Samsung SRD-443 User Manual

4 CHANNEL DVR

User Manual

SRD-443

4 Channel DVR

User Manual

Copyright

©2013 Samsung Techwin Co., Ltd. All rights reserved.

Trademark

The name of this product is the registered trademark of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their respective company.

Restriction

Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall be reproduced,
distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.

Disclaimer

Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be
provided. Use of this document and the subsequent results shall be entirely on the user's own responsibility. Samsung Techwin reserves the
right to change the contents of this document without prior notice.

Design and specifications are subject to change without prior notice.

The default administrator ID is “admin”, and the password must be set when the user log in at the first time.

Set password for your wireless net work if you use the pr oduct with a wireless router. Being not protec ted with password or using the
default wireless router password may expose your video data to potential threat.
To prevent from your per sonal information being exposed, please change your password every 3 months. Note that the security and
other related issues caused by careless management of password shall be be in the charge of the user.

is the registered logo of S amsung Techwin Co., Ltd.

overview

IMPORTANT SAFETY INSTRUCTIONS

Read these operating instructions carefully before using the unit.
Follow all the safety instructions listed below.
Keep these operating instructions handy for future reference.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. if the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from
tip-over.

13) Unplug this apparatus during lightning storms or when unused for long
periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.

! OVERVIEW

BEFORE START

This user manual provides Information for using the DVR such as brief introduction, part names, functions, connection
to other equipment, menu setup, etc.
You have to keep in mind the following notices :

• SAMSUNG retains the copyright on this manual.

• This manual cannot be copied without SAMSUNG’s prior written approval.

• We are not liable for any or all losses to the product incurred by your use of non-standard product or violation of

instructions mentioned in this manual.

• Prior to opening the case, please consult a qualified technician first. Whenever this is needed power must be
removed from the unit.

• Before installing an additional HDD or connecting an external storage device (USB memory or USB HDD) to this
DVR, check the compatibility. Consult your provider for the compatibility list.

English _3

overview

Warning

Battery

It is essential that when changing the battery in the unit, the replacement battery must be of the same type
otherwise there may be a possibility of an explosion.
The following are the specifications of the battery you are using now.

• Normal voltage : 3V

• Normal capacity : 170mAh

• Continuous standard load : 0.2mA

• Operating temperature : -20°C ~ +85°C

(-4°F ~ +185°F)

Caution

• Connect the power cord into a grounded outlet.

• The Mains plug is used as a disconnect device and shall stay readily operable at any time.

• Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

• Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the

Instructions.

System Shutdown

Turning off the power while the product is in operation, or undertaking improper actions may cause damage
or malfunction to the hard drive or the product.
Please turn off power by pressing the [POWER] button on the remote control or right-click to display the
context sensitive menu and select <Shutdown>.
For a safe power disconnection, select <OK> in the system shutdown dialog before unplugging the power cord.
You may want to install a UPS system for safe operation in order to prevent damage caused by an
unexpected power stoppage. (Any questions concerning UPS, consult your UPS retailer.)

CALIFORNIA USA ONLY

This Perchlorate warning applies only to primary CR (Manganese Dioxide)
Lithium coin cells in the product sold or distributed ONLY in California USA.

“Perchlorate Material - special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.”

Operating Temperature

The guaranteed operating temperature range of this product is 0°C ~ 40°C (32°F ~ 104°F).
This product may not work properly if you run right after a long period of storage at a temperature below the
guaranteed one.
Prior to using a device that has been stored for a long period in low temperatures, allow the product to stand
at room temperature for a period.
Especially for the built-in HDD in the product, its guaranteed temperature range is 5°C ~ 55°C (41°F ~ 131°F).
Likewise, the hard drive may not work at a temperature below the guaranteed one.

Security Precautions

The default administrator ID is “admin”, and the password must be set when the user log in at the first time.
Set password for your wireless network if you use the product with a wireless router. Being not protected with
password or using the default wireless router password may expose your video data to potential threat.
To prevent from your personal information being exposed, please change your password every 3 months.
Note that the security and other related issues caused by careless management of password shall be be in the
charge of the user.

4_ overview

CONTENTS

OVERVIEW

3

CONNECTING WITH OTHER DEVICE

12

LIVE

17

3 Important Safety Instructions
3 Before Start
5 Contents
7 Features
9 Part Names and Functions (Front)
10 Part Names and Functions (Rear)
11 Remote Control

12 Installation
12 Checking the installation environment
13 Connecting the Video, Audio, and Monitor
13 Connecting the USB
14 Connecting the Alarm Input/Output
14 Connecting the RS-485 Device
15 Connecting the Network

17 Getting Started
19 Live Screen Configuration
23 Live Mode
25 Spot Out
25 Zoom
26 Audio ON/OFF
26 Freeze
26 Event Monitoring

! OVERVIEW

USING THE DVR

28

28 System Setup
38 Setting the Device
45 Setting the Recording
48 Setting the Event
51 Backup
52 Network Configuration
63 Controlling a PTZ device

English _5

overview

SEARCH & PLAY

65

WEB VIEWER

70

BACKUP VIEWER

98

65 Search
68 Playback

70 Introducing Web Viewer
71 Connecting Web Viewer(Windows)
72 Using Live Viewer(Windows)
78 Using Search Viewer
82 Viewer Setup
93 About
94 Connecting Web Viewer(Mac)
95 Using Live Viewer(Mac)
97 Mobile Viewer

98 SEC Backup Viewer

APPENDIX

100

100 Product Specification
102 Product Overview
103 Default Setting
106 Troubleshooting
109 Open Source License Report on the Product

6_ overview

FEATURES

The DVR employs H.264 video encoding for 4 channel inputs and audio encoding for 1 channel while simultaneously
supports hard disc recording and playback.
These DVRs also supports network connectivity, providing remote monitoring from a remote PC transferring video
and audio data.

• Provides a convenient User Interface

• Supports CIF(S)/2CIF(M)/4CIF(L) recording formats

• With the network specific codec, network transfer enabled regardless of the recording conditions

• De-interlacing processor for better picture quality

• Display of HDD information and status by using HDD SMART

• Hard Disk overwrite function

• Mass storage hard disk backup through high-speed USB 2.0

• Simultaneous Record and Playback of 4 channel video data

• Various Search Modes (Time, Event, Backup, Motion Detection)

• Various Recording Modes (Time Lapse, Event, Scheduled Recording)

• Alarm Interface

• Remote Monitoring function by Network Viewer, Smart Viewer and Mobile Viewer

! OVERVIEW

English _7

overview

Standards Approvals

`

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15

M

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.

Package Contents

Please unwrap the product, and place the product on a flat place or in the place to be installed.
Check if the main unit and all the following accessories are included in the product package.

POWER

REC

DIGITAL VIDEO RECORDER SRD-443

DVR Power Cable

Remote Control / Battery (AAA x 2) Quick Manual User Manual CD

Network Viewer Software

Mouse

8_ overview

PART NAMES AND FUNCTIONS (FRONT)

REC

a

POWER

Part Names Functions

Power LED : Displays the power ON/OFF status.

LED Indicator

a

REC : Lights on when recording is in progress.

DIGITAL VIDEO RECORDER SRD-443

! OVERVIEW

English _9

overview

PART NAMES AND FUNCTIONS (REAR)

a

IN1 IN2

IN3 IN4

AUDIO IN

b c d

VIDEO OUT
(SPOT)

CH1 CH2

CH3 CH4

VIDEO IN

USB

AUDIO OUT

LAN

USB

hi

e

VGA

1 2 3 4 G

ALARM IN ALARM OUT RS-485

G

COM

1

+ -

DC 12V

fg

Part Names Functions

AUDIO IN (1~4) Input ports (RCA jacks) for the audio signal.

a

VIDEO IN Input port for the composite video signal.

b

VIDEO OUT(SPOT) BNC type of output port for the composite video signal.

c

LAN NETWORK connector port.

d

VGA Output port for VGA video signal.

e
f

g

h
i

`

M

`

10_ overview

DC 12V DVR power input port.

ALARM IN 1~4, G : Alarm Input port.

ALARM OUT 1, COM : Alarm Output port.

RS-485 Used to establish RS-485 communications.

USB USB connector port.

AUDIO OUT Output port (RCA jack) for the audio signal.

If you want to change the default output to VGA mode when the live screen is displayed with the beep after the
system booting, press the remote control buttons in sequence: [FREEZE]  [VIEW]  [RETURN ( )] 
[FREEZE]  [VIEW]  [RETURN (

)]. The DVR will switch to VGA mode with the beep after rebooting.

For more information about monitor output, refer to “Video Output”. (Page 43)

REMOTE CONTROL

Displays the search menu.

Changes the screen mode.

Displays the Exit pop up screen.

Used as the numeric input keys, or displays a single

Skip Backward (by unit time),

Slow Rewind, Slow Forward,

Skip Forward (by unit time)

Goes to the system menu screen.

Up/Down/Left/Right($%_ +)/ENTER

Moves the cursor up/down/left/right, and runs the

Freezes the screen temporarily.

Runs the digital zoom (x2) function.

Starts or ends the live recording.

Runs the View function in the PTZ mode.

SEARCH

MODE

POWER

NUMBER [0~+10]

channel.

T/W

Zooms in or out.

MENU

Select Menu.

FREEZE

ZOOM

REC

VIEW

BACKUP

Displays the Backup Menu.

DVR

Activates the DVR function.

ID

Sets the ID of the system.
Select 2 digits from 0 ~ 9 while pressing the ID Key.

Move Frame

While paused, moves to the previous/next frame.

FR, STOP, PLAY/PAUSE, FF

PTZ

Displays or ends PTZ.

SCROLL ,.

Moves the menu scroll.

RETURN

Returns to the previous screen.

AUDIO

Turns Audio on/off.

ALARM

Cancels the Alarm.

REC LOCK

Selects the recording lock function.

PRESET

Displays the Preset Setup.

! OVERVIEW

Using the Numeric buttons

1. Press any button among 1 to 4.

2. Move to the selected channel number.

Changing the Remote Control ID

1. Press the ID button of the remote control and check the ID displayed on the DVR screen.

The factory default ID of the remote control is 00.

2. Enter 2 digits of your selection in order, while pressing the system [ID] button.

3. When ID input is done, press the system [ID] button again to check the setting.

`

If you want to change the remote control ID to 08: Press 0 and 8 in order while the system [ID] button is pressed.

M

Remote control's ID and DVR’s ID should be matched for proper operation. Refer to “Remote Devices”. (Page 42)

English _11

connecting with other device

INSTALLATION

Please take note of the followings before using this product.

• Do not use the product outdoor.

• Do not spill water or liquid in the connection part of the product.

• Do not impose the system to excessive shock or force.

• Do not pull out the power plug forcefully.

• Do not disassemble the product on your own.

• Do not exceed the rated input/output range.

• Use a certified power cord only.

• For the product with an input ground, use a grounded power plug.

CHECKING THE INSTALLATION ENVIRONMENT

Samsung Digital Video Recorder (“DVR” hereinafter) is a
state-of-art security device, and contains mass storage hard
disk(s) and critical circuits inside.

When the temperature rises inside the product, the product
may breakdown and the product life be shortened.

Temperature
Unit: ºC

One Year: 24HR X 365 DAY =8,760 HR

Life (Unit: HOURS)

12_ connecting with other device

CONNECTING THE VIDEO, AUDIO, AND MONITOR

IN1 IN2

IN3 IN4

AUDIO IN

`

Only one mouse port is available.

M

CH1 CH2

CH3 CH4

VIDEO IN

VIDEO OUT
(SPOT)

AUDIO OUT

LAN

USB

USB

VGA

1 2 3 4 G

G

COM

1

ALARM IN ALARM OUT RS-485

+ -

DC 12V

CONNECTING THE USB

1. By factory default, two USB ports are provided for external connection.

2. You can connect a USB HDD, USB memory or mouse to the USB port.

If a USB HDD is connected to the system, recognition and settings are available in “Menu > Setting the Device >

3.

Storage Device”. (Page 40)

4. This product supports hot-plugging, which connects/removes the USB device during the system operation.

! CONNECTING WITH OTHER DEVICE

`

If you use the USB device for Backup purposes, format it with FAT32 on PC if it is not formatted on the DVR.

J

English _13

connecting with other device

CH4

AUDIO OUT

1

234

G

COM

G

1

ALARM OUT

CH4

AUDIO OUT

3

G

COM

G

ALARM IN

ALARM OUT

CONNECTING THE ALARM INPUT/OUTPUT

Connecting the alarm input signal

Connection port for the alarm input signal.

Connect one strand of the sensor signal line to one of 4
strands of the alarm input port, and connect the other strand
to the [G] port.

Connecting the alarm output signal

Connection port for the alarm output signal.

Connect one strand of the sensor signal line to the alarm
output port and connect the other to the [COM] port.

• ALARM IN : 5mA sink

• ALARM OUT : 24V DC 1A, 125VAC/0.5A

CONNECTING THE RS-485 DEVICE

Connect the rear [RS-485 +, –] port to the PTZ camera or system
keyboard.

`

You can connect and control the PTZ camera which supports

M

the RS485 communication.

`

Check if the RS-485 device is compatible with the product
first.

`

Pay attention not to change the polarity (+/-) of the
RS-485 device when connecting it.

`

Depending on camera’s type, connection polarity can be
different.
For further information, refer to the respective PTZ Camera’s
documentation.

VIDEO OUT
(SPOT)

CH2

USB

CH4

AUDIO OUT

1 2 3 4 G

ALARM IN ALARM OUT RS-485

VIDEO OUT
(SPOT)

CH2

USB

CH4

AUDIO OUT

1 2 3 4 G

ALARM IN ALARM OUT RS-485

LAN

USB

LAN

USB

VGA

1 2 3 4 G

G

COM

1

ALARM IN ALARM OUT RS-485

COM

1

VGA

1 2 3 4 G

G

COM

1

ALARM IN ALARM OUT RS-485

COM

1

+ -

DC 12V

G

+ -

+ -

DC 12V

G

+ -

14_ connecting with other device

CONNECTING THE NETWORK

Connecting to Network through Ethernet (10/100BaseT)

IN1 IN2

IN3 IN4

AUDIO IN

CH1 CH2

CH3 CH4

VIDEO IN

VIDEO OUT
(SPOT)

AUDIO OUT

LAN

USB

USB

VGA

1 2 3 4 G

G

COM

1

ALARM IN ALARM OUT RS-485

+ -

DC 12V

RJ-45 Ethernet Cable
(Direct Cable)

NETWORK

Back Bone

Hub/Switcher

Hub/Switcher

Windows
Network Viewer

Connecting to the Network using the router

VIDEO OUT

IN1 IN2

IN3 IN4

AUDIO IN

CH1 CH2

CH3 CH4

VIDEO IN

(SPOT)

AUDIO OUT

LAN

USB

USB

VGA

1 2 3 4 G

COM

1

ALARM IN ALARM OUT RS-485

G

+ -

DC 12V

! CONNECTING WITH OTHER DEVICE

Broadband Router

xDSL or Cable

Modem

NETWORK

xDSL or Cable

Modem

External Remote PC

DDNS Server

(Data Center)

English _15

connecting with other device

Connecting to Network through ADSL

VIDEO OUT
(SPOT)

LAN

VGA

NETWORK

Hub/Switcher

IN1 IN2

IN3 IN4

AUDIO IN

Phone(ADSL) Line

CH1 CH2

CH3 CH4

VIDEO IN

AUDIO OUT

USB

USB

ADSL MODEM

1 2 3 4 G

G

+ -

DC 12V

COM

1

ALARM IN ALARM OUT RS-485

RJ-45 Ethernet Cable
(Direct Cable)

Windows
Network Viewer

16_ connecting with other device

live

2013-01-01
01:10:25

2013-01-01 01:10:25

2013-01-01 01:10:25

GETTING STARTED

Starting the system

1. Connect the power cable of the DVR to the wall outlet.

`

It takes about 10 seconds to display the start screen after

M

booting.

2. You will see the initialization screen.

The initialization process will last about 1 minute.
If a new HDD is installed, the initialization process may
take longer.

3. The live screen appears with a beep.

Shutting Down the System

! LIVE

REC

You can shut down the system only if you have logged into the DVR.
You require permission to shut down the system if you are not logged in as admin.

1. Press the [POWER] button on the remote control or

right-click to display the context sensitive menu and select
<Shutdown>.

2. The “Shutdown” confirmation window appears.

3. Use the arrow keys on the remote control to move to

<OK> and press the [ENTER] button or click <OK>.
The system will shut down.

4. Disconnecting the power cable for power off and

reconnecting the power cable to restart.

`

For the permission management, refer to “Permission Management > Setting Permissions”. (Page 33)

M

Shutdown

Are you sure to shutdown?

OK Cancel

English _17

live

2013-01-01 01:10:25

2013-01-01 01:10:25

2013-01-01 01:10:25

Login

To access a DVR or restricted menu, you should have logged in to the DVR.

