to Address Book

. For further details

about the Address Book feature, see “Adding a New

Contact” on page 53.

Sending a Message to a Missed Call

1. From the Idle Screen, briefly press and use the

Right

navigation key to scroll to the

Missed Calls

folder.

2. Highlight the desired missed call.

3. Press

Options ➔ Send Message

4. From the

New Messages

screen, highlight the empty text

field and use the keypad to type a message. For more

information, refer to “Creating and Sending Messages” on page 78.

Deleting a Missed Call

1. From the Idle Screen, briefly press and use the

Right

navigation key to scroll to the

Missed Calls

folder.

2. Highlight the desired missed call.

3. Press

Options

➔ Delete and press the

Right

navigation key

to choose

Selected

All

4. At the

Delete?

prompt, press

Yes

to delete or No to cancel.

Call Time

1. Press

➔

My Stuff ➔ Tools

➔

Recent Calls ➔ Call

Time

. The following times display:

•Last Call Time

: shows the length of time for the last call.

•Total Sent

: shows the total length of time for calls sent.

• Total Received

: shows the total length of time for calls received.

2. Press

Reset

to reset the counters.

3. Enter the user-defined password and press Confirm to

reset all counters. For more information, refer to “Change

Phone Password” on page 41.

Data Volume

Data Volume refers to the amount of data sent to and from the phone.

1. Press

➔

My Stuff ➔ Tools

➔

Recent Calls ➔ Data

Volume

. The following data items display:

•Last Sent Data

: shows the size of the last data packet (measured in KB - kilobytes) sent by the phone since the last time this counter was reset.

• Last Received Data

: shows the size of the last data packet (measured in KB - kilobytes) received by the phone since the last time this counter was reset.

a687 Crunch.book Page 27 Tuesday, February 23, 2010 6:20 PM

Page 32

•Total Sent Data

: shows the size of the total data packet (measured in KB - kilobytes) which were sent by the phone since the last time this counter was reset.

• Total Received Data

: shows the size of the total data packet (measured in KB - kilobytes) which were received by the phone since the last time this counter was reset.

2. Press

Reset

to set the counters to zero.

3. Enter the password and press Confirm to reset all

counters. For more information, refer to “Change Phone

Password” on page 41.

Call Waiting

The Call Waiting feature allows you to answer an incoming call while you have a call in progress, if this service is supported by the network, and you have set the Settings ➔ Calls ➔

Voice Call

➔

Call Waiting

Menu to Activated. You are notified of an

incoming call by a call waiting tone.

To answer a call while you have a call in progress:

1. Press to answer the next incoming call. The first call

is automatically placed on hold.

2. To switch between the two calls, press

Options

➔ Swap.

•Swap

: Places the current call on hold and then activates the

previous call.

3-Way Calling (Multi-Party Calling)

The 3-Way or Multi-Party feature allows you to answer a series of incoming calls and place them on hold. If this service is supported by the network, you can join all the calls together. A call waiting tone notifies you of an incoming call.

Note:

The Join option combines all of the calls you have established with your phone (both active and on hold). Swap places the current call on hold and then activates the previous call.

This feature joins all of the calls you have established with your phone (both active and on hold) into a multi-party call.

1. Press to answer the first incoming call.

2. Press or

to answer the next incoming call. The

first call is automatically put on hold.

3. Press

Options

➔

Join

to join the two callers and create a

multi-party call.

4. Press to end the call.

a687 Crunch.book Page 28 Tuesday, February 23, 2010 6:20 PM

Page 33

Changing Your Settings 29

Section 6: Changing Your Settings

This section includes tips on how to use your phone’s features, as well as how to change and customize the display settings, call handling, security settings, and other settings associated with your phone.

Quick Tips

Quick Tips connects you to the AT&T Quick Tips web page where you can find information on the operation of your phone.

䊳

In Idle mode, select

➔

Settings ➔ Quick Tips

The AT&T Quick Tips web page displays.

Sound Profile

This menu allows you to specify how you are informed of incoming calls and messages as well as other notification sounds your phone can make.

Selecting a Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Press the radio button next to the profile name. The

selected profile activates. Choices include:

•Normal

•Silent

•Driving

• Outdoor

Normal Profile

The phone’s profile defaults to Normal where the incoming Alert Type is set to melody.

Editing the Normal - Call Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Highlight

Normal

and press

Edit

3. Highlight the

Call

tab.

4. Select the

Call Alert Type

field and press

Change

5. Select one of the following:

•Melody

: the phone rings using the ring melody selected in the

Message Alert Tone menu.

•Vibration

: the phone vibrates.

• Vibration then Melody

: the phone vibrates then plays a melody.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

6. Press the

Voice Call Ringtone

field and press

Change

a687 Crunch.book Page 29 Tuesday, February 23, 2010 6:20 PM

Page 34

Select

Shop Tones

to launch AppCenter and shop for a

tone.

– or –

Select one of the listed tones.

8. Highlight the

Ringtone Volume

field and press

Change

9. Use the

Left

Right

navigation key to adjust the volume

level (range is 1-7).

10. Press

Save

to return to the Sound Profile menu and save

your selections.

Editing the Normal - Message Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Highlight

Normal

and press

Edit

3. Highlight the

Message

tab.

4. Select the

Message Alert Type

field and press

Change

5. Select one of the following:

•Melody

: the phone rings using the ring melody selected in the

Message Alert Tone menu.

•Vibration

: the phone vibrates.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

6. Select the

Message Alert Tone

field and press

Change

7. Select one of the message tones or select

Other Tones

and

press

Select

8. Highlight the

Message Alert Repetition

field and press

Change

9. Select one of the following and press

Select

•Once

: repeats the message alert once.

•Periodic

: repeats the message alert periodically.

10. Highlight the

Message Tone Volume

field and press

Change

11. Use the

Left

Right

navigation key to adjust the volume

level (range is 1-7) and press

Select

12. Press

Save

to return to the Sound Profile menu.

Editing the Normal - Phone Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Highlight

Normal

and press

Edit

3. Highlight the

Phone

tab.

4. Highlight the

Keypad Tone

field and select one of the

following tones:

a687 Crunch.book Page 30 Tuesday, February 23, 2010 6:20 PM

Page 35

Changing Your Settings 31

•Beep

•Click

•Mute

5. Press the

Power On Type

field and press

Change

6. Select one of the following and press

•Melody

: the phone rings using the ring melody selected in the

Message Alert Tone menu.

•Vibration

: the phone vibrates.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

7. Highlight the

Power Off Type

field and press

Change

8. Select one of the following and press

•Melody

: the phone rings using a pre-set ring melody.

•Vibration

: the phone vibrates but does not ring.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

9. Highlight the

Phone Sound Volume

field and press

Change

10. Use the

Left

Right

navigation key to adjust the volume

level (range is 0-7) and press

Select

11. Press

Save

to return to the Sound Profile menu.

Silent Profile

Silent mode is convenient when you wish to stop the phone from making noise, in a theater for example.

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Highlight

Silent

and press

Select

Editing the Silent - Call Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile.

2. Highlight

Silent

and press

Edit

3. Highlight the

Call

tab, then select the

Call Alert Type

field

and press

Change

4. Select one of the following alert types and press

Select

•Vibration

: the phone vibrates but does not ring.

•Mute

: the phone is silent and does not play a melody or vibrate.

Editing the Silent - Message Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile.

2. Highlight

Silent

and press

Edit

3. Highlight the

Message

tab, select the

Message Alert Type

field and select one of the following:

a687 Crunch.book Page 31 Tuesday, February 23, 2010 6:20 PM

Page 36

•Vibration

: the phone vibrates.

•Mute

: the phone is silent and does not play a melody or vibrate.

4. Press

Select

to confirm your selection.

5. Highlight the

Message Alert Repetition

field and press

Change

6. Select one of the following options then press

Select

•Once

: repeats the message alert once.

•Periodic

: repeats the message alert periodically.

7. Press

Save

to return to the Sound Profile menu.

Driving Profile

In this case, the speaker is active and launches the currently selected Call alert type when the associated notification is activated.

Editing the Driving - Call Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile.

2. Highlight

Driving

and press

Edit

3. Highlight the

Call

tab.

4. Select the

Call Alert Type

field and press

Change

5. Select one of the following and press

Select

•Melody

: the phone rings using the ring melody selected in the Ring

tone menu.

•Vibration

: the phone vibrates but does not ring.

• Vibration then Melody

: the phone vibrates and then starts ringing.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

6. Press the

Voice Call Ringtone

field and press

Change

7. Select

Shop Tones

to launch AppCenter and shop for a

tone.

– or –

Select one of the listed tones.

8. Highlight the

Ringtone Volume

field and press

Change

9. Use the

Left

Right

navigation key to adjust the volume

level (range is 1-7).

10. Press

Save

to return to the Sound Profile menu and save

your selections.

Editing the Driving - Message Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile.

2. Highlight

Driving

and press

Edit

3. Highlight the

Message

tab.

a687 Crunch.book Page 32 Tuesday, February 23, 2010 6:20 PM

Page 37

Changing Your Settings 33

Select the

Message Alert Type

field and press

Change

5. Highlight one of the following and press

Select

•Melody

: the phone rings using the ring melody selected in the

Message Alert Tone menu.

•Vibration

: the phone vibrates but does not ring.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

6. Press the

Message Alert Tone

field and press

Change

7. Highlight one of the message tones or highlight Other

tones and press

Select

8. Select the

Message Alert Repetition

field and press

Change

9. Select one of the following options then press

Select

•Once

: repeats the message alert once.

•Periodic

: repeats the message alert periodically.

10. Highlight the

Message Tone Volume

field and press

Change

11. Use the

Left

Right

navigation key to adjust the volume

level (range is 1-7).

12. Press

Save

to return to the Sound Profile menu and save

your selections.

Editing the Driving - Phone Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Highlight

Driving

and press

Edit

3. Highlight the

Phone

tab.

4. Select the

Keypad Tone

field and press

Change

5. Highlight one of the following and press

Select

•Beep

•Click

•Mute

6. Highlight the

Power On Type

field and press

Change

7. Select one of the following and press

•Melody

: the phone rings using a pre-set ring melody.

•Vibration

: the phone vibrates but does not play a melody.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

8. Highlight the

Power Off Type

field and press

Change

9. Select one of the following and press

•Melody

: the phone rings using a pre-set ring melody.

•Vibration

: the phone vibrates but does not ring.

a687 Crunch.book Page 33 Tuesday, February 23, 2010 6:20 PM

Page 38

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

10. Highlight the

Phone Sound Volume

field and press

Change

11. Use the

Left

Right

navigation key to adjust the volume

level (range is 0-7).

12. Press

Save

to return to the Sound Profile menu and save

your selections.

Outdoor Profile

In this case, you are outdoors and might not be able to hear the phone, or need an increased volume in order to hear the phone. For example, you might be jogging and need the phone to vibrate and ring loudly.

Editing the Outdoor - Call Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Highlight

Outdoor

and press

Edit

3. Highlight the

Call

tab.

4. Select the

Call Alert Type

field and press Change.

5. Select one of the following and press

Select

•Melody

: the phone rings using the ring melody selected in the Ring

tone menu.

•Vibration

: the phone vibrates but does not ring.

• Vibration then Melody

: the phone vibrates and then starts ringing.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

6. Highlight the

Voice Call Ringtone

field and press

Change

7. Highlight

Shop Tones

or select one of the tones and press

Select

8. Select the

Ringtone Volume

field and press

Change

9. Use the

Left

Right

navigation key to adjust the volume

level (range is 1-7).

10. Press

Save

to return to the Sound Profile menu and save

your selections.

Editing the Outdoor - Message Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Highlight

Outdoor

and press

Edit

3. Highlight the

Message

tab.

4. Select the

Message Alert Type

field and press

Change

5. Highlight one of the following and press

Select

•Melody

: the phone rings using the ring melody selected in the

Message Alert Tone menu.

a687 Crunch.book Page 34 Tuesday, February 23, 2010 6:20 PM

Page 39

Changing Your Settings 35

•Vibration

: the phone vibrates but does not ring.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

6. Select the

Message Alert Tone

field and press

Change

7. Highlight one of the message tones or highlight

Other Tones

and press

Select

8. Select the

Message Alert Repetition

field and press

Change

9. Select one of the following and press

Select

•Once

: repeats the message alert once.

•Periodic

: repeats the message alert periodically.

10. Select the

Message Tone Volume

field and press

Change

11. Use the

Left

Right

navigation key to adjust the volume

level (range is 1-7).

12. Press

Save

to return to the Sound Profile menu and save

your selections.

Editing the Outdoor - Phone Profile

1. In Idle mode, select

➔

Settings ➔ Sound Profile

2. Highlight

Outdoor

and press

Edit

3. Highlight the

Phone

tab.

