Samsung SM-C9000 User Guide

User Manual

SM-C9000

English (HK). 12/2016. Rev.1.0

www.samsung.com/hk

Table of Contents

Basics

4 Read me first

5 Device overheating situations and

solutions

8 Package contents

9 Device layout

12 Battery

16 SIM or USIM card

20 Memory card (microSD card)

22 Turning the device on and off

23 Touchscreen

25 Home screen

31 Lock screen

32 Always On Display

34 Notification panel

50 Device and data management

53 Quick connect

55 Sharing features

56 Emergency mode

Applications

57 Installing or uninstalling apps

59 Phone

62 Contacts

64 Messages

66 Internet

68 Email

69 Camera

79 Gallery

36 Entering text

38 Screen capture

39 Opening apps

39 Secure Folder

43 Multi window

47 Samsung account

48 Transferring data from your previous

device

84 Game Launcher

86 Samsung Notes

88 Calendar

89 S Health

92 S Voice

93 Voice Recorder

95 My Files

96 Clock

97 Calculator

98 Radio

99 Google apps

Table of Contents

Settings

101 Introduction

101 Connections

112 Sounds and vibration

113 Notifications

113 Display

115 Wallpapers and themes

116 Advanced features

118 Device maintenance

120 Applications

120 Lock screen and security

125 Cloud and accounts

127 Google

127 Accessibility

128 General management

129 Software update

129 User manual

129 About device

Appendix

130 Troubleshooting

Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider, model specifications, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media.

•

You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty.

•

Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC,

Apps

→

you can view the FCC ID of the device. To view the FCC ID, tap

About device

→

Battery info

Settings

→

Basics

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

Device overheating situations and solutions

When the device heats up while charging the battery

While charging, the device and the charger may become hot. During wireless charging or fast charging, the device may feel hotter to the touch. This does not affect the device’s lifespan or performance and is in the device’s normal range of operation. If the battery becomes too hot, the charger may stop charging.

Do the following when the device heats up:

•

Disconnect the charger from the device and close any running apps. Wait for the device to cool down and then begin charging the device again.

•

If the lower part of the device overheats, it could be because the connected USB cable is damaged. Replace the damaged USB cable with a new Samsung-approved one.

•

When using a wireless charger, do not place foreign materials, such as metal objects, magnets, and magnetic stripe cards, between the device and the wireless charger.

Basics

When the device heats up during use

When you use features or apps that require more power or use them for extended periods, your device may temporarily heat up due to increased battery consumption. Close any running apps and do not use the device for a while.

The following are examples of situations in which the device may overheat.

•

During the initial setup after purchase or when restoring data

•

When downloading large files

•

When using apps that require more power or using apps for extended periods

–

When playing high-quality games for extended periods

–

When recording videos for extended periods

–

When streaming videos while using the maximum brightness setting

–

When using the Screen Mirroring feature (When connecting to a TV)

•

While multitasking (or, when running many apps in the background)

–

When using Multi window

–

When updating or installing apps while recording videos

–

When downloading large files during a video call

–

When recording videos while using a navigation app

•

When using large amount of data for syncing with the cloud, email, or other accounts

•

When using a navigation app in a car while the device is placed in direct sunlight

•

When using the mobile hotspot and tethering feature

•

When using the device in areas with weak signals or no reception

•

When charging the battery with a damaged USB cable

•

When the device’s multipurpose jack is damaged or exposed to foreign materials, such as liquid, dust, metal powder, and pencil lead

•

When you are roaming

Basics

Do the following when the device heats up:

•

Keep the device updated with the latest software.

•

Conflicts between running apps may cause the device to heat up. Restart the device.

•

Deactivate the Wi-Fi, GPS, and Bluetooth features when not using them.

•

Close apps that increase battery consumption or that run in the background when not in use.

•

Delete unnecessary files or unused apps.

•

Decrease the screen brightness.

•

If the device overheats or feels hot for a prolonged period, do not use it for a while. If the device continues to overheat, contact a Samsung Service Centre.

Precautions for operating environment

Your device may heat up due to the environment in the following conditions. Use caution to avoid damaging the device or shortening the battery’s lifespan.

•

Do not store your device in very cold or very hot temperatures.

•

Do not expose your device to direct sunlight for extended periods.

•

Do not use or store your device for extended periods in very hot areas, such as inside a car in the summertime.

•

Do not place the device in any areas that may overheat, such as on an electric heating mat.