1. In live mode, right-click any area of the screen.

You will see the context sensitive menu as in the right
figure.

2. Click <Login>.

The login dialog appears.
You can also see the login dialog to access a desired menu
by pressing the [MENU] button on the remote control.

`

The login dialog will also appear if you press a menu button on
the remote control of the DVR when the corresponding menu
requires logging in.

`

After logged in, press [RETURN] on the remote control to display
the logout dialog.

Login

ID admin



Password



OK Cancel

Scene Mode

Spot Out

Audio Off

Freeze

Stop Alarm

Record

Play

Search

Backup

Main Menu

Shutdown

Hide Launcher

Login





` The default administrator ID is “admin”, and the password must be set when the user log in at the first time.

J

` Set password for your wireless network if you use the product with a wireless router. Being not protected with password or

using the default wireless router password may expose your video data to potential threat.

` To prevent from your personal information being exposed, please change your password every 3 months.

` Note that the security and other related issues caused by careless management of password shall be be in the charge of the

user.

`

For the restricted permission, refer to “Permission Management > Setting Permissions”. (Page 33)

M

Locking All Buttons

This will restrict access to all buttons available in the DVR.

1. In Live mode, press the remote control buttons in the order
of [STOP (@)]
[MENU].

2. In the lock condition, press any button to display a dialog
where you are prompted to enter the password for
unlocking the buttons.
The button lock will be released if you enter the admin
password.

[FREEZE]  [STOP (@)]  [FREEZE] 



Key Lock Password

ID admin



Password



OK Cancel

18_ live

LIVE SCREEN CONFIGURATION

Icons on the Live Screen

You can check the status or operation of the DVR with the icons on the live screen.

a
b

c

System Operation

d

Video Input Status

e

2013-01-01 00:00:01

CAM 01

Name Description

Current Date, Time

Login Information

Screen Mode

Displays the current time and date.

When you are logged in, the “LOG ON” icon will be displayed.

Displayed if the zoom function is activated.

Displayed if you press the Pause button.

Displayed in Auto Sequence mode where all channels are switched at the
specific time interval.

This icon is displayed if a user with restricted access to the Record button tries
to make manual recording.

`

Only the user with the applicable permission can release (stop) the recording.

Displayed if the HDD is full and the DVR has an insufficient space to record.

Displayed if no HDD is installed or the existing HDD should be replaced.

Displayed if the HDD needs a technical examination.

Displayed while the backup is in process or if the backup data is played.

Displayed if the firmware can be updated via the network.

Displayed if no input is entered in the condition that the camera is set to <ON>.

Nothing will be displayed on the screen if the camera is set to <OFF>.

! LIVE

f

g

Camera Name/ Channel

Camera Operation

Displays the camera name and the changed channel, if any.

Displays the resolution of the recording screen. (Page 46)

Displayed in PTZ setting, and highlighted yellow if PTZ is in operation.

Displays AUDIO ON/MUTE.
Not displayed in video mode if deactivated.

If the sensor is set to <ON>, the input signal will be displayed on the screen of
the connected channel.

Displayed if a motion detected in the condition that the motion detection is set to
<ON>.

Displays the current record mode from Record/Event/Schedule.

English _19

live

2013-01-01 01:10:25

2013-01-01 01:10:25

2013-01-01 01:10:25

Error Information

• If the internal HDD is not connected, the “NO HDD”( ) message will appear; if there occurs a problem,

you will see the “HDD FAIL”(
service center for assistance as this may cause a failure of recording, playback or backup.

`

If you see the No HDD, HDD FAIL icons on the screen, contact the service center for more details.

M

Live Screen Menu

In addition to the buttons the remote control, you can access a desired menu by right-clicking the mouse any
area in live mode.
The context sensitive menu that appears by right-clicking the screen may differ, depending on the login/logout,
screen split mode and DVR operation mode.

`

Menu items of Search, Record, Backup, Shutdown can be deactivated, depending on the user permission.

M

) message in the top left corner. In this case, make sure you contact the

Scene Mode

Spot Out

Audio Off

Freeze

Stop Alarm

Record

Play

Search

Backup

Main Menu

Shutdown

Hide Launcher

Logout





Scene Mode

Spot Out

PTZ Control

Zoom In

Audio

Freeze

Stop Alarm

Record

Play

Search

Backup

Main Menu

Shutdown

Hide Launcher

Logout





< Split Mode Menu >

< Single Mode Menu >

Split Mode Menu

The context sensitive menu in split mode differs, depending on the login/logout status.

Scene Mode

Spot Out

Audio Off

Freeze

Stop Alarm

Record

Play

Search

Backup

Main Menu

Shutdown

Hide Launcher

Logout





13

20_ live

12

11

10

1

2

3

4

5

6

7

8

9

Menu Description

2013-01-01 01:10:25

Scene Mode Refer to “Live Mode”. (Page 23)

a

Spot Out Refer to “Spot Out”. (Page 25)

b

Audio On/Off Refer to “Audio ON/OFF”. (Page 26)

c

Freeze Refer to “Freeze”. (Page 26)

d

Stop Alarm

e

Record/Stop Starts/stops the standard recording.

f

Play Refer to “Search & Play > Play”. (Page 68)

g

Search Refer to “Search & Play > Search”. (Page 65)

h

Backup Refer to “Using the DVR > Setting the Backup”. (Page 51)

i

Main Menu Accesses the main menu. Refer to the Using the DVR section. (Page 28)

j

Stop the alarm output, deactivate the event icon and release the auto sequencing.
Refer to “Event Monitoring”. (Page 26)

! LIVE

Shutdown

k

Show/Hide Launcher

l

Login/Logout You can log in or out.

m

Turns down the DVR.

Shows or hides the launcher. Refer to “View the Launcher Menu”. (Page 22)

Single Mode Menu

The single mode menu is available only in Single Mode.
The context sensitive menu for the One Channel mode, in Split mode is different from that of the Single mode.

1

2

3

Menu Description

Full Screen

Spot Out

PTZ Control

Zoom In

Audio

Freeze

Stop Alarm

Record

Play

Shutdown

Hide Launcher

Logout



Full Screen

a

PTZ Control

b

Zoom In

c

Select and click a desired channel in Split mode to switch to the full screen of the selected
channel.

Accesses the PTZ Control menu.
The PTZ menu will be active on Live screen if you select a single channel.

Enlarges the selected image. (Page 25)

(Page 63)

English _21

live

2013-01-01
01:10:25

2013-01-01 01:10:25

2013-01-01
01:10:25

2013-01-01
01:10:25

2013-01-01
01:10:25

View the Launcher Menu

The Launcher menu appears on the bottom of the live screen.

1. In Live mode, right-click to display the context menu and
select <Show Launcher>.

2. Move the cursor to the bottom and click a desired item in
the Launcher menu.

`

If no input is entered for 10 seconds, the menu will disappear.

M

`

The Launcher menu can be accessed only by using the mouse.

PTZgAlarmhFreeze

a

Date/Time

a

Screen Mode Press this button to switch the screen mode in sequence.

b

Menu Expansion Button Click to display the hidden menu to the right.

c

Audio Turns ON/MUTE the sound of the selected channel.

d

Zoom Enlarges the selected area. This is available only in Single Live mode.

e

PTZ Runs the PTZ Control launcher.

f

Alarm Stops the alarm if it's activated.

g

Freeze Freezes the Live screen temporarily.

h

Play Enters Play mode if a file to play exist, and if not, enters Search mode.

i

Record Start/End recording the Live screen.

j

b

Menu Description

c d e ij

Displays the current time and date.
The indication of AM/PM is displayed if you set 12 hours for the time format in
“System > Date/Time/Language > Time”. (Page 28)

f

22_ live

LIVE MODE

CH1 CH2

CH3 CH4

CH1 CH2

CH4 CH2

CH3 CH1

CH1

CH3 CH1

CH1

CH2

CH1

CH1

CH2

CH1

CH2

Displays 4 live video images in 3 different modes.

Switching the screen mode

To switch the split mode, select a screen mode in the launcher menu, or right-click to select a screen mode in
the context menu.
Press the [MODE] button on the remote control to switch the mode in the sequence of the launcher menu
items.

! LIVE

CH1 CH2

CH3 CH4

;

CH1

CH2

;

CH1

4-split mode PIP Auto Sequence

Switching the screen automatically

With SRD-443 you can display 4 live single screens in sequence.

CH1

CH1

CH1

CH1

Single mode

`

In Single mode, If you have set <SEQ-Dwell Time> in “Setting the Device > Camera”, Auto Sequence will be

M

conducted at the set interval. (Page 38)

1

4

English _23

live

CH1

CH1

CH2

CH1 CH2

CH3 CH4

CH3 CH1

CH1

CH3 CH1

CH1

CH2

CH1

CH1

CH2

CH1

CH1

CH1

CH2

Channel Setting

You can display the channel in a desired area of a split screen.

1. Click a camera name to display a channel list where you can select a different channel.

2. Select a desired channel and click it.

The current channel will be switched to the selected one.
Use the cursor to select a channel to move, and drag and drop it to a desired channel; this can also
change the channel position.

`

Ex : if switching CH 1 to CH 4

CH1 CH2

CH4 CH2

;

CH3 CH4

Switching to Single Mode

When in split mode, select and double-click a desired channel to switch to its Single mode.
Press the number corresponding to a desired channel the remote control to switch to its Single mode.
Refer to “Remote Control > Using the numeric buttons”. (Page 11)

`

Ex : If double-clicking CH 3 or pressing the number “3” on the remote control.

CH1 CH2

;

CH3 CH4

CH3

24_ live

SPOT OUT

2013-01-01 01:10:25

2013-01-01 01:10:25

2013-01-01 01:10:25

The Spot Out monitoring is independent of the Live mode, which monitors a specific channel through the Spot Out
port.

Selecting a Spot Out mode

If an event occurs such as sensor, motion or alarm from the Spot Out port in connection with a monitor, you
can select a output screen mode.

1. In Live mode, right-click any area on the screen.

The Live menu appears.

2. Click <Spot Out>.

Supports the Spot output in Single screen with Auto
Sequence mode.

`

If the monitor is connected to the Spot port, the event that
occurred from the selected channel will be output on the
monitor.
For the Spot Out port of a model, refer to “Part Names and
Functions (Rear)”. (Page 10)

Scene Mode



Spot Out



Auto Sequence

Audio Off

CH1

CH2

Freeze

CH3

Stop Alarm

CH4

Record

Play

Search

Backup

Main Menu

Shutdown

Hide Launcher

Logout

< Multichannel Live Menu >

ZOOM

! LIVE

This is available only in Single Live mode. In Single mode, select a desired area and use the Zoom function to
enlarge it twice.

1. Select <Zoom In> in the right-click menu.
Press the [ZOOM] button on the remote control, or simply click <

> in the launcher menu. The zoom

box appears.

2. Use the direction keys, or drag and drop to specify an area to enlarge.

3. Press the [ENTER] button, or double-click the selected area to enlarge it twice.

`

In the enlarged image, use the direction buttons ($%_ +) on the remote controlto move the enlarged area.

4. Press the [ZOOM] button on the remote control, or simply click < > in the launcher menu to release
the zoom.

2013-01-01 01:10:25

;

English _25

live

CH1

CH2

AUDIO ON/OFF

You can turn the sound on/off in Live mode.

AUDIO ON/OFF in Single mode

Click the audio icon ( ) on the screen, or press the [AUDIO] button on the remote control to turn it on/off.

`

Only the channel where <AUDIO> is set to <ON> in “Device > Camera” displays the audio icon ( ) in Live mode

M

that you can use to turn the sound on/off.

FREEZE

This is available only in Live mode, this pauses playing the Live image temporarily.

>.

Freeze

> in the launcher menu.

1. Press the [FREEZE] button the remote control, or click <

The playback of the image is stopped temporarily.

2. Press the [FREEZE] button again, or click <

This will release the freeze.

EVENT MONITORING

Freeze

This will display the channel in sync with a specific event (Sensor/Motion/Video Loss) if it occurs.
In “Monitor > Event Display”, set the event monitoring to ON/OFF and specify the event display time. (Page 44)

• If multiple events occur simultaneously, the screen will switch to a split mode.

- 2~4 events : 4-split mode

• If the second event occurs within the set time of <Event Display>, the first event will last until the second

one is terminated. (Page 43)

`

Ex : If you set <Event Display> to 5 seconds, and only one event occurs in CH 1.

Event occurrence 5 seconds

Stop alarm

CH1

26_ live

`

CH1

CH2

CH1

CH2

Ex : If you set <Event Display> to 5 seconds, and the second event occurs in CH 2 within the set time after the first
event occurred in CH 1.

Event occurrence 4 seconds 9 seconds

Stop alarm

CH1 CH2

CH1

`

Press the [ALARM] button to reset the alarm settings and to release the event mode.

M

`

If an alarm activates in the condition you have set the event record, and pre/post alarm times, the event record will
be performed.

! LIVE

English _27

using the DVR

2013-01-01
01:10:25

2013-01-01 01:10:25

You can setup the system properties, devices, and options for recording, event,
backup and network.

SYSTEM SETUP

You can setup Date/Time/Language, Permission, System Properties and Log.

Date/Time/Language

You can check and setup the current Date/Time and time related properties, as well as the language used for
the interface on the screen.

Setting the Date/Time/Language

Set the Date/Time/Language

Using the mouse may help make setup easier.

1. Press the [MENU] button on the remote control.

` If not logged in, it prompts with login window.

Refer to “Login”. (Page 18)

2. Use the left/right buttons (

_ +

) to select the <System>.

System property setup menu is selected.

▲▼

3. Use the up/down buttons (

Language> and press the [ENTER] button.

4. Select <Date/Time/Language>.

A dialog to setup Date, Time and Language.

5. Use direction buttons (

▲▼_ +

) to select <Date/Time/

) to select an item to set

System

Date/Time/Language

Permission Management

System Management

Log Information

and make your changes.

• Date : Sets the date that will appear on the screen.
You can select the date format.

• Time : Sets the time and its format that will appear on the
screen.
Select either one from <24 Hours, 12 Hours (AM/PM)>.

• Time Zone : Sets the time zone of your area based on the
Greenwich Mean Time (GMT).

` GMT (Greenwich Mean Time) is standard World Time and the basis

Date/Time/Language

Date/Time/Language

Date 2013-01-01 YYYY-MM-DD



Time 08:14:24 24 Hours



Time Zone GMT



Time Sync. Setup



DST Dec First (Sun) 0 Dec First (Sun) 0



Language English



of world time zone.

• Time Sync. : You can set the DVR’s current time
synchronized to a selected <Time Server> regularly if you select to use <Time Server>.
In this case, <Date/Time/Language> setup does not allow time adjustment.

Holiday

OK Cancel

Logout

Return

28_ using the DVR

- Time Server : Enter an IP or URL address of the time
server.

- Last Sync Time : Displays the most recent
synchronization time from the selected time server.

- Activate as Server : Set to <Use> to allow the DVR to act
as a Time Server for other DVRs.

• DST : Set up Daylight Saving Time with its period to make
the time earlier than the GMT of its time zone by 1 hour
during the set period.

• Language : Select your language. Sets the language for the

Date/Time/Language

Date/Time/Language

Date 2011 -01-01 YYYY-MM-DD



Time Synchronization Setup

Synchronization Use



Time 08:14:24 24 Hours



Time Server 203.248.240.103



Time Zone GMT+08:00



Last Sync Time Fail



Time Sync. Setup Not Used



Activate as Server Use



DST Dec First (Sun) 0H Dec First (Sun) 0H



Language English



Holiday

OK Cancel

OK Cancel

interface.
English, French, German, Spanish, Italian, Chinese(Simplified), Russian, Korean, Polish, Japanese, Dutch,
Portuguese, Turkish, Czech, Danish, Swedish, Thai, Romanian, Serbian, Croatian, Hungarian, Greek,
Chinese (Traditional), Finnish and Norwegian are available.

6. When the Date/Time/Language setup is done, press <OK>.

` You can also use numeric buttons on the remote control to enter values for Date, Time and other numeric fields.

M

Setting Holiday

You can set specific dates to Holidays according to your preferences.
Holidays are applied to <Recording Schedule> and <Alarm Schedule> too.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Date/Time/Language> window to select <Date/Time/Language>, and

press the [ENTER] button.

2. Select <Holiday>.

A calendar for Holiday setup appears.

3. Use the left/right <

> buttons to select year or month,

and press the [ENTER] button.

Date/Time/Language

Date/Time/Language

2013 Jan

Sun Mon Tue Wed Thu Fri Sat
1 2 3 4 5

6 7 8 9 10 11 12

13 14 15 16 17 18 19

20 21 22 23 24 25 26

27 28 29 30 31

Holiday

! USING THE DVR

OK Cancel

4. Use direction buttons (

and press the [ENTER] button.
You will see the “Setting Holiday” screen.

