User Manual

English (HK). 07/2016. Rev.1.0

Table of Contents

Basics

4 Read me first

5 Package contents

6 Device layout

8 Battery

12 SIM or USIM card (nano-SIM card)

15 Memory card (microSD card)

17 Turning the device on and off

18 Touchscreen

20 Home screen

26 Lock screen

27 Notification panel

28 Entering text

31 Screen capture

32 Opening apps

32 Multi window

36 Samsung account

37 Transferring data from your previous

device

39 Device and data management

42 Quick connect

43 Sharing features

44 Emergency mode

Applications

45 Installing or uninstalling apps

47 Phone

50 Contacts

52 Messages

55 Internet

56 Email

57 Camera

66 Gallery

69 Game Launcher

72 S Planner

73 S Health

76 S Voice

77 Voice Recorder

79 My Files

80 Memo

80 Clock

82 Calculator

83 Radio

84 Google apps

Table of Contents

Appendix

114 Troubleshooting

Settings

86 Introduction

86 Wi-Fi

88 Bluetooth

89 Flight mode

90 Mobile hotspot and tethering

91 Data usage

91 SIM card manager

92 Mobile networks

92 NFC and payment

94 More connection settings

96 Smart Manager

98 Applications

98 Sounds and vibrations

99 Notifications

99 Do not disturb

99 Display

100 Advanced features

101 Wallpaper

101 Themes

101 Home screen

102 Lock screen and security

106 Privacy and safety

109 Easy mode

109 Accessibility

110 Accounts

111 Google

111 Backup and reset

112 Language and input

112 Battery

113 Storage

113 Date and time

113 User manual

113 About device

Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider, model specifications, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media.

•

You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty.

•

Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC, you can view the FCC ID of the device. To view the FCC ID, tap

Apps

→

Settings

→

About device

→

Battery info

Basics

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

Package contents

Check the product box for the following items:

•

Device

•

Quick start guide

•

The items supplied with the device and any available accessories may vary depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website.

Basics

Device layout

Microphone

Loud speaker

Back key

Multipurpose jack

Proximity sensor

Receiver

Power key

SIM card / Memory card tray

Touchscreen

Recents key

Headset jack

Home key (Fingerprint

recognition sensor)

Front camera

Microphone

Volume key

NFC antenna

Rear camera

Main antenna

Flash

GPS antenna

Basics

•

Connectivity problems and battery drain may occur in the following situations:

–

If you attach metallic stickers on the antenna area of the device

–

If you attach a device cover made with metallic material to the device

–

If you cover the device’s antenna area with your hands or other objects while using certain features, such as calls or the mobile data connection

•

Using a Samsung-approved screen protector is recommended. Unapproved screen protectors may cause the sensors to malfunction.

•

Do not allow water to contact the touchscreen. The touchscreen may malfunction in humid conditions or when exposed to water.

Keys

Key Function

Power

•

Press and hold to turn the device on or off.

•

Press to turn on or lock the screen.

Recents

•

Tap to open the list of recent apps.

•

Tap and hold to launch the split screen view.

Home

•

Press to turn on the screen while the screen is locked.

•

Press to return to the Home screen.

•

Press and hold to launch

Google

Back

•

Tap to return to the previous screen.

•

Tap and hold to access additional options for the current screen.

Volume

•

Press to adjust the device volume.

Basics

Battery

Charging the battery

Charge the battery before using it for the first time or when it has been unused for extended periods.

Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.

Connect the USB cable to the USB power adaptor, and then plug the end of the USB cable into the multipurpose jack.

Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty.

Plug the USB power adaptor into an electric socket.

After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket.

To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging.

Basics

Viewing the remaining charging time

While charging, open the Home screen and tap

Apps

→

Settings

→

Battery

The actual charging time may vary depending on the status of your device and the charging conditions. The remaining charging time may not be displayed when you charge the device in very cold or very hot conditions.

Reducing the battery consumption

Your device provides various options that help you conserve battery power.

•

Optimise the device using the Smart manager.

•

When you are not using the device, switch to sleep mode by pressing the Power key.

•

Activate power saving mode.

•

Close unnecessary apps.

•

Deactivate the Bluetooth feature when not in use.

•

Deactivate the Wi-Fi feature when not in use.

•

Deactivate auto-syncing of apps that need to be synced, such as emails.

•

Decrease the backlight time.

•

Decrease the screen brightness.

Battery charging tips and precautions

•

When the battery power is low, the battery icon appears empty.

•

If the battery is completely discharged, the device cannot be turned on immediately when the charger is connected. Allow a depleted battery to charge for a few minutes before turning on the device.

•

If you use multiple apps at once, network apps, or apps that need a connection to another device, the battery will drain quickly. To avoid losing power during a data transfer, always use these apps after fully charging the battery.

•

Using a power source other than the charger, such as a computer, may result in a slower charging speed due to a lower electric current.

•

The device can be used while it is charging, but it may take longer to fully charge the battery.

Basics

•

If the device receives an unstable power supply while charging, the touchscreen may not function. If this happens, unplug the charger from the device.

•

While charging, the device and the charger may heat up. This is normal and should not affect the device’s lifespan or performance. If the battery gets hotter than usual, the charger may stop charging.

•

If you charge the device while the multipurpose jack is wet, the device may be damaged. Thoroughly dry the multipurpose jack before charging the device.

•

If the device is not charging properly, take the device and the charger to a Samsung Service Centre.

Fast charging

The device has a built-in fast charging feature. You can use this feature to charge the battery more quickly while the device or its screen is turned off.

About Fast charging

•

Fast charging uses battery charging technology that charges the battery faster by increasing the charging power. The device supports Samsung’s Adaptive fast charging feature.

•

To use Fast charging on your device, connect it to a battery charger that supports Adaptive fast charging.

Increasing the charging speed

To increase the charging speed, turn the device or its screen off when you charge the battery.

•

While charging the battery when the device is turned off, the

icon appears on the

screen.

•

You cannot use the fast charging feature when the screen is turned on. Turn off the screen to increase the charging speed.

If the fast charging feature is not activated, on the Home screen, tap

Apps

→

Settings

→

Battery

, and then tap the

Fast cable charging

switch to activate it.

If the device heats up or the ambient air temperature rises, the charging speed may decrease automatically. This is a normal operating condition to prevent damage to the device.

Basics

Power saving mode

Save the battery power by limiting the device’s functions.

On the Home screen, tap

Apps

→

Settings

→

Battery

→

Power saving mode

, and then tap

the switch to activate it.

To automatically activate power saving mode when the remaining battery power reaches the preset level, tap

Start power saving

and select an option.

Ultra power saving mode

Use this mode to extend the device’s battery power. In ultra power saving mode, the device performs the following:

•

Displays colours on the screen as grey tones.

•

Restricts the available apps to essential and selected apps only.

•

Deactivates the mobile data connection when the screen turns off.

•

Deactivates the Wi-Fi and Bluetooth features.

On the Home screen, tap

Apps

→

Settings

→

Battery

→

Ultra power saving mode

, and

then tap the switch to activate it.

To deactivate ultra power saving mode, tap

→

Disable Ultra power saving mode

The usage time left shows the time remaining before the battery power runs out. Usage time left may vary depending on your device settings and operating conditions.

Basics

SIM or USIM card (nano-SIM card)

Installing the SIM or USIM card

Insert the SIM or USIM card provided by the mobile telephone service provider.

Use caution not to lose or let others use the SIM or USIM card. Samsung is not responsible for any damages or inconveniences caused by lost or stolen cards.

•

In some areas, data transfer speeds may be slower if two SIM cards are inserted in the device than when one SIM card is inserted.

•

Some LTE services may not be available depending on the service provider. For more information about service availability, contact your service provider.

1 2 3

Insert the ejection pin into the hole on the tray to loosen the tray.

Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged.

Pull out the tray gently from the tray slot.

Basics

Place the SIM or USIM card on the tray with the gold-coloured contacts facing downwards.

Place the primary SIM or USIM card on the tray 1 (

1 ) and the secondary SIM or USIM card

on the tray 2 (

2 ).

Tray 2

Tray 1

Gently press the SIM or USIM card into the tray to secure it.

If the card is not fixed firmly into the tray, the SIM card may leave or fall out of the tray.

Insert the tray back into the tray slot.

Correct card installation

Nano-SIM card

microSD card

•

Use only a nano-SIM card.

•

You cannot insert a nano-SIM card and a microSD card in tray 2 at the same time.

Removing the SIM or USIM card

Insert the ejection pin into the hole on the tray to loosen the tray.

Pull out the tray gently from the tray slot.

Basics

Remove the SIM or USIM card.

Insert the tray back into the tray slot.

Using dual SIM or USIM cards

If you insert two SIM or USIM cards, you can have two phone numbers or service providers for a single device.

Activating SIM or USIM cards

On the Home screen, tap

Apps

→

Settings

→

SIM card manager

. Select a SIM or USIM card

and tap the switch to activate it.

Customising SIM or USIM cards

On the Home screen, tap

Apps

→

Settings

→

SIM card manager

and select a SIM or USIM

card to access the following options:

•

Icon

: Change the icon of the SIM or USIM card.

•

Name

: Change the display name of the SIM or USIM card.

•

Network mode

: Select a network type to use with the SIM or USIM card.

Setting preferred SIM or USIM cards

When two cards are activated, you can assign voice calls, messaging, and data services to specific cards.

On the Home screen, tap

Apps

→

Settings

→

SIM card manager

and set the feature

preferences for your cards in

Preferred SIM card

Basics

Memory card (microSD card)

Installing a memory card

Your device accepts memory cards with maximum capacities of 128 GB. Depending on the memory card manufacturer and type, some memory cards may not be compatible with your device.

•

Some memory cards may not be fully compatible with the device. Using an incompatible card may damage the device or the memory card, or corrupt the data stored in it.

•

Use caution to insert the memory card right-side up.

•

The device supports the FAT and the exFAT file systems for memory cards. When inserting a card formatted in a different file system, the device asks to reformat the memory card.

•

Frequent writing and erasing of data shortens the lifespan of memory cards.

•

When inserting a memory card into the device, the memory card’s file directory appears in the

My Files

→

SD card

folder.

1 2 3

Basics

Insert the ejection pin into the hole on the tray to loosen the tray.

Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged.

Pull out the tray gently from the tray slot.

When you remove the tray from the device, the mobile data connection will be disabled.

Place a memory card on the tray 2 with the gold-coloured contacts facing downwards.

Tray 2

Tray 1

Insert the tray back into the tray slot.

