Clearing paper jams

In the duplex unit area

Click this link to open an animation about clearing a jam.

4. Troubleshooting

If you do not see the paper in this area, stop and go to next step:

4. Troubleshooting

Understanding the status LED

The color of the LED indicates the machine's current status.

• Some LEDs may not be available depending on model or country (see "Control panel overview" on page 23).

• To resolve the error, look at the error message and its instructions from the troubleshooting part (see "Understanding display messages" on page 101).

• You also can resolve the error with the guideline from the computers’s Samsung Printing Status program window (see "Using Samsung Printer Status" on page

240).

• If the problem persists, call a service representative.

4. Troubleshooting

Understanding the status LED

LED Status Description

Off The machine is off-line.

Blinking When the backlight blinks, the machine is receiving or printing data.

Green

On • The machine is on-line and can be used.

• A minor error has occurred and the machine is waiting for the error to be cleared. For models that supports display screen on the control panel, check the display message. When the problem is cleared, the machine resumes.

() Status

Red

() WPS

Blue

Blinking

Blinking The machine is connecting to a wireless network.

Off The machine is disconnected from a wireless network.

• Small amount of toner is left in the cartridge. The estimated cartridge life replacement. You may temporarily increase the printing quality by redistributing the toner (see "Redistributing toner" on

page 62).

• A toner cartridge has almost reached its estimated cartridge life "Replacing the toner cartridge" on page 64).

• The cover is opened. Close the cover.

• There is no paper in the tray when receiving or printing data. Load paper in the tray.

• The machine has stopped due to a major error. Check the display message (see "Understanding display messages" on page

101).

• A paper jam has occurred (see "Clearing paper jams" on page 85).

• An imaging unit has almost reached it’s estimated cartridge life

The machine is connected to a wireless networkG(see "Wireless network setup" on page 154).

of toner is close. Prepare a new cartridge for

. It is recommended to replace the toner cartridge (see

. It is recommended to replace the toner cartridge.

() Power

Blue

On The machine is in power save mode.

Off The machine is in ready mode or machine’s power is off.

4. Troubleshooting

LED Status Description

On Eco mode is on (see "Eco printing" on page 51).

Eco Green

a. Estimated cartridge life means the expected or estimated toner cartridge life, which indicates the average capacity of print-outs and is designed pursuant to ISO/IEC 19798. The number of pages

may be affected by operating environment, percentage of image area, printing interval, graphics, media and media size. Some amount of toner may remain in the cartridge even when red LED

is on and the printer stops printing. b. Some LEDs may not be available depending on model or country (see "Control panel overview" on page 23). c. When the imaging unit has reached its end of life, the machine will stop printing. In this case, you can choose to stop or continue printing from the SyncThru™Web Service (Settings > Machine

Settings > System > Setup > Supplies Management> Imaging Unit Stop) or Samsung Easy Printer Manager (Device Settings > System > Supplies Management > Imaging Unit Stop).

Turning off this option and continuing to print may damage the device’s system.

4. Troubleshooting

100

Understanding display messages

Messages appear on the control panel display to indicate the machine’s status or errors. Refer to the tables below to understand the messages’ and their meaning, and correct the problem, if necessary.

• You can resolve the error with the guideline from the computers’s

Printing Status program window (see "Using Samsung Printer Status" on

page 240).

• If a message is not in the table, reboot the power and try the printing job again. If the problem persists, call a service representative.

• When you call for service, provide the service representative with the contents of display message.

• Some messages may not appear on the display depending on the options or models.

• [error number] indicates the error number.

• [tray type] indicates the tray number.

• [media type] indicates the media type.

• [media size] indicates the media size.

• [color] indicates the color of toner.

Paper Jam-related messages

Message Meaning Suggested solutions

Paper jam

in exit area

Paper jam

inside of duplex

Paper jam

inside machine

Paper jam in tray1 Paper has jammed in the

Paper jam in tray 2 Paper has jammed in the

Paper jam in MP tray Paper has jammed in the

Paper has jammed in the exit area.

Paper has jammed during duplex printing. This is applicable only to machines with this feature.

Paper has jammed in inside the machine.

tray.

optional tray.

multi-purpose tray.

Clear the jam (see "In exit area" on page 94).

Clear the jam (see "In the duplex unit area" on page 96).

Clear the jam (see "Inside the machine" on page 90).

Clear the jam (see "In tray 1" on page 85).

Clear the jam (see "In optional tray" on page

86).

Clear the jam (see "In the manual feeder/ multi-purpose tray" on page 88).

4. Troubleshooting

101

Understanding display messages

Toner-related messages

Message Meaning Suggested solutions

Install toner A toner cartridge is not

installed.

A toner cartridge is not being detected

Not removed protective film from toner.

Not Compatible

Toner cartridge

Prepare new cartridge

The indicated toner cartridge is not suitable for your machine. Small amount of toner is left in the indicated cartridge. The estimated cartridge

of toner is close.

life

Reinstall the toner cartridge.

Reinstall the toner cartridge two or three times to confirm it is seated properly. If the problem persists, contact the service representatives. Remove the protective film from the toner cartridge.

Install the corresponding toner cartridge with a Samsung-genuine cartridge (see "Replacing the toner cartridge" on page 64). Prepare a new cartridge for a replacement. You may temporarily increase the printing quality by redistributing the toner (see "Redistributing toner" on page 62).

Message Meaning Suggested solutions

Replace

new cartridge

a. Estimated cartridge life means the expected or estimated toner cartridge life, which indicates

the average capacity of print-outs and is designed pursuant to ISO/IEC 19798 (see "Available consumables" on page 56). The number of pages may be affected by operating environment, percentage of image area, printing interval, media, percentage of image area, and media size. Some amount of toner may remain in the cartridge even when replace new cartridge appears and the machine stops printing.

A toner cartridge has reached its estimated

cartridge life

• You can choose Stop or Continue as shown on the control panel. If you select Stop, the printer stops printing. If you select Continue, the printer keeps printing but the printing quality cannot be guaranteed.

• Replace the toner cartridge for the best print quality when this message appears. Using a cartridge beyond this stage can result in printing quality issues (see "Replacing the toner cartridge" on page 64).

4. Troubleshooting

102

Understanding display messages

Samsung does not recommend using a non-genuine Samsung toner cartridge such as refilled or remanufactured. Samsung cannot guarantee a non-genuine Samsung toner cartridge's quality. Service or repair required as a result of using non-genuine Samsung toner cartridges will not be covered under the machine warranty.

4. Troubleshooting

103

Understanding display messages

Imaging unit-related messages

Message Meaning Suggested solutions

Not Installed

Imaging unit

Not compatible

Imaging unit

Prepare new Image unit

An imaging unit is not installed.

An imaging unit is not being detected

Not remove protective film from toner. The imaging unit is not suitable for your machine.

Small amount of toner is left in the imaging unit. The estimated cartridge life of toner is close.

Reinstall the imaging unit.

Reinstall the imaging unit two or three times to confirm it is seated properly. If the problem persists, contact the service representatives. Remove the protective film from the imaging unit. Install the corresponding cartridge with a Samsung-genuine cartridge (see "Replacing the imaging unit" on page 68). Prepare a new imaging unit for a replacement.

Message Meaning Suggested solutions

Replace new

Image unit

Samsung does not recommend using a non-genuine Samsung cartridge such as refilled or remanufactured. Samsung cannot guarantee a nongenuine Samsung cartridge's quality. Service or repair required as a result of using non-genuine Samsung cartridges will not be covered under the machine warranty.

An imaging unit has reached its estimated cartridge life.

• Replace the imaging unit for the best print quality when this message appears. Using a cartridge beyond this stage can result in printing quality issues (see "Replacing the imaging unit" on page 68).

• If the machine stops printing, replace the imaging unit (see "Replacing the imaging unit" on page 68).

4. Troubleshooting

104

Understanding display messages

Tray-related messages

Message Meaning Suggested solutions

Paper Empty

in [tray number]

There is no paper in the indicated tray.

Network-related messages

Message Meaning Suggested solutions

Network Problem:

IP Conflict

802.1x

Network Error

The IP address is used elsewhere.

Fail to authenticate. Check the network

Load paper in the tray (see "Loading paper in the tray" on page 37).

Check the IP address or obtain a new IP address.

authentication protocol. If the problem persists, contact your network administrator.

Misc. messages

Message Meaning Suggested solutions

Door Open

Close it

Error [error

number]

Install [color] toner

Error [error

number]

Turn off then on

Error [error

number]

Call for service

Install TR.

belt unit.

The cover is not securely latched.

The indicated toner cartridge is installed improperly, or the connector is polluted.

The machine unit cannot be controlled.

The transfer belt is not installed.

Close the cover until it locks into place.

Reinstall the Samsunggenuine toner cartridge two or three times to confirm it is seated properly. If the problem persists, please call for service.

Reboot the power and try the printing job again. If the problem persists, please call for service.

Install a Samsung-genuine transfer belt.

Not compatible

transfer belt

The transfer belt of the machine is not for your machine.

Install the a Samsunggenuine part designed for your machine.

4. Troubleshooting

105

Understanding display messages

Message Meaning Suggested solutions

Not installed

Waste tank

Not proper room

temp. Move set

Output bin Full

Remove paper

Prepare new

Transfer belt

Replace new

Transfer belt

The is waste toner container not installed.

The machine is in a room with improper room temperature.

The output tray is full. Remove papers from the

The life of the transfer belt will expired soon.

The life of the transfer belt has expired.

Install a Samsung-genuine waste toner container.

Move the machine to a room with proper roomG

temperature.

output tray, the machine resumes printing. If the problem persists, call for service.

Replace the transfer belt with a new one. If the problem persists, please call for service.

Message Meaning Suggested solutions

Transfer Belt

Error

Waste toner Full

Replace new one

The transfer belt cannot be controlled.

The waste toner container is full.

Reboot the power and try the printing job again. If the problem persists, please call for service.

Replace the waste toner container.

Replace

Fuser Soon

Replace new

Fuser unit

• Replace new Tray1 roller

• Replace new Tray2 roller

The life of the fuser unit will be expired soon.

The life of the fuser unit will be expired.

The life of the tray pick-up roller will expired soon.

The life of the tray pick-up roller will expired.

Replace the fuser unit with a new one. If the problem persists, please call for service.

Replace the tray pick-up roller with a new one. If the problem persists, please call for service.

4. Troubleshooting

106

5. Appendix

This chapter provides product specifications and information concerning applicable regulations.

• Specifications 108

• Regulatory information 116

• Copyright 127

Specifications

General specifications

The specification values listed below are subject to change without notice. See www.samsung.com for possible changes in information.

