Samsung SM-N9150 User Guide
User Manual
SM-N9150
English (HK). 05/2015. Rev.1.2
www.samsung.com/hk
Table of Contents
Read me first
Getting started
7 Package contents
8 Device layout
10 S Pen
13 Using the SIM or USIM card and
battery
16 Charging the battery
19 Using a memory card
21 Turning the device on and off
21 Locking and unlocking the screen
45 Entering text
48 Screen capture
48 Using the dictionary
49 My Files
50 Power saving feature
51 Viewing help information
S Pen features
52 Air command
53 Action memo
55 Smart select
56 Image clip
57 Screen write
58 S Note
Basics
22 Using the touchscreen
25 Home screen layout
27 Edge screen
39 All apps screen
40 Indicator icons
41 Notification and quick settings panels
43 Opening apps
43 Installing or uninstalling apps
65 Scrapbook
66 Using the S Pen
Motions & usability features
69 Motions and gestures
72 Multi window
77 One-handed operation
78 Increasing touchscreen sensitivity
2
Table of Contents
Personalising
79 Managing the Home and All apps
screens
81 Setting wallpaper and ringtones
82 Changing the screen lock method
83 My Places
86 Finger Scanner
91 Private mode
92 Easy mode
93 Transferring data from your previous
device
94 Setting up accounts
Phone & contacts
96 Phone
99 Contacts
Useful apps
118 Car mode
120 S Finder
121 S Planner
123 S Health
125 S Voice
127 Music
129 Video
131 Internet
132 Voice Recorder
134 Clock
136 Calculator
136 Dropbox
137 Flipboard
137 Smart Remote
140 Evernote
141 PEN.UP
Messages & email
101 Messages
102 Email
Camera & gallery
104 Camera
113 Gallery
Safety assistance
116 Emergency mode
141 Google apps
Connecting with other
devices
144 Quick Connect
146 Bluetooth
148 Wi-Fi Direct
149 NFC
152 Screen Mirroring
154 MirrorLink
155 Mobile printing
117 Send help messages
3
Table of Contents
Device & data manager
156 Updating the device
157 Transferring files between the device
and a computer
158 Backing up and restoring data
158 Performing a data reset
Settings
159 An introduction
159 Configuring settings
159 QUICK SETTINGS
160 CONNECTIONS
164 DEVICE
169 PERSONALISATION
171 SYSTEM
176 APPLICATIONS
Accessibility
177 About Accessibility
177 Using the Home key to open
accessibility menus
177 Voice feedback (TalkBack)
183 Vision
185 Hearing
187 Dexterity and interaction
190 Answering or ending calls
190 Using single tap mode
190 Managing accessibility settings
Troubleshooting
4
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Some content may differ from your device depending on the region, service provider, or
device’s software.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
•
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services depending on your data plan. For
large data transfers, it is recommended to use the Wi-Fi feature.
•
Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
5
Read me first
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: essential information for using the device, functional limitations of using the
device, usage charge information, or legal notices
Note: notes, usage tips, or additional information
6
Getting started
Package contents
Check the product box for the following items:
•
Device
•
Battery
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
7
Getting started
Headset jack
Microphone
Device layout
LED indicator
Speaker
Power key
Front camera
Proximity/Light/Gesture
sensor
Touchscreen
Recents key
Microphone
Multipurpose jack
GPS antenna
Rear camera
Edge screen
Home key (Fingerprint
recognition sensor)
Back key
Microphone
Infrared port
Flash
Back cover
Loud speaker
S Pen
Volume key
NFC antenna (on the
battery)
Main antenna
8
Getting started
•
Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.
•
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
•
Do not allow water to contact the touchscreen. The touchscreen may malfunction
in humid conditions or when exposed to water.
•
The colours on the curved screen may look different depending on your viewing
position.
Keys
Key Function
•
Press and hold to turn the device on or off.
Power
•
Press to turn on or lock the screen.
