Samsung SmartThings Hub User Manual

SmartThings Hub Manual

Welcome

Hi, and thanks for joining the SmartThings family. Please make sure you followed
the Getting Started steps in your kit. This user manual will give you some additional
info on your SmartThings Hub. If you have any questions at all, simply boot up your
mobile app to talk to us directly or go to www.smartthings.com.

Meet Your Hub

The SmartThings Hub acts as the bridge between all of your connected SmartThings
and the Internet. In brief, it does a few things:



Connects to SmartThings – The SmartThings Hub speaks a few different
languages. ZigBee, Zwave, IP and more. Depending on what SmartT hings
you have in your world, the SmartThings Hub basically acts as a universal
interpreter.



Connects to the Internet – Once plugged into your Internet router via the
enclosed Ethernet cable, the SmartThings Hub automatically makes a secur e
connection to the Internet and the SmartThings Cloud.

 Passes Events and Commands – When one of your connected SmartThings

has a message (for instance motion was detected or a door opened) or you
or an installed SmartApp have an instruction for a SmartThing (turn on a
light), and SmartThings hub will be responsible for sending that message
along securely.

Getting Around

The good news is that your SmartThings Hub does all the heavy lifting for you, and
it’s pretty simple. No buttons to worry about. (INSERT IMAGE WITH LABELS)

 Ethernet Jack – Provides connectivity to the Internet via the included Ethernet

cable.

 Power Cable – The SmartThings Hub runs on a micro-USB power provided

by the included pluggable power adapter and cable.

 Power Light – Let’s you know when the SmartThings Hub is powered on.

There is an important code on the bottom of your SmartThings Hub that you’ll need
for registration. It’s right here. (ARROW POINTING TO IT)

Installation

The SmartThings Hub works best if installed in a central location to where your
SmartThings will be connected. Avoid installing the SmartThings Hub near or inside
sources of metal, radio or electromagnetic interference.

Please follow the instructions provided online when installing your SmartThings Hub.
There are three critical steps:

1. Connecting your SmartThings Hub to your Internet router via the included
Ethernet cable.