Items Description

Dimension Width x Length x Height 366 x 365.6 x 262.5 mm (14.4 x 14.39 x 10.33 inches)

Weight Machine with consumables • M332xND/M382xD series: 9.92 kg (21.9 lbs)

• M382xND/M382xDW/M402xND series: 10.21 kg (22.5 lbs)

Noise Level

Ready mode Less than 26 dB (A)

Print mode • M332x series: Less than 54 dB (A)

• M382x/M402x series: Less than 56 dB (A)

Temperature Operation 10 to 30 °C (50 to 86 °F)

Storage (packed) -20 to 40 °C (-4 to 104 °F)

Humidity Operation 20 to 80% RH

Storage (packed) 10 to 90% RH

Power rating

110 volt models AC 110 - 127 V

220 volt models AC 220 - 240 V

5. Appendix

108

Specifications

Items Description

Power consumption Average operating mode Less than 600 W

Ready mode Less than 60 W

Power save mode

Power off mode

Wireless

a. Sound Pressure Level, ISO 7779. Configuration tested: basic machine installation, A4 paper, simplex printing. b. See the rating label on the machine for the correct voltage (V), frequency (hertz) and of current (A) for your machine. c. The power consumption of power save mode may be affected by machine's status, setting conditions, operating environment. d. Power consumption can be completely avoided only when the power cable is not connected. e. Wireless models only (see "Features by models" on page 8).

Module SPW-B4319U

Less than 0.3 W (Wi-Fi Direct on: Less than 0.9 W)

Less than 0.1 W

5. Appendix

109

Specifications

Print media specifications

Type Size Dimensions

Plain paper Letter 216 x 279 mm (8.5 x 11 inches)

Legal 216 x 356 mm (8.5 x 14 inches)

US Folio 216 x 330 mm (8.5 x 13 inches)

A4 210 x 297 mm (8.26 x 11.69 inches) Oficio 216 x 343 mm (8.5 x 13.5 inches) JIS B5 182 x 257 mm (7.16 x 10.11 inches)

ISO B5 176 x 250 mm (6.93 x 9.84 inches)

Executive 184 x 267 mm (7.25 x 10.5 inches)

A5 148 x 210 mm (5.82 x 8.26 inches)

A6 105 x 148 mm (4.13 x 5.82 inches)

Envelope Envelope Monarch 98 x 191 mm (3.87 x 7.5 inches) Not available in tray1/

Envelope No. 10 105 x 241 mm (4.12 x 9.5 inches)

Envelope DL 110 x 220 mm (4.33 x 8.66 inches) Envelope C5 162 x 229 mm (6.37 x 9.01 inches) Envelope C6 114 x 162 mm (4.48 x 6.38 inches)

Thick paper Refer to the Plain

Refer to the Plain paper section

paper section

Thicker paper Refer to the Plain

Refer to the Plain paper section Not available in tray1/

paper section

Thin paper Refer to the Plain

Refer to the Plain paper section

paper section

Tray1 / Optional tray Multi-purpose tray

70 to 85 g/m bond)

• 250 sheets of 80 g/m (20 lbs bond)

• 150 sheets of 75 g/m (20 lbs bond)

optional tray.

86 to 105 g/m bond)

optional tray.

60 to 70 g/m bond)

(19 to 24 lbs

(23 to 28 lbs

(16 to 19 lbs

Print media weight/Capacity

70 to 85 g/m

(19 to 24 lbs

bond)

• 50 sheets of 80 g/m lbs bond)

75 to 90 g/m

(20 to 24 lbs

bond)

86 to 105 g/m2 (23 to 28 lbs bond)

164 to 220 g/m

(44 to 58

lbs bond)

60 to 70 g/m2 (16 to 19 lbs bond)

Manual feederb

70 to 85 g/m

(19 to 24 lbs

bond)

(20

• 1 sheet of 80 g/m bond)

75 to 90 g/m2 (20 to 24 lbs bond)

86 to 105 g/m2 (23 to 28 lbs bond)

164 to 220 g/m2 (44 to 58 lbs bond)

60 to 70 g/m2 (16 to 19 lbs bond)

(20 lbs

5. Appendix

110

Specifications

Type Size Dimensions

Tray1 / Optional tray Multi-purpose tray

Transparency Letter, A4 Refer to the Plain paper section Not available in tray1/

optional tray.

Labels

Letter, Legal, US Folio,

A4, JIS B5, ISO B5,

Refer to the Plain paper section Not available in tray1/

optional tray.

Executive, A5

Card stock Letter, Legal, US Folio,

A4, JIS B5, ISO B5,

Refer to the Plain paper section

121 to 163 g/m lbs bond)

(32 to 43

Executive, A5

Bond paper Refer to the Plain

paper section

Minimum size (custom)

e, f

Refer to the Plain paper section

• Multi-purpose(or manual

106 to 120 g/m lbs bond)

60 to 163 g/m

(28 to 32

(16 to 43 lbs bond)

feeder) tray(: 76 x 127 mm (2.99 x 5 inches)

Not available in optional tray.

• Tray 1: 105 x 148.5 mm (4.13 x

5.85 inches)

Maximum size (custom) 216 x 356 mm (8.5 x 14 inches)

Print media weight/Capacity

138 to 146 g/m

(36.81 to

38.91 lbs bond)

120 to 150 g/m

(32 to 40

lbs bond)

121 to 163 g/m2 (32 to 43 lbs bond)

106 to 120 g/m2 (28 to 32 lbs bond)

Manual feederb

138 to 146 g/m2 (36.81 to

38.91 lbs bond)

120 to 150 g/m2 (32 to 40 lbs bond)

121 to 163 g/m2 (32 to 43 lbs bond)

106 to 120 g/m2 (28 to 32 lbs bond)

a. Maximum capacity may differ depending on media weight, thickness, and environmental conditions. b. M332xND/M382xD series only. c. 1 sheet for manual feeder. d. The smoothness of the labels used in this machine is 100 to 250 (sheffield). This means the numeric level of smoothness. e. The paper types available in multi-purpose tray: Plan, Thick, Thicker, Thin, Cotton, Colored, Pre-printed, Recycled, Envelope, Transparency, Labels, Cardstock, Bond, Archive f. The paper types available in tray 1: Plan, Thick, Thin, Recycled, Cardstock, Bond, Archive

5. Appendix

111

Specifications

System requirements

Microsoft® Windows

Requirement (recommended)

Operating system

CPU RAM free HDD space

Windows® XP Intel® Pentium® III 933 MHz (Pentium IV 1 GHz)

Windows Server® 2003 Intel® Pentium® III 933 MHz (Pentium IV 1 GHz)

Windows Server® 2008 Intel® Pentium® IV 1 GHz (Pentium IV 2 GHz)

Windows Vista

Intel® Pentium® IV 3 GHz

Windows® 7 Intel® Pentium® IV 1 GHz 32-bit or 64-bit processor or higher

• Support for DirectX

9 graphics with 128 MB memory (to enable the Aero theme).

•DVD-R/W Drive

Windows Server® 2008 R2 Intel® Pentium® IV 1 GHz (x86) or 1.4 GHz (x64) processors (2 GHz or faster)

Windows® 8 Intel® Pentium® IV 1 GHz 32-bit or 64-bit processor or higher

128 MB (256 MB) 1.5 GB

128 MB (512 MB) 1.25 GB to 2 GB

512 MB (2 GB) 10 GB

512 MB (1 GB) 15 GB

1 GB (2 GB) 16 GB

512 MB (2 GB) 10 GB

1 GB (2 GB) 16 GB

• Internet Explorer 6.0 or higher is the minimum requirement for all Windows operating systems.

• Users who have administrator rights can install the software.

• Windows Terminal Services is compatible with your machine.

5. Appendix

112

Specifications

Mac

Operating system

Requirements (Recommended)

CPU RAM Free HDD space

Mac OS X 10.5

Mac OS X 10.6

Mac OS X 10.7 - 10.8

Linux

Items Requirements

Operating system

•Intel

processors

512 MB (1 GB) 1 GB

• 867 MHz or faster Power PC G4/G5

•Intel

Redhat

processors

Enterprise Linux WS 4, 5, 6 (32/64 bit)

1 GB (2 GB) 1 GB

2 GB 4 GB

Fedora 5 ~ 15 (32/64 bit)

OpenSuSE

10.2, 10.3, 11.0, 11.1, 11.2, 11.3, 11.4 (32/64 bit)

Mandriva 2007, 2008, 2009, 2009.1, 2010 (32/64 bit)

Ubuntu 6.06, 6.10, 7.04, 7.10, 8.04, 8.10, 9.04, 9.10, 10.04, 10.10, 11.04 (32/64 bit)

SuSE Linux Enterprise Desktop 10, 11 (32/64 bit)

Debian 4.0, 5.0, 6.0 (32/64 bit)

CPU Pentium IV 2.4GHz (Intel Core™2)

RAM 512 MB (1 GB)

5. Appendix

113

Specifications

Items Requirements

Free HDD space 1 GB (2 GB)

Unix

Items Requirements

Sun Solaris 9, 10, 11 (x86, SPARC)

Operating system

Free HDD space Up to 100 MB

HP-UX 11.0, 11i v1, 11i v2, 11i v3 (PA-RISC, Itanium)

IBM AIX 5.1, 5.2, 5.3, 5.4, 6.1, 7.1 (Power PC)

5. Appendix

114

Specifications

Network environment

Network and wireless models only (see "Features by models" on page 8).

You need to set up the network protocols on the machine to use it as your network machine. The following table shows the network environments supported by the machine.

Items Specifications

Network interface • Ethernet 10/100/1000 Base-TX Wired Lan

•802.11b/g/n Wireless LAN

Network operating system

•Windows Server

XP, Windows Server® 2003, Windows Vista®, Windows® 7, Windows® 8, Windows

2008 R2

•Various Linux OS

• Mac OS X 10.5 -10.8

•UNIX OS

Network protocols •TCP/IPv4

• DHCP, BOOTP

• DNS, WINS, Bonjour, SLP, UPnP

• Standard TCP/IP Printing (RAW), LPR, IPP, WSD, AirPrint, Google Cloud Print

• SNMPv 1/2/3, HTTP, IPSec

• TCP/IPv6 (DHCP, DNS, RAW, LPR, SNMPv 1/2/3, HTTP, IPSec)

Wireless security • Authentication: Open System, Shared Key, WPA Personal, WPA2 Personal (PSK)

• Encryption: WEP64, WEP128, TKIP, AES

5. Appendix

115

Regulatory information

This machine is designed for a normal work environment and certified with several regulatory statements.

Laser safety statement

The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 608251 : 2007.

Class I laser products are not considered to be hazardous. The laser system and printer are designed so there is never any human access to laser radiation above a Class I level during normal operation, user maintenance or prescribed service condition.

Warning

When using this product, these basic safety precautions should always be followed to reduce risk of fire, electric shock, and injury to persons:

Never operate or service the printer with the protective cover removed from laser/scanner assembly. The reflected beam, although invisible, can damage your eyes.

5. Appendix

116

Regulatory information

Ozone safety

Power saver

This printer contains advanced energy conservation technology that reduces power consumption when it is not in active use.

When the printer does not receive data for an extended period of time, power consumption is automatically lowered.

This product’s ozone emission rate is under 0.1 ppm. Because ozone is heavier than air, keep the product in a place with good ventilation.

Recycling

Recycle or dispose of the packaging material for this product in an environmentally responsible manner.

ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.

For more information on the ENERGY STAR program see http:// www.energystar.gov

For ENERGY STAR certified models, the ENRGY STAR label will be on your machine. Check if your machine is ENERGY STAR certified.

