Samsung SPHP500 User Manual
DRAFT
FOR INTERNA L USE ONLY
This document is watermarked because certain important information in the document has not yet been verified. This document has been
sent to you as a draft and for informational purposes only. The document should only be used for internal purposes and may not be
distributed outside of Samsung, except to Samsung's carrier customer for testing purposes. Distributing the document outside of
Samsung, except to Samsung's carrier customer for testing purposes could result in legal exposure to the company if the preliminary,
unverified information in the draft turns out to be inaccurate.
SPH-P500
User Guide
©2012 Sprint. Sprint and the logo are trademarks of Sprint. Other marks are trademarks of their
respective owners.
DRAFT
FOR INTERNA L USE ONLY
Table of Contents
Get Started ................................................................................................................................ 1
Your Device at a Glance ..................................................................................................... 1
Set Up Your Device ............................................................................................................ 1
Activate Your Device ........................................................................................................... 3
Complete the Setup Application .......................................................................................... 4
Sprint Account Information and Help ................................................................................... 5
Sprint Account Passwords ........................................................................................... 5
Manage Your Account ................................................................................................. 6
Device Basics ............................................................................................................................ 7
Your Device’s Layout .......................................................................................................... 7
Key Functions .............................................................................................................. 7
Turn Your Device On and Off .............................................................................................. 9
Turn Your Screen On and Off ............................................................................................. 9
Touchscreen Navigation ..................................................................................................... 9
Your Home Screen ............................................................................................................11
Creating Shortcuts ......................................................................................................11
Adding and Removing Primary Shortcuts ...................................................................12
Adding and Removing Widgets ...................................................................................13
Extended Home Screens ............................................................................................13
Recently Used Applications ........................................................................................14
Mini App Tray .............................................................................................................14
Status Bar ..........................................................................................................................15
Enter Text ..........................................................................................................................16
Touchscreen Keyboards .............................................................................................17
Text Input Methods .....................................................................................................17
Keyboard Input Options ..............................................................................................18
Text Entry Options ......................................................................................................20
Predictive Text ............................................................................................................21
Google Voice Typing ..................................................................................................22
Tips for Editing Text ....................................................................................................23
TOC i
DRAFT
FOR INTERNA L USE ONLY
Settings .....................................................................................................................................25
Wi-Fi Settings ....................................................................................................................26
Advanced Wi-Fi Settings.............................................................................................26
Bluetooth Settings ..............................................................................................................26
Data Usage Settings ..........................................................................................................26
More Settings.....................................................................................................................27
Flight Mode .................................................................................................................27
Mobile Networks .........................................................................................................28
Tethering ....................................................................................................................28
Wi-Fi Direct .................................................................................................................29
VPN ............................................................................................................................30
Nearby Devices ..........................................................................................................31
Roaming .....................................................................................................................31
Sound Settings ..................................................................................................................32
Volume .......................................................................................................................32
Default Notifications ....................................................................................................33
Touch Sounds ............................................................................................................33
Screen Lock Sounds ...................................................................................................33
Display Settings .................................................................................................................33
Brightness ..................................................................................................................33
Screen Timeout ..........................................................................................................33
Auto-rotate Screen ......................................................................................................34
Font Style ...................................................................................................................34
Font Size ....................................................................................................................34
Auto Adjust Screen Tone ............................................................................................34
Quick Launch ..............................................................................................................34
Wallpaper Settings .............................................................................................................35
Home Screen Wallpaper .............................................................................................35
Lock Screen Wallpaper ...............................................................................................35
Home and Lock Screens Wallpaper ............................................................................35
Power Saving Settings .......................................................................................................36
Storage Settings ................................................................................................................37
Device Memory ...........................................................................................................37
TOC ii
DRAFT
FOR INTERNA L USE ONLY
SD Card ......................................................................................................................38
Battery Settings .................................................................................................................39
Battery Use .................................................................................................................39
Application Manager ..........................................................................................................39
Manage Applications ..................................................................................................39
Running Services........................................................................................................40
Memory Use ...............................................................................................................40
Accounts and Sync Settings ..............................................................................................40
Set Up a New Account ................................................................................................40
Manage Existing Accounts ..........................................................................................41
Location Services Settings .................................................................................................41
Use Location Services ................................................................................................41