` Ex : Select January 14th and check on <1/14> only to make

every January 14th a holiday. Check both on <1/14> and <Jan
2nd Mon> to make every January 14th and 2nd Monday of
January holidays.

▲▼_ +

) to select a desired date,

Date/Time/Language

Date/Time/Language

2013 Jan

Setting Holiday

Sun Mon Tue Wed Thu Fri Sat
1 2 3 4 5

6 7 8 9 10 11 12

13 14 15 16 17 18 19

20 21 22 23 24 25 26

27 28 29 30 31

Holiday

1 / 14

Jan 2nd Mon

OK Cancel

5. When the Holiday setup is done, press <OK>.

OK Cancel

Using the Calendar

Using the mouse may help make setup easier.

➀

Select year and month.

Select the left/right <
adjust by 1 year/month.

➁

Use direction buttons to select a date and press [ENTER] button.

` A date with recorded data to be searched will appear in yellow in the System Log, Event Log, Time Search and Event

Search.

> key on the left/right side of year/month and press [ENTER] button to

English _29

using the DVR

Permission Management

You can set permissions of each user over the DVR's specific function and settings.

Setting the Administrator

You can set and change Administrator’s ID and password.
The administrator can use and set all menu items and functions.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <System> window to
move to <Permission Management>, and press
[ENTER] button.

2. Select <Admin>.
A dialog for Admin ID and Password input appears.

3. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the ID and password.

Permission Management

Admin

ID admin



New Password



Confi rm P/W



Group

************

************

User Setup

` The default administrator ID is “admin”, and the password

M

must be set when the user log in at the first time.

OK Cancel

` To prevent from your personal information being exposed, please change your password every 3 months.

` Note that the security and other related issues caused by careless management of password shall be be in the charge

of the user.

4. When the administrator setup is done, press <OK>.

Using Virtual Keyboard



For alphanumeric inputs, the virtual keyboard window

appears.



Use direction buttons (

▲▼_ +

) to move to a desired

character, and press the [ENTER] button.



In the upper text input box of the virtual keyboard, there

displays a list of candidate words containing the selected
character.



Select a word from the list, or use the keyboard to enter the

whole word.

` If there are many of candidate words, use < , > buttons to move between them forward and backward.

Select <OK>.



Entered word is applied.

` For upper case letters, use <Caps Lock> button.
` For special characters, use <Shift> button.
` Using the virtual keyboard is the same to a normal keyboard use in your region.
` You can enter the ID with case-insensitive alphanumeric characters only.
` For the password, use alphabets and special characters excluding <
` You can use number buttons on the remote control.

` 1 2 3 4 5 6 7 8 9 0 - =

q w e r t y u i o p [ ] \

a s d f g h j k l ; ‘

z x c v b n m , . /

Space Ctrl

OK Cancel

> and <“>.

\

Caps Lock

Shift



Del

30_ using the DVR

Setting the Group

You can create user groups and setup permissions for those user groups.
You can register a user for each group in <User>.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <System> window to
move to <Permission Management>, and press
[ENTER] button.

2. Select <Group>.
A window for <Add>, <Delete>, <Rename>, and
<Group Authority> setup appears.

3. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Add, Delete, Rename : You can add, delete, rename a

group or modify the permissions given to the group.
The virtual keyboard appears when <Add> or <Rename> was selected.

- Add : When you first run the DVR with the admin account, only the admin account exists. Add has already
been deactivated. Select to display the virtual keyboard. Enter a group name. You can add up to 10
groups.

- Delete : Deletes a user group that is already registered. Selecting Delete will delete all user accounts
belonging to that group.

- Rename : Renames a group that is already registered. Select <Rename> to display the virtual keyboard.

` For entering a group name, refer to “Using Virtual Keyboard”. (Page 30)

• Group Authority : Sets permissions to access menu items of each group.
Users of a group can access checked functions.

4. When the group setup is done, press <OK>.

Permission Management

Admin

Group



Group Authority

Group

Live View

Search

Backup

Menu

Bi-directional audio

Record Lock PTZ Remote Alarm Out Shutdown

Setup

Setup

Setup

Setup

User

Add Delete Rename

OK Cancel

Setup

! USING THE DVR

To set the group authority

You can set the permissions of the group users to access the menu according to the channel.

1. Select a menu to which the group permission is assigned.

The menu where the group permission is assigned will be
displayed in the Live menu when a group user logs in.

• Live View : You can set the permission to access the Live
screen according to the channel.

• Search : You can set the permission to access the Search
menu according to the channel.

• Backup : You can set the permission to access the Backup
menu according to the channel.

• Menu : You can set menus accessible with a specific
permission.
Group users can access the permitted menus only.
Select a menu to display the Menu Permission screen

• Bi-directional audio : You will be given permission to use two-way audio features.

• Record Lock, PTZ, Remote Alarm Out, Shutdown : Select an item so that the item will be added to the

permissions.

2. Select <OK>.

Select and assign a group user so that the user can access the specified menu.

Permission Management

Admin

Group ABC



Group Authority

Group

Channel Setup

Live View

Search

Backup

Menu

Bi-directional audio

Record Lock PTZ Remote Alarm Out Shutdown

Setup

All

Setup

1 2 3 4

Setup

Setup

User

Add Delete Rename

OK Cancel

OK Cancel

Setup

English _31

using the DVR

To restrict the user permissions

If the admin restricts all permissions of an added group, the users belonging to that group can access only
the default minimum menus and can change the user’s own password only.

1. Start the DVR.

If all permissions are restricted, only the Login dialog
should appear.

2. Log in with a registered user ID.

Login

ID abc



Password



OK Cancel

3. Right-click any area on the screen.

If all permissions are restricted, only the accessible context

2013-01-01 01:10:25

menus should appear.

Scene Mode



Audio Off

Freeze

Stop Alarm

User Menu

Hide Launcher

Logout

To change the user password

If you log in with a user account that is restricted to access the menu, you can change your own password
only.

1. Log in with your account.

2. Select <User Menu>.

The Permission Management setup screen appears.

3. Select <Permission Management>.

The Password setup dialog appears.

4. Enter a new password.

5. Select <OK>.

You change to the password will be applied.

Permission Management

User

ID abc



New Password



Confi rm P/W



************

************

OK Cancel

32_ using the DVR

Setting the User

Users can be added only if a group was created in <Group> menu.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <System> window to

move to <Permission Management>, and press
[ENTER] button.

2. Select <User>.

A window for Add User appears.

3. Use direction buttons (

▲▼_ +

window.
A window for “Add User” appears.
You can configure the Network Viewer settings including
name, ID, viewer, Select Group and password.
Result of the user setup appears in the <User> window.
To change the user property, use “Edit User”.
The “Edit User” window appears when you select a
desired item to be changed in the <User> window.

• Viewer : If you select <Use>, you will be given access to the
Web Viewer and Network Viewer.

` Refer to “Connecting Web Viewer”. (Page 71)

` For more information about use of Network Viewer, refer to the

Network Viewer's user guide. (Page 8)

4. When the user setup is done, press <OK>.

) to select <Add> from the

Permission Management

Admin

Group All Group



Group Name ID Viewer Del

Permission Management

Admin

Group All Group



Group Name ID Viewer Del

Group

Group

Add User

Name



ID



Viewer Not Used



Select Group ABC



Password



Confi rm P/W



User

OK Cancel

User

OK Cancel

OK Cancel

Setup

Previous/Next Page

Setup

Previous/Next Page

Add

! USING THE DVR

Add

Setting Permissions

You can set restricted access for all general users.
Items with restrictions will require logging in for use.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <System> window to

move to <Permission Management>, and press
[ENTER] button.

2. Select <Setup>.

The Restricted Access, Restriction on Network Access,
Auto Log out, Manual Input of ID setup screen appear.

3. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Restricted Access : All menu items allowed for a user can
be set with restricted access.

- Checked (

- Not checked (

) : Restricted

) : Accessible

` If it is not checked ( ) in <Restricted Access>, any user can access the item no matter what the <Group Authority>

setting.

` If it is checked ( ) in <Restricted Access>, a user can access the item only if the user has permission in <Group

Authority> setting.

• Restriction on Network Access : Restricts remote access from a <Restricted Access> network.

- All Network : Restricts all access instances via Network Viewer and Web Viewer.

- Web Viewer : Restricts access via the Web Viewer.

• Auto Log out :

A user will be automatically logged out if there is no operation on DVR for over set period of time.

Permission Management

Admin

Restricted Access

Restriction on Network Access

Auto Log out OFF



Manual Input of ID ON



Group

Live View Backup Record Lock Search

PTZ Remote Alarm Out Shutdown All

All Network Web Viewer

User

OK Cancel

Setup

English _33

using the DVR

• Manual Input of ID : Prompts you to enter the user ID
manually for the login process.

- Checked (
[] symbols.
Use the virtual keyboard to enter the user ID.

4. When the permission setup is done, press <OK>.

System Management

You can check the system version, update to a newer version, as well as data backup and initialization.

Checking the System Information

You can check the current system version, broadcasting system, MAC address. You can update the system.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <System> window to

move to <System Management>, and press [ENTER]
button.

2. Check the Version, Broadcast Format, and MAC Address.

• System Information : Shows the current system’s
information.
The values can not be changed by a user.

• S/W Upgrade : Updates the DVR’s software.

) : Encloses the registered user IDs with the

Login

ID



*****

Password



OK Cancel

System Management

System Information

System Information

Software Version v1.0xh_yymmddhhmmss



Broadcast Format



MAC Address 00:00:F0:54:FF:FF



S/W Upgrade

Device No Device



Version No S/W Data



Settings

NTSC

Previous

Upgrade

` Ex : If you connect to a storage device that has upgradable software

installed, and return to the <System Management> menu, the
current software version will be displayed.

34_ using the DVR

System Management

System Information

System Information

Software Version v1.0xh_yymmddhhmmss



Broadcast Format



MAC Address 00:00:F0:54:FF:FF



S/W Upgrade

Device USB2FlashStorage



Version v1.0xh_yymmddhhmmss



Settings

NTSC

Previous

Upgrade

• Updating the Software

1. Connect a device storing the software to be updated.

(It may take about 10 seconds to recognize the device.)

` Upgradeable devices include USB memory and network device.

` To update the network, the current DVR should have been

connected to the network.
Upgrade via the proxy server may not be enabled due to the
restricted access.

2. Select <System Management> from <System> window.

System Management

System Information

System Information

Software Version v1.0xh_yymmddhhmmss



System Upgrade

Broadcast Format



MAC Address 00:00:F0:54:FF:FF



Current Version v1.0xh_yymmddhhmmss
New Version v1.0xh_yymmddhhmmss

S/W Upgrade

Do you want to upgrade?

Device USB2FlashStorage



Version V1.08_090731170402



Settings

NTSC

OK Cancel

Previous

Upgrade

3. Select <System Information>.

4. When the recognized device appears, select <Upgrade>.

` The <Upgrade> button will be activated only if the current <Software Version> of the <System Information> is

same to or older than that of <S/W Upgrade>.

! USING THE DVR

5. Press <OK> in the “System Upgrade” window.

` While updating, it shows the progress.

• Updating progresses with 3 steps as shown in the figure.

6. When the updating is done, it automatically restarts.

Do not turn the power off until it finishes restarting.

System Management

System Information

System Information

Software Version v1.0xh_yymmddhhmmss



Broadcast Format



S/W Upgrade

MAC Address 00:00:F0:54:FF:FF



Software upgrading...

S/W Upgrade

Device USB2FlashStorage



Version V1.08_090731170402



Settings

NTSC

Previous

System Management

System Information

System Information

Software Version v1.0xh_yymmddhhmmss



Broadcast Format



S/W Upgrade

S/W Upgrade

MAC Address 00:00:F0:54:FF:FF



Software upgrading...

S/W Upgrade

Device USB2FlashStorage



Version V1.08_090731170402



Settings

NTSC

Software upgrading...

Do not turn off during the upgrade.

Previous

Upgrade

Upgrade

` If “Upgrade Failed” appears, retry from the step 4.

M

When you experience continued failure, consult the service
center for assistance.

` When you perform S/W update remotely using Smart Viewer,

it may take a max of 3 minutes to complete the update since
Smart Viewer popped up a confirmation message. This is to
guarantee that the DVR set operates stably. For a faster
update, use the USB cable to connect to the DVR set.

English _35

using the DVR

Settings

You can copy and import the DVR settings by using a storage media.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <System> window to

move to <System Management>, and press [ENTER]
button.

2. Select <Settings>.

A window of storage device and load factory default
appears.

3. Use direction buttons (

▲▼_ +

item, and export or import settings data to a storage
device.

• Storage Device : Shows the connected storage device.

• Export : Exports DVR settings to the connected storage device.

• Import : Imports DVR settings from the storage device and applies to the DVR.

` If <Include Network Settings> is checked, the network settings will be imported too.

) to move to a desired

System Management

System Information

Storage Device 0 MB (Remained Capacity)



DVRUSB 10041400



USBDVR No data



Include Network Settings

Load Factory Default



Settings

Default

Previous

Export

Import

• Load Factory Default : If <Default> is selected, a
confirmation dialog for “Load Factory Default” prompts.
Press <OK> to initialize the system to the factory default.

4. To move to the previous menu, press <Previous>.

System Management

System Information

Storage Device 0 MB (Remained Capacity)



Load Factory Default

DVRUSB 10041400



USBDVR No data



Sure to Default Setting?

Include Network Settings

Load Factory Default



Settings

Export

Import

OK Cancel

Default

Previous

Log Information

You can browse logs on the system and events.

System Log

System Log shows log and timestamp on every system start up, system shutdown, and changes on system
settings.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <System> window to

move to <Log Information>, and press [ENTER] button.

2. Select <System Log>.

` Refer to “Using the Calendar”. (Page 29)

Click on the calendar < > to display the calendar window.

Log Information

System Log

Search Day 2013-01-01

First Page

No. Log List Date/Time

Event Log

Last Page

Backup Log

Search

Type View all

• Type : When there are too many logs, you can display logs of
the desired format by selecting the type.

3. Use direction buttons (

▲▼_ +

) to move to a desired item,

and press <Search>.

36_ using the DVR

Previous/Next Page

Previous

Event Log

Event log shows recorded events on alarms, motion detections and video loss.
It also shows the log and its timestamp.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <System> window to
move to <Log Information>, and press [ENTER] button.

2. Select <Event Log>.

3. Use direction buttons (

▲▼_ +

) to move to the desired

item.

4. Set Search Day, Channel and Type and the press
<Search>.

` Refer to “Using the Calendar”. (Page 29)

Log Information

System Log

Search Day 2013-01-01

First Page

No. Log List Date/Time

7 Motion Detection [CH 1] 2013-01-01 00:02:14

6 Motion Detection [CH 2] 2013-01-01 00:02:14

5 Motion Detection [CH 3] 2013-01-01 00:02:14

4 Motion Detection [CH 4] 2013-01-01 00:02:18

3 Motion Detection [CH 3] 2013-01-01 00:02:18

2 Motion Detection [CH 2] 2013-01-01 00:02:18

1 Motion Detection [CH 1] 2013-01-01 00:02:18

Event Log

Last Page

CH All CHs Type View all

Previous

Backup Log

Search

Previous/Next Page

Click on the calendar < > to display the calendar window.

Backup Log

You can find out who backed up and the details (backup time, channel, device to use, file format, etc.).

Using the mouse may help make setup easier.

1. In the <System> window, press the up/down (▲▼) button
to move to <Log Information> and press the [ENTER]
button.

2. Select <Backup Log>.

3. Use the four direction buttons (

▲▼_ +

) to move to a

desired item.

4. Specify a search term and select <Search> in the right
corner.
Backup details for the search term will be listed.

Log Information

System Log

Search Day 2013-01-01 ~ 2013-01-02

First Page

No. User Date/Time

Event Log

Last Page

Backup Log

Previous/Next Page

Previous

Search

! USING THE DVR

English _37

using the DVR

SETTING THE DEVICE

You can setup Camera, Storage Device, Remote Device and Monitor.

Camera

Setting the Camera

You can set Video, Audio, Channel Name and Dwell Time of a Camera.

Using the mouse may help make setup easier.

1. Press the [MENU] button on the remote control.

_ +

2. Use the left/right button (

Device setting menu is selected.

3. Use the up/down buttons (
and press [ENTER] button.

) to select <Device>.

▲▼

) to move to <Camera>,

Device

Camera

Storage Device

Remote Device

Monitor

Logout

Return

4. Select <Camera>.
You will see a window where you can configure the
camera settings including Video, Audio, CH Name,
SEQ-Dwell Time.

5. Use direction buttons (

▲▼_ +

) to move to a desired

Camera

Camera

CH Video  Audio CH Name SEQ-Dwell Time

1 ON  OFF  CAM 01 5 sec

2 ON  OFF  CAM 02 5 sec

3 ON  OFF  CAM 03 5 sec

4 ON  OFF  CAM 04 5 sec

item, and set the value.