5. Appendix

117

Regulatory information

Dan hab yungh youq gij digih haijbaz 2000 m doxroengz haenx ancienz sawjyungh.

2000m

China only

Correct disposal of this product (Waste electrical & electronic equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other s of waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

5. Appendix

118

Regulatory information

(The United States of America only)

Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect Or call, (877) 278 - 0799

State of California Proposition 65 Warning (US Only)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or experienced radio TV technician for help.

Radio frequency emissions

FCC information to the user

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that may cause undesired operation.

Change or modifications not expressly approved by the manufacturer responsible for compliance could void the user's authority to operate the equipment.

5. Appendix

119

Regulatory information

Canadian radio interference regulations

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus”, ICES-003 of the Industry and Science Canada.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.

United States of America

Federal Communications Commission (FCC)

The FCC has set a general guideline of 20 cm (8 inches) separation between the device and the body, for use of a wireless device near the body (this does not include extremities). This device should be used more than 20 cm (8 inches) from the body when wireless devices are on. The power output of the wireless device (or devices), which may be embedded in your printer, is well below the RF exposure limits as set by the FCC.

This transmitter must not be collocated or operation in conjunction with any other antenna or transmitter.

Operation of this device is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.

Wireless devices are not user serviceable. Do not modify them in any way. Modification to a wireless device will void the authorization to use it. Contact manufacturer for service.

Intentional emitter per FCC Part 15

Low power, Radio LAN devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz/5 GHz Band, may be present (embedded) in your printer system. This section is only applicable if these devices are present. Refer to the system label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in the United States of America if an FCC ID number is on the system label.

5. Appendix

120

Regulatory information

FCC Statement for Wireless LAN use:

While installing and operating this transmitter and antenna combination the radio frequency exposure limit of 1m W/cm2 may be exceeded at distances close to the antenna installed. Therefore, the user must maintain a minimum distance of 20cm from the antenna at all times. This device cannot be colocated with another transmitter and transmitting antenna.

Turkey only

Russia only

Germany only

Thailand only

Replacing the Fitted Plug (for UK Only)

Important

The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and has a 13 amp fuse. When you change or examine the fuse, you must re-fit the correct 13 amp fuse. You then need to replace the fuse cover. If you have lost the fuse cover, do not use the plug until you have another fuse cover.

Contact the people from you purchased the machine.

5. Appendix

121

Regulatory information

The 13 amp plug is the most widely used in the UK and should be suitable. However, some buildings (mainly old ones) do not have normal 13 amp plug sockets. You need to buy a suitable plug adaptor. Do not remove the moulded plug.

If you cut off the moulded plug, get rid of it straight away.

You cannot rewire the plug and you may receive an electric shock if you plug it into a socket.

Important warning:

You must earth this machine.

The wires in the mains lead have the following color code:

• Green and Yellow: Earth

• Blue: Neutral

• Brown: Live

You must connect the brown wire to the pin which is marked with the letter “L” or colored red.

You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.

Declaration of conformity (European countries)

Approvals and Certifications

Hereby, Samsung Electronics, declares that this [ProXpress M332xND, ProXpress M382xD, ProXpress M382xND, ProXpress M402xND] is in compliance with the essential requirements and other relevant provisions of Low Voltage Directive (2006/95/EC), EMC Directive (2004/ 108/EC).

Hereby, Samsung Electronics, declares that this [ProXpress M382xDW] is in compliance with the essential requirements and other relevant provisions of R&TTE Directive 1999/5/EC.

If the wires in the mains lead do not match the colors marked in your plug, do the following:

You must connect the green and yellow wire to the pin marked by the letter “E” or by the safety ‘Earth symbol’ or colored green and yellow or green.

You must connect the blue wire to the pin which is marked with the letter “N” or colored black.

The declaration of conformity may be consulted at www.samsung.com, go to Support > Download center and enter your printer (MFP) name to browse the EuDoC.

January 1, 1995: Council Directive 2006/95/EC Approximation of the laws of the member states related to low voltage equipment.

January 1, 1996: Council Directive 2004/108/EC, approximation of the laws of the Member States related to electromagnetic compatibility.

5. Appendix

122

Regulatory information

March 9, 1999: Council Directive 1999/5/EC on radio equipment and

telecommunications terminal equipment and the mutual recognition of their conformity. A full declaration, defining the relevant Directives and referenced standards can be obtained from your Samsung Electronics Co., Ltd. representative.

EC Certification

Certification to 1999/5/EC Radio Equipment & Telecommunications Terminal Equipment Directive (FAX)

This Samsung product has been self-certified by Samsung for pan-European single terminal connection to the analogue public switched telephone network (PSTN) in accordance with Directive 1999/5/EC. The product has been designed to work with the national PSTNs and compatible PBXs of the European countries:

In the event of problems, you should contact the Euro QA Lab of Samsung Electronics Co., Ltd. in the first instance.

European radio approval information (for products fitted with EU-approved radio devices)

Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz/5 GHz band, may be present (embedded) in your printer system which is intended for home or office use. This section is only applicable if these devices are present. Refer to the system label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in the European Union or associated areas if a CE mark is on the system label.

The power output of the wireless device or devices that may be embedded in you printer is well below the RF exposure limits as set by the European Commission through the R&TTE directive.

European states qualified under wireless approvals:

The product has been tested against TBR21. To assist in the use and application of terminal equipment which complies with this standard, the European Telecommunication Standards Institute (ETSI) has issued an advisory document (EG 201 121) which contains notes and additional requirements to ensure network compatibility of TBR21 terminals. The product has been designed against, and is fully compliant with, all of the relevant advisory notes contained in this document.

EU countries

European states with restrictions on use:

EEA/EFTA countries

No limitations at this time

5. Appendix

123

Regulatory information

Israel only

Regulatory compliance statements

Wireless guidance

Low power, Radio LAN devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz/5 GHz Band, may be present (embedded) in your printer system. The following section is a general overview of considerations while operating a wireless device.

Additional limitations, cautions, and concerns for specific countries are listed in the specific country sections (or country group sections). The wireless devices in your system are only qualified for use in the countries identified by the Radio Approval Marks on the system rating label. If the country you will be using the wireless device in, is not listed, contact your local Radio Approval agency for

The power output of the wireless device or devices that may be embedded in your printer is well below the RF exposure limits as known at this time. Because the wireless devices (which may be embedded into your printer) emit less energy than is allowed in radio frequency safety standards and recommendations, manufacturer believes these devices are safe for use. Regardless of the power levels, care should be taken to minimize human contact during normal operation.

As a general guideline, a separation of 20 cm (8 inches) between the wireless device and the body, for use of a wireless device near the body (this does not include extremities) is typical. This device should be used more than 20 cm (8 inches) from the body when wireless devices are on and transmitting.

This transmitter must not be collocated or operation in conjunction with any other antenna or transmitter.

Some circumstances require restrictions on wireless devices. Examples of common restrictions are listed below:

Radio frequency wireless communication can interfere with equipment on commercial aircraft. Current aviation regulations require wireless devices to be turned off while traveling in an airplane. IEEE 802.11 (also known as wireless Ethernet) and Bluetooth communication devices are examples of devices that provide wireless communication.

requirements. Wireless devices are closely regulated and use may not be allowed.

5. Appendix

124

Regulatory information

In environments where the risk of interference to other devices or services is harmful or perceived as harmful, the option to use a wireless device may be restricted or eliminated. Airports, Hospitals, and Oxygen or flammable gas laden atmospheres are limited examples where use of wireless devices may be restricted or eliminated. When in environments where you are uncertain of the sanction to use wireless devices, ask the applicable authority for authorization prior to use or turning on the wireless device.

Every country has different restrictions on the use of wireless devices. Since your system is equipped with a wireless device, when traveling between countries with your system, check with the local Radio Approval authorities prior to any move or trip for any restrictions on the use of a wireless device in the destination country.

If your system came equipped with an internal embedded wireless device, do not operate the wireless device unless all covers and shields are in place and the system is fully assembled.

Wireless devices are not user serviceable. Do not modify them in any way. Modification to a wireless device will void the authorization to use it. Contact manufacturer for service.

Only use drivers approved for the country in which the device will be used. See the manufacturer System Restoration Kit, or contact manufacturer Technical Support for additional information.

5. Appendix

125

Regulatory information

China only

5. Appendix

126

This user’s guide is provided for information purposes only. All information included herein is subject to change without notice.

Samsung Electronics is not responsible for any direct or indirect damages, arising from or related to use of this user’s guide.

• Samsung and the Samsung logo are trademarks of Samsung Electronics Co., Ltd.

• Microsoft, Windows, Windows Vista, Windows 7, Windows 8 and Windows Server 2008 R2 are either registered trademarks or trademarks of Microsoft Corporation.

• Google, Picasa, Google Docs, Android and Gmail are either registered trademarks or trademarks of Google Inc.

• Google Cloud Print is a trademark of Google Inc.

• iPad, iPhone, iPod touch, Mac and Mac OS are trademarks of Apple Inc., registered in the U.S and other countries. AirPrint and the AirPrint logo are trademarks of Apple Inc.

• All other brand or product names are trademarks of their respective companies or organizations.

Refer to the 'LICENSE.txt' file in the provided CD-ROM for the open source license information.

REV.0.91

5. Appendix

127

User’s Guide

ADVANCED

This guide provides information about installation, advanced configuration, operation and troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

This guide provides information concerning installation, basic operation and troubleshooting on windows.

ADVANCED

Information 194

1. Software Installation

Installation for Mac 132

Reinstallation for Mac 133

Installation for Linux 134

Reinstallation for Linux 135

2. Using a Network-Connected Machine

Useful network programs 137

Wired network setup 138

Installing driver over the network 142

IPv6 configuration 151

Wireless network setup 154

Layout 195

Paper 197

Graphic 198

System Setup 199

Emulation 202

Network 203

Job Management 205

4. Special Features

Altitude adjustment 208

Entering various characters 209

Printing features 210

Using optional device features 226

Samsung MobilePrint 186

AirPrint 187

Google Cloud Print™ 189

3. Useful Setting Menus

Before you begin reading a chapter 193

5. Useful Management Tools

Accessing management tools 229

Easy Capture Manager 230

Samsung AnyWeb Print 231

Easy Eco Driver 232

Using SyncThru™ Web Service 233

129

ADVANCED

Using Samsung Easy Printer Manager 237

Using Samsung Printer Status 240

Using Samsung Printer Experience 242

Using the Linux Unified Driver Configurator 248

6. Troubleshooting

Paper feeding problems 253

Power and cable connecting problems 254

Printing problems 255

Printing quality problems 259

Operating system problems 267

130

1. Software Installation

This chapter provides instructions for installing essential and helpful software for use in an environment where the machine is connected via a cable. A locally connected machine is a machine directly attached to your computer using the cable. If your machine is attached to a network, skip the following steps below and go on to installing a network connected machine’s driver (see "Installing driver over the network" on page 142).

• Installation for Mac 132

• Reinstallation for Mac 133

• Installation for Linux 134

• Reinstallation for Linux 135

• If you are a Windows OS user, refer to the Basic Guide for installing the machine’s driver (see "Installing the driver locally" on page 26).

• Only use a USB cable no longer then 3 meter (118 inches).

