Samsung SGH-S7550 User Guide

GT-S7550
safety and usage information
Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone.
Mobile Phone
user manual
Some of the contents in this manual may differ from your phone depending on the
software of the phone or your service provider.
Bluetooth QD ID: B015755
www.samsungmobile.com
Printed in Korea
Code No.:GH68-25815A English (EU). 08/2010. Rev. 1.3
Safety precautions
Drive safely at all times
Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible.
Follow all safety warnings and regulations
Comply with any regulations that restrict the use of a mobile phone in a certain area.
Use only Samsung-approved accessories
Using incompatible accessories may damage your phone or cause injury.
Turn off the phone near medical equipment
Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel.
Turn off the phone or disable the wireless functions when in an aircraft
Your phone can cause interference with aircraft equipment. Follow all airline regulations
and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel.
Protect the phone and batteries from damage
Avoid exposing your phone and batteries to very cold or very hot temperatures (below
0° C/32° F or above 45° C/113° F). Extreme temperatures can cause the deformation
of the phone and reduce the charging capacity and life of your phone and batteries.
Safety warnings
Keep your phone away from small children and pets
Keep your phone and all accessories out of the reach of small children or animals. Small
parts may cause choking or serious injury if swallowed.
Protect your hearing
Listening to a headset at high volumes can damage your hearing. Use only the minimum volume setting necessary to hear your conversation or music.
Install mobile phones and equipment with caution
Ensure that any mobile phones or related equipment installed in your vehicle are
securely mounted. Avoid placing your phone and accessories near or in an air bag
deployment area. Improperly installed wireless equipment can cause serious injury when air bags inate rapidly.
Prevent batteries from contacting metal objects, as this can create a connection
• between the + and – terminals of your batteries and lead to temporary or permanent battery damage.
Never use a damaged charger or battery.
Handle your phone carefully and sensibly
Do not disassemble your phone due to a risk of electric shock.
Do not allow your phone to get wet—liquids can cause serious damage and will
• change the colour of the label that indicates water damage inside the phone. Do not handle your phone with wet hands. Water damage to your phone can void your manufacturer's warranty.
Avoid using or storing your phone in dusty, dirty areas to prevent damage to moving
• parts.
Your phone is a complex electronic device—protect it from impacts and rough handling
• to avoid serious damage.
Do not paint your phone, as paint can clog moving parts and prevent proper operation.
If your phone has a camera ash or light, avoid using it close to the eyes of children or
• animals.
Your phone may be damaged by exposure to magnetic elds. Do not use carrying
• cases or accessories with magnetic closures or allow your phone to come in contact
with magnetic elds for extended periods of time.
Avoid interference with other electronic devices
Your phone emits radio frequency (RF) signals that may interfere with unshielded or improperly shielded electronic equipment, such as pacemakers, hearing aids, medical devices, and other electronic devices in homes or vehicles. Consult the manufacturers of
your electronic devices to solve any interference problems you experience.
Handle and dispose of batteries and chargers with care
Use only Samsung-approved batteries and chargers specically designed for your
phone. Incompatible batteries and chargers can cause serious injuries or damage to
your phone.
Never dispose of batteries or phones in a re. Follow all local regulations when
• disposing of used batteries or phones.
Never place batteries or phones on or in heating devices, such as microwave ovens,
stoves, or radiators. Batteries may explode when overheated.
Never crush or puncture the battery. Avoid exposing the battery to high external
pressure, which can lead to an internal short circuit and overheating.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for
guidance.
Important usage information
Use your phone in the normal position
Avoid contact with your phone's internal antenna.
Internal antenna
Allow only qualied personnel to service your phone
Allowing unqualied personnel to service your phone may result in damage to your
phone and will void your warranty.
Ensure maximum battery and charger life
Avoid charging batteries for more than a week, as overcharging may shorten battery
• life.
Over time, unused batteries will discharge and must be recharged before use.
• Disconnect chargers from power sources when not in use.
• Use batteries only for their intended purpose.
Handle SIM cards and memory cards with care
Do not remove a card while the phone is transferring or accessing information, as this
could result in loss of data and/or damage to the card or phone.
