Samsung ST10WL Users Manual

Notices

No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, mechanical photocopying, recording or
otherwise, without the prior written permission of the manufacturer.

The information within this manual is subject to change without notice.
The manufacturer shall not be held liable for technical or editorial errors or omissions

contained in herein; nor for incidental or consequential damages resulting from the
furnishing, performance or use of this material.
Microsoft Windows is a registered trademark of the Microsoft Corporation.
Product names mentioned herein are for identification purposes only, and may be

trademarks and/or registered trademarks of their respective companies.

Macrovision Statement

If your computer has a DVD drive and an analog TV Out port, the following
paragraph applies:

This product incorporates copyright protection technology that is protected by method
claims of certain U.S. patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.

Copyright 2002 All rights are reserved

Notices i

Important Safety Information

Safety Instructions

Your system is designed and tested to meet the latest standards for safety of
information technology equipment. However, to ensure safe use of this product, it is
important that the safety instructions marked on the product and in the documentation
are followed.

Always follow these instructions to help guard against personal injury and
damage to your system.

i

Setting Up your System

Read and follow all instructions marked on the product and in the

•

documentation before you operate your system. Retain all safety and operating
instructions for future use.

• Do not use this product near water or a heat source such as a radiator.

• Set up the system on a stable work surface.

ii Users Manual

• The product should be operated only with the type of power source indicated on

the rating label.

• Ensure that the electrical outlet you are using to power your equipment is easily

accessible in case of fire or short circuit.

• If your computer has a voltage selector switch, make sure that the switch is in

the proper position for your area.

• Openings in the computer case are provided for ventilation. Do not block or

cover these openings. Make sure you provide adequate space, at least 6 inches
(15 cm), around the system for ventilation when you set up your work area.
Never insert objects of any kind into the computer ventilation openings.

• Ensure that the fan vents on the bottom of the casing are clear at all times. Do

not place the computer on a soft surface, doing so will block the bottom vents.

• If you use an extension cord with this system, make sure that the total ampere

rating on the products plugged into the extension cord does not exceed the
extension cord ampere rating.

Care During Use

•

Do not walk on the power cord or allow anything to rest on it.

• Do not spill anything on the system. The best way to avoid spills is to not eat or

drink near your system.

• Some products have a replaceable CMOS battery on the system board. There is

a danger of explosion if the CMOS battery is replaced incorrectly. Replace the
battery with the same or equivalent type recommended by the manufacturer.
Dispose of batteries according to the manufacturer’s instructions. If the CMOS
battery requires replacement insure that a qualified technician performs the task

• When the computer is turned off, a small amount of electrical current still flows

through the computer. To avoid electrical shock, always unplug all power
cables, remove the battery and modem cables from the wall outlets before
cleaning the system.

• Unplug the system from the wall outlet and refer servicing to qualified

personnel if:

– The power cord or plug is damaged.
– Liquid has been spilled into the system.
– The system does not operate properly when the operating instructions are

followed.
– The system was dropped or the casing is damaged.
– The system performance changes.

Replacement Parts and Accessories

Use only replacement parts and accessories recommended by manufacturer.

To reduce the risk of fire, use only No. 26 AWG or larger telecommunications

line cord.

Do not use this product in areas classified as hazardous. Such areas include

Writtenby:Daryl L.Osden

patient care areas of medical and dental facilities, oxygen rich environments,

or industrial areas.

Important Safety Information iii

Battery Disposal

Do not put rechargeable batteries or products powered by non-removable

rechargeable batteries in the garbage.

Contact the Samsung Helpline for information on how to dispose of batteries that you
cannot use or recharge any longer.

Follow all local regulations when disposing of old batteries.

iv Users Manual

Regulatory Compliance Statements

Wireless Guidance

Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook
system. The following section is a general overview of considerations while operating
a wireless device.

Additional limitations, cautions, and concerns for specific countries are listed in the
specific country sections (or country group sections). The wireless devices in your
system are only qualified for use in the countries identified by the Radio Approval
Marks on the system rating label. If the country you will be using the wireless device
in, is not listed, please contact your local Radio Approval agency for requirements.
Wireless devices are closely regulated and use may not be allowed.

The power output of the wireless device or devices that may be embedded in your
notebook is well below the RF exposure limits as known at this time. Because the
wireless devices (which may be embedded into your notebook) emit less energy than
is allowed in radio frequency safety standards and recommendations, manufacturer
believes these devices are safe for use. Regardless of the power levels, care should be
taken to minimize human contact during normal operation.

As a general guideline, a separation of 20 cm (8 inches) between the wireless device
and the body, for use of a wireless device near the body (this does not include
extremities) is typical. This device should be used more than 20 cm (8 inches) from the
body when wireless devices are on and transmitting.

This transmitter must not be collocated or operation in conjunction with any other
antenna or transmitter.

Some circumstances require restrictions on wireless devices. Examples of common

Some circumstances require restrictions on wireless devices. Examples of common
restrictions are listed below:

restrictions are listed below:

Radio frequency wireless communication can interfere with equipment on

commercial aircraft. Current aviation regulations require wireless devices to be

turned off while traveling in an airplane. 802.11B (also known as wireless

Ethernet or Wifi) and Bluetooth communication devices are examples of

devices that provide wireless communication.

Regulatory Compliance Statements v

In environments where the risk of interference to other devices or services is

harmful or perceived as harmful, the option to use a wireless device may be

restricted or eliminated. Airports, Hospitals, and Oxygen or flammable gas

laden atmospheres are limited examples where use of wireless devices may

be restricted or eliminated. When in environments where you are uncertain of

the sanction to use wireless devices, ask the applicable authority for

authorization prior to use or turning on the wireless device.

Every country has different restrictions on the use of wireless devices. Since

your system is equipped with a wireless device, when traveling between

countries with your system, check with the local Radio Approval authorities

prior to any move or trip for any restrictions on the use of a wireless device in

the destination country.

If your system came equipped with an internal embedded wireless device, do

not operate the wireless device unless all covers and shields are in place and

the system is fully assembled.

Wireless devices are not user serviceable. Do not modify them in any way.