Installation for Mac

Make sure that the machine is connected to your computer and

powered on.

Insert the supplied software CD into your CD-ROM drive.

Double-click the CD-ROM icon that appears on your Mac desktop.

• For Mac OS X 10.8, double-click the CD-ROM that appears on Finder.

Double-click the MAC_Installer folder > Installer OS X icon.

Click Continue.

Select Direct Connection using USB cable on the Printer Connection Type and click Continue.

Click Add Printer button to select your printer and add it to your printer list.

If your machine supports fax, click Add Fax button to select your fax and add it to your fax list

After the installation is finished, click Close.

Read the license agreement and click Continue.

Click Agree to agree to the license agreement.

Click Install. All components necessary for machine operations will be

installed.

If you click Customize, you can choose individual components to install.

Enter the password and click OK.

1. Software Installation

132

Reinstallation for Mac

If the printer driver does not work properly, uninstall the driver and reinstall it.

Open the Applications folder > Samsung > Printer Software

Uninstaller.

To uninstall printer software, click Continue.

Check the program you want to delete and click Uninstall.

Enter the password and click OK.

After the uninstallation is finished, click Close.

If a machine has already been added, delete it from the Print Setup Utility or Print & Fax.

1. Software Installation

133

Installation for Linux

You need to download Linux software packages from the Samsung website to install the printer software (http://www.samsung.com > find your product > Support or Downloads).

Installing the Unified Linux Driver

Make sure that the machine is connected to your computer and

powered on.

When the Administrator Login window appears, type “root” in the

You must log in as a super user (root) to install the machine software. If you are not a super user, ask your system administrator.

The installation program added the Unified Driver Configurator desktop icon and the Unified Driver group to the system menu for your convenience. If you have any difficulties, consult the on-screen help that is available through your system menu or from the driver package Windows applications, such as Unified Driver Configurator or Image Manager.

From the Samsung website, download the Unified Linux Driver package

to your computer.

Right-click the Unified Linux Driver package and extract the package.

Double click cdroot > autorun.

When the welcome screen appears, click Next.

When the installation is complete, click Finish.

1. Software Installation

134

Reinstallation for Linux

If the printer driver does not work properly, uninstall the driver and reinstall it.

Make sure that the machine is connected to your computer and

powered on.

When the Administrator Login window appears, type “root” in the

You must log in as a super user (root) to uninstall the printer driver. If you are not a super user, ask your system administrator.

Open the Terminal program. When the Terminal screen appears, type in

the following.

[root@localhost root]#cd /opt/Samsung/mfp/uninstall/

[root@localhost uninstall]#./uninstall.sh

4 5

Click Next.

Click Finish.

1. Software Installation

135

2. Using a NetworkConnected Machine

This chapter gives you step-by-step instructions for setting up a network connected machine and software.

• Useful network programs 137

• Wired network setup 138

• Installing driver over the network 142

• IPv6 configuration 151

• Wireless network setup 154

• Samsung MobilePrint 186

• AirPrint 187

• Google Cloud Print™ 189

Supported optional devices and features may differ according to your model (see "Features by models" on page 8).

Useful network programs

There are several programs available to setup the network settings easily in a network environment. For the network administrator especially, managing several machines on the network is possible.

• Before using the programs below, set the IP address first.

• Some features and optional goods may not be available depending on model or country (see "Features by models" on page 8).

SyncThru™ Web Service

The web server embedded on your network machine allows you to do the following tasks (see "Using SyncThru™ Web Service" on page 233).

• Check the supplies information and status.

SyncThru™ Web Admin Service

Web-based machine management solution for network administrators. SyncThru™ Web Admin Service provides you with an efficient way of managing network devices and lets you remotely monitor and troubleshoot network machines from any site with corporate internet access.

• Download this program from http://solution.samsungprinter.com.

SetIP wired network setup

This utility program allows you to select a network interface and manually configure the IP addresses for use with the TCP/IP protocol.

• See "IPv4 configuration using SetIP (Windows)" on page 138.

• Customize machine settings.

• Set the email notification option. When you set this option, the machine status (toner cartridge shortage or machine error) will be sent to a certain person's email automatically.

• Configure the network parameters necessary for the machine to connect to various network environments.

• See "IPv4 configuration using SetIP (Mac)" on page 139.

• See "IPv4 configuration using SetIP (Linux)" on page 140.

• The machine that does not support the network port, it will not be able to use this feature (see "Rear view" on page 21).

• TCP/IPv6 is not supported by this program.

2. Using a Network-Connected Machine

137

Wired network setup

Printing a network configuration report

You can print Network Configuration Report from the machine’s control panel that will show the current machine’s network settings. This will help you to set up a network.

• Accessing menus may differ from model to model (see "Accessing the menu" on page 31).

• It may be necessary to press OK to navigate to lower-level menus for some models.

Using this Network Configuration Report, you can find your machine’s MAC address and IP address.

For example:

• MAC Address: 00:15:99:41:A2:78

• IP Address: 169.254.192.192

Setting IP address

• The machine that does not support the network interface, it will not be able to use this feature (see "Rear view" on page 21).

• TCP/IPv6 is not supported by this program.

First, you have to set up an IP address for network printing and managements. In most cases a new IP address will be automatically assigned by a DHCP (Dynamic Host Configuration Protocol) server located on the network.

• The machine has the display screen: Press the (Menu) button on the

control panel and select Network > Network Conf.

• The machine does not have the display screen: Press the

(Cancel)button for more than five seconds on the control panel.

IPv4 configuration using SetIP (Windows)

Before using the SetIP program, disable the computer firewall from Control Panel > Security Center > Windows Firewall.

2. Using a Network-Connected Machine

138

Wired network setup

Download the software from the Samsung website then unpack and

install it: (http://www.samsung.com > find your product > Support or Downloads).

Follow the instructions in the installation window.

Connect your machine to the network with a network cable.

Turn on the machine.

From the Windows Start menu, select All Programs > Samsung

Printers > SetIP > SetIP.

Click the icon (third from left) in the SetIP window to open the TCP/

IP configuration window.

Enter the machine’s new information into the configuration window as

follows. In a corporate intranet, you may need to have this information assigned by a network manager before proceeding.

Find the machine’s MAC address from the Network Configuration Report (see "Printing a network configuration report" on page 138) and enter it without the colons. For example, 00:15:99:29:51:A8 becomes 0015992951A8.

Click Apply, and then click OK. The machine will automatically print the

Network Configuration Report. Confirm that all the settings are

correct.

IPv4 configuration using SetIP (Mac)

Before using the SetIP program, disable the computer firewall from System Preferences > Security > Firewall.

The following instructions may vary from your model.

Connect your machine to the network with a network cable.

Insert the supplied software CD into your CD-ROM drive.

2. Using a Network-Connected Machine

139

Wired network setup

4 5 6 7 8

Double-click the CD-ROM icon that appears on your Mac desktop.

• For Mac OS X 10.8, Double-click the CD-ROM that appears on Finder.

Double-click the MAC_Installer folder > Installer OS X icon.

Click Continue.

Read the license agreement and click Continue.

Click Agree to agree to the license agreement.

Click Install. All components necessary for machine operations will be installed.

If you click Customize, you can choose individual components to install.

Enter the password and click OK.

Select Network connection on the Printer Connection Type and click Set IP Address button.

Click Apply, and then click OK. The machine will automatically print the Network Configuration Report. Confirm that all the settings are

correct.

IPv4 configuration using SetIP (Linux)

Before using the SetIP program, disable the computer firewall from System Preferences or Administrator.

The following instructions may vary from your model or operating systems.

Click the icon (third from left) in the SetIP window to open the TCP/ IP configuration window.

Enter the machine’s new information into the configuration window. In a corporate intranet, you may need to have this information assigned by a network manager before proceeding.

Open /opt/Samsung/mfp/share/utils/.

Double-click the SetIPApplet.html file.

Click to open the TCP/IP configuration window.

Enter the machine’s new information into the configuration window. In

a corporate intranet, you may need to have this information assigned by a network manager before proceeding.

2. Using a Network-Connected Machine

140

Wired network setup

The machine will automatically print the Network Configuration

Report.

2. Using a Network-Connected Machine

141

Installing driver over the network

• Some features and optional goods may not be available depending on model or country (see "Features by models" on page 8).

• The machine that does not support the network interface, it will not be able to use this feature (see "Rear view" on page 21).

• You can install the printer driver and software when you insert the software CD into your CD-ROM drive.

For Windows, select the printer driver and software in the Select

Software to Install window.

2. Using a Network-Connected Machine

142

Installing driver over the network

Windows

Make sure that the machine is connected to the network and powered

on. Also, your machine’s IP address should have been set (see "Setting IP address" on page 138).

Insert the supplied software CD into your CD-ROM drive.

If the installation window does not appear, click Start > All programs > Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CD- ROM drive and click OK.

• For Windows 8,

If the installation window does not appear, from Charms, select Search > Apps and search for Run. Type in X:\Setup.exe, replacing “X” with the letter that represents your CD-ROM drive and click OK.

Using Enhanced Features and Participating in Printer Usage Information Collection Program (optional). Then, click Next.

Select Network connection on the Printer Connection Type screen.

If the Connected Device window appears, check that the machine is

connected to your network. Then, click Next.

The firewall software might be blocking network communication. Before connecting the device to the network, disable the computer’s firewall.

If “Tap to choose what happens with this disc.” pop-up window appears, click the window and select Run Setup.exe.

Read and accept The software End User License Agreement and

The searched machines will be shown on the screen. Select the one you

wish to use and click OK.

Follow the instructions in the installation window.

2. Using a Network-Connected Machine

143

Installing driver over the network

From the Windows 8 Start Screen

• Samsung Printer Experience app can only be used in the Start screen

when V4 driver is installed. The V4 driver is automatically downloaded from the Windows Update if your computer is connected to the Internet. If not, you can manually download the V4 driver from Samsung website, www.samsung.com > find your product > Support or downloads.

•You can download Samsung Printer Experience app from the

Windows Store. You need have a Microsoft account to use the Windows Store.

a From Charms, select Search. b Click Store.

c Search and click Samsung Printer Experience.

d Click Install.

• If you install the driver using the supplied software CD, V4 driver is not installed. If you want to use the V4 driver in the Desktop screen, you can

download from the Samsung website, www.samsung.com >find your

product > Support or downloads.

• If you want to install Samsung’s printer management tools, you need to install them using the supplied software CD.

Click Add a device.

Discovered machines will be shown on the screen.

Click the model name or host name you wish to use.

You can print a Network Configuration Report from the machine’s control panel that will show the current machine’s host name (see "Printing a network configuration report" on page 177).

The driver is automatically installed from the Windows Update.

Silent installation Mode

Silent installation mode is an installation method that does not require any user intervention. Once you start the installation, the machine driver and software are automatically installed on you computer. You can start the silent installation by typing /s or /S in the command window.

Make sure that the machine is connected to the network and powered

on. Also, your machine’s IP address should have been set (see "Setting IP address" on page 138).

From Charms, select Settings > Change PC settings > Devices.

Command-line Parameters

Following table shows commands that can be used in the command window.