Use GPS Satellites .....................................................................................................42
Location and Google Search ......................................................................................42
Security Settings ................................................................................................................42
Screen Lock................................................................................................................42
Encrypt Device ...........................................................................................................45
Encrypt SD card .........................................................................................................45
Make Passwords Visible .............................................................................................46
Device Administrators .................................................................................................46
Unknown Sources.......................................................................................................46
Trusted Credentials ....................................................................................................47
Install from Device Storage .........................................................................................47
Clear Credentials ........................................................................................................47
Language and Input Settings .............................................................................................47
Language ...................................................................................................................47
Default Input Method ..................................................................................................48
Android Keyboard .......................................................................................................48
Google Voice Typing ..................................................................................................48
Samsung Keyboard ....................................................................................................48
T9 Trace .....................................................................................................................49
Voice Search ..............................................................................................................50
Text-to-speech Output ................................................................................................50
TOC iii
DRAFT
FOR INTERNA L USE ONLY
Pointer Speed .............................................................................................................51
Back Up and Reset Settings ..............................................................................................51
Mobile Backup and Restore ........................................................................................51
Factory Data Reset .....................................................................................................52
Accessory Settings ............................................................................................................52
Date and Time Settings .....................................................................................................52
Accessibility Settings .........................................................................................................53
TalkBack Settings .......................................................................................................54
Developer Options Settings ...............................................................................................55
USB Debugging ..........................................................................................................55
Development Device ID ..............................................................................................55
Allowing Mock Locations.............................................................................................55
Desktop Backup Password .........................................................................................55
User Interface Options ................................................................................................56
Application Options .....................................................................................................56
System Update Settings ....................................................................................................56
Update PRL ................................................................................................................57
Update Profile .............................................................................................................57
Update Samsung Software .........................................................................................57
Update Firmware ........................................................................................................57
About Device .....................................................................................................................58
Status .........................................................................................................................58
Legal Information ........................................................................................................58
Contacts....................................................................................................................................59
Get Started With Contacts .................................................................................................59
Access Contacts .........................................................................................................59
The Contacts List ........................................................................................................60
Add a Contact ....................................................................................................................61
Edit a Contact ....................................................................................................................62
Add or Edit Information for a Contact ..........................................................................63
Assign a Stored Picture to a Contact ..........................................................................63
Assign a New Picture to a Contact ..............................................................................63
Join a Contact .............................................................................................................64
TOC iv
DRAFT
FOR INTERNA L USE ONLY
Delete a Contact .........................................................................................................64
Synchronize Contacts ........................................................................................................64
Add Entries to Your Favorites ............................................................................................66
Add Facebook Content to Your Contacts ...........................................................................66
Add Your Facebook Friends to Your Contacts ............................................................66
Create Groups ...................................................................................................................67
Share a Contact .................................................................................................................67
Accounts and Messaging ..........................................................................................................69
Gmail / Google ...................................................................................................................69
Create a Google Account ............................................................................................69
Sign In to Your Google Account ..................................................................................70
Access Gmail ..............................................................................................................70
Send a Gmail Message ..............................................................................................71
Read and Reply to Gmail Messages ...........................................................................71
Email .................................................................................................................................72
Add an Email Account ................................................................................................72
Add a Corporate Email Account ..................................................................................73
Compose and Send Email ..........................................................................................74
View and Reply to Email .............................................................................................75
Manage Your Email Inbox ...........................................................................................75
Corporate Email Features ...........................................................................................76
Edit Email Account Settings ........................................................................................77
Delete an Email Account.............................................................................................80
Add the Mail Widget ....................................................................................................80
Social Networking Accounts ...............................................................................................80
Facebook ....................................................................................................................80
YouTube .....................................................................................................................81
Google Talk ................................................................................................................81
