Samsung SM-G800M User Manual

User Manual

SM-G800M

English (LTN). 08/2014. Rev.1.0

www.samsung.com

Table of Contents

Read me first

Getting started

8 Package contents

9 Device layout

11 Using the SIM or USIM card and

battery

17 Using a memory card

19 Turning the device on and off

20 Locking and unlocking the screen

Basics

21 Using the touch screen

Network connectivity

42 Mobile data

42 Wi-Fi

44 Tethering and Mobile hotspot

46 Internet

Motions & usability features

48 Motions and gestures

51 Air view

51 Toolbox

52 Increasing touch screen sensitivity

Personalising

24 Home screen layout

29 Notifications and quick setting panels

32 Opening apps

33 Installing or uninstalling apps

35 Entering text

37 Screen capture

37 My Files

39 Power saving feature

41 Viewing help information

53 Managing the Home and Apps screens

56 Setting wallpaper and ringtones

57 Changing the screen lock method

58 Finger Scanner

61 Private mode

62 Easy mode

63 Transferring data from your previous

device

64 Setting up accounts

Table of Contents

Phone

65 Making calls

68 Receiving calls

69 Options during calls

Contacts

71 Adding contacts

72 Managing contacts

Messages & email

75 Messages

78 Email

S Health

104 About S Health

105 Setting up a user profile

106 S Health main screen

108 Walking mate

110 Exercise mate

117 Recording food intake

119 Managing weight

122 Installing additional S Health apps

122 S Health settings

Security features

124 Emergency mode

125 Help message

Camera

81 Basic shooting

84 Shooting modes

89 Camera settings

Gallery

91 Viewing photos or videos

93 Editing photos or videos

97 Gallery settings

Multimedia

98 Music

101 Video

Useful apps and features

126 Kids Mode

130 S Finder

131 S Planner

134 S Voice

136 Clock

138 Calculator

138 Memo

140 Voice Recorder

142 Dropbox

143 Flipboard

144 Smart Remote

146 Torch

147 Magnifier

147 Google apps

Table of Contents

Connecting with other devices

150 Bluetooth

152 Wi-Fi Direct

154 NFC

156 S Beam

157 Quick connect

159 Screen Mirroring

161 Mobile printing

Device & data manager

162 Upgrading the device

163 Transferring files between the device

and a computer

164 Backing up and restoring data

165 Performing a data reset

Accessibility

193 About Accessibility

194 Using the Home button to open

accessibility menus

194 Voice feedback (TalkBack)

205 Changing the font size

205 Magnifying the screen

205 Setting notification reminders

206 Reversing the display colours

206 Colour adjustment

207 Turning off all sounds

207 Caption settings

208 Adjusting the sound balance

208 Mono audio

209 Assistive menu

211 Setting tap and hold delay options

211 Interaction control

212 Answering or ending calls

Settings

166 About Settings

166 QUICK SETTINGS

166 NETWORK CONNECTIONS

170 CONNECT AND SHARE

171 SOUND AND DISPLAY

175 PERSONALISATION

176 MOTION

177 USER AND BACKUP

178 SYSTEM

185 APPLICATIONS

212 Using single tap mode

212 Managing accessibility settings

214 Using other useful features

Troubleshooting

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media.

•

You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty.

Read me first

Maintaining water and dust resistance

The device may be damaged if water or dust enters the device. Follow these tips carefully to prevent damage to the device and to maintain the water- and dust-resistant performance of the device.

•

Do not immerse the device in water deeper than 1 m and keep it submerged for more than 30 minutes.

•

Ensure that the back cover is tightly closed. Otherwise, it may not provide protection from water and dust.

•

Do not immerse the device in water for extended periods.

•

Do not expose the device to water moving with force, such as water running from a tap, ocean waves, or waterfalls.

•

Do not open the device’s covers when the device is in water or in very humid places, such as swimming pools or bathrooms.

•

Do not open the back cover using wet hands or when the device is wet.

•

The rubber seal fitted to the back cover is an important component of the device. Take care when opening and closing the back cover to avoid damaging the rubber seal. Also, ensure that the rubber seal is free from debris, such as sand or dust to prevent damage to the device.