Recents
Home
Back
Volume
•
Tap to open the list of recent apps.
•
Tap and hold to access additional options for the current
screen.
•
Press to turn on the screen while the screen is locked.
•
Press to return to the Home screen.
•
Press twice to launch
•
Press and hold to launch
•
Tap to return to the previous screen.
•
Press to adjust the device volume.
S Voice
Google
.
.
9
Getting started
S Pen
S Pen button
S Pen nib
Name Functions
•
Use the S Pen to write, draw, or perform touch actions on the
screen.
S Pen nib
•
Hover the S Pen over items on the screen to access additional
Tweezers
S Pen button
Tweezers
S Pen features, such as Air Button and the air view feature.
•
Hover the S Pen over the screen and press the S Pen button to
display the air command features.
•
While pressing and holding the S Pen button, drag the S Pen over
items to select them.
•
Remove the S Pen nib with the tweezers when replacing the nib.
10
Getting started
Removing the S Pen
When you remove the S Pen from the slot, the device launches
air command features depending on the S Pen detachment option setting.
To change the setting, open the All apps screen and tap
options
.
Settings
Action memo
→
S Pen
Replacing the S Pen nib
If the nib is dull, replace it with a new one.
Firmly hold the nib with the tweezers and remove it.
1
or displays the
→
Detachment
11
Getting started
Insert a new nib into the S Pen.
2
Be careful not to pinch your fingers with the tweezers.
•
Do not reuse old nibs. Doing so may cause the S Pen to malfunction.
•
Do not press the nib excessively when inserting the nib into the S Pen.
•
Do not insert the round end of the nib into the S Pen. Doing so may cause damage
to the S Pen or your device.
•
If the S Pen is not working properly, take it to a Samsung Service Centre.
•
If you use the S Pen at sharp angles on the screen, the device may not recognise
the S Pen actions. Do not bend or apply excessive pressure with the S Pen while
using it.
•
The Recents key and the Back key can be used with the S Pen.
•
For more information about the S Pen, visit the Samsung website.
12
Getting started
Using the SIM or USIM card and battery
Installing the SIM or USIM card and battery
Insert the SIM or USIM card provided by the mobile telephone service provider, and the
included battery.
•
Only microSIM cards work with the device.
•
Some LTE services may not be available depending on the service provider. For
more information about service availability, contact your service provider.
Remove the back cover.
1
Be careful not to damage your fingernails when you remove the back cover.
Do not bend or twist the back cover excessively. Doing so may damage the cover.
13
Getting started
Insert the SIM or USIM card with the gold-coloured contacts facing downwards.
2
•
Do not insert a memory card into the SIM card slot. If a memory card happens to
be lodged in the SIM card slot, take the device to a Samsung Service Centre to
remove the memory card.
•
Use caution not to lose or let others use the SIM or USIM card. Samsung is not
responsible for any damages or inconveniences caused by lost or stolen cards.
Insert the battery with the battery’s gold-coloured contacts properly aligned with the
3
device’s contacts.
2
1
14
Getting started
Replace the back cover.
4
Removing the SIM or USIM card and battery
Remove the back cover.
1
Pull out the battery.
2
Press the SIM or USIM card with your finger, and then pull it out.
3
15
Getting started
Charging the battery
Using the battery charger
Charge the battery before using it for the first time or before using it after it has been unused
for an extended period.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
•
If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for
a few minutes before turning on the device.
•
Using a power source other than the USB power adaptor, such as a computer, may
result in a slower charging speed due to a lower electric current.
Connect the USB cable to the USB power adaptor, and then plug the end of the USB cable
into the multipurpose jack.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
•
If the device receives an unstable power supply while charging, the touchscreen
may not function. If this happens, unplug the charger from the device.
•
While charging, the device and the charger may heat up. This is normal and should
not affect the device’s lifespan or performance. If the battery gets hotter than usual,
the charger may stop charging.