Removing the memory card

Before removing the memory card, first unmount it for safe removal.

On the Home screen, tap

Apps

→

Settings

→

Storage

→

SD card

→

Unmount

Alternatively, tap

next to

SD card

Insert the ejection pin into the hole on the tray to loosen the tray.

Pull out the tray gently from the tray slot.

Remove the memory card.

Insert the tray back into the tray slot.

Do not remove the memory card while the device is transferring or accessing information. Doing so can cause data to be lost or corrupted or damage to the memory card or device. Samsung is not responsible for losses that result from the misuse of damaged memory cards, including the loss of data.

Basics

Formatting the memory card

A memory card formatted on a computer may not be compatible with the device. Format the memory card on the device.

On the Home screen, tap

Apps

→

Settings

→

Storage

→

SD card

→

Format

→

FORMAT

Before formatting the memory card, remember to make backup copies of all important data stored in the memory card. The manufacturer’s warranty does not cover loss of data resulting from user actions.

Turning the device on and off

Press and hold the Power key for a few seconds to turn on the device.

When you turn on your device for the first time or after performing a data reset, follow the onscreen instructions to set up your device.

To turn off the device, press and hold the Power key, and then tap

Power off

Follow all posted warnings and directions from authorised personnel in areas where the use of wireless devices is restricted, such as aeroplanes and hospitals.

Restarting the device

If your device is frozen and unresponsive, press and hold the Power key and the Volume Down key simultaneously for more than 7 seconds to restart it.

Power key

Volume Down key

Basics

Touchscreen

•

Do not allow the touchscreen to come into contact with other electrical devices. Electrostatic discharges can cause the touchscreen to malfunction.

•

To avoid damaging the touchscreen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips.

•

The device may not recognise touch inputs close to the edges of the screen, which are outside of the touch input area.

•

Leaving the touchscreen idle for extended periods may result in afterimages (screen burn-in) or ghosting. Turn off the touchscreen when you do not use the device.

•

It is recommended to use fingers when you use the touchscreen.

Tapping

To open an app, to select a menu item, to press an on-screen button, or to enter a character using the keyboard on the screen, tap it with your finger.

Tapping and holding

Tap and hold an item or the screen for more than 2 seconds to access available options.

Basics

Dragging

To move an item, tap and hold it and drag it to the target position.

Double-tapping

Double-tap on a webpage or image to zoom in. Double-tap again to return.

Swiping

Swipe to the left or right on the Home screen or the Apps screen to view other panels. Swipe upwards or downwards to scroll through a webpage or a list of items, such as contacts.

Basics

Spreading and pinching

Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.

Home screen

The Home screen is the starting point for accessing all of the device’s features. It displays widgets, shortcuts to apps, and more.

To view other panels, swipe to the left or right.

A widget

Screen indicators

Favourite apps

A folder

Apps screen icon

An app

News screen indicator. View the

latest articles in various

categories.

Basics

Home screen options

On the Home screen, tap

Apps

→

Settings

→

Home screen

to access the available options. Alternatively, on the Home screen, tap and hold an empty area. Customise the Home screen by adding, deleting, or rearranging Home screen panels. You can also set the Home screen wallpaper, add widgets to the Home screen, and more.

•

Wallpapers

: Change the wallpaper settings for the Home screen and the locked screen.

•

Widgets

: Add widgets to the Home screen. Widgets are small apps that launch specific

app functions to provide information and convenient access on your Home screen.

•

Themes

: Change the device’s theme. Visual elements of interface, such as colours, icons,

and wallpapers, will change depending on the selected theme.

•

Screen grid

: Change the size of the grid to display more or less items on the Home screen

and the Apps screen.

Adding items

Tap and hold an app or a folder from the Apps screen, and then drag it to the Home screen.

To add widgets, tap and hold an empty area on the Home screen, tap

Widgets

, tap and hold a

widget, and then drag it to the Home screen.

Basics

Moving items

Tap and hold an item on the Home screen, and then drag it to a new location.

You can also move frequently used apps to the shortcuts area at the bottom of the Home screen.

To move the item to another panel, drag it to the side of the screen.

To move an item more easily, tap and hold an item, and drag it to

Move apps

at the top of the screen. The item will move to the panel at the top of the screen. Swipe to the left or right to move to another panel and drag the item to a new location.

Removing items

Tap and hold an item, and then drag it to

Remove

at the top of the screen.

Creating folders

Create folders and gather similar applications to quickly access and launch apps.

On the Home screen, tap and hold an app, and then drag it over another app.

Drop the app when a folder frame appears around the apps.

A new folder containing the selected apps will be created.

Tap

Enter folder name

and enter a folder name.

To change the folder colour, tap

To add more apps to the folder, tap

, tick the apps, and then tap

ADD

. You can also add

an app by dragging it to the folder on the Home screen.

Basics

To move apps from a folder to the Home screen, tap the folder, and then drag an app to the Home screen.

To delete apps in a folder, tap the folder, and then drag the app you want to delete to

Remove

at the top of the screen.

Managing panels

On the Home screen, tap and hold an empty area to add, move, or remove a panel.

To add a panel, swipe to the left, and then tap

To move a panel, tap and hold a panel preview, and then drag it to a new location.

To remove a panel, tap and hold a panel preview, and then drag it to

Remove

at the top of

the screen.

To set a panel as the main Home screen, tap

Apps screen

The Apps screen displays icons for all apps, including newly installed apps.

On the Home screen, tap

Apps

to open the Apps screen. To view other panels, swipe to the

left or right.

Moving items

This feature may not be available depending on the region or service provider.

On the Apps screen, tap

EDIT

. Tap and hold an item and drag it to a new location.

To move the item to another panel, drag it to the side of the screen.

Creating folders

Create folders and gather similar applications to quickly access and launch apps you want.

This feature may not be available depending on the region or service provider.

On the Apps screen, tap

EDIT

Tap and hold an app, and then drag it over another app.

Basics

Drop the app when a folder frame appears around the apps.

A new folder containing the selected apps will be created.

Tap

Enter folder name

and enter a folder name.

To change the folder colour, tap

To add more apps to the folder, tap

, tick the apps, and then tap

ADD

. You can also add

an app by dragging it to the folder on the Apps screen.

To delete a folder, select a folder with

. Only the folder will be deleted. The folder’s apps will

be relocated to the Apps screen.

Rearranging items

You can rearrange items in alphabetical order on the Apps screen.

On the Apps screen, tap

A-Z

→

SAVE

Searching for items

You can search for items on the Apps screen.

On the Apps screen, tap

and enter characters. The device will search for and display

the items containing the characters you entered.

Basics

Indicator icons

Indicator icons appear on the status bar at the top of the screen. The icons listed in the table below are most common.

The status bar may not appear at the top of the screen in some apps. To display the status bar, drag down from the top of the screen.

Icon Meaning

No signal

Signal strength

Currently accessing SIM or USIM card

Roaming (outside of normal service area)

GPRS network connected

EDGE network connected

UMTS network connected

HSDPA network connected

HSPA+ network connected

LTE network connected (LTE-enabled models)

Wi-Fi connected

Bluetooth feature activated

GPS activated

Call in progress

Missed call

New text or multimedia message

Alarm activated

Mute mode activated

Vibration mode activated

Flight mode activated

Error occurred or caution required

Battery power level

Basics

Lock screen

Pressing the Power key turns off the screen and locks it. Also, the screen turns off and automatically locks if the device is not used for a specified period.

The screen is locked with

Swipe

, the default screen lock method.

Press the Power key or the Home key and swipe in any direction to unlock the screen.

To change the screen lock method, on the Apps screen, tap

Settings

→

Lock screen and

security

→

Screen lock type

, and then select a method.

When you set a pattern, PIN, password, or fingerprint for the screen lock method, you can protect your personal information by preventing others from accessing your device. After setting the screen lock method, the device will require an unlock code whenever unlocking it.

•

Swipe

: Swipe in any direction on the screen to unlock it.

•

Pattern

: Draw a pattern with four or more dots to unlock the screen.

•

: Enter a PIN with at least four numbers to unlock the screen.

•

Password

: Enter a password with at least four characters, numbers, or symbols to unlock

the screen.

•

None

: Do not set a screen lock method.

•

Fingerprints

: Register your fingerprints to unlock the screen. Refer to Fingerprint

recognition for more information.

•

If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it.

•

You can set your device to perform a factory data reset if you enter the unlock code incorrectly several times in a row and reach the attempt limit. On the Apps screen, tap

Settings

→

Lock screen and security

→

Secure lock settings

and tap the

Auto factory reset

switch to activate it.

Basics

Notification panel

Using the notification panel

When you receive new notifications, indicator icons appear on the status bar. To see more information about the icons, open the notification panel and view the details.

To open the notification panel, drag the status bar downwards. To close the notification panel, swipe upwards on the screen.

You can use the following functions on the notification panel.

Tap a notification and perform

various actions.

Clear all notifications.

Adjust the brightness.

Launch Quick connect.

View more quick setting buttons.

Launch Settings.

Access the notification settings.

Quick setting buttons

SIM and USIM card feature preferences. Tap to access the SIM card manager.

Using quick setting buttons

Tap quick setting buttons to activate some features. Swipe to the left or right on the buttons area, or tap

to view more buttons. To view more detailed settings, tap and hold a button.

To rearrange buttons, tap

→

EDIT

. Then, tap and hold a button and drag it to another

location.

Basics

S Finder

Search for a wide variety of content with a keyword.

Searching for content on the device

Open the notification panel and tap →

S Finder

Enter a keyword in the search field or tap

and say a keyword.

To get more refined results, tap

Filter

under the search field, and then select filter details.

Setting search categories

You can set search categories to search for content in specific search fields.

Tap

→

Select search locations

and select categories.

Entering text

Keyboard layout

A keyboard appears automatically when you enter text to send messages, create memos, and more.

Text entry is not supported in some languages. To enter text, you must change the input language to one of the supported languages.

Break to the next line.

Delete a preceding character.

Enter symbols.

Enter numbers.

Change the input language.

Enter a space.

Hide the keyboard.

Additional keyboard functions

Changing the input language

Tap →

Add input languages

, and then select the languages to use. Tap the input

language key to switch between the input languages.

Basics

Changing the keyboard layout

Tap , select a language under

Languages and types

, and then select a keyboard layout to

use.

3x4 keyboard

, a key has three or four characters. To enter a character, tap the

corresponding key repeatedly until the desired character appears.

Additional keyboard functions

•

: Add an item from the clipboard.

•

→

CANGJIE

: Switch to the qwerty keyboard.