Applications and Entertainment .................................................................................................83
DivX ...................................................................................................................................83
DivX Legal Information ...............................................................................................83
Locating Your VOD Registration Number ...................................................................84
Register Your DivX Device for VOD Playback of Purchased Movies...........................84
TOC v
DRAFT
FOR INTERNA L USE ONLY
Google Play Store App ......................................................................................................85
Find and Install an App ...............................................................................................86
Create a Google Checkout Account ............................................................................86
Request a Refund for a Paid App ...............................................................................87
Open an Installed App ................................................................................................87
Uninstall an App .........................................................................................................87
Get Help with Google Play ..........................................................................................87
Navigation ..........................................................................................................................88
Google Maps ..............................................................................................................88
TelenavTM GPS Navigation .........................................................................................89
Installing TeleNav GPS Navigator ...............................................................................89
Registering TeleNav GPS Navigator ...........................................................................90
TeleNav: Using TeleNav GPS Navigator ....................................................................90
TeleNav: Getting Driving Directions ............................................................................91
TeleNav: Creating a Favorites Location ......................................................................92
TeleNav: Sharing a Recent Location with Others ........................................................92
TeleNav: Configuring Your Navigation Preferences ....................................................92
Google Navigation ......................................................................................................94
Latitude .......................................................................................................................94
Music .................................................................................................................................94
Sprint Music Plus ........................................................................................................95
Music Player ...............................................................................................................95
Google Play Music ......................................................................................................96
Google Play Movies ...........................................................................................................99
Sprint TV & Movies ............................................................................................................99
AllShare Play ................................................................................................................... 100
Configuring AllShare Settings ................................................................................... 101
Setting Up Web Storage ........................................................................................... 102
Sharing Files via Web Storage.................................................................................. 102
Sharing Media via AllShare Play to a Target Device ................................................. 103
AllShare Play Screen Sharing via Group Cast .......................................................... 104
Peel Smart Remote.......................................................................................................... 104
Flipboard .......................................................................................................................... 104
TOC vi
DRAFT
FOR INTERNA L USE ONLY
Media Hub ....................................................................................................................... 104
Creating a New Media Hub Account ......................................................................... 105
Using Media Hub ...................................................................................................... 105
Media Hub Notices ................................................................................................... 106
NASCAR Sprint Cup Mobile ............................................................................................. 107
Web and Data ......................................................................................................................... 109
Wi-Fi ................................................................................................................................ 109
Turn Wi-Fi On and Connect to a Wireless Network ................................................... 109
Check the Wireless Network Status .......................................................................... 110
Connect to a Different Wi-Fi Network ........................................................................ 111
Data Services (Sprint 3G) ................................................................................................ 111
Your Data Services User Name ................................................................................ 111
Launch a Web Connection ........................................................................................ 112
4G Services ..................................................................................................................... 112
Virtual Private Networks (VPN) ........................................................................................ 113
Prepare Your Device for VPN Connection ................................................................ 113
Set Up Trusted Credential Storage ........................................................................... 113
Add a VPN Connection ............................................................................................. 113
Connect to a VPN ..................................................................................................... 114
Disconnect from a VPN ............................................................................................ 114
Browser ........................................................................................................................... 114
Learn to Navigate the Browser ................................................................................. 115
Browser Menu .......................................................................................................... 116
Select Text on a Web Page ...................................................................................... 117
Go to a Specific Website........................................................................................... 117
Adjust Browser Settings ............................................................................................ 118
Reset the Browser to Default .................................................................................... 120
Set the Browser Home Page .................................................................................... 120
Create Bookmarks .................................................................................................... 121
Create a New Homepage ......................................................................................... 121
Add Bookmarks to Your Home Screen ..................................................................... 121
Sprint Hotspot .................................................................................................................. 122
Camera and Video .................................................................................................................. 124
TOC vii
DRAFT
FOR INTERNA L USE ONLY
Take Pictures ................................................................................................................... 124
Open the Camera ..................................................................................................... 124
Viewfinder Screen..................................................................................................... 124
Review Screen ......................................................................................................... 125
Take a Picture .......................................................................................................... 126
Close the Camera ..................................................................................................... 127
Record Videos ................................................................................................................. 127
Camera Settings .............................................................................................................. 127
Change Advanced Settings ...................................................................................... 128
Camcorder Settings ......................................................................................................... 130
Change Advanced Settings ...................................................................................... 130
View Pictures and Videos Using Gallery .......................................................................... 131
Open Gallery ............................................................................................................ 131
View Photos and Videos ........................................................................................... 131