•
If the device is not charging properly, take the device and the charger to a
Samsung Service Centre.
16
Getting started
After fully charging, disconnect the device from the charger. First unplug the charger from the
device, and then unplug it from the electric socket.
Do not remove the battery before removing the charger. This may damage the
device.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
•
When you are not using the device, switch to sleep mode by pressing the Power key.
•
Activate power saving mode.
•
Close unnecessary apps using the task manager.
•
Deactivate the Bluetooth feature when not in use.
•
Deactivate the Wi-Fi feature when not in use.
•
Deactivate auto-syncing of apps.
•
Decrease the backlight time.
•
Decrease the screen brightness.
•
When the battery power is low, the battery icon appears empty.
•
If you use multiple apps at once, network apps, or apps that need a connection
to another device, the battery will drain quickly. To avoid disconnecting from the
network or losing power during a data transfer, always use these apps after fully
charging the battery.
•
The device can be used while it is charging, but it may take longer to fully charge
the battery.
17
Getting started
Fast charging
The device has a built-in fast charging feature. You can use this feature to charge the battery
more quickly while the device or its screen is turned off.
About Fast charging
•
Fast charging uses battery charging technology that charges the battery faster by
increasing the charging power. The device supports Samsung’s Adaptive fast charging
feature and Qualcomm Quick Charge 2.0.
•
To use Fast charging on your device, connect it to a battery charger that supports
Adaptive fast charging or Quick Charge 2.0.
Increasing the charging speed
To increase the charging speed, turn the device or its screen off when you charge the battery.
•
While charging the battery when the device is turned off, the icon appears on the
screen.
•
While charging the battery when the device’s screen is turned on, a pop-up window
appears requesting you to turn the screen off. Turn off the screen to increase the charging
speed.
•
You cannot use the built-in fast charging feature when you charge the battery
using a standard battery charger.
•
If the device heats up or the ambient air temperature rises, the charging speed may
decrease automatically. This is a normal operating condition to prevent damage to
the device.
18
Getting started
Using a memory card
Installing a memory card
Your device accepts memory cards with maximum capacities of 128 GB. Depending on the
memory card manufacturer and type, some memory cards may not be compatible with your
device.
•
Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.
•
Use caution to insert the memory card right-side up.
The device supports the FAT and the exFAT file systems for memory cards. When
inserting a card formatted in a different file system, the device asks to reformat the
memory card.
Remove the back cover.
1
Insert a memory card with the gold-coloured contacts facing downwards.
2
Replace the back cover.
3
•
Frequent writing and erasing of data shortens the lifespan of memory cards.
•
When inserting a memory card into the device, the memory card’s file directory
appears in the
My Files
→
SD card
folder.
19
Getting started
Removing the memory card
Before removing the memory card, first unmount it for safe removal.
On the Home screen, tap
Remove the back cover.
1
Pull out the memory card.
2
Replace the back cover.
3
Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or damage to the
memory card or device. Samsung is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.
→
Settings
→
Storage
→
Unmount SD card
.
Formatting the memory card
A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.
On the Home screen, tap
→
Erase everything
Before formatting the memory card, remember to make backup copies of all
important data stored in the memory card. The manufacturer’s warranty does not
cover loss of data resulting from user actions.
.
→
Settings
→
Storage
→
Format SD card
→
Format SD card
20
Getting started
Turning the device on and off
Press and hold the Power key for a few seconds to turn on the device.
When you turn on your device for the first time or after performing a data reset, follow the onscreen instructions to set up your device.
To turn off the device, press and hold the Power key, and then tap
Follow all posted warnings and directions from authorised personnel in areas where
the use of wireless devices is restricted, such as aeroplanes and hospitals.
Power off
.
Locking and unlocking the screen
Pressing the Power key turns off the screen and locks it. Also, the screen turns off and
automatically locks if the device is not used for a specified period.
To unlock the screen, press the Power key or the Home key and swipe in any direction.