•

→

STROKE

: Switch to stroke mode. Tap stroke keys to enter a character. Tap when

you are unsure about which stroke to enter.

•

→

HALF-SCREEN HANDWRITING

FULL-SCREEN HANDWRITING

: Switch to

handwriting mode.

This feature may not be available depending on the region or service provider.

•

: Enter text by voice.

Start or pause entering text by voice.

Change the voice input settings.

Delete a preceding character.

•

: Enter emoticons.

•

: Open the text editing panel.

•

: Change the keyboard settings.

Basics

Copying and pasting

Tap and hold over text.

Drag or to select the desired text, or tap

Select all

to select all text.

Tap

Copy

Cut

The selected text is copied to the clipboard.

Tap and hold where the text is to be inserted and tap

Paste

To paste text that you have previously copied, tap

Clipboard

and select the text.

Dictionary

Look up definitions for words while using certain features, such as when browsing webpages.

Tap and hold over a word that you want to look up.

If the word you want to look up is not selected, drag

or to select the desired text.

Tap

Dictionary

on the options list.

If a dictionary is not preinstalled on the device, tap

Manage dictionaries

→ next to a

dictionary to download it.

View the definition in the dictionary pop-up window.

To switch to the full screen view, tap

. Tap the definition on the screen to view more

definitions. In the detailed view, tap

to add the word to your favourite words list or tap

Search Web

to use the word as a search term.

Basics

Screen capture

Capture a screenshot while using the device.

Capturing screenshots

Press and hold the Home key and the Power key simultaneously. You can view captured images in

Gallery

You can also capture screenshots by swiping your hand to the left or right across the screen. If this feature is not activated, open the Apps screen, tap

Settings

→

Advanced features

→

Palm swipe to capture

and tap the switch to activate it.

It is not possible to capture a screenshot while using some apps and features.

Smart capture

You can capture the current screen and scrollable area. You can also immediately crop and share the captured screen.

If this feature is not activated, open the Apps screen, tap

Settings

→

Advanced features

→

Smart capture

, tap the switch to activate it, and then capture a screenshot. On the screen you

are capturing, use one of the following options:

•

Capture more

: Capture more content that continues across multiple screens, such as a

web page. The screen will automatically scroll down and more content will be captured.

•

: Share the screenshot.

•

Crop

: Crop a portion from the screenshot.

Basics

Opening apps

On the Home screen or the Apps screen, select an app icon to open it.

To open an app from the list of recently used apps, tap

and select a recent app window.

Closing an app

Tap and drag a recent app window to the left or right to close it. To close all running apps, tap

CLOSE ALL

Multi window

Introduction

Multi window lets you run two apps at the same time in the split screen view. You can also run multiple apps at the same time in the pop-up view.

Some apps may not support this feature.

Split screen view Pop-up view

Basics

Split screen view

Tap to open the list of recently used apps.

Swipe upwards or downwards and tap on a recent app window.

The selected app will launch in the upper window.

Swipe to the left or right to select another app to launch.

You can also launch the split screen view by tapping and holding .

Basics

Using additional options

When using apps in the split screen view, select an app window and tap the circle between the app windows to access the following options:

•

: Switch locations between app windows.

•

: Drag and drop text or copied images from one window to another. Tap and hold an

item in the selected window and drag it to a location in another window.

Some apps may not support this feature.

•

: Minimise the window.

•

: Maximise the window.

•

: Close the app.

Basics

Adjusting the window size

Drag the circle between the app windows up or down to adjust the size of the windows.

Pop-up view

On the Apps screen, launch an app to use in the pop-up view.

Drag down diagonally from either end of the top edge.

The app screen will appear in the pop-up view.

Minimise the window.

Close the app.

Maximise the window.

Drag and drop content.

Moving pop-up windows

To move a pop-up window, tap and hold the circle on a window and drag it to a new location.

Basics

Samsung account

Introduction

Your Samsung account is an integrated account service that allows you to use a variety of Samsung services provided by mobile devices, TVs, and the Samsung website. Once your Samsung account has been registered, you can use apps provided by Samsung, without signing in to your account.

Create your Samsung account with your email address.

To check the list of services that can be used with your Samsung account, visit

account.samsung.com. For more information on Samsung accounts, open the Apps screen

and tap

Settings

→

Accounts

→

Samsung account

→

Help

Registering your Samsung account

Registering a new Samsung account

If you do not have a Samsung account, you should create one.

On the Apps screen, tap

Settings

→

Accounts

→

Add account

Tap

Samsung account

→

CREATE ACCOUNT

Follow the on-screen instructions to complete creating your account.

Registering an existing Samsung account

If you already have a Samsung account, register it to the device.

On the Apps screen, tap

Settings

→

Accounts

→

Add account

Tap

Samsung account

Enter your email address and password, and then tap

If you forget your account information, tap

Forgotten your ID or password?

You can find your account information when you enter the required information and security code displayed that is on the screen.

Basics

Removing your Samsung account

When you remove your registered Samsung account from the device, your data, such as contacts or events, will also be removed.

On the Apps screen, tap

Settings

→

Accounts

Tap

Samsung account

and tap the account to remove.

Tap

→

Remove account

→

REMOVE ACCOUNT

Enter your Samsung account password and tap

CONFIRM

Tap

REMOVE ACCOUNT

Transferring data from your previous device

You can transfer data from a previous device to your device via Samsung Smart Switch.

The following versions of Samsung Smart Switch are available.

•

Mobile version: Transfer data between mobile devices. You can download the app from

Galaxy Apps

Play Store

•

Computer version: Transfer data between your device and a computer. You can download the app from www.samsung.com/hk/smartswitch.

•

Samsung Smart Switch is not supported on some devices or computers.

•

Limitations apply. Visit www.samsung.com/hk/smartswitch for details. Samsung takes copyright seriously. Only transfer content that you own or have the right to transfer.

Basics

Transferring data wirelessly

Transfer data from your previous device to your device.

On both devices, download and install Smart Switch from

Galaxy Apps

Play Store

Place the devices near each other.

Launch

Smart Switch

on both devices.

On your device, select the previous device type from the list and tap

START

Follow the on-screen instructions to transfer data from your previous device.

Transferring backup data from a computer

Back up data from your previous device to a computer and import the data to your device.

On the computer, visit www.samsung.com/hk/smartswitch to download Smart Switch.

On the computer, launch Smart Switch.

If your previous device is not a Samsung device, back up data to a computer using a program provided by the device’s manufacturer. Then, skip to the fifth step.

Basics

Connect your previous device to the computer using the USB cable.

On the computer, follow the on-screen instructions to back up data from the device. Then, disconnect your previous device from the computer.

Connect your device to the computer using the USB cable.

On the computer, follow the on-screen instructions to transfer data to your device.

Device and data management

Connecting the device to a computer for data transfer

Move audio, video, image, or other types of files from the device to the computer, or vice versa.

Do not disconnect the USB cable from the device when you are transferring files. Doing so may cause data loss or device damage.

The devices may not connect properly if they are connected via a USB hub. Directly connect the device to the computer’s USB port.

Connect the device to the computer using the USB cable.

Open the notification panel, and then tap

Transferring media files via USB

→

Transferring media files

If the computer cannot recognise your device, tap

Transferring images

Tap

ALLOW

to permit the computer to access your device’s data.

When the computer recognises your device, the device will appear in My PC.

Transfer files between your device and the computer.

Basics

Updating the device

The device can be updated to the latest software.

Updating over the air

The device can be directly updated to the latest software by the firmware over-the-air (FOTA) service.

On the Apps screen, tap

Settings

→

About device

→

Download updates manually

When you tap the

Download update automatically

switch to activate it, updates will

be downloaded when the device is connected to a Wi-Fi network.

Updating with Smart Switch

Connect the device to a computer and update the device to the latest software.

On the computer, visit www.samsung.com/hk/smartswitch to download and install Smart Switch.

On the computer, launch Smart Switch.

Connect the device to the computer using a USB cable.

If a software update is available, follow the on-screen instructions to update the device.

•

Do not turn off the computer or disconnect the USB cable while the device is updating.

•

While updating the device, do not connect other media devices to the computer. Doing so may interfere with the update process. Before updating, disconnect all other media devices from the computer.

Basics

Backing up and restoring data

Keep your personal information, app data, and settings safe on your device. You can back up your sensitive information to a backup account and access it later. You must sign in to your Google or Samsung account to back up or restore data. Refer to Samsung account and

Accounts for more information.

Using a Samsung account

On the Apps screen, tap

Settings

→

Backup and reset

→

Back up my data

for the Samsung account, tap the switches next to the items you want to back up to activate them, and then tap

BACK UP NOW

To set the device to automatically back up data, tap the

Auto back up

switch to activate it.

To restore data using a Samsung account, tap

Restore

. Current data will be deleted from the

device to restore the selected items.

Using a Google account

On the Apps screen, tap

Settings

→

Backup and reset

→

Back up my data

for the Google account, and then tap the switch to activate it. Tap

Backup account

and select an account as

the backup account.

To restore data using a Google account, tap the

Automatic restore

switch to activate it. When

you reinstall apps, backed up settings and data will be restored.

Performing a data reset

Delete all settings and data on the device. Before performing a factory data reset, ensure you back up all important data stored on the device. Refer to Backing up and restoring data for more information.

On the Apps screen, tap

Settings

→

Backup and reset

→

Factory data reset

→

RESET

DEVICE

→

ERASE EVERYTHING

. The device automatically restarts.

Basics

Quick connect

Introduction

Quickly search for and connect with nearby devices, such as Bluetooth headsets, using the Quick connect feature.

•

If the device you want to connect does not support the Quick connect feature, activate its Wi-Fi Direct or Bluetooth feature before launching

Quick connect

your device.

•

Connection methods may vary depending on the type of connected devices or the shared content.

Connecting to other devices

Open the notification panel and tap

Quick connect

The Wi-Fi and Bluetooth features are activated automatically.

Quick connect

is not visible on the notification panel, tap →

EDIT

and tap the

Quick connect

switch to activate it.

Tap

Scan for nearby devices

If there is no previously connected device, the device will automatically search for nearby devices.

Select a device from the list and connect to it by following the on-screen instructions.

The next steps may vary depending on the connected device.

To change your device’s visibility setting, tap

→

Set device visibility

, and then select

an option.

Sharing content

Share content with the connected devices.

Open the notification panel and tap

Quick connect

Tap

Scan for nearby devices

Basics

Select a device from the list of detected devices.

Tap

Share content

and select a media category.