4. Select the

Keypad Tone

field and press

Change

5. Highlight one of the following and press

Select

•Beep

•Click

•Mute

6. Highlight the

Power On Type

field and press

Change

7. Select one of the following and press

Select

•Melody

: the phone rings using a pre-set ring melody.

•Vibration

: the phone vibrates but does not play a melody.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

8. Press the

Power Off Type

field, select one of the following

and press OK:

•Melody

: the phone rings using a pre-set ring melody.

•Vibration

: the phone vibrates but does not ring.

• Vibration & Melody

: the phone vibrates and plays a melody

simultaneously.

•Mute

: the phone is silent and does not play a melody or vibrate.

9. Highlight the

Phone Sound Volume

field and press

Change

a687 Crunch.book Page 35 Tuesday, February 23, 2010 6:20 PM

Page 40

10.

Use the

Left

Right

navigation key to adjust the volume

level (range is 0-7).

11. Press

Save

to return to the Sound Profile menu and save

your selections.

Display

In this menu, you can change various settings for the display or lighting.

1. In Idle mode, press

➔ Settings ➔ Display and

press the Select soft key or the key.

The following options are available:

• Wallpaper

: allows you to select Picture or None. None leaves the

wallpaper blank. Press the

Edit

soft key, and scroll through the graphics in your Graphics folder (on the Phone or on an External Storage Card) to select your wallpaper. Press the

Select

soft key or

the key to confirm the selection.

•My Theme

: allows you to select from three different themes. Make

a selection and press the

Select

soft key or the key.

• Menu Style: allows you to select whether the phone’s menus are

presented in either a Grid Menu style or List Menu style. Make a selection and press the

Save

soft key or the key.

• Light Settings

: allows you to adjust the Brightness and set the

Backlight Time.

Note:

Light settings can affect the length of time before battery recharge is necessary.

–

Brightness

: allows you to adjust the display brightness for the LCD to see it better in different lighting conditions. Press the Left or Right Navigation keys to adjust the brightness. Press the

Save

soft key or the

key to confirm your selection.

–

Backlight Time: allows you to select the amount of time for the

backlight to remain on and the length of time for the actual dimming to occur. Highlight the On field and press the key. Then select from 10 Seconds, 30 Seconds, 1 Minute, 3 Minutes, or 10 Minutes. Highlight

Dim

and press the key. Choose from Off, 5 Seconds, 10 Seconds, 30 Seconds, 1 Minute, 3 Minutes, or 10 Minutes and press the key. Press the

Save

soft key to save your changes.

• Dialing Display: allows you to select the properties of those items

which are part of the display such as:

–

Font Type

: allows you to select the font to display. Press the Left or Right

Navigation keys to make your selection. Choose from

Normal 1

Normal

Press the

Save

soft key or the key to confirm your selection.

–

Font Size

: allows you to select a size for the selected font. Press the Left

or Right Navigation keys to make your selection. Choose from

Large

Medium

, or

Small

. Press the

Save

soft key or the key to confirm

your selection.

–

Font Color

: allows you to select a color for the selected font. Press the

Left or Right Navigation keys to make your selection. Choose from

Monochrome, Gradation

, or

Basic

. Press the Down Navigation key and

a687 Crunch.book Page 36 Tuesday, February 23, 2010 6:20 PM

Page 41

Changing Your Settings 37

select a color choice. Press the

Save

soft key or the key to confirm

your selection.

–

Background Color

: allows you to select a color for the background

screen

Press the Left or Right Navigation keys to make your selection.

Press the

Save

soft key or the key to confirm your selection.

• Greeting Message: allows you to enter the text to display on the

screen when the phone powers on.

Time & Date

This menu allows you to change the current time and date displayed.

1. In Idle mode, select

➔

Settings ➔ Time & Date

➔

Time Zone Updating

and press the

Left

Right

Navigation

key to select from one of the following:

•

Manual Only

: you need to manually set the time and date

according to the current time zone using the Set time menu.

•

Prompt First

: you are prompted before a time change is applied.

•

Automatic

: the phone automatically updates the time and date

according to the current time zone using the network service.

2. Highlight the

Time Zone

field and press

Change

Important!:

Current time zones are based upon Greenwich Mean Time.

3. Use the

Left

Right

Navigation key to locate a time-zone.

A corresponding area of the world map displays.

4. Highlight the

Daylight Saving

checkbox and press

Check

Daylight Saving time applies.

Note:

The

Time Zone

field does not display when

Time Zone Updating

is set to

Automatic

5. Select the

Time

field and enter the time in the following

format: HH/MM.

6. Highlight the

Date

field and enter the date in the following

format: MM/DD/YYYY.

7. Select the

Time Format

field and press the

Left

Right

Navigation key to select the 12 Hours or 24 Hours format.

8. Highlight the

Date Format

field and press the

Left

Right

Navigation key to select a format.

9. Press

Save

to save your settings.

Phone Settings

You can customize various phone settings.

䊳

In Idle mode, select

➔

Settings ➔ Phone

a687 Crunch.book Page 37 Tuesday, February 23, 2010 6:20 PM

Page 42

Language

This menu allows you to select a display language for Text language and Text Input mode. Choose from Automatic, English, Français, and Español.

1. In Idle mode, select

➔

Settings ➔ Phone

➔

Language

and press the key.

2. Highlight the

Screen Text

field and press

Change

3. Highlight one of the following selections and press

•Automatic

(uses the language set on your SIM card).

• English

•Français

•Español

4. Highlight the

Input Language

field and press

Change

5. Highlight one of the following selections and press

• English

•Français

•Español

6. Press

Save

to save your settings and return to Phone

settings page.

Shortcuts

The Shortcuts option allows you to change the applications assigned to your Navigation keys.

1. In Idle mode, select

➔

Settings ➔ Phone

➔

Shortcuts

2. Use the Navigation keys to select the Up, Down, Right, or

Left key.

3. Press the Options ➔ Change and press the Select soft key

or the key. Select a new application to assign to the

previously selected key.

4. Press the Save soft key or the key to assign the new

application.

Own Number

The Own Number option displays the number assigned to the SIM card in your phone. You can change the number, but entering another number may prevent you from making or receiving calls on the handset. You may also add other names and numbers into your phone for easy referral.

a687 Crunch.book Page 38 Tuesday, February 23, 2010 6:20 PM

Page 43

Changing Your Settings 39

Slide Down Setting

This setting allows you to choose what displays on the main screen when you slide down your phone.

1. In Idle mode, select

➔

Settings ➔ Phone ➔ Slide

Down Setting

and press the key.

2. Select one of the following options:

•Stop Operation

: when you slide the phone down, you are returned to the Idle screen. This will end a call or end any applications you are running.

Note:

After closing the slide, there may be a prompt prior to ending an application.

• Continue Operation

: when you slide the phone down, you will

remain at the screen you were at.

3. Press

Save

or press the key.

Security

The Security feature enables you to restrict the use of your phone by the others and to restrict the types of calls. Various codes and passwords are used to protect the features of your phone.

The following options are available:

Lock Phone

When the Lock Phone feature is enabled, the phone is locked and you must enter the 4- to 8-digit phone password each time the phone is powered on.

Note:

You are prompted to create a password the first time this feature is enabled.

To change the phone password, see “Change Phone Password” on page 41. Once you enter the correct password, you can use the phone until you switch it off. The following options are available:

–

Off

: you are not asked to enter the phone password when you switch on

the phone.

–

: you are required to enter the phone password when you switch on

the phone.

Lock SIM Card

When the Lock SIM Card feature is enabled, your phone only works with the current SIM. You must enter the SIM password to unlock the SIM so you can use a different SIM card. Once you enter the SIM password, you are asked to confirm your password. Reenter your password and press the Confirm soft key.

a687 Crunch.book Page 39 Tuesday, February 23, 2010 6:20 PM

Page 44

Note:

This SIM password is typically the last four digits of the current phone number. You can obtain a SIM password from an AT&T customer service representative.

Check PIN Code

•

When the

Check PIN Code

feature is enabled, you must enter your PIN each time you switch on the phone with the SIM Card. Consequently, any person who does not have your PIN cannot use your SIM without your approval.

The following options are available:

–

Off

: the phone connects directly to the network when you switch

it on.

–

: you must enter the PIN each time the phone is switched on.

Note:

Before disabling the Check PIN Code feature, you must enter your PIN.

You can obtain your PIN from an AT&T customer service representative.

Lock Applications

Using this option you can lock various applications. Once you lock the contents, you must enter the phone’s password to access the associated menus.

Note:

The first time you access the password screen, you are prompted to create a password.

The applications options are:

–

All

–

Messaging

–

Recent Calls

–

My Stuff

–

Calendar

–

Tas k s

–

Notes

–

Address Book

Set FDN Mode

FDN (Fixed Dial Number) mode, if supported by your SIM card, allows you to restrict the outgoing calls to a limited set of phone numbers. The following options are available:

–

Off

: you can call any number.

–

: you can only call phone numbers stored in the FDN contacts list. You must enter your PIN2. You can obtain the PIN2 Code from your service provider's customer care department.The following options for entering FDN contacts are available through the Address Book:

•

Entering Full length entries or wild cards into the FDN list.

•

Entering a full length number with a specific contact name into the FDN list.

•

Using wildcard entries allow you to dial a range of numbers with a single entry: ex. 555 – All dialed numbers that begin with 555 are

a687 Crunch.book Page 40 Tuesday, February 23, 2010 6:20 PM

Page 45

Changing Your Settings 41

allowed. Numbers that do not match the conditions in the FDN list are restricted.

Note:

Entering an asterisk (*) is not required for wild card entries.

Change Phone Password

The

Change Phone Password

option allows you to change your current phone password to a new one. Once you enter a new password, you are asked to confirm it by entering it again.

Change PIN Code

This option allows you to change your current PIN, provided that the PIN Check feature is enabled. You must enter the current PIN before you can specify a new one. Once you enter a new PIN, you are asked to confirm it by entering it again.

Change PIN2 Code

The Change PIN2 option allows you to change your current PIN2 to a new one. You must enter the current PIN2 before you can specify a new one. Once you enter a new PIN2, you are asked to confirm it by entering it again.

Note:

If your SIM card does not require a PIN2 password, this menu does not display.

APN Control

Allows you to turn control of Access Point Names (APN) On or Off. APNs are a method by which you can access advanced communication using your handset. This advanced communication can include instant messaging, multimedia messaging, email, and internet access. Turning On APN Control requires the PIN2 code. To access APN control:

1. In Idle mode, press

➔ Settings ➔ Phone ➔

Security ➔ APN Control and press the Select soft key or

the key.

2. Highlight

and press the Save soft key or the key.

Reset Phone

You can easily reset your phone to its default settings. To reset your phone:

1. In Idle mode, select

➔

Settings ➔ Phone ➔ Reset

Phone

2. At the

All Settings reset to factory defaults. Continue?

prompt, press Yes to reset, or No to cancel.

3. Enter your phone password, and press the Confirm soft

key.

a687 Crunch.book Page 41 Tuesday, February 23, 2010 6:20 PM

Page 46

After the phone settings are reset, the

Reset Phone done

confirmation displays.

Once your phone has been reset to its default settings for

those selected options, it will restart itself in order to

incorporate the new settings.

Note:

User Data such as contacts, messages, pictures, videos, and music is not deleted.

Restore Phone

The Restore Phone option is the same as the Reset Phone option described above in that all settings are reset to factory defaults. However, with the Restore Phone option, all user data deletes.

Warning!:

All User Data such as contacts, messages, pictures, videos, and music is deleted. Ensure that you remove your microSD card if applicable because it will erase during the Restore Phone option.

Warning!:

When performing the Restore Phone option, do not remove your battery until the phone completes the task and restarts, otherwise phone damage may occur.

Airplane Mode

Airplane Mode allows you to use many of your phone’s features, such as Games, Voice notes, and more, when you are in an

airplane or in any other area where making or receiving calls or data transmission is prohibited. When your phone is in Airplane Mode, it cannot send or receive any calls or access online information. When active, the ( ) icon displays in place of the signal strength indicator.

1. In Idle mode, select

➔

Settings ➔ Phone ➔ Airplane

Mode

2. Select On or Off and press

Save

or the key.

T-Coil Mode

T-Coil mode allows you to use a hearing aid with a T-coil setting in connection with the handset. You can set this mode to On or

Off

. When T-Coil Mode is On, the icon displays on the Idle

screen.

Set the T-Coil mode to On to activate it, or Off to deactivate it.

1. In Idle mode, select

➔

Settings

➔ Phone ➔ T-Coil

Mode.