Zoom In or Out on a Photo ....................................................................................... 132
Watch Video ............................................................................................................. 132
Working with Photos ........................................................................................................ 133
Rotate and Save a Photo .......................................................................................... 133
Crop a Photo ............................................................................................................ 133
Photo Editor ..................................................................................................................... 133
Installing the Application from Samsung Apps .......................................................... 133
Using Photo Editor .................................................................................................... 134
Share Photos and Videos ................................................................................................ 135
Send Photos or Videos by Email ............................................................................... 135
Send a Photo or Video by Multimedia Message ........................................................ 135
Send Photos or Videos Using Bluetooth ................................................................... 136
Share Photos or Videos on Google+ ......................................................................... 136
Share Photos on Picasa ........................................................................................... 136
Share Videos on YouTube ........................................................................................ 137
Tools and Calendar ................................................................................................................. 138
Calendar .......................................................................................................................... 138
Add an Event to the Calendar ................................................................................... 138
Event Alerts .............................................................................................................. 140
TOC viii
DRAFT
FOR INTERNA L USE ONLY
View Events .............................................................................................................. 141
Erase Events ............................................................................................................ 142
Alarm & Timer .................................................................................................................. 142
Calculator ........................................................................................................................ 143
World Clock ..................................................................................................................... 144
Memo .............................................................................................................................. 144
View the Memo Screen ............................................................................................. 144
Create a New Memo ................................................................................................. 145
S Suggest ........................................................................................................................ 146
My Files ........................................................................................................................... 147
Dropbox ........................................................................................................................... 147
Download the Desktop Application ........................................................................... 147
Accessing Dropbox on Your Device .......................................................................... 148
Manually Uploading a Picture to Dropbox ................................................................. 149
Voice Services ................................................................................................................. 149
S Voice ..................................................................................................................... 149
Voice Recorder ......................................................................................................... 149
Bluetooth ......................................................................................................................... 150
Turn Bluetooth On or Off........................................................................................... 151
The Bluetooth Settings Menu .................................................................................... 151
Change the Device Name ......................................................................................... 151
Connect a Bluetooth Headset or Car Kit ................................................................... 151
Reconnect a Headset or Car Kit ............................................................................... 152
Disconnect or Unpair from a Bluetooth Device .......................................................... 152
Send Information Using Bluetooth ............................................................................ 153
Receive Information Using Bluetooth ........................................................................ 154
microSD Card .................................................................................................................. 155
Remove the microSD Card ....................................................................................... 155
Insert a microSD Card .............................................................................................. 156
View the microSD Card Memory ............................................................................... 157
Format the microSD Card ......................................................................................... 157
Unmount the microSD Card ...................................................................................... 157
Update Your Device ......................................................................................................... 158
TOC ix
DRAFT
FOR INTERNA L USE ONLY
Update Your Device Firmware .................................................................................. 158
Update Your Android Operating System ................................................................... 160
Update Your Profile .................................................................................................. 160
Update Your PRL ..................................................................................................... 160
Index ....................................................................................................................................... 161
TOC x
DRAFT
FOR INTERNA L USE ONLY
Get Started
The following topics give you all the information you need to set up your device and Sprint
service the first time.
Your Device at a Glance
Set Up Your Device
Activate Your Device
Sprint Account Information and Help
Your Device at a Glance
The following illustration outlines your device’s primary external features and buttons.
Set Up Your Device
You must first install and charge the battery to begin setting up your device.
1. Plug the USB connector into the charger/accessory jack on the bottom of your device.
Warning! While the device is charging, if the touch screen does not function due to an
unstable power supply, unplug the USB power adapter from the power outlet or
unplug the USB cable from the device.
Settings 1
DRAFT
FOR INTERNA L USE ONLY
2. Plug the AC adapter into an electrical outlet and charge your battery. Fully charging a
battery may take up to three hours.
Note: Your device’s battery should have enough charge for the device to turn on and find a
signal, run the setup application, set up voicemail, and make a connection. You should fully
charge the battery as soon as possible.
3. Press the Power button to turn the device on.
Settings 2
DRAFT
FOR INTERNA L USE ONLY
If your device is activated, it will turn on, search for Sprint service, and begin the
setup application.
If your device is not yet activated, see Activate Your Device for more information.
Activate Your Device
Depending on your account or how and where you purchased your device, it may be ready to
use or you may need to activate it on your Sprint account.
● If you purchased your device at a Sprint Store, it is probably activated and ready to use.
● If you received your device in the mail and it is for a new Sprint account or a new line of
service, it is designed to activate automatically.
When you turn the device on for the first time, you should see a Hands Free
Activation screen, which may be followed by a PRL Update screen and a Firmware
Update screen. Follow the onscreen instructions to continue.
● If you received your device in the mail and you are activating a new device for an
existing number on your account (you’re swapping devices), you can activate on your
computer online or directly on your device.
Activate on your computer:
• Go to
device.
Activate on your device:
• Turn on your new device. (Make sure the old one is turned off.) Your device will
automatically attempt Hands-Free Activation.
Settings 3
sprint.com/activate and complete the online instructions to activate your
DRAFT
FOR INTERNA L USE ONLY
• Tap Activate to override auto-activation and start the manual activation wizard.
• Follow the onscreen prompts to complete the activation process.
● To confirm activation, make a device mobile data connection. If your device is still not
activated or you do not have access to the Internet, contact Sprint Customer Service at
1-888-211-4727 for assistance.
Tip: Do not press the Power button while the device is being activated. Pressing the Power
button cancels the activation process.
Note: If you are having any difficulty with activation, contact Sprint Customer Service by calling
1-888-211-4727 from any other device.