Follow the on-screen instructions to send content to the connected device.

The next steps may vary depending on the selected media category.

Sharing features

Share content by using various sharing options. The following actions are an example of sharing images.

You may incur additional charges when sharing files via the mobile network.

Tap

Gallery

on the Apps screen.

Select an image.

Tap

and select a sharing method, such as Bluetooth and email.

You can also use the following options:

•

Simple sharing

: Share content with your contacts. To use this feature, your phone

number must be verified.

•

This feature may not be available depending on the region or service provider.

•

If the recipients have not verified their phone numbers or if their devices do not support the feature, a link to the files will be sent to them via text message. The link will expire after a certain period.

•

Nearby sharing

: Share content with nearby devices via Wi-Fi Direct, Bluetooth, and

more.

•

: Print content using the printer plug-ins installed on the device.

Follow the on-screen instructions to share the image with others.

When the image is sent to the recipients’ devices, a notification will appear on their devices. Tap the notification to view or download the image.

Basics

Emergency mode

Emergency mode changes the screen to grey tones to reduce battery consumption. Some apps and functions will be restricted. In emergency mode, you can make an emergency call, send your current location information to others, sound an emergency alarm, and more.

Press and hold the Power key, and then tap

Emergency mode

Add more apps to use.

Make an emergency call.

Remaining battery power and

usage time left

Turn on the flash.

Make a call.

Send your current location

information in a message.

Browse the Internet.

Access additional options.

Sound alarms.

The usage time left shows the time remaining before the battery power runs out. Usage time left may vary depending on your device settings and operating conditions.

Deactivating emergency mode

To deactivate emergency mode, tap

→

Disable Emergency mode

. Alternatively, press

and hold the Power key, and then tap

Emergency mode

Applications

Installing or uninstalling apps

Galaxy Apps

Purchase and download apps. You can download apps that are specialised for Samsung Galaxy devices.

Tap

Samsung

→

Galaxy Apps

on the Apps screen.

This app may not be available depending on the region or service provider.

Installing apps

Browse apps by category or tap

to search for a keyword.

Select an app to view information about it. To download free apps, tap

INSTALL

. To purchase

and download apps where charges apply, tap the price and follow the on-screen instructions.

To change the auto update settings, tap

→

Settings

→

Auto update apps

and then select an option.

Play Store

Purchase and download apps.

Tap

Play Store

on the Apps screen.

Installing apps

Browse apps by category or search for apps by keyword.

Select an app to view information about it. To download free apps, tap

INSTALL

. To purchase

and download apps where charges apply, tap the price and follow the on-screen instructions.

To change the auto update settings, tap →

Settings

→

Auto-update apps

, and

then select an option.

Applications

Managing apps

Uninstalling or disabling apps

On the Apps screen, tap

EDIT

. The icon appears on the apps that you can disable or

uninstall. Select an app and tap

DISABLE

or OK. Alternatively, on the Apps screen, tap

Settings

→

Applications

→

Application manager

, select an app, and then tap

DISABLE

UNINSTALL

•

DISABLE

: Disable selected default apps that cannot be uninstalled from the device.

•

UNINSTALL

: Uninstall downloaded apps.

Enabling apps

On the Apps screen, tap

Settings

→

Applications

→

Application manager

→ →

Disabled

, select an app, and then tap

ENABLE

Setting app permissions

For some apps to operate properly, they may need permission to access or use information on your device. When you open an app, a pop-up window may appear and request access to certain features or information. Tap

ALLOW

on the pop-up window to grant permissions to

the app.

To view your app permission settings, open the Apps screen and tap

Settings

→

Applications

→

Application manager

. Select an app and tap

Permissions

. You can view the

app’s permissions list and change its permissions.

To view or change app permission settings by permission category, open the Apps screen, tap

Settings

→

Privacy and safety

→

App permissions

. Select an item and tap the switches

next to apps to grant permissions.

If you do not grant permissions to apps, the basic features of the apps may not function properly.

Applications

Phone

Introduction

Make or answer voice calls.

Making calls

Tap

Phone

on the Apps screen.

Enter a phone number.

If the keypad does not appear on the screen, tap

to open the keypad.

Tap or to make a voice call.

Add the number to the contacts

list.

Preview the phone number.

Hide the keypad.

Delete a preceding character.

Access additional options.

Using speed dial

Set speed dial numbers to quickly make calls.

To set a number to speed dial, tap

→

Speed dial

, select a speed dial number, and then

select a contact.

To make a call, tap and hold a speed dial number on the keypad. For speed dial numbers 10 and up, tap the first digit(s) of the number, and then tap and hold the last digit.

For example, if you set the number 123 as a speed dial number, tap 1, tap 2, and then tap and hold 3.

Applications

Making calls from the locked screen

On the locked screen, drag outside the large circle.

Making calls from call logs or contacts list

Tap

LOG

CONTACTS

, and then swipe to the right on a contact or a phone number to make

a call.

Making an international call

Tap to open the keypad if the keypad does not appear on the screen.

Tap and hold 0 until the + sign appears.

Enter the country code, area code, and phone number, and then tap or .

Receiving calls

Answering a call

When a call comes in, drag outside the large circle.

Rejecting a call

When a call comes in, drag outside the large circle.

To send a message when rejecting an incoming call, drag the reject message bar upwards.

To create various rejection messages, open the Apps screen, tap

Phone

→

Settings

→

Quick decline messages

, enter a message, and then tap .

Missed calls

If a call is missed, the icon appears on the status bar. Open the notification panel to view the list of missed calls. Alternatively, on the Apps screen, tap

Phone

→

LOG

to view missed

calls.

Applications

Blocking phone numbers

Block calls from specific numbers added to your block list.

On the Apps screen, tap

Phone

→

Settings

→

Block list

Tap , tick contacts, and then tap

DONE

To manually enter a number, tap

Enter phone number

, enter a phone number, and then

tap

When blocked numbers try to contact you, you will not receive notifications. The calls will be logged in the call log.

You can also block incoming calls from people that do not show their caller ID. Tap the

Block anonymous calls

switch to activate the feature.

Options during calls

During a voice call

The following actions are available:

•

HOLD

: Hold a call. Tap

RESUME CALL

to retrieve the held call.

•

Add call

: Dial a second call.

•

Extra volume

: Increase the volume.

•

Bluetooth

: Switch to a Bluetooth headset if it is connected to the device.

•

Speaker

: Activate or deactivate the speakerphone. When using the speakerphone, speak into the microphone at the bottom of the device and keep the device away from your ears.

•

Keypad

Hide

: Open or close the keypad.

•

Mute

: Turn off the microphone so that the other party cannot hear you.

•

: Send an email.

•

Message

: Send a message.

•

Internet

: Browse webpages.

•

Contacts

: Open the contacts list.

•

S Planner

: Open the calendar.

•

Memo

: Create a memo.

•

: End the current call.

Applications

Contacts

Introduction

Create new contacts or manage contacts on the device.

Adding contacts

Creating contacts manually

Tap

Contacts

on the Apps screen.

Tap and select a storage location.

Enter contact information.

•

: Add an image.

•

/ : Add or delete a contact field.

Tap

SAVE

To add a phone number to the contacts list from the keypad, open the Apps screen and tap

Phone

. If the keypad does not appear on the screen, tap to open the keypad. Enter the

number and tap

Add to Contacts

To add a phone number to the contacts list from received calls, open the Apps screen and tap

Phone

→

LOG

→ a contact.

Importing contacts

Import contacts from storage services to your device.

On the Apps screen, tap

Contacts

→

Settings

→

Import/Export contacts

→

IMPORT

and select an import option.

Applications

Searching for contacts

On the Apps screen, tap

Contacts

Use one of the following search methods:

•

Scroll up or down the contacts list.

•

Drag a finger along the index at the right side of the contacts list to scroll through it quickly.

•

Tap the search field at the top of the contacts list and enter search criteria.

Once a contact is selected, take one of the following actions:

•

: Add to favourite contacts.

•

: Make a voice call.

•

: Compose a message.

•

: Compose an email.

Sharing profile

Share your profile information, such as your photo and status message, with others using the profile sharing feature.

•

This feature may not be available depending on the region or service provider.

•

This feature is only available for contacts who have activated the profile sharing feature on their device.

On the Apps screen, tap

Contacts

→ your profile →

Profile sharing

, and then tap the switch to activate it. To use this feature, your phone number must be verified. You can view your contacts’ updated profile information in

Contacts

To set additional items to share, tap

Shared profile info

and select items.

To set a contact group to share your profile with, tap

Share with

and select an option.

Sharing contacts

You can share contacts with others by using various sharing options.

Tap

Contacts

on the Apps screen.

Tap

→

Applications

Tick contacts and tap

Select a sharing method.

Messages

Introduction

Send and view messages by conversation.

Sending messages

You may incur additional charges for sending messages when you are roaming.

Tap

Messages

on the Apps screen.

Tap .

Add recipients and enter a message.

Access additional options.

Enter a message.

Select contacts from the contacts list.

Enter emoticons.

Enter recipients.

Attach files.

Send the message.

Tap or to send the message.

Applications

Viewing messages

Messages are grouped into message threads by contact.

You may incur additional charges for receiving messages when you are roaming.

Tap

Messages

on the Apps screen.

On the messages list, select a contact.

View your conversation.

Blocking unwanted messages

Block messages from specific numbers or messages that contain phrases added to your block list.

Tap

Messages

on the Apps screen.

Tap

→

Settings

→

Block messages

Tap

Block list

To add phrases to block, tap

Blocked phrases

Tap

INBOX

CONTACTS

to select contacts and tap .

To manually enter a number, tap

Enter number

, enter a phone number, and then tap .

When you receive messages from the blocked numbers or messages including blocked phrases, you will not be notified. To view blocked messages, tap

→

Settings

→

Block

messages

→

Blocked messages

Applications

Setting the message notification

You can change notification sound, display options, and more.

Tap

Messages

on the Apps screen.

Tap

→

Settings

→

Notifications

, and then tap the switch to activate it.

Change the notification settings.

•

Notification sound

: Change the notification sound.

•

Vibrate

: Set the device to vibrate when you receive messages.

•

Pop-up display

: Set the device to display messages in pop-up windows.

•

Preview message

: Set the device to display message content on the locked screen

and in pop-up windows.

Setting a message reminder

You can set an alert at an interval to let you know that you have unchecked notifications. If this feature is not activated, open the Apps screen, tap

Settings

→

Accessibility

→

Notification reminder

, and then tap the switch to activate it. Then, tap the

Messages

switch

to activate it.