2. Select Enable or Disable and press

Save

or the key.

3. Press

Yes

when the T-Coil confirmation displays.

Important!:

The hearing aid category specified for this product represents compatibility only when the phone is open, which has maximum antenna efficiency. When the option is enabled and the phone is open during a call, the T-coil adjusts the audio for use with T-coil

a687 Crunch.book Page 42 Tuesday, February 23, 2010 6:20 PM

Page 47

Changing Your Settings 43

hearing aids (see “FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices” on page 131.)

Call Settings

䊳

In Idle mode, select

➔

Settings ➔ Calls

Adjusting the General Call Settings

1. Press

General

and select from the following options:

• Show My Number

: allows you to select how your caller ID is handled when an outgoing call is initiated. This is what others see on their Caller ID screen. Leave the value blank if you do not wish your number displayed to other users.

• Auto Reject

: selects which numbers are automatically sent to

voicemail based on a user-created list from within the

Reject List

• Call Answer

: selects how your phone answers incoming calls.

Selections are: Send Key, Open Slide, and Any Key.

• Auto Reply

: allows you to send an auto reply text message to a missed call number when this setting is activated. Set to On and enter a reply that you want to send.

• Call Status Tones

: allows you to activate an alert tone for one of two available status categories. Press an option to make your selection and then press

Save

to store your new selection. Options

include:

–

Call Connect Tone

: allows you to activate an alert tone which sounds

every time a call is connected.

–

Minute Minder

: allows you to activate an alert tone which sounds

every minute the call is active.

• Alerts on Call

: activates an alert tone for new messages being

received during an active call. Press

Save

to store setting.

2. Press twice return to the previous Settings page.

Adjusting the Voice Call Settings

1. Select

Voice Call

and choose from the following options:

• Call Forwarding

: incoming calls are re-routed to a secondary number that you specify. Select the condition for the call forward action:

–

Forward Always

activates an automatic forward of all incoming calls

regardless of condition.

–

Busy

activates an forward function only when your number is currently

in use and the caller receives a busy signal.

–

No Reply

activates an automatic forward of all incoming calls after a

preset amount of time (5 seconds - 30 seconds).

–

Unreachable

activates an automatic forward of all incoming calls only when you can not be reached and your phone status is set to unreachable.

–

Cancel All

cancels all call forwarding functions.

• Call Waiting

: this network service informs you when someone is trying to reach you during another call. You can specify individual call waiting options for voice calls and/or data calls.

–

Press of the available options:

Activate, Deactivate, Check Status

(checks the status of this service on your account).

a687 Crunch.book Page 43 Tuesday, February 23, 2010 6:20 PM

Page 48

• Auto Redial

: the phone automatically redials the last active number

if the call was either cut off or you were unable to connect.

–

Press either On or

Off

to activate/deactivate the function.

–

Press

Save

to store the new setting.

2. Press twice return to the previous Phone settings page.

Connectivity

You can edit several of the communication/connection parameters on this phone.

Bluetooth

Bluetooth is a short-range wireless communications technology capable of exchanging information over a distance of about 30 feet without requiring a physical connection. Unlike infrared, you don't need to line up the devices to beam information with Bluetooth. If the devices are within connectivity range of one another, you can exchange information between them, even if they are located in different rooms.

The Bluetooth wireless technology settings menu provides the ability to view and change the device name, show the visibility, and set the security for the device.

Activation

To use the Bluetooth option you must first activate it. When the Bluetooth is deactivated, you cannot send or receive information via Bluetooth. To save battery life or in situations where Bluetooth

use is prohibited, you can turn off the Bluetooth wireless technology headset.

1. In Idle mode, press

➔ Settings ➔ Connectivity

➔ Bluetooth and press the Select soft key or the

key.

2. If the first item in the Bluetooth menu is

Bluetooth:Off

highlight the

Bluetooth:Off

option press the Select soft key

or the key.

The

Bluetooth activated

confirmation prompt displays on

your phone.

Note:

If the first item in the Bluetooth menu is

Bluetooth:On

, then Bluetooth is

already activated.

Discoverable

The Discoverable option allows your phone to wirelessly transmit its phone name and status to every device within its range. This transmission can pose a security risk and incite unauthorized connection to your phone. It is recommended that you remain hidden unless necessary.

1. In Idle mode, press

➔ Settings ➔ Connectivity➔

Bluetooth and press the Select soft key or the key.

a687 Crunch.book Page 44 Tuesday, February 23, 2010 6:20 PM

Page 49

Changing Your Settings 45

If the second item in the Bluetooth menu is

Discoverable:Off

, then highlight the

Discoverable:Off

option

and press the Select soft key or the key.

The

Visibility enabled

confirmation prompt displays on your

phone.

Note:

If the second item in the Bluetooth menu is

Discoverable:On

, then

Bluetooth is already discoverable.

My Devices

The

My Devices

option provides a list of Bluetooth wireless

technology devices discovered by your handset.

1. In Idle mode, press

➔ Settings ➔ Connectivity➔

Bluetooth ➔ My Devices and press the Select soft key or

the key.

2. Highlight Search For New Device and press the Select

soft key or the key.

– or –

Highlight a device and press the Select soft key or the

key.

3. Enter the passkey (if applicable).

If connecting to a Bluetooth wireless device, consult your

Bluetooth device user manual for your assigned PIN.

If connecting to another handset, enter the same user-defined PIN on both handsets.

4. Highlight the

Connection Options

field and use the

Left

Right

Navigation key to select

Automatic

(reconnects

automatically), or

Always Ask

(asks before reconnecting)

and press the

Pair

soft key.

Note:

The first time you try to pair with a handset, you and the owner of the

other handset must enter the same Passkey. Once the handsets are paired, you do not need to use the Passkey again.

5. If you are unable to pair with the device a popup displays

on the screen. Press the Yes soft key to retry.

My Bluetooth Info

The

My Bluetooth Info

feature allows your phone to identify itself using the name, the Device Address and Hardware and Software Version, entered into the fields when your phone’s Bluetooth visibility is turned On. The information is altered by selecting the pre-existing text and replacing it with a new string.

a687 Crunch.book Page 45 Tuesday, February 23, 2010 6:20 PM

Page 50

In Idle mode, press

➔ Settings ➔ Connectivity

➔ Bluetooth ➔ My Bluetooth Info and press the Select

soft key or the key.

2. Press the key to erase the previous Device Name.

Note:

The default input entry method is Abc, where the initial character is Uppercase and each consecutive character in that same word is left as lowercase text.

3. Press the

Save

soft key when you are finished.

Search for New Device

This option allows you to search for new Bluetooth devices.

1. In Idle mode, press

➔ Settings ➔ Connectivity➔ Bluetooth ➔ Search for New Device and press the Select soft key or the key. The phone searches for

available devices.

2. Highlight a device and press the Select soft key or the

key.

3. Enter the passkey.

4. Select a connection option and press the

Pair

soft key.

Configuring Your Phone’s USB Settings

This menu selects the method of communication for the USB port.

Note:

Disable the Bluetooth feature before initiating a USB connection with the phone. Prior to connecting the USB cable to the phone, install the latest version of the PC Studio application. This application installs the necessary USB drivers onto your machine. For a free download of PC Studio, go to www.samsung.com/us/support.

1. In Idle mode, select

➔

Settings ➔ Connectivity

➔

Select USB Mode

2. Select one of the following USB modes:

• Ask on Connection

: causes the phone to present a “Select USB Mode” pop-up when you connect to the PC. You can choose from either:

PC Studio, Media Player

, or

Mass Storage

• Media Player

: sets the Media Player to launch as the default

application when a USB connection is detected.

• PC Studio

: sets PC Studio to launch as the default application when

a USB connection is detected.

• Mass Storage

: allows you to utilize the onboard storage capacity of the phone’s microSD card to store and upload files. This option allows your computer to detect the phone’s microSD card as a removable storage drive.

3. Press

Save

a687 Crunch.book Page 46 Tuesday, February 23, 2010 6:20 PM

Page 51

Changing Your Settings 47

Network Profile Configuration

Configuring your Network Profiles

Your phone is wirelessly connecting to the Internet via a built in WAP browser. Connection is made via one of the available WAP browsers: MEdia Net and AT&T MMS (MultiMedia Server). You need these settings to use the web browser or send MMS messages or e-mails.

Use this menu to create and customize the profiles containing the settings for connecting your phone to the network. Although you can change the active connection, please ask your local retailer or customer service representative to assist.

1. In Idle mode, press

➔

Settings

➔ Connectivity

➔ Network Profiles.

2. Highlight one of the following options and press the

View

soft key.

• MEdia Net

• AT&T MMS

• AT&T IMS

Note:

MEdia Net, AT&T MMS, and AT&T IMS are pre-configured and cannot be altered on this screen. Your phone is set up by default for connecting to the network.

– or –

Press Options ➔ New, and press the Select soft key or

the key to create a new connection.

3. Select one of the following parameters to edit. They may or

may not appear depending on the Network Profile that was

selected:

•

Set Name

: enter a profile name.

•

Access Name

: edit the access point name.

•

Auth Type

: select the type of authentication used for this WAP

connection: None, Normal, or Secure.

•

User ID

: enter the User ID required to connect to the network.

•

Password

: enter the user password required to connect to

the network.

•

Protocol

: set the connection protocol used by the WAP browser:

WAP, HTTP, or Other.

•

Home URL

: enter the URL address of the page to use as

your homepage.

•

Proxy Address

: MEdia Net set as the proxy server address

and port. This option only appears when the Protocol is set to HTTP.

• Gateway Address

: Enter the Gateway Address. This option only

appears when the Protocol is set to WAP.

a687 Crunch.book Page 47 Tuesday, February 23, 2010 6:20 PM

Page 52

• Secure Connection

: Select On or Off depending on whether or not you have a secure connection. This option only appears when the Protocol is set to WAP.

•

Linger Time (sec.)

: set a time period (in seconds) after which the network is disconnected if there is no new data traffic.

•

Advanced Settings

: allows you to configure some of the IP-specific information: Static IP, Static DNS, Server information, and Traffic Class. Highlight this option and press the Edit soft key to access the following options:

–

Static IP

: specify if you want to manually enter an IP address. Remove the check mark if you want the server to automatically assign the IP address.

–

Local Phone IP

: allows you to configure the local phone IP address.

–

Static DNS

: specify if you want to manually enter the Domain Name Server (DNS) address. Remove the check mark if you want the server to automatically assign the address.

–

Server 1/Server 2

: enter the Domain Name Server (DNS) addresses.

–

Traffic Class

: select the traffic class, press the Edit soft key, select a Traffic Class (Subscribed, Conversation, Streaming, Interactive, or Background) and press the OK soft key.

Note:

The WAP settings varies depending on the service provider.

IMS Settings

IMS is the method used to connect to the server in order set up the Video Share option.

1. In Idle mode, select

➔

Settings ➔ Connectivity

➔

IMS Settings

2. Select one of the following options:

•Service

allows you to set the IMS service to On or

Off

Important!:

If you reset the IMS Service to

Off

, you are unable to use the

Video Share Option.

• Profile

allows you to set the server which is providing service.

Select a profile and make your alterations.

Important!:

If you change from the default

AT&T IMS

, Video Sharing may be

unavailable.

Applications Settings

The Applications Settings feature allows you to configure the functional parameters for most of the onboard applications. These applications are described in more detail within other sections of this manual.

1. In Idle mode, select

➔

Settings

➔ Applications

Settings.

2. Select the type of application which you want to change:

• Messaging Settings

(see page 81)

• Browser Settings

(see page 103)

a687 Crunch.book Page 48 Tuesday, February 23, 2010 6:20 PM

Page 53

Changing Your Settings 49

• Camera Settings

(see page 71)

• Music Player Settings

(see page 49)

• Mobile Video Settings

(see page 76)

• Video Share Settings

(see page 49)

• Record Audio Settings

(see page 49)

• Calendar Settings

(see page 50)

• Address Book Settings

(see page 52).

Music Player Settings

To enable the Alerts, Auto Record, and Recording Location for Video Share, use the following steps.

1. In Idle mode, select

➔

Settings

➔ Applications

Settings

➔

Music Player Settings

2. Select one of the following options:

•

Play Mode

: allows you to set the order and repetition of your songs.

–

Shuffle

: set to On to randomly change the order that your songs are

played. Set to Off to play in the order that they are listed.

–

Loop

: allows you to set how many times a song is played. Set to Off,

Repeat 1, or Repeat All.

•

Play Via

: allows you to set how you listen to your music. Select

Phone or Bluetooth Headset.

•

Equalizer

: allows you to set the Equalizer to Normal, Rock, Pop,

Dance, Classic, or Jazz.