Complete the Setup Application
The Setup application helps you set up certain features and preferences on your device. Once
your device has been turned on and activated, you will see a Welcome message. You can then
complete the Setup application.
Note: You may be able to complete the setup application before your device has been
activated on your Sprint account.
1. Once your device is activated, you will see the Welcome screen. Tap Start to get
started.
2. Follow the onscreen instructions to complete each section. For each topic, you will have
an option to skip it and continue to the next screen.
Make it Google - Complete the steps to sign in to your current Google account, or
Backup or Backup and Restore - Select your Google account backup settings. If
tap Get an account to sign up for a new Google account right from your device.
• Sign in - Enter your Gmail address and password and tap Sign in to sign in to
your current Google account.
• Get an account - Follow the instructions to sign up for a new Google account.
There will be screens to enter your first and last names, create an email address
(Gmail), create a password, enter recovery information (including a backup email
address and a recovery question in case you forget your Google account sign-in
information), an option to join Google+, and an option to enable purchases from
the Google Play Store app. Tap Next between each screen.
you're signing in with an existing Google account, you can elect to restore your
Google account information, such as apps, bookmarks, Wi-Fi passwords, and
contacts, to your new Samsung Galaxy Tab2 10.1. Tap Next to continue.
Settings 4
DRAFT
FOR INTERNA L USE ONLY
Use Google location - Select your Google location options and tap Next.
This device belongs to... - If applicable, enter your first and last name and tap
Next. This information is used by the device to personalize some apps.
3. When you see the Setup complete screen, tap Finish to continue to the Dropbox
screen.
4. From the Dropbox screen, select an option and follow the onscreen instructions.
Create a new Dropbox account - Tap to set up a Dropbox account to save your
photos and videos to associated computers and to a Web-based storage area.
I already have an account - Tap to sign in to your current Dropbox account.
No thanks - Tap to skip the Dropbox setup screens.
5. Once you have completed the Dropbox screens, you may see a Sprint Connections
Optimizer notice.
Read the notice and tap I Agree to allow your device to automatically connect to
available configured Wi-Fi networks.
Tap Settings and uncheck the Sprint automatic connection option if you do not
wish to use the Sprint Connections Optimzer.
6. Your setup is now complete. Follow the onscreen instructions to learn about basic
touch/tap menu navigation.
Sprint Account Information and Help
Find out about account passwords and information about managing your account and finding
help.
Sprint Account Passwords
Manage Your Account
Sprint Support Services
Sprint Account Passwords
As a Sprint customer, you enjoy unlimited access to your personal account information, your
voicemail account, and your data services account. To ensure that no one else has access to
your information, you will need to create passwords to protect your privacy.
Account User Name and Password
If you are the account owner, you will create an account user name and password when you
sign on to
Settings 5
sprint.com. (Click Sign in/Sign up and then click Sign up now! to get started.) If you
DRAFT
FOR INTERNA L USE ONLY
are not the account owner (if someone else receives the bill for your Sprint service), you can get
a sub-account password at
Voicemail Password
You’ll create your voicemail password when you set up your voicemail. See Set Up Voicemail
for more information on your voicemail password.
Data Services Password
With your Sprint device, you may elect to set up an optional data services password to control
access and authorize Premium Service purchases.
For more information, or to change your passwords, sign on to sprint.com or call Sprint
Customer Service at 1-888-211-4727.
sprint.com.
Manage Your Account
Manage your Sprint account from your computer, your Sprint device, or any other device.
Online:
From Any Other Device
sprint.com
● Access your account information.
● Check your minutes used (depending on your Sprint service plan).
● View and pay your bill.
● Enroll in Sprint online billing and automatic payment.
● Purchase accessories.
● Shop for the latest Sprint devices.
● View available Sprint service plans and options.
● Learn more about data services and other products like games, ring tones, screen
savers, and more.
● Sprint Customer Service: 1-888-211-4727.
● Business Customer Service: 1-888-788-4727.
Settings 6
DRAFT
FOR INTERNA L USE ONLY
Device Basics
Your device is packed with features that simplify your life and expand your ability to stay
connected to the people and information that are important to you. The following topics will
introduce the basic functions and features of your device.
Your Device’s Layout
Turn Your Device On and Off
Turn Your Screen On and Off
Touchscreen Navigation
Customize the Home Screen
Status Bar
Enter Text
Your Device’s Layout
The following illustrations outline your device’s basic layout.
Key Functions
The following list defines the features listed in the above illustrations.
Front View
● External Speakers used in music or video playback, notification tones, and for other
sounds.