Applications

Internet

Introduction

Browse the Internet to search for information and bookmark your favourite webpages to access them conveniently.

Browsing webpages

Tap

Samsung

→

Internet

on the Apps screen.

Tap the address field.

Enter the web address or a keyword, and then tap Go.

To view the toolbars, drag your finger downwards slightly on the screen.

Open the homepage.

Move to the previously visited

page.

Open the browser's tab manager.

Access additional options.

Refresh the current webpage.

View your bookmarks, saved webpages, and recent browsing history.

Applications

Using secret mode

In secret mode, you can separately save and manage open tabs, bookmarks, and saved pages. You can lock secret mode using a password and your fingerprint.

Activating secret mode

In the toolbar at the bottom of the screen, tap

Tabs

→

ENABLE SECRET

. If you are using this

feature for the first time, set whether to use a password for secret mode.

In secret mode, you cannot use some features, such as screen capture.

In secret mode, the device will change the colour of the toolbars.

Changing security settings

You can change your password or the lock method.

Tap

→

Settings

→

Privacy

→

Secret mode security

→

Change password

. To set

your registered fingerprint as the lock method along with the password, tap the

Fingerprints

switch to activate it. Refer to Fingerprint recognition for more information about using your fingerprints.

Deactivating secret mode

In the toolbar at the bottom of the screen, tap

Tabs

→

DISABLE SECRET

Setting up email accounts

Set up an email account when opening

for the first time.

Tap

Samsung

→

on the Apps screen.

Enter the email address and password, and then tap

To manually register a email account, tap

MANUAL SETUP

Follow the on-screen instructions to complete the setup.

Applications

To set up another email account, tap

→

Settings

→

Add account

If you have more than one email account, you can set one as the default account. Tap

→

Settings

→

Set default account

Sending emails

Tap to compose an email.

Add recipients and enter an email text.

Tap

SEND

to send the mail.

Reading emails

When

is open, the device will automatically retrieve new emails. To manually retrieve

emails, swipe downwards on the screen.

Tap an email on the screen to read it.

If email syncing is disabled, new emails cannot be retrieved. To enable email syncing, tap

→

Settings

→ your account name, and then tap the

Sync account

switch

to activate it.

Camera

Introduction

Take photos and record videos using various modes and settings.

Basic shooting

You can take photos or record videos. View your photos and videos in

Gallery

Tap

Camera

on the Apps screen.

Camera etiquette

•

Do not take photos or record videos of other people without their permission.

•

Do not take photos or record videos where legally prohibited.

•

Do not take photos or record videos in places where you may violate other people’s privacy.

Applications

Taking photos or recording videos

Tap the image on the preview screen where the camera should focus.

Tap to take a photo or tap to record a video.

•

Spread two fingers apart on the screen to zoom in, and pinch to zoom out.

•

To adjust the brightness of photos or videos, tap the screen. When the adjustment bar appears, drag the adjustment bar towards

or .

•

To capture an image from the video while recording, tap

Capture

•

To change the focus while recording a video, tap where you want to focus. To focus on the centre of the screen, tap

Camera settings

Hide or show the

setting icons.

Quick settings

Record a video.

Take a photo.

Switch between the front and rear cameras.

Shooting modes

Preview thumbnail

Current mode

On the preview screen, swipe to the right to access the list of shooting modes. Or, swipe to the left to view photos and videos you have captured.

•

The preview screen may vary depending on the shooting mode and which camera is being used.

•

The camera automatically shuts off when unused.

•

Make sure that the lens is clean. Otherwise, the device may not work properly in some modes that require high resolutions.

•

Your device’s camera features a wide-angle lens. Minor distortion may occur in wide-angle photos and does not indicate device performance problems.

Applications

Launching Camera on the locked screen

To quickly take photos, launch

Camera

on the locked screen.

On the locked screen, drag

outside the large circle.

•

This feature may not be available depending on the region or service provider.

•

Some camera features are not available when you launch

Camera

from the locked

screen while the security features are activated.

Launching Camera quickly

Press the Home key twice quickly to launch

Camera

Some camera features are not available when you launch

Camera

from the locked

screen or when the screen is turned off while the security features are activated.

Locking the focus and exposure

Strong light/dark contrast and the subject being outside the auto focus area may make it difficult to achieve an appropriate exposure. Lock the focus or exposure and then take a photo. Tap and hold the area to focus, the AF/AE frame will appear on the area and the focus and exposure setting will be locked. The setting remains locked even after you take a photo.

This feature is only available in some shooting modes.

Customising shooting modes

On the preview screen, tap

MODE

and select a mode.

To view information for each mode, tap

INFO

To rearrange modes, tap

→

Edit

, tap and hold a mode icon, and then drag it to a new

location.

To add mode shortcuts to the Home screen, tap

→

Add shortcut on home screen

Auto mode

Auto mode allows the camera to evaluate the surroundings and determine the ideal mode for the photo.

On the preview screen, tap

MODE

→

Auto

Applications

Pro mode

Take photos while manually adjusting various shooting options, such as exposure value and ISO value.

On the preview screen, tap

MODE

→

Pro

. Select options and customise the settings, and

then tap

to take a photo.

•

: Select an appropriate white balance, so images have a true-to-life colour range.

•

: Select an ISO value. This controls camera light sensitivity. Low values are for stationary or brightly lit objects. Higher values are for fast-moving or poorly lit objects. However, higher ISO settings can result in noise in photos.

•

: Change the exposure value. This determines how much light the camera’s sensor

receives. For low-light situations, use a higher exposure.

Beauty face

Take a photo with lightened skin tone and modified facial features.

On the preview screen, tap

MODE

→

Beauty face

To apply beauty effect, tap

and select options. Refer to Applying beauty effects for more

information.

Panorama

Take a series of photos horizontally or vertically and then stitch them together to create a wide scene.

On the preview screen, tap

MODE

→

Panorama

To get the best shots using panorama mode, follow these tips:

•

Move the camera slowly in one direction.

•

Keep the image within the frame on the camera’s viewfinder. If the preview image is out of the guide frame or you do not move the device, the device will automatically stop taking photos.

•

Avoid taking photos of indistinct backgrounds, such as an empty sky or a plain wall.

Continuous shot

Take a series of photos of moving subjects.

On the preview screen, tap

MODE

→

Continuous shot

. Tap and hold

to take several

photos continuously.

Applications

Food

Take photos of food with more vibrant colours.

On the preview screen, tap

MODE

→

Food

Tap the screen and drag the circular frame over the area to highlight.

The area outside the circular frame will be blurred.

To resize the circular frame, drag a corner of the frame.

Tap and drag the adjustment bar to adjust the colour tone.

Tap to take a photo.

HDR (Rich tone)

Take photos with rich colours and reproduce details even in bright and dark areas.

On the preview screen, tap

MODE

→

HDR (Rich tone)

Without effect With effect

Applications

Night

Take a photo in low-light conditions, without using the flash.

On the preview screen, tap

MODE

→

Night

Selfie

Take self-portraits with the front camera. You can preview various beauty effects on the screen.

On the preview screen, tap to switch to the front camera for self-portraits.

Tap

MODE

→

Selfie

Face the front camera lens.

When the device detects your face, tap the screen to take a photo of yourself.

Alternatively, show your palm to the front camera. After recognising your palm, a countdown timer will appear. When the time is up, the device will take a photo.

Using the selfie flash

When taking self-portraits with the front camera in low-light situations, the touchscreen can serve as a flash.

On the preview screen, tap

repeatedly until you reach On. When you take a photo, the

touchscreen will flash.

Applying beauty effects

You can modify facial features, such as your skin tone or face shape, before taking selfportraits.

This feature is available only in

Selfie

mode.

On the preview screen, tap

Applications

Select the options below to apply beauty effects to your face on the preview screen and take a photo of yourself.

•

Large eyes

: Make your eyes appear bigger.

•

Slim Face

: Adjust the face shape and make your face appear slimmer.

•

Skin tone

: Make your skin appear brighter and clearer.

Wide selfie

Take a wide self-portrait to include more people in the photo and avoid leaving people out.

On the preview screen, tap to switch to the front camera for self-portraits.

Tap

MODE

→

Wide selfie

Face the front camera lens.

When the device detects your face, tap the screen to take a photo of yourself.

Alternatively, show your palm to the front camera. After recognising your palm, a countdown timer will appear. When the time is up, the device will take a photo.

Slowly swivel the device left and then right or vice versa to take a wide self-portrait.

The device will take additional photos when the white frame moves to each end of the viewfinder window.

Applications

•

Make sure to keep the white frame inside the viewfinder window.

•

The subjects should remain still while taking wide self-portraits.

•

The top and bottom parts of the image displayed on the preview screen may be cut out of the photo depending on the shooting conditions.

Downloading modes

Download more shooting modes from

Galaxy Apps

On the preview screen, tap

MODE

→

DOWNLOAD

Some downloaded shooting modes do not have access to every feature.

Camera settings

Quick settings

On the preview screen, use the following quick settings.

The available options may vary depending on the shooting mode and which camera is being used.

•

: Select a filter effect to use when taking photos or recording videos. To set whether

to display certain effects on the list or rearrange the order of effects, tap

Manager

. To

download more effects, tap

Download

•

: Select a metering method. This determines how light values are calculated.

Centre-

weighted

uses the light in the centre portion of the shot to calculate the exposure of

the shot.

Spot

uses the light in a concentrated centre area of the shot to calculate the

exposure of the shot.

Matrix

averages the entire scene.

•

: Select the length of the delay before the camera automatically takes a photo.

•

: Activate or deactivate the flash.

•

: Select a resolution for photos. Using a higher resolution will result in higher quality

photos, but they will take up more memory.

The resolution of a photo may be affected by lighting conditions when taking photos with the front camera.

•

: Adjust the colour tone.

•

: Focus on a subject inside the circular frame and blur the image outside the frame.

Applications

Camera settings

On the preview screen, tap .

The available options may vary depending on the shooting mode and which camera is being used.

•

Video size (rear)

Video size (front)

: Select a resolution for videos. Using a higher

resolution will result in higher quality videos, but they will take up more memory.

•

Save pictures as previewed

: Invert the image to create a mirror-image of the original

scene, when taking photos with the front camera.

•

Grid lines

: Display viewfinder guides to help composition when selecting subjects.

•

Location tags

: Attach a GPS location tag to the photo.

•

GPS signal strength may decrease in locations where the signal is obstructed, such as between buildings or in low-lying areas, or in poor weather conditions.