Following command-line are effective and operated when command is used with /s or /S. But /h, /H or /? are exceptional commands that can be operated solely.

2. Using a Network-Connected Machine

144

Installing driver over the network

Command- line Definition Description

/s or

Starts silent installation. Installs machine drivers

without prompting any UIs or user intervention.

/p”<port name>” or

/P”<port name>”

Specifies printer port.

Printer port name can be specified as IP address, hostname, USB local port

Network Port will be created by use of

name or IEEE1284 port name.

For example:

Standard TCP/IP Port monitor. For local port, this port must exist on system before being specified by

• /p”xxx.xxx.xxx.xxx” in where, “xxx.xxx.xxx.xxx” means IP address for network printer. / p”USB001”, /P”LPT1:”, / p”hostname”

command.

/a”<dest_path>” or

/A”<dest_path>”

Specifies destination path for installation.

Since machine drivers should be installed on the OS specific location, this command applies to only application

The destination

software.

path should be a fully qualified path.

Command- line Definition Description

/n”<Printer name>” or

/N”<Printer name>”

Specifies printer name. Printer instance shall be created as specified printer

With this parameter, you can add printer instances as your wishes.

name.

/nd or

/ND

Commands not to set the installed driver as a default machine driver.

It indicates installed machine driver will not be the default machine driver on your system if there are one or more printer drivers installed. If there is no installed machine driver on your system, then this option won’t be applied because Windows OS will set installed printer driver as a default machine driver.

/x or

Uses existing machine driver files to create printer instance if it is already installed.

This command provides a way to install a printer instance that uses installed printer driver files without installing an additional driver.

2. Using a Network-Connected Machine

145

Installing driver over the network

Command- line Definition Description

Mac

/up”<printer name>” or

/UP”<printer name>”

Removes only specified printer instance and not the driver files.

This command provides a way to remove only specified printer instance from your system without effecting other printer drivers. It will not remove printer driver files from your system.

Make sure that the machine is connected to your network and powered

on.

Insert the supplied software CD into your CD-ROM drive.

/d or

/v”<share name>” or

/V”<share name>”

/o or

/h, /H or /? Shows Command-line Usage.

Uninstalls all device drivers and applications from your system.

Shares installed machine and add other available platform drivers for Point & Print.

Opens Printers and Faxes folder after installation.

This command will remove all installed device drivers and application software from your system.

It will install all supported Windows OS platform’s machine drivers to system and share it with specified <share name> for point and print.

This command will open Printers and Faxes folder after the silent installation.

Double-click the CD-ROM icon that appears on your Mac desktop.

• For Mac OS X 10.8, double-click the CD-ROM that appears on Finder.

Double-click the MAC_Installer folder > Installer OS X icon.

Click Continue.

Read the license agreement and click Continue.

Click Agree to agree to the license agreement.

Click Install. All components necessary for machine operations will be

installed.

If you click Customize, you can choose individual components to install.

2. Using a Network-Connected Machine

146

Installing driver over the network

12 13 14

16 17

Enter the password and click OK.

Select Network connection on the Printer Connection Type and click Continue.

Click Add Printer button to select your printer and add it to your printer list.

Click IP and select HP Jetdirect - Socket in Protocol.

Enter the machine’s IP address in the Address input field.

Enter the queue name in the Queue input field. If you cannot determine the queue name for your machine server, try using the default queue first.

If Auto Select does not work properly, choose Select Printer Software and your machine name in Print Using.

Click Add.

After the installation is finished, click Close.

Install the Linux driver and add network printer

Make sure that the machine is connected to your network and powered

on. Also, your machine’s IP address should have been set.

Download the Unified Linux Driver package from the Samsung website.

Extract the UnifiedLinuxDriver.tar.gz file and open the new directory.

Double-click the cdroot > autorun.

The Samsung installer window opens. Click Next.

The add printer wizard window opens. Click Next.

Select network printer and click Search button.

The machine’s IP address and model name appears on list field.

Select your machine and click Next.

Input the printer description and Next.

Linux

You need to download Linux software packages from the Samsung website to install the printer software (http://www.samsung.com > find your product > Support or Downloads).

11 12

After the machine is added, click Finish.

When installation is done, click Finish.

2. Using a Network-Connected Machine

147

Installing driver over the network

Add a network printer

Double-click the Unified Driver Configurator.

Click Add Printer.

The Add printer wizard window opens. Click Next.

Select Network printer and click the Search button.

The printer’s IP address and model name appears on list field.

Select your machine and click Next.

Enter the printer description and click Next.

After the machine is added, click Finish.

To use the UNIX printer driver, you have to install the UNIX printer driver package first, then setup the printer. You can download the UNIX printer driver package from the Samsung website (http://www.samsung.com > find your product > Support or Downloads).

Installing the UNIX printer driver package

The installation procedure is common for all variants of UNIX OS mentioned.

From the Samsung website, download and unpack the UNIX Printer

Driver package to your computer.

Acquire root privileges.

“su -”

Copy the appropriate driver archive to the target UNIX computer.

UNIX

• Make sure your machine supports the UNIX operating system before installing the UNIX printer driver (see "Operating System" on page 8).

• The commands are marked with “”, when typing the commands, do not type “”.

• Some features and optional goods may not be available depending on model or country (see "Operating System" on page 8).

See administration guide of your UNIX OS for details.

Unpack the UNIX printer driver package.

For example, on IBM AIX, use the following commands.

“gzip -d < enter the package name | tar xf -”

Go to the unpacked directory.

2. Using a Network-Connected Machine

148

Installing driver over the network

Run the install script.

“./install –i”

install is the installer script file which is used to install or uninstall the

UNIX Printer Driver package.

Use “chmod 755 install” command to give the permission to the installer script.

Execute the “. /install –c” command to verify installation results.

Run “installprinter” from the command line. This will bring up the Add

Printer Wizard window. Setup the printer in this window referring to

the following procedures.

On some UNIX OS, for example on Solaris 10, just added printers may not be enabled and/or may not accept jobs. In this case run the following two commands on the root terminal:

Uninstalling the printer driver package

The utility should be used to delete the printer installed in the system.

a Run “uninstallprinter” command from the terminal.

It will open the Uninstall Printer Wizard. The installed printers are listed in the drop-down list.

b Select the printer to be deleted. c Click Delete to delete the printer from the system. d Execute the “. /install –d” command to uninstall the whole package. e To verify removal results, execute the “. /install –c” command.

To re-install it, use the command “. /install –i” to reinstall the binaries.

Setting up the printer

“accept <printer_name>”

“enable <printer_name>”

To add the printer to your UNIX system, run ‘installprinter’ from the command line. This will bring up the Add Printer Wizard window. Setup the printer in this window according to the following steps:

Type the name of the printer.

Select the appropriate printer model from the model list.

Enter any description corresponding to the type of the printer in the

Type field. This is optional.

2. Using a Network-Connected Machine

149

Installing driver over the network

Specify any printer description in the Description field. This is optional.

Specify the printer location in the Location field.

Type the IP address or DNS name of the printer in the Device textbox for

network-connected printers. On IBM AIX with jetdirect Queue type, only the DNS name is possible-numeric IP address is not allowed.

Queue type shows the connection as lpd or jetdirect in the

corresponding list box. Additionally, usb type is available on Sun Solaris OS.

Select Copies to set the number of copies.

Check the Collate option to receive copies already sorted.

9 10 11 12

Check the Reverse Order option to receive copies in the reverse order.

Check the Make Default option to set this printer as default.

Click OK to add the printer.

2. Using a Network-Connected Machine

150

IPv6 configuration

IPv6 is supported properly only in Windows Vista or higher.

• Some features and optional goods may not be available depending on model or country (see "Features by models" on page 8 or "Menu overview" on page 31).

• If the IPv6 network seems to not be working, set all the network setting to the factory defaults and try again using Clear Setting.

The machine supports the following IPv6 addresses for network printing and managements.

• Link-local Address: Self-configured local IPv6 address (Address starts with FE80).

• Stateless Address: Automatically configured IPv6 address by a network router.

• Stateful Address: IPv6 address configured by a DHCPv6 server.

From the control panel

Activating IPv6

• Accessing menus may differ from model to model (see "Accessing the menu" on page 31).

• It may be necessary to press OK to navigate to lower-level menus for some models.

Select (Menu) > Network > TCP/IP (IPv6) > IPv6 Protocol on the

control panel.

Select On and press OK.

Turn the machine off and turn it on again.

• Manual Address: Manually configured IPv6 address by a user.

In the IPv6 network environment, follow the next procedure to use the IPv6 address.

When you install the printer driver, do not configure both IPv4 and IPv6. We recommend to configure either IPv4 or IPv6.

DHCPv6 address configuration

If you have a DHCPv6 server on your network, you can set one of the following options for default dynamic host configuration.

2. Using a Network-Connected Machine

151

IPv6 configuration

• Accessing menus may differ from model to model (see "Accessing the menu" on page 31).

• It may be necessary to press OK to navigate to lower-level menus for some models.

Select (Menu) > Network > TCP/IP (IPv6) > DHCPv6 Config on the

control panel.

Press OK to select the required value you want.

• Router: Use DHCPv6 only when requested by a router.

• Always Use: Always use DHCPv6 regardless of router request.

• Never Use: Never use DHCPv6 regardless of router request.

From the SyncThru™ Web Service

Activating IPv6

Access a web browser, such as Internet Explorer, from Windows.GEnter

the machine IP address (http://xxx.xxx.xxx.xxx) in the address field and press the Enter key or click Go.

If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and password. We recommend you to change the default password for security reasons.

• ID: admin

• Password: sec00000

When the SyncThru™ Web Service window opens, move the mouse

cursor over the Settings of the top menu bar and then click Network Settings.

Click TCP/IPv6 on the left pane of the website.

Check the IPv6 Protocol check box to activate IPv6.

Click the Apply button.

Turn the machine off and turn it on again.

2. Using a Network-Connected Machine

152

IPv6 configuration

• You can also set the DHCPv6.

• To manually set the IPv6 address:

Check the Manual Address check box. Then, the Address/Prefix text box is activated. Enter the rest of the address (e.g.,:3FFE:10:88:194::AAAA. “A” is the hexadecimal 0 through 9, A through F).

IPv6 address configuration

Start a web browser, such as Internet Explorer, that supports IPv6

addressing as a URL.

Select one of the IPv6 addresses (Link-local Address, Stateless

Address, Stateful Address, Manual Address) from Network Configuration Report (see "Printing a network configuration report" on

page 138).

Address must be enclosed in '[ ]' brackets.

• Link-local Address: Self-configured local IPv6 address (Address

starts with FE80).

• Stateless Address: Automatically configured IPv6 address by a

network router.

• Stateful Address: IPv6 address configured by a DHCPv6 server.

• Manual Address: Manually configured IPv6 address by a user.

Enter the IPv6 addresses (e.g.,: http://[FE80::215:99FF:FE66:7701]).

2. Using a Network-Connected Machine

153

Wireless network setup

• Make sure your machine supports wireless networking. Wireless networking may not be available depending on the model (see "Features by models" on page 8).

• If the IPv6 network seems to not be working, set all the network settings to the factory defaults and try again using Clear Setting.