Settings 7
DRAFT
FOR INTERNA L USE ONLY
● Light Sensor controls screen brightness automatically and when taking photos with the
Front-facing Camera.
● Front-facing Camera Lens: allows you to take photos or video recordings of the person
holding the device face-forward. The subject of the photo or video will be the person
looking at the screen.
● Display Screen: The orientation of the display screen rotates with the tablet as you turn
it. You can turn this feature on and off.
Top View
● 3.5 mm Headset Jack allows you to plug in either a stereo headset or an optional
headset for convenient, hands-free conversations.
● Infrared Blaster emits infrared signals used for controlling external devices. For more
information, see
● MicroSD Card Slot
● Volume Buttons allow you to adjust the ringtone or media volume.
Peel Smart Remote.
● Power/Lock Button lets you turn the device on or off, turn the screen on or off, enable
or disable data network mode or airplane mode, or restart the device.
Back and Bottom Views
● Camera lens lets you take pictures and videos.
● Flash helps illuminate subjects in low-light environments when the camera is focusing
and capturing a photo or video.
Settings 8
DRAFT
FOR INTERNA L USE ONLY
● Microphone allows other callers to hear you when you are using the speaker device.
● Charger/Accessory Jack allows you to connect the device charger/USB cable
(included).
Turn Your Device On and Off
The instructions below explain how to turn your device on and off.
Turn Your Device On or Off
► Press and hold .
Your screen remains blank while your device is off (unless the battery is charging).
Turn Your Screen On and Off
Your device allows you to quickly turn the screen off when not in use and to turn it back on and
unlock it when you need it.
Turn the Screen Off When Not in Use
► To quickly turn the screen off, press the Power button. Pressing the Power button again
will turn on your device screen and show the lock screen.
To save battery power, the device automatically turns off the screen after a certain period of
time when you leave it idle. You will still be able to receive messages and mobile data connections
while the device’s screen is off.
Note: For information on how to adjust the time before the screen turns off, see Screen
Timeout
Turn the Screen On and Unlock It
1. To turn the screen on, press .
2. Swipe the screen in any direction to unlock the screen.
If you have set up a screen lock, you will be prompted to draw the pattern or enter
.
the password or PIN. See Screen lock.
Touchscreen Navigation
Your device’s touchscreen lets you control actions through a variety of touch gestures.
Tap
When you want to type using the onscreen keyboard, select items onscreen such as application
and settings icons, or press onscreen buttons, simply tap them with your finger.
Settings 9
DRAFT
FOR INTERNA L USE ONLY
<Insert Image>
Touch and Hold
To open the available options for an item (for example, a contact or link in a Web page), touch
and hold the item.
<Insert Image>
Swipe or Slide
To swipe or slide means to quickly drag your finger vertically or horizontally across the screen.
<Insert Image>
Drag
To drag, touch and hold your finger with some pressure before you start to move your finger.
While dragging, do not release your finger until you have reached the target position.
<Insert Image>
Flick
Flicking the screen is similar to swiping, except that you need to swipe your finger in light, quick
strokes. This finger gesture is always in a vertical direction, such as when flicking the contacts
or message list.
<Insert Image>
Rotate
For most screens, you can automatically change the screen orientation from portrait to
landscape by turning the device sideways. When entering text, you can turn the device
sideways to bring up a bigger keyboard.
<Insert Image>
Note: The Auto-rotate check box needs to be selected for the screen orientation to
automatically change. To make this selection, press and tap > Settings
> Display > Auto-rotate screen. See
Pinch and Spread
“Pinch” the screen using your thumb and forefinger to zoom out or “spread” the screen to zoom
in when viewing a picture or a Web page. (Move fingers inward to zoom out and outward to
zoom in.)
Auto-rotate screen for more information.
<Insert Image>
Settings 10
DRAFT
FOR INTERNA L USE ONLY
Tip: Pinching any Home screen will let you see thumbnails of all seven Home screens. Tap a
thumbnail to go straight to another Home screen.
Your Home Screen
The home screen is the starting point for your device’s applications, functions, and menus. You
can customize your home screen by adding application icons, shortcuts, folders, widgets, and
more. Your home screen extends beyond the initial screen. Swipe the screen left or right to
display additional screens.
Note: Your device's home screens cycle through so that you can keep swiping in one direction
and make it back to the home screen. The small circles toward the bottom of the screen
let you know your current screen position.
Tip: Press
to return to the main home screen from any other screen.
Creating Shortcuts
Learn how to add, move, or remove items from the home screen.