• Video

Screen Setup Privacy Region

- <ON/OFF> : You can turn ON/OFF the selected

channel’s camera.

- <Covert1> : Shows information other than the video of the selected channel.

` For privacy protection, it does not display the video while the recording continues.

- <Covert2> : Shows nothing but an empty screen while the recording continues.

• Audio

- If set to <ON>, you can turn the audio of the channel ON/OFF on the Live screen.

- If set to <OFF>, the channel’s audio is off on the Live screen and not recorded.

PTZ

OK Cancel











38_ using the DVR

• CH Name : Up to 15 characters including blanks are allowed. (The first character should not be empty.)

` Refer to “Using Virtual Keyboard”. (Page 30)

• SEQ-Dwell Time : You can set the dwell time between channels for the Live screen and Spot Out.

` If set to <OFF>, the channel is not listed in the Auto Sequence mode.

• Screen Setup : The video appeared on the screen may vary
depending on the channel’s camera, configure the DVR
display to your preferences.
Select a channel and adjust the <(Brightness)>,
<

(Contrast)>, and <(Color)> of the selected channel.

` Press the <Init> to initialize settings back to the default 50.

• Privacy Region : You can specify a certain area of the camera
video to be protected for your privacy.

6. When the camera setup is done, press <OK>.

Screen Setup

CH1 50 50 50

OK Cancel

Init Apply to All CH

To set the privacy zone



Select <Privacy Region>.



When “Privacy Region” window appears, select a

channel for detection and set the area of privacy
zone.

• To set the area in “Privacy Region” window

In the “Privacy Region” window, select desired region
from <

• Privacy Region

You can specify up to 4 privacy zones for each channel,
which can be identified by the color.

1

Purple 2 Green 3 Blue 4 Yellow

• To set the area using <Individual> selection

In the “Privacy Region” window, you can select cells

individually by using <Individual>.

When selected <Individual>, “Privacy Region” window disappears and you can select cells one by one.
When the motion area setup is done, Right-click to select <Menu> in the context menu or the [MENU]

button on the remote control to display the “Privacy Region” window again.

- Clear All : Selected cell is removed from the Privacy Region.

Menu : After selecting individual motion areas, move to the “Privacy Region” window.

-

` If selected <Apply to All CH>, selected motion area is applied to all channels.

When completing the privacy zone settings, click <OK>.



>.

Privacy Region

CH1

Privacy Region1

Individual

OK Cancel

Apply to All CH

Clear All

Menu

! USING THE DVR

English _39

using the DVR

Setting the PTZ

To use Camera’s PTZ functions, ID and protocols of each camera and DVR should be matched.
For other settings, refer to the “Remote Devices” settings. (Page 42)

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Device> window to
move to <Camera>, and press [ENTER] button.

2. Select <PTZ>.
A window of PTZ settings appears.

3. Use direction buttons (

▲▼_ +

) to move to a desired

item, and select it.

• ID : Set the ID of the connected camera of each channel.

You can easily setup by using the numeric buttons on the
remote control.

• Protocol : Set the protocol of the connected camera of each

channel.

` You can check the camera’s ID and protocol if you turn the camera off and on after connecting it to the DVR.

M

(Page 64)

4. When the PTZ setup is done, press <OK>.

Storage Device

Camera

Camera

CH ID Protocol

1 0 > None

2 1 > None

3 2 > None

4 3 > None

PTZ

OK Cancel











You can check information on storage devices.

Confirming Devices

You can check storage devices and their free space, usage as well as status.
Devices available are HDD, and USB devices (Memory, HDD).

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Device> window to
move to <Storage Device>, and press [ENTER] button.

2. Select <Device>.

• No. : Shows the assigned number of the internal HDD.

• Used/Total : Shows the used/total capacity of the storage

device.

• Used : Sets the storage device’s usage.

- USB memory is used for backup purpose only.

• Status/Management : Shows the current status of the HDD,

as in Normal/Check/Replace.

- Normal : Available to use

- Check : Available to use but recommended to replace

- Replace : Requires immediate replacement.

3. To move to the previous menu, press <OK>.

Storage Device

Device

Device No. Used/Total Used Status/Management

HDD 1 0G/494.94G Internal Normal

Format

OK Cancel

HDD Alarm

40_ using the DVR

Formatting

You can format a storage device.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Device> window to
move to <Storage Device>, and press [ENTER] button.

2. Select <Format>.
A window for selection of device for formatting appears.

3. Use direction buttons (
formatted.

▲▼_ +

) to select a device to be

Storage Device

Device

Device Select Used/Total Used

HDD 1 0G/494.94G Internal

Format

Format

OK Cancel

HDD Alarm

! USING THE DVR

4. Select <Format> on the bottom of the screen.
Press <OK> on the “Manage” confirmation window will
start formatting the selected device.

5. When the formatting is done, press <OK>.

` Even when formatted, used HDD space will not be 0 GB due

M

to the space reserved by the system required for operating.

Storage Device

Device

Device Select Used/Total Used

HDD 1 0G/494.94G Internal

Format

Manage

Format

HDD Alarm

Formatting deletes all recordings.

Proceed formatting?

OK Cancel

OK Cancel

HDD Alarm

You can set alarm settings for HDD defects such as Check Alarm Output Port, Replace Alarm Output Port,
and its duration.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Device> window to
move to <Storage Device>, and press [ENTER] button.

2. Select <HDD Alarm>.
A window for setting HDD check and replace output ports
and their durations appears.

3. Use direction buttons (

▲▼_ +

) to move to the desired

item.

Storage Device

Device

Check Alarm Output Port



Duration OFF



Replace Alarm Output Port



Duration OFF



Format

HDD Alarm

1 BEEP

All

1 BEEP

All

• Alarm

OK Cancel

- Alarm signal will output through the alarm out port on the

rear side when selected <1>.

- If <BEEP> was selected, a beep will sound.

- If <All> was selected, both beep sound and alarm signal through rear side ports will output.

• Check Alarm Output Port : If HDD generates check alarm, the alarm signal will output to the specified alarm

output port.

• Replace Alarm Output Port : If HDD generates replace alarm, the alarm signal will output to the specified

alarm output port.

• Duration : Sets the alarm duration for the alarm signal and beep sound.

English _41

using the DVR

` <Check> status means that the HDD is operating but it has problems that require technical examination.

M

4. When the HDD Alarm setup is done, press <OK>.

Remote Devices

You can set the RS-485 communication for use of PTZ Camera and system keyboard with the DVR.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Device> window to
move to <Remote Device>, and press [ENTER] button.

2. Use direction buttons (
item, and press [ENTER] button.

3. Set the values of each communication setup of the remote
device.

• Baudrate : Baud rate settings of the DVR, PTZ camera and

system keyboard should be matched for proper operations.

4. Specify the system keyboard and remote control ID, and
click <OK>.

) appears on the Live screen.

(

` <Replace> status means that the HDD has defect and requires immediate replacement.

( ) appears on the Live screen.

Remote Device

▲▼_ +

) to move to the desired

Baudrate Parity Data Stop Bit Transfer type

9600  None  8  1  Half Duplex

System Keyboard OFF ID 1

Remote Control ON ID 0

OK Cancel

` For changing the remote control’s ID, refer to “Changing the Remote Control ID”. (Page 11)

M

42_ using the DVR

Monitor

You can select which item(s) to be displayed on the screen.

Setting the Monitor

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Device> window to
move to <Monitor>, and press [ENTER] button.

2. Select <Monitor>.

3. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Event Display : Sets the dwell time of the event channel

display on the monitor when an event occurs.
If selected <Continuous>, it displays the channel until you
press [ALARM] button to release it.

• Display : Displays only checked items on the monitor

screen.

• Video Output : You can set the video output mode.

Auto : The default is set to Composite. (In VGA mode, the “SAMSUNG” logo will be displayed)

­If a VGA source is connected, the source from the VGA will be displayed as main. (In Composite mode,
the spot screen will be displayed)
The monitor distributor is not supported.
To switch to VGA mode, turn off the DVR set and connect the VGA jack. (The VGA monitor will turn on)

VGA : The main video mode will switch to VGA after the DVR set reboots; the composite source will be

­displayed on the spot screen.

Composite : The main video mode will switch to Composite after the DVR set reboots. In VGA mode, the

­“SAMSUNG” logo will be displayed.

4. When the monitor setup is done, press <OK>.

` If you want to change the default output to VGA mode when the live screen is displayed with the beep after the system

booting, press the remote control buttons in sequence: [FREEZE]  [VIEW]  [RETURN (
[VIEW]  [RETURN (

)]. The DVR will switch to VGA mode with the beep after rebooting.

Monitor

Monitor

Event Display OFF



Display Date Time CH Name Icon



Video Output Auto



Display Position Setup

Spot Out

OK Cancel

Mode

)]  [FREEZE] 

! USING THE DVR

Setting Display position

Some monitors many not display information (camera name, icon, time information, etc.) about the DVR,
depending on the condition. Then, you can change the display position of the data.

▲▼

1. In the <Device> window, press the up/down (
to move to <Monitor> and press the [ENTER] button.

2. Select the <Monitor> item.

3. Select <Display Position Setup> in the bottom.

You will move to the <Display Position Setup> window.

4. Use the four direction buttons or the number buttons on
the remote control to adjust the data position.

) button

2013-01-01 01:10:25

Display Position Setup

30

30 30

30

OK Cancel

English _43

using the DVR

Setting the Spot Out

You can set the DVR to output information / video apart from the monitor out.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Device> window to
move to <Monitor>, and press [ENTER] button.

2. Select <Spot Out>.

` The number of Spot Out terminals differs according to the

model.

Monitor

Monitor

Spot Out 1 SEQ



Event Display OFF



Spot Out

Mode

Set Mode All

3. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Spot Out 1 : You can select between Auto Sequence, and

Single.

• Set Mode : A window for “Set Spot Out” appears and you

can set the channel for it.
You can set the dwell time between the screen switching in
“Setting the Device > Camera > SEQ-Dwell Time”.
(Page 39)

• Event Display : Specify the time to display on the spot

output of the channel where an event took place.
If selected <Continuous>, it displays the channel until you
press [ALARM] button to release it.

` You can setup using the mouse right button in Live screen.

M

Refer to “Spot Out”. (Page 25)

4. When the Spot Out is done, press <OK>.

Setting the Screen Mode

You can configure the Live screen and Split Screens.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Device> window to
move to <Monitor>, and press [ENTER] button.

2. Select <Mode>.

3. Use direction buttons (

▲▼_ +

item, and set the value.

• Live Screen : Select split modes for the Live screen.

4-split screens are included by default.

• Play Screen : Select split modes for the playback screen.

Single screen and 4-split screen are provided by default.

4. When the screen mode setup is done, press <OK>.

) to move to a desired

OK Cancel

Monitor

Monitor

Spot Out 1 SEQ



Event Display OFF



Monitor

Monitor Spot Out

Spot Out

Set Spot Out

1 2 3 4

OK

OK Cancel

Live Screen

Play Screen

OK Cancel

Mode

Set Mode All

Mode

Live Play

44_ using the DVR

SETTING THE RECORDING

You can setup scheduled recording, event recording and other recording related settings.

Recording Schedule

Make your reservation on a date and time to schedule the recording on specified time.

Using the mouse may help make setup easier.

1. Press the [MENU] button on the remote control.

_ +

2. Use the left/right button (

Record menu is selected.

3. Use the up/down buttons (
Schedule>, and press [ENTER] button.

) to select <Record>.

▲▼

) to move to <Recording

Recording Schedule

Event Record Duration

REC Quality & Resolution

Record Option

Record

Logout

! USING THE DVR

Return

4. Select <Recording Schedule>.
A window of scheduled recording setup appears.

5. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Apply to All CH : If selected <Apply to All CH>, “Apply to

All CH” window appears.
Press <OK> to apply the setup to all channels.

6. When the recording schedule setup is done, press <OK>.

Recording Schedule

CH1

00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23

All

Sun

Mon

Tue

Wed

Thu

Fri

Sat

Hol

No Recording Continuous Event

Both(Cont&Evnt)

OK Cancel

Apply to All CH

Recording Schedule

CH1

00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23

All

Sun

Apply to All CH

Mon

Tue

Wed

Thu

Fri

Sat

Hol

No Recording Continuous Event

Both(Cont&Evnt)

Apply recording schedule to all channels?

OK Cancel

Apply to All CH

OK Cancel

English _45

using the DVR

Recording Color Tags

Color Function Description

White No Recording No schedule / event recording

Orange Continuous Scheduled recording only

Blue Event Event recording only

Green Both(Cont&Evnt) Both scheduled / event recordings

Each press of a selected cell will cycle through <No Recording>-<Continuous>-<Event>­<Both(Cont&Evnt)>.

Event Record Duration

You can set the beginning and ending point of a recording on an event.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Record> window to
move to <Event Record Duration>, and press [ENTER]
button.

2. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Pre Event : The recording of an event will start at a

pre-determined time prior to the actual occurrence of the event.
If it is set to 5 seconds, the recording begins from 5
seconds before the event.

• POST Event : The recording will continue for a

pre-determined time after the actual end of an event.
If it is set to 5 seconds, the recording ends in 5 seconds after an event.

Event Record Duration

CH Pre Event  POST Event

1 OFF

2 OFF

3 OFF

4 OFF

OK Cancel

1 min



1 min



1 min



1 min













3. When the event recording duration setup is done, press <OK>.

REC Quality / Resolution

You can set resolution, fps and quality of recordings by channel, and by recording type of standard / event.

For more information about the resolution, refer to the “Product Specification” section. (Page 100)

Setting Standard Recording Properties

You can set each channel’s resolution, quality and fps for normal recordings.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Record> window to
move to <REC Quality & Resolution>, and press
[ENTER] button.

2. Select <Standard>.

3. When the recording setup is done, press <OK>.

46_ using the DVR

REC Quality & Resolution

Standard

Remaining count : 4CIF(L) : 2 2CIF(M) : 4 CIF(S) : 8

CH Resolution  Record Rate  Record Quality

1 CIF(S)  7fps  Level4

2 CIF(S)  7fps  Level4

3 CIF(S)  7fps  Level4

4 CIF(S)  7fps  Level4

Event

OK Cancel











Setting Event Recording Properties

You can set each channel’s resolution, quality and fps for event recordings.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Record> window to
move to <REC Quality & Resolution>, and press
[ENTER] button.

2. Select <Event>.
Event recording setup window appears.

3. Use direction buttons (

▲▼_ +

) to move to a desired

REC Quality & Resolution

Standard

Remaining count : 4CIF(L) : 2 2CIF(M) : 4 CIF(S) : 8

CH Resolution  Record Rate  Record Quality

1 4CIF(L)  7fps  Level4

2 4CIF(L)  7ps  Level4

3 4CIF(L)  7fps  Level4

4 4CIF(L)  7fps  Level4

Event

item, and select it.

• Resolution : Sets the resolution of the recorded screen.

• Record Rate : Image Per Second, means the frames

OK Cancel

recorded per a second.

• Record Quality : Sets the recording quality.

` The estimated total remaining count means the total number of remaining recordings for both standard and event

M

recordings.

` You cannot increase the remaining count if the current remaining count has reached zero or there is no available

remaining count from any other page. If this is the case, reduce the remaining count for the current page, or do so
for the same channel on any other page.

4. When the Event recording setup is done, press <OK>.

Record Option











! USING THE DVR

Specify whether to stop recording or overwrite the HDD if the HDD is full.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Record> window to
move to <Record Option>, and press [ENTER] button.

2. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Disk End Mode : If selected <Overwrite>, recording will

continue despite the HDD full while overwriting the oldest.
If selected <Stop>, the recording will stop when the HDD is

Record Option

Disk End Mode Overwrite



Disk End Beep

Auto Delete

Auto Delete 180 day



The recording information will be deleted.

Do you want to proceed?

OK Cancel

full.

• Disk End Beep : If selected <Stop>, the button is activated.

If you check it, the beep will sound on the disk full and the

OK Cancel

recording stops.

• Auto Delete : If you check it, Record Period setup is activated.

If you specify the auto deletion period, the recording data before the period will be deleted automatically.

` This option will be enabled only if Disk End Mode is set to “Overwrite”.

3. When the recording option setup is done, press <OK>.

English _47

using the DVR

SETTING THE EVENT

You can set recording options for sensor, motion, and video loss event.

Sensor Detection

You can set the sensor’s operating condition and connected camera, as well as alarm output and its duration.

Using the mouse may help make setup easier.

1. Press the [MENU] button on the remote control.

_ +

2. Use the left/right button (

) to select <Event>.

Event setting menu is selected.

Sensor Detection

Motion Detection

Video Loss Detection

Alarm Schedule

Logout

Event

Return

3. Use the up/down buttons (

▲▼

) to move to <Sensor

Detection>, and press [ENTER] button.