Modification to a wireless device will void the authorization to use it. Please

contact manufacturer for service.

vi Users Manual

Only use drivers approved for the country in which the device will be used. See

the manufacturer System Restoration Kit, or contact manufacturer Technical

Support for additional information.

United States of America

Federal Communications Commission (FCC)

Intentional emitter per FCC Part 15

Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook
system. This section is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in the United
States of America if an FCC ID number is on the system label.

The FCC has set a general guideline of 20 cm (8 inches) separation between the device
and the body, for use of a wireless device near the body (this does not include
extremities). This device should be used more than 20 cm (8 inches) from the body
when wireless devices are on. The power output of the wireless device (or devices),
which may be embedded in your notebook, is well below the RF exposure limits as set
by the FCC.

This transmitter must not be collocated or operation in conjunction with any other

antenna or transmitter.

Operation of this device is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation of the device.

Wireless devices are not user serviceable. Do not modify them in any way.

Modification to a wireless device will void the authorization to use it. Contact

manufacturer for service.

FCC Statement for Wireless LAN use:

“While installing and operating this transmitter and antenna combina tion the

radio frequency exposure limit of 1mW/cm2 may be exceeded at distances

close to the antenna installed. Therefore, the user must maintain a minimum

distance of 20cm from the antenna at all times. This device can not be

colocated with another transmitter and transmitting antenna.”

Unintentional Emitter per FCC Part 15

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:(1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

Regulatory Compliance Statements vii

This equipment has been tested and found to comply with the limits for a Class

B digital device pursuant to Part 15 of the FCC Rules. These limits are

Writtenby:Daryl L.Osden

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generate uses and can radiate radio

frequency energy and if not installed and used in accordance with the

instructions may cause harmful interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

If necessary, the user should consult the dealer or an experienced radio/television
technician for additional suggestions. The user may find the following booklet helpful:
“Something About Interference.” This is available at FCC local regional offices. Our
company is not responsible for any radio or television interference caused by
unauthorized modifications of this equipment or the substitution or attachment of
connecting cables and equipment other than those specified by our company. The
correction will be the responsibility of the user. Use only shielded data cables with this
system.

Federal Communications Commission Part 68 Statement

This equipment compiles with part of the FCC rules. On the back of this equipment is
a label that contains, among other information, the FCC registration number and ringer
equivalence number (REN) for this equipment. If requested, this information must be
provided to the telephone company.

This equipment uses the following USOC jacks : RJ11C
An FCC compliant telephone cord and modular plug is provided with this equipment.

This equipment is designed to be connected to the telephone network or promises
wiring using a compatible modular jack which is Part 68 compliant. See Installation
Instructions for details.

viii Users Manual

The REN is used to determine the quantity of devices which may be connected to
telephone line. Excessive RENs on the telephone line may result in the devices not
ringing in response to an incoming call. In most, but not all areas, the sum of RENs
should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by total RENs, contact the local telephone company
to determine the maximum REN for the calling area.

If the terminal equipment causes harm to the telephone network, the Telephone
Company will notify you in advance that temporary discontinuance of service may be
required. But if advance notice is not practical, the telephone company will notify the
customer as soon as possible. Also, you will be advised of your right to file a complaint
with the FCC if you believe it is necessary.

The telephone company may make changes in its facilities, equipment, operations, or
procedures that could affect the operation of the equipment. If this happens, the
telephone company will provide advanced notice in order for you to make necessary
modifications to maintain uninterrupted service.

If trouble is experienced with this equipment (Modem) for repair or warranty
information, please contact your local distributor. If the equipment is causing harm to
the telephone network, the telephone company may request that you disconnect the
equipment until the problem is resolved.

The user must use the accessories and cables supplied by the manufacturer to get
optimum performance from the product.

No repairs may be done by the customer.
This equipment cannot be used on public coin phone service provided by the telephone

company. Connection to party line service is subject to state tariffs.
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to

use a computer or other electronic device, including fax machines, to send any message
unless such message clearly contains in a margin at the top or bottom of each
transmitted page or on the first page of the transmission, the date and time it is sent and
an identification of the business or other entity, or other individual sending the message
and the telephone number of the sending machine or such business, other entity, or
individual. (The telephone number provided may not be any number for which charges
exceed local or long-distance transmission charges.)

In order to program this information into your fax machine, refer to your
communications software user manual.

Regulatory Compliance Statements ix

Canada

Industry Canada (IC)

Intentional Emitter per RSS 210

Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook
system. This section is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in Canada if an
Industry Canada ID number is on the system label.

As a general guideline, a separation of 20 cm (8 inches) between the wireless device
and the body, for use of a wireless device near the body (this does not include
extremities) is typical. This device should be used more than 20 cm (8 inches) from the
body when wireless devices are on.

The power output of the wireless device (or devices), which may be embedded in your
notebook, is well below the RF exposure limits as set by Industry Canada.

This transmitter must not be collocated or operation in conjunction with any other
antenna or transmitter.

Operation of this device is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation of the device.

Unintentional Emitter per ICES-003

This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the radio interference regulations of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les
limitesapplicables aux appareils numériques de Classe B prescrites dans le règlement
sur le brouillage radioélectrique édicté par Industrie Canada.

x Users Manual

To prevent radio interference to licensed service, this device is intended to be

operated indoors and away from windows to provide maximum shielding.

Equipment (or its transmit antenna) that is installed outdoors is subject to

licensing.

Wireless devices are not user serviceable. Do not modify them in any way.

Modification to a wireless device will void the authorization to use it. Contact

manufacturer for service.

European Union

The following information is only applicable to systems labeled with the CE mark .

European Directives

This Information Technology Equipment has been tested and found to comply with the
following European directives:

• EMC Directive 89/336/EEC with amending directives 92/31/EEC & 93/68/

EEC as per

– EN 55022 Class B
– EN 61000-3-2
– EN 61000-3-3
– EN 55024

• Low Voltage Directive (Safety) 73/23/EEC as per EN 60950(A1/A2/A3/A4/

A11)

• Radio and Telecom Terminal Equipment Directive 199/5/EC as per

– CTR21 (if fitted with a modem device)
– ETS 300 328 (if fitted with a 2.4 GHz band embedded wireless device)
– ETS 301 489-1 (if fitted with a 2.4 GHz band embedded wireless device)
– ETS 301 489-17 (if fitted with a 2.4 GHz band embedded wireless device)

European Radio Approval Information
(for products fitted with EU-approved radio devices)

This Product is a Notebook computer; low power, Radio LAN type devices (radio
frequency (RF) wireless communication devices), operating in the 2.4 GHz band, may
be present (embedded) in your notebook system which is intended for home or office
use. This section is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in the European
Union or associated areas if a CE mark with a Notified Body Registration Number
and the Alert Symbol is on the system label.