•

Do not detach or remove the back cover from the device.

•

If the device is exposed to freshwater, dry it thoroughly with a clean, soft cloth. If the device is exposed to any liquid other than freshwater, rinse the device with freshwater immediately and dry it thoroughly with a clean, soft cloth. Failure to rinse the device in freshwater and dry it as instructed may cause the device to suffer from operability or cosmetic issues.

•

The back cover may be loosened if the device is dropped or receives an impact. Ensure that all the covers are properly aligned and tightly closed.

Read me first

•

If the device has been immersed in water or the microphone or the speaker is wet, sound may not be heard clearly during a call. Ensure that the microphone or the speaker is clean and dry by wiping it with a dry cloth.

•

The water-resistant design of the device causes it to vibrate slightly in certain conditions. Vibrations in these conditions, such as when the volume level is high, are normal and do not affect the device’s performance.

•

The touch screen and other features may not work properly if the device is used in water or in other liquids.

•

Your device has been tested in a controlled environment and certified to be waterand dust-resistant in specific situations (meets requirements of classification IP67 as described by the international standard IEC 60529 - Degrees of Protection provided by Enclosures [IP Code]; test conditions: 15 - 35 °C, 86 - 106 kPa, 1 metre, 30 minutes). Despite this classification, your device is not impervious to water damage in any situation.

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Note: notes, usage tips, or additional information

Getting started

Package contents

Check the product box for the following items:

•

Device

•

Battery

•

Quick start guide

•

The items supplied with the device and any available accessories may vary depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Some accessories, such as docking devices, may not have the same water- and dust-resistance certification.

•

Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website.

Getting started

Device layout

Infrared LED

Notification light

Earpiece

Touch screen

Home button

Recent apps button

Microphone

Proximity/Light sensor

Front camera

Power button

Back button

Multipurpose jack

Headset jack

GPS antenna

Rear camera

Flash

Back cover

Speaker

Microphone

Volume button

NFC antenna (on the battery)

Main antenna

Getting started

•

Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery.

•

Using a Samsung-approved screen protector is recommended. Unapproved screen protectors may cause the sensors to malfunction.

Buttons

Button Function

•

Press and hold to turn the device on or off.

Power

•

Press to turn on or lock the screen.

•

Tap to open the list of recent apps.

Recent apps

Home

Back

Volume

•

Tap and hold to access additional options for the current screen.

•

Press to turn on the screen while the screen is locked.

•

Press to return to the Home screen.

•

Press twice to launch

•

Press and hold to launch

•

Tap to return to the previous screen.

•

Press to adjust the device volume.

S Voice

Google

Getting started

Using the SIM or USIM card and battery

Installing the SIM or USIM card and battery

Insert the SIM or USIM card provided by the mobile telephone service provider, and the included battery.

Only microSIM cards work with the device.

Remove the back cover.

Be careful not to damage your fingernails when you remove the back cover.

Do not bend or twist the back cover excessively. Doing so may damage the cover.

Getting started

Insert the SIM or USIM card with the gold-coloured contacts facing downwards.

•

Do not insert a memory card into the SIM card slot. If a memory card happens to be lodged in the SIM card slot, take the device to a Samsung Service Centre to remove the memory card.

•

Use caution not to lose or let others use the SIM or USIM card. Samsung is not responsible for any damages or inconveniences caused by lost or stolen cards.

Insert the battery.

Getting started

Replace the back cover.

Align

•

Ensure that the back cover is closed tightly.

•

Use only Samsung-approved back covers and accessories with the device.

Press

Removing the SIM or USIM card and battery

Remove the back cover.

Pull out the battery.

Getting started

Press the SIM or USIM card with your finger, and then pull it out.

Charging the battery

Use the charger to charge the battery before using it for the first time. A computer can be also used to charge the battery by connecting them via the USB cable.

Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.

•

When the battery power is low, the battery icon appears empty.

•

If the battery is completely discharged, the device cannot be turned on immediately when the charger is connected. Allow a depleted battery to charge for a few minutes before turning on the device.