Turn off the phone in potentially explosive environments
Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone
could cause explosions or re in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry ammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories.
Reduce the risk of repetitive motion injuries
Do not use the phone if the screen is cracked or broken
Broken glass or acrylic could cause injury to your hand and face. Bring the phone to a
Samsung service centre to replace the screen. Damage caused by careless handling will void your manufacturer's warranty.
Protect cards from strong shocks, static electricity, and electrical noise from other
• devices.
Frequent writing and erasing will shorten the life span of memory cards.
Do not touch gold-coloured contacts or terminals with your ngers or metal objects. If
dirty, wipe the card with a soft cloth.
Ensure access to emergency services
Emergency calls from your phone may not be possible in some areas or circumstances.
Before travelling in remote or undeveloped areas, plan an alternate method of
contacting emergency services personnel.
Specic Absorption Rate (SAR) certication information
Your phone conforms to European Union (EU) standards that limit human exposure
to radio frequency (RF) energy emitted by radio and telecommunications equipment.
These standards prevent the sale of mobile phones that exceed a maximum exposure
level (known as the Specic Absorption Rate, or SAR) of 2.0 watts per kilogram.
During testing, the maximum SAR recorded for this model was 0.684 watts per kilogram. In normal use, the actual SAR is likely to be much lower, as the phone has been designed to emit only the RF energy necessary to transmit a signal to the nearest base station. By automatically emitting lower levels when possible, your phone reduces your overall exposure to RF energy.
The Declaration of Conformity of this manual demonstrates your phones compliance
with the European Radio & Terminal Telecommunications Equipment (R&TTE) directive. For more information about the SAR and related EU standards, visit the Samsung
mobile phone website.
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government ofce, for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
This EEE is compliant with RoHS.
Install the SIM card and battery
1. Remove the battery cover and insert the SIM card.
Battery cover
Do not use the speaker hole to remove the battery cover. The speaker may be
damaged.
2. Insert the battery and replace the battery cover.
Battery
SIM card
Speaker hole
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in
of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to
human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return
system.
this product should not be disposed of with other household waste at the end
Charge the battery
To charge the battery by travel adapter
1. Plug the supplied travel adapter.
To AC power outlet
Do not remove the battery from the phone before unplugging the travel adapter
rst. Otherwise, the phone may be damaged.
To charge the battery by sunlight
When you charge the battery by sunlight,
ensure the battery is inserted and expose the solar panel to direct sunlight and prevent it from shade.
To ensure efcient charging, place the
phone so that the solar panel faces the
sun directly, as shown.
2. When charging is nished,
unplug the travel adapter.
Phone layout
2
Dial key
Make or answer a call; In Idle mode, retrieve recently dialled, missed, or
1
4
5
2
6
3
1
Volume key
In ldle mode, adjust the key tone volume; Make a fake call (press and hold)
Make a fake call
Cautions for sunlight charging
Do not connect to the phone to a travel adapter or USB cable while charging by
• sunlight.
Do not leave the phone in an enclosed car for a long time, as the phone
may overheat. Charging the battery when it is overheated may cause re, deformation, breakdown, or malfunction of the phone.
Do not expose the solar panel to sunlight for a long time to avoid very hot
temperatures. Especially, do not leave your phone in a heated vehicle for a long
period of time. This may damage the phone or battery.
Do not charge the battery using a halogen or infrared lamp. This may cause re
• or explosion.
Do not focus sunlight on the solar panel with a mirror, lens, or eye glasses. This
may overheat the phone and consequently cause re, deformation, breakdown,
or malfunction of the phone.
Do not use the phone if the solar panel is cracked or broken. Broken glass
could cause injury to your hand and face. Bring the phone to a Samsung
service centre to replace the solar panel.