The power output of the wireless device or devices that may be embedded in you
notebook is well below the RF exposure limits as set by the European Commission
through the R&TTE directive.

Regulatory Compliance Statements xi

European States qualified under wireless approvals:
EU

Austria, Belgium, Denmark, Finland, France (with frequency
restrictions),

Germany, Greece, Ireland, Italy, Luxembourg, The

Netherlands, Portugal, Spain, Sweden and the United Kingdom.

Accept EU

Iceland, Liechtenstein, Norway and Switzerland

European States with restrictions on use:
EU

In France, the frequency range is restricted to 2446.5-2483.5 MHz for
devices above 10 mW transmitting power such as wireless LAN.

Accept EU No limitations at this time.

European Telecommunication Information
(for products fitted with EU-approved modems)

Marking by the symbol indicates compliance of this equipment to the Radio and
Telecom Terminal Equipment Directive 1999/5/EC. Such marking is indicative that
this equipment meets or exceeds the following technical standards:

CTR 21 – Attachment requirements for pan-European approval for connection to the
analogue Public Switched Telephone Networks (PSTNs) of TE (excluding TE
supporting voice telephony services) in which network addressing, if provided, is by
means of Dual Tone Multi-Frequency (DTMF) signaling.

Although this equipment can use either loop disconnect (pulse) or DTMF

(tone) signaling, only the performance of the DTMF signaling is subject to

regulatory requirements for correct operation. It is therefore strongly

recommended that the equipment is set to use DTMF signaling for access to

public or private emergency services. DTMF signaling also provides faster call

setup.

This equipment has been approved to Council Decision 98/482/EEC—“CTR 21” for
Pan-European single terminal connection to the Public Switched Telephone Network
(PSTN).

However, due to differences between the individual PSTNs provided in different
countries, the approval does not, of itself, give an unconditional assurance of
successful operation on every PSTN termination point. In the event of problems, you
should contact manufacturer Technical Support.

xii Users Manual

Japan

Wireless Devices

Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook
system. This section is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in Japan if a
TELEC ID is on the system label.

Operational guidelines for 2.4 GHz band wireless equipment (if equipped)

This equipment uses the 2.4 GHz ISM frequency band. The ISM band is the industrial,
scientific, and medical device band. Devices that might also use this band are
microwave ovens, other LAN devices, amateur radio stations, licensed premises radio
stations, and non-licensed specified low-power radio stations.

Prior to setting up your device:

1. Make sure that there are no other devices in your area using the same frequency

band.

2. Change the channel, location, or discontinue device use if you are interfering with

any other radio station.

3. Contact manufacturer if you have any problems with this device.

Regulatory Compliance Statements xiii

VCCI Statement

This equipment is in the Class B category (Information Technology Equipment to be
used in a residential area or an adjacent area thereto) and conforms to the standards set
by the Voluntary Control Council for Interference by Information Technology
Equipment aimed at preventing radio interference in such residential areas. When used
near a radio or TV receiver, it may become the cause of radio interference. Read
instructions for correct handling.

xiv Users Manual

Laser Safety

All systems equipped with CD or DVD drives comply with the appropriate safety
standards, including IEC 825. The laser devices in these components are classified as
“Class 1 Laser Products” under a US Department of Health and Human Services
(DHHS) Radiation Performance Standard. Should the unit ever need servicing, contact
an authorized service location.

Laser Safety Note:

Use of controls or adjustments or performance of procedures other than those

specified in this manual may result in hazardous radiation exposure. To

prevent exposure to laser beams, do not try to open the enclosure of a CD or

DVD drive.

Laser Safety xv

Power Cord Requirements

The power cord set (wall plug, cable and AC adapter plug) you received with your
computer meets the requirements for use in the country where you purchased your
equipment.

Power cord sets for use in other countries must meet the requirements of the country
where you use the computer. For more information on power cord set requirements,
contact your authorized dealer, reseller, or service provider.

General Requirements

The requirements listed below are applicable to all countries:

• The length of the power cord set must be at least 6.00 feet (1.8m) and a

maximum of 9.75 feet (3.0m).

• All power cord sets must be approved by an acceptable accredited agency

responsible for evaluation in the country where the power cord set will be used.

• The power cord set must have a minimum current capacity of 7 A and a

nominal voltage rating of 125 or 250 volts AC, as required by each country’s
power system.

• The appliance coupler must meet the mechanical configuration of an EN 60

320/IEC 320 Standard Sheet C13 connector, for mating with appliance inlet on
the computer.

xvi Users Manual

Country-Specific Power Cord Set Requirements

The requirements listed below are applicable to the specific country listed:

Country

Australia EANSW 1
Austria OVE 1
Belgium CEBC 1
Canada CSA 2
Denmark DEMKO 1
Finland FIMKO 1
France UTE 1
Germany VDE 1

Italy
Japan JIS 3

The Netherlands KEMA 1
Norway NEMKO 1
Sweden SEMKO 1
Switzerland SEV 1
United Kingdom BSI 1

United States

Accrediting
Agency

IMQ 1

UL 2

Applicable Note
Numbers

Writtenby:Daryl L.Osden

Notes:

1. Flexible cord must be Type HO5VV-F, 2-conductor, 1.0 mm² conductor

size. Power cord set fittings (appliance coupler and wall plug) must bear
the certification mark of the agency responsible for evaluation in the
country where it will be used.

2. Flexible cord must be Type SVT or equivalent, No.18 AWG. Wall plug must
be a two-pole grounding type.

3. Appliance coupler, flexible cord, and wall plug must bear a “T” mark and
registration number in accordance with the Japanese Dentori Law. Flexible
cord must be Type VCT or VCTF, 2-conductor, 0.75 mm² conductor size.
Wall plug must be a two-pole grounding type with a Japanese Industrial
Standard C8303 (15 A, 125V) configuration.