Adding Items from the Applications Menu
1. Press to display the main Home screen.
2. Navigate to the desired Home Page and tap
3. Scroll through the list and locate your desired application.
4. Touch and hold the application icon. This creates an immediate shortcut of the selected
icon and closes the Applications tab.
5. While still holding the onscreen icon, position it on the current page. Once complete,
release the screen to lock the new shortcut into its new position on the current screen.
to display your current applications.
Adding Items from the Home screen
1. Press to display the main Home screen.
Settings 11
DRAFT
FOR INTERNA L USE ONLY
2. Navigate to the desired Home Page.
3. Touch and hold an empty area of the Home screen.
4. Tap Add to Home screen > Apps tab.
5. Touch and hold the application icon. This creates an immediate shortcut of the selected
icon and closes the Applications tab.
6. While still holding the onscreen icon, position it on the current page. Once complete,
release the screen to lock the new shortcut into its new position on the current screen.
Deleting a Shortcut
1. Press to display the main Home screen.
2. Touch and hold the desired shortcut. This unlocks it from its location on the current
screen.
3. Drag the icon down to the Delete icon and release it. As you place the shortcut into the
Trash, both items turn red.
Note: This action does not delete the application, it simply removes the shortcut from the
current screen.
Adding and Removing Primary Shortcuts
You can change any of your primary shortcuts with the exception of the Apps shortcut. The
primary shortcuts are the bottom row of app shortcuts that remain static on all home screens (by
default Device, Contacts, Messaging, Internet, and Apps).
Note: Before replacing a primary shortcut, you must first add the replacement shortcut to the
Home Screen. For more information, see
1. Press to display the main Home screen.
2. Touch and hold the primary shortcut you want to replace and then drag it to an empty
space on any Home screen.
3. Scroll through the Home screen to find the shortcut you want to add as the new primary
shortcut.
4. Touch and hold the new shortcut and then drag it to the empty space in the row of
primary shortcuts.
5. The new primary shortcut will now appear on all Home screens.
Creating Shortcuts.
Settings 12
DRAFT
FOR INTERNA L USE ONLY
Adding and Removing Widgets
Widgets are self-contained applications that reside either in your Widgets tab or on the main or
extended Home screens. Unlike a shortcut, the Widget appears as an onscreen application.
Widgets can include Contacts shortcuts, bookmarks, Facebook status windows, Gmail and
email accounts, and many other types of apps.
Adding a Widget
1. Press to display the main Home screen.
2. Navigate to the desired Home Page.
3. Touch and hold an empty area of the Home screen.
4. Tap Apps and widgets > Widgets tab.
5. Touch and hold an available Widget to position it on the current screen.
Removing a Widget
1. Press to display the main Home screen.
2. Touch and hold the desired widget. This unlocks it from its location on the current
screen.
3. Drag the widget up to the Delete icon and release it. As you place the widget into the
Trash, both items turn red.
Note: This action does not delete the application, it simply removes it from the current screen
Extended Home Screens
In addition to the main home screen, your device has six extended home screens to provide
more space for adding icons, widgets, and more. Touch and hold the icon or widget and then
drag across the screen to move from the main screen to an extended screen.
There are six extended screens in addition to the main Home screen.
Note: You cannot add more screens, unless you have previously deleted any of the existing
screens. The maximum number of home screens is seven.
To go directly to a particular screen:
1. From any home screen, pinch the screen to display thumbnail images of all screens.
- or -
Touch and hold an empty area of the Home screen and then tap Page.
<Insert Image>
Settings 13
DRAFT
FOR INTERNA L USE ONLY
2. Tap the screen you want to open.
Recently Used Applications
You can access recently used applications through a display of shortcuts to the applications
themselves.
1. Press and hold
window.
2. Tap an image to open the selected application.
from any screen to open the recently used applications
Mini App Tray
There are shortcuts available that link to apps that you might need while working in other apps,
such as Alarm, Calculator, Calendar, Email, Music player, Task manager, and World clock. In
some cases, these shortcuts are actually links to the part of the app you need most and they
contain a link to the actual app where you can use other functions.
1. From any screen, touch
App Tray icons display.
2. Touch one of the icons to display a mini app pop-up. The pop-up varies depending on
the application. Various controls display at the top of the pop-up and other information is
displayed in the body of the pop-up.
<up arrow icon> at the bottom, center of the screen. The Mini
3. Touch items in the body of the pop-up, such as an email entry or keys on the Calculator.
4. Touch
5. Touch
Customizing the Mini App Tray
You can choose applications to display on the Mini App Tray and arrange them in any order.