•

If you use multiple apps at once, network apps, or apps that need a connection to another device, the battery will drain quickly. To avoid disconnecting from the network or losing power during a data transfer, always use these apps after fully charging the battery.

Connect the USB cable to the USB power adaptor.

Getting started

Plug the USB cable into the multipurpose jack.

•

Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty.

•

Ensure that the the back cover is closed tightly to prevent water and dust from entering the device. Open or loose back cover may allow water and dust to enter the device and cause damage.

Plug the USB power adaptor into an electric socket.

•

The device can be used while it is charging, but it may take longer to fully charge the battery.

•

If the device receives an unstable power supply while charging, the touch screen may not function. If this happens, unplug the charger from the device.

•

While charging, the device may heat up. This is normal and should not affect the device’s lifespan or performance. If the battery gets hotter than usual, the charger may stop charging.

•

If the device is not charging properly, take the device and the charger to a Samsung Service Centre.

Getting started

After fully charging, disconnect the device from the charger. First unplug the charger

from the device, and then unplug it from the electric socket.

Do not remove the battery before removing the charger. This may damage the device.

To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging.

Reducing the battery consumption

Your device provides options that help you save the battery power. By customising these options and deactivating features in the background, you can use the device longer between charges:

•

When you are not using the device, switch to sleep mode by pressing the Power button.

•

Close unnecessary apps using the task manager.

•

Deactivate the Bluetooth feature.

•

Deactivate the Wi-Fi feature.

•

Deactivate auto-syncing of apps.

•

Decrease the backlight time.

•

Decrease the screen brightness.

Getting started

Using a memory card

Installing a memory card

Your device accepts memory cards with maximum capacities of 64 GB. Depending on the memory card manufacturer and type, some memory cards may not be compatible with your device.

•

Some memory cards may not be fully compatible with the device. Using an incompatible card may damage the device or the memory card, or corrupt the data stored in it.

•

Use caution to insert the memory card right-side up.

•

The device supports the FAT and the exFAT file systems for memory cards. When inserting a card formatted in a different file system, the device asks to reformat the memory card.

•

Frequent writing and erasing of data shortens the lifespan of memory cards.

•

When inserting a memory card into the device, the memory card’s file directory appears in the

Remove the back cover.

Insert a memory card with the gold-coloured contacts facing downwards.

My Files

→

SD card

folder.

Replace the back cover.

Getting started

Removing the memory card

Before removing the memory card, first unmount it for safe removal. On the Home screen, tap

Apps

→

Settings

Remove the back cover.

Pull out the memory card.

Replace the back cover.

Do not remove the memory card while the device is transferring or accessing information. Doing so can cause data to be lost or corrupted or can damage the memory card or device. Samsung is not responsible for losses that result from the misuse of damaged memory cards, including the loss of data.

→

Storage

→

Unmount SD card

Formatting the memory card

A memory card formatted on a computer may not be compatible with the device. Format the memory card on the device.

On the Home screen, tap

→

card

Delete all

Before formatting the memory card, remember to make backup copies of all important data stored in the device. The manufacturer’s warranty does not cover loss of data resulting from user actions.

Apps

→

Settings

→

Storage

→

Format SD card

→

Format SD

Getting started

Turning the device on and off

Press and hold the Power button for a few seconds to turn on the device.

When you turn on your device for the first time or after performing a data reset, follow the onscreen instructions to set up your device.

To turn off the device, press and hold the Power button, and then tap

Follow all posted warnings and directions from authorised personnel in areas where the use of wireless devices is restricted, such as aeroplanes and hospitals.

Power off

Getting started

Locking and unlocking the screen

Pressing the Power button turns off the screen and locks it. Also, the screen turns off and automatically locks if the device is not used for a specified period.

To unlock the screen, press the Power button or the Home button and flick your finger in any direction within the unlock screen area.

You can change the unlock code to unlock the screen. Refer to Changing the screen lock

method for more information.

Basics

Using the touch screen

•

Do not allow the touch screen to come into contact with other electrical devices. Electrostatic discharges can cause the touch screen to malfunction.