Power Cord Requirements xvii

Using Your Documentation

Congratulations on your purchase of a notebook computer with the Windows® 2000
operating system. Whether you are new to using a notebook computer or are an
experienced user, this user’s manual can help you get the most from your computer.

Manual Documentation Conventions

Information Icons

Three icons and their associated messages appear in this manual. The information
icons are placed before the step/information they apply to:

Warning:

Indicates the possibility of personal injury.

Caution:

Warns you of possible damage to equipment or data.

Note:

Informs you of special circumstances.

Keyboard Conventions

Keys that you need to press to perform certain functions are displayed in the manual
using a small graphic of the button. For example:

<Ctrl>

indicates the control key (Ctrl on the keyboard).

If you need to press two keys at the same time, the key names are shown joined by a
plus sign. For example:

<Alt+PgUp>

means that you should press the Alt key and hold it and then press the PgUp key.

Using Your Documentation 1

CD-ROM Device Naming Convention

In many installation programs you will have to get a program from the CD-ROM
device. The program installation sequence assumes that the CD is drive d:\, however
this is not always the case. The name of the CD-ROM drive is the letter following the
letter assigned to your last HDD. For instance, if you have one HDD with two
partitions, the HDD is drives C: and D: and the CD-ROM drive is then drive E.

Touchpad Conventions

You may be asked to click or double-click on items on the display screen. As a general
note the touchpad actions act much in the same way as a wheel mouse, any differences
are explained fully.

The object that needs to be clicked upon will be displayed in Bold text or shown in a
small figure such as the “Start Button” shown on the right => .

Table 1. Touchpad Click Conventions

Action Process

Click Depress the touchpad left button and release

Double-Click Quickly click the left touchpad button two times

Windows Conventions:

Almost all "Windows" programs will display the name/function of a button or
icon if you place the touchpad pointer on the item you want information about.

Software User Documentation

Your computer is shipped from the factory with several software programs installed.
The software may include its own online or printed documentation. Refer to the
documentation or the Help options in the software for more information.

2 Users Manual

The figures and illustrations in this manual may not be identical to those on
your system.

General Icon Note:
Some of the Icons used in Windows may be placed on the taskbar by selecting
(ex: Place the volume icon in the taskbar) in the properties dialog box.

Introducing Your Computer

Your computer is a lightweight portable computer that includes features such as Dolby
Digital & Dolby Theater System support, CD-ROM/floppy drives, Biometric
(fingerprint) security system (factory option) and wireless LAN capability (factory
option), to meet your computing needs at home or on the road. [Figures may be
different depending on options).

Where Everything Is

The next 6 figures will explain the location of all of the buttons, LEDs and equipment
needed to operate your notebook computer.

Front

LCD Display

LCD Latch

Power Button

Biometric

Security

pad

Speaker

Cover Latch Slot Cover Latch Slot

LEDs

Keyboard

Power, Battery Status

& E-mail LEDs

SENS Keyboard

Buttons

Touchpad
Touchpad Buttons
Internal Microphone

Introducing Your Computer 3

Speaker

Buttons and LEDs

Power Button

Number Lock Icon

Caps Lock Icon

Scroll Lock Icon

Drive Access Icon

Right Side

E-Mail Button

Internet Button

User
Programmable
Button

Battery Status

Power

E-Mail Alert

Left Side

4 Users Manual

FDD Fan Vent LAN PortCD/DVD - ROM Hard Drive

PC Card Eject Buttons PC Card Slot

TV-Out Port

Fan Vent

Security Lock Port

Microphone Jack

Headphone Jack

Battery

Wheel Volume
Control

SPDIF In Jack

Line In Jack

Back Side

PS/2 Port

Modem Port

DC-In Port

Bottom

Hard Drive

Mini PCI

Compartment

Flex Bay Compartment

Parallel

Printer Port

Docking

Connector

1394 Port

USB Ports

Serial Port

External Monitor Port

Memory

Compartment

Battery Compartment

Flex Bay Latch

Introducing Your Computer 5

Using Your Computer for the First Time

This section gives you detailed information on using your computer for the first time.

Installing the Battery

To install the battery pack:

1. With the computer’s power off, close the LCD panel and turn the computer over

so the bottom of the unit faces up.

2. Slide the battery compartment cover straight up and off the computer. See
“Installing the Battery” on page 37.

Insert the battery into the battery compartment, ensuring the correct
orientation so that the battery fits in its slot properly.

3. Slide the battery pack into the compartment. Make sure the battery is fully inserted
into the compartment.

4. Align the tabs on the battery compartment cover with the slots on the battery
compartment.

5. Push the cover straight down until it snaps into place.

6 Users Manual

Attaching the AC Adapter

Your computer runs on power from the battery in the computer or from an electrical
outlet. The first time that you use your computer, fully charge the battery by attaching
the power cord to the computer and to an electrical outlet.

All batteries lose their charge if they sit unused for an extended time period.
When not used, battery can discharge fully in 2 to 3 months. The battery may
have discharged in the time it took for the computer to go from the factory to
you.

To attach the power cord:

1. Plug the AC adapter into the power connector on the back side of the computer.

2. Connect the power cord to the AC adapter and then to an electrical outlet.

AC Adapter

The battery starts charging as soon as you plug the power cord into an electrical outlet.
The battery charges faster if the computer is turned off during charging.

If the battery is fully depleted and the computer is turned off, the battery charges in
about 3 hours. If the computer is turned on, the battery charges in about 6 hours. When
the battery is charging, the battery charge light is red. When the battery is fully charged,
the light turns green.

See “Using Power Management Options” on page 46 for more information on using
your computer’s battery.

Using Your Computer for the First Time 7

Turning On the Computer

To turn on the computer’s power for the first time:

1. Slide the LCD latch, located on the front of the cover to the right.

2. Lift up the cover.

3. Press and then release the power button.

The power light is on when the computer’s power is on.