Getting started

Understanding your network type

Typically, you can only have one connection between your computer and the

Wireless network name and network password

Wireless networks require higher security, so when an access point is first set up, a network name (SSID), the type of security used, and a Network Password are created for the network. Ask your network administrator about this information before proceeding with the machine installation.

machine at a time.

Infrastructure mode

This is an environment generally used for homes and SOHOs (Small Office/ Home Office). This mode uses an access point to communicate with the wireless machine.

Ad hoc mode

This mode does not use an access point. The wireless computer and wireless machine communicate directly.

2. Using a Network-Connected Machine

154

Wireless network setup

Introducing wireless set up methods

Some wireless network installation types may not be available depending on the model or country.

You can set wireless settings either from the machine or the computer. Choose the setting method from the below table.

Set up method Connecting method Description & Reference

From the computer Windows user, see "Access point via USB cable" on page 161.

Windows user, see "Access point without a USB cable (recommended)" on page

164.

Mac user, see "Access point via USB cable" on page 170.

With Access Point

Mac user, see "Access point without a USB cable (recommended)" on page 172.

From the machine’s control panel See "Machines with a display screen" on page 158.

See "Using a network cable" on page 176.

See "Using the menu button" on page 160.

2. Using a Network-Connected Machine

155

Wireless network setup

Set up method Connecting method Description & Reference

From the computer Windows user, see "Ad hoc via USB cable" on page 167.

Without Access Point

• If problems occur during wireless set up or driver installation, refer to the troubleshooting chapter (see "Troubleshooting for wireless network" on page 181).

• It is strongly recommended that you set the password on Access Points. If you do not set the password on Acess Points, they might be exposed to illegal access from unknown machine including PCs, smart phones and printers. Refer to the Access Point user guide for password settings.

Mac user, see "Ad hoc via USB cable" on page 174.

Wi-Fi Direct setup See "Setting the Wi-Fi Direct for mobile printing" on page 179.

2. Using a Network-Connected Machine

156

Wireless network setup

Using the WPS button

Choosing your type

There are two methods available to connect your machine to a wireless network

If your machine and an access point (or wireless router) support Wi-Fi Protected Setup™ (WPS), you can easily configure the wireless network settings by

pressing the (WPS) button on the control panel without a computer.

• If you want to use the wireless network using the infrastructure mode, make sure that the network cable is disconnected from the machine. Using the WPS (PBC) button or entering the PIN from the computer to connect to the access point (or wireless router) varies depending on the access point (or wireless router) you are using. Refer to the user's guide of the access point (or wireless router) you are using.

• When using the WPS button to set the wireless network, security settings may change. To prevent this, lock the WPS option for the current wireless security settings. The option name may differ depending on the access point (or wireless router) you are using.

Items to prepare

using the (WPS) button on the control panel.

The Push Button Configuration (PBC) method allows you to connect your

machine to a wireless network by pressing both the (WPS) button on the control panel of your machine and the WPS (PBC) button on a Wi-Fi Protected Setup™ WPS-enabled access point (or wireless router) respectively.

The Personal Identification Number (PIN) method helps you connect your machine to a wireless network by entering the supplied PIN information on a WiFi Protected Setup™ WPS-enabled access point (or wireless router).

Factory default in your machine is PBC mode, which is recommended for a typical wireless network environment.

You can change the WPS mode from the control panel (Menu) > Network > Wi-Fi > WPS).

• Check if the access point (or wireless router) supports Wi-Fi Protected Setup™ (WPS).

• Check if your machine supports Wi-Fi Protected Setup™ (WPS).

• Networked computer (PIN mode only)

2. Using a Network-Connected Machine

157

Wireless network setup

Machines with a display screen

Connecting in PBC mode

Select (Menu) > Network > WiTFi > WPS > ConnectViaPBC on the

control panel.

Or press and hold the (WPS) button on the control panel for more than 2 seconds.

The machine starts waiting for up to two minutes until you press the WPS (PBC) button on the access point (or wireless router).

Press the WPS (PBC) button on the access point (or wireless router).

The messages are displayed on the display screen in the order below:

a Connecting: The machine is connecting to the access point (or

wireless router).

b Connected: When the machine is successfully connected to the

wireless network, the WPS LED light stays on.

c AP SSID: After completing the wireless network connection process,

the AP’s SSID information appears on the display.

Connecting in PIN mode

Select (Menu) > Network > WiTFi > WPS > ConnectViaPIN on the

control panel.

Or press and hold the (WPS) button on the control panel for more than 2 seconds.

The eight-digit PIN appears on the display.

You need to enter the eight-digit PIN within two minutes on the computer that is connected to the access point (or wireless router).

The messages are displayed on the display screen in the order below:

a Connecting: The machine is connecting to the wireless network.

b Connected: When the machine is successfully connected to the

wireless network, the WPS LED light stays on.

c SSID Type: After completing the wireless network connection

process, the AP’s SSID information is displayed on the LCD display.

Insert the supplied software CD into your CD-ROM drive, and follow the

instructions in the window to set up the wireless network.

Insert the supplied software CD into your CD-ROM drive, and follow the

instructions in the window to set up the wireless network.

2. Using a Network-Connected Machine

158

Wireless network setup

Machines without a display screen

Connecting in PBC mode

Press and hold the (WPS) button on the control panel for about 2 - 4

seconds until the status LED blinks quickly.

The machine starts connecting to the wireless network. The LED blinks slowly for up to two minutes until you press the PBC button on the access point (or wireless router).

Press the WPS (PBC) button on the access point (or wireless router).

a The light blinks fast on the WPS LED. The machine is connecting to

the access point (or wireless router).

b When the machine is successfully connected to the wireless

network, the WPS LED light stays on.

Insert the supplied software CD into your CD-ROM drive, and follow the

instructions in the window to set up the wireless network.

Connecting in PIN mode

The network configuration report, including PIN, must be printed (see

"Printing a network configuration report" on page 138).

In ready mode, press and hold the (Stop/Clear)button on the control panel for about 5 seconds. You can find your machine’s PIN.

Press and hold the (WPS) button on the control panel for more than

4 seconds until the status LED stays on.

The machine starts connecting to the access point (or wireless router).

You need to enter the eight-digit PIN within two minutes on the

computer that is connected to the access point (or wireless router).

The LED blinks slowly for up to two minutes until you enter the eightdigit PIN.

The WPS LED blinks in the order below:

a The light blinks fast on the WPS LED. The machine is connecting to

the access point (or wireless router).

b When the machine is successfully connected to the wireless

network, the WPS LED light stays on.

Insert the supplied software CD into your CD-ROM drive, and follow the

instructions in the window to set up the wireless network.

2. Using a Network-Connected Machine

159

Wireless network setup

Re-connecting to a network

When the wireless function is off, the machine automatically tries to re-connect to the access point (or wireless router) with the previously used wireless connection settings and address.

In the following cases, the machine automatically re-connects to the wireless network:

• The machine is turned off and on again.

• The access point (or wireless router) is turned off and on again.

Canceling the connection process

To cancel the wireless network connection when the machine is connecting to

the wireless network, press and release the (Stop/Clear) on the control panel. You need to wait 2 minutes to re-connect to the wireless network.

Disconnecting from a network

To disconnect the wireless network connection, press the (WPS) button on the control panel for more than two seconds.

• When the Wi-Fi network is in idle mode: The machine is immediately disconnected from the wireless network and the WPS LED turns off.

• When the Wi-Fi network is being used: While the machine waits until the current job is finished, the light blinks fast on the WPS LED. Then, the wireless network connection is automatically disconnected and the WPS

LED turns off.

Using the menu button

Some menus may not appear in the display depending on options or models. If so, it is not applicable to your machine (see "Features by models" on page 8).

Before starting, you will need to know the network name (SSID) of your wireless network and the network key if it is encrypted. This information was set when the access point (or wireless router) was installed. If you do not know about your wireless environment, please ask the person who set up your network.

2. Using a Network-Connected Machine

160

Wireless network setup

After completing the wireless network connection, you need to install a machine driver to print from an application (see "Installing driver over the network" on page 142).

Access point via USB cable

Items to prepare

Select (Menu) > Network > Wi-Fi > Wi-Fi Settings on the control

panel.

Press the OK to select the setup method you want.

• Search List(recommended): In this mode, the setup is automatic. The machine will display a list of available networks from which to choose. After a network is chosen then printer will prompt for the corresponding security key.

• Custom: In this mode, users can give or edit manually their own SSID, or choose the security option in detail.

Setup using Windows

• Access point

• Network-connected computer

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

• USB cable

Creating the infrastructure network

Check wheter the USB cable is connected to the machine.

Turn on your computer, access point, and machine.

Shortcut to the Wireless Setting program without the CD: If you have installed the printer driver once, you can access the Wireless Setting program without the CD. From the Start menu, select Programs or All

Programs > Samsung Printers > your printer driver name > Wireless Setting Program.

2. Using a Network-Connected Machine

161

Wireless network setup

Insert the supplied software CD into your CD-ROM drive.

If the installation window does not appear, click Start > All programs > Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CD- ROM drive and click OK.

• For Windows 8,

If “Tap to choose what happens with this disc.” pop-up window appears, click the window and select Run Setup.exe.

Select Wireless network connection on the Printer Connection Type

screen. Then, click Next.

If Select the Wireless Setup Method screen appears, select Using a

USB cable and click Next.

Read and accept The software End User License Agreement and

Using Enhanced Features and Participating in Printer Usage Information Collection Program (optional). Then, click Next.

2. Using a Network-Connected Machine

162

Wireless network setup

If your comupter is wirless network enabled PC running Windows 7 or higher, wireless network installation proceeds automatically. Go to step 10.

• Authentication: Select an authentication type.

Open System: Authentication is not used, and encryption may or may not be used, depending on the need for data security.

Shared Key: Authentication is used. A device that has a proper WEP key can access the network.

WPA Personal or WPA2 Personal: Select this option to authenticate the print server based on a WPA Pre-Shared Key. This uses a shared secret key (generally called Pre Shared Key pass phrase), which is manually configured on the access point and each of its clients.

• Encryption: Select the encryption (None, WEP64, WEP128, TKIP, AES,

TKIP AES).

• Network Password: Enter the encryption network password value.

• Confirm Network Password: Confirm the encryption network

password value.

• WEP Key Index: If you are using WEP Encryption, select the appropriate

WEP Key Index.

After searching, the window shows the wireless network devices. Select

the name (SSID) of the access point you want to use and click Next.

If you cannot find the network name you want to choose, or if you want to set the wireless configuration manually, click Advanced Setting.

The wireless network security window appears when the access point has security settings.

Enter the Network Password of the access point (or router).

• Enter the wireless Network Name: Enter the SSID of the access point

(SSID is case-sensitive).

• Operation Mode: Select Infrastructure.

2. Using a Network-Connected Machine

163

Wireless network setup

If your printer supports Wi-Fi Direct and this function is disabled, its

corresponding screen will appear.

Click OK and Next.

10 11

Select the components to be installed.

After selecting the components, you can also change the machine name, set the machine to be shared on the network, set the machine as the default machine, and change the port name of each machine. Click Next.

Click Finish.