•

When using a wireless charger, do not place foreign materials, such as metal objects, magnets, and magnetic stripe cards, between the device and the wireless charger.

•

Never use a damaged charger or battery.

Basics

Package contents

Check the product box for the following items:

•

Device

•

Quick start guide

•

The items supplied with the device and any available accessories may vary depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website.

Basics

Speaker

Device layout

Microphone

Front camera

Touchscreen

Home key (Fingerprint

recognition sensor)

Recents key

Headset jack

Proximity/Light sensor

Power key

Memory card tray

SIM card tray

Back key

Microphone

Speaker

Multipurpose jack

(USB Type-C)

Basics

Main antenna

Rear camera

NFC antenna

Main antenna

•

Connectivity problems and battery drain may occur in the following situations:

GPS antenna

Volume key

Flash

•

Using a Samsung-approved screen protector is recommended. Unapproved screen protectors may cause the sensors to malfunction.

•

Do not allow water to contact the touchscreen. The touchscreen may malfunction in humid conditions or when exposed to water.

–

If you attach metallic stickers on the antenna area of the device

–

If you attach a device cover made with metallic material to the device

–

If you cover the device’s antenna area with your hands or other objects while using certain features, such as calls or the mobile data connection

Basics

Keys

Key Function

•

Press and hold to turn the device on or off.

Power

•

Press to turn on or lock the screen.

•

Tap to open the list of recent apps.

Recents

•

Tap and hold to launch the split screen view.

•

Press to turn on the screen while the screen is locked.

Home

Back

Volume

•

Press to return to the Home screen.

•

Press and hold to launch

•

Tap to return to the previous screen.

•

Press to adjust the device volume.

Google

Basics

Battery

Charging the battery

Charge the battery before using it for the first time or when it has been unused for extended periods.

Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.

Connect the USB cable to the USB power adaptor, and then plug the end of the USB cable

into the multipurpose jack.

Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty.

Plug the USB power adaptor into an electric socket.

After fully charging, disconnect the device from the charger. First unplug the charger

from the device, and then unplug it from the electric socket.

To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging.

Basics

Charging with a Micro USB cable

Connect the Micro USB connector to charge the battery with a Micro USB cable.

Do not plug a Micro USB cable into your device’s multipurpose jack. Doing so may damage the device and the cable.

The Micro USB connector is used for charging the battery and connecting to a computer.

Viewing the remaining charging time

While charging, open the Home screen and tap

Battery

The actual charging time may vary depending on the status of your device and the charging conditions. The remaining charging time may not be displayed when you charge the device in very cold or very hot conditions.

Apps

→

Settings

→

Device maintenance

→

Basics

Reducing the battery consumption

Your device provides various options that help you conserve battery power.

•

Optimise the device using the device maintenance feature.

•

When you are not using the device, switch to sleep mode by pressing the Power key.

•

Activate power saving mode.

•

Close unnecessary apps.

•

Deactivate the Bluetooth feature when not in use.

•

Deactivate the Wi-Fi feature when not in use.

•

Deactivate auto-syncing of apps that need to be synced, such as emails.

•

Decrease the backlight time.

•

Decrease the screen brightness.

Battery charging tips and precautions

•

When the battery power is low, the battery icon appears empty.

•

If the battery is completely discharged, the device cannot be turned on immediately when the charger is connected. Allow a depleted battery to charge for a few minutes before turning on the device.

•

If you use multiple apps at once, network apps, or apps that need a connection to another device, the battery will drain quickly. To avoid losing power during a data transfer, always use these apps after fully charging the battery.

•

Using a power source other than the charger, such as a computer, may result in a slower charging speed due to a lower electric current.

•

The device can be used while it is charging, but it may take longer to fully charge the battery.

•

If the device receives an unstable power supply while charging, the touchscreen may not function. If this happens, unplug the charger from the device.

•

While charging, the device and the charger may heat up. This is normal and should not affect the device’s lifespan or performance. If the battery gets hotter than usual, the charger may stop charging.

•

If you charge the device while the multipurpose jack is wet, the device may be damaged. Thoroughly dry the multipurpose jack before charging the device.

•

If the device is not charging properly, take the device and the charger to a Samsung Service Centre.

Basics

Fast charging

The device has a built-in fast charging feature. You can charge the battery more quickly while the device or its screen is turned off.