Power button

Adjusting the LCD Display

You may wish to adjust the LCD (Liquid-Crystal Display) when you begin using your
computer. A TFT (Thin-Film Transistor) LCD does not require adjustment for contrast
because the contrast is set to remain at maximum.

To adjust the LCD:

8 Users Manual

Cover Latch

Initial Computer Startup:

The first time you start your computer you will see the operating system
registration screens. Simply read each screen and follow the simple directions.
You must complete this process in order to use your computer. A tutorial is
provided if you require it.

Power Light

• Press <Fn+Right Arrow> to increase the display brightness.

• Press <Fn+Left Arrow> to decrease the display brightness.

Turning Off Your Computer

Prior to shutting down your computer ensure all of your data and current work are
saved. The system will ask if you wish to save any unsaved work, saving your work
first will speed the shutdown process.

To turn off the computer, complete the following steps:

1. Click on the taskbar.

If you need to restart your computer after software (re)installation or because it is not
responding select the Restart option in step 2 below.

2. Click Shut Down to display the shutdown popup window shown below..

3. Select Shut down.

4. Click OK.

Power Off:

If the system does not power off, then press and hold the power button for over
5 seconds. See “Using Power Management Options” on page 46.

Power Button Functions:

The power button has several functions other than just turning on and off your
computer, see “Using Power Management Options” on page 46.

You can also perform a soft boot by saving your files and pressing
<Ctrl+Alt+Del> to pop-up the “Windows Task Manager” window.
Click Shut Down > Restart.

You can perform a cold boot by pressing the power button for more than 5 seconds to
turn the computer off, waiting more than five seconds, and then pressing the power
button to turn the computer on. The system may perform some extra checks during the
restart.

Using Your Computer for the First Time 9

Tips for Using Your Computer

The following information helps you avoid potential problems as you use your
computer:

Do not try to disassemble your computer. Opening the system chassis voids
your warranty. Only an authorised manufacturer service center can replace or
add any parts inside the chassis.

• Follow all the instructions and cautions in your computer user documentation.

• The LCD has a polarized surface and can be damaged easily. To prevent

damage, avoid touching the screen.

• Use only approved AC adapters, auto adapters, memory modules and other

options.

• Because a notebook computer is small and has restricted air flow around

components, it is more likely to overheat than a desktop computer. A fan inside
your computer runs when needed to help eliminate heat. Make sure the fan vent
on the left side of your computer is not blocked when you use the computer.
Occasionally check the vents and remove any accumulated dust on the outside.

• Avoid using or storing the computer in extremely hot or cold areas, such as a

car on a hot day. Keep the computer away from heaters and out of direct
sunlight. Exposure to excessive heat may damage computer components. If you
have left your computer in a hot place, let it cool down slowly to room
temperature (with the LCD panel open) before using it.

10 Users Manual

• Do not remove the memory-module compartment door, or try to install a

memory module when the computer is on.
(For information on installing memory modules, see “Installing a Memory
Module” on page 58.)

• Set up your computer work area to avoid physical strain. Sit with your back

straight and supported by your chair. Adjust your chair or work table so that
your arms and wrists can remain in a relaxed position, parallel with the floor.
Avoid bending or twisting your wrists as you work. Your hands should “float”
slightly above the keyboard. Refer to a book on office ergonomics for more
information on setting up your work area.

• Take frequent breaks from working at the computer to rest your eyes and

stretch your muscles.

• Remember to save your data files frequently and to make backup copies of your

files.

Travelling with Your Computer

If you are travelling by air, follow these tips:

• Take the computer with you as carry-on luggage. Do not check the computer

with your baggage.

• Allow the computer and disks to go through the X-ray security devices. Do not

hand-carry disks through the walk-through metal detectors, which can cause
loss of data.

• Please collect your computer immediately after X-ray scanning, this is a high

theft area for portable computers.

• Make sure that the battery is charged or the power cord is easily accessible.

You may be required to turn on the computer for airport security personnel.

• Be prepared to turn off the computer during take off and landing.

Handling Spills

Do not spill anything on your computer. The best way to avoid spills is to avoid eating
and drinking around your computer. If you do spill something on your computer, turn
off your computer, unplug it immediately, and do the following:

• If you spill liquid on the keyboard, drain as much of the liquid from the

keyboard as possible. Be careful not to let the liquid drip onto the LCD panel.
Allow the system to dry for several days before trying to use it.

• If you spill liquid on an external keyboard or keypad, unplug it and drain as

much of the liquid as possible. Allow the keyboard to sit at room temperature
for a full day before trying to use it.

Sweet liquids leave a sticky residue that may jam the keyboard despite your
efforts to dry it.

• If you spill liquid on the LCD panel, clean it immediately with a soft cloth and

denatured alcohol or a proprietary LCD screen cleaner. Do not use water,
window cleaner, acetone, aromatic solvent, or dry, rough towels to clean it.

Some liquids damage the polarized LCD screen. If your screen is damaged,
contact your authorized manufacturer’s service center for a replacement.

Using Your Computer for the First Time 11

Storing the Computer for Long Periods

If possible, leave the power cord connected to the computer and an electrical outlet
when the computer is not in use. This extends the life of the battery and keeps the
battery fully charged.

If you will not be using the computer for a long period of time (a month or more), you
should charge the battery until it is completely full. After you have done so, remove the
battery from the unit.

12 Users Manual

Using the Keyboard

Your computer has an 87/88-key keyboard. By pressing designated key combinations,
you can have access to all the key functions of a full-sized keyboard.

Function & Special Purpose Keys

Embedded
Numeric Keypad

Cursor/Screen

Control Keys

Application Key

Although the layout of the keys on your computer’s keyboard is different from
that on a desktop computer’s keyboard, the keyboard feels like a full-sized
keyboard when you use it.

Windows KeyFunction Key

The keys on the keyboard can be grouped into the following categories:

• Full-sized Alphanumeric typewriter keys are arranged like a standard

typewriter keyboard and are used for text entry. The Windows keys on either
side of the spacebar open Windows menus and perform other special functions.

• Function keys, when pressed together with the <Fn> key, enable special

functions.

• Cursor and Screen control keys move the cursor. They may perform other

functions, depending on your software.