3. After making any changes, press the

Save

soft key.

Video Share Settings

To enable the Alerts, Auto Record, and Recording Location for Video Share, use the following steps.

1. In Idle mode, select

➔

Settings

➔ Applications

Settings

➔

Video Share Settings

2. Select one of the following options:

•

Audio Alert

: allows you to turn On or

Off

the Video Share Alerts

which play a tone.

•

Auto Record

: allows you to turn On or

Off

the Auto Record which

records the Video Share call.

• Recording Location

: allows you to set whether video recorded

stores on the

Phone

or on the microSD

Memory Card

3. Press

Select

Record Audio Settings

To configure the filename and maximum length for a recording.

1. In Idle mode, select

➔

Settings

➔ Applications

Settings

➔

Record Audio Settings

2. Select either of the following fields and edit the

information:

a687 Crunch.book Page 49 Tuesday, February 23, 2010 6:20 PM

Page 54

•

Default Name

: allows you to enter a prefix name of all recorded

audio files. Press

Save

to store the new name.

•

Recording Time

: allows you to choose the maximum limit allowed for the recorded audio file (1 Minute, 5 Minutes, 10 Minutes,15 Minutes, 30 Minutes, 60 Minutes, or Limit for MMS). Press

Save

save the new Recording Time.

3. Press

Save

Calendar Settings

To configure the starting day and view used when opening the Calendar application.

1. In Idle mode, select

➔

Settings

➔ Applications

Settings

➔

Calendar Settings

2. Press either of the following fields and edit the information:

•

Starting Day

: allows you choose which day marks the first day in

your calendar week (Sunday or Monday).

•

Default View Mode

: allows you to choose the default view for appointments used by the Calendar application when launched (Month, Week, or Day).

3. Press

Save

Address Book Settings

For information on Address Book Settings, see see “Address Book Settings” on page 52.

Memory Management

You can easily check the amount of memory being used for storing data, such as messages, media, calendar data, or contacts entries. You can also delete any selected information from your phone:

1. In Idle mode, select

➔

Settings ➔ Memory

Management

2. Press any of the following options:

•

Clear Memory

•Used Space

Clear Phone Memor y

From this menu you can clear the memory for Files, Messages, Address Book entries, Calendar entries, Tasks, or Memos. You can all select All to clear everything listed.

Note:

To completely remove any personal information stored on your device,

see “Warranty Information” on page 139.

1. In Idle mode, select

➔

Settings ➔ Memory

Management ➔ Clear Memory

2. Press

Check

to place a checkmark alongside those

applications you wish to clear.

– or –

a687 Crunch.book Page 50 Tuesday, February 23, 2010 6:20 PM

Page 55

Changing Your Settings 51

Check

All

to clear all the memory settings.

3. Press

4. Enter the user-defined password and press

Confirm

clear the memory settings. For more information, refer to “Change Phone Password” on page 41.

– or –

Press

Back

to cancel.

Check the Used Space

1. In Idle mode, select

➔

Settings ➔ Memory

Management

➔ Used Space.

2. Select one of the following storage categories to view the

contents of a category’s memory:

• Shared Memory

• Messaging

•My Stuff

• Calendar

•Tasks

•Notes

• Address Book

3. Press to return to the Idle screen.

Software Update

The Software Update feature enables you to use your phone to connect to the network and upload any new phone software directly to your phone.

1. In Idle mode, select

➔

Settings ➔ Software Update

2. Select one of the following options:

• Resume Update

: allows you to resume the software update if you

had to pause the download.

• Check for Update

: checks the AT&T server to see if there are new software updates available. If new software is found, you can download it to your phone.

3. Follow the on screen instructions.

Phone Information

This option allows you to see the phone number on the SIM card (within the phone), the manufacturer, and the model number. This information may be necessary if talking to Customer Service in the event of a problem.

1. In Idle mode, select

➔

Settings

➔ Phone

Information.

2. Read and review the information displayed on the screen.

3. Press to return to Idle screen.

a687 Crunch.book Page 51 Tuesday, February 23, 2010 6:20 PM

Page 56

Section 7: Understanding Your Address Book

This section allows you to manage your contacts by storing their name and number in your Address Book. You can sort Address Book entries by name, entry, or group.

You can also synchronize your phone Address Book with AT&T Address Book, the network backup service.

Now, managing and keeping your contacts safe and accessible has never been easier!

Note:

When storing an Address Book entry into your SIM card, note that only

the name, phone number, group, and slot location are initially offered as fields (some SIM cards may allow an address as well). Although you may add additional fields to a SIM entry; if you move that same SIM card to another model phone, it is possible that only the basic information will transfer.

AT&T Address Book Activation

Upon activation of AT&T Address Book, the network backup service, contacts are automatically synchronized between your phone and online address book. The changes you make are automatically saved and if you ever upgrade, damage, or lose your phone, you can easily restore your contacts onto your new phone.

To activate the AT&T Address Book, follow these steps:

1. Press

➔

Address Book

2. When the AT&T Address Book Terms and Conditions

screen is displayed, press the

soft key.

3. Press the

soft key.

This activation process only begins when the device Address Book is opened for the first time.

For more information on the AT&T Address Book, see “Adding a New Contact” on page 53 and “Sync Settings” on page 56.

Address Book Settings

1. Press

➔

Address Book

➔

Address Book Settings

2. Press any of the following options to activate a function:

• My Business Card

: creates and attaches a virtual business card as

an attachment to outgoing messages. For more information, see

“Attaching Business Card to a Message”

on page 79.

• Save New Contacts to

: defines the destination for new contact

entries (Phone Memory, SIM Memory, or Always Ask).

• View Contacts from

: to filter the display of current Address Book

entries. Options include: All, Phone Memory, or SIM Memory.

a687 Crunch.book Page 52 Tuesday, February 23, 2010 6:20 PM

Page 57

Understanding Your Address Book 53

• Sync Settings

: allows you to enable synchronization on any change made to your contacts between your phone Address Book and the AT&T Address Book.

•Own Number

: to display your current phone number (page 57).

•FDN Contacts

: assigns phone numbers as FDN entries (page 57).

•Used Space

: displays the memory storage allocation (total available and remaining) within your Phone, SIM card, Additional No. 1, Additional No. 2, Email, and FDN Contacts. (page 61).

• About

: displays the AT&T Address Book version and last date

updated.

Adding a New Contact

Use the following procedure to store a new contact to your Address Book. New contacts are stored on your phone by default.

Add contacts into your Address Book one at a time or easily import them all by logging into your online AT&T Address Book at

att.com/addressbook

Saving a Number from the Idle screen

1. Press

➔

Address Book

➔

Add New Contact

. The

Add

New Contact

screen displays.

2. Highlight the

First Name, Last Name

, and

Display Name

fields and use the QWERTY keypad to enter names for this

contact. For more information, refer to “Entering Text” on

page 18.

3. Press the

Mobile - Private

field and use the QWERTY

keypad to enter the phone number for this contact.

4. Highlight the

Landline

field and use the QWERTY keypad to

enter the landline number for this contact.

5. Highlight the

Email - Private

field and use the QWERTY

keypad to enter a private email address for this contact.

6. Highlight the

Group

field and press . Select a group

name and press .

7. Highlight the

Caller ID

field and press .

8. Select an image to represent this contact and press

Options

➔

Select

9. Highlight the

Ringtone

field and press .

10. Select a tone to represent this contact and press

Select

11. Highlight the

Notes

field and use the QWERTY keypad to

enter a note. For more information, refer to “Entering Text”

on page 18.

12. Press

Options

➔

Save

Note:

By default, Contacts are saved on the phone. To copy them to a SIM

card, see “Copying an Entry to the SIM Card” on page 60.

a687 Crunch.book Page 53 Tuesday, February 23, 2010 6:20 PM

Page 58

Note:

Ringtones assigned to a contact will not be synchronized to AT&T Address Book.

Adding More Fields to a Number

While in the process of creating a new entry or editing an existing contact, you can add additional fields to the entry’s list of information.

1. Press

Address Book

➔

Contacts

, highlight a contact name

and press .

2. Press

Options

➔

Edit

3. Press

Options

➔

Add More Fields

4. From the Add Details field, use the

Left

Right

Navigation key to highlight the field to add and press Select or .

The selected field type displays on the Edit Contact screen.

5. Enter the information into the new field and press

Options

➔

Save

Deleting Fields From a Number

1. Press

Address Book

➔

Contacts

, highlight a contact name

and press .

2. Press

Options

➔

Edit

3. Highlight the field to delete and press

Options

➔

Delete

Field

Note:

Only certain new fields may be deleted. If you have not added any new

fields to the contact, the

Delete Field

button does not display.

4. Press

Options

➔

Save

Saving a Number During a Call

1. During the call press

Options

➔

Save to Address Book

2. At the prompt, select

New

•

Select

Update

if this was a previously created entry and your are

adding the current number to the previous entry.

3. Select the type of phone number and press

Select

or .

4. Enter the desired information, see “Saving a Number from

the Idle screen” on page 53.

Saving a Number After a Call Has Ended

1. Press to bring up the Recent Calls screen.

2. Highlight a phone number from the list and press

Options

➔

Save to Address Book

3. From the Select Type screen, press

New

a687 Crunch.book Page 54 Tuesday, February 23, 2010 6:20 PM

Page 59

Understanding Your Address Book 55

•

Select

Update

if this was a previously created entry and your are

adding the current number to the previous entry.

4. Enter the desired information, see “Saving a Number from

the Idle screen” on page 53.

Adding Pauses to Contact Numbers

When you call automated systems, you are often required to enter a password or account number. Instead of manually entering the numbers each time, you can store the numbers in your Contacts along with special characters called pauses.

To add a pause to a Contact:

1. Press

Address Book

➔

Contacts

, highlight a contact name

and press .

2. Press

Options

➔

Edit

3. Highlight the number type where you want to add the

pause.

4. After the phone number, press to add a two-second

pause. The letter p displays to indicate the pause.

Tip:

Press p multiple times to create longer pauses.

Note:

If more than a two-second pause is required, press as many times

as needed to add additional two-second pauses.

5. Press

Options

➔

Save

to store your changes.

Using Contacts

Dialing a Number from Address Book

Once you have stored phone numbers in the Address Book, you can dial them easily and quickly by either using their SIM card location number or by using the Search field to locate the entry.

Note:

The default Address Book entries are: *Now - *669, Check Bill Balance

- *225#, Customer Care - 1-800-331-0500, Directory Assistance 411, Pay My Bill - *729, View Data Usage - *3282#, View My Minutes *646#, Voice Dial - *08, and Music ID - #43.

Finding an Address Book Entry

You can store phone numbers and their corresponding names onto your SIM card and phone’s onboard memory. The two locations are physically separate but are used as a single entity, called the Address Book.

a687 Crunch.book Page 55 Tuesday, February 23, 2010 6:20 PM

Page 60

Depending on your particular SIM card, the maximum number of phone numbers the SIM card can store and how they are stored may differ.

1. In Idle mode, press

➔

Address Book ➔ Contacts

2. Use the

Down

Navigation key to locate a contact.

Tip:

The Groups tab allows you to locate contacts by group. Use the Left or Right Navigation key to move between Contacts and Groups.

3. Press the key or

Options

➔

Call

to call the contact.

Address Book Entry Options

To access the Address Book options, follow these steps:

1. Press

➔

Address Book ➔ Contacts

and select an

entry from the list and press the key.

2. Press

Options

and select from the following:

•Edit

: allows you to make changes to the contact information.

• Video Share Call

: allows you to share either a live video recording or recorded video with a phone that is similarly equipped, and if both SIMs have the feature enabled.

•Call:

allows you to call a currently selected entry.

• Send Message: allows you to send a text message or a multimedia

message to the selected entry.

• Delete

: delete the current address book entry from a target location

such as the Phone and/or SIM card.

• Send Business Card via

: allows you to send a business card to the

selected contact via Message or Bluetooth.

• Mark as Default Number:

allows you to Change, Save, or Reset

the Default number and Message for a contact.

•More:

allows you to Assign a Speed Dial number or save the

contact to your FDN Contacts list.

Sync Settings

This feature allows you to synchronize your phone Address Book information with AT&T Address Book, the network backup service.

If you were using AT&T Address Book on your previous phone contacts, merge or replace contacts on this phone with your AT&T Address Book contacts.

1. In Idle mode, press

➔

Address Book

➔

Address Book

Settings

➔

Sync Settings

2. Highlight one of the following options and press

Save

• Automatic Sync

: automatically synchronizes any change of your

contacts (Add, Edit, or Delete).

•Sync Now

: synchronizes any change of your contacts (Add, Edit, or

Delete).