received numbers
3
Back key
Open the application switch window (press
and hold); In Menu mode, return to the
previous level
4
Hold key
Lock the touch screen and the keys: Unlock the touch screen and the keys
(press and hold)
5
Camera key
In Idle mode, turn on the camera (press and hold); In Camera mode, take a photo
or record a video
6
Power/Menu exit key
Turn the phone on and off (press and
hold); End a call; In Menu mode, cancel
input and return to Idle mode
Your phone displays the following status indicators on the top of the screen:
Icon Description
Signal strength
GPRS network connected
EDGE network connected
UMTS network connected
HSDPA network connected
Voice call in progress
Video call in progress
Call diverting activated
SOS message feature activated
Alarm activated
Browsing the web
Connecting to secured web page
Bluetooth activated
Wi-Fi activated
Synchronised with PC
Notes for sunlight charging
When the phone is off, 1 hour of sunlight at about 80,000 lux (approximately the
• amount of sunlight at noon on a sunny day) charging will provide approximately
5-10 minutes of talk time. Talk time may vary depending environmental factors, such as weather, region, altitude of the sun, or signal strength.
Sunlight is a secondary power source. To ensure a fully-charged battery, use
• the travel adapter.
Sunlight charging is not possible in the following situations:
Near a window that blocks direct sunlight
-
In high or low temperatures
-
If any part of solar panel is covered
-
If you attach a protection lm or ornaments to the solar panel or scribble or
-
write on it
While wearing the phone on your neck, the battery may not charge efciently
• due to indirect sunlight.
The battery cannot be charged by articial light.
Always keep the solar charging point and the solar panel clean.
Icon Description
New text message (SMS)
New multimedia message (MMS)
New voice mail message
New email message
New conguration message
New push message
Message full
FM radio on
Memory card inserted
Normal prole activated
Silent prole activated
Eco prole activated
Charging by sunlight
Battery power level
Current time
Insert a memory card (optional)
Your phone accepts microSD™ or microSDHC™ memory cards up to 16 GB (depending on memory card manufacturer and type).
Formatting the memory card on a PC may cause incompatibility with your phone. Format the memory card only on the phone.
1. Remove the battery cover and battery.
2. Unlock the memory card cover.
Memory card cover
3. Lift the memory card cover and insert
a memory card with the label side facing down.
Memory card
4. Close and lock the memory card cover.
5. Replace the battery and battery cover.
Instructional icons
Note: notes, usage tips, or additional information
Followed by: the order of options or menus you must select to perform a step; for example: In Menu mode, select MessagesCreate message
(represents Messages, followed by Create message)
Turn your phone on or off
To turn your phone on,
1. Press and hold the Power/Menu exit key.
2. Enter your PIN and select Conrm (if necessary).
To turn your phone off, repeat step 1 above.
Use the touch screen
For the optimal use of the touch screen, remove the screen protection lm
before using your phone.
Touch an icon or option to select a menu or launch an application.
Drag your nger up or down to scroll through vertical lists.
Drag your nger left or right to scroll through horizontal lists.
Access menus
To access your phone's menus,
1. In Idle mode, select Menu to access Menu mode.
2. Scroll left or right to a Menu mode screen.
3. Select a menu or option.
4. Press the Back key to move up one level; Press the Power/Menu exit key
to return to Idle mode.
When you access a menu requiring the PIN2, you must enter the PIN2
supplied with the SIM card. For details, contact your service provider.
Samsung is not responsible for any loss of passwords or private information
• or other damages caused by illegal software.
Use widgets
Open the widget toolbar
In Idle mode, select the arrow at the bottom left of the screen to open the
widget toolbar. You can rearrange widgets on the widget toolbar or move them to the idle screen.
Move the widgets to the idle screen
1. Open the widget toolbar.
2. Drag a widget from the widget toolbar to the idle screen.
Change the widgets
1. In Menu mode, select Settings → Display and light → Widget.
2. Select the widgets you want to include to the toolbar and select Save.
Make a call
1. In Idle mode, select Keypad.
2. Enter an area code and a phone number.
2. Press the Dial key to dial the number.
For a video call, select → Video call.
3. To end the call, press the Power/Menu exit key.
Answer a call
1. When a call comes in, press the Dial key.
2. For a video call, select Show me to allow the caller to see you via the
front camera lens.
3. To end the call, press the Power/Menu exit key.
Adjust the volume
To adjust the volume of the ringtone
1. In Menu mode, select Settings → Phone proles.
2. Select next to the prole you are using.
If you are using the silent or ofine prole, you are not allowed to adjust the
volume of the ringtone.