To clean the computer keyboard, use slightly damp cotton swabs. Scrub the keys and
the surface around the keys.

Using the Keyboard 13

Do not allow liquid to drip into the keyboard or you may damage the keyboard.

Using the Numeric Keypad

Your keyboard includes a numeric keypad, which is a group of keys that you can set to
type numbers and mathematical symbols, such as the plus sign. A number or symbol
on the right corner of each keypad key shows its numeric function.

Num Lock LED

Press <Num Lock> to turn on the embedded numeric keypad. The numeric functions
of the keypad are enabled and the Num Lock light turns on.

While the numeric functions are enabled, you can temporarily return a key to its normal
function by pressing <Fn> and the key. For example to type the letter m, press
<Fn+m>.

To turn the numeric keypad off, press <Num Lock> again. The Num Lock light turns
off.

14 Users Manual

Using Special Function Keys

The <Fn> key activates special functions when it is pressed in combination with
another key.

Table 2. Description of Special Function Keys

<Fn> Key
Combination

<Fn+F1> Print screen: Takes a picture of the open screen, which you can paste into the Paint

<Fn+F2> System request: Reserved for use in software programs.

<Fn+F5> CRT/LCD: Switches the display between the LCD, the external monitor, and

<Fn+F6> Gauge: Displays the battery gauge in the upper-right corner of your screen.

<Fn+F8> Mute: Turns the audio output on and off.

<Fn+F9> Volume down: Decreases the audio volume.

<Fn+F10> Volume up: Increases the audio volume.

<Fn+F11> Rest: Puts the computer into Suspend mode. To resume normal operation from rest,

<Fn+F12> Scroll: In some applications, sets the cursor-control keys to scroll the page up or

<Fn+Right
Arrow>

<Fn+Left Arrow> Brightness down: Decreases the LCD brightness.

Function

program.

simultaneous display on both the LCD and the external monitor.

The gauge closes in a few seconds, or you can press <Esc> to close the gauge.
(See “Monitoring the Battery Charge” on page 37 for more information on the battery
gauge.)

press the power button. (See “Using Power Management Options” on page 46 for
more information about the rest mode.)

down while the cursor position does not change. Pressing <Fn+F12> again turns off
the scrolling function.

Brightness up: Increases the LCD brightness.

When you press a function key combination, the system sound may be
temporarily muted.

Using the Keyboard 15

User Defined Buttons (SENS Keyboard)

You may program the three buttons to the left of the power button to start any program
you have installed on your computer.

User defined program

Outlook Express

Internet Explorer

The default settings for these buttons are:

Internet E-Mail - Outlook Windows Calculator

To reprogram the Sens Keyboard, follow the steps below:

1. Double-Click icon on the Windows taskbar, the Key Setting window is

displayed.

2. Select Button you wish to reprogram from the drop down menus in the Key

3. Use the Browse button to locate the program you wish to assign to the SENS

4. Click on your program choice to select it.

5. Click Open.

6. Click OK to close window and complete programming the Sens Keyboard.

16 Users Manual

Setting window.

Keyboard button selected.

Using the Touchpad

Your computer is equipped with a touchpad, which is an integrated-pointing device
that is used to perform standard mouse functions. The touchpad is an advanced and
reliable pointing device that works with a touch of your finger.

Touchpad

Mouse buttons

Scroll button

Press on the touchpad gently. The touchpad responds to light pressure.

Table 3. Using the Touchpad

Action Process and Comment

Click/Tap

Process

Depress the touchpad left button and release or position the pointer
over the object and Quickly tap the touchpad once with your finger.
This action is called clicking.

Comment

This will cause a process to begin or select an object on the screen.

Using the Touchpad 17

Action Process and Comment

Double-Click/Tap

Click-Hold

Right-Click

Scroll up

Process

Quickly click the left touchpad button two times or position the pointer
over the object and Quickly tap the touchpad twice with your finger.
This action is called Double-clicking.

Comment

This will cause a process to begin or open a file folder.

Process

Depress the left touchpad button and do not release.

Comment

This is used to move/drag objects to new locations. See “Drag (Move)”
on page 19.

Process

Position the pointer over the object. Quickly press and release the right
button once.
This action is called Right-clicking.

Comment

This is usually used to obtain information about an object or access a
short cut menu.

Process

Place your finger on the top half of the button to scroll up the current
window.

Comment
Moves the current window down.

Scroll down

18 Users Manual

Process

Place your finger on the bottom half of the button to scroll up the current
window.

Comment

Moves the current window up.

PS/2 Mouse:

You may change the setup in Setup > Advanced Menu
Disabled prevents both the touchpad and external PS/2 port from functioning.
Single mouse (default) enables the external PS/2 port or the touchpad, and
external PS/2 port has priority. Dual Mouse allows the use of both the
touchpad and PS/2 port.

Drag (Move)

To move a window on the desktop, complete the following:

1. Click the window title bar or icon in the bottom of the window which you want

to drag using the touchpad.

2. Press the left touchpad button and hold it.

3. Drag the window using the touchpad.

1

11 Click the Window
Title Bar and Hold

Cursor in Windows

Title Bar

2

22 Drag your finger to
move the window

Area or Multiple item selection:

The drag function may be used to select an area or multiple items in an area
by clicking in one area and then dragging to create a selection window. The
items inside the window will be selected.

Using the Touchpad 19

Reading the System Status Lights

System Status lights show the status of computer functions.

Table 4. System Status Lights

LED Name Function

Num Lock Changes a portion of the keyboard to a numeric keypad.

Caps Lock Changes all alpha or letter input into capital letters.

Scroll Lock Scroll lock in certain software.

Drive Access Using the Disk Drives.

E-mail Alert The Light comes on when e-mail arrives.

Power Green - System power on.

Battery
Status

See “Using the Numeric Keypad” on page 14.

No changes occur to numeric and special keys.

Blinking Green - HDD is being accessed
Blinking Amber - FDD or CD-ROM is being accessed

To use this function, you must register an E-mail Account in the
Register E-mail Account window. To register an E-mail account
Select: Start > Programs > StartUp > Internet Launcher.

Blinking - Standby mode.

Green - No battery pack installed/battery fully charged.
Red - Charging.