• Sync Log

: displays a log of your Sync activity.

a687 Crunch.book Page 56 Tuesday, February 23, 2010 6:20 PM

Page 61

Understanding Your Address Book 57

Finding My Own Phone Number

This function is a memory aid, which you can use to check your own phone number if you need to do so.

䊳

In Idle mode, press

➔

Address Book

➔

Address Book

Settings

➔

Own Number

➔

FDN Mode

FDN (Fixed Dialing Number) mode, if supported by your SIM card, restricts your outgoing calls to a limited set of phone numbers. When this feature is enabled, you can make calls only to phone numbers stored in the FDN list on the SIM card.

Note:

FDN Mode must be set to On in the

➔

Settings

➔

Phone

➔

Security

➔

Set FDN Mode

option before you can add, change, or delete

contacts on the FDN List.

Changing the FDN mode Status

1. In Idle mode, press

➔

Settings

➔

Phone

➔

Security

2. Scroll down to the

Set FDN Mode

field and press the

key.

3. Select

(to enable fixed dialing) or

Off

to disable the

option and press

Save

4. Enter the

PIN2 code

if you selected On.

Important!:

With Fixed Dial Mode enabled, you are NOT able to dial any number other than those created as FDN numbers.

Creating New FDN Numbers

With the Fixed Dial mode On, follow these procedures:

1. In Idle mode, press

➔

Address Book ➔ FDN Contacts

– or –

Press

➔

Address Book ➔ Address Book Settings

➔

FDN Contacts

2. Press the key in the

FDN Contacts

field and select

Create FDN Contact

3. Enter your PIN2 password and press the key.

Note:

The PIN2 code is provided by your Service Provider.

4. Press

Name

and use the QWERTY keypad to enter a name

for this FDN contact.

5. Press

Phone Number

and use the QWERTY keypad to enter

a contact phone number for this FDN contact.

a687 Crunch.book Page 57 Tuesday, February 23, 2010 6:20 PM

Page 62

Highlight the SIM card location field and use the QWERTY keypad to enter a location value for the entry on the SIM

card.

7. Press

Options ➔ Save

to store the new FDN entry.

8. Press to return to Idle mode.

Group Settings

Creating New Group

1. In Idle mode, press

➔

Address Book ➔ Groups

2. Press

Options ➔ Create Group

3. Enter a name for this group in the

New Group

field and

press

Save

. For more information, refer to “Entering Text”

on page 18.

4. Press

Options ➔ Group Settings

and press the key.

5. Highlight the


field and press the key.

6. Select an image and press

Options ➔ Select

or the

key. The selected image displays in the Picture field and

displays the name of the image to the right.

7. Highlight the

Ringtone

field and press the key.

8. Select an audio file and press

Options ➔ Select

9. Press

Options ➔ Save

and press

Select

or the key.

10. Press

Back

to return to the Address Book.

11. Press to return to Idle mode.

Note:

Groups are not synchronized between your phone Address Book and AT&T Address Book.

Adding an Entry to a Group

1. In Idle mode, press

➔

Address Book ➔ Groups

2. Highlight a group entry and press the key.

3. Press

Options

➔

Add Member

, then press the key.

4. Highlight a member from the list or highlight

All

and press

Check

. A checkmark beside the name indicates adding this

person to the group.

5. Press

Add

Removing an Entry From a Group

1. In Idle mode, press

➔

Address Book ➔ Groups

2. Highlight a group entry and press the key.

3. Highlight the member to delete from this group and press

Options

➔

Remove

and press the key.

a687 Crunch.book Page 58 Tuesday, February 23, 2010 6:20 PM

Page 63

Understanding Your Address Book 59

Highlight a member from the list or highlight

All

and press

Check

. A checkmark beside the name indicates removing

this person from the group.

5. Press the

Remove

soft key.

Renaming a Caller Group

1. In Idle mode, press

➔

Address Book ➔ Groups

2. Highlight the group that you want to rename.

3. Press

Options

➔

Rename

4. Backspace over the original name and use the keypad to

enter a new name for this group, then press

Save

Adding Speed Dial Entries

1. In Idle mode, press

➔

Address Book ➔ Speed Dial

List

and press the key.

2. Highlight a position (2-9) on the keypad in which to assign

the speed dial number and press

Options ➔ Assign

3. Select Address Book or FDN Contacts and press the

key.

4. Highlight the contact to assign to the speed dial location

and press Select or the key.

The contact is automatically assigned to the speed dial

location.

Using the Service Dialing Numbers

You can view the list of Service Dialing Numbers (SDN) assigned by your service provider. These numbers may include emergency numbers, customer service numbers, and directory inquiries.

1. In Idle mode, press

➔

Address Book ➔ Service

Numbers

and press the key.

2. Scroll through the numbers by using the

Down

Navigation key.

3. Press to dial the selected number.

Managing Address Book Entries

You can copy, delete, and view the memory status for the Phone and SIM entries on your phone.

a687 Crunch.book Page 59 Tuesday, February 23, 2010 6:20 PM

Page 64

Copying an Entry to the SIM Card

Note:

When storing an Address Book entry into the SIM card, note that only the name, phone number, group, and slot location are initially offered as fields (some SIM cards may allow an address as well). To save additional information for a particular contact, such as other phone numbers, or e-mail, it is important to add new fields to that Contact information. It is also important to note that if you move the SIM card to another phone that does not support additional fields on the SIM card, this additional information may not be available.

1. In Idle mode, press

➔

Address Book ➔ SIM

Management

➔

Copy Contacts to SIM

and press the

key.

2. Highlight a member from the list or highlight

All

and press

Check

3. Press

Copy

Important!:

When copying from the Phone to the SIM card some information may be lost.

4. At the

Continue?

prompt, press

Yes

to copy the contact, or

to cancel.

5. Press to return to Idle mode.

Copying an Entry to the Phone

1. In Idle mode, press

➔

Address Book ➔ SIM

Management

➔

Copy Contacts from SIM

and press the

key. The phone displays a list of your current contacts

stored on the SIM card.

Note:

If the entry’s associated Group image has a SIM location icon on it, then the entry exists on the SIM card. This is the type you can duplicate.

If the entry’s associated Group image does not have a SIM location icon, then this entry currently exists on the phone.

2. Highlight a member from the list and press

Check

3. Repeat Step 3 for each entry you want to copy to the

Phone or highlight

All

and press the key to place a

checkmark alongside all entries.

4. Press

Copy

5. Press to return to Idle mode.

Deleting an Address Book Entry

You can delete a Phone or SIM entry from your phone’s memory.

a687 Crunch.book Page 60 Tuesday, February 23, 2010 6:20 PM

Page 65

Understanding Your Address Book 61

Deleting an entry from the Phone

1. In Idle mode, press

➔

Address Book

➔

Contacts

and

press the key.

2. Highlight a contact to delete and press the key.

3. Press

Options

➔

Delete

4. Press to return to Idle mode.

Note:

Deleting a contact from your phone Address Book also deletes the contact from AT&T Address Book.

Deleting all entries from the SIM

1. In Idle mode, press

➔

Address Book ➔ SIM

Management

➔

Delete Contacts from SIM

and press the

key.

2. Highlight a member from the list or highlight

All

and press

Check

3. Press

Delete

4. Press to return to Idle mode.

Note:

Entries on the FDN Address Book must be deleted from within the FDN Address Book

Checking the Address Book’s Used Space

You can check how many names and numbers are stored in the Address book, in both SIM card and the phone memory. You can also see the capacity of both memories.

䊳

In Idle mode, press

➔

Address Book

➔

Address Book

Settings

➔

Used Space

• Phone

: tells you how many Address Book entries (out of a possible

1000) are in use.

•SIM Card

: tell you how many SIM Card entries are in use.

• Additional No. 1

: if you have added additional numbers to contacts saved on the SIM card, this is a counter of the number of SIM contacts with a second number saved on your SIM card.

• Additional No. 2

: if you have added additional numbers to contacts saved on the SIM card, this is a counter of the number of SIM contacts with a third number saved on your SIM card.

•Email

: tells you how many entries are in use.

•FDN Contacts

: tells you how many entries are in use on your FDN

SIM memory.

Note:

Depending on the SIM card, the number of entries may differ.

5. Press to return to Idle mode.

a687 Crunch.book Page 61 Tuesday, February 23, 2010 6:20 PM

Page 66

Yellow Pages Mobile

The Yellowpages Mobile application provides quick and ready access to businesses, map locations, and storage of your favorite searches (My Place). This application allows you to tap into local businesses, locations, and events, connecting you to your search in real-time.

1. Press

➔

YPmobile

2. Follow the on-screen prompts to enter the desired

business name, location or search by category types.

a687 Crunch.book Page 62 Tuesday, February 23, 2010 6:20 PM

Page 67

My Stuff 63

Section 8: My Stuff

The topics covered in this section include Applications, Audio, Games, Picture, Online Locker, Tools, Video, Other Files, and Used Space.

1. Press

➔

My Stuff

2. Select from one of the following functions:

Applications, Audio, Games, Picture, Online Locker, Tools, Video, Other Files,

Used Space

3. Highlight the

On phone

tab or

On card

tab to filter the

entries based on their current location (

Phone

, or

Memory

Card

My Stuff Functions

This page provides you with several functions that you can activate from virtually any page within the My Stuff directories. Most editing features are only applicable to those files/folders that are not locked.

1. Press

➔

My Stuff

➔

On card

➔

Options

2. Select from the following:

•Open:

opens the selected application or folder.

•Copy:

allows you to copy a file or folder to your phone or memory

card.

• Create Folder

: allows you to create a new My Stuff folder.

• Memory Card Settings:

allows you to view Memory Card Details, format your memory card, rename your memory card, or turn Bluetooth visibility on. This option only displays when there is a memory card inserted in your phone.

•More:

provides you with the ability to Sort by, or view Properties.

–

Sort by

: allows you to sort by Name, Date, Size, or Type.

–

Properties

: displays the properties for the selected item.

Creating a New Folder

1. Press

➔

My Stuff

➔

On card

➔

Options

➔

Create

Folder

2. Use the keypad to create a new name for the folder and

press OK.

Memory Card Settings

Using the Memory Card settings menu you can view memory card details, format or rename the memory card, or turn Bluetooth visibility on.

1. Press

➔

My Stuff

➔

On card ➔Options

➔

Memory

a687 Crunch.book Page 63 Tuesday, February 23, 2010 6:20 PM

Page 68

Card Settings

2. Select one of the following and press the key:

• Memory Card Details

: displays details about the memory card such as Name, Maximum memory, and Available memory. Press Back

after viewing.

•Format

: formats the memory card.

•Rename Memory Card

: allows you to rename the memory card. Backspace and enter a new name for the memory card then press Save

• Bluetooth Visibility On

: allows you to enable Bluetooth visibility for this memory card. Press the key to activate Bluetooth visibility. Press the key again to turn it off.

Applications

The

Applications

menu option allows you to access applications

and shop for applications using AppCenter.

For more information, refer to “Applications” on page 84.

Audio

The

Audio

menu option allows you to shop tones, ringback tones, and music using AppCenter. You can also access previously stored (pre-recorded) audio files from your internal microSD card.

1. Press

➔

My Stuff

➔

Audio

2. Highlight an option (

Tone s, Ringback Tones, Music

, or

Recorded Audio

Tone s

You can shop, download, and save to your Downloaded Ringtones folder.

1. Press

➔

My Stuff

➔

Audio ➔ Tone s

. A menu displays

to provide the option of either shopping for tones or

selecting from files previously stored to your phone.

2. Select Shop Tones, select a file to download, and follow

the on-screen instructions. (These files are downloaded and stored in the Tone s folder.)

– or –

Select an available entry.

3. From the playback page, press

Options

➔

Set as

and select

from the following options:

• Call Ringtone

: allows you to assign the selected ringtone for use with general incoming calls when no other caller ringtone has been assigned.

• Caller Ringtone

: allows you to assign a ringtone to someone in

your Contacts list. Select

Search Contact

to find an existing contact

New

to create a new one.

• Alarm Tone

: allows you to assign the tone to an alarm.

a687 Crunch.book Page 64 Tuesday, February 23, 2010 6:20 PM

Page 69

My Stuff 65

Ringback Tones

You can shop and download Ringback Tones, manage your Ringback Tones, and access Help files. To access the

Ringback

Tones

menu option, use the following steps:

1. Press

➔

My Stuff

➔

Audio ➔ Ringback Tones

2. Select one of the following options and follow the

on-screen instructions.

• Shop Ringback Tones

: launches the browser from which you can select Shop Ringback Tones, then follow the on-screen instructions to purchase a file.

• Manage Ringback Tones

: launches the browser from which you can assign Ringback Tones to Callers and Groups, turn your greeting on or off, and shop for more Ringback Tones.