A window of sensor detection setup appears.

4. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Sensor Operation : Sets the operation mode of sensors.

- <OFF> : Sensor does not operate.

- <N.O (Normal Open)> : Sensor is opened.

If the sensor is closed, it generates alarm.

- <N.C (Normal Close)> : Sensor is closed.

If the sensor is open by interruption, it generates alarm.

• Cam : Select a channel to be connected to the sensor.

If selected camera, “Cam Preset setup” window appears.
Select a channel and setup the preset.

` Preset setup can be done in PTZ mode.

Refer to “Preset Setting”. (page 64)

• Alarm : Sets the alarm output method.

` For further information on alarm output, refer to “HDD Alarm >

Alarm”. (Page 41)

• Duration : Sets the duration of alarm signal and alarm
sound.

5. When the sensor detection setup is done, press <OK>.

Sensor Detection

Sensor

Sensor Operation  Cam  Alarm  Duration

1 OFF  1 None 10 sec

2 OFF  2 None 10 sec

3 OFF  3 None 10 sec

4 OFF  4 None 10 sec

OK Cancel

Sensor Detection

Cam Preset setup

Sensor

Sensor Operation  Cam  Alarm  Duration

1 OFF  1 None 10 sec

CH

 Preset

2 OFF  2 None 10 sec

1 None

3 OFF  3 None 10 sec

2 None

4 OFF  4 None 10 sec

CH

3 None



4 None



OK Cancel

OK Cancel

 Preset

Sensor Detection

Sensor

Sensor Operation  Cam  Alarm  Duration

1 OFF  1 None 10 sec

2 OFF  2 None 10 sec

Alarm Setup

3 OFF  3 None 10 sec

4 OFF  4 None 10 sec

1 BEEP All

OK Cancel



































48_ using the DVR

OK Cancel

Motion Detection

You can set target detection region and motion, as well as the alarm signal output.
When the motion detection region is set, it detects motion within the area.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Event> window to
move to <Motion Detection>, and press [ENTER] button.
A window of motion detection area setup appears.

2. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

Motion Detection

CH Mode  Sensitivity  Alarm  Alarm Duration

1 OFF  Level10(High)  None 10 sec

2 OFF  Level10(High)  None 10 sec

3 OFF  Level10(High)  None 10 sec

4 OFF  Level10(High)  None 10 sec

• Mode : Sets whether to activate motion detection.

• Sensitivity : Sets the sensitivity level of the motion detection.

• Alarm : Sets the alarm output method.

` For further information on alarm output, refer to “HDD Alarm >

OK Cancel

Motion Region

Alarm”. (Page 41)

• Alarm Duration : Sets the duration of alarm signal and alarm sound.

3. When the motion detection setup is done, press <OK>.

Setting the Motion Detection Area



Select <Motion Region>.



When “Motion Region” window appears, select a

channel for detection and set the area of motion
detection.

• To set the area in “Motion Region” window

In the “Motion Region” window, select desired region
from <

>.

• To set the area using <Individual> selection

In the “Motion Region” window, you can select cells
individually by using <Individual>.
When selected <Individual>, “Motion Region” window disappears and you can select cells one by one.

When the motion area setup is done, Right-click to select <Menu> in the context menu or the [MENU]
button on the remote control to display the “Motion Region” window again.

- Select : Selected cell is set to be a part of motion detection area.

- Unselect : Selected cell is removed from the motion detection area.

- Inverse : Unselected cells are set to be the motion detection area.

- Menu : After selecting individual motion areas, move to the “Motion Region” window.

` If selected <Apply to All CH>, selected motion area is applied to all channels.



When the motion detection setup is done, press <OK>.

Motion Region

CH1

Individual

OK Cancel

Apply to All CH

Select

Unselect

Inverse

Menu











! USING THE DVR

English _49

using the DVR

Video Loss Detection

You can set the alarm to be generated on a camera disconnection, which causes a video loss.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Event> window to
move to <Video Loss Detection>, and press [ENTER]
button.
A window of video loss detection area setup appears.

2. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Video Loss State : Sets whether to activate video loss

detection.

• Alarm : Sets the alarm output method.

` For further information on alarm output, refer to “HDD Alarm >

Alarm”. (Page 41)

• Alarm Duration : Sets the duration of alarm signal and alarm sound.

3. When the video loss detection setup is done, press <OK>.

Alarm Schedule

Video Loss Detection

CH Video Loss State  Alarm  Alarm Duration

1 OFF  None 10 sec

2 OFF  None 10 sec

3 OFF  None 10 sec

4 OFF  None 10 sec

OK Cancel











Help

You can set the conditions and operating hours for scheduled alarms.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Event> window to
move to <Alarm Schedule>, and press [ENTER] button.

2. A window of <Alarm Schedule> settings appears.

3. Alarm : Sets the alarm output method.

` For further information on alarm output, refer to “HDD Alarm >

Alarm”. (Page 41)

• <ON> : Marked in orange, and always generates alarm on

Alarm Schedule

Alarm1

00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23

All

Sun

Mon

Tue

Wed

Thu

Fri

Sat

Hol

OFF ON Event Sync

scheduled time.

• <OFF> : Marked in white, no alarm is generated even if an

event occurs.

• Event Sync : Marked in Blue, generates alarm only when an

event occurs.

• Apply to All Alarm : Applies the configured schedule to all

alarms.

` When the alarm is generated on the scheduled time, you can

M

stop the alarm by canceling the schedule.

4. When the Alarm Schedule setup is done, press <OK>.

Alarm Schedule

Alarm1

00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23

All

Sun

Mon

Tue

Wed

Thu

Fri

Sat

Hol

OFF ON Event Sync

Apply to All Alarm

OK Cancel

Apply to All Alarm

Apply the alarm scheduling to all?

OK Cancel

Apply to All Alarm

OK Cancel

50_ using the DVR

BACKUP

You can check the backup device and set the backup schedule by channel or by time.
The product only supports external HDD of USB memory and USB type. (Page 100)

Setting the Backup

You can backup the desired data to a connected device.

Using the mouse may help make setup easier.

! USING THE DVR

1. Press the [MENU] button on the remote control.

_ +

2. Use the left/right button (

) to select <Backup>.

Logout

Return

Backup menu is selected.

Backup

Backup

3. Press the [ENTER] button.

A backup window appears.
You can directly access it from the “Live screen menu”.
(Page 20)

4. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Backup Range : Sets the <Start> and <End> time for the

backup.

• Channel : Sets the channel to backup.

Backup

Start  End



2013-01-01 00:01:06 2013-01-01 08:25:45

Overlap List0



1 2 3 4 All

Device USB-Storage



Folder \20130101\



Check capacity

OK Cancel

Type DVR



File Name 0001



Backup

Used

Free

Change

You can select multiple channels.

• Device : Select a backup device from the recognized devices.

• Type : Sets the backup data format.

- DVR : Saved data can be played back only by the DVR.

- AVI : You can set recording options when sensor, motion, image loss detection or tampering event
occurs.

` If you need to install a codec in Windows, run the x264_dvr.exe file in the codec folder that is created when you back

up an AVI file.

- SEC : Saves data in the Samsung’s proprietary format with built-in viewer, which supports immediate
playback on a PC.

• File Name : You can set the back file name.

` Refer to “Using Virtual Keyboard”. (Page 30)

• Check capacity : Shows the size of the selected backup data, used and available capacity of the selected
backup device.

` Checking will be stopped if the backup size exceeds 200% of the available capacity.

• Overlap : Shows a list of overlapping data on a same time according to the number of data.
It appears when one channel has multiple data on a certain time point due to changing of time or time zone
settings, etc.

` Refer to time and time zone of “Setting the Date/Time/Language”. (Page 28)

English _51

using the DVR

5. When the backup setup is done, press <OK>.

` If no available device is recognized for backup, <OK> button is not activated.

` The application may slow down during the backup.

J

` You can switch to the menu screen during the backup in operation, but playback of data is not available.

` If backup has failed, select “Device > Storage Device” and check the free space of the HDD and check also if the

HDD is properly connected.

` Pressing the <Return> during the backup will return to the previous menu, while the backup progresses.

M

NETWORK CONFIGURATION

It provides networked monitoring of Live screen from a remote place, and supports mail forwarding function with
events. You can configure the network environment which enables such functions.

Connection Mode

You can set the network connection route and protocol.

Setting the Connection

Sets the protocol and environment of the network.

Using the mouse may help make setup easier.

1. Press the [MENU] button on the remote control.

_ +

2. Use the left/right button (

) to select <Network>.

Network menu is selected.

▲▼

3. Use the up/down buttons (

) to move to <Connection

Mode>, and press [ENTER] button.

4. Select <Connection>.

A window of connection mode setup appears.

5. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Connection Mode : Sets the network connection mode.

• Bandwidth : Sets the maximum data flow to be transferred.

(Upload speed)
Options will vary depending on the selected connection
mode.

- For <Static IP>, <Dynamic IP> : Select one from 50

kbps ~ 2Mbps, and Unlimited.

- For <ADSL>, select one from 50 kbps ~ 600 kbps.

Connection Mode

DDNS

Live Transfer

Mailing Service

Connection Mode

Connection

Connection Mode Static IP



Bandwidth 2Mbps



IP 192.168. 1.200



Gateway 192.168. 1. 1



Subnet Mask 255.255.255. 0



DNS Manual 168.126. 63. 1



Protocol

OK Cancel

Logout

Return

Network

52_ using the DVR

• IP, Gateway, Subnet Mask, and DNS

- For <Static IP> : You can directly input IP address,

Gateway, Subnet Mask and DNS.

- For <Dynamic IP> : IP address, Gateway, and Subnet

Mask are set automatically.

- For <ADSL> : IP address, Gateway, and Subnet Mask

are set automatically.

• User ID, Password : In case you selected ADSL, provide the

Connection Mode

Connection

Connection Mode ADSL



Bandwidth 600kbps



IP 192.168. 1.200



Gateway 192.168. 1. 1



Subnet Mask 255.255.255. 0



DNS Manual 168.126. 63. 1



User ID ID



Password



“User ID” and its “Password”.

` DNS server for <Dynamic IP> and <ADSL> can be set by user only if you selected <Manual>.

M

6. When the connection setup is done, press <OK>.

Setting the Protocol

Protocol

************

OK Cancel

! USING THE DVR

1. Use the up/down buttons (▲▼) in <Network> window to

move to <Connection Mode>, and press [ENTER]
button.

2. Select <Protocol>.

3. Use direction buttons (

▲▼_ +

) to move to a desired

item, and set the value.

• Protocol Type : Select the protocol type between TCP and
UDP.

Connection Mode

Interface

Protocol Type TCP



Port(TCP) 4520 ~ 4524



Port(UDP) 8000 ~ 8160



Unicast/Multicast Unicast



Multicast IP 224.126.63.1



TTL 5



Webviewer Port 80



* Multi Browser Support:
TCP Port 4505~4530, Webviewer Port 80

Port

OK Cancel

` If selected UDP, selections of Port (TCP), Port (UDP), and Unicast/

Multicast are activated.

` If setting the connection mode to ADSL, you cannot select UDP for the protocol type.

• Port(TCP) : Initially, <4520~4524> is set. It increases / decreases by 5.

- TCP: It has better stability and lower speed when compared to UDP, and recommended for internet

environments.

• Port(UDP) : Initially, <8000~8160> is set. It increases / decreases by 160.

- UDP : It has less stability and faster speed when compared to TCP, and recommended for local area

network (LAN) environments.

• Unicast/Multicast : Select one between Unicast and Multicast.
If selected Multicast, Multicast IP and TTL are activated.

- Unicast : Transfers data (UDP, TCP) individually to each connecting client.

- Multicast : Multiple client can receive the data (only in UDP) without putting additional traffic load to the

network.

• Multicast IP : User can directly input.

• TTL : Select from 0 ~ 255. Initial value for the TTL is set to <5>.

• Webviewer Port : Enter the port number for the Web Viewer. Initially, it is set to <80>.

• Multi Browser Support : The Web Viewer can be used with a browser that supports the Silverlight.

The multi viewer can be used only if the HTTP port is set to 80, protocol type is TCP and device ports range
within 4505-4530.
This is for the Siliverlight’s security purposes.

` As UDP protocol may cause a packet loss on the network, it is recommended to use TCP protocols.

M

` If you select UDP protocols and set port forwarding in the IP router, ending up with an unstable network connection,

configure the DMZ settings in the IP router as necessary.

4. When the protocol setup is done, press <OK>.

English _53

using the DVR

Notification

` In a multi-browser environment, the web port should be set to 80 (private port).

J

Select one between 4505 and 4530 for RTSP

• Network Overview

Router (External IP: 109.112.92.133,

Local IP: 192.168.1.1

Cable/ADSL

Modem

POWER

REC

DIGITAL VIDEO RECORDER SRD-443

Internet

DIGITAL VIDEO RECORDER SRD-443

DDNS Server
(www.samsungipolis.com)

POWER

REC

Local PC

DVR 1

DVR 2

DVR 1 DVR 2

System

WEB RTSP WEB RTSP

IP 192.168.1.200 192.168.1.200 192.168.1.202 192.168.1.202

Protocol TCP TCP TCP TCP

Private Port 80 4520~4524 81 4525~4529

Public Port 80 4520~4524 81 4525~4529

Connection Mode

Connection

Connection Mode Static IP



Bandwidth 2Mbps



IP 192.168.1.200



Gateway 192.168.1.1



Subnet Mask 255.255.255.0



DNS Manual 168.126.63.1



Protocol

OK Cancel

Connection Mode

Connection

Protocol Type TCP



Port(TCP) 4520 ~ 4524



Port(UDP) 8000 ~ 8160



Unicast/Multicast Unicast



Multicast IP 224.126.63.1



TTL 5



Webviewer Port 80



* Multi Browser Support :

TCP Port 4505~4530, Webviewer Port 80

Protocol

OK Cancel

Connection Mode

Connection

Connection Mode Static IP



Bandwidth 2Mbps



IP 192.168.1.202



Gateway 192.168.1.1



Subnet Mask 255.255.255.0



DNS Manual 168.126.63.1



Protocol

OK Cancel

Connection Mode

Connection

Protocol Type TCP



Port(TCP) 4525 ~ 4529



Port(UDP) 8000 ~ 8160



Unicast/Multicast Unicast



Multicast IP 224.126.63.1



TTL 5



Webviewer Port 81



* Multi Browser Support :

TCP Port 4505~4530, Webviewer Port 80

Protocol

OK Cancel

54_ using the DVR

• 1st Set Port Forwarding Setting

Port Forwarding is 4520~4524
(4520, 4521, 4522, 4523, 4524)

Port Forwarding is 80

SRD-443

192. 168. 1. 200

TCP

4520

4520

• 2nd Set Port Forwarding Setting

Port Forwarding is 4525~4529

(4525, 4526, 4527, 4528, 4529)

SRD-443

192. 168. 1. 202

TCP

4525

4525

SRD-443

192. 168. 1. 200

TCP

80

80

Port Forwarding is 81

SRD-443

192. 168. 1. 202

TCP

81

81

! USING THE DVR

English _55

using the DVR

Connecting and Setting the Network

Networking may differ from the connection method, check your environment before setting the connection
mode.

When no router is used

• Static IP mode

- Internet connection : Static IP ADSL, leased line, and LAN environments allows connection between the
DVR and remote user.

- DVR Network Settings : Set the <Connection Mode> in
<Connection> menu of the connected DVR to <Static IP>.

` Consult your network manager for IP, Gateway and Subnet Mask.

• Dynamic IP (DHCP) mode

- Internet connection : Connect the DVR directly to a cable
modem, DHCP ADSL modem or FTTH network.

- DVR Network Settings : Set the <Connection Mode> in
<Connection> menu of the connected DVR to <Dynamic
IP>.

• ADSL (PPPoE: ID and password certification)

- Internet connection : An ADSL modem is directly connected to the DVR, where the ADSL connection
requires user ID and password.

- DVR Network Settings : Set the <Connection Mode> in
<Connection> menu of the connected DVR to <ADSL>.

` ADSL <User ID> and <Password> should be the same to the

ADSL user information.
If you don’t know the ID and password, consult your ADSL service
provider.

Connection Mode

Connection

Connection Mode Static IP



Bandwidth 2Mbps



IP 192.168. 1.200



Gateway 192.168. 1. 1



Subnet Mask 255.255.255. 0



DNS Manual 168.126. 63. 1



Connection Mode

Connection

Connection Mode ADSL



Bandwidth 600kbps



IP 192.168. 1.200



Gateway 192.168. 1. 1



Subnet Mask 255.255.255. 0



DNS Manual 168.126. 63. 1



User ID ID



Password



Protocol

OK Cancel

Protocol

************

OK Cancel

56_ using the DVR

When a router is used

` To avoid IP address conflict with the DVR's static IP, check followings :

J

• Setting the DVR with a static IP

- Internet connection : You can connect the DVR to a router which is connected to an ADSL/Cable modem or
a router in a Local Area Network (LAN) environment.