•

Your location may appear on your photos when you upload them to the Internet. To avoid this, deactivate the location tag setting.

•

Shooting methods (rear)

Shooting methods (front)

: Select shooting options to use.

•

Review pictures

: Set the device to show photos after capturing them.

•

Quick launch

: Set the device to launch the camera by pressing the Home key twice

quickly.

•

Volume keys function

: Set the device to use the Volume key to control the shutter or

zoom function.

•

Reset settings

: Reset the camera settings.

Applications

Gallery

Introduction

View and manage photos and videos stored in the device.

Viewing images

Tap

Gallery

on the Apps screen.

Select an image.

Access additional options.

Move to the previous screen.

Share the image with others.

Delete the image.

Modify the image.

Add the image to favourites.

To hide or show the menus, tap the screen.

Applications

Viewing videos

Tap

Gallery

on the Apps screen.

Select a video to play. Video files show the icon on the preview thumbnail.

Change screen ratio.

Rewind or

fast-forward by

dragging the bar.

Display your videos.

Skip to the previous

video. Tap and hold

to rewind.

Skip to the next video. Tap and hold to fast-forward.

Access additional

options.

Switch to the pop-up video player.

Pause and resume playback.

Adjust the volume.

Drag your finger up or down on the left side of the playback screen to adjust the brightness, or drag your finger up or down on the right side of the playback screen to adjust the volume.

To rewind or fast-forward, swipe to the left or right on the playback screen.

Deleting images or videos

Deleting an image or a video

Select an image or a video and tap

Delete

at the bottom of the screen.

Deleting multiple images and videos

On the main Gallery screen, tap and hold an image or a video to delete.

Tick the images or videos to delete.

Tap

DELETE

Applications

Sharing images or videos

Select an image or a video, tap

at the bottom of the screen, and then select a sharing

method.

Sharing event albums

View photos and videos by time and location. You can share event albums with your contacts.

On the main Gallery screen, tap →

Events

You can view photos and videos sorted by event.

To manually create event albums, tap

and select photos or videos to add.

Select an event album to share.

Tap , select contacts, and then tap

DONE

When your contacts accept the share request, the event album will be shared and more photos and videos can be added to the event album by your contacts.

•

To use this feature, your phone number must be verified.

•

You may incur additional charges when sharing files via the mobile network.

•

If the recipients have not verified their phone numbers or if their devices do not support the feature, a link to the files will be sent to them via text message. Link recipients may not be able to use some features. The link will expire after a certain period.

Applications

Game Launcher

Introduction

Game Launcher gathers your games downloaded from

Play Store

and

Galaxy Apps

or another apps store into one place for easy access. You can set the device to game mode to play games more easily.

Access the Game Launcher settings.

A list of downloaded games

Mute and hide most of

notifications during games. Only

some notifications including

incoming calls will be displayed.

Reduce the battery usage for

playing games.

Turn on or off the Game Tools icon.

View game videos from YouTube.

View a list of the most popular

games for Galaxy users.

Applications

Using Game Launcher

On the Apps screen, tap

Game Launcher

is not on the Apps screen, tap

Settings

→

Advanced features

→

Games

→

Game Launcher

and tap the switch to activate it.

Game Launcher

will be

added to the Home screen and the Apps screen.

When you deactivate the feature,

Game Launcher

will be removed from the Home

screen and the Apps screen.

Tap a game from the games list.

Games downloaded from

Play Store

and

Galaxy Apps

or another apps store will be

automatically shown on the game launcher screen. If you cannot see your games, tap

Tap here to add unlisted games

Removing a game from Game Launcher

Tap and hold a game and drag it to

Remove

at the top of the screen.

Activating game power saving mode

When you activate game power saving mode, the device will lower games’ resolution and frame rate to reduce battery consumption.

On the Apps screen, tap

Game Launcher

→

Save power during game

. Select one of the

following options:

•

Off

: Power saving mode is not used.

•

Save power

: Decrease battery power consumption by lowering the resolution and frame

rate.

•

Save maximum power

: Dramatically decrease the battery power consumption by

lowering the resolution and frame rate.

Battery power efficiency may vary by game.

Applications

Using Game Tools

You can set the Game Tools icon to be displayed as a floating icon on game screens.

On the Apps screen, tap

Settings

→

Advanced features

→

Games

→

Game Tools

and tap

the switch to activate it.

While playing a game, tap

to display the game tools.

To move the icon, tap

and drag it to a new location.

To remove the icon from the current game screen, tap and hold

and drag it to

Remove

the top of the screen.

Capture screenshots.

Record your game session.

Minimise the game screen.

Lock the Recents and Back keys during games.

Access the Game Tools settings.

Mute and hide most of

notifications during games. Only some notifications including incoming calls will be displayed.

Game Tools icon

Blocking notifications during games

Tap → to mute notification sounds and display only notifications for incoming calls and emergency alerts, so that you can enjoy your games without being disturbed. If you receive an incoming call, a small notification will appear at the top of the screen.

Applications

S Planner

Introduction

Manage your schedule by entering upcoming events or tasks in your planner.

Creating events

Tap

S Planner

on the Apps screen.

Tap or double-tap a date.

If the date already has saved events or tasks in it, tap the date and tap

Enter event details.

Select a calendar to use or sync with.

Attach a map showing the location of the event.

Enter the location of the event.

Enter a title.

Set a start and end date for the

event.

Add more details.

Set an alarm.

Tap

SAVE

to save the event.

Applications

Creating tasks

Tap

S Planner

on the Apps screen.

Tap →

Tasks

Enter task details and tap

TODAY

TOMORROW

to set a due date.

To add more details, tap

Tap

SAVE

to save the task.

Syncing events and tasks with your accounts

On the Apps screen, tap

Settings

→

Accounts

, select an account service, and then tap the

Sync Calendar

switch to sync events and tasks with the account.

To add accounts to sync with, open the Apps screen and tap

S Planner

→

Manage calendars

→

Add account

. Then, select an account to sync with and sign in. When an

account is added, it will appear on the list.

S Health

Introduction

S Health helps you manage your wellness and fitness. Set fitness goals, check your progress, and keep track of your overall wellness and fitness.

Starting S Health

When running this app for the first time or restart it after performing a data reset, follow the on-screen instructions to complete the setup.

Tap

Samsung

→

S Health

on the Apps screen.

Follow the on-screen instructions to complete the setup.

Applications

Using S Health

You can view the key information from S Health menus and trackers to monitor your wellness and fitness.

Tap

Samsung

→

S Health

on the Apps screen.

Trackers

Goals and programmes

To add trackers, goals, or programmes to the S Health screen, tap

→

Manage items

and then select items under the

TRACKERS, GOALS

, or

PROGRAMMES

tab.

•

GOALS

: Set your daily fitness goals and view your progress.

•

PROGRAMMES

: Use customisable exercise programmes.

•

TRACKERS

: Monitor your activities, food intake, and body measurements.

To access more information about S Health functions, tap

→

Settings

→

Help

Applications

Additional information

•

S Health is intended for fitness and wellness purposes only and is not intended for use in the diagnosis of disease or other conditions, or in the cure, mitigation, treatment, or prevention of disease.

•

The available functions, features and addable applications for S Health may vary from country to country due to different local laws and regulations. You should check the features and applications available in your specific region before use.

•

S Health applications and its service can be changed or discontinued without prior notice.

•

The purpose for data collection is limited to providing the service that you have requested, including providing additional information to enhance your wellness, sync data, data analysis and statistics or to develop and provide better services. (But if you sign in to your Samsung account from S Health, your data may be saved on the server for data backup purposes.) Personal information may be stored until the completion of such purposes. You can delete personal data stored by S Health by using the Reset data option in the Settings menu. To delete any data you have shared with social networks or transferred to storage devices, you must delete them separately.

•

You may share and/or sync your data with additional Samsung services or compatible third party services that you select, as well as with any of your other connected devices. Access to S Health information by such additional services or third party devices will only be permitted with your express approval.

•

You assume full responsibility for the inappropriate use of data shared on social networks or transmitted to others. Use caution when sharing your personal data with others.

•

If the device is connected to measuring devices, verify the communication protocol to confirm proper operation. If you use a wireless connection, such as Bluetooth, the device may be affected by electronic interference from other devices. Avoid using the device near other devices that transmit radio waves.

•

Please read Terms and Conditions and Privacy Policy of S Health carefully before using it.

Applications

S Voice

Introduction

Perform various tasks simply by speaking.

Setting a wake-up command

You can launch

S Voice

using your own wake-up command.

When launching

S Voice

for the first time, tap

START

and set your own wake-up command.

To change the wake-up command, open the Apps screen and tap

Samsung

→

S Voice

. Then,

tap

→

Voice wake-up

→

Change wake-up command

→

START

, and then follow the on-

screen instructions.

To set the device to launch

S Voice

using the wake-up command while the device is locked,

tap

and tap the

Wake up in secured lock

switch to activate it.

Using S Voice

Say the preset wake-up command.

Alternatively, on the Apps screen, tap

Samsung

→

S Voice

When

S Voice

is launched, the device begins voice recognition.

This app may not be available depending on the region or service provider.

View examples of voice

commands.

S Voice settings

Say a voice command.

If the device recognises the command, the device will perform the corresponding action. To repeat a voice command or say a different command, tap

or say the preset wake-up

command.

This app will close automatically if the device is not used for a specified period.

Applications

Tips for better voice recognition

•

Speak clearly.

•

Speak in quiet places.

•

Do not use offensive or slang words.

•

Avoid speaking in dialectal accents.

The device may not recognise your commands or may perform unwanted commands depending on your surroundings or how you speak.

Setting the language

On the Apps screen, tap

Samsung

→

S Voice

→ →

Language

, and then select a

language.

The selected language is applied to

S Voice

only, not to the language displayed on

the device.

Voice Recorder

Introduction

Use different recording modes for various situations, such as in an interview. The device can convert your voice to text and distinguish between sound sources.

Making voice recordings

On the Apps screen, tap

Samsung

→

Voice Recorder

Applications

Tap to start recording. Speak into the microphone.

Tap

to pause recording.

While making a voice recording, tap

BOOKMARK

to insert a bookmark.

Change the recording mode.

Start recording.

Tap

SAVE

to finish recording.

Changing the recording mode

On the Apps screen, tap

Samsung

→

Voice Recorder

Select a mode from the top of the voice recorder screen.

•

STANDARD

: This is the normal recording mode.

•

INTERVIEW

: The microphone is sensitive to sounds from two directions. In this mode,

both the top and the bottom of the device pick up equal amounts of sound.