•

To avoid damaging the touch screen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips.

•

The device may not recognise touch inputs close to the edges of the screen, which are outside of the touch input area.

•

Leaving the touch screen idle for extended periods may result in afterimages (screen burn-in) or ghosting. Turn off the touch screen when you do not use the device.

•

It is recommended to use fingers when you use the touch screen.

Tapping

To open an app, to select a menu item, to press an on-screen button, or to enter a character using the keyboard on the screen, tap it with a finger.

Basics

Tapping and holding

Tap and hold an item or the screen for more than 2 seconds to access available options.

Dragging

To move an item, tap and hold it and drag it to the target position.

Double-tapping

Double-tap on a webpage or image to zoom in. Double-tap again to return.

Basics

Flicking

Flick left or right on the Home screen or the Apps screen to see another panel. Flick up or down to scroll through a webpage or a list of items, such as contacts.

Spreading and pinching

Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.

Basics

Home screen layout

Home screen

The Home screen is the starting point for accessing all of the device’s features. It displays widgets, shortcuts to apps, and more. Widgets are small apps that launch specific app functions to provide information and convenient access on your Home screen.

To view other panels, scroll left or right, or tap one of the screen indicators at the bottom of the screen. To customise the Home screen, refer to Managing the Home screen.

A widget

An app

A folder

Screen indicators

Favourite apps

Basics

Home screen options

On the Home screen, tap and hold an empty area, or pinch your fingers together to access the available options.

Basics

Using My Magazine

My Magazine

To activate

screen settings

displays live social network updates and news that you are interested in.

My Magazine

and tick

On the Home screen, tap

, tap and hold an empty area on the Home screen. Then, tap

My Magazine

or scroll right to open

My Magazine

Access additional options.

Home

To select the content to be displayed, tap → interest you.

To update the content automatically when

Auto refresh on opening

tick

My Magazine

Settings

, and then select the categories that

opens, tap →

Settings

, and then

Basics

Apps screen

The Apps screen displays icons for all apps, including newly installed apps.

On the Home screen, tap

Apps

to open the Apps screen. To view other panels, scroll left or right, or select a screen indicator at the bottom of the screen. To customise the Apps screen, refer to Managing the Apps screen.

Access additional options.

An app

Screen indicators

Basics

Indicator icons

Indicator icons appear on the status bar at the top of the screen. The icons listed in the table below are most common.

The status bar may not appear at the top of the screen in some apps. To display the status bar, drag down from the top of the screen.

Icon Meaning

No signal

Signal strength

Roaming (outside of normal service area)

GPRS network connected

EDGE network connected

UMTS network connected

HSDPA network connected

HSPA+ network connected

Wi-Fi connected

Bluetooth feature activated

GPS activated

Call in progress

Missed call

Smart stay or smart pause feature activated

Synced with the web

Connected to computer

No SIM or USIM card

Basics

Icon Meaning

New text or multimedia message

Alarm activated

Mute mode activated

Vibration mode activated

Flight mode activated

Error occurred or caution required

Battery power level

Notifications and quick setting panels

Using the notifications panel

When you receive new notifications, such as messages or missed calls, indicator icons appear on the status bar. To see more information about the icons, open the notifications panel and view the details.

To open the notifications panel, drag the status bar downwards. To close the notifications panel, drag the bar from the bottom of the screen upwards.

Basics

Launch Settings.

You can use the following functions on the notifications panel.

Activate or deactivate options.

Tap and hold a button to view

more detailed settings.

View all quick setting buttons.

Launch S Finder.

Adjust the brightness.

Launch Quick connect.

Clear all notifications.

Tap a notification and perform various actions.

Adjusting the brightness

To set the device to adjust the brightness automatically, tick brightness, drag the brightness adjustment bar to the left or right.

When the battery power is low, the brightness adjustment bar disappears from the

Auto

. To manually adjust the

notifications panel.

Rearranging quick setting buttons

To rearrange quick setting buttons on the notifications panel, tap , tap and hold an item, and then drag the item to another location.

+ 191 hidden pages