Access point without a USB cable (recommended)

Items to prepare

• WiFi-enabled PC running Windows 7 or higher and an access point (router)

• Software CD that was provided with your machine

• Wi-Fi Direct option appears on the screen only if your printer supports this feature.

• Can start to build Wi-Fi Direct by using Samsung Easy Printer Manager

(see "Setting up Wi-Fi Direct" on page 180).

• Wi-Fi Direct Name: The default Wi-Fi Direct Name is the model name and the maximum length is 22 characters.

• A machine installed with a wireless network interface

While setting the wireless netwok, the machine uses PC’s wireless LAN. You might not be able to connect to the Internet.

• Password setting is the numeric string, and the size is 8 ~ 64 characters.

When the wireless network set up is completed, disconnect the USB

cable between the computer and machine. Click Next.

2. Using a Network-Connected Machine

164

Wireless network setup

Creating the infrastructure network

Turn on your computer, access point, and machine.

Insert the supplied software CD into your CD-ROM drive.

If the installation window does not appear, click Start > All programs > Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CD- ROM drive and click OK.

• For Windows 8,

Select Wireless network connection on the Printer Connection Type

screen. Then, click Next.

If “Tap to choose what happens with this disc.” pop-up window appears, click the window and select Run Setup.exe.

Read and accept The software End User License Agreement and

Using Enhanced Features and Participating in Printer Usage Information Collecion Program (optional). Then, click Next.

2. Using a Network-Connected Machine

165

Wireless network setup

Select Using a direct wireless connection on the Select the Wireless

Setup Method screen. Then, click Next.

Even if your computer is running Windows 7 or higher, you cannot use this feature if your PC does not support wirless network. Set the wireless network using a USB cable (see "Access point via USB cable" on page

161).

If below screen apperas, press the (WPS) button from the control panel withing 2 minutes.

When the wireless network set up is completed, click Next.

Select the components to be installed.

After selecting the components, you can also change the printer driver

name, set the machine to be shared on the network, set the machine as the default machine. Click Next.

Click Finish.

2. Using a Network-Connected Machine

166

Wireless network setup

Ad hoc via USB cable

If you do not have an access point (AP), you may still connect the machine wirelessly to your computer by setting up an ad-hoc wireless network by following the simple steps below.

Items to prepare

• Network-connected computer

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

• USB cable

2. Using a Network-Connected Machine

167

Wireless network setup

Creating the ad hoc network in Windows

Turn on your computer and the wireless network machine.

Insert the supplied software CD into your CD-ROM drive.

If the installation window does not appear, click Start > All programs > Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CD- ROM drive and click OK.

• For Windows 8,

Select Configure the wireless network connection using USB cable

on the Printer Connection Type screen.

After searching the wireless networks, a list of wireless networks your

machine has searched appears. Click Advanced Setting.

If “Tap to choose what happens with this disc.” pop-up window appears, click the window and select Run Setup.exe.

Read and accept The software End User License Agreement and

Using Enhanced Features and Participating in Printer Usage Information Collection Program (optional). Then, click Next.

• Enter the wireless Network Name: Enter the SSID name you want (SSID

is case-sensitive).

• Operation Mode: Select ad hoc.

• Channel: Select the channel. (Auto Setting or 2412 MHz to 2467 MHz).

• Authentication: Select an authentication type.

Open System: Authentication is not used, and encryption may or may not be used, depending on the need for data security.

Shared Key: Authentication is used. A device that has a proper WEP key can access the network.

2. Using a Network-Connected Machine

168

Wireless network setup

• Encryption: Select the encryption (None, WEP64, WEP128).

• Network Password: Enter the encryption network password value.

• Confirm Network Password: Confirm the encryption network

password value.

• WEP Key Index: If you are using WEP Encryption, select the appropriate

WEP Key Index.

The wireless network security window appears when the ad hoc network has security enabled.

Select Open System or Shared Key for the authentication and click Next.

• WEP (Wired Equivalent Privacy) is a security protocol preventing unauthorized access to your wireless network. WEP encrypts the data portion of each packet exchanged on a wireless network using a 64-bit or 128-bit WEP encryption key.

The window showing the wireless network setting appears. Check the

settings and click Next.

Before entering the IP address for the machine, you must know the computer’s network configuration information. If the computer’s network configuration is set to DHCP, the wireless network setting should also be DHCP. Likewise, if the computer’s network configuration is set to Static, the wireless network setting should also be Static.

If your computer is set to DHCP and you want to use the Static wireless network setting, you must contact the network administrator to get the static IP address.

• For the DHCP method

If the IP address assignment method is DHCP, check if DHCP is shown in the Wireless Network Setting Confirm window. If it shows Static, click

Change TCP/IP to change the assignment method to Receive IP address automatically (DHCP).

• For the Static method

If the IP address assignment method is Static, check if Static is shown in the Wireless Network Setting Confirm window. If it shows DHCP, click Change TCP/IP to enter the IP address and other network configuration values for the machine.

For example, If the computer’s network information is as shown follows:

- IP address: 169.254.133.42

- Subnet Mask: 255.255.0.0 Then, the machine’s network information should be as below:

- IP address: 169.254.133.43

- Subnet Mask: 255.255.0.0 (Use the computer’s subnet mask.)

- Gateway: 169.254.133.1

2. Using a Network-Connected Machine

169

Wireless network setup

The Wireless Network Setting Complete window appears. Click Next.

When the wireless network settings are completed, disconnect the USB

cable between the computer and machine. Click Next.

Select the components to be installed.

Click Finish.

Setup using Mac

Access point via USB cable

Make sure that the machine is connected to your computer and

powered on.

Insert the supplied software CD into your CD-ROM drive.

Double-click the CD-ROM icon that appears on your Mac desktop.

• For Mac OS X 10.8, double-click the CD-ROM that appears on Finder.

Double-click the MAC_Installer folder > Installer OS X icon.

Click Continue.

Items to prepare

• Access point

• Network-connected printer

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

• USB cable

Read the license agreement and click Continue.

Click Agree to agree to the license agreement.

Click Install. All components necessary for machine operations will be

installed.

If you click Customize, you can choose individual components to install.

Enter the password and click OK.

2. Using a Network-Connected Machine

170

Wireless network setup

Select Wireless network connection on the Printer Connection Type and click Continue.

Select Using a USB cable on the Configure wireless

settings to the printer screen and click Next.

If the screen does not appear, go to step 15.

After searching, the window shows the wireless network devices. Select the name (SSID) of the access point you want to use and click Next.

2. Using a Network-Connected Machine

171

Wireless network setup

When you set the wireless configuration manually, click Advanced Setting.

• Enter the wireless Network Name: Enter the SSID of the access point

(SSID is case-sensitive).

• Operation Mode: Select Infrastructure.

• Authentication: Select an authentication type.

Open System: Authentication is not used, and encryption may or may not be used, depending on the need for data security.

Shared Key: Authentication is used. A device that has a proper WEP key can access the network.

WPA Personal or WPA2 Personal: Select this option to authenticate the print server based on the WPA Pre-Shared Key. This uses a shared secret key (generally called Pre Shared Key pass phrase) that is manually configured on the access point and each of its clients.

• Encryption: Select the encryption. (None, WEP64, WEP128, TKIP, AES,

TKIP, AES)

• Network Password: Enter the encryption network password value.

• Confirm Network Password: Confirm the encryption network

password value.

• Wi-Fi Direct option appears on the screen only if your printer supports this feature.

• Can start to build Wi-Fi Direct by using Samsung Easy Printer Manager

(see "Setting up Wi-Fi Direct" on page 180).

• Wi-Fi Direct Name: The default Wi-Fi Direct Name is the model name and the maximum length is 22 characters.

• Password setting is the numeric string, and the size is 8 ~ 64 characters.

14 15

The Wireless Network Setting Complete window appears. Click Next.

When the wireless network settings are completed, disconnect the USB cable between the computer and machine. Click Next.

Access point without a USB cable (recommended)

• WEP Key Index: If you are using WEP Encryption, select the appropriate

WEP Key Index.

The wireless network security window appears when the access point has security enabled.

Enter the Network Password of the access point (or router).

The window showing the wireless network setting appears. Check the settings and click Next.

Items to prepare

• WiFi-enabled Mac running Mac OS 10.7 or higher and an access point (router)

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

2. Using a Network-Connected Machine

172

Wireless network setup

Make sure that the machine is connected to your computer and

powered on.

Insert the supplied software CD into your CD-ROM drive.

Double-click the CD-ROM icon that appears on your Mac desktop.

• For Mac OS X 10.8, double-click the CD-ROM that appears on Finder.

Double-click the MAC_Installer folder > Installer OS X icon.

Click Continue.

Read the license agreement and click Continue.

Click Agree to agree to the license agreement.

Click Install. All components necessary for machine operations will be

installed.

Select Wireless network connection on the Printer Connection Type and click Continue.

If you click Customize, you can choose individual components to install.

Enter the password and click OK.

2. Using a Network-Connected Machine

173

Wireless network setup

Select Using a direct wireless connection on the Configure wireless

settings to the printer screen and click Next.

If the screen does not appear, go to step 13.

If below screen apperas, press the (WPS) button from the control panel withing 2 minutes.

12 13

When the wireless network set up is completed, click Next.

After the installation is finished, click Close.

Ad hoc via USB cable

If you do not have an access point (AP), you may still connect the machine wirelessly to your computer by setting up an ad hoc wireless network by following these simple directions.

2. Using a Network-Connected Machine

174

Wireless network setup

Items to prepare

• Network-connected computer

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

• USB cable

Creating the ad hoc network in Mac

Check whether the USB cable is connected to the machine.

Turn on your computer and the wireless network machine.

Insert the supplied software CD into your CD-ROM drive.

Double -click the CD-ROM icon that appears on your Mac desktop.

Double-click the MAC_Installer folder > Installer OS X icon.

After searching the wireless networks, a list of wireless networks your machine has searched appears. Click Advanced Setting.

• Enter the wireless Network Name: Enter the SSID name (SSID is case-

sensitive).

• Operation Mode: Select ad hoc.

• Channel: Select the channel (Auto Setting or 2412 MHz to 2467 MHz).

• Authentication: Select an authentication type.

Open System: Authentication is not used, and encryption may or may not be used, depending on the need for data security.

Shared Key: Authentication is used. A device that has a proper WEP key can access the network.

• Encryption: Select the encryption (None, WEP64, WEP128).

• Network Password: Enter the encryption network password value.

• Confirm Network Password: Confirm the encryption network

password value.

• WEP Key Index: If you are using WEP Encryption, select the appropriate

WEP Key Index.

6 7 8 9

Click Continue.

Read the license agreement and click Continue.

Click Agree to agree to the license agreement.

When the message that warns that all applications will close on your computer appears, click Continue.

Click Wireless Network Setting button on the User Options Pane.

The wireless network security window appears when the ad hoc network has security setting.

Select Open System or Shared Key for the authentication and click Next.

2. Using a Network-Connected Machine

175

Wireless network setup

The window showing the wireless network settings appears. Check the settings and click Next.

If your computer is set to DHCP and you want to use Static wireless network setting, you must contact the network administrator to get the static IP address.