• Setting the DVR Network

1. Set the <Connection Mode> in <Connection> menu of the connected DVR to <Static IP>.

2. Check whether the set IP address is in the static IP range provided by the Broadband Router.

IP, Gateway, and Subnet Mask : Consult your network manager.

` Check whether the set IP address is in the static IP range provided by the Broadband Router.

` If a DHCP server is configured with starting address (192.168.0.100) and end address (192.168.0.200), you should

J

set the IP address out of the configured DHCP range (192.168.0.2 ~ 192.168.0.99 and 192.168.0.201 ~

192.168.0.254).

3. Check the Gateway address and subnet mask are equal to those set in the Broadband Router.

• Setting the DHCP IP Address of the Broadband Router

1. To access the Broadband Router’s configurations, open a web browser on the local PC that is connected

to the Broadband Router and enter the router’s address (ex : http://192.168.1.1).

2. At this stage, make the local PC's windows network configurations to the below example :

Ex) IP : 192.168.1.2

Subnet Mask : 255.255.255.0
Gateway : 192.168.1.1

- Once connected to the Broadband Router, it prompts with password. While entering nothing to the User
Name field, enter “admin” into the password field and press <OK> to access the router configurations.

- Access the router’s DHCP configuration menu and set its DHCP server activation, and provide the start and
end address.
Set the start address (192.168.0.100) and end address (192.168.0.200).

! USING THE DVR

` Above steps may differ from the router devices depending on the manufacturer.

M

• Setting Router’s Port Forwarding

1. Set the protocol to <TCP>.

2. External Port Range : Enter the TCP Port set in the

<Port(TCP)> in <Protocol> menu of the connected DVR.
If more than one DVRs are connected to the router, the
TCP port can be different.

3. Internal PC IP Address : Enter the IP address set to the

<IP> in <Connection> menu of the connected DVR.

4. Internal Port Range : Set the same to the “External Port

Range”.

` Above steps may differ from the router devices depending on the manufacturer.

M

Port forwarding is required when you want to access the DVR connected to the router from outside of the router’s
network.

Connection Mode

Connection

Protocol Type TCP



Port(TCP) 4520 ~ 4524



Port(UDP) 8000 ~ 8160



Unicast/Multicast Unicast



Multicast IP 224.126. 63. 1



TTL 5



Webviewer Port 80



* Multi Browser Support:
Device Port 4505~4530, HTTP Port 80

Protocol

OK Cancel

English _57

using the DVR

DDNS

You can set the DDNS site for a remote user’s network connection.

Using the mouse may help make setup easier.

1. Use the up/down buttons (▲▼) in <Network> window to
move to <DDNS>, and press [ENTER] button.
DDNS Setup screen appears.

2. Use the virtual keyboard to enter the <Product ID>.

` Refer to “Using Virtual Keyboard”. (Page 30)

` If selected <OFF> input fields are deactivated.

` If selected <iPOLiS>, the server name field is disabled.

• DDNS Site : Set whether to use DDNS or not, and select

the DDNS site if enabled.

• Server Name : Enter the server name of the selected DDNS site.

• Product ID : Enter the product ID which was registered to the DDNS site.

• Quick Connect : Appears if the <DDNS Site> is set to <iPOLiS>.

To use this feature, connect the DVR to a UPnP router and set to <Use>.

` If the quick connect setup has been cancelled while progressing, it is automatically set to <Not Used>.

M

3. When the DDNS setup is done, press <OK>.

DDNS

DDNS Site iPOLiS



Server Name www.samsungipolis.com



Product ID



Quick Connect Not Used Use



DDNS Host Address http://www.samsungipolis.com/



OK Cancel

DDNS Setting

DDNS is a short form of Dynamic Domain Naming System.
DNS (Domain Name System) is a service that routes a domain name consisting of user friendly characters
(ex : www.google.com) to an IP address consisting of numbers (64.233.189.104).
DDNS (Dynamic DNS) is a service that registers a domain name and the floating IP address with the DDNS
server so that the domain name can be routed to the IP address even if the IP is changed in a dynamic IP
system.

• Setting DDNS in the DVR

Set <Protocol Type> in the <Port> menu of the connected DVR to the following :

Ex) Protocol Type : TCP

Device Port : 4520~4524
DDNS Site : iPOLiS

• DDNS Settings of the Router

Select the corresponding menu for the network transfer protocol of the router.

58_ using the DVR

• SETTING UP SAMSUNG iPOLiS DDNS

Go to Your PC

1. Open your browser and go to http://www.samsungipolis.
com and click <LOGIN>.

2. You first need to create an account.
Click <SIGN UP>.

3. Follow the account registration instructions on the website.

4. After completing the account registration, login to your account.

5. Add your DVR to your account. Click <PRODUCT

REGISTRATION>.

6. Create a name(Product ID) for your DVR. Use 4 to 20
alphanumeric characters without spaces. Select
classification, model number of the DVR and click
<REGISTER>.

! USING THE DVR

7. After registration, you should see your product in the list.

Go back to DVR

1. From network tab, click on <DDNS>.

2. Under DDNS Site, select <iPOLiS>.

Connection Mode

DDNS

Live Transfer

Mailing Service

DDNS

DDNS Site iPOLiS



Server Name www.samsungipolis.com



Product ID



Quick Connect Not Used Use



DDNS Host Address http://www.samsungipolis.com/



OK Cancel

Logout

Return

Network

English _59

using the DVR

3. Under Product ID, enter the product ID you created on the

Samsung iPOLiS website.
Under Quick Connect, select <Use> and click <OK>.

` If the connection was not successful, your router may not be

M

supporting UPNP.
For more information on enabling UPNP on your router, please
see Router manual.

DDNS

DDNS Site iPOLiS



Server Name www.samsungipolis.com



Product ID srd443



Quick Connect Not Used Use



DDNS Host Address http://www.samsungipolis.com/srd473d



DDNS

DDNS Site iPOLiS



Server Name www.samsungipolis.com



Connection

Product ID srd473d



Quick Connect Not Used Use



DDNS Host Address http://www.samsungipolis.com/srd473d



Live Transfer

Sets the quality of the image that is transferred from the DVR to the network.

Using the mouse may help make setup easier.

1. In the <Network> setting window, press the up/down

(▲▼) button to move to <Live Transfer> and press the
[ENTER] button.
The Live Transfer window appears.

2. Use the direction buttons (

▲▼_ +

) to move to a desired

item and set the value.

3. When the live transfer is done, press <OK>.

` The resolution is fixed to CIF, and you can specify the transfer

quality only.

Live Transfer

Resolution CIF(S)



Quality Low



OK Cancel

Quick Connect Success

OK

OK Cancel

OK Cancel

60_ using the DVR

Mailing Service

You can send an e-mail to a DVR-registered user at a specific time interval, or if an event occurs.

` If an event occurs with a channel where the camera’s video is set to <OFF> or the remaining recording count is set

M

to <OFF>, only the text notification will be sent to the applicable email address.

SMTP Setting

Sets the SMTP mail server.

Using the mouse may help make setup easier.

1. In the <Network> setting window, press the up/down
(▲▼) button to move to <Mailing Service> and press the
[ENTER] button.

2. Select <SMTP>.
You will see the SMTP setting window.

3. Use direction buttons (

▲▼_ +

) to move to a desired item

and set the value.

• ServerType : Displays the connected server type.

• Server : Enter a server to connect to.

• Port : Sets the communication port.

• Use Authentication : Check this if the SMTP server uses user authentication.

The account input box will be activated.

• User : Enter a user to use authentication when connecting to the SMTP server.

• Password : Enter the password of the SMTP server user.

• Secure Transfer : Select one from <Never> and <TLS(if Available)>.

• Sender : Use the virtual keyboard to provide the email address.

` Refer to “Using Virtual Keyboard”. (Page 30)

• TEST : Conducts the test on the server settings.

4. When the SMTP setting is done, press <OK>.

Mailing Service

SMTP

ServerType SMTP mail Server



Server



Port 25



User



Password



Secure Transfer Never



Sender ex. [e-mail]



TEST

Event

Use Authentication

Group Recipient

OK Cancel

! USING THE DVR

Event Setting

You can set the interval and type of the event that will be sent to the user.

Using the mouse may help make setup easier.

1. In the <Network> setting window, press the up/down
(▲▼) button to move to <Mailing Service> and press the
[ENTER] button.

2. Select <Event>.

3. Use direction buttons (

▲▼_ +

) to move to a desired item

and set the value.

• Event Interval : Set the event interval.

` If a series of events occurs, the e-mail will be sent at the specified

interval, not on each event.

• Use Event Transfer : Select an event type to send if an event occurs.

If the selected event occurs, the e-mail will be sent to the group that has the recipient authority.

4. When the event setting is done, press <OK>.

Mailing Service

SMTP

Event Interval 10 min





Use Event Transfer

Event

Sensor Motion

Change P/W HDD Info Video Loss

Power On/Off Manual Record

Group

OK Cancel

Recipient

English _61

using the DVR

Group Setting

You can set the group to whom the e-mail is sent, and specify the permission for each group.
You can add recipients for each group in the <Recipient> menu item.
The recipient is set separately from the DVR user group.

Using the mouse may help make setup easier.

1. In the <Network> setting window, press the up/down

(▲▼) button to move to <Mailing Service> and press the
[ENTER] button.

2. Select <Group>.

3. Use direction buttons (

▲▼_ +

) to move to a desired item

and set the value.

• Add : Select <Add> and use the virtual keyboard to add a

group.

` Refer to “Using Virtual Keyboard”. (Page 30)

• Delete : Deletes the selected group.

• Rename : You can reset the recipient permission of an existing group.

• Recipient Permission : Set the permission of the recipient group.

4. When the group setting is done, press <OK>.

Mailing Service

SMTP

Group





Recipient Permission

Sensor Motion

Change P/W HDD Info Video Loss

Power On/Off Manual Record

Event

OK Cancel

Group

Add Delete Rename

Recipient

Recipient Setting

You can add/remove a recipient(s) to/from the specified group and edit the group if necessary.

Using the mouse may help make setup easier.

1. In the <Network> setting window, press the up/down

(▲▼) button to move to <Mailing Service> and press the
[ENTER] button.

2. Select <Recipient>.

3. Use direction buttons (

▲▼_ +

) to move to a desired item

and set the value.

• Add : You can select a recipient name, e-mail address or
group.
You should have created a group in the <Group> menu
item before you can add a user to the group.

` For inputting the recipient name and email address, refer to

“Using Virtual Keyboard”. (Page 30)

4. When the recipient setting is done, press <OK>.

Mailing Service

SMTP

Group All Group



Group Name e-Mail Address Del

Mailing Service

SMTP

Group ABC



Group Name e-Mail Address Del

Event Group

OK Cancel

Event Group

Add recipient

Name



Email



Select Group ABC



OK Cancel

OK Cancel

Recipient

Add

Previous/ Next Page

Recipient

Add

Previous/Next Page

62_ using the DVR

CONTROLLING A PTZ DEVICE

2013-01-01 01:10:25

2013-01-01 01:10:25

2013-01-01 01:10:25

The DVR enables you to adjust the settings of a PTZ camera as well as an ordinary one to your preference.

PTZ Device

The PTZ device can be activated only if a channel in connection with the PTZ camera is selected.

Getting started with PTZ

The PTZ camera is available, only if a channel is selected, in the following way :

` Using the remote control buttons

Press the [PTZ] button on the remote control.

` Using the launcher menu

Click PTZ <

PTZ

> to display the live launcher.

` Using the right-click menu in Live mode

Right-click any area on the screen to display the context menu, and
select <PTZ Control>.

` Using icons on the live screen

Click the PTZ <

` The PTZ function is available only if the PTZ camera is

M

connected so that the PTZ icon is displayed on the screen.

> icon on the live screen.

Scene Mode

Spot Out

PTZ Control

Zoom In

Audio

Freeze

Stop Alarm

Record

Play

Search

Backup

Main Menu

Shutdown

Hide Launcher

Logout





! USING THE DVR

Using the PTZ camera

You can use one camera to perform all functions of PAN, TILT and ZOOM for monitoring multiple places and
set the preset to your preference in a desired mode.

1. Launch the <PTZ Control> menu.

As the PTZ <
yellow, you access the “PTZ Control” mode to display the
“PTZ Control” menu.

` Be sure to configure PTZ working environments before

M

operation, since the PTZ Working(Active) mark can be
appeared to be activated even when PTZ is not operative.

2. Use the PTZ wheel in the launcher menu to adjust the

monitoring area, or use the direction buttons (
the remote control to move the camera to a desired place.

• PTZ Wheel : Clicking a nearer point to the center will move in that direction slowly; clicking a farther point
from the center will move fast.

` Keep clicking left to rotate the lens counter clockwise; keep clicking right to rotate the lens clockwise.

• Zoom ( ) : You can use the Zoom function of the PTZ camera.

• IRIS (

• Focus (

• Auto Pan : The camera automatically runs between the two points that you selected.

• Scan : The camera moves to the preset points in the specified sequence.

If multiple presets are specified, the PTZ camera will automatically move to all of the preset points one at a
time.

) : Adjusts the intensity of radiation incoming to the iris.

> icon on the bottom right corner turns

▲▼_ +

) : Enables you to adjust the focus manually.

) on

PTZ Control CAM01

Auto Pan

Scan

Pattern

Preset

Select

Select

Select

Select

Exit

Camera Setup

Select Preset

Save Rename

Delete Delete All

Delete Delete All

English _63

using the DVR

2013-01-01 01:10:25

• Pattern : Makes the PTZ camera remember and follow the past route.

` The functions of Auto Pan, Scan and Pattern are supported in the protocols of Samsung, Panasonic and Pelco, and are

different in terms of the name and setting, depending on the protocols of Samsung, Panasonic and Pelco.
(Panasonic : Auto Pan, Sequence, Sort / Pelco : Auto Pan, Frame Scan (Scan), Pattern)

` Before entering the PTZ device control mode, set the values of the PTZ device in the <Setting the PTZ> menu.

M

(Page 40)

Preset Setting

A preset is a set of specific target points of a PTZ camera, and up to 20 presets per a camera can be stored.

Using the mouse may help make setup easier.

1. In PTZ Control mode, use the direction buttons to adjust the camera in a desired direction.

2. Select the <Save> key.

The virtual keyboard for inputting the preset will appear.

` Refer to “Using Virtual Keyboard”. (Page 30)

• Save : You can save the preset settings.

• Rename : You can change the settings of the existing presets.

• Delete : Deletes the selected preset.

• Delete All : Deletes all existing presets.

` If you replace the camera of the channel that stores the preset list with a new one, you should reset the preset

M

accordingly.

3. Press <OK>.

The preset will be saved as a name that you entered.

Camera Setting

A PTZ camera has its own menu system. Optimize the PTZ camera according to the DVR.

Using the mouse may help make setup easier.

1. Connect the PTZ camera to the DVR and run the PTZ camera again to display the camera’s protocol

setting window.

2. Check the protocol ID of the camera.

` In “Device > Setting the PTZ”, enter the PTZ camera ID in the ID input box of the channel that is connected to the PTZ

camera. (Page 40)

3. Select <Camera Setup> in the PTZ Control menu.

The camera-specific menu appears.

` You can configure the settings of only those cameras that support

the protocols of Samsung, Pelco D/P, AD and Panasonic.

` If you are setting Auto Pan or Pattern in the camera menu, press

and hold the appropriate button for a certain time so that the button
operation can be different from that in normal PTZ setting.

P/T Setting

Pan/Tilt Limit

Area Setting
Area Masking
Prop. P/T ON
Digital Flip ON
Image Hold ON
Jog Speed MANUAL
Max Speed Level 5

Camera Setup



Exit

64_ using the DVR

search & play

2013-01-01 01:10:25

2013-01-01 01:10:25

SEARCH

You can perform the search for recorded data by the time or by the search criteria such as an event.
You can access the <Search> menu directly in Live mode.

1. In Live mode, right-click any area of the screen.

The Live menu appears.

2. Select <Search>.

Or, press the [SEARCH] button on the remote control.

3. The Search menu appears.

4. The search can be restricted by the Auto Delete function.

Refer to “Setting the Recording > Record Option”.
(Page 47)

` Overlapped data : It only appears if there exists overlapped

M

data on a certain time, produced due to the change of DVR’s
time setup. The latest data comes first, from <List0>.
It does not appear in <Backup Search>.

Time Search

Event Search

Backup Search

Motion Search

Return

Scene Mode

Spot Out

Audio Off

Freeze

Stop Alarm

Record

Play

Search

Backup

Main Menu

Shutdown

Hide Launcher

Logout





! SEARCH & PLAY

Time Search

You can search for recorded data of a desired time.
As the time to display may be different depending on the time zone and the DST standard time, the time of
data recorded in the same time can be displayed differently depending on time zone and DST settings.