•

VOICE MEMO

: The device records your voice and simultaneously converts it to on-screen text. For best results, keep the device near your mouth and speak loudly and clearly in a quiet place.

If the voice memo system language does not match the language you are speaking, the device will not recognise your voice. Before using this feature, tap the current language to set the voice memo system language.

Applications

Playing selected voice recordings

When you review interview recordings, you can mute or unmute certain sound sources in the recording.

On the Apps screen, tap

Samsung

→

Voice Recorder

Tap

Recordings

and select a voice recording made in interview mode.

To mute certain sound sources, tap for the corresponding direction that sound is to be muted.

The icon will change to

and the sound will be muted.

Muted sound source

Unmuted sound source

My Files

Access and manage various files stored in the device.

On the Apps screen, tap

Samsung

→

My Files

View files by category or view files stored in the device.

To check the status of used and available memory, tap

STORAGE USAGE

To search for files or folders, tap

Applications

Memo

Create memos and organise them by category.

On the Apps screen, tap

Memo

Composing memos

Tap on the memos list and enter a memo. While composing a memo, use the following options:

•

Category

: Create or set a category.

•

Tasks

: Add tick boxes at the beginning of each row to create a list of tasks.

•


: Insert images.

•

Drawing

: Write or draw memos to insert. You can select pen thickness and colour.

•

Voice

: Make a voice recording to insert.

To save the memo, tap

SAVE

To edit a memo, tap a memo, and then tap the content of the memo.

Searching for memos

Tap

on the memos list and enter a keyword to search for memos that include the

keyword.

Clock

Introduction

Set alarms, check the current time in many cities around the world, time an event, or set a specific duration.

Alarm

On the Apps screen, tap

Clock

→

Alarm

Applications

Setting alarms

Set an alarm time and tap

SAVE

To open the keypad to enter an alarm time, tap the time input field.

To set an alarm with various alarm options, tap

OPTIONS

, set alarm options, and then tap

SAVE

To activate or deactivate alarms, tap the clock icon next to the alarm in the alarms list.

Stopping alarms

Tap

DISMISS

to stop an alarm. If you have previously enabled the snooze option, tap

SNOOZE

to repeat the alarm after a specified length of time.

Deleting alarms

Tap on an alarm in the list of alarms.

World clock

On the Apps screen, tap

Clock

→

World clock

Creating clocks

Enter a city name or select a city from the globe, and then tap .

Deleting clocks

Tap on a clock.

Stopwatch

On the Apps screen, tap

Clock

→

Stopwatch

Tap

START

to time an event.

To record lap times while timing an event, tap

LAP

Tap

STOP

to stop timing.

To restart the timing, tap

RESUME

To clear lap times, tap

RESET

Applications

Timer

On the Apps screen, tap

Clock

→

Timer

Set the duration, and then tap

START

To open the keypad to enter the duration, tap the duration input field.

Tap

DISMISS

when the timer goes off.

Calculator

Perform simple or complex calculations.

Tap

Calculator

on the Apps screen.

Rotate the device to landscape orientation to display the scientific calculator. If

Auto rotate

disabled, tap

to display the scientific calculator.

To see the calculation history, tap

HISTORY

. To close the calculation history panel, tap

KEYPAD

To clear the history, tap

HISTORY

→

CLEAR HISTORY

Applications

Radio

Listening to the FM radio

Tap

Radio

on the Apps screen.

Before you use this app, you must connect a headset, which serves as the radio antenna.

The FM radio scans and saves available stations automatically when running for the first time.

Tap

to turn on the FM radio. Select the radio station you want from the stations list.

View the list of favourites

stations.

Scan and save available stations

automatically.

Enter radio station frequency

manually.

Fine-tune the frequency.

Record a song from the FM radio.

View the list of available stations.

Access additional options.

Add the current radio station to the favourites list.

Search for an available radio

station.

Turn the FM radio on or off.

Scanning radio stations

Tap

Radio

on the Apps screen.

Tap

SCAN

, and then select a scan option. The FM radio scans and saves available stations

automatically.

Select the radio station you want from the stations list.

Applications

Google apps

Google provides entertainment, social network, and business apps. You may require a Google account to access some apps. Refer to Accounts for more information.

To view more app information, access each app’s help menu.

Some apps may not be available or may be labelled differently depending on the region or service provider.

Chrome

Search for information and browse webpages.

Gmail

Send or receive emails via the Google Mail service.

Maps

Find your location on the map, search for locations, and view location information for various places.

Play Music

Discover, listen to, and share music on your device. You can upload music collections stored on your device to the cloud and access them later.

Play Movies & TV

Download videos to watch from

Play Store

Drive

Store your content on the cloud, access it from anywhere, and share it with others.

YouTube

Watch or create videos and share them with others.

Applications

Photos

Search for, manage, and edit all your photos and videos from various sources in one place.

Hangouts

Chat with your friends individually or in groups and use images, emoticons, and video calls while you are chatting.

Google

Search quickly for items on the Internet or your device.

Settings

Introduction

Customise settings for functions and apps. You can make your device more personalised by configuring various setting options.

On the Apps screen, tap

Settings

To search for settings by entering keywords, tap

To edit the list of frequently used settings, tap

EDIT

. Then, tick items to add or deselect items

to remove.

Wi-Fi

Connecting to a Wi-Fi network

Activate the Wi-Fi feature to connect to a Wi-Fi network and access the Internet or other network devices.

Turn off Wi-Fi to save the battery when not in use.

On the Settings screen, tap

Wi-Fi

, and then tap the switch to activate it.

Select a network from the Wi-Fi networks list.

Networks that require a password appear with a lock icon.

Tap

CONNECT

•

Once the device connects to a Wi-Fi network, the device will reconnect to that network each time it is available without requiring a password. To prevent the device connecting to the network automatically, select it from the list of networks and tap

FORGET

•

If you cannot connect to a Wi-Fi network properly, restart your device’s Wi-Fi feature or the wireless router.

Settings

Wi-Fi Direct

Wi-Fi Direct connects devices directly via a Wi-Fi network without requiring an access point.

On the Settings screen, tap

Wi-Fi

, and then tap the switch to activate it.

Tap

Wi-Fi Direct

The detected devices are listed.

If the device you want to connect to is not in the list, request that the device turns on its Wi-Fi Direct feature.

Select a device to connect to.

The devices will be connected when the other device accepts the Wi-Fi Direct connection request.

Sending and receiving data

You can share data, such as contacts or media files, with other devices. The following actions are an example of sending an image to another device.

Tap

Gallery

on the Apps screen.

Select an image.

Tap

→

Wi-Fi Direct

and select a device to transfer the image to.

Accept the Wi-Fi Direct connection request on the other device.

If the devices are already connected, the image will be sent to the other device without the connection request procedure.

Ending the device connection

Tap

Wi-Fi

on the Settings screen.

Tap

Wi-Fi Direct

The device displays the connected devices in the list.

Tap the device name to disconnect the devices.

Settings

Bluetooth

Introduction

Use Bluetooth to exchange data or media files with other Bluetooth-enabled devices.

•

Samsung is not responsible for the loss, interception, or misuse of data sent or received via Bluetooth.

•

Always ensure that you share and receive data with devices that are trusted and properly secured. If there are obstacles between the devices, the operating distance may be reduced.

•

Some devices, especially those that are not tested or approved by the Bluetooth SIG, may be incompatible with your device.

•

Do not use the Bluetooth feature for illegal purposes (for example, pirating copies of files or illegally tapping communications for commercial purposes).

Samsung is not responsible for the repercussion of illegal use of the Bluetooth feature.

Pairing with other Bluetooth devices

On the Settings screen, tap

Bluetooth

, and then tap the switch to activate it.

The detected devices are listed.

Select a device to pair with.

If the device you want to pair with is not in the list, request that the device turns on its visibility option. Refer to the other device’s user manuals.

Your device is visible to other devices while the Bluetooth settings screen is open.

Accept the Bluetooth connection request on your device to confirm.

The devices will be connected when the other device accepts the Bluetooth connection request.

Settings

Sending and receiving data

Many apps support data transfer via Bluetooth. You can share data, such as contacts or media files, with other Bluetooth devices. The following actions are an example of sending an image to another device.

Tap

Gallery

on the Apps screen.

Select an image.

Tap

→

Bluetooth

, and then select a device to transfer the image to.

If your device has paired with the device before, tap the device name without confirming the auto-generated passkey.

If the device you want to pair with is not in the list, request that the device turns on its visibility option.

Accept the Bluetooth connection request on the other device.

Unpairing Bluetooth devices

Tap

Bluetooth

on the Settings screen.

The device displays the paired devices in the list.

Tap next to the device name to unpair.

Tap

Unpair

Flight mode

This disables all wireless functions on your device. You can use only non-network services.

On the Settings screen, tap

Flight mode

Make sure the device is turned off during takeoff and landing. After takeoff, you can use the device in flight mode if allowed by aircraft personnel.

Settings

Mobile hotspot and tethering

Use the device as a mobile hotspot to share the device’s mobile data connection with other devices when the network connection is not available. Connections can be made via Wi-Fi, USB, or Bluetooth.

On the Settings screen, tap

Mobile hotspot and tethering

You may incur additional charges when using this feature.

•

Mobile hotspot

: Use the mobile hotspot to share the device’s mobile data connection

with computers or other devices.

•

Bluetooth tethering

: Use Bluetooth tethering to share the device’s mobile data

connection with computers or other devices via Bluetooth.

•

USB tethering

: Use USB tethering to share the device’s mobile data connection with a computer via USB. When connected to a computer, the device is used as a wireless modem for the computer.

Using the mobile hotspot

Use your device as a mobile hotspot to share your device’s mobile data connection with other devices.

On the Settings screen, tap

Mobile hotspot and tethering

→

Mobile hotspot

Tap the switch to activate it.

The

icon appears on the status bar. Other devices can find your device in the Wi-Fi

networks list.

To set a password for the mobile hotspot, tap

→

Configure Mobile hotspot

and

select the level of security. Then, enter a password and tap

SAVE

On the other device’s screen, search for and select your device from the Wi-Fi networks list.

On the connected device, use the device’s mobile data connection to access the Internet.

Settings

Data usage

Keep track of your data usage amount and customise the settings for the limitation.

On the Settings screen, tap

Data usage

•

Mobile data

: Set the device to use data connections on any mobile network.

•

Background data

: Prevent apps that are running in the background from using a mobile

data connection.

•

Set mobile data limit

: Set a limit for mobile data usage.