You can change the screen lock method and utilise additional security features. Refer to
Changing the screen lock method for more information.
21
Basics
Using the touchscreen
•
Do not allow the touchscreen to come into contact with other electrical devices.
Electrostatic discharges can cause the touchscreen to malfunction.
•
To avoid damaging the touchscreen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.
•
The device may not recognise touch inputs close to the edges of the screen, which
are outside of the touch input area.
•
Leaving the touchscreen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touchscreen when you do not use the
device.
Tapping
To open an app, to select a menu item, to press an on-screen button, or to enter a character
using the keyboard on the screen, tap it with your finger or the S Pen.
22
Basics
Tapping and holding
Tap and hold an item or the screen for more than 2 seconds to access available options.
Dragging
To move an item, tap and hold it and drag it to the target position.
Double-tapping
Double-tap on a webpage or image to zoom in. Double-tap again to return.
23
Basics
Swiping
Swipe to the left or right on the Home screen or the All apps screen to view other panels.
Swipe upwards or downwards to scroll through a webpage or a list of items, such as contacts.
Spreading and pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
24
Basics
Home screen layout
Home screen
The Home screen is the starting point for accessing all of the device’s features. It displays
widgets, shortcuts to apps, and more. Widgets are small apps that launch specific app
functions to provide information and convenient access on your Home screen.
To view other panels, swipe to the left or right, or tap one of the screen indicators at the
bottom of the screen.
To customise the Home screen, refer to Managing the Home screen.
A widget
Screen indicators
Launch Phone.
Edge screen
All apps screen icon
25
Basics
Home screen options
On the Home screen, tap and hold an empty area, or pinch your fingers together to access
the available options. Customise the Home screen by adding, deleting, or rearranging Home
screen panels. You can also set the Home screen wallpaper, add widgets to the Home screen,
and more.
Flipboard Briefing
Use this feature to view the latest articles in various categories. You can get up to date on
news that interests you using this feature.
On the Home screen, tap or swipe to the right to open
1
Tap
2
3
GET STARTED
Swipe upwards to browse articles in each news category.
To deactivate
Then, tap
when launching this feature for the first time.
Flipboard Briefing
Home screen settings
, tap and hold an empty area on the Home screen.
and deselect
Flipboard Briefing
Flipboard Briefing
.
.
26
Basics
Edge screen
Edge screen
An introduction
Answer a call or check notifications directly on the Edge screen. Conveniently launch apps or
play music from the Edge screen instead of using the main screen.
Using the Edge screen
You can view call or message alerts and other notifications from the Edge screen. You can also
add more panels to the Edge screen to use the desired features.
Swipe to the left or right on the Edge screen to view a desired panel.
To add panels to the Edge screen, refer to Managing the Edge screen.
Main screen
27
Basics
Using the Quick tools
You can turn on the torch, record voices, or use other convenient functions directly from the
Edge screen. Drag
downwards from the top of the Edge screen to view the Quick tools.
To close the Quick tools, drag the bottom of the Edge screen upwards.
Ruler
Stopwatch
Timer
Torch
Voice Recorder
28
Basics
Activating the Edge screen only
You can activate the Edge screen and view the clock and notifications while the main screen
is off.
Swipe upwards then downwards, or vice versa, on the Edge screen to activate it, and then
swipe to the left or right to view the desired information. To launch apps or view notification
details, press the Home key to turn on the main screen.
Using the Edge screen from the locked screen
From the locked screen, you can view notifications and user-added panels, and use the Quick
tools.
To launch apps or view notification details, unlock the main screen.
29
Basics
Launching apps
Launch apps directly from the Edge screen. You can add frequently used apps to the apps
panel on the Edge screen and access them conveniently.
Swipe to the left or right on the Edge screen to view the apps panel.
1
Scroll up or down the apps list and select an app.
2
The selected app will launch on the main screen.
30
Loading...