20 Users Manual

Connecting to the Internet

This section explains how to connect you to the internet. For details on how to establish
the connection contact the Internet Service Provider [ISP] or system administrator
[SysAdmin].

Using the Modem

Install the Modem cable by simply plugging the cable into the slot in the back of the
computer.

Modem Cable

(Minimum 26 AWG)

1. Contact your Internet Service Provider to obtain information or CD required to
make the connection in your area.

2. After the cable is connected create a “Dialup” connection by clicking Start >
Settings > Network and Dial-Up Connections.

3. Double-Click icon to pop up the connection wizard.

4. Follow the instructions in provided in the Make New Connection wizard.

Connecting to the Internet 21

Precautions Before Use

Country Selection

Country Selection:

Because your computer is very mobile you must ensure you select the country
you are calling from is selected correctly, otherwise you may experience

connection problems.

To change the country selection proceed as follows:

1. Click Start > Settings > Control Panel.

2. Click Phone and Modem Options.

3. Click on the connection you wish to edit in the Locations: box.

4. Click Edit

5. Select the Country/region you are calling from in the General tab.

6. Click OK to close the "Edit Locations" box.

7. Click OK to close “Phone and Modem Options” box.

Digital Phone Lines:

If you connect the modem to a digital phone line (such as a company
4-wire system), the modem may be damaged.

DOS support

Using the Modem on a PBX system

If you use a Windows Communication Program:

1. Click Start > Settings > Control Panel.

2. Click Phone and Modem Options.

3. Click Properties in the Modems tab section.

4. Check off “Wait for dial tone before dialing” check box in the Modem tab

5. Click OK to close the dialog box.

6. Click OK to close “Modem Properties” dialog box.

22 Users Manual

• Windows 2000:Does not support pure DOS mode

support a DOS box in Windows. So you cannot use a
communication application which runs under DOS.

section.

and the modem does not

If you use a simple terminal program (i.e. hyper terminal):

Type the “ATX3&W” or “ATX3” command as an initialization command.

MODEM Notes:

1. In order to use the 56K feature, be sure to check if the standards supported
by the on-line service provider and the modem are identical.

2. If you use a PBX phone system, you can not connect using the 56K mode.

3. Internationally connected calls will be limited to 33.6K (Max.)

Using the LAN

You may connect to the network using either a LAN cable or by establishing a wireless
connection if factory option is installed..

Cable Connection

Install the LAN cable by simply plugging the cable into the slot in the right side of the
computer.

Your computer’s LAN adapter is ready to use for most situations, however if your
system does not have a DHCP server or you wish to personally configure your LAN
connection, proceed as outlined in “Configuring Network Environment” below.

Connecting to the Internet 23

Network Protocols:

You may need to consult your SysAdmin if their network protocols and settings
are required for your LAN environment.

Configuring Network Environment

Configure the Network Adapter as follows:

1. Click Start > Settings > Control Panel.

2. Double-Click Network and Dial-up Connections.

3. Right Click Local Area Connection > Properties.

4. Select Internet Protocol (TCP/IP) and click properties.

5. Select Use the following IP Address: then enter your IP address, Subnet mask
and Default gateway. If you use DHCP server, select Obtain an IP address
automatically.

6. Select Use the following DNS server address: and enter the address in the
Preferred DNS server and Alternate DNS server. If you use DHCP server,select
Obtain DNS server address automatically.

7. Click OK when you finish the TCP/IP setup.

Wireless Connection

If this factory option is installed, see the users manual included with the option to setup
and establish your connection. You should also consult your system administrator for
any questions you may have.

24 Users Manual

Using the Flex-Bay

The Flex-Bay provides an impressive array of secondary
storage devices listed below:

CD-ROM drive:

Shipped with some computers is also an available option.

CD-ROM R/W drive:

Shipped with some computers is also an available option.

DVD-ROM drive:

Shipped with some computers is also an available option.

DVD/CD-RW Combo drive:

Shipped with some computers is also an available option.

Optional secondary hard drive:

Available as an option for your computer.

Superdisk LS-120:

Available as an option for your computer

Second Battery:

Available as an option for your computer.

If your operating system is Windows, you can use the Bay Manager Utility to
hot-swap the devices. If you do not use Windows, make sure that the
computer’s power is off before you remove or install any devices.

Remove/Install a Flex-Bay Device - Power On

You can use the Softex Bay Manager utility to hot-swap your devices in the flex-bay.

To start the Softex Bay Manager utility:

1. Click Start > Settings > Control Panel > Softex Bay Manager.

- or -

2. Double-Click the Softex BayManager icon in the windows taskbar.

Using the Flex-Bay 25

To remove a device:

1. Start the Softex Bay Manager Utility.

You do not have to turn the computer over or tip it on its side to change
devices. Simply tilt the computer up at the front about 10 cm and locate the
Flex-Bay latch. See Figure below for the location of the Flex-Bay latch. The
computer in the figure is tilted on its side for clarity.

Flex-Bay Latch

2. Click Remove / Swap. A Device Change popup window stating, “Please wait until

3. Tilt the computer up & locate the smart bay latch.

4. Slide and hold the device latch toward the front of the computer.

5. Slide the device out.

6. Click OK. The message “Please wait until the system processes the device change”

7. Click OK to close the Softex Bay Manager Utility.

26 Users Manual

the system processes the device change” appears then another popup window
appears and says, “Please remove or swap your bay device(s) now and press OK.”

appears again.

To insert a device:

1. Open the Softex Bay Manager Utility.

You do not have to turn the computer over to change devices. Simply tilt the
computer up and locate the Flex-Bay latch. See “Bottom” on page 5 for the
location of the Flex-Bay latch.

2. Click Device Insert. A popup window appears stating “Please insert your device(s)
into the bay now and click OK.”

3. Insert the device.

4. Click OK to allow your computer to detect the device. The message “Please wait

until the system processes the device change” appears.

5. Click OK to close the Softex Bay Manager Utility.

Remove/Install a Flex-Bay Device - Power Off

Remove a Device:

1. Turn the computer’s power off.

2. Close the LCD panel, and turn the computer over so that the bottom of the unit

faces up.