3. Drag left or right the slide under Call alert volume to adjust the volume
level.
4. Select Save.
To adjust the volume of voice during a call
While a call is in progress, press the Volume key and adjust the volume.
In noisy environments, you may have difculty hearing the calls while using the speakerphone feature. For better audio performance, use the normal phone
mode.
Change your ringtone
1. In Menu mode, select Settings → Phone proles.
2. Select next to the prole you are using.
If you are using the silent or ofine prole, you are not allowed to change the
ringtone.
3. When you are nished, access Eco walk again and select End walk to stop the pedometre.
4. To check the results, select Saved trees or History. In the history view, select Kcal or Trees to see how many calories you have burned or how many trees you have saved.
Use the Eco calendar
In the calendar, you will see preset Eco days, such as World Ozone Day or
Green Consumer Day. You can share these events with other people via messages or Bluetooth.
Use Eco unlock
1. In Menu mode, select Settings Smart unlock Eco unlock Save.
2. When the phone is locked, press the Hold key and drag the can to the trash bin to unlock.
Add a new contact
1. In Idle mode, select Keypad and enter a phone number.
2. Select → Add to phonebook → New.
3. Select Phone or SIM.
4. Enter contact information.
5. Select Save to add the contact to memory.
3. Select Voice call ringtone or Video call ringtone.
4. Select a ringtone category → a ringtone.
5. Select Save twice.
To switch to another prole, select it from the list.
Call a recently dialled number
1. In Idle mode, press the Dial key.
2. Select the All drop-down menu and select a call type.
3. Select next to a number or name.
Enter text
To change the text input mode
Select Abc to select an input mode.
• Select T9 to switch to T9 mode.
• Select to switch to Symbol mode.
• Select EN to change the input language.
Send and view messages
To send a text or multimedia message
1. In Menu mode, select Messages → Create message → Message.
2. Select Tap to add recipient → Enter manually.
3. Enter a recipient number and select Done.
4. Select Tap to add text.
5. Enter your message text and select Done. ► Enter text
For sending as a text message, skip to step 7.
For attaching multimedia, continue with step 6.
6. Select Add media and add an item.
7. Select Send to send the message.
To view text or multimedia messages
1. In Menu mode, select Messages → Inbox.
2. Select a text or multimedia message.
T9 mode
1. Select the appropriate virtual key to enter an entire word.
2. When the word displays correctly, select to insert a space. If the correct word does not display, select an alternate word from the list that
appears.
ABC mode
Select an appropriate virtual key until the character you want appears on the
display.
Number mode
Select an appropriate virtual key to enter a number.
Symbol mode
Select an appropriate virtual key to enter a symbol.
To delete characters one by one, select . To delete all of the characters,
• press and hold .
To insert a space between characters, select .
To enter punctuation marks in English input modes, select 1.
Make fake calls
You can simulate an incoming call when you want to get out of meetings or unwanted conversations.
To make a fake call,
In Idle mode, press and hold the Volume key down.
With the keys locked, press the Volume key down four times.
Activate and send an SOS message
In an emergency, you can send SOS messages to your family or friends for
help.
This feature may not be available depending on your region or service provider.
To activate the SOS message
1. In Menu mode, select Messages → SOS messagesSending options.
2. Select On.
3. Select the recipient eld to open the recipient list.
4. Select to open your contact list.
5. Select a contact and select Add.
6. Select a number (if necessary).
Use Eco applications
Your phone includes features to help you protect the environment.
Switch to Eco display mode
In Eco display mode, your phone will reduce power consumption by using backlight options that require less power.
In Menu mode, select Settings → Display and light → Eco mode → On →
Save.
Switch to the Eco prole
In the Eco prole, your phone will reduce power consumption by using sound options that require less power.
In Menu mode, select Settings → Phone proles → Eco.
Use Eco walk
With Eco walk, you can check how many trees you have saved and how much carbon dioxide emissions you have prevented by walking instead of
driving. Begin by customising the pedomentre settings:
1. In Menu mode, select Eco walk.
2. Set options and select Save → Start.
The pedometre will count your steps.
To begin the pedometre, you can open the widget toolbar in Idle mode, drag to the idle screen, and then select Start.