To change the monthly reset date for the monitoring period, tap

→

Change cycle

Limiting data usage

Set the device to automatically disable the mobile data connection when the amount of mobile data you have used reaches your specified limit.

On the Settings screen, tap

Data usage

and tap the

Set mobile data limit

switch to

activate it.

Drag the limit adjustment bar upwards or downwards to set the limit.

Drag the warning adjustment bar upwards or downwards to set a data usage alert level.

The device will alert you when the warning level is reached.

SIM card manager

Activate your SIM or USIM cards and customise the SIM card settings. Refer to Using dual SIM

or USIM cards for more information.

On the Settings screen, tap

SIM card manager

•

Voice call

: Select a SIM or USIM card for voice calls.

•

Text messages

: Select a SIM or USIM card for messaging.

•

Mobile data

: Select a SIM or USIM card for data service.

•

Dual SIM always on

: Set the device to allow incoming calls from the other SIM or USIM

card during a call.

When this feature is enabled, you may incur additional charges for call forwarding depending on the region or service provider.

Settings

Mobile networks

Configure your mobile network settings.

On the Settings screen, tap

Mobile networks

•

Data roaming

: Set the device to use data connections when you are roaming.

•

Network mode SIM 卡 1

Network mode SIM 卡 2

: Select a network type.

•

Access Point Names

: Set up access point names (APNs).

•

Network operators

: Search for available networks and manually register a network.

NFC and payment

Introduction

Your device allows you to read near field communication (NFC) tags that contain information about products. You can also use this feature to make payments and buy tickets for transportation or events after downloading the required apps.

The device contains a built-in NFC antenna. Handle the device carefully to avoid damaging the NFC antenna.

Using the NFC feature

Use the NFC feature to send images or contacts to other devices, and read product information from NFC tags.

On the Settings screen, tap

NFC and payment

, and then tap the switch to activate it.

Settings

Place the NFC antenna area on the back of your device near an NFC tag.

The information from the tag appears.

Ensure that the device’s screen is unlocked. Otherwise, the device will not read NFC tags or receive data.

Making payments with the NFC feature

Before you can use the NFC feature to make payments, you must register for the mobile payment service. To register or get more information about the service, contact your service provider.

On the Settings screen, tap

NFC and payment

, and then tap the switch to activate it.

Touch the NFC antenna area on the back of your device to the NFC card reader.

To set the default payment app, open the Settings screen and tap

NFC and payment

→

Tap

and pay

→

PAYMENT

, and then select an app.

The payment services list may not include all available payment apps.

Sending data

Allow data exchange when your device’s NFC antenna touches the other device’s NFC antenna.

On the Settings screen, tap

NFC and payment

, and then tap the switch to activate it.

Tap

Android Beam

and tap the switch to activate it.

Settings

Select an item and touch the other device’s NFC antenna to your device’s NFC antenna.

When

Touch to beam.

appears on the screen, tap your device’s screen to send the item.

If both devices try to send data simultaneously, the file transfer may fail.

More connection settings

Options

Customise settings to control other features.

On the Settings screen, tap

More connection settings

•

Nearby device scanning

: Set the device to scan for nearby devices to connect to.

•

Printing

: Configure settings for printer plug-ins installed on the device. You can search for available printers or add one manually to print files. Refer to Printing for more information.

•

MirrorLink

: Use the MirrorLink feature to control your device’s MirrorLink apps on the

vehicle’s head unit monitor. Refer to MirrorLink for more information.

•

VPN

: Set up and connect to virtual private networks (VPNs).

Printing

Configure settings for printer plug-ins installed on the device. You can connect the device to a printer via Wi-Fi or Wi-Fi Direct, and print images or documents.

Some printers may not be compatible with the device.

Settings

Adding printer plug-ins

Add printer plug-ins for printers you want to connect the device to.

On the Settings screen, tap

More connection settings

→

Printing

→

Download plug-in

Search for a printer plug-in in

Play Store

Select a printer plug-in and install it.

Select the printer plug-in and tap the switch to activate it.

The device searches for printers that are connected to the same Wi-Fi network as your device.

To add printers manually, tap

→

Add printer

→

ADD PRINTER

To change print settings, tap

→

Printing settings

Printing content

While viewing content, such as images or documents, tap

→

→ →

All

printers

, and then select a printer.

MirrorLink

Connect your device to a vehicle to control your device’s MirrorLink apps on the vehicle’s head unit monitor.

On the Settings screen, tap

More connection settings

→

MirrorLink

Your device is compatible with vehicles that support MirrorLink version 1.1 or higher.

Connecting your device to a vehicle via MirrorLink

When using this feature for the first time, connect the device to a Wi-Fi or mobile network.

Pair your device with a vehicle via Bluetooth.

Refer to Pairing with other Bluetooth devices for more information.

Connect your device to the vehicle using a USB cable.

When they are connected, access your device’s MirrorLink apps on the head unit monitor.

Settings

Ending the MirrorLink connection

Unplug the USB cable from your device and the vehicle.

Smart Manager

Introduction

The Smart manager provides an overview of the status of your device’s battery, storage, RAM, and system security. You can also automatically optimise the device with a tap of your finger.

Using the quick optimisation feature

On the Settings screen, tap

Smart Manager

→

CLEAN ALL

The quick optimisation feature improves device performance through the following actions.

•

Clearing some memory.

•

Deleting unnecessary files and closing apps running in the background.

•

Scanning for malware.

Settings

Battery

On the Settings screen, tap

Smart Manager

→

Battery

Check the remaining battery power and time to use the device. For devices with low battery levels, conserve battery power by activating power saving features.

•

The usage time left shows the time remaining before the battery power runs out. Usage time left may vary depending on your device settings and operating conditions.

•

You cannot receive notifications from apps that use power saving mode.

Managing the battery

To save battery power by setting whether to optimise the battery usage for each app, tap

DETAILS

for the app power saving and tap the

App power saving

switch to activate it.

You can set the device to charge the battery more quickly. Tap the

Fast cable charging

switch

to activate it.

Storage

Check the status of the used and available memory.

On the Settings screen, tap

Smart Manager

→

Storage

Managing the memory

To delete residual files, such as cache, tap

DELETE

. To delete files or uninstall apps that you

do not use any more, tap

DETAILS

for the user data and select a category. Then, tick items to

select and tap

DELETE

RAM

On the Settings screen, tap

Smart Manager

→

RAM

To speed up your device by reducing the amount of RAM you are using, tap

END ALL

to close

all background apps.

Device security

Check the device’s security status. This feature scans your device for malware.

On the Settings screen, tap

Smart Manager

→

Device security

Settings

Applications

Manage the device’s apps and change their settings.

On the Settings screen, tap

Applications

•

Application manager

: View and manage the apps on your device.

•

Default applications

: Select a default setting for using apps.

•

Application settings

: Customise the settings for each app.

Sounds and vibrations

Change settings for various sounds on the device.

On the Settings screen, tap

Sounds and vibrations

•

Sound mode

: Set the device to use sound mode or silent mode.

•

Vibrate while ringing

: Set the device to vibrate and play a ringtone for incoming calls.

•

Volume

: Adjust the volume level for call ringtones, music and videos, system sounds, and

notifications.

•

Ringtone

: Change the ringtone settings.

•

Vibration pattern

: Select a vibration pattern.

•

Notification sounds

: Select a default notification sound. You can also change the

notification settings for each app.

•

Touch sounds

: Set the device to sound when you select an app or option on the

touchscreen.

•

Screen lock sounds

: Set the device to sound when you lock or unlock the touchscreen.

•

Charging sounds

: Set the device to sound when it is connected to a charger.

•

Dialling keypad tones

: Set the device to sound when you tap the buttons on the keypad.

•

Keyboard sound

: Set the device to sound when a key is touched.

•

Sound quality and effects

: Configure additional sound settings.

Settings

Notifications

Change the notification settings for each app.

On the Settings screen, tap

Notifications

To customise notification settings, tap

ADVANCED

and select an app.

•

Allow notifications

: Allow notifications from the selected app.

•

Set as priority

: Display notifications at the top of the notification panel and include them

in the allowed list when

Do not disturb

is activated.

•

Previews in pop-ups

: Display notification previews in pop-up windows.

•

Hide on lock screen

: Hide notifications from the selected app when the device is locked.

•

Hide content on lock screen

: Hide the content of notifications from the selected app

when the device is locked.

•

More settings

: Customise additional notification settings for the selected app.

Do not disturb

Set the device to mute incoming calls and notification sounds, except for allowed exceptions.

On the Settings screen, tap

Do not disturb

•

Enable now

: Activate Do not disturb mode immediately.

•

Enable as scheduled

: Activate Do not disturb mode at preset times. You can select days

and set the start and end times.

•

Allow exceptions

: Customise the settings for allowed exceptions.

Display

Change the display settings.

On the Settings screen, tap

Display

•

Brightness

: Adjust the brightness of the display.

•

Font

: Change the font size and type.

•

Display scaling

: Set whether to condense the display to view more content on the

screen. In condensed display mode, items on the screen will be smaller.

Condensed display mode will only be applied to some apps.

Settings

100

•

Icon backgrounds

: Set whether to display shaded backgrounds to make icons stand out.

•

Screen timeout

: Set the length of time the device waits before turning off the display’s

backlight.

•

Screen mode

: Change the screen mode to adjust the display’s colour and contrast.

•

LED indicator

: Set the device to turn on the LED indicator while the battery is charging,

when you have notifications, or when you make voice recordings.

•

Screensaver

: Set the device to launch a screensaver when the device is charging or

connected to a dock.

Advanced features

Activate advanced features and change the settings that control them.

On the Settings screen, tap

Advanced features

Excessive shaking or impact to the device may cause unintended input for some features.

•

Games

: Activate the Game Launcher and Game Tools icon and manage useful features

while you play games. Refer to Game Launcher for more information.

•

One-handed operation

: Activate one-handed operation mode for your convenience

when using the device with one hand.

This feature may not be available depending on the region or service provider.

•

Quick launch Camera

: Set the device to launch the camera by pressing the Home key

twice quickly.

•

Pop-up view gesture

: Set the device to view the app screen in the pop-up view. Refer to

Pop-up view for more information.

•

Smart capture

: Set the device to capture content that continues across multiple screens, and crop and share the screenshot immediately. Refer to Smart capture for more information.

•

Palm swipe to capture

: Set the device to capture a screenshot when you swipe your

hand to the left or right across the screen. You can view the captured images in

Gallery

It is not possible to capture a screenshot while using some apps and features.

Samsung SM-G5700, SM-A910F/DS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