• About Ringback Tones

: launches the browser from which you can navigate through the frequently asked questions regarding Ringback Tones.

Music

This menu displays all of your purchased songs. From this menu, you can also shop for music using the browser.

1. Press

➔

My Stuff

➔

Audio ➔ Music ➔ Shop Music

launch the browser.

2. Follow the on-screen instructions.

Recorded Audio

This menu shows a list of saved voice memos. When a voice memo is recorded and saved, it is stored in the Recorded Audio folder. To access this menu use the following steps:

1. Press

➔

My Stuff

➔

Audio ➔ Recorded Audio

2. Select a pre-recorded audio to begin playback.

3. Press

Back

to exit.

Creating a new audio recording

1. Press

➔

My Stuff ➔ Tools ➔ Record Audio

2. To start recording, press

Rec

For more information, refer to “Record Audio” on page 110.

Games

The

Games

menu option allows you to shop games using

AppCenter. You can download new games, then save them to the

Games

folder.

For more information, refer to “Games” on page 84.

a687 Crunch.book Page 65 Tuesday, February 23, 2010 6:20 PM

Page 70


The Picture menu option allows you to shop for and download new graphics (using AppCenter), then save them to your


folder. To access the Picture menu option, use the following steps:

1. Press

➔

My Stuff

➔


2. Depending on the type of picture or file the following

options may display:

•View

: allows you to view the selected picture.

•Send

: allows you to send a picture via Multimedia message, via

Mobile Share, or via Bluetooth.

•Set as

: allows you to set the selected picture as Wallpaper or as a

Caller ID.

• Delete

: allows you to Delete a selected picture or multiple pictures.

Note:

You cannot delete pre-loaded images.

•Rename

: allows you rename a picture.

•Move

: allows you to Move a selected picture or multiple pictures.

•Copy

: allows you to Copy a selected picture or multiple pictures.

•Take Photo

: launches the camera to allow you to take a photo.

• Create Folder

: create a new My Stuff folder on either the Phone or

Memory Card.

•More

: provides you with the ability to Lock or Unlock an image, set

Bluetooth Visibility, Sort by, or view the file Properties.

Shop Wallpapers

1. Press

➔

My Stuff

➔


➔

Shop Wallpapers

AppCenter launches.

2. Follow the on-screen instructions to purchase the new

wallpaper. The file downloads and stores in the


folder.

Image Features

Highlight an image from the Picture page and press the key to display the image. Depending on the image type the following options may be displayed after pressing

Options

•

Zoom

: allows you to magnify the current image.

•

Send

: allows you to send a picture via Multimedia message, via Mobile

Share, or via Bluetooth.

•

Set as

: allows you to assign the current image as either your current Wallpaper, or as a Caller ID image used by a specific entry in the Address Book.

•

Delete

: allows you to delete the image.

•

Rename

: allows you to rename the image.

•

Edit

: allows you to edit the image.

•

: allows you to choose from the following image options:

a687 Crunch.book Page 66 Tuesday, February 23, 2010 6:20 PM

Page 71

My Stuff 67

•Slide Show

: allows you play a slideshow using the graphics

currently available from within the Picture folder.

•Lock/Unlock

: allows you to lock/unlock the image file. Lock

prevents the image file from deletion. Unlock allows deletion.

• Bluetooth Visibility

: allows you to make the image file visible to a

Bluetooth device.

• Properties

: allows you to view the properties of an image.

Note:

Editing is only available for unlocked images or non DRM images.

Editing Images

1. Press

➔

My Stuff

➔

Picture ➔ <image>

and the

key.

2. Press

Options

➔

Edit

3. Press

Options

and select one of the following:

• Save as

: allows you to save the picture on your phone or memory

card.

• Effects

: allows you to choose from among several effects such as:

Filter, Style, Warp

, or

Partial Blur

• Adjust

: allows you to adjust

Brightness, Contrast

, and

Color

•Transform

: allows you to

Resize, Rotate

, or

Flip

the image.

•Crop

: allows you to crop the image. Use the Navigation keys to place the red box around the image until you center a portion in the box, then press

Options

➔

Crop

•Insert

: allows you to add

Frames, Cliparts, Emoticon

, or

Te xt

the image.

•Set as

: allows you to assign the current image as either your current Wallpaper, or as a Caller ID image used by a specific entry in the Address Book.

•Send

: allows you to send this picture via Multimedia Message or via

Bluetooth.

4. Press to return to Idle mode.

Online Locker

Online Locker lets you easily access photos and videos you have stored off your phone using AT&T Mobile Share. Browse and share your online pictures and videos with favorite websites or friends right from your phone.

Important!:

Standard Data rates apply when using Online Locker.

1. Press

➔

My Stuff

➔

Online Locker

2. Press

to accept the Terms & Conditions.

3. Your Online Locker Album List is displayed. Press

View

open an album.

4. Select a photo or media item and press the

Options

key.

The following options are available:

a687 Crunch.book Page 67 Tuesday, February 23, 2010 6:20 PM

Page 72

•View

: allows you to view media in your Online Locker.

• Send Photo/Video

: allows you to send a photo or video to a person, your favorite websites like Facebook and MySpace, your computer, and to your phone.

•Sort by

: allows you to sort media by Date or File Type.

• Multi Select

: allows you to select more than one media item to

send or delete.

• Search Album

: allows you to search media in your Online Locker.

• Delete Photo/Video

: allows you to delete a photo or video from

your Online Locker.

• Mobile Share Status

: allows you to see recent Mobile Share

transfers.

•Help

: allows you to receive help about using your Online Locker.

Tools

The Tools folder provides access to and allows you to use Camera, Voice Recognition, Record Audio files, set Alarms, use the Calendar features, view Recent Calls, create Tasks, write Notes, use the Calculator, use the Tip Calculator, use the Converter (for currency, length, weight, volume, area, and temperature), view the World Clock, set the Timer, and use the Stopwatch.

For more information, refer to “Tools” on page 109.

Video

This menu allows you shop for videos and to set up folders to save your videos using AppCenter.

1. Press

➔

My Stuff

➔

Video

➔

Shop Videos

. AppCenter

launches.

2. Follow the on-screen instructions to purchase a new video.

The file downloads and stores in the

Video

folder.

Other Files

This feature provide additional storage of other miscellaneous file types that may not fit into any of the previous categories.

䊳

Access the Other Files menu by selecting

My Stuff

➔

Other

Files

Used Space

The Used Space menu option allows you to view the usage and available memory for Applications, Audio, Games, Picture, Video, and Other Files. To access the Used Space option, use the following steps:

1. Press

➔

My Stuff

➔

Used Space

The memory usage for the different items displays.

a687 Crunch.book Page 68 Tuesday, February 23, 2010 6:20 PM

Page 73

My Stuff 69

Highlight

Applications, Audio, Games, Picture, Video

, or

Other Files

3. Highlight the item you want to delete (to free up memory)

and press

Select

or press the key. Highlight an item in

the list and press

Check

to place a checkmark next to the

item.

4. Press

All Files

to delete all items.

5. Press

Delete

6. At the

Delete?

prompt, press

Yes

to delete the item or No to

exit.

a687 Crunch.book Page 69 Tuesday, February 23, 2010 6:20 PM

Page 74

Section 9: Camera

This section explains how to use the camera on your phone. You can take photographs and shoot video by using the built-in camera functionality. Your 2.0 megapixel camera produces photos in JPEG format.

Important!:

Do not take photos of people without their permission. Do not take photos in places where cameras are not allowed. Do not take photos in places where you may interfere with another person’s privacy.

Using the Camera

Taking Photos

Taking pictures with your device’s built-in camera is as simple as choosing a subject, pointing the camera, then pressing the camera key.

Note:

When taking a photo in direct sunlight or in bright conditions, shadows

may display on the photo.

1. In Idle mode, press the Camera key to activate the

camera mode.

2. Using the phone’s main display screen as a viewfinder,

adjust the image by aiming the camera at the subject.

3. Press the Camera key until the shutter sounds. (The

picture automatically stores within your designated storage location. If no microSD is installed, all pictures are

stored on the Phone.) For more information, refer to

“Camera Options” on page 71.

Note:

The number of JPEG pictures remaining on the selected media displays

in the lower-left portion of the screen. This is an approximate number of total pictures you can take at the current image size.

4. Press

before taking the photo to access various

camera options.

5. Use the

and

Down

Volume keys to zoom in or out when viewing a picture after you have taken it. You can magnify

the picture up to x8.

Note:

The Zoom feature is not available when the picture size is set to the maximum size (1600x1200).

6. Press to return to Idle mode.

a687 Crunch.book Page 70 Tuesday, February 23, 2010 6:20 PM

Page 75

Camera 71

Camera Options

Options are represented by icons across the top of the screen when you press the

key.

•

Camera/Camcorder/Video Share Mode

: allows you to change between various modes. Once you change the mode, the corresponding indicator displays at the top left of the display. Choose from Camera, Camcorder, or Video Share.

•

Shooting mode

: allows you to set the shooting mode. Options

are:

–

Single Shot

: takes a single photo and view it before returning to the

shooting mode.

–

Multi-Shot

: takes a succession of consecutive photos.

–

Mosaic Shot

: takes multiple photos and then groups them together

into a single final photo.

–

Frame Shot

: allows you to choose a custom frame border for your

image. Choose from one of the 20 available frames. Press

to assign

the frame.

–

Panorama

: takes a landscape photo by taking an initial photo and then adding additional images to itself. The guide box lets you view the area where the second part of the panoramic picture should fall within by highlighting the box in orange. If you hold the camera still when it turns orange, the picture is automatically taken. Repeat this step for up to 6 segments. When you are done, press the Camera key.

•

Camera Resolution

: allows you to set the image size to either:

2M(1600x1200), 1.3M(1280x960), 640x480, or 320x240.

•

White Balance

: allows you to set this option from the following

choices: Auto, Daylight, Incandescent, Fluorescent, or Cloudy.

•

Night Mode

: allows you to take better pictures at night. Select

On or

Off.

• Timer: allows you to set a time delay before the camera takes

the photo or the camcorder begins recording video. Options include: Off, 3 seconds, 5 seconds, or 10 seconds.

•

Effects

: allows you to change the color tone or apply special effects to the photo or video. Options include: No Effects, Black & White, Sepia, or Negative.

•

Shortcuts:

In camera mode, press one of the following keys to

go straight to the option:

–

: Mode

–

: Shooting Mode

–

: Timer

–

: Viewfinder Mode

–

: Night Shot

•

Settings

: allows you to customize your camera settings. Choose from

the following options:

Settings: General tab

–

Shutter Sound

: allows you to select a tone to play when the camera’s shutter opens and closes. Sound selections are Shutter 1, Shutter 2, Shutter 3, or Off.

a687 Crunch.book Page 71 Tuesday, February 23, 2010 6:20 PM

Page 76

–

Default Storage

: allows you to configure the default storage location for images/videos as either Phone or Memory Card (if inserted).

Settings: Camera tab

–

Quality

: allows you to set the image quality to: High, Normal, or

Economy.

–

Single Shot Mode

: allows you to select Take and Review or Take and

Preview.

–

GPS

: allows you to turn GPS On or Off (also known as Geotagging). The location of where the picture is taken is attached to the picture. This option is only available in Camera mode. The following GPS icons display the GPS status:

–

: indicates that GPS is turned off.

–

: indicates that GPS is turned on and searching for GPS signal/ location information.

–

: indicates that GPS is turned on and has attained the GPS signal/ location information.

Settings: Camcorder tab

–

Quality

: allows you to set the video quality to: High, Normal, or

Economy.

–

Movie Format

: allows you to set the movie format to MP4, 3GP, or

Video Share.

Pictures/Videos Folder Options

After you have taken a photo or shot a video, you can access various options:

䊳

Press

Options

and select one of the following:

• Take Photo/Record Video

: allows you to take another photo or

record another video.

• Send/Send via

: allows you to send the photo or video via Message, via

Mobile Share, or via Bluetooth.

•Set as

: allows you to set the photo as Wallpaper or as a Caller ID.

•Rotate

: rotates the photo in 90 degree increments.

Accessing the Picture Folder

1. Press

➔

My Stuff

➔


2. Highlight a photo and press to open it in the viewer.

Editing a Photo

For information on editing a photo, see “Editing Images” on page 67.

Assigning an Image to an Address Book Entry

1. Press

➔

My Stuff

➔

Picture ➔ <image>

2. Press

Options

➔

Set as

➔

Caller ID

3. Press

Search Contact

, highlight an entry and press .