Using the mouse may help make setup easier.

1. Select <Time Search> in the <Search> menu.

2. Select a date to search.

` Refer to “Using the Calendar”. (Page 29)

3. The record data on the specific date will be listed.

The display bar is different according to the data type.
So check the data type for the color in the left pane.

4. Use direction buttons (

▲▼_ +

) to set the search criteria

and press the [ENTER] button.

• Go to First : Move to the earliest recording date.

• Go to Last : Move to the latest recording date.

• Time : Enter a time to perform the search or use the up/

down button <

>

> to select one.

Time Search

2013-01-01

2013/01/01 00:01:17

Standard Schedule

Motion Sensor

V.Loss Etc

Go to First Go to Last

Overlapped Data List1

00:01

All Data

CAM 01

CAM 02

CAM 03

CAM 04

Play Return

Zoom In Zoom Out

English _65

search & play

• Zoom In : The map enlarges in detail.
It will switch in the sequence of 24 hours - 16 hours - 8 hour

- 4 hours.

• Zoom Out : The map will switch in the reverse order of the
detailed mode above.
It will switch in the sequence of 4 hours - 8 hour - 16 hours

- 24 hours.

` Double-click a desired time to zoom it in/out.

M

Time Search

2013-01-01

2013/01/01 00:01:17

Standard Schedule

Motion Sensor

V.Loss Etc

Go to First

Overlapped Data List1

00:01

All Data

CAM 01

CAM 02

CAM 03

CAM 04

Play Return

• Preview : Click <Channel> and select (click, drag) a time in
<Duration> to display a still image for the portion.

- If the selected channel does not contain any recorded data, it will be marked black.

5. Select a data item and click <Play>.

The screen switches to the data playback mode.

Event Search

You can search for events by the channel and play them.

Using the mouse may help make setup easier.

1. Select <Event Search> in the <Search> menu.

2. Use direction buttons (

▲▼_ +

) to set the search criteria

and press the [ENTER] button.

` All record events on a specific date will be found. (Normal/

Schedule recording included)

• Date/Time Preview : If you select a data item in the list, the
still image of the selected data will be displayed in the left
preview pane.

• Event : Displays the type of the event that occurred.

3. Select a data item and click <Play>.

The screen switches to the event data playback mode.

Event Search

CAM 01

2013-01-01

Overlapped Data List1

2013/01/01 00:01:22

No. Date/Time Preview Event

3 02:47:54 ~ 02:48:59 Motion

2 00:39:06 ~ 00:40:30 Motion

1 00:01:22 ~ 00:02:28 Motion

Play Return

Go to Last

Zoom In Zoom Out

Go to First Go to Last

Previous/Next Page

Backup Search

Searches for backup data in the connected backup device.
Only data in the format of DVR is included in the search.
Refer to <Type> in “Backup > Setting the Backup”. (Page 51)

Using the mouse may help make setup easier.

1. Select <Backup Search> in the <Search> menu.

2. Use direction buttons (

and press the [ENTER] button.

• Record Period : Displays the record period.

• Channel : Displays the recorded channel.

• Play Start Time : Select a time that you start playing.

3. Select a data item and click <Play>.

The screen switches to the backup data playback mode.

66_ search & play

▲▼_ +

) to set the search criteria

Backup Search

No. Folder Name File Name

1 20130101 16190000

File Name 16190000  Channel info



Record Period 2013-01-01 01:01:01 - 2013-01-01 01:01:10



Play Start Time 2013-01-01 01:01:01



USB:USB2FlashStorage

Previous/Next Page

Play Return

Motion Search

If a motion is detected in each channel, you can set a desired area to perform the search.

You can use the mouse to select the related items.

1. Select <Motion Search> in the <Search> menu.

2. Use direction buttons (

▲▼_ +

) to set the search criteria

and press the [ENTER] button.

` If you set the motion area to <Manual Area>, the <Setup>

button will be activated.

• Motion Region : Select an area to perform the search.

- All Area : Searches for all areas of the selected channel.

- Current Area : Searches for the motion area for each

channel specified in “Motion Detection >
Setting the Motion Detection Area”. (Page 49)

- Manual Area : You can set the motion area manually.

• Setup : The Setup button will be activated only if you have
set the motion area to Manual. Press this button to display
the area setting window.

• Date/Time : The Date/Time will be automatically set by the
hour, and the end time will be automatically set to one hour
later than the start time if it is set.

• Preview : Select a data item in the list to display the still
image of the item.

Motion Search

Channel CAM 01 Motion Region All Area

Date/Time 2013-01-01 03:41:18 ~ 2013-01-01 05:11:44

No. Start Time

7 01:01:30

6 01:01:25

5 01:01:20

4 01:01:15

2013/01/01 01:01:30

3 01:01:10

2 01:01:05

1 01:01:01

Motion Region

CH1

Play Return

OK Cancel

Individual

Go to First Go to LastOverlapped Data List1

Apply to All CH

Setup

Search

Previous/Next Page

! SEARCH & PLAY

3. Select a data item and click <Play>.

The screen switches to the motion data playback mode.

English _67

search & play

2013-01-01 01:10:25

2013-01-01 01:10:25

PLAYBACK

Play

You can play data stored in the HDD and backup a desired portion of the data.

Using the mouse may help make setup easier.

1. In Live mode, click <Play> in the right-click menu or

< > in the launcher menu, or press the Play button on
the remote control.

▲▼

2. Use the up/down button (

` For data search, refer to <Search>. (Page 65)

3. Select a data item and click <Play> in the Search menu.

The selected data is played and the play launcher appears
on the screen.

` If there is an existing data, <Play> will start immediately without

performing the search.

• Playback Information : Displays the date and time of the
current data in the top corner.

) to select a menu.

Scene Mode

Spot Out

Audio Off

Freeze

Stop Alarm

Record

Play

Search

Backup

Main Menu

Shutdown

Hide Launcher

Logout





• Backup : Click <

> to set the current time to the start
time of backup; you can specify a backup area using the
mouse (yellow triangle).
Click < > again to set the current time to the end time of
the backup and the “Backup Range” window appears.

- Type : Supports formats of DVR and SEC.

Refer to a list of formats in “Setting the Backup”.
(Page 51)

- Device : Select a backup device.

- Check Capacity : Enables you to check the capacity of the

selected storage device.

4. If you want to return to the Live screen in Play mode, click <

[@] button on the remote control.

Backup Range

Start  End



2013-01-01 00:01:06 2013-01-01 01:10:25

Device USB Storage  Type DVR



Folder \20130101\  Filename 0001



Check capacity

Backup Cancel

> in the launcher menu or press the

Backup

Used

Free

Change

REC

68_ search & play

Using the Playback Button

Part Names Functions

Play Timeline Indicates the current playback point, and can be used to move.



Skip Backward Moves backward by unit time.

b

c

Backward Fast
Play

Used for quick backward playback.

! SEARCH & PLAY

REC

Backward Slow



Play

Step Backward Moves backward by one frame at a time.



Pause Stops playing the current video temporarily.



Stop Stops playback and moves to the live screen.



Step Forward Moves forward by one frame at a time.



Forward Slow



Play

Forward Fast



Play

Skip Forward Moves forward by unit time.



Return Return to the search setup screen.



Audio

m

REC Records all channels in Live mode.

n

Used for backward frame-by-frame search while in PAUSE.

Ensured to play forward up to 4 channels simultaneously at a low speed.

` In a split mode, the real time playback may not be supported, depending on the record

quality, resolution and number of channels. And some frame rates may be supported.

Used for quick forward playback.

Sets Audio ON/OFF.

` If using both web view and DVR set simultaneously, the audio signal will be output from the

DVR set.

Partial Backup



Mode Switch Click a desired playback mode or press [MODE] to switch the screen mode in sequence.



Begins backup of the selected section of the video being played, with the specified starting/
ending point.

English _69

web viewer

INTRODUCING WEB VIEWER

What is Web Viewer?

Web Viewer allows remote access to your DVRs. You have
access to live video, archived video, PTZ control (if configured),
etc.

PRODUCT FEATURES

• Remote connection using the browser

• PTZ camera control enabled

• Supports 1, 4 camera viewing formats (maximum of 4

cameras in the list).

• Gets JPEG, BMP format images to print and save to “Print
or Save JPEG, BMP format images”.

• Record video in AVI format-compatible with popular media players. (needed the H.264 codec)

SYSTEM REQUIREMENTS

The following lists the minimum suggested hardware and operating system requirements needed to run the
Web Viewer.

Windows XP Professional

OS

Windows Vista Home Basic / Premium

Windows 7

Mac OS 10.6 and later versions

70_ web viewer

- Windows OS : Internet Explorer 7.0 or higher, Firefox 3.6 or higher,

Web Browser

CPU Intel Pentium 4.2 GHz

Memory 512 MB

Monitor High Color 16-bit 1024 x 768

HDD

Chrome 12 or higher

- Mac OS : Safari 5 or higher, Firefox 3.6 or higher.

50 MB(Installation space required)

* Additional HDD space required for recording.

Recorded file size will vary depending on recording quality settings.

CONNECTING WEB VIEWER (Windows)

1. Open your web browser and type the IP address or URL

of DVR into the URL address box.

The basic URL of the DVR is as following in case of MAC

M

address :

` http://www.samsungipolis.com/Product ID (registered at the iPOLiS web site)
` You can also use registered URL which setups up in the Setup menu of your DVR.

2. Set the Admin ID and password same to those of the DVR

Admin.
For general users, enter the DVR user ID and password.

` The default administrator ID is “admin”, and the password must

J

be set when the user log in at the first time.

` Set password for your wireless network if you use the product

with a wireless router. Being not protected with password or using the default wireless router password may expose your
video data to potential threat.

` To prevent from your personal information being exposed, please change your password every 3 months. Note that the

security and other related issues caused by careless management of password shall be be in the charge of the user.

` It allows up to 4 simultaneous access including the Admin and general users.

M

` It does not allow multiple login of the Admin user.
` Password of the Admin and general users can be changed in <Permission Management> menu of the DVR.
` Normal users should have set <Viewer> under <Permission Management> to “Use” before connecting to the

Web Viewer. (Page 33)

` All settings are applied by the DVR’s settings.

! WEB VIEWER

3. Click <Install ActiveX Control…>.

Downloading Active-X control may take several minutes
according to the security settings on your PC.

4. Click <Install>.

5. You may have “Windows Security Alert” that attempts to

block this with the Windows Firewall. In that case, click
<Unblock> to start Web Viewer.

6. Installation is complete.

Now you can see the main screen of Live Viewer.

English _71

web viewer

USING LIVE VIEWER (Windows)

The Live Viewer screen consists of following :

a This displays the IP address and the model name of the connected DVR.
b These menus consist of <LIVE>, <SEARCH>, <SETUP>, <ABOUT>, <LOGOUT>.
c These buttons are used for the screen split and full screen mode.
d Shows the IP address and model name of the connected DVR.
e Select to turn the sound on/off.

Select <DVR Time> or <PC Time> for the OSD time information display setting of the Live Viewer.

f These buttons are used for sequence and changing the screen channel.
g These buttons are used for capture, print, and save the image.
h Shows the channel of the connected DVR.
i These buttons are used for PTZ related functions.
j This displays the screen for connected camera with DVR.

` The resolution is set to 1024X768 pixels.

M

` The initial split-screen mode is set according to the number of channels connected to DVR. You can change the

split-screen mode by clicking buttons for split-screen modes.

72_ web viewer

OSD INFORMATION DISPLAY

a The channel number, video size, and IP address of the

connected DVR are displayed.

b

This icon will appear if the audio signal is currently being output.

c The current date and time will be displayed according to the

selected time information display setting <DVR Time> or <PC
Time>.

d Alarm icon appears when alarm is issued.

It disappears when pressed the [ALARM] button of the DVR.

e Motion icon appears when motion is detected.

It disappears when pressed the [ALARM] button of the DVR.

f It displays whether the PTZ controls are active.

` If you have set PTZ cameras for the DVR, “PTZ” is displayed on the

M

screen. Select a PTZ camera channel and use the [PTZ] button for camera control.

SPLIT-SCREEN

You can change the split mode by clicking each number icon.

! WEB VIEWER

SINGLE MODE QUAD MODE

• Click <
The screen displays the selected camera connected to the DVR in
“SINGLE MODE”.

• Click <
The screen displays the selected camera connected to the DVR in
“QUAD MODE”.

• Click <
Switch the 1-split or 4-split mode to Full Screen mode.
Double clicking on the screen or pressing any button of the keyboard
returns to the previous mode.

> button.

> button.

> button.

English _73

web viewer

CONNECTED DVR

This displays the IP address and the status of the connecting DVR.

` Connection failure message

M

No Response : Appears when the DVR does not respond.
Access Denied : Appears when the maximum number of users is exceeded.

` The number of simultaneous connections are limited to 4.

Setting the display of the OSD time information

Select <DVR Time> or <PC Time> for the OSD time information display
setting.

• DVR Time : Based on the time of the connected DVR

• PC Time : Based on the time of the PC currently running the Web Viewer.

• Audio : Sound On/Off

CHANGING THE LIVE SCREEN MODE

` In the 4-split screen mode, “SEQUENCE”, “PREVIOUS” and “NEXT” buttons will be

deactivated.

• SEQUENCE : When this button is clicked, screens are switched at a

preset interval.
In SINGLE MODE, the channel numbers are sequentially switched from
1 to 4.

` Preset interval (10 seconds)

• PREVIOUS : When this button is clicked, the previous screen appears.

• NEXT : When this button is clicked, the next screen appears.

In SINGLE MODE, the channel numbers are sequentially switched from
1 to 4.

74_ web viewer

SAVING THE LIVE SCREEN ON THE PC

• CAPTURE : Saves the current screen into a BMP or JPEG
file.

` The default saving path is “C:\Program Files\Samsung\Dvr

M

Web Viewer\SnapShot\Live”. To change the saving path, click
<SAVE PATH (
want. For Windows Vista or 7, the saving path is “C:\users\
(user ID)\AppData\LocalLow\Samsung\DVR Web Viewer\
SnapShot\” by default.

)> button and then select the path you

` The file is automatically named as following : “IP address_Port number_YYYYMMDD_HHMMSS_camera number_

index”
Ex) 192.168.1.200_554_20110414_093118_01_00

• PRINT : Prints out the selected screen out of the currently
displayed live screens. It also prints the IP address, time,
camera number and the current event status together.

• RECORD : Saves the current image on the screen and
saves it as a avi video file.

` To record it, it is required at least 1GB of available space.

M

` The default saving path is “C:\Program Files\Samsung\Dvr

Web Viewer\VideoClip\Live”. To change the saving path, click
<SAVE PATH (
want. For Windows Vista or 7, the saving path is “C:\users\
(user ID)\AppData\Local-Low\Samsung\DVR Web Viewer\VideoClip\”.

)> button and then select the path you

` The file is automatically named as following : “IP address_Port number_YYYYMMDD_HHMMSS_camera number_

index”
Ex) 192.168.1.200_554_20110406_070455_01_00

` For AVI Save, you need the H.264 codec for playing saved files.
` HDD Minimum Free Size : During the recording, if there is no more capacity available in the HDD than set free space

will prompt with a popup message : “Cannot record due to insufficient disc space in the HDD”.

! WEB VIEWER

English _75

web viewer

CHANGING THE LIVE SCREEN CHANNEL

• Blue numbers : The channel connected to the current live
screen

• Gray numbers : The channel not connected to the current
live screen

` If you select 4-split mode, the channel button for each of cameras

1 ~ 4 will turn blue.

USING PTZ CAMERA

Click the direction buttons to control the camera.

• <

You can zoom in or out an image by using the ZOOM button.

• <

You can adjust the entering light amount by using the IRIS button.

• <

You can adjust the focus by using the FOCUS button.

• MENU : Appears the camera menu screen.

>

>

>

76_ web viewer

• Preset : Moves the lens direction to a preset direction.

1. If you click a preset, the camera moves to the selected

preset's position.

2. You can delete the selected preset or all presets.

3. You can save a new preset number and name.

` You can save presets up to 20.

M

• Auto Pan : Moves the camera lens direction between

2 points set for the camera.

• Scan : Moves the camera lens direction between 2 preset

points of the camera.

• Pattern : You can set camera various movement patterns

such as zoom, move, etc. so that a camera automatically
moves according to the pattern.

` While the DVR controls a PTZ camera, Web Viewer cannot

M

control the camera.

` Camera menu setup is only available for camera supporting

the function.

` Each function of PTZ is same to that of the DVR.
` Pan/Tilt of the Smart dome camera is manipulated

automatically to center the camera to the mouse clicked
point.

` If you drag the mouse using the left button on a certain point,

Pan/Tilt of the Smart dome camera is manipulated
automatically to center the camera to the middle point between the dragging start and end position.
Upward dragging will zoom out, while downward dragging will zoom in.