7. Select OK to save the recipients.
8. Select the Repeat drop-down menu and select the number of times to
repeat the SOS message.
9. Select SaveYes.
To send an SOS message
1. With the keys locked, press the Volume key four times to send an SOS
message to preset numbers.
The phone switches to SOS mode and sends the preset SOS message.
2. To exit SOS mode, press the Power/Menu exit key.
Activate the mobile tracker
When someone inserts a new SIM card in your phone, the mobile tracker
feature will automatically send the contact number to two recipients to help
you locate and recover your phone. To activate the mobile tracker,
1. In Menu mode, select Settings → Security → Mobile tracker.
2. Enter your password and select Conrm.
The rst time you access a menu requiring a password, you will be prompted to create and conrm a password.
3. Select On.
4. Select the recipient eld to open the recipient list.
5. Select a recipient input eld.
6. Enter a number and select Done.
7. Select OK to save the recipients.
8. Select the sender input eld
9. Enter the sender's name and select Done.
10. Select SaveAccept.
Use the camera
To capture photos
1. In Idle mode, press and hold the Camera key to turn on the camera.
2. Rotate the phone anti-clockwise to landscape view.
3. Aim the lens at the subject and make any adjustments.
4. Press the Camera key to take a photo.
The photo is saved automatically.
To view photos
In Menu mode, select My les → Images → My photos → a photo le.
To capture videos
1. In Idle mode, press and hold the Camera key to turn on the camera.
2. Rotate the phone anti-clockwise to landscape view.
3. Select to switch to Recording mode.
4. Aim the lens at the subject and make any adjustments.
5. Press the Camera key to start recording.
6. Select or press the Camera key to stop recording.
The video is saved automatically.
To view videos
In Menu mode, select My les → Videos → My video clips → a video le.
Listen to music
1. In Menu mode, select Music player.
2. Select a music category → a music le.
3. Control playback using the following icons:
Icon Function
Pause or resume playback
/
Skip backward; Scan backward in a le (touch and hold)
Skip forward; Scan forward in a le (touch and hold)
Change the equaliser type
Change the repeat mode
Activate Shufe mode
Listen to the FM radio
1. Plug the supplied headset into the phone.
2. In Menu mode, select FM radio.
3. Select Yes to start automatic tuning.
The radio scans and saves available stations automatically.
The rst time you turn on the FM radio, you will be prompted to start automatic
tuning.
4. Control the FM radio using the following icons.
Icon Function
Turn the FM radio on or off
/
Tune a radio station; Select a saved radio station (touch and hold)
/
Set the FM radio to retune frequencies for stations automatically when
/
the current radio signal is weak
Switch the sound output
/
Declaration of Conformity (R&TTE)
We,
Samsung Electronics
declare under our sole responsibility that the product
to which this declaration relates, is in conformity with the following standards and/or other normative documents.
SAFETY EN 60950-1 : 2001 +A11 : 2004
SAR EN 50360 : 2001 EN 62209-1 : 2006
EMC EN 301 489-01 V1.6.1 (09-2005) EN 301 489-07 V1.3.1 (11-2005) EN 301 489-17 V1.2.1 (08-2002) EN 301 489-24 V1.4.1 (09-2007)
RADIO EN 301 511 V9.0.2 (03-2003) EN 300 328 V1.7.1 (10-2006) EN 301 908-1 V3.2.1 (05-2007) EN 301 908-2 V3.2.1 (05-2007)
We hereby declare that [all essential radio test suites have been carried out and that] the above named product is in conformity to all the
essential requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and detailed in Annex[IV] of Directive 1999/5/EC has been followed with the involvement of the following Notied Body(ies):
BABT, Forsyth House, Churcheld Road, Walton-on-Thames, Surrey, KT12 2TD, UK* Identication mark: 0168
The technical documentation kept at :
Samsung Electronics QA Lab.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way, Yateley, Hampshire, GU46 6GG, UK*
2009.09.28 Yong-Sang Park / S. Manager
(place and date of issue) (name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone number of Samsung Service Centre, see the warranty card or
contact the retailer where you purchased your phone.
GSM Mobile Phone : GT-S7550
Loading...