– or –

a687 Crunch.book Page 72 Tuesday, February 23, 2010 6:20 PM

Page 77

Camera 73

Press

New

and follow the create a new Address Book entry with the image already assigned. For more information,

refer to “Understanding Your Address Book” on page 52.

Assigning an Image as a Wallpaper

1. Press

➔

My Stuff

➔

Picture ➔ <image>

2. Press

Options

➔

Set as

➔

Wallpaper

The wallpaper appears as a preview.

3. Press

Select

to set the wallpaper.

Using the Camcorder

In addition to taking photos, the camera also doubles as a camcorder allowing you to also record, view, and send videos.

Shooting Video

Tip:

When shooting video in direct sunlight or in bright conditions, it is recommended that you provide your subject with sufficient light by having the light source behind you.

1. In Idle mode, press the Camera key to activate the

camera mode.

2. Press

, then Highlight

Camcorder

and press .

3. Using the phone’s main display screen as a viewfinder,

adjust the image by aiming the camcorder at the subject.

4. Press the Camera key again to record a video.

5. Press

Stop

to stop recording and save the video file.

– or –

Before shooting, press

and select

Video Share

Important!:

You must subscribe to the Video Share service and charges may apply. Contact an AT&T customer service representative.

•

Video Share allows you to make a Video Share call by displaying a screen where you can input the number of a recipient that also has Video Share. (This option will only display if you have the Video Share service.) If the recipient accepts the Video Share call, you continue using the camcorder as usual.

•

Press to end the Video Share session. The recorded file automatically saves and the file name displays. You can continue or terminate the call.

6. Once the file saves, press to play the video for review.

7. Press to return to the viewer.

a687 Crunch.book Page 73 Tuesday, February 23, 2010 6:20 PM

Page 78

Camcorder Options

Options are represented by icons across the top of the screen when you press the Menu key.

•

Camera/Camcorder/Video Share Mode

: allows you to change between various modes. Once you change the mode, the corresponding indicator displays at the top left of the display. Choose from Camera, Camcorder, or Video Share.

•

Recording Mode

: select a video recording mode. Select Multimedia Message to record a video suitable for an MMS message. Select Normal to record a video within the limit of the currently available memory.

•

Camcorder Resolution

: allows you to set the video size to

176x144 or 320x240 (if in Normal Recording Mode).

•

White Balance

: allows you to set this option from the following

choices: Auto, Daylight, Incandescent, Fluorescent, or Cloudy.

•

Video Sound

: allows you to turn the video sound On or Off.

• Timer: allows you to set a time delay before the camera takes

the photo or the camcorder begins recording video. Options include: Off, 3 seconds, 5 seconds, or 10 seconds.

•

Effects

: allows you to change the color tone or apply special effects to the photo or video. Options include: No Effects, Black & White, Sepia, or Negative.

•

Shortcuts:

In camera mode, press one of the following keys to

go straight to the option:

–

: Mode

–

: Shooting Mode

–

: Timer

: Viewfinder Mode

•

Settings

: allows you to customize your camera settings. Choose from

the following options:

Settings: General tab

–

Shutter Sound

: allows you to select a tone to play when the camera’s shutter opens and closes. Sound selections are Shutter 1, Shutter 2, Shutter 3, or Off.

–

Default Storage

: allows you to configure the default storage location for images/videos as either Phone or Memory Card (if inserted).

Settings: Camera tab

–

Quality

: allows you to set the image quality to: High, Normal, or

Economy.

–

Single Shot Mode

: allows you to select Take and Review or Take and

Preview.

–

GPS

–

: indicates that GPS is turned off.

–

: indicates that GPS is turned on and searching for GPS signal/ location information.

a687 Crunch.book Page 74 Tuesday, February 23, 2010 6:20 PM

Page 79

Camera 75

–

: indicates that GPS is turned on and has attained the GPS signal/

location information.

Settings: Camcorder tab

–

Quality

: allows you to set the video quality to: High, Normal, or

Economy.

–

Movie Format

: allows you to set the movie format to MP4, 3GP, or

Video Share.

Accessing the Video Folder

1. Press

➔

My Stuff

➔

Video

2. Highlight the

On phone

On card

tab (wherever the video

resides) and select a video from the list.

3. Press to view the video.

– or –

Before you play the video press

Options

and select one of

the following:

•Play

: plays the selected video file.

• Video Share Call

: allows you to launch the Video Share Application.

Note:

The file format must be compatible with the Video Share format.

•Send

: allows you to send the video via Multimedia Message, via

Mobile Share, or via Bluetooth.

• Delete

: allows you to delete the Selected video or Multiple videos.

•Rename

: allows you to rename the video file.

•Move

: allows you to choose the Selected or Multiple videos to

move.

•Copy

: allows you to copy a selected or multiple videos.

• Record Video

: allows you to record another video.

• Create Folder

: creates a new My Stuff folder on either the Phone or

Memory Card.

•More

: provides you with the ability to Lock or Unlock a video, set

Bluetooth Visibility, Sort by, or view the video Properties.

a687 Crunch.book Page 75 Tuesday, February 23, 2010 6:20 PM

Page 80

Section 10: Mobile Video

Your phone is equipped with a WAP (Wireless Application Protocol) browser which allows you to access the Internet and download media files directly to your phone. These media files display using the built-in Media Player. Mobile Video is a media service which allows you to stream media content (Weather, News, Sports highlights, etc.) directly to your phone.

1. In Idle mode, press

➔

Mobile Video

to launch the

default Mobile Video homepage. When the homepage

displays, you can access the following content categories:

•My Favorites

: allows you to choose from recently uploaded video clips from media providers such as CNN, ESPN, HBO Mobile Preview, and NBC.

• Video Categories

: provides some general content categories from which to search for media: Entertainment, Sports, News & Weather, Music, Kids & Cartoons & HBO Mobile.

• Customize Mobile Video

: allows you to access the Mobile Video Settings menu where you can configure most of the settings associated with Mobile Video.

•Help

: provides basic on-line assistance which answers most of the

common issues users come across while using this feature.

2. Select from one of the available categories by highlighting

an option and pressing the key.

Viewing a Video Clip

1. In Idle mode, press

➔

Mobile Video

2. Select the video clip by highlighting the entry from within

the Favorites section and pressing the key.

3. After the stream has been buffered into memory, you can

choose to either pause or play the content.

•

Press the Pause/Play button to toggle between the two functions.

•

Press the Exit button to redisplay the Mobile Video homepage.

Using the Video Categories

This grouping of media categories provides access to an additional listing of streaming media. Although the previously mentioned Favorites list of media stream is user configurable, this list of categories is defined by Mobile Video’s homepage and is not configurable.

Customizing Mobile Video

Updating the Favorites List

You can edit and change the list of media providers which display in the Favorites section of the Mobile Video homepage.

a687 Crunch.book Page 76 Tuesday, February 23, 2010 6:20 PM

Page 81

Mobile Video 77

In Idle mode, press

➔

Mobile Video

➔ Customize

Mobile Video ➔

Edit

My Favorites. The screen is

composed of two sections:

•

Manage My Favorites: lists the current Favorites list and gives you the option of opening the page or deleting it from your Favorites.

•

Add to Favorites: selecting an item moves it to the Favorites list.

2. Do one of the following:

•

Press

to delete a Favorite.

•

Press

to open a Favorite.

•

Press

move an item to the Favorites.

Adding a Video Alert

When new media is available for upload to your phone (such as breaking news), you can set your phone to notify you of the new available content.

1. In Idle mode, press

➔

Mobile Video

➔ Customize

Mobile Video ➔ My Video Alerts ➔

Add to My Alerts

2. Press the red circle next to any of the available alert

services listed within the Add to My Alerts section of the

page (ex: Breaking News).

My Purchases

Use the Mobile Video homepage to shop for streaming multimedia content. The

My Purchases

section can help keep

track of your purchase history and view any new resale products.

1. In Idle mode, press

➔

Mobile Video

➔ Customize

Mobile Video ➔

My Purchases ➔ Purchase History

. This

provides you with an on screen listing of your “to date”

purchase history for media content.

2. Press

My Account

. This provides you with an on-screen

description of your account details.

a687 Crunch.book Page 77 Tuesday, February 23, 2010 6:20 PM

Page 82

Section 11: Messaging

This section describes how to send or receive different types of messages. It also includes the features and functionality associated with messaging.

Types of Messages

Your phone provides the following message types:

•

Text Messages

•

Multimedia (Picture and Video) Messages

•

IM Messages

•

Mobile Email

•

Voicemail

The Short Message Service (SMS) lets you send and receive text messages to and from other mobile phones or email addresses. To use this feature, you may need to subscribe to your service provider’s message service.

The Multimedia Messaging Service (MMS) lets you send and receive multimedia messages (such as picture messages and video messages) to and from other mobile phones or email addresses. To use this feature, you may need to subscribe to your service provider’s multimedia message service.

Important!:

When creating a message, adding an image, a sound file, or a video clip to a text message changes the message from a text message to a multimedia message.

Messaging icons display at the top of the screen and indicate when messages are received as well as their type. For more information, refer to “Icons” on page 13.

Creating and Sending Messages

1. From the Idle screen, press

➔

Messaging

➔

Text

➔

Compose New Message

Tip:

In Idle mode, you can access your messages by pressing up on the Navigation key.

2. Enter a phone number or email address in the Recipients

field.

– or –

Press

Add

from the

Recipients

field and select one of the

following:

•Contacts

: to select a recipient from your Contacts list (valid entries

must have a wireless phone number or email address).

a687 Crunch.book Page 78 Tuesday, February 23, 2010 6:20 PM

Page 83

Messaging 79

• Groups

: to select a recipient from the Group list.

• Recent Contacts

: to select a recipient from a list of recently sent

messages.

3. Select the message field and use the QWERTY keypad to

enter a message. For more information, refer to “Entering

Text” on page 18.

4. Press

Insert

then press the

Right

Navigation key and select

one of the following to insert:

•Picture

: inserts a picture from My Pictures folder, or you can take

a picture.

•Video

: inserts a video from the My Videos folder, or you can record

a video.

• Audio

: allows you to choose an existing audio file from the My

Audios folder, or record an audio file.

• Attachment

: attaches a Favorite URL, Contact Info, File, Contact

Card, Event, Tasks, or Note.

• Options

: allows you to Preview the file, View Attachment, Add Slide, or Delete slide. Press the corresponding number on the keypad to select the displayed option.

5. Review your message and press

Send

Attaching Business Card to a Message

To attach your Business Card to an outgoing message, follow these steps:

1. Create a contract entry (the information stored in the entry

is used as a business card). For more information, refer to

“Adding a New Contact” on page 53.

2. Press

➔

Address Book

➔

Contacts

3. Highlight the contact (the business card) in which you are

sending and press the key.

4. Press

Options

➔

Send business card via

and press the

Right

Navigation key.

5. Select

Message

and press the key.

6. Enter your message.

7. Add recipient(s) and press

Send

Viewing New Received Messages

1. In Idle mode, new messages are indicated by icons and a

New Message

pop-up.

2. Press the

View

button from the

New Message

pop-up.

Note:

If you accidentally exit from this notification screen, navigate to

➔

Messaging

➔

Tex t

to access your messages.

3. Your message displays on the screen.

a687 Crunch.book Page 79 Tuesday, February 23, 2010 6:20 PM

Page 84

Using Message Options

Message options at the Inbox level differ according to the message type, what you have done with the message, and whether you are viewing the message.

䊳

While viewing the list of messages highlight a message and press the

Options

soft key to access the following:

•View

: allows you to view the message.

• Compose New Message

: allows you to compose a new message.

• Reply All

: allows you to reply to all the recipients included in this

message.

• Reply to <phone number>

: allows you to reply in a message to

this phone number.

• Delete Conversation

: deletes the selected or multiple

conversations or messages.

• See All Recipients

: displays all the recipients copied on this

message.

• Call <phone number>

: dials the phone number for this recipient.

• View Sender’s Details

: displays the sender’s detail information if

the sender is in your Contact List.

䊳

With a message open for reading, use any of the following menu options:

• Reply to <phone number>

: allows you to compose and send a reply to the message. This option reads Reply (when replying to an SMS [Text] message), and Reply to (when replying to an MMS [Multimedia] message).

• Call <phone number>

: dials the recipients phone number.

• Save to Address Book

allows you to save the recipient or sender’s information from the message to your Address Book as either a New or Updated entry. For more information, refer to

“Understanding

Your Address Book”

on page 52.

•Forward Message

: allows you to forward the message.

• Add to Favorites

: adds this recipient to the Favorites list.

• Delete Message

: deletes the current message.

• Clear Conversation

: deletes the conversation

•View All Conversations

: displays all the conversations stored in

the Conversations log.