` Tilt of Power PTZ operates properly within 45°.
` Power and Pan Tilt functions are only available for camera supporting the functions.

Ex : Samsung SCP-2371

! WEB VIEWER

English _77

web viewer

USING SEARCH VIEWER

The Search Viewer screen consists of following :

a This displays the IP address and the model name of the connected DVR.
b There are 4 tabs available: <LIVE>, <SEARCH>, <SETUP>, <ABOUT>, <LOGOUT>.
c Switch to a split mode.
d Shows the IP address and model name of the connected DVR.
e Select to turn the sound on/off.
f These buttons are used for capture, print, and save the image.
g This displays a calendar at which you can search the recorded video.
h This displays a timeline at which you can search the recorded video by the time.
i These buttons are used for controlling playback.
j This displays the screen for playback of recorded video.

` <SEQUENCE>, <PREVIOUS>, <NEXT> buttons are not available in SEARCH menu.

M

` During the DVR backup, you may have a trouble accessing CMS & Web Search.

78_ web viewer

SPLIT-SCREEN

You can change the split mode by clicking each number icon.

SINGLE MODE QUAD MODE

! WEB VIEWER

• Click <
The screen displays the selected camera connected to the DVR in
“SINGLE MODE”.

• Click <
The screen displays the selected camera connected to the DVR in
“QUAD MODE”.

> button.

> button.

CONNECTED DVR

The IP of the connected DVR will be displayed.
Select to turn the sound on/off.

` Connection failure message

M

No Response : Appears when the DVR does not respond.
Access Denied : Appears when the maximum number of users is exceeded.

` The number of simultaneous connection is limited to 2.

English _79

web viewer

SAVING THE LIVE SCREEN ON THE PC

• CAPTURE : Saves the current screen into a BMP or JPEG

file.

` The default saving path is “C:\Program Files\Samsung\Dvr

M

Web Viewer\SnapShot\Search”. To change the saving path,
click <SAVE PATH (
you want. For Windows Vista or 7, the saving path is “C:\
users\(user ID)\AppData\LocalLow\Samsung\DVR Web
Viewer\SnapShot\”.

` The file is automatically named as following : “IP address_Port number_YYYYMMDD_HHMMSS_camera number_

index”
Ex) 192.168.1.200_554_20110414_093118_01_00

• PRINT : Print out the current screen. It also prints IP

address, time, camera number and current event state.

)> button and then select the path

• RECORD : While in playback, press this button saves the

video data of the selected channel as an AVI file. (It is saved
in the designated folder on your PC.)
To stop recording, click this button again.

` To record it, it is required at least 1GB of available space.

M

` The default saving path is “C:\Program Files\Samsung\Dvr

Web Viewer\VideoClip\Search”. To change the saving path,
click <SAVE PATH ( )> button and then select the path you want. For Windows Vista or 7, the saving path is
“C:\users\(user ID)\AppData\LocalLow\Samsung\DVR Web Viewer\VideoClip\”.

` The file is automatically named as following : “IP address_Port number_YYYYMMDD_HHMMSS_camera number_

index”
Ex) 192.168.1.200_554_20110406_070455_01_00

` For AVI save, you need the H.264 codec for playing saved files.

80_ web viewer

SEARCHING THE RECORDED VIDEO IN THE CALENDAR

If the video data has been recorded on a date, the date is
distinguished in green. If you click the date, the recorded video
information is displayed in the time line. When you click
<Today>, it will be synchronized with the system time (date) of
the current PC.

SEARCHING THE RECORDED VIDEO IN THE TIMELINE

It displays the recorded video data status on the DVR after a date is
selected. The normal mode displays the time ranging from 0 to 24 Hours
while the extension mode displays the time every 2 hours.

[Normal Mode]

• If you click <

• Each time line represents 1 hour.

[Extension Mode]

• If you click <

• Each time line represents 5 minutes.

> button, it changes to the extension mode.

> button, it changes to the normal mode.

! WEB VIEWER

` The channels are ranging from CH01 to CH04.

M

English _81

web viewer

CONTROLLING PLAYBACK

a Fast Backward : Play the video reversely. (at x2 ~ x64)
b Reverse Play : Performs Reverse Play.
c Play : Performs playback.
d Fast Forward : Play the video forward. (at x2 ~ x64)
e Go to First :
f Step Backward : Performs one step reverseplay by one frame.
g Pause : Stops the playback temporarily.
h Step Forward : Performs one step forward by one frame.
i Go to Last : Moves the last time of recorded video in the time line.

` Only the admin account can play the audio signal during the playback.

M

Moves the beginning time of recorded video in the time line.

If using both web view and DVR set simultaneously, the audio signal will be
output from the DVR set.

VIEWER SETUP

You can configure the DVR settings remotely on the network.

To configure the DVR settings, click <Setup>.

System

You can configure the various settings of the DVR system.

Date/Time/Language

For more information, refer to <Date/Time/Language> in the <System Setup> menu. (Page 28)

1. Select <Date/Time/Language> in the System menu.

2. Configure the DVR settings according to your system

environment.

• Date/Time

Set the date and time.

82_ web viewer

• Time Synchronization Setup

Set the time synchronization.

• Display

Date Format : Set the date type.

Time : Select a time format to display on the screen.

• DST (Daylight Saving Time)

DST is displayed an hour ahead of the standard time of the
time zone.

• Language

Select a preferred language for the DVR.

Holiday

You can set specific dates to Holidays according to your
preferences.
For more information, refer to <Setting Holiday> in the
<System Setup> menu. (Page 29)

! WEB VIEWER

Permission Management

For more information, refer to <Permission Management> in the <System Setup> menu. (Page 30)

• Admin

You can change the admin ID or the password.

English _83

web viewer

• Group

Users are classified into groups and the permission can be
set according to the group.

` First of all, add a group.

• User

You can add, change or remove a user or users.

• Setup

You can set the user permission.

System Management

For more information, refer to <System Management> in the <System Setup> menu. (Page 34)

• System Information

You can see information of the current system.
Check the software version, broadcast format and
MAC address.

84_ web viewer

Device

You can check a list of devices that are connected to the DVR and configure the necessary settings.
Click <Device> in the menu screen.
For more information, refer to “Setting the Device”. (Page 38)

Camera

• Camera

You can configure the settings of the camera that is
connected to the DVR.

• Privacy Region

You can specify a certain area of the camera video to be
protected for your privacy.

! WEB VIEWER

• PTZ

You can configure the settings of the PTZ camera that is
connected to the DVR.
Set the ID and protocol.

English _85

web viewer

Storage Device

You can check and change the settings of the storage device.

• Device

You will see a list of storage devices that are connected to the
DVR.
You can check the type, used/total, usage and status of the
device.

• HDD Alarm

You can set the alarm output channel and the alarm duration
for an error.

Remote Device

You can see a list of remote devices including PTZ cameras

and system keyboards that are connected to the RS-485 port

of the DVR and configure the necessary settings.

86_ web viewer

Monitor

• Monitor

You can configure the monitoring screen settings and set the
output system.

• Spot Out

With the monitor connected via the SPOT port, if there occurs
an event such as Sensor, Motion, or Alarm, you can select a
video output mode for external monitoring.

! WEB VIEWER

• Mode

You can switch between live mode and play mode.

English _87

web viewer

Record

For more information, refer to <Setting the Recording>. (Page 45)

Recording Schedule

If you set a recording schedule for a specific date and time,
the recording will start at that specific time.

- Apply to All CH : Click <Apply to All CH> to display the

confirmation window.

Event Record Duration

You can set the start and end times of recording that will be
activated if an event occurs.

88_ web viewer

REC Quality & Resolution

• Standard/Event

You can set the resolution, frame rate and recording quality for
each channel.

Record Option

You can set the Disk End Mode.

! WEB VIEWER

Event

For more information, refer to <Setting the Event>. (Page 48)

Sensor Detection

You can set the sensor operation mode and the synchronized
camera as well as the alarm output type and the duration.

English _89

web viewer

Motion Detection

You can set the motion detection mode and the sensitivity
as well as the alarm output type and the duration.

• Motion Region

Set the target motion detection area

Video Loss Detection

You can set the alarm output time if a video loss occurs.

Alarm Schedule

You can schedule the alarm output according to the day of
the week and the time.
The default setting is Event Sync, which activates the alarm
only if an event occurs.

90_ web viewer

Network

For more information, refer to <Network Configuration>. (Page 52)

Connection

A remote user can access the DVR via the network to check
the current mode and the IP address.

• Connection

You can set the network connection route.

• Protocol

You can configure the protocol related settings.

DDNS

You can check the DDNS settings.

! WEB VIEWER

English _91

web viewer

Live Transfer

A remote user can set the images of the DVR.

• Live Transfer

You can specify the quality of the image data that a remote
user will receive.

Mailing Service

You can specify the SMTP server that sends a mail if an event occurs and set the recipient group and users.

• SMTP

You can set the server that sends mails and specify if you use
the authentication process.

• Event

You can set the event interval and specify which events the
server sends mails for.

92_ web viewer

• Group

You can add a group to receive the mail if an event occurs
and set the permission to receive the event mail for each
group.

• Recipient

You can add a user or users who will receive the mail.

! WEB VIEWER

ABOUT

Click <ABOUT>.

Displays the model name of connected DVR and the version
of Web Viewer.

English _93

web viewer

CONNECTING WEB VIEWER (Mac)

Safari on MAC.

If you want to use SRD-Series DVR Web Viewer with Safari Browser on a Mac, please refer to this user guide
and install Multi Viewer with firmware upgrade if necessary.

• Mac OS versions available : 10.6 or later version

• Silverlight : 5 or later

• Safari : 5 or later

1. Click [Click now to Install] to display the installation

screen as shown.

2. Double-click the [Silverlight.pkg] icon to display the

Silverlight plug-in installation screen as shown.

3. Click [Continue] to start installing Silverlight plug-in.

When done, you will see the screen as below.

4. Click [Close] to exit from the Silverlight plug-in installation

screen.

94_ web viewer

• If Microsoft Silverlight plug-in is already installed

1. Use a web browser to connect to the DVR.

2. If Silverlight plug-in is already installed, you will see the

login screen as shown.

3. If the login screen does not appear, check if the DVR set is

connected properly with a valid IP address.

` If automatic proxy is activated and an invalid DNS server is specified while configuring network, the Internet access

M

may not be available.

` For more details on using the Web Viewer, please refer to “

USING LIVE VIEWER (Mac)

a
c

d
e

f
g
h

i

j

Connecting Web Viewer (Windows)

b

! WEB VIEWER

”. (Page 71)

k

The Live Viewer screen consists of following :

Menu Functions

Name, Address

a

Menu Selection

b

Split Mode Selection

c

Displays a connected DVR’s IP address and model name.

Consists of <

These buttons are used for the screen split and full screen mode.

LIVE

` Supports up to a maximum of 9 channels due to performance constraints of Silverlight

> , <

ABOUT

> and <

LOGOUT

> menu.

English _95

web viewer

Menu Functions

Name, Address

d

Audio

e

DVR Time, PC Time

f

Change Channel

g

CAPTURE

PRINT

h

RECORD

Channel

i

PTZ

j

Display Pane

k

Displays a connected DVR’s IP address and model name.

Sets the sound connected to each channel to ON/OFF.

Select <

DVR Time

Viewer.

Switches into previous/next channel or perform Auto Sequence.
Click Auto Sequence button to display the Time Interval Selection menu.

Saves current video for selected channel in designated path.

Prints current video image for selected channel through designated printer.

Starts and stops recording.
If you cannot play the file recorded from the web, please install the H.264 CODEC.
ex) MAC: perian_1.2.3.dmg (http://perian.org)

Indicates connected DVR's channels.

Controls connect PTZ camera(s).

Displays the video of camera connected to DVR.

> or <

> for the OSD time information display setting of the Live

PC Time

96_ web viewer

MOBILE VIEWER

What is Mobile Viewer?

Mobile Viewer is management software that enables you to connect to DVR (Digital Video Recorder) remotely
and control the video playback and PTZ operations (if confi gured) in real time.

Key Features

• Remote access via Smart phone

• Voice Recognition

• 1-split and 4-split modes supported in Live Viewer

• Supports single channel search function

• Switch channels using the touch-sensitive LCD panel

• PTZ camera operations supported

(complies with the protocol of the connected DVR)

• Up to 16 channels supported

Compatible Smartphone

This application is optimized for

• iOS v5.1, v6.0, v6.1 (iPhone 4/5, iPad 3/4)

• Android OS v2.3, v4.0, v4.1 (Galaxy S2/S3, Galaxy Note)

` For more information, refer to the user manual.

M

(http://www.samsungcctv.com)

2.X

20xx. xx. xx

! WEB VIEWER

English _97

backup viewer

SEC BACKUP VIEWER

You can play a file that is backed up in the format of SEC.

Backup in SEC format produces backup data file, library file and self-executable viewer file.

If you run the backup file viewer, the backup data file will be automatically played.

a b c

SRD-443_CAM 01 2013-01-01 21:47:00

d e f

Recommended System Requirements

PCs with a lower specification than the recommended below may not fully support forward/backward and
high-speed playback.

• OS : Windows XP professional, Windows Vista, Windows 7

• CPU : Intel i5 2.8GHz or faster

• RAM : DDR PC-3200 1G or more

• VGA : Geforce 6200 or higher

98_ backup viewer

ghj i

a

b

Part Names Functions

Set the screen’s aspect ratio to be displayed.

Split Screen

The screen switches to the selected split screen mode.

` Split screen function is not supported during the CD/DVD backup.

Saves the current video’s image as in an image file. Supports jpeg file format.

Screen Printout

Prints out the current screen. You should have installed the appropriate printer
driver before you can print out the screen.

! BACKUP VIEWER

/

c

d

e

f

g

h

i

Audio

Watermark

Deinterlace You can enable the De-interlace function.

Show OSD

Enlarge /

Reduce Timeline

Restore Timeline Restores the timeline to the default.

Display of storage time range

/

A toggle button. Each time you press this button, the audio output will toggle
between activated and deactivated.

You can adjust the volume level from 0 to 100.

Press the button to enable file tampering detection, to detect data file forging.

Check the OSD checkbox to display the OSD information on the backup playback
screen.
Information such as backup date, day of the week, time, model name, and
channel number will be displayed on the screen.

Collapses the time range that is displayed on the range bar of the storage time.
You can collapse the range bar until the overall range is shortened to
24 hours.

Enlarges the time range that is displayed on the range bar of the storage time.
You can enlarge the range bar until the overall range is extended to
1 minute.

Displays the time range of a stored video file.
You can move the gridline of the range bar to select a time point to play.

Playback Control You can adjust the video playback of the timeline.

j

` If it has a high recording rate and is played at high speed playback of 16x or higher speed in the backup viewer,

M

actual playback speed may not reach the set playback speed.

English _99

appendix

PRODUCT SPECIFICATION

Item Details

Video

Live

Performance

Operating System Embedded Linux

Recording

Search & Playback

Network

Smartphone

Inputs 4 composite video 0.5–1 Vpp, 75 ohm

Resolution 720x480 NTSC, 720x576 PAL

Frame rate 120fps NTSC, 100fps PAL

Resolution 720x480 NTSC, 720x576 PAL

Multi Screen display 1, 4, SEQUENCE, PIP

Compression H.264

Record Rate

Mode

Overwrite modes Selectable (Stop/Continuous)

Pre-Alarm Up to 5sec.

Post-Alarm Up to 6 hour. (5, 10, 20, 30 sec, 1, 3, 5, 10, 20 min,1, 2, 3, 4, 5, 6 hour)

Search mode

Playback function Fast Forward/Backward, Slow Forward/Backward, Step Forward/Backward

Transmission speed

Bandwidth

Bandwidth control

Stream H.264(CIF)

Maximum No. of remote
users

Protocol support TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP

Monitoring Webviewer, CMS(Smart viewer)

Smartphone Support

Protocol support RTP, RTSP, HTTP, CGI

Remote users Maximum Live(1)

NTSC : Up to 30fps @ 704x480 / PAL : Up to 25fps @ 704x576 : 4CIF(L)

NTSC : Up to 60fps @ 704x240 / PAL : Up to 50fps @ 704x288 : 2CIF(M)

NTSC : Up to 120fps @ 352x240 / PAL : Up to 100fps @ 352x288 : CIF(S)

NTSC : Manual, Schedule (Continuous/Event), Event (Pre/Post)

PAL : Manual, Schedule (Continuous/Event), Event (Pre/Post)

Date/time, Event, Back up, Motion

100 / 120fps

Up to (4)Mbps, Unlimited(4M)/2/1.5/1 Mbps/800/600/500/400/300/200/
100/50 kbps

Automatic

Search(2) / Live Unicast(4) / Live Multicast(20)

100_ appendix