About Fast charging

•

Fast charging uses battery charging technology that charges the battery faster by increasing the charging power. The device supports Samsung’s Adaptive fast charging feature and Qualcomm Quick Charge 2.0.

•

To use Fast charging on your device, connect it to a battery charger that supports Adaptive fast charging or Quick Charge 2.0.

Increasing the charging speed

To increase the charging speed, turn the device or its screen off when you charge the battery. While charging the battery when the device is turned off, the

If the fast charging feature is not activated, on the Home screen, tap

→

Device maintenance charging

switch to activate it.

•

You cannot use the built-in fast charging feature when you charge the battery using a standard battery charger.

•

If the device heats up or the ambient air temperature rises, the charging speed may decrease automatically. This is a normal operating condition to prevent damage to the device.

→

Battery

→

Advanced settings

icon appears on the screen.

Apps

→

Settings

, and then tap the

Fast cable

→

Power saving mode

Activate power saving mode to extend the battery’s usage time.

On the Home screen, tap

Apps

→

Settings

→

Device maintenance

→

Battery

→

MID

2 3

Tap

CUSTOMISE

mode.

Tap

APPLY

to change the power saving settings before entering power saving

Basics

Maximum power saving mode

In maximum power saving mode, the device decreases battery consumption by applying the dark theme and limiting the apps and features available. Network connections, except for the mobile network, will be deactivated.

On the Home screen, tap

Tap

2 3

After entering maximum power saving mode, on the Home screen, tap to use. To remove apps, tap

To deactivate maximum power saving mode, tap

mode

CUSTOMISE

saving mode.

Tap

APPLY

The estimated battery usage time may vary depending on your device settings and operating conditions.

to change the power saving settings before entering maximum power

Apps

→

Settings

Edit

and select an app with .

→

Device maintenance

→

Disable Maximum power saving

SIM or USIM card

→

Battery

and select an app

→

MAX

Installing the SIM or USIM card

Insert the SIM or USIM card provided by the mobile telephone service provider.

•

Use only a nano-SIM card.

•

Use caution not to lose or let others use the SIM or USIM card. Samsung is not responsible for any damages or inconveniences caused by lost or stolen cards.

•

Dual SIM models: In some areas, data transfer speeds may be slower if two SIM cards are inserted in the device than when one SIM card is inserted.

•

Some LTE services may not be available depending on the service provider. For more information about service availability, contact your service provider.

Basics

Insert the ejection pin into the hole on the SIM card tray to loosen the tray.

Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged.

Pull out the SIM card tray gently from the SIM card tray slot.

Place the SIM or USIM card on the SIM card tray with the gold-coloured contacts facing

downwards.

Place the primary SIM or USIM card on the SIM card tray 1 ( USIM card on the SIM card tray 2 (

2 ).

1 ) and the secondary SIM or

Basics

Gently press the SIM or USIM card into the tray to secure it.

If the card is not fixed firmly into the tray, the SIM card may leave or fall out of the tray.

Insert the SIM card tray back into the SIM card tray slot.

•

Carefully insert the SIM card tray to prevent the SIM cards from leaving or falling out of the tray.

•

If you insert the tray into your device while the tray is wet, your device may be damaged. Always make sure the tray is dry.

•

Fully insert the tray into the tray slot to prevent liquid from entering your device.

Removing the SIM or USIM card

Insert the ejection pin into the hole on the SIM card tray to loosen the tray.

Pull out the SIM card tray gently from the SIM card tray slot.

Remove the SIM or USIM card.

Insert the SIM card tray back into the SIM card tray slot.

Basics

Using dual SIM or USIM cards

If you insert two SIM or USIM cards, you can have two phone numbers or service providers for a single device.

Activating SIM or USIM cards

On the Home screen, tap SIM or USIM card and tap the switch to activate it.

If both cards are activated, you can receive calls and messages on each card. However, if you are on a call using one card, the other card cannot be used to receive new calls. These situations apply to voice and video calls.

Apps

→

Settings

→

Connections

Customising SIM or USIM cards

On the Home screen, tap a SIM or USIM card to access the following options:

•

Icon

: Change the icon of the SIM or USIM card.

•

Name

•

Network mode

: Change the display name of the SIM or USIM card.

Apps

→

Settings

: Select a network type to use with the SIM or USIM card.

→

Connections

Setting preferred SIM or USIM cards

→

SIM card manager

→

SIM card manager

. Select a

and select

When two cards are activated, you can assign voice calls, messaging, data services and NFC payment to specific cards.