• View Sender’s Details

: displays the sender’s detail information if

the sender is in your Contact List.

a687 Crunch.book Page 80 Tuesday, February 23, 2010 6:20 PM

Page 85

Messaging 81

Deleting Messages

When your phone’s memory is full, an notification message displays and you cannot receive any new messages. Use the

Delete

option to erase obsolete messages, freeing memory for new messages. You can delete the messages either individually or all at one time.

1. Press

➔

Messaging

➔

Tex t

All messages are stored in the Text folder.

2. Select a message to delete and press the key.

3. With the message displayed, press

Options

➔

Delete

Message

and press the key.

Messaging Settings

To configure the settings for text messages, multimedia messages, Voice mails, and Push messages.

䊳

Press

➔

Messaging

➔

Messaging Settings

Auto Cleanup

When you configure the Auto Cleanup option, messages are automatically removed from the Text folder without a warning message.

1. From the

Messaging Settings

page, press

Auto Cleanup

2. Select the age of messages before cleanup. Selections are:

Off, 1 Month Old, 2 Weeks Old, 1 Week Old

, or

The Oldest

When Full

and press

Save

Predictive Text Mode

This method automatically compares the series of keystrokes you make with an internal linguistic dictionary to determine the most likely word, should you accidentally misspell a word.

1. From the

Messaging Settings

page, press

Predictive Text

Mode

2. Select

and press

Save

3. Press

➔

Messaging

➔

Tex t

➔

Compose New

Message

4. While entering text, if you misspell a word or the word is

not in the internal dictionary, a word option is displayed. If the word you want is displayed, press the

Right

Navigation

key and the word will be entered in the message. Press the

Down

Navigation key to scroll through other available

words. If no words are correct, press the key to backspace.

a687 Crunch.book Page 81 Tuesday, February 23, 2010 6:20 PM

Page 86

Receiving Options

This option specifies the category of messages you want to receive and allows you to set the following:

•

Send Delivery Report

: when this option is enabled, the phone informs

the network whether or not your message was received.

•

Reject Anonymous

: automatically rejects messages with a category

of unknown or rejects unknown messages when turned off.

•

Reject Advertisement

: rejects messages with a category of

advertisement.

•

Allow Web Message

: allows messages with a category of Web.

Auto Resize Ima ge

Use this option to configure the size limits of the images added to new picture messages. Images larger then your setting, are resized to meet this value. Options include: No Resize, 100 KB, 300 KB, or 600 KB.

Creation Mode

Creation Mode allows you to limit your phone from including content in multimedia messages that may not be supported by the network or the receiving device. The following options are available:

•

Free

: Select Free to create a multimedia message with no restrictions.

•

Warning

: Sends a warning when unsupported content is included in a

message.

•

Restricted

: Prevents you from including unsupported content.

Message Center Address

The Message Center Address option allows you to change the settings used with the Text Message Center and the Multimedia Message Center.

Voicemail Number

The Voicemail Number option allows you edit the existing number and create a new number to use when accessing remote voicemail.

Important!:

Changing the Voicemail Center Address can affect your ability to access your voicemail. Check with your provider’s Customer Service before changing.

Used Space

You can check the amount of the memory used and the memory remaining for Multimedia, Conversations, Messages, Push Message, and Configuration Message. The display shows the total space including the used and free space. You can also view how much space is currently occupied by each message box.

1. Press

➔

Messaging ➔ Messaging Settings

➔

Used

Space

a687 Crunch.book Page 82 Tuesday, February 23, 2010 6:20 PM

Page 87

Messaging 83

Press a particular folder for review or both size and contents within the selected folder.

3. Press

Back

to return to the Messaging Settings screen.

Using Instant Messaging (IM)

Instant Messaging allows you to send and receive instant messages using AIM, Windows Live, and Yahoo!® communities.

Note:

Before using this feature, you need to subscribe to a messaging service. For further details, contact your service provider.

Signing into Your IM Account

Although each account type differs, the initial sign in procedure is common to all supported types. Before beginning the sign in procedure, you must complete the previous procedures for selecting your default IM Community to which you are subscribed.

1. Press

➔

Messaging ➔ IM

2. Select an IM client (AIM, Messenger, or Yahoo!).

3. Select

New Account

and then select the available fields to enter your information such as Sign In as, Screen Name, E-

mail Address or Yahoo! ID, and Password. Select any

additional fields.

4. Check the

Save password

Auto-Sign In

checkbox (if

desired).

5. Press

to continue.

Note:

Options and required fields will differ depending on the IM client you

have selected.

Using Mobile Email

Take your email with you! With Mobile Email you can check your Yahoo! Mail, AOL Mail®, AIM Mail, Windows Live Hotmail, AT&T Mail, Gmail, and other providers quickly and easily.

Signing into Your Mobile Email

To sign into your Mobile Email, follow these steps:

1. Press

➔

Mobile Email

2. Highlight an Email carrier of your choice and press

Select

3. Select a domain and press

Select

4. Enter your

Email Address

and

Password

then press

5. Follow on-screen instructions to complete the process.

Voicemail

This option dials and connects you to the Voicemail center. Follow the prompts to configure options or receive messages.

a687 Crunch.book Page 83 Tuesday, February 23, 2010 6:20 PM

Page 88

Section 12: Games & Applications

Games

The

Games

menu option allows you to access games that are on the phone and also shop for games using AppCenter. You can download new games and then save them to the

Games

folder.

1. Press

➔

My Stuff ➔ Games

2. From the

Games

menu, press a pre-installed application or

press

Shop Games

• Bubble Bash 2

• Diner Dash 2

•Ms. PAC-MAN by Namco

•Tetris

3. Follow the on-screen instructions.

Shop Games

1. Press

➔

My Stuff ➔ Games

➔ Shop Games to

launch AppCenter.

2. Follow the on-screen instructions. The file is downloaded

and stored in the

Games

folder.

Note:

Service charges and subscription purchase may be required.

For more information, refer to “AppCenter” on page 87.

Applications

The

Applications

menu option allows you to access applications that are on the phone and also shop applications using AppCenter. You can download applications and then save them to the

Applications

folder.

1. Press

➔

My Stuff ➔ Applications

2. From the

Applications

menu, press a pre-installed

application or press

Shop Applications

•Browser

: allows you to access the internet using att.home.

• AllSport GPS

: This application allows you to track how far and fast you run, walk, jog, or bike and it tells you how many calories were burnt.

• AppCenter

: The AppCenter allows you to shop for Ringtones, Games, Cool Tools/Apps, Videos, Color Graphics, Answer Tones, and Multimedia using the built-in browser. You can also access the MEdia Home site.

• AT&T Navigator

: is a JAVA based driving aid that uses GPS

navigation.

a687 Crunch.book Page 84 Tuesday, February 23, 2010 6:20 PM

Page 89

Games & Applications 85

• AT&T Social Net

: is a single mobile application with a live connection to your favorite social networks such as Facebook, Twitter, Myspace, and the News.

• Loopt

: is a cellphone-based GPS sharing system that allows users to visualize one another using their cell phones and share information. Loopt also enables users to explore the world around them by connecting users with integrated content from Yelp and other applications. For more information, refer to

“Loopt”

page 99.

• Make-UR-Tones

: The Make-UR-Tones application allows you to

create customized ringtones from full-track songs.

• Mobile Banking

: You can access your banking information on your phone. Mobile Banking allows you to view balances, perform transfers, view account history and pay bills directly from your mobile phone. Mobile Banking Providers include: U.S. Bank, Sun Trust, Regions, USAA, and Citi Mobile for Cards.

• Mobile Email

: Take your email with you! With Mobile Email you can check your Yahoo!® Mail, AOL®, AIM, Windows Live Hotmail, AT&T Yahoo!®, Gmail, and other providers quickly and easily.

• Mobile Web

: Your phone is equipped with att.net, your access to

the mobile web.

•MobiTV

: This is a subscription service that allows you to watch your

favorite TV shows using your handset.

•MobiVJ: This is a subscription service that allows you to watch

unlimited music videos using your handset.

• Movies Powered by IMDb

: allows you to access biographies and photos from thousands of films, actors, directors, producers and more. You can also access photo galleries, search local theatres for show times, order tickets directly from your mobile phone, check out new releases and hot tips, and watch a featured movie of the day.

•MusicID 2

: This is an application which uses the onboard microphone to analyze a music sample and then identify the song. Once the application completes the analysis of the song sample, it then provides you with the name of the song, artist and album art as well as opportunities to buy related content.

• My-Cast Weather

: This is a user-friendly application which runs on your mobile phone giving you access to all the weather information you need. You can check current and predicted National Weather Service data for your immediate location, your travel destination, or virtually anywhere else in the continental U.S.

•Where

: is a downloadable mobile application that uses your current location (obtained via the built-in GPS) to help you find places of interest, things to do, and local information while you’re on the go.

• WikiMobile

: With WikiMobile, you gain access to all 2 million Wikipedia articles, including pictures and quick facts. Bookmark your favorites for quick and easy tracking. Being a walking encyclopedia is now at your fingertips.

•XM Radio

: This service allows you to stream approximately 25

channels of commercial-free music through your handset.

• Yellowpages

: The Yellowpages Mobile application provides quick

and ready access to businesses, map locations, and storage of

a687 Crunch.book Page 85 Tuesday, February 23, 2010 6:20 PM

Page 90

your favorite searches (My Place). This application allows you to tap into local businesses, locations, and events, connecting you to your search in real-time.

3. Follow the on-screen instructions.

Shop Applications

1. Press

➔

My Stuff ➔ Applications

➔ Shop

Applications to launch AppCenter.

2. Follow the on-screen instructions to purchase the new

application. The file is downloaded and stored in the

Applications

folder.

3. To access a new application, press the entry from the

available list.

Note:

Service charges and subscription purchase may be required.

For more information, refer to “AppCenter” on page 87.

a687 Crunch.book Page 86 Tuesday, February 23, 2010 6:20 PM

Page 91

AppCenter 87

Section 13: AppCenter

The AppCenter allows you to shop for Ringtones, Games, Cool Tools/Apps, Videos, Color Graphics, Themes, and Answer Tones using the built-in browser. You can also access the MEdia Net Home site.

䊳

Press

➔

AppCenter

to launch the AppCenter application.

Ringtones

This option allows you to shop for ringtones using the built-in browser.

1. Press

➔

AppCenter ➔ Ringtones

2. Select an entry.

3. Follow the on-screen instructions to purchase a ringtone.

Games

This option allows you to shop for games using the built-in browser.

1. Press

➔

AppCenter ➔ Games

2. Follow the on-screen instructions to purchase games for

your phone.

Cool Tools/Apps

This menu option allows you to shop for tools and applications using the built-in browser. You can download new tools and applications to your

Applications

folder.

1. Press

➔

AppCenter ➔ Cool Tools/Apps

2. Follow the on-screen instructions to purchase a tool or an

application.

Videos

This menu option allows you to shop for Videos using the built-in browser. You can download new images to your

Videos

folder.

1. Press

➔

AppCenter ➔ Videos

2. Follow the on-screen instructions to purchase a video.

Color Graphics

This menu option allows you to shop for graphic images using the built-in browser. You can download new images to your

Pictures

folder.

1. Press

➔

AppCenter ➔ Color Graphics

2. Follow the on-screen instructions to purchase a color

graphic.

a687 Crunch.book Page 87 Tuesday, February 23, 2010 6:20 PM

Page 92

Themes

This menu option allows you to shop for new themes so you can customize your phone.

1. Press

➔

AppCenter ➔ Color Graphics

2. Follow the on-screen instructions to purchase a theme.

Answer Tones

This menu option allows you to shop for answer tones using the built-in browser.

1. Press

➔

AppCenter ➔ Answer Tones

2. If prompted to accept a redirection, press

3. Follow the on-screen instructions to purchase an answer

tone.

MEdia Net Home

The MEdia Net menu option allows you to quickly access your MEdia Net homepage using the built-in browser. This page gives you quick access to information such as local weather, sports scores, horoscope information and quick links to the previously mentioned shopping sites. To access this menu option, use the following steps:

䊳

When the Idle screen displays, press the

➔

AppCenter

➔

MEdia Net Home

to launch the built-in browser and launch this

AT&T homepage.

AppCenter Options

䊳

From the AppCenter home page, press the

Options

soft key.

The following options display:

•

MEdia Mall Home

: takes you back to the AppCenter home screen.

•

MyMEdia Club

: enables you to join the MyMEdia Club, where you can earn credits toward the purchase of tones, graphics, and games in the AT&T AppCenter.

Note:

A monthly charge is applied for MyMEdia membership.

•

MEdia Mall Account

: shows a history of your AppCenter account.

•

My Answer Tones

: allows you to shop for answer tones using the

built-in browser.

•