3. Tilt the computer up & locate the smart bay latch.

4. Slide and hold the device latch toward the front of the computer.

5. Slide the device out.

Install a Device:

1. Turn the computer’s power off.

2. Carefully slide the device into the bay.

3. Push the device in until it is flush with the chassis and the Flex-Bay latch snaps

into place. Your computer’s operating system automatically recognizes the device
in the Flex-Bay and configures your computer accordingly when power is restored.

Using the Flex-Bay 27

Using the Disk Drives

Using the Floppy Disk Drive

Your computer comes with a 1.44 MB, 3.5-inch, floppy drive.

To use a floppy disk in your computer, insert it into the floppy drive.

Floppy Disk Eject Button

To remove a floppy disk, press the floppy disk eject button on the front of the floppy
drive.

To protect the data on your floppy disks, follow the manufacturers guidelines.

28 Users Manual

Using the CD/DVD-ROM Drive

Compact discs are designed so that you can easily insert one into the computer when
you need it, and then remove it. See “Using the Flex-Bay” on page 25 for information
on installing the DVD-ROM drive into the computer.

DVD Notes:

A DVD player is a factory option and if you ordered this option you will have to
install the provided DVD software to view the DVD Title.

1. Press the button on the CD-ROM or DVD-ROM drive, and the tray slides out.
(Do not lean on the tray; because it will not support much weight.)

CD/DVD Drive Warnings:

Do not place reflective objects other than the CD/DVD disks in the disk slot
because of possible hazardous laser emissions. The laser beam used in this
CD/DVD-ROM drive is harmful to the eyes. Do not attempt to disassemble the
CD/DVD-ROM drive. Refer servicing to your authorized service center.

Do not touch the CD/DVD lens, doing so may damage the device.

CD/DVD Precautions:

The tray may be stuck, in which case straighten out a paper clip, insert
it into the Emergency Eject hole in the front of the CD/DVD-ROM and push it
until the tray ejects.

A LED on the drive tray is on when the computer is reading from a CD. Do not
remove a disc when this LED is on.

To clean a CD/DVD, wipe from the center outwards with clean and dry cloth.
Remove the CD/DVD when the drive activity LED is off.

2. Insert a CD/DVD, label side up (or remove a disc, if you have finished using it).

Using the Disk Drives 29

3. Push the tray in gently to close the drive tray.

Emergency eject button

Eject Button

CD-ROM Light

Install and/or start a CD-based program as you would run a program on a floppy disk.

30 Users Manual

Working with PC Cards

When you install PC Cards, you can add a multitude of functions to your notebook
computer similar to those found on add-in boards for desktop computers. There are
many PC Cards on the market, the supported PC Cards are listed below:

• Input/output, such as modem, network, video capture, and SCSI cards.

• Storage, such as hard drive and flash memory cards.

Your computer includes the following PC Card support:

• Two PC-Card slots: You can install Type I, II, or III cards in the slots.

TYPE III Cards:

Type III cards are thicker than Types I and II. If you install a Type III card in the
bottom slot, you cannot install a card in the top slot.

• CardBus hardware and software: CardBus enables the computer to use 32-bit

PC Cards. Windows 2000 supports 32-bit and 16-bit PC Cards.

• Zoomed video: Both PC Card slots and the video chip on your computer

support zoomed video. When you install a zoom video PC Card in the upper or
lower slot, data can be transferred directly from the PC Card to video and audio
systems without going through the microprocessor. Video conferencing and
real-time multimedia devices, such as video cameras, are supported by zoomed
video.

Maintaining PC Cards

To maintain your PC Cards, follow these guidelines:

• Keep cards away from excessive heat, direct sunlight, and liquids.

• Do not drop, bend, flex, or crush cards when handling.

• Keep dust, magnets, and static electricity away from PC Cards.

• When a card is not in use, carry it in its protective carrying case.

• Some PC Cards include cables that extend from the back of the cards. Be

careful not to bend or put excessive strain on these cables.

Working with PC Cards 31

Using PC Cards

To insert a PC Card into a slot:

1. Push the slot door in with the PC Card.

2. Align the card with a slot and insert the card into the slot until it locks in place.

PC Card Eject Buttons

PC Card: (Example)
Insert PC Card with product
information facing up

Windows automatically assigns computer resources (such as communication ports and
memory addresses) to a PC Card installed in your computer.

To remove a PC Card from your computer:

Use the following procedures to remove PC Cards, or you may lose data that
is being stored to a card.

1. Click icon on the taskbar.

2. Select the card currently in use, and click the Stop button.

The eject button for the card slot operates in two steps, therefore to remove a PC Card:

3. Push the eject button once to pop it outward then push the eject button again to

4. Pull the card out of the PC Card slot.

32 Users Manual

PC Card Eject Buttons

eject the card.

Multi Media Functions/Equipment

Media Player

You can play video and audio CD files with the Windows Media Player, as well as
watching TV, video and listening to the radio through internet. The on-board audio
hardware and software of your computer enable the computer to play audio/video
compact discs. The instructions to play a video CD-ROM are the same as the
instructions for the audio CD below. If you wish to do so, you can attach external
speakers to the Headphone jack.

Playing a Audio/Multimedia CD

To play an CD follow the instructions below:

1. Insert a compact disc into your CD-ROM drive.

2. Press the button on the CD-ROM drive to open the CD-ROM device.

3. Insert a CD, label side up.

4. Carefully push the tray in to close the drive tray. The Windows Media Player

button appears on the taskbar if not already there, and the music begins to play. If
the disk does not play click Start > Programs > Accessories > Entertainment >
Windows Media Player.

CD LED On:

A LED on the drive tray is on when the computer is reading from a CD. Do not
remove a disc when this LED is on.

Removing the Audio/Multimedia CD

To remove the CD follow the instructions below:

1. Click Start > Programs > Accessories > Entertainment > Windows Media
Player to open the Windows Media Player window, if not already open.

2. Click Stop in the Windows Media Player window or simply close the Windows

media player.

3. Press the button on your CD-ROM drive. The drive tray opens and you can remove
the CD from the CD-ROM drive.

4. For more information on playing compact discs, see the Help menu in the
Windows Media Player window.

Multi Media Functions/Equipment 33