On the Home screen, tap the feature preferences for your cards in

Apps

→

Settings

→

Connections

Preferred SIM card

→

SIM card manager

and set

Basics

Memory card (microSD card)

Installing a memory card

Your device’s memory card capacity may vary from other models and some memory cards may not be compatible with your device depending on the memory card manufacturer and type. To view your device’s maximum memory card capacity, refer to the Samsung website.

•

Some memory cards may not be fully compatible with the device. Using an incompatible card may damage the device or the memory card, or corrupt the data stored in it.

•

Use caution to insert the memory card right-side up.

•

The device supports the FAT and the exFAT file systems for memory cards. When inserting a card formatted in a different file system, the device asks to reformat the memory card.

•

Frequent writing and erasing of data shortens the lifespan of memory cards.

•

When inserting a memory card into the device, the memory card’s file directory appears in the

My Files

→

SD card

folder.

Basics

Insert the ejection pin into the hole on the memory card tray to loosen the tray.

Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged.

Pull out the memory card tray gently from the memory card tray slot.

Place a memory card on the memory card tray with the gold-coloured contacts facing

downwards.

Gently press the memory card into the tray to secure it.

Insert the memory card tray back into the memory card tray slot.

•

If you insert the tray into your device while the tray is wet, your device may be damaged. Always make sure the tray is dry.

•

Fully insert the tray into the tray slot to prevent liquid from entering your device.

Removing the memory card

Before removing the memory card, first unmount it for safe removal.

On the Home screen, tap

Storage settings

Insert the ejection pin into the hole on the memory card tray to loosen the tray.

Pull out the memory card tray gently from the memory card tray slot.

Remove the memory card.

Insert the memory card tray back into the memory card tray slot.

→

Apps

SD card

→

Unmount

Settings

→

Device maintenance

→

Storage

→ →

Do not remove the memory card while the device is transferring or accessing information. Doing so can cause data to be lost or corrupted or damage to the memory card or device. Samsung is not responsible for losses that result from the misuse of damaged memory cards, including the loss of data.

Basics

Formatting the memory card

A memory card formatted on a computer may not be compatible with the device. Format the memory card on the device.

On the Home screen, tap

Storage settings

Before formatting the memory card, remember to make backup copies of all important data stored in the memory card. The manufacturer’s warranty does not cover loss of data resulting from user actions.

→

Apps

SD card

→

Settings

Format

→

FORMAT

Device maintenance

→

Storage

→ →

Turning the device on and off

Press and hold the Power key for a few seconds to turn on the device.

When you turn on your device for the first time or after performing a data reset, follow the onscreen instructions to set up your device.

To turn off the device, press and hold the Power key, and then tap

Follow all posted warnings and directions from authorised personnel in areas where the use of wireless devices is restricted, such as aeroplanes and hospitals.

Power off

Restarting the device

If your device is frozen and unresponsive, press and hold the Power key and the Volume Down key simultaneously for more than 7 seconds to restart it.

Volume Down button

Power button

Basics

Touchscreen

•

Do not allow the touchscreen to come into contact with other electrical devices. Electrostatic discharges can cause the touchscreen to malfunction.

•

To avoid damaging the touchscreen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips.

•

The device may not recognise touch inputs close to the edges of the screen, which are outside of the touch input area.

•

Leaving the touchscreen idle for extended periods may result in afterimages (screen burn-in) or ghosting. Turn off the touchscreen when you do not use the device.

•

It is recommended to use fingers when you use the touchscreen.

Tapping

To open an app, to select a menu item, to press an on-screen button, or to enter a character using the keyboard on the screen, tap it with your finger.

Tapping and holding

Tap and hold an item or the screen for more than 2 seconds to access available options.

Basics

Dragging

To move an item, tap and hold it and drag it to the target position.

Double-tapping

Double-tap on a webpage or image to zoom in. Double-tap again to return.

Swiping

Swipe to the left or right on the Home screen or the Apps screen to view other panels. Swipe upwards or downwards to scroll through a webpage or a list of items, such as contacts.

Basics

Spreading and pinching

Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.

Home screen

The Home screen is the starting point for accessing all of the device’s features. It displays widgets, icons for all apps, and more.

To view other panels, swipe to the left or right, or tap one of the screen indicators at the bottom of the screen.

A widget

An app

A folder

News screen indicator. View the