• For the DHCP method

If the IP address assignment method is DHCP, check if DHCP is shown in the Wireless Network Setting Confirm window. If it shows Static, click

Change TCP/IP to change the assignment method to Receive IP address automatically (DHCP).

• For the Static method

For example, If the computer’s network information is shown as follows:

- IP address: 169.254.133.42

- Subnet Mask: 255.255.0.0 Then, the machine’s network information should be as shown below:

- IP address: 169.254.133.43

- Subnet Mask: 255.255.0.0 (Use the computer’s subnet mask.)

- Gateway: 169.254.133.1

When the window that tells you that the network cable connection is confirmed appears, disconnect the network cable and click Next..

If the network cable is connected, it may have trouble finding the machine when configuring the wireless network.

14 15

The wireless network connects according to the network configuration.

Wireless network set up is completed. After installation is finished, click Quit.

After completing the wireless network connection, you need to install a machine driver to print from an application (see "Installation for Mac" on page 132).

Using a network cable

Machines that do not support the network port will not be able to use this feature (see "Rear view" on page 21).

2. Using a Network-Connected Machine

176

Wireless network setup

Your machine is a network compatible machine. To enable your machine to work with your network, you will need to perform some configuration procedures.

• After completing the wireless network connection, you need to install a machine driver to print from an application (see "Installing driver over the network" on page 142).

• See your network administrator, or the person that set up your wireless network, for information about your network configuration.

Items to prepare

• Access point

• Network-connected computer

• Software CD that was provided with your machine

IP setting using SetIP Program (Windows)

This program is used to manually set the network IP address of your machine using its MAC address to communicate with the machine. The MAC address is the hardware serial number of the network interface and can be found in the Network Configuration Report.

See "Setting IP address" on page 138.

Configuring the machine’s wireless network

Before starting you will need to know the network name (SSID) of your wireless network and the network key if it is encrypted. This information was set when the access point (or wireless router) was installed. If you do not know about your wireless environment, please ask the person who set up your network.

To configure wireless parameters, you can use SyncThru™ Web Service.

• A machine installed with a wireless network interface

• Network cable

Printing a network configuration report

You can identify the network settings of your machine by printing a network configuration report.

See "Printing a network configuration report" on page 138.

Using SyncThru™ Web Service

Before starting wireless parameter configuration, check the cable connection status.

2. Using a Network-Connected Machine

177

Wireless network setup

Check whether or not the network cable is connected to the machine. If

not, connect the machine with a standard network cable.

Start a web browser such as Internet Explorer, Safari, or Firefox and enter

your machine’s new IP address in the browser window.

For example,

Click Login on the upper right of the SyncThru™ Web Service website.

Type in the ID and Password then click Login. We recommend you to

change the default password for security reasons.

• ID: admin

• Password: sec00000

When the SyncThru™ Web Service window opens, click Network

Settings.

Select the one Network Name(SSID) in the list.

• SSID: SSID (Service Set Identifier) is a name that identifies a wireless network, access points, and wireless devices attempting to connect to a specific wireless network must use the same SSID. The SSID is case sensitive.

• Operation Mode: Operation Mode refers to the type of wireless connections (see "Wireless network name and network password" on page 154).

- Ad-hoc: Allows wireless devices to communicate directly with

each other in a peer-to-peer environment.

- Infrastructure: Allows wireless devices to communicate with

each other through an access point.

If your network’s Operation Mode is Infrastructure, select the SSID of the access point. If the Operation Mode is Ad-hoc, select the machine’s SSID.

Click Next.

Click Wireless > Wizard.

Wizard will help you setup the wireless network configuration. However, if you want to set the wireless network directly, select Custom.

If the wireless security setting window appears, enter the registered password (network password) and click Next.

The confirmation window appears, please check your wireless setup. If

the setup is right, click Apply.

2. Using a Network-Connected Machine

178

Wireless network setup

Disconnect the network cable (standard or network). Your machine should then start communicating wirelessly with the network. In case of Ad-hoc mode, you can use a wireless LAN and wired LAN simultaneously.

Insert the supplied software CD into your CD-ROM drive, and follow the instructions in the window to set up the wireless network.

Turning the Wi-Fi network on/off

If your machine has a display, you can also turn on/off the Wi-Fi from the machine’s control panel using the Network menu.

Check whether the network cable is connected to the machine. If not,

connect the machine with a standard network cable.

Start a web browser such as Internet Explorer, Safari, or Firefox and enter

your machine’s new IP address in the browser window.

For example,

Type in the ID and Password, then click Login. We recommend you to

change the default password for security reasons.

• ID: admin

• Password: sec00000

When the SyncThru™ Web Service window opens, click Network

Settings.

Click Wireless > Custom.

You can also turn the Wi-Fi network on/off.

Setting the Wi-Fi Direct for mobile printing

Wi-Fi Direct is an easy-to-setup peer-to-peer connection method between the Wi-Fi Direct certified printer and a mobile device that provides a secure connection and better throughput than ad hoc mode.

With Wi-Fi Direct, you can connect your printer to a Wi-Fi Direct network while concurrently connecting to an access point. You can also use a wired network and a Wi-Fi Direct network simultaneously so multiple users can access and print documents both from Wi-Fi Direct and from a wired network.

Click Login on the upper right of the SyncThru™ Web Service website.

2. Using a Network-Connected Machine

179

Wireless network setup

• You cannot connect your mobile device to the internet through the printer’s Wi-Fi Direct.

• The supported protocol list may differ from your model, Wi-Fi Direct networks do NOT support IPv6, network filtering, IPSec, WINS, and SLP services.

• The maximum number of devices that can be connected via Wi-Fi Direct is 3.

Setting up Wi-Fi Direct

You can enable Wi-Fi Direct feature by one of the following methods.

From the USB cable-connected computer(recommended)

After the driver installation is complete, Samsung Easy Printer Manager can be set and changes in the Wi-Fi Direct can be made.

Samsung Easy Printer Manager is Available for Windows

and Mac OS users only.

 Device Name: Enter the printer’s name for searching for your

printer on a wireless network. By default, the device name is the model name.

 IP Address: Enter the IP address of the printer. This IP address is

used only for the local network and not for the infrastructure wired or wireless network. We recommend using the default local IP address (the default local IP address of the printer for Wi-Fi Direct is

192.168.3.1 )

 Group Owner: Activate this option to assign the printer the Wi-Fi

Direct group’s owner. The Group Owner acts similar to a wireless access point. We recommend activating this option.

 Network Password: If your printer is a Group Owner, a Network

Password is required for other mobile devices to connect to your

printer. You can configure a network password yourself, or can remember the given Network Password that is randomly generated by default.

From the machine (Machines with a display screen)

Accessing menus may differ from model to model (see "Accessing the menu" on page 31 ).

- From the Start menu, select Programs or All Programs > Samsung

Printers > Samsung Easy Printer Manager > Device Settings > Network.

 Wi-Fi Direct On/Off: Select On to enable.

• Select (Menu) > Network > Wi-Fi > Wi-Fi Direct on the control panel.

•Enable Wi-Fi Direct.

2. Using a Network-Connected Machine

180

Wireless network setup

From the network-connected computer

If your printer is using a network cable or a wireless access point, you can enable and configure Wi-Fi Direct from SyncThru™ Web Service.

• Access SyncThru™ Web Service, select Settings > Network Settings > Wireless > Wi-Fi Direct.

• Enable or disable Wi-Fi Direct and set other options.

•For Linux OS users,

- Print an IP network configuration report to check the output (see "Printing a network configuration report" on page 138).

- Access SyncThru Web Service, select Settings > Network Settings > Wireless > Wi-Fi Direct.

- Enable or disable Wi-Fi Direct.

• When you have found the printer you want to connect to from your mobile device, select the printer and the printer's LED will blink. Press the WPS button on the printer and it will be connected to your mobile device.

• If your mobile device does not support Wi-Fi Direct, you need to enter the "Network Key" of a printer instead of pushing the WPS button.

Troubleshooting for wireless network

Problems during setup or driver installation

Printers Not Found

Setting up the mobile device

• After setting up Wi-Fi Direct from the printer, refer to the user manual of the mobile device you are using to set its Wi-Fi Direct.

• After setting up Wi-Fi Direct, you need to download the mobile printing application (For example: Samsung Mobile printer) to print from your smartphone.

• Your machine may not be turned on. Turn on your computer and the machine.

• USB cable is not connected between your computer and machine. Connect the machine to your computer using the USB cable.

• The machine does not support wireless networking. Check the machine's user's guide included on the software CD supplied with your machine and prepare a wireless network machine.

2. Using a Network-Connected Machine

181

Wireless network setup

Connecting Failure - SSID Not Found

• The machine is unable to find the network name (SSID) you have selected or entered. Check the network name (SSID) on your access point and try connecting again.

• Your access point is not turned on. Turn on your access point.

2. Using a Network-Connected Machine

182

Wireless network setup

Connecting Failure - Invalid Security

• Security is not configured correctly. Check the configured security on your access point and machine.

Connecting Failure - General Connection Error

• Your computer is not receiving a signal from your machine. Check the USB cable and your machine’s power.

Connecting Failure - Connected Wired Network

• Your machine is connected with a wired network cable. Remove the wired network cable from your machine.

Connecting Failure - Assigning the IP address

• Cycle the power for the access point (or wireless router) and machine.

PC Connection Error

• The configured network address is unable to connect between your computer and machine.

- For a DHCP network environment

The machine receives the IP address automatically (DHCP) when computer is configured to DHCP.

If the printing job is not working in DHCP mode, the problem may be caused by the automatically changed IP address. Compare the IP address between

the product's IP address and the printer port's IP address.

How to compare:

1 Print the network information report of your printer, and then check the

IP address (see "Printing a network configuration report" on page 138).

2 Check the printer port's IP address from your computer.

a Click the Windows Start menu.

• For Windows 8, from Charms, select Search > Settings.

b For Windows XP/Server 2003, select Printer and Faxes.

• For Windows Server 2008/Vista, select Control Panel > Hardware

and Sound > Printers.

• For Windows 7/8, select Control Panel > Devices and Printers.

• For Windows Server 2008 R2, select Control Panel > Hardware >

Devices and Printers.

c Right-click your machine. d For Windows XP/2003/2008/Vista, press Properties.

For Windows 7/8 and Windows Server 2008 R2, from context menus, select the Printer properties.

If Printer properties item has  mark, you can select other printer drivers connected with selected printer.

e Click Port tab.

f Click Configure Port... button.

g Check if Pr int er Na me o r IP A ddr ess : is the IP address on the network

configuration Sheet.

3 Change the printer port's IP address if it is different from the network

information report's. If you want to use the software installation CD to change the port IP, Connect to a network printer. Then reconnect the IP address.

2. Using a Network-Connected Machine

183

- For a Static network environment

The machine uses the static address when the computer is configured to static address.

For example,

If the computer’s network information is as shown below:

 IP address: 169.254.133.42

 Subnet Mask: 255.255.0.0

Then the machine’s network information should be as below:

 IP address: 169.254.133.43

 Subnet Mask: 255.255.0.0 (Use the computer’s subnet mask.)

 Gateway: 169.254.133.1

Samsung SLM4025DW Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
