SAMSUNG SR294MIS User Manual

REFRIGERATOR

OWNER`S INSTRUCTIONS

Before operating the unit, please read this
manual thoroughly, and retain for future
reference.

ENGLISH

RT30G/RT30S/RT30D

RT34G/RT34S/RT34D

RT37G/RT37S/RT37D

RT31G/RT31S/RT31D

RT35G/RT35S/RT35D

RT38G/RT38S/RT38D

FEATURES

Large freezer storage area

- Stores large quantities of food in the
freezer.

Jumbo storage guard

- Holds large bottles securely.

Adjustable storage guards

- Position them for your convenience and
according to the height of your food

containers.

Safety pocket (option*)

- Store safely due to the locking system

that makes children not open it easily.

Silver Plus Deodorizer (option*)

- Powerful deodorizer through catalyst.

UV LED/PHOTOSYNTHESIS LED
(option*)

- Using the LED system, the contents in
chilled room and vegetable bin have
increased Chlorophyll and vitamin
contents. Also this system makes
contents in container more fresh.

Fresh Bread Zone (option*)

- Some kind of bread for long.

2
5
5

6

7

7

7

7

8

9

9
10
10
10
10
11
11
11
10
11
12
13
14
14

Remark :
* There is not some option according to
the model and country.

1

2

3

4

Energy Saving Tips

• Install the appliance in a cool, dry room with
adequate ventilation. Ensure that it is not
exposed to direct sunlight and never put it
near a direct source of heat
(radiator, for example).

• Never block any vents or grilles on the appliance.

• Allow warm food to cool down before placing
it in the appliance.

• Put frozen food in the refrigerator to thaw.
Then you can use the low temperatures of the
frozen products to cool food in the refrigerator.

• Do not keep the door of the appliance open for
too long when putting food in or taking food out.
The shorter time for which the door is open,
the less ice will form in the freezer.

• Allow clearance to the right, left, back and top
when installing. This will help reduce power
consumption and keep your energy bills lower.

5

Glass shelf model

Wire shelf model

hen the Refrigerator / Freezer
is not operating or the food
does not freeze suffciently:

- Is the plug properly connected?

- Is the power fuse blown?

- Are the temperature controls
set properly (not set to
“COLD”)?

- Is the appliance exposed to
direct sunlight or installed near
a heater?

- Does the appliance have
enough clearance from the wall
in all directions?

When food freezes in the
refrigerator:

- Are the temperature controls
set properly (not set to
“COLDER”)?

- If the food is juicy or very
moist, is the tem perature
control set to “COLDER”)?

- Is the ambient temperature
too low?

When there is noise from the
unit:

- Is the refrigerator installed on
a flat, stable surface?

- Is the appliance positioned too
close to a wall?

- Are there any objects behind or
under the refrigerator?

- Is the sound coming from the
compressor?

When the rear or side panel of
the refrigerator is hot:

- Is a radiation (air
ventilator/cooler) pipe
installed?

- Is the ambient temperature
high?

- How dew formed on the out
side of the appliance
because of high humidity?

hen you hear a sound like

water flowing:

- This sound is generated by
movement of the refrigerant
and is not a malfunction.

When you notice a foul odor
inside the appliance:

- Do you have spoiled food in
the refrigerator?

- Is all food stored in sealed
containers?

- Has fluid collected in the bot
tom of the vegetable bin?

- Are the freezer evaporation
slots clogged?

- Has the evaporation tray at the
back of the appliance become
foul?

When frost develops inside
the freezer:

- Does the door seal tightly?

- Are the evaporation slots
clogged?

- Is there enough room for effi
cient air circu lation?

When dow develops on the
vegetable compartment:

- Does the door seal tightly?

- Have you left the door open for
a long time?

- Is liquid stored without a
cover?

BEFORE CALLING SERVICE

W

W

14

Model name Depth (mm) Width (mm)

RT30/31/34/35 1

008 1015

RT37/38 1

058 1015

Manual_english_REV 0.1_page 21.pdf 7/15/2008 4:32:53 PM

ERP

• Do not attempt to repair, disassemble, or modify the appliance by yourself.

- Do not use any fuse (such as cooper, steel wire, etc.) other than the standard fuse.

- When repairing or reinstalling the appliance is required, contact your nearest service center.

- Failing to do so may result in electric shock, fire, problems with the product, or injury.

• The installation or any service of this appliance is recommended by a qualified technician or service company.

- Failing to do so may result in electric shock, fire, an explosion, problems with the product, or injury.

• This refrigerator must be properly installed and located in accordance with the manual before it is used.
Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops).

• Do not pull the power cord, when unplugging the power plug.

- Unplug the power plug by holding the plug firmly and pull straight out from the outlet.

- Failing to do so may result in electric shock or fire.

• Plug the power plug into the wall socket in the right direction so that the cord runs towards the floor.

- If you plug the power plug into the socket in the opposite direction, the electric wires within the cable may be damaged
and this may result in electric shock or fire.

• Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between
objects, or push the power cord into the space behind the appliance.

- This may result in electric shock or fire.

• Plug the power plug into the wall socket firmly. Do not use a damaged power plug, damaged power cord or loose wall
socket.

- This may result in electric shock or fire.

• If the appliance generates a strange noise, a burning or smell or smoke, unplug the power plug immediately and contact
your nearest service centre.

- Failing to do so may result in electric or fire hazards. Keep ventilation opening in the appliance enclosure or mounting
structure clear of obstruction.

• If any foreign substance such as water has entered the appliance, unplug the power plug and contact
your nearest service center.

- Failing to do so may result in electric shock or fire.

• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the
refrigerator for removing bad odors.

- This may result in electric shock or fire.

• In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the power plug.
Do not touch the appliance or power cord.

- Do not use a ventilating fan.

- A spark may result in an explosion or fire.

• Do not place food inside the refrigerator in a haphazard way.

- The food will not cool properly.

CE Notice (European Union)

• This product has been determined to be in compliance with the Low Voltage Directive (2006/95/EC),
the Electromagnetic Compatibility Directive (2004/108/EC) and the Eco-Design Directive(2009/125/EC)
implemented by Regulation (EC) No 643/2009 of the European Union.