1. Touch Edit at the right side of the tray to customize the Mini App Tray.
2. Touch and drag apps in and out of the tray or to another position in the tray.
3. Touch Done to save your changes.
Settings 14
to link to the application.
to close the mini app pop-up.
DRAFT
FOR INTERNA L USE ONLY
Status Bar
Icon
Description
Bluetooth® active
GPS active
Wi-Fi® active
Vibrate
Silence All
Mute
Speakerdevice Active
Network (full signal)
Network (roaming)
3G (data service)
4G (data service)
Airplane Mode
Sync Active
Alarm Set
Battery (charging)
Battery (full charge)
The status bar at the top of the home screen provides device and service status information on
the right side and notification alerts on the left. To view notification alerts, touch and hold the
status bar and drag it down.
Status Icons
Settings 15
DRAFT
FOR INTERNA L USE ONLY
Notification Icons
Icon
Description
New email
New Gmail
New message
Event
USB connection
Updates available
Download complete
Downloading
Device being used to control streaming media and is connected to a Digital
Living Network Alliance (DLNA) certified device using the AllShare Play
application.
Device is sharing/streaming media to paired device using the AllShare Play
application.
Samsung Account needs activation.
Displays when Wi-Fi Direct is active and configured for a direct connection to
another compatible device in the same direct communication mode.
Device is tethered via a supported USB cable connection.
Keyboard active
Enter Text
You can type on your device using the available touchscreen keyboards.
Touchscreen Keyboards
Text Input Methods
Tips for Editing Text
Settings 16
DRAFT
FOR INTERNA L USE ONLY
Touchscreen Keyboards
Touchscreen keyboard entry can be done in either Portrait or Landscape orientations. The
Landscape orientation provides more space and results in slightly bigger onscreen keys. If you
find that you prefer to enter text via the onscreen keyboard, and need bigger keys, use this
orientation.
Selecting a Text Input Method
Some characters and types, such as some symbols and emoticons, are not accessible from the
onscreen keyboard.
The Text Input Method can be assigned from within one of two locations:
Settings Menu:
► Press
an input method.
Text Input field:
1. From a screen where you can enter text, touch and drag up the Notifications area.
2. Tap (Select input method) and select an available input method.
and tap > Settings > Language and input > Default and select
Text Input Methods
There are three text input methods available: Google voice typing, Samsung keyboard, and T9
Trace.
● Google voice typing: provides a voice-to-text interface.
● Samsung keyboard: an onscreen QWERTY keyboard that can be used in both portrait
and landscape orientation.
● T9 Trace (default): (as part of the Samsung keyboard and not shown as an input
method), lets you enter letters and words by swiping across the onscreen keyboard.
Instead of tapping each key, use your finger to trace over each letter of a word.
The onscreen QWERTY keyboard works the same in both portrait and landscape mode.
Assigning T9 Trace
When T9 Trace is enabled, the onscreen keyboard can be used to enter text by either tapping
single letters or swiping across the onscreen keys.
1. Press
Samsung keyboard field).
Settings 17
and tap > Settings > Language and input > (adjacent to the
DRAFT
FOR INTERNA L USE ONLY
2. Tap T9 Trace to place a check mark next to T9 Trace. This turns T9 Trace on. Touching
it again clears the check mark, turning T9 Trace off.
Assigning the Samsung Keyboard
This device has a built-in, QWERTY keyboard which you can use to type letters, numbers,
punctuation, and other characters.
To use the Samsung keyboard you must first configure the settings to default to the Samsung
keyboard.
1. Press and tap > Settings > Language and input > Default > Samsung
keyboard.
- or -
From a screen where you can enter text, touch and drag up from the Notifications area
then select
2. The virtual keyboard is then assigned to the Samsung keyboard configuration for all
subsequent text input.
Note: Samsung keyboard is selected by default. Depending on your device's configuration,
there may not be another keyboard type available, although T9 Trace and Google voice
typing may still be used.
(Select input method) > Samsung keyboard.
Keyboard Input Options
With both T9 Trace and the Samsung Keyboard, it's easy to select input options such as ABC
Mode, entering symbols and numbers, and changing letter case.
Changing the Text Input Mode
1. From a screen where you can enter text, tap the text input field to reveal the onscreen
keyboard.
2. With Samsung keyboard as your text entry method, select one of the following text mode
options:
Abc
: to use alphabetic characters from the onscreen keyboard. In this mode,
the text mode button displays
Symbol/Numeric
keyboard. In this mode, the text mode button displays .
There are up to 3 available pages of numeric symbols available by tapping
Settings 18
: to enter numbers by tapping the numbers on the onscreen
.
.
Loading...
